before using your Kenwood appliance
●
Read these instructions carefully and retain for future reference.
●
Remove all packaging and any labels.
safety
●
The blades and discs are very sharp, handle
with care. Always hold the knife blade by
the finger grip at the top, away
from the cutting edge, both when
handling and cleaning.
●
Do not lift or carry the processor by the handle - or the handle
may break resulting in injury.
●
Always remove the knife blade before pouring contents from the
bowl.
●
Keep hands and utensils out of the processor bowl and liquidiser
jug whilst connected to the power supply.
●
Switch off and unplug:
●●
before fitting or removing parts
●●
after use
●●
before cleaning
●
Never use your fingers to push food down the feed tube. Always
use the pusher/s supplied.
●
Before removing the lid from the bowl or liquidiser/mill from the
power unit:-
●●
switch off;
●●
wait until the attachment/blades have completely stopped;
●●
be careful not to unscrew the liquidiser jug or mill from the
blade unit.
●
Allow all liquids to cool to room temperature before placing them
in the liquidiser.
●
Do not use the lid to operate the processor, always use the on/off
speed control.
●
This machine will be damaged and may cause injury
if the interlock mechanism is subjected to excessive
force.
●
Never use an unauthorised attachment.
●
Never leave the machine on unattended.
●
Never use a damaged machine. Get it checked or repaired: see
‘service’.
●
Never let the power unit, cord or plug get wet.
●
Don’t let excess cord hang over the edge of a table or worktop
or touch hot surfaces.
●
Never misuse your food processor and only use it for its
intended domestic use.
●
Do not exceed the maximum capacities stated.
●
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
●
Children should be supervised to ensure that they do not play
with the appliance.
●
Only use the appliance for its intended domestic use. Kenwood
will not accept any liability if the appliance is subject to improper
use, or failure to comply with these instructions.
●
Misuse of your processor/liquidiser can result in injury.
before plugging in
●
Make sure your electricity supply is the same as the one shown
on the underside of your machine.
Important – UK only
●
The wires in the cord are coloured as follows:
Green and Yellow = Earth,
Blue = Neutral,
Brown = Live.
●
The appliance must be protected by a 13A approved (BS1362)
fuse.
●
WARNING: THIS APPLIANCE MUST BE EARTHED.
Note:
●
For non-rewireable plugs the fuse cover MUST be refitted when
replacing the fuse. If the fuse cover is lost then the plug must not
be used until a replacement can be obtained. The correct fuse
cover is identified by colour and a replacement may be obtained
from your Kenwood Authorised Repairer (see Service).
●
If a non-rewireable plug is cut off it must be DESTROYED
IMMEDIATELY. An electric shock hazard may arise if an
unwanted non-rewireable pug is inadvertently inserted into a 13A
socket outlet.
●
This appliance conforms to EC directive 2004/108/EC on
Electromagnetic Compatibility and EC regulation no. 1935/2004
of 27/10/2004 on materials intended for contact with food.
before using for the first time
1 Remove all packaging including the plastic blade covers from the
knife blade. Take care the blades are very sharp. These
covers should be discarded as they are to protect the blade
during manufacture and transit only.
2Wash the parts see ‘cleaning’
3 Push excess cord into the back of the machine.
key
processor
power unit
detachable drive shaft
bowl
lid
feed tube
pushers
safety interlocks
cord storage
speed control with power on light
weighing function
on/zero button
display screen
kg/lb button
weighing plate
liquidiser
filler cap
lid
lid seal
jug
sealing ring
blade unit
2
3
choosing a speed for all functions
Tool/Attachment Function Speed Maximum Capacities
Knife Blade One Stage Cake Mix Min – Max 1.5Kg/3lb 5oz Total Wt
Pastry - rubbing fat into flour 5 – Max 340g/12oz Flour Wt
Adding water to combine pastry ingredients 1 – 5
Chopping/pureeing/pates Max 600g/1lb 6oz Meat
Knife Blade with maxi-blend canopy Soups – start at a low speed and move up to Max Min –Max 1.5 litres/2pts 12oz
Whisk Egg Whites Max 6 Egg Whites
Egg & sugar for fatless sponges Max
Cream 5 – Max 500 mls
Dough tool Yeasted mixes Max 600g/1lb 6oz
Discs – slicing/shredding/chipping Firm food items such as carrots, hard cheese. 5 – Max
Softer items such as cucumbers, tomatoes Min – 5
Rasping disc Parmesan cheese, Potatoes for German Max
potato dumplings.
Citrus Press Citrus fruits 1
Mini Bowl & knife All processing Max 200g/8oz
Liquidiser All processing Max 1.5 litres/2pts 12fl.oz
Mill All processing Max
Centrifugal juicer Fruit & Vegetables Max 500g/1lb oz
attachments
knife blade
dough tool
twin beater geared metal whisk
maxi-blend canopy
thick slicing/coarse shredding disc
thin slicing/fine shredding disc
fine (Julienne style) chipper disc
rasping disc
geared citrus press
mill
mini processor bowl
centrifugal juicer
KENSTORE™ attachments carousel
recipe book
spatula
to use your food processor
1 Fit the detachable shaft onto the power unit .
2 Then fit the bowl. Place the handle towards the back and turn
clockwise until it locks .
3Fit an attachment over the drive shaft.
●
Always fit the bowl and attachment onto the machine before
adding ingredients.
4 Fit the lid - ensuring the top of the drive shaft locates into the
centre of the lid.
●
Do not use the lid to operate the processor, always
use the on/off control.
5 Plug in and the power on light will come on. Switch on and select
a speed.
●
The processor won’t work if the bowl and lid are fitted
incorrectly.
●
Use the pulse (P) for short bursts. The pulse will operate for as
long as the control is held in position.
6 Reverse the above procedure to remove the lid, attachments and
bowl.
●
Always switch off before removing the lid.
important
●
Your processor is not suitable for crushing or grinding coffee
beans, or converting granulated sugar to caster sugar.
●
When adding almond essence or flavouring to mixtures avoid
contact with the plastic as this may result in permanent marking.
