KERN & Sohn GmbH
Ziegelei 1 |
Phone: +49-[0]7433- 9933-0 |
D-72336 Balingen |
Fax: +49-[0]7433-9933-149 |
E-Mail: info@kern-sohn.com |
Internet: www.kern-sohn.com |
Operating manual
Electronic Moisture Analyser
KERN MLB_C
Version 3.1
03/2014
GB
MLB_C-BA-e-1431
GB |
KERN MLB_C |
Version 3.1 03/2014 |
|
|
Operating manual |
|
Electronic Moisture Analyser |
|
|
|
|
Contents
1 |
|
TECHNICAL DATA............................................................................................. |
5 |
|
1.1 |
|
Dimensions ............................................................................................................................... |
6 |
|
2 |
|
DEVICE OVERVIEW........................................................................................... |
7 |
|
2.1 |
|
Keyboard overview................................................................................................................... |
8 |
|
2.2 |
|
Display overview (during measurement) ............................................................................... |
9 |
|
3 |
|
BASIC INFORMATION (GENERAL) ................................................................ |
10 |
|
3.1 |
|
Proper use............................................................................................................................... |
10 |
|
3.2 |
|
Improper Use .......................................................................................................................... |
10 |
|
3.3 |
|
Warranty .................................................................................................................................. |
10 |
|
3.4 |
|
Monitoring of Test Resources............................................................................................... |
10 |
|
4 |
|
BASIC SAFETY PRECAUTIONS ..................................................................... |
11 |
|
4.1 |
|
Pay attention to the instructions in the Operation Manual ................................................ |
11 |
|
4.2 |
|
Personnel training .................................................................................................................. |
11 |
|
4.3 |
|
Danger Information ................................................................................................................ |
11 |
|
5 |
|
TRANSPORT AND STORAGE......................................................................... |
13 |
|
5.1 |
|
Testing upon acceptance ...................................................................................................... |
13 |
|
5.2 |
|
Packaging / return transport ................................................................................................. |
13 |
|
6 |
UNPACKING, SETUP AND COMMISSIONING ............................................... |
15 |
||
6.1 |
|
Installation Site, Location of Use.......................................................................................... |
15 |
|
6.2 |
|
Unpacking and assembly ...................................................................................................... |
16 |
|
|
6.2.1 |
Scope of delivery ............................................................................................................. |
17 |
|
6.3 |
|
Mains connection ................................................................................................................... |
17 |
|
2 |
|
|
|
MLB_C-BA-e-1431 |
6.4 |
Switch on/switch off device .................................................................................................. |
17 |
Stability display ................................................................................................................................... |
17 |
|
Balance zero display ........................................................................................................................... |
17 |
|
6.5 |
Connection of peripheral devices......................................................................................... |
18 |
6.6 |
Initial Commissioning ............................................................................................................ |
18 |
7 |
WEIGH/TARE ................................................................................................... |
19 |
8 |
MENU................................................................................................................ |
20 |
9 |
P1 CAL - ADJUSTMENT.................................................................................. |
22 |
9.1 |
P1-01 External adjustment .................................................................................................... |
22 |
9.2 |
P1-02 Adjustment test............................................................................................................ |
23 |
9.3 |
P1-03 Temperature adjustment............................................................................................. |
24 |
9.5 |
P1-04 Adjustment record print-out....................................................................................... |
28 |
9.6 |
P1-05 temperature calibration............................................................................................... |
29 |
10 |
P2 GLP (GOOD LABORATORY PRACTICE) .............................................. |
31 |
11 |
P3 SETTING DATE/TIME.............................................................................. |
33 |
12 |
P4 BASIC SETTINGS ................................................................................... |
34 |
13 |
P5 RS 232 INTERFACE ................................................................................ |
36 |
14 |
P6 OTHER USEFUL FUNCTIONS................................................................ |
39 |
15 |
OPERATOR MENU – MOISTURE ANALYSIS ............................................. |
42 |
15.1 |
Moisture analysis without using the program library......................................................... |
42 |
Setting drying parameters.................................................................................................................. |
42 |
|
How to implement drying.................................................................................................................... |
51 |
|
15.2 |
Moisture analysis using the program library ...................................................................... |
55 |
Activate program library “P6-01-Libr”............................................................................................... |
55 |
|
Setting drying parameters.................................................................................................................. |
55 |
|
Select drying parameters and carry out drying ............................................................................... |
56 |
|
MLB_C-BA-e-1431 |
3 |
16 |
GENERAL INFORMATION CONCERNING MOISTURE ANALYSIS........... |
57 |
16.1 |
Application .............................................................................................................................. |
57 |
16.2 |
Basics ...................................................................................................................................... |
57 |
16.3 |
Adjustment to existing measuring method ......................................................................... |
57 |
16.4 |
Preparing a sample ................................................................................................................ |
58 |
16.5 |
Sample material ...................................................................................................................... |
59 |
16.6 |
Sample size / originally weighted in quantity...................................................................... |
59 |
16.7 |
Drying temperature ................................................................................................................ |
60 |
16.8 |
Recommendations / Guidelines............................................................................................ |
61 |
17 |
DATA OUTPUT ............................................................................................. |
62 |
17.1 |
Remote control instructions ................................................................................................. |
63 |
18 |
SERVICING, MAINTENANCE, DISPOSAL .................................................. |
64 |
18.1 |
Cleaning .................................................................................................................................. |
64 |
18.2 |
Change fuse ............................................................................................................................ |
66 |
18.3 |
Servicing, maintenance ......................................................................................................... |
66 |
18.4 |
Disposal................................................................................................................................... |
66 |
19 |
INSTANT HELP............................................................................................. |
67 |
20 |
DECLARATION OF CONFORMITY.............................................................. |
68 |
4 |
MLB_C-BA-e-1431 |
Data |
MLB 50-3C |
|
MLB 50-3C110V |
|
|
|
|
Radiator |
Infrared (1 x 400 W) |
||
|
|
|
|
Temperature range |
max. 160°C |
|
|
|
|
|
|
Maximum load (Max) |
50 g |
|
|
|
|
|
|
Readability (d) |
1 mg |
|
|
|
|
|
|
Display accuracy |
0,01 % |
|
|
Weighed portion < 1.5 g |
|
||
|
|
|
|
|
|
|
|
Display accuracy |
0,001 % |
|
|
Weighed portion > 1.5 g |
|
||
|
|
|
|
|
|
|
|
Recommended |
|
|
|
adjustment weight, not |
50g (F1) |
|
|
added (class) |
|
|
|
|
|
|
|
Sample size |
max. 50 g |
|
|
|
|
|
|
Warm-up time |
4 h |
|
|
|
|
|
|
Heating profiles |
Standard drying |
|
|
|
|
|
|
|
Step-by-step drying |
|
|
|
|
|
|
|
Quick drying |
|
|
|
|
|
|
|
Gentle drying |
|
|
|
|
|
|
Repeatability for |
|
|
|
originally weighted in |
0.24 % |
|
|
quantity 2 g |
|
|
|
Repeatability for |
|
|
|
originally weighted in |
0,04 % |
|
|
quantity 10 g |
|
|
|
Repeatability in weighing |
|
|
|
mode (= standard |
0,001g |
|
|
deviation) |
|
|
|
Environmental |
• +10°C….+40°C ambient temperature |
||
conditions |
• max 80% air humidity non-condensing |
MLB_C-BA-e-1431 |
5 |
Shut-down criteria |
• Automatic 1 (shut-down at change of weighing value |
|||
< 1mg within 10 s) |
|
|
|
|
|
• Automatic 2 (shut-down at change of weighing value |
|||
|
< 1mg within 25 s) |
|
|
|
|
• Automatic 3 (shut-down at change of weighing value |
|||
|
< 1mg within 60 s) |
|
|
|
|
• Automatic 4 (shut-down at change of weighing value |
|||
|
< 1mg within 90 s) |
|
|
|
|
• Automatic 5 (shut-down at change of weighing value |
|||
|
< 1mg within 120 s) |
|
|
|
|
• Manual |
|
|
|
|
• Time-controlled (1 min – 9h 59 min) |
|
||
Sample dishes included |
10 (Ø 92 mm) |
|
|
|
|
|
|
|
|
Display after drying |
Moisture [%] = |
|
|
0 – 100 % |
Weight loss from starting weight (SW) |
|
|||
|
|
|||
Display can be switched at |
|
|
|
|
Dry mass [%] = |
|
|
100 – 0 % |
|
any time |
Residual weight (RW) left from starting weight |
|
||
|
|
|||
|
(SW) |
|
|
|
|
|
|
|
|
|
ATRO[%] [(SG – RG) : RG ] x 100% |
0 – 999 % |
||
|
|
|
|
|
|
Residual weight |
|
|
[g] |
|
|
|
|
|
Dimensions |
Housing 206 x 333 x 192 mm |
|
||
|
|
|
||
|
Available drying chamber 120 x 120 x 20 mm |
|||
|
|
|
|
|
Net weight |
|
4.9 kg |
|
|
|
|
|
|
|
Electric Supply |
230V/420W 50 Hz AC |
|
110V/420W 60 Hz AC |
|
|
|
|
|
|
6 |
MLB_C-BA-e-1431 |
Pos. |
Description |
1 |
Heated cover |
2 |
Viewing panel |
3 |
Halogen lamp |
4 |
Sample dish |
5 |
Windshield |
6 |
Removal aid |
7 |
Display |
8 |
Keyboard |
9 |
Adjustable foot |
MLB_C-BA-e-1431 |
7 |
Button |
Function |
|
|
|
|
|
• |
Switch machine on/off |
|
|
|
|
• Switch display during drying process |
|
|
|
|
|
• |
Start/finish measurement |
|
|
|
|
• |
Exit menu |
|
• |
Quit |
|
|
|
|
• |
Navigation keys |
|
|
|
|
• Data export to external device |
|
|
• Confirm / store settings |
|
|
|
|
|
• |
Taring |
|
• |
Zeroing |
|
|
|
|
• Go to application menu |
|
|
|
(set drying parameters) |
|
• Call-up user menu |
|
|
|
|
8 |
MLB_C-BA-e-1431 |
1.Display in moisture %
2.Current moisture content in %.
3.Results display in moisture %
4.Heating profile
5.Shutoff criterion
6.Previous drying time
7.Current temperature
8.Drying process active
MLB_C-BA-e-1431 |
9 |
The device purchased by you is designed for a fast and reliable determination of material moisture in liquid, porous and solid materials by applying the method of thermogravimetrics.
Impacts and overloading exceeding the stated maximum load (max) of the device, minus a possibly existing tare load, must be strictly avoided.
Balance may be damage by this.
Never operate device in explosive environment. The serial version is not explosion protected.
The structure of the balance may not be modified. This may lead to incorrect weighing results, safety-related faults and destruction of the balance.
The balance may only be used according to the described conditions. Other areas of use must be released by KERN in writing.
Loss of warranty due to:
-Our conditions in the operation manual are ignored
-The appliance is used outside the described uses
-The appliance is modified or opened
-Mechanical damage and damage caused by media, liquids, natural wear and tear
-The appliance is improperly set up or incorrectly electrically connected
-The measuring system is overloaded
In the framework of quality assurance the measuring-related properties of the balance and, if applicable, the testing weight, must be checked regularly. The responsible user must define a suitable interval as well as type and scope of this test. Information is available on KERN’s home page (www.kern-sohn.com) with regard to the monitoring of balance test substances and the test weights required for this. In
KERN's accredited DKD calibration laboratory test weights and balances may be calibrated (return to the national standard) fast and at moderate cost.
10 |
MLB_C-BA-e-1431 |
Carefully read this operation manual before setup and commissioning, even if you are already familiar with KERN balances.
All language versions contain a non-binding translation.
The original German is binding.
The device may be used and serviced only by trained staff.
WARNING
!The moisture analyser is used to analyse the moisture content of materials. This instrument must be used exclusively for this purpose. Any other usage may cause a risk to personnel, damage to the instrument or other material damage.
!The moisture analyser should be used mainly for the drying of aqueous substances.
!The moisture analyser may not be used in a hazardous area.
!The instrument may only be operated and maintained by trained personnel.
!Carefully read this operation manual before setup and commissioning, even if you are already familiar with KERN instruments.
Hazards during and after measuring
!Ensure correct installation of all components, see chap. 6.2
!Careful when removing the sample. The sample itself, the sample dish and the heating unit may be very hot.
!Use the sample retainer at all times as it allows safe working and prevents burns.
!Individual parts of the case (e. g. the ventilation grids) may heat up considerably during operation. Therefore, only take hold of the instrument by the marked handles.
MLB_C-BA-e-1431 |
11 |
CAUTION
The moisture analyzer operates using heat!
+Maintain sufficient space in the environment of the instrument to prevent heat build-up (distance from the instrument 20cm, upwards 1m).
+The heat extractor of the sample must never be covered, blocked, taped up or altered in any other way.
+Never place combustible materials on, under or next to the instrument, as the environment of the instrument heats up to a high temperature.
+Careful when removing the sample. The sample itself, the sample dish and the heating unit may be very hot.
CAUTION
Fire or explosion
+Explosive, easily flammable samples and samples that go into a chemical reaction when subjected to heat, may not be analysed with the moisture analyser. Sample materials developing aggressive vapours (e. g. acids) may cause corrosion problems on some parts of the instrument.
+If in doubt, conduct a risk analysis.
+Select a drying temperature for samples of this kind that is low enough to prevent ignition or explosion.
+Wear safety goggles.
WARNING
Substances that contain toxic or corrosive ingredients, produce toxic gases when drying, cause irritation (eyes, skin, airways), induce nausea or result in death
+Sample materials emitting toxic substances must be dried with a special extraction system in place. Create an environment that prevents the inhalation of vapours hazardous to health.
+Sample materials developing aggressive vapours (e. g. acids) may cause corrosion problems on some parts of the instrument.
12 |
MLB_C-BA-e-1431 |
When receiving the appliance, please check packaging immediately, and the appliance itself when unpacking for possible visible damage.
Keep all parts of the original packaging for a possibly required return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove loose/mobile parts.
MLB_C-BA-e-1431 |
13 |
Secure all items against slipping or damage.
14 |
MLB_C-BA-e-1431 |
The instrument is designed to achieve reliable weighing results under normal conditions of use. You will work accurately and fast, if you select the right location for the instrument.
On the installation site observe the following:
!Remove explosion prone and easily flammable material in the immediate vicinity.
Emerging vapours, sample dish and all parts of the sample chamber are hot!
!Protect the instrument against direct draughts due to open windows and doors.
!Avoid extreme heat and temperature fluctuations e.g. due to installation next to radiators.
!Do not expose the instrument to extreme dampness for longer periods of time. Non-permitted condensation (condensation of air humidity on the instrument ) may occur if a cold instrument is taken to a considerably warmer environment. In this case, acclimatize the disconnected instrument for ca. 2 hours at room temperature.
!Avoid direct sunlight
!The air humidity should be between 45% and 75%, non-condensing.
!Sufficient distance from heat-sensitive materials in area around instrument.
!Protect the instrument against high humidity, vapours and dust,
!Major display deviations (incorrect weighing results) may be experienced should electromagnetic fields (e.g. due to mobile phones or radio instruments), static electricity accumulations or instable power supply occur. Change location or remove source of interference.
!Avoid static charging of the material to be weighed, weighing container and windshield
!Place the instrument on a firm, level surface.
!Avoid jarring during weighing.
MLB_C-BA-e-1431 |
15 |
Take the moisture meter carefully out of its packaging, remove the plastic jacket and install it at the designated work space.
The moisture meter is supplied part-assembled. Control whether the delivery is complete immediately after unpacking the individual parts and assemble the separate component parts according to the enclosed diagram.
Sample dish
Dish retainer
Removal aid
Windshield
Windshield base plate
Put on the dish retainer carefully, ensuring correct positioning:
Level instrument with foot screws until the air bubble of the water balance is in the prescribed circle.
Check levelling regularly.
16 |
MLB_C-BA-e-1431 |
6.2.1 Scope of delivery Serial accessories:
•Moisture analyzer, see illustration chap. 2
•10 sample dishes
•Power cable
•Operating manual
Power supply is provided via the supplied mains cable.
Check, whether the voltage acceptance on the scales is set correctly. Do not connect the scales to the power grid unless the information on the scales (sticker) matches the local mains voltage.
Important:
Does the rating match the standard local mains current?
-Do not connect if mains voltages are different!
-If matching, connect the scales.
The moisture analyzer must be connected to a standard socket with earth terminal.
Do not eliminate the protective effect by using an extension lead without earth terminal. For power supplies from power grids without earth terminals call a specialist to establish equivalent protection according to the relevant installation regulations.
Press the ON/OFF key. The unit will carry out a self-test. The device is ready for measuring as soon as 0.000 g appears on the weighing display. If the display deviates from zero, operate the TARE key.
For short pauses in measurement, switch off device at ON/OFF switch and do not disconnect from mains.
If the display shows the stability display [ ] the balance is in a stable status. If the status is instable the [ ] display disappears.
Should the balance not display exactly zero despite empty balance pan, wait for stability display and press the TARE button. The balance start with resetting to zero and the symbol "a" will appear.
MLB_C-BA-e-1431 |
17 |
Before connecting or disconnecting of additional devices (printer, PC) to the data interface, always disconnect the balance from the power supply.
With your balance, only use accessories and peripheral devices by KERN, as they are ideally tuned to your balance.
In order to obtain exact results with the electronic balances, your balance must have reached the operating temperature (see warming up time chap. 1).
During this warming up time the balance must be connected to the power supply (mains, accumulator or battery).
The accuracy of the balance depends on the local acceleration of gravity. Strictly observe hints in chapter Adjustment.
18 |
MLB_C-BA-e-1431 |
Weighing
Switch on with ON/OFF switch.
Place load on and off weighing platform several times before weighing.
Place items to be weighed on platform and wait for stability indicator [] to appear; take weight reading.
Tare
Tare device with TARE button if using a weighing container. The tare weight is saved until it is deleted.
Note:
The tare procedure can be repeated as many times as necessary, for example with initial weighing of several components for a mix (add-on weighing). The limit is reached when the total weighing range capacity is full. After removing the taring container the total weight is displayed as negative display.
Delete tare
Remove weight from scales and press TARE button, the zero display will appear.
MLB_C-BA-e-1431 |
19 |
The menu is arranged in a user and operator menu. The scales are adjusted to user requirements in the user menu; setting of drying parameters is carried out in the application menu. The user menu is displayed using the F switch, the application menu is displayed using the MENU switch.
|
|
|
User menu |
|
|
|
|
|
|
|
|
|
|
P1 |
CAL |
|
Adjustment |
|
|
|
|
P1 |
01 |
ECAL |
External adjustment |
|
|
|
P1 |
02 tCAL |
Adjustment test |
|
|
|
|
P1 |
03 tE_CAL |
Temperature adjustment |
|
|
|
|
P1 |
04 |
CALr |
Record print out |
yes/no |
|
|
P1 |
05 tSt_Co |
Temperature calibration |
|
|
|
P2 |
GLP |
|
Best laboratory practice |
|
|
|
|
P2 |
01 |
USr |
User |
|
|
|
P2 |
02 |
PrJ |
Project |
|
|
|
P2 |
03 |
Ptin |
Print time |
yes/no |
|
|
P2 |
04 |
PdAt |
Datum |
yes/no |
|
|
P2 |
05 |
PUSr |
User |
yes/no |
|
|
P2 |
06 |
PPrJ |
Print project |
yes/no |
|
|
P2 |
07 |
PId |
Print serial no. |
yes/no |
|
|
P2 |
08 |
PFr |
Frame printout |
yes/no |
|
P3 |
time |
|
Date/time |
|
|
|
|
P3 |
01 |
StinnE |
Date format |
M/T/J; T/M/J |
|
|
P3 |
02 |
SdAtE |
Time format |
12 h; 24 h |
|
P4 |
rEAd |
|
Basic Settings |
|
|
|
|
P4-01 AuE |
Filter settings |
Stand/Slouu/FASt |
|
||
|
P4-02 Auto |
Auto zero |
On/OFF |
|
||
P5 |
|
RS232-parameters |
|
|
||
|
P5-01 bAud |
Baud rate |
2400/4800/9600/19200 |
|
||
|
P5-02 PStb |
Show unstable weight readings |
YES/no |
|
||
|
P5-03 LinE_t |
Output interval |
1/2/3/5/10/20/30/60/120/180 |
|
||
|
P5-04 Prn-Pc |
Output to PC |
YES/no |
|
||
P6 |
other |
|
Other useful functions |
|
|
|
|
P6-01 Libr |
Program library |
YES/no |
|
||
|
P6-02 bL |
Display background illumination |
On/Aut/OF |
|
||
|
P6-03 bLba |
Brightness of display |
No/10/20/30/40/50/60/70/80/90/100 |
|
||
|
P6-04 bEEP |
Key sound |
yes/no |
|
||
|
P6-05 PrnS |
Print out “Current menu |
|
|
||
|
|
|
|
settings” |
|
|
|
P6-06 Preuer |
Not documented |
yes/no |
|
||
|
|
|
|
|
|
|
20 |
|
|
|
|
MLB_C-BA-e-1431 |
Navigation in the menu:
Button |
Function in Menu |
|
|
• |
Enter user menu |
|
|
|
|
• Scroll to next page |
|
|
• |
Reduce digit |
|
|
|
|
• |
Scroll back |
|
• |
Change parameter value |
|
• |
Increase digit |
|
|
|
|
• |
Submenu/Parameter call-up |
|
• Shift selection of number to be changed to the right |
|
|
|
|
|
• Exit sub-menu/parameter, return to menu |
|
|
• Shift selection of number to be changed to the left |
|
|
|
|
|
• |
Confirm/save settings |
|
|
|
|
• Quit function without changing the settings |
|
|
• |
Back to menu |
|
|
|
Storing / jumping back to weighing mode
Any changes made in the balance memory will only be saved when the storing process is complete.
To achieve this, press the key several times until “SAVE“? appears.
Any changes carried out are stored by pressing the key.
To cancel changes, press the key.
Afterwards the balance automatically jumps back to weighing mode.
MLB_C-BA-e-1431 |
21 |
