Find us at www.keysight.com Page 1
N9000B
CXA X-Series Signal Analyzer,
Multi-touch
This configuration guide will help you determine which performance options,
measurement applications, accessories, and services to include with your new
multi-touch CXA or to add as upgrades to an existing CXA.
Configure Your Keysight CXA Signal Analyzer
This step-by-step process will help you configure your new CXA X-Series signal
analyzer. Tailor the performance to meet your requirements.
Included in base product
Standard options and accessories come with the CXA base model at no additional
charge and do not need to be ordered. They include:
•
Spectrum analyzer measurement application
•
Dual-core, high-performance processor, 8 GB RAM, removable solid-state drive
•
Frequency reference
•
10 MHz analysis bandwidth
•
Enhanced phase noise
•
Microsoft Windows 10 operating system
•
Benchtop configuration
•
Multi-language user interface
•
User’s guide (included in the CXA’s embedded help system)
•
Power cord
For a summary of
specifications, refer to the
N9000B CXA data sheet
(literature number 5992-
1274EN).
A full set of specifications
are available in the N9000B
CXA Signal Analyzer
Specification Guide at
www.keysight.com/find/cxa_
specifications.
Find us at www.keysight.com Page 2
Description
Option number
Additional information
Step 1. Select maximum frequency range (required option; frequency range not upgradeable)
Frequency range, 9 kHz to 3.0 GHz
N9000B-503
Frequency range, 9 kHz to 7.5 GHz
N9000B-507
Frequency range, 9 kHz to 13.6 GHz
N9000B-513
Frequency range, 9 kHz to 26.5 GHz
N9000B-526
Step 2. Add a preamplifier
Preamplifiers improve the noise floor for low-level signal detection; +20 dB: 100
kHz to 26.5 GHz
Preamplifier, 100 kHz to 3.0 GHz
N9000B-P03
Compatible with N9000B-503, N9000B-507, N9000B-513, and N9000B-526
Preamplifier, 100 kHz to 7.5 GHz
N9000B-P07
Compatible with N9000B-507, N9000B-513, and N9000B-526
Preamplifier, 100 kHz to 13.6 GHz
N9000B-P13
Compatible with N9000B-513 and N9000B-526
Preamplifier, 100 kHz to 26.5 GHz
N9000B-P26
Compatible with N9000B-526
Step 3. Choose frequency reference
Frequency reference
Standard
Aging rate: ± 1 x 10–6/year
Precision frequency reference
N9000B-PFR
Reduces frequency drift for more accurate measurements; aging rate: ± 1 x 10–7/year
Step 4. Choose an attenuator
Mechanical attenuator
Standard
10 dB steps, 0 to 50 dB, for N9000B-503 and N9000B-507
10 dB steps, 0 to 70 dB, for N9000B-513 and N9000B-526
Fine resolution step attenuator
N9000B-FSA
Allows 2 dB steps for the full range of the attenuator
Step 5. Choose analysis bandwidth
10 MHz analysis bandwidth
Standard
Useful for most I oT d evic es and general-purpose radio devices measurement
applications
25 MHz analysis bandwidth
N9000B-B25
Extends the analysis (demod) bandwidth from 10 to 25 MHz; useful for most cellular
communications, wireless connectivity, and audio/video broadcasting measurement
applications
Step 6. Add a tracking generator
Tracking generator, 9 kHz to 3.0 GHz
N9000B-T03
Compatible with N9000B-503, N9000B-507 only
Tracking generator, 9 kHz to 6.0 GHz
N9000B-T06
Compatible with N9000B-507 only
Step 7. Choose performance
Enhanced phase noise
Standard
Licensed as N9000B-EP4
Find us at www.keysight.com Page 3
Description
Model number
Additional information
Step 8. Add instrument features
Enhanced display package
N90EMEDPB
Includes spectrogram, trace zoom, and zone span
Basic precompliance EMI
N90EMEMCB
Performs EMI precompliance measurements with CISPR 16-1-1 detectors and bandwidths.
Other associated features available from the standard spectrum analyzer mode, such as
CISPR band presets, and measure at marker, further enhance the EMI precompliance test
flow. See also
the differences between N90EMEMCB and N6141EM0E EMI
measurement application
PowerSuite
N90EMPSMB
One-button power measurements, including CHP, OBW, APCR, SEM, TOI, CCDF, etc. (requires
F/W A.31 or above)
External source control
N90EMESCB
External source control for selected Keysight EXG, MXG and PSG signal generators;
Includes 3 BNC cables and 1 cross-over LAN cable. This feature is compatible with N9000B
option 503 or 507 only
Step 9. Choose operating system
Windows 10 operating system
Standard
Licensed as N9000B-W10
Step 10. Add security features
Additional, removable
solid-state drive
N9000B-SS1
Provides a fully-imaged, removable solid-state drive in addition to the one installed in the
instrument, with Windows 10 operating system
Exclude launch program
N9000B-SF1
Prevents the launching of Windows programs from the instrument application
Prohibit saving results
N9000B-SF2
Prevents the saving/recall of measurement results or user configurations to/from instrument’s
data storage
Step 11. Add rear panel output utilities
Second IF output
N9000B-CR3
Wideband IF out; output on Aux IF connector at rear panel; compatible with N9000B-503 and
N9000B-507 only
Step 12. Choose measurement application or software and license type
Keysight understands your needs for the flexibility of using our industry-leading signal analysis applications, therefore, we provide you with the
following three ways of ordering our applications:
• Ordering at individual application, with full set of choices of license terms and types
• Ordering at custom bundles, with node-locked, subscription license only
• Ordering at industry-specific bundles, with node-locked, subscription license only
Note: Keysight offers flexible license types and terms for the measurement applications, refer to page 11 of X-Series Measurement
Applications - Brochure (5989-8019EN).
Ordering at individual application
Description
Model number
Additional information
General purpose
Spectrum analyzer
Standard
Traditional spectrum analysis
Phase noise
W9068EM0E
Adds one-button measurements for analyzing phase noise in frequency domain (log plot) and
time domain (spot frequency), supports external mixing
Find us at www.keysight.com Page 4
Description
Model number
Additional information
Noise figure
W9069EM0E
(requires
preamplifier)
Adds one-button measurements for noise figure, gain, and related metrics; requires
preamplifier to meet specifications; works with Keysight U1831C USB noise source, N400xA
Series smart noise sources and 346 Series noise sources; supports U7227 USB external
preamplifiers Includes the advanced NF measurement features including external LO control
over GPIB/LAN/USB, multi-stage converter tests with system LO, and manual mode to
simulate the legacy NF meter
Analog demodulation
W9063EM0E
One-button measurement for AM/FM/PM demodulation with metrics, tune and listen, and
AF spectrum; supports audio output (output voltage proportional to frequency deviation).
FM Stereo and RDS are included
Vector modulation analysis –
Digital demodulation
W9054EM0E
Performs one-button flexible modulation analysis measurements with FSK, PSK, QAM, MSK,
ASK, APSK, VSB etc. and popular format preset
Vector modulation analysis –
Custom OFDM
W9054EM1E
Performs one-button custom OFDM modulation analysis measurement with user-defined
settings or recalling 89600 VSA or Signal Studio output files
EMI
W6141EM0E
Performs pre-compliance conducted and radiated emission measurements
Remote language compatibility
W9061EM0E
Adds capability to emulate HP/Agilent 8566/68 and 856xE/EC spectrum analyzers
SCPI command language
compatibility
W9062EM0E
Adds capability to emulate the R&S FSP/FSU/FSE/FSL/FSV spectrum analyzers or ESU
EMI
receiver
MATLAB software
N6171A
Cellular communications
GSM/EDGE/Evo
W9071EM0E
Standard-based, one-button GSM/EDGE/EDGE Evolution measurements
W-CDMA/HSPA+
W9073EM0E
Standard-based, one-button W-CDMA, HSPA and HSPA+ measurements
LTE/LTE-Advanced FDD
W9080EM0E
Standard-based, one-button LTE/LTE-Advanced FDD measurements
NB-IoT & eMTC FDD
W9080EM3E
Standard-based, one-button NB-IoT/eMTC measurements
LTE V2X
W9080EM4E
Standard-based, one-button LTE-V2X transmitter measurements
LTE/LTE-Advanced TDD
W9082EM0E
Standard-based, one-button LTE/LTE-Advanced TDD measurements
Wireless connectivity
WLAN 802.11a/b/g/j/p/n/af/ah
W9077EM0E
Standard-based, one-button 802.11a/b/g/j/p/n/af/ah measurement
Bluetooth
®
W9081EM0E
Standard-based, one-button Bluetooth (BR/EDR, Low Energy 4.0/4.2 and Bluetooth 5)
measurements
Short range comm and IoT
W9084EM0E
Standard-based, one-button LoRa CSS measurement, 802.15.4 for ZigBee measurement
and
G.9959 for Z-Wave measurement
Ordering at custom bundles, with node-locked, subscription license only
It allows you to select any 3 or 5 signal analysis applications, in node-locked, subscription license only. This ordering method fits you well if you
prefer to use these desired measurement applications for a period time at a value price and also get the greatest flexibility of making purchase
choices when you spend your budget next time
Custom bundle
Pick any 3 applications
N9089BAXE-030
Pick any 3 applications, with node-locked license type, at 12-month subscription or 36month subscription
Pick any 5 applications
N9089BAXE-050
Pick any 5 applications, with node-locked license type, at 12-month subscription or 36month subscription
Find us at www.keysight.com Page 5
Description
Model number
Additional information
Ordering at industry-specific bundles, with node-locked, subscription license only
It allows you to select the following predefined industry-specific bundles, in node-locked subscription license only. This ordering method fits you
well if you frequently use these applications
Industry-specific bundle
5G and 4G
Cellular communication
N9089B01E
Node-locked license type, at 12-month or 36-month subscription only. Applications in
this bundle include:
• N9085EM0E 5G NR
• N9080EM0E LTE/LTE-A FDD
• N9089EM2E LTE/LTE-A TDD
• N9089EM3E NB-IoT/eMTC
Wireless connectivity
N9089B02E
Node-locked license type, at 12-month or 36-month subscription only. Applications in
this bundle include:
• N9077EM0E WLAN 802.11a/b/g/j/p/n
• N9077EM1E WLAN 802.11ac/ax
• N9077EM2E WLAN 802.11be
• N9081EM0E Bluetooth
• N9084EM0E Short range communication and IoT
General purpose
N9089B03E
Node-locked license type, at 12-month or 36-month subscription only. Applications in
this bundle include:
• N9054EM0E VMA digital demodulation
• N9054EM1E Custom OFDM
• N9063EM0E Analog demodulation
• N9068EM0E Phase noise
• N9069EM0E Noise figure
2G and 3G
Cellular communication
N9089B04E
Node-locked license type, at 12-month or 36-month subscription only. Applications in
this bundle include:
• N9071EM0E: GSM/EDGE
• N9072EM0E: cdma2000
• N9073EM0E W-CDMA/HSPA
• N9076EM0E 1xEV-DO
• N9079EM0E TD-SCDMA
Step 13. Choose 89600 VSA software licenses
Basic vector signal analysis and
hardware connectivity
89601200C
(required core
option)
Provides the tools and user interface that make up the 89600 VSA software including time
and frequency domain measurement, hardware connectivity, recordings, and playback
Channel quality modulation analysis
General purpose
Digital demodulation analysis
89601AYAC
•
Analysis of >40 modulation formats, including custom APSK and presets for communication
formats like GSM/EDGE, ZigBee FSK, Bluetooth® BR, APCO25 and SOQPSK
•
Proprietary and pre-standard, customized IQ constellation signals
•
TEDS modulation analysis
•
Channel response measurements such as phase/magnitude response and multi-tone group
delay
Custom OFDM modulation analysis
89601BHFC
•
Proprietary and pre-standard OFDM formats
Find us at www.keysight.com Page 6
Description
Model number
Additional information
Cellular communication
5G NR modulation analysis
89601BHNC
•
5G NR modulation analysis
•
Pre-5G modulation analysis
LTE/LTE-A FDD modulation analysis
89601BHGC
•
LTE FDD modulation analysis
•
LTE-Advanced FDD modulation analysis
LTE/LTE-A TDD modulation analysis
89601BHHC
•
LTE TDD modulation analysis
•
LTE-Advanced TDD modulation analysis
3G modulation analysis bundle
89601B7NC
•
W-CDMA/HSPA+ modulation analysis
•
TD-SCDMA/HSPA modulation analysis
•
cdma2000 modulation analysis
•
1xEV-DO and 1xEV-DV modulation analysis
Wireless connectivity
Wireless connectivity modulation
analysis
89601B7RC
•
WLAN 802.11a/b/g/j/p modulation analysis
•
WiMax modulation analysis
High throughput WLAN modulation
analysis
89601BHXC
•
WLAN 802.11n/ac modulation analysis
•
WLAN 802.11ax modulation analysis
IoT modulation analysis
89601BHTC
•
NB-IoT modulation analysis
•
RFID modulation analysis
Radar analysis
Pulse analysis
89601BHQC
•
Pulsed modulated radar signal analysis
FMCW radar analysis
89601BHPC
•
For multi-chirp linear FM modulated signals or automotive radar
Other standard formats
DOCSIS modulation analysis
89601BHMC
•
DOCSIS3.1 downstream and upstream modulation analysis
Multi-vendor hardware connectivity
89601301C
•
Connect multi-vendor hardware for modulation analysis
Step 14. Choose physical instrument configuration
Bench top configuration
Standard
Provides two side carrying straps, four rear feet, and four bottom feet with a tilt stand
Portable configuration
N9000B-PRC
Provides a convenient, pivoting carrying handle as well as rubber protective corners
and end guards; this configuration is intended for applications requiring more rugged
packaging, such as in the field
Step 15. Choose accessories
User guide
Standard
US – English localization
All user documentation is included in the CXA’s embedded help system
User documentation can be downloaded from: www.keysight.com/find/cxa_manuals
Power cord
Standard
Dependent upon region of use
Rack mount
1CM113A
Adds rack mount flanges to the CXA
Front handles
1CN103A
Adds front handles to the CXA
Rack mount with handles
1CP105A
Adds rack mount flanges and handles to the CXA
Find us at www.keysight.com Page 7
Description
Model number
Additional information
Rack slide
1CR013A
Adds a non-tilting rack slide to the CXA
USB DVD-ROM/CD-R/RW drive
1DVR001A
Enhances the usability of the Windows operating system
Mouse, USB interface
1MSE001A
Minimum loss pad, 50 to 75 Ω
(type-N to BNC)
MLP001A
50 Ω type-N male to 75 Ω BNC female adapter
Frequency range: 9 MHz to 2 GHz
Input/output return loss: 20 and 11 dB
Insertion loss: 5.7 dB
USB external preamplifier, 10 MHz
to 4 GHz
U7227A
Brings reliable gain and low noise figure to measurement systems, and improves the
overall system performance
USB external preamplifier,
0.1 to 26.5 GHz
U7227C
Brings reliable gain and low noise figure to measurement systems, and improves the
overall system performance
Near field probes
N9311X-100
Includes 4 pieces of H-field probes, for detecting EMI emissions
Step 16. Add calibration, technical training, support, and upgrade services
Commercial calibration certificate
with test data
N9000B-UK6
Calibration certificate only available at time of instrument purchase; only
provides measurement results
Keysight Cal + uncertainties +
guard banding (accredited cal)
N9000B-AMG
Provides ISO 17025A accredited calibration from factory
ANSI Z540-1-1994 calibration
N9000B-A6J
Provides ANSI Z540 compliant calibration from factory
Calibration Assurance Plan, Returnto-Keysight, 3 years
R-50C-011-3
Keysight tests your instrument against its original specifications and automatically
makes adjustments if outside of specified parameters; pre- and post-adjustment
measurement data reports also provided
Calibration Assurance Plan, Returnto-Keysight, 5 years
R-50C-011-5
Calibration Assurance Plan, Returnto-Keysight, 7 years
R-50C-011-7
Calibration Assurance Plan, Returnto-Keysight, 10 years
R-50C-011-10
Service: remote scheduled
productivity assistance
PS-S10-100
Hourly phone-in technical support service designed to help you understand and
operate your equipment through convenient phone and Web access
Service: 1-day start-up assistance
PS-S20-01
Training on how to operate your instrument effectively (recommended)
Service: Productivity assistance
PS-S20-100
Daily instrument and application consulting using your equipment and device under test
Service: Custom engineering
service
PS-X10-100
Application-specific technical assistance
Other calibration options may be available; for more information on calibration go to: www.keysight.com/find/calibration
Find us at www.keysight.com Page 8
Instrument Upgrades
Fast license-key upgrades for performance options that do not require additional hardware:
1. Place an order for the upgrade with Keysight and request to receive the option upgrade
entitlement certificate and a one-time software upgrade license through email
2. Redeem the certificate through the Web by following the instructions on the
certificate
3. Install the license file and latest software in the CXA
4. Begin using the new capability
1, 2
Installation and testing information is available at: www.keysight.com/find/cxa_upgrades
Description
Upgrade
number
Requirements
CXA
must already
include the following
Additional information
Increase analysis bandwidth from
10 to 25 MHz
N9000BU-B25
None
Add preamplifier, 3 GHz
N9000BU-P03
None
Add preamplifier, 7.5 GHz
N9000BU-P07
507, 513 or 526
Not compatible with Option 503
Add preamplifier, 13.6 GHz
N9000BU-P13
513 or 526
Not compatible with Option 503 or 507
Add preamplifier, 26.5 GHz
N9000BU-P26
526
Not compatible with Option 503, 507, or 513
Add fine resolution step attenuator
N9000BU-FSA
None
Add precision frequency
reference
N9000BU-PFR
None
Add tracking generator, 3 GHz
N9000BU-T03
None
Requires hardware and license key; not compatible with Options
513 or
526
Add tracking generator, 6 GHz
N9000BU-T06
None
Requires hardware and license key; not compatible with Options
503, 513, or 526
N9311X-100 (Near field probes)
CXA bench top configuration
You can upgrade!
Options can be added
after your initial purchase.
Most X-Series options are
license-key upgradeable.
Find us at www.keysight.com Page 9
Description
Upgrade
number
Requirements
CXA
must already
include the following
Additional information
Add basic EMI precompliance
features
N9000BU-EMC
None
Also orderable at N90EMEMCB (Requires F/W revision A.21.04
onward)
Add external source control
N9000BU-ESC
None
Adds feature to control selected Keysight EXG, MXG, and PSG
signal
generators; includes 3 BNC cables and 1 cross-over LAN
cable; not
compatible with Options 513 or 526. Also orderable at
N90EMESCB (requires F/W revision A.21.04 onward)
Add second IF output
N9000BU-CR3
None
Requires hardware and license key; not compatible with Options
513 or 526
Add enhanced display package
N9000B-EDP
None
Adds spectrogram, trace zoom, and zone span. Also orderable
at N90EMEDPB (requires F/W revision A.21.04 onward)
Add PowerSuite
N90EMPSMB
None
Adds power measurements such as channel power, OBW, ACPR,
TOI, CCDF, etc. (requires F/W revision A.31 or above)
Add security features, exclude
launch program
N9000BU-SF1
None
Prevents the launching of Windows programs from the
instrument
application
Add security features, prohibit
saving results
N9000BU-SF2
None
Prevents the saving/recall of measurement results or user
configurations to/from instrument’s data storage
Add removable solid-s ta te drive
N9000BU-SS1
None
Provides a fully-imaged, removable solid-state drive, with Windows
10 operating system
Upgrade operating system to
Windows 10
N9000BU-SS1
PC7, W7X
Provides a removable solid-state drive with Windows 10
operating system
Chinese version of Getting Started Guide
N9000BU-AB2
None
Spanish version of Getting Started Guide
N9000BU-ABE
None
French version of Getting Started Guide
N9000BU-ABF
None
Japanese version of Getting Started
Guide
N9000BU-ABJ
None
Russian version of Getting Started Guide
N9000BU-AKT
None
1. At the time of manufacture, the hardware related to many of these options was fully adjusted and the option performance was verified to be within its warranted
specifications. Within one year of the initial calibration date of the analyzer, this option is fully calibrated with no furt her adjustment or verification testing.
2. If this analyzer has been adjusted as part of a repair or calibration during its first year, or if the analyzer is more than one year old , additional adjustment
and performance verification tests are required to ensure that some newly installed options are functioning properly. However, the completion of these tests
does not guarantee that the analyzer meets all warranted specifications.
For more information on accessories go to: www.keysight.com/find/accessories
Find us at www.keysight.com Page 10
Thi s info rmatio n is subje ct to chang e with out n otice. © Key sight Techn ologies, 2018 - 2022, Publi shed in USA , Sep tember 2, 2022, 5992- 1275EN
Learn more at: www.keysight.com
For more information on Keysight Technologies’ products, applications, or services,
please contact your local Keysight office. The complete list is available at:
www.keysight.com/find/contactus
Related Literature
Keysight CXA signal analyzers
Publication title
Publication number
N9000B CXA X-Series Signal Analyzer, Multi-touch - Data Sheet
5992-1274EN
N9000B CXA Signal Analyzer, Technical Overview
3121-1302EN
X-Series Measurement Applications - Brochure
5989-8019EN
Bluetooth
®
and the Bluetooth
®
logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by Keysight Technologies is under license.
Loading...
