Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
Designs & specifications are subject to change without notice.
Type1-Way Bass-Reflex Type (Magnetically Shielded Type)
Speaker8 cm cone × 1
Power Handling Capacity140 W
Impedance4 Ω
Frequency Range90 Hz to 20 000 Hz
Sound Pressure Level80 dB/W•m
Dimensions (W × H × D)98.5 mm × 214.5 mm × 93.5 mm
Mass1.0 kg each
Type1-Way 2-Speaker Bass-Reflex Type (Magnetically Shielded Type)
Speaker8 cm cone × 2
Power Handling Capacity140 W
Impedance4 Ω
Frequency Range90 Hz to 20 000 Hz
Sound Pressure Level84 dB/W•m
Dimensions (W × H × D)435 mm × 99 mm × 93.5 mm
Mass2.0 kg
Type1-Way Bass-Reflex Type (Magnetically Shielded Type)
Speaker8 cm cone × 1
Power Handling Capacity140 W
Impedance4 Ω
Frequency Range90 Hz to 20 000 Hz
Sound Pressure Level76 dB/W•m
Dimensions (W × H × D)98.5 mm × 214.5 mm × 93.5 mm
Mass0.85 kg each
(No.MB618)1-3
Page 4
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purposes. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be performed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteristics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Service Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety characteristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassembling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isolation check on the exposed metal parts of the product (antenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particularly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ω per volt or more sensitivity
in the following manner. Connect a 1,500Ω 10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
0.15 F AC TYPE
Place this
probe on
1500 10W
Good earth ground
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of preforming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
each exposed
metal part.
1-4 (No.MB618)
Page 5
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(caption)
Anti-static wrist strap
1M
Conductive material
(conductive sheet) or iron palate
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.7 Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
• Apply solder to the short land sections before the card wire is disconnected from the connecto on the servo board. (If the card wire
is disconnected without applying solder, the pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.
Solder short land section
(No.MB618)1-5
Page 6
1.8 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABELS and PRINT
WARNING LABEL and PRINT
1-6 (No.MB618)
Page 7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the METAL COVER (See Fig.1, 2)
(1) Remove the four screws A attaching the METAL COVER.
(See Fig.1)
(2) Remove the one screw B attaching the METAL COVER by
use TORX driver. (See Fig.1)
TROX driver: size T 10
Parts number: DR-L70
(3) Remove the two screws C attaching the both side of MET-
AL COVER. (See Fig.2)
AAB
Fig.1
3.1.2 Removing the REAR PANEL (See Fig.3)
(1) Remove the power cord from POWER BOARD assembly.
(2) Remove the two screws D attaching the TUNER PACK and
then disconnect the card wire from connector CN205
MAIN BOARD assembly.
(3) Remove the three screws E attaching the AMP BOARD as-
sembly.
(4) Remove the one screw F attaching the POWER BOARD
assembly.
(5) Remove the one screw G attaching the HDMI BOARD as-
sembly.
(6) Remove the six screws H attaching the each I/O jack.
(7) Remove the one screw J attaching the REAR PANEL.
of the
C
Fig.2
EGFD
J
H
Fig.3
CN205
(No.MB618)1-7
Page 8
3.1.3 Removing the AMP BOARD assembly (See Fig.4)
(1) Disconnect the connector wire from POWER BOARD as-
sembly connected to connector CN501
BOARD assembly.
(2) Remove the two screws K attaching the HEAT SINK
BRACKET.
(3) Remove the three screws L attaching the AMP BOARD as-
sembly.
(4) Disconnect the CONNECTION BOARD assembly con-
nected connector CN504
3.1.4 Removing the DVD MECHANISM assembly (See Fig.5)
(1) Disconnect the connector wire from MAIN BOARD assem-
bly connected to connector CN811
sembly.
(2) Disconnect the card wires from DVD BOARD assembly
connected to connector CN201
MAIN BOARD assembly.
(3) Disconnect the card wire from DVD MECHANISM assem-
bly connected to connector CN212
assembly.
(4) Remove the one screw M attaching the DVD MECHANISM
assembly.
of the AMP BOARD assembly.
of the DVD BOARD as-
, CN202 and CN204 of the
of the AMP
of the MAIN BOARD
KL
M
Fig.4
CN811
CN504CN501
CN202
1-8 (No.MB618)
CN212
CN201
Fig.5
CN204
Page 9
3.1.5 Removing the FRONT PANEL assembly (See Fig.6 to 8)
(1) Disconnect the card wire from FRONT PANEL assembly
connected to connector CN211
sembly. (See Fig.6)
(2) Remove the one screw N attaching the EARTH WIRE from
FRONT PANEL assembly. (See Fig.6)
(3) Remove the one screw P attaching the EARTH WIRE from
USB BOARD assembly. (See Fig.6)
(4) Remove the three screws Q attaching the FRONT PANEL
assembly. (See Fig.7).
(5) Disengage hook a of bottom side and two hooks b of the
both side of FRONT PANEL assembly. (See Fig.7, 8)
of the MAIN BOARD as-
CN211
NP
Fig.6
Q
hook b
hook a
Fig.7
Fig.8
(No.MB618)1-9
Page 10
3.1.6 Removing the iPod BOARD assembly (See Fig.9)
(1) Disconnect the card wire from iPod BOARD assembly con-
nected to connector CN210
bly.
of the MAIN BOARD assem-
CN210
Fig.9
1-10 (No.MB618)
Page 11
3.1.7 Removing the POWER BOARD assembly (See Fig.10 to 12)
(1) Disconnect the connector wire from POWER BOARD as-
sembly connected to connector CN151
BOARD assembly. (See Fig.10)
(2) Disconnect the connector wires from POWER TRANS-
FORMER connected to connector CN102
the POWER BOARD assembly. (See Fig.11)
(3) Remove the one screw R attaching the POWER BOARD
assembly. (See Fig.11)
(4) Remove the two screws S attaching the POWER BOARD
assembly. (See Fig.12)
(5) Disconnect the connector wire from POWER TRANS-
FORMER connected to connector CN104
BOARD assembly. (See Fig.11)
of the MAIN
and CN103 of
of the POWER
CN151
Fig.10
CN104
CN103
R
Fig.11
CN102
S
Fig.12
(No.MB618)1-11
Page 12
3.1.8 Removing the MAIN BOARD assembly (See Fig.13)
(1) Disconnect the connector wire from Fan connected to con-
nector CN152
(2) Remove the four screws T attaching the MAIN BOARD as-
sembly.
3.1.9 Removing the USB BOARD assembly (See Fig.14)
(1) Remove the two screws U attaching the USB BOARD as-
sembly.
of the MAIN BOARD assembly.
CN152
T
Fig.13
1-12 (No.MB618)
U
Fig.14
Page 13
3.1.10 Removing the VFD BOARD assembly (See Fig.15, 16)
(1) Remove the two screws V attaching the BRACKET
BOARD. (See Fig.15)
(2) Remove the two screws W attaching the HEAD PHONE
BOARD assembly. (See Fig.15)
(3) Disconnect the card wire from TOUCH BOARD assembly
connected to connector CN601
bly. (See Fig.16)
(4) Remove the two screws X attaching the LED BOARD as-
sembly. (See Fig.16)
(5) Remove the ten screws Y attaching the VFD BOARD as-
sembly. (See Fig.16)
3.1.11 Removing the TOUCH BOARD assembly (See Fig.17)
(1) Remove the three screws Z attaching the TOUCH BOARD
assembly.
of the VFD BOARD assem-
VW
Fig.15
CN601
YX
Fig.16
Z
Fig.17
(No.MB618)1-13
Page 14
3.2 DVD mechanism
3.2.1 Removing the traverse mechanism
(See Fig.1 to 6)
(1) Remove the two screws A attaching the tramecha holder
from top side of DVD mechanism assembly. (See Fig.1)
(2) Remove the two screws B attaching the DVD module
board. (See Fig.2)
(3) Remove the four screws C attaching the CB holder and
take out it. (See Fig.3)
(4) Remove the four screws D attaching the traverse mecha-
nism. (See Fig.4)
(5) Solder the solder part of DVD pick up. (See Fig.5)
(6) Disconnect the card wire from CN101
DVD module board. (See Fig. 6)
Caution:
• Solder the short land section on the DVD pickup before dis-
connecting the card wire from the connector on the DVD
pickup. If the card wire is disconnected without attaching solders, the pickup may be destroyed by static electricity.
• When attaching the DVD pickup, be sure to remove solders
from the short land section after connecting the card wire to
the connector on the DVD pickup.
and CN201 on the
A
Clamper base
B
A
DVD mechanism assembly
Fig.1
DVD mechanism assembly
B
1-14 (No.MB618)
DVD module board
Fig.2
Page 15
DVD module board
DVD module board
CN101
CN201
C
C
CC
Fig.3
DVD mechanism assembly
Traverse mechanism assembly
Fig.6
DD
Fig.4
Solder short land section
Fig.5
(No.MB618)1-15
Page 16
3.2.2 Removing the pickup assembly
(See Fig.7 to 11)
(1) Remove the two rod springs pressing the guide shaft. (See
Fig.7)
(2) Remove the screw E and F attaching the spring holder.
(See Fig.8)
(3) Remove the read screw from traverse mechanism assem-
bly. (See Fig.9)
Caution:
When remove the lead screw, do not loss the middle
gear. (See Fig.10 and 11)
(4) Remove the bar spring pressing the shaft. (See Fig.10)
(5) Take out the pickup assembly from traverse mechanism
chassis by order. (See Fig.11)
(SHAFT)
(T.TABLE)
HOOK
(BAR SPRING)
Fig.10
ROD SPRINGROD SPRING
Fig.7
Spring holder
Fig.8
order 2
order 3
order 1
Fig.11
EF
Middle gear
1-16 (No.MB618)
Lead screw
Fig.9
Page 17
3.2.3 Removing the feed motor assembly
(See Fig.12)
(1) Remove the one screw G attaching the feed motor assem-
bly.
(2) Remove the feed motor wires from solder part of spindle
motor board.
Splder part
3.2.4 Removing the spindle motor assembly
(See Fig.13)
(1) Remove the three screws H attaching the spindle motor
from spindle motor board.
Middle gear
Lead screw
Fig.12
H
Spindle motor
Fig.13
G
(No.MB618)1-17
Page 18
3.2.5 Removing the tray assembly
(See Fig.14 & 15)
(1) Remove the two screws J attaching the clamper base.
(See Fig.14)
(2) Remove the one screw K attaching the shaft guide from
bottom side. (See Fig.14)
(3) Remove the two screws L attaching the shaft guide from
top side. (See Fig.15)
Caution:
When attach the tray assembly, boss of loading sub assembly
should attach to guide of bottom side at tray assembly. (See
Fig.15)
J
order 1
order 2
clamper base
L
K
Fig.15
[bottom side]
Fig.14
1-18 (No.MB618)
Page 19
SECTION 4
ADJUSTMENT
4.1 ATTENTION IN SERVICE OF DVD SECTION
(1) When pickup, Flash ROM ,DVD module board were changed, initialize EEPROM by all means.
(2) When full initialization was executed, execute learning with a DVD test disc by all means.
Test disc : VT-501, VT-502
Learning method : It is adjusted automatically by normal playback of a DVD disc.
4.2 DVD TEST MODE
4.2.1 Content of correspondence TEST MODE
(1) Version, Region, Learning status check mode
(2) NORMAL initialize, FULL initialize
(3) Device key write(CPPM, CPRM)
(4) Device key checksum indication mode
(5) Micon version indication mode
(6) FL all on mode
(7) FRONT END check mode
4.2.2 Mode transition
TEST MODE into the press [SOURC key] and [POWER key] together of main body, connect the AC power.
After into the TEST MODE, mode select by [MENU key].
SOURCE+POWER+AC
Version, Region, Learning
status indication mode
F.SKIP key 4sec
FULL
initialize
long press
SOURCE keyB.SKIP
NORMAL
initialize
MENU key
Device key
write
MENU key
MENU keyMENU keyMENU key
Device key
checksum
mode
Micon version
indication mode
MENU key
FL all on
mode
FRONT END
check mode
4.2.3 Processing details
The communication of operated FL(LCD) display and DVD back end microcomputer is shown as follows.
*It is assumed to be OK to differ from the content of the specification because the number of digits is different according to the set for
the FL(LCD) display.
*It is assumed to be OK to differ from the content of the specification because it also has the relation between arrangement and presence by the set also for the key.
STEPOperationMovementRemarks
1
AC is pulled out, and
double press [SOURCE]
and [POWER] key of the
main body
2Keep step 1, connect AC
Version, Region, Learning
status indication mode
Power on by test mode,
version indication to FL
FL(LCD)indication
132465798
T
JC#
10121113
Version indication
The display to the version code is as
follows.
0x01:JC 0x02:1U 0x03:D 0x04:E
0x05:2U 0x06:3U 0x07:UB 0x08:UT
0x09:4U 0x0a:UY 0x0b:EE 0x0c:UF
Region indication (# part)
Learning from the back end is displayed
in the 11th digit and the 12th digit
of the FL display.
Blank indication at 0xFF
Study status (11th column)
0x07: BCA CHECK OK incomplete
DVD learning incomplete
CD learning incomplete (indication 7)
0x06: BCA CHECK OK incomplete
DVD learning complete
CD learning incomplete (indication 6)
0x05: BCA CHECK OK incomplete
DVD learning incomplete
CD learning complete (indication 5)
(No.MB618)1-19
Page 20
STEPOperationMovementRemarks
132465798
FL(LCD)indication
10121113
0x04: BCA CHECK OK incomplete
DVD learning complete
CD leaning complete (indication 4)
0x03: BCA CHECK OK complete
DVD learning incomplete
CD learning incomplete (indication 3)
0x02: BCA CHECK OK complete
DVD learning complete
CD learning incomplete (indication 2)
0x01: BCA CHECK OK complete
DVD learning incomplete
CD learning complete (indication 1)
0x00: BCA CHECK OK complete
DVD learning complete
CD learning complete (indication 0)
(BCA READ CHECK result is only BCA
READ OK, it to complete)
Initialization status (12th column)
0X03: FULL initialize complete
(indication 3)
0x00: NORMAL initialize complete
(indication 0)
0xFF: Initialize incomplete
(blank indication)
Press a [SOURCE] key
of the main body.
NORMAL initialize
Continue pressing a
[F.SKIP] key of the main
body.(4sec)
FULL initialize
3
Press a [MENU] key of
the remote controller.
Press a [MENU] key of
the remote controller.
4Press a [MENU] key of
the remote controller.
5FL all on mode
Press a [MENU] key of
the remote controller.
6
Press a [MENU] key of
the remote controller.
Press a [1] key of the 10
key on remote controller
Press a [2] key of the 10
key on remote controller
Press a [3] key of the 10
key on remote controller
DEVICE CHECKSUM
indication mode
Indicate the CHECKSUM
of the Device key to FL
(4 byte)
Micon version indication
mode
Indicate the version to FL
All FL and all LED to ON
FRONT END check mode
Indicate the front end check
mode to FL
Disc startup and through
playback
(Playback starts from the
start position)
Presence of WOBBLE
0:WOBBLE_NO_CHECK
(un check)
1:WOBBLE_PRESS_MEDIA
(press)
2:WOBBLE_MINUS_MEDIA
(DVD-R/-RW media)
3:WOBBLE_PLUS_MEDIA
(DVD+R/+RW media)
Port check mode
(TRACK,INDEX,DEMP,
COPY)
1:INDEX Port = High
2:TRACK Port = High
3:COPY Port = High
4:DEMP Port = High
JC#T
JC#
T
bbcccac
CEHCK
CEHCK
The AVC protocol is returned from
high speed to normal speed.
(Return it to the normal mode when
coming off the TEST mode. )
Indicate CHECKSUM to FL
,,,
,,,
bb : Syscon Version
a : Syscon Romcorr Version
cccc: DVD Back end Version
Upper : 0
Lower : WOBBLE detection result
Upper : 0x01-0x04(check port number)
Lower : 0
,,,
: CPPM
: CPRM
: HDCP
1-20 (No.MB618)
Page 21
STEPOperationMovementRemarks
Press a [4] key of the 10
key on remote controller
Press a [5] key of the 10
key on remote controller
Press a [6] key of the 10
key on remote controller
Press a [8] key of the 10
key on remote controller
Press a [9] key of the 10
key on remote controller
Press a [10] key of the 10
key on remote controller
Press a [0] key of the 10
key on remote controller
Press a [ 10] key of the
10key on remote controller
Press a [STOP] key of
the main body or remote
controller
Press a [OPEN/CLOSE]
key of the main body or
remote controller
Press a [PLAY] key of
the main body or remote
controller
Press a [MENU] key of
7
the remote controller
Press a [POWER] key of
the main body
*1 Mode toggle done by press [MENU] key.
*2 STEP3 are only for DVD-AUDIO or VR correspondence model.
CD_LD lights and laser
current is displayed
DVD_LD lights and laser
current is displayed
DVD_SL x1 jitter
measurement mode
Content of BACKUP
memory(0x00-0x63)
indication (FWD)
Temperature sensor
(AD value) indication
DVD-DL(parallel,opposite)
Search & jitter
measurement of the
specified position of
DVD-SL
Upper : Laser current value
(BACKUP value,Real measured value)
Lower : 0
Upper : Laser current value
(BACKUP value,Real measured value)
Lower : 0
Upper : Laser current value
(BACKUP value,Real measured value)
Lower : Real measured value
Upper Byte1 : Display option
0x00 : BACKUP area
0xFF : permanent area
Upper Byte2 : BACKUP memory address
(0x00-0x63)
Lower : Content of BACKUP memory
Upper : 0
Lower : Temperature sensor value
Upper : 0x00-0x06(measure at VT501)
Lower : Jitter value
Upper : 0x00-0x0C
Lower : 0
Upper:Laser current value
(BACKUP value, Real measured value)
Lower:Jitter value
Release at each step
(No.MB618)1-21
Page 22
4.3 KEY special mode
MODE NAMEOPERATIONSTATUSFUNCTION
TUNER 9K/10kHz
select (U ver)
P. O F F
P. O F F
TRAY LOCK
DVD TEST mode
XM Diagnostic mode
P. O F F
AC off
P.OFF at XM
4.4 REMOCON KEY special mode
Change to 9kHz step by
press and hold [+] key,
then press [|<<] key.
Change to 10kHz step by
press and hold [+] key,
then press [>>|] key.
Press and hold [+] key,
then press [EJECT] key
Press and hold
[SOURCE] and [POWER]
key, and connecto to AC.
Press and hold [-] key,
and press [POWER] key
TUNER AM 9kHz/10kHz step select.
Indicate "9k STEP", "10k STEP".
Do the TRAY LOCK mode select. Done the tempolary
P.ON process, select the "LOCKED" and "UNLOCKED"
(Do no done the P.ON process).
Ended the transitory display (2 seconds) return to
P.OFF mode.‘
When press the [EJECT] key at LOCK mode, at P.OFF
status do templary P.ON process then the transitory display
(2 seconds) the "LOCKED", at P.ON status do the transitory
display (2 seconds) the "LOCKED".
DVD backend started by TEST mode.
Internal TEST mode process is refer the spec.
Into the XM Diagnostic mode.
MODE NAMEOPERATIONCODEFUNCTION
COLD START
[STOP] +
[POWER] + [0]
2 times input at P.OFF
When Fix by 2 times input, do the templary P.ON process
then indicate "COLD SET" by transitory (2 seconds).
Ended the indication, change to P.OFF mode.
FL all ON
Write the preset
frequency
[STOP] +
[POWER] + [1]
Input at P.ON
Write the preset frequency, LED all on check (each 300ms),
FL all on
LED on order : STANDBY -> ILLUMI ->
Volume control by [VOL+] and [VOL-] key of the remote
controller, it should high speed mode until next POWER OFF.
Version indication
[STOP] +
[POWER] + [10]
Input at P.ON
Syscon version indication -> Unit version indication
-> destination -> Chip select transitory indication (5 seconds).
Syscon version: "SC ## $$"
(## : Syscon version, $ : Syscon romcollection)
Unit version: "BE %%%%" (%%%% : Unit version)
Destination, Chip select: "$$ %% KX"
($$ : Syscon destination, %% : "D4" or "D5" or "D6" or "D7"
or "D8", K : KARAOKE, X : XM READY)
XM TEST MODE
[STOP] +
[POWER] + [5]
Input at XM SOURCE
XM ready test mode
TEST TONE (L/R 1 kHz) output
1-22 (No.MB618)
Page 23
4.5 TH-D SPECIAL MODE Ver 0.2
POWEREJECTB.SKIPF.SKIPSOURCE
MODEOPERATIONSET STATUSKEY1
DVD TEST MODE
TRAY LOCK
TUNE 9K
TUNE 10K
NORMAL INITIALIZE
FULL INITIALIZE
This service manual does not describe TROUBLESHOOTING.
AC OFFSOURCE
STANDBY
STANDBY
STANDBY
TEST MODE
TEST MODE
Press and keep [+] key
Press and keep [+] key
Press and keep [+] key
SOURCE
F.SKIP
SECTION 5
TROUBLESHOOTING
KEY2
POWER
EJECT
B.SKIP
F.SKIP
+
AC IN
Press
Press 4 seconds.
(No.MB618)1-23
Page 24
Victor company of Japan, Limited
Audio/Video Systems category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(No.MB618)
Printed in Japan
VPT
Page 25
PARTS LIST
TH-D5B,TH-D5E,TH-D5EN
TH-D5EV
* All printed circuit boards and its assemblies are not available as service parts.
MB618
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
DVD mechanism assembly and parts list (Block No.MJ)
DVD loading base assembly and parts list (Block No.MN)
Electrical parts list (Block No.01~05)
Packing materials and accessories parts list (Block No.M3)
3- 2
3- 6
3- 8
3-10
3-20
3-1
Page 26
Exploded view of general assembly and parts list
D
2
Block No.
M
M
1
M
67
USB board
4
64
b
63
39
65
66
43
75
27
c
m
74
G
23
73
65
43
43
D
b
72
C
25
12
12
p
VFD board
12
f
28
87
c
30
12
12
d
12
t
76
89
e
37
61
A
LED board
8
12
67
8
86
12
9
u
11
11
88
5
p
11
u
85
77
Touch board
12
13
12
jj
1
10
3
15
12
11
F
12
32
6
7
2
t
Head phone board
iPod board
d
38
15
26
27
B
3-2
Page 27
M
12
p
D board
32
58
57
55
59
27
ss
31
69
27
71
G
62
a
79
56
27
m
G
23
73
24
70
s
33
j
24
b
72
f
C
25
22
k
28
31
28
v
25
B
AMP board
a
Main board
18
k
41
12
87
30
12
28
89
f
m
n
x
y
c
e
89
89
j
z
42
52
46 47 54
48
49
53
50
45
51
ss
44
60
34
78
E
25
59
29
jj
19
h
89
82
81
16
35
s
Power board
r
41
68
28
r
40
d
12
t
76
37
D
27
61
40
27
g
83
17
E
27
40
C
d
20
84
h
21
38
27
e
B
g
14
15
A
F
The parts without symbol number are not service.
61
15
90
80
36
35
3-3
Page 28
General Assembly
Symbol No.Part No.Part NameDescriptionLocal
1GN10122-003AFRONT PANEL1A
2GN10123-018AARNAMENT
3GN20231-001APUSH BUTTON
4GN20233-005AWINDOW SCREEN
5LV42851-012AFL SCREEN
6GN30223-003ALENS
7LV30227-0A7ASPACER
8QYSDSF2608ZATAP SCREWM2.6 x 8mm(x2)
9GN40140-001ALENS(DVD)
10GN40152-001ASENSOR SPACER
11QYSDSF2608ZATAP SCREWM2.6 x 8mm(x4)
12QYSDSF2608ZATAP SCREWM2.6 x 8mm(x15)
13QYSDSG2606EATAP SCREWM2.6 x 6mm(x3)
14GN10124-003ABOTTOM CHASSI
15LV40301-002AFELT SPACER(x4)
16GN20234-201AHEAT SINK
17LV30227-0A1ASPACER(x2)
18GN20235-002ABRACKET(IC)
19GN20236-001ABRACKET(H.SINK)
20GN30224-001ABRACKET(POWER)
21GN30228-002APOWER BRACKT
22GN30225-201ABRACKET(FAN)
23GV30349-025ASPACER
24LV30226-037ASPACER(x2)
25GV30349-025ASPACER(x3)
26QYSDSG3008ZATAP SCREWM3 x 8mm(x3)
27LV43451-002ASPECIAL SCREW(x10)
28QYSDSG3006EATAP SCREWM3 x 6mm(x5)
29QYSBSG3010EATAP SCREWM3 x 10mm(x2)
30GV30349-025ASPACER
31QYSBSG3020ZATAP SCREWM3 x 20mm(x3)
32QYSDSG3008ZATAP SCREWM3 x 8mm
33QYSBSG3030ZATAP SCREWM3 x 30mm(x2)
34QYSBSG3010ZATAP SCREWM3 x 10mm(x3)
35QYSDSG3008ZATAP SCREWM3 x 8mm(x2)
36QYWBS326505ZAWASHER6.5mm/3.2mm x 0.5mm
37GN40145-001ABRACKET(x2)
38GN40146-001ABRACKET
39QYSBSG3016EATAP SCREWM3 x 16mm
40LV44937-001ASPACER(x4)
41QYSDSTL4008EATAP SCREWM4 x 8mm(x4)
42LV30227-092ASPACER
43VYSH101-009SPACER(x3)
44GN20237-027AREAR PANEL
45QYSBSGY3008EATAP SCREWM3 x 8mm
46QYSBSGY3008EATAP SCREWM3 x 8mm
47QYSBSGY3008EATAP SCREWM3 x 8mm
48QYSBSGY3008EATAP SCREWM3 x 8mm
49QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
50QYSBSGY3008EATAP SCREWM3 x 8mm
51QYSBSGY3008EATAP SCREWM3 x 8mm
52QYSBST3006EATAP SCREWM3 x 6mm
53QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
54QYSBSGY3008EATAP SCREWM3 x 8mm
55QYSBSGY3008EATAP SCREWM3 x 8mm(x2)
1LV22234-001ATM.CHASSIS
2LV22235-001ASPINDLE BASE
3QYSDST2005ZATAP SCREWM2 x 5mm(x2)
4LV36555-001AG.S.HOLDER
5QYSDST2005ZATAP SCREWM2 x 5mm
6LV44041-002AGUIDE SHAFT
7LV44479-001ABAR SPRING
8LV22236-001AFEED HOLDER
9QAR0165-001FEED MOTOR5.0V DC
10LV30225-0X5ASPACER(x2)
11LV36557-001AF.M.GEAR
12QYSPSPT2030MASCREWM2 x 3mm
13QYSDST2005ZATAP SCREWM2 x 5mm
14QAL0786-004P.UP
15LV22237-001ARACK ARM
16LV36560-001ARACK ARM SPRING
17QYSPSFU1740ZATAP SCREWM1.7 x 4mm(x2)
18QUQK05-2420AC-EFFC WIRE24pin 20cm
20LV44041-002AGUIDE SHAFT
21LV36559-001AL.S.GEAR
22LV41517-003ALEAD SCREW
23LV36558-001AMIDDLE GEAR
24LV36556-001ASPRING HOLDER
25LV44623-001ACOMP.SPRING
26QYSDST2005ZATAP SCREWM2 x 5mm
27QYSDST2616MATAP SCREWM2.6 x 16mm
28QAR0387-001S.MOTOR
29QYSPSPU1775ZASCREWM1.7 x 7.5mm(x3)
30LV44042-001AROD SPRING(x2)
31LV44046-001AADJUST SCREW(x4)
Block No. [M][J][M][M]
3-7
Page 32
DVD loading base assembly and parts list
Grease
JVS-1003
CFD-4007ZY2
21
20
19
16
h
FMU-MB5-1M
33
15
M
N
M
Block No.
M
2
3
14
12
1
h
< Back side >
13
DVD loading switch board
f
16
18
j
11
9
10
0.10mm
4
7
8
6
7.75mm
< In side >
Backside
5
j
d
c
DVD module board
32
31
32
3-8
24
23
g
e
A
24
B
23
26
A
k
B
24
22
23
30
c
k
27
29
25
24
f
d
30
23
g
e
The parts without symbol number are not service.
Page 33
DVD loading base
Symbol No.Part No.Part NameDescriptionLocal
1LV11065-010ALOADER SUB ASSY
2E407140-001SSC.D ROLLER
3E407149-001SSRUBBER TUBE
4LV10979-003ATRAY
5LV35499-003ASHAFT GUIDE
6LV44022-001ASHAFT
7QYSSSF2008ZATAP SCREWM2 x 8mm
8QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
9LV41741-004ASPECIAL SCREW
10QAR0197-001MOTOR2.0V DC
10orQAR0450-001MOTOR
11LV43844-002AMOTOR PULLEY
12QYSPSPU1730ZASCREWM1.7 x 3mm(x2)
13QYSDSF2008ZATAP SCREWM2 x 8mm
14LV43974-001ABELT
15LV21852-003ACLAMPER BASE
16QYSDSF2008ZATAP SCREWM2 x 8mm(x2)
18LV35056-002ADVD CLAMPER
19LV42930-003AP.C.MAGNET
19orLV41118-003AMAGNET
20LV43848-001AYOKE
21LE40906-002ASPECIAL SCREW
22FXL-D10-11MSINGLE DVD TRAM
23LV44043-001AINSULATOR(x4)
24LV44044-001ASPECIAL SCREW(x4)
25LV44007-001ATAPE
26LV44007-003ATAPE
27GN30226-001AHDMI BRACKET A
29GN20232-002AFITTING
30QYSBSF2608ZATAP SCREWM2.6 x 8mm(x3)
31QYSBSFG2606ZATAP SCREWM2.6 x 6mm
32GV30349-025ASPACER(x2)
33LV44603-003ALASER CAUTION
Block No. [M][N][M][M]
3-9
Page 34
Electrical parts list
Main board
Block No. [0][1]
Symbol No.
IC161PQ1CG21H2FZICRegulator
IC162KIA7806APIIC
IC181KIA7810APIIC
IC211MN101C49GAL1MASK ROM
IC212TC74VHCT08AFT-XIC(DIGITAL)
IC241BR24L08F-W-XIC(DIGITAL)
C1501QETM1EM-828E CAPACITOR8200uF 25V M
C1612NCB31CK-104XC CAPACITOR0.1uF 16V K
C1613QEZ0654-477ZE CAPACITOR470uF 10V M
C1614NCB31CK-104XC CAPACITOR0.1uF 16V K
C1621NCB31CK-104XC CAPACITOR0.1uF 16V K
C1622QETN1CM-107ZE CAPACITOR100uF 16V M
C1623NCB31CK-104XC CAPACITOR0.1uF 16V K
C1624QETN1AM-477ZE CAPACITOR470uF 10V M
C1701QETN1HM-106ZE CAPACITOR10uF 50V M
C1702QETN1CM-107ZE CAPACITOR100uF 16V M
C1801NCB31CK-104XC CAPACITOR0.1uF 16V K
C1802QETN1CM-107ZE CAPACITOR100uF 16V M
C1803NCB31CK-104XC CAPACITOR0.1uF 16V K
C1804QETN1EM-107ZE CAPACITOR100uF 25V M
C1901QETN1CM-107ZE CAPACITOR100uF 16V M
C1902QETN1EM-476ZE CAPACITOR47uF 25V M
C2101NDC31HJ-220XC CAPACITOR22pF 50V J
C2102NDC31HJ-220XC CAPACITOR22pF 50V J
C2103NCB31CK-104XC CAPACITOR0.1uF 16V K
C2104NCB31CK-104XC CAPACITOR0.1uF 16V K
C2105NCB31CK-104XC CAPACITOR0.1uF 16V K
C2201QETN1AM-108ZE CAPACITOR1000uF 10V M
C2301QETN1HM-106ZE CAPACITOR10uF 50V M
C2302QETN1CM-226ZE CAPACITOR22uF 16V M
C2303NCB31HK-102XC CAPACITOR1000pF 50V K
C2401QETN1CM-107ZE CAPACITOR100uF 16V M
C2402NCF31HZ-103XC CAPACITOR0.01uF 50V Z
C2601NCB31CK-104XC CAPACITOR0.1uF 16V K
C2602NCB31CK-104XC CAPACITOR0.1uF 16V K
C2603QETN1EM-107ZE CAPACITOR100uF 25V M
C2701QETN1HM-226ZE CAPACITOR22uF 50V M
C2702QETN1CM-107ZE CAPACITOR100uF 16V M
C2703QETN1EM-476ZE CAPACITOR47uF 25V M
C2801NCB31HK-272XC CAPACITOR2700pF 50V K
C2802NCB31HK-272XC CAPACITOR2700pF 50V K
C2803NCB31HK-272XC CAPACITOR2700pF 50V K
C2804NCB31HK-272XC CAPACITOR2700pF 50V K
C2805NCB31HK-272XC CAPACITOR2700pF 50V K
C2901QETN1AM-227ZE CAPACITOR220uF 10V M
C2902NCF31AZ-105XC CAPACITOR1uF 10V Z
C2903NDC31HJ-471XC CAPACITOR470pF 50V J
C2904NCF31AZ-105XC CAPACITOR1uF 10V Z
C3001QETN1HM-106ZE CAPACITOR10uF 50V M
C3002QETN1AM-227ZE CAPACITOR220uF 10V M
C3003QETN1AM-227ZE CAPACITOR220uF 10V M
C3004NDC31HJ-560XC CAPACITOR56pF 50V J
C3005NDC31HJ-560XC CAPACITOR56pF 50V J
C3006NCB31CK-104XC CAPACITOR0.1uF 16V K
C3007QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3008QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3201NCB31CK-393XC CAPACITOR0.039uF 16V K
C3202NCB31CK-393XC CAPACITOR0.039uF 16V K
C3203NCF31CZ-224XC CAPACITOR0.22uF 16V Z
C3204NCF31CZ-224XC CAPACITOR0.22uF 16V Z
C3205QETN1HM-475ZE CAPACITOR4.7uF 50V M
Part No.Part NameDescriptionLocal
3-10
Page 35
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C3206QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3207QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3208QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3209QETN1EM-476ZE CAPACITOR47uF 25V M
C3210NCB31CK-104XC CAPACITOR0.1uF 16V K
C3211QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3212QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3213QETN1HM-106ZE CAPACITOR10uF 50V M
C3214QETN1HM-106ZE CAPACITOR10uF 50V M
C3215NCB31EK-153XC CAPACITOR0.015uF 25V K
C3216QETN1CM-107ZE CAPACITOR100uF 16V M
C3219QTE1H46-475ZE CAPACITOR4.7uF 50V
C3220QTE1H46-475ZE CAPACITOR4.7uF 50V
C3221NCF31CZ-224XC CAPACITOR0.22uF 16V Z
C3222NCF31CZ-224XC CAPACITOR0.22uF 16V Z
C3223NCF31CZ-224XC CAPACITOR0.22uF 16V Z
C3224QTE1H46-475ZE CAPACITOR4.7uF 50V
C3225NCF31HZ-473XC CAPACITOR0.047uF 50V Z
C3226NCF31HZ-473XC CAPACITOR0.047uF 50V Z
C3227QFV61HJ-473ZMF CAPACITOR0.047uF 50V J
C3227 or QFV91HJ-473ZMF CAPACITOR0.047uF 50V J
C3228QFV61HJ-154ZMF CAPACITOR0.15uF 50V J
C3228 or QFV91HJ-154ZMF CAPACITOR0.15uF 50V J
C3229QFV61HJ-473ZMF CAPACITOR0.047uF 50V J
C3229 or QFV91HJ-473ZMF CAPACITOR0.047uF 50V J
C3230QFV61HJ-154ZMF CAPACITOR0.15uF 50V J
C3230 or QFV91HJ-154ZMF CAPACITOR0.15uF 50V J
C3231QFV61HJ-223ZMF CAPACITOR0.022uF 50V J
C3231 or QFV91HJ-223ZMF CAPACITOR0.022uF 50V J
C3232QFV61HJ-223ZMF CAPACITOR0.022uF 50V J
C3232 or QFV91HJ-223ZMF CAPACITOR0.022uF 50V J
C3233QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3234QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3301QETN1HM-225ZE CAPACITOR2.2uF 50V M
C3302NCB31CK-473XC CAPACITOR0.047uF 16V K
C3303QETN1HM-226ZE CAPACITOR22uF 50V M
C3304NCB31CK-473XC CAPACITOR0.047uF 16V K
C3305QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3306QTE1E46-476ZE CAPACITOR47uF 25V
C3307NCB31CK-105XC CAPACITOR1uF 16V K
C3401QETN1EM-476ZE CAPACITOR47uF 25V M
C3501QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3502QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3503QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3504QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3505QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3506QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3531QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3532QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3535QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3536QETN1CM-107ZE CAPACITOR100uF 16V M
C3541QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3544QETN1HM-475ZE CAPACITOR4.7uF 50V M
C3545QETN1CM-107ZE CAPACITOR100uF 16V M
C3551QETN1EM-476ZE CAPACITOR47uF 25V M
C3552NCB31CK-104XC CAPACITOR0.1uF 16V K
C3603NCF31CZ-104XC CAPACITOR0.1uF 16V Z
C4001NCB30JK-105XC CAPACITOR1uF 6.3V K
C4002NCB30JK-105XC CAPACITOR1uF 6.3V K
C4101QETN1EM-476ZE CAPACITOR47uF 25V M
C4102NCB31HK-103XC CAPACITOR0.01uF 50V K
C4103NCB31HK-103XC CAPACITOR0.01uF 50V K
C4105NCB30JK-105XC CAPACITOR1uF 6.3V K
C4106NCB30JK-105XC CAPACITOR1uF 6.3V K
C4107NCB31HK-103XC CAPACITOR0.01uF 50V K
C4108NDC31HJ-390XC CAPACITOR39pF 50V J
C4109NDC31HJ-390XC CAPACITOR39pF 50V J
C4110NDC31HJ-390XC CAPACITOR39pF 50V J
C4111NDC31HJ-390XC CAPACITOR39pF 50V J
C4112NDC31HJ-390XC CAPACITOR39pF 50V J
C4113NDC31HJ-390XC CAPACITOR39pF 50V J
C4114NDC31HJ-390XC CAPACITOR39pF 50V J
C4115NDC31HJ-390XC CAPACITOR39pF 50V J
C4201QETN1AM-477ZE CAPACITOR470uF 10V M
C4202NCB31CK-104XC CAPACITOR0.1uF 16V K
C4203NCB31HK-103XC CAPACITOR0.01uF 50V K
C4204NCB30JK-105XC CAPACITOR1uF 6.3V K
C4205NCB30JK-105XC CAPACITOR1uF 6.3V K
C4206QETN1CM-226ZE CAPACITOR22uF 16V M
C4207NCB30JK-105XC CAPACITOR1uF 6.3V K
C4208NCB30JK-105XC CAPACITOR1uF 6.3V K
C4209NCB30JK-105XC CAPACITOR1uF 6.3V K
C4210QETN1AM-477ZE CAPACITOR470uF 10V M
C4211QETN1AM-477ZE CAPACITOR470uF 10V M
C4212QETN0JM-108ZE CAPACITOR1000uF 6.3V M
C4213NCB31CK-104XC CAPACITOR0.1uF 16V K
C4301NDC31HJ-470XC CAPACITOR47pF 50V J
C4302NDC31HJ-470XC CAPACITOR47pF 50V J
C4303NDC31HJ-470XC CAPACITOR47pF 50V J
C4308QETN1AM-477ZE CAPACITOR470uF 10V M
C4310NCB30JK-105XC CAPACITOR1uF 6.3V K
C4311NCB31HK-103XC CAPACITOR0.01uF 50V K
C4312NDC31HJ-470XC CAPACITOR47pF 50V J
C4313NDC31HJ-470XC CAPACITOR47pF 50V J
C4314NCB30JK-105XC CAPACITOR1uF 6.3V K
C4315NDC31HJ-470XC CAPACITOR47pF 50V J
C4401QETN1HM-475ZE CAPACITOR4.7uF 50V M
C4402NCB31HK-331XC CAPACITOR330pF 50V K
C4411QETN1HM-475ZE CAPACITOR4.7uF 50V M
C4412NCB31HK-331XC CAPACITOR330pF 50V K
C4501QETN1HM-475ZE CAPACITOR4.7uF 50V M
C4502NDC31HJ-331XC CAPACITOR330pF 50V J
C4511QETN1HM-475ZE CAPACITOR4.7uF 50V M
C4512NDC31HJ-331XC CAPACITOR330pF 50V J
C4531NDC31HJ-470XC CAPACITOR47pF 50V J
C4532NDC31HJ-470XC CAPACITOR47pF 50V J
C4533NDC31HJ-470XC CAPACITOR47pF 50V J
C4534NDC31HJ-470XC CAPACITOR47pF 50V J
C4602QETN1EM-476ZE CAPACITOR47uF 25V M
C6401NBE21CM-106XTA E CAPACITOR10uF 16V M
C6402NDC31HJ-681XC CAPACITOR680pF 50V J
C6403NBE21CM-106XTA E CAPACITOR10uF 16V M
C6404NDC31HJ-680XC CAPACITOR68pF 50V J
C6405NBE21CM-106XTA E CAPACITOR10uF 16V M
C6501NDC31HJ-270XC CAPACITOR27pF 50V J
C6502NDC31HJ-2R0XC CAPACITOR2pF 50V J
C6503NDC31HJ-270XC CAPACITOR27pF 50V J
C6601NDC31HJ-270XC CAPACITOR27pF 50V J
C6602NDC31HJ-2R0XC CAPACITOR2pF 50V J
C6603NDC31HJ-270XC CAPACITOR27pF 50V J
C6701NDC31HJ-270XC CAPACITOR27pF 50V J
C6702NDC31HJ-2R0XC CAPACITOR2pF 50V J
C6703NDC31HJ-270XC CAPACITOR27pF 50V J
C7506NCB31CK-105XC CAPACITOR1uF 16V K
C5004QETM1EM-478E CAPACITOR4700uF 25V M
C5005QETN1JM-107ZE CAPACITOR100uF 63V M
C5006QETN1JM-107ZE CAPACITOR100uF 63V M
C5101NDC31HJ-681XC CAPACITOR680pF 50V J
C5102NDC31HJ-220XC CAPACITOR22pF 50V J
C5103QETN1CM-107ZE CAPACITOR100uF 16V M
C5104NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5105NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5106NCB31HK-104XC CAPACITOR0.1uF 50V K
C5107QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5201NDC31HJ-101XC CAPACITOR100pF 50V J
C5202NDC31HJ-3R0XC CAPACITOR3pF 50V J
C5203QETN1CM-107ZE CAPACITOR100uF 16V M
C5204NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5205NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5206NDC31HJ-471XC CAPACITOR470pF 50V J
C5207QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5301NDC31HJ-101XC CAPACITOR100pF 50V J
C5302NDC31HJ-3R0XC CAPACITOR3pF 50V J
C5303QETN1CM-107ZE CAPACITOR100uF 16V M
C5304NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5305NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5306NDC31HJ-471XC CAPACITOR470pF 50V J
C5307QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5401NDC31HJ-101XC CAPACITOR100pF 50V J
C5402NDC31HJ-3R0XC CAPACITOR3pF 50V J
C5403QETN1CM-107ZE CAPACITOR100uF 16V M
C5404NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5405NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5406NDC31HJ-471XC CAPACITOR470pF 50V J
C5407QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5501NDC31HJ-101XC CAPACITOR100pF 50V J
C5502NDC31HJ-3R0XC CAPACITOR3pF 50V J
C5503QETN1CM-107ZE CAPACITOR100uF 16V M
C5504NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5505NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5506NDC31HJ-471XC CAPACITOR470pF 50V J
C5507QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5601NDC31HJ-101XC CAPACITOR100pF 50V J
C5602NDC31HJ-3R0XC CAPACITOR3pF 50V J
C5603QETN1CM-107ZE CAPACITOR100uF 16V M
C5604NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5605NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C5606NDC31HJ-471XC CAPACITOR470pF 50V J
C5607QETN1HM-225ZE CAPACITOR2.2uF 50V M
C5801QETN1HM-106ZE CAPACITOR10uF 50V M
C5802QETN1CM-107ZE CAPACITOR100uF 16V M
C5803NCF31HZ-223XC CAPACITOR0.022uF 50V Z
C5901QETN1HM-106ZE CAPACITOR10uF 50V M
C5911NCB31HK-104XC CAPACITOR0.1uF 50V K
C5912NCB31HK-104XC CAPACITOR0.1uF 50V K
C5913NCB31HK-471XC CAPACITOR470pF 50V K
EV
C5914NCB31HK-471XC CAPACITOR470pF 50V K
C5921NCB31HK-104XC CAPACITOR0.1uF 50V K
C5922NCB31HK-104XC CAPACITOR0.1uF 50V K
C5923NCB31HK-471XC CAPACITOR470pF 50V K
C5924NCB31HK-471XC CAPACITOR470pF 50V K
C5931NCB31HK-104XC CAPACITOR0.1uF 50V K
C5932NCB31HK-104XC CAPACITOR0.1uF 50V K
C5933NCB31HK-471XC CAPACITOR470pF 50V K
C5934NCB31HK-471XC CAPACITOR470pF 50V K
C5941NCB31HK-104XC CAPACITOR0.1uF 50V K
C5942NCB31HK-104XC CAPACITOR0.1uF 50V K
C5943NCB31HK-471XC CAPACITOR470pF 50V K
C5944NCB31HK-471XC CAPACITOR470pF 50V K
C5951NCB31HK-104XC CAPACITOR0.1uF 50V K
C5952NCB31HK-104XC CAPACITOR0.1uF 50V K
C5953NCB31HK-471XC CAPACITOR470pF 50V K
C5954NCB31HK-471XC CAPACITOR470pF 50V K
C5961NCB31HK-104XC CAPACITOR0.1uF 50V K
C5962NCB31HK-104XC CAPACITOR0.1uF 50V K
C5963NCB31HK-471XC CAPACITOR470pF 50V K
C5964NCB31HK-471XC CAPACITOR470pF 50V K
L5101QQLZ038-R45COIL0.45uH
L5101 or QQLZ042-R45COIL0.45uH
L5201QQLZ038-R45COIL0.45uH
L5201 or QQLZ042-R45COIL0.45uH
L5301QQLZ038-R45COIL0.45uH
L5301 or QQLZ042-R45COIL0.45uH
L5401QQLZ038-R45COIL0.45uH
L5401 or QQLZ042-R45COIL0.45uH
L5501QQLZ038-R45COIL0.45uH
L5501 or QQLZ042-R45COIL0.45uH
L5601QQLZ038-R45COIL0.45uH
L5601 or QQLZ042-R45COIL0.45uH
L5911QQLZ038-R45COIL0.45uH
L5911 or QQLZ042-R45COIL0.45uH
L5921QQLZ038-R45COIL0.45uH
L5921 or QQLZ042-R45COIL0.45uH
L5931QQLZ038-R45COIL0.45uH
L5931 or QQLZ042-R45COIL0.45uH
L5941QQLZ038-R45COIL0.45uH
L5941 or QQLZ042-R45COIL0.45uH
L5951QQLZ038-R45COIL0.45uH
L5951 or QQLZ042-R45COIL0.45uH
L5961QQLZ038-R45COIL0.45uH
L5961 or QQLZ042-R45COIL0.45uH
C1003QCZ9079-102C CAPACITOR1000pF AC250V M
C1101QFLC2AJ-472ZM CAPACITOR4700pF 100V J
C1101 or QFNC2AJ-472ZM CAPACITOR4700pF 100V J
C1102QETM1EM-108E CAPACITOR1000uF 25V M
C1103NCF31EZ-104XC CAPACITOR0.1uF 25V Z
C1104NCB31CK-104XC CAPACITOR0.1uF 16V K
C1201NCB31HK-104XC CAPACITOR0.1uF 50V K
C1202NCB31HK-104XC CAPACITOR0.1uF 50V K
C1203NCB31HK-104XC CAPACITOR0.1uF 50V K
C1204NCB31HK-104XC CAPACITOR0.1uF 50V K
C1205NCB31HK-104XC CAPACITOR0.1uF 50V K
C1206NCB31HK-104XC CAPACITOR0.1uF 50V K
C1207NCB31HK-104XC CAPACITOR0.1uF 50V K
C1208NCB31HK-104XC CAPACITOR0.1uF 50V K
C1209NCB31HK-104XC CAPACITOR0.1uF 50V K
C1210NCB31HK-104XC CAPACITOR0.1uF 50V K
C1211NCB31HK-104XC CAPACITOR0.1uF 50V K
C1212NCB31HK-104XC CAPACITOR0.1uF 50V K
C1301NCB31HK-104XC CAPACITOR0.1uF 50V K
C1302NCB31HK-104XC CAPACITOR0.1uF 50V K
C1401QFLC1HJ-473ZM CAPACITOR0.047uF 50V J
C1401 or QFN31HJ-473ZM CAPACITOR0.047uF 50V J
C1402QEKC1HM-105ZE CAPACITOR1uF 50V M
C1403QETN1HM-476ZE CAPACITOR47uF 50V M
C1404QFNC2AJ-473ZM CAPACITOR0.047uF 100V J
C1404 or QFN31HJ-473ZM CAPACITOR0.047uF 50V J
C1405QETN1JM-107ZE CAPACITOR100uF 63V M
C2501QEKC1CM-227ZE CAPACITOR220uF 16V M
C2502NCF31AZ-105XC CAPACITOR1uF 10V Z
Part No.Part NameDescriptionLocal
3-15
Page 40
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C2511QEKC1CM-227ZE CAPACITOR220uF 16V M
C2512NCF31AZ-105XC CAPACITOR1uF 10V Z
C2521QEKC1CM-227ZE CAPACITOR220uF 16V M
C2522NCF31AZ-105XC CAPACITOR1uF 10V Z
C6001NCB31HK-102XC CAPACITOR1000pF 50V K
C6003NCB30JK-105XC CAPACITOR1uF 6.3V K
C6101NCF31AZ-105XC CAPACITOR1uF 10V Z
C7002NCB31EK-223XC CAPACITOR0.022uF 25V K
C7003NCB31EK-223XC CAPACITOR0.022uF 25V K
C7004NCF31HZ-103XC CAPACITOR0.01uF 50V Z
C7005NCF31HZ-103XC CAPACITOR0.01uF 50V Z
C7006NCF31HZ-103XC CAPACITOR0.01uF 50V Z
C7601QER61CM-476ZE CAPACITOR47uF 16V M
C7602NDC31HJ-470XC CAPACITOR47pF 50V J
C7603QER61CM-476ZE CAPACITOR47uF 16V M
C7604NDC31HJ-470XC CAPACITOR47pF 50V J
C7605NCB31HK-103XC CAPACITOR0.01uF 50V K
C7606NDC31HJ-470XC CAPACITOR47pF 50V J
C7607NDC31HJ-221XC CAPACITOR220pF 50V J
C7608NDC31HJ-221XC CAPACITOR220pF 50V J
C7610NCF21CZ-105XC CAPACITOR1uF 16V Z
C7611NCF21CZ-105XC CAPACITOR1uF 16V Z
C7612NCF21CZ-105XC CAPACITOR1uF 16V Z
C7613NCF21CZ-105XC CAPACITOR1uF 16V Z
C7614NDC31HJ-101XC CAPACITOR100pF 50V J
C7615NDC31HJ-101XC CAPACITOR100pF 50V J
C7616NDC31HJ-101XC CAPACITOR100pF 50V J
C7617NDC31HJ-101XC CAPACITOR100pF 50V J
C7618NCF21CZ-105XC CAPACITOR1uF 16V Z
C7619NCF21CZ-105XC CAPACITOR1uF 16V Z
C7620NCF31HZ-473XC CAPACITOR0.047uF 50V Z
C7621NDC31HJ-100XC CAPACITOR10pF 50V J
C7622NDC31HJ-100XC CAPACITOR10pF 50V J
C7627QER61CM-476ZE CAPACITOR47uF 16V M
C7628QER61CM-476ZE CAPACITOR47uF 16V M
C7629NDC31HJ-100XC CAPACITOR10pF 50V J
C7630NDC31HJ-100XC CAPACITOR10pF 50V J
C7631NDC31HJ-100XC CAPACITOR10pF 50V J
C7632NDC31HJ-100XC CAPACITOR10pF 50V J
C7633QER61CM-476ZE CAPACITOR47uF 16V M
C7634NCF21CZ-105XC CAPACITOR1uF 16V Z
C7635NDC31HJ-100XC CAPACITOR10pF 50V J
C7636NDC31HJ-100XC CAPACITOR10pF 50V J
C7639NCF21CZ-105XC CAPACITOR1uF 16V Z
C7640NCF21CZ-105XC CAPACITOR1uF 16V Z
R1001QRJ146J-100XUNF C RESISTOR10Ω 1/4W J
R1101QRJ146J-100XUNF C RESISTOR10
R1401QRE141J-104YC RESISTOR100k
R1402QRJ146J-100XUNF C RESISTOR10Ω 1/4W J
R1403QRJ146J-470XUNF C RESISTOR47Ω 1/4W J
R1404QRJ146J-682XUNF C RESISTOR6.8k
C101NCB31CK-104XC CAPACITOR0.1uF 16V K
C102NCB31CK-104XC CAPACITOR0.1uF 16V K
C103NCB31CK-104XC CAPACITOR0.1uF 16V K
C104NCB31CK-104XC CAPACITOR0.1uF 16V K
C105NEAF0JM-476XE CAPACITOR47uF 6.3V M
C106NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C107NCB31CK-104XC CAPACITOR0.1uF 16V K
C108NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C201NDC31HJ-221XC CAPACITOR220pF 50V J
C202NDC31HJ-221XC CAPACITOR220pF 50V J
C203NCB31HK-103XC CAPACITOR0.01uF 50V K
C204NCB31CK-104XC CAPACITOR0.1uF 16V K
C205NCB31HK-271XC CAPACITOR270pF 50V K
C206NDC31HJ-151XC CAPACITOR150pF 50V J
C210NCF31AZ-105XC CAPACITOR1uF 10V Z
C211NCB31HK-223XC CAPACITOR0.022uF 50V K
C217NCB31CK-104XC CAPACITOR0.1uF 16V K
C251NCB31AK-474XC CAPACITOR0.47uF 10V K
C256NCB31CK-104XC CAPACITOR0.1uF 16V K
Part No.Part NameDescriptionLocal
C257NCB31HK-822XC CAPACITOR8200pF 50V K
C258NCB31CK-153XC CAPACITOR0.015uF 16V K
C259NCB31CK-153XC CAPACITOR0.015uF 16V K
C260NCB31HK-223XC CAPACITOR0.022uF 50V K
C261NCB31HK-223XC CAPACITOR0.022uF 50V K
C262NCB31HK-223XC CAPACITOR0.022uF 50V K
C263NEAF1CM-107XE CAPACITOR100uF 16V M
C301NEAF0JM-227XE CAPACITOR220uF 6.3V M
C302NEAF0GM-476XE CAPACITOR47uF 4V M
C303NEAF0GM-476XE CAPACITOR47uF 4V M
C304NCB30JK-105XC CAPACITOR1uF 6.3V K
C305NCB31CK-104XC CAPACITOR0.1uF 16V K
C306NCB31CK-104XC CAPACITOR0.1uF 16V K
C307NCB31CK-104XC CAPACITOR0.1uF 16V K
C309NCB31CK-104XC CAPACITOR0.1uF 16V K
C310NCB31CK-104XC CAPACITOR0.1uF 16V K
C312NCB31CK-104XC CAPACITOR0.1uF 16V K
C313NCB31CK-104XC CAPACITOR0.1uF 16V K
C314NCB31CK-104XC CAPACITOR0.1uF 16V K
C315NCB31CK-104XC CAPACITOR0.1uF 16V K
C316NCB31CK-104XC CAPACITOR0.1uF 16V K
C318NCB31CK-104XC CAPACITOR0.1uF 16V K
C319NCB31CK-104XC CAPACITOR0.1uF 16V K
C320NCB31CK-104XC CAPACITOR0.1uF 16V K
C321NCB31CK-104XC CAPACITOR0.1uF 16V K
C322NCB31CK-104XC CAPACITOR0.1uF 16V K
C323NCB31CK-104XC CAPACITOR0.1uF 16V K
C324NCB30JK-105XC CAPACITOR1uF 6.3V K
C325NDC31HJ-120XC CAPACITOR12pF 50V J
C326NDC31HJ-100XC CAPACITOR10pF 50V J
C328NCB31HK-103XC CAPACITOR0.01uF 50V K
C330NCB31CK-104XC CAPACITOR0.1uF 16V K
C331NCB31CK-333XC CAPACITOR0.033uF 16V K
C332NCB31CK-104XC CAPACITOR0.1uF 16V K
C333NCB31CK-104XC CAPACITOR0.1uF 16V K
C334NCB31CK-104XC CAPACITOR0.1uF 16V K
C335NCB31CK-104XC CAPACITOR0.1uF 16V K
C337NCB31CK-183XC CAPACITOR0.018uF 16V K
C338NCB31HK-562XC CAPACITOR5600pF 50V K
C339NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C340NCB30JK-105XC CAPACITOR1uF 6.3V K
C341NCB30JK-105XC CAPACITOR1uF 6.3V K
C345NCB31CK-104XC CAPACITOR0.1uF 16V K
C347NCB31CK-104XC CAPACITOR0.1uF 16V K
C348NCB31CK-104XC CAPACITOR0.1uF 16V K
C349NCB31CK-104XC CAPACITOR0.1uF 16V K
C350NCB31HK-103XC CAPACITOR0.01uF 50V K
C351NCB31HK-103XC CAPACITOR0.01uF 50V K
C352NCB31CK-153XC CAPACITOR0.015uF 16V K
C353NCB31HK-561XC CAPACITOR560pF 50V K
C354NCB31HK-561XC CAPACITOR560pF 50V K
C356NCB30JK-105XC CAPACITOR1uF 6.3V K
C359NCB30JK-105XC CAPACITOR1uF 6.3V K
C370NCB31CK-104XC CAPACITOR0.1uF 16V K
C371NCF31AZ-105XC CAPACITOR1uF 10V Z
C372NCB31CK-104XC CAPACITOR0.1uF 16V K
C373NCB31CK-104XC CAPACITOR0.1uF 16V K
C374NCB31CK-104XC CAPACITOR0.1uF 16V K
C375NCB31CK-104XC CAPACITOR0.1uF 16V K
C378NCB31CK-104XC CAPACITOR0.1uF 16V K
C379NCB31CK-104XC CAPACITOR0.1uF 16V K
C380NCB21CK-105XC CAPACITOR1uF 16V K
C381NCB21AK-225XC CAPACITOR2.2uF 10V K
C382NCB31HK-471XC CAPACITOR470pF 50V K
C383NCB31CK-104XC CAPACITOR0.1uF 16V K
C391NEAF0JM-227XE CAPACITOR220uF 6.3V M
C392NCB31CK-104XC CAPACITOR0.1uF 16V K
C393NCB31HK-103XC CAPACITOR0.01uF 50V K
C455NCB31HK-103XC CAPACITOR0.01uF 50V K
C551NCB31CK-104XC CAPACITOR0.1uF 16V K
C552NCB31CK-104XC CAPACITOR0.1uF 16V K
C553NCB31CK-104XC CAPACITOR0.1uF 16V K
C554NCB31CK-104XC CAPACITOR0.1uF 16V K
C555NCB31CK-104XC CAPACITOR0.1uF 16V K
C557NCB31HK-102XC CAPACITOR1000pF 50V K
C558NBE20JM-226XTA E CAPACITOR22uF 6.3V M
C559NCB31CK-104XC CAPACITOR0.1uF 16V K
C560NCB31CK-104XC CAPACITOR0.1uF 16V K
3-17
Page 42
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C562NCF31AZ-105XC CAPACITOR1uF 10V Z
C563NCB31CK-104XC CAPACITOR0.1uF 16V K
C564NCB31CK-104XC CAPACITOR0.1uF 16V K
C701NCB31CK-104XC CAPACITOR0.1uF 16V K
C702NCB31CK-104XC CAPACITOR0.1uF 16V K
C703NCB31CK-104XC CAPACITOR0.1uF 16V K
C704NEAF0JM-476XE CAPACITOR47uF 6.3V M
C706NEAF1CM-106XE CAPACITOR10uF 16V M
C707NCB31CK-104XC CAPACITOR0.1uF 16V K
C708NCB31CK-104XC CAPACITOR0.1uF 16V K
C709NCB31CK-104XC CAPACITOR0.1uF 16V K
C711NCB21CK-105XC CAPACITOR1uF 16V K
C712NCB31HK-103XC CAPACITOR0.01uF 50V K
C713NCB21CK-105XC CAPACITOR1uF 16V K
C740NCB31CK-104XC CAPACITOR0.1uF 16V K
C741NCF31AZ-105XC CAPACITOR1uF 10V Z
C742NCB31CK-104XC CAPACITOR0.1uF 16V K
C743NCB31CK-104XC CAPACITOR0.1uF 16V K
C744NEAF1CM-106XE CAPACITOR10uF 16V M
C745NEAF1CM-106XE CAPACITOR10uF 16V M
C801NCB21CK-105XC CAPACITOR1uF 16V K
C802NCB21AK-225XC CAPACITOR2.2uF 10V K
C803NEAF0JM-227XE CAPACITOR220uF 6.3V M
C804NCB31HK-471XC CAPACITOR470pF 50V K
C901NCB21AK-105XC CAPACITOR1uF 10V K
C902NCB31HK-471XC CAPACITOR470pF 50V K
C903NCB21AK-225XC CAPACITOR2.2uF 10V K
C905NEAF0GM-476XE CAPACITOR47uF 4V M
C906NEAF0GM-476XE CAPACITOR47uF 4V M
C914NCF21CZ-225XC CAPACITOR2.2uF 16V Z
C916NCF21CZ-225XC CAPACITOR2.2uF 16V Z
C921NCF21CZ-225XC CAPACITOR2.2uF 16V Z
C922NCF21CZ-225XC CAPACITOR2.2uF 16V Z
C927NCB31CK-104XC CAPACITOR0.1uF 16V K
C928NCB30JK-105XC CAPACITOR1uF 6.3V K
C929NCB31CK-104XC CAPACITOR0.1uF 16V K
C930NCB30JK-105XC CAPACITOR1uF 6.3V K
C931NEAF0JM-476XE CAPACITOR47uF 6.3V M
C932NCB30JK-105XC CAPACITOR1uF 6.3V K
C933NCB30JK-105XC CAPACITOR1uF 6.3V K
C950NCB31CK-104XC CAPACITOR0.1uF 16V K
C951NCB31CK-104XC CAPACITOR0.1uF 16V K
C952NCB31CK-104XC CAPACITOR0.1uF 16V K
C953NCB31CK-104XC CAPACITOR0.1uF 16V K
C954NCB31CK-104XC CAPACITOR0.1uF 16V K
C955NCB31CK-104XC CAPACITOR0.1uF 16V K
C956NCB31CK-104XC CAPACITOR0.1uF 16V K
C957NCB31CK-104XC CAPACITOR0.1uF 16V K
C958NCB31CK-104XC CAPACITOR0.1uF 16V K
C959NCB31CK-104XC CAPACITOR0.1uF 16V K
C960NCB31CK-104XC CAPACITOR0.1uF 16V K
C961NCB31CK-104XC CAPACITOR0.1uF 16V K
C962NCB31CK-104XC CAPACITOR0.1uF 16V K
C963NCB31CK-104XC CAPACITOR0.1uF 16V K
C964NCB31CK-104XC CAPACITOR0.1uF 16V K
C965NCB31CK-104XC CAPACITOR0.1uF 16V K
C966NCB31CK-104XC CAPACITOR0.1uF 16V K
C967NCB31CK-104XC CAPACITOR0.1uF 16V K
C968NCB31CK-104XC CAPACITOR0.1uF 16V K
C969NCB31CK-104XC CAPACITOR0.1uF 16V K
C970NCB31CK-104XC CAPACITOR0.1uF 16V K
C971NCB31CK-104XC CAPACITOR0.1uF 16V K
C972NCB31CK-104XC CAPACITOR0.1uF 16V K
C973NCB31CK-104XC CAPACITOR0.1uF 16V K
C974NCB31CK-104XC CAPACITOR0.1uF 16V K
C975NCB31CK-104XC CAPACITOR0.1uF 16V K
C976NDC31HJ-1R0XC CAPACITOR1pF 50V J
C977NDC31HJ-1R0XC CAPACITOR1pF 50V J
C978NCB31CK-104XC CAPACITOR0.1uF 16V K
C979NCB31CK-104XC CAPACITOR0.1uF 16V K
No additional / supplemental order of WARRANTY CARDs are available.
Block No.
3
M
M
M
A16
A18
A18
P13
A15
A18
A18
P13
P17
A20,A21, A22,
A23,A24,
A25
P20
P17
P15
A13
P14
P13
A18
P13
A17
P11
A18
P18
P10
A14
P12
P16
A19
Bottom View
A19
P6
A1,
A2(Only E,EN),
A3,
A4(Only B),
A7,
A6,
A12
P2
P1
1/2
P3
A8,
1/2
A9
P5
P4
A11
A10
A5
P2
2/2
2/2
P3
P7
Only B
P8
Only B
P19
P9
The parts without symbol number are not service.
3-20
Page 45
Packing and Accessories
Symbol No.Part No.Part NameDescriptionLocal
A 1LVT1704-003AINST BOOKENGB
A 1LVT1704-004AINST BOOKGER FREE
A 1LVT1704-006AINST BOOKDAN FIN SWEEN
A 1LVT1704-008AINST BOOKHUN CZE POLEV
A 2LVT1704-005AINST BOOKITA DUTE
A 2LVT1704-007AINST BOOKSPA POREN
A 3LVT1755-001ASHEETB,E,EN
A 3LVT1755-002ASHEETEV
A 4VNA3000-204REGIST CARDB
A 5QQR0491-002FERRITE COREFL1 TDK (BLACK)
A 6------------WARRANTY CARDBT-54032-1
A 7QAM0955-002iPod CABLE
A 8QAL0014-003AM LOOP ANT
A 9QAL0457-001ANT.WIRE
A10LV37205-003ASTAND ASSY
A11------------BATTERY(x2)
A12RM-STHD5RREMOTE CONTROL UNIT
A139000009301FOOT(x2)
A14AB160039-01SPK WITH BOX-W
A15AB077025-01SPK WITH BOX-F(x2)
A16AB077025-02SPK WITH BOX-S(x2)
A17AB077026-01SPK WITH BOX-C
A189000007941FOOT(x20)
A199000006301FOOT(x4)
A206200045901SPK CORD-C
A216200045911SPK CORD-FR
A226200045921SPK CORD-FL
A236200045931SPK CORD-SR
A246200045941SPK CORD-SL
A256200047501SPEAKER CORD-SW
P 1LV37599-017ACARTON BOXB
P 1LV37599-002ACARTON BOXE,EN,EV
P 2GN10127-204APACKING PAD(F)
P 3GN10128-203APACKING PAD(R)
P 4QPC06506515PBPOLY BAG65cm x 65cm
P 5QPH01404905HPOLY SHEET14cm x 49cm
P 6QPA02503503PBPOLY BAG25cm x 35cm
P 7QPJ01203040POLY SHEET12cm x 30cmB
P 8LV34107-008APACKING SHEETB
P 9LV11399-001ACUSHION-A
P10LV11399-002ACUSHION-B
P11LV11399-003ACUSHION-C
P128500066131MIRROR SHEET
P138500066141MIRROR SHEET(x4)
P148500066151MIRROR SHEET
P158500047111POLY BAG
P168500066911POLY BAG
P178500066921POLY BAG(x4)
P188500066931POLY BAG
P19LV35831-0C2ACARTON BOX
P208500032771POLY BAG
Block No. [M][3][M][M]
3-21
Page 46
SCHEMATIC DIAGRAMS
DVD DIGITAL CINEMA SYSTEM
TH-D5B,TH-D5E,TH-D5EN
TH-D5EV
CD-ROM No.SML200707
SP-THD5W
SP-THD5S
SP-THD5C
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
SP-THD5F
XV-THD5
2-1
2-2
2-14 to 18
COPYRIGHT 2007 Victor Company of Japan, Limited.
No.MB618SCH
2007/7
Page 47
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
Page 48
Block diagram
DVD pickup
mechanism
DVD traverse
mechanism
D+/-
J7501
USB
VBUS
TO
i Pod
Front panel section
TOUCH
SENSOR
HEAD
PHONE
DVD section
A, B, C, D, E, F, RF+, LPC1, LPC2
LD(CD)
CN101
LD(DVD)
LASER DRIVER
F+/-, T+/-
FM+/-, WOUT, VOUT
CN201
UOUT, COM
IC505
CN811
SDRAM
5V
CN751
IC512
IC513
LATCH
iPod AMP section
iPod-Y, iPod-Cv
J7601
iPod-L/R
CHARGE
D6301
DVD LED
TOUCH
SENSOR
OSC
SENSE PLAY
SENSE STOP
SENSE PAUSE
TOUCH SENSOR AMP.
J7001
LPCO1, LPCO2
Q101 to Q104
CDLDCUR, DVDLDCUR
IC201
SPDRV, TRSDRV
FODRV, TRDRV
SPMUTE, FG
DRVER
X301
SDA
27MHz
IC510
EEPROM
SCK
X302,IC303
48MHz
MA0 to 11, MDQ0 to 15, BA0, BA1, MCK
DQM0, DQM1, NCSM, NRAS, NCAS, NWE
LADR0
to 15
IC801,Q801
5V REG.
IC509
D6V
NEXCE
EXADT0 to 15
NEXOE, NEXWE
EXADR16 to 20
FLASH ROM
IPOD_RX
IPOD_TX
IPOD_DET
IPOD_C
IC762
IPOD_Y, IPOD_CV
VIDEO DIFF. AMP
IC761
IPOD_L/R
AUDIO DIFF. AMP
D6101,Q6101,Q6102
STANDBY LED
FW615
FW605
PLAY-LED
D6801 to D6803
Q6801 to Q6803
FUNCTION LED
IC641,IC642
Q6401,Q6402
Q6501,Q6601,Q6701
STOP-LED
PAUSE-LED
PLAY
STOP
PAUSE
TRVSW
DP, DM
NEN, NOC
DVD_LED1
DVD_LED2
CN641
CN601
FW613
FW603
DVDOUT0 to 7, H_AOUT0 to 2, H_TX, SCK, SDA
CPURST, HCLK, VCLKO, H_BCK, H_LRCK, H_MCLK
TX5V
IC301
DV5
S2UDT, U2SDT, UCLK, SCS, UCS, RX, DAC1OUT to DAC5OUT
