Consists of XV-THP7, SP-WP7,
SP-THP7F, SP-THP7C and SP-THP7S
TH-P3
Consists of XV-THP3, SP-WP5,
SP-THP3F, SP-THP3C and SP-THP3S
TH-G10
Consists of XV-THG10, SP-THG10W,
SP-THG10F, SP-THG10C and SP-THG10S
INSTRUCTIONS
[US, UN, UG, UX, UW, UB, A, UH]
LVT1523-008C
Warnings, Cautions and Others
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
Thebutton in any position does not disconnect the
mains line.
Disconnect the mains plug to shut the power off
completely (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.
• When the system is on standby, the STANDBY
lamp lights red.
• When the system is turned on, the STANDBY lamp
goes off.
The power can be remote controlled.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to
get out.)
• Do not place any naked flame sources, such as
lighted candles, on the apparatus.
• When discarding batteries, environmental problems
must be considered and local rules or laws governing
the disposal of these batteries must be followed
strictly.
• Do not expose this apparatus to rain, moisture,
dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the
apparatus.
G-1
CAUTION
Excessive sound pressure from earphones or headphones can
cause hearing loss.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover or cabinet.
There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION:
Visible and/or invisible class 1M laser radiation when
open. Do not view directly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED INSIDE THE UNIT.
CAUTION
Battery shall not be exposed to excessive heat such as
sunshine, fire or the like.
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, place the apparatus on a level surface. The minimal
clearances are shown below:
Wall or
obstructions
15 cm
Front view
XV-THP7/
XV-THP3/
XV-THG10
15 cm
[European Union only]
SP-THP7: 20kg
15 cm
15 cm
Front
No
obstructions
CAUTION!
To avoid personal injury or
accidentally dropping the
unit, have two persons
unpack, carry, and install the
unit.
• Select a place which is level, dry and neither too hot nor
too cold; between 5°C and 35°C.
• Leave sufficient distance between the system and the TV.
• Do not use the system in a place subject to vibration.
Power cord
• Do not handle the power cord with wet hands.
• A small amount of power is always consumed while the
power cord is connected to the wall outlet.
• When unplugging the power cord from the wall outlet,
always pull on the plug, not the power cord.
To prevent malfunctions of the system
• There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
dealer.
• Do not insert any metallic object into the system.
• Do not use any non-standard shape disc (like a heart,
flower or credit card, etc.) available on the market,
because it may damage the system.
• Do not use a disc with tape, stickers, or paste on it,
because it may damage the system.
Label sticker
Sticker
Paste
Note about copyright laws
Check the copyright laws in your country before recording
from the discs. Recording of copyrighted material may
infringe copyright laws.
Note about copyguard system
The discs are protected by copyguard system. When you
connect the system to your VCR directly, the copyguard
system activates and the picture may not be played back
correctly.
7 Safety precautions
Avoid moisture, water and dust
Do not place the system in moist or dusty places.
Avoid high temperatures
Do not expose the system to direct sunlight and do not
place it near a heating device.
When you are away
When away on travel or for other reasons for an extended
period of time, disconnect the power cord plug from the
wall outlet.
Do not block the vents
Blocking the vents may damage the system.
Care of the cabinet
When cleaning the system, use a soft cloth and follow the
relevant instructions on the use of chemically-coated cloths.
Do not use benzene, thinner or other organic solvents
including disinfectants. These may cause deformation or
discoloring.
If water gets inside the system
Turn the system off and disconnect the power cord plug
from the wall outlet, then call the store where you made
your purchase. Using the system in this condition may
cause a fire or electrical shock.
Supplied accessories
Check to be sure you have all of the supplied accessories.
The number in parentheses is the quantity of the pieces
supplied.
If anything is missing, contact your dealer immediately.
• Remote control (1)
• Batteries (2)
• FM antenna (1)
• AM loop antenna (1)
• Composite Video cord (1)
• AC plug adapter (except for Hong Kong, the countries of
the Middle East, Thailand and Australia)
• Speaker cords (Only for TH-P7)
4 m: For satellite (front left/right), center speakers, and
subwoofer (4)
10 m: For satellite speakers (surround left/right) (2)
•Screws (Only for TH-P7)
M5 x 40 mm (4)
M4 x 20 mm (8)
• Speaker cord clamps (Only for TH-P7) (4)
2
About discs
F
Middle E
Playable disc types
This system has been designed to play back the following
discs:
DVD VIDEOAudio CD
VCDSVCD
√ in the list below shows available disc types and
The
recording formats.
Disc type
Recording
format
DVD Video—√√
DVD VR—√√
VCD/SVCD√——
Audio CD√——
MP3√√*
WMA√√*
JPEG√√*
ASF√√*
MPEG-2√*
MPEG-1√*
DivX√√*
1
*
This system can play finalized discs only.
2
*
Recorded with UDF Bridge format.
3
*
This system may not be able to play back a file if the file
CD-R/-RW
size is too large.
• It is possible to play back finalized +R/+RW (DVD Video
Format only) discs. “DVD” lights on the display panel
when a +R/+RW disc is loaded.
• This system accommodates the NTSC and PAL system.
When you play an NTSC disc with the scan mode set to
“PAL” (see page 16), the NTSC video signal is converted
to the PAL60 signal and output.
• The Non-DVD side of a “DualDisc” does not comply
with the “Compact Disc Digital Audio” standard.
Therefore, the use of Non-DVD side of a DualDisc on
this product may not be recommended.
• On some DVD VIDEOs, VCDs or SVCDs, their actual
operation may be different from what is explained in
this manual. This is due to the disc programming and
disc structure, not a malfunction of this system.
*1DVD-R*1DVD-RW*
2
2
2
2
3
3
√*
√*
2
2
2
√*
√*
√*
√*
√*
√*
√*
Notes on DVD-R and DVD-RW
• This system does not support “multi-border” disc.
Notes on CD-R and CD-RW
• This system can play CD-Rs or CD-RWs recorded with
ISO 9660 format.
• This system supports “multi-session” discs (up to 20
sessions).
• This system cannot play “packet write” discs.
Region code of DVD VIDEO
DVD VIDEO players and DVD VIDEO discs have their
own Region Code numbers. This system can play back
DVD VIDEO discs whose Region Code numbers include
the system’s Region Code, which is indicated on the rear
panel.
• Example of playable DVD:
or the countries of the
1
For Southeast Asia
For Australia, Central and South America
2
2
2
2
2
2
2
If a DVD with an improper Region Code number is loaded,
“REGION CODE ERROR!” appears on the TV screen and
playback cannot start.
Some discs may not be played back because of their disc
characteristics, recording conditions, or damage or stain on
ast
them.
Unplayable discs
DVD-ROM, DVD-RAM, CD-I (CD-I Ready), Photo CD,
SACD, etc.
Playing back these discs will generate noise and damage
the speakers.
DVD Logo is a trademark of DVD Format/Logo Licensing
Corporation.
3
About discs
Playable file types
For all playable files
• The system can only recognize and play files with one of
the following extensions, which can be in any
combination of upper and lower case;
MP3: “.MP3”, “.mp3”
WMA: “.WMA”, “.wma”
JPEG: “. J PG ”, “. J PE G”, “. jp g”, “. j pe g”
ASF: “. A SF ”, “. as f ”
MPEG-2/MPEG-1: “.MPG”, “.MPEG”, “.mpg”, “.mpeg”
DivX: “.DIVX”, “.DIV”, “.divx”, “.div”, and “.AVI”, “.avi”
• The system recognizes up to 150 tracks (files) per group,
99 groups per disc/device, and the total number of the
tracks (files) that the system can play is 4000.
• Some files may not be played back normally because of
their disc characteristics or recording conditions.
• MP3/WMA/JPEG/ASF/MPEG-2/MPEG-1/DivX files
require a longer readout time. (It differs due to the
complexity of the directory/file configuration.)
• If different kinds of files are mixed, set the FILE TYPE
setting in the PICTURE menu to the appropriate setting
for the data to be read (“AUDIO”, “STILL PICTURE” or
“VIDEO”). (See page 34.)
For MP3/WMA files
• The system supports MP3/WMA files recorded with a bit
rate of 32 – 320 kbps and a sampling frequency of 16 kHz,
22.05 kHz, 24 kHz*, 32 kHz, 44.1 kHz, or 48 kHz.
• If the track information (album name, artist, and track
title, etc.) is recorded, it appears in the file control display
on the TV screen. (See page 26.)
• We recommend to record each piece of material (song) at
a sample rate of 44.1 kHz and at a data transfer rate of
128 (96*) kbps.
* For WMA only
For JPEG files
• We recommend to record a file at 640 x 480 resolution. (If
a file has been recorded at a resolution of more than 640 x
480, it will take a longer time to be displayed.)
• This system can only play baseline JPEG files.
For ASF files
• The system supports the types of the advanced simple
profile as MPEG-4 files (MPEG-4 ASF).
• The system supports MPEG-4 files with the following
conditions:
File format: ASF
Visual profile: MPEG-4 SP (Simple Profile)
Audio CODEC: G.726
Max. picture size: 352 x 288 (CIF)
Max. bit rate: 384 kbps
For MPEG-2/MPEG-1 files
• The stream format should conform to MPEG system/
program stream.
• 720 x 576 pixels (25 fps)/720 x 480 pixels (30 fps) is
recommended for the highest resolution.
• This system also supports the resolutions of 352 x 576/
480 x 576/352 x 288 pixels (25 fps) and 352 x 480/480 x
480/352 x 240 pixels (30 fps).
• The file format should be MP@ML (Main Profile at Main
Level)/SP@ML (Simple Profile at Main Level)/MP@LL
(Main Profile at Low Level).
• Audio streams should conform to MPEG1 Audio Layer-2
or MPEG2 Audio Layer-2.
For DivX files
• The system supports DivX 6.x, 5.x, 4.x and 3.11.
• The system supports DivX files whose resolution is 720 x
480 pixels or less (30 fps), and 720 x 576 pixels or less
(25 fps).
• Audio stream should conform to Dolby Digital
(including multi channel) or MPEG1 Audio Layer-3
(MP3).
• The system does not support GMC (Global Motion
Compression).
• The file encoded in the interlaced scanning mode may
not be played back correctly.
• The system has its own Registration Code for DivX
playback.
If necessary, you can confirm the Registration Code of
your system using the OTHERS menu. (See page 35.)
• This product incorporates copyright protection
technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright
protection technology must be authorized by
Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized
by Macrovision. Reverse engineering or disassembly is
prohibited.
• “CONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE
SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE
CONNECTION TO THE ‘STANDARD DEFINITION’
OUTPUT.
IF THERE ARE QUESTIONS REGARDING OUR TV
SET COMPATIBILITY WITH THIS MODEL 525p
AND 625p DVD PLAYER, PLEASE CONTACT OUR
CUSTOMER SERVICE CENTER.”
• USE OF THIS PRODUCT IN ANY MANNER THAT
COMPLIES WITH THE MPEG-4 VISUAL
STANDARD IS PROHIBITED, EXCEPT FOR USE BY
A CONSUMER ENGAGING IN PERSONAL AND
NON-COMMERCIAL ACTIVITIES.
• DivX, DivX Ultra Certified, and associated logos are
trademarks of DivX, Inc. and are used under license.
• Official DivX
• Plays all versions of DivX® video (including DivX® 6)
with enhanced playback of DivX
DivX® Media Format
®
Ultra Certified product
®
media files and the
4
Index of parts and controls
The numbers in the figures indicate the pages where the details of the parts are described.
Front panel (center unit)
Display window
21361822
37
1836
17
14
12
Disc tray (inside): 17
17
Rear panel (center unit)
1830
17
18
17
14
20
15
37
15
12
27
1111
313016
15
Remote sensor: 6
7
12
9, 10
5
Index of parts and controls
Remote controlPutting batteries in the remote control
Insert the batteries into the remote control by matching the
polarity (+ and –) correctly.
31
31
Number
buttons: 19
15
20, 24, 33
18
15, 17
15, 17
17, 37
17, 37
19, 29
27, 28
28, 29
30
30
13, 15, 16,
25, 27, 29,
31, 32, 33
16
14
16
13
13
20
20, 24,
32
16, 20,
33
23
15
15, 36
19, 36
22
19, 25
15
16, 29
13, 15
13, 16
R6P (SUM-3)/AA (15F) type dry-cell batteries
(supplied)
If the range or effectiveness of the remote control decreases,
replace both batteries.
Operating the system from the remote
control
Aim the remote control directly to the front panel of the
center unit.
• Do not block the remote sensor.
6
Connections
Do not connect the power cord until all other connections have been made.
Connecting the FM and AM
antennas
7 AM loop antenna
Setting up supplied AM loop antenna
If the antenna cord is covered with the
insulation coat, twist and pull the
insulation coat off and remove.
Connecting AM loop antenna
If reception is poor
AM loop antenna
(white)
Outdoor single vinyl-covered wire
antenna (not supplied)
7 FM antenna
Center unit
Extend the supplied FM antenna
horizontally.
If reception is poor
Center unit
Center unit
FM antenna (supplied)
White
• Turn the loop antenna until you have the best reception
during AM broadcast program reception.
NOTE
• Make sure the antenna conductors do not touch any other
terminals, connecting cords or power cords. This could cause
poor reception.
Black
Outdoor FM antenna (not
Standard type (75 Ω
coaxial) connector
NOTE
• We recommend that you use coaxial cable for the FM
antenna as it is well-shielded against interference.
supplied)
Outdoor FM antenna cord
(not supplied)
7
Connections
Do not connect the power cord until all other connections have been made.
Connecting the satellite (front, center, surround) speakers and
the subwoofer
7 Assembling the front and surround speakers for
When assembling a speaker without stand:
TH-P7
Front speaker
(SP-THP7F) (2)
• Check the model name of each speaker from the label
on the rear to locate each speaker correctly.
Assembled speakers:
speaker
(SP-THP7S) (2)
Stand (4)Base plate (4)Surround
2
Speaker
A: Use these screws (M4 x
45 mm) when assembling the
speaker with the base plate.
Base plate
Stand (or speaker
directly)*
Screw M4 x 20 mm
(supplied)*
* When assembling the speaker with the base plate,
use the screws
A.
or
With stand: Refer to steps 1
to 3.
Before assembling —
• Prepare a Phillips screwdriver (not supplied).
• Take care not to drop any component part while
assembling; otherwise, it may cause damage to the floor
or personal injury.
Without stand : Refer to steps
2 and 3.
1
Speaker
Stand
Screw M5 x 40 mm
(supplied)
3
Red
Black
You can route the speaker cord
by using speaker cord clamp
(supplied).
Precautions for daily use
• When moving the speakers, do not pull the speaker
cords; otherwise, the speakers may fall over, causing
damage or injury.
• When holding a speaker, always grasp the lower portion.
• Do not lean against the speakers, as the speakers could
fall down or break, possibly causing an injury. Especially
be careful that children do not lean against them.
• Do not reproduce sounds at so high a volume that the
sound is distorted; otherwise, the speakers may be
damaged by internal heat buildup.
White
Black
8
Connections
Do not connect the power cord until all other connections have been made.
7 Connecting speakers for TH-P7
SP-THP7F
Front speakers
SP-THP7S
Surround
speakers
Speaker cord
• Connect the black cords to the black (–) terminals.
• Connect the white cords to the red (+) terminals.
Before connecting
the speaker cords;
Twist and pull the
insulation coat off
and remove.
White
SP-THP7C
Center speaker
Black
CAUTION
• If you connect speakers other than the supplied ones, use
speakers of the same speaker impedance (SPEAKER
IMPEDANCE) indicated on the rear of the center unit.
• DO NOT connect more than one speaker to one speaker
terminal.
9
BlackRed
• When installing the satellite speakers on the wall;
– Be sure to have them installed on the wall by qualified
personnel.
DO NOT install the satellite speakers on the wall by
yourself to avoid unexpected damage from falling off the
wall due to incorrect installation or weakness in wall
structure.
– Care must be taken in selecting a location for speaker
installation on a wall. Injury to personnel or damage to
equipment may result if the speakers installed interfere
with daily activities.
SP-WP7
Subwoofer
Connections
Do not connect the power cord until all other connections have been made.
7 Connecting speakers for TH-P3/TH-G10
SP-THP3F/SP-THG10F
Front speakers
SP-THP3S/SP-THG10S
Surround speakers
Speaker cord
For TH-P3:
• Connect the black cords to the black (–) terminals.
• Connect the white cords to the red (+) terminals.
For TH-G10:
• Connect the black-and-white-dash-lined cords to
the black (–) terminals.
• Connect the black cords to the red (+) terminals.
Before connecting the
speaker cords;
Twist and pull the
insulation coat off and
remove.
SP-THP3C/SP-THG10C
Center speaker
CAUTION
• If you connect speakers other than the supplied ones, use
speakers of the same speaker impedance (SPEAKER
IMPEDANCE) indicated on the rear of the center unit.
• DO NOT connect more than one speaker to one speaker
terminal.
• When installing the satellite speakers on the wall;
– Be sure to have them installed on the wall by qualified
personnel.
DO NOT install the satellite speakers on the wall by
yourself to avoid unexpected damage from falling off the
wall due to incorrect installation or weakness in wall
structure.
– Care must be taken in selecting a location for speaker
installation on a wall. Injury to personnel or damage to
equipment may result if the speakers installed interfere
with daily activities.
SP-WP5/SP-THG10W
Subwoofer
Precautions for daily use
• When moving the speakers, do not pull the speaker
cords; otherwise, the speakers may fall over, causing
damage or injury.
• Do not reproduce sounds at so high a volume that the
sound is distorted; otherwise, the speakers may be
damaged by internal heat buildup.
10
Connections
Do not connect the power cord until all other connections have been made.
Speaker layout
To obtain the best possible sound from this system, you
need to place all the speakers except the subwoofer at the
same distance from the listening position.
Center speaker
Front left
speaker
Surround left
speaker
If your speakers cannot be placed at the same distance
from the listening position
You can adjust the delay time of the speakers. See “Delay
menu (DELAY)” on page 34.
NOTE
• Place the satellite speakers on a flat and level surface.
• The front and center speakers are magnetically shielded to
avoid color distortions on TVs. However, if not installed
properly, they may cause color distortions. So, pay attention
to the following when installing the speakers.
– When placing the speakers near a TV set, turn off the TV’s
main power switch or unplug it before installing the
speakers. Then wait at least 30 minutes before turning on
the TV’s main power switch again.
Some TVs may still be affected even though you have
followed the above. If this happens, move the speakers away
from the TV.
• The surround speakers and the subwoofer are not
magnetically shielded.
If they are located nearby the TV or monitor, it will probably
cause color distortion on the screen. To avoid this, do not
place the speakers nearby the TV or monitor.
• Be sure to place the subwoofer to the TV’s right. If you place
the subwoofer to the TV’s left, keep sufficient distance
between them to prevent the TV screen from appearing
mottled.
Front right
speaker
Subwoofer
Surround right
speaker
Connecting a TV
• You can get better picture quality in the order —
Component video > S-video > Composite video.
• Distortion of picture may occur when connecting the TV
via a VCR, or to a TV with a built-in VCR.
• You need to set “MONITOR TYPE” in the PICTURE
menu correctly according to the aspect ratio of your TV.
(See page 33.)
7 To connect a TV equipped with the component video
input jacks
If your TV supports progressive video input, you can enjoy
a high quality picture by setting the progressive scan mode
to active. (See page 16.)
Center unit
To component
video input
Component video cord (not supplied)
NOTE
• If the component video input jacks of your TV are of the
BNC type, use a plug adapter (not supplied) to convert the
pin plugs to BNC plugs.
• The component video signals can be output only when you
select DVD or USB MEMORY as the source to play. (See
page 15.)
7 To connect a TV equipped with the composite or S-
video jack
Center unit
Composite video cord (supplied)
or
S-video cord
Align the 5
marks.
(not supplied)
To S-video
input
TV
To composite
video input
11
TV
NOTE
• Select the appropriate scan mode according to your TV. (See
page 16.)
• The composite and S-video signals can be output only when
you select DVD or USB MEMORY as the source to pla y. (S ee
page 15.)
Loading...
+ 30 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
