SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSORY ASSEMBLY <M1> The instruction manual to be provided with this product will differ according to the destination.

307

306

306A

ADHESIVE TAPE

308

312

(HR-J695MS/J795MS)

SPEC OF BARCODE

317 310

311

313 (HR-J695EK /J795EK)

302

FUNAL ASSY <M2>

301

SPEC OF BARCODE

311

303

(HR-J695EK/J795EK)

SPEC OF BARCODE

317 310 319

(HR-J690EU/J790EU)

SPEC OF BARCODE

316 310

315 (HR-J695MS/J795MS)

302

MODEL MARK MODEL MARK HR-J690EU A HR-J790EU D HR-J695EK B HR-J795EK E HR-J695MS C HR-J795MS F

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

P ACKING AND ACCESSOR Y ASSEMBLY <M1>

301 LP30855-003A PACKING CASE 302 LP30909-001C CUSHION ASSY 303 PQM30021-93 POLY BAG 306 LP20878-014A REMOTE CONTROLLER 306A LP40610-003A COVER(BATTERY) 307 – BATTERY,X2(“R6”TYPE) 308 QPC02202230P POLY BAG

310 LPT0627-001B INST.BOOK(EN),D

! ! ! ! ! ! ! ! ! ! ! ! ! !

LPT0627-002B INST.BOOK(GE),D LPT0627-003A INST.BOOK(FR),D LPT0627-004A INST.BOOK(DU),D LPT0627-005A INST.BOOK(SP),D LPT0627-006A INST.BOOK(IT),D LPT0627-007A INST.BOOK(DA),D LPT0627-008A INST.BOOK(FI),D LPT0627-009A INST.BOOK(SW),D LPT0627-010A INST.BOOK(NO),D LPT0627-011A INST.BOOK(PT),D LPT0627-012A INST.BOOK(GR),D LPT0627-013A INST.BOOK(CZ),D LPT0627-014A INST.BOOK(PO),D LPT0627-015A INST.BOOK(HU),D

! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !

311 QPC02503530P POLY BAG 312 PEAC0300-02 RF CABLE

LPT0628-001A INST.BOOK(EN),A LPT0628-002A INST.BOOK(GE),A LPT0628-003A INST.BOOK(FR),A LPT0628-004A INST.BOOK(DU),A LPT0628-005A INST.BOOK(SP),A LPT0628-006A INST.BOOK(IT),A LPT0628-007A INST.BOOK(DA),A LPT0628-008A INST.BOOK(FI),A LPT0628-009A INST.BOOK(SW),A LPT0628-010A INST.BOOK(NO),A LPT0628-011A INST.BOOK(PT),A LPT0628-012A INST.BOOK(GR),A LPT0628-013A INST.BOOK(CZ),A LPT0628-014A INST.BOOK(PO),A LPT0628-015A INST.BOOK(HU),A LPT0629-001A INST.BOOK(EN),E LPT0630-001A INST.BOOK(EN),B LPT0631-001B INST.BOOK(FR),F LPT0632-001A INST.BOOK(FR),C

313 QAL0095-005 LED CABLE ASSY,B,E 315 QAM0238-003 PERI CABLE,C,F 316 BT-54013-2 WARRANTY CARD,A,D 317 BT-54008-2 GUARANTY CARD,B,C,E,F 319 LYT0194-001B Q.CARD(JUK),B,E

5-1

5.2 FINAL ASSEMBLY <M2>

BEWARE OF BOGUS PARTS Parts that do not meet specifications may

cause trouble in regard to safety and performance. We recommend that genuine JVC parts be used.

516

515

503

502

505

515

503

501

501A

MAIN BOARD ASSY<03>

532

501B

533

510

533

511

516

510

517

Insert the bushing of POWER CORD

533

so as not to twist the cord.

523

JS3001

For the prevention of the DRUM FPC damage. When you attach the MECHA UNIT on B. CHASSIS. Attach the MECHA UNIT after the positioning boss "z" of the B. CHASSIS is matched to the positioning hole of the MECHA UNIT.

MECHANISM ASSY<M4>

REAR SIDE

<Phase alignment> Accord the position of V gap on R. Encoder and PWB silk " ". Accord the position of Boss on R. Encoder and PWB silk " ".

504

"Z"

To main CN7001

BACK SIDE

CN7003

WR4

ADV. JOG BOARD ASSY<38>

Front panel back side

R.PAUSE BOARD ASSY<91> [HR-J790EU/J795MS]

5-2

529 [HR-J790EU/J795EK/J795MS]

SAT CTL BOARD ASSY<94>

CN501

CN7102

CN7105

DRUM

512

From CAPSTAN MDA Right side

Right side

A/C HEAD

530

HR-J790EU/J795EK/J795MS

NOTE

1. Insert direction of FCC WIRE as follows.

CN2001

CN5001

electrode side

Right side Back side

supporting side

2. FFC WIRE and DRUM FPC WIRE should be insert as follows.

CN CN CN

3. Insert direction of POWER CORD.

CN7001

For JOG

from FRONT PANEL

Right side

U/U(C)/JPN

WHITE LINE

NEUTRAL

CN5001

Except U/U(C)/JPN

BLUE

NEUTRAL

CN5001

HR-J790EU/J795EK/J795MS

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

FINAL ASSEMBLY <M2>

501 LP10427-006H FRONT PANEL ASSY,D

LP10427-007G FRONT PANEL ASSY,E LP10427-008F FRONT PANEL ASSY,F LP10434-001E FRONT PANEL ASSY,A LP10434-004E FRONT PANEL ASSY,B

LP10434-006E FRONT PANEL ASSY,C 501A LP20961-022B CASSETTE DOOR 501B PQ46448 TORSION SPRING

502 LP10013-051B TOP COVER 503 QYTDSF3010R SCREW,X4,TOP COVER(SIDE) 504 QYTDSF3010M SCREW,TOP COVER(REAR) 505 PDV2539A DRUM ASSY,A,B,D,E

PDV2541A DRUM ASSY,C,F 510 QYSPSPD3008Z SCREW,X3,DRUM

511 LP10108-001H BOTTOM CHASSIS

512 LP10014-002C BOTTOM COVER 515 QYTDSF4012Z SCREW ,X2,MECHA 516 QYSPSFG3010Z SCREW,X2,MECHA

517 QMP4A10-170 POWER CORD,A,C,D,F

523 QYTDSF3010M SCREW,T.BOARD 529 LP31019-005D KNOB ASSY ,D,E,F 530 QYTPSFG2608Z SCREW,X2,ADV .JOG,D,E,F 532 QYTDSF3010Z SCREW ,MAIN 533 DPSF3010Z SCREW,X3,MAIN WR4 QUQ212-0414CG FFC WIRE,ADV.JOG CN7003,D,E,F

QMP51K0-170-K POWER CORD,B,E

5-3

5.3 MECHANISM ASSEMBL Y <M4>

112

124

127

128

138

126

110

118

122

130

121

107

105

131

137

138

151

123

125

126

119

120

111

115

105

107

117

113

112

116

114

A/C HEAD BOARD ASSY <12>

WR2

134

Classification drawing

Part No.

102

Symbol in

Grease KYODO-SH-JB AA Oil COSMO-HV56 BB

18B

18A

LOADING MOTOR BOARD ASSY <55>

23B

23A

62 59

WR3

WR1

NOTE:The section marked in AA and BB

indicate lubrication and greasing areas.

5-4

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

83 LP30003-035B TENSION SPRING

******************************

MECHANISM ASSEMBL Y <M4>

1 LP21039-001N MAIN DECK ASSY 3 LP40097-002D GUIDE POLE CAP 4 QAH0082-001 FULL ERASE HEAD 15 LP30958-001B LOAD.GEAR BASE 16 QYTPST2620Z SCREW,X2 18 LP40798-001A LOAD.GEAR(SUPPLY) ASSY 18A LP21040-001A LOAD.GEAR(SUPPLY) 18B LP40799-001A LOAD.ARM(SUPPLY) ASSY 19 LP40837-001A TORSION SPRING(SUPPLY) 20 LP40903-001A FIXING PLATE 21 LP40806-001D POLE BASE ASSY(SUPPLY) 22 LP30959-002A LOAD GEAR 23 LP40802-001B LOAD.GEAR(TAKE UP)ASSY 23A LP21041-001B LOAD.GEAR(TAKE UP) 23B LP40803-001A LOAD.ARM(TAKE UP) ASSY 24 LP40838-001A TORSION SPRING(TAKE UP) 26 LP40808-001F POLE BASE ASSY(TAKE UP) 36 LP21055-001E TU LEVER 37 LP40943-001A TENSION SPRING 38 LP40859-001D T-UP HEAD 39 LP30961-001C LID GUIDE 40 LP30002-0B7A SPACER 42 LP40810-001A PINCH ROLLER ARM ASSY 44 LP40840-001C TORSION SPRING 46 LP30963-001B PRESS LEVER 47 PQM30017-24 SLIT WASHER 49 LP40813-001D GUIDE ARM ASSY 50 LP40841-001A TORSION SPRING 51 LP30002-090A SPACER 52 QAH0081-001 AC HEAD 53 LP30965-001A HEAD BASE 55 LP40842-001A COMPRESSION SPRING 57 QYTSST2010Z SCREW,X3 58 QYTDST2606Z SCREW,X2 59 QAR0023-001 LOADING MOTOR 60 QYTPSP3003Z SCREW,X2 61 LP21056-002F MOTOR BRACKET 62 QYTPST2620Z SCREW 63 LP40814-001B WORM BEARING 64 LP21044-001D CONTROL CAM 65 PQM30017-24 SLIT WASHER 66 LP40815-001A WORM GEAR 67 LP40816-001B HELICAL GEAR 68 LP40817-001A CONNECT GEAR 69 LP10400-001H CONTROL PLATE 70 LP40843-001A TORSION SPRING 71 LP40818-001B TENSION ARM ASSY 72 LP40844-001C TENSION SPRING 73 LP21045-001D TENSION ARM BASE 74 LP40821-001A TENSION BAND ASSY 75 LP30967-001B BAND HOLDER-1 76 LP30968-001C BAND HOLDER-2 77 LP40822-002B ADJUST PIN 78 LP31000-005E TENSION ARM LEVER 79 LP21046-001C MAIN BRAKE(TAKE UP) 80 LP40824-001A BAND BRAKE ASSY 81 LP30969-002A BRAKE LEVER 82 LP30003-033B TENSION SPRING

84 LP40825-001B CAPSTAN BRAKE ASSY

!85 QAR0204-002 CAPSTAN MOTOR

86 QYTDSF2606M SCREW,X3 87 LP30005-010A BELT,CAPSTAN MOTOR 88 LP30970-001A IDLER ARM 89 LP40828-004A IDLER GEAR 1,X2 90 LP40829-001B IDLER GEAR 2,X2 91 LP31014-001A WIRE HOLDER 93 LP40934-001B CLUTCH UNIT 94 PQM30017-47 SLIT WASHER 95 LP30973-001A DIRECT GEAR 96 LP40939-001A COMP. SPRING 102 LP30974-001B CHANGE LEVER 105 LP21049-001A REEL DISK,X2 107 LP30017-004A SPACER,X2 110 LP10401-001F SIDE FRAME(L) 111 LP10402-001F SIDE FRAME(R) 112 QYTDST2606Z SCREW,X2 113 LP40917-001C TORSION SPRING 114 LP30976-001D SIDE PLATE 115 LP30977-002D LIMIT PLATE 116 LP40846-001C LIMIT SPRING 117 LP31100-001B DRIVE LEVER 118 LP30978-001B DRIVE ARM(L) 119 LP30979-001H DRIVE ARM(R) 120 LP40847-001B TORSION SPRING 121 LP30980-001A CONNECT PLATE 122 LP10403-001C SIDE HOLDER(L) 123 LP10404-001D SIDE HOLDER(R) 124 LP30983-001A LOCK LEVER(L) 125 LP30984-001A LOCK LEVER(R) 126 LP40924-001C TENSION SPRING,X2 127 LP40856-001B EARTH SPRING(1) 128 LP40857-001B EARTH SPRING(2) 130 LP30981-001E CASSETTE HOLDER ASSY 131 LP31135-001A C.H STOPPER 134 LP21051-002C REC SAFETY LEVER 137 LP21052-001F TOP FRAME 138 LP30002-0A7A SPACER,X2 151 LP30985-001G DOOR OPENER WR1 WJT0059-001C E-CARD WIRE,DRUM WR2 WJT0067-001B E-CARD WIRE,AC HEAD CN2001 WR3 WJS0022-001A E-FL/RB WIRE,ROADING MOTOR

5-5

MODEL MARK MODEL MARK

5.4 ELECTRICAL PARTS LIST

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

MAIN BOARD ASSEMBLY <03>

PW1 LPA10160-01D1 MAIN BOARD ASSY,D

LPA10160-02D1 MAIN BOARD ASSY,A LPA10160-03D1 MAIN BOARD ASSY,E LPA10160-04D1 MAIN BOARD ASSY,B LPA10160-05D1 MAIN BOARD ASSY,F

LPA10160-06D1 MAIN BOARD ASSY,C IC1 JCP8051-MVA IC IC251 LC74793 IC IC301 LA7358 IC,C,F IC2201 AN3651FBP IC IC3001 HD6432199RA43F IC,A,D

HD6432199RA45F IC,B,E

HD6432199RA47F IC,C,F

or HD64F2199RFA43 IC,A,D or HD64F2199RFA45 IC,B,E

or HD64F2199RFA47 IC,C,F IC3002 IC-PST3427U-X IC IC3003 LPN0711-006A-02 IC(EEPROM),D

LPN0719-003A-02 IC(EEPROM),E LPN0725-005A-01 IC(EEPROM),A LPN0727-003A-04 IC(EEPROM),F LPN0739-003A-01 IC(EEPROM),B LPN0740-003A-03 IC(EEPROM),C

IC6701 MSP3417D IC

or MSP3417DG3 IC

or MSP3417G IC IC7002 GP1U291Q IR DETECT UNIT

or PNA4652M00YC IR DETECT UNIT IC7102 MM1508XN IC,A,C,D,F IC7103 MM1508XN IC,A,C,D,F Q1 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q2 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q3 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q4 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q21 2SA1576A/QR/-X TRANSISTOR,C,F

or 2PA1576/R/-X TRANSISTOR,C,F

or 2SB1218A/QR/-X TRANSISTOR,C,F Q23 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q24 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q34 2SA1576A/QR/-X TRANSISTOR,C,F

or 2SB1218A/QR/-X TRANSISTOR,C,F

or 2PA1576/R/-X TRANSISTOR,C,F Q38 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR Q41 DTC144WU DIGI TRANSISTOR,A,C,D,F

or PDTC144WU DIGI TRANSISTOR,A,C,D,F

or RN1309 DIGI TRANSISTOR,A,C,D,F

or UN521E DIGI TRANSISTOR,A,C,D,F

HR-J690EU A HR-J790EU D HR-J695EK B HR-J795EK E HR-J695MS C HR-J795MS F

Q301 2SB1218A/QR/-X TRANSISTOR,C,F

or 2PA1576/R/-X TRANSISTOR,C,F or 2SA1576A/QR/-X TRANSISTOR,C,F

Q302 UN511E DIGI TRANSISTOR,C,F

or RN2309 TRANSISTOR,C,F or DTA144WU DIGI TRANSISTOR,C,F or PDTA144WU DIGI TRANSISTOR,C,F

Q2001 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2002 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q2003 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR or RN2309 TRANSISTOR or UN511E DIGI TRANSISTOR

Q2051 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2052 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q2053 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or UN521E DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR

Q2054 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q2055 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q2061 2SC4081/QRS/-X TRANSISTOR,D,F

or 2SD1819A/QRS/-X TRANSISTOR,D,F or 2PC4081/R/-X TRANSISTOR,D,F

Q2062 2SA1576A/QR/-X TRANSISTOR,D,F

or 2SB1218A/QR/-X TRANSISTOR,D,F or 2PA1576/R/-X TRANSISTOR,D,F

Q2063 DTC144WU DIGI TRANSISTOR,D,F

or PDTC144WU DIGI TRANSISTOR,D,F or RN1309 DIGI TRANSISTOR,D,F or UN521E DIGI TRANSISTOR,D,F

Q2201 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR or RN2309 TRANSISTOR or UN511E DIGI TRANSISTOR

Q2202 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q2203 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q2204 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2255 DTC114EU DIGI TRANSISTOR,A,C,D,F

or PDTC114EU DIGI TRANSISTOR,A,C,D,F or UN5211 DIGI TRANSISTOR,A,C,D,F

5-6

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or RN1302 DIGI TRANSISTOR,A,C,D,F Q3003 PTZ-NV16A PHOTO TRANSISTOR Q3004 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q3005 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR Q3007 UN521E DIGI TRANSISTOR

or DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSIST OR Q4001 UN5211 DIGI TRANSISTOR

or RN1302 DIGI TRANSIST OR

or DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR Q5101 2SK2632-CB14 POWER MOS FET

or 2SK2632 POWER MOS FET

or 2SK2129 POWER MOS FET

or 2SK2129-LT POWER MOS FET Q5102 2SD2144S/UV/-T TRANSISTOR Q5301 2SC1740S/RS/-T TRANSISTOR

or 2SC3199/YG/-T TRANSISTOR

Q5304 2SD2144S/UV/-T TRANSISTOR Q5305 DTA114EU DIGI TRANSISTOR

or RN2302 TRANSIST OR

or UN5111 DIGI TRANSISTOR

or PDTA114EU DIGI TRANSISTOR Q5306 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or UN5211 DIGI TRANSIST OR

or RN1302 DIGI TRANSIST OR Q5307 2SD2144S/UV/-T TRANSISTOR

Q5321 2SD1858/QR/-T TRANSISTOR Q6030 2SB1218A/RS/-X TRANSISTOR Q6031 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or UN5211 DIGI TRANSIST OR

or RN1302 DIGI TRANSIST OR Q6032 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSIST OR

or UN5211 DIGI TRANSIST OR Q7001 DTA143TU DIGI TRANSISTOR Q7002 DTA143TU DIGI TRANSISTOR Q7003 DTA143TU DIGI TRANSISTOR Q7004 DTA143TU DIGI TRANSISTOR Q7005 DTA143TU DIGI TRANSISTOR Q7006 DTC143TU DIGI TRANSISTOR Q7007 DTC143TU DIGI TRANSISTOR Q7008 DTC143TU DIGI TRANSISTOR Q7009 DTC143TU DIGI TRANSISTOR Q7010 DTC143TU DIGI TRANSISTOR Q7011 DTC143TU DIGI TRANSISTOR Q7012 DTC143TU DIGI TRANSISTOR Q7101 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q7102 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSIST OR

! !

or UN521E DIGI TRANSISTOR

Q7103 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q7104 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q7106 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SA1576A/QR/-X TRANSISTOR

Q7107 DTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR Q7201 2SC1317/RS/-T TRANSISTOR D201 1SS133 DIODE

or 1SS270A DIODE D2251 1SS133 DIODE

or 1SS270A DIODE D3001 LNB2301L01VI LE DIODE D3002 1SS133 DIODE

or 1SS270A DIODE D3003 RD39ES/B3/-T2 ZENER DIODE

or MTZJ39C ZENER DIODE D3004 11ES2 DIODE

or 1A3G DIODE D3005 11ES2 DIODE

or 1A3G DIODE D3008 1SS133 DIODE

or 1SS270A DIODE D5001 S1WB/A/60-4102 BRIDGE DIODE

or S1WB(A)60F4072X BRIDGE DIODE

or S1WB/A/60-X BRIDGE DIODE D5101 AU01 DIODE

or ERA18-04-T2 FR DIODE

or 10ELS4 FR DIODE

or 1SR153-400-T2 FR DIODE D5102 AU01 DIODE

or 1SR153-400-T2 FR DIODE

or 10ELS4 FR DIODE

or ERA18-04-T2 FR DIODE D5103 1SS133 DIODE

or 1SS270A DIODE D5105 1SS133 DIODE

or 1SS270A DIODE D5203 AU01Z FR DIODE

or 10ELS2 FR DIODE D5204 AU01Z FR DIODE

or 10ELS2 FR DIODE D5207 AK04 SB DIODE

or SBO40 SB DIODE

or 11EQS04 SB DIODE

or 1S4 SB DIODE D5209 AK04 SB DIODE

or SBO40 SB DIODE

or 11EQS04 SB DIODE

or 1S4 SB DIODE D5210 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE

or PG104RS FR DIODE

or 10ELS2 FR DIODE

5-7

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or 1SR153-400-T2 FR DIODE

D5301 MTZJ15C ZENER DIODE

or RD15ES/B3/-T2 ZENER DIODE

D5302 MTZJ11C ZENER DIODE

or RD11ES/B3/-T2 ZENER DIODE

D5303 MTZJ5.6A ZENER DIODE

or RD5.6ES/B1/-T2 ZENER DIODE

D5305 MTZJ5.6C ZENER DIODE

or RD5.6ES/B3/-T2 ZENER DIODE

D6002 HZ30-2L-T2 ZENER DIODE

or HZ30-2LTD Z DIODE (M)

D6701 1SS133 DIODE

or 1SS270A DIODE R1 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2 QRE141J-152Y RESISTOR 1.5kØ,1/4W R3 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W R5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7 NRSA02J-471X MG RESISTOR 470Ø,1/10W R21 NRSA02J-102X MG RESISTOR 1kØ,1/10W R22 NRSA02J-102X MG RESISTOR 1kØ,1/10W R33 NRSA02J-222X MG RESISTOR,C,F 2.2kØ,1/10W R37 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W R46 NRSA02J-331X MG RESISTOR 330Ø,1/10W R47 NRSA02J-821X MG RESISTOR,C,F 820Ø,1/10W R48 NRSA02J-102X MG RESISTOR,C,F 1kØ,1/10W R50 QRE141J-471Y RESISTOR 470Ø,1/4W R51 NRSA02J-471X MG RESISTOR 470Ø,1/10W R65 NRSA02J-102X MG RESISTOR,C,F 1kØ,1/10W R72 NRSA02J-333X MG RESISTOR,C,F 33kØ,1/10W R73 NRSA02J-682X MG RESISTOR,C,F 6.8kØ,1/10W R76 NRSA02J-102X MG RESISTOR,C,F 1kØ,1/10W R77 NRSA02J-103X MG RESISTOR 10kØ,1/10W R81 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R82 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R88 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R90 NRSA02J-391X MG RESISTOR 390Ø,1/10W R92 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R93 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R94 NRSA02J-332X MG RESISTOR,C,F 3.3kØ,1/10W R104 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R118 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R201 NRSA02J-471X MG RESISTOR 470Ø,1/10W R202 NRSA02J-103X MG RESISTOR 10kØ,1/10W R203 NRSA02J-103X MG RESISTOR 10kØ,1/10W R204 NRSA02J-474X MG RESISTOR 470kØ,1/10W R205 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R206 NRSA02J-474X MG RESISTOR 470kØ,1/10W R208 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R209 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R210 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R251 NRSA02J-103X MG RESISTOR 10kØ,1/10W R252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R254 NRSA02J-103X MG RESISTOR 10kØ,1/10W R255 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R256 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R258 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R259 NRSA02J-103X MG RESISTOR 10kØ,1/10W R301 NRSA02J-273X MG RESISTOR,C,F 27kØ,1/10W R302 NRSA02J-124X MG RESISTOR,C,F 120kØ,1/10W R303 NRSA02J-273X MG RESISTOR,C,F 27kØ,1/10W

R304 NRSA02J-682X MG RESISTOR,C,F 6.8kØ,1/10W R305 NRSA02J-473X MG RESISTOR,C,F 47kØ,1/10W R306 NRSA02J-273X MG RESISTOR,C,F 27kØ,1/10W R307 NRSA02J-222X MG RESISTOR,C,F 2.2kØ,1/10W R308 NRSA02J-222X MG RESISTOR,C,F 2.2kØ,1/10W R309 NRSA02J-821X MG RESISTOR,C,F 820Ø,1/10W R310 NRSA02J-223X MG RESISTOR,C,F 22kØ,1/10W R311 NRSA02J-392X MG RESISTOR,C,F 3.9kØ,1/10W R312 NRSA02J-272X MG RESISTOR,C,F 2.7kØ,1/10W R313 NRSA02J-223X MG RESISTOR,C,F 22kØ,1/10W R314 NRVA02D-243X CMF RESISTOR,C,F 24kØ,1/10W R315 NRSA02J-564X MG RESISTOR,C,F 560kØ,1/10W R316 NRSA02J-224X MG RESISTOR,C,F 220kØ,1/10W R329 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W R2003 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2005 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2007 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2008 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2010 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2013 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2014 NRSA02J-224X MG RESISTOR 220kØ,1/10W R2015 NRSA02J-181X MG RESISTOR 180Ø,1/10W R2016 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2017 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2019 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2053 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R2054 NRSA02J-153X MG RESISTOR,D,F 15kØ,1/10W

NRSA02J-123X MG RESISTOR,A,B,C,E 12kØ,1/10W R2055 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W R2056 NRSA02J-820X MG RESISTOR,A,B,C,E 82Ø,1/10W

NRSA02J-101X MG RESISTOR,D,F 100Ø,1/10W R2057 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2058 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2059 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2060 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2061 NRSA02J-273X MG RESISTOR,D,F 27kØ,1/10W R2062 NRSA02J-3R3X MG RESISTOR,D,F 3.3Ø,1/10W R2063 QRE141J-151Y RESISTOR,D,F 150Ø,1/4W R2064 NRSA02J-473X MG RESISTOR,D,F 47kØ,1/10W R2065 NRSA02J-183X MG RESISTOR,D,F 18kØ,1/10W R2201 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2202 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2203 NRSA02J-473X MG RESISTOR,D,F 47kØ,1/10W R2204 NRSA02J-682X MG RESISTOR,D,F 6.8kØ,1/10W R2205 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2206 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2207 NRSA02J-473X MG RESISTOR,D,F 47kØ,1/10W R2208 NRSA02J-682X MG RESISTOR,D,F 6.8kØ,1/10W R2209 NRSA02J-681X MG RESISTOR 680Ø,1/10W R2210 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2211 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R2212 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R2213 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2214 NRSA02J-681X MG RESISTOR 680Ø,1/10W R2215 NRSA02J-181X MG RESISTOR 180Ø,1/10W R2216 NRSA02J-122X MG RESISTOR,A,B,D,E 1.2kØ,1/10W R2217 NRSA02J-472X MG RESISTOR,A,B,D,E 4.7kØ,1/10W R2218 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R2219 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R2220 NRSA02J-102X MG RESISTOR 1kØ,1/10W

5-8

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R2222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2223 NRSA02J-511X MG RESISTOR 510Ø,1/10W R2224 NRSA02J-511X MG RESISTOR 510Ø,1/10W R2225 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2226 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2227 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2228 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2229 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2230 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2231 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2232 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2233 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2234 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2235 NRSA02J-681X MG RESISTOR,A,C,D,F 680Ø,1/10W R2236 NRSA02J-272X MG RESISTOR,A,C,D,F 2.7kØ,1/10W R2237 NRSA02J-681X MG RESISTOR,A,C,D,F 680Ø,1/10W R2238 NRSA02J-272X MG RESISTOR,A,C,D,F 2.7kØ,1/10W R2251 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2252 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2253 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2255 NRSA02J-273X MG RESISTOR 27kØ,1/10W R3024 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3025 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3026 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3027 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R3028 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3030 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3031 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3032 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3033 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3034 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3035 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3037 QUY160-100Y IM BUS WIRE R3038 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3039 QUY160-100Y IM BUS WIRE R3040 NRSA02J-0R0X MG RESISTOR,D,E,F 0Ø,1/10W R3041 NRSA02J-0R0X MG RESISTOR,D,E,F 0Ø,1/10W R3042 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3043 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W R3045 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3046 QUY160-100Y IM BUS WIRE R3047 QUY160-100Y IM BUS WIRE R3048 QUY160-100Y IM BUS WIRE R3049 QUY160-100Y IM BUS WIRE R3050 QUY160-100Y IM BUS WIRE R3051 QUY160-100Y IM BUS WIRE R3052 QUY160-100Y IM BUS WIRE R3053 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3054 QRE141J-102Y RESISTOR 1kØ,1/4W R3055 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3058 QUY160-100Y IM BUS WIRE R3059 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3060 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3061 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3062 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3063 QRE141J-271Y RESISTOR 270Ø,1/4W R3064 QRE141J-271Y RESISTOR 270Ø,1/4W R3065 QRE141J-271Y RESISTOR 270Ø,1/4W R3066 QRE141J-271Y RESISTOR 270Ø,1/4W R3067 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3068 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

R3069 QUY160-100Y IM BUS WIRE R3070 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3071 QUY160-100Y IM BUS WIRE R3072 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3073 QUY153-050Y IM BUS WIRE R3074 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3077 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3080 NRSA02J-101X MG RESISTOR 100Ø,1/10W R3082 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3083 QRE141J-102Y RESISTOR,A,C,D,F 1kØ,1/4W R3084 QUY153-050Y IM BUS WIRE R3085 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3086 QUY160-100Y IM BUS WIRE R3087 NRSA02J-102X MG RESISTOR,A,C,D,F 1kØ,1/10W R3088 NRSA02J-0R0X MG RESISTOR,A,C,D,F 0Ø,1/10W R3089 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W R3090 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3091 QUY153-050Y IM BUS WIRE R3092 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3093 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3094 QUY160-100Y IM BUS WIRE R3095 QUY160-100Y IM BUS WIRE R3096 NRSA02J-0R0X MG RESISTOR,D,F 0Ø,1/10W R3097 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W R3098 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3099 NRSA02J-0R0X MG RESISTOR,D,F 0Ø,1/10W R3100 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3101 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3102 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3205 QRE141J-181Y RESISTOR 180Ø,1/4W R3207 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3208 NRSA02J-121X MG RESISTOR 120Ø,1/10W R3209 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3210 NRSA02J-121X MG RESISTOR 120Ø,1/10W R3211 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3212 NRSA02J-474X MG RESISTOR 470kØ,1/10W R3213 NRSA02J-334X MG RESISTOR 330kØ,1/10W R3214 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3215 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3216 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3217 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3218 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3219 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3220 NRSA02J-104X MG RESISTOR 100kØ,1/10W R3222 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3223 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3224 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3225 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3229 NRSA02J-105X MG RESISTOR 1MØ,1/10W R3232 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3234 QRE141J-103Y RESISTOR 10kØ,1/4W R3235 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3236 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3244 NRSA02J-333X MG RESISTOR,D,E,F 33kØ,1/10W R3245 NRSA02J-333X MG RESISTOR,D,E,F 33kØ,1/10W R3246 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3248 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3251 NRSA02J-103X MG RESISTOR,D,F 10kØ,1/10W R3252 NRSA02J-153X MG RESISTOR 15kØ,1/10W R3253 QRE141J-103Y RESISTOR 10kØ,1/4W R4003 NRSA02J-561X MG RESISTOR 560Ø,1/10W

5-9

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R4004 NRSA02J-561X MG RESISTOR 560Ø,1/10W R4005 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R4007 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4009 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4011 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R4012 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R4015 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R4017 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5101 QRE141J-224Y RESISTOR 220kØ,1/4W R5102 QRE141J-224Y RESISTOR 220kØ,1/4W R5103 QRE141J-683Y RESISTOR 68kØ,1/4W R5104 QRG02GJ-683 OMF RESISTOR 68kØ,2W R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W R5107 QRE121J-331Y RESISTOR 330Ø,1/2W R5108 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R5109 QRE141J-561Y RESISTOR 560Ø,1/4W R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W R5111 NRSA02J-391X MG RESISTOR 390Ø,1/10W R5112 NRSA02J-221X MG RESISTOR 220Ø,1/10W R5302 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5303 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R5304 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5306 NRSA02J-181X MG RESISTOR 180Ø,1/10W R5310 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5312 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5313 NRSA02J-821X MG RESISTOR 820Ø,1/10W R5319 NRSA02J-221X MG RESISTOR 220Ø,1/10W R5332 QRL02DJ-391X OMF RESISTOR 390Ø,2W R6020 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6021 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6030 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6031 NRSA02J-271X MG RESISTOR 270Ø,1/10W R6032 NRSA02J-183X MG RESISTOR,C,F 18kØ,1/10W

NRSA02J-472X MG RESISTOR,A,B,D,E 4.7kØ,1/10W

R6033 NRSA02J-182X MG RESISTOR,A,B,D,E 1.8kØ,1/10W

NRSA02J-183X MG RESISTOR,C,F 18kØ,1/10W R6050 NRSA02J-101X MG RESISTOR,A,B,D,E 100Ø,1/10W R6051 QRE141J-101Y RESISTOR,A,B,D,E 100Ø,1/4W R6052 NRSA02J-101X MG RESISTOR,A,B,D,E 100Ø,1/10W R6056 NRSA02J-101X MG RESISTOR,A,B,D,E 100Ø,1/10W R6080 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6707 NRSA02J-330X MG RESISTOR 33Ø,1/10W R6708 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6709 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6710 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6711 NRSA02J-474X MG RESISTOR 470kØ,1/10W R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6713 NRSA02J-123X MG RESISTOR 12kØ,1/10W R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6715 NRSA02J-123X MG RESISTOR 12kØ,1/10W R6716 NRSA02J-470X MG RESISTOR 47Ø,1/10W R6719 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6720 QRE141J-562Y RESISTOR 5.6kØ,1/4W R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R7001 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7002 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7003 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7004 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7005 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7006 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7007 NRSA02J-331X MG RESISTOR 330Ø,1/10W

R7015 QRE141J-102Y RESISTOR 1kØ,1/4W R7020 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7021 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R7022 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R7023 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R7024 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R7025 NRSA02J-472X MG RESISTOR,A,B,C 4.7kØ,1/10W R7030 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7031 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R7032 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R7033 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R7034 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R7101 NRSA02J-473X MG RESISTOR 47kØ,1/10W R7102 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7103 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7105 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7107 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7108 NRSA02J-750X MG RESISTOR,A,C,D,F 75Ø,1/10W R7110 NRSA02J-221X MG RESISTOR,A,C,D,F 220Ø,1/10W R7111 NRSA02J-221X MG RESISTOR,A,C,D,F 220Ø,1/10W R7112 QRE141J-331Y RESISTOR 330Ø,1/4W R7113 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7114 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7116 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7117 QRE141J-750Y RESISTOR 75Ø,1/4W R7119 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7120 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7122 NQL402M-4R7X COIL 4.7µH R7124 NQL402M-4R7X COIL 4.7µH R7131 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7132 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R7133 QRE121J-471Y RESISTOR,A,C,D,F 470Ø,1/2W

QRE121J-331Y RESISTOR,B,E 330Ø,1/2W

R7134 NRSA02J-471X MG RESISTOR,A,C,D,F 470Ø,1/10W

NRSA02J-0R0X MG RESISTOR,B,E 0Ø,1/10W R7142 NRSA02J-0R0X MG RESISTOR,A,C,D,F 0Ø,1/10W R7143 NRSA02J-0R0X MG RESISTOR,A,C,D,F 0Ø,1/10W R7144 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7145 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R7146 NRSA02J-393X MG RESISTOR 39kØ,1/10W R7147 NRSA02J-223X MG RESISTOR 22kØ,1/10W R7148 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7160 NRSA02J-331X MG RESISTOR,D,F 330Ø,1/10W R7161 NRSA02J-101X MG RESISTOR,D,F 100Ø,1/10W R7162 NRSA02J-331X MG RESISTOR,D,F 330Ø,1/10W R7163 NRSA02J-750X MG RESISTOR,D,F 75Ø,1/10W R7201 QRE123J-100X RESISTOR 10Ø,1/2W R7202 QRE141J-221Y RESISTOR 220Ø,1/4W R7203 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W VR2251 QUY153-050Y IM BUS WIRE B5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B28 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B35 QUY153-050Y IM BUS WIRE,C,F B38 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W B40 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W B50 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W B201 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B301 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W B2051 QUY153-050Y IM BUS WIRE,A,B,C B3003 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5001 QUY160-100Y IM BUS WIRE

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

B5002 QUY160-100Y IM BUS WIRE B6701 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7113 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7114 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7116 NRSA02J-0R0X MG RESISTOR,B,E 0Ø,1/10W C1 NCB21HK-103X CAPACITOR 0.01µF,50V C2 NCB21HK-103X CAPACITOR 0.01µF,50V C3 NCB21HK-103X CAPACITOR 0.01µF,50V C4 NCB21HK-103X CAPACITOR 0.01µF,50V C5 QEKC0JM-476 E CAPACITOR 47µF,6.3V C6 QDYB1CM-103Y CAPACITOR 0.01µF,16V C7 NCB21HK-102X CAPACITOR 0.001µF,50V C8 NCB21EK-104X CAPACITOR 0.1µF,25V C9 QEKJ1HM-105 E CAPACITOR 1µF,50V C10 NDC21HJ-151X CAPACITOR 150pF,50V C11 NCB21EK-104X CAPACITOR 0.1µF,25V C12 NDC21HJ-390X CAPACITOR,C,F 39pF,50V

NDC21HJ-470X CAPACITOR,A,B,C,E 47pF,50V C14 NCB21EK-104X CAPACITOR 0.1µF,25V C15 NCB21HK-103X CAPACITOR 0.01µF,50V C16 NCB21EK-104X CAPACITOR 0.1µF,25V C17 QEKJ1HM-335 E CAPACITOR 3.3µF,50V C18 QEKJ1HM-105 E CAPACITOR 1µF,50V C19 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C20 NCB21AK-105X CAPACITOR 1µF,10V C21 NCB21EK-104X CAPACITOR 0.1µF,25V C22 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C23 NCB21EK-104X CAPACITOR 0.1µF,25V C24 NCB21EK-104X CAPACITOR 0.1µF,25V C25 NDC21HJ-6R0X CAPACITOR 6pF,50V C27 NCB21EK-223X CAPACITOR 0.022µF,25V C28 QEKJ1HM-335 E CAPACITOR 3.3µF,50V C29 NCB21EK-333X CAPACITOR 0.033µF,25V C30 QEKJ1HM-474 E CAPACITOR 0.47µF,50V C31 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C32 NCB21EK-104X CAPACITOR 0.1µF,25V C33 QERF1CM-106 E CAPACITOR 10µF,16V C34 NCB21CK-224X CAPACITOR 0.22µF,16V C35 NCB21HK-103X CAPACITOR 0.01µF,50V C36 QERF1EM-475 E CAPACITOR 4.7µF,25V C37 QEKJ1HM-105 E CAPACITOR 1µF,50V C38 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C39 NCB21HK-103X CAPACITOR 0.01µF,50V C40 QEKJ1EM-106 E CAPACITOR 10µF,25V C41 NCB21EK-104X CAPACITOR 0.1µF,25V C51 QEKC1HM-105 E CAPACITOR,D,F 1µF,50V C52 QEKJ1HM-105 E CAPACITOR 1µF,50V C53 NRSA02J-0R0X MG RESISTOR,C,F 0Ø,1/10W C61 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C64 NDC21HJ-220X CAPACITOR 22pF,50V C65 QEKJ1HM-105 E CAPACITOR 1µF,50V C69 NCB21HK-103X CAPACITOR 0.01µF,50V C70 NCB21HK-103X CAPACITOR 0.01µF,50V C79 NDC21HJ-390X CAPACITOR,C,F 39pF,50V C81 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C84 NDC21HJ-7R0X CAPACITOR,C,F 7pF,50V C92 NDC21HJ-330X CAPACITOR,B,E 33pF,50V C94 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C95 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C106 NCB21HK-821X CAPACITOR 820pF,50V C108 NDC21HJ-680X CAPACITOR 68pF,50V

C109 NCB21CK-224X CAPACITOR 0.22µF,16V C110 NDC21HJ-820X CAPACITOR 82pF,50V C114 NDC21HJ-181X CAPACITOR,A,C,D,F 180pF,50V C126 NDC21HJ-680X CAPACITOR 68pF,50V C127 NDC21HJ-680X CAPACITOR,B,E 68pF,50V C128 NDC21HJ-680X CAPACITOR,B,E 68pF,50V C129 NCB21HK-103X CAPACITOR,A,B,D,E 0.01µF,50V C130 NCB21EK-104X CAPACITOR 0.1µF,25V C201 NDC21HJ-220X CAPACITOR 22pF,50V C202 QERF1EM-475 E CAPACITOR 4.7µF,25V C203 NCB21HK-102X CAPACITOR 0.001µF,50V C204 NCB21HK-681X CAPACITOR 680pF,50V C205 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C207 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C209 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C210 NCB21HK-103X CAPACITOR 0.01µF,50V C212 NCB21HK-103X CAPACITOR 0.01µF,50V C213 NCB21HK-103X CAPACITOR,A,B,D,E 0.01µF,50V

NDC21HJ-100X CAPACITOR,C,F 10pF,50V C251 NCB21HK-103X CAPACITOR 0.01µF,50V C252 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C253 NCB21EK-563X CAPACITOR 0.056µF,25V C254 QEKJ1HM-105 E CAPACITOR 1µF,50V C255 QEKJ0JM-227 E CAPACITOR 220µF,6.3V C256 NCB21CK-224X CAPACITOR 0.22µF,16V C257 QEKJ1HM-105 E CAPACITOR 1µF,50V C258 NCB21CK-224X CAPACITOR,A,B,D,E 0.22µF,16V C259 QEKJ0JM-227 E CAPACITOR 220µF,6.3V C301 NDC21HJ-151X CAPACITOR,C,F 150pF,50V C302 QEKJ1HM-225 E CAPACITOR,C,F 2.2µF,50V C303 NCB21HK-682X CAPACITOR,C,F 0.0068µF,50V C304 NCB21HK-682X CAPACITOR,C,F 0.0068µF,50V C305 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C307 NDC21HJ-151X CAPACITOR,C,F 150pF,50V C308 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C309 NCB21EK-104X CAPACITOR,C,F 0.1µF,25V C310 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C311 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C312 NCB21HK-102X CAPACITOR,C,F 0.001µF,50V C313 QERF1HM-474 E CAPACITOR,C,F 0.47µF,50V C314 NDC21HJ-471X CAPACITOR,C,F 470pF,50V C315 QERF1CM-106 E CAPACITOR,C,F 10µF,16V C316 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C317 NCB21HK-681X CAPACITOR,C,F 680pF,50V C318 NCB21EK-223X CAPACITOR,C,F 0.022µF,25V C319 QERF1HM-105 E CAPACITOR,C,F 1µF,50V C320 NCB21HK-103X CAPACITOR,C,F 0.01µF,50V C321 NDC21HG-301X CAPACITOR,C,F 300pF,50V C322 NCB21CK-474X CAPACITOR,C,F 0.47µF,16V C323 QEKJ0JM-476 E CAPACITOR,C,F 47µF,6.3V C2001 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2002 QEKJ1HM-105 E CAPACITOR 1µF,50V C2003 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C2005 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2006 NCB21HK-123X CAPACITOR 0.012µF,50V C2007 QEKJ1CM-226 E CAPACITOR 22µF,16V C2008 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2009 NCB21HK-102X CAPACITOR 0.001µF,50V C2010 NCB21HK-152X CAPACITOR 0.0015µF,50V C2011 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2012 QEKC1HM-475 E CAPACITOR 4.7µF,50V

5-11

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C2013 NDC21HJ-6R0X CAPACITOR 6pF,50V C2016 NDC21HJ-181X CAPACITOR 180pF,50V C2051 NCB21HK-331X CAPACITOR 330pF,50V C2052 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V C2053 NCB21HK-472X CAPACITOR,A,B,C,E 0.0047µF,50V

NCB21HK-332X CAPACITOR,D,F 0.0033µF,50V

C2054 NCB21EK-223X CAPACITOR,A,C 0.022µF,25V

NCB21HK-223X CAPACITOR,B,E 0.022µF,50V

NCB21HK-103X CAPACITOR,D,F 0.01µF,50V C2055 QEKJ1EM-106 E CAPACITOR 10µF,25V C2061 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V

QFLC1HJ-823Z F CAPACITOR 0.082µF,50V C2062 NCB21HK-332X CAPACITOR,D,F 0.0033µF,50V C2063 NCB21HK-103X CAPACITOR,D,F 0.01µF,50V C2064 QEKJ1EM-106 E CAPACITOR,D,F 10µF,25V C2201 QEKJ1EM-106 E CAPACITOR 10µF,25V C2202 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2203 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2204 QEKJ0JM-336 E CAPACITOR 33µF,6.3V C2205 QEKJ1EM-106 E CAPACITOR 10µF,25V C2206 QEKJ1EM-106 E CAPACITOR 10µF,25V C2207 NCB21HK-153X CAPACITOR 0.015µF,50V C2208 NCB21HK-153X CAPACITOR 0.015µF,50V C2209 QERF1CM-106 E CAPACITOR 10µF,16V C2210 QERF1CM-106 E CAPACITOR 10µF,16V C2211 QEKJ0JM-336 E CAPACITOR 33µF,6.3V C2212 QERF0JM-476 E CAPACITOR 47µF,6.3V C2213 NCB21EK-104X CAPACITOR 0.1µF,25V C2214 QEKJ1EM-106 E CAPACITOR 10µF,25V C2215 QEKJ1EM-106 E CAPACITOR 10µF,25V C2216 QEKJ1CM-476 E CAPACITOR 47µF,16V C2217 NCB21EK-104X CAPACITOR 0.1µF,25V C2218 QEKJ1EM-106 E CAPACITOR,A,B,C,E 10µF,25V C2219 QEKJ1CM-226 E CAPACITOR,A,B,C,E 22µF,16V C2220 QEKJ1EM-106 E CAPACITOR 10µF,25V C2221 NCB21EK-223X CAPACITOR 0.022µF,25V C2222 NCB21HK-103X CAPACITOR 0.01µF,50V C2223 NCB21EK-473X CAPACITOR 0.047µF,25V C2224 NCB21EK-473X CAPACITOR 0.047µF,25V C2225 NCB21AK-105X CAPACITOR,A,C,D,F 1µF,10V C2226 NCB21AK-105X CAPACITOR,A,C,D,F 1µF,10V C2227 QERF1CM-106 E CAPACITOR 10µF,16V C2230 QEKJ1EM-106 E CAPACITOR,A,C,D,F 10µF,25V C2231 QEKJ1EM-106 E CAPACITOR,A,C,D,F 10µF,25V C2251 NCB21HK-103X CAPACITOR 0.01µF,50V C2252 NCB21HK-103X CAPACITOR 0.01µF,50V C2253 NCB21HK-103X CAPACITOR 0.01µF,50V C2254 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C2255 NCB21HK-103X CAPACITOR 0.01µF,50V C2256 NCB21HK-103X CAPACITOR 0.01µF,50V C2257 NCB21HK-103X CAPACITOR 0.01µF,50V C2258 NDC21HJ-181X CAPACITOR,A,C,D,F 180pF,50V C2259 QEKJ1HM-334 E CAPACITOR 0.33µF,50V C3004 NCB21EK-473X CAPACITOR 0.047µF,25V C3011 QETL0JM-338 E CAPACITOR 3300µF,6.3V C3012 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C3013 NCB21HK-103X CAPACITOR 0.01µF,50V C3014 QERF0JM-476 E CAPACITOR 47µF,6.3V C3016 NCB21EK-473X CAPACITOR 0.047µF,25V C3022 NCB21EK-473X CAPACITOR 0.047µF,25V C3024 NDC21HJ-120X CAPACITOR 12pF,50V

C3025 QAT3725-300Z TRIM CAPACITOR TIMER CLOCK,A,D C3030 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C3031 NCB21EK-473X CAPACIT OR 0.047µF,25V C3033 NCB21EK-473X CAPACIT OR 0.047µF,25V C3036 NDC21HJ-180X CAPACITOR 18pF,50V C3037 NDC21HJ-120X CAPACITOR 12pF,50V C3041 NDC21HJ-180X CAPACITOR,B,C,E,F 18pF,50V C3045 NDC21HJ-101X CAPACITOR 100pF,50V C3050 NCF21EZ-104X CAPACITOR 0.1µF,25V C3051 NCB21EK-104X CAPACITOR 0.1µF,25V C3052 QEKJ1EM-106 E CAPACITOR 10µF,25V C3054 NCB21HK-222X CAPACITOR 0.0022µF,50V C3056 NCB21EK-104X CAPACITOR 0.1µF,25V C3071 QEKJ1CM-336 E CAPACITOR 33µF,16V C3073 QDYB1CM-103Y CAPACITOR 0.01µF,16V C3074 NCB21HK-103X CAPACITOR 0.01µF,50V C3075 NCB21HK-103X CAPACITOR 0.01µF,50V C3076 NCB21HK-103X CAPACITOR 0.01µF,50V C4002 NCB21HK-103X CAPACITOR 0.01µF,50V C4004 QERF1CM-226 E CAPACITOR 22µF,16V C4005 NCB21HK-222X CAPACITOR 0.0022µF,50V C4006 QERF0JM-476 E CAPACITOR 47µF,6.3V C4007 NCB21HK-102X CAPACITOR,D,F 0.001µF,50V C4008 QEQF1HM-105 NP E CAPACITOR 1µF,50V C4009 NCB21HK-563X CAPACITOR 0.056µF,50V C4010 NCB21EK-223X CAPACIT OR 0.022µF,25V C401 1 NCB21EK-104X CAPACITOR 0.1µF,25V C4012 QERF1HM-105 E CAPACITOR 1µF,50V C4014 NDC21HJ-101X CAPACITOR 100pF,50V C4015 NCB21HK-102X CAPACITOR 0.001µF,50V C4016 NDC21HJ-101X CAPACITOR 100pF,50V C4031 QEKJ1CM-336 E CAPACITOR 33µF,16V

C5001 QFZ9072-473 F CAPACITOR 0.047µF,125V

C5004 QCZ9071-222 CAPACITOR 0.0022µF,250V C5006 QEZ0375-686 E CAPACITOR 68µF,400V C5101 QCZ0212-472 CAPACITOR 0.0047µF,1kV C5102 QCZ0302-330Z CAPACITOR 33pF,1kV C5104 QEKJ1HM-105 E CAPACITOR 1µF,50V C5105 QFN31HJ-153 F CAPACITOR 0.015µF,50V C5106 QCBB1HJ-271 CAPACITOR 270pF,50V C5107 QFV91HJ-104 F CAPACITOR 0.1µF,50V C5202 QETN1CM-108 E CAPACITOR 1000µF,16V C5203 QEMT1AM-128 E CAPACITOR 1200µF,10V C5204 QETJ2AM-475 E CAPACITOR 4.7µF,100V C5206 QEKJ1CM-476 E CAPACITOR 47µF,16V C5207 QEKJ1CM-107 E CAPACITOR 100µF,16V C5301 QEKJ1CM-107 E CAPACITOR 100µF,16V C5303 QEKJ1CM-107 E CAPACITOR 100µF,16V C5305 QFVF1HJ-274Z F CAPACITOR 0.27µF,50V C5307 QEKJ1CM-476 E CAPACITOR 47µF,16V C5308 QEKJ1CM-107 E CAPACITOR 100µF,16V C6008 NCB21HK-123X CAPACITOR,C,F 0.012µF,50V C6013 NCB21HK-103X CAPACITOR 0.01µF,50V C6016 NDC21HJ-101X CAPACITOR,A,B,D,E 100pF,50V C6027 NDC21HJ-151X CAPACITOR,A,B,D,E 150pF,50V C6032 NCB21EK-473X CAPACITOR,A,B,D,E 0.047µF,25V C6037 QEKJ1HM-106 E CAPACITOR 10µF,50V C6056 NDC21HJ-470X CAPACITOR,A,B,D,E 47pF,50V C6501 QEKJ1EM-106 E CAPACITOR 10µF,25V C6502 NCB21HK-103X CAPACITOR 0.01µF,50V C6704 NCB21HK-103X CAPACITOR 0.01µF,50V

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C6707 NDC21HJ-470X CAPACITOR 47pF,50V C6708 NDC21HJ-8R0X CAPACITOR 8pF,50V C6709 NDC21HJ-2R0X CAPACITOR 2pF,50V C6713 NCF21CZ-224X CAPACITOR 0.22µF,16V C6714 NCB21HK-222X CAPACITOR 0.0022µF,50V C6715 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6716 NCB21HK-222X CAPACITOR 0.0022µF,50V C6717 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6719 QEKJ1EM-106 E CAPACITOR 10µF,25V C6720 QEKJ1EM-106 E CAPACITOR 10µF,25V C6721 NCB21HK-103X CAPACITOR 0.01µF,50V C6723 NCB21HK-103X CAPACITOR 0.01µF,50V C6724 QEKJ1HM-225 E CAPACITOR,C,F 2.2µF,50V C7011 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C7103 NCB21HK-681X CAPACITOR,A,C,D,F 680pF,50V C7104 NCB21HK-681X CAPACITOR,A,C,D,F 680pF,50V C7117 QETN0JM-477 E CAPACITOR 470µF,6.3V C7119 NCB21HK-681X CAPACITOR 680pF,50V C7120 NCB21HK-681X CAPACITOR 680pF,50V C7128 QEKJ1CM-107 E CAPACITOR 100µF,16V C7129 NCB21HK-103X CAPACITOR 0.01µF,50V C7131 QETJ0JM-477 E CAPACITOR,A,C,D,F 470µF ,6.3V C7141 NCB21HK-103X CAPACITOR,A,C,D,F 0.01µF,50V C7143 NDC21HJ-330X CAPACITOR,A,C,D,F 33pF,50V C7144 NDC21HJ-680X CAPACITOR,A,C,D,F 68pF,50V C7155 NDC21HJ-680X CAPACITOR,A,C,D,F 68pF,50V C7156 QEKJ1HM-474 E CAPACITOR,A,C,D,F 0.47µF,50V C7157 QEPF1HM-474 NP E CAPACITOR,A,C,D,F 0.47µF,50V C7158 QEKJ1HM-474 E CAPACITOR,A,C,D,F 0.47µF,50V C7159 QEKJ1HM-474 E CAPACITOR,A,C,D,F 0.47µF,50V C7160 NDC21HJ-330X CAPACITOR,A,C,D,F 33pF,50V C7164 NCB21HK-681X CAPACITOR,D,F 680pF,50V C7166 NCB21HK-681X CAPACITOR,D,F 680pF,50V C7168 NCB21HK-681X CAPACITOR 680pF,50V C7169 NCB21HK-681X CAPACITOR 680pF,50V C7170 NCB21HK-821X CAPACITOR 820pF,50V C7171 NCB21HK-821X CAPACITOR 820pF,50V C7182 NCB21HK-681X CAPACITOR 680pF,50V C7183 NCB21HK-681X CAPACITOR 680pF,50V C7197 NCB21EK-104X CAPACITOR 0.1µF,25V C7201 QETN0JM-477 E CAPACITOR 470µF,6.3V L1 QQL29BJ-100Z COIL 10µH L2 QUY153-050Y IM BUS WIRE L3 QQL29BJ-100Z COIL 10µH L4 QQL29BJ-100Z COIL 10µH L5 QQL29BJ-100Z COIL 10µH L12 QQR0967-001 COIL 12µH L13 QQL071J-330Y COIL 33µH L14 QQL29BJ-101Z COIL,C,F 100µH L20 QQL071J-221Y COIL,C,F 220µH L22 QQL231J-1R0Y COIL,B,E 1.0µH L24 QQL071J-270Y COIL 27µH L27 QQL071J-330Y COIL 33µH L28 QQL071J-680Y COIL 68µH L201 QQL071J-150Y COIL 15µH L202 QUY153-050Y IM BUS WIRE L203 QQL071J-330Y COIL,C,F 33µH

QUY153-050Y IM BUS WIRE,A,B,D,E L204 QQL071J-151Y COIL 150µH L251 QUY153-050Y IM BUS WIRE L252 QUY153-050Y IM BUS WIRE

L301 QQL29BJ-100Z COIL,C,F 10µH L302 QQL29BJ-6R8Z COIL,C,F 6.8µH L303 QQL231J-270Y COIL,C,F 27µH L2001 QUY153-050Y IM BUS WIRE L2201 QUY153-050Y IM BUS WIRE L2251 QQL29BJ-100Z COIL 10µH L2252 QQL29BJ-151Z COIL,A,C,D,F 150µH L3001 QQL231J-100Y COIL 10µH L4001 QUY153-050Y IM BUS WIRE L5201 PELN1184 COIL 33µH L5202 PELN1184 COIL 33µH L6001 QQL29BJ-100Z COIL,C,F 10µH

QQL29BK-1R0Z COIL,A,B,D,E 1.0µH L6002 QQL29BJ-100Z COIL 10µH L6501 QQL29BJ-3R3Z COIL 33µH L6502 QUY153-050Y IM BUS WIRE L7101 QQL231J-R22Y COIL 0.22µH L7102 QQL231J-R22Y COIL 0.22µH L7107 QUY153-050Y IM BUS WIRE L7109 QQL231J-1R0Y COIL,A,C,D,F 1.0µH L7113 QQL231J-1R0Y COIL,A,C,D,F 1.0µH L7201 QQL071J-100Y COIL 10µH X1 QAX0576-001Z CRYSTAL RESONATOR X3001 QAX0444-001 CRYSTAL RESONATOR,B,C,E,F

QAX0445-001 CRYSTAL RESONATOR,A,D X3002 QAX0527-001 CRYSTAL RESONATOR X6701 QAX0443-001 CRYSTAL RESONATOR S3001 QSW0602-004 PUSH SWITCH,REC SAFATY S7001 QSW0456-002Z TACT SWITCH S7002 QSW0456-002Z TACT SWITCH S7004 QSW0456-002Z TACT SWITCH S7006 QSW0456-002Z TACT SWITCH S7008 QSW0456-002Z TACT SWITCH S7010 QSW0456-002Z TACT SWITCH S7012 QSW0456-002Z TACT SWITCH S7014 QSW0456-002Z TACT SWITCH S7015 QSW0456-002Z TACT SWITCH S7016 QSW0456-002Z TACT SWITCH K2001 NQL103K-R10X COIL 0.1µH K2002 NQL103K-R10X COIL 0.1µH K2003 NQR0403-003X FERRATE BEADS K2004 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W K2251 NQR0007-002X FERRATE BEADS K2252 NQR0007-002X FERRATE BEADS K2253 NQR0007-002X FERRATE BEADS K5101 QQR0678-001Z FERRATE BEADS K5102 QUY153-050Y IM BUS WIRE K6701 NQR0200-003X FERRATE BEADS K6702 NQR0200-003X FERRATE BEADS K6703 NQR0200-003X FERRATE BEADS K6704 NQR0200-003X FERRATE BEADS K6705 NQR0200-003X FERRATE BEADS K6706 NQR0200-003X FERRATE BEADS K6707 NQR0200-003X FERRATE BEADS,C,F PC3001 RPI-304J IC(PHOTO SENSOR) PC3002 RPI-304J IC(PHOTO SENSOR)

PC5101 PS2561L1-1/L/ IC(PHOTO COUPLER) T2051 PELN0832 OSC TRANSFORMER,A,B,D,E

PELN0860 OSC TRANSFORMER,C,F T2052 PELN0861 OSC TRANSFORMER,D,F

T5001 QQS0083-001 SW TRANSF

5-13

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

TU6001 QAU0261-002 TUNER,A,B,D,E

QAU0266-001 TUNER,C,F SD1 LP21105-001A SHIELD CASE DI7001 LTG-Y2K16M-02J LE DIODE ET1 PQ21623-2-5 EARTH PLATE(RF) HS1 LP40090-001A HEAT SINK,Q5101 JS3001 QSW0954-002 ROTARY ENCODER J7101 PEMC1104 RGB21PIN SOCKET,AV1 J7102 PEMC1104 RGB21PIN SOCKET,AV2 J7103 QNN0292-003 PIN JACK,REAR OUT J7105 QNN0381-002 PIN JACK,FRONT IN,D,F

TB1 LP20317-009B TERMINAL.BOARD(PAL),D,F

OT1 QYTDST3006Z SCREW,Q5101 FC5001 QNG0006-001Z FUSE CLIP,F5001 FC5002 QNG0006-001Z FUSE CLIP,F5001

LF5002 QQR0978-001 LINE FILTER CN1 QGF1201C2-09 FPC CONNECTOR,(1-9)DRUM CN2001 QGF1207C1-06 FPC CONNECTOR,(1-6)A/C HEAD CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD CN3001 QGB2032M4-12 CONNECTOR,(1-12)CAPSTAN MOTOR

CN5001 QGA7901C3-02 CONNECTOR,(1-2)AC IN CN7001 QGF1207C1-04 CONNECTOR,(1-4)ADV.JOG,D,E,F

CP3001 QMFZ050-1R5X-E FUSE T1.5A,125V

CP4001 QMFZ050-1R5X-E FUSE T1.5A,125V

F5001 QMF51E2-2R0J1 FUSE T2.0A,AC250V

LP20317-010B TERMINAL.BOARD(PAL),A,B,C,E

******************************

R.PAUSE BOARD ASSEMBLY(HR-J790EU/J795MS) <91>

PW3 LPA10160-01A3 R.PAUSE BOARD ASSY R7166 NRSA02J-101X MG RESISTOR 100Ø,1/10W J7107 PU60612 MINI JACK CN7104 QUM022-18A4A4 PARA RIBON WIRE

******************************

SAT CTL BOARD ASSEMBLY <94>

PW4 LPA10160-01A4 SAT_CTL BOARD ASSY R7167 NRSA02J-101X MG RESISTOR 100Ø,1/10W J7108 PU60612 MINI JACK CN7106 QUM022-18A4A4 PARA RIBON WIRE

******************************

A/C HEAD BOARD ASSEMBLY <12>

PW1 LPA10158-01A1 A/C HEAD BOARD ASSY

******************************

ADV.JOG BOARD ASSEMBLY(HR-J790EU/J795EK/J795MS) <38>

PW1 LPA20013-07A ADV.JOG BOARD ASSY UN7001 QSW0905-001 ROTARY ENCODER CN7003 QGF1207F1-04 FPC CONNECTOR,(1-4)MAIN

******************************

LOADING MOTOR BOARD ASSEMBLY <55>

PW2 LPA10158-01A2 LOADING MOTOR BOARD ASSY

5-14
