WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS UNIT TO
RAIN OR MOISTURE.
NOTES:
• The rating plate and safety caution are on the
bottom and/or the back of the main unit.
• The serial number plate is on the battery pack
mount.
• The rating information and safety caution of the
AC adapter are on its upper and lower sides.
Caution on Replaceable lithium battery
The battery used in this device may present a fire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Replace battery with Panasonic, Sanyo, Sony or
Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
• Dispose of used battery promptly.
• Keep away from children.
• Do not disassemble and do not dispose of in fire.
For USA-California Only
This product contains a CR Coin Cell Lithium
Battery which contains Perchlorate Material
– special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
DO NOT REMOVE COVER (OR BACK).
DO NOT REMOVE COVER (OR BACK).
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
NO USER-SERVICEABLE PARTS INSIDE.
NO USER-SERVICEABLE PARTS INSIDE.
The lightning flash with arrowhead symbol, within an
The lightning flash with arrowhead symbol, within an
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
equilateral triangle, is intended to alert the user to the
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
presence of uninsulated "dangerous voltage" within the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
product's enclosure that may be of sufficient magnitude
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
to constitute a risk of electric shock to persons.
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
The exclamation point within an equilateral triangle is
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
intended to alert the user to the presence of important
intended to alert the user to the presence of important
operating
operating
operating
the literature accompanying the appliance.
the literature accompanying the appliance.
the literature accompanying the appliance.
and maintenance (servicing) instructions in
and maintenance (servicing) instructions in
and maintenance (servicing) instructions in
When the equipment is installed in a cabinet or on
a shelf, make sure that it has sufficient space on all
sides to allow for ventilation (10 cm (3-15/16") or
more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holesare blocked by a
newspaper, or cloth etc. the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
uld be placed on the apparatus.
sho
When discarding batteries, environmental
problems must be considered and the local rules or
laws governing the disposal of these batteries must
be followed strictly.
The apparatusshall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroom or places
with water.
Also do not place a
ny containers filled with water
or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of thisunit.
(If water or liquid is allowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lens directly into the sun. This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There is also a
risk of fire or electric
shock.
CAUTION!
The following notes concern possible physical
damage to the cameraand to the user.
Carrying or holding the camera by the LCD monitor
can result in dropping the unit, or in a malfunction.
Do not use a tripod on unsteady or unlevel surfaces. It
could tip over, causing serious damage to the camera.
CAUTION!
Connecting cables (Audio/Video, etc.) to the
cameraand leaving it on top of the TV is not
recommended, as tripping on the cables will cause
the camera to fall, resulting in damage.
CAUTION:
The mains plug shall remain readily operable.
WARNING:
The battery pack, the camera with battery installed,
and the remote control with battery installed should not be exposed to excessive heat such as direct
sunshine, fire or the like.
2
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use thisapparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sas radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Protect the power cord from being walked on or pinched
9.
particularly at plugs, convenience receptacles, and thepoint where they exit from the apparatus.
10. Only use attachments/accessoriesspecified by the
manufacturer.
11. Use only with the cart,
stand, tripod, bracket,
or table specified by
the manufacturer, or
sold with the apparatus.
When a cart is used,use caution when
moving the cart/
apparatus combination
to avoid injury from tip-over.
12. Unplug this
when unused for long periods of time.
13. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has
does not operate normally, or has been dropped.
apparatus during lightning storms or
been exposed to rain or moisture,
If thissymbol isshown, it is only valid in
the European Union.
ourcessuch
Declaration of Conformity
Model Number : GY-HM100U
Tr ade Name : JVC
Responsible party : JVC AMERICAS CORP.
Address : 1700 Valley Road Wayne, N. J. 07470
Telephone Number : 973-317-5000
This device complies with Part 15 of FCC
Rules. Operation issubject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not approved by
JVC could void the user’s authority to operate
the equipment. This equipment has been
tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates,
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by t
equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures: Reorient or relocate
the receiving antenna. Increase the separation
between the equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/
TV technician for help.
uses, and can radiate
urning the
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
AC adapter
When using the AC adapter in areas other than
the USA
The provided AC adapter features automatic voltage
selection in the AC range from 110 V to 240 V.
USING HOUSEHOLD AC PLUG ADAPTER
In case of connecting the unit’s power cord to
an AC wall outlet other than American National
Standard C73 series type use an AC plug adapter,
called a “Siemens Plug”, asshown.
For this AC plug adapter, consult your neares
JVC dealer.
Plug Adapter
t
3
Getting Started
Main Features
This camcorder enables recording of HD format images as
videos or still pictures on an SD card, and also playback of
these videos or still pictures.
䡵 Supports various HD video recording formats
(1080i, 1080p, and 720p)
Shooting can be performed in different HD recording
modes, thus supporting a wide variety of content
production.
䡵 QuickTime(MOV)/MP4 format for video files
Enables direct recording in the QuickTime file format used
by Apple Inc.’s Final Cut Pro. The recorded clips can be
edited directly using Final Cut Pro. In addition, the support
for MP4 file format enables the video files to be used
widely in different environments.
䡵 SD card recording
This camcorder comes with two SD card slots, and
enables continuous recordingT to two SD cards by
switching automatically between the slots. In addition,
recorded files can also be moved or copied between the
two SD cards. However, video files can only be copied.
T When the slots are switched automatically, it takes a few
seconds for recording to resume. Recording of images
is not possible during switching of slots.
䡵 Supports both video recording and still picture
recording modes
You can select a mode from video recording and still
picture recording. During playback of a file, you can select
a video or still picture from the thumbnail display on the
index screen or date search screen.
䡵 Supports 60 Hz/50 Hz HD signals
䡵 Focus Assist function
Enables easy and accurate focusing during shooting.
䡵 User buttons added
Enables you to switch camera settings instantly to suit the
shooting conditions.
䡵 Time code reader/generator
The built-in time code reader/generator can be used to
record and play back the time code and user’s bit.
䡵 Built-in viewfinder and color LCD display
Displays the status screens, menu screens for settings,
and alarm indications, in addition to the camera image
and playback image.
䡵 Built-in monitor speaker for audio checking
䡵 Recording check function for convenient
recording review
䡵 Camera designed with 3-CCD system for high-
quality picture
䡵 Zebra pattern video level indication
䡵 Full Auto shooting mode
Eliminates the need for troublesome switch operations by
automatically providing a wide range of compatibility with
shooting conditions that change as you move between
indoors and outdoors or between bright and dark
locations.
䡵 Image Stabilizer feature
Reduces blurring of images due to camera shake.
䡵 ND filters provided
䡵 Program AE function
Enables selection of shooting conditions according to the
scenes of your preference.
䡵 White balance adjustment feature
Enables white balance to be adjusted automatically or
manually.
䡵 Built-in color bars (multi-format color bars)
䡵 Slow shutter
Makes it possible to brightly shoot video of dark subjects
with little motion by accumulating the images.
䡵 Three audio input terminals
This camcorder comes with two XLR terminals and one
mini-jack terminal, which can be used as audio input
terminals for the built-in or external microphone.
䡵 Three video output terminals
This camcorder comes with an HDMI terminal, a
component terminal, and an A/V OUT (video/audio
output) terminal, which support a wide variety of TV
monitor types.
䡵 Connection to PCs via USB port
Video or still picture files stored on an SD card can be
retrieved to a PC.
䡵 Saving and loading of setting files
The current menu and camcorder settings can be saved
to an SD card. (Up to four files) In addition, settings files
stored on the SD card can also be loaded onto the
camcorder according to the shooting scene to reproduce
the most suitable settings.
● All rights reserved by JVC. Unauthorized duplication or
reprinting of this manual, in whole or in part, is strictly
prohibited.
● All other product names used in this manual are
trademarks or registered trademarks of their respective
companies. Marks such as ™, 姞 and 姝 have been
omitted in this manual.
● Illustrated designs, specifications and other contents of
this manual are subject to changes for improvement
without prior notice.
Remember that this camcorder is intended for
private consumer use only.
Any commercial use without proper permission
is prohibited. (Even if you record an event such
asashow, performance or exhibition for personal
enjoyment, it is strongly recommended that you
obtain permission beforehand.)
Trademarks
HDMI is a trademark of HDMI
•
Licensing, LLC.
We recommend using the Category 2 HDMI cable
•
(High Speed cable) for viewing in higher image quality.
QuickTime and Final Cut Pro are trademarks of
•
Apple Inc.
Other product and company names included in
•
this instruction manual are trademarks and/or
registered trademarks of their respective holders.
This camcorder comes bundled with the following
accessories.
AC Adapter
AP-V21M
Component Cable
CD-ROM
The CD-ROM provided with this camcorder comes with
[JVC ProHD Clip Manager] and other application software
as well as the user guides.
TFor detail, refer to the user guides for each application
software.
Battery
BN-VF823U
AV C or d
Audio Unit
Battery Charger
AA-VF8KR
Power Cord
⳯2
Remote
Control Unit
USB Cable
Microphone
Attaching the Audio Unit
The audio unit (with handle) is not attached to the camcorder
unit when purchased.
Attach the audio unit according to the following procedure.
Shoe
AUDIO IN Terminal
Cable
Open the cover
SD Cards
This camcorder saves the recorded images and audio sound
on the SD card (sold separately) in the card slot.
Memo :
● If the SD card contains files recorded by devices other than
this camcorder or files that are saved from a PC, the
recordable time may be shorter or data may not be
properly recorded. In addition, the remaining space on the
card may not increase even when files are deleted using a
PC.
Make use of the following SD cards.
Video: SDHC card that supports Class 6 or higher
Still Picture : SD card (256 MB to 2 GB), SDHC card (4 GB
● Panasonic, TOSHIBA, or SanDisk
Using cards other than those specified above may prevent
data from being recorded correctly or result in loss of
data.
(4 GB to 32 GB)
to 32 GB)
1 . Attach the audio unit by sliding it all the way into
the shoe on the top of the camcorder.
2 . Turn t h e screw on the audio unit clockwise to fasten
it fully and securely to the camcorder.
TIf the audio unit is not fully and securely tightened, it will be
loose and may drop off from the camcorder during use.
3 . Connect the audio unit cable to the AUDIO IN
terminal of the camcorder.
Memo :
● The clamp on the audio unit is for fixing the microphone
cable and cannot be used to fix the audio unit cable.
(A Page 18)
7
Getting Started
Precautions for Proper Use
䡵 Allowable ambient temperature and humidity
Be sure to use this device within the allowable temperature range
of 0°C to 40°C and a relative humidity of 35 % to 80 %. Using this
device at a temperature or humidity outside the allowable ranges
could result not only in malfunction but the impact on the CCD
elements could be serious as small white spots may be generated.
䡵 Strong electromagnetic waves or magnetism
Noise may appear in the picture or audio and/or the colors may
be incorrect if the camera is used near a radio or television
transmitting antenna, in places where strong magnetic fields are
generated by transformers, motors, etc., or near devices emitting
radio waves, such as transceivers or cellular phones.
䡵 Use of wireless microphone near the camera
When a wireless microphone or wireless microphone tuner is used
near the camera during recording, the tuner could pick up noise.
䡵 Avoid using or placing this device in the
following places.
● Places subject to extreme heat or cold
● Places with excessive dirt or dust
● Places with high humidity or moisture
● Places subject to smoke or vapor such as near a cooking stove
● Places subject to strong vibrations or unstable surfaces
● In a parked car under direct sunlight or near a heater for long
hours
● Places subject to radiation or X-rays, or where corrosive gases
occur
䡵
Protect this device from being splashed with water.
(Especially when shooting in the rain)
䡵 Protect this device from getting wet when
shooting on a beach. In addition, salt and sand
may adhere to the camera body. Be sure to clean
the camera after use.
䡵 Protect this device against penetration of dust
when using it in a place subject to sandy dust.
䡵 Do not expose this device and the remote
control to excessive heat, such as direct
sunlight or fire. The built-in battery may explode
if it gets heated up.
䡵 Optical performance of lens
Due to the optical performance of the lens, color divergence
phenomena (magnification chromatic aberration) may occur. This
is not a camera malfunction.
䡵
Noise may appear in the image when switching
between the playback picture and the EE picture.
䡵 If placed on its side, heat release efficiency will
deteriorate.
䡵 Precautions for transportation
● When carrying the camcorder, be sure to hold the carrying
handle. Holding the lens or viewfinder may result in damage.
● Do not drop or hit this device against a hard object.
䡵 Do not insert objects other than the memory
card into the card slot.
䡵 Do not leave the card slot cover open for a long
period of time. Dirt entering the interior of the
slot may cause it to malfunction.
䡵 Do not turn off the [POWER] switch or remove
the power cord during recording or playback.
䡵 The camera may not show stable pictures for a
few seconds immediately after the power is
turned on, but this is not a malfunction.
䡵 Do not turn off the [POWER] switch when the
camera reboots due to the following operations.
● Rebooting when the video/still picture mode is switched while
the [SYSTEM SELECT] menu is set to [720-**]
● Rebooting when the [SYSTEM SELECT] menu is set
● Rebooting after a setting file stored on the SD card is loaded
● Rebooting when the [SYSTEM SELECT] menu is changed
with the default value settings
䡵 Use the supplied AC adapter as the power
supply. Do not use the supplied AC adapter on other devices.
䡵 When the connectors that come with connector
covers are not in use, put on the covers to
prevent damage to the connectors.
䡵 When this device is not in use, be sure to set the
[POWER] switch to AOFFB in order to reduce
power consumption.
䡵 Wipe the external cabinet of the device with a
soft cloth. Do not wipe the body with benzene or
thinner. Doing so may cause the surface to melt
or turn cloudy. When it is extremely dirty, soak
the cloth in a solution of neutral detergent, wipe
the body with it, and then use a clean cloth to
remove the detergent.
LCD Screen and Viewfinder
䡵 The LCD and viewfinder screens are
manufactured using high-precision technology.
Black spots may appear on the LCD and
viewfinder screens, or red, blue, and/or white
spots may not turn off. However, this is not a
malfunction and these spots are not recorded
on the SD card.
䡵 If you use this device continuously for a long
period of time, the characters displayed in the
viewfinder may temporarily remain on the
screen. This is not recorded on the SD card.
They will not appear after you turn the power off
and then on again.
䡵 If you use this device in a cold place, the images
may appear to lag on the screen, but this is not a
malfunction. This is not recorded on the SD
card.
䡵 Do not press against the surface with force or
subject it to strong impact. Doing so may
damage or break the screens.
Handling of SD Cards
䡵 The access lamp blinks when data on the SD
card is being accessed (recording, playback,
formatting, etc.). Do not remove the SD card,
turn off the power, or remove the battery/AC
adapter during access.
8
䡵 If the SD card is removed during access, a
h
recovery request message may be displayed
repeatedly. In this case, switch to the EE screen
and format the SD card. All data will be deleted.
䡵 Do not use or store this device in a place that is
subject to static electricity or electrical noise.
䡵 Inserting the SD card incorrectly may result in
damage of this device or the SD card.
䡵 We are not liable for any accidental loss of data
stored on the SD card. (Please back up any
important data.)
䡵 Make use of the SD card within the prescribed
conditions of use.
Do not use the SD card in places that are subject to direct
sunlight, high humidity or corrosion, places near thermal
equipment, or in a car under the sun with the doors and windows
closed.
䡵 Do not bend or drop the SD card, or subject it to
strong impact or vibration.
䡵 Do not splash the SD card with water.
䡵 Do not place the SD card near locations that are
exposed to strong magnetic fields or radio
waves.
䡵 Do not touch the metal parts.
䡵 If you want to wipe out all information by
completely erasing the data, we recommend
either using commercially available software
that is specially designed for that purpose, or by
physically destroying the SD card with a
hammer, etc. When formatting or erasing data
using the camera, only the file administration
information is changed. The data is not
completely erased from the SD card.
Rechargeable Battery
䡵 Be sure to use only JVC batteries.
We do not guarantee the safety and performance
of this device if a battery other than a JVC
product is used.
䡵 The battery is not charged when purchased.
䡵 When using the battery in a low temperature
environment (10°C or below), the operating time
may be shortened, or it may not function
properly. When using the device outdoors in the
winter weather, warm the battery, such as by
placing it in the pocket, before attaching it.
䡵 Do not expose the battery to excessive heat,
such as direct sunlight or fire.
䡵 If the battery is not to be used for a long time,
A
use up the charge completely and detach it from the
camera to prevent deterioration. (Wait for the battery
to run out by itself such as through continuous
shooting or playback.)
B charge the battery once every half a year, and store it
again after using up the charge.
䡵 Attach the battery cap after removing the
battery, and store it in a dry place between 15°C
to 25°C.
Battery
Battery Cap
䡵 ATTENTION:
The product you have purchased is powered by
a rechargeable battery that is recyclable.
Please call 1-800-8-BATTERY for information on
how to recycle this battery.
Characteristic CCD Phenomena
Smear and blooming
When shooting an extremely bright light source, vertical
streaking (called "smear") may occur or expansion of light
(called "blooming") may appear around it. This is a
characteristic of the CCD and not a malfunction.
Smear
Vertical pale streaking appearing at hig
luminous object
High luminous object
(Electric light, sunlight, etc.)
Blooming
Monitor Screen
Moire or aliasing
Stripes, lines or other fine patterns may appear jagged
when they are shot.
White dots
High temperatures can cause CCD sensor pixels to
produce white dots in the image. This condition is
conspicuous especially when gain is applied.
This is a characteristic of the charged-coupled device
(CCD). As far as possible, use this device under conditions
where the temperature of this device does not increase.
Blurring in highlight
Characteristic Lens Phenomena
When shooting an extremely bright light source, ghosting
may occur. This is a characteristic of the lens and not a
malfunction.
Copyright
Any recordings made on this camcorder that are played back
for profit or public preview may infringe on the rights of the
owner of the recordings.
Do not use the recordings for purpose other than personal
enjoyment without prior consent from the owner.
9
Getting Started
Names of Parts and
Functions
FrontTop
Qdcb
AWB
SR
TUVWXY
Front
A Tally lamp (A Page 56)
B Tally lamp (A Page 56)
C Remote control sensor (A Page 18)
D [AWB] Auto White Balance button (A Page 35)
For adjusting the white balance.
E Lens/Lens cover (A Page 20)
Za
TW
To p
F Shoe
For mounting separately sold accessories.
G Eyepiece focus lever
Lever for adjusting the visibility. It is found on the under
side.
H Eyepiece
I Viewfinder (A Page 22)
J [SNAPSHOT] Snapshot button (A Page 29)
Button for starting the recording of still images.
K Zoom lever (A Page 30)
For zooming to the Tele (T) or Wide (W) end.
L Microphone holder (A Page 18)
For mounting an external microphone.
M Knob
Knob for locking the microphone in place.
N External microphone (A Page 18)
SNAP
SHOT
10
LCD Side
CH-2 INPUT
INPUT1
INPUT2
AUDIO INPUT
- LINE -
- MIC MIC+48V
INPUT1
INPUT2
hij
AUTO MANUAL
AUDIO
SELECT
AUTO MANUAL
2
3
4
CH-1
5
0
1
2
CH-2
3
g
Q
USER1
USER2
ND
FILTER
ON
FOCUS
R
S
A Built-in microphone (A Page 40)
B Lens cover switch (A Page 20)
C Manual ring (A Page 30)
D [ND FILTER] switch (A Page 32)
Reduces the amount of incident light to 1/10.
E [GAIN] switch (A Page 37)
For selecting one of the three sensitivity levels.
F [WHT.BAL.] White balance selection switch (A Page 35)
For selecting one of the three types of white balance.
G [A/B] Card slot A/B selection button (A Page 23)
H Card slot A access lamp (A Page 23)
I Card slot A (A Page 23)
Slot for SD cards.
Open the door to insert the SD card.
J Card slot B (A Page 23)
Slot for SD cards.
Open the door to insert the SD card.
K Card slot B access lamp (A Page 23)
L [FULL AUTO] Full Auto mode selection button
(A Page 25)
For setting the shooting mode to the Full Auto or Manual
mode.
M [AF/MF] Focusing mode selection button (A Page 26)
For setting the focusing mode to the Auto or Manual
mode.
N [FOCUS/ZOOM] ring switch
For setting the function of the manual ring to focus
(A Page 31) or zoom adjustment (A Page 30).
ZOOM
OFF
AF/MF FULL AUTO
GAIN
WHT.BAL A / B
L-
B-
M-
A-
H-
PRST-
TUVW XYZa
f
e
d
c
b
AB
O [USER2] User 2 button (A Page 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
P [USER1] User 1 button (A Page 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
adjustment knob (A Page 40)
For adjusting the audio input level for the CH-1 or CH-2
audio.
R [CH-1/CH-2 AUDIO SELECT] CH-1/CH-2 audio selection
switch (A Page 40)
For setting the method of adjusting the audio recording
level for the CH-1 or CH-2 audio to the Auto or Manual
mode.
S [INPUT1/INPUT2 AUDIO INPUT] INPUT1/INPUT2 audio
input signal selection switch (A Page 40)
For selecting the input signal for the INPUT1 or INPUT2
terminal.
T [CH-2 INPUT] CH-2 audio input terminal selection switch
(A Page 40)
For selecting whether to input audio signals to CH-2
audio from the INPUT1 or INPUT2 terminal.
Memo :
● INPUT1 terminal, INPUT2 terminal: R, S on Page 13
11
Getting Started
Names of Parts and
Functions (continued)
LCD Side (LCD Cover)
AUTO MANUAL
2
3
4
CH-1
CH-2 INPUT
5
AUDIO INPUT
- LINE -
AUDIO
INPUT1
- MIC -
SELECT
INPUT2
MIC+48V
0
1
2
CH-2
INPUT1 INPUT2
3
AUTO MANUAL
USER1
USER2
ND
FILTER
ON
FOCUS
ZOOM
OFF
AF/MF FULL AUTO
GAIN
WHT.BAL A / B
L-
B-
M-
A-
H-
PRST-
AB
When the LCD cover is opened
CAM /MEDIA
USER3
Q.REVIEW
MENU
A / V OUT
SRQ
COMPONENT
Bottom
DISPLAY
OUT
d
UVWXY
cb
T
INDEX
T
W
REC
Z
a
P
R
O
G
R
A
M
A
E
A LCD cover
B [COMPONENT OUT] Component output terminal
(A Page 49)
C [A/V OUT] Audio/Video output terminal (A Page 49)
D [Q.REVIEW] Quick Review button (A Page 27)
For checking the video image immediately before
shooting starts.
E [MENU] Menu button (A Page 57)
Displays the menu screen. Press this button again to exit
the menu screen.
F Built-in speaker (A Page 47)
G [CAM/MEDIA] Camera shooting/media playback
selection button (A Page 25)
For setting this camcorder to the Camera Shooting or
Media Playback mode.
H [USER3] User 3 button (A Page 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
I [DISPLAY] Display button
For switching the displays on the LCD screen and
viewfinder. (A Page 15)
When in the playback mode, pressing this button displays
the file information.
(A Page 46)
J [REC] Video recording button (A Page 27)
Button for starting or stopping video recording.
K LCD screen (A Page 22)
L [INDEX] Index button
Displays the remaining space on the SD card
(A Page 27) and the remaining battery power
(A Page 20).
When in the playback mode, pressing this button
switches between the playback index and date search
screens. (A Page 45)
M Set Lever
When in the shooting mode, this lever is used for
Program AE selection and as the zooming lever.
(A Page 32)
When in the playback mode, this lever is used for
playback file selection and playback control. (A Page 43)
When the menu screen is displayed, this lever is used for
menu setting. (A Page 57)
Bottom
N Tripod mounting holes (A Page 18)
● To prevent the camcorder from falling, attach securely
using the rotation prevention hole.
● Use screws with screw length 5 mm and below.
12
Q
RearGrip Belt Side
c
hi
b
a
REC
Z
IRIS
SHUTTER
OPEN
R
AE
±
CLOSE
PUSH
ADJ./ VOL.
TUVWXY
S
ACCESS
DC
Rear
A [IRIS] Aperture button (A Page 38)
Press this button to set the aperture manually.
B [SHUTTER] Shutter Speed button (A Page 37)
Press this button to set the shutter speed manually.
C [AE±] Exposure button (A Page 33)
Press this button to set the exposure manually.
D [ADJ./VOL.] Adjustment/Volume knob
ADJ. : For adjusting the aperture (A Page 38), shutter
speed (A Page 37), and exposure (A Page 33).
VOL. : Also for adjusting the volume of a headphone and
the built-in speaker. (A Page 41)
E Battery mount (A Page 19)
F [HDMI] terminal (A Page 49)
G [USB (2) ] terminal (A Page 54)
H [DC] input terminal (A Page 19)
I Battery lock release button (A Page 19)
J [REC] Video recording button (A Page 27)
For starting or stopping video recording.
K Still picture indicating lamp (A Page 25)
Lights up during still picture shooting or still picture
playback mode.
L Video indicating lamp (A Page 25)
Lights up during video shooting or video playback mode.
M [ACCESS] Charging/Access indicating lamp
Lights up or blinks during recording or playback.
Blinks when the battery is charging. (Light goes out when
charging is complete.)
MIC
efg
d
e
Grip Belt Side
N [POWER/MODE] Power/Operating mode switch
POWER : Turns the power On/Off. (A Page 20)
MODE: Switches between the video mode and still
picture mode. (A Page 25)
O Grip belt mount (A Page 18)
P [HEADPHONE ()] Headphone jack (A Page 41)
Q [MIC] Microphone input terminal (A Page 40)
For connecting a mini-jack microphone.
● The MIC terminal provides a 4 V power supply to the
microphone.
R [INPUT1] Audio input 1 terminal (A Page 40)
For connecting an XLR microphone.
S [INPUT2] Audio input 2 terminal (A Page 40)
For connecting an XLR microphone.
13
Getting Started
T
Names of Remote Control
Parts and Functions
Q
R
S
SET
U
V
W
a
Z
Y
X
b
f
e
SET
c
d
A [STA RT / STOP] button
Button for starting or stopping video recording.
B [ZOOM] button
Press (T) to zoom in.
Press (W) to zoom out.
Playback zoom can be used when a video is paused or
during playback of still images.
C [S.SHOT] SNAPSHOT button
Button for starting the recording of still images.
D [–] button
Moves to the previous date when the playback index
screen is displayed.
E [N] Reverse button
Returns to the beginning of the file during playback.
F [PLAYLIST] button
This function is not available on this camcorder.
G [DISP] DISPLAY button
For switching the displays on the LCD screen and
viewfinder.
H [INDEX] button
Displays the remaining space on the SD card and the
remaining battery power.
When in the playback mode, pressing this button
switches between the playback index and date search
screens.
I [O] Forward button
Advances to the next file during playback.
J [+] button
Moves to the next date when the playback index screen is
displayed.
K [INFO] button
When in the playback mode, pressing this button displays
the file information.
L [ ] Left button
Moves the cursor to the left on the menu screen or
playback index screen.
It is also used to perform reverse search during playback.
M [ ] Down button
Moves the cursor downward on the menu screen or
playback index screen.
N [ ] Right button
Moves the cursor to the right on the menu screen or
playback index screen.
It is also used to perform forward search during playback.
O [ ] Up button
Moves the cursor upward on the menu screen or
playback index screen.
P [SET] button
For confirming a selected item on the menu screen or
playback index screen.
It is also used to start or stop playback when in the
playback mode.
The Left, Right, Up, and Down buttons can be used to shift
the zoom position when a still image is enlarged using the
ZOOM button.
Memo :
● To use the remote control, set [REMOTE] in the [CAMERA
SETTINGS] menu to [ON]. (A Page 66)
14
Indications on the LCD
䡵 When in the video playback or still picture
playback mode
Screen and in the Viewfinder
The status screen can be displayed on the LCD screen or
viewfinder.
Status screen is a screen display for identifying the current
settings.
Displaying the Status Screen
䡵 When in the video shooting or still picture
shooting mode
Pressing the DISPLAY button each time toggles the display
as follows:
“Main information for camera shooting” B “Full display” B
“Simple display”
DISPLAY
Main information for camera shooting
±
0
F5.6
1/4000
18dB
[
A
1h56m
[
B
1h56m
00:00:00:00
]
]
Select the details to display using the settings in the [ON-
SCREEN DISPLAY] menu.
ASetting Menu ScreensB: (A Page 57)
OFF: No display.
DISPLAY ALL: Displays all icons and the date and time.
DISPLAY DATE
ONLY: Displays only the date and time.
DISPLAY DATE
5 SEC: Displays only the date and time for 5
seconds in the following cases:
● When playback starts
● When a file is changed during playback
● When the menu screen is closed
During video playback, pressing the DISPLAY button each
time toggles the display as follows:
[DISPLAY DATE ONLY]B[DISPLAY ALL]B[OFF]
DISPLAY
DISPLAY DATE ONLY
CH1
CH2
Full display
±
0
F5.6
1/4000
18dB
ND
3200K
SPORT
CH1
CH2
Simple display
10x
00:00:00:00
DISPLAY
[
A
1h56m
[
B
1h56m
4:50 PM
NOV.1.2009
DISPLAY
]
]
Appears when the remaining
time falls below 2 minutes
The diagrams above are displays in the video shooting
mode.
DISPLAY button
CAM / MEDIA
USERS
DISPLAY
Q.REVIEW MENU
COMPONENT
A / V OUT
OUT
4:50 PM
NOV.1.2009
DISPLAY ALL
OFF
DISPLAY
+
A
00:00:00:00
NOV.1.2009
1
005/600
4:50 PM
DISPLAY
Memo :
● When in the still mode or when the index screen is
displayed, pressing the DISPLAY button displays the file
information.
● To display this screen on the monitor that is connected to
the video output terminal of this camcorder, set [DISPLAY
ON TV] in the [CONNECTION SETTINGS] menu to [ON].
15
c
T
V
Y
Q
V
Getting Started
Indications on the LCD
Screen and in the
Viewfinder (continued)
Items Displayed During Video and Still
Picture Shooting
Q
R
S
U
W
X
Z
A Shooting Mode
B Focusing Mode
C Exposure
D Aperture
E Shutter Speed
F ND Filter
G White Balance Color Temperature
H Program AE
I Image Stabilizer [OFF]
J LCD Screen Backlight
K Microphone Input Level
L Date/Time
M Battery
N Focus Assist
O Speaker/Headphone Volume (displayed during volume
P Zoom
±
0
F5.6
10x
1/4000
ND
3200K
SPORT
CH1
CH2
A :Full Auto Shooting
M :Manual Shooting
AF : Auto Focus
MF : Manual Focus
L :Fixed
Displayed when the ND filter switch is set to AONB.
PORT : Portrait
SPORT : Sports
SNOW : Snow
SPOT.L : Spotlight
TWIL. : Night
Displayed when [OIS] in the [CAMERA SETTINGS] menu
is set to [OFF].
Displayed when [MONITOR BACKLIGHT] in the
[DISPLAY SETTINGS] menu is set to [ON].
Blinks in red when the battery runs out.
Displayed when [FOCUS ASSIST] in the [CAMERA
PROCESS] menu is set to [ON].
adjustment)
hi
A
B
4:50
NOV.1.2009
PM
g
f
e
d
b
a
Q Card Slot
: The selected card slot is indicated by the card icon
as shown on the left.
R Automatic Slot Switch
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
S Tele Macro
Displayed when [TELE MACRO] in the [CAMERA
PROCESS] menu is set to [ON].
Items Displayed During Video Shooting
Only
Y
Z
X
[
[
1h56m
1h56m
00:00:00:00
]
]
R
18dB
b
a
S
A Video Mode
B Sensitivity
C Wind Noise
Displayed when the [WIND CUT] menu is set to [ON].
D Simultaneous Still Picture Recording
E Continuous Clip Recording
Displayed when the [CLIP CONTINUOUS REC] menu is
set to [ON].
F Mode Indicator
RREC : Recording
RW: Record Standby mode (Record Pause mode)
G Time Code or User’s Bit
TC : Time Code
UB : User’s Bit
The framing mode display for the time code is as follows:
00:00:00:00
H Remaining Time on the SD Card
I Video Picture Quality
SP:Standard
HQ : High
J Frame Rate
K Vertical Resolution
L Horizontal Resolution
The color of the icons in I, J, K and L changes
according to the settings in the [FILE FORMAT] menu.
When set to [QuickTime file format] : Displays in blue.
When set to [MP4 file format]: Displays in orange.
Colon (:) for non-drop frames
Dot (.) for drop frames
W
U
T
16
Items Displayed During Still Picture
S
T
Q
T
Q
VW
Shooting Only
V
W
X
Q
R
A Still Picture Mode
B Focus Icon
Blinks in yellow: Focusing in progress
Lights in green: Focusing completed
C Self-Timer
: 10-second self-timer
: 2-second self-timer
D Still Picture Recording
E Shutter Mode
: Continuous Shooting
: Bracket Shooting
F Remaining Number of Shots on the SD Card
G Still Picture Quality
FINE : High
STD : Standard
H Still Picture Size
[
9999
[
9999
11010
The framing mode display for the time code is as follows:
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
J Video Picture Quality
SP:Standard
HQ : High
K Frame Rate
L Vertical Resolution
M Horizontal Resolution
The color of the icons in J, K, L and M changes
according to the settings in the [FILE FORMAT] menu.
When set to [QuickTime file format] : Displays in blue.
When set to [MP4 file format]: Displays in orange.
Colon (:) for non-drop frames
Dot (.) for drop frames
Items Displayed During Still Picture
Playback
Items Displayed During Video Playback
cb
A
00:00:00:00
A Video Mode
B Date/Time
C Battery
Blinks in red when the battery runs out.
D Speaker/Headphone Volume (displayed during volume
adjustment)
E Time Code or User’s Bit
TC: Time Code
UB: User’s Bit
005/600
4:50 PM
NOV.1.2009
WXYZa
+
1
V
U
S
R
101-0098
4:50 PM
NOV.1.2009
A Still Picture Mode
B Date/Time
C Battery
Blinks in red when the battery runs out.
D Slideshow (Blinks during playback)
E Current File’s Folder Number and File Number
F Card Slot
G Automatic Slot Switch
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
U
T
S
R
17
Preparations
Settings and Adjustments
Before Use
Adjusting the Grip Belt
Open the pad and adjust the position of the grip belt accordingly.
Caution :
● If the grip is loose, the camcorder may fall off resulting in
injuries or malfunction.
● Parents should take extra care when your child is using the
camcorder.
Attaching an External Microphone
You can attach a microphone to the microphone holder.
The supplied microphone is a phantom microphone.
1 . Turn the knob on the microphone holder
anticlockwise to loosen it and open the microphone
holder.
2 . Place the microphone in the microphone holder.
3 . Turn the knob on the microphone holder clockwise
to secure the microphone.
4 . Connect the microphone to the INPUT1/INPUT2
audio input terminal, or the MIC terminal according to
the type of microphone cable terminal you are using.
INPUT1/INPUT2 Terminal: XLR Terminal
MIC Terminal: Mini-jack Terminal (stereo)
5 . Attach the microphone cable to the clamp.
6 . Specify the audio input settings correctly.
(A Page 40)
1.3. Knob
2. Microphone
Setting up the Remote Control
The remote control comes supplied with batteries when you
purchase this product.
To start using, pull out the insulation sheet.
Insulation Sheet
AWB
Remote Control Sensor
Memo :
● To use the remote control, set [REMOTE] in the [CAMERA
SETTINGS] menu to [ON].
● Point the front end of the remote control toward the sensor.
Use the remote control within a distance of 5 meters from
the camcorder. The camcorder may not respond to the
remote control operations at some angles.
䡵 Replacing batteries
1 . Press the lock tab, and pull out the battery holder.
2 . Replace the button battery (CR2025).
Lock Tab
5. Clamp
Microphone Holder
4. INPUT1/
INPUT2 Terminals
IO IN
UD
A
N
PE
O
AUDIO IN
Terminal
4. MIC Terminal
Memo :
● When the audio unit cable is connected to the AUDIO IN
terminal of the camcorder, the MIC terminal is disabled.
Attaching the Tripod
To prevent the camcorder from falling off, which may result in
injuries or damages, read the instruction manual of the tripod
to be used and make sure that it is securely attached.
(A Page 12)
Caution :
● Use the tripod on a stable surface.
18
Button Battery
Removing the Hood
Charging the Battery with this Camcorder
Remove the hood when attaching a filter (with external
diameter 50 mm and below), teleconverter or wide converter
to the front of the lens.
䡵 Turn the hood in an anti-clockwise direction to
remove it.
Hood
Charging the Battery
There are two ways to charge the battery.
䡵 Charging with the supplied battery charger.
䡵 Charging with this camcorder.
Charging the Battery with the Supplied
Charger
1 . Connect the battery charger to a power outlet using
the provided power cord.
2 . Attach the supplied battery to the battery charger
by pressing and sliding it in the direction of the
arrow.
● When battery charging starts, the indicating lamp
blinks.
● When charging is complete, the indicating lamp lights
up.
3 . Remove the battery by sliding it in the opposite
direction after charging is complete.
1. Turn off the power of the camcorder.
2 . Attach the supplied battery.
With the battery mark (D) on the left, insert it into the
camcorder, and slide it to the left.
3 . Connect the AC adapter that is provided with the
camcorder.
Connect the DC cable to the DC terminal, and the AC
adapter to a power outlet using the provided power cord.
● When battery charging starts, the access indicating
lamp blinks.
● When charging is complete, the access indicating lamp
goes out.
Battery Lock
Release Button
Battery
AC Adapter
Charging time and continuous recording time (approximate)
Battery
BN-VF815UApprox. 2 hrs 40
BN-VF823U
(Provided)
Access Indicating Lamp
DC Terminal
Power Cord
Charging Time
mins
Approx. 3 hrs 40
mins
N
I
O
I
D
AU
OPEN
MIC
To Power Outlet
Continuous
Recording Time
Approx. 1 hr 25
mins
Approx. 2 hrs 10
mins
To Power Outlet
Power Cord
Battery
Charger
Battery
Indicating Lamp
● The above are the approximate charging times when
used under an ambient temperature range of 10°C to
35°C.
● A longer charging time may be required if the battery has
been left unused for a long time.
● Recording time may differ depending on the age of the
battery, charging condition, and operating environment.
● Recording time is shortened in cold environments.
● Recording time is shortened when the zoom lens and
LCD screen are frequently used.
䡵 Removing the battery
1 . Turn off the power of the camcorder.
2 . Press the battery lock release button and slide the
battery to the right.
19
Preparations
Settings and Adjustments
Before Use (continued)
Checking the Remaining Battery Power
Preparation: Attach the battery.
1 . Press INDEX.
● The remaining battery power and recordable time are
displayed for about 3 seconds.
INDEX
To display the information for about 15 seconds, press
INDEX for 2 seconds or longer.
BATTERY CONDITION
MAX TIME
min
Turning On the Power
Preparation: Attach a charged battery or connect the AC
adapter.
1 . Set the POWER/MODE switch to ON.
POWER/MODE Switch
MIC
●The camcorder turns on in the video shooting mode.
䡵 Turning off the power
1 . Set the POWER/MODE switch to OFF.
䡵 Auto Power Off feature
When [AUTO POWER OFF] in the [CAMERA SETTINGS]
menu is set to [ON], the power turns off automatically when it
is not operated for 5 minutes or longer.
INDEX
INDEX
INDEX
T
P
R
O
G
R
A
M
A
E
W
REC
IRIS
SHUTTER
AE
±
PUSH
ADJ./ VOL.
REC
DC
Memo :
● The recordable time display should only be used as a
guide.
It is displayed in units of 10 minutes.
● The recordable time shown on the LCD screen may differ
from that shown on the viewfinder.
䡵 When the power is on
1 . Video shooting mode: Press INDEX three times.
Still picture shooting mode: Press INDEX once.
2 . Press INDEX to clear the display.
Memo :
● When video shooting is in progress, the information does
not appear.
● When the AC adapter is in use, the information does not
appear.
Lens Cover
Before shooting, open the lens cover.
When this camcorder is not in use, close the lens cover to
protect the lens.
䡵 Use the lens cover switch to open or close the lens cover.
Memo :
● Do not press against the lens cover with force. Doing so
may damage the lens or the cover.
USER1
USER2
ND
FILTER
ON
FOCUS
ZOOM
OFF
AF/MF FULL AUTO
GAIN
WHT.BAL A / B
L-
B-
M-
A-
PRST-
H-
Lens Cover Switch
AB
20
Setting the Date
1 . Turn on the power.
2 . Press MENU.
MENU
3 . Select the [DISPLAY SETTINGS] menu.
Push the Set Lever up or down to select, then press the
center.
4 . Select [CLOCK ADJUST].
Push the Set Lever up or down to select, then press the
center.
5 . Set the date and time.
Push the Set Lever up or down to change the setting value.
Push the Set Lever to the left or right to jump to the next digit.
Press the center of the Set Lever to confirm your selection.
Setting the Language
The following are steps to change the display language.
1 . Turn on the power.
2 . Press MENU.
MENU
3 . Select the [DISPLAY SETTINGS] menu.
Push the Set Lever up or down to select, then press the
center.
4 . Select [LANGUAGE].
Push the Set Lever up or down to select, then press the
center.
5 . Set the desired language.
Push the Set Lever up or down to select.
Press the center of the Set Lever to confirm your selection.
DISPLAY SETTINGS
CLOCK ADJUST
DATETIME
NOV1011AM35
SELECTSET
2009
MENU
STOP
䡵 To return to the previous screen, push the Set Lever to the
left.
䡵 To close the menu screen, press MENU.
Memo :
● If the date and time are not set, a ASET DATE/TIME!B
message will appear every time you turn on the power.
● You can select the display style of the date and time using
the [DATE DISPLAY STYLE] item in the [DISPLAY SETTINGS] menu. (A Page 65)
日本語
ENGLISH
FRANÇAIS
DEUTSCH
SET MENU QUITSELECT
䡵 To return to the previous screen, push the Set Lever to the
left.
䡵 To close the menu screen, press MENU.
DisplayLanguage
Japanese
English
French
German
Spanish
Italian
Russian
Simplied Chinese
Assigning Functions to the USER Buttons
This camcorder comes with three USER buttons. A specific
function can be assigned to each USER button according to
your preference.
Set Lever
INDEX
T
P
R
O
G
R
A
M
A
E
W
REC
DISPLAY
MENU
USERS
Q.REVIEW MENU
CAM / MEDIA
IRIS
SHUTTER
AE
AUTO MANUAL
2
3
4
CH-1
5
AUDIO INPUT
CH-2 INPUT
- LINE -
AUDIO
INPUT1
- MIC -
SELECT
INPUT2
MIC+48V
0
1
2
INPUT1
INPUT2
CH-2
3
AUTO MANUAL
±
PUSH
ADJ./ VOL.
REC
USER1
USER2
ND
FILTER
ON
FOCUS
DC
ZOOM
OFF
AF/MF FULL AUTO
WHT.BAL A / B
GAIN
L-
B-
M-
A-
H-
PRST-
AB
COMPONENT
CAM / MEDIA
USERS
DISPLAY
Q.REVIEW MENU
OUT
A / V OUT
USER1 USER2
USER3
CAM / MEDIA
USER3
DISPLAY
Q.REVIEW MENU
To do so, make use of [USER1], [USER2], and [USER3] in
the [CAMERA SETTINGS] menu. (A Page 65)
21
Preparations
Settings and Adjustments
Before Use (continued)
Viewing the Viewfinder/LCD Screen
You can monitor video images on this camcorder using the
viewfinder, LCD screen, or both.
䡵 Viewing with the viewfinder
1 . Pull out the viewfinder.
2 . Incline the viewfinder vertically to a position that
enables easy viewing.
3 . Turn the eyepiece focus lever to adjust the focus.
䡵 Viewing with the LCD screen
1 . Open the LCD cover.
䡵 Adjusting the brightness of the viewfinder/LCD
screen
When a screen is displayed on the viewfinder, performing
the following steps adjusts the brightness of the viewfinder.
When a screen is displayed on the LCD, the brightness of
the LCD is adjusted.
When a screen is displayed on both the viewfinder and
LCD, only the brightness of the viewfinder is adjusted.
Select [MONITOR BRIGHT] in the [DISPLAY SETTINGS]
menu. (A Page 65)
A slide bar for adjusting the screen brightness appears.
1 . Push the Set Lever to the left or right.
● Doing so moves the slide bar and changes the
brightness of the screen.
2 . Press the center of the Set Lever.
2 . Incline the LCD cover to a position that enables
easy viewing.
180 Degrees
Rotation
ON
ON
Relationship between the viewfinder and LCD screen
displays
VF StatusLCD StatusVideo Output
OFFOFFVF
ONOFFVF
OFFONLCD, VF (T2)
ONONIn accordance with the
ONON (180 degrees
rotation)
T1 In accordance with [PRIORITY SETTING] in the [CAMERA
SETTINGS] menu. (A Page 66)
T2 When [PRIORITY SETTING] is set to [ALWAYS-ON
VIEWFINDER]
Eyepiece
Focus Lever
menu settings (T1)
VF and LCD
0
䡵 Setting the brightness of the LCD screen backlight
Select [MONITOR BACKLIGHT] in the [DISPLAY
SETTINGS] menu. (A Page 65)
Memo :
● When the HDMI, COMPONENT OUT or A/V OUT terminal
is connected, video images will not appear on the
viewfinder.
22
Inserting an SD Card
This camcorder comes with two SD card slots.
(Slot A and Slot B)
䡵 SD cards to use
● See ASD CardsB on Page 7.
● SDXC cards are not supported.
A/B
Preparation: Turn off the power.
Notched Corner
Door
Automatic Slot Switch
Video mode:
Remaining time
Still picture mode:
Remaining number of shots
䡵 Removing the SD card
Display of selected slot
with an SD card icon
during shooting mode
[
A
[
B
5h3 6m
5h3 6m
]
]
1 . Open the door.
2 . Insert an SD card with the notched corner first.
3 . Close the door.
䡵 Selecting a card slot
Press the A/B button.
● Doing so switches between Slot A and Slot B.
● When an SD card is inserted, the access lamp of the
selected slot lights up.
● When data in the SD card is being accessed, the
access lamp blinks.
䡵 Switching between Slot A and Slot B
automatically
Set [SLOT AUTO SWITCHING] in the [CAMERA SETTINGS]
menu to [ON]. (A Page 65)
● When the space on an SD card runs out during
recording in the shooting mode, data is automatically
recorded to the other SD card.
● When playback from an SD card ends in the playback
mode, playback from the other SD card starts
automatically.
● When the Automatic Slot Switch feature is turned [ON],
an automatic slot switch icon appears on the screen.
1 . Open the door.
2 . Make sure the SD card to be removed is not being
accessed (access lamp blinking).
3 . Push the SD card and remove it from the slot.
4 . Close the door.
Caution :
● Do not touch the metal part of the SD card when inserting
or removing the SD card.
Memo :
● If the SD card to switch to cannot be read, slot switching
will not be performed.
● When an SD card is inserted into the slot to switch to
during recording, slot switching will not be performed as
the SD card cannot be read. Stop the recording first and
allow the SD card to be read.
23
