JVC LST0728-001B User Manual

NETWORK VIDEO RECORDER
INSTRUCTIONS
VR-N1600U VR-N1600E VR-N900U
VR-N900U (B)
WARNIN G
ALARM
HDD
LOCK

SEARCHFUNCTION ALARM CLEARKEY REC/STOP STOP(PB) PLAY
SERIAL
㧝 㧞 㧟
㧡
㧥  
   
CANCEL ZOOM OUT ZOOMIN
㧢*1/'
㧣
LIVE/BROWSE
OPERATE
SELECT
REC CONTROL
Please read the following before getting started:
Thank you for purchasing this JVC product. Before operating this unit, please read the instructions carefully to ensure the best possible performance.
REV FWD
SKIP
VR-N1600U/E
VR-N900U
Powered by Milestone
For Customer Use:
Enter below the Serial No. which is located on the body. Retain this information for future reference.
Model No. VR-N1600U/VR-N900U Serial No.
LST0728-001B
IMPORTANT SAFEGUARDS
I
SAFETY PRECAUTIONS (for USA)
Please use this unit in an appropriate power source.
Veuillez employer cette unité dans une source d'énergie appropriée.
(VR-N900U)
II
SAFETY PRECAUTIONS
Please use this unit in an appropriate power source.
PRECAUTIONS WHEN MOUNTING RACK
CAUTION
Do not install the VR-N1600U/E/VR-N900U to the rack in places where ambient temperature becomes 40˚C or more.
When rack mounting, keep the internal temperature of rack assembly 40˚C or less.
When using rack mount, keep the clearance between the rack and the rear of unit 150mm or more.
When installing this unit or the like to the rack, refer to the consumption current value of the nameplate of each
device so that the current capacity (including rated capacity of power supply wire) of the rack is not exceeded.
Use the rack that meets the following requirements:
• must be equipped with overcurrent protection
• must be equipped with protective earthing conductor power plug and socket
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: This unit should be mounted at the bottom of the rack if it is the only unit in the rack. When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest component at the bottom of the rack. If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in the rack.
CAUTION
Before you mount this device in a rack, make sure that the rack is secure and in no danger of tipping over.
III
,
INFORMATION (FOR CANADA) RENSEIGNEMENT
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil num rique de la Class A es t
(POUR CANADA)
WARNING (FOR EUROPE):
This is a Class A product. In a domestic environment cause radio interference in which adequate
measures.
case the user may be required to take
this product may
IV
SICHERHEITSVORKEHRUNGEN (for Germany)
Benutzen Sie bitte diese Maßeinheit in einer passenden Energiequelle.
V
VI
SICHERHEITSVORKEHRUNGEN (for Germany)
VII
1600E/VR-N900U
E/VR-N900U
E/VR-N900U
E/VR-N900U.
1600E/VR-N900U
E/VR-N900U
VIII

Getting Started

Features

Automatic detection of network cameras
Significantly reduces the hassle of complex camera registration procedures.
Built-in large-capacity hard disk (500 GB) (VR­N1600U/E)
Built-in hard disk (250 GB) (VR-N900U)
Supports HDD expansion
You can add 250 GB HDD for internal of VR-N900U, and 500 GB HDD for internal of VR-N1600U/E. For external, up to 2 TB HDD units can be added for both models of
and
N900U
VR-N1600U/E
.
Simultaneous recording up to 9 channels at 120 ips (VR-N900U)
Equipped with 4-channel analog input (VR­N900U)
Display performance of 60 ips and distribution performance of 30 ips (VR-N900U)
Enables simultaneous recording and playback
Playback of recorded images, jog dial playback and skip playback are possible while recording is in progress.
Direct Search
Enables you to retrieve data of a specific date/time or alarm position speedily.
VR-
Display and distribution performance at 80 ips is guaranteed (VR-N1600U/E)
Supports RAID1 (VR-N1600U/E)
Adding a built-in HDD enables support for RAID1. RAID1 writes the same data to two hard disks simultaneously (mirroring), so that one of them remains usable when the other breaks down.
Simultaneous recording up to 16 channels at 160 ips (VR-N1600U/E)
Simultaneous recording up to 16 channels at 240 ips is possible when NVR Viewer is not started up.
Supports cameras that allow bidirectional audio transmission (VR-N1600U/E)
Microphone audio that is input into the AUDIO IN 1 terminal is transmitted to the camera that supports bidirectional audio transmission, and output from the speakers connected to the camera
How to Read this Manual
Documents
There are two documents on this unit.
(1) Startup Guide
This comes in a booklet together with this product. It is also available in the PDF file format. You can find it in the CD-ROM provided.
(2) Instruction Manual (PDF)
This manual is available in the PDF file format. You can find it in the CD-ROM provided.
Symbols Used in this Manual
Caution
Notes
A
Precautions to take during operation of this unit.
Details for reference, such as functions and restrictions on uses.
Page or item to refer to.
.
Power failure recovery record
If a power failure occurs during recording, the system resumes recording in the mode selected before the power failure after recovery.
Alarm recording
Enables recording to start automatically in the alarm recording mode when alarm signal input is received during recording.
Motion Detect
Enables recording to start automatically when “motion” is detected in the preset live image. You can also specify the detection area for each camera.
Alarm Mail Notification
Enables notification by e-mails to be sent out when an alarm or motion is detected.
2
Content of this Manual
The copyright of this manual belongs to JVC. Reproduction or copy of this manual, in part or in whole, without the prior consent of JVC is strictly prohibited.
Product names used in this manual are the trademarks or registered trademarks of the respective companies. Symbols such as ™, ®, and © are omitted in this manual.
Milestone and XProtect Enterprise are the registered trademarks of Milestone Systems, Inc.
Designs, specifications and other details used in this manual may be modified for improvement without prior notice.
Images and illustrations of VR-N1600U/E are used in the explanation of this manual except for some special cases. When images or illustrations of VR-N900U are used, the model name is indicated at the top right corner of the illustration.
oEnd-User License Agreement for Milestone's Software embedded in JVC's NVR products
This license agreement is a legally binding agreement among you (You, either an individual or a single entity), Milestone Systems A/S (Milestone) and Victor Company of Japan, Limited (JVC) for the software product embedded in JVC's Network Video Recorder(NVR) products (Software), which may include associated software components, media, printed materials, and online or electronic documentation, if any. By using JVC's NVR product incorporating the Software, you agree to be bound by the terms of this agreement. The Software is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties. Note that the Software is licensed, not sold.
1. Grant of Use.
Milestone hereby grants you the right to use the Software on JVC's NVR products.
2. Copyright.
All title, including but not limited to copyrights, in and to the Software and any copies thereof are owned by Milestone. All rights not expressively granted are reserved by Milestone.
3. No Warranties.
Milestone and JVC expressly disclaims any warranty for the Software. The Software and any related documentation is provided "as is" without warranty of any kind, either express or implied, including, without limitation, the implied warranties of merchantability, fitness for a particular purpose or non-infringement. The entire risk and liability arising out of use or performance of the Software remains with you as the user. You are notified that the Software, when used with certain equipment or other software, may enable you to perform surveillance actions and data processing which are likely to be restricted by or contrary to applicable law, including without limitation data privacy and criminal law. The sole responsibility for verification of your use against compliance with applicable law lies with you as the user.
4. Limitation of Liability.
The provisions of this paragraph are in effect to the maximum extent permitted by applicable law. In no event shall Milestone, JVC or their suppliers be liable for any special, incidental, indirect, or consequential damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information, or any other pecuniary loss) arising out of the use of or inability to use the Software or the provision of or failure to provide proper support, even if Milestone or JVC have been advised of the possibility of such damages. Absent any wilful misconduct or gross negligence, The entire liability of Milestone and JVC under any provision of this agreement shall be limited to the amount paid by you for the Software portion of JVC's NVR product.
5. Miscellaneous.
You acknowledge that the Software is embedded in JVC's NVR products, and you may not make copies of the Software.
(a)
If necessary for backup and archival purposes, please contact JVC.
(b)
You may not remove the Software from JVC's NVR product nor distribute copies of the Software to third parties.
(c)
You may not reverse engineer, decompile, or disassemble any of the Software except to the extent permitted by applicable law which cannot be contractually waived.
You may permanently transfer all of your rights for the Software, provided the recipient of JVCÕs NVR product
(d)
incorporating the Software agrees to the terms of this agreement.
6.Termination.
Without prejudice to any other rights, Milestone may terminate this license agreement if you fail to comply with its terms and conditions. In such event you must cease to use the Software.
7. Governing Law.
These License Terms and the contract is governed by Japanese law and the sole and proper forum for the settlement of disputes hereunder shall be the Tokyo District Court.
3
Getting Started
VR-N1600U/VR-N1600E/VR-N900U (hereinafter referred to as “this device”) is installed with Windows姞XP Embedded Runtime (hereinafter referred to as “the software”), a licensed software from Microsoft Corporation. By using this device and the software, you agree to abide by the following Microsoft Software License Terms.
Microsoft Software License Terms for:
Windows XP Embedded Runtime
These license terms are an agreement between you and JVC. Please read them. They apply to the software included on this device. The software also includes any separate media on which you received the software. The software on this device includes software licensed from Microsoft Corporation or its affiliate. The terms also apply to any Microsoft
Updates,
Supplements,
Internet-based services, and
Support services
for this software, unless other terms accompany those items. If so, those terms apply. If you obtain updates or supplements directly from Microsoft, then Microsoft, and not JVC, licenses those to you.
As described below, using some features also operates as your consent to the transmission of certain standard computer information for Internet-based services. By using the software, you accept these terms. If you do not accept them, do not use or copy the software. Instead, contact JVC to determine its return policy for a refund or credit.
If you comply with these license terms, you have the rights below.
1 Use Rights.
You may use the software on the device with which you acquired the software.
2 Additional Licensing Requirements and/or Use Rights.
a.Specific Use.
JVC designed this device for a specific use. You may only use the software for that use.
b.Other Software.
You may use other programs with the software as long as the other programs
Directly support the manufacturer
Provide system utilities, resource management, or anti-virus or similar protection.
s specific use for the device, or
Software that provides consumer or business tasks or processes may not be run on the device. This includes email, word processing, spreadsheet, database, scheduling and personal finance software. The device may use terminal services protocols to access such software running on a server.
c.Device Connections.
You may use terminal services protocols to connect the device to another device running business task or processes software such as email, word processing, scheduling or spreadsheets.
You may allow up to ten other devices to access the software to use
File Services,
Print Services,
Internet Information Services, and
Internet Connection Sharing and Telephony Services.
The ten connection limit applies to devices that access the software indirectly through multiplexing or other software or hardware that pools connections. You may use unlimited inbound connections at any time via TCP/IP.
3 Scope of License.
The software is licensed, not sold. This agreement only gives you some rights to use the software. JVC and Microsoft reserve all other rights. Unless applicable law gives you more rights despite this limitation, you may use the software only as expressly permitted in this agreement. In doing so, you must comply with any technical limitations in the software that allow you to use it only in certain ways. For more information, see the software documentation or contact JVC. Except and only to the extent permitted by applicable law despite these limitations, you may not:
Work around any technical limitations in the software;
Reverse engineer, decompile or disassemble the software;
Make more copies of the software than specified in this agreement;
Publish the software for others to copy;
Rent, lease or lend the software; or
Use the software for commercial software hosting services.
Except as expressly provided in this agreement, rights to access the software on this device do not give you any right to implement Microsoft patents or other Microsoft intellectual property in software or devices that access this device.
4
You may use remote access technologies in the software such as Remote Desktop to access the software remotely from another device. You are responsible for obtaining any licenses required for use of these protocols to access other software.
Remote Boot Feature.
If the JVC enabled the device Remote Boot feature of the software, you may
(i) your server and to deploy the software on licensed devices as part of the Remote Boot process; and (ii) use the Remote Boot Installation Service only for deployment of the software to devices as part of the Remote Boot
process; and
(iii)download the software to licensed devices and use it on them.
For more information, please refer to the device documentation or contact JVC.
Internet-Based Services.
Microsoft provides Internet-based services with the software. Microsoft may change or cancel them at any time.
a.Consent for Internet-Based Services.
The software features described below connect to Microsoft or service provider computer systems over the Internet. In some cases, you will not receive a separate notice when they connect. You may switch off these features or not use them. For more information about these features, visit
http://www.microsoft.com/windowsxp/downloads/updates/sp2/docs/privacy.mspx.
By using these features, you consent to the transmission of this information.
Microsoft does not use the information to identify or contact you.
b.Computer Information.
The following features use Internet protocols, which send to the appropriate systems computer information, such as your Internet protocol address, the type of operating system, browser and name and version of the software you are using, and the language code of the device where you installed the software. Microsoft uses this information to make the Internet­based services available to you.
Web Content Features.
Features in the software can retrieve related content from Microsoft and provide it to you. To provide the content, these features send to Microsoft the type of operating system, name and version of the software you are using, type of browser and language code of the device where the software was installed. Examples of these features are clip art, templates, online training, online assistance and Appshelp. These features only operate when you activate them. You may choose to switch them off or not use them.
Digital Certificates.
The software uses digital certificates. These digital certificates confirm the identity of Internet users sending X.509 standard encrypted information. The software retrieves certificates and updates certificate revocation lists. These security features operate only when you use the Internet.
Auto Root Update.
The Auto Root Update feature updates the list of trusted certificate authorities. You can switch off the Auto Root Update feature.
Windows Media Player.
When you use Windows Media Player, it checks with Microsoft for
Compatible online music services in your region;
New versions of the player; and
Codecs if your device does not have the correct ones for playing content. You can switch off this feature. For more
information, go to: http://microsoft.com/windows/windowsmedia/mp10/privacy.aspx.
Windows Media Digital Rights Management.
Content owners use Windows Media digital rights management technology (WMDRM) to protect their intellectual property, including copyrights. This software and third party software use WMDRM to play and copy WMDRM-protected content. If
the software fails to protect the content, content owners may ask Microsoft to revoke the software WMDRM to play or copy protected content. Revocation does not affect other content. When you download licenses for
protected content, you agree that Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. Microsoft software that includes WMDRM will ask for your consent prior to the upgrade. If you decline an upgrade, you will not be able to access content that requires the upgrade. You may switch off WMDRM features that access the Internet. When these features are off, you can still play content for which you have a valid license.
c.Misuse of Internet-based Services.
You may not use these services in any way that could harm them or impair anyone else the services to try to gain unauthorized access to any service, data, account or network by any means.
s use of them. You may not use
s ability to use
5
Getting Started
Microsoft Software License Terms for: (continued)
4 Windows Update Agent (also known as Software Update Services).
The software on the device includes Windows Update Agent ( WUA ) functionality that may enable your device to connect to and access updates (
any other disclaimer in this Micrososoft Software License Terms or any EULA accompanying a Windows Update, you acknowledge and agree that no warranty is provided by MS, Microsoft Corporation or their affiliates with respect to any Windows Update that you install or attempt to install on your device.
Windows Updates ) from a server installed with the required server component. Without limiting
5 Product Support.
Contact JVC for support options. Refer to the support number provided with the device.
6 Backup Copy.
You may make one backup copy of the software. You may use it only to reinstall the software on the device.
7 Proof Of License.
If you acquired the software on the device, or on a disc or other media, a genuine Certificate of Authenticity label with a genuine copy of the software identifies licensed software. To be valid, this label must be affixed to the device, or included on or
in JVC packaging to prove that you are licensed to use the software.
To identify genuine Microsoft software, see http://www.howtotell.com.
s software packaging. If you receive the label separately, it is not valid. You should keep the label on the device or
8 Transfer to a Third Party.
You may transfer the software only with the device, the Certificate of Authenticity label, and these license terms directly to a third party. Before the transfer, that party must agree that these license terms apply to the transfer and use of the software. You may not retain any copies of the software including the backup copy.
9 Not Fault Tolerant.
The software is not fault tolerant. JVC installed the software on the device and is responsible for how it operates on the device.
10 Restricted Use.
The Microsoft software was designed for systems that do not require fail-safe performance. You may not use the Microsoft software in any device or system in which a malfunction of the software would result in foreseeable risk of injury or death to any person. This includes operation of nuclear facilities, aircraft navigation or communication systems and air traffic control.
11 No Warranties for the Software.
The software is provided as is . You bear all risks of using it. Microsoft gives no express warranties, guarantees or conditions. Any warranties you receive regarding the device or the software do not originate from, and are not binding on,
Microsoft or its affiliates. When allowed by your local laws, JVC and Microsoft exclude implied warranties of merchantability, fitness for a particular purpose and non-infringement.
6
12 Liability Limitations.
You can recover from Microsoft and its affiliates only direct damages up to two hundred fifty U.S. Dollars (U.S. $250.00). You cannot recover any other damages, including consequential, lost profits, special, indirect or incidental damages.
This limitation applies to:
Anything related to the software, services, content (including code) on third party internet sites, or third party programs; and
Claims for breach of contract, breach of warranty, guarantee or condition, strict liability, negligence, or other tort to the extent permitted by applicable law.
It also applies even if Microsoft should have been aware of the possibility of the damages.
The above limitation may not apply to you because your country may not allow the exclusion or limitation of incidental, consequential or other damages.
13 Export Restrictions.
The software is subject to United States export laws and regulations. You must comply with all domestic and international export laws and regulations that apply to the software. These laws include restrictions on destinations, end users and end use.
For additional information, see www.microsoft.com/exporting.
7
Getting Started

Contents

Getting Started
Features .................................................................................2
Contents ................................................................................. 8
Precautions for Proper Use of this Product .......................... 10
Part Names and Functions (VR-N1600U/E) ........................12
Part Names and Functions (VR-N900U) ..............................16
Rear Panel Terminals ...........................................................20
Camera Control Terminal (VR-N900U) .............................21
Differences when operating VR-N1600U/E and VR-N900U
Mounting to a Rack ..............................................................21
Operation Lock .....................................................................22
During Initial Startup ............................................................ 22
Preparation
System Connection Example ............................................... 26
Clock Display ........................................................................27
Performance Meter ............................................................... 27
Character Input and Mouse Pointer .....................................28
Entering Characters Using a Mouse ................................. 28
Controlling Mouse Pointer from the Front Panel
(Without Connecting a Mouse (Sold Separately)) ......28
Changing Monitor Resolution ............................................... 29
Precautions when Changing Settings .................................. 29
Basic Operation
Switching the Power On/Off ................................................. 30
Switching Operation On/Off .................................................30
Login ....................................................................................31
Opening the Main Menu .......................................................32
NVR Viewer ..........................................................................33
Viewing Live Images via Front Panel Control .......................34
Displaying the [Live] Screen .............................................34
Select a view ....................................................................34
Select a Camera ...............................................................34
Operating the Camera ......................................................35
Viewing Live Images via Mouse Control ..............................36
Displaying the [Live] Screen .............................................36
Select a view ....................................................................36
Select a Camera ...............................................................36
Viewing Images Using the PTZ Features .........................37
Using Preset Positions ......................................................38
Other Useful Functions .....................................................38
Playing Back Recorded Images via Front Panel Control ...... 40
Select a view ....................................................................40
Searching Recorded Image Using a Specific Date/Time
Playing, Skipping and Stopping Recorded Images ...........41
Adjusting the Playback Speed (Jog/Shuttle Playback) ..... 41
.....21
...... 40
Playing Back Recorded Images via Mouse Control ..............42
Select a view .....................................................................43
Searching Recorded Image Using [Time Navigation] .......43
Searching Recorded Image Using the Timeline Browser
Searching Recorded Image Using Sequence ...................44
Searching Recorded Image from the Alert List .................45
Smart Search ....................................................................45
Playing, Skipping and Stopping Recorded Images ...........46
Listening to Audio Sound ..................................................47
Writing Images/Audio Sound to CDs, DVDs and
Other Media (Export) ......................................................47
Deleting Temporary Files (Operation on the Unit) .............50
Deleting Data from a CD-RW (Operation on the Unit) ......50
Writing Data to a USB Memory Device
(Operation on the Unit) ...............................................50
Operation from a Surveillance Computer ..........................50
Printing Recorded Images
(Operation from a Surveillance Computer) .....................51
Recording Camera Images ...................................................52
Recording Modes ..............................................................52
Recording Operation During Power Failure ......................52
Selecting the Recording Control Mode .............................53
Selecting the Manual Recording Mode .............................53
Scheduler Setting ..............................................................53
Specifying Image Recording Settings ...............................55
Settings .............................................................................56
Setting Picture Quality ......................................................58
Specifying Audio Recording Settings ................................59
Renaming Cameras and Assigning Camera Numbers .....60
Screen Setup ........................................................................60
Screen Display (Groups and Views) .................................60
Creating Groups and Views ..............................................61
Adding Cameras to a View ................................................63
Adjusting Camera Settings ...............................................63
Using Your Views on Different Computers ........................64
Adding a Carousel ............................................................64
Adding Hot Spots (Enlarged Images) ...............................66
Using the [Html Page] .......................................................67
Using Still Images (GIF/JPEG files, etc.) ..........................67
Adding Matrix Content ......................................................67
......44
8
Applications
Main Menu List .....................................................................68
List of Menu Screens ........................................................ 68
Unit Setting .......................................................................69
OS Setting ........................................................................72
Image Server Setting ........................................................76
Auto Detect Setting ........................................................... 80
Camera Record Setting ....................................................84
Adding Cameras ..................................................................86
Analog Cameras (VR-N900U) .......................................... 86
Adding an Analog Camera (VR-N900U) ........................... 86
Editing Device Settings ........................................................87
PTZ Camera Settings (COM1/COM2) ................................. 88
Defining a Preset PTZ Position ............................................90
Stopping the Recording Server ........................................90
Display the [PTZ Preset Positions for Device Name]
window ........................................................................ 90
Defining a Preset Position ................................................92
Moving to Preset Positions by Events ...............................92
Auto PTZ Patrolling ...........................................................93
Camera Input/Output Port and Events ................................. 95
I/O Settings ....................................................................... 95
Input/Output Terminal on Rear Panel ............................... 97
Specifying a VMD Event ...................................................97
Specifying Timer Events ...................................................97
Specifying an Output ........................................................ 98
[Advanced] Screen ...........................................................98
Configuring Event Buttons ................................................99
Specifying Generic Events .............................................100
Event Notification Settings ..............................................102
Specifying an Output Port ...............................................102
Camera Output Settings .................................................103
Motion Settings ..................................................................104
General Settings ................................................................ 106
E mail Settings ................................................................107
Archiving ............................................................................ 108
Precautions when Changing NAS Archive Settings .......109
Precautions when Changing Archive Settings ................109
Database Settings ..............................................................110
Flash Memory Utility .......................................................... 111
Auto Detect Settings ..........................................................113
Specifying IP Lease ........................................................113
Language Setting ............................................................... 115
HDD Utility ..........................................................................116
Restoring Default Settings .................................................117
Distribution Settings (Details) .............................................118
Connecting to a Computer .................................................120
Audio Transmission Application Control (VR-N1600U/E)
Audio Transmission .........................................................126
Event Audio Settings (VR-N1600U/E) ................................ 128
Audio Copying ................................................................ 129
Setting Copy ...................................................................130
Password ........................................................................130
Communication Settings .................................................131
.......126
Others
Compatible Equipment .......................................................132
Compatible Network Cameras ........................................132
Connecting a UPS ..........................................................132
External Hard Disk Drives ...............................................132
Connecting the External Hard Disk Drive .......................132
NAS .................................................................................133
Special Key Operations ......................................................134
Combining a Button with the [FUNCTION] Button ..........134
Pressing a Button for Two Seconds or Longer ................134
Recording Before/After Occurrence of Event or Motion .....135
PTZ Camera Control ..........................................................135
Display and Saving of Maintenance Information ................137
Export Viewer .....................................................................138
Customizing Joystick Settings ............................................140
Configuring NAS .................................................................141
Recording Time Schedule (VR-N1600U/E) ........................142
Default Value List ................................................................146
Troubleshooting ..................................................................150
Specifications .....................................................................152
VR-N1600U/E .................................................................152
VR-N900U .......................................................................153
9
Getting Started

Precautions for Proper Use of this Product

Locations of Storage and Use
Do not place this product at the following locations.
Doing so may cause this product to malfunction or break down.
Hot or cold places beyond the allowable operating
I
temperature range (5
Humid places beyond the allowable operating humidity range (30%RH to 80%RH) (no condensation)
Places that emit a strong magnetic field, such as near transformers and motors
Places near devices that emit radio waves, such as transceivers and mobile phones
Places with considerable dust and sand
Places with strong vibrations
Places where water droplets may be formed, such as window sides
Places with considerable vapor and oil, such as kitchens
Places that emit radiation, X-rays, and corrosive gases
Using this unit and the cable that is connected to it near
places where strong radio waves or magnetic fields (such as near radios, TVs, transformers, and monitors) are emitted may cause noises in the video images or color changes.
Handling Precautions
Do not stack the devices on one another during use.
Heat and noise from the devices may cause the unit to malfunction or break down, and lead to fire.
Do not block the ventilation holes.
Doing so may cause heat to trap inside the unit and result in fire. Do not use this unit by laying it down sideways, upside down, or at an angle.
Do not place objects on this unit.
Placing heavy objects, such as TV monitors, or objects that are bigger in size on this unit may cause it to lose balance and drop or fall, hence resulting in injuries.
Do not stand or sit on this unit.
Doing so may cause this unit to fall or break down, and result in injuries. Keep it out of the reach of young children.
Do not place objects with water (e.g., vases, flower pots,
cups, cosmetic products, and chemicals) on this unit. Water may enter this unit through the ventilation holes and
result in fire or electric shock.
Do not insert objects into this unit.
Metallic or other flammable objects that enter this unit from the ventilation holes may result in fire or electric shock.
to 40I)
Precautions for Handling Hard Disk Drive
The distance between the head and the disk is only about
0.02 µ m when the hard disk (henceforth HDD) is reading the data. Vibration or impact that is exerted on the HDD may therefore cause the head to hit against the disk, hence causing the disk surface to dent or the disk to chip. When this occurs, data may not be properly read, or in a worse scenario, continued use in this condition may result in head crash (damage). Careful attention must therefore be paid when handling it.
Precautions During Installation and Change of Installation
Location Moving of this unit or installation work is strictly prohibited
when the power of this unit is on or immediately after the power is turned off (approximately 1 minute). The HDD continues to move under its own inertia for some time after the power is disconnected, and exertion of vibration or impact during this interval may result in HDD failure. When moving this unit, wrap it using cushioning materials to protect it from external shock.
Handling Precautions
Handle this unit carefully without exerting vibration or
impact on it.
Do not remove the power plug during recording or playback, or when the HDD is being accessed.
The HDD is a consumable product. Although it may vary according to the environment of use, it is recommended to replace the HDD after using for 18,000 hours in a
I
surrounding temperature of 25 reference time and not a quaranty for HDD life span. ) For inquiries on maintenance plans and expenses, consult your nearest JVC dealers.
When installing an external hard disk, we recommend the
use of UPS (uninterruptible power supply) to ensure the stable operation of the system. [Connecting a UPS] (A Page 132)
Power failure that occurs during formatting or
disconnection of the HDD may affect its subsequent use even when the UPS is connected.
JVC shall not be held responsible for the compensation of
losses incurred in the event that recording or playback fails due to defects in this unit or its hard disk drive.
Images recorded on the HDD will be deleted when you
replace it with a new disk. Note also that recorded images may be deleted when you upgrade the software for this unit.
. (However, this is only a
Clock
Use of a time server is recommended to ensure recording
at an accurate time.
There may be a daily error of 10 to 20 seconds depending
on the operating environment.
The clock time may vary significantly when the lithium
battery level used for backup in this unit is running low.
Connect the time server to the LAN2 network.
10
Precautions when Moving this Unit
Remove all connected cords before moving
Turn off the power and remove the power plug before moving this unit. Failure to do so may cause damage on the cords, and result in fire or electric shock.
Moving of this unit or installation work is strictly prohibited
when the power of this unit is on or immediately after the power is turned off (approximately 1 minute).
The HDD continues to move under its own inertia for some time after the power is disconnected, and exertion of vibration or impact during this interval may result in HDD failure.
When moving this unit, wrap it using cushioning materials
to protect it from external shock.
Handle this unit carefully without exerting vibration or
impact on it.
Precautions for Handling Power Cords
Do not use the supplied cords on devices other than this
unit.
Do not place heavy objects on the power cord, or place it
under this unit Doing so may cause damage on the cords, and result in
fire or electric shock.
Do not use cords other than those supplied with this unit
Use only power cords supplied together with this unit. Using cords with different withstanding voltage specifications or damaged cords may result in fire or electric shock.
Do not remove the power plug during recording or
playback, or when the HDD is being accessed.
Maintenance
Turn off the power before performing maintenance of this
unit.
Wipe this unit using a soft cloth. Wiping using thinner or
benzene may cause the surface to melt or fog. When the surface is extremely dirty, wipe using a cloth that is dipped into a neutral detergent diluted with water, followed by wiping with a dry cloth.
Energy Conservation
Turn off the power of the system for safety reasons and to
save energy if this unit is not to be used for a long time.
Copyright
Use of video or audio sound recorded using this unit for
commercial purposes or playing them for public viewing or listening may be an infringement of the copyrights of their respective authors under the copyright law.
These video (audio) recordings shall only be restricted to
personal uses, and their use without prior consent of the copyright holder is strictly prohibited under the copyright law.
Others
When there is variation in the supply voltage such as
during lightning, operation of this unit may be disabled to protect the system until the supply voltage stabilizes again.
Eliminate static electricity before performing work that
requires you to touch the input/output terminals, such as when installing devices.
Do not touch the rear panel of this unit when it is running
as static electricity may cause it to malfunction.
When there is a large number of data recorded on this
unit, such as short alarm records, a longer time may be required during search or backup. This is not a malfunction.
Data recorded from TV broadcasts or video (audio)
recordings shall only be restricted to personal uses, and their use without the prior consent of the copyright holder is strictly prohibited under the copyright law.
The width of the border lines (black in color) of images on
the split screen varies according to the type of input signals. This is due to the characteristics of the camera’s input signals, and is not a malfunction. The condition may also be improved by adjusting this unit. For details, consult our authorized dealers or JVC service centers.
This unit comes with a high-precision hard disk device. Be
careful not to exert vibration or impact on this unit when handling it.
Exertion of vibration or impact particularly when the power
is on or when the hard disk is being accessed may cause this unit to break down.
When moving this unit, do so about 1 minute after
disconnecting the power supply.
Do not turn off the power switch at the rear of this unit or
unplug the power cord during recording or playback, or when the hard disk is being accessed. Otherwise, it may break down.
Precautions During Master/Slave Connection of Milestone XProtect Enterprise (XPE) and this Unit
Connect only one master PC to this slave unit.
Connecting multiple master computers to this slave unit may cause it to malfunction.
Software Installation
Do not install any software to this device other than the
provided application software. Otherwise, operations may become unstable. Any malfunctions arised in such a case will not be covered under warranty.
11
Getting Started

Part Names and Functions (VR-N1600U/E)

Front
T
OPERATE
A B
A
[OPERATE] Button/Indicator
REC CONTROL
SELECT
PTZ/PRESET
SERIAL
㧡
㧥  
CANCEL ZOOM OUT ZOOM IN
㧣
㧢*1/'
   
㧝 㧞 㧟
LIVE/BROWSE
Switches operation on or off. Press the button to turn operation
AONB
and hold down the button to turn operation AOFFB. The
indicator blinks while the recorder is starting up or shutting down.
B
[REC CONTROL] Button/Indicator
Switches the recording control mode on or off. The indicator lights up when the recording control mode is set to on. Press and hold the [FUNCTION] button, and press the [REC CONTROL] button at the same time to display the menu.
Memo :
The main menu cannot be displayed in the recording control mode or during recording.
The recording control mode performs recording in accordance with the settings in the [Camera Record Setting] menu. (APage 53)
C
[SELECT] Button/Indicator
Use the S key to set to the camera selection mode. The indicator lights up when the camera selection mode is set to on. (
D
[PTZ/PRESET] Button/Indicator
Switches between the PTZ mode and PRESET mode of the S key. The mode changes each time the button is pressed. The indicator lights up when PTZ mode is selected and blinks when PRESET mode is selected.
E
[SERIAL] Terminal
For connecting the communication control terminals on a mouse (sold separately), flash memory (sold separately) or UPS (sold separately).
Memo :
Use the [SERIAL1 to 4] port on the rear panel for additional hard disk drive connection. (
A
Page 14)
Note :
Attach the serial port cover supplied with this product if this port is not in use.
This product may malfunction due to the presence of static electricity. Remove any static before starting operation.

ENTER
WARNIN G
ALARM
HDD
LOCK
FEDC
A
Page 36)
G
QRS
REV FWD
SEARCHFUNCTION ALARM CLEARKEY REC/STOP STOP(PB) PLAY
HJKML
I
F
Status indicators
[WARNING] Indicator
Lights up when an error occurs. ( Press and hold the [ALARM CLEAR] button to turn off the light.
[ALARM] Indicator
Lights up when an alarm is activated. Goes off when the [ALARM CLEAR] button is pressed.
[HDD] Indicator
Lights up when the built-in hard disk drive is accessed.
[LOCK] Indicator
Lights up when operation is locked. (
G
[FUNCTION] Button
Press the [FUNCTION] together with another button to use the corresponding features. [Special Key Operations] (APage 134)
H
[SEARCH] Button
Displays the date and time search screen when in the playback
A
mode. (
I
Page 40)
[KEY] Button
When [KEY] button is pressed while pressing [FUNCTION] button, key operation on front panel will be disabled. (Key locked mode) To disable, perform same procedure again. Press to display or hide the
A
software keyboardB.
Memo :
Use the software keyboard to input characters. (APage 28)
J
[ALARM CLEAR] Button
Clears the [ALARM] display when an event occurs or motion is detected. Press and hold this button to turn off the [WARNING] indicator.
K
[REC/STOP] Button
Press to start recording in all cameras. (When the recording control mode is turned on, recording on all cameras starts after turning off the recording control mode. ) Press and hold down to stop recording. When in the recording control mode, press and hold this button to exit the recording control mode.
SKIP
N
A
Page 151)
A
Page 22)
P
O
12
Memo :
The manual recording mode executes recording from all cameras regardless of the settings in the [Camera Record Setting]. Recording is carried out in accordance with the frame rate selected in [Camera Record Setting]. (APage 84)
L
[STOP(PB)] Button
Stops playback when you press this button in the playback mode.
M
[PLAY] Button
Plays back at the speed and in the direction specified by the Shuttle Dial position.
N
[SKIP] Button
䡵[S
]
Press to move the item selection in the reverse direction in the menu or settings screen. Jumps to the beginning of the previous sequence on the selected camera when you press this button in the playback mode. Press and hold it to jump to the first image in the database of the selected camera.
䡵[T
]
Press to move the item selection in the forward direction in the menu or settings screen. Jumps to the beginning of the next sequence on the selected camera when you press this button in the playback mode. Press and hold it to jump to the last image in the database of the selected camera.
Memo :
“Sequence” indicates a certain block of images that are recorded during motion detection.
Recorded images are stored in the database. “Database” refers to data recorded in this unit.
O
Jog dial
Plays back a single frame when it is rotated in the playback mode.
P
Shuttle dial
The position of the dial specifies the playback speed and playback direction when in the playback mode. Playback speed is selectable from x 1/20, x 1/5, x 1, x 2, x 5, x 10 and x 20 according to the angle.
Q
[REC] Indicator
Lights up during recording. Flashes during EMERGENCY or EXT REC IN recording.
R
Center panel
Do not remove the cover.
S
Keypad buttons/Indicator
[0] to [16]
Login screen
For entry of passwords (numeric characters). ([1] to [10/0], A0B is input when the [10/0] button is pressed.)
Setting screens on the main menu
PTZ mode Keypad
For selecting a menu item. ([2/D], [10/0/E])
Camera selection keypad mode
For entering numeric characters. ([1] to [10/0], A0B is input when the [10/0] button is pressed.)
Live image display and recorded image playback screens
Camera selection keypad mode
For selecting a camera number. Upon selecting, the indicator corresponding to the selected camera input lights up.
PTZ keypad mode (live image display screen only)
Moves the camera in the direction indicated by the arrow. ([1/
D
] [3/ ][5/C][7/B] [9/ ][10/0/E] [11/ ])
][2/
[6/HOME] moves the camera to the home position.
Preset keypad mode (live image display screen only)
For selecting the preset position. ([1] to [9]. 10 to 19 can be selected when [10/0/E] is pressed at first.)
During search for recorded images
For narrowing down the search using a date, month, week, or time.
E
([1/ ] to [10/0/
During display of software keyboard
Selection keypad mode
For entering numeric characters. ([1/ ] to [10/0/E], A0B is input when the [10/0/
PTZ keypad mode (live image display screen only)
Moves the mouse pointer in the direction indicated by the arrow. [1/ ][2/ the mouse pointer to the center of the screen.)
], A0B is input when the [10/0/E] button is pressed.)
E
] button is pressed.)
D
] [3/ ][5/C][7/B] [9/ ][10/0/E] [11/ ], [6/HOME] moves
[13/CANCEL]
Setting screens on the main menu
Cancels the selection.
[14/ZOOM OUT]
Live image display and recorded image playback screens
PTZ keypad mode (live image display screen only)
Zooms out.
Preset keypad mode
For selecting the next view.
Press the [14/ZOOM OUT] button while holding down the [FUNCTION] button to change the resolution of VGA output.
[15/ZOOM IN]
Live image display and recorded image playback screens
PTZ keypad mode (live image display screen only)
Zooms in.
Preset keypad mode
For selecting the previous view.
Press the [15/ZOOM IN] button while holding down the [FUNCTION] button to change the resolution of VGA output.
[16/ENTER]
Setting screens on the main menu
Confirms the selection.
During display of software keyboard
To perform the mouse click operation.
T
[LIVE/BROWSE] Button/Indicator
Switches between the [Live] mode and [Browse] mode. The indicator lights up when in the [Live] mode. Pressing the [LIVE/BROWSE] button when the wallpaper screen is displayed shows the [Live] screen. Press and hold the [FUNCTION] button, and press and hold the [LIVE/ BROWSE] button at the same time to log out of the system. Press and hold the [FUNCTION] button, and press the [LIVE/BROWSE] button at the same time to reboot the NVR Viewer as well as the internal distribution server.
Memo :
When [Auto Logon] is enabled, the login operation starts automatically immediately after logging out. (APage 69 [Unit Setting])
13
Getting Started
Part Names and Functions (VR-N1600U/E) (continued)
Rear Panel
d
U
POWER
ON
OFF
AUDIO IN
AUDIO
OUT
V
SIGNALGND
W
U
[POWER] switch
Switches the power on or off.
Memo :
Be sure to press and hold down the [OPERATE] button on the front panel to shut down the system before switching off the power supply.
V
[AC IN 120V H 240VH 50Hz/60Hz] power input
terminal
Connect to an AC120 H 240 V outlet using the power cable supplied.
W
[AUDIO IN 1/AUDIO IN 2] audio input terminals 1/2
(RCA)
Connect to the audio output terminal of the device from which audio signals are to be recorded.
X
[AUDIO OUT] audio output terminal (RCA)
Outputs live sound in the live viewing mode. Outputs recorded sound in the playback mode.
Memo :
There is no audio output when playing back still images, when running searches other than x1, or when playing back frame-by­frame.
Y
[VGA OUT] VGA output terminal
Outputs live images, recorded images and the menu screens.
Z
[SERIAL1 to 4] serial terminals 1 to 4
For connecting the communication control terminals on a mouse (sold separately), flash memory (sold separately), UPS (sold separately) or additional disk drive (sold separately).
a
[LAN1] LAN1 connection terminal (camera network)
For connecting to the IP camera (sold separately) network using a LAN cable.
X
LAN2
b
a
Color Status
Orange
Green Off Communicating at 10 Mbit/
Orange
c
Off Not connected to the network. On Connected to the network. Blinking Communicating.
second.
On Communicating at 100 Mbit/
second.
Blinking Communicating at 1 Gbit/
second.
VGA O UT
Y
ALARMIN
LAN1
1 2
3 4
SERIAL
Z
Left Indicator
Right Indicator
b
[LAN2] LAN2 connection terminal (Intranet)
For connecting to the remote PC network using a LAN cable.
Color Status
Left Indicator
Right Indicator
c
Connector cover
Green Off Not connected to the network.
Blinking Connected to the network.
Green Off Not communicating.
Blinking Communicating.
Memo :
Do not remove the cover.
d
Signal input/output terminals
For operating VR-N1600U/E using external alarm signals or signals received from external devices, or for operating external devices by outputting signals.
Memo :
Diameter of applicable cable: AWG22 to AWG28
14
Rear I/O Terminals
ON
OFF
AUDIOIN
SIGNALGND
AUDIO
OUT
VGA O UT
p
Input ports
e
[ALARM IN 1 to 8] alarm input terminals 1 to 8
Alarm recording is activated when signals are input to these terminals.
f
[EMERGENCY] emergency input terminal
Recording is activated in all cameras when a signal is input to this terminal.
g
[ALARM RESET] alarm reset input terminal
Output from the alarm output terminal is stopped when a signal is input during output of the Alarm Out signals. Turns off the [ALARM] indicator F on the unit. Press and hold down to turn off the [WARNING] indicator
h
[EXT REC IN] external recording input terminal
Recording in all cameras is started or stopped by an external signal. Recording will not be started in cameras to which no video signal is being input.
i
[OPE ON/OFF] Operate ON/OFF terminal
Switches between OPERATE ON or OFF when a signal is input. (
A
Page 30)
Note :
Input ports e to i will not operate when the main menu is displayed. Inputs such as alarms will also be ignored when the main menu is displayed.
F
.
ALARMIN
e
LAN2
LAN1
1 2
3 4
SERIAL
fghijklmn
Output ports
j
[COMMON] signal ground terminal
This is a common ground terminal. Connect it to the signal ground terminal on the connected device. (This can be used when there are insufficient common ground terminals.)
k
[ALARM OUT] alarm output terminal
Outputs a signal when recording is started by an alarm.
l
[WARNING OUT] warning output terminal
Outputs a signal when an error such as operation abnormality occurs on the hard disk.
m
[REC TALLY] recording status output terminal
Outputs the recording status of this unit.
n
[OPTION OUT1][OPTION OUT2] OPT OUT output
terminals 1/2
Outputs a signal when an event is detected.
o
[COMMON] signal ground terminal
Same as j.
p
[SIGNAL GND] signal ground terminal
This is a common ground terminal. Connect it to the signal ground terminal on the connected device. (This can be used when there are insufficient common ground terminals.
Memo :
Do not use this terminal for protective earthing.
o
15
Getting Started

Part Names and Functions (VR-N900U)

Front Panel
V
A B
F G
EDC
A
[OPERATE] Button/Indicator
Switches operation on or off. Press the button to turn operation
AONB
and hold down the button to turn operation AOFFB. The
indicator blinks while the recorder is starting up or shutting down.
B
[REC CONTROL] Button/Indicator
Switches the recording control mode on or off. The indicator lights up when the recording control mode is set to on. Press and hold the [FUNCTION] button, and press the [REC CONTROL] button at the same time to display the menu.
Memo :
The main menu cannot be displayed in the recording control mode or during recording.
The recording control mode performs recording in accordance with the settings in the [Camera Record Setting] menu. (APage 53)
C
[SELECT] Button/Indicator
Use the S key to set to the camera selection mode. The indicator lights up when the camera selection mode is set to on. ( Press the [FUNCTION] button, [ALARM CLEAR] button and the [SELECT] button at the same time to reboot the NVR Viewer as well as the internal distribution server.
D
[PTZ/PRESET] Button/Indicator
Switches between the PTZ mode and PRESET mode of the S key. The mode changes each time the button is pressed. The indicator lights up when PTZ mode is selected and blinks when PRESET mode is selected.
E
[SERIAL] Terminal
For connecting the communication control terminals on a mouse (sold separately), flash memory (sold separately) or UPS (sold separately).
Memo :
Use the [SERIAL1 to 4] port on the rear panel for additional hard disk drive connection. (APage 14)
H
A
Page 36)
I
STU
JLMON
K
Note :
Attach the serial port cover supplied with this product if this port is not in use.
This product may malfunction due to the presence of static electricity. Remove any static before starting operation.
F
[ZOOM OUT/CANCEL] Button
Selects ZOOM OUT (APage 35) when PTZ mode is selected and selects a view in PRESET mode. Cancels the selected values in the Main Menu window. Also, pressing the [ZOOM OUT/CANCEL] button while holding down the [FUNCTION] button changes the resolution of VGA output.
G
[ZOOM IN/ENTER] Button
Selects ZOOM OUT (APage 35) when PTZ mode is selected and selects a view in PRESET mode. Sets the selected values in the Main Menu window. Also, pressing the [ZOOM IN/ENTER] button while holding down the [FUNCTION] button changes the resolution of VGA output. You can control the click action of the mouse when the software keyboard is displayed. (
H
Status indicators
[WARNING] Indicator
Lights up when an error occurs. (APage 151) Press and hold the [ALARM CLEAR] button to turn off the light.
[ALARM] Indicator
Lights up when an alarm is activated. Goes off when the [ALARM CLEAR] button is pressed.
[HDD] Indicator
Lights up when the built-in hard disk drive is accessed.
[LOCK] Indicator
Lights up when operation is locked. (APage 22)
I
[FUNCTION] Button
Press the [FUNCTION] together with another button to use the corresponding features. [Special Key Operations] (APage 134) Press the [FUNCTION] button, [ALARM CLEAR] button and the [SELECT] button at the same time to reboot the NVR Viewer as well as the internal distribution server.
A
Page 28)
P
R
Q
16
J
[SEARCH] Button
Displays the date and time search screen when in the playback mode. (
A
Page 40)
K
[KEY] Button
When [KEY] button is pressed while pressing [FUNCTION] button, key operation on front panel will be disabled. (Key locked mode) To disable, perform same procedure again. Press to display or hide the
A
software keyboardB.
Memo :
Use the software keyboard to input characters. (APage 28)
L
[ALARM CLEAR] Button
Clears the [ALARM] display when an event occurs or motion is detected. Press and hold this button to turn off the [WARNING] indicator. Press the [FUNCTION] button, [ALARM CLEAR] button and the [SELECT] button at the same time to reboot the NVR Viewer as well as the internal distribution server.
M
[REC/STOP] Button
Press to start recording in all cameras. (When the recording control mode is turned on, recording on all cameras starts after turning off the recording control mode. ) Press and hold down to stop recording. When in the recording control mode, press and hold this button to exit the recording control mode.
Memo :
Recording will not be started in cameras to which no video signal is being input.
The manual recording mode executes recording from all cameras regardless of the settings in the [Camera Record Setting]. Recording is carried out in accordance with the frame rate selected in [Camera Record Setting]. (APage 84)
N
[STOP(PB)] Button
Stops playback when you press this button in the playback mode.
O
[PLAY] Button
Plays back at the speed and in the direction specified by the Shuttle Dial position.
P
[SKIP] Button
䡵[S
]
Press to move the item selection in the reverse direction in the menu or settings screen. Jumps to the beginning of the previous sequence on the selected camera when you press this button in the playback mode. Press and hold it to jump to the first image in the database of the selected camera.
䡵[T
]
Press to move the item selection in the forward direction in the menu or settings screen. Jumps to the beginning of the next sequence on the selected camera when you press this button in the playback mode. Press and hold it to jump to the last image in the database of the selected camera.
Memo :
“Sequence” indicates a certain block of images that are recorded during motion detection.
Recorded images are stored in the database. “Database” refers to data recorded in this unit.
Q
Jog dial
Plays back a single frame when it is rotated in the playback mode.
R
Shuttle dial
The position of the dial specifies the playback speed and playback direction when in the playback mode. Playback speed is selectable from x 1/20, x 1/5, x 1, x 2, x 5, x 10 and x 20 according to the angle.
S
[REC] Indicator
Lights up during recording. Flashes during EMERGENCY or EXT REC IN recording.
T
Center panel
Do not remove the cover.
U
Keypad buttons/Indicator
[0] to [9]
Selects the camera input when viewing live images and when playing back recorded images. The indicator that corresponds to the selected camera input lights up during camera selection mode. Used to move the camera to the specified position during PTZ mode, to enter the preset number during PRESET mode and to narrow down the search date, month, week and time in the search mode. You can move the mouse cursor when the software keyboard is displayed. When the main menu is displayed, press the [2/ [8/
E
] button to move the option highlight. These buttons are also
used as numeric keys.
V
[LIVE/BROWSE] Button/Indicator
Switches between the [Live] mode and [Browse] mode. The indicator lights up when in the [Live] mode. Pressing the [LIVE/BROWSE] button when the wallpaper screen is displayed shows the [Live] screen. Press and hold the [FUNCTION] button, and press and hold the [LIVE/ BROWSE] button at the same time to log out of the system. Press the [FUNCTION] button, [ALARM RESET] button and the [SELECT] button at the same time to reboot the NVR Viewer as well as the internal distribution server.
D
] or
Memo :
When [Auto Logon] is enabled, the login operation starts automatically immediately after logging out. ( Setting])
A
Page 69 [Unit
17
Getting Started
Part Names and Functions (VR-N900U) (continued)
Rear Panel
W
X
hifg
Z
a b
W
[POWER] switch
Switches the power on or off.
Memo :
Be sure to press and hold down the [OPERATE] button on the front panel to shut down the system before switching off the power supply.
X
[AC IN 120V H 240VH 50Hz/60Hz] power input
terminal
Connect to an AC outlet using the power cable supplied.
Y
[RESET]
Resets the system. Press this button when a malfunction occurs.
Note :
Do not press this button in normal circumstances.
Z
[AUDIO IN 1/AUDIO IN 2] audio input terminals 1/2
(RCA)
Connect to the audio output terminal of the device from which audio signals are to be recorded.
a
[AUDIO OUT] audio output terminal (RCA)
Outputs live sound in the live viewing mode. Outputs recorded sound in the playback mode.
Memo :
There is no audio output when playing back still images, when running searches other than x1, or when playing back frame-by­frame.
b
[VIDEO IN1 to 4] camera video signal input terminals
1 to 4
Connect to the video output terminal of the analog camera (sold separately).
c
[VGA OUT] VGA output terminal
Outputs live images, recorded images and the menu screens.
d
[SERIAL1 to 4] serial terminals 1 to 4
For connecting the communication control terminals on a mouse (sold separately), flash memory (sold separately), UPS (sold separately) or additional disk drive (sold separately).
cYd
e
e
Connector cover
Memo :
Do not remove the cover.
f
[LAN1] LAN1 connection terminal (camera network)
For connecting to the IP camera (sold separately) network using a LAN cable.
Color Status
Left Indicator
Green On Connected to a 100Mbit/Sec
Orange
Right Indicator
g
[LAN2] LAN2 connection terminal (Intranet)
For connecting to the remote PC network using a LAN cable.
Left Indicator
Right Indicator
h
[CAMERA CONTROL] camera control terminal
Lets you control the analog cameras.
i
Signal input/output terminals
For operating VR-N1600U/E using external alarm signals or signals received from external devices, or for operating external devices by outputting signals.
Orange
Color Status
Green Off Not connected to the network.
Green Off Not communicating.
Off Not connected to the network or
connected to a 10Mbit/Sec network.
network.
On Connected to a 1Gbit/Sec
network. Off Not communicating. Blinking Communicating.
Blinking Connected to the network.
Blinking Communicating.
Memo :
Diameter of applicable cable: AWG22 to AWG28
18
Rear I/O Terminals
u
klmnopqrs
j
t
Input ports
j
[ALARM IN 1 to 4] alarm input terminals 1 to 4
Alarm recording is activated when signals are input to these terminals.
k
[EMERGENCY] emergency input terminal
Recording is activated in all cameras when a signal is input to this terminal.
l
[ALARM RESET] alarm reset input terminal
Output from the alarm output terminal is stopped when a signal is input during output of the Alarm Out signals. Turns off the [ALARM] indicator to turn off the [WARNING] indicator
m
[EXT REC IN] external recording input terminal
Recording in all cameras is started or stopped by an external signal. Recording will not be started in cameras to which no video signal is being input.
n
[OPE ON/OFF] Operate ON/OFF terminal
Switches between OPERATE ON or OFF when a signal is input. (
A
Page 30)
Note :
Input ports j to n will not operate when the main menu is displayed. Inputs such as alarms will also be ignored when the main menu is displayed.
H
on the unit. Press and hold down
H
.
Output ports
o
[COMMON] signal ground terminal
This is a common ground terminal. Connect it to the signal ground terminal on the connected device. (This can be used when there are insufficient common ground terminals.)
p
[ALARM OUT] alarm output terminal
Outputs a signal when recording is started by an alarm.
q
[WARNING OUT] warning output terminal
Outputs a signal when an error such as operation abnormality occurs on the hard disk.
r
[REC TALLY] recording status output terminal
Outputs the recording status of this unit.
s
[OPTION OUT1][OPTION OUT2] OPT OUT output
terminals 1/2
Outputs a signal when an event is detected.
t
[COMMON] signal ground terminal
Same as j.
u
[SIGNAL GND] signal ground terminal
This is a common ground terminal. Connect it to the signal ground terminal on the connected device. (This can be used when there are insufficient common ground terminals.
Memo :
Do not use this terminal for protective earthing.
19
Getting Started
N

Rear Panel Terminals

Rear I/O Terminals
Terminal Remarks
[ALARM IN]
Name of Input Event
Alarm IN 1 to 8 Falling (VR-N1600U/E) Alarm IN 1 to 4 Falling (VR-N900U)
ame of Input Event
Alarm IN 1 to 8 Rising (VR-N1600U/E) Alarm IN 1 to 4 Rising (VR-N900U)
Make Contact Input
[EMERGENCY] [ALARM RESET]
[EXT REC IN]
[OPE ON/OFF]
250 ms and above
Make
250 ms and above
Break
Memo :
Set the impedance at the output end to 10 kK or lower.
250 ms and above
Memo :
Set the impedance at the output end to 10 kK or lower.
250 ms and above
Memo :
Set the impedance at the output end to 10 kK or lower.
Make Contact Input
Make Contact Input
Make Contact Input
[REC TALLY] [ALARM OUT] [WARNING OUT] [OPTION OUT1] [OPTION OUT2]
20
1 s and above
OPE ON
Approx. 50 ms
OPE OFF
Memo :
Set the impedance at the output end to 10 kK or lower.
Name of Output Event
Set output Option Out 1,2 high
Make Output
(External Pull-up Level) The make contact is formed using the individual output terminals and the COM terminal. Turning off the power of this unit switches the output of the output terminals to break.
Name of Output Event
Set output Option Out 1,2 low
Auto Collector Output (DC15V, 10 mA and below)

Camera Control Terminal (VR-N900U)

Use connection cables according to the table below. Also make sure that you read through the instruction manual of the equipment to be connected.
Signal Pin No.
RX+ 1
RX- 2 TX- 3
TX+ 4
GND 5
NC 6 NC 7 NC 8 NC 9
(D-sub 9 pin, male)

Differences when operating VR-N1600U/E and VR-N900U

Mounting to a Rack

Use the supplied rack mount bracket to mount this unit to the EIA rack. For the installation to the rack, consult the specialist or dealer.
1 Mount the rack mount bracket using screw (1)
Use the 4 screws (M4 x 10 mm) supplied to fasten this unit at the two sides.
2 Remove the foot screws B (4 pcs) at the bottom
of the unit
Remove the foot.
3 Mount to the rack using screws C
Use the 4 screws (M5 x 11 mm) supplied to fasten this unit to the rack.
The name of control buttons and operating methods may vary between VR-N1600U/E and VR-N900U. Such circumstances will be indicated using the rules below.
When name of control button is different
A
Indicated accordingly using [button name of VR­N1600U/E] and (button name of VR-N900U)
B
`
mark is inserted at the end of the sentence
A
Press the [16/ENTER](ZOOM IN/ENTER)button.
When operating method is different
The operation for the respective model is stated, and the model name is indicated at the end of the sentence.
B
Rack Mount Bracket
(4 Screws)
Note :
Do not place any object on this unit when it is mounted to the rack. Doing so may cause it to lose balance and drop or fall, hence resulting in injuries or damages.
When mounting more than one of this unit to the rack, make sure to mount each at a distance that is at least equivalent to one unit.
When remounting the removed foot, make sure to use same screws (M3x6 mm). Using a longer screw may cause malfunction.
21
Getting Started

Operation Lock

VR-N1600U/VR-N1600E/VR-N900U is equipped with an operation lock feature to prevent the system from being turned off accidentally as well as unauthorized recording operations.
Setting Operation Lock
1
Press and hold the [FUNCTION] button, and press the [KEY] button at the same time
Operation is locked. The [LOCK] indicator lights up when in the operation lock mode.
Canceling Operation Lock
1 (When in the operation lock mode) Press the
[KEY] button while holding down the [FUNCTION] button
Operation lock is canceled.
The light of the [LOCK] indicator goes off.
[LOCK] Indicator

During Initial Startup

Perform language setting and automatic camera registration when starting up this unit for the first time.
Before Starting Up.
The DHCP setting is required for the IP camera beforehand. Start up this unit first, then switch the camera on after confirming that the [Auto Detect Setting] window is displayed.
Refer to the user manual supplied with the camera for instructions on how to specify the IP camera settings.
By default, Time zone is set to GMT. Specify a Time zone according to the region used. Refer to the INSTRUCTIONS on how to specify a Time zone settings.
Keypad
VR-N1600U/E
OPERATE
REC CONTROL
LIVE/BROWSE
SELECT
PTZ/PRESET
SERIAL
㧝 㧞 㧟
㧡
㧢*1/'
㧥  
   
CANCEL ZOOMOUT ZOOM IN ENTER
WARNING
ALARM
HDD
㧣
LOCK

SEARCHFUNCTION ALARMCLEARKE Y REC/STOP STOP(PB) PLAY
REV FWD
SKIP
OPERATE
REC CONTROL
LIVE/BROWSE
SELECT
PTZ/PRESET
SERIAL
㧝 㧞 㧟
㧡
㧣
㧢*1/'
㧥  
   
CANCEL ZOOMOUT ZOOM IN ENTER
[FUNCTION] button
[FUNCTION] button
WARNING
ALARM
HDD
LOCK

SEARCHFUNCTION ALARMCLEARKEY REC/STOP STOP(PB) PLAY
[KEY] Button
[LOCK] Indicator
[KEY] Button
VR-N1600U/E
REV FWD
SKIP
VR-N900U
[16/ENTER] Button
Keypad
[ZOOM IN/ENTER]
[KEY] Button
[KEY] Button
[SKIP] Button
VR-N900U
[SKIP] Button
Button
Starting the unit
1 Turn on the power switch at the rear panel.
Doing so starts up the unit.
22
