Keithley 3721-MTC-3 Keithley Cable Guide

Cables

Model Description Type

236-ILC-3

237-A LG-2

237-ALG-15

2000-MTC-2

2000-MTCD-2

2107-4

2107-30

2107-50

2260- 005

2260- 006

2260- 007

2290-5-SHV

2290-5-MH V

2290-10-SHV

2290-10-SHVUC

2290-INT-CABLE

2450 -TR X-BA N

Cables

2600 -ALG-2

2651 A-K IT-1

2651 A-K IT-2

2651 A-K IT- 3

3720- MT C-1.5

3720-MTC-3

3721- MTC-1.5

3721-M TC-3

3722-MTC-1.5

3722-MTC-1.5/MM

3722-MTC-3

3722-MTC-3/MM

3732-MTC-1.5

3732-MTC-3

420 0-MT RX-1

4200 -MT RX-2

4200-MTR X-3

4200-PRB-C

4200-RPC-0.3

4200 -RPC-2

4200-RPC-3

4200-RPC- 6

4200-TRX-0.3

420 0-TR X-1

4200-TRX-2

4200-TRX-3

4801

480 2-10

4803

6011

6011-10

6517-ILC-3

ACCESSORIES

6517B-ILC-3

Safety Interlock Shielded twisted pair 3-pin round 3-pin round 3 10 4200-SCS, 8007, 8008

Low Noise Input Tria x 3-slot male triax Alligator clips (3) 2 6.6

Low Noise Input Tria x 3-slot male triax Alligator clips (3) 15 50

Cable Assembly Shielded twisted pair DB44 female Unterminated 2 6.6 2000-20

Cable Assembly

Input Cable Shielded twisted pair LEMO Copper spade lugs (4) 1.2 4 2182A

Input Cable Shielded twisted pair LEMO Copper spade lugs (4) 9.1 30 2182A, Ser ies 2200

Input Cable Shielded twisted pair LEMO Copper spade lugs (4) 15 50 2182A, Series 2200

Input Cable 0.5 1.6 Series 2260B

Input Cable 0.5 1.6 Series 2260B

Input Cable 0.5 1.6 Series 2260B

Input Cable

Input Cable

Input Cable

Input Cable

Interlock Cable 3-conductor 3 -pin Unterminated

Adapter Cable Tria x 3-slot male triax Banana input jack 0.3 1 2450

Low Noise Input Tria x 3-slot male triax Alligator clips (3) 2 6.6 2635B, 2636B, 4200 -PA

Cable Assembly Coax 2-pin plug 2-pin plug 1 3.3 2651A, 8011

Cable Assembly Coax 2-pin plug 2-pin plug 2 6.6 2651A, 8011

Cable Assembly Coax 2-pin plug 2-pin plug 3 10 2651A, 8011

Mass Terminated Assembly

Mass Terminated Assembly

Mass Terminated Assembly

Mass Terminated Assembly

Mass Terminated Assembly Shielded twisted pair D-sub male 104-pin D-sub female 1.5 5 3722

Mass Terminated Assembly Shielded twisted pair D-sub male 104-pin D-sub male 1.5 5 3722

Mass Terminated Assembly Shielded twisted pair D-sub male 104-pin D-sub female 3 10 3722

Mass Terminated Assembly Shielded twisted pair D-sub male 104-pin D-sub male 3 10 3722

Mass Terminated Assembly

Mass Terminated Assembly

Ultra Low Noise SMU tria x Miniature male 3-slot ma le 1 3.2 4200-SCS

Ultra Low Noise SMU tria x Miniature male 3-slot ma le 2 6.5 4200-SCS

Ultra Low Noise SMU tria x Miniature male 3-slot ma le 3 9.8 4200-SCS

Cable Assembly Y adapter cable Female SM A 2 fema le SSMC 4200-PIV, 4210-CVU

Cable Assembly Remote PreA mp DB15 DB15 0.3 1 42 00-PA

Cable Assembly Remote PreA mp DB15 DB15 2 6.5 4200-PA

Cable Assembly Remote PreA mp DB15 DB15 3 9.8 42 00 -PA

Cable Assembly Remote PreA mp DB15 DB15 6 19.6 4200 -PA

Ultra Low Noise PreAmp triax 3-slot male 3-slot male 0.3 1ft 4200-PA

Ultra Low Noise PreAmp triax 3-slot male 3-slot male 1 3.2 420 0-PA

Ultra Low Noise PreAmp triax 3-slot male 3-slot male 2 6.5 4200 -PA

Ultra Low Noise PreAmp triax 3-slot male 3-slot male 3 9.8 4200 -PA

Low Noise Input Coax Male BNC Male BNC 1.2 4 6482, 6485

Low Noise Input Coax Male BNC Unterminated 3 10 6482, 6485

Low Noise Cable Kit Coax Male BNC (10) Female BNC (5) 15.2 50 6482, 6485

Input Leads Tria x 2-slot male triax A lligator clips (3) 1.5 5 Instruments with 2-slot triax connectors

Input Leads Tria x 2-slot male triax A lligator clips (3) 3 10 Instruments with 2-slot tr iax connectors

4-pin Interlock Cable Shielded 4-pin female DIN 4-pin female DIN 1 3.3 6517A, 8009

Interlock Cable Shielded 4-pin Phoenix 4-pin DIN 1 3.3 6517 B, 8 009

TERMINATIONS LENGTH

Shielded multiple
conductors

Coax SHV Female SHV Female

Coax SHV Female MHV Male

Coax SHV Male SHV Male

Coax SHV Male Unterminated

Shielded multiple
conductor

Shielded multiple
conductor

Shielded multiple
conductor

Shielded multiple
conductor

Shielded multiple
conductor

Shielded multiple
conductor

DB44 female DB50 male 2 6.6 2000-SCA N-20

D-sub female 78-pin D -sub male 1.5 5 3720, 3723, 3724

D-sub female 78-pin D -sub male 3 10 3720, 3723, 3724

D-sub female 50-pin D -sub male 1.5 5 3721, 3730, 3731, 3740, 3750

D-sub female 50-pin D -sub male 3 10 3721, 3730, 3731, 3740, 3750

D-sub female 78-pin D -sub male 1.5 5 3732

D-sub female 78-pin D -sub male 3 10 3732

3 10

3 10

3 10

3 10

3.05 10

USE WITH:From To m ft

Series 2200, Series 2600B, 420 0-PA, 6220,
6221, 64 82, 64 87, 6514, 6517A, 6517B

Series 2200, Series 2600B, 420 0-PA, 6220,
6221, 64 82, 64 87, 6514, 6517A, 6517B

2290-5, 2290-5-SH VBH

2290-5

2290-10, 2290-10-SHVBH

229 0-10

2290-5, 2290-10

Cables

A Tektronix Company

Cables

Model Description Type

7009-5

7019C-MTCI-2

7020- MTC-2

7024-3

7024 -10

7025 -10

7051-*

7078-DIN

7078-M TC-5

7078-MTC-20

7078 -TRX-1

7078-TR X-3

7078-TR X-5

7078 -TRX-10

7078 -TRX-12

7078-TR X-20

7078-TR X-6IN

7173-50-CSEP

Cables

7705-MTC-2

7711- BNC -SMA

7712 -SMA -1

7754- 3

8007-GN D-3

8542-301

8607

CA-18-1

CA-19-2

CA-126 -1A

CA-180 -3A

CA-321-1

CA-322 -1

CA-404B

CA- 405B

CA-406B

CA-446A

CA -447A

CA -451A

CA-452A

CA-557-1 A

CA-557-2A

CA-557-3

CA-558-x

CA-559-0A

CA-559-2A

CA-560 -0A

CA-560-2A

CA -561 -0 A

CA -561 -2A

CA-562-0B

CA-562-2B

Shielded RS-232 Shielded Male DB-9 Fema le DB-9 1.5 5 All R S-232 capable instruments

Kelvin Instrument Cable Shielded twisted pair Card connector

Mass Terminated Assembly Twisted pair (45) 96-pin female 96-pin female 2 6.6 7020

Low Noise Tria x 2-slot male tria x 2-slot male tria x 0.9 3 Instruments with 2-slot triax connectors

Low Noise Tria x 2-slot male tria x 2-slot male tria x 3 10 Instruments with 2-slot triax con nectors

Low Noise Input Tria x 2-slot male tria x Unterminated 3 10 Instr uments with 2-slot triax con nectors

BNC Interconnect Coax BNC BNC 2015, 2016, 3390

707A Master/Slave Twisted pair (9) 8 -pin DIN 8 -pin DIN 1.8 6 7 07A

Mass Terminated Assembly Twisted pair (12) 38-pin connector 38-pin connector 1.5 5 7071, 7071-4, 7074-D

Mass Terminated Assembly Twisted pair (12) 38-pin connector 38-pin connector 6.1 20 7071, 7071-4, 7074-D

Low Noise Tria x

Low Noise Tria x

Low Noise Tria x

Low Noise Tria x

Low Noise Tria x

Low Noise Tria x

Low Noise Tria x 3-slot male triax 3-slot triax 0.15 0 .5 6430

4-cable Set Coax SMB female BNC male 0.6 2 717 3-50

Mass Terminated Assembly Twisted pair (25) D-sub male D-sub female 2 6.6 7703, 7705, 7707, 7709

5 SMA to BNC Cables Coax SMA Male BNC Female 0.15 0.5 7711

SMA Cables Coax SMA Male SMA Male 1 3.3 7711, 7712, System 46, System 46T

BNC Coax BNC Male Alligator clips 0.9 3 Instruments with 2-slot BNC connectors

Safety Ground Wire Single wire Crimp lug Crimp lug 3 10 8007

LIV Cable Multiple conductor DB9 female

1kV Test Cables Single wire (2) Safety banana Safety banana 1 3.3 2 410, 6487, 6517A , 6517B

Shielded Coax Dua l banan a plug Dual banana plug 1.2 4 Bind ing post inputs

RG58 RG58 BNC male BNC male 1.5 5 4200-SCS

Digital I/O Shielded DB25 m ale DB25 female 1.5 5 Series 2600B, Series 3700A

Crossover Cable Twisted pai r RJ45 R J45 3 10

Temperature Control Cable Multiple conductor DB15 female

Dual Temperature Control
Cable

RG18 8 Coax SMA male SMA male 2 6 .5 4200-SCS

RG18 8 Coax SMA male SMA male 0.15 0.5 4200-SCS

RG18 8 Coax SMA male SM A male 0.33 1.08 4200-SCS

Cable Assembly Coax SMA male SMA male 3 9.8 4210-CVU

Cable Assembly Coa x SMA male SMA male 1.5 5 4210-CV U

RG18 8 Coax SMA male SMA male 0.108 0.35 4200-SCS

RG18 8 Coax SMA male SMA male 0.203

Cable Assembly Multiple conductor 8-pin receptacle 8-pin receptacle 1 3.3 2651A, 8011

Cable Assembly Multiple conductor 8-pin receptacle 8-pin receptacle 2 6.6 2651A, 8011

Cable Assembly Multiple conductor 8-pin receptacle 8-pin receptacle 3 10 2651A, 8011

Interlock Cable Twisted pair (2) 25-pin D-sub 3-pin 1, 2, 3

Black Banana Jumper Jumper Banana Banana 0.102 4 in. 8010

Red Banana Jumper Jumper Banana Banana 0.102 4 in. 8010

Banana Plug Jumper Cable Jumper

Banana Plug Jumper Cable Jumper Banana Banana 0.203 8 in.

Black Banana Jumper Jumper Banana Banana 0.203 8 in. 8010

Red Banana Jumper Jumper Banana Banana 0.203 8 in. 8 010

Black Safety Banana Plug
Jumper Cable

Red Safet y Banana Plug
Jumper Cable

TERMINATIONS LENGTH

Shielded banana plug
cabl es (6)

3-slot

male triax 3-slot male triax

male triax 3-slot male triax

3-slot

male triax 3-slot male triax

3-slot

male triax 3-slot male triax

3-slot

male triax 3-slot male triax

3-slot

male triax 3-slot male triax

3-slot

Multiple terminations:
Triax (2500), 2 dual
bananas (24XX) GND wire

8-position Phoenix
(CS-846 equivalent)

Multiple conductor DB15 female

Banana Banana 0.203 8 in.

Jumper Banana Banana 0.254 10 in.

Jumper Banana Banana 0.254 10 in.

Y cable to two 8-position
Phoenix (CS-846)

2 6.6 Series 2400

0.3 1 2635B, 2636B, 6482, 6 487, 6514, 6517A, 6517B, 7072, 7174A

0.9 3 2635B, 2636B, 6482, 6487, 6514, 6517A, 6517B, 7072, 7174A

1.5 5 2635B, 2636B, 6 482, 6487, 6514, 6517A, 6517B, 7072, 7174A

3 10 2635B, 2636B, 6482 , 6487, 6514, 6517A, 6517B, 7072, 7174A

4 12 2635B, 2636B, 6482, 64 87, 6514, 6517A, 6517B, 7072, 7174A

6.1 20 2635B, 2636B, 6482, 6487, 6514, 6517A, 6517B, 7072, 7174A

1.8 6 2500, Series 2400, System 25, 8544, 8544-TEC

1.8 6 2510, 8 544

1.8 6 2510, 8544, 8544-TEC

8 in.

3.3, 6.6,
10

USE WITH:From To m ft

Series 2600B, 2701, 3390, Series 3700A,

6221, all TSP-enabled instruments

4200-SCS

Series 2600B, 2657A

8010

8010

8010

8010

Cables

ACCESSORIES

A Tektronix Company

Cables

Model Description Type

CA-563C

CA -567-0A

CA -567-2A

CA-568-X A

HV- CA-554-x

HV- CA -571-3

S46- SM A-0.5

S46 -SMA -1

SC-9

SC-22

SC-93

SC-182

SC-200A

SC-206

SHV- CA-553-x

USB-B-1

BNC to Banana Jumper Jumper BNC Banana 0.241 9.5 i n.

Black Banana Jumper Jumper Banana Banana 0.203 8 in. 8010

Red Banana Jumper Jumper Banana Banana 0.203 8 in. 8 010

Protective Earth Ground Safety Eye lug Eye lug 0.3, 0.45, 3 1, 1.5, 10

3kV Rated High voltage Tri ax Triax

High Voltage Triax Tr iax Unterminated 2657A

SMA Cable Coax SMA Male SMA Male 0.15 0 .5 7711, 7712, System 46, System 46T

SMA Cable Coax SMA Male SMA Male 0.30 1.0 7711, 7712, System 46, System 46T

Low Noise Coax Unterminated Unterminated Sold by the foot

Low Noise Tria x Unterminated Unterminated Sold by the foot CS -631

Low Thermal Shielded Unterminated Unterminated Sold by t he foot 2182 -KIT

Low Inductance Coa x Unterminated Unterminated Sold by the foot 2302, 2303, 2303 -PJ, 2304A , 2306, 2306-PJ

General Purpose Shielded twisted pair Unterminated Unterminated Sold by the inch Series 2600B

High Current Coax Cable Coax

3kV Rated High voltage Triax SHV

USB Cable Coax USB Type A USB Type B 1

TERMINATIONS LENGTH

0.5, 1,

1.6, 3.3,

2, 3

Unterminated Unterminated

Sold by the inch 2 651A

3.3, 6.6,

1, 2,

3

USE WITH:From To m ft

8010

8010

8010, 2657A

6.6, 10

2657A

10

2100, Series 2200, 3390, Series 3700A, Ser ies 2600, 2450

3.3

Cables

Model 236-ILC-3 Safety Interlock Cable:
Designed to connect the lid interlock circuit of
the Models 8007 and 8008 test fixtures to the
interlock circuit of the Model 237 SMU and 486
and 487 Picoammeters.

For use with: 4200-SCS, 8007, 8008

Model 2000-MTC-2 Cable Assembly: 2-meter
cable with a 44-pin connector on one end that is
designed to mate with the 2000-20 scanner card.
The other end is unterminated for direct connec­tion to measurement fixtures or devices.

For use with: 2000-20

Cables

Model 2107-* Low-Thermal Input Cables with
Spade Lugs: An input cable terminated with a

LEMO connector on one end and four copper
spade lugs on the other.

2107-4 1.2m (4 ft) length
2107-30 9.1m (30 ft) length
2107-50 15m (50 ft) length

For use with: 2182A, Series 2200

Model 237-ALG -*: Low noise triax cable (SC-22)
terminated with a 3-slot male triax connector on
one end and 3 alligator clips on the other.

237-ALG-2 2m (6.6 ft) length
237-ALG-15 15m (50 ft) length

For use with: Series 2200, Series 2600B,

ACCESSORIES

4200-PA, 6220, 6221, 6487, 6514, 6482,
6517A , 6517B

Model 2000-MTCD-2 Cable Assembly: 2-meter
cable with a 44-pin connector on one end that
is designed to mate with the 2000-SCAN-20
scanner card. The other end is equipped with a
50-pin D-sub male connector.

For use with: 2000-SCAN-20

Model 2260-005: Cable, 0.5m (1.6 ft.), to
connect two Series 2260B power supplies
in series.

For use with: Series 2260

A Tektronix Company

Cables

Model 2260-006: Cable, 0.5m (1.6 ft.), to
connect two Series 2260B power supplies
in parallel.

For use with: Series 2260

Cables

Model 2260-007: Cable, 0.5m (1.6 ft.), to
connect three Series 2260B power supplies
in parallel.

For use with: Series 2260

Model 2290-5-MHV: 3m (10 ft) of RG-8A/U
coaxial cable terminated with a SHV female con­nector on one end and a MHV male connector
on the other end. Maximum operating voltage
is 5000Vrms. Characteristic cable impedance
is 50Ω.

For use with: 2290-5

Model 2290-5-SHV: 3m (10 ft) of RG-8A /U
coaxial cable terminated with a SHV female
connector on both ends. Maximum operating
voltage is 5000Vrms. Characteristic cable impe­dance is 50Ω.

For use with: 2290-5

Model 2290-10-SHV: 3m (10 ft) of RG-213/U
coaxial cable terminated with a SHV male con­nector on both ends. Maximum operating volt­age is 10,000Vrms.

For use with: 2290-10, 2290-10-SHVBH

Model 2290-10-SHVUC: 3m (10 ft) of RG-213/U
coaxial cable terminated with a SHV male con­nector on one end and unterminated cable on
the other end. Maximum operating voltage is
10,000Vrms.

For use with: 2290-10

Model 2290-INT-CABLE: Safety interlock cable,

3.05m (10 ft). 3-conductor cable with 3-pin con­nector on one end and unterminated wires on
the other end.

For use with: 2290-5, 2290-10

Model 2450-TR X-BA N: For adapting the Model
2450’s rear panel triaxial connectors to banana
jack inputs. Length: 0.3m (1 ft).

For use with: 2450

Cables

Model 2600-ALG-2: 2m (6.6 ft) cable terminated
with a 3-slot male triax connector on one end
and 3 alligator clips on the other.

For use with: 2635B, 2636B, 4200-PA

A Tektronix Company

ACCESSORIES

Cables

Model 2651A-KIT-*: High current, low impe­dance, coaxial cable assembly.

2651A- K IT-1: 1m (3.3 ft).
2651A- K IT-2: 2m (6.6 ft).
2651A- K IT-3: 3m (10 ft).

Cables

For use with: 2651A, 8011

Model 3720-MTC-*: 78-pin D-sub female to
78-pin D-sub male cable.

3720-MTC-1.5: 1.5m (5 ft) length
3720-MTC-3: 3m (10 ft) length

For use with: 3720, 3723, 3724

Model 3721-MTC-*: 50-pin D-sub female to
50-pin D-sub male cable.

3721-MTC-1.5: 1.5m (5 ft) length
3721-MTC-3: 3m (10 ft) length

For use with: 3721, 3730, 3731, 3740, 3750

Model 3722-MTC-*: 104-pin D-sub male to
104-pin D-sub female cable.

3722-MTC-1.5: 1.5m (5 ft) length
3722-MTC-3: 3m (10 ft) length

For use with: 3722

Model 3722-MTC-*/MM: 104-pin D-sub male to
104-pin D-sub male cable.

3722-MTC-1.5/MM: 1.5m (5 ft) length
3722-MTC-3/MM: 3m (10 ft) length

For use with: 3722

Model 3732-MTC-*: 78-pin D-sub female to
78-pin D-sub male cable.

3732-MTC-1.5: 1.5m (5 ft) length
3732-MTC-3: 3m (10 ft) length

For use with: 3732

Model 4200-MTR X-*: Ultra low noise SMU triax
cable is terminated with a miniature male triax
connector on one end and a standard 3-slot
male triax connector on the other end. This
cable connects a Model 4200-SMU or 4210-SMU
source measurement unit installed in a Model
4200-SCS to a test fixture. (4200-MTRX-* cables
are intended only for connection to an SMU that
does not have a 4200-PA PreAmp installed.)

4200 -MTR X-1: 1m (3.2 ft)
4200-MTRX-2: 2m (6.5 ft) (two included with

each 4200-SCS SMU not configured with a
4200-PA Remote PreAmp)

4200-MTRX-3: 3m (9.8 ft)

For use with: 4200-SCS

Model 4200-PRB-C: SMA to SSMC Y adapter
cable with local ground that connects the
4200-PIV package to DC probe manipulators.
The cable is terminated at one end with a sin­gle female SMA. The other end splits into two
gold SSMC plugs (female connectors) and a
black wire with integrated connector, which is
used to connect to the shield of another Model
4200-PRB-C cable.

For use with: 4200-PIV, 4210-CVU

Cables

ACCESSORIES

A Tektronix Company

Cables

Model 4200-RPC-*: Remote PreAmp cable
terminated at each end with a high density
DB15 connector. This cable connects a Model
4200-SMU or 4210-SMU source measurement
unit installed in a Model 4200-SCS to a remotely
mounted Model 4200-PA PreAmp.

4200-RPC-0.3: 0.3m (1 ft) (for use inside prober
shield)

Cables

4200-RPC-2: 2m (6.5 ft) (one included with each
420 0-PA)

4200-RPC-3: 3m (9.8 ft)
4200-RPC-6: 6m (19.6 f t)

For use with: 4200-PA

Model 4801 Input Cable: Low noise coax cable,

1.2m (48 in) in length, with male BNC con nec­tors on each end.

For use with: 6482, 6485

2 Slot Tria x

Model 6011 2-slot Triax Cable: 1.5m (5 ft) of
tri ax cable (SC-22) ter mi nat ed with a 2-slot triax
plug on one end and three alligator clips on the
other. Also available in 3m (10 ft) length (Model

6011-10).

For use with instruments with 2-slot triax
connectors

Cables

Model 4200 -TRX-*: Ultra low noise PreAmp
triax cable terminated with a standard 3-slot
male triax connector on each end. This cable
connects a Model 4200-PA PreAmp option
installed in the Model 4200-SCS to the
test fixture.

4200-TRX-0.3: 0.3m (1 ft) (recommended for
remote location of the 4200-PA)

4200 -T R X-1: 1m (3.2 ft)
4200-TR X-2: 2m (6.5 ft) (two included with each

Model 4200-PA)
4200-TRX-3: 3m (9.8 ft)

For use with: 4200-PA

Model 4802-10: 3m (10 ft) of low noise coax
cable with male BNC connector at one end and
unterminated at the other.

For use with: 6482, 6485

Model 4803 Low Noise Cable Kit: In cludes
15m (50 ft) of low noise coax cable, 10 male BNC
con nec tors, and 5 female BNC chassis-mount
connectors.

For use with: 6482, 6485

Model 6517-ILC-3 Interlock Cable: De sign ed to
connect the Interlock of the 6517A with the 8009
test fixture. Configuring the 6517A with the 8009
test fixture results in all the elec trode constants
already being programmed into the unit.

For use with: 6517A Electrometer, 8009

Model 6517B-ILC-3 Interlock Cable: De sign ed
to connect the interlock of the 6517B with the
8009 test fixture. Configuring the 6517B with the
8009 test fixture results in all the elec trode con
stants already being programmed into the unit.

For use with: 6517B Electrometer, 8009

-

ACCESSORIES

A Tektronix Company

Cables

Model 7009-5 Shielded RS-232 Cable: 1.5m

Cables

(5 ft) RS-232 cable with a male DB-9 connector
at one end and a female DB-9 connector on the
other end. Wired as a straight through, not as a
null modem cable.

For use with: All RS-232 capable instruments

Model 7020-MTC-2: 2m (6.6 ft) mass terminat­ed cable assembly for connection to 7020. The
cable has 45 pairs with outer shield. The cable is
terminated at each end with 96-pin female DIN
connectors with strain relief.

For use with: 7020

2 Slot Tria x

Model 7025-10 2-slot Triax Cable: 3m (10 ft)
low noise triax input cable (SC-22) terminated
on one end with 2-slot male triax connector.

For use with instruments with 2-slot triax
connectors

Cables

7022

Model 7019C-MTCI-2 6-wire Kelvin Ex tend er
and Instru ment Cable: Used with Model

7019-C 6-Wire Ohms Matrix Card and a
SourceMeter SMU instrument. The Source Meter
cables are 0.6m (2 ft) long and the DUT cables
are 2m (6.6 ft) long. The cable set is used in a
basic system to test a resistor network.

For use with: Series 2400 SourceMeter SMU
Instruments

ACCESSORIES

2 Slot Tria x

Model 7024-* 2-slot Triax Cable: Low noise
triax cable (SC-22) with 2-slot male triax connec­tors on each end.

7024-3 0.9m (3 ft)
7024-10 3m (10 ft)

For use with instruments with 2-slot triax
connectors

Model 7051- *: General purpose BNC to BNC
cable (G-58C).

7051-2 0.6m (2 ft)
7051-5 1.5m (5 ft)
7051-10 3m (10 ft)

For use with: 2015, 2016, 3390, 7711, some
instrument external trigger I/O lines

Model 7078-DIN: This 1.8m (6 ft) cable ac ces­sory connects between Model 707A main frames
when operated as one unit in Master/Slave
mode. One cable is required for each mainframe.

For use with: 707A

A Tektronix Company

Cables

Model 7078-MTC-5: 1.5m (5 ft) mass terminated
cable for connection to column inputs (7071 and

Cables

7071-4). Also used for matrix expansion (7071,
7071-4, or 7074). The cable has 12 sets of shielded
twisted pair wires for isolation of critical circuits
and noise rejection in the system. The cable is ter
minated at each end in a 38-pin connector block
with strain relief. Model 7078-MTC-20 can be
used as is or cut in half to make two 10 ft cables.

For use with: 7071, 7071-4, 7074-D

3 Slot Tria x

Model 7078-TRX-* 3-slot Triax Cables: Low
noise triax cables terminated at both ends in
3-slot male triax connectors.

7078-TR X-1 0.3m (1 ft)
7078 -TRX-3 0.9m (3 ft)
7078 -TRX-5 1.5m (5 ft)
7078-TR X-10 3.0m (10 ft)
7078-TR X-12 3.5m (12 ft)
7078 -TRX-20 6.0m (20 ft)

For use with: 2635B, 2636B, 6220, 6221, 6482,
6487, 6514, 6517A , 6517B, 7072, 7174A

Model 7078-TRX-6IN 3-slot Triax Cable: 0.15m
(6 inch), 3-slot, low-noise, guarded triax cable that
minimizes leakage current and input capacitance
when used with the Model 6430 Remote PreAmp
(lower noise than 1 foot or longer versions).

For use with: 6430

-

Model 7173-50-CSEP: The 7173-50-CSEP cable
set provides the capability to expand a switching
configuration to include more than one 7173-50.
Each set contains four 0.6m (25 in) cables. One
cable is required to expand each row or column
connection between adjacent cards. For exam­ple, using two 7173-50 cards to create a 4×24
matrix would require connecting the rows of
two adjacent cards together. One 7173-50-CSEP
set has enough cables to do this. Connecting the
12 columns together on two adjacent cards cre­ates an 8×12 matrix. This would require three
7173-50-CSEP sets, 12 cables.

For use with: 7173-50

3 Slot Tria x

Model 7705-MTC-2: 2m (6.6 ft) 50-conductor
male to female D-sub cable assembly.

For use with: 7703, 7705, 7707, 7709, 7701

Cables

Model 7707-MTC-2: 2m (6.6 ft) 25-conductor
male to female D-sub cable assembly.

For use with: 7701, 7707, 7709

Model 7711-BNC-SM A: Male SMA to female
BNC cables (5 each), 0.15m (0.5 ft) in length.

For use with: 7711

A Tektronix Company

ACCESSORIES

Cables

Model 7712-SMA-1: SMA cable, male to male,
1m (3.3 ft).

For use with: 7711, 7712, System 46,
System 46T

Cables

Model 8542-301: 1.8m (6 ft) LIV test system
cable.

For use with: Series 2400, 2500, System 25,
8544, 8544-TEC

Item shipped may
vary from mode l
pictured here.

CA-19-2: 1.5m (5 ft) RG58 cable terminated with
a BNC male plug on each end.

For use with: 4200-SCS

Cables

Model 7754-3 BNC to Alligator Cable: 0.9m
(3 ft) terminated on one end with a BNC plug
and on the other with two alligator clips.

For use with instruments with 2-slot BNC
connections

Model 8007- GND-3: Safety ground wire, 3m
(10 f t).

For use with instruments with a safety
ground connector

ACCESSORIES

Model 8607 1kV Source Banana Cable Set:
The 8607 cable set is made up of one red and
one black high voltage test lead with fixed safety
banana plug ends. The leads are 1 meter (3.3 ft)
long and have a voltage rating of 1500V DC.

For use with: 2410, 6487, 6517A, 6517B

Item shipped may vary from
model pictured here.

CA -18 -1: 1.2m (4 ft) shielded cable te r m i nat ed
with a dual banana plug on each end. For use
with binding post inputs or dual banana jacks.

For use with: Binding post inputs

CA-126-1A Digital I/O Cable: 1.5m (5 ft) of
cable, from DB25 male to DB25 female.

For use with: Series 2600B, Series 3700A

CA -180-3A: 3m (10 ft), CAT5 crossover cable for
Ethernet or TSP-Link.

For use with: Series 2600B, 2701, 3390,
Series 3700A, 6221, all TSP-Link enabled
instruments

CA -321-1: Temperature control cable.

For use with: 2510, 8544

A Tektronix Company

Cables

CA -322-1: Dual temperature control cable.

For use with: 2510, 8544, 8544-TEC

Cables

CA-404B: 2m (6.5 ft) RG188 coax cable termi­nated with an SMA male plug on each end, 50Ω
impedance.

For use with: 4200-SCS, System 46,
System 46T

CA-406B: 33cm (13 in) RG188 coax cable termi­nated with an SMA male plug on each end, 50Ω
impedance.

For use with: 4200-SCS

CA-446A: 3m (9.8 ft) coax cable terminated
with an SMA male plug on each end, 100Ω
impedance.

For use with: 4210-CVU

CA- 451A : 10.8cm (4.25 in) RG188 coax cable
terminated with an SMA male plug on each, 50Ω
impedance.

For use with: 4200-SCS

Cables

CA-452A : 20.4cm (8 in) RG188 coax cable termi­nated with an SMA male plug on each end, 50Ω
impedance.

For use with: 4200-SCS

CA-405B: 15cm (6 in) RG188 coax cable termi­nated with an SMA male plug on each end, 50Ω
impedance.

For use with: 4200-SCS

CA- 447A: 1.5m (4.9 ft) coax cable terminated
with an SMA male plug on each end, 100Ω
impedance.

For use with: 4210-CVU

CA-557-*: 8-pin male to 8-pin male cable assem­bly with straight through pin configuration.

CA -557-1: 1m (3.3 ft)
CA-557-2: 2m (6.6 ft)
CA-557-3: 3m (10 ft)

For use with: 2601B, 2602B, 2611B, 2612B,
2651A SourceMeter® SMU Instruments, 2600­PCT-x, 4200-PCT-x, 8010

ACCESSORIES

A Tektronix Company

Cables

CA-558-2: 25-pin D-sub to 3-pin interlock cable
assembly.

For use with: Series 2600B, 2600-PCT-x,

Cables

2651A, 2657A, 4200-SCS, 4200-PCT-x, 8010

CA-559-0A and CA-559-2A: Banana to banana
jumper (102mm).

For use with: 2600-PCT-x, 4200-PCT-x, 8010

CA-560-0A and CA-560-2A: Banana to banana
jumper (203mm).

For use with: 2600-PCT-x, 4200-PCT-x, 8010

CA-562-0B and CA-562-2B: Safety banana to
banana jumper (254mm).

For use with: 2600-PCT-x, 4200-PCT-x, 8010

CA-563C: BNC to banana jumper (240mm).

For use with: 2600-PCT-x, 4200-PCT-x, 8010

HV- CA-554-x: High voltage triax to triax cable
(3kV rated) (x = 0.5, 1, 2, or 3m).

For use with: 2657A, 2657-LIM-3,
2657- PIM-200, 8010

Cables

HV-CA-571-3: High voltage triax to untermina­ted cable.

For use with: 2657A, 2600-PCT-x, 4200-PCT-x

CA-561-0A and CA-561-2A: Banana to banana
jumper (305mm).

For use with: 2600-PCT-x, 4200-PCT-x, 8010

ACCESSORIES

CA-568-xA: Protective earth safety ground cable
with eye lugs (x = 12, 18, or 120 inches).

For use with: 2657A, 2657-LIM-3,
2657- PIM-200, 8010

SHV-CA-553-x: High voltage triax to SHV cable
(x = 1, 2, or 3m) (3kV rated).

For use with: 2657A

A Tektronix Company

Cables

S46-SMA-0.5: SMA cable, male to male, 0.15m
(0.5 ft).

For use with: 7711, 7712, System 46,
System 46T

SC-22: Low noise triax cable without con nec tors
(sold by the inch).

For use with: CS-631

SC-200A: Shielded twisted pair cable (sold by
the inch). Recommended for general-purpose
use with Series 2600B System SourceMeter SMU
instruments.

For use with: Series 2600B

Cables

S46-SMA-1: SMA cable, male to male, 0.3m (1 ft).

For use with: 7711, 7712, System 46,
System 46T

SC-9: Low noise coax cable without con nec tors
(sold by the foot).

Cables

USB-B-1: USB Cable, 1m (3.3 ft).

For use with: 2100, Series 2200, 3390, Series
3700A, Series 2600, 2450

SC-93: Low thermal, 2-conductor shielded cable,
#22AWG solid copper (sold by the foot).

For use with: 2182-KIT

SC-182: Low inductance (42nH/ft) coaxial cable
for minimizing test lead impedance in circuits
using fast transient response power supplies.
The cable is sold by the foot and comes without
connectors.

For use with: 2302, 2303, 2303-PJ, 2304A,
2306, 2306-PJ, 2306-VS

A Tektronix Company

ACCESSORIES
