JVC TH-A35 User Manual
DVD DIGITAL CINEMA SYSTEM
TH-A35
Consists of XV-THA35 and SP-THA35
STANDBY/ON
SOUND
AUDIO
VCRTV
SUBWOOFER
CENTER
1234
REAR-RREAR-L
5678
CLEAR SETTINGFM MODE
TEST
9
0
PROGRESSIVE
DVD FM/AM
AUX
SEARCH
TV/VIDEO
CONTROL
TV
VCR
TV VOL
MUTING
REC/MEMORY
AUDIO VOL
TOP
MENU
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
SUB TITLE ANGLE ZOOM
RETURN DIMMER DSP
RM-STHA35U
DVD CINEMA SYSTEM
ENTER
ON SCREEN
SLOW
SURROUND
SLEEP
STANDBY/ON
STANDBY
DVD DIGITAL CINEMA SYSTEM TH-A35
DIGITAL
COMPACT
DIGITAL•EX
SUPER VIDEO
PRO LOGIC
SURROUND
VOLUME
PHONES
DSPSURROUNDSOURCE
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1009-012A
[A]
Warnings, Cautions and Others
Caution –– STANDBY/ON switch!
Disconnect the mains plug to shut the power off completely. The
STANDBY/ON switch in any position does not disconnect the
mains line. The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get
out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
IMPORTANT FOR LASER PRODUCTS
REPRODUCTION OF LABELS
1 CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE
CLASS 1
LASER PRODUCT
2 WARNING LABEL, PLACED INSIDE THE UNIT
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 10 cm from the sides.
Top: No obstructions in 10 cm from the top.
Back: No obstructions in 15 cm from the back
Bottom: No obstructions, place on the level surface.
In addition, maintain the best possible air circulation as illustrated.
Spacing 15 cm or more
Wall or obstructions
1. CLASS 1 LASER PRODUCT
2. CAUTION: Invisible laser radiation when open and
interlock failed or defeated. Avoid direct exposure to
beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the unit; leave all servicing to
qualified service personnel.
XV-THA35
Front
Stand height 15 cm or more
Floor
G-1
Table of Contents
Parts Identification ...................................... 2
Center Unit ................................................................................. 2
Remote Control .......................................................................... 3
Getting Started ........................................... 4
Before Installation ...................................................................... 4
Checking the Supplied Accessories ........................................... 4
Putting Batteries in the Remote Control .................................... 4
Connecting the FM and AM Antennas ....................................... 5
Speaker Layout Diagram ............................................................ 6
Connecting the Speakers ............................................................ 7
Connecting Audio/Video Component ........................................ 8
TV Setting ................................................ 10
Changing the Color System ..................................................... 10
Changing the Scanning Mode .................................................. 10
Adjusting the Pictures .............................................................. 11
Basic DVD Operations ................................ 12
1 Turn On the Power ............................................................... 12
2 Select the Source .................................................................. 12
3 Load a DVD ......................................................................... 12
4 Start Playback ...................................................................... 12
5 Adjust the Volume ................................................................ 12
6 Activate Surround or DSP Mode ......................................... 13
7 Stop Playback ...................................................................... 13
Basic VCD/CD Operations .......................... 14
1 Turn On the Power ............................................................... 14
2 Select the Source .................................................................. 14
3 Load a VCD/CD .................................................................. 14
4 Start Playback ...................................................................... 14
5 Adjust the Volume ................................................................ 14
6 Activate Surround or DSP Mode ......................................... 15
7 Stop Playback ...................................................................... 15
Basic Tuner Operations .............................. 16
1 Turn On the Power ............................................................... 16
2 Select the Band .................................................................... 16
3 Adjust the Volume ................................................................ 16
4 Tune into a Station ............................................................... 16
5 Activate Surround or DSP Mode ......................................... 17
Other Basic Operations .............................. 18
Enjoying Sounds from the External Component ..................... 18
Listening with the Headphones ................................................ 19
Adjusting the Brightness .......................................................... 19
Turning Off the Power with the Timer ..................................... 20
Creating Realistic Sound Fields ................... 21
7 Dolby Surround .................................................................... 21
7 Dolby Digital ........................................................................ 21
7 DTS Digital Surround .......................................................... 21
7 DSP (Digital Signal Processor) Modes ................................ 22
Activating the Surround Mode ................................................. 22
Adjusting the Sound ................................................................. 23
Disc Introduction—DVD/VCD/CD ................ 24
Basic Disc Operations ................................ 25
DVD Playback ........................................... 26
Showing the On-Screen Menu ................................................. 26
Showing the Information on the TV Screen............................. 26
Selecting the Subtitles .............................................................. 27
Selecting the Audio Languages ................................................ 27
Selecting the Multi-Angle Views ............................................. 27
Disc Menu-Driven Playback .................................................... 28
Moving to a Particular Portion Directly ................................... 28
Searching for a Particular Point ............................................... 29
Repeating Playback .................................................................. 29
7 Repeat Play ........................................................................... 29
7 A–B Repeat ........................................................................... 29
Playing Back Chapters in Random Order—Shuffle Play ........ 30
Programming the Playing Order of the Chapters
—Program Play .................................................................. 31
DVD Special Effect Playback .................................................. 32
7 Still Picture/Frame-by-Frame Playback ............................... 32
7 Slow Motion Playback ......................................................... 33
7 Zoom .................................................................................... 33
VCD/CD Playback...................................... 34
Showing the On-Screen Menu ................................................. 34
Showing the Information on the TV Screen............................. 34
Disc Menu-Driven Playback (Only for VCD) .......................... 35
Selecting Playback Channel ..................................................... 35
Moving to a Particular Portion Directly ................................... 35
Searching for a Particular Point ............................................... 36
Repeating Playback .................................................................. 36
7 Repeat Play ........................................................................... 36
7 A–B Repeat ........................................................................... 37
Playing Back Tracks in Random Order—Shuffle Play ............ 37
Programming the Playing Order of the Tracks
—Program Play .................................................................. 38
VCD Special Effect Playback .................................................. 39
7 Still Picture/Frame-by-Frame Playback ............................... 39
7 Slow Motion Playback ......................................................... 39
7 Zoom .................................................................................... 39
MP3 Playback ........................................... 40
Starting Playback ..................................................................... 41
Operations Using the On-Screen Display ................................ 42
Moving to a Particular Track Directly...................................... 42
Programming the Playing Order of the Tracks
—Program Play .................................................................. 42
JPEG Playback .......................................... 44
Loading the Disc ...................................................................... 44
Operations Using the On-Screen Display ................................ 45
Moving to a Particular File Directly ........................................ 46
Programming the Playing Order of the Files
—Program Play .................................................................. 46
Tuner Operations ....................................... 48
Tuning in Stations .................................................................... 48
Using Preset Tuning ................................................................. 49
Selecting the FM Reception Mode ........................................... 49
Setting up the DVD Preferences ................. 50
Using the Choice Menus .......................................................... 50
Language Menu ........................................................................ 51
Picture Menu ............................................................................ 52
Audio Menu ............................................................................. 53
Setting Menu ............................................................................ 53
Setting the Parental (Rating) Level .......................................... 55
Operating JVC’s Components ...................... 56
Operating Other Manufacturers’ TV ............ 57
Maintenance ............................................. 58
Troubleshooting ......................................... 59
Specifications............................................ 60
1
Parts Identification
Center Unit
Front Panel
1
STANDBY
STANDBY/ON
See pages in the parentheses for details.
2
DVD DIGITAL CINEMA SYSTEM
3
Front Panel
1 STANDBY/ON button and STANDBY lamp (12 – 17)
2 Disc tray (12, 14)
3 Illumination lamp
4 Display window
5 VOLUME control (12, 14, 16)
6 Remote sensor
7 PHONES jack (19)
8 0 (open/close) button (12 – 15, 25, 41)
• Pressing this button also turns on the power and
changes the source to the DVD player.
45
8
9 3/8, 7, 4, and ¢ buttons
• Pressing 3/
source to the DVD player.
p SOURCE button (12, 14, 16, 18, 48)
q SURROUND button (13, 15, 17, 19, 22)
w DSP button (13, 15, 17, 19, 22)
9 p q w
8
also turns on the power and changes the
67
VOLUME
PHONES
DSPSURROUNDSOURCE
Display Window
R
RS
2
P–SCAN
DIGITAL
ProLogic II
w
8
3
CD
VCDSTEREO MP3
e
1
L
C
S
LS
See pages in the parentheses for details.
Display Window
1 Audio channel indicators
• Indicates audio channels currently source signal.
2 P-SCAN indicator (11)
3 Disc indicators (25)
• DVD, CD, VCD, and MP3
4 Playback indicators
• 3 (play) and 8 (pause)
5 TITLE indicator (25)
6 TRK (track) indicator (25)
7 TUNED indicator (16, 48)
8 CHP (chapter) indicator (25)
543
6 7 8 9 p q
REPEAT 1
r t
9 PROG (program) indicator (31, 38)
p Repeat mode indicators (29, 30, 36, 37)
• REPEAT, 1, and A–B
q Sleep indicator (20)
w Sound signal indicators (21, 22)
• DIGITAL, PRO LOGIC II, and DTS
e STEREO indicator (49)
r Main display
t Frequency unit indicators
• MHz (for FM station) and kHz (for AM station)
A–BPROGCHPTUNEDTRKTITLE
3
k
Hz
MHz
2
Remote Control
See pages in the parentheses for details.
1
2
3
4
5
6
7
8
9
p
q
w
e
r
t
y
Remote Control
SOUND
1234
5678
TEST
9
DVD FM/AM
TV
TOP
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
RETURN DIMMER DSP
STANDBY/ON
VCRTV
CENTER
CONTROL
TV VOL
SUB TITLE ANGLE ZOOM
DVD CINEMA SYSTEM
SUBWOOFER
REAR-RREAR-L
CLEAR SETTING FM MODE
0
AUX
TV/VIDEO
VCR
MUTING
AUDIO VOL
ENTER
SLOW
SLEEP
RM-STHA35U
AUDIO
PROGRESSIVE
SEARCH
REC/MEMORY
MENU
ON SCREEN
SURROUND
u
i
o
;
a
s
d
f
g
h
j
k
l
1 STANDBY/ON buttons
• TV
• VCR
• AUDIO
button (12, 14, 56, 57)
button (56)
button (12 – 17)
2 SOUND button (23)
3 • Number buttons
(25, 28, 30, 35, 38, 42, 43, 46, 47, 49, 55–57)
• CLEAR button (28, 32, 35, 39, 52)
• Sound setting buttons (23)
CENTER + and – buttons
SUBWOOFER + and – buttons
REAR-L + and – buttons
REAR-R + and – buttons
TEST button
SETTING button
4 Source selecting buttons (10, 12, 14, 16, 18, 23, 48, 49)
• DVD, FM/AM, AUX
• Pressing one of these buttons also turns on the power.
5 CONTROL buttons
• TV CONTROL button (56, 57)
• VCR CONTROL button (56)
6 TV VOL + and – buttons (56, 57)
7 AUDIO VOL + and – buttons (12, 14, 16, 18)
8 TOP MENU button (28)
9 Menu operation buttons
• cursor 3, 2, 5, and ∞ buttons
• ENTER button
p CHOICE button (11, 50–54)
8
q 7, 3, and
buttons
w 4 and ¢ buttons (25, 35, 41, 43, 45, 47, 56)
TUNING UP and DOWN buttons (16, 48)
e AUDIO button (27, 35)
r SUB TITLE button (27)
t RETURN button (35)
y DIMMER button (19)
SLEEP button (20)
u FM MODE button (49)
i PROGRESSIVE button (11)
o SEARCH button (28, 35)
; TV/VIDEO button (56, 57)
a REC/MEMORY button (10, 49, 56)
s MUTING button (13, 15, 16, 18)
d MENU button (28, 35)
f ON SCREEN button (26, 29–32, 34, 36–39)
g 1 and ¡ buttons (29, 33, 36, 39, 49, 56, 57)
SLOW + and – buttons (33, 39)
h ZOOM button (33, 39, 45, 47)
j ANGLE button (27)
k SURROUND button (13, 15, 17, 19, 22)
l DSP button (13, 15, 17, 19, 22)
3
Getting Started
Before Installation
General Precautions
• DO NOT insert any metal object into the center unit.
• DO NOT disassemble the center unit or remove screws, covers, or
cabinet.
• DO NOT expose the center unit to rain or moisture.
Locations
• Install the center unit in a location that is level and protected from
moisture.
• The temperature around the center unit must be between 5˚C and
35˚C.
• Make sure there is good ventilation around the center unit. Poor
ventilation could cause overheating and damage the center unit.
Handling the center unit
• DO NOT touch the power cord with wet hands.
• DO NOT pull on the power cord to unplug the cord. When
unplugging the cord, always grasp the plug so as not to damage
the cord.
• Keep the power cord away from the connecting cords and the
antennas. The power cord may cause noise or screen interference.
It is recommended to use a coaxial cable for antenna connection,
since it is well-shielded against interference.
• When a power failure occurs, or when you unplug the power cord,
the preset settings such as preset FM/AM channels and sound
adjustments may be erased in a few days.
Checking the Supplied Accessories
Putting Batteries in the Remote Control
Before using the remote control, put two supplied batteries first.
• When using the remote control, aim the remote control directly at
the remote sensor on the center unit.
1. On the back of the remote control, remove the
battery cover.
2. Insert batteries. Make sure to match the polarity:
(+) to (+) and (–) to (–).
3. Replace the cover.
Check to be sure you have all of the following supplied accessories.
The number in the parentheses indicates the quantity of the pieces
supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
• Video cord (1)
• Speaker cords
6 m (4)*: For left front speaker, right front speaker, center
speaker, and subwoofer
10 m (2)*: For left rear speaker and right rear speaker
* The lengths of the speaker cords above are approximate.
If anything is missing, contact your dealer immediately.
If the range or effectiveness of the remote control decreases, replace
the batteries. Use two R6P (SUM-3)/AA(15F) type dry-cell
batteries.
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
• Place batteries in the remote control so they match the polarity: (+)
to (+) and (–) to (–).
• Use the correct type of batteries. Batteries that look similar may
differ in voltage.
• Always replace both batteries at the same time.
• Do not expose batteries to heat or flame.
4
Connecting the FM and AM Antennas
132
If FM reception is poor, connect
outdoor FM antenna (not supplied).
A
N
T
E
N
COAXIAL
FM Antenna (supplied)
N
A
FM 75
AM LOOP
If AM reception is poor, connect single vinyl-covered
wire (not supplied).
AM Loop Antenna
(supplied)
AM
EXT
Snap the tabs on the loop into
the slots of the base to
assemble the AM loop antenna.
CENTER
SUBWOOFER
AC IN
SPEAKER
FM antenna connection
Connect the supplied FM antenna to the COAXIAL FM 75 Ω
terminal as temporary measure.
Extend the supplied FM antenna horizontally.
• If reception is poor, connect an outdoor antenna.
Before attaching a 75 Ω coaxial cable (with a standard type
connector), disconnect the supplied FM antenna.
REAR
SPEAKERS
RIGHT LEFT
FRONT
SPEAKERS
RIGHT LEFT
OPTICAL
DIGITAL INDIGITAL
OUT
ANALOG VIDEO OUT
IN
L
VIDEO
R
S-VIDEO
AUX
A
N
T
E
N
COAXIAL
N
A
FM 75
YPBP
CONPONENT VIDEO OUT
AM LOOP
R
Center unit
AM antenna connection
Connect the supplied AM loop antenna to the AM LOOP terminals.
Connect the white cord to the AM EXT terminal, and the black cord
terminal.
to
Turn the loop until you have the best reception.
• If reception is poor, connect an outdoor single vinyl-covered wire
to the AM EXT terminal. (Keep the AM loop antenna connected.)
Note:
If the AM loop antenna wire is covered with vinyl, remove
the vinyl by twisting it as shown in the diagram.
AM
EXT
5
Getting Started
Speaker Layout Diagram
Center unit
STANDBY
STANDBY/ON
DVD DIGITAL CINEMA SYSTEM TH-A35
DIGITAL
COMPACT
DIGITAL•EX
SUPER VIDEO
PRO LOGIC
SURROUND
VOLUME
DSPSURROUNDSOURCE
Left front
speaker
PHONES
Subwoofer
Left rear
speaker
Center speaker
Right front
speaker
Right rear
speaker
AC IN
SUBWOOFER
CAUTION
SUBWOOFER IMPEDANCE
10 OHMS
To subwoofer
To center speaker
CENTER
SPEAKER
SPEAKER IMPEDANCE
REAR
SPEAKERS
RIGHT LEFT
CAUTION
6-8 OHMS
FRONT
SPEAKERS
RIGHT LEFT
To left front speaker
To right front speaker
To left rear speakerTo right rear speaker
Y
6
Connecting the Speakers
Connect the satellite speakers and subwoofer to the terminals on the
rear panel using speaker cords supplied.
Color labels are attached to the speaker cords to indicate the speaker
and the terminal to which each is to be connected.
• The five satellite speakers can be used for any positions—center,
front left and right, and rear left and right.
• Connect the color labeled cord to the color (+) terminal, and the
other cord to the black (–) terminal respectively.
CAUTION:
Use speakers with the SPEAKER IMPEDANCE indicated by the
speaker terminals.
Connecting speaker cords to the terminals
When setting the speakers
To obtain the best possible sound from this system, you need to
place all the speakers except the subwoofer at the same distance
from the listening position with each front faced toward the listener.
Since bass sound is less-directional, but normally place it in
between right and left front speaker shown as below.
Left front
speaker
Subwoofer
Center speaker
Right front
speaker
132
1
Open the terminal clamp.
2
Insert the speaker cord.
3
Close the clamp.
Notes:
• If the speaker cord is covered with vinyl, remove the
vinyl by twisting it as shown in the diagram.
• Make sure the core wire of speaker cords do not
expose to out of the terminals. This could cause
short-circuit.
Left rear
speaker
Right rear
speaker
If your speakers cannot be placed at the same distance from the
listening position
You can adjust the delay time of the center speaker and rear
speakers. For in-depth information about adjusting the delay time,
see “Setting Menu” on pages 53 and 54.
Note:
Subwoofer phase is closely related with the distance from the
listening position to the front speakers and subwoofer. You can change
the phase to obtain better bass sound by connecting the speaker
cords to the terminals of the subwoofer inversely—the color labeled
cord to the black terminal, and the black cord to the color terminal.
CAUTION:
• When attaching the satellite speakers on the wall, have them
attached to the wall by a qualified person.
DO NOT attach the satellite speakers on the wall by yourself to
avoid an unexpected damage of their falling from the wall, caused
by incorrect attachment or weakness in the wall.
• Care is required in selecting a location for attaching speakers to the
wall. Injury to personnel, or damage to equipment, may result if the
speakers are attached in a location which interferes with daily
activities.
7
Getting Started
Connecting Audio/Video Component
Turn the power off to all components before connections.
Audio Component connection
Connect the other component to the center unit with the
audio cord.
Use the cords supplied with the other component or
purchase them at an electric appliance store.
Optical digital cord (not supplied)
A
Audio cord (not supplied)
B
Input Terminals
Illustrations of the input/output terminals below are typical
examples.
When you connect the other component, refer also to its
manuals since the terminal name actually printed on the rear
vary among the components.
If you connect a sound-enhancing device such as a graphic
equalizer between the source component and the center
unit, the sound output through this system may be
distorted.
DBS Tuner
MD Recorder
DIGITAL
IN
OPTICAL
DIGITAL INDIGITAL
OUT
Center unit
ANALOG VIDEO OUT
IN
L
VIDEO
R
ANALOG
IN
S-VIDEO
L
R
AUX
Before connecting an
optical digital cord, unplug
the protective plug.
A
A
N
T
E
N
COAXIAL
N
A
FM 75
YP
CONPONENT VIDEO OUT
AM LOOP
BPR
AM
EXT
B
DIGITAL
OPTICAL OUT
AUDIO
OUT
DBS Tuner
MD Recorder
Cassette Deck
VCR
LEFT
RIGHT
TV
Output Terminal
DIGITAL
OUT
8
Before connecting an
optical digital cord, unplug
the protective plug.
A
MD Recorder
DIGITAL
OPTICAL IN
• If you use the OPTICAL DIGITAL OUT to connect the external component, you
select the output signal type correctly. See “Audio Menu” on page 53.
TV connection
The S-video cord and the component video cord are not supplied with this system.
Use the cords supplied with another components or purchase them at an electric appliance store.
A
Video cord (supplied) Component video cord (not supplied)
B
S-video cord (not supplied)
You can select one of three connection types—A, B, and C.
• If your TV has S-video (Y/C-separation) and/or component video
(Y, PB, PR) jacks, connect them using an S-video cord (not
supplied)B and/or component video cord (not supplied)C.
By using these jacks, you can get a better picture quality—in the
order : Component video > S-video > Composite video.
• If you use the S-video cord to connect the TV, you select the
video signal type correctly. See “Picture Menu” on page 52.
VIDEO OUT
VIDEO
C
• If your TV supports the progressive video input, you can enjoy a
high quality picture by making the progressive scanning mode
active (see page 11.)
A
B
S-VIDEO
TV
CENTER
REAR
SUBWOOFER
SPEAKER
AC IN
RIGHT LEFT
SPEAKERS
FRONT
SPEAKERS
RIGHT LEFT
YPBP
CONPONENT VIDEO OUT
R
OPTICAL
DIGITAL INDIGITAL
OUT
ANALOG VIDEO OUT
IN
L
VIDEO
R
S-VIDEO
AUX
A
N
T
E
N
COAXIAL
N
A
FM 75
YPBP
CONPONENT VIDEO OUT
AM LOOP
AM
EXT
R
Y
C
PB/C
B
P
R/CR
Now, you can plug the power cord of the center unit into the AC outlet.
Notes:
• Keep the power cord away from the connecting cords and the antenna cords. The power cord may cause noise or screen interference.
• Connecting to a TV through a VCR, or to a TV with a built-in VCR, may cause distortion of picture.
9
TV Setting
SOUND
CENTER
1234
5678
TEST
9
DVD
CHOICE
7
DVD FM/AM
CONTROL
TV
TV VOL
TOP
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
RETURN DIMMER DSP
STANDBY/ON
VCRTV
SUBWOOFER
REAR-RREAR-L
CLEAR SETTING FM MODE
0
AUX
PROGRESSIVE
TV/VIDEO
VCR
MUTING
REC/MEMORY
AUDIO VOL
ENTER
SLOW
SUB TITLE ANGLE ZOOM
SLEEP
RM-STHA35U
DVD CINEMA SYSTEM
AUDIO
SEARCH
MENU
ON SCREEN
SURROUND
PROGRESSIVE
REC/MEMORY
3/2/5/∞
ENTER
Changing the Color System
This system is compatible with the PAL and NTSC systems. Select
the color system to match the color system of your TV. Make sure
that the color system of a DVD, Video CD, or SVCD disc labeled on
the package matches your TV.
From the remote control ONLY:
1
Press DVD.
DVD
The source changes to DVD.
3
If a disc is not loaded, go to step
2
Press 7.
.
Playback stops.
3
Press REC/MEMORY
REC/MEMORY
and ENTER at once.
• Each time you press the
both buttons, the TV
system alternates between “NTSC” and
“PAL.”
NTSC: Select this when the color system of your TV is NTSC.
PAL: Select this when the color system of your TV is PAL.
Note:
You can also select the TV system in the choice menu. See “Picture
Menu” on page 52.
ENTER
Changing the Scanning Mode
This system supports the progressive scanning system (480p*) as
well as the conventional interlaced scanning system (480i*).
If your TV equipped with component video jacks supports the
progressive video input, you can enjoy a high quality picture by
activating the progressive scanning mode.
• Refer also to the instruction manuals supplied with your TV.
• If your TV equipped with component video jacks does not support
the progressive video input, do not change the scanning mode to
the progressive scanning mode (P–SCAN MODE.)
* 480p and 480i indicate the number of scanning lines and scanning
format of a video signal.
• 480p indicates 480 scanning lines with progressive format.
• 480i indicates 480 scanning lines with interlaced format.
You can select the scanning mode if your TV equipped with
component video jacks supports the progressive video input.
10
From the remote control ONLY:
1
Press DVD.
2
Press PROGRESSIVE.
• Each time you press the button, the scanning
mode alternates between “INTERLACE” and
“P–SCAN.”
INTERLACE:
Select this if your TV does not support the progressive video input
(conventional TV).
P (Progressive)–SCAN:
Select this if your TV equipped with component video jacks
supports the progressive video input.
DVD
PROGRESSIVE
Adjusting the Pictures
You can adjust parameters that affect the appearance of picture.
From the remote control ONLY:
1
Press CHOICE while playing back a
disc.
Video Enhance menu appears on TV-screen.
Video Enhance
Brightness
Edges
Color
Contrast
2
Press cursor 5/∞ repeatedly to
CHOICE
select a parameter you want to
adjust.
• Adjust gradually to show preferable
appearance by confirming the picture.
ENTER
When you select the “P-SCAN”, P-SCAN indicator lights up on the
display.
Notes:
• If you press PROGRESSIVE while playing back a disc, playing
back stops.
• Some progressive TVs and High-Definition TVs are not fully
compatible with this system, resulting in the unnatural picture when
playing back a DVD in the progressive scanning mode.
In such a case, change the scanning mode to “INTERLACE.”
To check the compatibility of your TV, contact your local JVC
customer service center.
• All JVC progressive TVs and High-Definition TVs are fully
compatible with this system.
About scanning system
The conventional scanning method to display video signals on
the TV screen is called “Interlaced scanning.” With this method,
only half of the horizontal lines (called a “field”) are displayed
at a time. So two fields complete a single picture (frame); i.e.,
the first field, containing all the odd-numbered lines, is followed
by the second field, containing all the even-numbered lines.
On the other hand, the Progressive scanning system scans all
horizontal lines at a time, so you can double the number of
scanning lines displayed at a time, resulting in a flicker-free,
high-density picture.
To enjoy the progressive scanned picture, a monitor (or TV or
projector) connected to the system must support the progressive
video inputs.
Depending on the material source format, DVD video can be
classified into two types; film source and video source (note that
some DVD video contain both film source and video source).
Film sources are recorded as 24-frame-per-second data, while
(NTSC) video sources are recorded as 30-frame-per-second (60field-per-second interlaced).
When this system plays back a film source data, uninterlaced
progressive output signals are created using the original data.
When a video source is played back, the unit interleaves lines
between the interlaced lines to create the pseudo uninterlaced
picture and outputs as the progressive signals.
Brightness: Controls the brightness of the screen.
Edges: Controls the sharpness of the screen.
Color: Controls the color of the screen.
Contrast: Controls the contrast of the screen.
3
Press cursor 3/2 repeatedly to
change the setting.
ENTER
4
Press CHOICE.
Video Enhance menu disappears.
CHOICE
Note:
If you turn off the unit, the video enhance setting return to initial
setting.
11
Basic DVD Operations
This manual mainly explains operations using the buttons on
the remote control. You can also use the buttons on the center
unit if they have the similar names (or marks) as those on the
remote control.
If operations using the center unit are different from those
using the remote control, they are then explained.
STANDBY/ON
AUDIO
VCRTV
CENTER
1234
5678
9
CONTROL
TV
TV VOL
SUBWOOFER
REAR-RREAR-L
CLEARTEST SETTING FM MODE
0
AUX
PROGRESSIVE
SEARCH
TV/VIDEO
VCR
MUTING
REC/MEMORY
AUDIO VOL
ENTER
ON SCREEN
SLOW
SUB TITLE ANGLE ZOOM
SURROUND
SLEEP
MENU
1
AUDIO
TV/VIDEO
MUTING
6
SURROUND
TV
2
DVD
5
AUDIO VOL
+/–
7
7
6
DSP
SOUND
DVD FM/AM
TOP
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
RETURN DIMMER DSP
4
3
2
Select the Source
Press DVD.
The source changes to DVD.
3
Load a DVD
On the front panel ONLY:
Press 0 to open the disc tray, then place a DVD
correctly with its label side up.
CORRECT INCORRECT
• DO NOT use the disc stabilizer.
4
Start Playback
Press 3.
The disc tray closes. “READING” appears for a
while.
• You can also start playback by closing the disc
tray using 0 on the front panel.
5
Adjust the Volume
DVD
RM-STHA35U
DVD CINEMA SYSTEM
• For in-depth information about DVD operations, see
pages 24 to 33.
1
Turn On the Power
Before turning on the system, turn on your TV and select the correct
video input. (See the manual supplied with your TV.)
• When you use a JVC’s TV, you can turn on your TV by pressing
on the remote control, and select the video input by
TV
pressing TV/VIDEO. (If your TV is not a JVC’s, see “Operating
Other Manufacturers’ TV” on page 57.)
• For changing the OSD messages—the information on the TV
screen—into the desired language, see “ Language Menu” on
pages 51.
Press AUDIO
panel).
The STANDBY lamp goes off and the illumination lamp
(or STANDBY/ON on the front
AUDIO
on the center unit lights up. The source indication
selected previously appears on the display.
From the remote control :
To increase the volume,
press and hold AUDIO VOL +.
AUDIO VOL
To decrease the volume,
press and hold AUDIO VOL –.
On the front panel :
VOLUME
To increase the volume,
turn VOLUME control clockwise.
To decrease the volume,
turn VOLUME control counterclockwise.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing AUDIO VOL + or – repeatedly, you can adjust the
volume level step by step.
• The volume level can be adjusted within 64 steps—
“MIN (minimum),” 01 to 62, and “MAX (maximum).”
• If you have turned off the unit with the volume level set at more than
level “25,” the volume level will be automatically set at level “25” next
time you turn on the unit.
12
To turn off the sounds temporarily
From the remote control ONLY:
Press MUTING.
To restore the sound, press MUTING again.
• Pressing AUDIO VOL + or – also restores the sound.
6
Activate Surround or DSP Mode
You can enjoy three kinds of surround—Digital Multichannel
Surround (Dolby Digital and DTS Digital Surround), Dolby Pro
Logic II and DSP modes.
MUTING
Digital Multichannel Surround—Dolby Digital
and DTS Digital Surround
Dolby Digital or DTS Digital Surround takes effect only when you
enjoy a disc encoded with its signals.
To activate Dolby Digital or DTS Digital Surround
When a disc encoded with the Dolby Digital or DTS Digital
Surround is loaded, the system detects it and starts playing the disc
automatically with Multichannel Surround activated.
– For in-depth information about surround modes, see “Creating
Realistic Sound Fields” on pages 21 to 22.
Dolby Pro Logic II—Pro Logic II Music and Pro
Logic II Movie
To activate Pro Logic II modes
Press SURROUND.
The current Pro Logic II mode appears on the display
for a while.
• Each time you press the button, Pro Logic II mode
changes as follows:
SURROUND
Note:
Before activating the Surround or DSP mode, adjust the speaker
setting to bring out the best performance from this system.
For in-depth information about adjusting the speaker setting, see
“Setting Menu” on pages 53.
7
Stop Playback
Press 7 twice.
Playback stops completely.
• This system can memorize the end point even when you
press 7 once. When you start playback again by
pressing 3, playback begins from where it has been stopped—
Resume play.
To remove the loaded disc
Press 0.
“OPEN” appears on the display and the disc tray comes
out.
To close the disc tray, press 0 again.
To prohibit disc ejection
On the front panel ONLY:
Press and hold 6 and 4 for more than
3 seconds.
“LOCKED” appears on the display, and the
disc tray is locked.
To cancel the prohibition, press and hold
6 and 4 for more than 3 seconds.
“UNLOCK” appears on the display, and the
disc tray is unlocked.
PL II MUSIC PL II MOVIE
PL II OFF
• When Dolby Pro Logic II mode is activated, the
II indicator lights up on the display.
– For in-depth information about Dolby Pro Logic II modes, see
“Creating Realistic Sound Fields” on pages 21 to 22.
PRO LOGIC
DSP modes—CONCERT, STADIUM, HALL,
THEATER, LIVE HOUSE
To activate DSP modes
Press DSP.
The current DSP mode appears on the display for a
while.
• Each time you press the button, DSP mode changes as
follows:
LIVE HOUSE
HALL
THEATERDSP OFF
– For in-depth information about DSP modes, see “Creating
Realistic Sound Fields” on pages 21 to 22.
CONCERT
STADIUM
DSP
To turn off the power (into standby)
Press AUDIO (or STANDBY/ON on the front
panel).
The illumination lamp goes off and the STANDBY lamp
lights up.
• If you press AUDIO (or STANDBY/ON on the front
panel) while the disc tray is kept open, the disc tray closes
automatically, then the system is turned off.
• A small amount of power is consumed even in standby mode. To
turn the power off completely, unplug the AC power cord.
AUDIO
13
Basic VCD/CD Operations
2
Select the Source
STANDBY/ON
AUDIO
VCRTV
CENTER
1234
5678
9
CONTROL
TV
TV VOL
DVD CINEMA SYSTEM
SUBWOOFER
REAR-RREAR-L
CLEARTEST SETTING FM MODE
0
AUX
PROGRESSIVE
SEARCH
TV/VIDEO
VCR
MUTING
REC/MEMORY
AUDIO VOL
ENTER
ON SCREEN
SLOW
SUB TITLE ANGLE ZOOM
SURROUND
SLEEP
RM-STHA35U
MENU
1
AUDIO
TV/VIDEO
6
SURROUND
TV
2 DVD
5
AUDIO VOL
+/–
7
7
6
DSP
SOUND
DVD FM/AM
TOP
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
RETURN DIMMER DSP
• SVCD can be operated by using the VCD operation
procedure.
• For in-depth information about VCD/CD operations,
see pages 24, 25, and 34 to 39.
MUTING
4
3
Press DVD.
3
Load a VCD/CD
DVD
On the front panel ONLY:
Press 0 to open the disc tray, then place a disc
correctly with its label side up.
CORRECT INCORRECT
• When using a CD single (8 cm), place it on the inner circle of the
disc tray.
• Continued use of irregular shape CDs (heart-shape, octagonal,
etc.) can damage the center unit.
• DO NOT use the disc stabilizer.
4
Start Playback
Press 3.
The disc tray closes. “READING” appears for a while.
• You can also start playback by closing the disc tray
using 0 on the front panel.
5
Adjust the Volume
1
Turn On the Power
Before turning on the system, turn on your TV if necessary and
select the correct video input. (See the manual supplied with your
TV.)
• When you use a JVC’s TV, you can turn on your TV by pressing
TV on the remote control, and select the video input by
pressing TV/VIDEO. (If your TV is not a JVC’s, see “Operating
Other Manufacturers’ TV” on page 57.)
• For changing the OSD messages—the information on the TV
screen—into the desired language, see “ Language Menu” on
pages 51.
Press AUDIO
(or STANDBY/ON on the front panel).
AUDIO
The STANDBY lamp goes off and the illumination lamp
on the center unit lights up. The source indication selected
previously appears on the display.
From the remote control :
To increase the volume,
AUDIO VOL
press and hold AUDIO VOL +.
To decrease the volume,
press and hold AUDIO VOL –.
On the front panel :
VOLUME
To increase the volume,
turn VOLUME control clockwise.
To decrease the volume,
turn VOLUME control counterclockwise.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing AUDIO VOL + or – repeatedly, you can adjust the
volume level step by step.
• The volume level can be adjusted within 64 steps—
“MIN (minimum),” 01 to 62 and “MAX (maximum).”
• If you have turned off the unit with the volume level set at more than
level “25,” the volume level will be automatically set at level “25” next
time you turn on the unit.
14
To turn off the sounds temporarily
From the remote control ONLY:
Press MUTING.
To restore the sound, press MUTING again.
• Pressing AUDIO VOL + or – also restores the sound.
6
Activate Surround or DSP Mode
You can enjoy Dolby Pro Logic II mode and DSP modes.
MUTING
Dolby Pro Logic II—Pro Logic II Movie and Pro
Logic II Music
7
Stop Playback
Press 7 twice.
Playback stops completely.
• This system can memorize the end point even when
you press 7 once. When you start playback again by
pressing 3, playback begins from where it has been stopped—
Resume play.
To remove the loaded disc
Press 0.
“OPEN” appears on the display and the disc tray comes
out.
To close the disc tray, press 0 again.
To activate Pro Logic II modes
Press SURROUND.
The current Pro Logic II mode appears on the display
for a while.
• Each time you press the button, Pro Logic II mode
changes as follows:
SURROUND
PL II MUSIC PL II MOVIE
PL II OFF
• When Dolby Pro Logic II mode is activated, the PRO LOGIC
II indicator lights up on the display.
– For in-depth information about Dolby Pro Logic II modes, see
“Creating Realistic Sound Fields” on pages 21 to 22.
DSP modes—CONCERT, STADIUM, HALL,
THEATER, LIVE HOUSE
DSP modes take effect only when you enjoy a disc recorded using
Linear PCM.
To activate DSP modes
Press DSP.
The current DSP mode appears on the display for a
while.
• Each time you press the button, DSP mode changes
as follows:
LIVE HOUSE
HALL
CONCERT
DSP
To prohibit disc ejection
On the front panel ONLY:
Press and hold 6 and 4 for more than
3 seconds.
“LOCKED” appears on the display, and the
disc tray is locked.
To cancel the prohibition, press and hold
6 and 4 for more than 3 seconds.
“UNLOCK” appears on the display, and
the disc tray is unlocked.
To turn off the power (into standby)
Press AUDIO (or
STANDBY/ON on the front panel).
The illumination lamp goes off and the STANDBY lamp
lights up.
• If you press AUDIO
panel) while the disc tray is kept open, the disc tray closes
automatically, then the system is turned off.
• A small amount of power is consumed even in standby mode. To
turn the power off completely, unplug the AC power cord.
(or STANDBY/ON on the front
AUDIO
THEATERDSP OFF
– For in-depth information about DSP modes, see “Creating
Realistic Sound Fields” on pages 21 to 22.
Note:
Before activating the Surround or DSP mode, adjust the speaker
setting to bring out the best performance from this system.
For in-depth information about adjusting the speaker setting, see
“Setting Menu” on pages 53.
STADIUM
15
Basic Tuner Operations
STANDBY/ON
AUDI O
VCRTV
CENTER
1234
5678
9
CONTROL
TV
TV VOL
DVD CINEMA SYSTEM
SUBWOOFER
REAR-RREAR-L
SETTINGCLEAR
0
AUX
PROGRESSIVE
TV/VIDEO
MUTING
ENTER
SLEEP
SEARCH
REC/MEMORY
ON SCREEN
SLOW
SURROUND
VCR
AUDIO VOL
SUB TITLE ANGLE ZOOM
RM-STHA35U
MENU
1
5
2
FM/AM
3
AUDIO VOL
+ / –
4
TUNING
DOWN/UP
5
DSP
SOUND
TEST FM MODE
DVD FM/AM
TOP
MENU
CHOICE
DOWN - TUNING - UP
AUDIO
RETURN DIMMER DSP
For in-depth information about tuner operations, see
“Tuner Operations” on pages 48 to 49.
AUDIO
MUTING
SURROUND
On the front panel:
SOURCE
Press SOURCE repeatedly until the desired band
(TUNER FM or TUNER AM) appears on the
display.
The last received station of the selected band is tuned into.
• Each time you press the button, the source changes as follows:
DVD
TUNER FM
TUNER AM
ANALOG INDIGITAL IN
3
Adjust the Volume
From the remote control :
To increase the volume,
press and hold AUDIO VOL +.
To decrease the volume,
press and hold AUDIO VOL –.
On the front panel :
To increase the volume,
turn VOLUME control clockwise.
To decrease the volume,
turn VOLUME control counterclockwise.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing AUDIO VOL + or – repeatedly, you can adjust the
volume level step by step.
• The volume level can be adjusted within 64 steps—
“MIN (minimum),” 01 to 62 and “MAX (maximum).”
• If you have turned off the unit with the volume level set at more than
level “25,” the volume level will be automatically set at level “25” next
time you turn on the unit.
AUDIO VOL
VOLUME
1
Turn On the Power
Press AUDIO (or STANDBY/ON on the front
panel).
The STANDBY lamp goes off and the illumination lamp
lights up on the center unit.
The source indication selected previously appears on the
display.
2
Select the Band
From the remote control:
Press FM/AM.
The last received station of the selected band is tuned
into.
• Each time you press the button, the band alternates
between FM and AM.
16
AUDIO
FM/AM
To turn off the sounds temporarily
From the remote control ONLY:
Press MUTING.
To restore the sound, press MUTING again.
• Pressing AUDIO VOL + or – also restores the sound.
4
Tune into a Station
From the remote control:
Press and hold TUNING UP or DOWN until
the station frequency starts changing
continuously on the display.
The system starts searching for a station.
When a station of sufficient signal strength is tuned in, the system
stops searching, and the TUNED indicator lights up on the display.
On the front panel:
Press and hold 4 or ¢ until the station frequency starts
changing continuously on the display.
MUTING
DOWN - TUNING - UP
Notes:
• When an FM stereo program is received, the STEREO indicator
also lights up.
• When you press the button repeatedly, the frequency changes step
by step.
5
Activate Surround or DSP Mode
You can enjoy Dolby Pro Logic II mode and DSP modes.
Dolby Pro Logic II—Pro Logic II Movie and Pro
Logic II Music
To activate Pro Logic II modes
Press SURROUND.
The current Pro Logic II mode appears on the display
for a while.
• Each time you press the button, Pro Logic II mode changes as
follows:
SURROUND
PL II MUSIC PL II MOVIE
PL II OFF
• When Dolby Pro Logic II mode is activated, the
II indicator lights up on the display.
PRO LOGIC
AUDIO
To turn off the power (into standby)
Press AUDIO (or STANDBY/ON on the front
panel) again.
The illumination lamp goes off and the STANDBY lamp lights up.
• A small amount of power is consumed even in standby mode. To
turn the power off completely, unplug the AC power cord.
– For in-depth information about Dolby Pro Logic II modes, see
“Creating Realistic Sound Fields” on pages 21 to 22.
DSP modes—CONCERT, STADIUM, HALL,
THEATER, LIVE HOUSE
To activate DSP modes
Press DSP.
The current DSP mode appears on the display for a
while.
• Each time you press the button, DSP mode changes as
follows:
LIVE HOUSE
HALL
THEATERDSP OFF
– For in-depth information about DSP modes, see “Creating
Realistic Sound Fields” on pages 21 to 22.
Note:
Before activating the Surround or DSP mode, adjust the speaker
setting to bring out the best performance from this system.
For in-depth information about adjusting the speaker setting, see
“Setting Menu” on pages 53.
CONCERT
STADIUM
DSP
17
Loading...
