8517B S-Parameter Test Set,
0.045 to 50 GHz, 2.4 mm
Data Sheet
Frequency Range 0.045 to 50 GHz
Test Ports (port 1 or 2
Nominal Operating Power Level:
+2 to -29 dBm
Opt 007: +5 to -16 dBm
Connector Type: 2.4 mm, male
Impedance, DC Bias: 50 ohm nominal, 500 mA, 40 Vdc maximum
Attenuation Range (incident signal):
0 to 60 dB, in 10 dB steps
RF Input Connector (rear panel)
Maximum Input Power: +16 dBm
Connector Type: 2.4 mm, female
Dynamic Ra nge (for transmission measurements)
Frequency Range GHz
.045 0.84 20 40
to 0.84 to 20 to 40 to 50
Maximum Power (dB m)
Measured at Port 2: +17 +8 +3 -4
Opt 007: +17 +12 +5 -5
Reference Power (dBm)
at Port 1 (nominal): +2 -7 -17 -29
Opt 007: +5 +2 -5 -16
Minimum Power
Measured at Port 2: -75 -97 -91 -90
Opt 007: -70 -92 -89 -91
Receiver
Dynamic Ra nge (dB): 92 105 94 86
Opt 007: 87 104 94 86
System
Dynamic Range (dB: 77 90 74 61
Opt 007: 75 94 84 75
Measurement Port Characteristics
Frequency Range GHz
.045 0.84 20 40
to 0.84 to 20 to 40 to 50
Residual (dB)
Directivity: 42 42 38 36
Source Match: 41 38 33 31
Load Match: 42 42 38 36
Reflection Tracking: ±0.001 ±0.008 ±0.02 ±0.027
Transmission Tracking: ±0.014 ±0.045 ±0.110 ±0.137
Crosstalk: 99 110 91 80
Raw (typical) (dB) (Before calibration/error correction)
Directivity: 20 20 20 20
Source Match: 20 12 10 10
Load Match: 20 12 10 10
