PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine
JVC parts be used.
1. EXPLODED VIEW
1.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
306
(HR-V205ER, HR-V206ER, HR-V405ER,HR-V406ER)
306A
305
ADHESIVE TAPE
312
302
306A
FINAL ASSY <M2>
306
(HR-P201ER)
303
307
(HR-V205ER, HR-V206ER, HR-V405ER,HR-V406ER)
308
SPEC OF BARCODE
316
310
302
301
SPEC OF BARCODE
(No.82992)3-1
1.2 FINAL ASSEMBLY <M2>
507
502
506
506
517
MECHANISM
ASSY<M4>
516
515
505
518
518A
c
515
MAIN BOARD
ASSY<03>
c
3
0
0
3
Q
1
0
0
3
D
1
0
0
3
S
J
d
c
e
C
N
50
0
2
0
0
3
Q
1
c
516
d
510
511
e
501A
501B
3-2(No.82992)
501
501C
1.3 MECHANISM ASSEMBLY <M4>
112
AA
124
127
128
126
AA
110
AA
118
77
76
134
AA
122
130
121
74
105
88
BB
90
89
21
4
AA
BB
BB
BB
BB
90
72
71
AA
73
75
37
AA
78
89
38
AA
36
107
AA
Not used
79
137
151
123
125
126
119
107
111
115
80
105
117
26
86
AA
83
81
AA
56
52
58
161
55
53
1
39
3
AA
120
82
113
112
116
114
A/C HEAD
BOARD ASSY <12>
WR2
57
58
42
50
44
49
WR1
51
85
102
AA
AA
69
70
PMD0044A-C
AA
95
AA
96
18B
93
94
Classification Part No. Symbol in drawing
Grease KYODO-SH-JB AA
Oil COSMO-HV56 BB
18A
22
AA
23B
AA
64
65
23
23A
WR3
67
62
59
68
AA
61
60
63
66
AA
15
AA
19
20
LOADING MOTOR
BOARD ASSY <55>
16
24
18
NOTE:The section marked in AA and BB
indicate lubrication and greasing areas.
87
AA
84
AA
46
47
(No.82992)3-3
2. PARTS LIST PACKING AND ACCESSORY ASSEMBLY <M1>
Symbol No.
301 LP31249-002A PACKING CA SE A
301 LP31249-003A PACKING CA SE B,C,D,E
302 LP31251-001A CUSHION ASSY
303 LP41038-002A POLY BAG
305 ------------ BATTERY R6 TYPE(x2) A
306 LP30767-001A REMOCON A
306 LP21138-008A REMOCON B,C,D,E
306A LP40689-001A COVER(BA TTERY) A
306A LP40991-002B COVER(BATTERY) B,C,D,E
307 QAB0057-001 LITHIUM BATTERY B,C,D,E
308 QPC02202230P POLY BAG 22cm x 22cm
310 LPT0833-001B INST BOOK (RUSSIAN) A
310 LPT0810-001A INST BOOK (RUSSIAN) B,C,D,E
312 QAM0505-001 RF CABLE
316 BT-54012-3 WARRANTY CARD B,C,D,E
Part No. Part Name Description Local
FINAL ASSEMBLY <M2>
Symbol No.
501 LP10480-008D FRONT PANEL ASSY A
501 LP10480-004D FRONT PANEL ASSY B
501 LP10480-005D FRONT PANEL ASSY C
501 LP10480-011D FRONT PANEL ASSY D
501 LP10480-012D FRONT PANEL ASSY E
501A LP21159-004A CASSETTE DOOR A
501A LP21159-001A CASSETTE DOOR B,D
501A LP21159-003A CASSETTE DOOR C,E
501B PQ46448 TORSION SPRING
501C LP41035-014A STICKER
502 PQ11898-56-25 TOP COVER A,B,D
502 PQ11898-58-25 TOP COVER C,E
505 PDV2534A DRUM FINAL ASSY A,B,C
505 PDV2537A DRUM FINAL ASSY D,E
506 QYTDSF3010R TAP SC REW
506 QYTDSF3010M T AP SCREW
507 QYTDSF3010M T AP SCREW
510 QYSPSPD3008Z SCREW
511 LP20262-002K BOTTOM CHASSIS
515 QYTDSF4012Z TAP SCREW
516 QYSPSFG3010Z TAP SC REW
517 QMP4A10-170 POWER CORD 1.7m BLACK
518 LP40910-002G HE A D C L E A N E R ASSY
518A PQ46419-2 CLEANER
Part No. Part Name Description Local
M3 x 10mm,SIDE(x2)
3mm x 10mm,SIDE(x2)
3mm x 10mm,REAR
3mm x 8mm,DRUM(x3)
M3 x 10mm, MECHANISM(x2)
M3 x 10mm, MECHANISM(x2)
MECHANISM ASSEMBLY <M4>
Symbol No.
1 LP21039-001X MAIN DECK ASSY
3 LP40097-002E GUIDE POLE CAP
4 NAH0004-001 FE HEAD
15 LP30958-001B LO A D I N G G E A R B AS E
16 QYTPST2620Z TAP SCREW 2. 6 m m x 2 0 m m ( x 2 )
18 LP40798-001A
18A LP21040-001A
18B LP40799-001A
19 LP40837-001A
20 LP40903-002B FIXING PLATE
21 LP40806-001D
22 LP30959-001B LOADING GEAR
23 LP40802-001C
23A LP21041-001D
23B LP40803-001A
24 LP40838-001A
26 LP40808-001E
36 LP21055-001G TAKE UP LEVER
37 LP40943-001A TENSION SPRING
Part No. Part Name Description Local
LOADING GEAR(SUPPL Y) ASSY
LOADING GEAR(SUPPLY)
LOADING ARM(SUPPLY) ASS Y
TORSION SPRING(SUPPL Y)
POLE BASE ASSY(SUPPLY)
LOADING GEAR(T AKE UP) ASSY
LOADING GEAR(TAKE UP)
LOADING ARM(TAKE UP) ASSY
TORSION SPRING(T AKE UP)
POLE BASE ASSY(TAKE UP)
A,B,D
C,E
MODEL MARK
HR-P201ER
HR-V205ER
HR-V206ER
HR-V405ER
Symbol No.
38 LP40859-001D TA KE UP HE AD
39 LP30961-001C LID GUIDE
42 LP40810-001C
44 LP40840-001D TORSION SPRING
46 LP30963-001C PRESS LEVER
47 PQM30017-24 SLIT WASHER
49 LP40813-001D GUIDE ARM ASSY
50 LP40841-001A TORSION SPRING
51 LP30002-090A SPACER
52 NAH0003-001 AC HEAD
53 LP30965-001A HEAD BASE
55 LP40842-001D COMP.SPRING
56 QYTDST2006M TAP SCREW M2 x 6mm
57 LP41036-001A A/C ADJ.SCREW (x2)
58 QYTDST2606Z TAP SCREW 2. 6 mm x 6 mm(x 2 )
59 QAR0289-001 LOADING MOTOR
60 QYTPSP3003Z SCREW 3mm x 3mm(x2)
61 LP21056-002J MOTOR BRACKET
62 QYTPST2620Z TAP SCREW 2.6mm x 20mm
63 LP40814-001B WORM BEARING
64 LP21044-001E CONTROL CAM
65 PQM30017-24 SLIT WASHER
66 LP40815-001A WORM GEAR
67 LP40816-001B HELICAL GEAR
68 LP40817-001A CONNECT GEAR
69 LP10400-001K CONTROL PLATE
70 LP40843-001A TORSION SPRING
71 LP40818-001B TENSION ARM ASSY
72 LP40844-001F TENSION SPRING
73 LP21045-001D TENSION ARM BASE
74 LP40821-001A TENSION BAND ASSY
75 LP30967-001B BAND HOLDER-1
76 LP30968-001C BAND HOLDER-2
77 LP40822-002B ADJUST PIN
78 LP31000-005E TENSION ARM LEVER
79 LP21046-001C MAI N B R A K E ( TAK E U P )
80 LP40824-001A BAND BRAKE ASSY
81 LP30969-002B BRAKE LEVER
82 LP30003-033B TENSION SPRING
83 LP30003-035B TENSION SPRING
84 LP40825-001B
85 QAR0267-002 CAPSTAN MOTOR
86 QYTPSG2606Z TAP SCREW 2. 6 m m x 6mm(x 3 )
87 LP30005-010A BELT
88 LP30970-001A IDLER ARM
89 LP40828-004A IDLER GEAR 1 (x2)
90 LP40829-002A IDLER GEAR 2 (x2)
93 LP40934-001B CLUTCH UNIT
94 PQM30017-47 SLIT WASHER
95 LP30973-001A DIRECT GEAR
96 LP40939-001A COMP.SPRING
102 LP30974-001C CHANGE LEVER
105 LP21049-001A REEL DISK (x2)
107 LP30017-004A SPACE R (x2)
110 LP10401-001K SIDE FRAME(L)
111 LP10402-001M SIDE FRAME(R)
112 QYTDST2606Z TAP SCREW 2. 6 m m x 6mm(x 2 )
113 LP40917-001D TORSION SPRING
114 LP30976-001E SIDE PLATE
115 LP30977-002D LIMIT PLATE
116 LP40846-001C LIMIT SPRING
117 LP31100-002A DRIVE LEVER
118 LP30978-001B DRIVE ARM(L)
119 LP30979-001N DRIVE ARM(R)
120 LP40847-001B TORSION SPRING
121 LP30980-001E CONNECT PLATE
122 LP10403-001C SIDE HOLDER(L)
123 LP10404-001E SIDE HOLDER(R)
124 LP30983-001B LOCK LEVER(L)
125 LP30984-001B LOCK LEVER(R)
126 LP40924-001D TENSION SPRING (x2)
127 LP40972-001A EARTH SPRING(1)
128 LP40857-001B EARTH SPRING(2)
130 LP30981-001G C.HOLDER ASSY
134 LP21051-002C REC SAFETY LEVER
137 LP21052-001K TOP FRAME
151 LP30985-002K DOOR OPENER
Part No. Part Name Description Local
PINCH ROLLER ARM ASSY
CAPSTAN BRAKE ASSY
MODEL MARK
HR-V406ER E
A
B
C
D
3-4(No.82992)
Symbol No.
Part No. Part Name Description Local
Symbol No.
MODEL MARK
HR-P201ER
HR-V205ER
HR-V206ER
HR-V405ER
MODEL MARK
HR-V406ER E
A
B
C
D
Part No. Part Name Description Local
161 LP40993-001A TAPE GU IDE
WR1 WJT0117-001A E-CARD WIRE DRUM-CAPSTAN
WR2 WJT0067-001B E-CARD WIRE A/C HEAD CN2001
WR3 WJS0022-001A E-FL/RB WIRE LOADING MOTOR
MAIN BOARD ASSEMBLY <03>
Symbol No.
PW1 LPA10205-06A MAIN BOARD ASSY A
PW1 LPA10205-08A MAIN BOARD ASSY B,C
PW1 LPA10205-05A MAIN BOARD ASSY D,E
IC1 JCP8060-MSA IC
IC3001 MN101D06GJX IC(MCU)
IC3001 or MN101DF06KAFJX IC(MCU)
IC3002 IC-PST3425U-X IC B,C,D,E
IC3002 or S-80825CNNB-X IC B,C,D,E
IC3003 LPN0812-008A-12 IC(EEPROM)
IC3003 LPN0812-006A-36 IC(EEPROM)
IC3003 LPN0812-002A-38 IC(EEPROM)
IC7002 GP1UM291QK IR DETECT UNIT 38kHz
Q7 2SC4081/QRS/-X TRANSISTOR D,E
Q7 or 2PC4081/R/-X TRANSISTOR D,E
Q7 or 2SD1819A/QRS/-X TRANSISTOR D,E
Q8 2SC4081/QRS/-X TRANSISTOR D,E
Q8 or 2PC4081/R/-X TRANSISTOR D,E
Q8 or 2SD1819A/QRS/-X TRANSISTOR D,E
Q9 2SC4081/QRS/-X TRANSISTOR D,E
Q9 or 2PC4081/R/-X TRANSISTOR D,E
Q9 or 2SD1819A/QRS/-X TRANSISTOR D,E
Q10 2SC4081/QRS/-X TRANSISTOR D,E
Q10 or 2PC4081/R/-X TRANSISTOR D,E
Q10 or 2SD1819A/QRS/-X TRANSISTOR D,E
Q202 2SC4081/QRS/-X TRANSISTOR
Q202 or 2PC4081/R/-X TRANSISTOR
Q202 or 2SD1819A/QRS/-X TRANSISTOR
Q2001 2SC4081/QRS/-X TRANSISTOR
Q2001 or 2SD1819A/QRS/-X TRANSISTOR
Q2001 or 2PC4081/R/-X TRANSISTOR
Q2002 2SC4081/QRS/-X TRANSISTOR
Q2002 or 2SD1819A/QRS/-X TRANSISTOR
Q2002 or 2PC4081/R/-X TRANSISTOR
Q2003 DTA144WUA-X DIGI TRANSISTOR
Q2003 or UN511E-X DIGI TRANSISTOR
Q2003 or RN2309-X DIGI TRANSISTOR
Q2003 or PDTA144WU-X DIGI TRANSISTOR
Q2051 2SC4081/QRS/-X TRANSISTOR
Q2051 or 2SD1819A/QRS/-X TRANSISTOR
Q2051 or 2PC4081/R/-X TRANSISTOR
Q2052 2SA1576A/QR/-X TRANSISTOR
Q2052 or 2SB1218A/QR/-X TRANSISTOR
Q2052 or 2PA1576/R/-X TRANSISTOR
Q2053 DTC144WUA-X DIGI TRANSISTOR
Q2053 or UN521E-X DIGI TRANSISTOR
Q2053 or RN1309-X DIGI TRANSISTOR
Q2053 or PDTC144WU-X DIGI TRANSISTOR
Q2054 2SA1576A/QR/-X TRANSISTOR
Q2054 or 2SB1218A/QR/-X TRANSISTOR
Q2054 or 2PA1576/R/-X TRANSISTOR
Q2055 DTC144WUA-X DIGI TRANSISTOR
Q2055 or UN521E-X DIGI TRANSISTOR
Q2055 or RN1309-X DIGI TRANSISTOR
Q2055 or PDTC144WU-X DIGI TRANSISTOR
Q3003 PTZ-NV16A IC(PHOTO SENSOR)
Q3004 2SD1819A/QRS/-X TRANSISTOR B,C,D,E
Q3004 or 2SC4081/QRS/-X TRANSISTOR B,C,D,E
Q3004 or 2PC4081/R/-X TRANSISTOR B,C,D,E
Q3005 2SD1819A/QRS/-X TRANSISTOR A
Q3005 or 2SC4081/QRS/-X TRANSISTOR A
Q3005 or 2PC4081/R/-X TRANSISTOR A
Q3006 2SD1819A/QRS/-X TRANSISTOR A
Q3006 or 2SC4081/QRS/-X TRANSISTOR A
Q3006 or 2PC4081/R/-X TRANSISTOR A
Part No. Part Name Description Local
*(REFER TO BELOW)
*(REFER TO BELOW)
*(REFER TO BELOW)
B,C
D,E
Q4001 UN5211-X DIGI TRANSISTOR
Q4001 or DTC114EUA-X DIGI TRANSISTOR
Q4001 or PDTC114EU-X DIGI TRANSISTOR
Q4001 or RN1302-X DIGI TRANSISTOR
Q4002 2SD1819A/QRS /-X TRANSISTOR
Q4002 or 2SC4081/QRS/-X TRANSISTOR
Q4002 or 2PC4081/R/-X TRANSISTOR
Q5101 2SK2632-CB14 POWER MOS FET
Q5101 or 2SK2129-LT POWER MOS FET
Q5101 or 2SK2632 POWER MOS FET
Q5101 or 2SK2129 POWER MOS FET
Q5102 2SD2144S/UV/-T TRANSISTOR
Q5301 2SC1740S/RS/-T TRANSISTOR
Q5301 or 2SC3199/YG/-T TRANSISTOR
Q5304 2SD2144S/UV/-T TRANSISTOR
Q5305 DTA114EUA-X DIGI TRANSISTOR
Q5305 or UN5111-X DIGI TRANSISTOR
Q5305 or RN2302-X DIGI TRANSISTOR
Q5305 or PDTA114EU-X DIGI TRANSISTOR
Q5306 DTC114EUA-X DIGI TRANSISTOR
A
Q5306 or UN5211-X DIGI TRANSISTOR
Q5306 or RN1302-X DIGI TRANSISTOR
Q5306 or PDTC114EU-X DIGI TRANSISTOR
Q5307 2SD2144S/UV/-T TRANSISTOR
Q5321 2SD1858/QR/-T TRANSISTOR
Q6030 2SB1218A/RS/-X TRANSISTOR B,C,D,E
Q6031 DTC114EUA-X DIGI TRANSISTOR B,C,D,E
Q6031 or UN5211-X DIGI TRANSISTOR B,C,D,E
Q6031 or RN1302-X DIGI TRANSISTOR B,C,D,E
Q6031 or PDTC114EU-X DIGI TRANSISTOR B,C,D,E
Q6032 DTC114EUA-X DIGI TRANSISTOR B,C,D,E
Q6032 or UN5211-X DIGI TRANSISTOR B,C,D,E
Q6032 or RN1302-X DIGI TRANSISTOR B,C,D,E
Q6032 or PDTC114EU-X DIGI TRANSISTOR B,C,D,E
Q7001 DTA143TUA-X DIGI TRANSISTOR B,C,D,E
Q7002 DTA143TUA-X DIGI TRANSISTOR B,C,D,E
Q7003 DTA143TUA-X DIGI TRANSISTOR B,C,D,E
Q7004 DTA143TUA-X DIGI TRANSISTOR B,C,D,E
Q7005 DTA143TUA-X DIGI TRANSISTOR B,C,D,E
Q7008 DTC143TUA-X DIGI TRANSISTOR B,C,D,E
Q7008 or UN5216-X DIGI TRANSISTOR B,C,D,E
Q7009 DTC143TUA-X DIGI TRANSISTOR B,C,D,E
Q7009 or UN5216-X DIGI TRANSISTOR B,C,D,E
Q7010 DTC143TUA-X DIGI TRANSISTOR
Q7010 or UN5216-X DIGI TRANSISTOR
Q7011 DTC143TUA-X DIGI TRANSISTOR
Q7011 or UN5216-X DIGI TRANSISTOR
Q7012 DTC143TUA-X DIGI TRANSISTOR B,C,D,E
Q7012 or UN5216-X DIGI TRANSISTOR B,C,D,E
Q7013 DTC143TUA-X DIGI TRANSISTOR B,C,D,E
Q7013 or UN5216-X DIGI TRANSISTOR B,C,D,E
Q7014 DTC143TUA-X DIGI TRANSISTOR B,C,D,E
Q7014 or UN5216-X DIGI TRANSISTOR B,C,D,E
Q7106 2SB1218A/QR/-X TRANSISTOR
Q7106 or 2SA1576A/QR/-X TRANSISTOR
Q7106 or 2PA1576/R/-X TRANSISTOR
D2001 1SS133-T2 DIODE
D2001 or 1SS270A-T2 SI DIODE
D3001 LNB2301L01VI LED
D3002 1SS133-T2 DIODE
D3002 or 1SS270A-T2 SI DIODE
D3003 RD33ES/B3/-T2 Z DIODE B,C,D,E
D3003 or MTZJ33C-T2 Z DIODE B,C,D,E
D3004 10EDB20-T2 SI DIODE
D3004 or 1A3G-T2 SI DIODE
D3005 10EDB20-T2 SI DIODE B,C,D,E
D3005 or 1A3G-T2 SI DIODE B,C,D,E
D3009 RD3.9ES/B2/-T2 Z DIODE A
D3009 or MTZJ3.9B-T2 Z DIODE A
D5001 S1WB/A/60-4102 BRIDGE DIODE
D5001 or S1WB/A/60-X BRIDGE DIODE
D5001 or S1WB(A)60F4072X BRIDGE DIODE
D5001 or DI106S-X BRIDGE DIODE
D5001 or DF06S-X BRIDGE DIODE
D5101 AU01-T2 SI DIODE
D5101 or 1SR153-400-T2 FR DIODE
D5101 or ERA18-04-T2 FR DIODE
*The VCR goes to jig RCU mode after replacing the EEPROM and the VCR does not accept some RCU command.
Therefore please set the VCR to the user RCU mode after replacing the EEPROM.
The method of setting the VCR to the user RCU mode is written on the service manual.
(No.82992)3-5
Symbol No.
Part No. Part Name Description Local
Symbol No.
MODEL MARK
HR-P201ER
HR-V205ER
HR-V206ER
HR-V405ER
MODEL MARK
HR-V406ER E
A
B
C
D
Part No. Part Name Description Local
D5101 or 10ERB40-T2 FR DIODE
D5102 AU01-T2 SI DIODE
D5102 or 1SR153-400-T2 FR DIODE
D5102 or ERA18-04-T2 FR DIODE
D5102 or 10ERB40-T2 FR DIODE
D5103 1SS133-T2 DIODE
D5103 or 1SS270A-T2 SI DIODE
D5105 1SS133-T2 DIODE
D5105 or 1SS270A-T2 SI DIODE
D5203 AU01Z-T2 FR DIODE
D5203 or 10ERB20-T2 FR DIODE
D5203 or 1F4G-T2 FR DIODE
D5204 AU01Z-T2 FR DIODE
D5204 or 10ERB20-T2 FR DIODE
D5204 or 1F4G-T2 FR DIODE
D5207 AK04-T2 SB DIODE
D5207 or 11EQS04-T 2 SB DIODE
D5207 or 1S4-T2 SB DIODE
D5207 or SBO40-T2 SB DIODE
D5209 AK04-T2 SB DIODE
D5209 or 11EQS04-T 2 SB DIODE
D5209 or 1S4-T2 SB DIODE
D5209 or SBO40-T2 SB DIODE
D5210 AU01Z-T2 FR DIODE
D5210 or 1F4G-T2 FR DIODE
D5210 or 1SR153-400-T2 FR DIODE
D5210 or 10ERB20-T2 FR DIODE
D5210 or PG104RS-T2 FR DIODE
D5301 MTZJ15C-T2 Z DIODE
D5301 or RD15ES/B3/-T2 Z DIODE
D5302 MTZJ11C-T2 Z DIODE
D5302 or RD11ES/B3/-T2 Z DIODE
D5303 MTZJ5.6A-T2 Z DIODE
D5303 or RD5.6ES/B1/-T2 Z DIODE
D5305 MTZJ5.6C-T2 Z DIODE
D5305 or RD5.6ES/B3/-T2 Z DIODE
D6002 HZ30-2L-T2 Z DIODE
D6002 or HZ30-2LTD Z DIODE
D7004 SLR-342MG-T16 LED POWER-ON A
D7007 SLR-342VR-T16 LED STANDBY/REC A
PC3001 RPI-304J IC(PHOTO SENSOR)
PC3002 RPI-304J IC(PHOTO SENSOR)
PC5101 PC123Y 22 P HOTO COUPLER
C1 NDC21HJ-151X C CAPACITOR 150pF 50V J
C2 NDC21HJ-470X C CAPACITOR 47pF 50V J
C4 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C5 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C6 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C7 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C8 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C9 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C10 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C11 QEPF1HM-105Z E CAPACITOR 1uF 50V M
C13 QEKJ1HM-105Z E CAPACITOR 1uF 50V M D,E
C14 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C15 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C17 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C19 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C20 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C22 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C24 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C25 QEKJ1HM-335Z E CAPACITOR 3.3uF 50V M
C26 QEKJ1EM-106Z E CAPA CITOR 10uF 25V M
C27 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C30 NCB21HK-331X C CAPACITOR 330pF 50V K
C31 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C32 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C33 QEKJ1EM-106Z E CAPA CITOR 10uF 25V M
C34 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C35 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C36 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C37 NDC21HJ-4R0X C CAPACITOR 4pF 50V J
C38 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C39 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C40 NCB21HK-103X C CAPA CITOR 0.01uF 50V K
C41 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C43 QEKJ1HM-335Z E CAPACITOR 3.3uF 50V M
C44 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C45 NCB21HK-472X C CAP AC ITOR 4700pF 50V K
C46 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C47 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C48 NCB21EK-223X C CAPACITOR 0.022uF 25V K
C49 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C55 NDC21HJ-151X C CAPACITOR 150pF 50V J
C56 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C57 NCB21HK-103X C CAP AC ITOR 0.01uF 50V K
C58 NCB21HK-103X C CAP AC ITOR 0.01uF 50V K
C59 NCB21HK-103X C CAP AC ITOR 0.01uF 50V K D,E
C60 NCB21HK-103X C CAP AC ITOR 0.01uF 50V K D,E
C61 QEKC0JM-476Z E CAPACITOR 47uF 6.3V M
C62 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C63 NCB21HK-103X C CAP AC ITOR 0.01uF 50V K D,E
C64 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K D,E
C71 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C201 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C202 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C203 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C205 NDC21HJ-101X C CAPACITOR 100pF 50V J
C207 NCF21CZ-105X C CAPACIT O R 1uF 16V Z
C209 NCB21HK-103X C CAPACITO R 0.01uF 50V K
C211 NCB21HK-103X C CAPACITO R 0.01uF 50V K
C212 NDC21HJ-271X C CAPACITOR 270pF 50V J
C2001 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2002 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C2003 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C2004 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C2005 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 NCB21HK-682X C CAPACITOR 6800pF 50V K
C2007 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2008 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2009 NCB21HK-821X C CAPACITOR 820pF 50V K
C2010 NCB21HK-152X C CAPACITOR 1500pF 50V K
C2011 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C2012 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C2051 NCB21HK-331X C CAPACITOR 330pF 50V K
C2052 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C2053 NCB21HK-472X C CAPACITOR 4700pF 50V K
C2054 NCB21EK-223X C CAPACITOR 0.022uF 25V K
C2055 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
C3011 QETL0JM-338 E CAPACITOR 3300uF 6.3V M B,C,D,E
C3022 NCB21HJ-103X C CAPACITOR 0.01uF 50V J
C3023 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C3024 NDC21HJ-120X C CAPACITOR 12pF 50V J B,C,D,E
C3030 QERF0JM-107Z E CAPACITOR 100uF 6.3V M A
C3031 NCF21EZ-104X C CAPAC ITOR 0.1uF 25V Z
C3036 NDC21HJ-220X C CAPACITOR 22pF 50V J
C3037 NDC21HJ-180X C CAPACITOR 18pF 50V J
C3042 QAT3725-300Z TRIM CAPACITOR
30pF ,TIMER CLOCK
C3045 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C3051 NCF21EZ-104X C CAPAC ITOR 0.1uF 25V Z
C3052 QEKJ1EM-106Z E CAPACITOR 10uF 25V M B,C,D,E
C3054 NCB21HJ-103X C CAPACITOR 0.01uF 50V J
C3056 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C3071 QEKJ1CM-336Z E CAPACITOR 33uF 16V M
C3078 NCB21HK-102X C CAPACITOR 1000pF 50V K B,C,D,E
C4001 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C4002 QERF1HM-105Z E CAPACITOR 1uF 50V M
C4004 QERF1AM-336Z E CAPACITOR 33uF 10V M
Ω
C4006 NRSA02J-0R0X MG RESISTOR 0
1/10W J
C4007 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C4009 NCB21HK-102X C CAPACITOR 1000pF 50V K
C4010 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C4011 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C4013 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C4014 NDC21HJ-101X C CAPACITOR 100pF 50V J
C4019 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C4031 QETF1CM-336Z E CAPACITOR 33uF 16V M
C5001 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K
C5004 QCZ9071-222 C CAPACITOR 2200pF AC400 V M
C5006 QEZ0375-686 E CAPACITOR 68uF 400V M
C5101 QCZ0212-472 C CAPACIT O R 4700pF 1kV K
C5102 QCZ0339-101Z C CAPACITOR 100pF 1kV K
C5104 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C5105 QFN31HJ-183Z M CAPACITOR 0.018uF 50V J
B,C,D,E
3-6(No.82992)
Symbol No.
Part No. Part Name Description Local
Symbol No.
MODEL MARK
HR-P201ER
HR-V205ER
HR-V206ER
HR-V405ER
MODEL MARK
HR-V406ER E
A
B
C
D
Part No. Part Name Description Local
C5106 QCBB1HJ-271Y C CAPACITOR 270pF 50V J
C5107 QFV91HJ-104Z MF CAP ACITOR 0.1uF 50V J
C5202 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C5203 QEMT1AM-128 E CAPACITOR 1200uF 10V M
C5204 QETJ2AM-475Z E CAPACITOR 4.7uF 100V M
C5206 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C5207 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C5301 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C5303 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C5305 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C5307 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C5308 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C6006 NCB21HK-103X C CAPACITOR 0.01uF 50V K B,C,D,E
C6008 NCB21HK-103X C CAPACITOR 0.01uF 50V K B,C,D,E
C6013 NCB21HK-153X C CAPACITOR 0.015uF 50V K A
C6013 NCB21HK-103X C CAPACITOR 0.01uF 50V K B,C,D,E
C6014 NCB21HK-103X C CAPACITOR 0.01uF 50V K B,C,D,E
C6016 NCB21HK-103X C CAPACITOR 0.01uF 50V K B,C,D,E
C6032 NCB21EK-473X C CAPAC ITOR 0.047uF 25V K B,C,D,E
C6037 QEKJ1HM-106Z E CAPACITOR 10uF 50V M B,C,D,E
C7011 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C7114 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C7119 NCB21HK-681X C CAPACITOR 680pF 50V K
C7128 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C7133 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C7164 NCB21HK-681X C CAPACITOR 680pF 50V K D,E
C7197 NCB21HK-103X C CAPACITOR 0.01uF 50V K
R1 NRSA02J-622X MG RESISTOR 6.2kΩ 1/10W J
R2 NRSA02J-152X MG RESISTOR 1.5kΩ 1/10W J
R3 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R11 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R12 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R21 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J D,E
R22 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J D,E
R36 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R37 NRSA02J-153X MG RESISTOR 15kΩ 1/10W J
R201 NRSA02J-332X MG RESISTOR 3.3kΩ 1/10W J
R202 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R203 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R204 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R210 NRSA02J-332X MG RESISTOR 3.3kΩ 1/10W J
R211 NR SA02J-0R0X MG RESISTOR 0Ω 1/10W J
R2001 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R2003 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J A
R2003 NRSA02J-681X MG RESISTOR 680Ω 1/10W J B,C,D,E
R2004 NRSA02J-392X MG RESISTOR 3.9kΩ 1/10W J A
R2004 NRSA02J-272X MG RESISTOR 2.7kΩ 1/10W J B,C,D,E
R2005 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
Ω
R2006 QRE141J-473Y C RESISTOR 47k
1/4W J D,E
R2008 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R2009 NRSA02J-562X MG RESISTOR 5.6k
R2011 QRE141J-473Y C RESISTOR 47k
Ω
1/10W J D,E
Ω
1/4W J
R2012 NRSA02J-562X MG RESISTOR 5.6kΩ 1/10W J
R2013 NRSA02J-123X MG RESISTOR 12k
R2014 NRSA02J-394X MG RESISTOR 390k
Ω
1/10W J
Ω
1/10W J
R2015 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R2016 NRSA02J-333X MG RESISTOR 33k
Ω
1/10W J
R2017 NRSA02J-183X MG RESISTOR 18kΩ 1/10W J
Ω
R2018 NRSA02J-472X MG RESISTOR 4.7k
R2019 NRSA02J-472X MG RESISTOR 4.7k
1/10W J
Ω
1/10W J
R2021 NRSA02J-333X MG RESISTOR 33kΩ 1/10W J
Ω
R2022 NRSA02J-103X MG RESISTOR 10k
R2023 NRSA02J-103X MG RESISTOR 10k
1/10W J
Ω
1/10W J
R2053 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
Ω
R2054 NRSA02J-123X MG RESISTOR 12k
R2055 NRSA02J-3R3X MG RESISTOR 3.3
R2056 QRE141J-820Y C RESISTOR 82
R2057 NRSA02J-473X MG RESISTOR 47k
1/10W J
Ω
1/10W J
Ω
1/4W J
Ω
1/10W J
R2058 NRSA02J-183X MG RESISTOR 18kΩ 1/10W J
Ω
R2059 NRSA02J-473X MG RESISTOR 47k
R2060 NRSA02J-183X MG RESISTOR 18k
1/10W J
Ω
1/10W J
R3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
Ω
R3016 NRSA02J-0R0X MG RESISTOR 0
R3017 NRSA02J-471X MG RESISTOR 470
1/10W J
Ω
1/10W J
R3018 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
Ω
R3021 NRSA02J-102X MG RESISTOR 1k
R3025 NRSA02J-0R0X MG RESISTOR 0
1/10W J
Ω
1/10W J
R3031 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R3032 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R3035 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R3042 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J B,C,D,E
R3057 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
Ω
R3066 NRSA02J-0R0X MG RESISTOR 0
R3084 NRSA02J-0R0X MG RESISTOR 0
1/10W J D,E
Ω
1/10W J
R3088 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R3091 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3092 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3093 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3094 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3205 QRE141J-181Y C RESISTOR 180Ω 1/4W J
R3207 NRSA02J-183X MG RESISTOR 18kΩ 1/10W J
R3208 NRSA02J-121X MG RESISTOR 120Ω 1/10W J
R3209 NRSA02J-183X MG RESISTOR 18kΩ 1/10W J
R3210 NRSA02J-121X MG RESISTOR 120Ω 1/10W J
R3211 NRSA02J-183X MG RESISTOR 18kΩ 1/10W J
R3212 NRSA02J-474X MG RESISTOR 470kΩ 1/10W J
R3213 NRSA02J-334X MG RESISTOR 330kΩ 1/10W J
Ω
R3214 NRSA02J-103X MG RESISTOR 10k
R3215 NRSA02J-103X MG RESISTOR 10k
1/10W J
Ω
1/10W J
R3216 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3217 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3218 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J B,C,D,E
R3219 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J B,C,D,E
R3220 NRSA02J-104X MG RESISTOR 100kΩ 1/10W J B,C,D,E
R3223 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3224 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3225 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3229 NRSA02J-105X MG RESISTOR 1MΩ 1/10W J
R3230 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R3232 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J A
R3235 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3236 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3237 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3244 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3245 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3246 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R3247 NRSA02J-681X MG RESISTOR 680Ω 1/10W J A
R3248 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R3249 NRSA02J-331X MG RESISTOR 330Ω 1/10W J A
R3250 NRSA02J-682X MG RESISTOR 6.8kΩ 1/10W J A
R3253 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R4001 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R4002 NRSA02J-562X MG RESISTOR 5.6kΩ 1/10W J
R4003 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R4010 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R4011 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
Ω
R4012 NRSA02J-153X MG RESISTOR 15k
1/10W J
R4018 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R4019 NRSA02J-102X MG RESISTOR 1k
R5101 QRE141J-224Y C RESISTOR 220k
Ω
1/10W J
Ω
1/4W J
R5102 QRE141J-224Y C RESISTOR 220kΩ 1/4W J
R5103 QRE141J-683Y C RESISTOR 68k
R5104 QRG02GJ-683 OMF RESISTOR 68k
Ω
1/4W J
Ω
2W J
R5106 QRT01DJ-R39X MF RESISTOR 0.39Ω 1W J
R5107 QRE121J-331Y C RESISTOR 330
Ω
1/2W J
R5108 NRSA02J-152X MG RESISTOR 1.5kΩ 1/10W J
Ω
R5109 QRE141J-561Y C RESISTOR 560
R5110 NRSA02J-224X MG RESISTOR 220k
1/4W J
Ω
1/10W J
R5111 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
Ω
R5112 NRSA02J-221X MG RESISTOR 220
R5302 NRSA02J-102X MG RESISTOR 1k
1/10W J
Ω
1/10W J
R5303 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
Ω
R5304 QRE141J-471Y C RESISTOR 470
R5306 NRSA02J-181X MG RESISTOR 180
R5310 NRSA02J-103X MG RESISTOR 10k
R5312 NRSA02J-102X MG RESISTOR 1k
1/4W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
R5313 NRSA02J-821X MG RESISTOR 820Ω 1/10W J
Ω
R5319 NRSA02J-221X MG RESISTOR 220
R5332 QRE121J-391Y C RESISTOR 390
1/10W J
Ω
1/2W J
R6020 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J B,C,D,E
Ω
R6021 NRSA02J-102X MG RESISTOR 1k
R6030 NRSA02J-102X MG RESISTOR 1k
1/10W J B,C,D,E
Ω
1/10W J B,C,D,E
R6031 NRSA02J-271X MG RESISTOR 270Ω 1/10W J B,C,D,E
Ω
R6032 NRSA02J-472X MG RESISTOR 4.7k
R6033 NRSA02J-182X MG RESISTOR 1.8k
1/10W J B,C,D,E
Ω
1/10W J B,C,D,E
(No.82992)3-7
Symbol No.
Part No. Part Name Description Local
Symbol No.
MODEL MARK
HR-P201ER
HR-V205ER
HR-V206ER
HR-V405ER
Part No. Part Name Description Local
MODEL MARK
HR-V406ER E
A
B
C
D
R6050 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J A
R6050 NRSA02J-101X MG RESISTOR 100Ω 1/10W J B,C,D,E
R6051 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R6052 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R6056 NRSA02J-331X MG RESISTOR 330Ω 1/10W J A
R6056 NRSA02J-101X MG RESISTOR 100
R7002 NRSA02J-331X MG RESISTOR 330
R7003 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R7004 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R7005 NRSA02J-331X MG RESISTOR 330Ω 1/10W J B,C,D,E
R7006 NRSA02J-331X MG RESISTOR 330Ω 1/10W J B,C,D,E
R7007 NRSA02J-331X MG RESISTOR 330Ω 1/10W J B,C,D,E
R7008 NRSA02J-331X MG RESISTOR 330Ω 1/10W J B,C,D,E
R7015 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R7020 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R7021 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R7022 NRSA02J-182X MG RESISTOR 1.8kΩ 1/10W J
R7023 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R7024 NRSA02J-272X MG RESISTOR 2.7kΩ 1/10W J
R7025 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R7026 NRSA02J-682X MG RESISTOR 6.8k
R7030 NRSA02J-103X MG RESISTOR 10k
R7031 NRSA02J-122X MG RESISTOR 1.2kΩ 1/10W J
R7032 NRSA02J-182X MG RESISTOR 1.8kΩ 1/10W J
R7033 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R7121 NRSA02J-750X MG RESISTOR 75Ω 1/10W J
R7122 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R7131 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R7132 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R7133 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R7134 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R7151 NRSA02J-750X MG RESISTOR 75Ω 1/10W J
R7152 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R7160 NRSA02J-331X MG RESISTOR 330Ω 1/10W J D,E
R7163 NRSA02J-750X MG RESISTOR 75Ω 1/10W J D,E
L3 QQL29BJ-100Z P COIL 10uH J
L5 QQL29BJ-100Z P COIL 10uH J
L6 QQL29BJ-100Z P COIL 10uH J
L10 QQL29BJ-100Z P COIL 10uH J
L15 QQL01BJ-120Z P COIL 12uH J
L201 QQL29BJ-100Z P COIL 10uH J
L203 QQL231J-4R7Y COIL 4.7uH J
L4001 QQL231J-1R0Y INDUCTOR 1uH J
L5201 PELN1184 CHOKE COIL
L5202 PELN1184 CHOKE COIL
L6001 QQL29BK-1R0Z P COIL 1uH K B,C,D,E
L6002 QQL29BK-1R0Z P COIL 1uH K B,C,D,E
L7107 QQL29BJ-100Z P COIL 10uH J
T2051 PELN0832 OSC TRANS
T5001 QQS0186-001 SW TRANSF
B1 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
B4 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
B7 NRSA02J-0R0X MG RESISTOR 0
B201 NRSA02J-0R0X MG RESISTOR 0
B2001 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
B2004 NRSA02J-0R0X MG RESISTOR 0
B3001 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J A
B6051 NRSA02J-0R0X MG RESISTOR 0
B6052 NRSA02J-0R0X MG RESISTOR 0
B6053 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J B,C,D,E
B6054 NRSA02J-0R0X MG RESISTOR 0
B7002 NRSA02J-0R0X MG RESISTOR 0
B7102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
B7108 NRSA02J-0R0X MG RESISTOR 0
B7110 NRSA02J-0R0X MG RESISTOR 0
B7112 NRSA02J-0R0X MG RESISTOR 0
B7113 NRSA02J-0R0X MG RESISTOR 0
B7114 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
CN1 QGF1201C2-06 CONNECTOR FFC/FPC (1-6)
CN2001 QGF1207C1-06 CONNECTOR FFC/FPC (1-6)
CN2002 QGB2532J1-02 CONNECTOR B-B (1-2)
CN3001 QGB2032M4-12 CONNECTOR B-B (1-12)
CN5001 QGA7901C3-02 CONNECTOR W-B (1-2)
CN7004 QGB2530J1-03 CONNECTOR B-B (1-3) A
CN7005 QGB2530K1-03 CONNECTOR B-B (1-3) A
CP3002 NMFZ012-1R0X-M FUSE 1A
Ω
1/10W J B,C,D,E
Ω
1/10W J B,C,D,E
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J B,C,D,E
Ω
1/10W J A
Ω
1/10W J A
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
CP4002 NMFZ012-1R0X-M FUSE 1A
DI7001 LTG-Y2K16M-02J LED B,C,D,E
F5001 QMF51E2-2R0-J1 FUSE 2A AC250V
FC5001 QNG0006-001Z FUSE CLIP
FC5002 QNG0006-001Z FUSE CLIP
HD1 LP31260-001A LED HOLDER A
HS1 LP40090-001A HEAT SINK FOR Q5101
J7103 QNN0292-002 PIN JACK REAR A/V OUT
J7104 QNN0292-002 PIN JACK REAR A/V IN
J7105 QNN0382-002 PIN JACK FRONT A/V IN D,E
JS3001 QSW0954-002 ROTARY ENCODER
K5101 QQR0678-001Z FERRITE BEADS
LF5002 QQR0978-001 LINE FILTER
OT1 LP30859-001A EARTH PLATE A
OT2 PQ21623-2-5 EARTH PLATE(RF) B,C,D,E
OT3 QYSDST3006M TAP SCREW
OT4 QYTDST3006Z TAP SCREW 3mm x 6 m m ,Q 5 1 0 1
S3001 QSW0602-004 PUSH SWITCH REC SAFETY SW
S7002 QSW0456-002Z TACT SWITCH POWER
S7003 QSW0456-002Z TACT SWITCH PRS7006 QSW0456-002Z TACT SWITCH REW
S7008 QSW0456-002Z TACT SWITCH FWD
S7010 QSW0456-002Z TACT SWITCH REC
S7011 QSW0456-002Z TACT SWITCH STOP/EJECT
S7013 QSW0456-002Z TACT SWITCH PLAY
S7017 QSW0456-002Z TACT SWITCH PR+
SD1 LP21105-002A SHIELD CASE
TB1 PQ21977-21 TERMINAL BOARD A
TB1 PQ21977-17-3 TERMINAL BOARD B,C,D,E
TU6001 QAU0330-001 RF CONVERTER A
TU6001 QAU0261-002 TUNER B,C,D,E
W1 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W2 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W3 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W6 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W7 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W9 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W11 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W13 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W15 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W17 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W18 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W19 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W20 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W22 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W26 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J D,E
W27 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W28 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
W815 QRE141J-101Y C RESISTOR 100Ω 1/4W J
W877 QRE141J-101Y C RESISTOR 100
X1 QAX0740-001 CRYSTAL 4.433619MHz
X2 QAX0739-001 CRYSTAL 3.57MHz
X3001 QAX0728-001 CRYSTAL 14.318180MHz
X3002 QAX0444-001 CRYSTAL 32.768kHz B,C,D,E
M3 x 6mm,T .BOARD
Ω
1/4W J D,E
A/C HEAD BOARD ASSEMBLY <12>
Symbol No.
PW1 LPA10158-01A1 A/C HEAD BOARD ASSY
Part No. Part Name Description Local
LOADING MOTOR BOARD ASSEMBLY <55>
Symbol No.
PW1 LPA10158-01A2 LOADING MOTOR BOARD ASSY
Part No. Part Name Description Local
A
3-8(No.82992)
Loading...
