JVC HR-DD840KR User Manual

VIDEO CASSETTE RECORDER
HR-DD840KR
POWER
A
B
C.MEMORY
ENTER
OSDADD
12
3 6
45
DAILY (M–F)
WEEKLY
9
807
AUX
C.RESET
CANCEL
TIMER
CH SKIP
TV
CH
VOL.
DISPLAY TV/VCR
CABLE
TV
VCR
PLAY
FF
REW
REC
U
N
E
M
MULTI BRAND
REMOTE CONTROL UNIT
STOP
PAUSE
S
K
I
P
S
E
A
R
C
H
O
K
E
D
I
I
L
U
L
G
U
I
POWER
MENU CH OK
(
VIDEO
MONO)L – AUDIO – R
+8
VCR
4
REC
STSAP
SP/EP
0
PLAY
AM
SP
6 10
PAUSE
–20dB
PM
L
R
TIMER
M
NORM
HMS
INSERT
A. DUB
REW FF
q
S
L
O
W
W
O
L
S
JOG
SHUTTLE
INSTRUCTIONS
LPT0002-0F9A
2 EN
Dear Customer,
Thank you for purchasing the JVC VHS video cassette recorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of your new VCR.
Failure to heed the following precautions may result in
CAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION:
This video cassette recorder should be used with AC 110V – 220V`, 60Hz only. To prevent electric shocks and fire hazards, DO NOT use any other power source.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
damage to the VCR, remote control or video cassette.
1. DO NOT place the VCR . . .
... in an environment prone to extreme temperatures or
humidity. ... in direct sunlight. ... in a dusty environment. ... in an environment where strong magnetic fields are
generated. ... on a surface that is unstable or subject to vibration.
2. DO NOT block the VCR’s ventilation openings.
3. DO NOT place heavy objects on the VCR or remote control.
4. DO NOT place anything which might spill on top of the VCR or remote control.
5. AVOID violent shocks to the VCR during transport.
**MOISTURE CONDENSATION
Moisture in the air will condense on the VCR when you move it from a cold place to a warm place, or under extremely humid conditions—just as water droplets form on the surface of a glass filled with cold liquid. Moisture condensation on the head drum will cause damage to the tape. In conditions where condensa­tion may occur, keep the VCR’s power turned on for a few hours to let the moisture dry before inserting a tape.
**ABOUT HEAD CLEANING
Accumulation of dirt and other particles on the video heads may cause the playback picture to become blurred or inter­rupted. Be sure to contact your nearest JVC dealer if such troubles occur.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
CAUTION:
Changes or modifications not approved by JVC could void user's authority to operate the equipment.
G-CODE is a trademark applied for by Gemstar Development Corporation. The G-CODE system is manufactured under license from Gemstar Development Corporation.
TM
DSS
is an official trademark of DIRECTV, Inc., a unit of GM Hughes Electronics. PRIMESTAR is a registered service mark of Primestar Partners, L.P. DISH Network Echostar Communications Corporation.
n Cassettes marked "VHS" (or "S-VHS") can be used with this
video cassette recorder. However, only "VHS" recordings can be played back in this model.
n HQ VHS is compatible with existing VHS equipment.
TM
is a trademark of
CONTENTS
NSTALLING YOUR NEW VCR 4
I
Basic Connections ..................................4
NITIAL SETTINGS 5
I
Plug & Play .................................................. 5
Language ..................................................... 6
Clock ............................................................7
Preparation ................................................................7
Semi-Auto..................................................................8
Manual ......................................................................9
Auto ..........................................................................9
Tuner ..........................................................10
Set Receivable Channels..........................................10
Add Or Delete A Channel ........................................12
Cable Box Control.......................................13
Situate And Connect Controller ...............................13
Set Cable Box Output Channel ................................14
Set Cable Box Brand ................................................15
G-CODE Setup ............................................. 16
DBS Receiver Control................................... 18
Situate And Connect Controller ...............................18
Set DBS Receiver Output Channel ...........................19
Set DBS Receiver Brand...........................................20
IMPLE PLAYBACK AND
S
RECORDING 21
Simple Playback .........................................21
Simple Recording ........................................ 22
LAYBACK AND RECORDING FEATURES 23
P
Playback Features ......................................23
Still Picture/Frame-By-Frame Playback.....................23
Slow Motion/Reverse Slow Motion ..........................23
High-Speed Search ..................................................23
Manual Tracking ......................................................24
Tape Position Indicator ............................................24
Video Stabilizer .......................................................25
Superimpose............................................................26
Select The Soundtrack .............................................27
Index Search............................................................28
Instant ReView.........................................................28
Repeat Playback ......................................................29
Counter Reset ..........................................................29
Counter Memory .....................................................29
Next-Function Memory............................................29
AV COMPU LINK Playback.....................................30
Auto Picture ................................................ 32
Preparation ..............................................................32
Playback..................................................................33
Time Scan ................................................... 34
Variable-Speed Search/Reverse Motion Playback .....34
Skip Search..............................................................35
Time Scan Audio .....................................................36
EN 3
Recording Features .....................................37
Record One Program While
Watching Another....................................................37
Display Elapsed Recording Time..............................37
Stereo And SAP (Second Audio Program).................38
To Record SAP Programs..........................................38
Hi-Fi Audio Recording Level Control .......................39
IMER RECORDING 40
T
G-CODE Timer Programming .......................40
On-Screen Timer Programming ...................42
Check And Cancel Programs ...................................44
Auto Timer...............................................................45
Instant Timer Recording (ITR) .......................46
DITING 47
E
Edit To Or From Another VCR .......................47
Edit From A Camcorder ...............................48
Insert Editing ..............................................50
Audio Dubbing ...........................................52
PECIAL FEATURES 53
S
TV Multi-Brand Remote Control ..............................53
Cable Box Multi-Brand Remote Control...................54
DBS Receiver Multi-Brand Remote Control..............55
Control Two JVC VCRs ............................................56
ROUBLESHOOTING 57
T
Power ........................................................ 57
Tape Transport ............................................57
Playback ....................................................57
Recording ................................................... 58
Timer Recording..........................................58
Other Problems .......................................... 59
UESTIONS AND ANSWERS 60
Q
Playback ....................................................60
Recording ................................................... 60
Timer Recording..........................................60
NDEX 61
I
List Of Terms............................................... 61
Front View.................................................. 62
Rear View .................................................. 63
Front Display Panel.....................................63
Remote Control ...........................................64
PECIFICATIONS 65
S
4 EN
Basic
INSTALLING YOUR NEW VCR
CHECK CONTENTS
Make sure the package contains all of the accessories listed in “SPECIFICATIONS” (Z pg. 65).
1
Connections
Antenna or Cable
AC Power Cord
Back of VCR
AC Outlet
TV
Coaxial Cable
Flat Feeder
Matching Transformer (not supplied)
Audio/Video Cable (supplied)
75 ohm terminal
ANTENNA IN (Antenna or Cable input)
TV OUT
Back of VCR
CH3
CH4
RF Cable (supplied)
SITUATE VCR
Place the VCR on a stable, horizontal surface.
2
CONNECT VCR TO TV
The connection method you use depends on the type of TV you have.
3
RF Connection
To Connect To A TV With NO AV Input Terminals . . .
a– Disconnect the TV antenna from the TV. b– Connect the TV antenna cable to the ANTENNA
IN jack on the rear of the VCR.
c– Connect the supplied RF cable between the TV
OUT jack on the rear of the VCR and the TV’s antenna terminal. Set TV on CH3 or CH4 corre­sponding to the CH3 – CH4 switch setting on the back of the VCR.
AV Connection
To Connect To A TV With AV Input Terminals . . .
a– Connect the antenna, VCR and TV as shown in
the illustration.
b– Connect an Audio/Video Cable between the AUDIO
OUT and VIDEO OUT jacks on the rear of the VCR and the AV IN jacks on the TV. Set your TV in video input mode or A/V input mode. Refer to the TV Instruction Manual.
CONNECT VCR TO POWER SOURCE
Connect the power plug to an AC outlet.
The clock and tuner channels will automatically be
4
set when the antenna is connected and when the AC is first connected to the VCR (Z pg. 5). (If "Auto" or "CH" is displayed on the front display panel before the VCR is powered on, the clock and tuner channels are being set automatically. Wait for the time to be displayed on the front display panel before powering on the VCR.)
NOTES:
The VCR channel is the channel on the TV which will display the audio and video signals from the VCR. The VCR's CH3­CH4 switch, on the back of the VCR, sets the VCR channel to CH3 or CH4.
The CH3–CH4 switch is preset to the CH3 position. Set to CH4 if CH3 is used for broadcasting in your area and set the channel on the TV to correspond to the VCR's CH3– CH4 switch setting.
If RF connection to TV is used, when switching from VCR to TV mode and from TV to VCR it may be necessary to issue a CH UP and then CH DOWN on TV to obtain a good quality picture.
Even if you are using AV cables to connect your VCR to your TV, you must also connect it using the RF cable. This will ensure that you can record one show while watching another (Z pg. 37).
For full identification of the VCR's rear panel, refer to the Index (REAR VIEW Z pg. 63).
FINAL PREPARATION FOR USE
Power on the VCR and select the VCR channel (3 or 4) by setting the switch on the rear of the VCR as shown in
5
the illustration. You can now perform simple playback (Z pg. 21) or simple recording (Z pg. 22).
INITIAL SETTINGS
Plug & Play
Auto Clock Set/Auto Tuner Set
q
IMPORTANT
Don’t press any buttons on the VCR or remote while Plug & Play is in progress.
If you perform Plug & Play successfully, there’s no need to perform the Clock (Z pg. 7) and Tuner (Z pg. 10) procedures. If, however , you want to add or delete channels, refer to “Add Or Delete A Channel” on page 12.
ATTENTION CABLE BOX SUBSCRIBERS
If you perform the Plug & Play procedure . . .
Select the PBS channel on your cable box before plugging your VCR’s power plug into the AC outlet. (If you have more than one PBS channel, you may have to select an alternative PBS channel if Plug & Play is not successful.)
If there is no PBS channel in your area, perform the Manual Clock Set procedure (Z pg. 9).
For automatic clock adjustment to take place the VCR's power must be off and the cable box must be set to the PBS channel at clock adjustment times.
If you perform Plug & Play successfully, D.S.T. will be set to “AUTO”. At the D.S.T. adjustment time (Z pg. 9), your VCR's power must be off and your cable box must be set to the host PBS channel in your area for the D.S.T. adjustment to take place. If the clock is not set correctly, change the D.S.T. setting to “ON” or “OFF. See step 9 of Semi-Auto procedure (Z pg. 8) or step 6 of Manual procedure (Z pg. 9).
NOTE:
If the memory backup fails, because of a power outage or because the AC was removed from the VCR, Plug & Play will be performed when power is restored to the VCR.
EN 5
The Plug & Play function sets the clock and tuner channels automatically when power is first connected to the VCR. The antenna cable must be connected for the Plug & Play function.
The time and date can be set automatically from clock setting data that is transmitted by one of the regular TV broadcast channels. We call this TV channel the “Host Channel” and it is a PBS channel in your area.
PLUG & PLAY SETUP
Connect the antenna cable to the VCR (Z pg. 4). Then connect the VCR’s power plug to an AC outlet. Do not
1
power on the VCR. The clock and tuner channels will automatically be set.
Auto clock set is performed first. The auto clock set function scans all the channels received by your VCR to find the Host Channel and then sets the clock. "Auto" blinks on the front display panel during Auto clock set.
Auto channel set is performed next. The auto channel set function scans all the channels that are receivable by your VCR. It then automatically assigns each receivable channels to the CH ▲▼ buttons. It skips non-receivable channels. During auto channel set the channel numbers are displayed as they are scanned and set.
When Plug & Play has been completed successfully the correct time is displayed.
If "AUTO CLOCK SET" or "SEMI-AUTO CLOCK SET" is selected at the Override Auto Clock Set screen on page 8, the clock will be adjusted automatically by the Host PBS every hour on the hour (except for 11:00 PM, midnight, 1:00 AM and 2:00 AM) by the incoming PBS channel clock setting data. (This automatic clock adjustment can only be performed when the VCR’s power is turned off. The clock will be adjusted on the hour based on the time displayed on the VCR, not on the actual real time.) The default setting is "AUTO CLOCK SET".
If an incorrect time is displayed on the front display panel, you may be receiving the clock setting data of a PBS channel from an adjacent time zone, or an incorrect PBS channel from a cable TV system. In this case, perform the Semi-Auto ( Clock Set ( already taken place and it need not be set again.
If “- -:- -” appears on the display, your antenna cable may not be connected to the VCR, there may not be a Host PBS signal available in your area, or your cable box may not be set to the PBS channel. Ensure that the antenna cable is connected correctly. If you use a cable box ensure that your local PBS channel is selected on your cable box ( SCRIBERS). Then power on and power off the VCR; the Plug & Play function will be automatically reactivated and "Auto" will be displayed on the VCR's front panel. If Plug & Play is not performed but everything is con­nected and set correctly, perform the Manual Clock Set procedure ( place, so please also perform the “Set Receivable Channels” procedure (
Z pg. 9) procedure. Auto channel set has
Z ATTENTION CABLE BOX SUB-
Z pg. 9). Auto channel set has not yet taken
Z pg. 8) or Manual
Z pg. 10).
During Initial Auto Clock Set
"Auto" blinks.
During Auto Channel Set
The channel numbers are displayed as they are scanned and set.
PM
Plug & Play Completed
The current time (including AM/PM) is displayed.
6 EN
POWER
MENU
CH5∞
OK
Language
INITIAL SETTINGS (cont.)
This VCR offers you the choice to view on-screen messages in English, Spanish or French (not including messages superimposed on the TV picture). Select the desired language using this procedure. The default setting is "ENGLISH".
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
12 45 7
8 0
3 6 9
CH5∞
TURN ON THE VCR
Press POWER.
1
ACCESS ON-SCREEN MENU
Press MENU as many times as necessary.
2
ACCESS CUSTOM SET SCREEN
At the Main Menu screen, move the highlight bar
3
(arrow) to “CUSTOM SET” by pressing CH 5∞ or
PUSH JOG 5∞, then press OK.
ACCESS LANGUAGE SELECT SCREEN
The messages are preset to appear in English. If you want
4
to see them in Spanish or French, move the highlight bar (arrow) to “LANGUAGE SELECT” by pressing CH or PUSH JOG 5∞, then press OK.
5
MAIN MENU
PROGRAM SET FUNCTION SET TUNER SET
= CUSTOM SET
AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
CUSTOM SET
OVERRIDE
AUTO CLOCK SET
=LANGUAGE SELECT
G-CODE SET-UP DBS RECEIVER OUTPUT DBS RECEIVER BRAND SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
MENU
OK
PUSH JOG5∞
SELECT LANGUAGE
At the Language Select screen, move the highlight
5
bar (arrow) to the desired language by pressing CH
5
or PUSH JOG 5∞,
then press MENU as many times as necessary to return to the normal screen.
LANGUAGE SELECT
=ENGLISH
ESPAÑOL FRANCAIS
PRESS (5,) TO SELECT PRESS (MENU) TO END
Clock
POWER
MENU
CH
OK
EN 7
Perform clock setting only if the clock has not been set correctly by the Plug & Play function. Access the Override Auto Clock Set screen to choose the Auto, Semi-Auto or Manual clock setting procedure. Each procedure starts from step 5. *Auto need only be selected if Semi-Auto or Manual had previously been selected.
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
12 45 7
8 0
3 6 9
CH
Preparation
TURN ON THE VCR
Press POWER.
1
ACCESS ON-SCREEN MENU
Press MENU as many times as necessary.
2
ACCESS CUSTOM SET SCREEN
At the Main Menu screen, move the highlight bar
3
(arrow) to “CUSTOM SET” by pressing CH 5∞ or
PUSH JOG 5∞, then press OK.
ACCESS CLOCK SET MODE SELECT SCREEN
Move the highlight bar (arrow) at the Custom Set
4
screen to “OVERRIDE AUTO CLOCK SET” by pressing CH 5∞ or PUSH
JOG 5∞, then press OK.
PROGRAM SET FUNCTION SET TUNER SET
=CUSTOM SET
AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
=OVERRIDE
AUTO CLOCK SET
LANGUAGE SELECT G-CODE SET-UP DBS RECEIVER OUTPUT DBS RECEIVER BRAND SET
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
MAIN MENU
CUSTOM SET
MENU
OK
PUSH JOG
8 EN
MENU
CH
OK
MENU
12 45
8
7
0
3 6 9
CH
q
OK
PUSH JOG
INITIAL SETTINGS (cont.)
Semi-Auto
SELECT MODE
At the Override Auto Clock Set screen, move the
5
highlight bar (arrow) to “SEMI-AUTO CLOCK SET” by pressing CH ▲▼ or
PUSH JOG 5∞, then press OK.
OVERRIDE AUTO CLOCK SET
AUTO CLOCK SET
=SEMI–AUTO CLOCK SET
MANUAL CLOCK SET
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
ACCESS SELECT SCREENS
At the Semi-Auto Clock Set screen, move the highlight
6
bar (arrow) to the desired mode by pressing CH ▲▼ or PUSH JOG 5∞, then press OK.
To select the Host Channel — step 7 To select the Time Zone — step 8 To select the D.S.T. mode — step 9
NOTE:
The time that has been set previously by the Plug & Play function will be erased when any of the three settings mentioned above is changed.
SEMI–AUTO CLOCK SET
= HOST CHANNEL SELECT
TIME ZONE SELECT D.S.T. SELECT
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
SELECT HOST CHANNEL
You can either select "AUTO", or enter a PBS
7
channel number. For automatic selection, press MENU if "AUTO" is highlighted on the Host Channel Select screen. To manually select "AUTO" or the PBS channel, press CH ▲▼ or PUSH JOG 5∞ to cycle through "AUTO" or the channel numbers (hold button down to speed through numbers) and stop when the desired number appears. Press MENU and the Semi-Auto Clock Set screen reappears.
HOST CHANNEL SELECT
PRESS (5,) TO SELECT
PRESS (MENU) TO END
(CATV)
CH AUTO
NOTES:
For cable box users: Select "AUTO" or the channel on your VCR that receives the cable box channels, and set the cable box to the PBS channel.
There are some PBS channels that do not transmit clock setting data.
EN 9
SELECT TIME ZONE
You can select the zone automatically or manually
8
by pressing CH ▲▼ or PUSH JOG 5∞. If an
incorrect time is displayed you may be receiving the clock setting data of a PBS channel from an adjacent time zone or from an incorrect PBS channel from a cable TV system. If you selected "AUTO" in step 7 select "MANUAL" and select the correct time zone manually.
If you selected "AUT O", press MENU to return to the Semi-Auto Clock Set screen.
If you selected "MANUAL", press OK and the screen to the right appears. Move the highlight bar (arrow) to your choice by pressing CH ▲▼ or PUSH JOG
5
, then press MENU
twice to return to the Semi-Auto Clock Set screen.
TIME ZONE SELECT
PRESS (5,) TO SELECT PRESS (MENU) TO END
TIME ZONE SELECT
=ATLANTIC
PRESS (5,) TO SELECT PRESS (MENU) TO END
SELECT D.S.T. MODE
You have three choices:
a–Select “AUTO” and the
9
adjustment to your VCR’s clock will be made according to the incoming signal from the host channel. b–Select “ON” and the adjustment will be made based on the clock itself. c–Select “OFF” if Daylight Saving Time doesn’t apply to you. Move the highlight bar (arrow) to your choice by pressing CH and the Semi-Auto Clock Set screen reappears.
5
or PUSH JOG
D.S.T. SELECT
PRESS (5,) TO SELECT PRESS (MENU) TO END
5
, then press MENU
=AUTO
MANUAL
EASTERN CENTRAL MOUNTAIN PACIFIC ALASKA HAWAII
=AUTO
ON OFF
Manual
SELECT MODE
At the Override Auto Clock Set screen (Z pg. 10), move the highlight bar (arrow) to “MANUAL CLOCK SET” by
5
pressing CH ▲▼ or PUSH JOG 5∞, then press OK.
SET DATE, TIME AND D.S.T.
The Manual Clock Set screen is displayed and the
6
month digit begins blinking. Press the appropriate NUMBER keys to set the date and time (if only 1 digit, press "0" first). Press CH ▲▼ or PUSH JOG 5∞ to set AM/PM and D.S.T. (Daylight Saving Time). Press OK after AM/ PM and D.S.T. settings. Set D.S.T. to "ON" to set the D.S.T. according to the VCR's clock or to "OFF" if D.S.T. doesn't apply to you.
When you’re finished with this set-up procedure, press MENU to start the clock.
NOTES:
CH ▲▼ and PUSH JOG
all operations. (In this case, press OK after each setting.)
At the Manual Clock Set screen, the setting that can be set blinks. When setting of a highlighted item is completed, the highlight bar moves down by 1 line to the next item.
MANUAL CLOCK SET
DATE 1/ 1/97 WED
TIME – –:– – AM D.S.T. ON
PRESS NUMBER KEY (O–9)
OR (5,), THEN (OK)
PRESS (MENU) TO END
5
can be used to perform
MAKE CORRECTIONS
To change any of the settings, press OK or PUSH JOG
%
until the item you want to change blinks, then set
7
as in step 6.
Auto
IMPORTANT
T urn the VCR off after performing the Semi-Auto Clock Set procedure. "Auto" will appear on the front display panel when the clock is being set. The current time will appear automatically when the clock is set.
SELECT MODE
At the Override Auto Clock Set screen, move the highlight bar (arrow) to "AUTO CLOCK SET" by
5
pressing CH ▲▼ or PUSH JOG 5∞, then power off the VCR. Do not power it on again until the clock has been adjusted. The clock is automatically adjusted on the hour except at 11:00 PM, midnight, 1:00 AM and 2:00 AM. (The clock will be adjusted on the hour based on the time displayed on the VCR, not on the actual real time.)
**AUTO DAYLIGHT SAVING TIME
This function enables automatic adjustment of the VCR’s clock at the start and end of Daylight Saving Time. With Auto DST activated, . . . . . . on the first Sunday of April at 2:00 AM, the clock is
adjusted to 3:00 AM.
. . . on the last Sunday of October at 2:00 AM, the clock is
adjusted to 1:00 AM.
10 EN
POWER
MENU
CH
OK
INITIAL SETTINGS (cont.)
Set Receivable Channels
Tuner
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
12 45 7
8 0
3 6 9
CH
TURN ON THE VCR
Press POWER.
1
ACCESS MAIN MENU SCREEN
Press MENU as many times as necessary.
2
ACCESS TUNER SET SCREEN
Move the highlight bar (arrow) to "TUNER SET" by
3
pressing CH 5∞ or PUSH JOG 5∞, then press OK.
PERFORM AUTO CHANNEL SET
Move the highlight bar (arrow) to "AUTO
4
CHANNEL SET" by pressing CH 5∞ or PUSH
JOG 5∞, then press OK.
Receivable channels in your area are automatically assigned to the CH 5∞ buttons, and non-receivable channels are skipped.
PROGRAM SET FUNCTION SET
=TUNER SET
CUSTOM SET AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
BAND AFC
=AUTO CHANNEL SET
MANUAL CHANNEL SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
AUTO CHANNEL SET
MAIN MENU
TUNER SET
MENU
OK
PUSH JOG
NOTES:
At the end of Auto Channel Set, “SCAN COMPLETED” appears on screen.
If the scan was unsuccessful, “SCAN COMPLETED– NO SIGNAL” appears on screen. Check the connections and start again.
RETURN TO NORMAL
SCANNING...
PRESS (MENU) TO END
SCREEN
Press MENU as many times as necessary.
5
EN 11
MENU
OK
CH
INFORMATION
The VCR detects the band (TV or CATV) and selects the correct band automatically during Auto Channel Set. If necessary, you can check the setting at the Band screen after Auto Channel Set has set the channels.
At the Tuner Set screen, move the highlight bar (arrow) to
q
"BAND" by pressing CH 5∞ or PUSH JOG 5∞, then press OK.
TUNER SET
=BAND
AFC AUTO CHANNEL SET MANUAL CHANNEL SET
BAND TV
=CATV
MENU
12 45
8
7
0
3 6 9
CH
OK
PUSH JOG
PRESS (5,), THEN (OK) PRESS (MENU) TO END
PRESS (5,) TO SELECT PRESS (MENU) TO END
Press MENU as many times as necessary to return to the normal screen.
12 EN
MENU
CH
OK
ADD
NUMBER
CH.SKIP
12 45
8
7
0
3 6 9
CH
INITIAL SETTINGS (cont.)
Add Or Delete A Channel
ACCESS TUNER SET SCREEN
Access by performing steps 2 and 3 of the Tuner
q
procedure on page 10.
1
To add a channel, go to step 2.
To delete a channel, skip to step 4.
ACCESS AFC SCREEN
Move the highlight bar (arrow) to "AFC" by pressing CH
5
or PUSH JOG 5∞, then press OK.
2
MAKE SELECTION
Move the highlight bar (arrow) to "SPCL" by
3
pressing CH 5∞ or PUSH JOG 5∞, then press MENU to return to the
Tuner Set screen.
AFC set to SPCL (special) is necessary for tuning on certain CATV systems.
ACCESS MANUAL CHANNEL SET SCREEN
Move the highlight bar (arrow) to "MANUAL CHANNEL SET" by pressing CH 5∞ or PUSH JOG 5∞, then press
4
OK.
AFC
NORM
=SPCL
PRESS (5,) TO SELECT PRESS (MENU) TO END
MENU
STORE OR SKIP DESIRED CHANNEL
OK
PUSH JOG
Input the channel number using the NUMBER keys or
5
by pressing CH 5∞ or PUSH JOG 5∞, then press ADD to add or CH.SKIP to
delete. Repeat for each channel you want to store or skip.
MANUAL CHANNEL SET
(CATV)
CH 125 ADD
SELECT CH NO. AND PRESS (ADD/SKIP) PRESS (MENU) TO END
RETURN TO NORMAL SCREEN
Press MENU as many times as necessary.
6
Cable Box Control
Suggested Location
Place the cable box on top of the VCR. Attach the VCR's Controller to the top of the VCR with the Controller’s transmitter pointed towards the cable box’s remote sensor.
Attention:
The Controller can also control a DBS receiver. If both a cable box and a DBS receiver are used, position the controller so its signal reaches the remote control sensors of both the cable box and DBS receiver.
Cable box
Your VCR
Cable box
Controller (suggested locations)
EN 13
This procedure is required if you receive your TV channels through a cable box (descrambler). The Controller allows the VCR to automatically switch the cable box channel during timer-recording. The Controller is effective for recording shows that have been programmed using G-CODE (Z pg. 40) or On­Screen Timer Programming (Z pg. 42).
Situate And Connect Controller
SITUATE CONTROLLER
Place the Controller so that the path between its transmitter and the cable box’s remote sensor is
1
unobstructed.
ATTACH CONTROLLER
Fasten securely using the supplied adhesive strips.
2
CONNECT CABLE BOX TO VCR
The connection method depends on the type of cable box you have.
3
If your cable box has AUDIO and VIDEO OUT connectors . . .
. . . connect them to the AUDIO and VIDEO IN connectors on your VCR; select the correct external input mode as described in step 4, 5, 9 11 on page
50. Set the VCR to channel "AU" to use the cable box.
If your cable box doesn’t have AUDIO and VIDEO OUT connectors . . .
. . . connect the antenna output connector on the cable box to the ANTENNA IN connector on the rear of your VCR. Set the VCR tuner to the same channel as the cable box RF output (see page 14 also).
Controller
Your VCR
Transmitter
Connected to ANTENNA IN
CABLE
BOX
Connected to VIDEO/ AUDIO IN
NOTE:
When connecting your cable box refer to its instruction manual.
CONNECT CONTROLLER TO VCR
Connect to the CABLE BOX connector on your VCR.
4
About Your Cable Box
This VCR has two separate methods to control your Cable Box.
The VCR's Wireless Remote Control Unit can control your Cable Box. This eliminates the need for a separate Cable Box Remote Control Unit.
The VCR's Controller can also control your Cable Box. This allows the VCR to change your Cable Box's channel number during timer recording.
Each method must be set up separately. To set up the VCR's Remote Control unit, refer to page 54. To set up the Controller go to page 14.
14 EN
MENU
CH
POWER
OK
INITIAL SETTINGS (cont.)
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
NUMBER
12 45 7
8 0
3 6 9
CH
ACCESS CUSTOM SET SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
3
highlight bar (arrow) to “CUSTOM SET”, then press OK.
=CUSTOM SET
ACCESS G-CODE SET-UP SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
4
highlight bar (arrow) to “G-CODE SET-UP”, then press OK.
OVERRIDE LANGUAGE SELECT
=G-CODE SET-UP
DBS RECEIVER OUTPUT DBS RECEIVER BRAND SET
ACCESS CABLE BOX OUTPUT SCREEN
Press CH JOG
5
highlight bar (arrow) to “CABLE BOX OUTPUT”, then press OK.
5
5
to move the
or PUSH
GUIDE CHANNEL SET GUIDE CHANNEL MAP
=CABLE BOX OUTPUT
CABLE BOX BRAND SET
MAIN MENU
PROGRAM SET FUNCTION SET TUNER SET
AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
CUSTOM SET
AUTO CLOCK SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
G-CODE SET-UP
PRESS (5,), THEN (OK) PRESS (MENU) TO END
MENU
Set Cable Box Output Channel
TURN ON THE VCR
Press POWER.
1
ACCESS MAIN MENU SCREEN
Press MENU as many times as necessary.
2
OK
PUSH JOG
SELECT CABLE BOX OUTPUT CHANNEL
Your selection depends on how your cable box is
6
connected to your VCR.
If your cable box is connected to your VCR using an RF connection . . .
. . . press CH 5∞ or PUSH JOG 5∞ to move the
highlight bar (arrow) to the channel number representing the cable box’s output (2–6).
If your cable box is connected to your VCR’s AUDIO/ VIDEO IN connectors . . .
. . . press CH 5∞ or PUSH JOG 5∞ to move the highlight bar (arrow) to “ON LINE”.
CABLE BOX OUTPUT
=OFF
PRESS (5,) TO SELECT PRESS (MENU) TO END
RETURN TO G-CODE SET-UP SCREEN
Press MENU.
7
ON CH2 ON CH3 ON CH4 ON CH5 ON CH6 ON LINE
EN 15
Set Cable Box Brand
TURN ON CABLE BOX
Select a channel other than channel 9 on your Cable Box.
1
ACCESS CABLE BOX BRAND SET SCREEN
At the G-CODE Set-Up screen, press CH 5∞ or
2
PUSH JOG 5∞ to move
the highlight bar (arrow) to “CABLE BOX BRAND SET”, then press OK.
ENTER CABLE BOX BRAND
Press the appropriate
NUMBER keys to enter the
3
Cable Box Code from the CABLE BOX BRAND LIST to the right, then press OK.
If the cable box’s channel changes to 9, setting is complete.
If there are more than one code number listed for your brand of cable box, repeat step 3 until the cable box’s channel changes to 9.
If the code numbers for your model of cable box is not listed the channel may not change even if you go through all the listed numbers. If this occurs try all other numbers between 1 and 69.
GUIDE CHANNEL SET GUIDE CHANNEL MAP CABLE BOX OUTPUT
=CABLE BOX BRAND SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
CABLE BOX BRAND SET
PRESS NUMBER KEY (0-9) PRESS (MENU) TO END
CABLE BOX BRAND LIST
BRAND CODE
ZENITH 11, 12, 60, 61 DEREUNG 10
G-CODE SET-UP
1
THEN (OK)
RETURN TO NORMAL SCREEN
Press MENU as many times as necessary.
4
You can now set up the G-C
NOTES:
Although the supplied Controller is compatible with many different cable box brands, it is possible that it will not work with your cable box.
If your cable box doesn’t respond to any code between 1 and 69, you can’t use the Controller to change cable box channels. In this case, make sure to leave the cable box turned on and tuned to the proper channel before the scheduled start of timer recording. Please contact your cable company about the possibility of exchanging your current cable box with one that is compat­ible with your VCR.
The VCR can only change the cable box channel through the Controller during timer recording.
If your cable box is one that can’t be operated with a remote control (because it has no remote sensor), you can’t use the Controller to change its channels. Make sure to leave the cable box turned on and tuned to the proper channel before the scheduled start of timer recording.
ODE feature ( Z pg. 16).
16 EN
MENU
CH
POWER
OK
G-CODE Setup
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
NUMBER
12 45 7
8 0
3 6 9
CH
INITIAL SETTINGS (cont.)
The G-CODE timer programming system eliminates the need to input channel, date, start and stop time data when setting the timer record function. Simply key in the G-CODE number for the TV program you wish to record (found in most TV listings) and the VCR’s timer is automatically programmed.
Depending on the TV or cable stations that you receive and the channel numbers that they are received on in your area, you may have to make certain changes in your VCR’ s “Guide Channel Set” menu to get proper results. Please read the following information carefully to find out which tasks you need to perform.
Before G-C procedures:
Plug & Play (Z pg. 5)
Clock setting (Z pg. 7) and Tuner setting (Z pg. 10)
Cable box setting if you receive your TV channels through a
cable box (Z pg. 13)
Channel Number Matching
Most TV listings have a chart indicating the “Guide Channel” number assigned to each station for purposes of G-CODE programming. Check the chart in your TV listings and see if the Guide Channel numbers listed for the stations you receive are the same as the channel number on which each is received by your VCR or cable box.
**SPECIAL NOTES FOR CABLE SUBSCRIBERS**
In many instances, cable TV stations have G-CODE Guide Channel numbers that DO NOT match the number of the channel on which you receive the station. Check your TV listings, or contact your cable supplier for details.
Many normal broadcast TV stations can be viewed on cable. Check your TV listing, or contact your cable supplier for details.
If the numbers match, go directly to “G-C Programming” (Z pg. 40).
If the numbers are different, and you want to be able to timer record programs from those stations, you have to inform the VCR of the mismatch. Go to step 1. If you will not want to timer record from those stations, you can go directly to “G-C Timer Programming” (Z pg. 40).
ODE setup you must have performed the following
ODE Timer
ODE
MENU
TURN ON THE VCR
Press POWER.
1
ACCESS MAIN MENU
OK
PUSH JOG
SCREEN
Press MENU as many times as necessary.
2
EN 17
ACCESS CUSTOM SET SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
3
highlight bar (arrow) to “CUSTOM SET”, then press OK.
PROGRAM SET FUNCTION SET TUNER SET
=CUSTOM SET
AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
ACCESS G-CODE SET-UP SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
4
highlight bar (arrow) to “G-CODE SET-UP”, then press OK.
OVERRIDE
AUTO CLOCK SET
LANGUAGE SELECT
=G-CODE SET-UP
DBS RECEIVER OUTPUT DBS RECEIVER BRAND SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
ACCESS GUIDE CHANNEL SET SCREEN
Press CH JOG
5
highlight bar (arrow) to “GUIDE CHANNEL SET”, then press OK.
5
5
to move the
or PUSH
=GUIDE CHANNEL SET
GUIDE CHANNEL MAP CABLE BOX OUTPUT CABLE BOX BRAND SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
INPUT GUIDE CHANNEL NUMBER
Press CH 5∞, PUSH JOG
5
or the appropriate
6
NUMBER keys to input the G-CODE Guide Channel number as shown in the TV listing. Then press OK.
If you receive your channels with a cable box and if you have properly set your Controller, “CABLE CH” appears in place of “VCR CH”. If not, refer to pages 13–14 and re-perform the procedure.
(Ex.) When inputting the Guide Channel number 6 for WNJU(Ind.)
GUIDE CHANNEL SET
PRESS NUMBER KEY (0-9) PRESS (MENU) TO END
MAIN MENU
CUSTOM SET
G-CODE SET-UP
GUIDE CH : 6
VCR CH : 6
OR (5∞), THEN (OK)
INPUT RECEIVING CHANNEL NUMBER
Press CH 5∞, PUSH JOG
5
or the appropriate
7
NUMBER keys to input the number of the channel on which the GuideChannel’s broadcasts are received. Then press OK.
If there is more than one mismatch, repeat steps 6 and 7 for each instance.
(Ex.) If WNJU(Ind.) is received on channel 47
GUIDE CHANNEL SET
GUIDE CH : 6
VCR CH : 47
PRESS NUMBER KEY (0-9)
OR (5∞), THEN (OK)
PRESS (MENU) TO END
RETURN TO G-CODE SET-UP SCREEN
Press MENU.
8
CHECK INPUT DATA
Press CH 5∞ or PUSH JOG 5∞ to move the
9
highlight bar (arrow) to “GUIDE CHANNEL MAP”, then press OK.
The Guide Channel and VCR or cable box channel numbers you input appear on the screen in ascending order. Check to ensure you’ve entered them correctly.
If you entered more than 10 sets of numbers, press OK to see the next set of numbers.
Guide Channel Map contains only the Guide Channels and VCR or CABLE channels that you entered.
G-CODE SET-UP
GUIDE CHANNEL SET
=GUIDE CHANNEL MAP
CABLE BOX OUTPUT CABLE BOX BRAND SET
PRESS (5,), THEN (OK) PRESS (MENU) TO END
GUIDE CHANNEL MAP
GUIDE: VCR GUIDE: VCR
6 : 47 10 : 55 12 : 41 15 : 38 33 : 28 67 : 49
PRESS (OK) TO NEXT PRESS (MENU) TO END
RETURN TO NORMAL SCREEN
Press MENU as many times as necessary.
10
You can now use G-CODE for quick and simple timer programming (Z pg. 40).
18 EN
DBS Receiver Control
Suggested Location
Place the DBS (Direct Broadcast DBS) receiver on top of the VCR. Attach the VCR's Controller to the top of the VCR with the Controller’s transmitter pointed towards the DBS receiver's remote sensor.
Attention:
The Controller can also control a cable box. If both a DBS receiver and a cable box are used, position the controller so its signal reaches the remote control sensors of both the DBS receiver and cable box.
INITIAL SETTINGS (cont.)
The following procedure is required if you receive DBS channels through a DBS (Direct Broadcast DBS) Receiver . The Controller allows the VCR to automatically switch the DBS Receiver's channels during timer recording.
The VCR can control the DBS Receiver during timer recording using its Controller.
NOTES:
The Controller can automatically change the DBS Receiver channels when the VCR has been programmed using On­Screen Timer Programming (Z pg. 42). Because DBS programming does not use G-CODE; the Controller can not change the DBS Receiver channels during G-C
ODE
Timer Recording. If a cable box is also used it is recommended that you connect the DBS receiver to your VCR's A/V inputs and the cable box to your VCR's antenna input.
Situate And Connect Controller
DBS receiver
Your VCR
Your VCR
Controller
DBS receiver
Transmitter
Connected to ANTENNA IN
CABLE
BOX
Controller (suggested locations)
Connected to VIDEO/ AUDIO IN
About Your DBS Receiver
This VCR has two separate methods to control your DBS Receiver.
The VCR's Wireless Remote Control Unit can control your DBS Receiver. This eliminates the need for a separate DBS Receiver Remote Control Unit.
The VCR's Controller can also control your DBS Receiver. This allows the VCR to change your DBS receiver's channel number during timer recording.
Each method must be set up separately. To set up the VCR's Remote Control unit, refer to page 55. To set up the Controller go to page 19.
SITUATE CONTROLLER
Place the Controller so that the path between its transmitter and the DBS receiver's remote sensor is
1
unobstructed.
ATTACH CONTROLLER
Fasten securely using the supplied adhesive strips.
2
CONNECT DBS RECEIVER TO VCR
The connection method depends on the type of DBS receiver you have.
3
If your DBS receiver has AUDIO and VIDEO OUT connectors . . .
. . . connect them to the AUDIO and VIDEO IN connectors on your VCR; select the correct external input mode as described in step 4, 5, 911 on page
48. Set the VCR to channel "AU" to use the DBS receiver.
If your DBS receiver doesn’t have AUDIO and VIDEO OUT connectors . . .
. . . connect the antenna output connector on the DBS receiver to the ANTENNA IN connector on the rear of your VCR. Set the VCR tuner to the same channel as DBS receiver RF output. (See page 19 also.)
NOTE:
When connecting your DBS receiver refer to its instruction manual.
CONNECT CONTROLLER TO VCR
Connect to the CABLE BOX connector on your VCR.
4
EN 19
MENU
CH
POWER
OK
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
q
POWER
12 45 7
8 0
3 6 9
CH
Set DBS Receiver Output Channel
TURN ON THE VCR
Press POWER.
Set the VCR to the channel (3 or 4 or AU) on which
1
the signals from the DBS receiver are received.
ACCESS MAIN MENU SCREEN
Press MENU as many times as necessary.
2
ACCESS CUSTOM SET SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
3
highlight bar (arrow) to “CUSTOM SET”, then press OK.
ACCESS DBS RECEIVER OUTPUT SCREEN
Press CH 5∞ or PUSH JOG 5∞ to move the
4
highlight bar (arrow) to “DBS RECEIVER OUT­PUT”, then press OK.
MAIN MENU
PROGRAM SET FUNCTION SET TUNER SET
= CUSTOM SET
AUTO PICTURE VIDEO STABILIZER PRESS (5,), THEN (OK) PRESS (MENU) TO END
CUSTOM SET
OVERRIDE
AUTO CLOCK SET LANGUAGE SELECT G-CODE SET-UP
=DBS RECEIVER OUTPUT
DBS RECEIVER BRAND SET
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
MENU
OK
PUSH JOG
SELECT DBS RECEIVER OUTPUT CHANNEL
Your selection depends on how your DBS receiver is
5
connected to your VCR.
If your DBS receiver is connected to your VCR using an RF connection . . .
. . . press CH 5∞ or PUSH JOG 5∞ to move the
highlight bar (arrow) to the channel number representing the DBS receiver's output (3–4).
If your DBS receiver is connected to your VCR’s AUDIO/VIDEO IN connectors . . .
. . . press CH 5∞ or PUSH JOG 5∞ to move the highlight bar (arrow) to “ON LINE”.
DBS RECEIVER OUTPUT
PRESS (5,) TO SELECT
PRESS (MENU) TO END
RETURN TO CUSTOM SET SCREEN
Press MENU.
6
=OFF
ON CH3 ON CH4 ON LINE
20 EN
MENU
CH
OK
NUMBER
12 45
8
7
0
3 6 9
CH
INITIAL SETTINGS (cont.)
Set DBS Receiver Brand
TURN ON DBS RECEIVER
Select a channel other than channel 55, 100 or 205 on your DBS receiver.
1
q
ACCESS DBS RECEIVER BRAND SET SCREEN
At the Custom Set screen, press CH 5∞ or PUSH
2
JOG 5∞ to move the
highlight bar (arrow) to “DBS RECEIVER BRAND SET”, then press OK.
ENTER DBS RECEIVER BRAND
Press the appropriate
NUMBER keys to enter the
3
DBS Receiver Code from the following list, then press OK. The unit is pre-set to code 80 (RCA) when shipped.
CUSTOM SET
OVERRIDE
AUTO CLOCK SET LANGUAGE SELECT G-CODE SET-UP DBS RECEIVER OUTPUT
=DBS RECEIVER BRAND SET
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
DBS RECEIVER BRAND SET
80
PRESS NUMBER KEY (0-9) PRESS (MENU) TO END
THEN (OK)
MENU
OK
PUSH JOG
NOTES:
It is possible that the Controller will not work with all types of DBS receiver.
If your DBS receiver doesn’t respond to the code, you can’t use the Controller to change DBS channels. In this case, make sure to leave the DBS receiver turned on and tuned to the proper channel before the scheduled start of timer recording.
The VCR can only change the DBS channel through the Controller during timer recording.
If your DBS receiver is one that can’t be operated with a remote control (because it has no remote sensor), you can’t use the Controller to change its channels. Make sure to leave the DBS receiver turned on and tuned to the proper channel before the scheduled start of timer recording.
BRAND CODE
RCA (DSS) 80 SONY (DSS) 81 PRIMESTAR 90 ECHOST AR 91
If the DBS receiver's channel changes as follows, setting is complete:
RCA or SONY [ 205 PRIMESTAR [ 55 ECHOSTAR [ 100
After OK is pressed, the program currently received through the DBS receiver will appear for about 10 seconds.
RETURN TO NORMAL SCREEN
Press MENU as many times as necessary.
4
SIMPLE PLAYBACK AND RECORDING
STOP
STOP/EJECT
PLAY
TIME SCAN SHUTTLE
PLAY
Simple
1
Playback
Turn on the TV and select the VCR channel 3 or 4 (or AV mode).
2
q
3 4
EN 21
LOAD A CASSETTE
Make sure the window side is up, the rear label side is facing you and the arrow on the front of the cassette is pointing towards the VCR. Don’t apply too much pressure when inserting.
The VCR’s power comes on automatically.
The counter is automatically reset to "0H 00M 00S".
If the cassette's record safety tab has been removed,
playback begins automatically.
FIND PROGRAM START POINT
If the tape is advanced past the start point, press REW or turn the TIME SCAN SHUTTLE ring to the left. To go forward, press FF or turn the TIME SCAN SHUTTLE ring to the right.
START PLAYBACK
Press PLAY. "AUTO PICTURE" appears on screen (Z pg. 33).
STOP PLAYBACK
Press STOP or STOP/EJECT. Then press STOP/EJECT to remove the cassette.
REW (Rewind)
12 45
8
7
0
3 6 9
FF (Fast-Forward)
Usable cassettes
Full-Size VHS T-30 (ST-30**) T-60 (ST-60**) T-90 T-120 (ST-120**) T-160 (ST-160**) ST-210**
Compact VHS* TC-20 (ST-C20**) TC-30 (ST-C30**) TC-40 (ST-C40**)
* Compact VHS camcorder recordings can be played on
this video recorder. Simply place the recorded cassette into a VHS Cassette Adapter and it can be used just like any full-sized VHS cassette.
**This video recorder can record on regular VHS and
Super VHS cassettes. However, it will record and play back regular VHS signals only. It is not possible to play back Super VHS recordings.
Loading...
+ 47 hidden pages
