Kawai CE200 User Manual
Digital Piano
CE200
Owner’s Manual
CE200
Important Safety Instructions
SAVE THESE INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF
FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN
OR MOISTURE.
AVIS : RISQUE DE CHOC ELECTRIQUE
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the leterature accompanying the
product.
- NE PAS OUVRIR.
Examples of Picture Symbols
denotes that care should be taken.
The example instructs the user to take care not to allow fingers to be trapped.
denotes a prohibited operation.
The example instructs that disassembly of the product is prohibited.
denotes an operation that should be carried out.
The example instructs the user to remove the power cord plug from the AC outlet.
Read all the instructions before using the product.
WARNING - When using electric products, basic precautions should always be followed,
including the following.
WARNING
The product should be connected to
an AC outlet of the specified
voltage.
Indicates a potential hazard that could result in death
or serious injury if the product is handled incorrectly.
● If you are going to use an AC power cord,
120V 240V230V
make sure that its has the correct plug shape
and conforms to the specified power voltage.
● Failure to do so may result in fire.
Do not insert or disconnect the power
cord plug with wet hands.
The chair must be used properly (it must be
used only when playing the product).
● Do not play with it or stand on it.
● Only one person is allowed to sit on it.
● Do not sit on it when opening the lid.
When using the headphones, do not
listen for long periods of
time at high volume levels.
Do not lean against the keyboard.
INTRODUCTION 3
Doing so may cause electric shock.
Doing so may cause the chair to fall over or your
fingers to be trapped, resulting in injury.
Doing so may result in hearing problems.
Doing so may cause the product to fall over,
resulting in injury.
Do not disassemble, repair or modify
the product.
Doing so may result in product breakdown, electric
shock or short-circuit.
When disconnecting the AC power cord's
plug, always hold the plug
and pull it to remove it.
The product is not completely disconnected from the
power supply even when the power switch is turned
off. If the product will not be used for a long time,
unplug the AC power cord from the AC outlet.
● Pulling the AC power cord itself may damage
the cord, causing a fire, electric shock or
short-circuit.
● Failure to do so may cause fire in case of
lightning.
● Failure to do so may over-heat the product,
resulting in fire.
This product may be equipped with a polarized line plug (one blade
wider than the other). This is a safety feature.
If you are unable to insert the plug into the outlet, contact an
electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the plug.
It is a good practice to have the instrument near the AC outlet and the power cord plug in a position
so that it can readily be disconnected in an emergency because electricity is always charging
while the plug is in the AC outlet even in a power switch off condition.
Indicates a potential hazard that could result in injury
CAUTION
Do not use the product in the following areas.
● Areas, such as those near windows, where the product is
exposed to direct sunlight
● Extremely hot areas, such as near a heater
● Extremely cold areas, such as outside
● Extremely humid areas
● Areas where a large amount of sand or dust is present
● Areas where the product is exposed to excessive
vibrations
or damage to the product or other
Using the product in such areas may result in
product breakdown.
Use the product only in moderate climates (not
in tropical climates).
When you close the keyboard cover,
close it gently.
Before connecting cords, make sure
that the power to this product
and other devices is turned
OFF.
Take care not to allow any foreign
matter to enter the product.
Do not drag the product on the floor.
Take care not to drop the product.
Do not place the product near electrical
appliances such as TVs and
radios.
When connecting the AC power cord
and other cords, take care
not to get them tangled.
Closing it roughly may trap your fingers, resulting
in injury.
OFF
Failure to do so may cause breakdown of this
product and other devices.
Entry of water, needles or hair pins may result
in breakdown or short-circuit.
The product shall not be exposed to dripping or
splashing. No objects filled with liquids, such as
vases, shall be placed on the product.
Please lift up the product when moving it.
Please note that the product is heavy and must
be carried by more than two persons.
Dropping the product may result in breakdown.
● Doing so may cause the product to generate
noise.
● If the product generates noise, move the
product sufficiently away from the electrical
appliance or connect it to another AC outlet.
Failure to do so may damage them, resulting in
fire, electric shock or short-circuit.
4
KAWAI DIGITAL PIANO CE200
Notes on Repair
Should an abnormality occur in the product, immediately turn the power OFF, disconnect the
power cord plug, and then contact the shop from which the product was purchased.
The product should be serviced by qualified service personnel when:
●
The power supply cord or the plug has been damaged.
●
Objects have fallen, or liquid has been spilled into the product.
●
The product has been exposed to rain.
●
The product does not appear to operate normally or exhibits a marked change in
performance.
●
The product has been dropped, or the enclosure damaged.
Do not place naked flame sources, such as lighted candles on the product.
● Doing so may cause the product to become
deformed or fall over, resulting in breakdown
or injury.
Do not stand on the product or exert
excessive force.
The product should be located so that its location or position does not interfere with its proper
ventilation. Ensure a minimum distance of 5cm around the product for sufficient ventilation.
Ensure that the ventilation is not impeded by covering the ventilation openings with items,
such as newspaper, table-cloths, curtains, etc.
This product should be used only with the stand that is provided by the manufacturer.
CAUTION:
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION:
Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqu'au fond.
Instruction for AC power cord (U.K.)
Do not plug either terminal of the power cord to the ground of the AC outlet on the wall.
Canadian Radio Interference Regulations
This instrument complies with the limits for a class B digital apparatus, pursuant to the Radio Interference
Regulations, C.R.C., c. 1374.
● Doing so may result in discoloration or deformation
of the product.
● When cleaning the product, put a soft cloth in
lukewarm water, squeeze it well, then wipe the
product.
Do not wipe the product with benzene
or thinner.
An information on Disposal for users
If your product is marked with this recycling symbol it means that, at the end of its
life, you must dispose of it separately by taking it to an appropriate collection point.
You should not mix it with general household waste. Disposing of this product correctly
will prevent potential negative effects on the environment and human health which
could otherwise arise due to inappropriate waste handling.
For further details, please contact your local authority.
(European Union only)
INTRODUCTION 5
N
p
FCC Information (U.S.A)
OTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
ursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING:
could void the userís authority to operate the equipment.
Changes or modifications not expressly approved by the party responsible for compliance
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Model Name : CE200
Responsible Party Name : Kawai America Corporation
Address :
Telephone : 310-631-1771
This applies only to products distributed by Kawai America Corporation.
2055 East University Drive Rancho
Dominguez, CA 90220
6
KAWAI DIGITAL PIANO CE200
THANK Y OU FOR PURCHASING A KAWAI DIGITAL PIANO!
The Kawai digital piano is a revolutionary new keyboard instrument that
combines the latest in electronic advances with traditional craftsmanship
inherited from Kawai’s many years of experience in building fine pianos.
Its keyboard provides the touch response and full dynamic range required
for a superb performance on the piano, harpsichord, organ, and other
instruments. In addition, the CE200 piano is equipped with reverb and a
digital effect processor for an even fuller sound. Industry-Standard MIDI
(Musical Instrument Digital Interface) jacks are included which allow you
to play other electronic instruments at the same time—opening a whole
new world of musical possibilities.
This Owner’s Manual contains valuable information that will help you
make full use of this instrument’s many capabilities. Please read all
sections carefully and keep this manual handy for further reference.
READ ME FIRST
Before beginning the assembly of your CE200 read and become familiar with the assembly instructions
that follow. Then, carefully unpack the piano and check your unit against the parts list.
PARTS PROVIDED
Side Panel (A) 2 pcs.
Back Board (B) 1 pc.
Pedal Board (C) 1 pc.
Screw D (M6 x 25) 4 pcs.
Screw E (M4 x 12) 4 pcs.
Screw F (ø4 x 20) 4 pcs.
Screw G (ø4 x16) 10 pcs.
Adjuster (H) 1 pc.
Headphone Hook 1 pc.
Screw (ø4 x 14) 2 pcs.
M6x25
(D)
M4x12
(E)
ø4x20 ø4x16
(F) (H)
(G)
Adjuster
INTRODUCTION 7
(G)
(A)
Pedal Unit
Bottom View
(H)
(H)
(C)
1. Insert the Adjuster (H) on the Pedal Unit.
2. Untie the pedal cable on the bottom of the Pedal Board (C).
3. Fasten the Side Panels (A) and the Pedal Board (C) with five screws (G) on both the left and right
side of the instrument (totalling ten screws).
(E)
4. Hold the Back Board (B) behind the Pedal
Board (C) and in front of the fixing metal of
the Side Panels (A).
5. Fasten the Side Panels (A) and Back Board
(A)
(B)
(F)
(B) with two screws (E) on both side of the
instrument (totalling four screws).
6. Fasten the Pedal Board (C) and Back
Board (B) with four screws (F).
(C)
CAUTION:
To prevent personal injury, do not handle the main unit from the ends.
7. The next step requires one person on each end of the main unit.
Grasp the unit with both hands, one under the front, the other under
the rear (remember, not the end) and carefully center the main unit on
top of the stand so that the hook brackets located on the bottom rear
of the main unit are inside the stand side panels (A) and approximately
one-third of the rear, top edge of the side panels are exposed. (See the
illustration to the right)
(D)
8. Maintaining a firm grasp under the front of the main, unit slide it
toward the rear of the stand until the hook brackets engage the brackets
at the rear top of the side panels (A). This hook arrangement is design
(A)
to prevent the main unit from tilting forward while the screws are
installed. Keep one hand under the front of the main unit, push down
on the front to be certain that hooks are properly engaged.
9. Fasten the main unit and the stand with four screws (D).
8 KAWAI DIGITAL PIANO CE200
CAUTION:
Be sure to secure the main unit to the stand with the screws. If you fail to do so, the unit could fall
from the stand causing damage or personal injury.
10. Insert the pedal connection cord that comes from Pedal
Board into the main unit’s pedal jack and fix with the clamp of
the Side Panel.
11. Turn the adjuster (installed on the bottom of the Pedal Unit)
down until it makes firm contact with the floor. If the floor is
carpeted, place a spiked furniture cup under the adjuster so that
it makes firm contact with the carpet backing. Press any pedal
with your foot. If the pedal rail flexes, lower the adjuster until
flexing is minimized.
CAUTION:
Before moving your piano, turn the adjuster up so that it clears the floor.
ATTACHING THE HEADPHONE HOOK
1. Attach the Headphone Hook with two screws
(ø4 x 14) to the holes next to the headphone jacks.
Headphone Hook
Headphone Jacks
Screws
ø4 x 14
9INTRODUCTION
1. Quick Start p. 12
1.1 S
ETTING UP THE PIANO
1.2 P
OWER SWITCH
1.3 V
OLUME SLIDER
1.4 H
EADPHONES
1.5 D
EMO SONGS
1.6 P
LAYING THE PIANO
1.7 P
EDALS
1.8 P
LAYING WITH MORE SOUNDS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. Advanced Playing p. 15
2.1 V
ALUE BUTTONS
2.2 D
UAL
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3 S
PLIT
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 F
OUR HANDS MODE
2.5 D
UAL/SPLIT BALANCE SLIDER
2.6 E
FFECTS/REVERB
2.7 V
OICING
2.8 M
ETRONOME
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3. Recorder p. 22
B
ASICS OF THE RECORDER
3.1 R
ECORDING
3.2 P
LAYING BACK A SONG
3.3 E
RASING A SONG
(REC B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
UTTON
) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
(PLAY/STOP B
UTTON
) . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4. Piano Music p. 27
10
5. Function Buttons p. 28
5.1 S
ELECTING THE TOUCH SENSITIVITY
5.2 T
RANSPOSING THE PIANO
THER FUNCTIONS
5.3 O
1. B
2. T
3. D
4. S
5. T
6. L
7. MIDI C
8. S
9. L
10. T
11. M
12. C
13. L
14. L
15. L
16. D
17. U
RILLIANCE
UNING
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
AMPER RESONANCE
TRING RESONANCE
EMPERAMENT
OWER OCTAVE SHIFT
HANNEL
ENDING PROGRAM CHANGE NUMBERS
OCAL CONTROL ON/OFF
RANSMIT PROGRAM CHANGE ON/OFF
ULTI-TIMBRAL ON/OFF
HANNEL MUTE
OWER PEDAL ON/OFF
AYER OCTAVE SHIFT
AYER DYNAMICS
AMPER HOLD
SER MEMORY
(TOUCH & TRANSPOSE B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
/ F
ACTORY RESET
(T
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
(TOUCH B
RANSPOSE BUTTON
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
UTTON
) . . . . . . . . . . . . . . 28
). . . . . . . . . . . . . . . . . . . 29
UTTONS
) . . . . . . . . . . . 30
6. Using MIDI p. 42
U
NDERSTANDING
6.1 U
SING THE
6.2 U
SING THE
MIDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
CE200 P
CE200 P
IANO AS CONTROLLER
IANO AS A MULTI-TIMBRAL SOUND MODULE
. . . . . . . . . . . . . . . . . . . . . . 44
. . . . . . . 47
7. Jacks p. 50
MIDI J
USB J
LINE OUTJ
LINE IN J
HEADPHONE J
ACKS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
ACK
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
ACKS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
ACKS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
ACKS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8. Appendices p. 54
P
ROGRAM CHANGE NUMBER MAPPING
R
HYTHM STYLE LIST
P
IANO MUSIC LIST
F
RONT PANEL
S
OUND DEMO SONG LIST
S
PECIFICATIONS
MIDI E
MIDI I
XCLUSIVE DATA FORMAT
MPLEMENTATION CHART
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
11
Quick Start
1. QUICK START
1.1 SETTING UP THE PIANO
The first thing you’ll need to do before playing the piano is to set up the
instrument.
ASSEMBLING THE STAND
First, you need to assemble the stand unit. Assemble the stand following
the instructions at the beginning of this manual.
SUPPLYING AC POWER
The CE200 piano is equipped with stereo speakers and an amplifier. You
do not need any other equipment to play your piano. You can enjoy the
CE200 piano wherever AC power is available. Simply connect the power
cable that comes with the CE200 piano to an AC outlet.
Connect the AC power cable to the piano’s power jack and the
other end of the cable to the AC outlet on the wall.
1.2 POWER SWITCH
Press this button to turn on the power.
Pressing it again will turn off the power.
1.3 VOLUME SLIDER
1.4 HEADPHONES
1.5 DEMO SONGS
Pressing this button while holding down the REC and PLAY/STOP buttons
will erase all the songs currently stored in the Recorder. (See page 26.)
This slider controls the master volume level of the piano’s sound.
Move this slider to the right to increase the volume and move to
the left to decrease the volume.
This slider also controls the headphone’s volume and the LINE output
level of the piano’s sound.
For private performances you may want to use the headphones. The
speakers will be turned off automatically when the headphones are
plugged in, and the CE200 piano will only be heard through the
headphones. The CE200 piano has two headphones jacks.
The CE200 has 18 built-in sound demo songs. Each of the demo songs
presents a musical piece to introduce the different preset sounds.
12 KAWAI DIGITAL PIANO CE200
Press the DEMO button and the demo song for the Piano 1 category
will start. After the Piano 1 demo songs are finished playing, the demo
songs for another sound category will be selected at random.
If you would like to listen to the demos for a particular category, just
press the desired SOUND SELECT button while the demo is playing. When
you press the button, the demo will play the demo songs for the newly
selected category. Then the demo songs for another category will be
selected at random. See page 56 for the list of sound demo songs.
1.6 PLAYING THE PIANO
Turning on the power.
You will find the POWER SWITCH at the right end of the front panel.
Press this button to turn on the power. Pressing it again will turn off the
power.
Adjust the volume level.
The VOLUME SLIDER controls the volume level of the speakers and the
headphones. Use this slider to set the volume to a comfortable listening
level.
Quick Start
1.7 PEDALS
Sostenuto
Soft
Sustain
Now try playing the keyboard.
You will hear the CE200’s main piano sound.
The CE200 piano responds just like a real acoustic piano when you play
it. It produces a louder sound when you play hard and a softer sound
when you play soft. The volume level changes in relation to how fast the
keys are pressed. This system is called “touch sensitivity” on an
electronic musical instrument. The initial touch sensitivity setting has
been adjusted to the standard of an acoustic piano. You can however,
select a different type of touch sensitivity on the CE200 piano if you are
not comfortable with the standard setting. For more detail, please read
“5.1 Selecting the Touch Sensitivity (TOUCH Button)” on page 28.
The CE200 piano has three pedals—just like a grand piano. They are
Sustain, Soft and Sostenuto.
The sustain pedal is capable of responding to half pedaling, which provides
even finer control of the dampering effect.
13QUICK START
Quick Start
1.8 PLAYING WITH MORE SOUNDS
You have already heard the CE200’s main piano sound. The CE200 has a
total of 20 sounds, not only different types of piano sounds but different
instruments as well.
The different instrument sounds built into CE200 piano are called “preset
sounds”.
All of the preset sounds have been created through advanced digital
sampling technology achieving as natural and realistic sound as possible.
Let’s try some of the preset sounds.
SELECTING ANOTHER PRESET SOUND
Press the SOUND SELECT button under the name of the
instrument you would like to listen to. When the button is pressed,
the LED indicator will be turned on to indicate that this sound is selected.
The SOUND SELECT buttons are assigned with two or three preset sounds
to select. To select the other sounds, press the button repeatedly.
Sound variation
number 1
When a SOUND SELECT button is pressed, the variation number is briefly
shown in the display. Pressing the same SOUND SELECT button again
will select the next variation sound assigned to the SOUND SELECT
button.
You can also select any preset sounds by using the VALUE buttons.
14 KAWAI DIGITAL PIANO CE200
2. ADVANCED PLAYING
2.1 VALUE BUTTONS
These two buttons are used to change the value for certain functions.
First select the function or option you would like to change the
value for by pressing the appropriate button(s), then use the
VALUE buttons to change the value. “
value and “
These buttons can also be used to select the various sounds. You can
select all of the preset sounds assigned to the eight SOUND SELECT
buttons.
However, Sounds cannot be selected by using the VALUE buttons when
you are in DUAL or SPLIT mode.
2.2 DUAL
Another feature of the CE200 piano is the ability to layer two preset sounds
together to create a more complex sound. For example, piano layered
with strings, electric piano with choir sound, and so on.
” decreases the value.
” button increases the
Advanced Playing
Sound variation
number 1 and 3
are layered.
To layer two sounds, select the first sound and then, while holding
down that SOUND SELECT button, select the second sound by
pressing another SOUND SELECT button. The LED indicators for
each will be turned on to indicate the two sounds you have chosen. The
display briefly shows the combination of the selected sound variation
numbers.
If you want to layer two sounds assigned to the same SOUND SELECT
button, while pressing the desired SOUND SELECT button use the VALUE
buttons to select your desired layered sound.
ABOUT POLYPHONY
The CE200 piano is capable of playing up to 96 notes simultaneously (96note polyphony). When playing in dual mode, or when playing the stereo
piano sound, the polyphony will be reduced by half since the piano has to
produce two sounds for each note.
15ADVANCED PLAYING
2.3 SPLIT
Advanced Playing
Variation 2 for
lower and 1 for
upper.
SELECTING SPLIT SOUNDS
The split function divides the keyboard into two sections—upper and
lower—and lets you play each part with a different sound.
First press the desired SOUND SELECT button to select the upper
sound. Then, while holding down the SPLIT button, press the
desired SOUND SELECT button to select the lower sound. The
LED indicator for the upper sound will be turned on and the LED for the
lower sound will start flashing. The display shows the combination of
the selected sound variation numbers during the SPLIT button is pressed.
The number on the left is for lower sound and the number on the right is
for upper sound.
CHANGING THE SPLIT POINT
The default split point is set between B2 and C3. This point can be moved
to anywhere on the keyboard.
Press the desired key on the keyboard while holding down the
SPLIT button.
The key you pressed becomes the lowermost note for the upper section.
2.4 FOUR HANDS MODE
It is possible to divide the keyboard into left and right sections at the
default split point, and to play both sections in the same key range using
the four hands mode. The key range is lowered by two octaves for the
right section, and raised by two octaves for the left section. When four
hands mode is active, the sustain pedal (right pedal) acts as the sustain
pedal for the right section, and the soft pedal (left pedal) acts as the sustain
pedal for the left section. When four hands mode is active the CE200
functions as two pianos, so you can enjoy duet performances or use one
CE200 piano for two students or a teacher and a student.
ENTERING FOUR HANDS MODE
Press the sustain pedal and the soft pedal while holding down the SPLIT
button. The SPLIT button LED indicator will start blinking and the piano
is now in Four Hands Mode.
16 KAWAI DIGITAL PIANO CE200
EXITING FOUR HANDS MODE
To exit Four Hands Mode, press the SPLIT button again. The LED indicator
will be turned off.
SELECTING SOUNDS IN FOUR HANDS MODE
The method for selecting sounds is the same as in Split Mode. After you
are in Four Hands Mode simply use the SOUND buttons to change the
sound for the upper section. To change the sound for the lower section,
press and hold the SPLIT button and then use the SOUND buttons.
CHANGING SPLIT POINT
The method for changing the split point is the same as in Split Mode.
After you are in Four Hands Mode press and hold the SPLIT button and
press any key on the keyboard. The key you pressed becomes the
lowermost note for the upper section. The default split point is set between
E3 and F3.
OCTAVE SHIFT FOR THE LOWER SECTION
When in Four Hands Mode, you can use the Octave Shift function to change
the octave of the lower section. Please see page 35 for more information
on using Octave Shift.
Advanced Playing
2.5 DUAL/SPLIT BALANCE SLIDER
You can adjust the volume balance between the two sounds in Dual or
Split mode. Use the Dual/Split Balance slider to adjust the balance.
Move the slider to the right to increase the volume of the rightmost sound
(in dual mode) or upper sound (in split mode) and decrease the volume
of the leftmost sound (in dual mode) or lower sound (in split mode). The
balance changes in the opposite way when the slider is moved to the left.
2.6 EFFECTS/REVERB
You might have noticed that when you select some of the preset sounds,
the LED indicator for the EFFECTS or the REVERB is turned on. The
reason for this is some of the preset sounds are set up with an effect on as
their initial setting.
Adding an effect to the sound enhances tonal quality and improves
acoustical realism. The CE200 piano is provided with two separate groups
of effects. The first is reverb and the second contains chorus, delay,
tremolo and rotary speaker.
17ADVANCED PLAYING
Advanced Playing
REVERB
Reverb adds reverberation to the sound, simulating the acoustic
environment of a recital room, stage, or concert hall. There are five types
of reverb available. They are Room 1&2, Stage, and Hall 1&2. (listed in
order of reverberation amount).
CHORUS
Chorus is an effect that simulates the rich character of a vocal choir or
string ensemble, by layering a slightly detuned version of the sound over
the original to enrich it.
DELAY
Delay is an effect that adds echoes to the sound.
TREMOLO
This is a vibrato type effect.
ROTARY
This effect simulates the sound of the Rotary Speaker cabinet commonly
used with electronic organs. Rotary 1 is normal rotary and Rotary 2 is
with distortion effect.
The soft pedal is used to change the speed of the rotor between SLOW
and FAST.
TO ADD REVERB
Press the REVERB button. The LED indicator will be turned on to
indicate that reverb is in use. Press and hold the REVERB button and the
currently selected reverb type will be shown in the display.
Room 1
Room 2
Stage Hall 1 Hall 2
To change the reverb type, use the VALUE buttons while holding down
the REVERB button.
TO ADD OTHER EFFECTS
Press the EFFECTS button. The LED indicator will be turned on to
indicate that the effect is in use. Press and hold the EFFECTS button and
the currently selected effect will be shown in the display.
Delay
TremoloChorus
Rotary 1
Rotary 2
18 KAWAI DIGITAL PIANO CE200
Loading...
