LCD PROJECTOR
Operating Instructions
Model No.
LX-P1010ZU/
LX-P1010ZE
Please read these instructions completely before operating
this LCD Projector.
By clicking on the red highlighted words in this document, you
can go directly to a support page.
Top page
Dear JVC Customer:
This instruction manual provides all the necessary operating
information that you might require. We hope it will help you to
get the most performance out of your new product, that you will
be pleased with your JVC LCD Projector.
For your own protection and prolonged operation of your LCD
Projector, please be sure to read the “Important Safeguards”
carefully, before use.
Things You Should Know
Caution:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician
for help.
Previous
screen
Continued on the next page...
2
Things You Should Know
Declaration of Conformity (USA only)
Model Number: LX-P1010ZU/LX-P1010ZE
Trade Name:
Responsible party: PSEL Dept. JVC America Corp.
Address: 1700 Valley Road Wayne,N.J 07407
Telephone number: (973) 315-5000
This device complies with Part 15 of the FCC Rules, Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Warning: (USA only)
To assure continued FCC compliance, use only the provided grounded
power supply cord and prevent undesirable interference, use only the
provided shielded computer cable with 2 ferrite cores while
connecting LCD to computer and all other connecting cables should be
shielded. Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.
Warning: (E.U. only)
To assure continued CE Mark compliance, use only the provided
earthed power supply cord and prevent undesirable interference, use
only the provided shielded computer cable with 2 ferrite cores while
connecting LCD to computer and all other connecting cables should be
shielded.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to operate
this equipment.
© 2000 VICTOR COMPANY OF JAPAN, LIMITED
All product/brand names are trademarks or registered trademarks of the
respective holders.
Previous
screen
3
Important Safeguards
CAUTION: Please read all of these instructions
before you operate your LCD Projector.
Save these instructions for future
reference.
Machine Noise Information Ordinance 3. GSGV, January 18, 1991:
The sound pressure level at the operator position is equal or less
than 44 dB (A) according to ISO 7779. (However, this is when the
ambient temperature is less than
30 °C.)
Electrical energy can perform many useful functions.
This LCD Projector has been engineered and
manufactured to meet applicable safety standards. But
IMPROPER USE CAN RESULT IN POTENTIAL
ELECTRICAL SHOCK OR FIRE HAZARDS. In order not
to defeat the safeguards incorporated into this LCD
Projector, observe the following basic rules for its
installation, use and servicing.
1 Unplug the LCD Projector from the wall outlet before
cleaning.
2 Do not use liquid cleaners or aerosol cleaners. Use a
soft dry cloth to clean the LCD Projector unit. If the
unit is very dirty, wet a cloth with neutral detergent,
squeeze it tight, wipe the unit with it, and finish by
wiping with a dry cloth. Do not use a chemical duster
or polisher-cleaner because it can adversely affect
the unit and peel the paint coat.
3 Do not use attachments not recommended by JVC,
as they may cause hazards.
Previous
screen
Continued on the next page...
4
Important Safeguards
4 Do not use the LCD Projector near water; for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in
a wet basement, near a swimming pool, etc. Never spill
liquid into the LCD Projector.
5 Do not place the LCD Projector on an
unstable cart, stand, or table. The LCD
Projector may fall, which may cause
serious injury to a child or an adult,
and/or serious damage to the unit. Use
only with a cart or stand recommended
by its manufacturer, as being suitable for use with the
LCD Projector.
6 The LCD Projector equipment and cart combinations
should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the equipment
and cart combination to overturn.
7 Slots and openings in the cabinet back and bottom are
provided for ventilation. To ensure reliable operation of
the LCD Projector and to protect it from overheating,
these openings must not be blocked or covered. These
openings should never be covered with cloth or other
material. The bottom opening should not be blocked by
placing the LCD Projector on a bed, sofa, rug, or other
similar surface. The LCD Projector should not be
placed near or over a radiator or heating vent. The
LCD Projector should not be placed in a built-in
installation such as a bookcase unless proper
ventilation is provided.
Previous
screen
Continued on the next page...
5
Important Safeguards
8 The LCD Projector should be operated only from the
type of power source indicated on the back of the LCD
Projector or in the specifications. If you are not sure of
the type of power supplied to your home, consult your
LCD Projector dealer or local power company.
9 Do not allow anything to rest on the power cord. Do
not place the LCD Projector where the cord will be
walked on.
10 Follow all warnings and instructions marked on the
LCD Projector.
11 As a safety feature, the LCD Projector is equipped with
a 3-prong grounded plug. The 3-prong grounded plug
will fit only into a grounding type power outlet. If the
plug does not fit, use an adaptor that is properly
grounded or have an electrician install a grounded
type outlet. Do not attempt to modify this AC plug.
12 For added protection of the LCD Projector during a
lightning storm, or when it is left unattended or not in
use for long periods of time, unplug it from the wall
outlet and disconnect any cable systems. This will
prevent damage to the projector due to lightning and
power-line surges.
13 Do not overload wall outlets and extension cords with
too many products, because this can result in fire or
electric shock.
Previous
screen
Continued on the next page...
6
Important Safeguards
14 Never push objects of any kind into the LCD Projector
through cabinet slots as they may touch dangerous
voltage points or short out parts, which could result in
a fire or electric shock.
15 Do not attempt to service the LCD Projector yourself.
Opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
16 Unplug the LCD Projector equipment from the wall
outlet and refer servicing to qualified service
personnel under the following conditions:
A.When the power cord or plug is damaged or frayed.
B.If liquid has been spilled into the LCD Projector.
C.If the LCD Projector has been exposed to rain or
water.
D.If the LCD Projector does not operate normally when
you follow the operating instructions. Adjust only
those controls that are covered by the operating
instructions; improper adjustment of other controls
may cause damage and will often require extensive
work by a qualified technician to restore the LCD
Projector to normal operation.
E.If the LCD Projector has been dropped or the
cabinet has been damaged.
F. When the LCD Projector exhibits a distinct change in
performance – this indicates a need for service.
Previous
screen
Continued on the next page...
7
Important Safeguards
17 Upon completion of any service or repairs to the LCD
Projector, ask the service technician to perform a
routine safety check to determine that the LCD
Projector is in safe operating condition.
18 When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer that have the same
characteristics as the original parts. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
19 Air filter should be cleaned every 100 lamp on hours.
The LCD Projector may become too hot if filter is not
cleaned when required.
20 If lens becomes dirty, or smudged, clean with a clean,
dampened cloth. Never touch the lens with your
fingers.
21 Do not look directly into the aperture and lens while
operating as this may result in damage to your eyes.
Previous
screen
Continued on the next page...
8
Important Safeguards
IMPORTANT: THE MOULDED PLUG (U.K. only)
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT
CAREFULLY.
This appliance is supplied with a moulded three pin mains
plug for your safety and convenience. A 13 amp fuse is
fitted in this plug. Should the fuse need to be replaced, please
ensure that the replacement fuse has a rating of 13 amps and
that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of
the fuse.
If the plug contains a removable fuse cover, you must ensure
that it is refitted when the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
JVC Dealer.
If the fitted moulded plug is unsuitable for the socket
outlet in your home, then the fuse should be removed and
the plug cut off and disposed of safely. There is a danger
of severe electrical shock if the cut off plug is inserted
into any 13 amp socket.
If a new plug is to be fitted, please observe the wiring code as
shown below.
If in any doubt, please consult a qualified electrician.
Previous
screen
Continued on the next page...
9
Important Safeguards
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are coloured in
accordance with the following code:
Green-and-Yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wire in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows.
The wire which is coloured GREEN-AND-YELLOW must be
connected to the terminal in the plug which is marked with
the letter E or by the Earth symbol
or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the
terminal in the plug which is marked with the letter N or
coloured BLACK.
or coloured GREEN
The wire which is coloured BROWN must be connected to
the terminal in the plug which is marked with the letter L or
coloured RED.
How to replace the fuse. Open the fuse
compartment with a screwdriver and
replace the fuse.
Previous
screen
FUSE
10
LCD Projector Features
1 Compact & Lightweight
A compact, lightweight liquid crystal projector with the
mobility for mobile presentations as well.
2 Built-in Simple Stand
The Built-in Simple Stand makes it possible to match
the projection angle with the basic use environment of
your office with one-touch ease.
3 Attachable/Removable Swivel Stand
Flexible settings are possible because the projected
image height and left/right tilt can be adjusted freely.
4 One-touch Auto Setup
One-touch image adjustments of RGB input can be
made. The unit detects the condition (up/down) of the
simple stand and automatically corrects keystone
distortion.
5 Compatible with most Personal Computers
The RGB input accepts signals from VGA, SVGA,
XGA, SXGA, and Macintosh compatible computers
with no additional hardware.
6 Supports Component Video (YPBPR) Input
This unit supports progressive DVD and HDTV (480 i/
480 p/625 i/720 p/1 080 i) when components are
connected.
Previous
screen
Continued on the next page...
11
LCD Projector Features
7 Accommodates all International Broadcast Video
Signal Formats
The LCD Projector accepts NTSC/PAL/SECAM/PAL-M/
PAL-N/NTSC4.43 video signal formats.
8 Digital Zoom and Freeze Feature
With remote control operation, you can display a
enlarged portion of the screen up to 5 times. You can
also display a freeze frame (paused) screen.
9 On-board Card Type Wireless Remote Control
Keys necessary for basic operation have been simply
arranged on this compact remote control which can be
stored neatly in the unit.
10 On Screen Display
In addition to English, you can select German, French,
Spanish, Italian, Japanese, and Chinese.
11 Automatic Universal Power Supply
This unit has an operating voltage range of AC 100 V 240 V.
12 CD-ROM Manual
Because this is an electronic manual, by simply
clicking on the link given for each item of information,
you can go directly to the related page for instructions.
Previous
screen
Continued on the next page...
12
LCD Projector Features
13 Image Quality Select Feature, R/G/B Level Adjust
Feature
With the Image Quality mode switch (Dynamic/
Natural) you can also fine-adjust the white balance of
the projected image.
14 Frontal Air Vent Design
Vented air will not blow on persons located to the side
or in rear of the projector and light leakage will not be
a problem with the Frontal Air Vent design.
Equipped with a variety of convenient functions
A variety of functions such as the following have been
provided.
•A blue screen is projected (at start-up only) when no signal
is being input.
•Freeze functions for video and audio signals can be toggled
on and off.
•The input signal display function can be toggled on and off.
•16:9 (wide) screen projection is provided.
•Two projection modes (directions) to choose from.
Previous
screen
13
Contents of LCD Projector Box
Please confirm that the following items are packed in the LCD
Projector box.
They are provided to help you use or set up your LCD Projector.
(1) LCD Projector
(2) Wireless Remote Control Unit
(3) CR2025 Lithium Battery (Included with the remote control unit)
(4) 2.44 m Power Cord (LX-P1010ZE only)
(5) 2.35 m Power Cord (LX-P1010ZE only)
(6) 2.99 m Power Cord (LX-P1010ZU only)
(7) Computer Cable (mini D-Sub15 pin)
(8) Video Cable
(9) Audio Cable
(10) Lens Cap (Included with the projector)
(11) Carrying Bag
(12) Swivel Stand
(13) CD ROM (Operating Instructions)
(14) Quick Reference Manual
Previous
screen
14
Product Information
LCD Projector
Labels on the unit are omitted.
■ Top, right and front
Zoom Ring
Focus Ring
Air Filter
Swivel Stand
(Supplied)
■ Back and bottom
Speaker
Air Inlet Port
AC Socket
(In case Swivel stand is installed.)
Air Outlet Port
Remote
Control
Sensor
Remote
Control unit
EJECT Knob
Remote
Control unit
Holder
Remote
Control Sensor
Hole for
Swivel Stand
Installation
Previous
screen
Security Lock
Simple Stand
Lamp
Cover
15
Product Information
INPUT
KEYSTONE
MENU
ENTER
STATUS
POWER
LCD Projector
■ Control panel
STANDBY(RED)
ON(GREEN)
INPUT
Button
KEYSTONE
Button
MENU
Button
POWER ButtonPOWER Indicator
STATUS Code
Indicator
Adjust
Buttons
(Also used for
Volume -/+)
ENTER
Button
Previous
screen
16
Product Information
LCD Projector
■ Connector panel
RS232C RGB/YPBPR IN AUDIO IN VIDEO IN
SERIAL
Connector
RGB/YPBPR
Input
Connector
Audio
Input
Connector
Video
Input
Connector
S-VIDEO IN
S-Video
Input
Connector
Note
The serial connector which is on the terminal board of the
projector conforms to the RS-232C interface specification, so that
the projector can be controlled by a personal computer which is
connected to this connector. Consult your dealer or nearest JVC
representative for details.
Previous
screen
17
Product Information
Remote Control unit
Transmitter
POWER
Button
SHUTTER
Button
, , ,
Buttons
VOLUME
-/+ Buttons
FREEZE
Button
POWER
SHUTTER
FREEZE D.ZOOM
INPUT
AUTO SETUP
MENU
VOLUME
ENTER
Battery Holder
INPUT
Button
AUTO SETUP
Button
MENU
Button
ENTER
Button
D.ZOOM
Button
Previous
screen
18
Before using the Remote Control Unit
Remote Control comes with battery inside. Please remove white
protective film before use.
■ Replacing the battery
Insert the new lithium battery making sure the polarities (+)
and (-) are correct.
WARNING:
Replace battery with CR2025 only. Use of another battery may
present a risk of fire or explosion.
Caution: Battery may explode if mistreated. Dispose of used
battery promptly. Keep away from children. Do not recharge,
disassemble or dispose of in fire.
1 While pushing the battery
holder tab to the left, pull out
Push the tab
the battery holder.
Pull out
2 Insert the battery into the
battery holder so that the + side
is facing upward.
3 Insert the battery holder.
Note
• Do not drop the remote control unit.
• Keep the remote control unit away from liquids.
• Remove the battery if not using the remote control unit for
long periods.
• If the remote control becomes inoperable or does not
operate properly, it is likely due to battery dissipation.
Replace the battery with a new one.
Previous
screen
19
Before using the Remote Control Unit
■ Operating range
If the remote control unit is held so that it is facing directly in front of
the front or rear remote control signal receptors, the operating range
is within approximately 7 m (23 ft) from the surfaces of the
receptors. Furthermore, the remote control unit can be operated
from an angle of ±30 º to the left or right and ±15 º above or below
the receptors. (In this case, the operating range is shortened.)
30°
30°
approximately
7 m (23 ft)
15°
15°
30°
30°
approximately
7 m (23 ft)
15°
15°
Note
• If there are any obstacles in between the remote control unit and
the receptors, the remote control unit may not operate correctly.
• If strong light is allowed to shine onto the remote control signal
receptor, or if there are any obstacles between the remote
control signal receptor and the remote control unit, correct
remote control operation may not be possible.
• Ensure that remote control light sensor is not subject to direct
sunlight or light from fluorescent lighting. This may prevent the
remote control from operating correctly, or may cause
malfunctioning.
• If facing the remote control unit toward the screen to operate the
projector, the operating range of the remote control unit will be
limited by the amount of light reflection loss caused by the
characteristics of the screen used.
Previous
screen
20
Attaching and Removing the Swivel Stand
1)
2)
A swivel stand can be attached to or removed from the LCD
Projector. When attached, you can fine-adjust the projection angle.
To attach or remove the swivel stand, follow the steps below.
•Attachment
1 Place the unit upside down.
Place the unit on a flat,
stable surface covered with
a soft cloth, etc.
2 1) First, insert the swivel base
into the front openings of the
projector.
2) Then, while pressing the
PUSH Button, insert into the
rear openings.
PUSH
Button
•Removal
1 Place the unit upside down.
Place the unit on a flat,
stable surface covered with
a soft cloth, etc.
2 While pressing the PUSH
Button, remove the Swivel
stand.
Caution:
Never pick the unit up by the swivel stand.
Previous
screen
PUSH Button
21
System Configuration Example
Example of connection to audio-visual equipment
DVD Player
Audio Cable
(Supplied)
S-Video Cable
(not included)
AUDIO IN
S-VIDEO IN
VIDEO IN
Video Cable
Audio Cable
(Supplied)
(Supplied)
VCR
Note
• Only one audio system circuit is available for the AUDIO IN jack,
so if you wish to change the audio input source, you will need to
remove and insert the appropriate plugs.
• If the video signal source is connected using a cable with a
BNC junction plug, use the BNC-RCA Adaptor (not included) to
convert the pin jack.
• Use the cable included with this unit. If a cable longer than the
unit’s accessory cable is used, the display can become unstable
and clear projection may not be possible.
Previous
screen
22
System Configuration Example
Example of connection to a Personal Computer
Personal Computer
RGB/YPBPR IN AUDIO IN
Audio
output
port
Monitor
port
Computer Cable
(Supplied)
PC Audio Cable (not included)
Note
• Use the cable included with this unit. If a cable longer than the
unit’s accessory cable is used, the display can become unstable
and clear projection may not be possible.
• Use the cable included with this unit. If a cable longer than the
unit’s accessory cable is used, the display can become unstable
and clear projection may not be possible.
• When using this projector, do not bind its power cable together
with your computer cable, as this could cause it to malfunction.
• When LCD Projector power is turned off, turn the personal
computer off as well.
• Refer to the “Signals that can be Input” for types of RGB signals
which can be input to the projector by connecting a personal
computer.
Previous
screen
23
System Configuration Example
Connecting D-sub15-BNC5 (female) Adaptor Cable
The Component signal (YPBPR signal) can be input and projected
with this LCD Projector. Please read the operating instructions
regarding the output side of the component when connecting.
DVD Player
BNC-RCA Adaptor
(not included)
BNC Cable (not included)
Red
(Connect to PR Input Signal)
Blue
(Connect to PB Input Signal)
Green
(Connect to Y Input Signal)
Audio Cable
(Supplied)
D-sub15-BNC5
(female) Adaptor
Cable
(not included)
Previous
screen
RGB/YPBPR IN AUDIO IN
Continued on the next page...
24
System Configuration Example
Notes on system configuration
• Turn off the power supply of each system component before
connecting any of the components.
• Read the instruction manual for each system component before
connecting it.
• If the cables necessary for connecting a component to the
system are not included with the component or available as an
option, you may need to fashion a cable to suit the component
concerned.
• If there is a lot of jitter in the video signal input from the video
source, the picture on the screen may flicker. In such cases, it
will be necessary to connect a TBC (time base corrector).
• It may not be possible to connect some types of personal
computer.
Note
• Because each Y, PB, and PR signal is input independently, the
Component signal allows for more faithful color reproduction.
• The Component signal output terminal indication will differ
according to the output device (PR, PB, Y/R-Y, B-Y, Y/Cr, Cb, Y,
etc.). Please read the operating instructions included with the
output device.
• You need to change the input signal setting on this LCD
Projector when inputting the Component signal. In this case,
please refer to “Setting of the RGB/YPBPR Input Signal
Selection”.
• D-sub15-BNC5 (female) Adaptor Cable (sold separately) often
have BNC connectors, however a DVD output device usually
has RCA jacks. In this case, you will need BNC-RCA adaptors
(not included).
Previous
screen
25
Setting-up Positions
There are two ways of installing this projector as shown next page.
This section explains the standard case of the floor-mounted front
projection.
(The projection method can be set from the MENU screen. Refer to
the “Changing the Projection Mode”.)
Caution: When you set up the LCD Projector
• Do not place it in humid or dusty places, or places where the air
is sooty or full of cigarette smoke. If the lens, mirror, or other
optical components become dirty, the picture will blur or darken,
making viewing difficult.
• Do not expose to extreme heat or cold. Permissible operating
temperature: 0 ºC – 40 ºC (32 ºF – 104 ºF)
Preparation
• Refer to “screen size and required distance”.
• Select a room that can be darkened.
• This unit’s specification is not intended for suspension, so do not
install it in a suspended manner.
Previous
screen
Continued on the next page...
26
Setting-up Positions
Front projection
Viewing a picture projected on the front of the screen from a floor.
Viewer
Rear projection
Viewing a picture projected through the back of the screen from a
floor installation.
Translucent screen
Viewer
Previous
screen
27
Setting-up Positions
■ screen size and required distance
The screen should be positioned so that it is not directly touched by
sunlight or room light as this will wash out the colors of the picture
making it hard to see. When possible, close all blinds, curtains, etc.
and dim the lights. Also, the LCD Projector should be at a 90° angle
to the screen for the best picture results. To determine the distance
for the desired size, please refer to the “LCD Projector /Screen
Relative Position Chart”.
L
SW
SH
H1
Previous
screen
L
28
Setting-up Positions
■ LCD Projector /Screen Relative Position Chart
The picture can be adjusted to the desired size within the range of
the zoom lens. (The values in the table are reference values.)
Throw distance (L)
Wide
(LW)
1.6 m
2.4 m
3.2 m
4.0 m
6.0 m
8.1 m
10.1 m
12.1 m
Telephoto
(LT)
1.6 m
2.1 m
3.1 m
4.2 m
5.2 m
7.8 m
10.5 m
13.1 m
15.7 m
Height
position
(H1)
6.5 cm
8.7 cm
13.1 cm
17.4 cm
21.8 cm
32.7 cm
43.5 cm
54.4 cm
65.3 cm
Screen
size
30 in
40 in
60 in
80 in
100 in
150 in
200 in
250 in
300 in
Screen type (4:3)
Width
(SW)
0.61 m
0.81 m
1.22 m
1.63 m
2.03 m
3.05 m
4.06 m
5.08 m
6.10 m
Height
(SH)
0.46 m
0.61 m
0.91 m
1.22 m
1.52 m
2.29 m
3.05 m
3.81 m
4.57 m
Setting-up dimensions which are not given in the above table
can be calculated using the formulas below.
If the screen size is SD, then the following formula is first
used to obtain the screen width (SW).
SW (m) = SD x 0.0254 5 x 4
The value for SW obtained above can then be used with the
following functions to calculate the projection distance.
LW (m) = 1.98 x SW
LT (m) = 2.57 x SW
For 16:9 aspect ratios, the following formula can be used to
calculate the screen width (SW) and the projection distance
for the wide lens position.
SW (m) = SD x 0.0254 18.36 x 16
Previous
screen
29
Turning the power on and off
If the power cord is removed while the cooling fan is running,
or you project immediately after turning on the power, such
problems as damaging of the light source lamp or reduced
illumination may occur. Be sure to follow the below procedure
for turning the power “On” and “Off.”
POWER Button
POWER Indicator
STANDBY(RED)
ON(GREEN)
POWER Button
(Supplied)
Note
• Insert Power Cord into LCD Projector AC socket and
connect to properly grounded wall outlet.
• When power is turned off, the cooling fan continues to
operate (approximately 2 minutes) in order to cool the
projector interior.
• This unit consumes approx. 15 W in OFF condition when
plugged into an AC outlet.
Previous
screen
Continued on the next page...
30
Turning the power on and off
POWER Button
Turning on the power
Press POWER Button on the LCD Projector or remote
1
control unit.
The power indicator will flash, then turn solid green and a
2
picture will be projected onto the screen.
POWER Indicator
STANDBY(RED)
ON(GREEN)
POWER Button
Note
The LCD Projector cannot be turned on for 2 minutes
after turning it off.
Turning off the power
1
Press POWER Button on the LCD Projector or remote
control unit. “Please press POWER button again to power
off.” is displayed on the screen, and then press POWER
Button again.
The power indicator will illuminate flashing red.
2
3 Wait for the cooling fan to stop.
The power indicator changes to solid red, the cooling fan
stops, and the projector goes into Stand-by mode. (After
about 2 minutes)
Previous
screen
31
Adjusting the Lens
Refer to the “LCD Projector/Screen Relative Position Chart”.
After placing the LCD Projector to the throw distance which
corresponds with the desired screen size, follow the steps
below to adjust the zoom and focus while viewing a projected
image.
ZOOM Ring
• Adjustment procedure
FOCUS Ring
1 Turn the ZOOM Ring to adjust the size of the picture.
• When facing the rear of the projector, turn the ring to the
right for a smaller picture, or to the left for a larger picture.
2 Turn the FOCUS Ring to adjust the focus of the picture.
• Turn the ring to the right or left until the picture is at the
optimum focus.
3 Turn the ZOOM Ring again to adjust the size of the
picture.
• When you turn the FOCUS Ring, the size of the picture
changes.
Previous
screen
32
Menu operations
This section explains how to reach the desired selection or setting
screens from the MENU screen.
When an RGB signal is being projected.
(for white balance adjustment of the red component)
1 Press the MENU
Button.
The Main MENU
screen will be
displayed.
Use the ,
Buttons to select
an item, and then
press the ENTER
Button.
The Second MENU
screen will be
displayed.
2 Press the or
Buttons to select
an item, and then
press the or
Buttons to adjust
the setting.
White Balance
Synchronization
Function
Language
Information
(Main MENU)
White Balance
R Level
G Level
B Level
Standard (Push ENTER)
(Second MENU)
0
0
0
Note
• The last adjustment condition is saved and will not be erased
even if the power is turned off.
• The value differs with each input signal.
Previous
screen
33
Menu operations
Returning to the previous screen
If you press the MENU Button while a menu screen is being
displayed, the display will return to the previous screen.
If you press the MENU Button while the Main MENU screen will be
cleared.
Returning adjustment values to the factory default settings
(standard values)
If “Standard” is selected while the “Second MENU” is displayed, the
setting can be returned to the factory default setting.
However, the operation of this function varies depending on which
screen is being displayed.
Use the , Buttons
to select “Standard”,
and then press the
ENTER Button.
Image Quality
Brightness
Contrast
Standard (Push ENTER)
•Dynamic •Natural
0
0
Previous
screen
34
Changing the Projection Mode
The projection mode used by the projector can be changed in
accordance with the setting-up position. You may select from
two direction types. At the time of shipment from the factory,
the projector is set to the “Front” projection mode, but this can
be changed if required.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
• Selecting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Function”,
and then ENTER to
display the screen.
3 Press or to
select “Projection
Mode”.
4 Press or to
select projecting
mode.
• Front (Factory
setting)
• Rear (Right and
Left displays in
reverse)
White Balance
Synchronization
Function
Language
Information
Function
RGB/YPBP
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
R
•RGB •YPBP
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
R
Previous
screen
35
Setting the Screen Type
This LCD Projector is compatible with wide screen (16:9 ratio). If a
wide screen is used and you set the screen type to 16:9 in order to
project a wide (16:9) picture to fill the entire screen, pictures are
correctly projected within the screen when projecting older (normal)
4:3 ratio pictures. Please follow the instructions below to set the
screen type.
The procedure and on-screen display as below are based on
S-VIDEO/VIDEO as the input signal.
• Setting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Function”,
and then ENTER to
display the screen.
3 Press or to
select “Screen”.
4 Press or to
change the screen
type.
• The 4:3 type
screen is set at
the factory.
White Balance
Video System
Function
Language
Information
Function
Projection Mode
Screen
16:9
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•Front •Rear
•4:3 •16:9
•ON •OFF
•ON •OFF
•YES •NO
Previous
screen
36
Changing to 16:9 (wide) screen format
When a S-VIDEO/VIDEO or DTV Format (RGB, YPBPR) signals
is input, the image can be displayed in 16:9 (wide) screen by the
following procedure. This only applies for S-VIDEO/VIDEO and
DTV Format signals. The procedure below describes the onscreen displays when the S-VIDEO signal or the VIDEO signal is
being projected.
•Selecting procedure
1 Press MENU to
display the menu.
2 Press or to select
“Function”, and then
ENTER to display the
screen.
3 Press or to select
“16 : 9”.
4 Press or to select
“ON” or “OFF”.
• Select “OFF” to return
the normal screen.
(This is the factory
setting.)
• Select “ON” to display
in 16:9 (wide) screen.
White Balance
Video System
Function
Language
Information
Function
Projection Mode
Screen
16:9
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•Front •Rear
•4:3 •16:9
•ON •OFF
•ON •OFF
•YES •NO
Previous
screen
37
Explanation of Screen Type
16:9 (Wide) Function OFF 16:9 (Wide) Function ON
Screen
4:3 Type Screen
16:9 Type Screen
Projected pictures
(4:3)
Screen
Projected pictures
(4:3)
Screen
Projected pictures
(16:9)
Screen
Projected pictures
(16:9)
Note
Even if the 16:9 (wide) screen feature is set to OFF, when an
“S1” signal or DTV Format signal (720 p, 1 080 i) is input, the
image is automatically displayed in 16:9 (wide) screen.
Previous
screen
38
Changing the input signal
The input source for picture signals can be changed by
pressing the INPUT Buttons on the projector operating panel
or on the remote control unit.
INPUT
INPUT
Press the INPUT Buttons
(LCD Projector)
RGB
BPR
YP
or
(Remote
Control unit)
The signal from the source which is
connected to the RGB/YPBPR IN connector
is projected.
This terminal accepts input of RGB input
signals from a personal computer and DTV
Format signals (RGB, YPBPR) from a DVD
or a digital broadcast. No monitor or
projector can automatically decide whether
a Component signal is the RGB-type or the
YPBPR-type. So, you will have to select
either RGB or YPBPR manually.
S-VIDEO
Previous
screen
VIDEO
The signal from the source which is
connected to the S-VIDEO IN connector or
VIDEO IN connector is projected.If cables
are connected to both connectors, the SVIDEO signal will be selected
automatically. (The S-VIDEO signal has
priority.) If you would like to project the
VIDEO signals being input to the VIDEO
IN connector, do not connect any cables to
the S-VIDEO IN connector.
Continued on the next page...
39
Changing the input signal
Note
• To turn off the input signal on-screen display, please see
“Turning off the input signal display”.
• Only one audio system circuit is available for the AUDIO IN
jack, so if you wish to change the audio input source, you
will need to remove and insert the appropriate plugs.
• The LCD Projector is shipped from the factory with the
system format selection function set to “AUTO”. If the
correct picture is not projected when S-VIDEO/VIDEO
signal is input and it is necessary to change the input to
match the input signal, refer to “S-VIDEO/VIDEO Signal
Format Selection”.
• Please refer to the “Setting of the RGB/YPBPR Input
Signal Selection” if you change the signal input to the
RGB/YPBPR connector.
• When RGB signal is input, please input the registered
signals found.
Previous
screen
40
Adjusting the LCD Projector projection angle
Adjusting the LCD Projection angle of the LCD Projector.
When the projector is in the horizontal position, keystone
correction is unnecessary and a correct image can be viewed.
■ Using the simple stand
While lifting up the front of the
projector, pull down the simple stand
located underneath the unit.
Note
Pressing the trapezoid correction KEYSTONE button will detect
the opening and closing of the swinging stand and automatically
make a trapezoidal correction, however, a slight distortion may
sometimes remain due to the installation condition of the unit.
Caution:
Never pick the unit up by the simple stand.
■ Using the swivel stand
1 Slide the TIGHTEN Knob to
the LOOSEN position.
2 Adjust to the desired projection
angle. If necessary, you can also tilt
to the right or left.
3 Slide the TIGHTEN Knob to
the TIGHTEN position.
Previous
screen
FRONT
(Top view)
FRONT
(Top view)
41
Basic LCD Projector Operation
Adjusting the Volume
The volume can be adjusted using the VOLUME -/+ Buttons
on the remote control unit.
VOLUME
(Remote
Control unit)
• Press VOLUME - Button to
turn down the volume.
• Press VOLUME + Button to
turn up the volume.
Volume 30
Note
• The “Volume” will remain displayed on the
screen for approximately 5 seconds.
(LCD Projector)
Freezing the picture
Projection can be switched between a frozen (still) picture
and a moving picture each time the FREEZE Button on the
remote control unit is pressed. Press FREEZE Button again to
resume motion.
• Volume cannot be adjusted with the , keys
on the unit while D. ZOOM and MENU
screens are displayed.
FREEZE
(Remote
Control unit)
Previous
screen
Freeze
Note
Sound is muted while the picture is frozen.
42
Basic LCD Projector Operation
Turning off the Picture and Sound at the same time
When SHUTTER Button is pressed on the remote control the
picture and sound turns off and the screen goes black,
Press SHUTTER Button again to resume picture and sound.
SHUTTER
(Remote
Control unit)
Black screen
Note
• When the screen goes black, the picture will not be shown
on the screen. However, the picture continues to be sent
from the personal computer or video source.
• The projector uses less power in shutter mode than it does
in normal projection mode.
Previous
screen
43
Using the Auto Setup Feature
Auto Setup
When projecting an image other than a video signal, it can
simultaneously adjust such elements as the picture vertical
position, horizontal position, dot clock and phase. Operate as
follows to use this function.
AUTO SETUP
Press the AUTO SETUP Button
on the remote control unit.
The words “Auto Setup” appear on
(Remote
Control unit)
the screen and the automatic
adjustment begins.
At this time, only the Power button
is accepted.
The adjustment is complete when
the “Auto Setup” display
disappears.
Note
• If normal picture can not be attained during RGB signal
input or DTV format signal input, please press the AUTO
SETUP Button on the remote control.
• The LCD Projector detects whether the simple stand is
down or up and automatically corrects keystone distortion.
• Adjusted settings are saved as is even if power is turned
off.
• If the edges of the projected picture are indistinct, or if a
dark picture is being projected, the automatic set up
processing may stop automatically before it is complete. If
this happens, project a different picture and then press the
AUTO SETUP Button once more. Or, perform the following
operations as indicated in the on-screen display.
Refer to the “Adjusting the Image Position, Dot Clock and
Phase”.
Refer to the “Keystone correction function”.
Previous
screen
44
Adjusting the Image Position, Dot Clock and Phase
Confirm the picture position, Dot Clock, and Phase. If the
picture is not correctly positioned within the display area of
the screen (the edge of the picture does not appear), adjust
the picture position. The items which can be adjusted will vary
depending on the type of input signal.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
• When adjusting the Horizontal Position (H Position)
1 Press MENU to
display the menu.
2 Press or to
select
“Synchronization”,
and then ENTER to
display the screen.
3 Press or to
select “H Position”.
• When adjusting the
Vertical Position,
Dot Clock, and
Phase, move the
arrow to the item
you want to adjust.
4 Press or to adjust
the H Position setting.
• The current setting
will be displayed on
the screen by
numerals and a bar.
White Balance
Synchronization
Function
Language
Information
Synchronization
H Position
V Position
Dot Clock
Phase
Standard (Push ENTER)
49
27
900
15
Previous
screen
Continued on the next page...
45
Adjusting the Image Position, Dot Clock and
Phase
Depending on the adjustment item, the adjust procedure and
adjustment will vary. Please refer to the chart below.
Adjustment
item
H Position
V Position
Dot Clock
Button Adjustment Details
Press
Button.
Press
Button.
Press
Button.
Press
Button.
Adjust the personal computer’s dot clock and
the projector’s dot clock so that no bit interference (vertical stripes) appears on the screen.
The image moves to the right.
The image moves to the left.
The image moves up.
The image moves down.
Remarks
RGB,
BPR
YP
only
Phase
Previous
screen
Adjust in order to remove any picture interference or contour blurring which may occur in
computer images.
RGB
only
46
Selecting the Image Quality
This LCD Projector can select Dynamic or Natural as the
special characteristic of image quality.
Follow the instructions below to select the image qualities you
prefer.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
• Setting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Picture”, and
then ENTER to
display the screen.
3 Press or to
select “Image
Quality”.
4 Press or to
select the Image
Quality.
• Dynamic is the
factory RGB input
signal setting.
• Natural is the
factory S-VIDEO/
VIDEO, YPBPR
input signal
setting.
White Balance
Synchronization
Function
Language
Information
Image Quality
Brightness
Contrast
Standard (Push ENTER)
•Dynamic •Natural
0
0
Previous
screen
47
Adjusting the Picture to the Desired Setting
The items which can be adjusted will vary depending on the
type of input signal.
The adjustment procedure below describes the on-screen
displays when the S-VIDEO signal or the VIDEO signal is
being projected.
•Adjustment procedure (when adjusting the Color)
1 Press MENU to
display the menu.
2 Press or to
select “Picture”, and
then ENTER to
display the screen.
3 Press or to
select “Color”.
4 Press or to
adjust the color.
• The current setting
will be displayed on
the screen by
numerals and a
bar.
White Balance
Video System
Function
Language
Information
Image Quality
Color
Tint
Brightness
Contrast
Sharpness
Standard (Push ENTER)
•Dynamic •Natural
0
0
0
0
0
Previous
screen
Continued on the next page...
48
Adjusting the Picture to the Desired Setting
Depending on the adjustment item, the adjust procedure and
adjustment will vary. Please refer to the chart below.
Adjustment
item
Color
Tint
Brightness
Contrast
Button Adjustment Details
Press
The color becomes deeper.
Button.
Press
The color becomes paler.
Button.
Press
Flesh tones become greenish.
Button.
Press
Flesh tones become reddish.
Button.
Press
The screen becomes brighter.
Button.
Press
The screen becomes darker.
Button.
Press
Button.
Press
Button.
Only the Highlights of the
image become brighter,
adding Contrast.
The Highlights become less
bright, diminishing Contrast.
Remarks
YPBPR,
S-VIDEO/
VIDEO only
NTSC/
NTSC 4.43
(S-VIDEO/
VIDEO) only
Press
Button.
Sharpness
Press
Button.
The picture quality becomes
sharper.
The picture quality becomes
softer.
Note
The different adjustment condition cannot be saved for
S-VIDEO and VIDEO.
Previous
screen
YPBPR,
S-VIDEO/
VIDEO only
49
Adjusting the White Balance
The picture may become over-saturated with red or blue
colour, and the white colour may not be at the desired degree
of whiteness. In such cases, adjust the white balance by the
following procedure.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
•Adjustment procedure
(for white balance adjustment of the red component)
1 Press MENU to
display the menu.
2 Press or to
select “White
Balance”, and then
ENTER to display
the screen.
3 Press or to
select
“R Level”.
4 Press or to
adjust the R Level
setting.
• The current setting
will be displayed on
the screen by
numerals and a bar.
White Balance
Synchronization
Function
Language
Information
White Balance
R Level
G Level
B Level
Standard (Push ENTER)
0
0
0
Previous
screen
Continued on the next page...
50
Adjusting the White Balance
Depending on the adjustment item, the adjust procedure and
adjustment will vary. Please refer to the chart below.
Adjustment
item
Button
Press Button.
Adjustment Details
The red component becomes
stronger.
R Level
Press Button.
Press Button.
The red component becomes weaker.
The green component becomes
stronger.
G Level
The green component becomes
Press Button.
Press Button.
weaker.
The blue component becomes
stronger.
B Level
Press Button.
The blue component becomes
weaker.
Note
Unless properly adjusted, none of the colour may display
normally.
Previous
screen
51
Setting of the RGB/YPBPR Input Signal Selection
DTV Format Signal, such as DVD or digital broadcast, etc. can be
input and projected with this Projector. When using this function,
please refer to correctly connect to the output device of the DTV
Format Signal and perform the following settings correctly.
This LCD Projector allows input of RGB or YPBPR signals
(Component input signal) to the RGB/YPBPR input terminal,
but you will need to change the setting of the input signal
selection manually when changing the signal to be input. If
the input signal selection is not set correctly, a normal image
will not be projected.
The RGB input signal is set at the factory. Please follow the
instructions below to change the input signal.
• Setting procedure
1 Press MENU to
display the menu.
2 Press or to select
“Function”, and then
ENTER to display the
screen.
3 Press or to select
“RGB/YPBPR”.
4 Press or to
change the input
signal.
Previous
screen
White Balance
Synchronization
Function
Language
Information
Function
RGB/YPBPR
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•RGB •YPBPR
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
52
Turning off the input signal display
The function which displays the currently selected input signal
on the screen can be turned off by the following procedure.
Freeze displays will also be turned off.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
•Selecting procedure
1 Press MENU to
display the menu.
2 Press or to select
“Function”, and then
ENTER to display the
screen.
3 Press or to select
“On Screen Display”.
4 Press or to select
“ON” or “OFF”.
• Select “OFF” to turn
off the input signal
display function.
• Select “ON” to turn
the input signal
display function. The
input signal will be
displayed each time
it is changed. (This
is the factory
setting.)
White Balance
Synchronization
Function
Language
Information
Function
RGB/YPBP
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
R
•RGB •YPBP
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
R
Previous
screen
53
Auto Lamp Off
The power save function operates as follows: If the projector
continues projecting for 15 minutes or more while there is no
input signal to be projected, the light source will shut off
automatically to save power. And, the projector will enter
standby mode. At the time of shipment from the factory, the
Auto Lamp Off function is set YES, so that if you will not use
this function, you can turn it off by the following procedure.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
•Selecting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Function”,
and then ENTER
to display the
screen.
3 Press or to
select “Auto Lamp
Off”.
4 Press or to
select “YES” or
“NO”.
White Balance
Synchronization
Function
Language
Information
Function
RGB/YPBPR
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•RGB •YPBPR
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
Previous
screen
54
Canceling enlarging (scanning line conversion) function
When a signal less than 800 X 600 dots signals is input, the
LCD Projector automatically enlarges the image to 800 X 600
dots. This may cause picture quality degration. For better
image, select Expansion: OFF by the following procedure.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
• Setting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Function”,
and then ENTER to
display the screen.
3 Press or to
select “Expansion”.
4 Press or to select
“ON” or “OFF”.
• Select “OFF” to
cancel enlarge
(scanning line
conversion)
function.
• Select “ON” to use
enlarge (scanning
line conversion)
function. (This is the
factory setting.)
White Balance
Synchronization
Function
Language
Information
Function
RGB/YPBPR
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•RGB •YPBP
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
R
Previous
screen
55
Keystone correction function
When the screen and projector are not level, a keystone
(trapezoid) image may occur. This can be corrected by doing
the following.
• procedure
1 Project a picture onto the screen.
2 Press the
KEYSTONE Button
on the projector.
KEYSTONE
(LCD Projector)
3 Press or to
adjust the Keystone.
Previous
screen
Keystone 0
Adjust EscapeMENU
Continued on the next page...
56
Keystone correction function
Keystone Image Corrected Image
Screen
Projected pictures
Press ...Top becomes nar-
Keystone (top : wide)
Press ...Bottom becomes
Keystone (under : wide)
row.
Screen
Projected pictures
narrow.
Screen
Projected pictures
Screen
Projected pictures
Note
• When keystone is corrected, the screen becomes smaller.
• The LCD Projector detects whether the Simple Stand is
down or up and automatically corrects keystone distortion
when the KEYSTONE Button is pressed.
Previous
screen
57
Selecting the Language for On-Screen Displays
The language of the LCD Projector is set to English as the
factory setting. To select one of seven different languages for
on-screen display, follow the instructions below. The
procedure below describes the on-screen display when the
S-VIDEO signal or the VIDEO signal is being projected.
•Selecting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Language”,
and then ENTER to
display the screen.
3 Press or to
select language.
• You can select
English, German,
French, Spanish,
Italian, Japanese
and Chinese.
White Balance
Video System
Function
Language
Information
Language
English
Deutsch
Français
Español
Italiano
Previous
screen
58
Information Functions
You can display the input signal type and lamp run time.
Display items differ depending on the input signal. The
procedure and on-screen display as shown below are based
on RGB as the input signal from a personal computer.
• procedure
1 Press MENU to
display the menu.
2 Press or to
select “Information”.
3 Press ENTER to
display the screen.
White Balance
Synchronization
Function
Language
Information
Information
No. of Dots
H Frequency
V Frequency
Lamp Runtime
800 x 600
37.88 kHz
60 Hz
100 h
Previous
screen
Continued on the next page...
59
Information Functions
RemarksDescriptionDisplay Item
No. of Dots
H Frequency
V Frequency
Signal
Lamp
Runtime
Input signal dot number is
displayed.
Horizontal frequency number is
displayed.
Vertical frequency number is
displayed.
Name of the input signal type is
displayed.
When AUTO is selected in the
Video System screen, the
selected format will be
displayed.
Number of hours the lamp has
been used is displayed.
Personal
Computer
Signals
(RGB) only
YPBPR
VIDEO/
S-VIDEO
only
Previous
screen
60
Digital Zoom Functions
You can enlarge and project specific portions of the input
picture and select the enlargement ratio for this portion using
the D.ZOOM buttons on the remote control unit.
X1.0
X1.5
X2.0
X3.0
D.ZOOM
(Remote
Control unit)
D.Zoom
• Press D.ZOOM Button
the picture will become
bigger.
x 1.5
Move
Note
You can enlarge the centre portion
of the image to one of 6
magnifications.
Previous
screen
X4.0
X5.0
Continued on the next page...
61
Digital Zoom Functions
• Use the and arrow Buttons to
move the position up and down.
VOLUME
• Use the and arrow Buttons to
move the position to the left and right.
(Remote
Control unit)
Note
• Position cannot be moved with arrow Buttons on the unit.
• The volume cannot be adjusted while the digital zoom
function is being used.
Previous
screen
62
Status Code Display Indications
Warning Indicators
This LCD Projector has a STATUS Code Display which calls
your attention to problem conditions existing inside the LCD
Projector. The LCD Projector displays a status Code
Indication each time an internal problem is detected.
If any of the following indications appear in the STATUS Code
Display, immediately turn off the Power Button, and then see
the chart to determine a course of action.
Example: If the total lamp operating time is over 1 900 hours, the
status codes “L”, “-“, and “1” will be displayed in
sequence.
STATUS Code
display
Note
Please wait 2 minutes before turning the power back on, to
allow the lamp to cool. A much longer time may be required
if the projector had attained an abnormally high internal
temperature.
Previous
screen
Continued on the next page...
63
Status Code Display Indications
STATUS
Code
F-L
C-0
A-n
A-0
L-n
P-2
P-3
P-4
Symptom
Lamp does
not light up.
Problem
• Cooling fan
malfunction.
• Misinstalled Air Filter
Unit or Lamp cover.
• Temperature Sensor
malfunction.
• Clogged air filter.
• Blocked air intake.
• The ambient
temperature and
humidity is outside the
range of permitted
operating conditions.
• If the Lamp will not
light after turning on
the main power 2 or 3
times, the Lamp may
be damaged.
• Lamp Voltage is not
correct.
• Abnormal temperature
rise.
• Other causes.
• Request its repair from your dealer
or JVC service representative.
• Properly install Air Filter Unit or
Lamp cover.
• Request its repair from your dealer
or JVC service representative.
• Clean the filter.
• Relocate projector to a proper
location.
• Place Projector so that surrounding temperature is between 0 °C
(32 °F) and 40 °C (104 °F) and
the humidity is between 20 %
and 80 % (with no condensation.)
• Request its repair from your
dealer or JVC service representative.
Possible Solution
L-1
L-0
C-d
Previous
screen
Lamp operation
time is over
1 900 hours.
Lamp operation
time reaches
2 000 hours.
Forced cooling
fan operating to
expedite lamp
replacement.
• It is nearly time to
replace the Lamp Unit.
• Consult your dealer or JVC
• The Lamp Unit must be
replaced.
service representative on
replacement of the lamp unit.
64
Cleaning the Air Filter
REMOTE
Air Filter
The air filter should be cleaned about every 100 hours. Also,
clean the air filter if the “A-0” is indicated in the STATUS Code
display.
Replace the filter when it is clogged or dirty even after
cleaning.
POWER Button
STATUS Code
display
Air Filter unit
• Cleaning procedure (Tools required: Vacuum Cleaner.)
1 Set the POWER Button to OFF and unplug the power
cord.
Note
Wait until the cooling fan stops and the STANDBY(R) ON(G)
indicator turns solid red.
2 Remove the Air Filter unit
Hold the indent on the Air
Filter unit with your hands and
pull the Air Filter unit out of
the LCD Projector.
Previous
screen
Continued on the next page...
Indent
65
Cleaning the Air Filter
REMOTE
3 Clean the Filter.
Gently remove any accumulated
dust from Air Filter unit with your
vacuum cleaner.
CAUTION: Operating LCD Projector with torn or damaged
Filter may cause damage to LCD Projector.
4 Replace the Air Filter unit.
Slide the Air Filter into the LCD
Projector so that the
indentations of the filter and
projector are aligned. Then,
press on the arrow mark until
you hear it snap into place.
• The LCD Projector power cannot be turned on unless the
Air Filter unit is correctly installed.
• Using with the air filter sponge removed will result in dirt
and dust being drawn in and lead to malfunction.
Note
If the dust cannot be removed by cleaning, it is time to
replace the air filter. Consult your dealer or JVC service
representative.
Previous
screen
66
Lamp Replacement (To retailers)
Warning
STATUS Code display
Lamp replacement period
The LCD Projector lamp has a limited
operating life of approximately 2 000
hours.
If lamp operation time exceeds 1 900
hours, “L-1” is displayed as the STATUS
Code.
“Lamp replacement is recommended.”
will be displayed on-screen when
operation time reaches 1 900 hours.
If the lamp does not illuminate and the status
code “L-n” is displayed, try switching on the
lamp two or three times. If the lamp still does
not illuminate, the lamp may be broken. Do
not attempt to replace the lamp, as there is a
risk of injury on broken lamp fragments. Call
the JVC service center for repairs.
Lamp replacement is
recommended.
Take the LCD Projector to your dealer for repair.
(Order Lamp BHNPETLAC50.)
• When the lamp operation time has exceeded 1 900 hours, a
warning will appear for 15 seconds when the LCD Projector
power is turned on.
Previous
screen
Continued on the next page...
67
Lamp Replacement (To retailers)
In case lamp time reaches 2 000 hours
The LCD Projector will shut itself OFF and
Unless you change to a
new lamp, POWER will
be off 5 minutes later.
the STATUS Code indication becomes “L-0”.
• The on-screen display urging you to
replace the lamp unit will be displayed for
five minutes after the power has been
turned on, the power will then automatically
go off and it will enter the standby mode.
Note
• To maintain the initial brightness and picture quality,
replace the lamp as soon as possible when the lamp
replacement display appears.
• The replacement display appears after approximately 1900
hours, as a indication that it is time for the lamp to be
replaced.
• The replacement display is, after all, only a guideline to
the time for lamp replacement and is not an assurance of
the lamp’s service life.
• The lamp could go out before the replacement display
appears, for such reasons as individual lamp
characteristics, or the usage conditions and usage
environment. We thus recommend that you keep a
replacement lamp on hand.
• Fluorescent lamps should be replaced by your retailer or
the JVC service center. A lamp replacement fee may be
charged in addition to the cost of the replacement lamp.
Previous
screen
68
Signals that can be Input
The projection mode will be matched automatically to one of the
modes which have been pre-set inside the Projector.
If a signal which differs greatly from any of the types listed below is
input, the picture image may not be displayed correctly, or a blue
background may be displayed.
Inputtable computer input signal (RGB)
Signal data
Display
mode name
VGA400 (70 Hz) 640 X 400 31.47 70.08 25.175
VGA480 (60 Hz) 640 X 480 31.47 59.94 25.175
Macintosh 13˝ 640 X 480 35.00 66.67 30.241
VESA400 (85 Hz) 640 X 400 37.86 85.08 31.500
VESA480 (72 Hz) 640 X 480 37.86 72.81 31.500
No. of dots
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Dot clock
frequency
(MHz)
VESA480 (75 Hz) 640 X 480 37.50 75.00 31.500
VESA480 (85 Hz) 640 X 480 43.27 85.01 36.000
SVGA (56 Hz) 800 X 600 35.16 56.25 36.000
SVGA (60 Hz) 800 X 600 37.88 60.32 40.000
SVGA (72 Hz) 800 X 600 48.08 72.19 50.000
SVGA (75 Hz) 800 X 600 46.88 75.00 49.500
SVGA (85 Hz) 800 X 600 53.67 85.06 56.250
XGA (60 Hz) 1 024 X 768 48.36 60.00 65.000
Personal Computer Signals
XGA (70 Hz) 1 024 X 768 56.48 70.07 75.000
XGA (75 Hz) 1 024 X 768 60.02 75.03 78.750
Macintosh 16″ 832 X 624 49.73 74.55 57.283
Macintosh 19″ 1 024 X 768 60.24 74.93 80.000
XGA (85Hz) 1 024 X 768 68.68 85.00 94.500
Previous
screen
*
*
*
*
*
*
Continued on the next page...
69
Signals that can be Input
Signal data
Display
mode name
No. of dots
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Dot clock
frequency
(MHz)
1 152 X 864 (70 Hz) 1 152 X 864 63.85 70.01 94.500
1 152 X 864 (75 Hz) 1 152 X 864 67.50 75.00 108.000
1 152 X 864 (85 Hz) 1 152 X 864 77.09 85.00 121.500
Macintosh 21˝ 1 152 X 870 68.68 75.06 100.000
1 280 X 960 (60 Hz) 1 280 X 960 60.00 60.00 108.000
1 280 X 960 (75 Hz) 1 280 X 960 75.00 75.00 126.000
1 280 X 1 024 (60 Hz)
Personal Computer Signals
1 280 X 1 024 (75 Hz)
480 i 664 X 485 15.73 29.97 12.650
480 p 720 X 483 31.47 59.94 27.000
720 p 1 280 X 720 45.00 60.00 74.250
*
1 080 i 1 920 X 1 080 33.75 30.00 74.250
625 i 756 X 576 15.63 25.00 14.500
DTV Format Signals
*
*
*
*
*
*
*
1 280 X 1 024 63.98 60.02 108.000
*
1 280 X 1 024 79.98 75.03 135.000
*
Note
•*Changing the number of dots to be displayed to within
800 X 600 may cause a portion of information to be
omitted, or the image quality to be degraded.
• DTV Format Signals are picture signals from a DVD or a
digital broadcast.
• The Sync. signal of a DTV format signal (RGB) is only
supported if the Horizontal and Vertical frequencies are
separate.
Previous
screen
70
Signals that can be Input
Inputtable component signal (YPBPR)
Signal data
Display
mode name
480 i 664 X 485 15.73 29.97 12.650
480 p 720 X 483 31.47 59.94 27.000
No. of dots
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Dot clock
frequency
(MHz)
720 p 1 280 X 720 45.00 60.00 74.250
Signals
1 080 i 1 920 X 1 080 33.75 30.00 74.250
DTV Format
625 i 756 X 576 15.63 25.00 14.500
*
*
Note
•*Changing the number of dots to be displayed to within
800 X 600 may cause a portion of information to be omitted, or
the image quality to be degraded.
• DTV Format Signals are picture signals from a DVD or a digital
broadcast.
Previous
screen
71
Signals that can be Input
Inputtable S-VIDEO/VIDEO signal
Signal format
name
AUTO
NTSC
NTSC4.43
PAL-M
PAL
PAL-N
SECAM
Horizontal scanning
frequency
(kHz)
Selected automatically.
15.75
15.63
Vertical scanning
frequency
(Hz)
60.00
50.00
Colour sub-carrier
frequency
(MHz)
3.58
4.43
3.58
4.43
3.58
4.25 or 4.41
Note
• NTSC and PAL-M have the same scanning frequencies
and color sub-carrier frequencies, but they have different
colour modulation methods. Because of this, if the
incorrect setting is selected, colour pictures may appear in
black-and-white.
• The video system screen is not displayed with no
S-VIDEO/VIDEO input signal.
Previous
screen
72
S-VIDEO/VIDEO Signal Format Selection
If the correct signal format is not selected and the picture
does not appear normal when VIDEO or S-VIDEO signal is
being input, select the format by the following procedure. This
function is set to “AUTO” at the time of shipment from the
factory, so that the projector can normally be used with this
setting.
• Setting procedure
1 Press MENU to
display the menu.
2 Press or to
select “Video
System”, and then
ENTER to display the
screen.
3 Press or to
switch the setting to
“AUTO”, “NTSC”,
“NTSC4.43”, “PAL”,
“PAL-M”, “PAL-N” or
“SECAM” until a
normal picture is
obtained.
White Balance
Video System
Function
Language
Information
Video System
AUTO
NTSC
NTSC4.43
PAL
PAL-M
PAL-N
SECAM
Note
If using a signal source with poor picture quality, such as a
dubbed tape, it may not be possible to get the picture to display
properly.
Previous
screen
73
Blue (Black) Screen with No Input Signal
The LCD Projector is equipped with an internal Blue (Black)
Screen function which turns the screen blue black when the
video or personal computer equipment connected to the
input jack is turned off, or when there is nothing connected
to the input jack.
• If the power is turned on when no
input signal is input to the LCD
Projector, the screen will turn blue.
The Focus screen appears only
until the video or personal
computer equipment is connected
to the input jack and turned on.
• During operation, if the input
signal is terminated, the screen
goes black and “No Signal” will
be displayed.
• If an unrecognizable signal is
input, the screen goes black and
“Signal” is displayed.
• When RGB signal is input, please
input the registered signals found on
“Signals that can be Input”.
No Signal
Signal
Previous
screen
74
Specifications
LCD panels
Drive method
No. of pixels
Projection lens
Projector lamp
Contrast ratio
Brightness
No. of colours
Screen size
Projection (throw) distance
Lens axis shift
Color systems
Video input signal
S-Video input signal
Audio input signal
Audio out
Video signal
RGB/YP
input signal
BPR
Sync signal
H-Frequency
V-Frequency
0.7″ Poly silicon LCD panel X 3,
RGB shutter method, using Translucent TN crystal panels
Active Matrix 4:3 Aspect Ratio panels, TFT (Thin Film
Transistor)
480 000 (800 X 600) stripe pixels X 3 panels
1-1.3 zoom lens, F2.3-2.6, f28 mm- 37 mm Manual Focus
130 W UHM Lamp
300 : 1
700 lumen / ANSI
16 777 216
30″ - 300″
1.6 m - 15.7 m
6:1 Low position
PAL/SECAM/NTSC/PAL-M/PAL-N/NTSC4.43
1 V [p-p], sync negative, 75 Ω terminated
Y (luminance signal) : 1 V [p-p], sync negative, 75 Ω
terminated
C (chrominance signal) : burst 0.286 V [p-p], 75 Ω
terminated
0.32 V [rms]
0.5 W Mono
RGB Analog (0.7 V [p-p], 1.0 V [p-p] with sync on green,
75 Ω)
BPR (Y: 1.0 V [p-p], PB, PR: 0.7 V [p-p], 75 Ω)
YP
H/V separate, H/V composite, or Sync-on-Green
24 KHz - 80 KHz (TTL Level)
50 Hz - 86 Hz (TTL Level)
Connectors S-Video Input: Mini Din 4-pin X 1
Video Input : RCA pin X 1
Audio Input: M3 stereo mini pin X 1
Serial Port (RS-232C): Mini Din 8-pin X 1
BPR Input: D-Sub mini 15-pin X 1
Previous
RGB/YP
Continued on the next page...
screen
75
Specifications
Controls Cabinet Buttons/
Switches
Remote Control
Buttons
Speaker
Permissible operating temperature
Permissible operating humidity
Storage Temperature
Storage Humidity
Power Supply
Power consumption
Dimensions W x H x D
(excluding projected portion)
Weight
Approvals
Note
Power ON/OFF, Menu, Input, , ,
(Volume -), (Volume +), Enter, Keystone
Power ON/OFF, Freeze, Shutter, Enter, Menu,
Input, , , (Volume -), (Volume +),
D.Zoom, Auto setup
36 mm round
0 ºC (32 ºF) - 40 ºC (104 ºF)
20 % - 80 %
-20 °C to 40 °C
(-4 °F to 104 °F)
5 % - 85 %
(non-condensing)
100 V - 240 V AC (50 Hz or 60 Hz) Automatic
210 W
267 mm x 74 mm x 208 mm
40 °C to 60 °C
(104 °F to 140 °F)
Normal humidity
2.5 kg
FCC, UL, C-UL, CE, VDE
Specifications and design subject to change without notice.
Previous
screen
76
Before Requesting Service
If the LCD Projector unit fails, check the following before calling
your dealer for service.
Problem Possible Cause
Power does
not turn on.
No picture
appears.
The picture
is fuzzy.
•The power cord may not be connected.
•The main power supply may not be supplied to the wall
outlet.
•The Status Codes are indicated on the STATUS Code
Display.
•The lamp unit or lamp unit cover may not have been
correctly installed.
•The Air Filter Unit may not have been correctly in-
stalled.
•The lens cap may still be attached to the lens.
•The signal input source may not be connected prop-
erly.
•The input selection setting may not be correct.
•The Brightness adjustment may be lowest setting.
•The LCD Projector may be set to the Shutter mode.
•The connected signal source may be turned off.
•The lens focus may not have been set correctly, or the
Projector may not be at the correct distance from the
screen.
•The lens may be dirty.
•The LCD Projector may not be set up so that it is per-
pendicular to the screen.
•The VIDEO or R, G, B adjustments may not have been
set correctly.
Colour is too
light or tint is
poor.
Previous
screen
•Colour or Tint adjustment may be incorrect.
•The video formats may not match.
•The signal cables may be connected incorrectly. For
instance, the PB, PR connectors may be reversed.
•Do you use a polarization screen? A polarization
screen cannot be used.
Continued on the next page...
77
Before Requesting Service
Problem Possible Cause
No sound can be
heard.
•The audio signal source may not be connected
properly.
•The volume adjustment may be at the lowest
possible setting.
•The Mute function or Audio/Video Shutter function
may be active.
Remote Control
does not operate.
The colour is
black-and white.
•The batteries may be spent, or they may not be
inserted correctly.
•There may be an object blocking the infrared
signals between remote control unit and the Projector.
•The remote control unit may be out of the operat-
ing range.
• The Video System may not be correct.
Note
• If normal picture can not be attained during RGB signal input or
DTV format signal input, please press the AUTO SETUP button
on the remote control.
Previous
screen
78
Previous
screen
Loading...
