JVC KB2 Service Manual

PARTS LIST

[ MX-KB2 ]

* All printed circuit boards and its assemblies are not available as service parts.

Area suffix

UY ------------------------ Argentina

MB335

- Contents -

Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~05)
Packing materials and accessories parts list (Block No.M3)

3- 2
3- 6
3-14

3-1

Exploded view of general assembly and parts list

o

9

5

6

Block No.

76

41

12

13

Main board

10

78

M

M

1

M

5

27

60

20

59

42

26

21

19

68

46

Main Key b

59

9

49

22

5

59

67

35

70

2

68

7

48

34

3

6

47

1

43

63

14

72

67

11

17

33

38

72

58

44

58

63

68

33

4

44

32

38

25

79

32

14

58

45

80

8

77

18

65

28

29

64

30

31

23

24

39

3-2

64

59

60

59

57

Main Key board

59

9

15

36

59

57

50

60

61

71

57

56

Display board

57

60

64

57

59

59

15

61

54

F804

90

F803

89

F802

65

88

F801

87

64

52

64

37

51

73

64

49

64

64

83

55

55

91

85

74

86

66

75

66

84

64

68

40

65

63

62

57

62

64

64

69

53

Power board

62

65

16

65

3-3

General Assembly



Symbol No. Part No. Part Name Description Local

1 OW43-01001-03 CASS LENS L
2 OW43-01001-04 CASS LENS R
3 OW43-01001-05 DISPLAY WINDOW
4 OW48-01001-00 VOLUME RING
5 OW48-01001-01 KNOB BRACKET FUNCTION
6 OW48-01001-02 CASS BRACKET L
7 OW48-01001-03 CASS BRACKET R
8 OW48-01001-04 BASS KNOB LEVER
9 OW48-01001-05 SOUND KNOB LEVER
10 OW48-01001-06 VFD BRACKET
11 OW48-01001-07 REMOTE BRACKET
12 OW48-01001-08 PCB BRACKET L MAIN
13 OW48-01001-09 PCB BRACKET R MAIN
14 OW48-01001-10 SUPPORT BLOCK (x2)
15 OW48-01001-11 SUPPORT WASHER (x2)
16 OW48-01001-12 PCB BRACKET TUNER
17 OW51-01001-00 VOLUME KNOB
18 OW53-01001-00 AUX KNOB
19 OW53-01001-01 OPEN CLOSE KNOB
20 OW53-01001-02 RECORD KNOB
21 OW53-01001-03 REPEAT KNOB
22 OW53-01001-04 CLOCK KNOB
23 OW53-01001-05 CD KNOB
24 OW53-01001-06 STOP KNOB
25 OW53-01001-07 BASS KNOB
26 OW53-01001-08 SOUND KNOB
27 OW53-01001-09 POWER KNOB
28 OW53-01001-11 FM/AM KNOB
29 OW53-01001-12 CD PLAY KNOB
30 OW53-01001-13 TAPE A KNOB
31 OW53-01001-14 TAPE B KNOB
32 OW55-00005-80 LATCH (x2)
33 OW55-00005-81 LATCH HOLDER (x2)
34 OW55-01001-00 JVC BADGE
35 OW60-01001-02 FRONT PANEL
36 OW60-01001-01 TOP CABINET
37 OW61-01001-00 HEATSINK COVER
38 OW63-00303-80 DAMPER GEAR for CASS DOOR(x2)
39 OW65-01001-00 SIDE PANEL L
40 OW65-01001-01 SIDE PANEL R
41 OW66-01001-00 3 CD DOOR
42 OW66-01001-01 CASS DOOR L
43 OW66-01001-02 CASS DOOR R
44 OW36-00005-80 CASS SPRING (x2)
45 OW36-01001-00 SPRING BASS KNOB
46 OW36-01001-01 SPRING SOUND KNOB
47 OW36-01001-02 SPRING CASS DOOR L
48 OW36-01001-03 SPRING CASS DOOR R
49 OW39-01001-01 BOTTOM
50 OW39-01001-03 SUPPORT PLATE for DISPLAY&KEY PCB
51 OW39-01001-04 HEAT SINK
52 OW39-01001-05 HEAT SINK BKT L
53 OW39-01001-06 HEAT SINK BKT R
54 OW39-01001-19 BACK PLATE
55 OW40-84006-53 SCREW (x4)
56 OW40-92008-01 SCREW (x3)
57 OW40-92608-11 SCREW (x13)
58 OW40-92610-01 SCREW (x6)
59 OW40-92612-01 SCREW (x19)
60 OW40-92615-01 SCREW (x6)
61 OW40-92616-01 SCREW (x2)
62 OW40-93006-51 SCREW (x6)
63 OW40-93008-11 SCREW (x10)
64 OW40-93008-51 SCREW (x22)
65 OW40-93010-01 SCREW (x12)
66 OW40-93010-51 SCREW (x4)
67 OW40-93015-01 SCREW (x4)
68 OW40-93015-02 SCREW (x6)
69 OW40-93015-51 SCREW (x2)
70 OW43-01001-00 MIRROR SHEET
71 OW68-91002-00 SHIELD PAPER
72 OW81-01001-00 RUBBER FOOT (x2)
73 OW81-01001-01 MICA SHEET
74 OW81-01001-02 RUBBER FOOT (x2)

Block No. [M][1][M][M]

3-4



Symbol No. Part No. Part Name Description Local



75 OW84-10002-80 STRAIN RELIEF
76 OW98-01001-00 CD CHANGER CMS-FR3BN
77 OW94-01002-00 CASSETTE MECHA CWM43FF44
78 OW91-01002-00 VFD DISPLAY
79 OW12-21235-80 HEADPHONE JACK EJ-3511-0202B
80 OW12-10035-12 PHONE JACK F3.5 ST-101



83 OW15-01002-05 POWER TRANS EI-76
84 OW12-00006-81 SPK TERMINAL CJ-0007-040



85 OW16-60014-80 VOL SELECTOR
86 OW48-01001-14 BRACKET VOLTAGE SELECTOR



87 OW33-57402-02 FUSE F801 4A 250V



88 OW33-57402-02 FUSE F802 4A 250V



89 OW33-57202-03W FUSE F803 2A 250V



90 OW33-57402-02 FUSE F8044A 250V



91 OW30-01002-05 AC CORD

3-5

Electrical parts list

Main board

Block No. [0][1]



Symbol No.

U101 TA8189N IC OW03-08189-80
U201 TC9422 IC OW03-09422-80
U202 TA7291S IC OW03-07291-80
U203 TA7291S IC OW03-07291-80
U300 OW03-87261-80 IC 87EP26F-4K76
U401 TC9462F IC OW03-09462-80
U402 TA2153FN IC OW03-02153-80
U403 TA2092N IC OW03-02092-80
U404 TC94A02F IC OW03-09402-80
U405 AS7C31024-15JC IC OW03-31024-80
U406 TC74HC14 IC OW03-07404-80

Q100 DTC314TS TRANSISTOR OW01-00314-20
Q101 DTC314TS TRANSISTOR OW01-00314-20
Q102 2SC945-P TRANSISTOR OW01-00945-80
Q103 2SC945-P TRANSISTOR OW01-00945-80
Q104 2SA733PNP TRANSISTOR OW01-00733-80
Q105 2SC945-P TRANSISTOR OW01-00945-80
Q106 2SC945-P TRANSISTOR OW01-00945-80
Q108 KSA928A-Y TRANSISTOR OW01-00928-80B
Q109 2SC945-P TRANSISTOR OW01-00945-80
Q110 KSA928A-Y TRANSISTOR OW01-00928-80B
Q111 2SC945-P TRANSISTOR OW01-00945-80
Q112 KSA928A-Y TRANSISTOR OW01-00928-80B
Q113 2SC945-P TRANSISTOR OW01-00945-80
Q115 2SA733PNP TRANSISTOR OW01-00733-80
Q116 DTC314TS TRANSISTOR OW01-00314-20
Q117 DTC314TS TRANSISTOR OW01-00314-20
Q118 DTC314TS TRANSISTOR OW01-00314-20
Q119 DTC314TS TRANSISTOR OW01-00314-20
Q120 DTC314TS TRANSISTOR OW01-00314-20
Q121 DTC314TS TRANSISTOR OW01-00314-20
Q122 2SA733PNP TRANSISTOR OW01-00733-80
Q123 2SC945-P TRANSISTOR OW01-00945-80
Q207 2SC945-P TRANSISTOR OW01-00945-80
Q208 KSA928A-Y TRANSISTOR OW01-00928-80B
Q209 2SC945-P TRANSISTOR OW01-00945-80
Q210 KSA928A-Y TRANSISTOR OW01-00928-80B
Q211 2SC945-P TRANSISTOR OW01-00945-80
Q212 2SC945-P TRANSISTOR OW01-00945-80
Q300 2SC945-P TRANSISTOR OW01-00945-80
Q302 2SC945-P TRANSISTOR OW01-00945-80
Q405 2SA733PNP TRANSISTOR OW01-00733-80
Q406 2SC945-P TRANSISTOR OW01-00945-80
Q407 2SC945-P TRANSISTOR OW01-00945-80
Q408 2SC945-P TRANSISTOR OW01-00945-80
Q409 8050D TRANSISTOR OW01-08050-81
Q410 8050D TRANSISTOR OW01-08050-81
Q411 8050D TRANSISTOR OW01-08050-81

D300 1N4148 DIODE OW02-04148-81
D301 1N4148 DIODE OW02-04148-81
D302 1N4148 DIODE OW02-04148-81
D303 1N4148 DIODE OW02-04148-81
D304 1N4148 DIODE OW02-04148-81
D305 1N4148 DIODE OW02-04148-81
D404 1N4001 DIODE OW02-04001-81
D406 1N4001 DIODE OW02-04001-81

C03 OW05-77102-10 C CAPACITOR Axial 1000pF
C04 OW05-77102-10 C CAPACITOR Axial 1000pF
C05 OW05-77102-10 C CAPACITOR Axial 1000pF
C06 OW05-77102-10 C CAPACITOR Axial 1000pF
C100 OW05-73561-00 C CAPACITOR 560pF
C101 OW05-73561-00 C CAPACITOR 560pF
C102 OW05-73221-00 C CAPACITOR 220pF
C104 OW05-73391-05 C CAPACITOR 390pF
C105 OW05-73391-05 C CAPACITOR 390pF
C106 OW05-73820-00 C CAPACITOR 82pF
C107 OW05-73820-00 C CAPACITOR 82pF
C108 OW05-73561-00 C CAPACITOR 560pF
C109 OW05-73561-00 C CAPACITOR 560pF

Part No. Part Name Description Local



Symbol No.

C110 OW05-73561-00 C CAPACITOR 560pF
C111 OW05-73561-00 C CAPACITOR 560pF
C120 OW05-73102-06F C CAPACITOR 1000pF
C121 OW05-73102-06F C CAPACITOR 1000pF
C124 OW05-73104-06F C CAPACITOR 0.1uF
C125 OW05-73104-06F C CAPACITOR 0.1uF
C126 OW05-73221-00 C CAPACITOR 220pF
C127 OW05-73221-00 C CAPACITOR 220pF
C130 OW05-73104-06F C CAPACITOR 0.1uF
C131 OW05-73104-06F C CAPACITOR 0.1uF
C132 OW05-73104-06F C CAPACITOR 0.1uF
C133 OW05-73102-06F C CAPACITOR 1000pF
C134 OW05-73102-06F C CAPACITOR 1000pF
C156 OW05-73103-06F C CAPACITOR 0.01uF
C200 OW05-73104-06F C CAPACITOR 0.1uF
C201 OW05-73561-00 C CAPACITOR 560pF
C202 OW05-73561-00 C CAPACITOR 560pF
C203 OW05-73104-06F C CAPACITOR 0.1uF
C204 OW05-73104-06F C CAPACITOR 0.1uF
C205 OW05-73103-06F C CAPACITOR 0.01uF
C206 OW05-73103-06F C CAPACITOR 0.01uF
C207 OW05-73471-06F C CAPACITOR 470pF
C208 OW05-73471-06F C CAPACITOR 470pF
C209 OW05-73104-06F C CAPACITOR 0.1uF
C210 OW05-73104-06F C CAPACITOR 0.1uF
C211 OW05-73104-06F C CAPACITOR 0.1uF
C212 OW05-73820-00 C CAPACITOR 82pF
C213 OW05-73820-00 C CAPACITOR 82pF
C214 OW05-73104-06F C CAPACITOR 0.1uF
C215 OW05-73104-06F C CAPACITOR 0.1uF
C218 OW05-73104-06F C CAPACITOR 0.1uF
C219 OW05-73103-06F C CAPACITOR 0.01uF
C220 OW05-73103-06F C CAPACITOR 0.01uF
C221 OW05-73104-06F C CAPACITOR 0.1uF
C222 OW05-73101-00 C CAPACITOR 100pF
C300 OW05-73104-06F C CAPACITOR 0.1uF
C301 OW05-73104-06F C CAPACITOR 0.1uF
C302 OW05-73150-00 C CAPACITOR 15pF
C303 OW07-76000-30 C RESISTOR 0 ohm 1/16W
C304 OW05-73240-00 C CAPACITOR 24pF
C305 OW05-73240-00 C CAPACITOR 24pF
C306 OW05-73150-00 C CAPACITOR 15pF
C307 OW05-73104-06F C CAPACITOR 0.1uF
C308 OW05-73104-06F C CAPACITOR 0.1uF
C309 OW05-73104-06F C CAPACITOR 0.1uF
C310 OW05-73223-06F C CAPACITOR 0.022uF
C311 OW05-73223-06F C CAPACITOR 0.022uF
C315 OW05-73104-06F C CAPACITOR 0.1uF
C316 OW05-73103-06F C CAPACITOR 0.01uF
C317 OW05-73103-06F C CAPACITOR 0.01uF
C318 OW05-73104-06F C CAPACITOR 0.1uF
C319 OW05-73104-06F C CAPACITOR 0.1uF
C320 OW05-73104-06F C CAPACITOR 0.1uF
C322 OW05-73104-06F C CAPACITOR 0.1uF
C400 OW05-73104-06F C CAPACITOR 0.1uF
C402 OW05-73102-06F C CAPACITOR 1000pF
C403 OW05-73102-06F C CAPACITOR 1000pF
C405 OW05-73330-00 C CAPACITOR 33pF
C406 OW05-73330-00 C CAPACITOR 33pF
C407 OW05-73473-00 C CAPACITOR 0.047uF
C408 OW05-73473-00 C CAPACITOR 0.047uF
C409 OW05-73473-00 C CAPACITOR 0.047uF
C410 OW05-73103-06F C CAPACITOR 0.01uF
C411 OW05-73473-00 C CAPACITOR 0.047uF
C412 OW05-73104-06F C CAPACITOR 0.1uF
C413 OW05-73473-00 C CAPACITOR 0.047uF
C414 OW05-73153-00 C CAPACITOR 0.015uF
C415 OW05-73470-06F C CAPACITOR 47pF
C416 OW05-73104-06F C CAPACITOR 0.1uF
C417 OW05-73103-06F C CAPACITOR 0.01uF
C418 OW05-73272-00 C CAPACITOR 2700pF
C419 OW05-73104-06F C CAPACITOR 0.1uF
C420 OW05-73104-06F C CAPACITOR 0.1uF
C421 OW05-73473-00 C CAPACITOR 0.047uF
C422 OW05-73104-06F C CAPACITOR 0.1uF
C423 OW05-73473-00 C CAPACITOR 0.047uF

Part No. Part Name Description Local

3-6



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C424 OW05-73104-06F C CAPACITOR 0.1uF
C425 OW05-73104-06F C CAPACITOR 0.1uF
C426 OW05-73473-00 C CAPACITOR 0.047uF
C427 OW05-73473-00 C CAPACITOR 0.047uF
C428 OW05-73471-06F C CAPACITOR 470pF
C429 OW05-73471-06F C CAPACITOR 470pF
C430 OW05-73473-00 C CAPACITOR 0.047uF
C431 OW05-73473-00 C CAPACITOR 0.047uF
C432 OW05-73224-06F C CAPACITOR 0.22uF
C433 OW05-73224-06F C CAPACITOR 0.22uF
C434 OW05-73104-06F C CAPACITOR 0.1uF
C435 OW05-73820-00 C CAPACITOR 82pF
C436 OW05-73104-06F C CAPACITOR 0.1uF
C437 OW05-73020-00 C CAPACITOR 2pF
C438 OW05-73473-00 C CAPACITOR 0.047uF
C439 OW05-73104-06F C CAPACITOR 0.1uF
C440 OW05-73104-06F C CAPACITOR 0.1uF
C441 OW05-73101-00 C CAPACITOR 100pF
C442 OW05-73104-06F C CAPACITOR 0.1uF
C443 OW05-73104-06F C CAPACITOR 0.1uF
C444 OW05-73104-06F C CAPACITOR 0.1uF
C445 OW05-73222-00 C CAPACITOR 2200pF
C446 OW05-73222-00 C CAPACITOR 2200pF
C447 OW05-73104-06F C CAPACITOR 0.1uF
C448 OW05-73104-06F C CAPACITOR 0.1uF
C449 OW05-73104-06F C CAPACITOR 0.1uF
C450 OW05-73104-06F C CAPACITOR 0.1uF
C451 OW05-73104-06F C CAPACITOR 0.1uF
C452 OW05-73104-06F C CAPACITOR 0.1uF
C453 OW05-73334-00 C CAPACITOR 0.33uF
C454 OW05-73104-06F C CAPACITOR 0.1uF
C455 OW05-73104-06F C CAPACITOR 0.1uF
C460 OW05-73221-00 C CAPACITOR 220pF
C461 OW05-73473-00 C CAPACITOR 0.047uF
C462 OW05-73561-00 C CAPACITOR 560pF
C463 OW05-73561-00 C CAPACITOR 560pF
C465 OW05-73104-06F C CAPACITOR 0.1uF
C466 OW05-73104-06F C CAPACITOR 0.1uF
C468 OW05-77103-20 C CAPACITOR Axial 0.01uF
C469 OW05-77103-20 C CAPACITOR Axial 0.01uF

R100 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R101 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R102 OW07-75513-06 C RESISTOR 51 Kohm 1/16W
R103 OW07-75513-06 C RESISTOR 51 Kohm 1/16W
R104 OW07-75303-06 C RESISTOR 30 Kohm 1/16W
R105 OW07-75303-06 C RESISTOR 30 Kohm 1/16W
R106 OW07-75470-06 C RESISTOR 47 ohm 1/16W
R107 OW07-75470-06 C RESISTOR 47 ohm 1/16W
R108 OW07-75184-06F C RESISTOR 180 Kohm 1/16W
R109 OW07-75184-06F C RESISTOR 180 Kohm 1/16W
R110 OW07-75153-06F C RESISTOR 15 Kohm 1/16W
R111 OW07-75153-06F C RESISTOR 15 Kohm 1/16W
R112 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R113 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R114 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R115 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R116 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R117 OW07-74101-50T C RESISTOR 100 ohm 1/8W
R118 OW07-75394-06F C RESISTOR 390 Kohm 1/16W
R119 OW07-75394-06F C RESISTOR 390 Kohm 1/16W
R120 OW07-75391-06F C RESISTOR 390 ohm 1/16W
R121 OW07-75391-06F C RESISTOR 390 ohm 1/16W
R122 OW07-75201-06 C RESISTOR 200 ohm 1/16W
R123 OW07-75201-06 C RESISTOR 200 ohm 1/16W
R124 OW07-75513-06 C RESISTOR 51 Kohm 1/16W
R125 OW07-75513-06 C RESISTOR 51 Kohm 1/16W
R126 OW07-75562-06F C RESISTOR 5.6 Kohm 1/16W
R127 OW07-75562-06F C RESISTOR 5.6 Kohm 1/16W
R128 OW07-75221-06F C RESISTOR 220 ohm 1/16W
R129 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R131 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R132 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R133 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R134 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R135 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R136 OW07-75220-06F C RESISTOR 22 ohm 1/16W
R137 OW07-74100-50T C RESISTOR 10 ohm 1/8W

R138 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R139 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R140 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R141 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R142 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R143 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R144 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R145 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R146 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R147 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R148 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R149 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R150 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R151 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R152 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R153 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R154 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R155 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R156 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R157 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R158 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R159 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R160 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R161 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R162 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R163 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R164 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R165 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R168 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R169 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R171 OW07-75105-06F C RESISTOR 1 Mohm 1/16W
R172 OW07-75184-06F C RESISTOR 180 Kohm 1/16W
R173 OW07-75184-06F C RESISTOR 180 Kohm 1/16W
R174 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R175 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R176 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R178 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R179 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R180 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R181 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R206 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R208 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R209 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R210 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R211 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R212 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R213 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R214 OW07-74101-50T C RESISTOR 100 ohm 1/8W
R217 OW07-74101-50T C RESISTOR 100 ohm 1/8W
R218 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R220 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R222 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R226 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R227 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R228 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R229 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R230 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R231 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R232 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R233 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R234 OW07-75391-06F C RESISTOR 390 ohm 1/16W
R239 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R240 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R241 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R242 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R243 OW07-75221-06F C RESISTOR 220 ohm 1/16W
R244 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R245 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R246 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R247 OW07-75561-06 C RESISTOR 560 ohm 1/16W
R248 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R249 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R250 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R251 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R252 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R253 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R254 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R255 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W

3-7



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R256 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R257 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R262 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R263 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R264 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R265 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R266 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R267 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R268 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R269 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R270 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R271 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R272 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R273 OW07-75823-06F C RESISTOR 82 Kohm 1/16W
R274 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R275 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R276 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R277 OW07-75823-06F C RESISTOR 82 Kohm 1/16W
R278 OW07-75104-06F C RESISTOR 100 Kohm 1/16W
R279 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R300 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R301 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R302 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R303 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R304 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R306 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R307 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R308 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R309 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R310 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R311 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R313 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R314 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R315 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R316 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R317 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R318 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R319 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R320 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R321 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R322 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R323 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R324 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R325 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R326 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R327 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R329 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R330 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R331 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R332 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R333 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R334 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R335 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R336 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R337 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R338 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R339 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R340 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R341 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R342 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R343 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R344 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R345 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R346 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R347 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R348 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R350 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R351 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R354 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R355 OW07-75331-06 C RESISTOR 330 ohm 1/16W
R357 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R358 OW07-75334-06F C RESISTOR 330 Kohm 1/16W
R361 OW07-74101-50T C RESISTOR 100 ohm 1/8W
R406 OW07-75100-06F C RESISTOR 10 ohm 1/16W
R407 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R408 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R409 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R410 OW07-75103-06F C RESISTOR 10 Kohm 1/16W

R411 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R412 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R413 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R414 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R417 OW07-75224-06 C RESISTOR 220 Kohm 1/16W
R418 OW07-75683-06F C RESISTOR 68 Kohm 1/16W
R419 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R420 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R421 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R422 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R423 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R424 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R425 OW07-75221-06F C RESISTOR 220 ohm 1/16W
R426 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R427 OW07-75823-06F C RESISTOR 82 Kohm 1/16W
R428 OW07-75220-06F C RESISTOR 22 ohm 1/16W
R429 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R430 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R431 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R432 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R433 OW07-75562-06F C RESISTOR 5.6 Kohm 1/16W
R434 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R435 OW07-75332-06F C RESISTOR 3.3 Kohm 1/16W
R436 OW07-74102-30T C RESISTOR 1 Kohm 1/16W
R437 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R438 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R439 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R440 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R441 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R442 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R443 OW07-75473-06F C RESISTOR 47 Kohm 1/16W
R444 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R445 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R446 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R447 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R448 OW07-75471-06 C RESISTOR 470 ohm 1/16W
R450 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R451 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R452 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R453 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R454 OW07-75333-06 C RESISTOR 33 Kohm 1/16W
R455 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R456 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R457 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R458 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R459 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R460 OW07-75271-06 C RESISTOR 270 ohm 1/16W
R461 OW07-75271-06 C RESISTOR 270 ohm 1/16W
R462 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R463 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R464 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R465 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R466 OW07-75271-06 C RESISTOR 270 ohm 1/16W
R467 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R468 OW07-75225-06F C RESISTOR 2.2 Mohm 1/16W
R469 OW07-75271-06 C RESISTOR 270 ohm 1/16W
R470 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R471 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R472 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R473 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R474 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R475 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R476 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R477 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R478 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R479 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R480 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R481 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R482 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R484 OW07-75752-06 C RESISTOR 7.5 Kohm 1/16W
R485 OW07-75752-06 C RESISTOR 7.5 Kohm 1/16W
R487 OW07-75753-06F C RESISTOR 75 Kohm 1/16W
R489 OW07-76000-30 C RESISTOR 0 ohm 1/16W
R498 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R499 OW07-75100-06F C RESISTOR 10 ohm 1/16W
R500 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R501 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R502 OW07-75103-06F C RESISTOR 10 Kohm 1/16W

3-8



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R507 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R508 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R509 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R510 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R511 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R513 OW07-75331-06 C RESISTOR 330 ohm 1/16W
R514 OW07-75331-06 C RESISTOR 330 ohm 1/16W
R516 OW07-75151-06F C RESISTOR 50 ohm 1/16W
R517 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R518 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R519 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R520 OW07-75103-06F C RESISTOR 10 Kohm 1/16W
R521 OW07-75223-06F C RESISTOR 22 Kohm 1/16W
R522 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R523 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R524 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R525 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R526 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R527 OW07-75472-06F C RESISTOR 4.7 Kohm 1/16W
R529 OW07-75223-06F C RESISTOR 22 Kohm 1/16W

L100 OW09-39000-80 CHOKE COIL 39mH
L101 OW09-39000-80 CHOKE COIL 39mH
L102 OW09-70102-80 LEAD INDUCTOR Axial 100mH
L200 OW09-70102-83 LEAD INDUCTOR Axial CEC36-101K
L201 OW09-70102-83 LEAD INDUCTOR Axial CEC36-101K
L300 OW09-70102-80 LEAD INDUCTOR Axial 100mH
L301 OW09-70102-80 LEAD INDUCTOR Axial 100mH
L401 OW08-01122-80 FERRITE BEAD RH03509ST-B246
L402 OW08-01122-80 FERRITE BEAD RH03509ST-B246
L403 OW08-01122-80 FERRITE BEAD RH03509ST-B246
L404 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L405 OW09-70101-80 LEAD INDUCTOR Axial 0mH
L406 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L407 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L408 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L409 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L410 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L411 OW09-70471-80 LEAD INDUCTOR Axial 47mH
L412 OW09-70471-80 LEAD INDUCTOR Axial 47mH
T100 OW08-07163-80 BIAS COIL LOD8869056

CN100 OW20-21030-80 CONNECTOR 3P
CN101 OW20-21070-80 CONNECTOR 7P
CN103 OW20-80130-02 CONNECTOR 13P
CN202 OW20-61030-01 CONNECTOR 3P
CN204 OW20-41101-24 CONNECTOR 10P
CN205 OW20-61133-00 CONNECTOR 13P
CN206 OW20-42110-00 CONNECTOR 11P
CN207 OW20-21130-80 CONNECTOR 13P
CN208 OW20-41020-00 CONNECTOR 2P
CN401 OW20-80160-82 CONNECTOR 16P
CN402 OW20-21060-80 CONNECTOR 6P
CO2 OW06-70108-20 E CAPACITOR 1000uF 10V
EC100 OW06-71476-20 E CAPACITOR 47uF 16V
EC101 OW06-70227-20 E CAPACITOR 220uF 10V
EC102 OW06-70227-20 E CAPACITOR 220uF 10V
EC103 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC104 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC105 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC106 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC107 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC108 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC109 OW06-71476-20 E CAPACITOR 47uF 16V
EC120 OW06-71476-20 E CAPACITOR 47uF 16V
EC121 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC122 OW06-71477-20 E CAPACITOR 470uF 16V
EC123 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC124 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC125 OW06-70227-20 E CAPACITOR 220uF 10V
EC126 OW06-70107-20 E CAPACITOR 100uF 10V
EC127 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC128 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC129 OW06-71476-20 E CAPACITOR 47uF 16V
EC207 OW06-70107-20 E CAPACITOR 100uF 10V
EC208 OW06-70227-20 E CAPACITOR 220uF 10V
EC209 OW06-70227-20 E CAPACITOR 220uF 10V
EC210 OW06-75225-20 E CAPACITOR 2.2uF 50V

EC211 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC212 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC213 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC214 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC215 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC216 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC217 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC218 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC219 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC220 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC221 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC222 OW06-75105-20 E CAPACITOR 1uF 50V
EC223 OW06-75105-20 E CAPACITOR 1uF 50V
EC224 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC225 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC226 OW06-70227-20 E CAPACITOR 220uF 10V
EC227 OW06-70227-20 E CAPACITOR 220uF 10V
EC228 OW06-71476-20 E CAPACITOR 47uF 16V
EC231 OW06-70227-20 E CAPACITOR 220uF 10V
EC232 OW06-71476-20 E CAPACITOR 47uF 16V
EC233 OW06-70107-20 E CAPACITOR 100uF 10V
EC234 OW06-70107-20 E CAPACITOR 100uF 10V
EC235 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC236 OW06-75225-20 E CAPACITOR 2.2uF 50V
EC300 OW06-75105-20 E CAPACITOR 1uF 50V
EC301 OW06-70108-20 E CAPACITOR 1000uF 10V
EC302 OW06-70108-20 E CAPACITOR 1000uF 10V
EC303 OW06-70107-20 E CAPACITOR 100uF 10V
EC304 OW06-72226-20 E CAPACITOR 22uF 25V
EC305 OW06-75105-20 E CAPACITOR 1uF 50V
EC306 OW06-71476-20 E CAPACITOR 47uF 16V
EC307 OW06-72106-20 E CAPACITOR 10uF 25V
EC308 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC404 OW06-70227-20 E CAPACITOR 220uF 10V
EC405 OW06-71476-20 E CAPACITOR 47uF 16V
EC406 OW06-72226-20 E CAPACITOR 22uF 25V
EC408 OW06-75105-20 E CAPACITOR 1uF 50V
EC409 OW06-70107-20 E CAPACITOR 100uF 10V
EC411 OW06-71476-20 E CAPACITOR 47uF 16V
EC412 OW06-71476-20 E CAPACITOR 47uF 16V
EC413 OW06-71476-20 E CAPACITOR 47uF 16V
EC415 OW06-70107-20 E CAPACITOR 100uF 10V
EC416 OW06-71476-20 E CAPACITOR 47uF 16V
EC417 OW06-70107-20 E CAPACITOR 100uF 10V
EC425 OW06-71476-20 E CAPACITOR 47uF 16V
EC426 OW06-72106-20 E CAPACITOR 10uF 25V
EC427 OW06-71477-20 E CAPACITOR 470uF 16V
EC429 OW06-71476-20 E CAPACITOR 47uF 16V
EC430 OW06-71476-20 E CAPACITOR 47uF 16V
EC431 OW06-71476-20 E CAPACITOR 47uF 16V
EC432 OW06-71476-20 E CAPACITOR 47uF 16V
EC433 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC434 OW06-75475-20 E CAPACITOR 4.7uF 50V
EC436 OW06-71476-20 E CAPACITOR 47uF 16V
EC437 OW06-71476-20 E CAPACITOR 47uF 16V
EC438 OW06-71476-20 E CAPACITOR 47uF 16V
EC439 OW06-71476-20 E CAPACITOR 47uF 16V
EC440 OW06-71476-20 E CAPACITOR 47uF 16V
EC441 OW06-71476-20 E CAPACITOR 47uF 16V
EC442 OW06-71476-20 E CAPACITOR 47uF 16V
EC443 OW06-71476-20 E CAPACITOR 47uF 16V
EC444 OW06-71476-20 E CAPACITOR 47uF 16V
EC445 OW06-70227-20 E CAPACITOR 220uF 10V
JR10 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR11 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR12 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR13 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR14 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR15 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR16 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR17 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR18 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR19 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR20 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR21 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR22 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR23 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR24 OW07-76000-30 C RESISTOR 0 ohm 1/16W

3-9



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

JR25 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR26 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR27 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR28 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR29 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR31 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR32 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR33 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR34 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR35 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR37 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR38 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR39 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR40 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR41 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR42 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR43 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR44 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR45 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR47 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR48 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR49 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR50 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR51 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR52 OW07-75001-05F C RESISTOR 0 ohm 1/8W
MC102 OW05-72822-10 M CAPACITOR 0.0082uF
MC103 OW05-72822-10 M CAPACITOR 0.0082uF
MC104 OW05-72472-10 M CAPACITOR 0.0047uF
MC105 OW05-70221-05 C CAPACITOR 220pF
MC106 OW05-72682-10 M CAPACITOR 0.0068uF
MC107 OW05-72102-10 M CAPACITOR 0.001uF
MC108 OW05-72102-10 M CAPACITOR 0.001uF
MC109 OW05-72102-10 M CAPACITOR 0.001uF
MC110 OW05-72102-10 M CAPACITOR 0.001uF
MC111 OW05-72102-10 M CAPACITOR 0.001uF
MC401 OW05-72472-10 M CAPACITOR 0.0047uF
MC402 OW05-72472-10 M CAPACITOR 0.0047uF
P1-2 OW05-77104-82 C CAPACITOR Axial 0.1uF
P3-4 OW05-77104-82 C CAPACITOR Axial 0.1uF
X300 OW09-50720-80 C RESONATOR ZTA7.2MT
X301 OW04-32768-80 CRYSTAL 32.768MHz
X401 OW04-16934-70 CRYSTAL 16.9344MHz
XXXXX OW20-51061-20 CONNECTOR WIRE 6P To CD Pick up
XXXXX OW20-61030-00 CONNECTOR WIRE 3P For Play header
XXXXX OW20-61070-00 CONNECTOR WIRE 7P For R/P Header
XXXXX OW20-61073-11 CONNECTOR WIRE 7P To Power PCB
XXXXX OW39-00013-80 HEAT SINK CDT13 for U403
XXXXX OW11-01002-00 MAIN PCB
XXXXX OW25-61135-80 FFC CABLE 16P
XXXXX OW25-61260-80 CABLE 13P
Z200 3.3V0.5W Z DIODE OW02-50033-80T
Z201 6.2V0.5W Z DIODE OW02-50062-80
Z306 10V0.5W Z DIODE OW02-50100-80
Z402 3.3V0.5W Z DIODE OW02-50033-80T
Z403 3.3V0.5W Z DIODE OW02-50033-80T
Z404 3.9V0.5W Z DIODE OW02-50039-81

Power board

Block No. [0][2]



Symbol No.

IC801 STK402-050 IC(HYBRID) OW03-40205-00
U802 L7809CV IC OW03-07809-85
U803 L7806CV IC OW03-07806-84

Q801 8050 TRANSISTOR OW01-08050-80
Q802 2SB1243 TRANSISTOR OW01-01243-80
Q803 8050 TRANSISTOR OW01-08050-80
Q812 8050 TRANSISTOR OW01-08050-80
Q813 8050 TRANSISTOR OW01-08050-80
Q860 8050 TRANSISTOR OW01-08050-80
Q861 8050 TRANSISTOR OW01-08050-80
Q862 8550 TRANSISTOR OW01-08550-86

Part No. Part Name Description Local

Q864 8050 TRANSISTOR OW01-08050-80
Q865 8050 TRANSISTOR OW01-08050-80
Q867 8050 TRANSISTOR OW01-08050-80
Q868 8550 TRANSISTOR OW01-08550-86
Q869 8050 TRANSISTOR OW01-08050-80
Q870 8050 TRANSISTOR OW01-08050-80
Q871 8050 TRANSISTOR OW01-08050-80

D1 1N4148 DIODE OW02-04148-81
D2 1N4148 DIODE OW02-04148-81
D800 1N4148 DIODE OW02-04148-81
D803 1N4148 DIODE OW02-04148-81
D804 1N4001 DIODE OW02-04001-81
D806 1N4001 DIODE OW02-04001-81
D807 1N4001 DIODE OW02-04001-81
D808 1N4001 DIODE OW02-04001-81
D809 1N4001 DIODE OW02-04001-81
D845 1N4001 DIODE OW02-04001-81
D846 1N4001 DIODE OW02-04001-81
D849 1N5402 DIODE OW02-05402-80
D850 1N5402 DIODE OW02-05402-80
D851 1N5402 DIODE OW02-05402-80
D852 1N5402 DIODE OW02-05402-80
D864 1N4001 DIODE OW02-04001-81
D865 1N4148 DIODE OW02-04148-81

C802 OW05-73221-00 C CAPACITOR 220pF
C803 OW05-73050-05 C CAPACITOR 5pF
C804 OW05-73474-00 C CAPACITOR 0.47uF
C805 OW05-73474-00 C CAPACITOR 0.47uF
C806 OW05-73050-05 C CAPACITOR 5pF
C807 OW05-73102-00 C CAPACITOR 1000pF
C808 OW05-73102-00 C CAPACITOR 1000pF
C814 OW05-73561-00 C CAPACITOR 560pF
C815 OW05-73561-00 C CAPACITOR 560pF
C816 OW05-73221-00 C CAPACITOR 220pF
C821 OW05-73104-00 C CAPACITOR 0.1uF
C839 OW05-73103-00 C CAPACITOR 0.01uF
C842 OW05-73103-00 C CAPACITOR 0.01uF
C860 OW05-73474-00 C CAPACITOR 0.47uF
C861 OW05-73474-00 C CAPACITOR 0.47uF
C862 OW05-73105-06F C CAPACITOR 1uF
C863 OW05-73105-06F C CAPACITOR 1uF
C865 OW05-73104-00 C CAPACITOR 0.1uF
C866 OW05-73104-00 C CAPACITOR 0.1uF

R801 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R802 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R803 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R805 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R806 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R807 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R809 OW07-75047-10 C RESISTOR 4.7 ohm 1W
R810 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R812 OW07-75010-50 C RESISTOR 1 ohm 1/8W
R815 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R816 OW07-70101-11 C RESISTOR 100 ohm 1/2W
R817 OW07-75223-50 C RESISTOR 22 Kohm 1/8W
R818 OW07-75153-50 C RESISTOR 15 Kohm 1/8W
R819 OW07-75153-50 C RESISTOR 15 Kohm 1/8W
R820 OW07-75047-10 C RESISTOR 4.7 ohm 1W
R821 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R823 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R824 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R825 OW07-75331-50 C RESISTOR 330 ohm 1/8W
R826 OW07-75331-50 C RESISTOR 330 ohm 1/8W
R827 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R829 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R830 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R831 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R832 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R837 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R853 OW07-75472-50 C RESISTOR 4.7 Kohm 1/8W
R860 OW07-75472-50 C RESISTOR 4.7 Kohm 1/8W
R861 OW07-75472-50 C RESISTOR 4.7 Kohm 1/8W
R862 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R863 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R864 OW07-75103-50 C RESISTOR 10 Kohm 1/8W

3-10



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R867 OW07-75000-50 C RESISTOR 0 ohm 1/8W
R868 OW07-75000-50 C RESISTOR 0 ohm 1/8W
R870 OW07-75000-50 C RESISTOR 0 ohm 1/8W
R871 OW07-75473-50 C RESISTOR 47 Kohm 1/8W
R872 OW07-75473-50 C RESISTOR 47 Kohm 1/8W
R877 OW07-75223-50 C RESISTOR 22 Kohm 1/8W
R878 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R879 OW07-75122-50 C RESISTOR 1.2 Kohm 1/8W
R880 OW07-75122-50 C RESISTOR 1.2 Kohm 1/8W
R881 OW07-75183-50 C RESISTOR 18 Kohm 1/8W
R882 OW07-75183-50 C RESISTOR 18 Kohm 1/8W
R884 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R885 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R886 OW07-75561-50 C RESISTOR 560 ohm 1/8W
R887 OW07-75561-50 C RESISTOR 560 ohm 1/8W
R901 OW07-74561-40 C RESISTOR 560 ohm 1W
R902 OW07-74561-40 C RESISTOR 560 ohm 1W

L801 OW09-34004-80 CHOKE COIL Spring 2mH
L802 OW09-34004-80 CHOKE COIL Spring 2mH
L804 OW09-00080-00 CHOKE COIL 8mH
L805 OW09-00080-00 CHOKE COIL 8mH

AC3 OW37-00002-80 EYELET F 2 X 4 mm
AC5 OW37-00002-80 EYELET F 2 X 4 mm
AC6 OW37-00002-80 EYELET F 2 X 4 mm
AC7 OW37-00002-80 EYELET F 2 X 4 mm
AC8 OW37-00002-80 EYELET F 2 X 4 mm
AC9 OW37-00002-80 EYELET F 2 X 4 mm
AC-B OW37-00002-80 EYELET F 2 X 4 mm
AC-L OW37-00002-80 EYELET F 2 X 4 mm
AC-N OW37-00002-80 EYELET F 2 X 4 mm
AC10 OW37-00002-80 EYELET F 2 X 4 mm
AC11 OW37-00002-80 EYELET F 2 X 4 mm

AC110 OW37-00002-80 EYELET

AC127 OW37-00002-80 EYELET

AC220 OW37-00002-80 EYELET

AC230 OW37-00002-80 EYELET

CE802 OW06-72228-20B E CAPACITOR 2200uF 25V
CE803 OW06-75107-20 E CAPACITOR 100uF 50V
CE804 OW06-72477-20 E CAPACITOR 470uF 25V
CE805 OW06-75106-20 E CAPACITOR 10uF 50V
CE806 OW06-72107-20 E CAPACITOR 100uF 25V
CE807 OW06-71107-20 E CAPACITOR 100uF 16V
CE808 OW06-72107-20 E CAPACITOR 100uF 25V
CE809 OW06-72107-20 E CAPACITOR 100uF 25V
CE810 OW06-71107-20 E CAPACITOR 100uF 16V
CE811 OW06-75476-20 E CAPACITOR 47uF 50V
CE829 OW06-75228-80 E CAPACITOR 2200uF 50V
CE830 OW06-75228-80 E CAPACITOR 2200uF 50V
CE861 OW06-71107-20 E CAPACITOR 100uF 16V
CE862 OW06-71107-20 E CAPACITOR 100uF 16V
CE865 OW06-72107-20 E CAPACITOR 100uF 25V
CE866 OW06-75106-20 E CAPACITOR 10uF 50V
CN801 OW20-11020-80 CONNECTOR 2P
CN802 OW20-11070-80 CONNECTOR 7P
CN803 OW20-12110-80 CONNECTOR 11P
CN804 OW20-45041-80 CONNECTOR 4P
CN861 OW20-41051-37 CONNECTOR 5P
CN901 OW20-15040-80 CONNECTOR 4P
CN902 OW20-11050-80 CONNECTOR 5P
GND1 OW37-00002-80 EYELET F 2 X 4 mm
J901 OW12-00006-81 SPEAKER JACK NSX-1
JK901 OW12-21235-80 HEADPHONE JACK F 3.5 mm
JW836 OW07-74472-50T C RESISTOR 4.7 Kohm 1/8W
JW901 OW09-00080-00 CHOKE COIL 8mH
JW902 OW09-00080-00 CHOKE COIL 8mH



RL801 OW16-50212-00 RELAY SWITCH

XXXXX OW39-10001-81 FUSE HOLDER F801-F804(x4)
XXXXX OW81-00707-80 BUSHING for U802
XXXXX OW81-00707-80 BUSHING for U803
XXXXX OW11-01002-01 POWER PCB
XXXXX OW11-01002-04 HEADPHONE PCB
XXXXX OW11-01002-06 SPEAKER PCB

F 2 X 4 mm
AC110V
F 2 X 4 mm
AC127V
F 2 X 4 mm
AC220V
F 2 X 4 mm AC230­240V

OSA-SS-212DM5
DC12V

XXXXX OW11-01002-17 VOL SELE PCB
XXXXX OW25-83120-80 CONNECTOR WIRE 2P A1B1 to A2B2
XXXXX OW84-00003-80 CABLE TIE 4 UL
ZD822 13V0.5W Z DIODE OW02-50130-80
ZD823 4.7V0.5W Z DIODE OW02-50047-80

Display board

Block No. [0][3]

Symbol



No.

U500 PT6311 IC OW03-16311-80

D500 1N4148 DIODE OW02-04148-81

C500 OW05-73104-06F C CAPACITOR 0.1uF
C501 OW05-73104-06F C CAPACITOR 0.1uF
C502 OW05-73221-00 C CAPACITOR 220pF
C503 OW05-73221-00 C CAPACITOR 220pF
C504 OW05-73474-03T C CAPACITOR B47K
C505 OW05-73474-03T C CAPACITOR B47K
C506 OW05-73104-06F C CAPACITOR 0.1uF

R500 OW07-75563-06F C RESISTOR 56 Kohm 1/16W
R501 OW07-75101-06F C RESISTOR 100 ohm 1/16W
R503 OW07-75681-06F C RESISTOR 680 ohm 1/16W
R504 OW07-75273-06F C RESISTOR 27 Kohm 1/16W
R505 OW07-75471-06F C RESISTOR 470 ohm 1/16W
R506 OW07-75681-06F C RESISTOR 680 ohm 1/16W
R507 OW07-75821-06 C RESISTOR 820 ohm 1/16W
R508 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R509 OW07-75122-06 C RESISTOR 1.2 Kohm 1/16W
R510 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R511 OW07-75182-06F C RESISTOR 1.8 Kohm 1/16W
R512 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R513 OW07-75272-06 C RESISTOR 2.7 Kohm 1/16W
R514 OW07-75392-06 C RESISTOR 3.9 Kohm 1/16W
R515 OW07-75562-06F C RESISTOR 5.6 Kohm 1/16W
R516 OW07-75822-06F C RESISTOR 8.2 Kohm 1/16W
R518 OW07-75273-06F C RESISTOR 27 Kohm 1/16W
R519 OW07-75471-06F C RESISTOR 470 ohm 1/16W
R520 OW07-75681-06F C RESISTOR 680 ohm 1/16W
R521 OW07-75821-06 C RESISTOR 820 ohm 1/16W
R522 OW07-75102-06F C RESISTOR 1 Kohm 1/16W
R523 OW07-75122-06 C RESISTOR 1.2 Kohm 1/16W
R524 OW07-75152-06F C RESISTOR 1.5 Kohm 1/16W
R525 OW07-75182-06F C RESISTOR 1.8 Kohm 1/16W
R526 OW07-75222-06F C RESISTOR 2.2 Kohm 1/16W
R527 OW07-75272-06 C RESISTOR 2.7 Kohm 1/16W
R528 OW07-75392-06 C RESISTOR 3.9 Kohm 1/16W
R529 OW07-75562-06F C RESISTOR 5.6 Kohm 1/16W
R530 OW07-75822-06F C RESISTOR 8.2 Kohm 1/16W
R531 OW07-75153-06F C RESISTOR 15 Kohm 1/16W
R532 OW07-75153-06F C RESISTOR 15 Kohm 1/16W

L501 OW09-70102-80 LEAD INDUCTOR Axial 47mH
L502 OW08-04446-00 FERRITE COIL 4T 46mH
L503 OW08-04446-00 FERRITE COIL 4T 46mH
L504 OW08-04446-00 FERRITE COIL 4T 46mH

CN500 OW20-41130-00 CONNECTOR 13P
CN504 OW20-21030-80 CONNECTOR 3P
CN505 OW20-11040-80 CONNETOR 4P
CN508 OW20-41040-00 CONNECTOR 4P
EC500 OW06-70227-24 E CAPACITOR 220uF 10V
EC501 OW06-70226-24 E CAPACITOR 220uF 10V
EN500 OW18-51211-00 R.ENCODER 25 mm
IR500 OW02-61719-00 SENSOR HRM138BB1719

LED500 L-1034HD LED

S500 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S501 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S502 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S503 OW16-10102-85 SWITCH 4.3 mm SKQSAE

Part No. Part Name Description Local

OW02-21034-80
RED

3-11



Symbol
No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

S504 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S505 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S506 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S507 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S508 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S509 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S510 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S511 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S512 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S513 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S514 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S515 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S516 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S517 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S518 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S519 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S520 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S521 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S522 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S523 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S524 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S527 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S528 OW16-10102-85 SWITCH 4.3 mm SKQSAE
S529 OW16-10102-85 SWITCH 4.3 mm SKQSAE
SJ500 OW12-10035-12 PHONE JACK F 3.5 ST-101
XXXXX OW05-70104-10 C CAPACITOR 0.1uF
XXXXX OW08-04344-89T FERRITE CORE For CN500
XXXXX OW11-01002-07 DISPLAY PCB

XXXXX OW25-83050-05 CONNECTOR WIRE

XXXXX OW25-83100-02 CONNECTOR WIRE

XXXXX OW25-94060-80 CONNECTOR WIRE

5P CN501 to
CN502

2P CN510 to
CN511
2P CN503 to
CN509

Tuner board

Block No. [0][4]



Symbol No.

IC601 TC9257 IC OW03-09257-81
IC602 TA2149BN IC OW03-02149-81

Q601 9014 TRANSISTOR OW01-09014-85
Q602 9014 TRANSISTOR OW01-09014-85
Q603 9014 TRANSISTOR OW01-09014-85
Q604 9014 TRANSISTOR OW01-09014-85
Q605 2SC945-P TRANSISTOR OW01-00945-80
Q606 9014 TRANSISTOR OW01-09014-85
Q607 8550 TRANSISTOR OW01-08550-86
Q608 2SC945-P TRANSISTOR OW01-00945-80
Q609 2SC945-P TRANSISTOR OW01-00945-80
Q610 SVC348S VARI CAP DIODE OW02-00348-80
Q611 2SC945-P TRANSISTOR OW01-00945-80

D601 1N4148 DIODE OW02-04148-81
D602 1N4148 DIODE OW02-04148-81
D603 1N4148 DIODE OW02-04148-81
D604 1N4148 DIODE OW02-04148-81

C600 OW05-73104-00 C CAPACITOR 0.1uF
C601 OW05-73330-05 C CAPACITOR 33pF
C602 OW05-73330-05 C CAPACITOR 33pF
C603 OW05-73104-00 C CAPACITOR 0.1uF
C604 OW05-73223-00 C CAPACITOR 0.022uF
C605 OW05-73102-00 C CAPACITOR 1000pF
C606 OW05-73102-00 C CAPACITOR 1000pF
C608 OW05-73103-00 C CAPACITOR 0.01uF
C609 OW05-73104-00 C CAPACITOR 0.1uF
C610 OW05-73331-00 C CAPACITOR 330pF
C611 OW05-73104-00 C CAPACITOR 0.1uF
C612 OW05-73100-05 C CAPACITOR 10pF
C613 OW05-73180-05 C CAPACITOR 18pF
C614 OW05-73060-05 C CAPACITOR 6pF

Part No. Part Name Description Local

C615 OW05-73180-05 C CAPACITOR 18pF
C616 OW05-73220-05 C CAPACITOR 22pF
C617 OW07-75000-50 C RESISTOR 0 ohm 1/8W
C618 OW05-73220-05 C CAPACITOR 22pF
C619 OW05-73270-05 C CAPACITOR 27pF
C620 OW05-73103-00 C CAPACITOR 0.01uF
C621 OW05-73104-00 C CAPACITOR 0.1uF
C622 OW05-73104-00 C CAPACITOR 0.1uF
C623 OW05-73474-00 C CAPACITOR 0.47uF
C624 OW05-73103-00 C CAPACITOR 0.01uF
C625 OW05-73474-00 C CAPACITOR 0.47uF
C626 OW05-73105-06F C CAPACITOR 1uF
C627 OW05-73105-06F C CAPACITOR 1uF
C628 OW05-73474-00 C CAPACITOR 0.47uF
C629 OW05-73104-00 C CAPACITOR 0.1uF
C630 OW05-73104-00 C CAPACITOR 0.1uF
C631 OW05-73473-00 C CAPACITOR 0.047uF
C632 OW05-73104-00 C CAPACITOR 0.1uF
C633 OW05-73104-00 C CAPACITOR 0.1uF
C634 OW05-73223-00 C CAPACITOR 0.022uF
C635 OW05-73180-05 C CAPACITOR 18pF
C636 OW05-73223-00 C CAPACITOR 0.022uF
C637 OW05-73103-00 C CAPACITOR 0.01uF
C638 OW05-73101-05 C CAPACITOR 100pF
C639 OW05-73104-00 C CAPACITOR 0.1uF
C640 OW05-73104-00 C CAPACITOR 0.1uF
C641 OW05-73102-00 C CAPACITOR 1000pF
C642 OW05-73332-00 C CAPACITOR 3300pF
C644 OW05-73180-05 C CAPACITOR 18pF
C645 OW05-73104-00 C CAPACITOR 0.1uF
C647 OW05-73100-05 C CAPACITOR 10pF
C649 OW05-73101-05 C CAPACITOR 100pF
C650 OW05-73101-05 C CAPACITOR 100pF
C651 OW05-73101-05 C CAPACITOR 100pF
C652 OW07-75000-50 C RESISTOR 0 ohm 1/8W
VC603 SVC201 VARI CAP DIODE OW02-00201-81
VC604 OW05-78200-22 TR CAPACITOR 20pF
VC605 SVC201 VARI CAP DIODE OW02-00201-81
VC606 OW05-08100-82 TR CAPACITOR 10pF

R600 OW07-75471-50 C RESISTOR 470 ohm 1/8W
R601 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R602 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R603 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R604 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R605 OW07-75122-50 C RESISTOR 1.2 Kohm 1/8W
R606 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R608 OW07-75331-50 C RESISTOR 330 ohm 1/8W
R609 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R610 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R611 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R612 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R613 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R614 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R615 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R616 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R617 OW07-75472-50 C RESISTOR 4.7 Kohm 1/8W
R618 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R619 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R621 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R622 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R623 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R624 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R625 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R626 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R627 OW07-75471-50 C RESISTOR 470 ohm 1/8W
R629 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R630 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R631 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R632 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R633 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R634 OW07-75221-50 C RESISTOR 220 ohm 1/8W
R635 OW07-75333-06 C RESISTOR 33 Kohm 1/16W
R637 OW07-75331-50 C RESISTOR 330 ohm 1/8W
R639 OW07-75473-50 C RESISTOR 47 Kohm 1/8W
R640 OW07-75392-50 C RESISTOR 3.9 Kohm 1/8W
R641 OW07-75392-50 C RESISTOR 3.9 Kohm 1/8W
R642 OW07-75103-50 C RESISTOR 10 Kohm 1/8W

3-12



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R643 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R644 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R645 OW07-75222-50 C RESISTOR 2.2 Kohm 1/8W
R648 OW07-75332-50 C RESISTOR 3.3 Kohm 1/8W
R649 OW07-75100-50 C RESISTOR 10 ohm 1/8W
R650 OW07-75220-50 C RESISTOR 22 ohm 1/8W
R651 OW07-75100-50 C RESISTOR 10 ohm 1/8W
R652 OW07-75223-50 C RESISTOR 22 Kohm 1/8W
R653 OW07-75473-50 C RESISTOR 47 Kohm 1/8W
R654 OW07-75473-50 C RESISTOR 47 Kohm 1/8W
R655 OW07-75104-50 C RESISTOR 100 Kohm 1/8W
R656 OW07-75104-50 C RESISTOR 100 Kohm 1/8W
R657 OW07-75104-50 C RESISTOR 100 Kohm 1/8W
R660 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R661 OW07-75332-50 C RESISTOR 3.3 Kohm 1/8W

L601 OW09-65035-80 FM COIL F3.5 X 61/20.5
L602 OW09-65035-80 FM COIL F3.5 X 61/20.5
L603 OW09-70101-82T COIL 10mH
L604 OW09-35040-80 FM COIL F 4mm
L605 OW09-35040-80 FM COIL F 4mm

CE600 OW06-72477-20 E CAPACITOR 470uF 25V
CE601 OW06-75475-20 E CAPACITOR 4.7uF 50V
CE602 OW06-75475-20 E CAPACITOR 4.7uF 50V
CE603 OW06-72477-20 E CAPACITOR 470uF 25V
CE604 OW06-72477-20 E CAPACITOR 470uF 25V
CE611 OW06-75225-20 E CAPACITOR 2.2uF 50V
CE612 OW06-75225-20 E CAPACITOR 2.2uF 50V
CF602 OW09-50107-81 CERAMIC FILTER LT10.7MS3
CF604 OW09-50450-89 CERAMIC FILTER AHCFM2-450BL
CN601 OW20-21130-80 CONNECTOR 13P
FMANT OW12-00007-82 FM ANTENNA 75 ohm TC-103
IFT601 OW08-12179-80 IFT COIL AHK7-864364NP
IFT602 OW08-00234-80 IFT COIL 10mm
IFT605 OW08-71495-80 IFT COIL 7mm
IFT606 OW08-87630-80 AM ANT COIL 0A10-876 305NP
J601 OW12-00201-00 AM ANT SOCKET WP2-2B
JW603 OW07-76000-50 C RESISTOR 0 ohm 1/8W
JW614 OW07-76000-50 C RESISTOR 0 ohm 1/8W
JW617 OW07-74221-50T C RESISTOR 220 ohm 1/8W
JW625 OW07-75000-50 C RESISTOR 0 ohm 1/8W
JW626 OW07-76000-50 C RESISTOR 0 ohm 1/8W
JW627 OW07-76000-50 C RESISTOR 0 ohm 1/8W
JW642 OW07-75000-50 C RESISTOR 0 ohm 1/8W
XT601 OW04-07200-80 CRYSTAL 7.2MHz
XXXXX OW08-04344-83 FERRITE CORE For CN500
XXXXX OW81-10001-80 SPONGE L604 L605(x2)
XXXXX OW37-00002-80 EYELET forFM ANT
XXXXX OW08-04344-88 FERRITE CORE T-25 X 15 X 10
XXXXX OW11-01002-03 TUNER PCB
ZD601 3.3V0.5W Z DIODE OW02-50033-80T

CE1 OW06-71476-00 E CAPACITOR 47uF 10V
LED1 OW02-00102-80 INFRARED LED EL-1L2
X1 OW09-50455-80 C RESONATOR 2TB455
XXXXX OW11-01002-08 REMOTE PCB
XXXXX OW36-05000-08 SPRING Remote Spring +
XXXXX OW36-05000-09 SPRING Remote Spring ­XXXXX OW36-05000-82 SPRING CONTACT
XXXXX OW42-05000-15 REMOTE INLAY JVC
XXXXX OW58-01282-05 BATTERY DOOR
XXXXX OW60-01282-06 TOP CABINET
XXXXX OW61-01282-05 BOTTOM CABINET
XXXXX OW81-05000-04 RUBBER KEY
XXXXX OW85-00025-81A POLY BAG

Remote board

Block No. [0][5]



Symbol No.

U1 SC6122 IC OW03-06122-80

Q1 2SC945-P TRANSISTOR OW01-00945-80

D1 1SS-133TP DIODE OW02-00133-80
D2 1SS-133TP DIODE OW02-00133-80
D3 1SS-133TP DIODE OW02-00133-80

C1 OW05-73221-05 C CAPACITOR 220pF
C2 OW05-73221-05 C CAPACITOR 220pF
C3 OW05-73471-05 C CAPACITOR 470pF

R1 OW07-74010-30 C RESISTOR 1 ohm 1/16W
R2 OW07-74104-30 C RESISTOR 100 Kohm 1/16W
R3 OW07-74104-30 C RESISTOR 100 Kohm 1/16W
R4 OW07-74104-30 C RESISTOR 100 Kohm 1/16W

Part No. Part Name Description Local

3-13

Packing materials and accessories parts list

A

A3

A4

P2

P7

Block No.

A2

P1

M

3

M

M

A7

A5

6

P3

A1

P4

P5

P6

3-14

P8

Packing and Accessories



Symbol No. Part No. Part Name Description Local

A 1 OW88-01002-13 INST BOOK LVT1251-008A SPA
A 2 OWRM-SMXKB2U REMOTE UNIT
A 3 OW29-21400-80 FM ANT
A 4 OW23-04910-81 AM LOOP ANT
A 5 ------------ BATTERY (x2)
A 6 MXKB2UW-SPBOX-L SPEAKER BOX L OW00-01002-03
A 7 MXKB2UW-SPBOX-R SPEAKER BOX R OW00-01002-03
P 1 OW85-00025-81A POLY BAG
P 2 OW85-90710-84 POLY BAG
P 3 OW81-01001-04 SHEET SPONGE
P 4 OW86-01001-01 POLYFOAM RIGHT
P 5 OW85-92434-40 POLY BAG
P 6 OW85-91014-82 POLY BAG
P 7 OW86-01001-00 POLYFOAM LEFT
P 8 OW89-01002-07 CARTON BOX

Block No. [M][3][M][M]

3-15
