Thank you for purchasing this product.
(These instrustions are for TK-C1460U and TK-C1460E)
Before beginning to operate this unit, please read the instruction manual
carefully in order to make sure that the best possible performance is obtained.

CONTENTS

INTRODUCTION

Features .......................................................................................................................

........

6

Operating Precautions ......................................................................................................... 7

Controls, Connectors and Indicators ................................................................................... 8

CONNECTION/INSTALLATION

RM-P2580 System.............................................................................................................12

Procedures .....................................................................................................................

...

14

Mounting the lens .............................................................................................................. 15

Connections on the back ...................................................................................................16

Mounting the camera .........................................................................................................18

Lens adjustment ................................................................................................................ 20

Back focus adjustment....................................................................................................... 21

Auto white balance control adjustment ............................................................................. 22

MENU SETTING

Setting the menu...............................................................................................................

.

23

The flow of menu screen ...................................................................................................24

SYNC ADJUST Screen ..................................................................................................... 26

ALC SETTINGS Screen .................................................................................................... 26

VIDEO ADJUST Screen ....................................................................................................31

MODE SELECT Screen .................................................................................................... 32

MOTION DETECT Screen................................................................................................. 34

COMMUNICATION Screen ............................................................................................... 35

FACTORY SETTINGS Screen........................................................................................... 35

BLC EDITTING Screen ..................................................................................................... 36

Manual Adjustment of White Balance ...............................................................................37

CAMERA TITLE Setting ....................................................................................................38

Setting the MOTION DETECT Function ........................................................................... 39

Output of Black-White/Color switching signal ...................................................................40

Control by Black-White/Color switching signal from the outside ......................................41

OTHERS

Installing the ferrite core ....................................................................................................42

Specifications.................................................................................................................

....

42

E-6

 A new DSP (Digital Signal Processor)

features a Extended Dynamic Range
(ExDR) and enables to shoot both bright
and dark locations.

 The use of a new CCD with a SENSE UP

(X32) function realized the minimum
luminous flux density for subject of 0.8 lx
(F1.2, 50%, AGC 20dB) and 0.025 lx (at
SENSE UP (X32)). Furthermore, we
realized 0.02 lx (F1.2, 50% AGC 20dB)
thanks to the function of B/W mode.

 A motion detector function detects the

motion inside an image and emits alarm
signals.

 The equipped Y/C terminals and RS-

422A/RS-485 terminals allow intended
compatibility with diversified systems.

 Day/Night surveillance

When the light is low, the camera pictures
can be switched automatically to black
and white pictures.

 Electronic zoom

The 10x electronic zoom allows
monitoring in far greater detail.

Features

 Before starting an important recording,

be sure to perform a test recording in
order to confirm that a normal
recording is possible.

 We do not accept liability for the loss of

a recording in the case of it becoming
impossible to record due to a problem
in the video camera, VCR or video tape.

 We do not accept liability for any

damage to the camera in cases when it
is dropped because of incomplete
installation due to not observing the
installation instructions correctly. Please
be careful when installing the camera.

 The motion detector is not a feature to

prevent theft, fire, etc. Even if an
accident should occur resulting in
damage, we do not accept any liability.

INTRODUCTION

Characters and symbols used in this instruction manual.

CAUTION : Cautionary notes concerning operation of the unit.

MEMO : Reference such as restrictions of features, etc.

 : Reference page or item.

E-7

● To save energy, when it is not being used

turn the system’s power off.

● This camera has been designed for indoor

use. When you use it outdoor, be sure to
use a housing and the like.

● Do not install or use the camera in the

following places.

• In a place exposed to rain or moisture.

• In a place with vapor or oil soot, for

example in a kitchen.

• When the ambient temperature rises
above or falls below the acceptable
range (from –10°C to 50°C).

• Near a source of radiation, X-rays,
strong radio waves or magnetism.

• In a place subject to vibration.

• In a place with excessive dirt.

● If this camera and the cables connected
to this camera are used where there are
strong electromagnetic waves or where
there is magnetism present, for example
near a radio or TV transmitter, power
transformer or an electric motor, the picture
may produce noise and the colours may
be affected.

● This camera incorporates an AGC circuit.
As a result, when it is used under low light
conditions, the camera sensitivity is
automatically boosted and the picture may
look uneven. However, this is not a
malfunction.

● While AGC activated, if use kind of
transceiver which cause strong
electromagnetic wave at close distance,
picture might have influence for beat and
etc.
So please kindly use camera more than
three meters apart from such transceivers.

● When this camera is used in the ATW
mode, the recorded colours may be slightly
different from the actual colours due to the
operational principles of the auto-tracking
white balance circuit. However, this is not
a malfunction.

● If a high-intensity object (such as a lamp)
is shot, the image on the screen may have
vertical lines (smear) or blur (blooming)

Operating Precautions

at its periphery. This is a characteristic of
the CCD, and is not a defect.

● Observe the following when carrying out
camera maintenance.

• Turn the power OFF before proceeding

to carry out maintenance.
If it is contaminated seriously, clean the
contaminated part with a cloth (or a
tissue) which has been soaked in a
solution of water and a neutral detergent.

● TK-C1460U and TK-C1460E
The unit is to be powered by a DC 12 V or
an AC 24 V power supply.
The AC 24 V power supply should conform
to the following:

TK-C1460U Class 2 only
TK-C1460E Isolated power supply only

● Caution for operating the video iris lens
In case the video iris lens is set to an
extremely low level, malfunction

– such as
the hunting phenomenon in which the iris
opens or closes unintentionally

– can
occur.
In such a case, first set the “LEVEL”
potentiometer on the lens to the H position
(iris open), and then adjust it to an optimum
level.

● The cable stopper on the terminal block
can come off sometimes. Therefore, be
sure to take enough time and fix the cable
securely.

● When a highly bright subject is shot,
sometimes undulations can be observed
on the vertical lines of the subject.
However, this phenomenon is peculiar to
the unit and is not a sign of malfunction.

● The beat may sometimes appear on the
screen if gain is raised when the line lock
is in use, but the phenomenon takes place
due to the fluctuation of power frequency
and is not a malfunction.

● You may hear some noise when the
screen is switched between the color and
the black and white, because the optical
filter moves. Also, black vertical bands
will appear on the screen.

E-8

INTRODUCTION

1

Lens mount

This means to attach the lens.
This is applicable to both the C-mount
lenses and CS-mount lenses.

2

Back focus adjustment ring

Adjusting the back focus during lens
installation.
When readjustment is required, loosen
the locking screw

3

by turning it
counterclockwise and turn the back focus
adjustment ring

2

.
After the adjustment, tighten the locking
screw

3

again.

3

[BF LOCK] Back focus locking screw

This serves to fix the back focus-adjusting
ring.

4

Camera-mounting bracket

The bracket has been attached on the
bottom of the camera before shipment. It
can also be attached on the top
according to the circumstance.
To re-attach the bracket use the threaded
holes at the top, with the camera
mounting bracket fixing screws

7.5

Camera-mounting screw
hole (1/4 inch)

Use this hole when mounting
the camera onto a fixer, pan/
tilt unit, and the like. (Use a
screw shorter than 7 mm.)

6

Rotation-preventive hole

Make use of this rotation-preventive hole
to prevent any fall when mounting the
camera. Make sure that the camera is
securely mounted.

7

Camera mounting bracket fixing screws
(×2: M2.6 × 6 mm)

Be sure to use a 6 mm long screw.

1

2

3

4

5

6

7

MAX.

7

mm

Controls, Connectors and Indicators

E-9

8

Cover

The cover opens if it is pulled to the left
while being pushed.

9

[VIDEO/DC] Iris Selector Switch

This is set according to the type of lens
when an automatic iris control lens is
used.
VIDEO: In case of lens with EE amp built-

in.

DC: In case of lens without EE amp

built-in.

(

At time of factory shipment
VIDEO: TK-C1460E
DC: TK-C1460U

)

10

[IRIS] Iris Terminal

This is connected to an automatic iris
control lens.
( Page 15)

11

[MENU] Menu Button

When the button is pressed, a menu
screen is brought up.
( Page 23)

ON

SIMPLEX

ON
LL

SET

AWC

MENU

CAMERA
SETUP

EXT TERM-OFF

INT/GL

DUPLEX

RX TERM-OFF

NOT USED

VIDEO

DC

IRIS

#$

@

!

%
^
&
*

0

9

8

12

[SET/AWC] Set. Auto White Control
Button
SET: Press this button to display a sub-

menu.
( Page 23)

AWC: If this button is kept pressed for

more than 1 second, a one-push­auto-white-balance function works
and sets the white balance. Once
it is set, even if colour temperature
changes, white balance does not
change. It is also possible to make
fine adjustments on the set white
balance.
( Page 22)

E-10

INTRODUCTION

13

[

,

,

,

] Up-and-down, left-and-

right Button

These buttons select items on the menu
screen and change a set value.
( Page 23)

14

[EXT.TERM-ON/OFF] Terminal On/Off
Switch of External Synchronization
Signal

This is a terminating ON/OFF switch for
the external synchronization input signal.
When this is switched ON, termination is
executed via a 75 Ω resistor.

ON: terminates at 75Ω.
OFF: does not terminate at 75Ω.

(ON: At time of factory shipment)

15

[INT/GL, LL] Selector Switch for
Synchronizing System

This switch can set a synchronizing system
of the camera.

INT/GL:

This is set for internal synchronization
(INT) or external synchronization (GL).

LL (Line Lock):

The camera’s vertical synchronization is
locked to the AC 24V power line frequency.
When switching between multiple cameras
using a switcher, selecting this mode and
adjusting the vertical phase can reduce the
monitor sync disturbances occurring when
the camera image is switched. (This cannot
be used in regions where the power
frequency is 50 Hz (60 Hz) ( ): TK-C1460U)
(INT/GL: At time of factory shipment)

16

[DUPLEX, SIMPLEX] Selector Switch
for Transmission System

If the setting is changed, be absolutely
sure to switch on the power again.

DUPLEX:

This switch sets to DUPLEX when the
transmission between the camera and a
remote control unit is in a duplex system
(two-way).

SIMPLEX:

This switch sets to SIMPLEX when the
transmission between the camera and a
remote control unit is in a simplex system
(one-way).
(DUPLEX: At time of factory shipment)

17

[RX.TERM-ON/OFF] RX Signal Terminal
ON/OFF Switch

This sets whether or not the signal
between RX + and RX

– on the back

20

should be terminated at the value of
110Ω resistance.

ON: terminates.
OFF: does not terminate.

If the system including the camera is the
M.DROP (Multi-drop, RS-485) system,
only the camera mounted at the terminal
of control signal cable is set to

“ON” and

the other camera is set to

“OFF”. In case
of the M.DROP system, it becomes
necessary to set the Machine ID. ( Page

35)
If the system including the camera is the
P TO P (Point to Point, RS-422A) system,
set this switch of all the cameras to

“ON”.
The item STYLE on the COMMUNICA­TION screen sets M.DROP or P TO P
( Page 35)
(ON: At time of factory shipment)

18

NOT USED

This cannot be used. Do not switch.

Controls, Connectors and Indicators (Continued)

E-11

DC12V

AC24V

Y/C OUT

SYNC IN

POWER

VIDEO OUT

SEE INST­RUCTION
MANUAL

+

-

12

CLASS 2 ONLY(U TYPE)

ISOLATED POWER ONLY

(E TYPE)

TX

+

TX

-

RX

+

RX

-

AUX

GND

ABCD

⁄

)

(

fi

›

¤

19

[DC 12V, AC 24V] Power input terminals

To input DC 12V or AC 24V power.

20

[TX+A, TX-B, RX+C, RX-D] Control
signal connection terminals

Terminals for inputting signals with
electrical characteristics conforming to
the EIA/TIA RS-422A or RS-485 standard.



17

RX.TERM switch

21

[AUX, GND] Auxiliary Input/Output
Terminals

If there is any change in the area set on
the MOTION DETECT screen, these
terminals output the corresponding
signals. ( Page 34)
These terminals also output the B&W/
COLOUR signal. ( Page 30)
[Open-collector low signal. Maximum
voltage 30V, current 30mA.]
When carrying out B&W/COLOUR
switching using the control signal, the
signals are input through these terminals.
( Page 30)
[B&W: make; COLOUR: break]

22

[Y/C OUT] Y/C output connector

This 4-pin connector outputs the luminance
and chrominance signal.

• Pin configuration of Y/C OUT connector

23

[VIDEO OUT] Video signal output
connector

This BNC connector outputs a composite
video signal. Connect this to the video input
connector of a video monitor, switcher, etc.

24

[POWER] Power indicator lamp

This lamp lights when power is supplied
to the camera.

25

[SYNC IN] Sync signal input connector

This BNC connector accepts the input of
an external sync signal such as a composite
video (VBS) or black burst (BB) signal.
When a sync signal is input into this
connector, the camera operation is
automatically synchronized with the
external sync signal.
To terminate this connector at 75Ω, turn
ON the EXT.TERM switch

14

.

Pin No. Signal

1 GND
2GND
3 Luminance (Y)
4 Chrominance (C)

4

2

3

1

E-12

REC

PLAY

FFREW

REVERSE

PAUSE/
STILL

REC
CHECK

STOP/EJECT

COUNT/
CLOCK

TIME
MODE

TIMER
REC

AL/PL
RESET

MENU

VIDEO CASSETTE RECORDER

SHIFT/TRACKING

SET/V.LOCK

RESET
/CANCEL

OPERATE

SR-L910

OPE. LOCK

1

TO CAMERATO CAMERA DATA I / ODATA I / O

RXRX+RXRX

­TXTX+TX

-

COM

1 2 3 4 5 6 7 8

COM

9/19/110/210/211/311/312/412/413/513/514/614/615/715/716/816/8

COM COMCOM COM

CAMERACAMERA
SWSW

UNITUNIT
ALARMALARM

AUTOAUTO

431 2 875 6

2 3 4 5 6 7

8

1

MONITORMONITOR
OUTPUTOUTPUT

MONITORMONITOR

SERIAL-2SERIAL-2SERIAL-1SERIAL-1

VIDEO INPUTVIDEO INPUT

VIDEO OUTPUTVIDEO OUTPUT

OUTPUTOUTPUT

2

1

ON

2 3 4 5 6 7

8

POWER

OFF

AC INPUT

ALC

LEVEL

Av Pk

L H

ALC

LEVEL

Av Pk

L H

ALC

LEVEL

Av Pk

L H

•••••

CAMERA

SW

Remote Control Unit

RM-P2580

Time lapse VCR

MONITOR

MONITOR

CAM SW
OUT

VIDEO IN

COM

TO

CAMERA

MONITOR
OUTPUT 2

MONITOR
OUTPUT 1

CONNECTION/INSTALLATION

RM-P2580 System

 System with up to 8 cameras

Camera

TK-C1460

Camera

TK-C1460

Camera

TK-C1460

Camera 1

Camera 2

Camera 8

Control signal cable

Video signal cable

Powe r
cable

AC24V
or
DC12V

AC24V
or
DC12V

AC24V
or
DC12V

MONITOR screen

(example showing camera ID as

“05”)

When controlling with any system except the RM-P2580, execute proper settings using
switches and menu screens according to the systems used. ( Page 14)

PROT OOLDUPLEXID-05C

:

“DUPLEX” should
be displayed.

The number shown in the
□□ part of ID-□□
should be correct.

MACHINE ID:1
(Menu screen)
RX TERM: OFF
(switch)

MACHINE ID:2
(Menu screen)
RX TERM: OFF
(switch)

MACHINE ID:8
(Menu screen)
RX TERM: ON
(switch)

MEMO

• When operating a system using the RM-P2580, several cameras (up to 16) can be
connected and used on one control signal cable. Consequently, an incorrect switch setting
on just a single camera will cause the entire system to work incorrectly.

• Confirm switch settings on the screen as follows.

q Confirm that the image from the camera to be checked

is displayed on the monitor.

w Tur n OFF and then ON the AC 24 V power to the

camera to be checked.

e The camera begins the initial operation and charac-

ters similar to those shown in the illustration on the
right appear on the monitor screen.

r Confirm that “DUPLEX” and

“ID-□□” are displayed

and that the ID number is the correct number (the
number should be the same as the number of the
VIDEO INPUT terminal to which the camera is con­nected on the rear panel of the RM-P2580).

t If wrong, set the camera ID again.

E-13

CAMERA
SETUP

SET

MENU

EXT TERM-OFF

INT/GL

DUPLEX
RX TERM-OFF

NOT USED

ON
LL
SIMPLEX
ON

EXT TERM-OFF

INT/GL

DUPLEX

RX TERM-OFF

NOT USED

ON
LL
SIMPLEX
ON

VIDEO

DC

IRIS

AWC

A RX

+

B RX
C TX

+

D TX

TX+ A
TX

B

RX

+

C

RX

D

TX

+

A

TX

B

RX

+

C

RX

D

RM-P2580

Camera 2
control signal
connection terminals

Connect:
Camera TX+ to RM-P2580 RX+
Camera TX– to RM-P2580 RX

–

Camera RX+ to RM-P2580 TX+
Camera RX– to RM-P2580 TX–
The A B C D marks indicated on both the
camera terminals and the RM-P2580 termi­nals facilitate correct connections. Connect
the terminals with identical marks.

 Connecting the control signal cable

(Use a twisted-pair cable for connection.  Page 17.)

Camera 1
control signal
connection terminals

 Setting the switches ( Page 10)

Select the synchronization method of the
camera image.
Set the switch on all cameras to LL (Line Lock)
and match with the V. PHASE.
( Page 26.)

Set this switch to the DUPLEX
* If the setting is changed, be absolutely sure to

switch on the power again.

Set this switch to ON (signal termination ON)
only on the camera placed at the end of the
control signal cable.
Set to OFF on all other cameras.

 Setting on the MENU screen ( Page 35)

* If the setting is changed, escape from the menu screen once, and definitely switch on the power again.

MACHINE ID setting switches

Set this item to match the RM-P2580 VIDEO
INPUT terminal number for each camera.

When connecting

● Turn OFF the power supply to all equipment to be used before making connections.

● Carefully read the Instructions for each piece of equipment to be used before making

connections.

● For the appropriate connection cables and the length of these, carefully read “Connections
on the back” on page 16.

● The control signal cable cannot be used for loop connection.

Set to M.DROP

Set to M.DROP when the RM-P2580 is used
as a remote control unit. When controlling
from another machine, make sure that it
matches the communication system used.

MMCO UNI CATION

ST LE M.DROPY
MA H NE DII 1C

E-14

CONNECTION/INSTALLATION

SET

MENU

CAMERA
SETUP

EXT TERM-OFF

INT/GL

DUPLEX

RX TERM-OFF

IOT USED

ON
LL
SIMPLEX
ON

VIDEO

DC

ALC

LEVEL

Av Pk

L H

DC12V

AC24V

CLASS 2 ONLY(U TYPE)

ISOLATED POWER ONLY

(E TYPE)

TX

+

TX

-

RX

+

RX

-

AUX

Y/C OUT

SYNC IN

POWER

VIDEO OUT

GND

A

B

CD

SEE INST­RUCTION
MANUAL

1

+

-

2

Execute connection/installation according to the procedures described below.
Turn OFF the power supply to all equipment to be used before making carefully.

1.

Mounting the lens
( Page 15)

4.

Setting the switches
( Page 13)

6.

Back focus adjustment
( Page 21)

5.

Lens adjustment
( Page 20)

7.

Auto white balance
control adjustment
( Page 22)

3.

Mounting the camera
( Page 18)

To controlling systems
such as RM-P2580

To alarm terminals
such as switches

Monitor

2.

Connections

( Page 16)

DC 12V/AC 24V
power supply

Genlock sync
signal generator

Procedures

E-15

Mounting the lens

VIDEO

DC

IRIS

VIDEO

DC

3

42

1

Mount the lens according to the procedures described below.

1.

Before mounting a lens, check whether
it is a C-mount or CS-mount lens.
To change the mounting method, loosen
the back-focus locking screw (M 2.6)
using a Phillips head screwdriver, turn
the back-focus adjusting ring with your
fingers or the screwdriver and change
the mounting method.
As regards the dimension (b) of the area
to which the lens is to be installed as
illustrated on the left diagram, use the
one with less value than what’s shown
in the table below.
For both the C-mount and CS-mount,
never use whatever exceeds the dimen­sion (b), as such will not allow normal
installation and damage the inner part
of the camera, resulting in a malfunc­tion.

The F mark indicates a focal point.

2.

Mount the lens on the camera by turning
the lens clockwise. Adjust its position.

3.

When using an auto-iris lens with an EE
amplifier, turn the switch to the “VIDEO”
side. When no EE amplifier is equipped,
turn the switch to the “DC” side.

4.

If the lens has an auto-iris mechanism,
connect the lens cable after checking the
pin arrangement.
If the lens cable has a different type of
plug, use the 4-P plug supplied.

Lens Flange back (c) Dimension (b)

C mount lens 17.526mm 5.5mm or less

CS mount lens

12.5mm 5.5mm or less

1

3

4

2

B

F

L

O

C

K

(b)

(c)

F

Lens DC IRIS VIDEO IRIS

Pin No. (does not contain EE amplifier) (contain EE amplifier)

1 Brake

–

9V [max 50mA]

2 Brake

+

NC

3 Drive

+

VIDEO

4 Drive

–

GND

3.

2.

4.

Attached 4 pin plugs

1

3

2

4

CAUTION:

Always attach the fer­rite core (supplied) to
the lens cable.
( Page 42)

E-16

DC12V

AC24V

CLASS 2 ONLY(U TYPE)

ISOLATED POWER ONLY

(E TYPE)

TX

+

TX

-

RX

+

RX

-

AUX

Y/C OUT

SYNC IN

POWER

VIDEO OUT

GND

ABCD

SEE INST­RUCTION
MANUAL

1

+

-

2

Connect the DC 12 V or the AC 24 V power
supply to the DC 12V/AC 24V terminals. To
prevent connection errors or a cable
disconnection, we recommend the use of lug
plates for the connections.
The following table shows the connection
distances and connection cables provided
that 2-conductor VVF cables (vinyl-insulated
vinyl sheath cables) are used.

Maximum extension
(reference)

Conductor
diameter

100 m 260 m 410 m 500 m

1.0∅mm 1.6∅mm 2.0∅mm 2.6∅ mm
and more and more and more and more

Connections on the back

CONNECTION/INSTALLATION

 Power supply

(DC 12 V or AC 24 V)

MEMO

• If thin cables are used (i.e. with a high
resistance), a significant voltage drop will
occur when the unit is at its maximum
power consumption. Either use a thick
cable to restrict the voltage drop at the
camera side to below 10%, or place the
power supply near to the camera. If
voltage drop occurs during operation, the
performance will be unstable.

• Attach the cable conductors so that they
do not come into contact with the drop
prevention wires.

• Do not allow input from both a DC 12 V
and AC 24 V power supply at the same
time.

• When using a DC 12 V power supply,
ensure that the polarities of the cable are
correct.

• The AC 24 V power supply should
conform to the following:
TK-C1460U Class 2 only
TK-C1460E Isolated power supply only

E-17

 Control signal cables

These cables should be connected only when
it is required to control the camera using the
RS-442A or RS-485 signals. The use of 0.65
4-conductor twisted pair cables is recom­mended. With these cables, the maximum ex­tension distance is 1,200 m.

Connect to the other
side in pairs like this.

Connect to the other
side in pairs like this.

A

B

TX+
TX

-

C

D

RX+
RX

-

 Genlock connection

With some systems, when the external sync
signal is a composite video or black burst sig­nal genlocking by applying an external sync
input requires the horizontal phase (H
PHASE) and colour phase (SC COARSE) to
be adjusted.

MEMO

• Genlocking is not possible with a signal
containing too much jitter, such as a VCR
or videodisc playback signal.

• For details, consult a JVC authorized
dealer.

E-18

DC12V

AC24V

CLASS 2 ONLY(U TYPE)

ISOLATED POWER ONLY

(E TYPE)

T

X

+

T

X

-

R

X

+

R

X

-

A

U

X

Y

/

C

O

U

T

S

Y

N

C

IN

P

O

W

E

R

V

ID

E

O

O

U

T

G

N

D

A

B

CD

S

E

E

IN

S

T

-

R

U

C

T

IO

N

M

A

N

U

A

L

+

-

1

2

2mm

6mm

M3 x 6mm

MAX.

7

mm

Mounting the camera

CONNECTION/INSTALLATION

Camera mounting
screw hole

Camera-mounting bracket

Rotation prevention hole

When mounting the camera on a fixer, pan/
tilt, etc., use the camera mounting screw hole
located on the camera-mounting bracket.

Furthermore, make use of the rotation
prevention hole to prevent the camera from
falling and securely mount the camera.
Special precautions must be taken for
mounting the camera on a wall or a ceiling.
We are not liable for any damage caused by
improper installation.

Fall Prevention

• Exercise maximum caution when
installing the unit to the wall or ceiling. You
should not engage in the installation work
yourself. Ask a professional to do the job,
since the fall of the unit can result in
injuries and accidents.

• When installing the unit on a fixer, Pan/
Tilt unit, etc., make sure to install it firmly
using a rotation-preventing hole provided
to prevent fall.

• To prevent fall, connect the unit to a
section with sufficient strength (ceiling
slab or channel) using a fall prevention
wire such as a wire chain and the like.
Use the screw hole on the back of the unit
for installation.
Pay utmost attention to the length of the
wire, too.

• Specified screw (M3 × 6 mm)
Never use any screw longer than the
specified length as the inside can be
damaged.

CAUTION:

Use the screw with a
length shorter than 7mm
from a camera-mounting
face.

E-19

VIDEO

DC

IRIS

VIDEO

DC

IRIS

Camera­mounting bracket

Fixing screws

Installation of camera

• Mounting from the bottom
This camera is originally designed to be
mounted from the bottom, as shown q.
The hole is standard photographic pan­head screw size (1/4-20 UNC). Example
the Fixing unit or Pan/Tilt unit.

• Mounting from the top
Remove the CAMERA MOUNTING
BRACKET from the bottom of the camera
by removing two fixing screws as shown
w. Attach the CAMERA MOUNTING
BRACKET to the top, then mount the
camera on the Fixing Unit as shown e.
Make sure that two original screws are
used when mounting the CAMERA
MOUNTING BRACKET. Be sure to use a
6 mm long locking screw for the camera­mounting bracket.
(This camera is used indoor and under
similar conditions.)

q

w

e

E-20

CONNECTION/INSTALLATION

Lens adjustment

ALC

LEVEL

Av Pk

L H

Connect the camera according to the connection method, turn it on, display an image on the
monitor, and check the image. The camera has been factory-adjusted to the best position, but
it may need to be adjusted according to the object conditions or combination of lenses. If the
image is unnatural, adjust it as follows: (Also read the instruction manual of the lens.)

• LEVEL adjustment

Monitor screen

LEVEL turning direction

Too bright Counterclockwise (Toward L)

Too dark Clockwise (Toward H)

MEMO

• If the sensitivity adjustment LEVEL is
turned excessively to L, the sensitivity in­creases because of the AGC function of
the camera, and the image looks grainy.

• If the video iris lens is set to too low a level,
malfunction such as the hunting phenom­enon, in which the iris opens or closes
unintentionally, may occur.
In such a case, first set LEVEL potentiom­eter on the lens to the H (iris open) posi­tion then adjust it to the optimum level.

LEVEL
adjustment

ALC adjustment

(Does not operate.)

MEMO

Note that the lens cannot make ALC adjust­ments. Make ALC adjustments using the item
AVERAGE: PEAK on the menu.
( Page 26)

E-21

Back focus adjustment

• With a fixed-focus lens

If the focus can not be adjusted correctly by
rotating the lens focus ring, adjust the back
focus as follows.

1.

Loosen the back focus locking screw by
turning it counterclocckwise (

) with a

screwdriver.

2.

Shoot a pattern closely.

3.

Turn the lens focus ring to ⬁.

4.

Turn the back focus adjustment ring to
focus at the best point.

5.

Tighten the back focus locking screw by
turning it clockwise (

).

• With a zoom lens

If the image is out of focus when zooming
(telephoto wide-angle), adjust the camera as
follows:

1.

Loosen the back focus locking screw by
turning it counterclocckwise (

) with a

screwdriver.

2.

Shoot a comparatively dark scene with
thin lines.

3.

Set the lens to the maximum telephoto
position, and adjust the lens focus.

4.

Set the lens to the maximum wide-angle
position, and turn the back focus ring to
adjust the focus.
(Repeat steps

3.

and

4.

two or three

times.)

5.

Tighten the back focus locking screw by
turning it clockwise (

).

 Back focus adjustment

Be sure to make back-focus adjustments when changing the lens mounting method or using
a different lens. If required, adjust it as follows:

● To make accurate back focus adjustments, use the electronic shutter and the ND filter,
and carry out the following adjustments in a state where the lens iris is released. (The ND
filter acts to reduce the amount of incident light entering the lens evenly over the entire
wavelength band.)

MEMO

Focus setting can differ on the color and on
the black and white screen. Make adjust­ments so that the focus will come to the opti­mum on both screens.

Back focus locking
screw (M2.6)

Back focus
adjustment ring

Lens focus ring

B

F

L

O

C

K

Tighten

Loosen

E-22

CONNECTION/INSTALLATION

Auto white balance control adjustment

Each light source has its own colour temperature. Therefore, when the main light source
lighting an object is changed, the white balance should be adjusted again by pressing the
AWC button.

1.

Place a white object under the same
lighting condition as the object to be shot
and zoom in to fill the screen with white.

2.

When the AWC button is pressed for
approx. one sec., the white balance is
adjusted for the object being recorded.

3.

During the time when the Auto White
function is operated, "AWC OPERA­TION" is displayed (for approx. 0.5 sec.).
When the appropriate white balance is
acquired, "AWC OK" is displayed.

4.

Error message display

● NG : OBJECT

Displayed when there is not enough
white colour on an object or the colour
temperature is not suitable.
By taking a shot of a white object to
fill the screen, adjust the white balance
again.

● ERROR : LOW LIGHT

Displayed when the light is low. In­crease the illumination then re-adjust
the white balance.

● ERROR : HIGH LIGHT

Displayed when the light is too bright.
Decrease the illumination then re-ad­just the white balance.

MEMO

Even if you press the AWC button, the white
balance will not be re-adjusted during the
operation in the black-and-white mode.

CAMERA
SETUP

SET

MENU

EXT TERM-OFF

INT/GL

DUPLEX

RX TERM-OFF

NOT USED

ON
LL
SIMPLEX
ON

VIDEO

DC

IRIS

AWC

AWC button

AWC OK

DISPLAYING RESULT

AWC OPERATION

DURING OPERATION

AWC NG : OBJECT

OBJECT ERROR

AWC ERROR : LOW LIGHT

LOW LIGHTING

AWC ERROR : HIGH LIGHT

OVER LIGHTING

E-23

MENU SETTING

Setting the menu

CAMERA
SETUP

SET

MENU

EXT TERM-OFF

INT/GL

DUPLEX

RX TERM-OFF

NOT USED

CAMERA
SETUP

SET

MENU

ON
LL
SIMPLEX
ON

VIDEO

DC

IRIS

AWC

1.

Press the MENU button.

The MENU screen is displayed.

2.

Set the cursor (>) to a desired
sub-menu using the

,

button.

3.

Press the SET button.

The selected sub-menu screen is
displayed.

4.

Use the

,

button to set the

cursor (>) to a desired item.

5.

Change the set value using the

,

button.

Change of the set value displays a
change mark (∗).

If you wish to change the set values of
another items, repeat items

2.

to

5.

above.

6.

Press the MENU button.

The screen returns to the previous one
(MENU screen).

7.

Press the MENU button.

The screen returns to the normal screen
(quitting the menu display).

* When the setting is executed using the RM-

P2580, use a joy stick instead of the

button.

LACSETTINGS

IIRSLEVEL NORMAL

AEVRAEG:PEAK 82:

ACGMODE

2dB0

SUTHTERExDR)(

NRMALO

PIORRITY –––
BCLOFF

SNSEEUP OFF

B&W/COLOUR MODE

LACSETTINGS

AEVRAEG:PEAK 82:

ACGMODE

2dB0

SUTHTERExDR)(

NRMALO

PIORRITY –––
BCLOFF

SNSEEUP OFF

I

∗

IRSLEVEL -5

B&W/COLOUR MODE

MENU button

SET button

..

MENU

SYNC ADJUST..

V IDEO ADJUST
MODE ESLECT

ALC SETT INGS

COMMUN ICAT I ON
FACTORY SETTINGS

MOT IO N

D

E

TECT

..
..

..

..

..

LACSETTINGS

IIRSLEVEL NORMAL

AEVRAEG:PEAK 82:

ACGMODE

2dB0

SUTHTERExDR)(

NRMALO

PIORRITY –––
BCLOFF

SNSEEUP OFF

B&W/COLOUR MODE

E-24

MENU

SYNC ADJUST

VIDEOADJUST
MODE ESLECT

ALC SE TTI NGS

COMMUNI CATI ON
FACTORY SETT I NGS

MOT ION

D

E

TECT

SYNC DAJUST

VPHASE 0
HPHASE 0
SC ECOARS 0
SC FI NE 128

DEVI O ADJUST

WH TE BA L E AT WNC

A

I

CO OUR LE NORMALEL

V

L

EN ANCE L E NORMALEL

V

H

PE

E

STAL LE NORMALEL

V

D

AU

O

BLAC K OFFTL

C

T

TIMO O N DET EC T

MO E OFFD
LE EL NORMALV
AR A EDIE
AL

R

MTI EM10sA

DE

ON

STRAT

I

N

O

M

CTFA ORY SE NGSTT I

CA CELN
CL A WI

(

HOUT T I TL E)RTE

C

DATA CLEARED

LA

(

)RALLE

WH I T E B AL

A

NCE CON

T

ROL

AWC SE T . .
RB

::

MG

::

g

.

.

..

..

..

..

..

..

..

T

..

MENU SETTING

The flow of menu screen

 Page 26

 Page 31

 Page 34

 Page 35

 Page 37

 Page 39

The word “COLOUR” is displayed as “COLOR” on the TK-C1460U.

E-25

 Page 26

 Page 32

 Page 35

 Page 30

 Page 36

(The TK-C1460U does not display these
characters.)

 Page 38

LACSE TTINGS

IIRS LEVEL NORMAL

AEVRAEG:PEAK 8 2:

ACGMODE

2dB0

SUTHTERExDR)(

NRMALO

PIORRITY –––
BCLOFF

SNSEEUP OFF

MODE SEL E CT

CAMERA TI TL E ED IT . .
REVERSE MODE OFF
ALM .T I TLE S Z

E

IDOUBLE

ALARM COLOUR WHI TE

MMCO UNICATION

ST LE P TO PY
MA H NE DII – – –C

SHUTT RE(ExDR)

SHUTTER SPEED

SPEED

1 120/

–––
–––
–––

FAST LIM IT
ED

x

ER

ED

x

R

LLEV

M.

CAMERA T

I

T

L

E

’
ДЦ ВК ОФ ЫЗС
длпцьвк оф

Ü

ûáé

í

ó

аим тщзсЯ

¡¿

ú

0123456789

:-/

.,
ABCDE KL MNOPFGHI J
QRST UVWXYZ
ab

c

de klmnopf g hi j

qr

s

tuvwxyz

TDislayitle

WIDE TELE

B&W/COLOUR MODE

AUX TERMINAL
D. Z00M MAX

(B&W IN)
x2

B&W/COLOUR MODE

B&W A UX

NORMAL

LEVEL

E-26

Item Functions and set values Initial value

V PHASE

H PHASE

SC COARSE

SC FINE

This adjusts the vertical synchronization to those of other cameras
when a selector switch for the synchronizing system on the side
is at LL. (50Hz (60Hz) power region only. ( ): TK-C1460U)
When it is not set to LL, “---” will appear, disabling change
the set value.
TK-C1460U
[Set value: –131 to 0 to 131]
TK-C1460E
[Set value: –156 to 0 to 156]

This adjusts the horizontal synchronization to those of other
cameras and systems when a selector switch for the
synchronizing system on the side is at INT/GL.
When external signals are not input, “---” will appear, disabling
change the set value.
[Set values: –16 to 0 to 16]

Coarse adjustment of the SC phase in gen-lock operation.
The SC phase can be varied by up to 90° in each direction.
Adjust with reference to another camera (or system) and
together with the SC FINE adjustment.
Adjust SC COARSE and SC FINE only after adjusting H
PHASE.
When it is not set to GL, “---” will appear, disabling change
the set value.
[Set values: 0°, 90°, 180°, 270°]

Fine adjustment of the SC phase in gen-lock operation.
When it is not set to GL, “---” will appear, disabling change
the set value.
[Set values: 0 to 255]

MENU SETTING

SYNC ADJUST Screen

This executes the setting regarding synchronization.

0

0

0°

128

ALC SETTINGS Screen

Item Functions and set values Initial value

IRIS LEVEL

AVERAGE:
PEAK

This makes automatic adjustments according to brightness.

Adjusts the brightness level of the video signal.

• To lower the brightness level ... Decrease the value

• To raise the brightness level .... Increase the value

[Set values: –5 to NORMAL to 5]

Sets the exposure detection as a ratio of the average value
and the peak value.

• AVERAGE value large: Increase the AVERAGE value
when portions other than the highlighted areas of the
screen are dark and look corrupted. (Ex. 10:0)

• PEAK value large: Increase the PEAK value when
halation occurs in the highlighted areas of the screen.
(Ex. 5:5)

[Set values: 10:0, 9:1, 8:2, 7:3, 6:4, 5:5]

NORMAL

8 : 2

E-27

Item Functions and set values Initial value

SHUTTER
(ExDR)

* When the SHUTTER (ExDR) item is set to NORMAL, the following items

(SHUTTER SPEED, FAST LIMIT, ExDR LEVEL, and M.ExDR SPEED)
cannot be changed.

SHUTTER
SPEED

NORMAL

1/120

(1/100)

This sets the electronic shutter as well as the ExDR (Extended
Dynamic Range).
The use of an electronic shutter function enables shooting
with proper brightness, as more brightness results in higher
shutter speed.
The ExDR function allows even the shooting of a subject
having different luminous flux density by composing a picture
shot at 1/100 (1/120) sec. shutter speed with a picture shot
by a high-speed shutter. ( ): TK-C1460U
NORMAL: This fixes the shutter speed to 1/50 (1/60).

The ExDR does not function.

MANUAL: This sets the shutter speed by the item

SHUTTER SPEED on the SHUTTER screen.
The ExDR does not function.
When SENSE UP is functioning, MANUAL
cannot be selected. (Not displayed on MENU)

AUTO: This automatically switches the shutter speed

according to brightness.
The ExDR does not function.
The item FAST LIMIT on the SHUTTER (ExDR)
screen sets a maximum shutter speed value.

M.ExDR: This is used when shooting a subject with

difference in a luminous flux density in the screen
under a fixed illumination condition, and so on.
During ExDR mode, the item M.ExDR.SPEED on
the SHUTTER (ExDR) screen sets the composing
high shutter speed. It is possible to set only when
the items BLC and SENSE UP are OFF. What’s
more, the ExDR LEVEL sets the signal level of
the composing high-speed shutter.

A.ExDR: This is used when the subjects having different

luminous flux densities are continuously used
night and day in the situation where both indoor
and outdoor subjects are mixed in existence, and
so forth. During ExDR mode, the composing
shutter speed automatically varies according to
the contrast of a subject. This is set when shooting
the subject with changing brightness.
This can be set only when the item BLC is OFF.
What’s more, the ExDR LEVEL sets the signal
level of the composing high-speed shutter.

MEMO

• Do not set to A.ExDR when using a manual lens.

• When M.ExDR mode or A.ExDr mode is used, the border

between a bright part and a dark part can be coloured
(cyan, orange, etc.), but this is not a malfunction.

• When the SHUTTER (ExDR) item is set to M.ExDR or
A.ExDR, a flicker can occur under a fluorescent lamp,
mercury lamp, etc. However, this occurs by principle of
the ExDR function, and therefore this is not a
malfunction.

This sets a shutter speed when MANUAL is set.
The AUTO, M. ExDR, A. ExDR set value is displayed as
“---” and cannot be changed
[Set values: 1/120 (1/100), 1/250, 1/500, 1/1000, 1/2000,
1/4000, and 1/10000] ( ):TK-C1460U

E-28

Item Functions and set values Initial value

FAST LIMIT

ExDR
LEVEL

M.ExDR
SPEED

AGC MODE

SENSE UP

1/100000

NORMAL

1/4000

20dB

OFF

ALC SETTINGS Screen (Continued)

MENU SETTING

This sets the fastest value of a shutter speed when AUTO is set.
The MANUAL, M. ExDR, A. ExDR set value is displayed as “---” and
cannot be changed. The higher the shutter speed becomes, the more
smear phenomenon is emphasized, which is peculiar to the CCD.
[Set values: 1/1000, 1/2000, 1/4000, 1/10000, 1/20000, 1/40000, 1/100000]

This sets the signal level of the composing high-speed shutter during
ExDR mode. This is set according to the brightness of a subject.
When using M.ExDR, be sure to set M.ExDR SPEED in advance.
When the SHUTTER (ExDR) item is set to MANUAL or AUTO,
“---” appears, disabling setting.
To give priority to the low-brightness parts of the subject

…

increase the value

To give priority to the high-brightness parts of the subject…

decrease the value

[Set values: –5 to NORMAL to 5]

MEMO

• In the case of a subject with a large difference in the luminous
flux density, sometimes images do not change even if ExDR
LEVEL is varied. However, this occurrence is a peculiarity of
the unit and is not a malfunction.

This sets the composing high shutter speed when ExDR is set to M.ExDR.
Set the shutter speed in order that a subject with a high luminous flux
density (outdoor, etc.) may come out most clearly. This is displayed as
“---” dur ing MANUAL, AUTO or A. ExDR and cannot be set.
[Set values: 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/20000]

This sets a maximum gain of the AGC (Automatic Gain Control).
OFF: When the AGC function is not used.
10dB: When luminous energy is insufficient.
20dB: When luminous energy is extremely insufficient.
SUPER: When brightness is insufficient even when it is set to

20dB.

• If the gain is increased, the screen gets rough in a dark place.

• If it is set to SUPER, it can sometimes consume operation time

to cope with a drastic level change.

•

When the item “B&W” is set to “AUTO”, [SUPER] is displayed when
the item “AGC MODE” is set to “SUPER”, and [20dB] is displayed
for other settings. Increase the gain up to the value displayed.

This item makes up a sensitivity should be heightened automatical-

ly when a subject becomes dark.

In case of the X32 AUTO, the sensitivity is automatically heightened

up to 32 times continuously as compared with standard.

As the sensitivity becomes higher, the shutter speed becomes

lower, resulting in unnatural motion.

If SHUTTER (ExDR) is set to MANUAL or the M.ExDR,

“---” will appear, disabling the SENSE UP function.

[Set values: OFF, X2 AUTO, X4 AUTO, X8 AUTO, X16 AUTO, X32

AUTO]

MEMO

• When the magnification of SENSE UP is enhanced, the screen
can become coarse or whitish, or whitish flaws can emerge
sometimes, but this is not abnormal.

• When the item SENSE UP is set other than to OFF, a flicker can
occur under a fluorescent lamp, mercury lamp, etc. However,
this occurs by principle of SENSE UP, and therefore this is not a
malfunction.

E-29

Item Functions and set values Initial value

PRIORITY

BLC

MOTION

OFF

OFF AREA 1 AREA 2 AREA 3 AREA 4

Light
metering
area

Light
metering
area

Light
metering
area

Light
metering
area

Light
metering
area

This item sets the order in which the AGC and slow shutter
speed decrease function when the object brightness
becomes low.

If B&W item of the B&W/COLOUR mode is set to AUTO, and the
AGC MODE item or the SENSE UP item is set to OFF, “---” will
appear, disabling any setting.

MOTION: Priority is given to motion.

This is suitable to a subject with quick motion,
since the AGC (automatic gain control) functions
with priority when the subject becomes dark.

PICTURE: Priority is given to image.

When the subject becomes dark, SENSE UP
(sensitivity goes up) functions with priority,
offering suitability that gives priority to image.

Sets the backlight compensation function. Set when a
bright light source, etc. is placed in the same direction as
the subject.

If the item SHUTTER (ExDR) is set to the M.ExDR or the
A.ExDR, “---” will appear, and the BLC does not function.

OFF: The backlight compensation function does not work.

AREA 1 to AREA 4: When the SET button is pressed, the
fixed light metering areas are displayed. Select one of
the four types. (Indicated positions on the screen are rough
guides. Execute required settings after checking and
confirming the functions on actual images.)

* The indicated position on the screen should be used as

a rough guide.

EDIT 1 to EDIT 2: When the SET button is pressed, the
user light metering areas are displayed. Select one of the
two types.

 “BLC EDITTING Screen

”

on page 36.

E-30

ALC SETTINGS Screen (Continued)

MENU SETTING

Item Functions and set values Initial value

B&W COLOUR

MODE .....

B&W

LEVEL

This function sets the colour modes to colour or B&W.
When switching the mode between “colour’’ and “B&W”
is carried out, the focus may be dislocated. In such a
case adjust the focus again.

Switches the mode from colour to B&W and visa-versa.
OFF : Turns the B&W mode switching function off.
ON : Sets the camera permanently to B&W mode.
AUTO : The camera automatically switches to Colour

mode when the object is bright and B&W mode
when it is dark. ( Page 40)

AUX : B&W/COLOUR switching is carried out

according to the signal input from the AUX
terminal. ( Page 41)

MEMO

• If AUTO is selected as the B&W item, the B&W/COLOUR
setting can be switched as appropriate according to the
brightness of the object, but illumination and screen
conditions may make this impossible. Moreover, when
you use infrared illumination, if the subject excessively
reflects, a B/W screen can switch to a color screen. To
make absolutely certain of B&W/COLOUR switching,
set to AUX and input the control signal to the AUX
terminal.

• If AUX is selected as the B&W item, the AUX TERMINAL
item is automatically set to B&W IN. If this changes to
anything other than AUX, the AUX TERMINAL item
reverts to the value set before the change was made.
( Page 33.)

When the “B&W” function is set to “AUTO”, this function
sets the signal level of the object at which the camera will
automatically switch to B&W mode.
LOW : Switches to B&W mode when the signal level of

the object indicates low illumination.

NORMAL

: Switches to B&W mode when the signal level of

the object indicates medium illumination.

HIGH : Switches to B&W mode when the signal level of

the object indicates high illumination.

MEMO

When the item “B&W” is set to other than AUTO, “---” is
displayed and the settings to the item “LEVEL” cannot be
varied.

AUX

NORMAL

E-31

Item Functions and set values Initial value

WHITE
BALANCE

COLOUR
LEVEL

ENHANCE
LEVEL

PEDESTAL
LEVEL

AUTO
BLACK
CTL

Selects the white balance adjustment function. The white
balance can be adjusted manually or automatically for
light within the colour temperature range of 2500K to
8000K.

• ATW: Auto-Tracking White Balance mode.
This automatically adjusts the white balance.

• AWC: Auto White Balance Controll mode. When the
SET button is pressed, the adjustment
screen appears.
( See page 37.)

MEMO

The “---” will appear during operation in the black-and-
white mode and any setting cannot be changed.

To adjust the colour level of the video signal.

• To make colours lighter

… Decrease the v

alue

• To make colours darker … Increase the value

[Set values: –5 to NORMAL to 5]

MEMO

The “- - -” will appear during operation in the black-and­white mode and any setting cannot be changed.

To adjust the contour enhancing level of the video signal.

• To make the picture quality harder

… Increase the v

alue

• To make the picture quality softer

… Decrease the v

alue

[Set values: –5 to NORMAL to 5]

To adjust the pedestal level of the video signal.

• To brighten picture … Increase the v

alue

• To darken picture … Decrease the value

[Set values: –5 to NORMAL to 5]

This is set when it is difficult to view a dark part of the
image even if gain is boosted by the AGC (automatic gain
control).
ON: When a black level of the image signal is low, a

pedestal level that becomes the standard of black
is automatically elevated, making it easier to view a
dark part.

OFF: AUTO BLACK does not function.

MEMO

• When PEDESTAL LEVEL is set to 5, no function can

take place even if AUTO BLACK CTL is ON.

• When AGC MODE is set to OFF, no function can take

place even if AUTO BLACK CTL is ON.

AT W

NORMAL

NORMAL

NORMAL

OFF

VIDEO ADJUST Screen

Adjustments are made on video signals.

E-32

MODE SELECT Screen

Titles, image reversion, etc., are set.

Item Functions and set values Initial value

CAMERA
TITLE EDIT

REVERSE
MODE

ALM.TITLE
SIZE

ALARM
COLOUR

–

OFF

DOUBLE

WHITE

ALARM

ALARM

NORMAL DOUBLE

Bring up the CAMERA TITLE, EDIT screen.
( Page 38)

Settings are executed for image reversion.
OFF: Image does not reverse.
R-L: Left and right of the image are reversed.
U-D: Up and down of the image are reversed.
ALL: Up and down and left and right of the image are

reversed.

Set the size of the characters displayed in the case of
alarms.

This sets the colour of an alarm title.
[Set values: WHITE, YELLOW, CYAN, GREEN]

MEMO

In the ALARM mode, the colour of camera title appears
in the ALARM COLOUR set.

MENU SETTING

E-33

Item Functions and set values Initial value

AUX
TERMINAL

D-ZOOM
MAX

(B&W IN)

x2

For setting the signal input or output of the AUX terminal.

MOTION: A signal is output if there is a change in the

area set on the MOTION DETECT screen.

B&W OUT: A signal is output when the camera switches

to B&W or Colour mode.

B&W IN: Set to this position when inputting the B&W/

Colour switching control signal to the AUX
terminal. ( Page 11, 30.)

MEMO

• In setting B&W OUT, if you use an infrared illuminator in

link motion, hunting can occur. To prevent this, we
recommend that you link in motion this unit and the
infrared illuminator, etc., by control signals after setting
to B&W IN.

• If the B&W item is set to AUX, the AUX TERMINAL item

changes to [B&W IN] and can not be changed.

This function sets the maximum zoom ratio of the
electronic zooming.
[Set values: x1, x2, x4, x6, x8, x10]

MEMO

• The electronic zoom function can only be used by the

communication command of exclusive controllers (RM­P2580, etc.).

• Note Picture quality deteriorates under electronic

zooming as it is accompanied by digital image
processing.

• When the electronic zoom magnification ratio is

increased, there may be blurring in the upper center left
of the screen. This is a characteristic of the main unit
and is not a malfunction.

E-34

MENU SETTING

MOTION DETECT Screen

Item Functions and set values Initial value

MODE

Settings are executed about the motion detecting function that emits alarm signals when
there exists any motion in the image. Alarm signals are output from the auxiliary terminals on
the back.

This sets ON/OFF of motion detecting function.
OFF: Motion detecting function does not work.
ON: Motion detecting function works.

OFF

LEVEL

AREA EDIT

ALARM TIME

DEMONSTRA­TION

This sets the level that detects motion.
If the item MODE is set to OFF, “---” will appear, and
settings cannot be changed.
To function with large signal level change…decrease the
value
To function with small signal level change…increase the
value
[Set values: –5 to NORMAL to 5]

This sets the range in which the motion detecting function
works.
( Page 39)

This sets the output time of the alarm signal output of
AUX terminal as well as “ALARM” display on the screen
when motion is detected.
If the item MODE is set to OFF, “---” will appear, and
settings cannot be changed.
[Set values: OFF, 5s, 6s, 7s, 8s, 9s, 10s, 15s, 20s, 30s,
1min]

MEMO

Even when the ALARM TIME item is set to OFF, an alarm
signal is output from the AUX terminal for about 500ms,
and “ALARM” is not displayed on the screen.

This is used when checking and confirming the set motion
detecting function. The detection area is shown in gray.
( Page 39)

NORMAL

–

10s

–

E-35

Item Functions and set values Initial value

FACTORY
SETTINGS

Set values are returned to initial values.

The values set on the menu are returned to initial values.
CANCEL : No return to the initial value.
CLEAR : Returns set values except titles to the
(WITHOUT TITLE)

initial value.

CLEAR (ALL) : Returns all set values including titles

to the initial value.
Select respective set value and press the SET button. Then,
“DATA CLEARED” will appear for about 3 seconds. Be
sure not to switch off the power while the display is still on.

MEMO

However, when FACTORY SETTINGS by means of
transmitted commands, the contents of the
COMMUNICATION menu do not return to the factory
settings.

–

This sets a communication system according to the
system used.
P TO P (Point to point)
This is set when a remote control unit controls a camera.
M.DROP (Multi-drop)
This is set when a remote control unit controls a plural
number of cameras.

This is set when the STYLE item is set to M.DROP. This
is the number that identifies individual cameras in a group.
No proper function can be realized if an ID number is
repeated within a system.
A combined use with the RM-P2580 necessitates the
setting together with the video input number of the RM­P2580.
If the item STYLE is set to P TO P, “---” will appear, and
settings cannot be changed.
[Set values: 1 to 99]

COMMUNICATION Screen

Item Functions and set values Initial value

STYLE

MACHINE ID

Settings are made for the control signal-connecting terminals on the back.
If the setting is changed, be absolutely sure to switch on the power again.

P TO P

– – –

FACTORY SETTINGS Screen

E-36

BLC EDITTING Screen

MENU SETTING

It is possible to set freely the light metering area for backlight compensation. The 2 screens
of EDIT1 and EDIT2 can be set.

CAMERA
SETUP

SET

MENU

AWC

LACSETTINGS

IIRSLEVEL NORMAL
AEV RAGE :PEAK 8 2:
SUTHTERExDR)(NRMALO

PIORRITY MTIONO
BCL

EDIT 1

SNSEEUP OFF

ACGMODE 2dB0

B&W/COLOUR MODE

EDIT 1 screen

Light metering
area

Light metering
area

SET button

SET button

SET button

MENU button

EDIT 2 screen

1.

Set the item BLC on the ALC
SETTING screen to EDT1.

2.

Press the SET button.

The EDIT1 screen is brought up.

3.

Set the upper side and left side
of the metering area using the

button.

The sides having

marks can

be changed.

4.

Press the SET button.

The changeable sides of the metering
area move to the right side and base
side.

5.

Set the base and right side of the
metering area using the

button.

If the SET button is pressed once more,
the two changeable sides of the meter­ing area return to the top and left sides.
(The EDIT2 screen can also be set
likewise)

6.

Upon completion of setting,
press the MENU button.

The screen returns to ALC SETTING
SCREEN.

* To use the set metering area, set the item

BLC to EDIT1 or EDIT2.

* The indicated position on the screen

should be used as a rough guide.

E-37

Manual Adjustment of White Balance

When automatic adjustment of the white balance results in a “reddish screen”, etc., adjust the
white balance manually.

1.

Set the WHITE BALANCE item on the
VIDEO ADJUST screen to AWC and
press the SET button.
* The WHITE BALANCE adjustment

screen appears on the monitor.

2.

Select the hue to be adjusted. (R/B or
Mg/G)
Press the

or

button.

3.

Adjust the hue.
Press the

or

button.

* The “ ı ” indicator moves in accordance

with the setting. When a setting is
changed, the “+” mark appears at the
original position.

4.

Concluding manual white balance ad­justment.
Pushing the MENU button returns the
screen to VIDEO ADJUST.

MEMO

If the mode is changed from color to black­and-white during the color phase adjustment
on the WHITE BALANCE CONTROL screen,
the VIDEO ADJUST screen will be brought
back. At this time, any adjusted value will not
be saved.

DEVI O ADJUST

WH T E BA L E AWCNC

A

I

CO OUR LE NORMALEL

V

L

EN ANCE LE NORMALEL

V

H

PE

E

STAL LE NORMALEL

V

D

AU

O

BLAC K OFFTL

C

T

WHI T E BAL

A

NCE CON

T

ROL

AWC SE T . .

RB

::

MG

::

g

VIDEO ADJUST screen

WHITE BALANCE
CONTROL screen

CAMERA
SETUP

SET

MENU

AWC

SET buttonMENU button

The word “COLOUR” is displayed as “COLOR” on the TK-C1460U.

E-38

1.

Select the item CAMERA TITLE
on the MODE SELECT screen,
and push the SET button.

Then, the CAMERA TITLE screen is
brought up.

2.

Select the first character from the
character area using
buttons.

The selected character is displayed
flashing on and off.

3.

Push the SET button.

The first character gets fixed and the
blinking title input area moves to the
second character.

4.

Repeat the above items 2 to 3.

It is possible to use up to 24 characters
to input the title.

5.

Push the MENU button.

The screen returns to MODE SELECT.

Up to 24 characters can be selected as camera text for each camera. The set characters are
displayed at the bottom of the screen.

MENU SETTING

CAMERA TITLE Setting

CAMERA
SETUP

SET

MENU

AWC

SET buttonMENU button

MODE S EL E CT

CAMERA T I TLE ED IT . .

REVERS E MODE OFF

ALM .T I TLE S Z

E

I D OUBLE
ALARM COLOUR WH ITE
AUX TERMINAL (B&W IN)
D. ZOOM MAX x2

MODE SELECT screen

CAMERA TITLE screen

CAMERA T

I

T

L

E

’
ДЦ ВК ОФЫ ЗС
длп цьвко ф

Ü

ûáé

í

ó

аим тщзсЯ

¡¿

ú

0123456789

:-/

.,
ABCDE KLMNOPFGH IJ
QRSTUVWXYZ
ab

c

de kl mnopf g hi j

qr

s

tuvwxyz

TDislayitle

WD

IE LETE

Space

Character area

Title input area

(The TK-C1460U does
not display these
characters.)

▲

E-39

Setting the MOTION DETECT Function

It is possible to set freely the area where MOTION DETECTING functions.

TIMO ON DE T ECT

MO E OFFD
LE EL NORMALV
AR A ED ITE
AL

R

MTI EM10sA

DE

ON

STRATI N

O

M

..

..

MOTION DETECT screen

flash

lights gray

flash

Setting screen

1.

Select the item AREA EDIT on
the MOTION DETECT screen.

2.

Press the SET button.

The setting screen is brought up.

3.

Select the area not subject to
detection using the
button.

The area flashing ON and OFF in black
and white moves.

4.

Press the SET button.

The area not subject to detection is set,
and it turns gray (lights up).
To cancel the set area, press the SET
button again.

5.

Repeat items 3 and 4 above.

6.

Upon completion of setting,
press the MENU button.

The screen returns to the MOTION
DETECT menu.

MEMO

• Indicated positions on the screen are rough
guides.
Be sure to check and conform the positions
on the actual screen.

* It is possible to check and confirm the set

areas on the DEMONSTRATION screen.
The detection area is shown in gray.

• The MOTION DETECT function does not
work for about 5 seconds after exiting
MENU.

The motion detector is not a feature to prevent theft, fire, etc. Even if an accident should occur
resulting in damage, we do not accept any liability.

E-40

MODE S EL E CT

CAMERA T I TLE ED IT . .
REVERS E MODE OFF
ALM .T I TLE S Z

E

I D OUBLE
ALARM COLOUR WH ITE
AUX TERMINAL (B&W IN)
D. ZOOM MAX x2

Output of Black-White/Color switching signal

It is possible to output black-white/color switching signal from the AUX terminal on the back of
this unit. Perform the following settings.

 Set the B&W Item to AUTO.

1.

Select the B&W/COLOR MODE item on
the ALC SETTING screen.

2.

Press the SET button.
The B&W/COLOR MODE screen

appears.

3.

Press either the

button or the

button and select the B&W item.

4.

Press either the

button or the

button and set to “AUTO”.

5.

Upon completion of setting, press the
MENU button twice.
Then, the MAIN MENU screen is
brought back.

 Set the AUX TERMINAL Item to

B&W OUT.

1.

Select MODE SELECT on the MAIN
MENU screen.

2.

Press the SET button.
The MODE SELECT screen appears.

3.

Press either the

button or the
button and select the AUX TERMINAL
item.

4.

Press either the

button or the
button and set to

”B&W OUT”.

5.

Upon completion of setting, press the
MENU button twice.

• Then, the normal screen is brought

back.

B&W
LEVEL

NORMAL

AUTO

B&W/COLOR MODE

CAMERA
SETUP

SET

MENU

AWC

SET buttonMENU button

MEMO

• When you use infrared illumination, if the
subject excessively reflects, a B/W screen
can switch to a color screen.
To perform switching with higher accuracy,
we recommend that you use it by the setting
mentioned in [Control by Black-White/Color
Switching Signal From the Outside],
referring to Page 41.

CAUTION:

When you use near infrared ray illumi­nations, use a lens that is compatible
with the near infrared ray illuminations.
Any lens other than the compatible one
can result in out-of-focus due to such
characteristics.

E-41

Control by Black-White/Color Switching Signal From the Outside

Carry out the following setting when you link in motion the black-white/color switching of this
unit and infrared illumination, etc., using the switching signal from the outside control device.

 Set the B&W item to AUX.

1.

Select B&W/COLOR MODE on
the ALC SETTING screen.

2.

Press the SET button.

• The B&W/COLOR MODE screen
appears.

3.

Press either the

button or the

button and select the B&W

item.

4.

Press either the

button or the

button and set to “AUX”.

Then, the AUX TERMINAL item on the
MODE SELECT screen is automatically
set to (B&W IN). Refer to  Page 33.

5.

Upon completion of setting,
press the MENU button.

• Then, the ALC SETTING screen is
brought back.

LACSETTINGS

IIRSLEVEL NORMAL

AEVRAEG:PEAK 82:

ACGMODE

2dB0

SUTHTERExDR)(

NRMALO

PIORRITY
BCLED

SNSEEUP OFF

B&W/COLOR MODE

TION

T1

MO

I

CAMERA
SETUP

SET

MENU

AWC

SET buttonMENU button

B&W
LEVEL

NORMAL

AUTO

B&W/COLOR MODE

DC12V

AC24V

Y/C OUT

SYNC IN

POWER

VIDEO OUT

SEE INST­RUCTION
MANUAL

+

-

12

CLASS 2 ONLY(U TYPE)

ISOLATED POWER ONLY

(E TYPE)

TX

+

TX

-

RX

+

RX

-

AUX

GND

ABCD

B&W: Make signal
COLOR: Break signal

TK-C1460

Switching
signal

Infrared illumination, etc.

Sensor or switch

Outside control device

CAUTION:

When you use near infrared ray illumi­nations, use a lens that is compatible
with the near infrared ray illuminations.
Any lens other than the compatible one
can result in out-of-focus due to such
characteristics.

It is requested that you consult our JVC dealer about connecting
devices, etc.

E-42

OTHERS

Installing the ferrite core

To retain electromagnetic compatibility, use the ferrite cores provided when connecting to the lens or
the power source.

VIDEO

DC

IRIS

ALC

LEVEL

Av Pk

L H

Notes:

Install the ferrite cores within 50 mm of the camera-side connectors. (Fasten the ferrite
core with the wire clamp provided.)
For lens connection: Pass the lens cable through the ferrite core twice and con-

nect it to the camera.

Wind twice

Ferrite core

Video-iris lens
(or galvanometnc-iris lens)

DIMENSIONS (Unit: mm)

71

70

55

63

42

138

149

41

U1-32U1-32

39

35

1/4 – 20UNC

Specifications

E-43

Image pickup device: TK-C1460U

1/3 type IT CCD, 768 (H) × 494 (V)

TK-C1460E

1/2 type IT CCD, 752 (H) × 582 (V)
Synchronization method : Internal, Line lock, Full Genlock
Scanning frequency: TK-C1460U

(H) 15.734 kHz, (V) 59.94 Hz

TK-C1460E

(H) 15.625 kHz, (V) 50 Hz
Resolution: 480 TV lines (H)
VIDEO OUT: Composite video signal 1 V (p-p), 75Ω (BNC)
Y/C OUT: TK-C1460U (4-pin)

Y: 0.714V(p–p), 75Ω

C: 0.286V(p–p), 75Ω

TK-C1460E (4-pin)

Y: 0.7V(p–p), 75Ω

C: 0.3V(p–p), 75Ω
Video S/N ratio: 50 dB (AGC OFF)
Minimum required illumination: 0.8 lx (50%, F1.2, AGC 20 dB)

0.4 lx (25%, F1.2, AGC 20 dB)

0.02 lx (50%, F1.2, AGC 20 dB, B&W MODE)

0.025 lx (50%, F1.2, AGC 20 dB, SENSE UP × 32)

Communication: RS-422A or RS-485 (switchable)

9600 bit/s
Lens mount: C/CS mount
Power supply and power consumption:

TK-C1460U

AC24V `, 60 Hz, DC12V

—

---

6.0 W

TK-C1460E

AC 24 V ` 50 Hz/60 Hz, DC 12 V

—

---

550 mA

Ambient temperature: –10°C to 50°C (operation)

0°C to 40°C (recommended)
Mass: 640 ˝
Accessory: TK-C1460U

Instructions ......................... 1 Ferrite core ................ 1

4P plug ............................... 1 Warranty card ............ 1

Service Information card .........

1

TK-C1460E

Instructions ......................... 2 Ferrite core ................ 1

4P plug ............................... 1

Specifications (Continued)

Design and specifications are subject to change without notice.
