Selector Guide Digital Multimeters
Model 197A 2000 2000-20 2010 2001
Digits 51⁄2 61⁄2 61⁄2 71⁄2 71⁄2
Expansion Channels 10 20 10 10
DC Volts
Sensitivity 1 µV 100 nV 100 nV 1 nV 10 nV
Maximum Reading 1000 V 1000 V 1000 V 1000 V 1100 V
Basic Accuracy 0.011% 0.002% 0.002% 0.0018% 0.0018%
Ratio • Option
DC Peak Spikes •
AC Volts (TRMS)
Sensitivity 1 µV 100 nV 100 nV 100 nV 100 nV
Maximum Reading 750 V 750 V 750 V 750 V 775 V (1100 V pk)
Basic Accuracy 0.35% 0.05% 0.05% 0.05% 0.03%
Bandwidth 20 Hz–100kHz 3 Hz–300 kHz 3 Hz–300 kHz 3 Hz–300 kHz 1 Hz–2 MHz
dB, dBm •• ••
Frequency, Period •• ••
Peak/Avg/RMS •
AC, AC + DC •
THD, Harmonics
4V Sine Source
9V Sine Source
Ohms (2/4 Wire)
Sensitivity 1 mΩ 100 µΩ 100 µΩ 1 µΩ 1 µΩ
Maximum Reading 220 MΩ 120 MΩ 120 MΩ 120 MΩ 1 GΩ
Selector Guide: Digital Multimeters
Basic Accuracy 0.018% 0.008% 0.008% 0.0032% 0.0032%
Continuity Test •* •
Diode Test •* ••
Offset Compensation ••
Dry Circuit •
Constant Current •• ••
Open Source Detect
DC Amps
Sensitivity 1 nA 10 nA 10 nA 10 nA 10 pA
Range Span 200 mA–10 A 10 mA–3 A 10 mA–3 A 10 mA–3 A 200 µA–2 A
Basic Accuracy 0.1% 0.03% 0.03% 0.03% 0.03%
In Circuit Current •
AC Amps (TRMS)
Sensitivity 1 nA 1 µA 1 µA 1 µA 100 pA
Range Span 200 mA–10 A 1 A–3 A 1 A–3 A 1 A–3 A 200 µA–2A
Basic Accuracy 0.8% 0.1% 0.1% 0.1% 0.1%
Bandwidth 20 Hz–30 kHz 3 Hz–5 kHz 3 Hz–5 kHz 3 Hz–5 kHz 20 Hz–100 kHz
General Features
Interface GPIB, RS-232 GPIB, RS-232 GPIB, RS-232 GPIB
Reading Hold Min/Max hold • • •
Digital I/O •
Reading Memory 100 rdg. 1024 rdg. 1024 rdg. 1024 rdg. Opt to 30,000
Maximum Speed 3 rdg/s 2000 rdg/s 2000 rdg/s 2000 rdg/s 2000 rdg/s
Temperature Meas. TC TC TC, RTD TC, RTD
Language Emulation 8840/42, 196/199 8840/42, 196/199 196/199
1.888.KEITHLEY (U.S. only)
DIGITAL MULTIMETERS
www.keithley.com
A GREATER MEASURE OF CONFIDENCE
Page 2
Selector Guide Digital Multimeters
Model 2002 2015, 2015-P 2016 2700 2750
Digits 81⁄2 61⁄2 61⁄2 61⁄2 61⁄2
Expansion Channels 10 80 200
DC Volts
Sensitivity 1 nV 100 nV 100 nV 100 nV 100 nV
Maximum Reading 1100 V 1000 V 1000 V 1000 V 1000 V
Basic Accuracy 0.0006% 0.002% 0.002% 0.002% 0.002%
Ratio Option
DC Peak Spikes •
AC Volts (TRMS)
Sensitivity 100 nV 100 nV 100 nV 100 nV 100 nV
Maximum Reading 775 V (1100 V pk) 750 V 750 V 750 V 750 V
Basic Accuracy 0.02% 0.05% 0.05% 0.06% 0.06%
Bandwidth 1 Hz–2 MHz 3 Hz–300 kHz 3 Hz–300 kHz 3 Hz–300 kHz 3 Hz–300 kHz
dB, dBm •••
Frequency, Period •••••
Peak/Avg/RMS •••
AC, AC + DC •
THD, Harmonics ••
Spectrum Peaks • (2015-P)
4V Sine Source •
9V Sine Source •
Ohms (2/4 Wire)
Sensitivity 100 nΩ 100 µΩ 100 µΩ 100 µΩ 1 µΩ
Maximum Reading 1 GΩ 120 MΩ 120 MΩ 120 MΩ 120 MΩ
Basic Accuracy 0.0007% 0.008% 0.008% 0.008% 0.008%
Continuity Test ••
Diode Test •••
Offset Compensation ••• •
Dry Circuit •
Constant Current •••••
Open Source Detect •
DC Amps
Sensitivity 10 pA 10 nA 10 nA 10 nA 10 nA
Range Span 200 µA–2 A 10 mA–3 A 10 mA–3 A 20 mA–3 A 20 mA–3 A
Basic Accuracy 0.027% 0.03% 0.03% 0.03% 0.03%
In Circuit Current •
AC Amps (TRMS)
Sensitivity 100 pA 1 µA 1 µA 1 µA 1 µA
Range Span 200 µA–2A 1 A–3 A 1 A–3 A 1 A–3 A 1 A–3 A
Basic Accuracy 0.1% 0.1% 0.1% 0.15% 0.15%
Bandwidth 20 Hz–100 kHz 3 Hz–5 kHz 3 Hz–5 kHz 3 Hz–5 kHz 3 Hz–5 kHz
General Features
Interface GPIB GPIB, RS-232 GPIB, RS-232 GPIB, RS-232 GPIB, RS-232
Reading Hold ••••
Digital I/O • 2 in/5 out (TTL) 2 in/5 out (TTL)
Reading Memory Opt to 30,000 1024 rdg. 1024 rdg. 55,000 rdg. 110,000 rdg.
Maximum Speed 2000 rdg/s 2000 rdg/s 2000 rdg/s 2000 rdg/s 2000 rdg/s
Temperature Meas. TC, RTD TC TC TC, RTD, Thermistor TC, RTD, Thermistor
Language Emulation HP 3458
