1. PREFACE

1.1. INTRODUCTION

Congratulations on having purchased a KEMPPI product. Properly installed and used KEMPPI
products should prove to be productive machines requiring only a small amount of regular
maintenance.This manual is designed to give you a good understanding of the equipment and its safe
use. There is also information on maintenance of the unit and the machine´s technical data. Read

the instructions before bringing the machine into use or servicing it for the rst time. Additional

information on Kemppi products and their use can be obtained from Kemppi or a Kemppi dealer.

The specications and designs presented in this manual are subject to change without prior notice.
In this document, the following symbol is used to indicate a risk of injury or death:

Read the warnings carefully and follow the instructions. Please also study the instructions for safe
operation and follow them when installing, operating and servicing the machine.

1.2. PRODUCT INTRODUCTION

Kempact™ Pulse 2800 MVU Automotive is a compact puls MIG inverter specially suitable for
car body repair. Good MIG brazing characteristics have been emphasized in designing of the

machine.

1.3. SAFE OPERATION

Read the warnings carefully and follow the instructions.

Welding arc and spatter

The arc and the reected radiation from it can damage unprotected eyes. Shield your eyes and
protect your surroundings appropriately before you start welding. The arc and welding spatter will
burn unprotected skin. When welding, use protective clothes and clothing.

Danger of re and explosion

Observe the re safety instructions. Remove ammable material in and near the location in which
you will weld. Make sure the necessary re extinguisher equipment is nearby. Note the dangers
posed by special jobs, such as the risk of re and explosion when welding tanks. Note! Sparks
may ignite a re even hours later! Welding involves working with a naked ame, note the special
instructions for such work.

Mains voltage

Never bring the welding machine inside the work piece (e.g. container or car). Never set the
welding machine on a wet surface. Replace faulty cables immediately, they create a danger to life
and can cause a re. Ensure that the connecting cable does not stick, touch sharp edges, or come
in contact with a hot piece.

Welding current circuit

Isolate yourself from the welding current circuit by wearing dry and undamaged protective clothing.
Never work on a wet surface. Never use damaged welding cables. Never set the electrode holder,
earth clamp, or welding cables on top of the power source or other electrical equipment.

Welding fumes

Ensure adequate ventilation. Always take special measures when welding metals containing lead,
cadmium, zinc, mercury or beryllium.

This equipment’s electromagnetic compatibility (EMC) makes it suitable for use in an
industrial environment. Class A equipment is not intended for use in a residential location
where the electrical power is provided by the public low-voltage supply system.

4 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

2. BEFORE YOU START USING THE UNIT

2.1. UNPACKING

The equipment is packed in durable packages, designed specially for it. Nevertheless, before using
the equipment, always make sure it was not damaged during transport. Also check that you have
received what you ordered and it is accompanied by the appropriate instructions. NOTE! The
packaging material is suitable for recycling.

2.2. PLACEMENT OF THE UNIT

Place the unit on a horizontal, solid, and clean surface. Shield it from heavy rain and scorching
sun. Make sure that cooling air circulates freely.

2.3. SERIAL NUMBER

The serial number of the unit is marked on its rating plate. The serial number makes it possible to
trace product manufacturing series. You might need the serial number when placing spare parts
orders or when planning maintenance.

2.4. CONNECTION TO THE MAINS SUPPLY

The Kempact™ Pulse 2800 MVU Automotive is delivered with a ve metre mains cable without
a plug. Installation of the plug should be carried out only by a competent electrician. Power source
recognizes the mains voltage automaticly. For fuse and cable sizes, see the technical data in the

end of this document.

2.5. GROUND CABLE

Fasten the earth clamp of the return current cable carefully, preferably direct onto the piece to be
welded. The contact surface of the earth clamp should always be as large as possible.

Clean the fastening surface of paint and rust. Use at least two 35 mm² cables. Thinner cross sectional

areas may cause the connectors to overheat.

Kempact™ pulse 2800 mVu automotiVe / 0709 – 5© Kemppi oy

1.

2. 2.

6 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

2.6. INSTALLATION OF WELDING GUN

Make sure the gun wire conduit and the contact tip match the manufacturer’s recommendations
for the type and diameter of wire you use. Too small a conduit may overload the wire feed device
and impede the wire feeding. Tighten the gun’s quick connector to eliminate voltage loss. A loose
joint will heat up the gun and wire heater.

Never use defected gun.

2.7. MOUNTING AND LOCKING OF WIRE REEL

– Release locking nails of wire reel hub by turning locking knob a quarter round.

– Mount the reel at its place. Note rotating direction of reel!

– Lock the reel with locking knob, locking nails of hub remain to outside position and will

lock the reel..

2.8. AUTOMATIC WIRE FEED TO GUN

Automatic wire feed makes change of wire reel more rapid. In reel change the pressure of feed
rolls need not to be released and ller wire goes automatically to correct wire line..

– Make sure that groove of feed roll matches the diameter of welding wire used.

– Release the wire end from reel and cut off the bent length. Be careful that the wire does not

spill from the reel to sides!

– Straighten about 20 cm of the wire and see that the end of it has no sharp edges (le off if

necessary). A sharp edge may damage the wire guide tube and contact tip of the welding

gun.

– Draw a bit of loose wire from wire reel. Feed wire through back liner to feed rolls. Do not

release pressure of feed rolls!

– Press the gun switch and feed a bit wire until wire goes through feed rolls to gun. See that

wire is in grooves of both feed roll pairs!

– Press still the gun switch until wire has come through contact tip.

Automatic feed may sometimes fail with thin wires (Fe, Fc, Ss: 0,6...0,8 mm, Al: 0,8...1,0 mm). In
that case you might have to open feed rolls and feed wire manually through feed rolls.

Note! Check that the wire or wire reel does not touch the equipment body, there is
a danger of short circuit!

2.9. ADJUSTMENT OF PRESSURE

Adjust the pressure of the feed rolls with the control screw so that the wire is fed into the wire
guide tube evenly and allows a little braking when emerging from the contact tip, without slipping

on the feed rolls.

Excessive pressure will cause the ller wire to atten and damage its coating, as well

as undue wear and tear of the feed rolls and friction damage.

LOCKED OPEN

Kempact™ pulse 2800 mVu automotiVe / 0709 – 7© Kemppi oy

2.10. ADJUSTMENT OF TIGHTNESS OF SPOOL BRAKE

Brake force can be adjusted through the hole in the spool hub’s locking device of spool hub by
screwing the control screw with a screwdriver. Adjust the braking force so that it is sufcient to
prevent the wire from becoming too loose on the spool and spilling when the spool stops rotating.
The greater the wire feed speed, the greater the braking force required. Do not keep the brake
unnecessarily tight, since this will impose a strain on the motor.

2.11. SHIELDING GAS

The MIG shielding gas consists of carbon dioxide, mixed gases and argon. Shielding gas ow
rate is determined by the amount of welding current. The typical ow rate of gas in the welding
steel is 8-15 l /min.

The following installation instructions are valid for most gas ow regulator types:

1. Step aside and open the bottle valve (A) for a while to blow out possible impurities.

2. Turn the press regulation screw (B) of the regulator until no spring pressure can be felt.

3. Close the needle valve if there is one in the regulator.

4. Install the regulator onto bottle valve and tighten the connecting nut (C) with a wrench.

5. Install the hose spindle (D) and jacket nut (E) into the gas hose and tighten with a hose

clamp

6. Connect the hose with the regulator and the other end with the wire feed unit. Tighten jacket

nut.

7. Open the bottle valve slowly. The gas bottle pressure meter (F) shows bottle pressure.
Note! Do not use the whole contents of the bottle. The bottle pressure should be lled when

bottle pressure is 2 bar.

8. Open the needle valve if there is one in the regulator.

9. Turn the regulation screw (B) until the hose pressure meter (G) displays the required ow
(or pressure). When regulating the ow amount, the power source should be switched on

and the ”GAS PURGE” -switch pressed simultanously.

Close the bottle valve after welding is nished. If the machine will not be in use for a long time,
unscrew the pressure regulation screw.

Always fasten the gas cylinder securely in an upright position on a wall rack intended
for the purpose or on a cylinder cart. Always close the cylinder valve after you have

nished welding.

A Gas bottle valve

B Press regulation screw

C Connecting nut

D Hose spindle

E Jacket nut

F Gas bottle pressure meter

G Gas hose pressure meter

E

B

D

CAF

G

A

8 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

3. OPERATION

3.1. MAIN SWITCH AND SIGNAL LIGHTS

With the switch in the ’I’ position, the primary and control circuits of the machine become live
and the ’ON’ signal light on the panel lights up. The welding circuit receives voltage when the gun
switch is operated or when the wire feed test switch is pressed. Always use the main switch to turn
the machine on and off with the main switch; do not use the power plug for this purpose.

3.2. TO SELECT POLARITY FOR WELDING

Solid wire is usually welded in the +pole and gasfree ller wires in the - pole gun. When welding
with other ller wires, check for the recommended polarity on the package or consult the supplier
of the product. The welding of very thin steelplates (0.5 to 0.7 mm) a - polarity might also work
best for solid wire.

3.2.1. Changing the polarity

Only a service shop authorised by Kemppi may change the polarity.

3.3. PANEL

+ pole

- pole

Kempact™ pulse 2800 mVu automotiVe / 0709 – 9© Kemppi oy

3.3.1. Choosing the welding method

Normal MIG/MAG welding:

with a separate wire feed and voltage regulation can be chosen in the 1-MIG position.
Curve number ”00” provides a free wire feed range between 1-18 m/min. The voltage
can be set between special pre-programmed limits depending on the wire feed. Curve
number ”01” wire feed speed and voltage are not depended on each other. When curve
”01” is selected, the wire feed speed and voltage will be independent of one another.

Synergic MIG/MAG welding (1-MIG)

Synergic MIG/MAG welding (1-MIG): MIG welding in which the wire feed speed
determines all the other welding parameter values, allowing the adjustment of welding
power with a single knob. Choose the appropriate synergy curve for the ller wire and
shielding gas to determine how the wire feed speed affects the pulse parametres.

Synergic Pulse MIG welding:

through this welding method, based on pulsing the welding current, the ller metal on the
workpiece is kept spatter-free. The power source pulse parameters change automatically
(synergy) enabling welding power regulation using a single knob. Choose the appropriate
synergy curve for the ller wire and shielding gas to determine how the wire feed speed

affects the pulse parametres.

3.3.2. Selecting 1-mig/pulse mig synergy curves

The program number of the synergy curve is selected using the plus-minus buttons and is displayed

on ”SYNERGIC PRG”.

The middle display is actual material group display (eg. SS, AL, CUS, FE, GEN). Wire diameter
(mm) can be seen on the right side. This information will only be displayed for a while.

The ”PRG INFO” button gives more curve information:

One press will revert to the material group and diameter display, a second will display the type

number of the material and a third run through the gas consistency components one by one.

10 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

3.3.3. Adjustments, display and weld data

Display for welding current and welding material
thickness. Changing can be made using the button

behind the display. There is a percentage display

(eg. gas consistency) and seconds display (see
timer). The relative length of arc will be displayed
when adjusted. Otherwise the predicted current
value is displayed (not in 2-MIG).

Process Manager™ for setting all welding

parameters.

The display for wire feed speed, welding voltage or material group. This can be switched using
the button under the display (wire feed speed/length of arc). The voltage can be adjusted in the
normal and 1-MIG position (wire feed range/the length of arc). During pulse welding the voltage
is determined by the wire feed speed while the length of arc affects some other parameters.

When pressed simultaneously, the weld data buttons recall the wire feed speed on the display, the
welding voltage and welding current values which have been used when welding was stopped.

3.3.4. Timer

intermittent welding

spot welding

The spot time is set immediately after pressing the switch button, on the display SPt.
The pause time is set accordingly, on the PSE display. The time is set using the Process

Manager.

3.3.5. Adjustment of welding dynamics

For adjusting of MIG/MAG welding dynamics, the adjustment value dyn -9...0...9 is
displayed. The welding stability and quantity of spatter are affected by the welding

dynamics control, the 0-position is the recommended reference range. Values -9...-1

give a smoother arc and less spatter, while values 1...9 give a rougher arc and increased
stability, when using a 100% CO² shielding gas when welding steel.

3.3.6. Remote control

Gun control, wire feed speed or welding power control is changed using RMT 10.
Control of the welding voltage or the length of the welding arc can be adjusted using
the potentiometer on the panel. Panel control, adjustments using the potentiometer on

the panel.

3.3.7. Mig extra functions

Crater lling, 1-MIG and pulse MIG:

Crater lling reduces welding mistakes caused by end craters.The welding power and
end level can be changed using the SETUP-function.

Kempact™ pulse 2800 mVu automotiVe / 0709 – 11© Kemppi oy

Crater lling

Hot Start

Wire range/power/
Welding current

The Hot Start:

The Hot Start function is supposed to decrease faults in the start welding heat conductive materials
as for example aluminium. The Hot Start function is used with 1-MIG and pulse MIG welding. Time
is determined by SETUP parameters. The level of Hot Start can be changed by SETUP function.

The Hot Start level, Hot Start time, crater ll level and downslope time can be easily adjusted
using the ‘QUICK SETUP’ function:

1. First, press the SETUP button and then , while still pressing the SETUP button, press the
extra function button.

2. Adjust the Hot Start level.

3. Repeat step 1, upon which the display will show the next adjustable parameter.

Exit by pressing any button (except SETUP)

3.3.8. Use of gas test

If you press the gas test button, gas will begin to ow without any starting power source
or wire feed. Gas ow can be measured by using an external measuring device.

Cut off the gas ow by pressing the same button again, or the gun trigger. If the trigger
is not pressed again, the gas ow will end within 20 seconds.

The display will show “GAS” and the time.

3.3.9. Testing wire feed

The wire feed switch will start the wire feed motor without opening the gas valve. The
power source will start up, but without providing welding power. The wire feed range
will be 5m/min but can be adjusted as desired.

3.3.10. SETUP

Using the SETUP function, the user can change welding parameters which do not have their own
panel functions. These parameters can be set separately for 1-MIG and Pulse MIG. SETUP settings

are separate for each memory channel.

12 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

Parameter Name Nr Display 1-MIG Pulsed

MIG

Factory
value

Unit Explanation

PostGasTime 1 PoG X X Curve s PostGas time 0.0…9.9 s
PreGasTime 2 PrG X X Curve s PreGas time, functions by

2T 0.0…9.9 s

HotStartLevel 11 Hot X X 30 % Hot start ratio to welding

power 50…+75%

HotStartTime 2T 12 H2t X X 2 s 2T Hot start timer 0.1-9.9 s
CraterFillLevel 14 CFL X X 30 % Welding end level 10-90 %
CraterFillSlope 15 CFS X X 1 s/10m Wire slowing-down

1…20 s/10m

CreepStartLevel 17 CSL X X Syn Wire speed start value

10…90

CreepStartSlope 18 CSS X X 0 s/10m Wire speed up time

0.1…5 s/10m

DoubleFrequency 21 dFr

-----

DoubleAmpiltude 22 dA

-----

StartPower 31 StP X X 0 Start power control

-9…0…+9

PulseCurrent 33 PuC X 0 % Pulse top current control

10…+15%

ArcLength
AdjRange

41 ALr X X 0 % Arc length adjustment

range 50…+75%

Calibration 42 CAL X X 1 V/100A Setting mid value of arc

length ne adjustment

0.0…10.0 V/100A

WFS

51 FS 18 m/min Wire feed maximum

18 or 25 m/min

Gun 53 Gun On liquidcooled thermal

protection on/off

GunRemote 54 GrE On Disabling of gun remote

control automatic

identication

Display reset
time

81 dLY X X 5 s 1...20 s

PRG INFO - feeld
selection

82 diS X X 1 1,2,3

Restore 99 FAC X OFF Restoring factory settings

(OFF=no reset,
Pan=panel and setup
ALL= also memory
channels)

Setup functions on pulse panel

Kempact™ pulse 2800 mVu automotiVe / 0709 – 13© Kemppi oy

Changing parameters

By pressing the (SETUP) selection switch a little longer the machine will enter the SETUP state.
The display will show the set parameter’s runnning number (blinking), its abbreviation and value.
Select the parameter number using the “SYNERGIC PRG” + and - buttons or the “SETUP” button
(which will jump by tens). Change the value using the control button (in some cases, the value
can be found from the synergy curve). “Syn” and the curve value will blink by turns on the right
of the display. Set the value by turning the button anticlockwise.

Exit for SETUP using a long press.

3.3.11. Error codes

Error codes are among others the following:

Err 3: Overvoltages in the mains supply. Also the pilot light of overvoltage is lighting.

Err 4: The thermal protection of power suorce has stopped welding. Also the pilot light of

thermal protection is lighting.

Err 6: The terminal voltage has rised. Take the device to service.

Err 153: Liquid cooled PMT- or WS-gun is overheated. Or torch-PTC or RMT10 has beeb installed,

but the jumber inside the torch is in FU-position, look also instruction of torch.

Err 154: Overloading of the wire feed motor

Error code is eliminated when the reason is aborted, except Err 6, which demands to turn down

the machine.

4. MAINTENANCE

4.1. DAILY MAINTENANCE

Be careful of mains voltage when handling electric cables!

Clean the wire channel of the gun and check the contact tip regularly. Always check the condition
of the mains and welding cable before operation and replace defective cables.

Note! Only a qualied electrician should remove or install the mains cable!

4.2. REGULAR MAINTENANCE

KEMPPI -service workshops sign special service contracts with customers for regular maintenance.
All parts are cleaned, checked and if necessary, repaired. The operation of the welding machine

is also tested.

4.3. DISPOSAL OF THE MACHINE

Do not dispose of electrical equipment together with normal waste!

In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment and its implementation in accordance with national law, electrical equipment

that has reached the end of its life must be collected separately and returned to an

environmentally compatible recycling facility. As the owner of the equipment, you should

get information on approved collection systems from our local representative.

By applying this European Directive you will improve the environment and human
health!

14 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

5. ORDERING INFORMATION

Item Ordering number

Kempact™ Pulse 2800 MVU Automotive 62182800302

GH 30 Gun holder 6256030

PMT 25 3 m 6252513

PMT 25 4,5 m 6252514

PMT 27 3 m 6252713

PMT 27 4,5 m 6252714

PMT 32 3 m 6253213

PMT 32 4,5 m 6253214

PMT 35 3 m 6253513

PMT 35 4,5 m 6253514

WS 35 6 m, Al 1,2 6253516A12

WS 35 6 m, Ss 1,0 6253516S10

MMT 25 3 m 6252513MMT

MMT 25 4,5 m 6252514MMT

MMT 27 3 m 6252713MMT

MMT 27 4,5 m 6252714MMT

Remote Control Unit RMT 10 6185475

Earth cable 35 mm² 5 m 6184311

Transport unit P20 6185261

Transport unit P250 6185268

Lift hook 4298180

Gas hose 6 m W000566

Wire spool pole 4289880

5 kg spool adapter 4251270

Kempact™ pulse 2800 mVu automotiVe / 0709 – 15© Kemppi oy

Kempact™ Pulse 2800 MVU Automotive

Mains connection 3~230 V +/-10 %, 50/60 Hz

3~400 V +/-15 %, 50/60 Hz

Connected load

40 % ED 10 kVA, 250 A

60 % ED 8 kVA, 207 A

100 % ED 6,5 kVA, 160 A

Mains cable/fuse 4x1,5 mm², 5 m/16 A delayed

Load capacity

40 % ED 250 A / 26,5 V

60 % ED 207 A / 24 V

100 % ED 160 A / 22 V

Adjustment range 8 - 30 V

Wire feed speed

1 - 18 m/min

Open circuit voltage 68 V

Power factor 0,78 (250 A / 26,5 V)

Efciency 0,83 (250 A / 26,5 V)

Filler wires

Fe, Ss

0,6 ... 1,0 mm

Cored wire 0,9 ... 1,2 mm

Al

0,9 ... 1,2 mm

CuSi

0,8 ... 1,0 mm

Shielding gas CO², Ar, Ar & CO² mixed gases

Wire spool diameter

300 mm (15 kg)

Feed roll Ø 32 mm

Thermal class H (180 °C) / B (130 °C)

Dimensions

length 580 mm

width 280 mm

height 600 mm

Weight

33 kg

Gun connector EURO

Principle of operation 4-wheel feed

Range of temperature
for use

- 20 °C ...+ 40 °C

Storage temperature
for use

- 40 °C ...+ 60 °C

Degree of protection IP23C

6. TECHNICAL DATA

The products meet conmormity reguirements for CE marking.

16 – Kempact™ pulse 2800 mVu automotiVe / 0709 © Kemppi oy

7. TERMS OF GUARANTEE

Kemppi Oy provides a guarantee for products manufactured and sold by them if defects in

manufacture and materials occur. Guarantee repairs must be carried out only by an Authorised
Kemppi Service Agent. Packing, freight and insurance costs to be paid by orderer. The guarantee is
effected on the date of purchase. Verbal promises which do not comply with the terms of guarantee

are not binding on guarantor.

Limitations on guarantee

The following conditions are not covered under the terms of guarantee: defects due to natural wear
and tear, non-compliance with operating and maintenance instructions, connection to incorrect or
faulty supply voltage (including voltage surges outside equipment spec.), incorrect gas pressure,
overloading, transport or storage damage, re of damage due to natural causes i.e. lightning or
ooding.

This guarantee does not cover direct or indirect travelling costs, daily allowances or accommodation.
Note: Under the terms of guarantee, welding torches and their consumables, feeder drive rolls and

feeder guide tubes are not covered. Direct or indirect damage due to a defective product is not

covered under the guarantee. The guarantee is void if changes are made to the product without

approval of the manufacturer, or if repairs are carried out using non-approved spare parts.

The guarantee is also void if repairs are carried out by non-authorised agents.

Undertaking guarantee repairs

Guarantee defects must be informed to Kemppi or authorised Kemppi Service Agents within the
guarantee period. Before any guarantee work is undertaken, the customer must provide proof of

guarantee or proof of purchase, and serial number of the equipment in order to validate the guarantee.
The parts replaced under the terns of guarantee remain the property of Kemppi.

Following the guarantee repair, the guarantee of the machine or equipment, repaired or replaced,
will be continued to the end of the original guarantee period.

KEMPPI OY
PL 13
FIN – 15801 LAHTI
FINLAND
Tel [phone]
Telefax [phone]
www.kemppi.com

KEMPPIKONEET OY
PL 13
FIN – 15801 LAHTI
FINLAND
Tel [phone]
Telefax [phone]
e-mail: myynti.fi @kemppi.com

KEMPPI SVERIGE AB
Box 717
S – 194 27 UPPLANDS VÄSBY
SVERIGE
Tel [phone]
Telefax [phone] 94
e-mail: [e-mail]

KEMPPI NORGE A/S
Postboks 2151, Postterminalen
N – 3103 TØNSBERG
NORGE
Tel [phone]
Telefax 33 34 60 10
e-mail: [e-mail]

KEMPPI DANMARK A/S
Literbuen 11
DK – 2740 SKOVLUNDE
DANMARK
Tel [phone]
Telefax 44 941 536
e-mail:[e-mail]

KEMPPI BENELUX B.V.
Postbus 5603
NL – 4801 EA BREDA
NEDERLAND
Tel [phone]
Telefax [phone]
e-mail: [e-mail]

KEMPPI (UK) Ltd
Martti Kemppi Building
Fraser Road
Priory Business Park
BEDFORD, MK443WH
ENGLAND
Tel [phone]
Fax [phone]
e-mail: [e-mail]

KEMPPI FRANCE S.A.
65 Avenue de la Couronne des Prés
78681 EPONE CEDEX
FRANCE
Tel [phone]
Telefax (01) 30 90 04 45
e-mail: [e-mail]

KEMPPI GmbH
Otto – Hahn – Straße 14
D – 35510 BUTZBACH
DEUTSCHLAND
Tel [phone]
Telefax (06033) 72 528
e-mail:[e-mail]

KEMPPI SP. z o.o.
Ul. Piłsudskiego 2
05-091 ZA¸BKI
Poland
Tel [phone]
Telefax [phone]
e-mail: [e-mail]

KEMPPI WELDING
MACHINES AUSTRALIA PTY LTD
P.O. Box 404 (2/58 Lancaster Street)
Ingleburn NSW 2565, Australia
Tel. [phone]
Telefax [phone]
e-mail: [e-mail]

OOO KEMPPI
127018 Moscow, Polkovaya str. 1,
Building 6
e-mail: [e-mail]

ООО КЕМППИ
127018 Москва, ул. Полковая 1,
строение 6

Ver. 1 0

www.kemppi.com
