Audio sectionFront/Surround40 W per channel, RMS at 3 Ω at 1 kHz, with 10 % total harmonic distortion.
Center100 W, RMS at 4 Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer100 W, RMS at 4 Ω at 30 Hz, with 10 % total harmonic distortion.
Video sectionVideo SystemPAL
Horizontal Resolution500 lines
Signal-to-Noise Ratio64 dB (Composite signal when "RGB" is selected)
Video output levelComposite : 1.0 V(p-p)/75 Ω
Only for XV-THP7/XV-THP5Component-Y : 1.0 V(p-p)/75 Ω
USB storageUSB specificationCompatible with the USB 2.0 Full-Speed
Compatible deviceMass Storage Class
Compatible file systemFAT16, FAT32
Bus power supplyMax. 500 mA
Tuner sectionTuning RangeFM : 87.50 MHz to 108.00 MHz
GeneralPower RequirementsAC 230 V , 50 Hz
Power Consumption60 W (at operation)
Dimensions (W × H × D)435 mm × 70 mm × 308 mm
Mass3.0 kg
Subwoofer (SP-WP7/SP-WP5)
TypeBass-Reflex Type
Speaker16 cm cone × 1
Power Handling Capacity100 W
Impedance4 Ω
Frequency Range35 Hz to 200 Hz
Sound Pressure Level75 dB/W·m
Dimensions (W × H × D)129 mm × 284 mm × 337 mm
Mass3.1 kg
Y : 1.0 V(p-p)/75 Ω
C : 0.3 V(p-p)/75 Ω
RGB : 0.7 V(p-p)/75 Ω
Component-PB/PR : 0.7 V(p-p)/75 Ω
AM (MW) : 522 kHz to 1 629 kHz
1.4 W (in standby mode)
Satellite speakers (For TH-P7)
Front speakers
(SP-THP7F)
Center speaker
(SP-THP7C)
Surround speakers
(SP-THP7S)
Type1-Way Bass-Reflex Type (Magnetically-shielded Type)
Speaker5.5 cm cone × 1
Power Handling Capacity40 W
Impedance3 Ω
Frequency Range100 Hz to 20 000 Hz
Sound Pressure Level74 dB/W·m
Dimensions (W × H × D)280 mm × 1106 mm × 280 mm
Mass3.1 kg each
Type1-Way 2-Speaker Bass-Reflex Type (Magnetically-shielded Type)
Speaker6.5 cm cone × 2
Power Handling Capacity100 W
Impedance4 Ω
Frequency Range90 Hz to 20 000 Hz
Sound Pressure Level82 dB/W·m
Dimensions (W × H × D)250 mm × 85 mm × 91 mm
Mass0.8 kg
Type1-Way Bass-Reflex Type
Speaker5.5 cm cone × 1
Power Handling Capacity40 W
Impedance3 Ω
Frequency Range100 Hz to 20 000 Hz
Sound Pressure Level73 dB/W·m
Dimensions (W × H × D)280 mm × 1106 mm × 280 mm
Mass3.1 kg each
Designs & specifications are subject to change without notice.
1-2 (No.MB530)
Page 3
SECTION 1
PRECAUTION
1.1Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purposes. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be performed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteristics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Service Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety characteristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassembling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isolation check on the exposed metal parts of the product (antenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particularly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ω per volt or more sensitivity
in the following manner. Connect a 1,500Ω 10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
0.15 F AC TYPE
Place this
probe on
1500 10W
Good earth ground
1.2Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of preforming repair of this system.
1.4Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
each exposed
metal part.
(No.MB530)1-3
Page 4
1.5 Safety Precautions (U.K only)
(1) This design of this product contains special hardware and many circuits and components specially for safety purposes. For con-
tinued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits.
(2) Any unauthorised design alterations or additions will void the manufacturer's guarantee; furthermore the manufacturer cannot
accept responsibility for personal injury or property damage resulting therefrom.
(3) Essential safety critical components are identified by ( ) on the Parts List and by shading on the schematics, and must never
be replaced by parts other than those listed in the manual. Please note however that many electrical and mechanical parts in
the product have special safety related characteristics. These characteristics are often not evident from visual inspection. Parts
other than specified by the manufacturer may not have the same safety characteristics as the recommended replacement parts
shown in the Parts List of the Service Manual and may create shock, fire, or other hazards.
(4) The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be separated from live parts,
high temperature parts, moving parts and/or sharp edges for the prevention of electric shock and fire hazard. When service is
required, the original lead routing and dress should be observed, and it should be confirmed that they have been returned to
normal, after re-assembling.
1.5.1 Warning
(1) Service should be performed by qualified personnel only.
(2) This equipment has been designed and manufactured to meet international safety standards.
(3) It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
(4) Repairs must be made in accordance with the relevant safety standards.
(5) It is essential that safety critical components are replaced by approved parts.
(6) If mains voltage selector is provided, check setting for local voltage.
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
1-4 (No.MB530)
Page 5
1.6Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.6.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(caption)
Anti-static wrist strap
1M
Conductive material
(conductive sheet) or iron palate
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.7Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.8Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
• Apply solder to the short land sections before the card wire is disconnected from the connecto on the servo board. (If the card wire
is disconnected without applying solder, the pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.
Solder short
(No.MB530)1-5
Page 6
1.9Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABELS and PRINT
WARNING LABEL and PRINT
1-6 (No.MB530)
Page 7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
(No.MB530)1-7
Page 8
SECTION 3
DISASSEMBLY
3.1Main Body
3.1.1 Removing the top cover
(See Fig.1 and 2)
(1) Remove the two screws A attaching the top cover of both
side. (See Fig.1)
(2) Remove the five screws B attaching the top cover of rear
side. (See Fig.2)
A
Fig.1
B
Fig.2
1-8 (No.MB530)
Page 9
3.1.2 Removing the front panel assembly
(See Fig.3 to 5)
(1) Remove the three screws C attaching the front panel as-
sembly from bottom side. (See Fig.3)
(2) Remove the screw D attaching the earth wire to power sup-
ply board. (See Fig.4)
(3) Disconnect the parallel wires from connectors CN101
CN422 and the card wire CN421 on the main board. (See
Fig.4)
(4) Release the hook a of bottom side and hook b of both side
of front panel assembly. (See Fig.3 and 5)
C
,
a
Fig.3
D
CN421CN422
CN101
Fig.4
b
Fig.5
(No.MB530)1-9
Page 10
3.1.3 Removing the tuner pack
(See Fig.6 and 7)
(1) Disconnect the card wires from connector CN652
board. (See Fig.6)
(2) Remove the two screws E attaching the tuner pack from
rear panel. (See Fig.7)
of video
CN652
Fig.6
E
Fig.7
1-10 (No.MB530)
Page 11
3.1.4 Removing the DVD mechanism assembly
(See Fig.8 to 10)
(1) Disconnect the card wire from connectors CN405
, CN413 of main board. (See Fig.8)
CN412
(2) Disconnect the connector wire from connector CN414 of
main board. (See Fig.8)
(3) Disconnect the connector wire from connector CN811
(See Fig.9)
(4) Remove the two screws F attaching the DVD mechanism
assembly from bottom cover. (See Fig.10)
(5) Press the hook c and slide out the DVD mechanism for di-
rection the arrow. (See Fig.10)
, CN411,
.
CN414
Fig.8
CN405
CN412
CN411
CN413
F
CN811
Fig.9
Fig.10
c
(No.MB530)1-11
Page 12
3.1.5 Removing the video board
(See Fig.11 and 12)
(1) Disconnect the card wires from connectors CN601
. (See Fig.11)
CN651
(2) Remove the two screws G attaching the video board. (See
Fig.11)
(3) Remove the three screws H attaching the video board from
rear panel. (See Fig.12)
,
CN601
G
Fig.11
H
Fig.12
1-12 (No.MB530)
Page 13
3.1.6 Removing the main board
(See Fig.13 and 14)
(1) Disconnect the parallel wires from connectors CN401
, CN404 on the main board. (See Fig.13)
CN403
(2) Remove the four screws J attaching the main board. (See
Fig.13)
(3) Remove the two screws K attaching the main board from
rear panel. (See Fig.14)
,
J
CN401
CN403
CN404
J
K
Fig.13
Fig.14
(No.MB530)1-13
Page 14
3.1.7 Removing the power supply board
r
(See Fig.15)
Caution:
When remove the power supply board, do not touch the capacitor (C905) because it keep voltage.
(1) Remove the four screws L attaching the power supply
board.
(2) Release the power supply board from fastener.
.
fastene
.
3.1.8 Removing the switch board
(See Fig.16)
(1) Remove the three screws M attaching the switch board.
3.1.9 Removing the headphone board
(See Fig.16)
(1) Remove the screw N attaching the headphone board.
3.1.10 Removing the FL board
(See Fig.17)
(1) Remove the three screws P attaching the FL board.
.
Fig.15
M
N
Fig.16
1-14 (No.MB530)
P
Fig.17
Page 15
3.2DVD mechanism
3.2.1 Removing the traverse mechanism
(See Fig.1 to 7)
(1) Remove the two screws A attaching the tramecha holder
from top side of DVD mechanism assembly. (See Fig.1)
(2) Remove the two screws B attaching the DVD module
board. (See Fig.2)
(3) Remove the one screw C attaching the tramecha holder.
(See Fig.3)
(4) Through the DVD module board from mecha tramecha
holder and take out the mecha holder. (See Fig.4)
(5) Remove the four screws D attaching the traverse mecha-
nism. (See Fig.5)
(6) Solder the solder part of DVD pick up. (See Fig.6)
(7) Disconnect the card wire from CN101
DVD module board. (See Fig. 7)
Caution:
• Solder the short land section on the DVD pickup before dis-
connecting the card wire from the connector on the DVD
pickup. If the card wire is disconnected without attaching solders, the pickup may be destroyed by static electricity.
• When attaching the DVD pickup, be sure to remove solders
from the short land section after connecting the card wire to
the connector on the DVD pickup.
and CN201 on the
DVD mechanism assembly
B
B
A
A
Clamper base
DVD module board
Fig.2
DVD mechanism assembly
DVD mechanism assembly
Fig.1
DVD module board
C
Fig.3
(No.MB530)1-15
Page 16
DVD module board
r
Solder short
Fig.6
DVD module board
Tramecha holde
CN101
CN201
DVD mechansim assembly
Fig.4
DVD mechanism assembly
Traverse mechanism assembly
DD
Fig.7
1-16 (No.MB530)
Fig.5
Page 17
3.2.2 Removing the pickup assembly
(See Fig.8 to 12)
(1) Remove the two rod springs pressing the guide shaft. (See
Fig.8)
(2) Remove the screw E and F attaching the spring holder.
(See Fig.9)
(3) Remove the read screw from traverse mechanism assem-
bly. (See Fig.10)
Caution:
When remove the lead screw, do not loss the middle
gear. (See Fig.11 and 12)
(4) Remove the bar spring pressing the shaft. (See Fig.11)
(5) Take out the pickup assembly from traverse mechanism
chassis by order. (See Fig.12)
(SHAFT)
(T.TABLE)
HOOK
(BAR SPRING)
Fig.11
ROD SPRINGROD SPRING
Fig.8
Spring holder
Fig.9
order 2
order 3
order 1
Fig.12
EF
Middle gear
Lead screw
Fig.10
(No.MB530)1-17
Page 18
3.2.3 Removing the feed motor assembly
(See Fig.13)
(1) Remove the one screw G attaching the feed motor assem-
bly.
(2) Remove the feed motor wires from solder part of spindle
motor board.
Splder part
3.2.4 Removing the spindle motor assembly
(See Fig.14)
(1) Remove the two screws H attaching the spindle motor from
spindle motor board.
Middle gear
Lead screw
Fig.13
H
Spindle motor
Fig.14
G
1-18 (No.MB530)
Page 19
3.2.5 Removing the tray assembly
(See Fig.15 and 16)
(1) Remove the two screws J attaching the clamper base.
(See Fig.15)
(2) Remove the one screw K attaching the shaft guide from
bottom side. (See Fig.15)
(3) Remove the two screws L attaching the shaft guide from
top side. (See Fig.16)
Caution:
When attach the tray assembly, boss of loading sub assembly
should attach to guide of bottom side at tray assembly. (See
Fig.16)
J
order 1
order 2
clamper base
L
K
Fig.16
[bottom side]
Fig.15
(No.MB530)1-19
Page 20
SECTION 4
ADJUSTMENT
4.1ATTENTION IN SERVICE OF DVD SECTION
(1) When pickup, Flash ROM ,DVD module board were changed, initialize EEPROM by all means.
(2) When full initialization was excuted, excute learning with a DVD test disc by all means.
Test disc : VT-501, VT-502
Learning method : It is adjusted automatically by normal playback of a DVD disc.
4.2TEST MODE
4.2.1 OUTLINE
To the set which is using the DVD module, in order to perform common correspondence in production, TEST mode is prepared.
Table 1 is corresponded in TEST mode.
MODECONTENTS
The destination, a region, study
state check mode
NORMAL initialize, FULL initialize
Device key write (CPPM, CPRM)
Device key check sum indication
mode
Micon version indication mode
FL all on mode
FRONT END check mode
Table 1. Contents corresponding to TEST mode.
Indication the distination code, region number and study state fo DVD micon.
Mode of DVD micon initialize. Initialize has NORMAL initialize and FULL initialize.
NORMAL initialize : Initialize the value of user setting item, like a indication contents of
SETUP OSD.
FULL initialize : Plus the contents of study which are carrying out the memory by
FRONT END for lead shortening are initialized for NORMAL initialize
contents.
For device key writing mode. Device key have CPPM(DVD Audio) and CPRM(VR).
Indication the wrote device key check sum. Indication this value, it can check the device key was
wrote or not.
Indication System micon, DVD micon, other ROM version. With a set, correspondence and the
contents of correspondence shall be individual, and shall be decided.
Mode of FL (LCD) all on. With a set, correspondence and the contents of correspondence shall be
individual, and shall be decided.
Mode of relation of FRONT END.
4.2.2 SET OPERATE
TEST mode performs correspondence by operation specially so that a user cannot enter.
* TEST MODE start should be press PLAY key & POWER key of main unit together and keep condition, connect AC.
* After set up TEST MODE, mode select by MENU key.
The changes to the key in TEST mode are shown in Fig. 1.
Fig.1 Change to TEST MODE and key
PLAY+POWER+AC
The destination, a region,
study state indication mode
PAUSE key
NORMAL
initialize
STOP key
4sec. pressPLAY key
FULL
initialize
MENU keyMENU key
MENU key
Device key check sum
indication mode
Device key
writing
MENU keyMENU keyMENU key
Micon version
indication mode
FL all on
mode
FRONT END
check mode
(*1) : Shift from destination, region and study state indication mode to NORMAL initialize, FULL initialize and device
writing mode should only can main unit key.
1-20 (No.MB530)
Page 21
4.2.3 PROCESS
Below, FL (LCD) display to operation and communication with a DVD back end micon are shown.
* Since the number of beams changes with sets about FL (LCD) display, also set differing from the contents of specification to O.K.
* Since there are arrangement and a relation of existence with a set also about a key, also set differing from the contents of specification to O.K.
STEPOPERATIONMOVEMENT
Release AC, press PLAY & POWER key
1
together of main unit.
Keep STEP 1, connect AC.
2
Press PAUSE key of main unit.
1
NORMAL initialize
Long press(4sec) STOP key of main unit.
2
FULL initialize
Press MENU key of remocon.
3
Press MENU key of remocon.Micon version indication mode.
4
Press MENU key of remocon.FL all on mode.
5
Press MENU key of remocon.FRONT END check mode.
6
Press 1 at 10 key of remocon.Disc startup and through playback
1
Press 2 at 10 key of remocon.Existence of WOBBLE.
2
Press 3 at 10 key of remocon.Port check mode
3
Press 4 at 10 key of remocon.CD_LD on & Laser current indication.
4
5
Press 5 at 10 key of remocon.DVD_LD on & Laser current indication.
6
Press 6 at 10 key of remocon.DVD_SL x 1 jitter measurement mode.
The destination, a region, study state
indication mode.
Indication the destination by TEST mode
power on.
Device key check sum indication mode.
Indication check sum of device key for FL.
(4byte)
*1 Mode toggle by press MENU key.
*2 STEP2-3 and STEP3 are only for DVD-AUDIO or VR correspondence model.
4.3Key special mode
Mode nameOperationFunction
Tuner 9k/10k select
(U*version)
TRAY LOCK
DVD TEST MODE
SYSTEM TEST MODE
AVC ROM-CORE MODE
Press STOP key & PLAY key together
at TUNER AM then 9kHz step.
Press STOP key & PAUSE key together
at TUNER AM then 10kHz step.
Press STOP key & EJECT1 key together
at P.OFF.
At AC off line condition, press
PLAY+POWER together and keep
condition, connect AC.
At AC off line condition, press
PAUSE+POWER key together and keep
condition, connect AC.
At AC off line condition, press
STOP+PAUSE key together and keep
condition, connect AC.
FL (LCD) indication
13121110123456789
CH E C K
9kHz/10kHz step select of TUNER AM band.
DO the TRAY LOCK mode select. Temporaly P.ON operation, select
"LOCKED", "UNLOCKED". (Not done P.ON operation).
Transience (2sec.) indication end, and then return to P.OFF mode.
When press the EJECT key at LOCK mode, at P.OFF condition
tempraly P.ON operation and then transience (2sec.) indication
"LOCKED".
At P.ON condition, transience (2sec.) indication "LOCKED".
"Operation to TEST mode to on of DVD backend.
Operation of internal TEST MODE is refer the TEST mode."
"Set to speaker measurement mode.At source AM, operation the
beat cut by remote controller.Other operation is as same as normal
condition.
Mode release by POWER OFF."
Into the AV compulink rom-core rewrite mode.
4.4Remocon special mode
Mode nameCODEFunction
B330COLD START
B331FL all on
Preset frequency writeing
B33E
1-22 (No.MB530)
Operation
2-times input at P.OFF.
Input at P.ON.
Input at P.ON.Version indication
"Fix by 2 time input, operation temporaly P.ON and then transience(3sec.)
indication "COLD SET".
Indication end, done the P.OFF mode.
AC to off line, operation the COLD START.B330 : remote controller press
POWER + STOP + 0 key together."
"Rewrite preset frequency, LED on chek(each 300ms), FL all onLED on turn
: STANDBY - ILLUMI - REMOCON<VOL+> - <VOL->Volume control of key
input, keep high-speed mode until POWER OFF.
B331 : Remocon POWER + STOP + 1 key together"
"Indication turn Syscon version - Unit version - Distination, Chip select by
transience(5 sec.).
Syscon version : "SC ## $$" (## : Sys version,$ : Sys ROM-core)
Unit version : "BE %%%% "(%%%% : Unit version)
Distination, Chip select : "$$ %%"($$ : sys distination, %% :
"P3" or "P5" or "P7")
B33E : Press remocon POWER + STOP + 10 key together."
Page 23
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
(No.MB530)1-23
Page 24
Victor Company of Japan, Limited
Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(No.MB530)
Printed in Japan
VPT
Page 25
PARTS LIST
TH-P7B,TH-P7E,TH-P7EN
TH-P7EV,TH-P7EE
* All printed circuit boards and its assemblies are not available as service parts.
No.MB530
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Speaker assembly and parts list(Subwoofer) (Block No.M2)
DVD mechanism assembly and parts list (Block No.MJ)
DVD loading base assembly and parts list (Block No.MN)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)
(TH-P7B,TH-P7E,TH-P7EN,TH-P7EV)
Packing materials and accessories parts list (Block No.M4) (TH-P7EE)
3- 2
3- 5
3- 6
3- 8
3-10
3-18
3-20
3-1
Page 26
Exploded view of general assembly and parts list
39
39
Block No.
M
M
1
M
40
39
39
39
23
56
38
5
48
24
10
FL board
53
e
26
10
USB Jack board
5
59
14
54
h
57
g
f
55
52
24
A
51
41
40
42
10
Key board
1
8
49
c
b
48
9
3-2
37
5
2
4
d
3
C
37
2
37
7
6
15
Headphone board
13
13
13
Page 27
M
20
9
54
14
board
23
k
23
B
30
58
n
45
35
35
29
32
h
34
52
Video board
25
g
22
f
e
c
57
g
f
55
21
22
n
d
22
15
h
b
22
19
47
17
B
k
Main board
50
46
17
32
31
28
43
m
Power supply board
17
m
36
33
33
44
15
13
13
27
27
13
12
17
16
47
12
11
C
A
18
3-3
Page 28
General Assembly
Block No. [M][1][M][M]
Symbol No.Part No.Part NameDescriptionLocal
1LV11230-006AFRONT PANEL
2GV40313-002AFELT SPACER(x2)
3LV11231-008AFRONT LENS
4LV44574-001AFL SCREEN
5QYSDSF2608ZATAP SCREWM2.6 x 8mm(x3)
6QYSDSF2608ZATAP SCREWM2.6 x 8mm
7LV30225-011ASPACER
8LV22266-001ABUTTON
9LV44516-001ASTANDBY LENS
10QYSDSF2608ZATAP SCREWM2.6 x 8mm(x3)
11LV11232-001ACHASSIS BASE
12GV40313-002AFELT SPACER(x2)
13QYSDSG3006ZATAP SCREWM3 x 6mm(x4)
14QYSDSG3006ZATAP SCREWM3 x 6mm
15LV30225-011ASPACER(x2)
16LV36990-001ABARRIER
17QYSDSG3006ZATAP SCREWM3 x 6mm(x5)
18LV44573-001AFASTENER
19QYSBSG3010ZATAP SCREWM3 x 10mm(x3)
20LV36680-002AHEAT SINK
21LV30226-048ASPACER(x3)P7B,P7E
22QYSBSGY3008EATAP SCREWM3 x 8mm(x4)
23QYSDSG3006ZATAP SCREWM3 x 6mm(x2)
24LV30225-011ASPACER(x2)
25LV30225-011ASPACER
26LV30227-048ASPACER
27QYSDSF3008ZATAP SCREWM3 x 8mm(x2)
28LV22267-007AREAR PANEL
29QZW0033-001STRAIN RELIEF
30QMPN160-200-JDPOWER CORD(EU)2m BLACKP7B
30QMPK200-200-JDPOWER CORD(EU)2m BLACKP7E,P7EN,P7EV,P7EE
31QYSBSGY3008EATAP SCREWM3 x 8mm
32QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
33QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
34QAU0413-001TUNER
35QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
36QYSBSGY3008EATAP SCREWM3 x 8mm
37QYSDSG3006ZATAP SCREWM3 x 6mm(x3)
38LV22268-001A/S/METAL COVER
39QYSBSGY3008EATAP SCREWM3 x 8mm(x5)
40E406308-007SPECIAL SCREW(x2)
41LV36678-001ATRAY FITTING
42LV36679-001AFITTING LENS
1LV22234-001ATM.CHASSIS
2LV22235-001ASPINDLE BASE
3QYSDST2005ZATAP SCREWM2 x 5mm(x2)
4LV36555-001AG.S.HOLDER
5QYSDST2005ZATAP SCREWM2 x 5mm
6LV44041-002AGUIDE SHAFT
7LV44479-001ABAR SPRING
8LV22236-001AFEED HOLDER
9QAR0165-001FEED MOTOR
10LV30225-0X5ASPACER
11LV36557-001AF.M.GEAR
12QYSPSPT2030MASCREWM2 x 3mm
13QYSDST2005ZATAP SCREWM2 x 5mm
14QAL0786-002P.UP
15LV22237-001ARACK ARM
16LV36560-001ARACK ARM SPRING
17QYSPSFU1740ZATAP SCREWM1.7 x 4mm(x2)
18QUQK05-2415AC-EFFC WIRE24pin 15cm
20LV44041-002AGUIDE SHAFT
21LV36559-001AL.S.GEAR
22LV41517-003ALEAD SCREW
23LV36558-001AMIDDLE GEAR
24LV36556-001ASPRING HOLDER
25LV44623-001ACOMP.SPRING
26QYSDST2005ZATAP SCREWM2 x 5mm
27QYSDST2616MATAP SCREWM2.6 x 16mm
28QAR0386-001S.MOTOR
29QYSPSPU1775ZASCREWM1.7 x 7.5mm(x3)
30LV44042-001AROD SPRING(x2)
31LV44046-001AADJUST SCREW(x4)
Block No. [M][J][M][M]
3-7
Page 32
DVD loading base assembly and parts list
Grease
JVS-1003
JVG-450
< Back side >
20
19
18
16
h
FMU-MB1-21M
29
15
16
M
N
M
Block No.
M
2
3
28
12
h
14
28
DVD module board
27
17
m
11
j
n
1
9
10
0.10mm
4
7
8
6
7.75mm
Backside
5
27
j
26
B
A
k
c
13
DVD loading switch board
g
e
f
3-8
d
22
23
k
B
n
25
A
m
22
21
23
f
c
23
e
22
d
The parts without symbol number are not service.
Page 33
DVD loading base
Symbol No.Part No.Part NameDescriptionLocal
1LV11065-007ALOADER SUB ASSY
2E407140-001SSC.D ROLLER
3E407149-001SSRUBBER TUBE
4LV10979-002ATRAY
5LV35499-001ASHAFT GUIDE
6LV44022-001ASHAFT
7QYSSSF2008ZATAP SCREWM2 x 8mm
8QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
9LV41741-004ASPECIAL SCREW
10QAR0197-001MOTOR
11LV43844-002AMOTOR PULLEY
12QYSPSPU1730ZASCREWM1.7 x 3mm(x2)
13QYSDSF2008ZATAP SCREWM2 x 8mm
14LV43974-001ABELT
15LV21852-003ACLAMPER BASE
16QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
17LV35056-002ADVD CLAMPER
18LV42930-003AP.C.MAGNET
19LV43848-001AYOKE
20LE40906-002ASPECIAL SCREW
21-----------------SINGLE DVD TRAM
22LV44043-001AINSULATOR(x4)
23LV44044-001ASPECIAL SCREW(x4)
25LV22269-003AMECHA HOLDER
26QYSBSF2608ZATAP SCREWM2.6 x 8mm
27LV44209-001AWASHER SCREW(x2)
28QYSBSF3008ZATAP SCREWM3 x 8mm(x2)
29LV44603-001ALASER CATION
C1002NCB31CK-224XC CAPACITOR0.22uF 16V K
C1003NCB31CK-104XC CAPACITOR0.1uF 16V K
C1004NCB31HK-103XC CAPACITOR0.01uF 50V K
C1005NCB31CK-104XC CAPACITOR0.1uF 16V K
C1006NCB31HK-103XC CAPACITOR0.01uF 50V K
C1007NCB31CK-104XC CAPACITOR0.1uF 16V K
C1008NCB31CK-104XC CAPACITOR0.1uF 16V K
C1009NCB31CK-104XC CAPACITOR0.1uF 16V K
C1010NCB31CK-104XC CAPACITOR0.1uF 16V K
C1011QETN1CM-107ZE CAPACITOR100uF 16V M
C1012NCB31CK-104XC CAPACITOR0.1uF 16V K
C1013QETN1HM-226ZE CAPACITOR22uF 50V M
C1014NCB31HK-104XC CAPACITOR0.1uF 50V K
C1015QETN1HM-226ZE CAPACITOR22uF 50V M
Part No.Part NameDescriptionLocal
Symbol No.
C1016NCB31HK-104XC CAPACITOR0.1uF 50V K
C1017NCB31HK-104XC CAPACITOR0.1uF 50V K
C1018NCB31HK-104XC CAPACITOR0.1uF 50V K
C1019QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1020QETM1HM-228E CAPACITOR2200uF 50V M
C1021NCB31HK-104XC CAPACITOR0.1uF 50V K
C1022QETN1CM-107ZE CAPACITOR100uF 16V M
C1023NCB31CK-105XC CAPACITOR1uF 16V K
C1024NCB31CK-104XC CAPACITOR0.1uF 16V K
C1028NCB31HK-104XC CAPACITOR0.1uF 50V K
C1029NCB31HK-104XC CAPACITOR0.1uF 50V K
C1030QETN1EM-476ZE CAPACITOR47uF 25V M
C1031NCB21CK-104XC CAPACITOR0.1uF 16V K
C1034NCB31CK-104XC CAPACITOR0.1uF 16V K
C1035NDC31HJ-150XC CAPACITOR15pF 50V J
C1037NCB31CK-104XC CAPACITOR0.1uF 16V K
C1040NCB31CK-104XC CAPACITOR0.1uF 16V K
C1041NCB31HK-104XC CAPACITOR0.1uF 50V K
C1101NCB31HK-104XC CAPACITOR0.1uF 50V K
C1102NCB31HK-333XC CAPACITOR0.033uF 50V K
C1103NCB31HK-681XC CAPACITOR680pF 50V K
C1104NCB31HK-681XC CAPACITOR680pF 50V K
C1105QETN1VM-477ZE CAPACITOR470uF 35V M
C1106QETN1VM-477ZE CAPACITOR470uF 35V M
C1107QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1108NCB31HK-472XC CAPACITOR4700pF 50V K
C1109NCB31HK-472XC CAPACITOR4700pF 50V K
C1110NCB31HK-472XC CAPACITOR4700pF 50V K
C1111NCB31HK-472XC CAPACITOR4700pF 50V K
C1112NCB31HK-473XC CAPACITOR0.047uF 50V K
C1113NCB31HK-473XC CAPACITOR0.047uF 50V K
C1114NCB31HK-271XC CAPACITOR270pF 50V K
C1115NCB31HK-271XC CAPACITOR270pF 50V K
C1116NCB31HK-223XC CAPACITOR0.022uF 50V K
C1117QFVF1HJ-224ZMF CAPACITOR0.22uF 50V J
C1118NDC31HJ-271XC CAPACITOR270pF 50V J
C1119NDC31HJ-560XC CAPACITOR56pF 50V J
C1120NCB31HK-152XC CAPACITOR1500pF 50V K
C1121QETN1CM-227ZE CAPACITOR220uF 16V M
C1123NCB31HK-104XC CAPACITOR0.1uF 50V K
C1124QETN1HM-106ZE CAPACITOR10uF 50V M
C1125NCB31HK-104XC CAPACITOR0.1uF 50V K
C1126NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1127NCB31HK-104XC CAPACITOR0.1uF 50V K
C1201NCB31HK-104XC CAPACITOR0.1uF 50V K
C1202NCB31HK-333XC CAPACITOR0.033uF 50V K
C1203NCB31HK-681XC CAPACITOR680pF 50V K
C1204NCB31HK-681XC CAPACITOR680pF 50V K
C1205QETN1VM-477ZE CAPACITOR470uF 35V M
C1206QETN1VM-477ZE CAPACITOR470uF 35V M
C1207QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1208NCB31HK-472XC CAPACITOR4700pF 50V K
C1209NCB31HK-472XC CAPACITOR4700pF 50V K
C1210NCB31HK-472XC CAPACITOR4700pF 50V K
C1211NCB31HK-472XC CAPACITOR4700pF 50V K
C1212NCB31HK-473XC CAPACITOR0.047uF 50V K
C1213NCB31HK-473XC CAPACITOR0.047uF 50V K
C1214NCB31HK-271XC CAPACITOR270pF 50V K
C1215NCB31HK-271XC CAPACITOR270pF 50V K
C1216NCB31HK-223XC CAPACITOR0.022uF 50V K
C1217QFVF1HJ-224ZMF CAPACITOR0.22uF 50V J
C1218NDC31HJ-271XC CAPACITOR270pF 50V J
C1219NDC31HJ-560XC CAPACITOR56pF 50V J
C1220NCB31HK-152XC CAPACITOR1500pF 50V K
C1221QETN1CM-227ZE CAPACITOR220uF 16V M
C1223NCB31HK-104XC CAPACITOR0.1uF 50V K
C1224QETN1HM-106ZE CAPACITOR10uF 50V M
C1225NCB31HK-104XC CAPACITOR0.1uF 50V K
C1226NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1227NCB31HK-104XC CAPACITOR0.1uF 50V K
C1301NCB31HK-104XC CAPACITOR0.1uF 50V K
C1302NCB31HK-104XC CAPACITOR0.1uF 50V K
C1303NCB31HK-333XC CAPACITOR0.033uF 50V K
C1304NCB31HK-333XC CAPACITOR0.033uF 50V K
C1305NCB31HK-681XC CAPACITOR680pF 50V K
C1306NCB31HK-681XC CAPACITOR680pF 50V K
Part No.Part NameDescriptionLocal
3-10
Page 35
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C1307NCB31HK-681XC CAPACITOR680pF 50V K
C1308NCB31HK-681XC CAPACITOR680pF 50V K
C1309QFVM2AJ-474ZMF CAPACITOR0.47uF 100V J
C1310NCB31HK-104XC CAPACITOR0.1uF 50V K
C1311NCB31HK-104XC CAPACITOR0.1uF 50V K
C1312NCB31HK-472XC CAPACITOR4700pF 50V K
C1313NCB31HK-472XC CAPACITOR4700pF 50V K
C1314NCB31HK-472XC CAPACITOR4700pF 50V K
C1315NCB31HK-472XC CAPACITOR4700pF 50V K
C1316NCB31HK-473XC CAPACITOR0.047uF 50V K
C1317NCB31HK-473XC CAPACITOR0.047uF 50V K
C1318NCB31HK-561XC CAPACITOR560pF 50V K
C1319NCB31HK-561XC CAPACITOR560pF 50V K
C1320NCB31HK-271XC CAPACITOR270pF 50V K
C1321NCB31HK-271XC CAPACITOR270pF 50V K
C1323NCB31HK-104XC CAPACITOR0.1uF 50V K
C1324QETN1HM-106ZE CAPACITOR10uF 50V M
C1325NCB31HK-104XC CAPACITOR0.1uF 50V K
C1326NCB31HK-104XC CAPACITOR0.1uF 50V K
C1327NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1328NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1401NCB31HK-104XC CAPACITOR0.1uF 50V K
C1402NCB31HK-333XC CAPACITOR0.033uF 50V K
C1403NCB31HK-681XC CAPACITOR680pF 50V K
C1404NCB31HK-681XC CAPACITOR680pF 50V K
C1405QETN1VM-477ZE CAPACITOR470uF 35V M
C1406QETN1VM-477ZE CAPACITOR470uF 35V M
C1407QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1408NCB31HK-472XC CAPACITOR4700pF 50V K
C1409NCB31HK-472XC CAPACITOR4700pF 50V K
C1410NCB31HK-472XC CAPACITOR4700pF 50V K
C1411NCB31HK-472XC CAPACITOR4700pF 50V K
C1412NCB31HK-473XC CAPACITOR0.047uF 50V K
C1413NCB31HK-473XC CAPACITOR0.047uF 50V K
C1414NCB31HK-271XC CAPACITOR270pF 50V K
C1415NCB31HK-271XC CAPACITOR270pF 50V K
C1416NCB31HK-223XC CAPACITOR0.022uF 50V K
C1423NCB31HK-104XC CAPACITOR0.1uF 50V K
C1424QETN1HM-106ZE CAPACITOR10uF 50V M
C1425NCB31HK-104XC CAPACITOR0.1uF 50V K
C1426NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1427NCB31HK-104XC CAPACITOR0.1uF 50V K
C1501NCB31HK-104XC CAPACITOR0.1uF 50V K
C1502NCB31HK-333XC CAPACITOR0.033uF 50V K
C1503NCB31HK-681XC CAPACITOR680pF 50V K
C1504NCB31HK-681XC CAPACITOR680pF 50V K
C1505QETN1VM-477ZE CAPACITOR470uF 35V M
C1506QETN1VM-477ZE CAPACITOR470uF 35V M
C1507QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1508NCB31HK-472XC CAPACITOR4700pF 50V K
C1509NCB31HK-472XC CAPACITOR4700pF 50V K
C1510NCB31HK-472XC CAPACITOR4700pF 50V K
C1511NCB31HK-472XC CAPACITOR4700pF 50V K
C1512NCB31HK-473XC CAPACITOR0.047uF 50V K
C1513NCB31HK-473XC CAPACITOR0.047uF 50V K
C1514NCB31HK-271XC CAPACITOR270pF 50V K
C1515NCB31HK-271XC CAPACITOR270pF 50V K
C1516NCB31HK-223XC CAPACITOR0.022uF 50V K
C1523NCB31HK-104XC CAPACITOR0.1uF 50V K
C1524QETN1HM-106ZE CAPACITOR10uF 50V M
C1525NCB31HK-104XC CAPACITOR0.1uF 50V K
C1526NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1527NCB31HK-104XC CAPACITOR0.1uF 50V K
C1601NCB31HK-104XC CAPACITOR0.1uF 50V K
C1602NCB31HK-104XC CAPACITOR0.1uF 50V K
C1603NCB31HK-333XC CAPACITOR0.033uF 50V K
C1604NCB31HK-333XC CAPACITOR0.033uF 50V K
C1605NCB31HK-681XC CAPACITOR680pF 50V K
C1606NCB31HK-681XC CAPACITOR680pF 50V K
C1607NCB31HK-681XC CAPACITOR680pF 50V K
C1608NCB31HK-681XC CAPACITOR680pF 50V K
C1609QFVM2AJ-474ZMF CAPACITOR0.47uF 100V J
C1610NCB31HK-104XC CAPACITOR0.1uF 50V K
C1611NCB31HK-104XC CAPACITOR0.1uF 50V K
C1612NCB31HK-472XC CAPACITOR4700pF 50V K
C1613NCB31HK-472XC CAPACITOR4700pF 50V K
C1614NCB31HK-472XC CAPACITOR4700pF 50V K
C1615NCB31HK-472XC CAPACITOR4700pF 50V K
C1616NCB31HK-473XC CAPACITOR0.047uF 50V K
C1617NCB31HK-473XC CAPACITOR0.047uF 50V K
C1618NCB31HK-561XC CAPACITOR560pF 50V K
C1619NCB31HK-561XC CAPACITOR560pF 50V K
C1620NCB31HK-271XC CAPACITOR270pF 50V K
C1621NCB31HK-271XC CAPACITOR270pF 50V K
C1623NCB31HK-104XC CAPACITOR0.1uF 50V K
C1624QETN1HM-106ZE CAPACITOR10uF 50V M
C1625NCB31HK-104XC CAPACITOR0.1uF 50V K
C1626NCB31HK-104XC CAPACITOR0.1uF 50V K
C1627NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1628NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1701QETN1EM-107ZE CAPACITOR100uF 25V M
C1702NCB31HK-102XC CAPACITOR1000pF 50V K
C1703QETN1EM-107ZE CAPACITOR100uF 25V M
C1704NCB31HK-104XC CAPACITOR0.1uF 50V K
C1705NCB31HK-104XC CAPACITOR0.1uF 50V K
C4002NCF21CZ-105XC CAPACITOR1uF 16V Z
C4003NCF21CZ-105XC CAPACITOR1uF 16V Z
C4014NCB31HK-102XC CAPACITOR1000pF 50V K
C4015NCB31HK-102XC CAPACITOR1000pF 50V K
C4016NCB31HK-102XC CAPACITOR1000pF 50V K
C4017NDC31HJ-151XC CAPACITOR150pF 50V J
C4091QETN1HM-226ZE CAPACITOR22uF 50V M
C4092NCB31HK-103XC CAPACITOR0.01uF 50V K
C4093NCB31HK-103XC CAPACITOR0.01uF 50V K
C4601QETN1HM-226ZE CAPACITOR22uF 50V M
C4602NCB31CK-104XC CAPACITOR0.1uF 16V K
C4603NCF21CZ-474XC CAPACITOR0.47uF 16V Z
C4604QETN1HM-226ZE CAPACITOR22uF 50V M
C4605NCB31CK-104XC CAPACITOR0.1uF 16V K
C4606NCB31CK-104XC CAPACITOR0.1uF 16V K
C4607NDC31HJ-471XC CAPACITOR470pF 50V J
C4608NDC31HJ-471XC CAPACITOR470pF 50V J
C4609QETN1HM-106ZE CAPACITOR10uF 50V M
C4610QETN1HM-106ZE CAPACITOR10uF 50V M
C4705NCB31HK-103XC CAPACITOR0.01uF 50V K
C4706NCB31HK-103XC CAPACITOR0.01uF 50V K
C4707QETN1CM-107ZE CAPACITOR100uF 16V M
C4708NCB31HK-103XC CAPACITOR0.01uF 50V K
C4709NCB31HK-103XC CAPACITOR0.01uF 50V K
C4710NCB31HK-103XC CAPACITOR0.01uF 50V K
C4711QETN1HM-106ZE CAPACITOR10uF 50V M
C4771NCB31CK-104XC CAPACITOR0.1uF 16V K
C4772NCB31CK-104XC CAPACITOR0.1uF 16V K
C4773NCB31CK-104XC CAPACITOR0.1uF 16V K
C4774NCB31CK-104XC CAPACITOR0.1uF 16V K
C4775NCB31HK-103XC CAPACITOR0.01uF 50V K
C4776NCB31HK-103XC CAPACITOR0.01uF 50V K
C4791NCB31CK-104XC CAPACITOR0.1uF 16V K
C4793NCB31CK-104XC CAPACITOR0.1uF 16V K
C4794QETN1CM-107ZE CAPACITOR100uF 16V M
C4795NCB31CK-104XC CAPACITOR0.1uF 16V K
C4901QETN1CM-107ZE CAPACITOR100uF 16V M
C4902NCB31HK-103XC CAPACITOR0.01uF 50V K
C4903QETN1CM-107ZE CAPACITOR100uF 16V M
C4904NCB31HK-103XC CAPACITOR0.01uF 50V K
C4921NCF21CZ-105XC CAPACITOR1uF 16V Z
C4922NDC31HJ-471XC CAPACITOR470pF 50V J
C4923NCB31AK-105XC CAPACITOR1uF 10V K
C4924QETN1CM-107ZE CAPACITOR100uF 16V M
C4925NCB31HK-104XC CAPACITOR0.1uF 50V K
C8001NCB31HK-182XC CAPACITOR1800pF 50V K
C8002NCB31HK-182XC CAPACITOR1800pF 50V K
C8003NDC31HJ-150XC CAPACITOR15pF 50V J
C8004NDC31HJ-150XC CAPACITOR15pF 50V J
Q6481KRC102S-XDIGI TRANSISTOR
Q6482KRC102S-XDIGI TRANSISTOR
Q6483KRA102S-XDIGI TRANSISTOR
Q6484KRC102S-XDIGI TRANSISTOR
Q6501KRC104S-XTRANSISTOR
Q6502KRC104S-XTRANSISTOR
Q90012SJ632-XPOWER MOS FET
Q9002KTA1504/YG/-XTRANSISTOR
Q9003KTC3875/YG/-XTRANSISTOR
Q9004KRA102S-XDIGI TRANSISTOR
Q90112SJ609POWER MOS FET
Q9013KTC3875/YG/-XTRANSISTOR
Q9031KRC102S-XDIGI TRANSISTOR
Q9032KRC102S-XDIGI TRANSISTOR
Q9034KRC102S-XDIGI TRANSISTOR
Q9036KTC3265/Y/-XTRANSISTOR
Q9037KTA1504/YG/-XTRANSISTOR
Q9038KRC104S-XTRANSISTOR
Q90392SJ651POWER MOS FET
Q9041RTQ035P02-WMOS FET
C506NCB31CK-105XC CAPACITOR1uF 16V K
C507NCB31HK-103XC CAPACITOR0.01uF 50V K
C511NCB31CK-105XC CAPACITOR1uF 16V K
C515NCB31HK-103XC CAPACITOR0.01uF 50V K
C901QFZ9073-154MM CAPACITOR0.15uF AC250V M
C902QCZ9079-102C CAPACITOR1000pF AC250V M
C903QCZ9079-102C CAPACITOR1000pF AC250V M
C904QFZ9073-154MM CAPACITOR0.15uF AC250V M
C905QEZ0792-227E CAPACITOR220uF
C906QCZ0136-332ZC CAPACITOR3300pF 1kV K
C907QCZ0340-102C CAPACITOR1000pF 2kV K
C909QEZ0657-226ZE CAPACITOR22uF
C910NCB31HK-471XC CAPACITOR470pF 50V K
C911QETN1HM-105ZE CAPACITOR1uF 50V M
C912NCB31HK-104XC CAPACITOR0.1uF 50V K
C913NCB31HK-332XC CAPACITOR3300pF 50V K
C914NDC31HJ-101XC CAPACITOR100pF 50V J
C921QCZ9079-102C CAPACITOR1000pF AC250V M
C5901NCB31HK-103XC CAPACITOR0.01uF 50V K
C5902NCB31HK-103XC CAPACITOR0.01uF 50V K
C5903NCB31CK-224XC CAPACITOR0.22uF 16V K
C5904NCB31HK-103XC CAPACITOR0.01uF 50V K
C5905NCB31HK-103XC CAPACITOR0.01uF 50V K
C5906NCB31HK-103XC CAPACITOR0.01uF 50V K
C5907NCB31CK-224XC CAPACITOR0.22uF 16V K
C6001QETN1AM-477ZE CAPACITOR470uF 10V M
C6002NCB31CK-104XC CAPACITOR0.1uF 16V K
C6003QETN1HM-226ZE CAPACITOR22uF 50V M
C6004NCB31CK-104XC CAPACITOR0.1uF 16V K
C6301NCB30JK-105XC CAPACITOR1uF 6.3V K
C6311NCB30JK-105XC CAPACITOR1uF 6.3V K
C6321NCB31HK-103XC CAPACITOR0.01uF 50V K
C6331NCB30JK-105XC CAPACITOR1uF 6.3V K
C6341NCB30JK-105XC CAPACITOR1uF 6.3V K
C6351NCB30JK-105XC CAPACITOR1uF 6.3V K
C6401QETN1AM-477ZE CAPACITOR470uF 10V M
C6424NDC31HJ-470XC CAPACITOR47pF 50V J
C6431QETN1AM-477ZE CAPACITOR470uF 10V M
C6432NDC31HJ-470XC CAPACITOR47pF 50V J
C6433NDC31HJ-470XC CAPACITOR47pF 50V J
C6441QETN1AM-477ZE CAPACITOR470uF 10V M
C6442NDC31HJ-470XC CAPACITOR47pF 50V J
C6443NDC31HJ-470XC CAPACITOR47pF 50V J
C6451QETN1AM-477ZE CAPACITOR470uF 10V M
C6452NDC31HJ-470XC CAPACITOR47pF 50V J
C6453NDC31HJ-470XC CAPACITOR47pF 50V J
C6473NCB31HK-331XC CAPACITOR330pF 50V K
C6474NCB31HK-331XC CAPACITOR330pF 50V K
C6475QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6476QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6491NCB31HK-103XC CAPACITOR0.01uF 50V K
C6501NCB31CK-104XC CAPACITOR0.1uF 16V K
C6502QETN1EM-476ZE CAPACITOR47uF 25V M
C6503QETN1EM-476ZE CAPACITOR47uF 25V M
C6504NCB31CK-104XC CAPACITOR0.1uF 16V K
C6551QETN1CM-107ZE CAPACITOR100uF 16V M
C6601QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6602QETN1HM-226ZE CAPACITOR22uF 50V M
C6603NDC31HK-101XC CAPACITOR100pF 50V K
C6604QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6605NCB31HK-102XC CAPACITOR1000pF 50V K
C6651NCB31HK-822XC CAPACITOR8200pF 50V K
C6652NCB30JK-105XC CAPACITOR1uF 6.3V K
C6701QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6702QETN1HM-226ZE CAPACITOR22uF 50V M
C6703NDC31HK-101XC CAPACITOR100pF 50V K
C6704QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6705NCB31HK-102XC CAPACITOR1000pF 50V K
C6751NCB31HK-822XC CAPACITOR8200pF 50V K
C6752NCB30JK-105XC CAPACITOR1uF 6.3V K
C9001QCZ0136-332ZC CAPACITOR3300pF 1kV K
C9002QEZ0779-827E CAPACITOR820uF
C9003QEZ0779-827E CAPACITOR820uF
C9004NDC31HJ-101XC CAPACITOR100pF 50V J
C9005QEZ0655-826ZE CAPACITOR82uF
C9006QCZ0136-101ZC CAPACITOR100pF 1kV K
C9007QEZ0657-396ZE CAPACITOR39uF
C9008NCB31HK-223XC CAPACITOR0.022uF 50V K
C9009NCB31HK-103XC CAPACITOR0.01uF 50V K
C9010QETN1HM-226ZE CAPACITOR22uF 50V M
C9012QETN1CM-107ZE CAPACITOR100uF 16V M
C9013NCB31HK-222XC CAPACITOR2200pF 50V K
C9014QEZ0655-107ZE CAPACITOR100uF
C9015NCB31HK-472XC CAPACITOR4700pF 50V K
C9017QEZ0655-337ZE CAPACITOR330uF
C9018NCB31HK-222XC CAPACITOR2200pF 50V K
C9019QETN1CM-107ZE CAPACITOR100uF 16V M
C9021NCB31HK-103XC CAPACITOR0.01uF 50V K
C9022NCB31HK-222XC CAPACITOR2200pF 50V K
C9023QEZ0701-827E CAPACITOR820uF 16V M
C9024QEZ0655-107ZE CAPACITOR100uF
C9025NCB31HK-222XC CAPACITOR2200pF 50V K
C9031QETN1HM-107ZE CAPACITOR100uF 50V M
C9036QEZ0654-108ZE CAPACITOR1000uF
C9037NCB31HK-103XC CAPACITOR0.01uF 50V K
C9038NCB31HK-103XC CAPACITOR0.01uF 50V K
C9039NCB31HK-104XC CAPACITOR0.1uF 50V K
C9071NCB31HK-333XC CAPACITOR0.033uF 50V K
C9072QFVF1HJ-154ZMF CAPACITOR0.15uF 50V J
C9073QETN1HM-106ZE CAPACITOR10uF 50V M
C9082QETN1CM-107ZE CAPACITOR100uF 16V M
C9084NCB31CK-104XC CAPACITOR0.1uF 16V K
L902QQR1723-001LINE FILTER
L6001QQL25CK-221ZCOIL220uH K
L9001QQL81AK-331ZCOIL330uH K
L9002QQL83AK-101ZCOIL100uH K
L9003QQL82AK-101COIL100uH K
L9004QQL244K-100ZCOIL10uH K
L9005QQL26AK-100ZCOIL10uH K
C101NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C102NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C103NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C104NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C105NEAF0JM-476XE CAPACITOR47uF 6.3V M
C106NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C107NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C108NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C201NDC31HJ-221XC CAPACITOR220pF 50V J
C202NDC31HJ-221XC CAPACITOR220pF 50V J
C203NCB31HK-103XC CAPACITOR0.01uF 50V K
C204NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C205NCB31HK-271XC CAPACITOR270pF 50V K
C206NDC31HJ-151XC CAPACITOR150pF 50V J
C210NCF31AZ-105XC CAPACITOR1uF 10V Z
C211NCB31HK-223XC CAPACITOR0.022uF 50V K
C217NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C251NCB31AK-474XC CAPACITOR0.47uF 10V K
C256NCB31CK-104XC CAPACITOR0.1uF 16V K
C257NCB31HK-822XC CAPACITOR8200pF 50V K
C258NCB31CK-153XC CAPACITOR0.015uF 16V K
C259NCB31CK-153XC CAPACITOR0.015uF 16V K
C260NCB31HK-223XC CAPACITOR0.022uF 50V K
C261NCB31HK-223XC CAPACITOR0.022uF 50V K
C262NCB31HK-223XC CAPACITOR0.022uF 50V K
C263NEAF1CM-107XE CAPACITOR100uF 16V M
C301NEAF0GM-227XE CAPACITOR220uF 4V M
C302NEAF0GM-476XE CAPACITOR47uF 4V M
C303NEAF0GM-476XE CAPACITOR47uF 4V M
C304NCB30JK-105XC CAPACITOR1uF 6.3V K
C305NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C306NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C307NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C308NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C309NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C310NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C311NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C312NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C314NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C316NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C317NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C318NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C319NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C320NCB31CK-104XC CAPACITOR0.1uF 16V K
C321NCB31CK-104XC CAPACITOR0.1uF 16V K
C322NCB31CK-104XC CAPACITOR0.1uF 16V K
C323NCB31CK-104XC CAPACITOR0.1uF 16V K
C324NCB30JK-105XC CAPACITOR1uF 6.3V K
C325NDC31HJ-120XC CAPACITOR12pF 50V J
Part No.Part NameDescriptionLocal
Symbol No.
C326NDC31HJ-120XC CAPACITOR12pF 50V J
C327NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C328NCB31HK-103XC CAPACITOR0.01uF 50V K
C330NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C331NCB31CK-333XC CAPACITOR0.033uF 16V K
C332NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C333NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C334NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C335NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C337NCB31CK-183XC CAPACITOR0.018uF 16V K
C338NCB31HK-562XC CAPACITOR5600pF 50V K
C339NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C340NCB30JK-105XC CAPACITOR1uF 6.3V K
C341NCB30JK-105XC CAPACITOR1uF 6.3V K
C345NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C347NCB31CK-104XC CAPACITOR0.1uF 16V K
C348NCB31CK-104XC CAPACITOR0.1uF 16V K
C349NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C350NCB31HK-103XC CAPACITOR0.01uF 50V K
C351NCB31HK-103XC CAPACITOR0.01uF 50V K
C352NCB31CK-153XC CAPACITOR0.015uF 16V K
C353NCB31HK-561XC CAPACITOR560pF 50V K
C354NCB31HK-561XC CAPACITOR560pF 50V K
C356NCB30JK-105XC CAPACITOR1uF 6.3V K
C359NCB30JK-105XC CAPACITOR1uF 6.3V K
C370NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C371NCF31AZ-105XC CAPACITOR1uF 10V Z
C372NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C373NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C374NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C375NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C378NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C379NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C380NCB21CK-105XC CAPACITOR1uF 16V K
C381NCB21AK-225XC CAPACITOR2.2uF 10V K
C382NCB31HK-471XC CAPACITOR470pF 50V K
C383NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C393NCB31HK-103XC CAPACITOR0.01uF 50V K
C455NCB31HK-103XC CAPACITOR0.01uF 50V K
C551NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C554NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C555NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C557NCB31HK-102XC CAPACITOR1000pF 50V K
C558NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C559NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C560NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C562NCF31AZ-105XC CAPACITOR1uF 10V Z
C563NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C564NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C721NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C801NCB21CK-105XC CAPACITOR1uF 16V K
C802NCB21AK-225XC CAPACITOR2.2uF 10V K
C803NEAF0JM-227XE CAPACITOR220uF 6.3V M
C804NCB31HK-471XC CAPACITOR470pF 50V K
C811NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C812NCF31EZ-104XC CAPACITOR0.1uF 25V Z
No additional / supplemental order of WARRANTY CARDs are available.
P6
A1,A2,A3, A4,
A5,A6, A8
Only B ver.
Block No.
M
3
M
M
P9
A9
P24
P2
1/2
P4
P1
P10
1/2
P5
P3
P2
2/2
2/2
P3
A7
E,EN,EV ver.
P17
A14
P13
A16,A17,
A18,A19,
A20,A21
P7
P17
A14
P14
P15
P14
A13
P23
P18
P15
A12
P15
A13
P14
P19
3-18
P8
P11
P12
P21
A22
P21
A23
P22
P16
A11
A15
A24
P15
P14
A13
P14
P15
A10
P15
A13
P14
P20
Page 43
Packing and Accessories (TH-P7B,TH-P7E,TH-P7EN,TH-P7EV)
Symbol No.Part No.Part NameDescriptionLocal
A 1LVT1523-001BINST BOOKENGP7B
A 1LVT1523-002BINST BOOKGER FREP7E
A 1LVT1523-004AINST BOOKSPA PORP7EN
A 1LVT1523-006AINST BOOKCZE POL HUNP7EV
A 2LVT1523-003CINST BOOKDUT ITAP7E
A 2LVT1523-005AINST BOOKSWE FIN DANP7EN
A 3---------------WARRANTY CARDBT-54028-1
A 4QAL0457-001ANT.WIRE
A 5QAL0476-002AM LOOP ANT
A 6RM-STHP7RREMOCON UNIT
A 7---------------BATTERY1.5V(x2)
A 8VNA3000-204REGIST CARDP7B
A 9QAS0412-003SPEAKER BOXSPK WITH BOX-WO
A 10AB050051-01SPEAKER BOXSPK WITH BOX-F(x2)
A 11AB066004-01SPEAKER BOXSPK WITH BOX-C
A 12AB050052-01SPEAKER BOXSPK WITH BOX-S(x2)
A 139906600501STAND ASSY(x4)
A 149900035301BASE ASSY(x4)
A 159000008411FOOT(x3)
A 166200047501SPEAKER CORD-WO
A 176200045941SPK CORD-SL
A 186200045931SPK CORD-SR
A 196200045921SPK CORD-FL
A 206200045911SPK CORD-FR
A 216200045901SPK CORD-C
A 227010954004SCREW(x4)
A 237010942006SCREW(x8)
A 246400018701CORD CLAMP(x4)
P 1LV36778-001ACARTON BOX
P 2LV22270-002ACUSHION(F)
P 3LV22271-001ACUSHION(R)
P 4LV36967-001ACARTON SPACER
P 5QPC06506515PPOLY BAG65cm x 65cm
P 6QPA02503503PPOLY BAG25cm x 35cm
P 7QPA01503503POLY BAG15cm x 35cmP7B
P 88500062261MIRROR SHEET
P 98500055721POLY BAG
P 10LV22320-001ATOP CUSHION
P 11LV22320-002ABOTTOM CUSHION
P 12LV35831-097APACKING CASE
P 138500032771POLY BAG
P 148500062251MIRROR SHEETFRONT SURROUND & STAND(x8)
P 158500061661POLY BAGFRONT SURROUND & STAND(x8)
P 168500061671POLY BAGCENTER
P 178500062401MIRROR BAGSTAND BASE ASSY(x4)
P 18LV11266-001ACUSHION A
P 19LV11266-002ACUSHION B
P 20LV11266-003ACUSHION C
P 218500047141POLY BAG(x2)
P 228500035721POLY BAG
P 23LV36862-001ACUSHION
P 248500060071NONWOVENS SHEET
Block No. [M][3][M][M]
3-19
Page 44
Packing materials and accessories parts list
(TH-P7EE)
No additional / supplemental order of WARRANTY CARDs are available.
P6
A1,A3,A4,
A5,A6,
P4
P3
1/2
P2
2/2
A7
P17
A14
P3
P13
A16,A17,
A18,A19,
A20,A21
1/2
P1
P5
2/2
P2
P17
A14
P14
P15
P14
A13
P23
Block No.
P15
M
P18
A12
A13
P14
4
P15
P19
M
M
P11
P9
P25
A9
P24
P8
P12
P10
P21
A22
P21
A23
P22
P16
A11
A15
A24
P15
P14
A13
P14
P15
A10
P15
A13
P14
P20
3-20
Page 45
Packing and Accessories (TH-P7EE)
Symbol No.Part No.Part NameDescriptionLocal
A 1LVT1523-007AINST BOOKRUS
A 3---------------WARRANTY CARDBT-54028-1
A 4QAL0457-001ANT.WIRE
A 5QAL0476-002AM LOOP ANT
A 6RM-STHP7RREMOCON UNIT
A 7---------------BATTERY1.5V(x2)
A 9QAS0412-003SPEAKER BOXSPK WITH BOX-WO
A 10AB050051-01SPEAKER BOXSPK WITH BOX-F(x2)
A 11AB066004-01SPEAKER BOXSPK WITH BOX-C
A 12AB050052-01SPEAKER BOXSPK WITH BOX-S(x2)
A 139906600501STAND ASSY(x4)
A 149900035301BASE ASSY(x4)
A 159000008411FOOT(x3)
A 166200047501SPEAKER CORD-WO
A 176200045941SPK CORD-SL
A 186200045931SPK CORD-SR
A 196200045921SPK CORD-FL
A 206200045911SPK CORD-FR
A 216200045901SPK CORD-C
A 227010954004SCREW(x4)
A 237010942006SCREW(x8)
A 246400018701CORD CLAMP(x4)
P 1LV36689-002ACARTON BOX
P 2LV22270-002ACUSHION(F)
P 3LV22271-001ACUSHION(R)
P 4LV36967-001ACARTON SPACER
P 5QPC06506515PPOLY BAG65cm x 65cm
P 6QPA02503503PPOLY BAG25cm x 35cm
P 88500062261MIRROR SHEET
P 98500055721POLY BAG
P 10LV22320-001ATOP CUSHION
P 11LV22320-002ABOTTOM CUSHION
P 12LV37013-001APACKING CASE
P 138500032771POLY BAG
P 148500062251MIRROR SHEETFRONT SURROUND & STAND(x8)
P 158500061661POLY BAGFRONT SURROUND & STAND(x8)
P 168500061671POLY BAGCENTER
P 178500062401MIRROR BAGSTAND BASE ASSY(x4)
P 18LV11266-001ACUSHION A
P 19LV11266-002ACUSHION B
P 20LV11266-003ACUSHION C
P 218500047141POLY BAG(x2)
P 228500035721POLY BAG
P 23LV36862-001ACUSHION
P 248500060071NONWOVENS SHEET
P 25LV37015-002APACKING SPACER
Block No. [M][4][M][M]
3-21
Page 46
SCHEMATIC DIAGRAMS
DVD DIGITAL CINEMA SYSTEM
TH-P7B,TH-P7E,TH-P7EN
TH-P7EV,TH-P7EE
CD-ROM No.SML200605
SP-THP7C
SP-TP7F
SP-THP7S
SP-WP7
XV-THP7
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
COPYRIGHT 2006 Victor Company of Japan, Limited.
2-1
2-2
2-11 to 12
No.MB530SCH
2006/5
Page 47
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
Audio sectionFront/Surround40 W per channel, RMS at 3 Ω at 1 kHz, with 10 % total harmonic
distortion.
Center100 W, RMS at 4 Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer100 W, RMS at 4 Ω at 30 Hz, with 10 % total harmonic distortion.
Video sectionVideo SystemPAL/NTSC
Horizontal Resolution500 lines
Signal-to-Noise Ratio64 dB
Video output level Composite1.0 V(p-p)/75 Ω
S-video-Y1.0 V(p-p)/75 Ω
S-video-CFor PAL : 0.3 V(p-p)/75 Ω
For NTSC : 0.286 V(p-p)/75 Ω
Component
(Interlace/Progressive)
USB storageUSB specificationCompatible with the USB 2.0 Full-Speed
Compatible deviceMass Storage Class
Compatible file systemFAT16, FAT32
Bus power supplyMax. 500 mA
Tuner sectionFM (Tuning Range)87.50 MHz to 108.00 MHz
AM (Tuning Range)At 10 kHz intervals
Speaker impedance Front/Surround3 Ω to 16 Ω
Center/Subwoofer4 Ω to 16 Ω
GeneralPower RequirementsAC 110 V - 240 V , 50/60 Hz
Power Consumption60 W (at operation)
Dimensions (W × H × D)435 mm × 70 mm × 308 mm
Mass3.0 kg
Y : 1.0 V(p-p)/75 Ω
PB/PR : 0.7 V(p-p)/75 Ω
530 kHz to 1 710 kHz (*1 600 kHz)
At 9 kHz intervals
531 kHz to 1 710 kHz (*1 602 kHz)
* For the countries of the Middle East
1.4 W (in standby mode)
Subwoofer (SP-WP7/SP-WP5)
TypeBass-Reflex Type
Speaker16 cm cone × 1
Power Handling Capacity100 W
Impedance4 Ω
Frequency Range35 Hz to 200 Hz
Sound Pressure Level75 dB/W
Dimensions (W × H × D)129 mm × 284 mm × 337 mm
Mass3.1 kg
1-2 (No.MB560)
·m
Page 64
Satellite speakers (For TH-P7)
Front speakers
(SP-THP7F)
Center speaker
(SP-THP7C)
Surround speakers
(SP-THP7S)
Type1-Way Bass-Reflex Type (Magnetically-shielded Type)
Speaker5.5 cm cone × 1
Power Handling Capacity40 W
Impedance3 Ω
Frequency Range100 Hz to 20 000 Hz
Sound Pressure Level74 dB/W
Dimensions (W × H × D)280 mm × 1106 mm × 280 mm
Mass3.1 kg each
Type1-Way 2-Speaker Bass-Reflex Type (Magnetically-shielded Type)
Speaker6.5 cm cone × 2
Power Handling Capacity100 W
Impedance4 Ω
Frequency Range90 Hz to 20 000 Hz
Sound Pressure Level82 dB/W
Dimensions (W × H × D)250 mm × 85 mm × 91 mm
Mass0.8 kg
Type1-Way Bass-Reflex Type
Speaker5.5 cm cone × 1
Power Handling Capacity40 W
Impedance3 Ω
Frequency Range100 Hz to 20 000 Hz
Sound Pressure Level73 dB/W
Dimensions (W × H × D)280 mm × 1106 mm × 280 mm
Mass3.1 kg each
·m
·m
·m
Designs & specifications are subject to change without notice.
(No.MB560)1-3
Page 65
SECTION 1
PRECAUTION
1.1Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purposes. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be performed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteristics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Service Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety characteristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassembling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isolation check on the exposed metal parts of the product (antenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particularly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ω per volt or more sensitivity
in the following manner. Connect a 1,500Ω 10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
0.15 F AC TYPE
Place this
probe on
1500 10W
Good earth ground
1.2Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of preforming repair of this system.
1.4Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
each exposed
metal part.
1-4 (No.MB560)
Page 66
1.5Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(caption)
Anti-static wrist strap
1M
Conductive material
(conductive sheet) or iron palate
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.7Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
• Apply solder to the short land sections before the card wire is disconnected from the connecto on the servo board. (If the card wire
is disconnected without applying solder, the pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.
Solder short
(No.MB560)1-5
Page 67
1.8Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABELS and PRINT
WARNING LABEL and PRINT
CLASS 1
LASER PRODUCT
1-6 (No.MB560)
CLASS 1
LASER PRODUCT
Page 68
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
CAUTION: Symbol C905(in power supply board) is noted not to touch because
the voltage collects in the capacitor.
EP902
C902
C904
CN901
FC901FC902
R901
C901
C922
L902
L901
EP901
D901
VA901
R906
C903
C905
TH901
R902
B9304
D903
R909
R908
B9305
IC901
C909
D904
C911
R912
B9101
C908
B9209
R905
T901
C916
C906
D902
C907
HS901
B9601
B9501
R910
D905
B901
D906
D907
B9109
R913
R911
C921
C9006
C9072
IC951
PC901
R9072
D9032
C9074
R9077
C9076
R9080
D9037
R9005
C9005
CP951
D9003
D9002
D9036
R9088
D9038
R9004
HS951
D9024
B9951
B9204
C9007
D9023
D9039
B9401
C9003
B9203
B9303
B9402
R9008
D9031
B9105
B9191
R9009
C9073
D9033
B9301
B9302
R9015
B9503
B9502
B9604
L9001
B9195
Q9039
L9004
FW901
C9010
C9016
B9196
R9001
B9701
D9009
C9011
D9007
C9012
C9019
C9014
D9004
B9207
D9021
R9082
R9081
D9022
B9193
D9001
C9001
B9107
D9081
B9194
CP952
D9034
D9035
C9002
B9504
B9404
B9307
B9602
B9310
B9403
D9010
D9005
C9023
D9011
C9017
D9012
C9024
FW903
B9205
C9082
B9103
R9034
D9015
D9014
D9041
B9208
Q9011
L9002
C9031
D9013
L9005
B9108
L9003
FW902
HS953
IC953
B9309
C9036
EP951
(No.MB560)1-7
Page 69
SECTION 3
DISASSEMBLY
3.1Main Body
3.1.1 Removing the metal cover
(See Fig.1, 2)
(1) Remove the two screws A attaching the metal cover of both
side. (See Fig.1)
(2) Remove the five screws B attaching the metal cover of rear
side. (See Fig.2)
A
Fig.1
B
Fig.2
1-8 (No.MB560)
Page 70
3.1.2 Removing the front panel assembly
(See Fig.3 to 5)
(1) Remove the three screws C attaching the front panel as-
sembly from bottom side. (See Fig.3)
(2) Remove the screw D attaching the earth wire to the power
supply board. (See Fig.4)
(3) Disconnect the parallel wires from the connectors CN101
CN422 and the card wire CN421 of the main board. (See
Fig.4)
(4) Release the one hook a of bottom side and two hooks b of
both side of the front panel assembly. (See Fig.3, 5)
C
,
a
Fig.3
D
CN421CN422
CN101
Fig.4
b
Fig.5
(No.MB560)1-9
Page 71
3.1.3 Removing the tuner
(See Fig.6, 7)
(1) Disconnect the card wire from the connector CN652
video board. (See Fig.6)
(2) Remove the two screws E attaching the tuner from the rear
panel. (See Fig.7)
of the
CN652
Fig.6
E
Fig.7
1-10 (No.MB560)
Page 72
3.1.4 Removing the DVD mechanism assembly
(See Fig.8 to 10)
(1) Disconnect the card wire from the connectors CN405
, CN412, CN413 of the main board. (See Fig.8)
CN411
(2) Disconnect the connector wire from the connector CN414
of the main board. (See Fig.8)
(3) Disconnect the connector wire from the connector CN811
(See Fig.9)
(4) Remove the two screws F attaching the DVD mechanism
assembly from the chassis base. (See Fig.10)
(5) Press the two hooks c and slide out the DVD mechanism
for direction the arrow. (See Fig.10)
,
CN405
.
Fig.8
CN412
CN411
CN413
CN414
F
CN811
Fig.9
c
Fig.10
(No.MB560)1-11
Page 73
3.1.5 Removing the USB jack board
(See Fig.11)
(1) Remove the one screw G attaching the USB jack board.
3.1.6 Removing the video board
(See Fig.12, 13)
(1) Disconnect the card wires from the connectors CN601
CN651 of the video board. (See Fig.12)
(2) Remove the two screws H attaching the video board. (See
Fig.12)
(3) Remove the three screws J attaching the video board from
rear panel. (See Fig.13)
3.1.7 Removing the main board
(See Fig.11, 13)
(1) Disconnect the parallel wires from the connectors CN401
CN403, CN404 of the main board. (See Fig.11)
(2) Disconnect the connector wire from the connector CN417
of the main board. (See Fig.11)
(3) Remove the four screws K attaching the main board. (See
Fig.11)
(4) Remove the two screws L attaching the main board from
the rear panel. (See Fig.13)
3.1.8 Removing the fan motor
(See Fig.13, 14)
(1) Remove the two screws M attaching the fan bracket. (See
Fig.14)
K
USB jack board
,
CN401
CN403
CN404
,
Main board
video board
CN417
KK
Fig.11
CN601CN651
G
1-12 (No.MB560)
M
H
L
Fig.12
J
P
Fig.13
fan motor
Fig.14
Page 74
3.1.9 Removing the power supply board
r
(See Fig.15)
Caution:
When remove the power supply board, do not touch the capacitor (C905
(1) Remove the four screws N attaching the power supply
(2) Disconnect the power cord from the connector CN901
(3) Release the power supply board from fastener.
3.1.10 Removing the rear panel
(1) Remove the one screw P attaching the rear panel. (See
(2) Release the two hooks d of both side. (See Fig.16)
) because it keep voltage.
board.
the power supply board.
(See Fig.13, 16)
Fig.13)
of
power supply board
N
N
fastene
CN901
P
Fig.15
3.1.11 Removing the key board
(See Fig.17)
Remove the three screws Q attaching the key board.
3.1.12 Removing the headphone board
(See Fig.17)
(1) Remove the one screw R attaching the headphone board.
3.1.13 Removing the FL board
(See Fig.18)
(1) Remove the three screws S attaching the FL board.
d
Headphone board
R
S
(both side)
Fig.16
Q
Key board
Fig.17
FL board
Fig.18
(No.MB560)1-13
Page 75
3.2DVD mechanism
3.2.1 Removing the traverse mechanism
(See Fig.1 to 7)
(1) Remove the two screws A attaching the tramecha holder
from top side of DVD mechanism assembly. (See Fig.1)
(2) Remove the two screws B attaching the DVD module
board. (See Fig.2)
(3) Remove the one screw C attaching the tramecha holder.
(See Fig.3)
(4) Through the DVD module board from mecha tramecha
holder and take out the mecha holder. (See Fig.4)
(5) Remove the four screws D attaching the traverse mecha-
nism. (See Fig.5)
(6) Solder the solder part of DVD pick up. (See Fig.6)
(7) Disconnect the card wire from CN101
DVD module board. (See Fig. 7)
Caution:
• Solder the short land section on the DVD pickup before dis-
connecting the card wire from the connector on the DVD
pickup. If the card wire is disconnected without attaching solders, the pickup may be destroyed by static electricity.
• When attaching the DVD pickup, be sure to remove solders
from the short land section after connecting the card wire to
the connector on the DVD pickup.
and CN201 on the
DVD mechanism assembly
B
B
A
A
Clamper base
DVD module board
Fig.2
DVD mechanism assembly
DVD mechanism assembly
Fig.1
1-14 (No.MB560)
DVD module board
C
Fig.3
Page 76
DVD module board
r
Solder short
Fig.6
DVD module board
Tramecha holde
CN101
CN201
DVD mechansim assembly
Fig.4
DVD mechanism assembly
Traverse mechanism assembly
DD
Fig.7
Fig.5
(No.MB560)1-15
Page 77
3.2.2 Removing the pickup assembly
(See Fig.8 to 12)
(1) Remove the two rod springs pressing the guide shaft. (See
Fig.8)
(2) Remove the screw E and F attaching the spring holder.
(See Fig.9)
(3) Remove the read screw from traverse mechanism assem-
bly. (See Fig.10)
Caution:
When remove the lead screw, do not loss the middle
gear. (See Fig.11 and 12)
(4) Remove the bar spring pressing the shaft. (See Fig.11)
(5) Take out the pickup assembly from traverse mechanism
chassis by order. (See Fig.12)
(SHAFT)
(T.TABLE)
HOOK
(BAR SPRING)
Fig.11
ROD SPRINGROD SPRING
Fig.8
Spring holder
Fig.9
order 2
order 3
order 1
Fig.12
EF
Middle gear
1-16 (No.MB560)
Lead screw
Fig.10
Page 78
3.2.3 Removing the feed motor assembly
(See Fig.13)
(1) Remove the one screw G attaching the feed motor assem-
bly.
(2) Remove the feed motor wires from solder part of spindle
motor board.
Splder part
3.2.4 Removing the spindle motor assembly
(See Fig.14)
(1) Remove the two screws H attaching the spindle motor from
spindle motor board.
Middle gear
Lead screw
Fig.13
H
Spindle motor
Fig.14
G
(No.MB560)1-17
Page 79
3.2.5 Removing the tray assembly
(See Fig.15 and 16)
(1) Remove the two screws J attaching the clamper base.
(See Fig.15)
(2) Remove the one screw K attaching the shaft guide from
bottom side. (See Fig.15)
(3) Remove the two screws L attaching the shaft guide from
top side. (See Fig.16)
Caution:
When attach the tray assembly, boss of loading sub assembly
should attach to guide of bottom side at tray assembly. (See
Fig.16)
J
order 1
order 2
clamper base
L
K
Fig.16
[bottom side]
Fig.15
1-18 (No.MB560)
Page 80
SECTION 4
ADJUSTMENT
4.1ATTENTION IN SERVICE OF DVD SECTION
(1) When pickup, Flash ROM ,DVD module board were changed, initialize EEPROM by all means.
(2) When full initialization was excuted, excute learning with a DVD test disc by all means.
Test disc : VT-501, VT-502
Learning method : It is adjusted automatically by normal playback of a DVD disc.
4.2TEST MODE
4.2.1 OUTLINE
To the set which is using the DVD module, in order to perform common correspondence in production, TEST mode is prepared.
Table 1 is corresponded in TEST mode.
MODECONTENTS
The destination, a region, study
state check mode
NORMAL initialize, FULL initialize
Device key write (CPPM, CPRM)
Device key check sum indication
mode
Micon version indication mode
FL all on mode
FRONT END check mode
Table 1. Contents corresponding to TEST mode.
Indication the distination code, region number and study state fo DVD micon.
Mode of DVD micon initialize. Initialize has NORMAL initialize and FULL initialize.
NORMAL initialize : Initialize the value of user setting item, like a indication contents of
SETUP OSD.
FULL initialize : Plus the contents of study which are carrying out the memory by
FRONT END for lead shortening are initialized for NORMAL initialize
contents.
For device key writing mode. Device key have CPPM(DVD Audio) and CPRM(VR).
Indication the wrote device key check sum. Indication this value, it can check the device key was
wrote or not.
Indication System micon, DVD micon, other ROM version. With a set, correspondence and the
contents of correspondence shall be individual, and shall be decided.
Mode of FL (LCD) all on. With a set, correspondence and the contents of correspondence shall be
individual, and shall be decided.
Mode of relation of FRONT END.
4.2.2 SET OPERATE
TEST mode performs correspondence by operation specially so that a user cannot enter.
* TEST MODE start should be press PLAY key & POWER key of main unit together and keep condition, connect AC.
* After set up TEST MODE, mode select by MENU key.
The changes to the key in TEST mode are shown in Fig. 1.
Fig.1 Change to TEST MODE and key
PLAY+POWER+AC
The destination, a region,
study state indication mode
PAUSE key
NORMAL
initialize
STOP key
4sec. pressPLAY key
FULL
initialize
MENU keyMENU key
MENU key
Device key check sum
indication mode
Device key
writing
MENU keyMENU keyMENU key
Micon version
indication mode
FL all on
mode
FRONT END
check mode
(*1) : Shift from destination, region and study state indication mode to NORMAL initialize, FULL initialize and device
writing mode should only can main unit key.
(No.MB560)1-19
Page 81
4.2.3 PROCESS
Below, FL (LCD) display to operation and communication with a DVD back end micon are shown.
* Since the number of beams changes with sets about FL (LCD) display, also set differing from the contents of specification to O.K.
* Since there are arrangement and a relation of existence with a set also about a key, also set differing from the contents of specification to O.K.
STEPOPERATIONMOVEMENT
Release AC, press PLAY & POWER key
1
together of main unit.
Keep STEP 1, connect AC.
2
Press PAUSE key of main unit.
1
NORMAL initialize
Long press(4sec) STOP key of main unit.
2
FULL initialize
Press MENU key of remocon.
3
Press MENU key of remocon.Micon version indication mode.
4
Press MENU key of remocon.FL all on mode.
5
Press MENU key of remocon.FRONT END check mode.
6
Press 1 at 10 key of remocon.Disc startup and through playback
1
Press 2 at 10 key of remocon.Existence of WOBBLE.
2
Press 3 at 10 key of remocon.Port check mode
3
Press 4 at 10 key of remocon.CD_LD on & Laser current indication.
4
5
Press 5 at 10 key of remocon.DVD_LD on & Laser current indication.
6
Press 6 at 10 key of remocon.DVD_SL x 1 jitter measurement mode.
The destination, a region, study state
indication mode.
Indication the destination by TEST mode
power on.
Device key check sum indication mode.
Indication check sum of device key for FL.
(4byte)
*1 Mode toggle by press MENU key.
*2 STEP2-3 and STEP3 are only for DVD-AUDIO or VR correspondence model.
4.3Key special mode
Mode nameOperationFunction
Tuner 9k/10k select
(U*version)
TRAY LOCK
DVD TEST MODE
SYSTEM TEST MODE
AVC ROM-CORE MODE
Press STOP key & PLAY key together
at TUNER AM then 9kHz step.
Press STOP key & PAUSE key together
at TUNER AM then 10kHz step.
Press STOP key & EJECT1 key together
at P.OFF.
At AC off line condition, press
PLAY+POWER together and keep
condition, connect AC.
At AC off line condition, press
PAUSE+POWER key together and keep
condition, connect AC.
At AC off line condition, press
STOP+PAUSE key together and keep
condition, connect AC.
FL (LCD) indication
13121110123456789
CH E C K
9kHz/10kHz step select of TUNER AM band.
DO the TRAY LOCK mode select. Temporaly P.ON operation, select
"LOCKED", "UNLOCKED". (Not done P.ON operation).
Transience (2sec.) indication end, and then return to P.OFF mode.
When press the EJECT key at LOCK mode, at P.OFF condition
tempraly P.ON operation and then transience (2sec.) indication
"LOCKED".
At P.ON condition, transience (2sec.) indication "LOCKED".
"Operation to TEST mode to on of DVD backend.
Operation of internal TEST MODE is refer the TEST mode."
"Set to speaker measurement mode.At source AM, operation the
beat cut by remote controller.Other operation is as same as normal
condition.
Mode release by POWER OFF."
Into the AV compulink rom-core rewrite mode.
4.4Remocon special mode
Mode nameCODEFunction
B330COLD START
B331FL all on
Preset frequency writeing
B33E
Operation
2-times input at P.OFF.
Input at P.ON.
Input at P.ON.Version indication
"Fix by 2 time input, operation temporaly P.ON and then transience(3sec.)
indication "COLD SET".
Indication end, done the P.OFF mode.
AC to off line, operation the COLD START.B330 : remote controller press
POWER + STOP + 0 key together."
"Rewrite preset frequency, LED on chek(each 300ms), FL all onLED on turn
: STANDBY - ILLUMI - REMOCON<VOL+> - <VOL->Volume control of key
input, keep high-speed mode until POWER OFF.
B331 : Remocon POWER + STOP + 1 key together"
"Indication turn Syscon version - Unit version - Distination, Chip select by
transience(5 sec.).
Syscon version : "SC ## $$" (## : Sys version,$ : Sys ROM-core)
Unit version : "BE %%%% "(%%%% : Unit version)
Distination, Chip select : "$$ %%"($$ : sys distination, %% :
"P3" or "P5" or "P7")
B33E : Press remocon POWER + STOP + 10 key together."
(No.MB560)1-21
Page 83
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
1-22 (No.MB560)
Page 84
(No.MB560)1-23
Page 85
Victor Company of Japan, Limited
Audio/Video Systems Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(No.MB560)
Printed in Japan
VPT
Page 86
PARTS LIST
TH-P7A,TH-P7US,TH-P7UB, TH-P7UF
TH-P7UP,TH-P7UX,TH-P7UG, TH-P7UN
* All printed circuit boards and its assemblies are not available as service parts.
No.MB560
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Speaker assembly and parts list(Subwoofer) (Block No.M2)
DVD mechanism assembly and parts list (Block No.MJ)
DVD loading base assembly and parts list (Block No.MN)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3) (Except TH-P7UF)
Packing materials and accessories parts list (Block No.M4) (TH-P7UF)
3- 2
3- 6
3- 7
3- 9
3-11
3-20
3-22
3-1
Page 87
Exploded view of general assembly and parts list
45
45
Block No.
M
M
1
M
46
45
45
45
24
60
44
29
A
57
47
46
48
10
Key board
29
h
63
p
e
10
g
f
59
58
31
1
FL board
10
14
USB Jack board
5
8
55
c
b
54
5
54
9
3-2
43
5
2
4
d
3
C
43
2
43
7
6
15
Headphone board
13
13
13
Page 88
51
22
20
19
24
24
k
62
28
n
28
j
26
40
h
j
p
23
n
23
Video board
30
56
58
61
g
f
23
59
15
g
f
e
c
d
k
Main board
27
25
52
41
27
17
41
35
34
37
38
36
m
42
39
39
65
64
50
33
49
m
17
h
b
23
rd
21
17
53
17
Power supply board
16
53
15
32
32
13
13
12
11
C
A
12
13
18
3-3
Page 89
General Assembly
Block No. [M][1][M][M]
Symbol No.Part No.Part NameDescriptionLocal
1LV11230-005AFRONT PANEL
2GV40313-002AFELT SPACER(x2)
3LV11231-008AFRONT LENS
4LV44574-001AFL SCREEN
5QYSDSF2608ZATAP SCREWM2.6 x 8mm(x3)
6QYSDSF2608ZATAP SCREWM2.6 x 8mm
7LV30225-011ASPACER
8LV22266-001ABUTTON
9LV44516-001ASTANDBY LENS
10QYSDSF2608ZATAP SCREWM2.6 x 8mm(x3)
11LV11232-001ACHASSIS BASE
12GV40313-002AFELT SPACER(x2)
13QYSDSG3006ZATAP SCREWM3 x 6mm(x4)
14QYSDSG3006ZATAP SCREWM3 x 6mm
15LV30225-011ASPACER(x2)
16LV36990-001ABARRIER
17QYSDSG3006ZATAP SCREWM3 x 6mm(x5)
18LV44573-001AFASTENER
19LV30226-048ASPACER
20LV30226-048ASPACER(x2)
21QYSBSG3010ZATAP SCREWM3 x 10mm(x3)
22LV36680-002AHEAT SINK
23QYSBSGY3008EATAP SCREWM3 x 8mm(x4)
24QYSDSG3006ZATAP SCREWM3 x 6mm(x2)
25QAR0390-001FAN MOTOR12V DC
26LV36681-001AFAN BRACKET
27QYSBSG3020ZATAP SCREWM3 x 20mm(x2)
28QYSDSG3006ZATAP SCREWM3 x 6mm(x2)
29GV30349-025ASPACER(x2)A,US,UB,UP,UX,UG,UN
29LV30225-011ASPACER(x2)UF
30GV30349-025ASPACERA,US,UB,UP,UX,UG,UN
30LV30225-011ASPACERUF
31LV30227-048ASPACER
32QYSDSF3008ZATAP SCREWM3 x 8mm(x2)
33LV22267-006AREAR PANEL
34QZW0033-001STRAIN RELIEF
35QMPG080-244-JDPOWER CORD(EU)2.44m BLACKA
35QMPK200-200-JDPOWER CORD(EU)2m BLACKUS,UX,UG,UN
35QMPN160-200-JDPOWER CORD(EU)2m BLACKUB
35QMPR480-200-JCPOWER CORD(EU)2m BLACKUF
35QMPR310-200-JCPOWER CORD(EU)2m BLACKUP
36QYSBSGY3008EATAP SCREWM3 x 8mm
37QYSBSGY3008EATAP SCREWM3 x 8mm
38QYSBSGY3008EATAP SCREWM3 x 8mm
39QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
40QAU0412-001TUNERFM/AMA,US,UB,UF,UX,UG,UN
40QAU0413-001TUNERFM/AMUP
41QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
42QYSBSGY3008EATAP SCREWM3 x 8mm
43QYSDSG3006ZATAP SCREWM3 x 6mm(x3)
44LV22268-001A/S/METAL COVER
45QYSBSGY3008EATAP SCREWM3 x 8mm(x5)
46E406308-007SPECIAL SCREW(x2)
47LV36678-001ATRAY FITTING
48LV36679-001AFITTING LENS
1LV22234-001ATM.CHASSIS
2LV22235-001ASPINDLE BASE
3QYSDST2005ZATAP SCREWM2 x 5mm(x2)
4LV36555-001AG.S.HOLDER
5QYSDST2005ZATAP SCREWM2 x 5mm
6LV44041-002AGUIDE SHAFT
7LV44479-001ABAR SPRING
8LV22236-001AFEED HOLDER
9QAR0165-001FEED MOTOR
10LV30225-0X5ASPACER
11LV36557-001AF.M.GEAR
12QYSPSPT2030MASCREWM2 x 3mm
13QYSDST2005ZATAP SCREWM2 x 5mm
14QAL0786-002P.UP
15LV22237-001ARACK ARM
16LV36560-001ARACK ARM SPRING
17QYSPSFU1740ZATAP SCREWM1.7 x 4mm(x2)
18QUQK05-2415AC-EFFC WIRE24pin 15cm
20LV44041-002AGUIDE SHAFT
21LV36559-001AL.S.GEAR
22LV41517-003ALEAD SCREW
23LV36558-001AMIDDLE GEAR
24LV36556-001ASPRING HOLDER
25LV44623-001ACOMP.SPRING
26QYSDST2005ZATAP SCREWM2 x 5mm
27QYSDST2616MATAP SCREWM2.6 x 16mm
28QAR0386-001S.MOTOR
29QYSPSPU1775ZASCREWM1.7 x 7.5mm(x3)
30LV44042-001AROD SPRING(x2)
31LV44046-001AADJUST SCREW(x4)
Block No. [M][J][M][M]
3-8
Page 94
DVD loading base assembly and parts list
Grease
JVS-1003
JVG-450
< Back side >
20
19
18
16
h
FMU-MB1-21M
29
15
16
M
N
M
Block No.
M
2
3
28
12
h
14
28
DVD module board
27
17
m
11
j
n
1
9
10
0.10mm
4
7
8
6
7.75mm
Backside
5
27
j
26
B
A
k
c
13
DVD loading switch board
g
e
f
d
22
23
k
B
n
25
A
m
22
21
23
f
c
23
e
22
d
The parts without symbol number are not service.
3-9
Page 95
DVD loading base
Symbol No.Part No.Part NameDescriptionLocal
1LV11065-007ALOADER SUB ASSY
2E407140-001SSC.D ROLLER
3E407149-001SSRUBBER TUBE
4LV10979-002ATRAY
5LV35499-001ASHAFT GUIDE
6LV44022-001ASHAFT
7QYSSSF2008ZATAP SCREWM2 x 8mm
8QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
9LV41741-004ASPECIAL SCREW
10QAR0197-001MOTOR
11LV43844-002AMOTOR PULLEY
12QYSPSPU1730ZASCREWM1.7 x 3mm(x2)
13QYSDSF2008ZATAP SCREWM2 x 8mm
14LV43974-001ABELT
15LV21852-003ACLAMPER BASE
16QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
17LV35056-002ADVD CLAMPER
18LV42930-003AP.C.MAGNET
19LV43848-001AYOKE
20LE40906-002ASPECIAL SCREW
21-----------------SINGLE DVD TRAM
22LV44043-001AINSULATOR(x4)
23LV44044-001ASPECIAL SCREW(x4)
25LV22269-003AMECHA HOLDER
26QYSBSF2608ZATAP SCREWM2.6 x 8mm
27LV44209-001AWASHER SCREW(x2)
28QYSBSF3008ZATAP SCREWM3 x 8mm(x2)
29LV44603-001ALASER CATION
Block No. [M][N][M][M]
3-10
Page 96
Electrical parts list
Main board
Block No. [0][1]
Symbol No.
IC102TAS5086DBT-XIC
IC103TAS5142DDV-XIC
IC104TAS5142DDV-XIC
IC105RC4580ID-XIC
IC108RC4558D-XIC
IC109IMX9-WTRANSISTOR
IC461AK5358ET-XIC
IC471MN101C49GPT1IC MASK
IC472S-80840CNNB-G-W IC
IC473SN74AHCT08NS-X IC
IC477BR24L08F-W-XIC(DIGITAL)
IC491KIA7805APIIC
IC492MM1593DF-XIC
IC493LB1641IC
IC494KIA78S09P-TIC
C1002NCB31CK-224XC CAPACITOR0.22uF 16V K
C1003NCB31CK-104XC CAPACITOR0.1uF 16V K
C1004NCB31HK-103XC CAPACITOR0.01uF 50V K
C1005NCB31CK-104XC CAPACITOR0.1uF 16V K
C1006NCB31HK-103XC CAPACITOR0.01uF 50V K
C1007NCB31CK-104XC CAPACITOR0.1uF 16V K
C1008NCB31CK-104XC CAPACITOR0.1uF 16V K
C1009NCB31CK-104XC CAPACITOR0.1uF 16V K
C1010NCB31CK-104XC CAPACITOR0.1uF 16V K
C1011QETN1CM-107ZE CAPACITOR100uF 16V M
Part No.Part NameDescriptionLocal
Symbol No.
C1012NCB31CK-104XC CAPACITOR0.1uF 16V K
C1013QETN1HM-226ZE CAPACITOR22uF 50V M
C1014NCB31HK-104XC CAPACITOR0.1uF 50V K
C1015QETN1HM-226ZE CAPACITOR22uF 50V M
C1016NCB31HK-104XC CAPACITOR0.1uF 50V K
C1017NCB31HK-104XC CAPACITOR0.1uF 50V K
C1018NCB31HK-104XC CAPACITOR0.1uF 50V K
C1019QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1020QETM1HM-228E CAPACITOR2200uF 50V M
C1021NCB31HK-104XC CAPACITOR0.1uF 50V K
C1022QETN1CM-107ZE CAPACITOR100uF 16V M
C1023NCB31CK-105XC CAPACITOR1uF 16V K
C1024NCB31CK-104XC CAPACITOR0.1uF 16V K
C1028NCB31HK-104XC CAPACITOR0.1uF 50V K
C1029NCB31HK-104XC CAPACITOR0.1uF 50V K
C1030QETN1EM-476ZE CAPACITOR47uF 25V M
C1031NCB21CK-104XC CAPACITOR0.1uF 16V K
C1034NCB31CK-104XC CAPACITOR0.1uF 16V K
C1035NDC31HJ-150XC CAPACITOR15pF 50V J
C1037NCB31CK-104XC CAPACITOR0.1uF 16V K
C1040NCB31CK-104XC CAPACITOR0.1uF 16V K
C1041NCB31HK-104XC CAPACITOR0.1uF 50V K
C1101NCB31HK-104XC CAPACITOR0.1uF 50V K
C1102NCB31HK-333XC CAPACITOR0.033uF 50V K
C1103NCB31HK-681XC CAPACITOR680pF 50V K
C1104NCB31HK-681XC CAPACITOR680pF 50V K
C1105QETN1VM-477ZE CAPACITOR470uF 35V M
C1106QETN1VM-477ZE CAPACITOR470uF 35V M
C1107QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1108NCB31HK-472XC CAPACITOR4700pF 50V K
C1109NCB31HK-472XC CAPACITOR4700pF 50V K
C1110NCB31HK-472XC CAPACITOR4700pF 50V K
C1111NC B31HK -472XC CAPACITOR4700pF 50V K
C1112NCB31HK-473XC CAPACITOR0.047uF 50V K
C1113NCB31HK-473XC CAPACITOR0.047uF 50V K
C1114NCB31HK-271XC CAPACITOR270pF 50V K
C1115NCB31HK-271XC CAPACITOR270pF 50V K
C1116NCB31HK-223XC CAPACITOR0.022uF 50V K
C1117QFVF1HJ-224ZMF CAPACITOR0.22uF 50V J
C1118NDC31HJ-271XC CAPACITOR270pF 50V J
C1119NDC31HJ-560XC CAPACITOR56pF 50V J
C1120NCB31HK-152XC CAPACITOR1500pF 50V K
C1121QETN1CM-227ZE CAPACITOR220uF 16V M
C1123NCB31HK-104XC CAPACITOR0.1uF 50V K
C1124QETN1HM-106ZE CAPACITOR10uF 50V M
C1125NCB31HK-104XC CAPACITOR0.1uF 50V K
C1126NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1127NCB31HK-104XC CAPACITOR0.1uF 50V K
C1201NCB31HK-104XC CAPACITOR0.1uF 50V K
C1202NCB31HK-333XC CAPACITOR0.033uF 50V K
C1203NCB31HK-681XC CAPACITOR680pF 50V K
C1204NCB31HK-681XC CAPACITOR680pF 50V K
C1205QETN1VM-477ZE CAPACITOR470uF 35V M
C1206QETN1VM-477ZE CAPACITOR470uF 35V M
C1207QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1208NCB31HK-472XC CAPACITOR4700pF 50V K
C1209NCB31HK-472XC CAPACITOR4700pF 50V K
C1210NCB31HK-472XC CAPACITOR4700pF 50V K
C1211NCB31HK-472XC CAPACITOR4700pF 50V K
C1212NCB31HK-473XC CAPACITOR0.047uF 50V K
C1213NCB31HK-473XC CAPACITOR0.047uF 50V K
C1214NCB31HK-271XC CAPACITOR270pF 50V K
C1215NCB31HK-271XC CAPACITOR270pF 50V K
C1216NCB31HK-223XC CAPACITOR0.022uF 50V K
C1217QFVF1HJ-224ZMF CAPACITOR0.22uF 50V J
C1218NDC31HJ-271XC CAPACITOR270pF 50V J
C1219NDC31HJ-560XC CAPACITOR56pF 50V J
C1220NCB31HK-152XC CAPACITOR1500pF 50V K
C1221QETN1CM-227ZE CAPACITOR220uF 16V M
C1223NCB31HK-104XC CAPACITOR0.1uF 50V K
C1224QETN1HM-106ZE CAPACITOR10uF 50V M
C1225NCB31HK-104XC CAPACITOR0.1uF 50V K
C1226NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1227NCB31HK-104XC CAPACITOR0.1uF 50V K
C1301NCB31HK-104XC CAPACITOR0.1uF 50V K
C1302NCB31HK-104XC CAPACITOR0.1uF 50V K
Part No.Part NameDescriptionLocal
3-11
Page 97
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C1303NCB31HK-333XC CAPACITOR0.033uF 50V K
C1304NCB31HK-333XC CAPACITOR0.033uF 50V K
C1305NCB31HK-681XC CAPACITOR680pF 50V K
C1306NCB31HK-681XC CAPACITOR680pF 50V K
C1307NCB31HK-681XC CAPACITOR680pF 50V K
C1308NCB31HK-681XC CAPACITOR680pF 50V K
C1309QFVM2AJ-474ZMF CAPACITOR0.47uF 100V J
C1310NCB31HK-104XC CAPACITOR0.1uF 50V K
C1311NCB31HK-104XC CAPACITOR0.1uF 50V K
C1312NCB31HK-472XC CAPACITOR4700pF 50V K
C1313NCB31HK-472XC CAPACITOR4700pF 50V K
C1314NCB31HK-472XC CAPACITOR4700pF 50V K
C1315NCB31HK-472XC CAPACITOR4700pF 50V K
C1316NCB31HK-473XC CAPACITOR0.047uF 50V K
C1317NCB31HK-473XC CAPACITOR0.047uF 50V K
C1318NCB31HK-561XC CAPACITOR560pF 50V K
C1319NCB31HK-561XC CAPACITOR560pF 50V K
C1320NCB31HK-271XC CAPACITOR270pF 50V K
C1321NCB31HK-271XC CAPACITOR270pF 50V K
C1323NCB31HK-104XC CAPACITOR0.1uF 50V K
C1324QETN1HM-106ZE CAPACITOR10uF 50V M
C1325NCB31HK-104XC CAPACITOR0.1uF 50V K
C1326NCB31HK-104XC CAPACITOR0.1uF 50V K
C1327NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1328NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1401NCB31HK-104XC CAPACITOR0.1uF 50V K
C1402NCB31HK-333XC CAPACITOR0.033uF 50V K
C1403NCB31HK-681XC CAPACITOR680pF 50V K
C1404NCB31HK-681XC CAPACITOR680pF 50V K
C1405QETN1VM-477ZE CAPACITOR470uF 35V M
C1406QETN1VM-477ZE CAPACITOR470uF 35V M
C1407QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1408NCB31HK-472XC CAPACITOR4700pF 50V K
C1409NCB31HK-472XC CAPACITOR4700pF 50V K
C1410NCB31HK-472XC CAPACITOR4700pF 50V K
C1411NCB31HK-472XC CAPACITOR4700pF 50V K
C1412NCB31HK-473XC CAPACITOR0.047uF 50V K
C1413NCB31HK-473XC CAPACITOR0.047uF 50V K
C1414NCB31HK-271XC CAPACITOR270pF 50V K
C1415NCB31HK-271XC CAPACITOR270pF 50V K
C1416NCB31HK-223XC CAPACITOR0.022uF 50V K
C1423NCB31HK-104XC CAPACITOR0.1uF 50V K
C1424QETN1HM-106ZE CAPACITOR10uF 50V M
C1425NCB31HK-104XC CAPACITOR0.1uF 50V K
C1426NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1427NCB31HK-104XC CAPACITOR0.1uF 50V K
C1501NCB31HK-104XC CAPACITOR0.1uF 50V K
C1502NCB31HK-333XC CAPACITOR0.033uF 50V K
C1503NCB31HK-681XC CAPACITOR680pF 50V K
C1504NCB31HK-681XC CAPACITOR680pF 50V K
C1505QETN1VM-477ZE CAPACITOR470uF 35V M
C1506QETN1VM-477ZE CAPACITOR470uF 35V M
C1507QFVF1HJ-105ZMF CAPACITOR1uF 50V J
C1508NCB31HK-472XC CAPACITOR4700pF 50V K
C1509NCB31HK-472XC CAPACITOR4700pF 50V K
C1510NCB31HK-472XC CAPACITOR4700pF 50V K
C1511NCB31HK-472XC CAPACITOR4700pF 50V K
C1512NCB31HK-473XC CAPACITOR0.047uF 50V K
C1513NCB31HK-473XC CAPACITOR0.047uF 50V K
C1514NCB31HK-271XC CAPACITOR270pF 50V K
C1515NCB31HK-271XC CAPACITOR270pF 50V K
C1516NCB31HK-223XC CAPACITOR0.022uF 50V K
C1523NCB31HK-104XC CAPACITOR0.1uF 50V K
C1524QETN1HM-106ZE CAPACITOR10uF 50V M
C1525NCB31HK-104XC CAPACITOR0.1uF 50V K
C1526NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1527NCB31HK-104XC CAPACITOR0.1uF 50V K
C1601NCB31HK-104XC CAPACITOR0.1uF 50V K
C1602NCB31HK-104XC CAPACITOR0.1uF 50V K
C1603NCB31HK-333XC CAPACITOR0.033uF 50V K
C1604NCB31HK-333XC CAPACITOR0.033uF 50V K
C1605NCB31HK-681XC CAPACITOR680pF 50V K
C1606NCB31HK-681XC CAPACITOR680pF 50V K
C1607NCB31HK-681XC CAPACITOR680pF 50V K
C1608NCB31HK-681XC CAPACITOR680pF 50V K
C1609QFVM2AJ-474ZMF CAPACITOR0.47uF 100V J
C1610NCB31HK-104XC CAPACITOR0.1uF 50V K
C1611NCB31HK-104XC CAPACITOR0.1uF 50V K
C1612NCB31HK-472XC CAPACITOR4700pF 50V K
C1613NCB31HK-472XC CAPACITOR4700pF 50V K
C1614NCB31HK-472XC CAPACITOR4700pF 50V K
C1615NCB31HK-472XC CAPACITOR4700pF 50V K
C1616NCB31HK-473XC CAPACITOR0.047uF 50V K
C1617NCB31HK-473XC CAPACITOR0.047uF 50V K
C1618NCB31HK-561XC CAPACITOR560pF 50V K
C1619NCB31HK-561XC CAPACITOR560pF 50V K
C1620NCB31HK-271XC CAPACITOR270pF 50V K
C1621NCB31HK-271XC CAPACITOR270pF 50V K
C1623NCB31HK-104XC CAPACITOR0.1uF 50V K
C1624QETN1HM-106ZE CAPACITOR10uF 50V M
C1625NCB31HK-104XC CAPACITOR0.1uF 50V K
C1626NCB31HK-104XC CAPACITOR0.1uF 50V K
C1627NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1628NCF21HZ-474XC CAPACITOR0.47uF 50V Z
C1701QETN1EM-107ZE CAPACITOR100uF 25V M
C1702NCB31HK-102XC CAPACITOR1000pF 50V K
C1703QETN1EM-107ZE CAPACITOR100uF 25V M
C1704NCB31HK-104XC CAPACITOR0.1uF 50V K
C1705NCB31HK-104XC CAPACITOR0.1uF 50V K
C4002NCF21CZ-105XC CAPACITOR1uF 16V Z
C4003NCF21CZ-105XC CAPACITOR1uF 16V Z
C4014NCB31HK-102XC CAPACITOR1000pF 50V K
C4015NCB31HK-102XC CAPACITOR1000pF 50V K
C4016NCB31HK-102XC CAPACITOR1000pF 50V K
C4017NDC31HJ-151XC CAPACITOR150pF 50V J
C4091QETN1HM-226ZE CAPACITOR22uF 50V M
C4092NCB31HK-103XC CAPACITOR0.01uF 50V K
C4093NCB31HK-103XC CAPACITOR0.01uF 50V K
C4201QETN1CM-107ZE CAPACITOR100uF 16V M
C4202QETN1CM-107ZE CAPACITOR100uF 16V M
C4203QETN1EM-476ZE CAPACITOR47uF 25V M
C4601QETN1HM-226ZE CAPACITOR22uF 50V M
C4602NCB31CK-104XC CAPACITOR0.1uF 16V K
C4603NCF21CZ-474XC CAPACITOR0.47uF 16V Z
C4604QETN1HM-226ZE CAPACITOR22uF 50V M
C4605NCB31CK-104XC CAPACITOR0.1uF 16V K
C4606NCB31CK-104XC CAPACITOR0.1uF 16V K
C4607NDC31HJ-471XC CAPACITOR470pF 50V J
C4608NDC31HJ-471XC CAPACITOR470pF 50V J
C4609QETN1HM-106ZE CAPACITOR10uF 50V M
C4610QETN1HM-106ZE CAPACITOR10uF 50V M
C4705NCB31HK-103XC CAPACITOR0.01uF 50V K
C4706NCB31HK-103XC CAPACITOR0.01uF 50V K
C4707QETN1CM-107ZE CAPACITOR100uF 16V M
C4708NCB31HK-103XC CAPACITOR0.01uF 50V K
C4709NCB31HK-103XC CAPACITOR0.01uF 50V K
C4710NCB31HK-103XC CAPACITOR0.01uF 50V K
C4711QETN1HM-106ZE CAPACITOR10uF 50V M
C4771NCB31CK-104XC CAPACITOR0.1uF 16V K
C4772NCB31CK-104XC CAPACITOR0.1uF 16V K
C4773NCB31CK-104XC CAPACITOR0.1uF 16V K
C4774NCB31CK-104XC CAPACITOR0.1uF 16V K
C4775NCB31HK-103XC CAPACITOR0.01uF 50V K
C4776NCB31HK-103XC CAPACITOR0.01uF 50V K
C4791NCB31CK-104XC CAPACITOR0.1uF 16V K
C4793NCB31CK-104XC CAPACITOR0.1uF 16V K
C4794QETN1CM-107ZE CAPACITOR100uF 16V M
C4795NCB31CK-104XC CAPACITOR0.1uF 16V K
C4901QETN1CM-107ZE CAPACITOR100uF 16V M
C4902NCB31HK-103XC CAPACITOR0.01uF 50V K
C4903QETN1CM-107ZE CAPACITOR100uF 16V M
C4904NCB31HK-103XC CAPACITOR0.01uF 50V K
C4921NCF21CZ-105XC CAPACITOR1uF 16V Z
C4922NDC31HJ-471XC CAPACITOR470pF 50V J
C4923NCB31AK-105XC CAPACITOR1uF 10V K
C4924QETN1CM-107ZE CAPACITOR100uF 16V M
C4925NCB31HK-104XC CAPACITOR0.1uF 50V K
C8001NCB31HK-182XC CAPACITOR1800pF 50V K
C8002NCB31HK-182XC CAPACITOR1800pF 50V K
C8003NDC31HJ-150XC CAPACITOR15pF 50V J
C8004NDC31HJ-150XC CAPACITOR15pF 50V J
Q6501KRC104S-XTRANSISTOR
Q6502KRC104S-XTRANSISTOR
Q6601KTC3875/YG/-XTRANSISTOR
Q6701KTC3875/YG/-XTRANSISTOR
Q90012SJ632-XPOWER MOS FET
Q9002KTA1504/YG/-XTRANSISTOR
Q9003KTC3875/YG/-XTRANSISTOR
Q9004KRA102S-XDIGI TRANSISTOR
Q90112SJ609POWER MOS FET
Q9013KTC3875/YG/-XTRANSISTOR
Q9031KRC102S-XDIGI TRANSISTOR
Q9032KRC102S-XDIGI TRANSISTOR
Q9034KRC102S-XDIGI TRANSISTOR
Q9036KTC3265/Y/-XTRANSISTOR
Q9037KTA1504/YG/-XTRANSISTOR
Q9038KRC104S-XTRANSISTOR
Q90392SJ651POWER MOS FET
Q9041RTQ035P02-WMOS FET
C506NCB31CK-105XC CAPACITOR1uF 16V K
C507NCB31HK-103XC CAPACITOR0.01uF 50V K
C511NCB31CK-105XC CAPACITOR1uF 16V K
C515NCB31HK-103XC CAPACITOR0.01uF 50V K
C901QFZ9073-154MM CAPACITOR 0.15uF AC250V M A,UB,UF,UP
C901QFZ9073-334MM CAPACITOR 0.33uF AC250V M
C902QCZ9079-102C CAPACITOR1000pF AC250V M
C903QCZ9079-102C CAPACITOR1000pF AC250V M
C904QFZ9073-154MM CAPACITOR 0.15uF AC250V M A,UB,UF,UP
C904QFZ9073-334MM CAPACITOR 0.33uF AC250V M
C905QEZ0792-227E CAPACITOR220uF 400V MA,UB,UF,UP
C905QEZ0791-477E CAPACITOR470uF
C906QCZ0136-332ZC CAPACITOR3300pF 1kV K
C907QCZ0340-102C CAPACITOR1000pF 2kV K
C909QEZ0657-226ZE CAPACITOR22uF 35V M
C910NCB31HK-471XC CAPACITOR470pF 50V K
C911QETN1HM-105ZE CAPACITOR1uF 50V M
C912NCB31HK-104XC CAPACITOR0.1uF 50V K
C913NCB31HK-332XC CAPACITOR3300pF 50V K
C914NDC31HJ-101XC CAPACITOR100pF 50V J
C921QCZ9079-102C CAPACITOR1000pF AC250V M
C5901NCB31HK-103XC CAPACITOR0.01uF 50V K
C5902NCB31HK-103XC CAPACITOR0.01uF 50V K
C5903NCB31CK-224XC CAPACITOR0.22uF 16V K
C5904NCB31HK-103XC CAPACITOR0.01uF 50V K
C5905NCB31HK-103XC CAPACITOR0.01uF 50V K
C5906NCB31HK-103XC CAPACITOR0.01uF 50V K
C5907NCB31CK-224XC CAPACITOR0.22uF 16V K
C6001QETN1AM-477ZE CAPACITOR470uF 10V M
C6002NCB31CK-104XC CAPACITOR0.1uF 16V K
C6003QETN1HM-226ZE CAPACITOR22uF 50V M
C6004NCB31CK-104XC CAPACITOR0.1uF 16V K
C6301NCB30JK-105XC CAPACITOR1uF 6.3V K
C6311NCB30JK-105XC CAPACITOR1uF 6.3V K
C6321NCB31HK-103XC CAPACITOR0.01uF 50V K
C6331NCB30JK-105XC CAPACITOR1uF 6.3V K
C6341NCB30JK-105XC CAPACITOR1uF 6.3V K
C6351NCB30JK-105XC CAPACITOR1uF 6.3V K
C6401QETN1AM-477ZE CAPACITOR470uF 10V M
C6402NDC31HJ-470XC CAPACITOR47pF 50V J
C6411NCB31HK-103XC CAPACITOR0.01uF 50V K
C6412NDC31HJ-470XC CAPACITOR47pF 50V J
C6421QETN1AM-477ZE CAPACITOR470uF 10V M
C6423NDC31HJ-470XC CAPACITOR47pF 50V J
C6431QETN1AM-477ZE CAPACITOR470uF 10V M
C6432NDC31HJ-470XC CAPACITOR47pF 50V J
US,UX,UG,UN
US,UX,UG,UN
US,UX,UG,UN
US,UX,UG,UN
C6441QETN1AM-477ZE CAPACITOR470uF 10V M
C6442NDC31HJ-470XC CAPACITOR47pF 50V J
C6451QETN1AM-477ZE CAPACITOR470uF 10V M
C6452NDC31HJ-470XC CAPACITOR47pF 50V J
C6501NCB31CK-104XC CAPACITOR0.1uF 16V K
C6502QETN1EM-476ZE CAPACITOR47uF 25V M
C6503QETN1EM-476ZE CAPACITOR47uF 25V M
C6504NCB31CK-104XC CAPACITOR0.1uF 16V K
C6551QETN1CM-107ZE CAPACITOR100uF 16V M
C6601QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6602QETN1HM-226ZE CAPACITOR22uF 50V M
C6603NDC31HJ-101XC CAPACITOR100pF 50V J
C6604QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6605NCB31HK-102XC CAPACITOR1000pF 50V K
C6651NCB31HK-822XC CAPACITOR8200pF 50V K
C6652NCB30JK-105XC CAPACITOR1uF 6.3V K
C6701QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6702QETN1HM-226ZE CAPACITOR22uF 50V M
C6703NDC31HJ-101XC CAPACITOR100pF 50V J
C6704QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6705NCB31HK-102XC CAPACITOR1000pF 50V K
C6751NCB31HK-822XC CAPACITOR8200pF 50V K
C6752NCB30JK-105XC CAPACITOR1uF 6.3V K
C6811NCB31HK-331XC CAPACITOR330pF 50V K
C6812QETN1HM-475ZE CAPACITOR4.7uF 50V M
C6821NCB31HK-331XC CAPACITOR330pF 50V K
C6822QETN1HM-475ZE CAPACITOR4.7uF 50V M
C9001QCZ0136-332ZC CAPACITOR3300pF 1kV K
C9002QEZ0779-827E CAPACITOR820uF 35V M
C9003QEZ0779-827E CAPACITOR820uF 35V M
C9004NDC31HJ-101XC CAPACITOR100pF 50V J
C9005QEZ0655-826ZE CAPACITOR82uF 16V M
C9006QCZ0136-101ZC CAPACITOR100pF 1kV K
C9007QEZ0657-396ZE CAPACITOR39uF 35V M
C9008NCB31HK-223XC CAPACITOR0.022uF 50V K
C9009NCB31HK-103XC CAPACITOR0.01uF 50V K
C9010QETN1HM-226ZE CAPACITOR22uF 50V M
C9012QETN1CM-107ZE CAPACITOR100uF 16V M
C9013NCB31HK-222XC CAPACITOR2200pF 50V K
C9014QEZ0655-107ZE CAPACITOR100uF 16V M
C9015NCB31HK-472XC CAPACITOR4700pF 50V K
C9017QEZ0655-337ZE CAPACITOR330uF 16V M
C9018NCB31HK-222XC CAPACITOR2200pF 50V K
C9019QETN1CM-107ZE CAPACITOR100uF 16V M
C9021NCB31HK-103XC CAPACITOR0.01uF 50V K
C9022NCB31HK-222XC CAPACITOR2200pF 50V K
C9023QEZ0701-827E CAPACITOR820uF 16V M
C9024QEZ0655-107ZE CAPACITOR100uF 16V M
C9025NCB31HK-222XC CAPACITOR2200pF 50V K
C9031QETN1HM-107ZE CAPACITOR100uF 50V MA,UB,UF,UP
C9031QEHR1VM-107ZE CAPACITOR100uF 35V M
C9036QEZ0654-108ZE CAPACITOR1000uF 10V M
C9037NCB31HK-103XC CAPACITOR0.01uF 50V K
C9038NCB31HK-103XC CAPACITOR0.01uF 50V K
C9039NCB31HK-104XC CAPACITOR0.1uF 50V K
C9071NCB31HK-333XC CAPACITOR0.033uF 50V K
C9072QFVF1HJ-154ZMF CAPACITOR0.15uF 50V J
C9073QETN1HM-106ZE CAPACITOR10uF 50V M
C9076QETN1HM-106ZE CAPACITOR10uF 50V M
C9082QETN1CM-107ZE CAPACITOR100uF 16V M
C9084NCB31CK-104XC CAPACITOR0.1uF 16V K
