Jwin JD-VD765 User Manual

JD-VD765

P ortable DVD Player

User Guide

Playable Disk Format:
DVD/CD/CD-R/CD-RW

English

JDVD765V10M10EN07262005

Table of Contents

FCC and Safety Information ........................................................................................................... 4

Important Safety Instructions .......................................................................................................... 5

Precautions ...................................................................................................................................... 6

Selecting the type of disc for the type of TV connected .............................................................. 7

Chapter 1. DVD

1-1 DVD Playback ............................................................................................................................ 8

Basic Playback ............................................................................................................................................................................ 8

Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc) ................................................ 8

Stopping Playback....................................................................................................................................................................... 9

Rapid Advance and Rapid Reverse ........................................................................................................................................... 9

Skipping Ahead or Back to Chapters......................................................................................................................................... 9

Still Picture (PAUSE) .................................................................................................................................................................... 9

Repeat Viewing ........................................................................................................................................................................ 10

1-2 Convenient functions .............................................................................................................. 10

Displaying Scene Information ................................................................................................................................................... 10

Changing Audio Soundtrack Language ................................................................................................................................... 10

Clearing/Displaying Subtitles (A) ............................................................................................................................................. 11

Changing Subtitle Language (B) .............................................................................................................................................. 11

Viewing From Another Angle ................................................................................................................................................... 11

Mute the DVD Player ................................................................................................................................................................. 12

Using DVD Menu ....................................................................................................................................................................... 12

Using the Menu Function .......................................................................................................................................................... 12

Chapter 2. Audio CD

2-1 Audio CD Playback.................................................................................................................. 13

Basic Playback .......................................................................................................................................................................... 13

Stopping Playback..................................................................................................................................................................... 13

Rapid Advance and Rapid Reverse ......................................................................................................................................... 13

Skipping Ahead or Back to Tracks........................................................................................................................................... 14

Pause ......................................................................................................................................................................................... 14

2-2 Information [Audio CDs] .......................................................................................................... 14

Displaying Track Information .................................................................................................................................................... 14

Chapter 3. Special Functions

3-1 Playing Kodak Picture CDs .................................................................................................... 15

Basic Playback .......................................................................................................................................................................... 15

Slide Show ................................................................................................................................................................................ 15

Thumbnail Mode ........................................................................................................................................................................ 16

3-2 Playing JPEG picture CDs ...................................................................................................... 17

Basic Playback .......................................................................................................................................................................... 17

File Manager .............................................................................................................................................................................. 17

Thumbnail Mode ........................................................................................................................................................................ 18

En 2

Table of Contents-continued

Chapter 4. Setup

4-1 Language Setup ...................................................................................................................... 19

On Screen Display (OSD) Language Setting .......................................................................................................................... 19

DVD MENU Language Setting .................................................................................................................................................. 20

AUDIO Soundtrack Language Selection [DVD] ....................................................................................................................... 21

SUBTITLE Language Selection [DVD] ...................................................................................................................................... 22

4-2 Screen Setup ........................................................................................................................... 23

TV Type Setting ........................................................................................................................................................................ 23

TV System ................................................................................................................................................................................. 24

Video Out Setting ...................................................................................................................................................................... 25

4-3 AUDIO Setup ............................................................................................................................ 27

Digital Out Setting ...................................................................................................................................................................... 27

Analog Out Setting .................................................................................................................................................................... 28

4-4 Custom Setup .......................................................................................................................... 29

Angle Mark Setting [DVD] ......................................................................................................................................................... 29

Default Setting .......................................................................................................................................................................... 30

4-5 LCD Setup ................................................................................................................................ 31

Panel Setting .............................................................................................................................................................................. 31

Color Setting .............................................................................................................................................................................. 31

Bright Setting ............................................................................................................................................................................. 32

Panel Close Setting ................................................................................................................................................................... 32

Chapter 5. For Your Reference

5-1 Troubleshooting....................................................................................................................... 33

5-2 Disc Handling and Maintenance ............................................................................................ 34

5-3 Definition of Terms .................................................................................................................. 35

NOTICE:
Y ou may experience distortion on image when using a new battery for the first time or using a
battery that has not been used for a long time. In this case, recharge the battery. This is a
normal characteristic for batteries, which is NOT a defect.

En 3

FCC and Safety Information

CAUTION:

This unit employs a laser. Due to possible eye injury, only qualified service personnel should remove the
cover or attempt to service this device. Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation exposure.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Since it is usual for DVD movies to be released at different times in different regions of the world, all players have region
codes and disc can have an optional region code. If you load a disc of a different region code to your player, you will see the
region code notice on the screen. The disc will not play, and should be unloaded.

(Possible region codes:)

There are 6 regions (also called “locals”). Each DVD player and disc will be played in one region ONLY.
1: Canada, U.S., U.S. Territories
2: Japan, Europe, South Africa, Middle East (including Egypt)
3: Southeast Asia, East Asia (including Hong Kong)
4: Australia, New Zealand, Pacific Islands, Central America, Mexico, South America, Caribbean
5: Former Soviet Union, Indian Subcontinent, Africa (also North Korea, Mongolia)
6: China

Never make or change connections with the power switched on.

CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM

(WARNING LOCATION: INSIDE ON LASER COVERSHIELD)

For DVD Players with 525p, but not 625p, progressive scan output:

‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION
TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT
AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE.
IN CASE OF 525 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO
THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING YOUR TV SET COMPATIBILITY WITH THIS MODEL
525p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE
CENTER.’

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Confidential Unpublished Works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved.

En 4

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a damp cloth.

7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with one wider than the
other. The wide blade is provided for your safety. When the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point
where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Unplug this apparatus during lighting storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way; such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.

14. Ambient Temperature 0~40

0

C.

Outdoor use or wet location applications:

An apparatus that does not comply with the requirements in Appendix A# (Outdoor Use and Wet Location Apparatus) shall be
marked or the instruction manual packed with the word “WARNING” and the following or equivalent: “To reduce the risk of fire
or electric shock, do not expose this apparatus to rain or moisture.

A Class II APPARATUS shall be permanently marked with the words “DOUBLE INSULATION” or “Double insulated” and
“When servicing use only identical replacement parts.”

WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall
not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

En 5

Precautions

Please read these precautions before operating this unit.



Power cord protection



To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the
following.

 Hold the plug firmly when connecting or disconnecting the AC power cord.
 Keep the AC power cord away from heating appliances.
 Never put any heavy object on the AC power cord.
 Do not attempt to repair or reconstruct the AC power cord in any way.



Placement





Avoid placing the unit in areas of:

 direct sunlight or heating radiators, or closed automobiles
 high temperature (over 35
 much dust as the internal parts may be seriously damaged.



Non-use periods





When the unit is not being used, turn it off. When left unused for a long period of time, the unit should be unplugged from
the household AC outlet.



No fingers or other objects inside





Touching internal parts of this unit is dangerous, and may cause serious damage to the unit. Do not attempt to

disassemble the unit.

 Do not put any foreign object on the disc tray.



Keep away from water/magnet







Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage could

occur.

 Never bring a magnet or magnetized object near the unit.



Stacking







Place the unit in a horizontal position, and do not place anything heavy on it.



Condensation





Moisture may form on the lens in the following conditions:

 immediately after a heater has been turned on
 in a steamy or very humid room
 when the unit is suddenly moved from a cold environment to a warm one

If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and wait about one hour for
the moisture to evaporate.





If there is noise interference on the TV while a broadcast is being received



Depending on the reception condition of the TV, interference may appear on the TV monitor while you watch a TV
broadcast and the unit is left on. This is not a malfunction of the unit or the TV. To watch a TV broadcast, turn off the unit.

0

C) or high humidity (over 90%)

En 6

Selecting the type of disc for the type of TV connected

DVDs are recorded in PAL or NTSC formats. Please refer to the table below to find the appropriate format for your
region.

 

Connecting to a multi-system TV



 

 



Connecting to a NTSC TV

 

En 7





Connecting to a PAL TV



1-1 DVD Playback

Preparation

Attach the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment,
please perform the following:

 Press on the power button of the TV set, and select “Video” as the TV input.
 Press on the power button of the stereo system if the player has been connected to one.

For your reference:

 When “

operation is prohibited by the player.

Basic Playback

1 Press POWER on.
2 Press <OPEN> to open the disc cover.
3 Hold the edge of the disc to put it in the center with the printed side up.

Hold the disc without touching its surfaces, position it with the printed title side facing up, align it

with the guides, and place it in its proper position.
4 Close the disc cover.
 Close the disc cover and the portable DVD player starts playback if the disc does not have any

menus recorded on it.
 If the disc has one or more titles recorded on it, a menu screen will appear on the screen.

<< NOTE>>

Proceed with steps 5 and 6 when a menu is available on the disc.

” appears while a button is being operated, it means that the corresponding

5 Press

<< NOTE>>

To select a title, input the number, i.e. 1 for chapter 1, 10 for chapter 10, and etc.

6 Press

The player now starts playing the selected item.

< / / / > or the number button(s) to select the preferred title.

<PLAY/SEL.> .

Stopping Playback and Returning to The Menu Screen (If a Menu Screen Is Available on

The Disc)

Press <MENU>.

The portable DVD player stops playback and displays the menu screen.

After operation

When the portable DVD player is not in use, remove the disc and press POWER to turn off the

player. Close the display panel.

<< NOTE >>

 The disc continues to rotate while the menu is displayed even after the player has finished

playing a particular disc. When no further selections are to be played, be sure to press the

<STOP> button to clear the menu screen.
 If the disc is placed in upside down (and it is a single sided disc), the player’s display will

appear “NO DISC”.

En 8

1-1 DVD Playback-continued

Stopping Playback

Press <STOP> once to prestop. Press <STOP> twice to stop.

Note: PRE-STOP stops the playback, displays the manufacturer’s logo, and allows playback to be resumed

from the point at which

<STOP> twice completely stops the disc, and playback can no longer be resumed.

Rapid Advance and Rapid Reverse

Press <F.BWD> or <F.FWD> during playback.

 Normal playback is resumed when you press

 The speed of advance (

x16, x32) changes with each press of the <F.BWD> or <F.FWD> button.

Skipping Ahead or Back to Chapters

You can skip a specific chapter or track to playback.

Skipping Ahead

Press

Skips a chapter each time you press the button.

Skipping Back

Press

When you press the button once midway through a chapter, the portable DVD player returns to the beginning of the
chapter being played back. The player skips a chapter each time you press the button.

<NEXT> during playback.

<PREVIOUS> during playback.

<STOP> was pressed—simply by pressing the <PLAY/SEL.> . Pressing

<PLAY/SEL.>.

x2, x4, x8, x16, x32) or reverse ( x2, x4, x8,

Still Picture (PAUSE)

Press <PAUSE> once during playback.

The screen is paused.

 To return to normal playback

Press

<PLAY/SEL.>.

En 9

1-1 DVD Playback-continued

Repeat Viewing

Press <1/ALL REPEAT> during playback.

Each time you press the button, the disc will repeat a chapter or title.
Press once:

Press twice:

Press three times:

Press four times:

To return to normal playback

Press

<< NOTE >>

 Repeat playback works only with discs for which the elapsed playing time appears on the player’s display

 Repeat playback may not work correctly with some DVDs.

CHAPTER (Repeat chapter)

TITLE (Repeat title)

DISC (Repeat disc)

Off (Repeat cancelled)

<1/ALL REPEAT> several times until “ Off” appears on the screen.

during playback.

1-2 Convenient functions

Displaying Scene Information

Press <INFO.> during playback.

Press

on the screen.

To stop displaying scene information

Press

<INFO.> a number of times, the title number, chapter number, and other information will show

<INFO.> a number of times until the information disappears.

Changing Audio Soundtrack Language

You can change the audio language from the one selected at the initial settings to a different language.
(This operation functions only with discs on which multiple audio soundtrack languages are recorded.)

1 Press

2 Press

For your reference:

 When the preferred language is not selected even after pressing the button several times, it may

 When you turn on or remove the disc, the portable DVD player will playback the language which

<AUDIO> during playback.

<AUDIO> a number of times until the preferred language is selected.

indicate that language is not available on the disc.

is selected at the initial setting. If you select a language which is not recorded on the disc, the
portable DVD player will playback a prior language programmed on the disc.

En 10

1-2 Convenient functions-continued

Clearing/Displaying Subtitles (A)

If a disc provides subtitles, you can choose to hide or display them. (This operation works only with discs
that provide subtitles.)

Press

When you press

subtitles recorded will display in sequence as you press the button.

 You may change to another language with this function, or you can clear the subtitle by pressing

<SUBTITLE> during playback to display subtitles or hide them.

<SUBTITLE> once, the first subtitle recorded on the disc will display. The rest of the

this button a number of times until “SUBTITLE OFF” appears on the screen.

Changing Subtitle Language (B)

You can change the subtitle language with the initial settings. (This operation works only with discs on
which multiple subtitle languages are included.)

1 Press

When no subtitles are recorded, “

2 Press

selected.

<< NOTE>>

In some cases, the subtitle language may not change immediately to the selected one.

For your reference:

 When the preferred subtitle language is not selected even after pressing the button

 When you turn on or remove the disc, the portable DVD player will playback the subtitle

<SUBTITLE> during playback.

” will display instead of the language number.

<SUBTITLE> a number of times until the preferred language is

several times, it may indicate that the language is not available on the disc.

language which is selected at the initial setting. If you select a subtitle language which is
not recorded on the disc, the portable DVD player will playback a prior subtitle language
programmed on the disc.

Viewing From Another Angle

Some DVD discs may contain scenes which have been shot simultaneously from a number of different
angles. For these discs, the same scenes can be viewed from each of these different angles using the

<ANGLE> button. (The recorded angles vary depending on the disc programmed.)

1 Press

2 Press

Press

<< NOTE >>

ANGLE will only function on discs where different angles have been recorded.

<ANGLE> during playback.

<ANGLE> a number of times until the preferred viewing angle is selected.

<ANGLE> button a number of times to change the viewing angle.

En 11

1-2 Convenient functions-continued

Mute the DVD Player

Press <MUTE> button during playback.

 When “MUTE” appears on the screen, the portable DVD player is mute. To resume sound, press

the button until “MUTE OFF” appears on the screen.

Using DVD Menu

Some DVD discs have unique menu structures. For example, DVDs programmed with complex contents
provide guide menus, and those recorded with various languages provide menus for audio and subtitle
language. Although the DVD menu’s contents and operation vary from disc to disc, the following explains
basic operation when this feature is used.

1 Press

The DVD menu available on the disc now appears.

<TITLE> in stop mode.

2 Press

3 Press <PLAY/SEL.>.You now enter to the selected item.

 To enter other menu screen

Repeat steps 2 and 3.

 To return to the previous menu screen

Press

< / / / > to select the preferred item.

<TITLE>.

Using the MENU Function

1 Press <PLAY/SEL.>.

2 Press

A DVD chapter menu with brief broadcast of each paragraph now appears. You may see the

introduction of each chapter and then decide with which chapter to start first.

3 Press

<< NOTE>>

The menu details vary.

<MENU>.

< / / / > or number button(s) to select the preferred item.

En 12

2-1 Audio CD Playback

Preparation

Attach the battery or connect the portable DVD player to a wall outlet. If connecting to external equipment,
please perform the following:

 Press on the power button of the TV set, and select “Video” as the TV input.
 Press on the power button of the stereo system if the player has been connected to one.

Basic Playback

1 Press POWER on.
2 Press <OPEN> to open the disc cover.
3 Hold the edge of the disc to put it in the center with the printed side up.

Hold the disc without touching its surfaces, position it with the printed title side facing up, align it
with the guides, and place it in its proper position.

4 Close the disc cover.

 For audio CDs without playback control:

The portable DVD player starts to playback.

Stopping Playback

Press <STOP> once to prestop. Press <STOP> twice to stop.

Rapid Advance and Rapid Reverse

Press <F.BWD> or <F.FWD> during playback.

 Normal playback is resumed when you press <PLAY/SEL.>.

 The speed of advance ( x2, x4, x8, x16, x32) or reverse ( x2, x4, x8,

x16, x32) changes with each press of the <F.FWD> or <F.BWD> button.

En 13

2-1 Audio CD Playback-continued

Skipping Ahead or Back to Tracks

Skipping Ahead

Press

A track is skipped each time you press the button.

Skipping Back

Press

When you press the button once midway through a track, the portable DVD player returns to the beginning
of the track being played. The player skips a track each time the button is pressed.

Pause

Press <PAUSE> once during playback.

The player will pause playback.

 To return to normal playback

<NEXT> during playback.

<PREVIOUS> during playback.

Press

<PLAY/SEL.>.

2-2 Information [Audio CDs]

Displaying Track Information

Press <INFO.> during playback.

Press

on the screen.

 To stop displaying track information

<INFO.> a number of times, the elapsed time, track number and other information will show

Press

<INFO.> a number of times until the information disappears.

En 14

3-1 Playing Kodak Picture CDs

Basic Playback

You can play Kodak picture CDs for viewing on the screen.

Load a kodak picture CD.
After few seconds, the portable DVD player starts to play back the pictures in slide show automatically.
OR
You can press the number buttons corresponding to the order of the picture, then press

<PLAY/SEL.>.

Press

 To pause slide show

 To stop slide show

 To resume slide show

<INFO.>, the current picture number and total picture numbers will show on the screen.

Press

Press

Press

<PAUSE>, the slide show will pause.

<STOP>, then enter Thumbnail mode.

<PLAY/SEL.> again.

Slide Show

1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous picture.

2 Press

Press

Press

 To pause slide show

Press

 To stop slide show

Press

 To resume slide show

Press

<RIGHT> button or <LEFT> button to rotate the picture.

<RIGHT> button to rotate right by 90 degrees.

<LEFT> button to rotate left by 90 degrees.

<PAUSE>, the slide show will pause.

<STOP>, then enter Thumbnail mode.

<PLAY/SEL.> again.

En 15

3-1 Playing Kodak Picture CDs-continued

Thumbnail Mode

1 Press <TITLE> to enter Thumbnail mode.

While in Thumbnail mode, there are 12 pictures per page for viewing.

2 Press

< / / / > to select the picture in thumbnail. If you want to view the selected

picture in its original size, press

When you view the picture in its original size, you can press

thumbnail.

3 Press

<NEXT> or <PREVIOUS> to view the next or previous thumbnail page.

<PLAY/SEL.>.

<STOP> to view the pictures in

En 16

3-2 Playing JPEG picture CDs

Basic Playback

You can play JPEG pictures CDs for viewing on the screen.

Load a JPEG picture CD.
After few seconds, the portable DVD player starts to play back the pictures in slide show automatically.
OR

You can press the number buttons corresponding to the order of the picture, then press

SEL.>.

Press

the screen.

 To pause slide show

 To stop slide show

 To resume slide show

<INFO.>, the current picture number, total picture numbers and other information will show on

Press

Press

Press

<PAUSE>, the slide show will pause.

<STOP>, then enter the File Manager.

<PLAY/SEL.> again.

File Manager

1 Under File Manager Menu, press < / / / > to choose the preferred picture, then

<PLAY/

press

<PLAY/SEL.> to playback the picture.

2 Press <NEXT> to skip for the next six pictures or <PREVIOUS> to skip for the previous

six pictures.

En 17

3-2 Playing JPEG picture CDs-continued

Slide Show

1 Press <NEXT> to view the next picture or <PREVIOUS> to view the previous picture.

2 Press

Press

Press

 To pause playback

Press

 To stop playback

Press

 To resume playback

Press

<RIGHT> button or <LEFT> button to rotate the picture.

<RIGHT> button to rotate right by 90 degrees.

<LEFT> button to rotate left by 90 degrees.

<PAUSE>.

<STOP>, then enter to the File Manager.

<PLAY/SEL.> again.

Thumbnail Mode

1 Press <TITLE> to enter Thumbnail mode.

While in Thumbnail mode, there are 12 pictures per page for viewing.

2 Press

picture in its original size, press

When you view the picture in its original size, you can press

Manager.

3 Press

< / / / > to select the picture in thumbnail. If you want to view the selected

<PLAY/SEL.>.

<NEXT> or <PREVIOUS> to view the next or previous thumbnail page.

<STOP> to return to File

En 18

4-1 Language Setup

On Screen Display (OSD) Language Setting

Allows you to set various languages for the on screen display (OSD).

1 Press

2 Press

3 Press

SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen.

Press

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Language Setup”, and then press

<PLAY/SEL.>.

<UP> button / <DOWN> button to select “OSD”, and then press <PLAY/

<UP> button / <DOWN> button to select the preferred language.

<PLAY/SEL.>.

<LEFT> button.

Language Setup

OSD

Menu

Audio

Subtitle

English

French

German

Italian

Spanish

To finish the setup operation.

Press

<SETUP> to exit from SETUP MENU screen.

En 19

4-1 Language Setup-continued

DVD Menu Language Setting

You can select a language that has been recorded on the disc menu.

1 Press

2 Press

3 Press

SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen.

Press

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Language Setup”, and then press

<PLAY/SEL.>.

<UP> button / <DOWN> button to select “Menu”, and then press <PLAY/

<UP> button / <DOWN> button to select the preferred language.

<PLAY/SEL.>.

<LEFT> button.

Language Setup

OSD

Menu

Audio

Subtitle

English

Chinese

Japanese

French

German

To finish the setup operation.

Press

<SETUP> to exit from SETUP MENU screen.

En 20

4-1 Language Setup-continued

AUDIO Soundtrack Language Selection [DVD]

You can select a preferred soundtrack language that has been recoreded on DVD discs.

1 Press

2 Press

3 Press

SEL.>.

4 Press

5 Press

<<ORIGINAL>>

The top-priority language of each disc will always playback first.

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Language Setup”, and then press

<PLAY/SEL.>.

<UP> button / <DOWN> button to select “Audio”, and then press <PLAY/

<UP> button / <DOWN> button to select the preferred language.

<PLAY/SEL.>.

Language Setup

OSD

Menu

Audio

Subtitle

To return to the SETUP MENU screen.

Press

<LEFT> button.

English

Chinese

Japanese

French

German

To finish the setup operation.

Press

For your reference:

 If the language selected is not recorded on the disc, the portable DVD player will play

<SETUP> to exit from SETUP MENU screen.

back the top-priority language of the disc.

En 21

4-1 Language Setup-continued

SUBTITLE Language Selection [DVD]

You can select a preferred language that has been recorded on the DVD.

1 Press

2 Press

3 Press

SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen.

Press

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Language Setup”, and then press

<PLAY/SEL.>.

<UP> button / <DOWN> button to select “Subtitle”, and then press <PLAY/

<UP> button / <DOWN> button to select the preferred language.

<PLAY/SEL.>.

<LEFT> button.

Language Setup

OSD

Menu

Audio

Subtitle

English

Chinese

Japanese

French

German

To finish the setup operation.

Press

For your reference:

If the language selected is not recorded on the disc, the portable DVD player will playback the

top-priority language of the disc.

<SETUP> to exit from SETUP MENU screen.

En 22

4-2 Screen Setup

TV Type Setting

The kind of TV set (4:3 or 16:9) connected to the player and a wide-screen picture type for a 4:3 TV can be
selected.

1 Press

<SETUP> in the stop mode.

2 Press

<PLAY/SEL.>.

3 Press

SEL.>.

4 Press

5 Press

<UP> button / <DOWN> button to select “Screen Setup”, and then press

<UP> button / <DOWN> button to select “TV Type”, and then press <PLAY/

<UP> button / <DOWN> button to select a preferred TV display.

<PLAY/SEL.>.

Screen Setup

TV Type

TV System

Video Output

To return to the SETUP MENU screen.

Press

To finish the setup operation.

Press

4:3 Pan Scan

Select 4:3 PS for a conventional size TV set. Video material formatted in the pan & scan
style has the left and right edges trimmed.

4:3 Letter Box

Select 4:3 LB for a conventional size TV set. Black bands appear at top and bottom of
screen (letter-box style).

 Video material not formatted in the pan & scan style is played in the letter-box style.

16:9 Wide
Select 16:9 for a wide-screen TV set. Played in “FULL” size.

 Setting the wide-screen TV to “FULL” mode is also necessary.
 Each screen shows an example when the video material for a wide-screen

is played.

<LEFT> button.

<SETUP> to exit from SETUP MENU screen.

4:3 PS

4:3 LB

16:9

En 23

4-2 Screen Setup-continued

TV System Setting

The player provides “PAL”, “NTSC” and “AUTO” settings for your selection. When connecting the portable
DVD player to your TV, set the “TV System” from the on-screen display to the format that is compatible with
your TV’s system. Set “AUTO” if your system is a multi-TV system that supports both PAL and NTSC.

1 Press

2 Press

<PLAY/SEL.>.

3 Press <UP> button / <DOWN> button to select “TV System”, and then press

<PLAY/SEL.>.

4 Press

clearest view.

5 Press

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Screen Setup”, and then press

<UP> button / <DOWN> button to select the appropriate TV system for your

<PLAY/SEL.>.

Screen Setup

TV Type

TV System

Video Output

To return to the SETUP MENU screen.

Press

To finish the setup operation.

Press

<LEFT> button.

<SETUP> to exit from SETUP MENU screen.

NTSC

PAL

AUTO

En 24

4-2 Screen Setup-continued

Video Output Setting

Please choose the preferred video output according to the output format.

1 Press

2 Press

<PLAY/SEL.>.

3 Press

<PLAY/SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen.

Press

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Screen Setup”, and then press

<UP> button / <DOWN> button to select “Video Output”, and then press

<UP> button / <DOWN> button to select the preferred video output setting.

<PLAY/SEL.>.

<LEFT> button.

Screen Setup

TV Type

TV System

Video Output

S-Video

P-SCAN

To finish the setup operation.

Press

<SETUP> to exit from SETUP MENU screen.

En 25

4-2 Screen Setup-continued

Video Output Setting-continued

If you choose “P-Scan”, the following will show on the screen as the reminder.

Screen Setup

TV Type

TV System

Your TV support P-SCAN

Video Output

S-Video

P-SCAN

YES Press PLAY
NO Press STOP

4

If your TV supports P-Scan feature, press

<< NOTE >>

If you choose “P-Scan” as the video output setting, make sure your TV set supports P-Scan

input feature and the YUV cable be properly connected to your TV and the portable DVD player.

If your TV doesn’t support P-Scan feature, press

<<Troubleshooting>>

What if the screen turns black while operating...

Solution: Press

<Mode> to switch to “S-Video” mode.

<PLAY/SEL.>.

<STOP>.

En 26

4-3 Audio Setup

Digital Out Setting

The portable DVD player provides three options, “SPDIF/PCM”, “SPDIF/RAW” and “Off” for the digital out
setting.

1 Press

<SETUP> in the stop mode.

2 Press

<PLAY/SEL.>.

3 Press

<PLAY/SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen

Press

<UP> button / <DOWN> button to select “Audio Setup”, and then press

<UP> button / <DOWN> button to select “Digital Out”, and then press

<UP> button / <DOWN> button to select the preferred digital out setting.

<PLAY/SEL.>.

<LEFT> button.

Audio Setup

Digital Out

Analog Out

SPDIF/PCM

SPDIF/RAW

Off

To finish the setup operation

Press

For your reference:
If you have a Dolby Digital 5.1 or DTS capable amplifier, you must set the audio output to SPDIF/RAW.
If you have a 2-channel Dolby Digital amplifier, you must set the audio output to SPDIF/PCM.

<SETUP> to exit from SETUP MENU screen.

En 27

4-3 Audio Setup-continued

Analog Out Setting

1 Press <SETUP> in the stop mode.

2 Press

<PLAY/SEL.>.

3 Press

<PLAY/SEL.>.

4 Press

5 Press

To return to the SETUP MENU screen

Press

<UP> button / <DOWN> button to select “Audio Setup”, and then press

<UP> button / <DOWN> button to select “Analog Out”, and then press

<UP> button / <DOWN> button to select the preferred analog out setting.

<PLAY/SEL.>.

<LEFT> button.

Audio Setup

Digital Out

Analog Out

2 Channel

To finish the setup operation

Press

<SETUP> to exit from SETUP MENU screen.

En 28

4-4 Custom Setup

Angle Mark Setting [DVD]

You can choose to display or hide the angle mark “ ” on the screen.

1 Press

2 Press

<PLAY/SEL.>.

3 Press

<PLAY/SEL.>.

4 Press

<PLAY/SEL.>.

<< NOTE >>

Whether the ANGLE MARK is set to “On” or “Off” with this setting, when you press

button, the portable DVD player will still playback multi-angles that are available on the dvd discs.

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Custom Setup”, and then press

<UP> button / <DOWN> button to select “Angle Mark”, and then press

<UP> button / <DOWN> button to select “On” or “Off”, and then press

Custom Setup

Angle Mark

Default

On

Off

<ANGLE>

To return to the SETUP MENU screen

Press

To finish the setup operation

Press

<LEFT> button.

<SETUP> to exit from SETUP MENU screen.

En 29

4-4 Custom Setup-continued

Default Setting

You may re-set the previous settings in CUSTOM SETUP to the default setting.

1 Press

2 Press

<PLAY/SEL.>.

3 Press

SEL.>.

4 Press

<< EXCEPTION>>

The viewer rating and the password setting will NOT be changed even though you re-set to the

default setting.

<SETUP> in the stop mode.

<UP> button / <DOWN> button to select “Custom Setup”, and then press

<UP> button / <DOWN> button to select “Default”, and then press <PLAY/

<RIGHT> button to select “Read”, and then press <PLAY/SEL.>.

Custom Setup

Angle Mark

Default

Read

To return to the SETUP MENU screen

Press

To finish the setup operation

Press

<LEFT> button.

<SETUP> to exit from SETUP MENU screen.

En 30

4-5 LCD Setup

Panel Setting

The portable DVD player provides two panel adjustment options: “16:9” or “4:3”.

1 Press

<LCD>, the LCD setting information shows on the screen.

2 Press

3 Press

then the panel will change to the selected setting.

To finish the setup operation

Press

Color Setting

You can adjust the color of video with this setting to a soothing view for your eyes.

1 Press

2 Press

3 Press

the panel will change to the selected setting.

<LCD> a number of times to select “PANEL”.

<LEFT> button or <RIGHT> button to choose the preferred panel setting, and

PP

ANEL:ANEL:

ANEL:

ANEL:ANEL:
ANEL:ANEL:

ANEL:

ANEL:ANEL:

16:9
4:3

P

PP
PP

P

PP

<LCD> again until the LCD setting information disappears.

<LCD>, the LCD setting information shows on the screen.

<LCD> a number of times to select “COLOR”.

<LEFT> button or <RIGHT> button to choose the preferred color setting, and then

COLOR: COLOR:

COLOR: +3

COLOR: COLOR:
COLOR: COLOR:

COLOR: +2

COLOR: COLOR:
COLOR: COLOR:

COLOR: +1

COLOR: COLOR:
COLOR: COLOR:

COLOR: 0

COLOR: COLOR:
COLOR: COLOR:

COLOR: -1

COLOR: COLOR:
COLOR: COLOR:

COLOR: -2

COLOR: COLOR:
COLOR: COLOR:

COLOR: -3

COLOR: COLOR:

To finish the setup operation

Press

<LCD> again until the LCD setting information disappears.

En 31

4-5 LCD Setup-continued

Bright Setting

You can manually increase or decrease the brightness of the video.

1 Press

<LCD>, the LCD setting information shows on the screen.

2 Press

3 Press

then the panel will change to the selected setting.

To finish the setup operation

Press

Panel Close Setting

1 Press <LCD>, the LCD setting information shows on the screen.

2 Press

3 Press

then the panel will change to the selected setting.

<< NOTE>>

When you choose “ON” in the panel setting, the LCD turns off and the power indicator will blink in

yellow light.

To finish the setup operation

Press

<LCD> a number of times to select “BRIGHT”.

<LEFT> button or <RIGHT> button to choose the preferred bright setting, and

BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT
BRIGHTBRIGHT

BRIGHT

BRIGHTBRIGHT

<LCD> again until the LCD setting information disappears.

<LCD> a number of times to select “CLOSE”.

<LEFT> button or <RIGHT> button to choose the preferred panel setting, and

CLOSE: CLOSE:

CLOSE: OFF

CLOSE: CLOSE:
CLOSE: CLOSE:

CLOSE: ON

CLOSE: CLOSE:

<LCD> again until the LCD setting information disappears.

::

:

+3

::
::

:

+2

::
::

:

+1

::
::

:

0

::
::

:

-1

::
::

:

-2

::
::

:

-3

::

Setting CLOSE to ON will blank the JD-VD755’s LCD. This is useful when you wish to experience the unit’s
playback on an external TV or LCD panel, without having the player’s own LCD panel turned on. Note that
when using CLOSE for this purpose, the player’s Volume control should be turned to its minimum setting,
since the audio will be heard on the external device.

En 32

5-1 Troubleshooting

Before requesting service for your portable DVD player, check the chart below for a possible cause of the
problem you are experiencing. Some simple checkups or a minor adjustment on your part may eliminate
the problem and restore proper operation.

SYMPTOM (COMMON) REMEDY

No power. · Insert the power plug securely into the power outlet.

The player does not start playback · Condensation may have formed. Try again in 1 to 2 hours to ensure that the
when PLAY is pressed. condensation has evaporated.

The player starts playback but stops · The disc may be dirty and may require cleaning.
immediately. · Ensure that the disc is installed with the label side up.
No picture. · Ensure that the equipment is connected properly.

No sound. · Ensure that the equipment is connected properly.

Distorted sound. · Ensure that the input settings for the TV and stereo system are proper.

No audio at Digital Output. · Check the digital connections.

capabilities.
Distorted picture. · Check the disc for fingerprints and clean it with a soft cloth, wiping it from center

Completely distorted picture or no color · The disc format is not compatible to the TV-set used (PAL/NTSC).
in picture.
Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal.
advance or rapid reverse.
No rapid advance (or rapid reverse) · Some discs may have sections which prohibit rapid advance (or rapid reverse).
playback.
No 4:3 (16:9) picture. · Choose the correct setup “TV DISPLAY” item which matches the TV set used.
Picture is distorted during rapid · The picture will be somewhat distorted at times: this is normal.
advance or rapid reverse.
No operations perform with the · Check the batteries are installed with the correct polarity (+ and –).

remote control. · The batteries are depleted: replace them with new ones.

No key operation (by the DVD player · Turn the unit off and then back on. Alternatively, turn off the unit, disconnect the AC
power and/or the remote control) is cord and then re-connect it. (The player may not be operating properly due to

effective. lightning, static electricity or some other external factor.)
PLAY does not start playback even · This may be a result of the parental lock function that has been set.
when title is selected. Confirm the “PARENTAL” setup.
Audio soundtrack and/or subtitle · If the audio soundtrack and/or subtitle language does not exist on the disc, the
language is not the one selected language selected at the initial settings will not be seen/heard.
at the initial settings.
No subtitles. · Subtitles appear only with discs that contain them.

Alternative audio soundtrack · An alternative language can not be selected may result of no more than one language
(or subtitle) languages cannot be selected. available.
Angle cannot change. · This function depends on software availability. Even if a disc has a number of angles
recorded, these angles may be recorded for specific scenes only.

· Check if the ON/OFF button on the right of the player is set to on.

· Check if no power at the AC outlet may be the fault by plugging in another appliance
for a test.

· Ensure that the disc format is supported by your DVD player.

· Check if the disc is defective by trying another disc.

· Check the region (local) code.

· Ensure that the input setting for the TV is “Video”.

· Check if external equipment is on.

· Select the same channel and source on the TV as on the player.

· Check if the LCD is on.

· If using a HiFi amplifier, try another sound source.

· Check the Audio Output Setting menu to make sure that Analog Output is selected.

· Check the Volume Adjustment.

· No sound is heard during still picture (pause).

· Check the settings menu to make sure that the digital output is set to on.

· Check if the audio format of the selected audio language matches your receiver

to edge.

· Sometimes a small amount of picture distortion may appear. This is not a malfunction.

· Point the remote control unit at the remote control signal sensor and operate.

· Operate the remote control unit at a distance but no more than 6 meters from the
remote control signal sensor.

· Remove obstacles between the remote control unit and remote control signal sensor.

· Subtitles are hidden from the TV screen. Press SUBTITLE to display the subtitles.

En 33

5-2 Disc Handling and Maintenance

Handling Precautions



Hold the disc by the edges so the surface will not be soiled with fingerprints. (A)
Fingerprints, dirt and scratches can cause skipping and distortion.

 Do not write on the label side with a ball-point pen or other writing utensils.
 Do not use record cleaning sprays, benzene, thinner, static electricity prevention liquids or any other

solvent.

 Be careful not to drop or bend the disc.
 Do not install more than 1 disc on the disc tray.
 Do not try to close the disc cover when the disc is not installed properly.
 Be sure to store the disc in its exclusive case when not in use.

If the surface is soiled (B)

Wipe gently with a soft, damp (water only) cloth.
When wiping discs, always move the cloth from the center hole toward the outer edge.
(If you wipe the discs using a circular motion, circular scratches are likely to occur, which will cause noise.)

(A) (B)

If the disc is brought from a cold to a warm environment, moisture may form on the disc

Wipe this moisture off with a soft, dry, lint-free cloth before using the disc.

Improper disc storage

You can damage discs if you store them in the following places:

 Areas exposed to direct sunlight
 Humid or dusty areas
 Areas directly exposed to a heat outlet or heating appliance

Disc which cannot be played with this player

 CD-ROM (Application Program)
 CVD
 CD-G
 DVD with a Locale No. other than that shown on the DVD unit’s Region Code Label on the rear panel

Maintenance

 Be sure to turn the unit off and disconnect the AC power cord before performing maintenance on the

unit.

 Wipe this unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has

been dipped in a weak soap-and-water solution and wrung out thoroughly, and then wipe again with a
dry cloth.

 Never use alcohol, benzene, thinner, cleaning fluid or other chemicals. And do not use compressed air

to remove dust.

En 34

5-3 Definition of Terms

Angle

Recorded onto some DVD discs are scenes which have been simultaneously shot from a number of different
angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the
ANGLE button can be used to view the scene from different angles.

Chapter Number

These numbers are recorded on DVD discs. A title is subdivided into many sections, each of which is
numbered, and specific parts of video presentations can be searched quickly using these numbers.

DVD

These refer to a high-density optical disc on which high-quality pictures and sound have been recorded by
means of digital signals. Incorporating a new video compression technology (MPEG II) and high-density
recording technology, DVD enables aesthetically pleasing full-motion video to be recorded over long periods
of time (for instance, a whole movie can be recorded).
DVD has a structure consisting of two 0.6 mm thin discs which are adhered to each other. Since the thinner
the disc, the higher the density at which the information can be recorded, a DVD disc has a greater capacity
than a single 1.2 mm thick disc. Since the two thin discs are adhered to each other, there is the potential to
achieve double-sided play sometime in the future for even longer duration play.

Subtitles

These are the printed lines appearing at the bottom of the screen which translate or transcribe the dialogue.
They are recorded on DVD discs.

Time Digit

This indicates the play time which has elapsed from the start of a disc or a title. It can be used to find a specific
scene quickly. (It may not work with some discs.)

Title Number

These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are
numbered as title 1, title 2, etc.

Track Number

These numbers are assigned to the tracks which are recorded on audio CDs. They enable specific tracks to
be located quickly.

En 35
