Operation manual
Analytical balances
KERN AES/AEJ
Version 1.2
09/2009
GB
AES/AEJ-BA-e-0912
AES/AEJ-BA-e-0912
2
GB
KERN AES/AEJ
Version 1.2 09/2009
Operating Instructions Analytical Balances
Table of Contents
1 Technical Data.......................................................................................... 5
1.1 Dimensions ........................................................................................................................ 7
1.2 Conversion tables for weighing units ............................................................................. 7
2 Declaration of conformity
........................................................................ 8
3 Appliance overview
.................................................................................. 9
3.1 Keyboard overview.......................................................................................................... 10
3.2 Overview of display......................................................................................................... 11
4 Basic Information (General) .................................................................. 12
4.1 Proper use........................................................................................................................ 12
4.2 Improper Use ................................................................................................................... 12
4.3 Warranty ........................................................................................................................... 12
4.4 Monitoring of Test Resources........................................................................................ 12
5 Basic Safety Precautions ...................................................................... 13
5.1 Pay attention to the instructions in the Operation Manual ......................................... 13
5.2 Personnel training ........................................................................................................... 13
6 Transportation & Storage ...................................................................... 13
6.1 Testing upon acceptance ............................................................................................... 13
6.2 Packaging......................................................................................................................... 13
7 Unpacking, Setup and Commissioning................................................ 13
7.1 Installation Site, Location of Use................................................................................... 13
7.2 Unpacking and erection.................................................................................................. 14
7.3 Connection of peripheral devices.................................................................................. 15
7.4 Initial Commissioning ..................................................................................................... 16
8 Basic Operation
...................................................................................... 16
8.1 Switching on/off............................................................................................................... 16
8.2 Simple weighing .............................................................................................................. 17
8.3 Taring................................................................................................................................ 17
8.4 Net/gross .......................................................................................................................... 18
8.5 Display speed................................................................................................................... 19
8.6 Data output....................................................................................................................... 19
8.7 Underfloor weighing ....................................................................................................... 20
9 Adjustment
............................................................................................. 21
9.1 Adjustment with internal weight (KERN AEJ only)...................................................... 21
9.2 Adjustment with external weight (only AEJ) ................................................................ 22
9.3 Adjustment with external weight (only AES)................................................................ 23
9.4 Adjustment with external weight (only AES)................................................................ 24
9.5 Advice CAL/Auto-CAL (KERN PEJ only)....................................................................... 25
9.6 Standard deviation (KERN PEJ only) ............................................................................ 26
9.7 Verification ....................................................................................................................... 26
9.7.1 Verification switch and seals ............................................................................................. 27
AES/AEJ-BA-e-0912
3
10 Menu ........................................................................................................ 27
10.1 Menu 1...............................................................................................................................28
10.1.1 Navigation in menu 1 .........................................................................................................28
10.1.2 Overview Menu 1 ...............................................................................................................29
10.1.3 Settings for density determination......................................................................................32
10.1.4 Settings for tolerance weighing / add-up ...........................................................................32
10.1.5 Settings for serial interface ................................................................................................33
10.2 Menu 2...............................................................................................................................34
10.2.1 Navigation in menu 2 .........................................................................................................34
10.2.2 Overview Menu 2 ...............................................................................................................35
11 Operating modes.................................................................................... 36
11.1 Weighing / Weighing unit change ..................................................................................37
11.2 Parts counting ..................................................................................................................37
11.3 Percent determination .....................................................................................................41
11.3.1 Entering the reference weight by weighing........................................................................41
11.3.2 Numeric entering of the reference weight..........................................................................43
11.4 Weighing with freely programmable weighing unit .....................................................44
11.5 Density determination of solids (hydrostatic weighing)..............................................46
11.6 Adding of displayed values.............................................................................................51
11.6.1 Add-up without AUTO-TARE .............................................................................................52
11.6.2 Adding with AUTO-TARA...................................................................................................53
11.7 Weighing with tolerance range.......................................................................................54
11.7.1 General ..............................................................................................................................54
11.7.2 Display of the results..........................................................................................................55
11.7.3 Enable function / settings in menu .....................................................................................57
11.7.4 Tolerance control for absolute values................................................................................58
11.7.5 Tolerance control for differential values.............................................................................63
12 How to set date/time .............................................................................. 67
12.1 Time ...................................................................................................................................67
12.2 Date....................................................................................................................................68
13 Description of individual menu items................................................... 69
13.1 Automatic cut-off of display backlight...........................................................................69
13.2 How to change weighing units .......................................................................................69
13.3 How to change readability (models AES only) .............................................................69
13.4 Save tare value automatically (models AES only)........................................................70
13.5 Instant start.......................................................................................................................70
13.6 Interval output function...................................................................................................70
13.7 How to enter ID number for weighing balance .............................................................72
AES/AEJ-BA-e-0912
4
14 Data output ............................................................................................. 73
14.1 RS 232C interface ............................................................................................................ 73
14.2 Printer interface (unidirectional data exchange).......................................................... 76
14.3 Description of interface .................................................................................................. 76
14.4 Data output....................................................................................................................... 77
14.4.1 Format for data transmission............................................................................................. 77
14.4.2 Signs.................................................................................................................................. 77
14.4.3 Numeric data ..................................................................................................................... 77
14.4.4 Units................................................................................................................................... 78
14.4.5 Output weighing data in operating mode........................................................................... 79
14.4.6 Data status......................................................................................................................... 79
14.4.7 Interval data output............................................................................................................ 79
14.4.8 Output time ........................................................................................................................ 80
14.5 Input commands.............................................................................................................. 80
14.5.1 Feedback........................................................................................................................... 80
14.5.2 External tare command ..................................................................................................... 81
14.5.3 Remote control instructions ............................................................................................... 81
15 Printer mode
........................................................................................... 82
15.1 How to issue an adjustment protocol ........................................................................... 82
15.2 ISO/GLP/GMP – compliant output for weighing data .................................................. 83
15.3 Printout examples ........................................................................................................... 84
16 Service, maintenance, disposal ............................................................ 86
16.1 Cleaning............................................................................................................................ 86
16.2 Service, maintenance...................................................................................................... 86
16.3 Disposal............................................................................................................................ 86
17 Error messages, troubleshooting guide .............................................. 87
AES/AEJ-BA-e-0912
5
1 Technical Data
KERN AEJ 120-4M AEJ 220-4M
Weighing range (max) 120 g 220 g
Readability (d) 0.1 mg
Minimum load (Min) 10 mg
Verification value (e) 1 mg
Verification class I
Adjustment weight intern
Weighing Units mg, g, ct
Reproducibility 0.1 mg
Linearity ± 0.3mg
Stabilization time (typical) 3 sec
Warm-up time 8 hours
Minimum unit weight at
piece counting
> 0,5 mg
Reference quantities at
piece counting
5, 10, 30, 100
Electric Supply
Line adapter 220V-240V, 50 Hz
Weighing balance 9 V DC, 600mA
Operating temperature + 10° C …. + 30° C
Humidity of air max. 80 % (not condensing)
Underfloor weighing Clevis type eyelet, standard
Case (plastic), W x D x H [mm] 213 x 290 x 314
Dimensions wind screen (plastic), W
x D x H [mm]
178 x 170 x 209 (weighing space)
197 x 185 x 230 (exterior)
Weighing plate (stainless steel)
78 mm (outside)
65 mm (inside)
Weight kg (net) 7 kg
Interface RS 232C
AES/AEJ-BA-e-0912
6
KERN AES 120-4 AES 220-4
Weighing range (max) 120 g 220 g
Readability (d) 0.1 mg
Recommended adjustment weight,
not added (class)
100 g (E1) 200 g (E1)
Weighing Units
ct, dwt, g, gn, lb, mg, mo, oz, ozt, tl (Cn),
tl (HK), tl (Singap. Malays), tl (Tw), tol
Reproducibility 0.1 mg
Linearity ± 0.3mg
Stabilization time (typical) 3 sec.
Warm-up time 8 hours
Minimum unit weight at
piece counting
> 0,5 mg
Reference quantities at
piece counting
5, 10, 30, 100
Electric Supply
Line adapter 220V-240V, 50 Hz
Weighing balance 9 V DC, 600mA
Operating temperature + 10° C …. + 30° C
Humidity of air max. 80 % (not condensing)
Underfloor weighing Clevis type eyelet, standard
Case (plastic), W x D x H [mm] 213 x 290 x 314
Dimensions wind screen (plastic), W
x D x H [mm]
178 x 170 x 209 (weighing space)
197 x 185 x 230 (exterior)
Weighing plate (stainless steel)
78 mm (outside)
65 mm (inside)
Weight kg (net) 7 kg
Interface RS 232C
AES/AEJ-BA-e-0912
7
1.1 Dimensions
1.2 Conversion tables for weighing units
Weighing unit Gram Carat Ounce Pound Troy ounce Penny weight
1g 1 5 0.03527 0.00220 0.03215 0.64301
1ct 0.2 1 0.00705 0.00044 0.00643 0.12860
1oz 28.34952 141.74762 1 0.06250 0.91146 18.22917
1lb 453.59237 2267.96185 16 1 14.58333 291.66667
1ozt 31.10348 155.51738 1.09714 0.06857 1 20
1dwt 1.55517 7.77587 0.05486 0.00343 0.05 1
1GN 0.06480 0.32399 0.00229 0.00014 0.00208 0.04167
1tl (HK) 37.429 187.145 1.32027 0.08252 1.20337 24.06741
1tl (SGP,Mal) 37.79936 188.99682 1.33333 0.08333 1.21528 24.30556
1tl (Taiwan) 37.5 187.5 1.32277 0.08267 1.20565 24.11306
1mom 3.75 18.75 0.13228 0.00827 0.12057 2.41131
1to 11.66380 58.31902 0.41143 0.02571 0.37500 7.5
Weighing unit Grain
Tael
(Hong Kong)
Tael
(Singapore,
Malaysia)
Tael
(Taiwan)
Momme Tola
1g 15.43236 0.02672 0.02646 0.02667 0.26667 0.08574
1ct 3.08647 0.00534 0.00529 0.00533 0.05333 0.01715
1oz 437.5 0.75742 0.75 0.75599 7.55987 2.43056
1lb 7000 12.11874 12 12.09580 120.95797 38.88889
1ozt 480 0.83100 0.82286 0.82943 8.29426 2.66667
1dwt 24 0.04155 0.04114 0.04147 0.41471 0.13333
1GN 1 0.00173 0.00171 0.00173 0.01728 0.00556
1tl (HK) 577.61774 1 0.99020 0.99811 9.98107 3.20899
1tl (SGP,Mal) 583.33333 1.00990 1 1.00798 10.07983 3.24074
1tl (Taiwan) 578.71344 1.00190 0.99208 1 10 3.21507
1mom 57.87134 0.10019 0.09921 0.1 1 0.32151
1to 180 0.31162 0.30857 0.31103 3.11035 1
AES/AEJ-BA-e-0912
8
2 Declaration of conformity
KERN & Sohn GmbH
D-72322 Balingen-Frommern
Postfach 4052
E-Mail: info@kern-sohn.de
Tel: 0049-[0]7433- 9933-0
Fax: 0049-[0]7433-9933-149
Internet: www.kern-sohn.de
Declaration of conformity
EC-Konformitätserklärung EC-Declaration of -Conformity
EC-
Déclaration de conformité EC-Declaración de Conformidad
EC-Dichiarazione di conformità EC-Conformiteitverklaring
EC- Declaração de conformidade EC- Prohlášení o shode
EC-Deklaracja zgodności EC-Заявление о соответствии
D
Konformitätserklärung
Wir erklären hiermit, dass das Produkt, auf das sich diese Erklärung bezieht,
mit den nachstehenden Normen übereinstimmt.
GB
Declaration of
conformity
We hereby declare that the product to which this declaration refers conforms
with the following standards.
CZ
Prohlášení o
shode
Tímto prohlašujeme, že výrobek, kterého se toto prohlášení týká, je v souladu
s níže uvedenými normami.
E
Declaración de
conformidad
Manifestamos en la presente que el producto al que se refiere esta
declaración está de acuerdo con las normas siguientes
F
Déclaration de
conformité
Nous déclarons avec cela responsabilité que le produit, auquel se rapporte la
présente déclaration, est conforme aux normes citées ci-après.
I
Dichiarazione di
conformitá
Dichiariamo con ciò che il prodotto al quale la presente dichiarazione si riferisce è conforme alle norme di seguito citate.
NL
Conformiteitverklaring
Wij verklaren hiermede dat het product, waarop deze verklaring betrekking
heeft, met de hierna vermelde normen overeenstemt.
P
Declaração de
conformidade
Declaramos por meio da presente que o produto no qual se refere esta
declaração, corresponde às normas seguintes.
PL
Deklaracja
zgodności
Niniejszym oświadczamy, że produkt, którego niniejsze oświadczenie
dotyczy, jest zgodny z poniższymi normami.
RUS
Заявление о
соответствии
Мы заявляем, что продукт, к которому относится данная декларация,
соответствует перечисленным ниже нормам.
Electronic Balance: KERN AES, AEJ
Mark applied EU Directive Standards
2004/108/EC EN 55022 (2006)
2006/95/EC EN 60950 (2001)
Date: 07.10.2008 Signature:
Gottl. KERN & Sohn GmbH
Management
Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0,Fax +49-[0]7433/9933-149
AES/AEJ-BA-e-0912
9
3 Appliance overview
Display
Wind screen
Protection ring
Weighing plate
RS 232 interface
Printer interface
Foot
Foot screw
Underfloor
weighing device
Connection mains adapter
Air bubble
AES/AEJ-BA-e-0912
10
3.1 Keyboard overview
Function
Key Designation
short key pressing
TARE key
• Taring
• Zeroing
• During numeric input increase of digit
• Change menu settings
ON/OFF
switch
• Turn on/off
CAL-key
• Adjustment
PRINT-key
• Calculate weighing data via interface
• Cancel process/input
S-key
• Save settings/back to weighing mode
• For instructions how to change the speed of the dis-
play, see chpt. 8.5
F-key
• Change to additional operating modes/weighing
unit/net-gross
• During numeric input selection of next digit
• How to invoke a menu, see chpt.10.1.1
• How to select a menu, see chpt.10.1.1
AES/AEJ-BA-e-0912
11
3.2 Overview of display
Display Description
Tolerance marker
＊
Power display (power supply for balance via line adapter)
Balance in adding mode
}
Stability display
＋
Prompt for reference optimisation
−
Minus
M Display storage value, flashes during storage process
→0← Zeroing display
Bar graph/capacity display
CAL Adjustment symbol
This is displayed during setting of date/time.
Flashes during interval output
Calculate weighing data via interface
B/G Gross weight
Net Tare symbol
＃
Symbol during weighing with freely programmable weighing unit
Σ Symbol during display of “total”
Pcs Symbol during piece counting
(mom) Weighing unit Momme
％
Symbol during percentage calculation
Display weighing unit
mg Milligram
S, X Display depending on function
Display last decimal place (AEJ only)
AES/AEJ-BA-e-0912
12
4 Basic Information (General)
4.1 Proper use
The balance you purchased is intended to determine the weighing value of material
to be weighed. It is intended to be used as a “non-automatic“ balance, i.e. the material to be weighed is manually and carefully placed in the centre of the weighing
plate. As soon as a stable weighing value is reached the weighing value can be
read.
4.2 Improper Use
Do not use balance for dynamic weighings. In the event that small quantities are
removed or added to the material to be weighed, incorrect weighing results can be
displayed due to the “stability compensation“ in the balance. (Example: Slowly
draining fluids from a container on the balance.)
Do not leave permanent load on the weighing plate. This may damage the measuring system.
-Impacts and overloading exceeding the stated maximum load (max) of the balance,
minus a possibly existing tare load, must be strictly avoided. Balance may be damage by this.
Never operate balance in explosive environment. The serial version is not explosion
protected.
The structure of the balance may not be modified. This may lead to incorrect weighing results, safety-related faults and destruction of the balance.
The balance may only be used according to the described conditions. Other areas
of use must be released by KERN in writing.
4.3 Warranty
Warranty claims shall be voided in case
• Our conditions in the operation manual are ignored
• The appliance is used outside the described uses
• The appliance is modified or opened
• Mechanical damage or damage by media, liquids, natural wear and tear
• The appliance is improperly set up or incorrectly electrically connected
• The measuring system is overloaded
4.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the balance and, if applicable, the testing weight, must be checked regularly. The responsible user must define a suitable interval as well as type and scope of this test. Information is available on KERN’s home page (www.kern-sohn.com with regard to
the monitoring of balance test substances and the test weights required for this. In
KERN’s accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.
AES/AEJ-BA-e-0912
13
5 Basic Safety Precautions
5.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and commissioning, even if you
are already familiar with KERN balances.
5.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
6 Transportation & Storage
6.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the appliance itself when unpacking for possible visible damage.
6.2 Packaging
Keep all parts of the original packaging in case you need to return the appliance.
Only use original packaging for returning.
Before sending, disconnect all connected cables and loose/movable parts.
Attach possibly existing transport safeguards. Secure all parts, e.g. weighing plate,
power unit etc., to prevent slipping and damage.
7 Unpacking, Setup and Commissioning
7.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use.
You will work accurately and fast, if you select the right location for your balance.
Therefore, observe the following for the installation site:
• Place the balance on a firm, level surface;
• Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
• Protect the balance against direct draughts due to open windows and doors;
• Avoid jarring during weighing;
• Protect the balance against high humidity, vapors and dust;
• Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
• Avoid static charge of goods to be weighed or weighing container.
AES/AEJ-BA-e-0912
14
Major display deviations (incorrect weighing results) may be experienced should
electromagnetic fields (e.g. due to mobile phones or radio equipment), static electricity accumulations or instable power supply occur. Change location or remove
source of interference.
7.2 Unpacking and erection
Carefully remove the balance from the packaging, remove plastic cover and setup
balance at the intended workstation.
Ö Scope of delivery / serial accessories
Balance Carrier of weighing plate Weighing plate
Mains adapter Operating Manual
Ö Positioning of weighing plate
Screw down carrier according to drawing and then insert weighing pan.
Weighing plate
Support
AES/AEJ-BA-e-0912
15
Ö Levelling balance
Level balance with foot screws until the air bubble of the
water balance is in the prescribed circle.
Ö Mains connection
Power is supplied via the external mains adapter. The stated voltage value must be
the same as the local voltage.
Only use original KERN mains adapters. Using other makes requires consent by
KERN.
7.3 Connection of peripheral devices
Before connecting or disconnecting of additional devices (printer, PC) to the data
interface, always disconnect the balance from the power supply.
With your balance, only use accessories and peripheral devices by KERN, as they
are ideally tuned to your balance.
Air bubble
Foot screw
Connection mains adapter
AES/AEJ-BA-e-0912
16
7.4 Initial Commissioning
In order to obtain exact results with the electronic balances, your balance must have
reached the operating temperature (see warming up time chap. 1).
During this warming up time the balance must be connected to the power supply
(mains, accumulator or battery).
To adapt the balance to ambient conditions, open wind screen doors.
The accuracy of the balance depends on the local acceleration of gravity.
Strictly observe hints in chapter Adjustment.
8 Basic Operation
8.1 Switching on/off
If the (*) sign can be seen, the balance is being supplied with power via the mains adaptor.
Turn on balance by pressing the ON/OFF key. The
balance will carry out a self-test The balance is ready
for weighing when the weight display appears.
The weighing balance will start in the mode it was in
when last switched off, e. g. piece counting.
Turn off balance by pressing the ON/OFF key.
Symbol (*) appears.
AES/AEJ-BA-e-0912
17
8.2 Simple weighing
Ö Place goods to be weighed on balance.
Ö Wait until the stability display appears [|].
Ö Read weighing result.
If the display shows the stability display [|] the balance is in a stable status. If the status is instable the
[|] display disappears.
Observe stable environmental conditions.
stable
unstable
Bar graph display
The bar graph display moves from the left to the right
and proceeds equally to the weight loaded onto the
weighing balance. Its full width is reached at maximum load.
This is an analogue display of the current allocation
of the weighing area.
Balance zero display
If the weighing balance does not definitely show
zero, wait for the stability display [|] and then press
the TARE-key. The balance starts with resetting to
zero. Symbol [ a ] appears.
8.3 Taring
Ö Place the weighing box and press the TARE-key.
After successful control of the rest position you
will see displayed zero and the Net symbol. The
weight of the container is now internally saved.
0.0000
g
a
Net
Ö Weigh the material, the net weight will be indi-
cated.
100.0000
g
Net
Ö The weight of the weighing container will be displayed as a minus number after
removing the weighing container.
Ö To delete the tare value, remove load from weighing pan and press the TARE-
key.
Ö The tare procedure can be repeated as many times as necessary, for example
with initial weighing of several components for a mix (add-on weighing). The limit
is reached when the total weighing range capacity is full.
Zero
Highest load
AES/AEJ-BA-e-0912
18
8.4 Net/gross
The dead weight of any weighing container may be tared away by pressing a button. For subsequent weighings the net weight of the goods to be weighed as well as
the gross weight goods + taring container can be displayed.
Condition: Menu setting [q SET.1],see chpt. 10.1.2
Ö Place the weighing box and press the TARE-key.
After successful control of the rest position you
will see displayed zero and the Net symbol. The
weight of the container is now internally saved.
0.0000
g
a
Net
Ö Weigh the material, the net weight will be indi-
cated.
100.0000
g
Net
Ö Press the F-key to prompt a display of the gross
weight (load + weighing container) and the symbol
B/G.
Ö To switch between net and gross weight, press
the F-key several times.
130.0000
g
B/G
Ú
100.0000
g
Net
• This procedure may be repeated any number of times until the weighing
range of the weighing balance has been exhausted.
• Net/gross function only available in weighing mode.
• Taring is only available as long as net weight is displayed.
AES/AEJ-BA-e-0912
19
8.5 Display speed
To change the display speed of the weighing balance without invoking the menu,
press the S-key. However, this only will limit your options to the three settings nor-
mal Æ slow Æ fast.
Within the menu it is possible to fine-tune the weighing balance for certain ambient
conditions and measuring purposes, see chpt. 10.1.1, menu items [S.RE.*] and
[6.EnU.*].
Ö Press the S-key, current setting appears.
Ö Repeated pressing of the S-key allows you to se-
lect any of the following settings
normal Æ slow Æ fast
Ö After selecting, wait until the weighing balance
has returned automatically to weighing mode.
FAST
Ú
NORNAL
These settings correspond to the settings in menu item [S.RE.*] and [6.EnU.*].
Corresponding settings
in menu
S-key
Adjustment Description
6.EnU S.RE.
FAST
FAST
Weighing balance sensitive and
fast
0 1
nORNAL
NORMAL
Weighing balance working at
medium speed
0 3
SLQU
SLOW
Weighing balance insensitive and
slow
1 3
8.6 Data output
To print out or transfer weighing and GLP data to a computer you will have to connect a printer or computer. The weighing balance’s factory settings define that data
output happens after successful rest position control was carried out followed by
pressing the PRINT-key. For additional settings see chpt. 10.1.5.
During a display
weighing data are calculated via interface.
AES/AEJ-BA-e-0912
20
8.7 Underfloor weighing
Objects unsuitable for placing on the weighing scale due to size or shape may be
weighed with the help of the flush-mounted platform.
Proceed as follows:
• Switch off the balance
• Remove the weighing pan and carefully turn over the weighing balance.
• Loosen screw, turn cover plate (1) by 90º and reattach with the help of
the screw.
• Suspend hook for underfloor weighing carefully and completely.
• Place weighing balance over an opening.
• Attach load to hook and carry out weighing procedure.
Fig. 1: Setup of balance for underfloor weighing
CAUTION
▬ Always ensure that all suspended objects are stable enough to
hold the desired goods to be weighed safely (danger of breaking).
▬ Never suspend loads that exceed the stated maximum load (max)
(danger of breaking)
▬ Always ensure that there are no persons, animals or objects that
might be damaged underneath the load.
After completing the underfloor weighing the opening on the bottom of
the balance must always be closed (dust protection).
2
1
AES/AEJ-BA-e-0912
21
9 Adjustment
As the acceleration value due to gravity is not the same at every location on earth,
each balance must be coordinated - in compliance with the underlying physical
weighing principle - to the existing acceleration due to gravity at its place of location
(only if the balance has not already been adjusted to the location in the factory).
This adjustment process must be carried out during the initial start-up, after change
in location and variation of surrounding temperature. To receive accurate measuring
values it is also recommended to adjust the balance periodically in weighing operation.
Observe stable environmental conditions. A warming up time (see chapter 1)
is required for stabilization. Ensure that there are no objects on the weighing
plate.
9.1 Adjustment with internal weight (KERN AEJ only)
With the internal adjustment weight, the weighing accuracy can be checked and readjusted at any time.
Condition: For menu setting [
xCA.1
] see chpt. 10.1.2
Ö Press the CAL key
AWT. CAL
CAL
PWSH C
CAL
Ö Press the CAL-key again and adjustment will take
place automatically.
AWT. CAL
CAL
CH. O
1
CAL
CH. F.S.
1
CAL
Ö The process of adjustment is completed.
Adjustment protocols will be issued automatically
if you connect an optional printer, see chpt. 15
“printer mode”. Whilst printing is in progress [busy
] will be displayed.
EnD
CAL
Ö The balance returns automatically into weighing
mode.
AES/AEJ-BA-e-0912
22
9.2 Adjustment with external weight (only AEJ)
During adjustment tests the balance automatically compares the saved value of the
adjustment weight with the actual value. This is only a check, i.e. no values are
changed.
Condition: Menu setting [
xCA.
2
], see chpt. 10.1.2
Ö Press the CAL key
T. nT
CAL
PWSH C
CAL
Ö Press the CAL-key again and the adjustment test
will take place automatically.
T. nT
CAL
T. O
CAL
T. F.S.
CAL
Ö The difference between the saved value and the
measured value is displayed.
Adjustment protocols will be issued automatically
if you connect an optional printer, see chpt. 15
“printer mode”. Whilst printing is in progress
[busy ] will be displayed.
D1FF
CAL
z0007
CAL
g
Ö Press any key; adjustment process will stop. The
balance returns to weighing mode.
AES/AEJ-BA-e-0912
23
9.3 Adjustment with external weight (only AES)
Carry out adjustment with the help of the recommended adjustment weight (see
chapter 1 “Technical Specifications”).
Info about adjustment weights can be found on the Internet at: http://www.kernsohn.com
Condition: Menu setting [
xCA.3
], see chpt. 10.1.2
Ö Press the CAL key
EHT.CAL
CAL
1
K
PWSH C
CAL
Ö Press the CAL-key again; zero point will be
saved.
EHT.CAL
CAL
1
K
Qn. O
CAL
Ö When display [on F.S] appears, put the adjusting
weight carefully in the centre of the weighing pan.
CAL
Qn
F.5.
Ö The adjustment process is started
CAL
Qn
F.5.
Ö The process of adjustment is completed.
Adjustment protocols will be issued automatically
if you connect an optional printer, see chpt. 15
“printer mode”. Whilst printing is in progress
[busy ] will be displayed.
BWSX
CAL
EnD
CAL
Ö The balance returns automatically into weighing
mode.
Take away adjustment weight. An adjusting error
or incorrect adjusting weight will be indicated by
the error message [- Err]. Repeat adjustment
procedure.
AES/AEJ-BA-e-0912
24
9.4 Adjustment with external weight (only AES)
During adjustment tests the balance automatically compares the saved value of the
adjustment weight with the actual value. This is only a check, i.e. no values are
changed.
Condition: For menu setting [
x CA.
4
] see chpt. 10.1.2
Ö Press the CAL key
T. EHT.
CAL
1
PWSH C
CAL
Ö Operate the CAL-key
T. EHT.
CAL
1
Qn. O
CAL
Ö When display [on F.S] appears, put the adjusting
weight carefully in the centre of the weighing pan.
CAL
Qn
F.5.
Ö Adjustment test is starting
CAL
Qn
F.5.
Ö The difference between the saved value and the
measured value is displayed.
Ö Adjustment protocols will be issued if you connect
an optional printer and by pressing the PRINT-
key, see chpt. 15 “printer mode”. Whilst printing is
in progress [ ] will be displayed.
D1FF
CAL
z0007
CAL
g
Ö Press any key; adjustment process will stop. Re-
move adjusting weight, balance will return into
weighing mode.
EnD
CAL
AES/AEJ-BA-e-0912
25
• When the PRINT-key is pressed during the adjusting procedure, [stop] will
be displayed and adjustment interrupted. The balance returns to weighing
mode.
• You can cancel the adjusting procedure by pressing any key.
• The following error messages may be displayed during adjust-
ment/adjustment test.
1-Err
Incorrect adjusting weight
2-Err
Divergence last external adjustment > 1%
3-Err
During the adjustment there was one weight on the weighing plate
4-Err
Divergence from last internal adjustment > 1%
A-Err
Internal adjustment automatics defective
Adjustment protocols can be issued by connecting an optional
printer, see chpt. 15 "printer operation".
[ ] is displayed during printing.
9.5 Advice CAL/Auto-CAL (KERN PEJ only)
Automatic adjustment is started or required every 4 hours, or when a temperature
change of 5 ºC occurs, depending on the setting in the menu, see chpt. 10.1.1.
Advice CAL = menu setting [
E. ADC.
1
]
When “Advice CAL“ is set, the required adjustment will merely be requested and
manual adjustment must be carried out.
“CAL” will start flashing if adjustment is required (after 4 h/ ± 5ºC). “CAL" will keep
flashing until the adjustment is started.
For AEJ models this is carried out with an internal adjustment weight (chpt. 9.1), for
AES models with an external adjustment weight (chpt. 9.3).
Advice CAL = menu setting [
E. ADC. 2
]
Automatic adjustment is carried out when “Auto-CAL“ is set and an adjustment due
(after 4 h / ± 5ºC).
“CAL” will start flashing 10 minutes before the start of automatic adjustment with
internal adjusting weight. Complete current weighing in processes within this time
frame. Automatic adjustment will not be started until the weighing balance is
unloaded and a successful stability display has appeared.
It is only possible to enable the Auto-Cal function in menu setting
[
xCA.1
], see chpt. 10.1.2.
AES/AEJ-BA-e-0912
26
9.6 Standard deviation (KERN PEJ only)
Ö Keep CAL-key pressed until [
AR
N
] appears.
Ö The weighing balance in conjunction with the adjusting weight defines 10 meas-
ured values Î in succession.
Ö The defined standard deviation (e.g. 0.000073 g) will be displayed.
Ö Press any key; balance will return to weighing mode.
Ö To interrupt measuring, press the PRINT-key.
9.7 Verification
General introduction:
According to EU directive 90/384/EEC balances must be officially verified if they are
used as follows (legally controlled area):
a) For commercial transactions if the price of goods is determined by weighing.
b) For the production of medicines in pharmacies as well as for analyses in the
medical and pharmaceutical laboratory.
c) For official purposes.
d) For manufacturing final packages.
In cases of doubt, please contact your local trade in standard.
Verification instructions
An EU type approval exists for balances described in their technical data as verifiable. If a balance is used where obligation to verify exists as described above, it
must officially verified and re-verified in regular intervals.
Re-verification of a balance is carried out according to the respective national regulations. The validity for verification of balances in Germany is e.g. 2 years.
The legal regulation of the country where the balance is used must be observed!
Verification of the balance is invalid without the "seal".
Balances with obligation to verify must be taken out of operation if:
• The weighing result of the balance is outside the error limit. Therefore,
in regular intervals load balance with known test weight (ca. 1/3 of the max.
load) and compare with displayed value.
• The reverification deadline has been exceeded.
AES/AEJ-BA-e-0912
27
9.7.1 Verification switch and seals
Prior to verification you will have move the calibration switch to verification position
(See direction of arrow, fig. 1). In this position the display shows a bracket around
the last display point.
After verification the balance is sealed at the indicated positions.
Seal of approval Seal of approval
Fig. 1
Move verification switch to
verification position.
Seal/rubber plug/verification switch
Access to the verification switch is achieved
by removing the possibly existing seal (verification becomes invalid) and the rubber
plug.
Position of
verification switch
Status
forwards
Balance is unlocked for the adjustment process, adjustment will be possible "ADJ" appears when the balance is switched on.
backwards Verification position - Adjustment locked
10 Menu
In the menu the settings of the balance can be modified and functions can be activated. This way, the balance can be adjusted to individual weighing requirements.
The menu is sub-divided into “menu 1” and “menu 2”.
AES/AEJ-BA-e-0912
28
10.1 Menu 1
10.1.1 Navigation in menu 1
Access to menu
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release but-
ton. The first menu item showing the current setting will be displayed.
Fonm
How to select menu items
Ö Press the F-key to select the individual menu
items showing the current settings one by one.
How to change settings
Ö Press the TARE-key to change the setting of a
selected menu item. Each time the TARE-key is
pressed the next setting will be displayed. As
soon as the desired setting appears on the display you can select the next menu item (see
above) or exit the menu (see paragraphs below).
How to save settings and to exit the menu
Ö Press the S-key; balance will return to weighing
mode.
or
Ö Press the F-key repeatedly until the weighing bal-
ance returns to weighing mode.
Ö All changes will be saved.
Cancel
Ö Press the PRINT-key briefly; balance will return to
weighing mode. Changes will not be saved.
AES/AEJ-BA-e-0912
29
10.1.2 Overview Menu 1
Default setting is marked by *.
Menu item
Display Selection
Description
* 1
Weighing
2
Count pieces / weigh
3
Percentage calculation / weigh
4
Weighing with freely programmable weighing unit
5
Density determination of
solids
Weighing mode
q SET.
6
Determining density of
liquids
For settings
see chpt.
10.1.3
* 0
Disabled
1
Add up [26. AD.N.]
2
Tolerance weighing
Additional functions
r SEL
3
Tolerance weighing /Add
up
For settings
see chpt.
10.1.4
0
Automatic zero tracking off
* 1
Automatic zero tracking on
2
3
Automatic zero point
correction
(zero tracking)
sA.O
4
Level of deviation (1-4)
weak
strong
models AES
only
only AES 1
* 2
3
Stability display
t S.D.
4
Fast (rough)
Slow (fine)
0
Setting for dispensing
1
2
* 3
4
Display speed
u RE.
5
Sensitive/fast
Insensitive / slow
* 0
Calm and stable environment
Vibration filter
6. EnU
1
Busy environment
(See
chpt. 8.5)
0
deactivated
* 2
7-digit data format
3
extended 7-digit data format
Interface
7. K.F.
4
Special formats
See chpt.
10.1.5
AES/AEJ-BA-e-0912
30
* 41
Special format 1
Special format
7. K.F.
42
Special format 2
During setting only
[7. K.F. 4]
0
CAL-key deactivated
*1 1
Internal adjustment
2
Adjustment test using
internal weight
Models AEJ only
*2 3
External adjustment
Adjustment
8. CA.
4
Adjustment test using
external weight
Models AES only
0
Hide bar graph
Bar graph
9. B.G.
*
1
Show bar graph
0
Automatic turn-off for battery operation (function
only exists for battery operation)
A. A.P.
*
1
Not documented
0
Off
Auto backlight OFF function
B. A.B.
*
1
Backlight will switch off automatically 3
minutes after achieving a stable weighing
value. Changes in weight or pressing of
keys will automatically result in backlight
switching on again.
1
mg
* 2
g
4
ct
5
oz
6
lb
7
ozt
8
dwt
9
gn
A
tl (HK)
B
tl (Singap. Malays)
C
tl (Tw)
D
mom
Weighing unit A
(standard weighing unit)
Not all units are available
for calibrated weighing
balances, see chpt. 1
CK. W.A
E
tol
*1
2
3
4
Change readability for
weighing unit A,
see chpt. 13.3 (models
AES only)
C2. D.A
5
Fine
Rough
* 0
No unit
1
±
Weighing unit B
To choose between units
A and B, press the F-key
C3. W.B
E
Settings [ 1 ~ E ]
See weighing units A
AES/AEJ-BA-e-0912
31
*1
2
3
4
Change readability for
weighing unit A,
see chpt. 13.3 (models
AES only)
C4. D.B
5
Fine
Rough
Is only displayed at
setting
[C3. W.B] = [1 ~ E]
0
No
Display last fractional digit
Models AEJ only
D.A.1.
*
1
Yes; always use this setting!
*2 0
Disabled
1
Advice CAL
Advice CAL/
Auto CAL
E. AD.C.
*1 2
Auto CAL, only models AEJ
* 0
No
ISO/GLP/GMP – compliant output
F. GLP
1
Yes
0
No
Output adjustment protocol
Fq QWT
*
1
Yes
* 0
No ISO/GLP/GMP – compliant output for weighing
data, see chpt. 15.2
F2. QD.
1
Yes
* 1
English
Selection of Language
F3. P.F.
2
not documented
Setting
[F. GLP 1]
only
1
Display in year-month-day
2
Display in month-day-year
Date output
G. DATE
*
3
Display in day-month-year
* 0
Output - NO
Time output
qT.Q
.
H
1
Output - YES
1
Zero displayed immediately after key-
stroke
Taring range
(models AES only)
* 2
Zero displayed after keystroke not until
weighing value is stable
* 0
No
How to store the tare
value see chpt. 13.4
(models AES only)
1
Yes
* 0
When connecting the mains cable, the
balance will immediately go into stand-by
mode
Instant start,
see chpt. 13.5
n. D.ST.
1
Balance switches on when plugging in
mains power supply
0
Display background illumination off
1
Display background illumination on
Backlight
P. B.L.
*
2
Backlight of display on (for
connection via line adapter)
1
not documented
2
not documented
Output interface
(models AEJ only)
n. P.RF.
*
3
For calibrated weighing balances always
use this setting
* Marks default setting
*1 Default setting model KERN AEJ only
*2 Default setting model KERN AES only
AES/AEJ-BA-e-0912
32
10.1.3 Settings for density determination
* 0
dest. Water
Measure medium
1q NED.
1
Measuring liquid of your selection
* 0
only output measuring value density
Data output
12. D.Q.D.
1
Output of all density parameters
* 0
OFF (Output only after pressing PRINT key)
Density determination
Autom.
Data output
13. A.Q.
1
ON
10.1.4 Settings for tolerance weighing / add-up
Not displayed at menu setting „r SEL 0“
Menu item
Display
Selection
Description
* 1
Tolerance marker is always displayed, even if
standstill control is not yet displayed.
Display conditions of
the tolerance marker
21. CQ.
2
Tolerance marker is only displayed in connection
with standstill control.
0
Tolerance marker is only displayed above zero
range (mind + 5).
Tolerance range
22. LK.
* 1
Tolerance marker is displayed for the whole
range.
1
1- Limiting point (OK/ -)
* 2
2- Limiting points (+/OK/-)
3
3- Limiting points (1-4)
Number of limiting
points
23. P1
4
4- Limiting points (1-5)
* 1
for absolute values
Grading
24. TXP.
2
for differential values
* 1
Display via +, OK or -
Display of
Results
25. LG
2
For setting 2 limits display in bar graph is possible
* 1
Add-up function without
AUTO-TARE
Adding
26 AD.N.
2
Adding function with
AUTO-TARA
During setting only
[r SEL1] or
[r SEL3]
AES/AEJ-BA-e-0912
33
10.1.5 Settings for serial interface
Not shown for menu setting „7K.F0“ (interface de-activated).
Menu item
Display
Selec-
tion
Description
0
no data output
1
Continuous data output
2
Continuous data output stable weighing values
* 3
Output for stable and instable weighing values after pressing PRINT key
4
Output for stable weighing value after previ-
ous relief of balance
5
One output for stable weighing value. No
output for stable weighing values. Renewed
output after stabilization
6
One output for stable weighing value. Continuous output for instable weighing values.
* 7
Output of stable weighing values after press-
ing PRINT key
A
One-off instant output after fixed interval (see
chpt. 13.6
Output condition at
interface
71. Q.m.
*
1
B
One-off instant output after fixed interval and
stable weighing value (see chpt. 13.6)
* 1
1200 bps
2
2400 bps
3
4800 bps
4
9600 bps
Baud rate
7r B.L.
5
19200 bps
* 0
No parity bit
1
Odd parity
Parity
7s PA.
2
Even parity
During setting only
[7K.F] = [2~4]
7
7 bits
Data Bits
7t D.L.
* 8
8 bits
1
1 bit
Stop Bits
7u ST.
* 2
2 bit
During setting only
[7K.F] = [3, 4]
* 0
Always use this setting
not documented
76 W.N.
1
* 1
A00/Exx Format
Feedback, see
chpt. 14.5.1
7w RES.
2
ACK/NAK Format
AES/AEJ-BA-e-0912
34
10.2 Menu 2
10.2.1 Navigation in menu 2
Access to menu
Ö Hold F-key while TARE key is pressed until
[FWnm 2] is displayed. Release button. The first
menu item showing the current setting will be displayed.
Fonm2
1. 1D 0
How to select menu items
Ö Press the F-key to select the individual menu
items showing the current settings one by one.
1. 1D 0
2 .Q.N.P.1 0
How to change settings
Ö Press the TARE-key to change the setting of a
selected menu item. Each time the TARE-key is
pressed the next setting will be displayed. As
soon as the desired setting appears on the display you can select the next menu item (see
above) or exit the menu (see paragraphs below).
1. 1D 0
1. 1D 2
How to save settings and to exit the menu
Ö Press the S-key; balance will return to weighing
mode.
or
Ö Press the F-key repeatedly until the weighing bal-
ance returns to weighing mode.
Ö All changes will be saved.
Cancel
Ö Press the PRINT-key briefly; balance will return to
weighing mode. Changes will not be saved.
AES/AEJ-BA-e-0912
35
10.2.2 Overview Menu 2
Default setting is marked by *.
Menu item
Display
Selec-
tion
Description
* 0
Off
Setup balance ID no.
1. 1D
1
ON
* 0
Always use this setting
Not documented
2. Q.N.P.
1
* 0
Off
Overwriting the adjusting weight
Attention:
Modifications may only be carried
out by specialized personnel!
3. R.CA
1
ON
Non-calibrated
models AEJ
only
* 0
Always use this setting
Not documented
4. N.E.HK.
1
AES/AEJ-BA-e-0912
36
11 Operating modes
Depending on the setting in menu 1, it is possible to switch the weighing balance to
additional enabled operating modes by pressing the F-key, see chpt. 10.1.2 menu
item [q SET.]. Additional operating modes such as add-up / tolerance weighing
may be enabled under menu item [r SEL] (except density determination mode).
Menu item Application
q SET. 1
Weighing
q SET. 2
Weighing/parts counting
q SET. 3
Weighing/percent determination
q SET. 4
Weighing / weighing with freely programmable weighing unit
q SET. 5
Weighing / density determination of solids
q SET. 6
Weighing / density determination of liquids
r SEL 1
Adding
r SEL 2
Tolerance weighing
r SEL 3
Add-up / tolerance weighing
Overview of available functions
Mode Additional functions
Operating mode
Unit Function
Adding Tolerance
weighing
Weighing unity A Weighing
{ {
Weighing unit A
B/G
Gross weight
× ×
Weighing unit B
Weighing
× ×
Weighing
Weighing unit A Σ
Adding Display
×
Pcs Counting
{ {
Pcs Σ
Total piece counting Display
×
Weighing unit A Pcs
Average parts weight
× ×
Parts counting
Weighing unity A
Weighing
× ×
% Percent determina-
tion
{
% Σ
Total percentage Display
Percent determination
Weighing unity A
Weighing
×
# Multiplication factor
{ {
# Σ
Total Display
×
Weighing with freely
programmable
weighing unit
Weighing unity A
Weighing
× ×
Density determination (solids/liquids)
g (fix) Density determina-
tion mode
× ×
{
= available
×
= not available
Display = value being shown
AES/AEJ-BA-e-0912
37
11.1 Weighing / Weighing unit change
Ö Place goods to be weighed on balance
Ö Wait until the stability display appears [|]
Ö Read weighing result.
Ö Press repeatedly the button F to switch-over dis-
play into net/gross
Net weight unity A ↔ gross weight unity A
see chapter 8.4, or in other activated weighing
unity (menu setting [ C3.W.B ] )
100.0000
g
100.0000
g
B/G
500.000
mT
11.2 Parts counting
During piece counting parts can either be counted into a container or out of a container. To count a greater number of parts the average weight per part has to be
determined with a small quantity (reference quantity).
The larger the reference quantity, the higher the counting exactness.
High reference must be selected for small parts or parts with considerably different
sizes.
The process has four steps:
• Tare the weighing container
• Determine the reference unit
• Original weighing of reference weight
• Count the items
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Use the TARE-key to select “piece counting” and
confirm by pressing the S-key.
The balance is situated in the piece counting
mode.
0
PCS
AES/AEJ-BA-e-0912
38
Determine the reference unit
Ö If required, place a weighing container on the
weighing pan
Ö Press the F-key for about 4 seconds until
[U. SEt.] appears and then let go.
The reference quantity is displayed flashing.
The display e.g. 10 Pcs. prompts you to enter 10
pieces as reference.
U. SET.
Qn 1O
PCS
M
Change reference quantity
Ö Select the desired number of reference pieces by
pressing the TARE-key.
Important: The larger the reference quantity, the
more accurate the parts counting.
Original weighing of reference weight
Ö Place as many pieces to add-up as required by
the set reference piece number.
Ö Press F key
Qn 10
PCS
+
The balance offers the possibility of
reference optimisation. If you do not
want this, press F key.
Ö By adding more pieces (up to the 3-fold quantity),
you can optimise the reference. At every reference optimisation, the reference weight is calculated anew. As the additional pieces increase the
base for the calculation, the reference also becomes more exact.
Symbol [+] on the display indicates that you are
requested to add more parts.
Qn 28
PCS
+
10
5 30
100
AES/AEJ-BA-e-0912
39
How to save the reference
Ö Press the F-key to save the reference whereupon
the weighing scale automatically calculates an
average weight per part.
Remove reference weight. The balance is now in
parts counting mode and counts all units on the
weighing plate.
Qn 41
PCS
+
Count the items
Ö Place load on pan and read the number of
pieces.
100
PCS
Display change
Pressing the F-key repeatedly is a way to change the
display value, for instance to:
• Number of parts placed on balance "Pcs"
• Average part weight "g/Pcs"
• Weight of parts placed on balance in "g"
100
PCS
r02531
PCS
g
100.0000
g
AES/AEJ-BA-e-0912
40
Print
Ö The display value can be printed out by connecting an optional printer and press-
ing the PRINT-key, see chpt. 15 “printer mode”.
[ ] is displayed during printing.
Printout
• Number of parts placed
1 2
• Average part weight "g/Pcs"
3 4
• Weight of parts placed on balance in "g"
5 6 7
Display Description
SUB
3-fold quantity was exceeded during reference optimisation.
Either you accept the error and confirm by pressing the F-key or restart reference calculation.
ADD
The number of pieces placed is too small for a correct reference calculation.
Either you accept the error and confirm by pressing the F-key or you
add additional items.
L-ERR
Piece below minimum weight of piece (See chpt. 1 “Technical specifications“):
To interrupt a reference calculation, press the PRINT-key.
The reference weight will remain stored even after the weighing balance was
turned off until the reference is reset.
+199.996/7 G S
+9.999719 GUU
+0000020 PC S
1 PC Parts counting
2 S Stable value
3 GU
Average weight of parts
in gram
4 U Instable value
5 /
Auxiliary display
(verifiable models only)
6 G Weighing unit “gram”
7 S Stable value
AES/AEJ-BA-e-0912
41
11.3 Percent determination
Percentage calculation facilitates weight display in percent related to a reference
weight equivalent to 100 %.
11.3.1 Entering the reference weight by weighing
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Press the TARE-key repeatedly until menu item
“percentage calculation” appears.
Ö Confirm by pressing the S-key.
The balance is situated in the percent determining
mode.
0
%
How to determine a reference weight (100 %)
Ö If required, place a weighing container on the
weighing pan
Ö Press the F-key for about 4 seconds until
[P. SEt.] appears and then let go.
The most recently saved reference weight will be
displayed (flashing).
P. SET.
.
O 0000
g
M
Ö Put on reference weight (=100 %)
Ö Confirm by pressing the F-key. This completes
the determination of a reference weight.
Ö Remove reference weight
10z00
%
Percent determination
Ö Place goods to be weighed on balance.
The weight of the sample is displayed in percentage in terms of the reference weight.
8u37
%
AES/AEJ-BA-e-0912
42
Display change
Pressing the F-key repeatedly is a way to change the display value to [g] or [%] or
additional functions (see chpt. 11).
Print
Ö The display value can be printed out by connecting an optional printer and press-
ing the PRINT-key, see chpt. 15 “printer mode”.
[ ] is displayed during printing.
Printout
• Display value in [%]
1 2
• Display value in [g]
3 4 5
• Total in [%]
6 7
L-ERR
Reference weight < minimum weight = underload
1 %
Minimum load ≤ reference weight < minimum load x 10
0.1 %
Minimum load x 10 ≤ reference weight < minimum load x 100
0.01 %
Minimum load x 100 ≤ reference weight
Minimum load dependent on model, see chpt. 1 “Technical specifications“.
The reference weight (100 %) will remain stored even after the weighing balance was turned off until the reference is reset.
+00086.97 %TS
+199.996/7 G U
+00033.33 % S
1 % Percent determination
2 S Stable value
3 /
Auxiliary display
(verifiable models only)
4 G Weighing unit “gram”
5 U Instable value
6 T Sum
7 S Stable value
AES/AEJ-BA-e-0912
43
11.3.2 Numeric entering of the reference weight
Activate function
Ö See chpt. 11.3.1
0
%
How to determine a reference weight (100 %)
Ö If required, place a weighing container on the
weighing pan
Ö Press the F-key for about 4 seconds until
[P. SEt.] appears and then let go.
The most recently saved reference weight will be
displayed (flashing).
P. SET.
.
O 0000
g
M
Ö Enter reference weight (=100 %)
Each time the TARE-key is pressed, numbers will run
through from 0-9 and the decimal point.
⇒0⇒
0
1
⇒⇒⇒
≈
2
9
Select the number to be changed using F key (the
active position flashes):
Ö Save the reference weight by pressing the
S-key
or
cancel the entry by pressing the PRINT-key.
000z0000
g
012z0000
g
Percent determination
Ö Place goods to be weighed on balance.
The weight of the sample is displayed in percentage in terms of the reference weight.
8u37
%
Display change
Pressing the F-key repeatedly is a way to change the
display value, for instance to [g] or [%].
AES/AEJ-BA-e-0912
44
11.4 Weighing with freely programmable weighing unit
The weighing value in [g] will automatically be multiplied by the variable factor set
and the result will be displayed (showing unit #).
Example:
A sheet of paper of the size 10 x 10 cm weighs 0.6 g – the task is to determine the
weight/1m². For this purpose the factor needs to be set to 100.
From this follows a display value of 0.6 g x 100 = 60.0 #, that is 60 g/m².
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Press the TARE-key repeatedly until the menu
item “Weighing with freely programmable weighing unit” appears.
Ö Confirm by pressing the S-key.
0
#
Enter the factor for the weighing unit
Ö Press the F-key for about 4 seconds until
[C. SEt.] appears and then let go.
The most recently saved factor will be displayed
(flashing).
C.SET.
z000000
#
M
Ö To enter the factor, press the TARE-key; the en-
abled digit starts flashing.
Each time the TARE-key is pressed, numbers will
run through from 0-9 and the decimal point.
⇒0⇒
0
1
⇒⇒⇒
≈
2
9
Select the number to be changed using F key (the
active position flashes):
Save the factor by pressing the S-key
or cancel the entry by pressing
the PRINT-key.
z000000
#
M
000000r5
#
AES/AEJ-BA-e-0912
45
Weighing by applying factor
Place goods to be weighed on balance. The
weighing value in [g] will automatically be multiplied by the set factor, e. g.
Display value 250.000 #
= factor (2.5) x weighing value in ”g“ (100.000 g)
25z0000
#
Display change
Pressing the F-key repeatedly is a way to change the
display value to [g] or [#] or additional enabled functions (see chpt. 11).
25z0000
#
Ú
100.0000
g
Print
Ö The display value can be printed out by connecting an optional printer and press-
ing the PRINT-key, see chpt. 15 “printer mode”.
[ ] is displayed during printing.
Printout
• Display value in [#]
1 2
• Display value in [g]
3 4 5
Readability is automatically set to 1, 2 or 5 according to the factor set.
+050.000/5 G U
+0500.033 # S
1 % Variable factor for weighing unit
2 S Stable value
3 /
Auxiliary display (verifiable models
only)
4 G Weighing unit “gram”
5 U Instable value
AES/AEJ-BA-e-0912
46
11.5 Density determination of solids (hydrostatic weighing)
Density is the relationship of weight [g] : volume [cm3]. The weight is determined by
weighing the sample in air. The volume results from the ascending force [g] of the
sample dipped in a liquid. The density [g/cm3] of that liquid is known (principle of
Archimedes).
1. How to prepare the weighing balance
The density is determined with help of the underfloor
weighing device.
Prepare the balance as follows:
• Switch off the balance
• Remove the weighing pan and carefully turn
over the weighing balance.
• Screw-in hook for underfloor weighing (option)
• Place weighing balance over an opening.
• Attach sample holder (1)
• Fill measuring liquid (2) in a vessel e.g. beaker
and temper it.
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Press the TARE-key repeatedly until the menu
item “density determination solids” appears.
Ö Press and hold the F-key until the next menu item
appears that is used for selecting the auxiliary
liquid.
[ 0 ] : dest. Water
[ 1 ] :
Measuring your choice of liquid,
density of which is known
Ö Confirm by pressing the S-key.
0.0000
g
D
1 2
AES/AEJ-BA-e-0912
47
2. Input parameter auxiliary liquid
Was dest.water selected as measuring liquid [1q NED. 0] the water temperature is
input (input range 0.0 to 99.9°).
Ö Press and hold the TARE-key until the flashing
display used for entering water temperature appears.
Each time the TARE-key is pressed, numbers will
run through from 0-9 and the decimal point.
Select the number to be changed using F key (the
active position flashes):
Ö Confirm by pressing the S-key.
15.0
DT
0.0000
g
D
Defined as auxiliary liquid of your choice [1q NED. 1]its density is input (input
range 0.0001 to 9.9999 g/cm3).
Ö Press and hold the TARE-key until the flashing
display used for entering density appears.
Each time the TARE-key is pressed, numbers will
run through from 0-9 and the decimal point.
Select the number to be changed using F key
(the active position flashes):
Ö Confirm by pressing the S-key.
1.0000
D
0.0000
g
D
0⇒ 1⇒ 2～9
0⇒ 1⇒ 2～9
AES/AEJ-BA-e-0912
48
3. Density determination sample
After the parameter input for the measuring liquid, the density of your sample will be
determined
Weight of the sample in air
Tare sample holder by pressing the TARE-key.
0.0000
g
D
Ö Put-on sample
Wait until the weight display of the weighing balance has become stable and then press the S-
key. [
i
n
] is flashing, weight of "sample in air“ is
displayed.
[ W ] indicates that the weight of the “sample in
air“ has been saved.
21.4705
D
g
Weight of sample in auxiliary liquid
Immerse sample holder and tare by pressing the
TARE-key
AES/AEJ-BA-e-0912
49
Ö Place sample and immerse it
Make sure that the sample holder does not touch
the beaker.
Wait until the weight display of the weighing balance has become stable and then store by pressing the S-key.
The density of your sample is displayed, characterized by the X symbol right above.
13.5416
D
g
2.7004
D
(1) Display change
Repeated pressing of the F-key is a way to
change from [density of sample] to [volume of
sample].
2.7004
D
Ú
7.9513
D
(2) Back to weighing mode. When [density of
sample] appears on the screen, press the S-key.
Weight of sample is indicated.
To interrupt measuring, press the PRINT-key.
AES/AEJ-BA-e-0912
50
4. Data output in density determination mode
In density determination mode data output will take place after this was set in menu
item [13. A.Q.], regardless of the settings in menu item [ 71. Q.m. ], see chpt.
10.1.5.
The content of the data output is defined in menu item [12. D.Q.D. ].
For settings in menu see chpt. 10.
* 0
only output measuring value density
Data output
12. D.Q.D.
1
Output of all density parameters
* 0
OFF (Output only after pressing PRINT key)
Autom.
Data output
13. A.Q.
1
ON
Examples of data output
Printout
Menu settings
Auxiliary liquid water
Measuring liquid of your
selection
DENSI T Y SOLI D
2. 751
SAMPLE WEI GHT
21. 4705 g
TEMPERATURE NOW
15. 0 c
DENSI T Y SOLI D
2. 414
SAMPL E WEI GHT
30. 0023 g
DENSI T Y MED. L I Q
1. 325
VOLUME/ cm3
10. 2198
12. D.Q.D. 1
Output of all density
parameters
Output of all density
parameters
12. D.Q.D. 0
DENSI T Y L I QUI D
1. 2351
only output measuring value density
AES/AEJ-BA-e-0912
51
11.6 Adding of displayed values
This function can be used to automatically add any number of single weighings to a
total, such as single weighings of a batch.
The add-up function is available for the following functions:
• Weighing
• Parts counting
• Percent determination
• Weighing with freely programmable weighing unit
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Press the F-key and menu item [2 SEL] will
appear.
Ö Select the desired setting by pressing the TARE-
key
[1] : Add-up
[3] : Tolerance weighing /Add-up
Ö Press the F-key again
Ö Select the desired setting by pressing the TARE-
key
[ 1 ] : Add-up without AUTO-TARA
[ 2 ] : Adding with AUTO-TARA
Ö Confirm by pressing the S-key.
(*) indicates that weighing balance is in add-up
mode.
AES/AEJ-BA-e-0912
52
11.6.1 Add-up without AUTO-TARE
Menu setting [
26. AD.N. 1
]
Adding
1. Press the TARE-key and wait for zero to be dis-
played.
2. Deposit weight A
3. Wait until stability display [|] appears and then
press the S-key. The displayed value is added
into the total adding memory.
The total [ ∑ ] is briefly shown
0.0000
g
a
20.0000
g
4. Remove load
or
leave load on weighing pan and reset display to
zero by pressing the TARE-key.
5. Wait until the balance zero display is shown, then
place weight B on balance
30.0000
g
6. Wait until stability display [|] appears and then
press the S-key. The displayed value is added
into the total adding memory.
The total [ ∑ ] is briefly shown.
Remove weight and place further weights on balance; for each weight, repeat step
2 to 4
Display “total“
Ö Press the F-key repeatedly; total for all single
weighings will be displayed or switch-over to additional enabled functions will take place (see chpt.
11).
Delete total added memory
Ö Display total and then press the TARE-key.
Back to weighing mode / start new add-up
process.
Ö Press F key
AES/AEJ-BA-e-0912
53
11.6.2 Adding with AUTO-TARA
Menu setting [
26. AD.N. 2
]
Adding of displayed values is possible without removing the weight.
Implementation same as for add-up without AUTO-TARA (see chpt. 11.6.1).
Hereby omit step 4. The balance is automatically reset to zero, without taking away
the weight.
Print
Ö The display value can be printed out by connecting an optional printer and
pressing the PRINT-key, see chpt. 15 “printer mode”.
[ ] is displayed during printing.
Printout
• Single weighings A - C
1 2
• Sum
3 4 5 6
T-ERR
Display was not reset to zero after pressing the S-key.
*
You may add more load.
+069.226/9 GTU
+009.999/3 G S
+019.999/7 G S
+010.000/3 G S
1 G Weighing unit “gram”
2 S Stable value
3 /
Auxiliary display (verifiable models
only)
4 G Weighing unit “gram”
5 T Total of all individual weighings
AES/AEJ-BA-e-0912
54
11.7 Weighing with tolerance range
11.7.1 General
This balance can be used as dispensing as well as sorting balance; the respective
lower tolerance limit as well as upper tolerance limit can be programmed. An acoustic signal supports portioning, dispensing or sorting.
Tolerance weighing function in menu (see chpt. 10.1):
[2.SEL.2]
or activate the combination tolerance weighing/adding (tolerance control on
the respective poured quantity):
[2. SEL.3]
Entering limits is possible for the following functions:
• Weighing
• Parts counting
• Percent determination
• Weighing with freely programmable weighing unit
There are two different ways to carry out evaluation of limits:
1. Evaluation of absolute values [24. TXP.1]:
An exact reference value (e.g. 1 kg) is set.
2. Evaluation with difference values [24. TXP.2]:
An upper limit and a lower limit for a reference value are set.
Example:
Reference value Lower limit Upper limit
Poured quantity 100.0000 g 97.0000 g 105.0000 g
Evaluation of absolute
values
100.0000 g 97.0000 g 105.0000 g
Evaluation with
difference values
100.0000 g -3.0000 g 5.0000 g
AES/AEJ-BA-e-0912
55
There are two different ways to set the tolerance limits:
1. By weighing, that is by placing item on weighing balance and saving this
value.
2. Numeric entry of values via keyboard
• If a limiting value was set it remains saved until the balance is turned off.
• For the functions weighing, counting, percent individual limits can be set.
• When entering limits, pay particular attention to the type of classification
set (absolute/differential values).
11.7.2 Display of the results
The triangular tolerance marker ( ) in the display of the display shows whether the
goods to be weighed are within the two tolerance limits.
The tolerance marker is only in operation during operating mode tolerance weighing; it is otherwise not visible.
The tolerance marker provides the following information:
Goods to be weighed above tolerance limit
Goods to be weighed within tolerance range
Goods to be weighed below tolerance limit
Bar graph display:
Lower limit < Weight
Lower limit ≤ Weight ≤ Upper limit
Weight < Lower limit
AES/AEJ-BA-e-0912
56
Upper tolerance limit
Within tolerance range
Lower tolerance limit
Limit 5
Limit 4
Limit 3
Limit 2
Limit 1
Display tolerance tag at 1-2 limiting points:
Grading If a point is set as lower
limit
If two points are set as
upper and lower limit
Goods to be weighed
above tolerance limit
No display Upper limit < weight
Goods to be weighed
within tolerance range
Lower limit ≤ Weight
Lower limit ≤Weight ≤
Upper limit
Goods to be weighed below tolerance limit
Weight < lower limit Weight < lower limit
Display tolerance tag at 3-4 limiting points:
Limit 5
4. Limiting point ≤ weight
Limit 4
3. Limiting point ≤ weight < 4th limiting point
Limit 3
2. Limiting point ≤ weight < 3th limiting point
Limit 2
1. Limiting point ≤ weight < 2nd limiting point
Limit 1 Weight < 1st limiting point
AES/AEJ-BA-e-0912
57
11.7.3 Enable function / settings in menu
Activate function
Ö In weighing mode keep the F-key pressed down
until [FWnm] appears on the display. Release button. The first menu item showing the current setting will be displayed.
Fonm
Ö Press the F-key and menu item [2 SEL] will
appear.
Ö Select the desired setting by pressing the TARE-
key
[2] : Tolerance weighing
[ 3 ]: Tolerance weighing /Add-up
Select menu item “settings“
Ö Press the F-key again
Ö Press the TARE-key to select the desired setting,
see chpt. 10.1.4. From then on additional settings
can be selected each time the F-key is pressed.
The first menu item for setting
the tolerance marker appears.
How to change settings
Ö Select the desired setting by pressing the TARE-
key, see chpt. 10.1.4.
Ö Confirm by pressing the S-key.
How to save settings / how to exit the menu
Ö Press the S-key
Weighing balance is in tolerance mode, the triangular tolerance tags are faded in.
0.0000
g
AES/AEJ-BA-e-0912
58
11.7.4 Tolerance control for absolute values
• Entering 2 limits by weighing
1. How to enable the tolerance weighing function
[2.SEL.2] or [2.SEL.3], see chpt. 11.7.3.
2. For settings in menu see chpt. 11.7.3.
Setting for 2 limiting values:
Setting for absolute value:
3. How to save settings / how to exit the menu
Ö Press the S-key
Weighing balance is in tolerance mode, the triangular tolerance tags are faded in.
0.0000
g
4. Entering limiting values:
Ö Press the S-key for about 4 seconds until
[L. SET.] appears and then let go. The most re-
cently saved lower limit will be displayed (flashing).
L. SET
0.0000
g
M
AES/AEJ-BA-e-0912
59
5. Place sample for the lower (i.e. smaller) limiting
value on the weighing plate:
6. Save by pressing the F-key. The lower limit will
briefly be faded in, followed by [H. SET] (This
completes the entry provided only one limit is set
for tolerance control – menu setting [23. P1.1])
H. SET
1
7. Wait until the display starts flashing and the most
recently upper limit is displayed. Place sample for
the upper (i.e. larger) limiting value on the weighing plate.
0.0000
g
M
8. Save by pressing the F-key.
The upper limit will be faded in and the weighing balance returns to tolerance weighing mode.
Remove sample. From here evaluation takes place
whether the goods to be weighed are within the two
tolerance limits.
0.0000
g
Display change
Pressing the F-key repeatedly is a way to change the display value to additional enabled functions.
AES/AEJ-BA-e-0912
60
Print
Ö The display value can be printed out by connecting an optional printer and press-
ing the PRINT-key, see chpt. 15 “printer mode”.
[ ] is displayed during printing.
Printout
• Goods to be weighed within tolerance range
1 2 3 4
• Goods to be weighed below tolerance limit
1 2 5 4
• Goods to be weighed above tolerance limit
1 2 6 4
• Entering 3 or 4 limits by weighing
Menu setting [23. P1. 3] or [23. P1. 4].
For setting of limits proceed as for entry of 2 limits. Instead of [L. SET] and [H. SET]
appears [L1. SET] - [L3. SET] or [L4. SET]. For this purpose repeat step 2 and 3 in
each case.
Display of tolerance mark:
L2. SET
LK. SET
L4. SE
T
L3. SE
T
+011.217/6 GHS
+009.217/9 GLS
+010.217/7 GGS
1 /
Auxiliary display
(verifiable models only)
2 G Weighing unit “gram”
3 G
Goods to be weighed
within tolerance range
4 S Stable value
5 L
Goods to be weighed
below tolerance limit
6 H
Goods to be weighed
above tolerance limit
AES/AEJ-BA-e-0912
61
• Numeric entering of 2 limits
Example:
Lower limit Upper limit
Weight value 97.0000g 105.0000 g
Input 97.0000g 105.0000 g
1. How to enable the tolerance weighing function
[2.SEL.2] or [2.SEL.3], see chpt. 11.7.3.
2. For settings in menu see chpt. 11.7.3.
Setting for 2 limiting values:
Setting for absolute value:
3. How to save settings / how to exit the menu
Ö Press the S-key
Weighing balance is in tolerance mode, the triangular tolerance tags are faded in.
0.0000
g
4. Entering limiting values:
Ö Press the S-key for about 4 seconds until
[L. SET] appears and then let go.
The most recently saved lower limit will be
displayed (flashing).
L. SET
0.0000
g
M
AES/AEJ-BA-e-0912
62
5. Press and hold the TARE-key until the display
used for entering the limit appears.
Each time the TARE-key is pressed, numbers will
run through from 0-9 and the decimal point.
⇒0⇒
0
1
⇒⇒⇒
≈
2
9
Select the number to be changed using F key (the
active position flashes):
6. Save by pressing the S-key. The lower limit will
briefly be faded in, followed by [H. SET] (This
completes the entry provided only one limit is set
for tolerance control – menu setting [23. P1.1])
H. SET
1
7. Wait until the display starts flashing and the most
recently upper limit is displayed. Enter upper limit
by repeating 5-6.
0.0000
g
M
8. Save by pressing the S-key.
The upper limit will briefly be faded in and the weighing balance returns to tolerance weighing mode.
Remove sample. From here evaluation takes place
whether the goods to be weighed are within the two
tolerance limits.
0.0000
g
• Numeric entry of 3 or 4 limits
Menu setting [23. P
1. 3] or [23. P1. 4].
For numeric entry of limits proceed as for entry of 2 limits. Instead of [L. SET] and
[H. SET] appears [L1. SET] - [L3. SET] or [L4. SET]. For this purpose repeat step 5
to 7 in each case.
AES/AEJ-BA-e-0912
63
11.7.5 Tolerance control for differential values
• Entering 2 limits by weighing
1. How to enable the tolerance weighing function
[2.SEL.2] or [2.SEL.3], see chpt. 11.7.3.
2. For settings in menu see chpt. 11.7.3.
Setting for 2 limiting values:
Setting for differential value:
3. How to save settings / how to exit the menu
Ö Press the S-key
Weighing balance is in tolerance mode, the triangular tolerance tags are faded in.
0.0000
g
4. How to set reference weight and limits:
Ö Press the S-key for about 4 seconds until
[r. SET.] appears and then let go. The most re-
cently saved reference weight will be displayed
(flashing).
z0000
g
M
AES/AEJ-BA-e-0912
64
5. Place the sample used to determine the reference
weight on the weighing pan.
6. Save by pressing the F-key. The reference weight
will briefly be faded in, followed by [L. SET].
7. Wait until the display starts flashing and the most
recently stored value is displayed.
L. SET
0.0000
g
M
9. Place sample for the lower (i.e. smaller) limiting
value on the weighing plate:
10. Save by pressing the F-key. The difference “reference weight – lower limit“ will briefly be faded in,
followed by [H. SET].
H. SET
1
11. Wait until the display starts flashing and the most
recently upper limit is displayed. Place sample for
the upper (i.e. larger) limiting value on the weighing plate:
0.0000
g
M
12. Save by pressing the F-key. The difference “reference weight – upper limit“ will briefly be faded
in, followed by the weight value of the sample.
The balance returns to tolerance weighing mode.
Remove sample. From here evaluation takes place
whether the goods to be weighed are within the two
tolerance limits.
0.0000
g
• Entering 3 or 4 limits by weighing
Menu setting [23. P1. 3] or [23. P1. 4].
For setting of limits proceed as for entry of 2 limits. Instead of [L. SET] and [H. SET]
appears [L1. SET] - [L3. SET] or [L4. SET]. For this purpose repeat step 5 to 7 in
each case.
Display of tolerance mark:
AES/AEJ-BA-e-0912
65
• Numeric entering of 2 limits
Example:
Reference weight Lower limit Upper limit
Weight value 100.0000 g 97.0000 g 105.0000 g
Input 100.0000 g -3.0000 g 5.0000 g
1. How to enable the tolerance weighing function
[2.SEL.2] or [2.SEL.3], see chpt. 11.7.3.
2. For settings in menu see chpt. 11.7.3.
Setting for 2 limiting values:
Setting for differential value:
3. How to save settings / how to exit the menu
Ö Press the S-key
Weighing balance is in tolerance mode, the triangular tolerance tags are faded in.
0.0000
g
4. How to set reference weight and limits:
Ö Press the S-key for about 4 seconds until
[r. SET.] appears and then let go. The most re-
cently saved reference weight will be displayed
(flashing).
z0000
g
M
AES/AEJ-BA-e-0912
66
5. Press and hold the TARE-key until the display
used for entering the reference weight appears.
Each time the TARE-key is pressed, numbers will
run through from 0-9 and the decimal point.
⇒0⇒
0
1
⇒⇒⇒
≈
2
9
Select the number to be changed using F key (the
active position flashes):
8. Confirm by pressing the S-key.
The reference weight will briefly be faded in, fol-
lowed by [L. SET].
L. SET
6. Wait until the display starts flashing and the most
recently stored value is displayed.
Enter difference “reference weight – lower limit“
as described in step 5.
7. Confirm by pressing the S-key.
The value will briefly be faded in, followed by [H.
SET].
(This completes the entry provided only one limit
is set for tolerance control – menu setting
[23. P1.1] ).
H. SET
1
8. Wait until the display starts flashing and the most
recently stored value is displayed.
Enter difference “reference weight – upper limit“
as described in step 5.
9. Save by pressing the S-key.
The balance returns to tolerance weighing mode.
Remove sample. From here evaluation takes place
whether the goods to be weighed are within the two
tolerance limits.
0.0000
g
• Numeric entry of 3 or 4 limits
Menu setting [23. P1. 3] or [23. P1. 4].
For numeric entry of limits proceed as for entry of 2 limits. Instead of [L. SET] and
[H. SET] appears [L1. SET] - [L3. SET] or [L4. SET]. For this purpose repeat step 5
to 7 in each case.
AES/AEJ-BA-e-0912
67
12 How to set date/time
12.1 Time
Invoke time
Ö Press and hold the F-key in weighing mode until
[FWnm] followed by [D-SET] appears.
Fonm
Ö Press the F-key again; most recently saved time
will appear.
15 OO OO
::
L
How to change time
Ö Press the S-key. Press the TARE-key to change
the numeric value. Press the F-key to select the
digit (enabled digit is flashing each time). Press
the PRINT-key to cancel your entry.
15 OO OO
::
L
How to save time settings
Ö Press the S-key; date display appears. For
change of settings, see chapter 12.2 below.
1OO87-1 -
L
Return to weighing mode
Ö Press F key
Output of time adjustable in menu item [
qT.Q
.
H
], see chpt. 10.1.2.
AES/AEJ-BA-e-0912
68
12.2 Date
Invoke time
Ö Press and hold the F-key in weighing mode until
[FWnm] followed by [D-SET] appears.
Fonm
Ö Press the F-key repeatedly.
1OO87-1 -
L
Change date
Ö Press the S-key. Press the TARE-key to change
the numeric value. Press the F-key to select the
digit (enabled digit is flashing each time). Press
the PRINT-key to cancel your entry.
1OO87-1 -
L
Save date
Ö Press the S-key; balance will automatically return
to weighing mode.
Output format of time adjustable in menu item [
G. DATE
], see chpt. 10.1.2.
AES/AEJ-BA-e-0912
69
13 Description of individual menu items
13.1 Automatic cut-off of display backlight
(Auto backlight OFF)
Menu item: [
B. A
B
] see chpt. 10.1.2
To save battery when function is enabled backlight of display will automatically
switch off after 3 minutes during which there was no change of load or activity.
13.2 How to change weighing units
Menu item: [
Cq W.A
] and [
Cs W.
B
] see chpt. 10.1.2.
This setting can be used to set different display units (A or B) for a weighing value.
Use the F-key to choose between units A and B.
• “Units A“ are available in all operating modes.
• “Units B“ are only available in weighing mode [
qSET1
].
13.3 How to change readability (models AES only)
Menu item: [ ] and [
] see chpt. 10.1.2.
This function is used to change readability for weighing unit A or B. The last decimal
place will be rounded or removed from the display.
Example for weighing unit [ g ] :
Function 1
Readability
Reaction to ambient conditions
1 0.0001 g sensitive
2 0.0002 g
3 0.0005 g
4 0.001 g
Menu settings
5 0.002 g insensitive
AES/AEJ-BA-e-0912
70
13.4 Save tare value automatically (models AES only)
Menu item: [ ] see chpt. 10.1.2
Last tare value will be saved if function is enabled.
After turning off/on the weighing balance will continue working with the saved tare
value.
13.5 Instant start
Menu item: [
n. D.ST
.
] see chpt. 10.1.2
If this function is enabled, the weighing balance will automatically start when the line
adapter is connected without having to press the ON/OFF-key.
13.6 Interval output function
Menu item: [
7q Q.m.
A
] and [
7q Q.m B
.
] see chpt. 10.1.5.
This menu item is used to define after which interval data output must take place.
Call function
Ö In weighing mode keep the S-key pressed until
[
KnT.VAL
] appears.
Time to be changed is flashing
KnT.VAL
00 0O O5
::
AES/AEJ-BA-e-0912
71
How to change settings
Ö Press the TARE-key to change the numeric value.
Press the F-key to select the digit (enabled digit is
flashing each time). Press the PRINT-key to cancel your entry.
Save setting
Ö Press the S-key; balance will automatically return
to weighing mode.
Start interval output
Ö Press the PRINT-key
[
L
] flashing between output
[ ] flashing during output
START
10.0000
g
L
Stop interval output
Ö Press the PRINT-key; balance will automatically
return to weighing mode.
EnD
• Error message [
6-ER
R
] appears for invalid entries,
such as interval = 0
• When menu item [
qT.Q
.
H
] is enabled, see chpt. 10.2 interval output will
take place showing current time.
⇒ 0⇒ 1⇒ 2～9⇒
AES/AEJ-BA-e-0912
72
13.7 How to enter ID number for weighing balance
The weighing balance ID number set in this menu item will be issued during
ISO/GLP/GMP printouts.
Display symbol [ W ] and [ S ]
You may enter a 6-digit number ranging from [0-9], [A-F], [ - ] and blank char-
acters [ _ ].
Call function
Ö Go to menu 2 and invoke menu item
[
q1D
1
], see chpt. 10.2.1.
q1D1
Ö Press the F-key, current ID No. will appear.
Ö Press the TARE-key, changed digit will start
flashing.
How to change settings
Ö Press the TARE-key to change the numeric value.
Press the F-key to select the digit (enabled digit is
flashing each time). Press the PRINT-key to cancel your entry.
Save setting
Ö Press the S-key, current menu item will appear.
Ö Press the S-key again; balance will automatically
return to weighing mode.
AES/AEJ-BA-e-0912
73
14 Data output
The regular equipment of the balance includes an RS 232C interface and a printer
interface.
14.1 RS 232C interface
The RS 232C interface allows a bi-directional data exchange from the balance to
external devices. This data exchange is asynchronous using ASCII - Code.
Pin allocation of balance output plug:
Pin nr. Signal Input/Output Function
1 -
2 RXD Input Receive data
3 TXD Output Transmit data
4 DTR Output HIGH
5 GND - Signal ground
6 - -
7 - -
8 - -
9 - -
AES/AEJ-BA-e-0912
74
PC
D-SUB9P
Balance
D-SUB9P
PC
D-SUB25P
Balance
D-SUB25P
Interface cable:
• Balance – PC 9-pole
• Balance – PC 25-pole
TXD
RX
GN
DC
RTS
CTS
DS
DTR
RX
TXD
GN
3
2
5
1
7
8
6
4
2
3
5
TXD
RXD
GND
DCD
RTS
CTS
DSR
DTR
RXD
TXD
GND
5
3
2
5
20
7
8
6
4
2
3
AES/AEJ-BA-e-0912
75
Technical Data
1. Transmission system Serial/start-stop synchronous
2. Baud rate 1200/2400/4800/9600/19200 bps
3. Transmission code ASCII codes (8/7 bits)
4. Signal HIGH level (data logic 0) +5 to +15 V
LOW level (data logic 1) -5 to -15 V
Start bit 1 bit
Data bits 8/7 bits
Parity bit 0/1 bit
5. Bit setting
Stop bits 2/1 bit
6. Parity None/Odd/Even
Example: 8 Data bits/2 Stop bits
LSB
MSB
Logic
“1”
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12)
Logic
“0”
Data bit
Start bit Parity bit
Stop bit
AES/AEJ-BA-e-0912
76
14.2 Printer interface (unidirectional data exchange)
Pin allocation of balance output plug:
Pin nr. Signal Input/Output Function
1 EXT.TARE Input External tare function
2 -
3 -
4 TXD Output Transmit data
5 GND - Signal ground
6 - -
7 - -
8 - -
14.3 Description of interface
The selection of a certain operating mode allows you to set the output format, the
output control, the transmission speed and the parity bit. The different options are
described in chpt. 10.1.5 under "parameter for serial interface".
1
2
3
4
5
6
7
8
AES/AEJ-BA-e-0912
77
14.4 Data output
14.4.1 Format for data transmission
You may customise the format of data transmission according to your requirements
(7-digit data format / extended 7-digit data format). See menu overview chpt. 10.2.
Setting ex-works:
7-digit data format, consisting of 16 characters, including terminator; CR=0DH,
LF=0AH (CR=weighing balance reverse / LF=vertical spacing). A parity bit can
be appended. The oblique “/” is printed just before the last digit.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
P1 D1 D2 D3 D4 D5 D6 D7 D8 D9 U1 U2 S1 S2 CR LF
14.4.2 Signs
P 1 = 1 word
P 1
Code Significance
+ 2 B H Data is 0 or positive
- 2 D H Data is negative
14.4.3 Numeric data
D 1 to D 8 8 words with 7-digit format
D 1 bis D 8
Code Significance
0 - 9 30 H – 39 H Data 0 to 9
2 EH Decimal point, position not fixed
Sp 20 H Space character, leading cero suppressed
AES/AEJ-BA-e-0912
78
14.4.4 Units
U 1, U 2 = 2 characters
U1 U2 ASCII code Significance Display
M G 4DH 47H Milligram mg
(SP) G 20H 47H
Gramm
g
C T 43H 54H
Carat
O Z 4FH 5AH
Ounce
L B 4CH 42H Pound
O T 4FH 54H Troy ounce
D W 44H 57H Pennyweight
G R 4BH 52H Grain GN
T L 54H 4CH Tael (Hong Kong)
T L 54H 4CH
Tael (Singapore,
Malaysia)
Top right
T L 54H 4CH Tael (Taiwan)
Bottom right
M O 4DH 4FH Momme mom
t o 74H 6FH Tola
P C 50H 43H Parts counting Pcs
(SP) % 20H 25H
Percent determina-
tion
%
(SP) # 20H 23H
Freely programma-
ble weighing unit
#
AES/AEJ-BA-e-0912
79
14.4.5 Output weighing data in operating mode
S 1 = 1 word
S1 Code Significance
L 4CH Goods to be weighed below tolerance limit
G 47H Goods to be weighed within tolerance range
H 48H Goods to be weighed above tolerance limit
1- or 2 end points
1 31H Limit 1
2 32H Limit 2
3 33H Limit 3
4 34H Limit 4
5 35H Limit 5
3- or 4 end points
T 54H Total (add-up)
U 55H
Average piece weight (piece counting /
weight value (weighing)
(SP) 20H No rating
d 64H Gross
File Type
14.4.6 Data status
S 2 = 1 word
S 2 Code Significance
S 53 H Data stabilized *
U 55 H Data not stabilized (fluctuating) *
E 45 H Data error, all data apart from S 2 not allowed.
Balance indicating error (o-Err, u-Err)
sp 20 H No special status
14.4.7 Interval data output
When an interval output is started or stopped, this will result in the output of a
header or footer line.
Header
consisting of 15 characters (CR=0DH, LF=0AH)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
- - - - - - - - - - - - - - -
Footers
Two line feeds are inserted.
AES/AEJ-BA-e-0912
80
14.4.8 Output time
1 2 3 4 5 6 7 8
h h : m m : s s
* hh: Hours (00-23), mm: Minutes (00-59) min: Seconds (00-59) s:
14.5 Input commands
14.5.1 Feedback
The format for the feedback can be set under menu item [
7w RE
S
].
(1) [A00/Exx Format]
Menu item [
7w RES
1
]
Consisting of 5 characters including the terminators (CR, LF).
1 2 3 4 5
A1 A2 A3 CR LF
A1 A2 A3 ASCII code
A 0 0 41H 30H 30H Free from error
E 0 1 45H 30H 31H Error message
E 0〜9 0〜9 45H
30H
39H
30H
39H
Additional error deviant E01
(2) ACK/NAK Format
Menu item [
7w RES
2
]
Consisting of 1 character, without terminator.
1
A1
A1 ASCII code
ACK 06H Free from error
NAK 15H Error message
AES/AEJ-BA-e-0912
81
14.5.2 External tare command
C1 C2 ASCII code Description Value Feedback
T (SP) 54H 20H
y Taring
y Zeroing
None
A00: Execution successful
E01: Error
E04: Taring / zero not possible, admissible
range exceeded.
14.5.3 Remote control instructions
* Do not operate the PRINT-key whilst using these remote control commands
(would interrupt data transmission). If data transmission is interrupted disconnect
weighing balance briefly from mains.
C1 C2 Code Significance Feedback
O 0 4FH 30H No data output
O 1 4FH 31H Continuous data output
O 2 4FH 32H
Continuous data output stable weighing
values
O 3 4FH 33H
Output for stable and instable weighing
values after pressing PRINT key
A00: Free from
error
O 4 4FH 34H
Output for stable weighing value after
previous relief of balance
E01: Error mes-
sage
O 5 4FH 35H
One output for stable weighing value. No
output for stable weighing values. Renewed output after stabilization
E02: Interval
error
(OA or OB
only)
O 6 4FH 36H
One output for stable weighing value.
Continuous output for instable weighing
values.
O 7 4FH 37H
Output of stable weighing values after
pressing PRINT key
O 8 4FH 38H Single immediate output*
O 9 4FH 39H Single output after stabilization*
O A 4FH 41H
Single immediate output after a determined interval*
O B 4FH 42H
Single immediate output after a determined interval and a stable weighing
value*
AES/AEJ-BA-e-0912
82
Remarks:
• The performance delivered by the output control via the commands “O0~O7” or
setting the weighing balance functions is the same.
• Models “O8 and O9“ are specifically designed for input commands.
• Once a command of "O0~O9” has been executed its status will remain enabled
until the next command is given. However, after turning off the weighing balance
output control returns to initial setting.
15 Printer mode
The following conditions must be met to provide successful communication between
the weighing balance and the printer.
• Use a suitable cable to connect the weighing balance to the interface of the
printer. Faultless operation requires an adequate KERN interface cable.
• Communication parameters (Baudrate, bits and parity) of weighing balance
and printer have to match, see chpt. 10.1.5 “Settings for serial interface”.
15.1 How to issue an adjustment protocol
For menu settings [
] and [
Fq QoT
1
], see chpt. 10.1
An adjustment protocol is issued after completing an adjustment/adjustment test.
For sample protocols see chpt. 15.3.
AES/AEJ-BA-e-0912
83
15.2 ISO/GLP/GMP – compliant output for weighing data
Quality assurance systems require printouts of weighing results as well as of correct
adjustment of the balance stating date and time and balance identification. The
easiest way is to have a printer connected.
1. For menu setting
[
] and [ ], see chpt. 10.1
2. Output header prior to weighing.
Keep PRINT-key pressed until
[ ] appears.
3. Output weighing data via PRINT-
key. For details see chpt. 15.3.
4. Output footer.
Keep PRINT-key pressed until
[ ] appears.
Do not press any key during data output [ ].
END
DATE: 28.19.2008
TIME: 16:17
SIGNATURE
*****************************
GOTTL. KERN & SOHN
TPYE:
AEJ220-4M
S/N 081853001
ID
START
DATE: 28.19.2008
TIME: 16:16
+050.005/8 G U
AES/AEJ-BA-e-0912
84
1 2 3
1 2 3 4
15.3 Printout examples
• Standard printout “weighing data“
1. „/“ Tag auxiliary display (verifiable models only)
2. „G“ Weighing unit “gram” (For display of additional units see chpt. 14.4.4)
3. “U” unstable
1. „/“ Tag auxiliary display
2. „G“ Weighing unit “carat”
3. “d” Gross
4. “S” stable
+100.005/8 CT d S
+050.005/8 G U
AES/AEJ-BA-e-0912
85
• ISO/GLP/GMP – compliant adjustment protocols
“Adjustment with internal weight” Adjustment with external weight
“Adjustment test with internal weight” Adjustment test with external weight
**
CAL.TEST
***************
DATE: 28.19.2008
TIME: 16:16
GOTTL. KERN & SOHN
TPYE:
AES120-4M
S/N 081873001
ID
1214 A
CAL.EXT.TEST
REF:
100.0000 g
DIFF:
-000.0007 g
COMPLETE
DATE: 28.19.2008
TIME: 16:17
SIGNATURE
**
CAL.TEST
****************
DATE: 28.19.2008
TIME: 16:16
GOTTL. KERN & SOHN
TPYE:
AEJ220-4M
S/N 081853001
ID
101
CAL.INT.TEST
REF:
220.000[0] g
DIFF:
-000.041[3] g
COMPLETE
DATE:
28.19.2008
TIME: 16:17
SIGNATURE
*****************************
**
CALIBRATION
***********
DATE: 28.19.2008
TIME: 16:16
GOTTL. KERN & SOHN
TPYE:
AES120-4M
S/N 081873001
ID
1214 A
CAL.EXTERNAL
REF:
100.0000 g
COMPLETE
DATE: 28.19.2008
TIME: 16:17
SIGNATURE
*****************************
**
CALIBRATION
***********
DATE: 28.19.2008
TIME: 16:16
GOTTL. KERN & SOHN
TPYE:
AEJ220-4M
S/N 081853001
ID
101
CAL.INTERNAL
REF:
220.000[0] g
COMPLETE
DATE:
28.19.2008
TIME: 16:17
SIGNATURE
*****************************
AES/AEJ-BA-e-0912
86
16 Service, maintenance, disposal
16.1 Cleaning
Before cleaning, please disconnect the appliance from the operating voltage.
Please do not use aggressive cleaning agents (solvents or similar agents), but a
cloth dampened with mild soap suds. Ensure that no liquid penetrates into the device and wipe with a dry soft cloth.
Loose residue sample/powder can be removed carefully with a brush or manual
vacuum cleaner.
Spilled weighing goods must be removed immediately.
16.2 Service, maintenance
The appliance may only be opened by trained service technicians who are authorized by KERN.
Before opening, disconnect from power supply.
16.3 Disposal
Disposal of packaging and appliance must be carried out by operator according to
valid national or regional law of the location where the appliance is used.
AES/AEJ-BA-e-0912
87
17 Error messages, troubleshooting guide
In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning.
Fault Possible cause
• The balance is not switched on.
• The mains supply connection has been interrupted
(mains cable not plugged in/faulty).
The displayed weight does
not glow.
• Power supply interrupted.
• Draught/air movement
• Table/floor vibrations
The displayed weight is
permanently changing
• The weighing plate is in contact with foreign matter.
• Electromagnetic fields / static charging
(choose different location/switch off interfering device if possible)
• The display of the balance is not at zero
• Adjustment is no longer correct.
The weighing result is obviously incorrect
• Great fluctuations in temperature.
Electromagnetic fields / static charging (choose
different location/switch off interfering device if possible)
Error message Possible cause
o-Err
• Weighing range exceeded
u-Err
• Insufficient preload, e. g. missing weighing pan
b-Err
• Check ambient conditions (draught, vibrations etc.)
d-Err
• Damaged electronics
A-Err
• Internal adjustment automatics defective
Should other error messages occur, switch balance off and then on again. If the
error message remains inform dealer.
Loading...
