JVC HR-S6975 User Manual

VIDEO CASSETTE RECORDER

HR-S6975EK

625

INSTRUCTIONS

LPT0912-001A

safety first2

Safety Precautions

The rating plate and the safety caution are on the rear of the unit.

WARNING: DANGEROUS VOLTAGE INSIDE

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN

OR MOISTURE.

IMPORTANT

■ Please read the various precautions on pages 2–4 of this instruction manual before installing or operating the recorder.

■ It should be noted that it may be unlawful to re-record pre-recorded tapes, records, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable programme and in any literary, dramatic, musical, or artistic work embodied therein.

IMPORTANT

Connection to the mains supply in the United Kingdom. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is

too short to reach a power point, then obtain a proper safety approved extension lead/adapter or consult your dealer.

In the unlikely event of the plug fuse failing be sure to replace the fuse only with an identical approved type, as originally fitted, and to replace the fuse cover. If the fuse fails again consult your nearest JVC dealer.

If nonetheless the mains plug is cut off remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply. If this product is not supplied fitted with a mains plug then follow the instructions given below: DO NOT make any connection to the Larger Terminal coded E or Green. The wires in the mains lead are coloured in accordance with the following code:

Blue to N (Neutral) or Black Brown to L (Live) or Red

If these colours do not correspond with the terminal identifications of your plug, connect as follows: Blue wire to terminal coded N (Neutral) or coloured Black. Brown wire to terminal coded L (Live) or coloured Red.

If in doubt — consult a competent electrician.

CAUTION

■ When you are not using the recorder for a long period of time, it is recommended that you disconnect the power cord from the mains outlet.

■ Dangerous voltage inside. Refer internal servicing to qualified service personnel. To prevent electric shock or fire hazard, remove the power cord from the mains outlet prior to connecting or disconnecting any signal lead or aerial.

The STANDBY/ON o button does not completely shut off mains power from the unit, but switches operating current on and off. “y ” shows electrical power standby and “ z” shows

Video tapes recorded with this video recorder in the LP (Long Play) mode cannot be played back on a single-speed video recorder.

ON.

safety first 3

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear.)

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

Failure to heed the following precautions may result in damage to the recorder, remote control or video cassette.

DO NOT place the recorder…

… in an environment prone to extreme temperatures or humidity. … in direct sunlight. … in a dusty environment. … in an environment where strong magnetic fields are generated. … on a surface that is unstable or subject to vibration.

DO NOT block the recorder’s ventilation openings or holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

DO NOT place heavy objects on the recorder or remote control.

DO NOT place anything which might spill on top of the recorder or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

DO NOT expose the apparatus to dripping or splashing.

DO NOT use this equipment in a bathroom or places with water. Also DO NOT place any con-

tainers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

DO NOT place any naked flame sources, such as lighted candles, on the apparatus.

AVOID violent shocks to the recorder during transport.

MOISTURE CONDENSATION

Moisture in the air will condense on the recorder when you move it from a cold place to a warm place, or under extremely humid conditions—just as water droplets form in the surface of a glass filled with cold liquid. Moisture condensation on the head drum will cause damage to the tape. In conditions where condensation may occur, keep the recorder turned on for a few hours to let the moisture dry.

ATTENTION

TO MOBILE PHONE USERS:TO MOBILE PHONE USERS:

TO MOBILE PHONE USERS:

TO MOBILE PHONE USERS:TO MOBILE PHONE USERS: Using a mobile phone in the vicinity of the recorder may cause picture vibration on the TV screen or change the screen to a blue back display.

ON PLACING THE RECORDER:ON PLACING THE RECORDER:

ON PLACING THE RECORDER:

ON PLACING THE RECORDER:ON PLACING THE RECORDER: Some TVs or other appliances generate strong magnetic fields. Do not place this appliance on top of the recorder as it may cause picture disturbance.

625

■ Cassettes marked “S-VHS” and “VHS” can be used with this video cassette recorder. However, S-VHS recordings are possible only with cassettes marked “S-VHS”. By using the S-VHS ET function, it is possible to record and play black with S-VHS picture quality on VHS cassettes with this recorder.

■ VIDEO Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VIDEO Plus+ system is manufactured under license from Gemstar Development Corporation.

safety first4

Some Do’s And Don’ts On The Safe Use Of Equipment

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

DO read the operating instructions before you attempt to use the equipment. DO ensure that all electrical connections (including the mains plug, extension leads and interconnec-

tions between pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your

equipment.

DO be careful with glass panels or doors on equipment. DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is

damaged in any way — switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages. DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is

designed for unattended operation or has a standby mode. Switch off using the switch on the equipment and make sure that your family knows how to do this. Special arrangements may need to be made for infirm or handicapped people.

DON’T use equipment such as personal stereos or radios so that you are distracted from the require-

ments of road safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume, as such use can permanently damage your hearing. DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings.

Overheating will cause damage and shorten the life of the equipment.

DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety

always fit the manufacturer’s approved stand or legs with the fixings provided according to the instructions.

DON’T allow electrical equipment to be exposed to rain or moisture.

ABOVE ALL...

— NEVER let anyone especially children push anything into holes, slots or any other opening in

the case — this could result in a fatal electrical shock;

— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than

sorry!

Contents

Diagrams of Equipment ................................ 6

Equipment Key ............................................. 7

Welcome to JVC ............................................8

Three-Step Quick Start............................... 10

Basic Features ............................................ 13

Advanced Features .....................................29

Subsidiary Information .............................. 55

List of Terms .............................................. 59

diagrams of equipment6

1 2 3

t y

^ &

)

(

W E R

front panel

ENTREE/DECODEUR IN/DECODER

010

ENTREE/SORTIE

L-1L-2

IN/OUT

AUDIO

SORTIE

ENTREE ANT. IN

OUT

ANTENNE

SORTIE RF OUT

*DECODER function is not available in the UK.

rear panel

0 9 8 7 6 5

display

S-VHS

VCR

6 7

remote control

Diagram Key

FRONT PANEL

1 STANDBY/ON o Button turns VCR on/off (loading a cassette also turns power on). 2 Cassette Loading Slot is where cassette is inserted; door closes. 3 24H EXPRESS c Button enables 24H Express Timer Programming. 4 Advanced JOG Dial enables picture search, preset position selection or 24H Express Timer Programming. 5 c Button engages timer— standby mode. 6 b(Display) Button switches display between clock time and Preset Position *(or Mode).

* Preset Position (or Mode) is not displayed during playback.

7 Display Panel provides clear view of various displays and indicators. 8 Infrared Beam Receiving Window is where Remote Control should be aimed when in use.

0000

Button resets

9 countenance the on-screen display to ‘0:00:00’. 10 SP/LP Button select tape speed. 11 T Button starts regular recording (press once), Instant Timer Recording (press twice); sets duration of ITR. 12 | Button stops tape temporarily during recording; stops tape temporarily during playback; plays back frame by frame with each additional press.

SATc Button enables/

disables the Auto Satellite Programme Recording mode.

§ Button stops tape;

13 ejects tape during Stop mode. 14 . Button plays back tape; cancels Pause, Still, Slow, Search modes.

REAR PANEL

1 Mains Power Cord supplies power to VCR. 2 ANT. IN Connector enables connection of aerial. 3 L-2 IN/DECODER Connector enables connection of satellite receiver or second recorder.

* DECODER function is not available in the

UK.

4 L-1 IN/OUT Connector enables AV connection to TV or second VCR.

5 AUDIO OUT (L/R) Connectors enable connection of audio cassette recorder, TV or second VCR for dubbing. 6 RF. OUT Connector enables connection to aerial terminal of TV receiver.

VCR DISPLAY PANEL

Indicator blinks after

1 timer-recording and shows how many programmes have been timer-recorded. 2 Play Indicator lights up during playback; blinks during Repeat Playback or when using Next Function Memory for playback. 3 Record Indicator lights up during recording; blinks during Instant Timer Recording. 4 Channel Display shows preset position where the station currently being received is stored.

Mode shows external input

mode selected (L-1 or L-2)

Clock Display shows

current time.

Preset Position* (or Mode) and Clock Display appear alternately when b is pressed.

* Preset Position (or Mode) is not displayed during playback.

Indicator lights up

5 during Auto Satelite Programme Recording standby model; blinks when Auto Satelite Programme Recording in progress. 6 c Indicator lights when the c button has been pressed to engage Timer mode. 7 VCR Indicator lights when the VCR is in the video mode. At this point, the TV automatically enters AV mode. 8 Programme Stop Time Indicator shows the programme stop time for 24H Express Timer Programming.

9 S-VHS Indicator lights when a cassette marked S-VHS is inserted with S-VHS mode set to ‘ON’, when an S-VHS-recorded tape or S-VHS ET-recorded tape is played back, or when S-VHS ET mode is engaged. 10 Programme Start Time Indicator shows the programme start time for 24H Express Timer Programming.

REMOTE CONTROL

ButtonButton

Button ejects tape

ButtonButton

during stop mode.

STARTSTART

START + / – Button

STARTSTART access Regular Program screen; inputs programme Start Time.

STOPSTOP

STOP

STOPSTOP programme Stop Time. 4 PDC Button enables/ disables PDC recording.

* VPS (Video Programme System) recording is not currently available in the U.K. and not possible with this VCR.

5 x Button cancels timer- programme.

0000 Button resets counter on the on-screen display to ‘0:00:00’. 6 Auto Tracking Button enables/disables auto tracking mode during playback.

/ Button selects tape. 7 AUDIO Button changes output sound mode. 8 PROG Button accesses Timer Programming Set screen. 9 OK Button enters selections made in on-screen menus.

10 Buttons initiate functions such as frame by frame playback and variable speed search. 11 C Button accesses Program screens/displays to check the programme that you have programmed (next programme’s information screen appears each time button is pressed). 12 Buttons initiate index function. 13 < Button rewinds the tape; inltiates reverse picture search. 14 S Button stops tape.

+ / –

ButtonsButtons

Buttons input

ButtonsButtons

equipment key 7

15 T Button starts regular recording (press . the same time)

Button shows current

16 VCR status on the TV screen if O.S.D is set to ON. 17 TV PR +/– Buttons select the connected JVC TV's channel. 18 rButton ‘reviews’ timer-recorded programme. 19 TV

input terminal. 20 STANDBY/ON o Button — same as button on VCR. 21 Number Keys are used in preset position selection and the VIDEO Plus+ Timer Programming. 22 DATE + / – Button input date of programme for timer recording. 23 DAILY Button enables timer recording of daily serials. 24 WEEKLY Button enables timer recording of weekly serials. 25 AUX Button selects VCR’s auxiliary input mode. 26 c Button engages timer- standby mode. 27 b(Display) Button switches display between clock time and Preset Position* (or Mode).

Preset Position (or Mode) is not displayed during playback.

28 TV/VCR Button switches connected TV’s mode between TV and AV. 29 MENU Button accesses Menu screen. 30 PR Buttons are used for selection in on-screen menus.

preset position. 31 3 Button initiates a 30-second period of fast-motion playback. 32 . Button — same as button on VCR. 33 > Button fast- forwards tape; inltiates forward picture search. 34 | Button — same as button on VCR. 35 TV volume of connected JVC TV. 36 TV STANDBY/ON o

Button turns TV on/off.

Button switches TV

PR + / – Buttons select a

+/– Buttons control

welcome to jvc8

before you start

Please read the SAFETY

FIRST on pages 2–4

it tells you about some

safety points

Refer to the diagrams on

pages 6–7 when reading

through these

instructions

Refer to the List of

Terms on page 57 if you

need an explanation for

any terms in this manual

remote control

The Remote Control can

operate most of your

VCR’s functions, as well

as basic functions of JVC

TV sets. (see page 7)

Depending on the type

of JVC TV. Some or all

functions cannot be

operated using the

Remote Control.

Welcome to JVC

Thank you for choosing JVC.

We hope that you will get many hours of enjoyment from your new unit.

In just three easy steps you will be ready to enjoy the exceptional performance of your new VCR. More detailed instructions begin on page 10. They will explain how to use the many sophisticated features this VCR boasts.

Getting Everything Ready

check the contents Unpack the box and place the VCR on a flat, stable surface.

Check that you have the items shown below.

If the Remote Control

doesn’t work properly,

remove it’s battery,

replace the battery and

then try again.

Buttons on the Remote

Control with a small dot

on the left side of the

name can be used to

operate your JVC TV only.

Video Cassette Recorder

RF Cable

“AA” Batteries (x 2)

Infrared Remote

Control Unit

scart and rf

SCART is a

recommended option

because its use

improves the quality of

the picture.

If connecting to a stereo

TV you will need a

SCART cable.

There are several types

of SCART cables, fully-

wired and others.

If you use a SCART

cable, you must also

connect the RF cable.

welcome to jvc 9

GETTING EVERYTHING READY (continued)

connect cables Connect the cables as indicated in the diagram (below), using

the TV Aerial Cable, the

Mains Power Cord

Mains Outlet

You are now ready to start the Three-Step Quick Start which begins on the next page.

RF Cable and the 21-pin SCART Cable (not provided).

RF Cable

(provided)

21-pin SCART Cable

(not provided)

ENTREE/DECODEUR

L-2

IN/DECODER

*DECODER function is not available in the UK.

010

ENTREE/SORTIE

L-1

IN/OUT

SORTIE

OUT

AUDIO

Back of VCR

ENTREE ANT. IN

ANTENNE

SORTIE RF OUT

TV Aerial Cable

(not provided)

three-step quick start10

Three-Step Quick Start

Auto Setup

before you start

Check that the VCR is

turned off and no

cassette is inserted

Load the battery into the

Remote Control

Refer to the Remote

Control diagram

on pages 6–7

Unless indicated

otherwise, use the

buttons on the Remote

Control

Check that the

connection is completed

Turn on the TV

– –:– –

START AUTO SETUP

Press the o button. If ‘Auto’ appears on the display panel, press OK (or ).

what will happen? The display panel on the front of the VCR will show the

word ‘Auto’. Do not press any button on the VCR or the Remote Control.

S-VHS

VCR

The VCR is automatically setting up the tuner channels, clock, the VIDEO Plus+ system assigned Guide Program numbers and the video channel. This only happens the first time that the VCR is

Auto Setup is running: don’t touch any buttons

turned on.

rf and scart connection If you have chosen to

connect the VCR to the TV with both the RF Cable

AUTO SET

PLEASE WAIT

and a 21-pin SCART Cable (not provided) and the TV set is in its AV mode (see the TV manual), you will see the following information displayed on

[MENU]: EXIT

your TV screen:

Your TV screen during Auto Setup if SCART is used

SELECT THE VIDEO CHANNEL

Auto Setup has finished, you will see the following display panel on your VCR:

When

rf cable only If you have only used the RF

S-VHS

VCR

Cable to connect the VCR to the TV, you will see this display. The number is the channel on the TV that the Auto Setup has chosen to be the video channel. In the example, we have presumed that channel 52 is vacant and have set the VCR to 52:

Now tune the TV set to channel 52 (refer to TV manual if necessary); you should see two vertical white bars appear on the TV screen. If the bars do not appear or are not clear, choose another vacant channel pressing PR +/ -- on the Remote Control and try again. If you cannot obtain the vertical white bars on any channel between 22 and 69, consult your local JVC dealer.

rf and scart connection If you have chosen

S-VHS

VCR

to connect the VCR to the TV with both the RF Cable and a 21-pin SCART Cable (not provided), you need to press the PR -- on the Remote Control until the figure reads ‘– –’. This is because you will use the TV in AV mode to view video pictures and therefore do not need a dedicated video channel.

FINISH AUTO SETUP

OK button and move on to Step 2 to check the results.

Press

oops! If there is a power cut or you accidentally press a button during Auto

Setup, turn the VCR off and then on again. Re-perform Auto Setup.

three step quick start 11

Check the Results

When Auto Setup finishes, you will see one of the three following examples on the VCR display panel:

The Preset Positions and the Clock have been set successfully

Go straight to Step 3 (20:00 used as example only).

The Preset Positions have been set successfully but the Clock has not

Perform Clock Set on page 51.

Step 3.

Go to

Neither the Preset Positions or the Clock have been set successfully

Make sure the cables are connected properly to the VCR and turn the VCR off and then on again. Try

Auto Set Up again.

Finish Off

Select the Video channel or AV mode, then make sure that all necessary stations have been stored in the VCR’s memory by using the If station names (ID — 墌 pg.49) have also been stored in the VCR’s memory, the station name will be displayed at the top left corner of the TV screen for about 5 seconds each time you select a different channel via the VCR.

The VCR is now set up. You can now use it to play and record.

IMPORTANT

re-running setup Auto Setup may not behave as described if it has already

• been run on the VCR. This is because some of the information gathered on the first Auto Setup- is retained in memory and that part of the process may be skipped by the VCR.

bad reception In certain reception conditions, station names may not be

• stored correctly, and happens, when you timer-record a TV programme using the VIDEO Plus+ system, the VCR will record a TV programme of a different station. When programming the timer using the VIDEO Plus+ system, be sure to check that the preset position corresponding to the broadcasting station you wish to record has been selected (墌 pg.21,

duplicate stations You may be able to receive the same station from two

• different transmitters in which case Auto Setup will detect and store both. It is normal for one transmitter to give you a better quality picture than the other; to delete those stations which have a poor picture 墌

manual station setting If any of the above problems occur, refer to

• pages47–48 to input station names (墌 change station preset positions (墌

rf connections In certain reception conditions, the Video Channel may not

• be set correctly and interference may appear in the TV picture while the VCR’s power is on. Set your Video Channel manually. (墌 pg.44,

Guide Program Numbers may not be set properly. If this

VIDEO Plus+ Timer Programming).

Change Station Name). You can also

Change Station Preset Position).

PR and PR buttons.

Delete A Channel on page47.

Video Channel Set)

IF YOU HAVE ANY DIFFICULTY WITH THE ABOVE PROCEDURES CALL THE JVC CUSTOMER SERVICE HOT LINE ON 0870 330 5000

three-step quick start12

Basic Features

Playback..................................................... 14

Playback Features ...................................... 16

Recording ................................................... 18

VIDEO Plus+® Timer Programming ............ 21

Express Timer Programming ...................... 24

24H Express Timer Programming ...............26

basic features14

Playback

Playback is the most basic operation possible with your VCR. Audio-visual information recorded on a cassette will be played back on your TV screen just like a broadcast programme.

Load a Video Cassette

before you start

Turn the TV on

Tune the TV to your

Video Channel or to its

AV mode

ntsc tapes

If an NTSC tape is

played, ‘NTSCaPAL’

appears on screen for

about 5 seconds

Some TVs will shrink

the picture and place

black bars at the top and

bottom of the screen.

This is not a malfunction

but you may lose some

on-screen information

The picture may roll up

or down. Correct this by

adjusting the vertical

hold on the TV set

Make sure that the window side of the cassette is facing up and the spine label is facing away from the VCR. Insert the cassette as shown in the diagram below; don’t use too much force. If the VCR was turned off before you inserted the cassette, the power will come on automatically.

The counter on the TV screen will reset to

0:00:00’. If the record safety tab on the

read ‘ video cassette has been removed, playback begins automatically.

Play

If the cassette that you inserted does not start playing automatically, press the . button on the VCR or the Remote Control. ‘bESt’ appears blinking in the display panel during automatic tracking (墌 pg.34).

Stop & Eject

stop Press the § button on the VCR or the S button on the Remote

Control once to stop playback.

The counter and tape

remaining times will be

incorrect

The picture will be

distorted during search,

still or frame-by-frame

playback

eject Press the § button on the VCR a second time or press on the

Remote Control to eject the cassette from the VCR. The cassette will take about 6 seconds to appear once the

NOTE: You can also eject the cassette while the VCR is turned off.

§ button has been pressed.

basic features 15

Rewind and Fast Forward

During Stop Mode:

rewind Press the < button on the Remote Control or turn the JOG Dial

to the left.

fast forward Press the > button on the Remote Control or turn the

JOG Dial to the right.

Video Heads Cleaning

The heads get dirty in the following cases:

• in an environment prone to extreme temperature or humidity.

• in a dusty environment.

• flaw, dirt or mold on video tapes.

• continuous usage for a long time.

Use a dry cleaning cassette — JVC TCL-2 — in the following cases:

• Rough, poor picture appears while a tape is played back.

• The picture is unclear or no picture appears.

• ‘USE CLEANING CASSETTE’ appears on the screen (only with ‘O.S.D.’ set to ‘ON’ ( pg.43).

basic features16

Playback Features

Advanced JOG Dial

The JOG Dial can be found on the front right of the VCR. It has various functions, such as picture search ( this page and pg. 17), selecting preset position ( pg.18), 24H Express Timer Programming ( pg. 28), etc.

Pause During Playback

There are two ways to view a still picture during playback:

method one Press the centre part of the JOG Dial.

method two Press the | button on the VCR or the Remote Contol.

• If the paused picture on the TV screen jumps vertically, press the PR buttons

on the Remote Control until the picture is steady.

• Press . or the JOG Dial to resume playback.

Single Frame Movement

You can move backward or forward from the still picture in one of three ways:

method one Turn the JOG Dial right for forward or left for back.

method two Press the | button on the VCR or the Remote Control. Each time

the | button is pressed, the frame will move forward one frame.

method three Press or on the Remote Control. Each time one of these

buttons is pressed, the frame will advance or move back one frame.

• Press . to resume playback.

basic features 17

Slow Motion

This VCR will play your cassette forwards or backwards in slow motion. You can make it do this in one of three ways:

method one During playback, turn the JOG Dial one click to the left for

forward slow motion. To play in reverse slow motion, continue to turn the JOG Dial to the left one more time.

method two During still picture, press and hold | on the VCR or the Remote

Control for 2 seconds, then release. Press and release | again to return to still picture.

method three During still picture, press and hold the or button on the Remote Control. The picture will return to still when you release the button.

• If the slow motion picture on the TV screen jumps vertically, press the PR

buttons on the Remote Control until the picture is steady.

• Press . to resume playback.

Variable Speed Search

You can use variable speed search with one of two methods:

method one During playback, turn the JOG Dial. The speed forward or reverse

depends upon the number of click stops of the JOG Dial.

method twoDuring playback, press the or button on the Remote

Control. The more times that you press either button, the faster the rate of search. To decrease the speed of search, press the button for the opposite direction.

• Press . to resume playback.

Picture Search

You can perform high speed search in either direction using the JOG Dial or the Remote Control.

jog dial During playback, turn the JOG Dial to the right (for forward search)

or left (for reverse search).

remote control During playback or still picture, press the > on the

Remote Control for forward picture search, or the < button for reverse picture search. Each time you press <or >, the search speed changes between low-speed and high-speed.

• Press . to resume playback.

NOTES:

In the search, still, slow motion or frame-by-frame playback mode

• The picture will be distorted

• The noise bars will appear

• There will be a loss of colour with an LP-recorded tape.

basic features18

Recording

TV signals being received by the recorder’s built in tuner can be recorded onto a video tape. You can ‘capture’ a TV programme using your VCR.

Choose a Programme

before you start

Turn the TV on

Tune the TV to your

Video Channel or to its

AV mode

Choose a blank

cassette which has the

record safety tab still in

place

Record

Safety Tab

Load the cassette into

the VCR (see page 14)

There are two ways to select a preset position of the VCR.

method one Press PR or PR or the number keys on the Remote Control

to select the channel that you wish to record.

method two Push the center part of the JOG Dial so that the preset position

appears on the display panel. While the display is shown, turn the right or left.

JOG Dial to the

Set the Tape Speed

Press /. The current setting for the tape speed appears on the on-screen display or the VCR display panel for about 5 seconds. Press /again to change the setting while tape speed is displayed. You can choose Standard Play (SP) or Long Play (LP). The picture quality on LP recordings will not be as high as on SP recordings, but the tape will last longer.

Start Recording

There are two ways to start recording:

method one Press and hold T and then press . on the Remote Control.

method two Press T on the VCR.

Pause and Resume During Recording

On either the VCR or the Remote Control, press | to temporarily stop recording and press . to resume. You cannot change the preset position on the VCR while it is recording but you can while it is paused (see of this page).

Choose a Programme at the top

+ 42 hidden pages
