JVC GSTD1BUS, GS-TD1 User Manual

HD MEMORY CAMERA

GS-TD1

Detailed User Guide

LYT2327-002A

Table of Contents

Beginner's Guide ............................................................ 4

Charging .................................................................................. 4

Recording ................................................................................ 4

Playback .................................................................................. 4

Shooting Tips ........................................................................... 4

Holiday Season/Christmas ...................................................... 5

Wedding .................................................................................. 6

Travel ....................................................................................... 7

Amusement Park ..................................................................... 9

Getting Started

Precautions on Recording and Playing Back 3D Images

............................................................................................ 11

Verifying the Accessories ...................................................... 13

Charging the Battery Pack ..................................................... 15

Grip Adjustment ..................................................................... 16

Inserting an SD Card ............................................................. 16

Types of Usable SD Card ................................................... 17

Using the Touch Screen ........................................................ 18

Names of Buttons and Functions on the LCD Monitor ....... 18

Clock Setting ......................................................................... 19

Resetting the Clock ............................................................ 20

Changing the Display Language ............................................ 21

Holding this Unit .................................................................... 22

Tripod Mounting .................................................................... 22

Using the Remote Control ...................................................... 22

Attaching Headphones .......................................................... 23

Attaching an External Microphone ......................................... 24

Using this Unit Overseas ....................................................... 24

Charging the Battery Pack Overseas ................................. 24

Setting the Clock to Local Time when Traveling ................. 25

Setting Daylight Saving Time ............................................. 25

Optional Accessories ............................................................. 26

Recording

Taking Videos in 3D Mode ..................................................... 27

Taking Still Images in 3D Mode ............................................. 28

Taking Videos in Intelligent Auto Mode .................................. 29

Zooming ............................................................................. 31

Taking Still Images in Intelligent Auto Mode .......................... 32

Zooming ............................................................................. 34

Adjusting Parallax During Recording ..................................... 34

Manual Recording ................................................................. 35

Scene Selection ................................................................. 36

Adjusting Focus Manually .................................................. 37

Using Focus Assist ............................................................. 38

Adjusting Brightness .......................................................... 38

Setting Shutter Speed ........................................................ 39

Setting Aperture ................................................................. 39

Setting White Balance ........................................................ 40

Setting Backlight Compensation ........................................ 41

Taking Close-up Shots ....................................................... 41

Setting the USER Button .................................................... 42

Using the Control Dial for Recording .................................. 43

Reducing Camera Shake ....................................................... 44

Capturing Subjects Clearly (TOUCH PRIORITY AE/AF) ....... 44

Capturing Smiles Automatically (SMILE SHOT) ................. 45

Recording at Intervals (TIME-LAPSE RECORDING) ............. 46

Taking Group Shots (Self-timer) ............................................ 48

Remaining Recording Time/Battery Power ............................ 49

Playback

Playing Back Videos .............................................................. 52

Playing a Video with Defective Management Information

........................................................................................ 54

Playing Back Still Images ....................................................... 55

Adjusting Parallax During Playback ....................................... 56

Slideshow Playback ............................................................... 57

Searching for a Specific Video/Still Image ............................. 58

Date Search ....................................................................... 58

Connecting to and Viewing on TV .......................................... 58

Playing Back 3D Images .................................................... 58

Playing Back 2D Images .................................................... 60

Playing Back a DVD or Blu-ray Disc Created on this Unit

............................................................................................ 63

Digest Playback on a Blu-ray or DVD Player ...................... 64

Editing

Deleting Unwanted Files ........................................................ 65

Deleting the Currently Displayed File ................................. 65

Deleting Selected Files ...................................................... 65

Protecting Files ...................................................................... 66

Protecting/Releasing Protection of the Currently Displayed File

........................................................................................ 66

Protecting/Releasing Protection of Selected Files .............. 66

Capturing a Still Image in the Video during Playback ............. 67

Capturing a Required Part in the Video (TRIMMING) ............ 68

Capturing Videos for Uploading to YouTube .......................... 69

Copying

Copying Files ......................................................................... 70

Creating Discs with a DVD Writer .......................................... 72

Preparing a DVD Writer (CU-VD50U) ................................ 73

Preparing a DVD Writer (CU-VD3U) .................................. 73

Creating a Disc ................................................................... 73

Playing Back with a DVD Writer ......................................... 77

Finalizing Discs After Copying ............................................ 78

Creating Discs with an External Blu-ray Drive ........................ 78

Preparing an External Blu-ray Drive ................................... 79

Creating a Disc ................................................................... 79

Playing Back with an External Blu-ray Drive ....................... 82

Creating a Disc Using a Connected Blu-ray Recorder ........... 83

Dubbing Files by Connecting to a DVD Recorder .................. 83

Using a USB External Hard Disk Drive .................................. 84

Preparing a USB External Hard Disk Drive ......................... 84

Copying All Files ................................................................ 84

Playing Back Files in the USB External Hard Disk Drive

........................................................................................ 85

Deleting Folders in the USB External Hard Disk Drive ....... 86

Formatting the USB External Hard Disk Drive .................... 87

Importing Files from the USB External Hard Disk Drive

........................................................................................ 87

Dubbing Files to a VHS Tape Using a VCR ........................... 88

Copying Files to an SD Card .................................................. 89

Moving Files to an SD Card ................................................... 90

Copying to Windows PC ........................................................ 91

Verifying System Requirements (Guideline) ....................... 92

Installing the Provided Software ......................................... 92

Backing Up All Files ........................................................... 93

Organizing Files ................................................................. 94

Recording Videos to Discs ................................................. 95

Backing Up Files Without Using Provided Software ........... 96

List of Files and Folders ..................................................... 97

JVC Software Licence Agreement ..................................... 98

Menu Settings

Operating the Menu ............................................................... 99

Operating the Main Menu ................................................... 99

Operating the Common Menu ............................................ 99

Main Menu for Video Recording .......................................... 100

SCENE SELECT .............................................................. 102

FOCUS ............................................................................ 102

FOCUS ASSIST ............................................................... 102

FOCUS ASSIST COLOR ................................................. 102

BRIGHTNESS ADJUST ................................................... 102

SHUTTER SPEED ........................................................... 102

APERTURE PRIORITY .................................................... 102

2

WHITE BALANCE ............................................................ 102

BACKLIGHT COMP. ........................................................ 102

TELE MACRO (2D mode only) ........................................ 102

TOUCH PRIORITY AE/AF ............................................... 102

DIS ................................................................................... 102

GAIN UP .......................................................................... 103

WIND CUT ....................................................................... 103

GRID ................................................................................ 104

TIME-LAPSE RECORDING ............................................. 104

3D VIDEO REC FORMAT (3D mode only) ....................... 104

VIDEO QUALITY .............................................................. 105

ZOOM (2D mode only) ..................................................... 106

x.v.Color (2D mode only) ................................................. 106

USER BUTTON SETTING ............................................... 106

3D SOUND ...................................................................... 107

MIC LEVEL ...................................................................... 107

MIC LEVEL SETTING ...................................................... 108

HEADPHONE VOL. ADJ. ................................................ 108

Main Menu for Still Image Recording ................................... 110

SCENE SELECT .............................................................. 112

FOCUS ............................................................................ 112

FOCUS ASSIST ............................................................... 112

FOCUS ASSIST COLOR ................................................. 112

BRIGHTNESS ADJUST ................................................... 112

SHUTTER SPEED ........................................................... 112

APERTURE PRIORITY .................................................... 112

WHITE BALANCE ............................................................ 112

BACKLIGHT COMP. ........................................................ 112

TELE MACRO (2D mode only) ........................................ 112

TOUCH PRIORITY AE/AF ............................................... 112

SMILE SHOT ................................................................... 112

SMILE LEVEL .................................................................. 112

SELF-TIMER .................................................................... 112

GAIN UP .......................................................................... 113

GRID ................................................................................ 113

SHUTTER MODE ............................................................ 114

CONT. SHOOTING SPEED ............................................. 114

IMAGE SIZE ..................................................................... 115

USER BUTTON SETTING ............................................... 115

Main Menu for Video Playback ............................................ 116

SEARCH DATE ................................................................ 117

PROTECT/CANCEL ........................................................ 117

COPY ............................................................................... 117

MOVE .............................................................................. 117

TRIMMING ....................................................................... 117

UPLOAD SETTINGS ....................................................... 117

PLAYBACK OTHER FILE ................................................ 117

3D MOTION RELIEF (3D mode only) .............................. 117

Main Menu for Still Image Playback ..................................... 118

SEARCH DATE ................................................................ 118

PROTECT/CANCEL ........................................................ 118

COPY ............................................................................... 118

MOVE .............................................................................. 118

Common Menu .................................................................... 119

CLOCK ADJUST .............................................................. 121

DATE DISPLAY STYLE ................................................... 121

LANGUAGE ..................................................................... 122

MONITOR BRIGHTNESS ................................................ 122

REC MEDIA FOR VIDEO ................................................. 122

REC MEDIA FOR IMAGE ................................................ 123

OPERATION SOUND ...................................................... 123

AUTO POWER OFF ......................................................... 124

QUICK RESTART ............................................................ 124

REMOTE .......................................................................... 125

DEMO MODE .................................................................. 125

TOUCH SCREEN ADJUST ............................................. 126

3D DISPLAY WARNING (3D mode only) ......................... 127

VIDEO OUTPUT (2D mode only) ..................................... 127

HDMI OUTPUT ................................................................ 128

HDMI CONTROL ............................................................. 129

AUTO FINALIZE .............................................................. 129

FACTORY PRESET ......................................................... 130

UPDATE

FORMAT BUILT-IN MEM. ................................................ 130

FORMAT SD CARD ......................................................... 131

ERASE ALL DATA ........................................................... 131

.......................................................................... 130

Names of Parts

Front .................................................................................... 132

Rear ..................................................................................... 132

Bottom ................................................................................. 133

Interior ................................................................................. 133

Indications on the LCD monitor

Common Recording Indications .......................................... 134

Video Recording .................................................................. 134

Still Image Recording ........................................................... 135

Video Playback .................................................................... 135

Still Image Playback ............................................................ 136

Troubleshooting

Battery Pack ........................................................................ 137

Recording ............................................................................ 137

Card ..................................................................................... 138

Playback .............................................................................. 138

Editing/Copying ................................................................... 139

Computer ............................................................................. 139

Screen/Image ...................................................................... 140

Other Problems ................................................................... 140

Error Message? ................................................................... 141

Maintenance ............................................................... 142

Specifications ............................................................. 143

3

Beginner's Guide

Charging

Refer to the operating instructions found in the animation on the Detailed

0

User Guide.

Recording

Refer to the operating instructions found in the animation on the Detailed

0

User Guide.

Playback

Refer to the operating instructions found in the animation on the Detailed

0

User Guide.

Shooting Tips

Basic Way to Hold a Camcorder
~ Recording Stable Images ~

[Getting Ready]

o

A Open your feet to the width of your shoulders.
B Extend your right hand and hold the camcorder over your head.
C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

Caution :

Use this way of shooting only as a last resort as it is difficult to achieve

0

stable images.
Set to the wide angle as much as possible as the image will be prone to

0

camera shake.
Be considerate. Do not inconvenience the people around you.

0

Squatting and Shooting at Eye Level

This is the standard way of shooting while standing up.
Be sure to master this basic technique in order to achieve stable images.

[Getting Ready]

o

A Open your feet to the width of your shoulders.
B Keep the elbow of your right arm, which is holding the camcorder, close

to your side.

C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

.

Extending Your Hands to Shoot
~ High-Angle Shooting ~

Staying low is a common position to take when shooting small children.
By recording from the eye level of the child, you can capture all his cute
expressions clearly.

[Getting Ready]

o

A Kneel down with your left knee while keeping your right foot on the

ground.

B Place the elbow of your right arm, which is holding the camcorder, on

your right knee.

C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

.

Caution :

To record 3D images, refer also to “Precautions on Recording and Playing

0

Back 3D Images”.

“Precautions on Recording and Playing Back 3D Images” (A p. 11)

Extend your hand when your subject is being hidden behind a crowd of
people.

.

4

Useful Shooting Techniques

Holiday Season/Christmas

Record the happy Christmas celebration with your family!

Photo by 101st CAB, Wings of Destiny

Creative Commons Attribution-No Derivative Works 3.0

Decorating the Tree and Preparing the Dinner

The decoration of tree and preparation of dinner are part of the joy of
Christmas. Be sure to record these happy family times!

Decorating the tree

o

.

Recording the Christmas Party

.

Photo by InnerSpirit

Creative Commons Attribution-No Derivative Works 3.0

After all preparations, it is finally the Christmas party itself.
Not only should you record the candle-blowing scene, but also the smiles of
the family while being surrounded by good food, or even the father who is
slightly drunk from champagne!

Finding the Presents

A tree is the most important thing to bring out the mood of Christmas.

.

Simply the scene of all family members engaging in the decorating of a fir
tree with various colorful ornaments is full of the feeling of happiness.

Preparing the Dinner

o

.

Photo by Manicosity

Creative Commons Attribution-No Derivative Works 3.0

Record the scenes as everyone helps to prepare the feast of the night.
You can film the mother who is cooking, the children who are helping, and
of course, the process of making a cake!

For children, the greatest joy of Christmas is receiving presents the next

.

morning.
Their expression of delight when finding a present next to their pillow is a
recording opportunity not to be missed. Get ready to shoot before the
children wake up!

5

Useful Shooting Techniques

Wedding

Create an awesome wedding video for the bride and groom!

.

Discussing and Planning Before the Event

Before the day of the wedding reception, it is important to discuss with the
bride and groom about various details such as the order of the ceremony
and whether there are any entertainment programs or change of clothes.
By understanding the preferences of the bride and groom, you will be able
to shoot more appropriately.

Finding the Right Angle to Capture Both Bride and Groom

Composing the picture with the groom in front and the

o

guests at the back

Closing Up on the Bride's Face During the Thank You Speech

The climax of the event finally comes during the bride and groom's thank you
speech and presentation of flowers. The touching words of appreciation from
the bride and tears of joy from the parents are scenes that must not be
missed.
Start by closing up on the bride's face using zoom. As the tears start to form
in the bride's eyes, continue shooting for a little longer. Then, slowly zoom
out to the wide angle to show the parents who are moved by the speech.

Advanced Operation with Two Camcorders

If video-editing is to be done, record using two camcorders so that a video
with varying scenes can be created. You can try asking a close friend who
has a camcorder at home.
Set the borrowed camcorder on a tripod to focus on taking close-up shots
of the bride and groom. In this way, the other camcorder can be moved
around to record other scenes, enabling an interesting video with changing
scenes to be created through editing and compilation.
As most people own at least a digital camera nowadays, even if you are really
unable to find an extra camcorder, inserting still pictures to the video at
various points is also a good way to add variety. Do give it a try!

<Camcorder 1>

o

Closing up on the bride and groom all the time

<Camcorder 2>

o

Recording the congratulatory messages from friends at the
same time

The main characters of a wedding are of course the bride and groom. Record

.

their expressions clearly during the toast, speech, entertainment programs,
and other scenes.
Another recommendation is to capture the face shots of the guests, then pan
towards the groom. Picture composition containing the crowd of guests only
lacks fun, so be sure to pay attention to the shooting angle and size.

Recording the Expressions and Comments of Guests

Setting the shot from eye level to chest level

o

You can record comments from the guest by going around asking, "Please
say a few words for the bride and groom".
This can be done at the guests' waiting room, when the bride and groom are
changing, or during the entertainment programs.

.

.

6

Travel

Capture all the good times of your domestic or overseas trips!

Battery Charger

o

Useful Shooting Techniques

.

Bringing the Necessary Equipment

The necessary things to bring on a trip depends on your traveling purpose
and the destination.
For overseas trips in particular, you have to think about what to bring in
accordance to the local conditions.
Here are some suggestions for your consideration.

Camcorder

o

Think about how many hours of shooting you will usually perform in a day.
Be sure to prepare enough recording medium especially for long overseas
trips.
If you are recording in SD cards, get ready the sufficient number of cards,
including some for backup.

Battery Pack

o

Prepare a battery pack that is ready for double the expected recording time
in a day. For example, if you plan to record for 2 hours a day, prepare a
battery pack that is ready for 4 hours (actual recording time).
For a day trip, you can prepare a battery with low capacity but for a long trip,
do prepare a few batteries with high capacities.

AC Adapter

o

The JVC AC adapter supports voltages from 100 V to 240 V, and hence can
be used anywhere in the world.
Bring along the adapter if you are traveling for a long time. Charge the battery
pack while sleeping so that you can record with full battery power the next
day.

Power Plug Adapter

o

Recording cannot be performed when an AC adapter is connected to the

.

camcorder for battery charging.
You can bring an additional battery charger to charge battery packs if you
plan to use the camcorder for recording at night. You can also charge
multiple battery packs by using both the battery charger and this camcorder
at the same time.

Tripod

o

.

A tripod is an essential item to take stable images. Select an appropriate
tripod in accordance to your purpose and style of traveling, such as a
compact one to be used on a table or one that is at least 1 m tall.

Recording the Excitement Before Departure

It may be a little abrupt to start your travel video at the destination suddenly.
Record also the preparations prior to departure if it is a family trip, or the time
when everyone is gathered at the meeting place if you are traveling with your
friends.
For overseas trips, taking a shot of the signs and displays at the airport of
the flight you are taking may be useful for future reference.

The shape of the power plug varies according to countries. Be sure to check

.

the shape of the power plug beforehand, and bring the appropriate power
plug adapter.
“Charging the Battery Pack Overseas” (A p. 24)

.

.

7

Useful Shooting Techniques

Using Pan at the Places of Interest

Tourists spots with beautiful scenery or historical sites are places that you
would certainly want to record.
To capture the magnificence of a scene which cannot be fitted into a single
frame, try the panning technique.
Refer to the "Shooting Tips" found in this website on how to use panning
effectively.
In addition, you may also like to take a shot of the signs or monuments that
can often be found at the tourist spots.

.

.

Showing Everyone Having a Good Time

When taking a video, it is rather dull to shoot only the scenery or historical
sites.
Talk about your feelings while recording the breath-taking scenery of an
attraction so that it will be an interesting scene to view later.

8

Useful Shooting Techniques

Amusement Park

Take more shots of the smiling faces of everyone in the family!

.

Taking Videos or Still Images According to the Attraction

You may choose to take videos all the time. However, you may want to take
some still images too.
The following section explains the scenarios suitable for taking videos or still
images.

Scenarios suitable for taking videos

o

Inducing Responses by Calling Out

.

Videos with no waving of hands nor laughter are not only dull when you view
them later, but also put the capability of the audio-recording function of the
camcorder to a waste.
When recording, induce more reactions by enthusiastically waving your
hands or shouting out "Is it fun?" and the like.

Capturing the Best Moment in a Video as a Still Image

Shots with the eyes closed are often taken by accident. To reduce such
mistakes, make use of the function to capture still images from videos.
As videos are actually continuous recording of 60 still images within 1 minute,
using this function allows you to select the best moment and save it as a still
image.
“Capturing a Still Image in the Video during Playback” (A p. 67)

Scenarios with changes in body movement are suitable for taking videos.

.

This includes situations where there are rapid changes in facial expressions
or voices of surprise and delight.
*Some amusement parks do not allow passengers to perform any recording.
Be sure to check beforehand.
[Examples]

Merry-go-round, go kart, coffee cup, etc.

0

Scenarios suitable for taking still images (photos)

o

.

Scenarios with little movement of the subject are suitable for taking still
images.
Try to take the still images from an angle such that the surroundings can be
seen clearly.
[Examples]

Carousal, ferris wheel, fun bicycle rides, etc.

0

Photo by just that good guy jim

.

Creative Commons Attribution-No Derivative Works 3.0

Video Playback in Progress

.

Photo by talk rhubarb

Creative Commons Attribution-No Derivative Works 3.0

Capturing a Still Image

Photo by just that good guy jim

.

Creative Commons Attribution-No Derivative Works 3.0

Video Playback in Progress

9

Useful Shooting Techniques

Advanced Operation with Backlight Compensation

When the subject’s face is in backlight or when the expression cannot be
seen clearly, the Intelligent Auto function of this unit automatically increases
its brightness for recording.
If Intelligent Auto fails to function as expected or if the brightness correction
is insufficient, you can increase the brighness by using backlight
compensation in the Manual mode.
“Setting Details” (A p. 41)

<Without backlight compensation>

o

.

<With backlight compensation>

o

.

10

Getting Started

Precautions on Recording and Playing Back 3D Images

3D images can be recorded and played back on this unit. You can enjoy realistic and powerful 3D images recorded on this unit by playing back on a 3D
compatible TV. Before use, please read the following precautions to ensure safe and comfortable viewing of the 3D images.

Recording 3D Images

This unit makes use of the misalignment between the images that enter the left and right eyes to create the 3D effect during 3D recording. As the images that
enter the left and right eyes are different, fatigue may be experienced. In addition, depending on the content of the video, an illusion of movement may be
experienced and result in motion sickness. Take note of the following when recording 3D images.

Basic Way to Hold a Camcorder During 3D Recording

o

(Recording Stable Images)

.

Shooting Distance During 3D Recording

o

(Achieving Comfortable 3D Images)

.

Memo :

Make sure that you have stable footing during recording.

0

Do not swing the camera horizontally or vertically during recording.

0

If the subject is not recorded within the recommended shooting distance, 3D effect may be weak.

0

When recording night scenes or landscapes, 3D effect of some subjects may be weak.

0

For subjects that appear at the side of the screen, 3D effect may be weak.

0

Operate slowly when using the zoom.

0

If the image is zoomed in too much, 3D effect may be weak.

0

It is recommended to make use of a tripod.

0

* If you do not take note of the above points during 3D recording, the recorded scenes may be played back in stop-motion during playback.
“3D MOTION RELIEF (3D mode only)” (A p. 117)

11

Getting Started

3D Display on the LCD Monitor

The LCD monitor supports 3D images during both recording and playback. Press the “3D/2D” button on the touch screen to change the display on the LCD
monitor between 3D and 2D.

When using the 3D recording mode, the image will be recorded in 3D even if the display on the LCD monitor is set to 2D.

0

3D effect appears stronger when viewed at approximately 30 cm (11-3/4”) from the front.

0

3D effect may be weak if viewed from an angle other than the front.

0

The LCD monitor appears darker when 3D images are displayed. Change the display to 2D when it is difficult to see, such as when using this unit outdoors.

0

Caution :

Recording and viewing of the 3D images is not recommended for people with medical history of photosensitivity, heart diseases, feel sick, suffer from lack

0

of sleep, suffer from fatigue, or are drunk.

Medical conditions may worsen.

Do not shoot a subject from a distance shorter than the minimum shooting distance.

0

The 3D effect may become stronger and result in fatigue or discomfort.
The minimum shooting distance of this camera is 80 cm (31-1/2”) (using wide angle).

Be careful not to shake the camera during recording.

0

Excessive shaking while riding in a vehicle or during walking may result in fatigue or discomfort.
To perform recording while moving the camera, keep the speed slow and steady.
Keep the camera in a horizontal position, as much as possible, during recording.

If you have vision problems such as short-sightedness, long-sightedness, varying vision in the left and right eyes, or astigmatism, it is recommended to

0

correct your vision by wearing glasses, etc.
Stop recording or viewing of the 3D images if you see double images.

3D images may appear differently for different people. Correct your vision appropriately before viewing the 3D images.

Stop recording or viewing of the 3D images if you experience fatigue or discomfort.

0

Continual recording or viewing of the 3D images may result in health problems.
Take an adequate rest.
Recording or viewing of the 3D images in an environment where shaking of the monitor is expected, such as while riding in a vehicle or during walking, may
result in fatigue or discomfort.

If you experience fatigue or discomfort while recording or viewing of the 3D images on the LCD monitor, set the display to 2D.

0

Continual recording and viewing of the 3D images may result in health problems.

Rest well after recording or viewing of the 3D images.

0

After recording or viewing of the 3D images, check that you do not experience fatigue or discomfort before driving, etc.

Take a break every 30 to 60 minutes when recording or viewing of the 3D images.

0

Long periods of recording or viewing may cause visual fatigue.

Keep a distance of at least 3 times the effective height of the screen when viewing of the 3D images on a 3D compatible TV.

0

Viewing of the 3D images from a distance shorter than the recommended distance may cause visual fatigue.

TV Size

54” Approx. 2.0 m (6’6-3/4”)

50” Approx. 1.9 m (6’2-3/4”)

46” Approx. 1.7 m (5’6-7/8”)

42” Approx. 1.6 m (5’3”)

Recording and viewing of the 3D images is only recommended for ages 5 to 6 and above.

0

Guardians should pay close attention to children as health problems may result if fatigue and discomfort are not noticed immediately.

Recommended Distance

3D Effect Mechanism

3D images on the LCD monitor of this unit are displayed using the parallax barrier system. Placed in front of an image source, a parallax barrier consists of a
series of slits arranged alternately for the left and right eyes, allowing each eye to see a different image when viewing from a distance, thus creating the 3D
effect. As such, 3D effect may appear weak depending on the angle of viewing.

.

12

Verifying the Accessories

If any of the items are missing or defective, consult your JVC dealer or the nearest JVC service center.

Illustration Description

AC Adapter
AP-V20U

Connects to this unit to charge the battery pack.

0

.

.

.

It can also be used when recording or playing back videos indoors.

Battery Pack
BN-VF815U

Attaches to this unit to supply power.

0

Remote Control
RM-V760U

Operates certain functions from a distance.

0

Getting Started

HDMI Mini Cable

Connects this unit to a TV to play back recorded images on the TV in a better quality.

0

.

AV Cable

Connects this unit to a TV to play back recorded images on the TV.

0

.

USB Cable
(Type A - Mini Type B)

Connects this unit to a computer.

0

.

Basic User Guide

Read well and keep in a safe place where it can be accessed easily when necessary.

0

Memo :

.

CD-ROM

For installing the provided software Everio MediaBrowser 3D on a computer.

0

.

13

Getting Started

SD cards are sold separately.
“Types of Usable SD Card” (A p. 17)
When using the AC adapter overseas, please prepare a commercially available converter plug for the country or region of visit.
“Charging the Battery Pack Overseas” (A p. 24)

14

Getting Started

Charging the Battery Pack

Charge the battery pack immediately after purchase and when the remaining
battery power is low.
The battery pack is not charged at the time of purchase.

Attach the battery pack.

1

.

Align the top of the battery with the mark on this unit, and slide in until

0

the battery clicks into place.

Connect the AC adapter to the DC connector.

2

.

Plug in the power.

3

Detaching the Battery Pack

Press the battery release lever to detach the battery from this unit.

.

Approximate Battery Charging Time (Using AC Adapter)

Battery Pack Charging Time

BN-VF815U
(Supplied)

BN-VF823U 3 h 40 m

When the battery life is reached, the recording time becomes shorter even

0

if the battery pack is fully charged.
(Replace the battery pack with a new one.)

* The charging time is when the unit is used at 25°C (77°F). If the battery
pack is charged outside the room temperature range of 10°C to 35°C (50°F
to 95°F), charging may take a longer time or it may not start. The recordable
and playable time may also be shortened under some usage conditions such
as at low temperature.
“Approximate Recording Time (Using Battery)” (A p. 51)

2 h 40 m

.

The charging lamp blinks when charging is in progress.

0

It goes out when charging is finished.

Caution :

Be sure to use JVC battery packs.

If you use any other battery packs besides JVC battery packs, safety and

0

performance cannot be guaranteed.
Charging time: Approx. 2 h 40 m (using supplied battery pack)

0

The charging time is when the unit is used at 25°C (77°F). If the battery
pack is charged outside the room temperature range of 10°C to 35°C (50°F
to 95°F), charging may take a longer time or it may not start. The
recordable and playable time may also be shortened under some usage
conditions such as at low temperature.

Be sure to use the supplied JVC AC adapter.

If you use any other AC adapters besides the supplied JVC AC adapter,

0

malfunctions may occur.

Rechargeable Batteries：

When using the battery in a low temperature environment (10°C (50°F) or

0

below), the operating time may be shortened, or it may not function
properly. When using this unit outdoors in the winter weather, warm the
battery, such as by placing it in the pocket, before attaching it. (Keep away
from direct contact with a warm pack.)

Do not expose the battery to excessive heat, such as direct sunlight or fire.

0

After removing the battery, store it in a dry place between 15°C to 25°C

0

(59°F to 77°F).

0

Keep a 30 % battery level (X) if the battery pack is not to be used for a
long period of time. In addition, fully charge and then fully discharge the
battery pack every 2 months, then continue to store it at a 30 % battery

level (X).

Memo :

You can connect this unit to the AC adapter to record for long hours

0

indoors.
(Battery charging begins when the LCD monitor is closed.)

15

Getting Started

Grip Adjustment

.

A Pull back the belt
B Adjust the length
C Attach the belt

Caution :

Be sure to fasten the grip belt properly.

0

If the belt is loose, this unit may drop and result in injuries or damages.

Inserting an SD Card

When a commercially available SD card is inserted, recordings can be made
to either the card or built-in memory separately.
“Types of Usable SD Card” (A p. 17)
“Approximate Video Recording Time” (A p. 50)

Open the LCD monitor.

1

.

2

Press and hold the M button for 2 seconds or more to turn off the power.

Open the cover.

3

.

Insert an SD card.

4

.

Insert with the label facing upwards.

0

Warning

Make sure not to insert the card in the wrong direction.

0

It may cause damage to the unit and card.
Turn off the power of this unit before inserting or removing a card.

0

Do not touch the metal contact area when inserting the card.

0

Memo :

To record to the card, it is necessary to perform media settings.

0

When no card is available, set media settings to “BUILT-IN MEMORY” for
recording.

“REC MEDIA FOR VIDEO” (A p. 122)
“REC MEDIA FOR IMAGE” (A p. 123)

To use cards that have been used on other devices, it is necessary to

0

format (initialize) the card using “FORMAT SD CARD” from media
settings.

“FORMAT SD CARD” (A p. 131)

16

Removing the Card

Push the SD card inward once, then pull it out straight.

Getting Started

Using SD cards (including SDHC/SDXC cards) other than those specified

0

above may result in recording failure or data loss.
To record videos with “VIDEO QUALITY” set to “THR”, use of a Class 10

0

card is recommended. (Class 6 or higher SDHC/SDXC card is required.)
To record videos with “VIDEO QUALITY” set to “UXP”, use of a Class 6

0

compliant SDHC/SDXC card is recommended.
Class 4 and Class 6 are guaranteed to have a minimum transfer rate of 4

0

MB/s and 6 MB/s respectively during reading or writing of data.
You can also use a Class 10 compliant SDHC/SDXC card.

0

To protect the data, do not touch the terminals of the SD card.

0

Both videos and still images can be recorded on one SD card.

0

.

Types of Usable SD Card

The following SD cards can be used on this unit.
Operations are confirmed on the SD cards from the following manufacturers.

Panasonic

0

TOSHIBA

0

SanDisk

0

SD Card

.

This unit supports 256 MB to 2 GB SD cards.

0

Use a Class 4 or higher compatible SD card (2 GB) for video recording.

0

SDHC Card

When your computer cannot recognize the SDXC card

Confirm and update the OS of your computer.

Windows XP /
Windows XP
SP1

Windows XP
SP2 /
Windows XP
SP3

Windows
Vista

Windows
Vista SP1 /
Windows
Vista SP2

Windows 7 Necessary to download the update software.

Necessary to update to SP2 or higher.

Necessary to download the update software.
(KB955704)

http://www.microsoft.com/downloads/details.aspx?
FamilyID=1cbe3906-ddd1-4ca2-b727­c2dff5e30f61&displaylang=en

Necessary to update to SP1 or higher.

Necessary to download the update software.
(KB975823)

32 bit version

0

http://www.microsoft.com/downloads/en/
details.aspx?FamilyID=2d1abe01-0942-4f8a­abb2-2ad529de00a1

64 bit version

0

http://www.microsoft.com/downloads/en/
details.aspx?FamilyID=7d54c53f-017c-4ea5­ae08-34c3452ba315

(KB976422)

32 bit version

0

http://www.microsoft.com/downloads/en/
details.aspx?FamilyID=3ee91fc2-a9bc-4ee1­aca3-2a9aff5915ea

64 bit version

0

http://www.microsoft.com/downloads/en/
details.aspx?FamilyID=73f766dd-7127-4445­b860-47084587155f

.

Use a Class 4 or higher compatible SDHC card (4 GB to 32 GB) for video

0

recording.

SDXC Card

.

Use a Class 4 or higher compatible SDXC card (Max. 64 GB) for video

0

recording.

Memo :

17

Getting Started

Using the Touch Screen

Icon operation buttons, thumbnails, and menu items are displayed on the
touch screen according to the mode in use.

To operate, tap the icon operation buttons, thumbnails, or menu items on

0

the touch screen lightly.
There are two ways to operate the touch screen, namely “tap” and “drag”.

0

The following are some examples.

A Tap the displayed button (icon) or thumbnail (file) on the touch screen

0

to make selection.
B Drag the thumbnails on the touch screen to search for the desired file.

0

.

The touch screen of this unit is pressure-sensitive. When the touch screen

0

does not respond smoothly, apply slightly more force to your fingertip.
Do not press or rub with excessive force.

0

If you apply a protect sheet or a sticker, the touch screen may not respond

0

smoothly.
Do not operate the touch screen using an object with a sharp or hard tip.

0

Pressing two or more places at a time may cause a malfunction.

0

Tap the buttons (icons) on the touch screen accurately. The buttons may

0

not respond if they are not tapped on the right area.
Perform “TOUCH SCREEN ADJUST” if the reactive area of the screen is

0

misaligned with the touched area. (Adjust by lightly tapping with a corner
of an SD card, etc. Do not press with an object with a sharp tip or do not
press hard.)

“TOUCH SCREEN ADJUST” (A p. 126)

Names of Buttons and Functions on the LCD Monitor

The following screens are displayed during the video and still image modes,
and operate as the touch screens.

Recording Screen (Video/Still Image)

“Operating the Menu” (A p. 99)

Display Button

7

Some displays disappear after approximately 3 seconds.
Use the n button to change the displays as shown below.

0

Tap n button
Displays appear for approximately 3 seconds with every tap.

0

Tap and hold n button
Displays are fixed such that they do not disappear. After setting, the

display button changes from n to m.
Tap m to release the displays.

Playback Screen (Video)

.

Parallax Adjustment Button

1

Adjusts the 3D effect when 3D images are displayed on the LCD

0

monitor.

“Adjusting Parallax During Playback” (A p. 56)

Recording/Playback Mode Button

2

Switches between recording and playback modes.

0

Index Screen Button

3

“Operation Buttons for Video Playback” (A p. 53)

Delete Button

4

“Deleting the Currently Displayed File” (A p. 65)

LCD Monitor 3D/2D Display Switching Button

5

Switches the display on the LCD monitor between 3D and 2D.

0

Menu Button

6

“Operating the Menu” (A p. 99)

Operation Buttons

7

“Operation Buttons for Video Playback” (A p. 53)

.

Parallax Adjustment Button

1

Adjusts the 3D effect when 3D images are displayed on the LCD

0

monitor.

“Adjusting Parallax During Recording” (A p. 34)

Zoom Button

2

“Zooming” (A p. 31)

Recording/Playback Mode Button

3

Switches between recording and playback modes.

0

Recording Start/Stop Button

4

g: Video Recording Start Button

0
0

a: Video Recording Stop Button

0

Q: Still Image Recording Button

LCD Monitor 3D/2D Display Switching Button

5

Switches the display on the LCD monitor between 3D and 2D. The

0

image will be recorded in 3D even if the display on the LCD monitor
is set to 2D.

Menu Button

6

Playback Screen (Still Image)

.

Group Playback Button

1

Continuous playback of grouped files (such as still images captured

0

by continuous shooting).

“Playing Back Still Images” (A p. 55)

Parallax Adjustment Button

2

Adjusts the 3D effect when 3D images are displayed on the LCD

0

monitor.

“Adjusting Parallax During Playback” (A p. 56)

Recording/Playback Mode Button

3

Switches between recording and playback modes.

0

Index Screen Button

4

“Operation Buttons for Still Image Playback” (A p. 55)

Delete Button

5

18

Getting Started

“Deleting the Currently Displayed File” (A p. 65)

LCD Monitor 3D/2D Display Switching Button

6

Switches the display on the LCD monitor between 3D and 2D.

0

Menu Button

7

“Operating the Menu” (A p. 99)

Operation Buttons

8

“Operation Buttons for Still Image Playback” (A p. 55)

Index Screen

.

Date Button

1

“Operation Buttons for Video Playback” (A p. 53)
“Operation Buttons for Still Image Playback” (A p. 55)

Recording/Playback Mode Button

2

Switches between recording and playback modes.

0

Index Screen Switching Button (Still image only)

3

Switches between the group or full index screen displays.

0

Delete Button

4

“Deleting Selected Files” (A p. 65)

Playback Media Button

5

Switches between SD card and built-in memory.

0

Menu Button

6

“Operating the Menu” (A p. 99)

Page Forward/Back Button

7

“Operation Buttons for Video Playback” (A p. 53)
“Operation Buttons for Still Image Playback” (A p. 55)

Menu Screen

Clock Setting

The “SET DATE/TIME!” screen appears when you turn on this unit for the
first time after purchase, when it has not been used for a long time, or when
the clock is not set yet.
Set the clock before recording.

Open the LCD monitor.

1

.

The unit turns on.

0

When the LCD monitor is closed, the unit turns off.

0

Tap “YES” when “SET DATE/TIME!” is displayed.

2

.

Set the date and time.

3

.

When the year, month, day, hour, or minute item is tapped, “∧” and

0

“∨” will be displayed.

Tap ∧ or ∨ to adjust the year, month, day, hour, and minute.

0

After setting the date and time, tap “SET”.

4

.

Help Button

1

Menu Items

2

Return Button

3

Common Menu Button

4

Close Button

5

“Operating the Menu” (A p. 99)

.

Select the region where you live and tap “SAVE”.

5

.

The city name and time difference are displayed.

0

Tap “<” or “>” to select the city name.

0

Memo :

The clock can be reset again later.

0

“Resetting the Clock” (A p. 20)

19

Getting Started

When using this unit overseas, you can set it to the local time for recording.

0

“Setting the Clock to Local Time when Traveling” (A p. 25)

“SET DATE/TIME!” is displayed when you turn on this unit after it has not

0

been used for a prolonged period.
Connect the AC adapter for more than 24 hours to charge the internal clock
battery of this unit before setting the clock.

“Charging the Battery Pack” (A p. 15)

Resetting the Clock

Set the clock with “CLOCK ADJUST” from the menu.

Tap “MENU”.

1

.

2

Tap “Q”.

.

Tap “CLOCK ADJUST”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap “CLOCK SETTING”.

4

.

Set the date and time.

5

.

When the year, month, day, hour, or minute item is tapped, “∧” and

0

“∨” will be displayed.
Tap ∧ or ∨ to adjust the year, month, day, hour, and minute.

0

After setting the date and time, tap “SET”.

6

20

.

Getting Started

Select the region where you live and tap “SAVE”.

7

.

The city name and time difference are displayed.

0

Tap < or > to select the city name.

0

Changing the Display Language

The language on the display can be changed.

Tap “MENU”.

1

.

2

Tap “Q”.

.

Tap “LANGUAGE”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap to the desired language.

4

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

21

Getting Started

Holding this Unit

When holding this unit, keep your elbows close to your sides to prevent
camera shake.

.

Hold the LCD monitor with your left hand and adjust the angle accordingly.

0

Holding the LCD monitor with your left hand helps to stabilize the camera
for recording.

Caution :

Be careful not to drop this unit during transportation.

0

Guardians should pay close attention when this unit is being used by

0

children.

Memo :

If camera shake is excessive, use the digital image stabilizer.

0

“Reducing Camera Shake” (A p. 44)

Using the Remote Control

You can operate this unit from a distance away using the supplied remote
control.

.

Memo :

Point the remote control toward the sensor directly and use it within 5 m

0

from this unit.
The transmitted beam may not be effective or may cause incorrect

0

operation when the sensor is directly exposed to sunlight or powerful
lighting.

Preparing the Remote Control

Using the Remote Control for the First Time

Tripod Mounting

This unit can be mounted on a tripod (or monopod). This is useful for
preventing camera shake.

.

To prevent this unit from falling off, check the tripod mounting screw holes

0

and positioning holes on the unit carefully before mounting, and turn the
screws until they are fastened firmly.

Caution :

To prevent injuries or damages which may result if this unit falls off, read

0

the instruction manual of the tripod (or monopod) to be used and make
sure that it is securely attached.

Memo :

It is recommended to use a tripod or monopod when recording in

0

conditions prone to camera shake (such as in dark places or when zoomed
to the telephoto end).

Set the digital image stabilizer to Z (OFF) when using a tripod for

0

recording.

“Reducing Camera Shake” (A p. 44)

.

A button battery (CR2025) is included inside the remote control at the time

0

of purchase.
Remove the insulation sheet before use.

Reinserting the Battery

.

Pull out the battery holder by pressing the lock tab.

0

Insert the button battery with the + side facing upward.

0

22

Getting Started

Operation Buttons on Remote Control Unit

.

Recording Start/Stop Button

1

Starts/stops video recording.

0

Still Image Button

2

Takes a still image.

0

Zoom Button

3

T: Zooms in

0

W: Zooms out

0

Basic Playback Operations

4

Attaching Headphones

You can attach optional headphones to this unit.

Open the cover of the headphones connector.

1

.

Connect the headphones to the headphones connector.

2

.

Memo :

The volume level of the headphones can be adjusted using

0

“HEADPHONE VOL. ADJ.” in the menu.

“HEADPHONE VOL. ADJ.” (A p. 108)

Operation Button Description

Playback/Pause
Button

d / e

Left Button j

Right Button i

T Button N

W Button O

Index Button

5

Stops playback and returns to thumbnail display.

0

Info Button

6

Recording: Displays the remaining time (for video only) and battery

0

power.
Playback: Displays file information such as recording date.

0

Starts/pauses playback of videos or

0

slideshows.

Moves the cursor to the left.

0

Performs reverse search during playback.

0

Moves the cursor to the right.

0

Performs forward search during playback.

0

Zooms in. (during pause)

0

Turns up (+) the volume during video playback.

0

Zooms out. (during pause)

0

Turns down (-) the volume during video

0

playback.

23

Getting Started

Attaching an External Microphone

You can attach an optional external microphone to this unit.

The recommended external microphone for this unit is MZ-V8. For details,

0

consult your JVC dealer.

Attach an external microphone (optional) to the shoe.

1

.

Open the cover of the microphone connector and connect the cable of

2

the external microphone.

Using this Unit Overseas

The shape of the power outlet varies according to countries and regions.
To charge the battery pack, you need a converter plug that matches the
shape of the outlet.
“Charging the Battery Pack Overseas” (A p. 24)
Change the date and time display to the local time by selecting your travel
destination in “AREA SETTING” of “CLOCK ADJUST”.
“Setting the Clock to Local Time when Traveling” (A p. 25)
When “ON” is selected in “DST SETTING” of “CLOCK ADJUST”, the time is
set 1 hour ahead.
“Setting Daylight Saving Time” (A p. 25)

Charging the Battery Pack Overseas

The shape of the power outlet varies according to countries and regions.
To charge the battery pack, you need a converter plug that matches the
shape of the outlet.

.

Memo :

Do not apply too much force when attaching accessories such as an

0

external microphone.
The microphone level display and setting can be changed in the menu.

0

“MIC LEVEL” (A p. 107)
“MIC LEVEL SETTING” (A p. 108)

.

24

Getting Started

Setting the Clock to Local Time when Traveling

Change the date and time display to the local time by selecting your travel
destination in “AREA SETTING” of “CLOCK ADJUST”.
Restore the region settings after you returned from the trip.

Tap “MENU”.

1

.

2

Tap “Q”.

.

Tap “CLOCK ADJUST”.

3

Setting Daylight Saving Time

When “ON” is selected in “DST SETTING” of “CLOCK ADJUST”, the time is
set 1 hour ahead.

Tap “MENU”.

1

.

2

Tap “Q”.

.

Tap “CLOCK ADJUST”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap “AREA SETTING”.

4

.

Select the area you are traveling to and tap “SAVE”.

5

.

The city name and time difference are displayed.

0

Tap < or > to select the city name.

0

Memo :

Setting “AREA SETTING” changes the clock time such that time difference

0

is accounted for.
After returning to your country, re-select the region that was set initially to
restore the original clock settings.

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap “DST SETTING”.

4

.

Tap “ON”.

5

.

Memo :

What is daylight saving time?

0

Daylight saving time is the system of setting the clock 1 hour ahead for a
fixed period in summer.
It is used mainly in the Western countries.

Restore the daylight saving time settings after you returned from the trip.

0

25

Getting Started

Optional Accessories

You can record for a longer time by using the optional battery pack.

Product Name Description

Battery Pack

BN-VF815U

0

BN-VF823U

0

Battery Charger

AA-VF8

0

HDMI Cable

VX-HD310

0

VX-HD315

0

VX-HD320

0

VX-HD330

0

BN-VF815U is the same battery pack that comes

0

with this unit. BN-VF823U provides a longer
recording time than the provided battery pack. It
can also be used as a spare battery pack.

Enables the battery pack to be charged without

0

using this unit.

Allows viewing in high picture quality when

0

connected to a TV.
Transmits video, audio, and control signals

0

between devices.

Memo :

For more information, consult your JVC dealer.

0

For details on the provided accessories, refer to “Verifying the

0

Accessories”.

“Verifying the Accessories” (A p. 13)

Approximate Recording Time (Using Battery)

3D Display on LCD Monitor

o

Battery Pack Actual Recording Time Continuous Recording Time

3D Recording MP4(MVC) 3D Recording AVCHD 3D Recording MP4(MVC) 3D Recording AVCHD

BN-VF815U
(Supplied)

55 m 1 h 1 h 45 m 2 h

BN-VF823U 1 h 20 m 1 h 35 m 2 h 40 m 3 h 5 m

2D Display on LCD Monitor

o

Battery Pack Actual Recording Time

3D Recording MP4(MVC) 3D Recording AVCHD 2D Recording

BN-VF815U
(Supplied)

BN-VF823U 1 h 25 m 1 h 40 m 1 h 55 m

Battery Pack Continuous Recording Time

BN-VF815U
(Supplied)

BN-VF823U 2 h 45 m 3 h 15 m 3 h 50 m

The above are values when “MONITOR BRIGHTNESS” is set to “STANDARD”.

0

The actual recording time may be shorter if zooming is used or if recording is stopped repeatedly.

0

(It is recommended to prepare battery packs ready for three times the expected recording time.)
When the battery life is reached, the recording time becomes shorter even if the battery pack is fully charged.

0

(Replace the battery pack with a new one.)

55 m 1 h 5 m 1 h 20 m

3D Recording MP4(MVC) 3D Recording AVCHD 2D Recording

1 h 50 m 2 h 10 m 2 h 35 m

26

Taking Videos in 3D Mode

You can record 3D images by pressing the 3D button to set to the 3D mode.
During 3D mode, “3D” is displayed on the LCD monitor.

Open the lens cover.

1

.

Open the LCD monitor and select the video mode.

2

.

0

The video mode icon A appears.

3

Check if the recording mode is P Intelligent Auto.

Recording

You can change the display on the LCD monitor between 3D and 2D

0

during recording by tapping on the 3D/2D icon. The image will be recorded
in 3D even if the display on the LCD monitor is set to 2D. To record 2D
images, press the 3D button to switch to the 2D mode before recording.

“Taking Videos in Intelligent Auto Mode” (A p. 29)

If the microphone level is frequently displayed in red, lower the setting in

0

“MIC LEVEL SETTING” such that the display turns green so that more
realistic audio sounds can be recorded.

“MIC LEVEL SETTING” (A p. 108)

3D recording formats

There are 2 types of 3D recording formats, namely “AVCHD” and
“MP4(MVC)”.
By default, “3D VIDEO REC FORMAT” is set to “AVCHD”.
“Changing the Setting” (A p. 104)

AVCHD

o

Set to this recording format for higher compatibility.

.

0

If the mode is H Manual, press the H/T button to switch to P
Intelligent Auto.
The mode changes between Intelligent Auto and Manual with every
press.

Press the 3D button to set to the 3D mode.

4

.

During 3D mode, “3D” is displayed on the LCD monitor.

0

3D images may be recorded when the 3D button lights up.

0

Start recording.

5

.

Press again to stop.

0

Memo :

To record 3D images, refer also to ““Precautions on Recording and Playing

0

Back 3D Images” (A p. 11) ”.
If the left and right images of an object close to the camera do not appear

0

to be in alignment, or the 3D effect of a distant object is weak, adjust the
parallax.

“Adjusting Parallax During Recording” (A p. 34)

When “PARALLAX ADJUSTMENT” is assigned to the ADJ button,

0

parallax can be adjusted manually using the ADJ button and control dial.

“Using the Control Dial for Recording” (A p. 43)

.

MP4(MVC)

o

Set to this recording format for higher video quality.

.

Memo :

Videos recorded in “MP4(MVC)” format are saved in full high definition

0

and can only be played back on this unit.
To record 3D images to a disc with a Blu-ray recorder or a computer, set

0

to “AVCHD”.
By dubbing videos recorded in “AVCHD” format to a Blu-ray recorder, the

0

left and right images will be recorded or played back separately, allowing
3D images to be enjoyed when connected to a 3D compatible TV.

Videos recorded in “MP4(MVC)” and “AVCHD” are displayed on the

0

playback index screen separately.

27

Recording

Taking Still Images in 3D Mode

You can record 3D images by pressing the 3D button to set to the 3D mode.
During 3D mode, “3D” is displayed on the LCD monitor.

Open the lens cover.

1

.

Open the LCD monitor and select the still image mode.

2

.

0

The still image icon B appears.

Press the 3D button to set to the 3D mode.

3

.

During 3D mode, “3D” is displayed on the LCD monitor.

0

3D images may be recorded when the 3D button lights up.

0

Set the focus on the subject.

4

.

When focused, the focus icon lights up in green.

0

Take a still image.

5

.

PHOTO lights up when a still image is being captured.

0

Memo :

When 3D recording is performed, still images will be saved in both 3D and

0

2D formats.
3D still images are saved as MP files (*.mpo).

0

3D still images cannot be printed. To print, make use of the 2D still image

0

that is captured at the same time.
Use the provided software (Everio Media Browser 3D) to transfer 3D still

0

images to a computer for playback.

“Copying to Windows PC” (A p. 91)

To record 3D images, refer also to ““Precautions on Recording and Playing

0

Back 3D Images” (A p. 11) ”.
If the left and right images of an object close to the camera do not appear

0

to be in alignment, or the 3D effect of a distant object is weak, adjust the
parallax.

“Adjusting Parallax During Recording” (A p. 34)

When “PARALLAX ADJUSTMENT” is assigned to the ADJ button,

0

parallax can be adjusted manually using the ADJ button and control dial.

“Using the Control Dial for Recording” (A p. 43)

28

Recording

Taking Videos in Intelligent Auto Mode

You can record without worrying about the setting details by using the
Intelligent Auto mode.

Before recording an important scene, it is recommended to conduct a trial

0

recording.

Open the lens cover.

1

.

Open the LCD monitor and select the video mode.

2

.

0

The video mode icon A appears.

3

Check if the recording mode is P Intelligent Auto.

Indications During Video Recording

.

Display Icon Description

Parallax

1

Adjustment Value
(3D mode only)

3D VIDEO REC

2

FORMAT (3D mode
only)

Displays the adjusted value when performing
parallax adjustment manually.
“Adjusting Parallax During Recording”
(A p. 34)

Displays the recording format for 3D video
recording.

.

0

If the mode is H Manual, press the H/T button to switch to P
Intelligent Auto.
The mode changes between Intelligent Auto and Manual with every
press.

Start recording.

4

.

Press again to stop.

0

Video Quality Displays the icon of the “VIDEO QUALITY”

3

setting selected in the recording menu.
“VIDEO QUALITY” (A p. 105)

3D/2D Mode Displays the current recording mode of 3D or

4

2D. “3D” is displayed during 3D recording,
while “2D” is displayed during 2D recording.

Image Stabilizer Displays the icon of the “DIS” setting selected

5

in the recording menu.
“Reducing Camera Shake” (A p. 44)

Recording Media Displays the icon of the media where videos

6

are recorded to.
You can change the setting with “REC MEDIA
FOR VIDEO”.
“REC MEDIA FOR VIDEO” (A p. 122)

Battery Indicator Displays the approximate remaining battery

7

power.
Details of the battery power can be displayed
by pressing the INFO button.
“Remaining Recording Time/Battery Power”
(A p. 49)

Recording Mode

8

Displays the current recording mode of P
(Intelligent Auto) or H (Manual).

The mode changes with every press of the
i.AUTO button.

Remaining

9

Recording Time

Displays the remaining time for video
recording.

Scene Counter

0

(Recorded Time)

Displays the elapsed time of the video that is
currently being recorded.

29

Recording

Scenes of Intelligent Auto

o

Display Icon Description

E

A

D

I

B

J

G

H

F

C

K

L

Captures one’s skin beautifully.

Allows people to be captured naturally.

Focuses at a far distance and captures a sharp
image with vivid colors.

Records with minimal noise in the overall image.

Allows night scenes to be captured accurately with
minimal noise in the overall image.

Prevents colors from fading even when recording
in a bright environment.

Records while focusing on a near object.

Reproduces the green color of trees vividly.

Reproduces the colors of sunset naturally.

Adjusts settings so that the subject does not
appear too dark due to backlight.

Allows people to be captured naturally with minimal
noise in the overall image.

Records while focusing on a near object even in a
dark environment.

Operation Buttons for Video Recording

.

Operation Button Description

1

2 / 3

4

Parallax
Adjustment

T/W Zoom Allows the same functions as the zoom

Recording/
Playback Mode

Adjusts the 3D effect when 3D images
are displayed on the LCD monitor.
“Adjusting Parallax During Recording”
(A p. 34)

lever to be performed.
Camera shake that often occurs when
using the zoom lever can be minimized.
“Zooming” (A p. 31)

Switches between recording and
playback modes.

Memo :

Scenes can be detected according to the shooting conditions and

0

automatically adjusted in Intelligent Auto mode.
Some functions may not work properly depending on the shooting

0

conditions.

5 / 6

7

8

9

Recording Start g
Record-Standby

a

LCD Monitor 3D/2D
Display

MENU Displays the various menus of video

Display Button n

Functions as the START/STOP button.

Switches the display on the LCD monitor
between 3D and 2D. The image will be
recorded in 3D even if the display on the
LCD monitor is set to 2D.

recording.
“Operating the Menu” (A p. 99)

Some displays disappear after
approximately 3 seconds.

Use the n button to change the displays
as shown below.

0

Tap n button
Displays appear for approximately 3
seconds with every tap.

0

Tap and hold n button
Displays are fixed such that they do not
disappear. After setting, the display

button changes from n to m.
Tap m to release the displays.

30

Recording

Useful Settings for Recording

When “AUTO POWER OFF” is set to “ON”, this unit turns itself off

0

automatically to conserve power when it is not operated for 5 minutes.
(only when using the battery pack)

“AUTO POWER OFF” (A p. 124)

When “TOUCH PRIORITY AE/AF” is set to “FACE TRACKING”, this unit

0

detects faces and automatically adjusts its brightness and focus to record
the faces more clearly.

“Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 44)

Caution :

Do not expose the lens to direct sunlight.

0

Do not use this unit in the rain, snow, or places with high humidity like the

0

bathroom.
Do not use this unit in places subject to excessive humidity or dust, as well

0

as places exposed to steam or smoke directly.
Do not remove the battery pack, AC adapter, or SD card when the access

0

lamp is lighted. The recorded data may become unreadable.

“Playing a Video with Defective Management Information” (A p. 54)

Make a backup of important recorded data.

0

It is recommended to copy your important recorded data to a DVD or other
recording media for storage.
JVC will not be responsible for any lost data.

Memo :

Before recording an important scene, it is recommended to conduct a trial

0

recording.
Check the remaining recording time in the media before you start shooting.

0

If there is not enough space, move (copy) the data to a computer or disc.
Do not forget to make copies after recording!

0

Recording stops automatically as it cannot be performed for 12 or more

0

consecutive hours according to specifications.
(It may take some time to resume recording.)

For long recordings, the file is split into two or more files if the size exceeds

0

4 GB.
You can connect this unit to the AC adapter to record for long hours

0

indoors.
The maximum number of files that can be recorded to the same media is

0

9999 for MP4 video and still image files respectively.

Zooming

The angle of view can be adjusted using zoom.

Use the W end (wide angle end) to shoot a wider field of view.

0

Use the T end (telephoto end) to magnify the subject for shooting.

0

.

The following zoom options are available:

0

- Optical Zoom (1 – 5x) *During 3D recording

- Optical Zoom (1 – 10x) *During 2D recording

- Digital Zoom (11 – 200x) *During 2D recording
You can also use the zoom (T/W) button on the touch screen to zoom.

0

.

Memo :

When digital zoom is used, the image becomes grainy as it is digitally

0

enlarged.
The zoom ratio range can be changed.

0

“ZOOM (2D mode only)” (A p. 106)

31

Recording

Taking Still Images in Intelligent Auto Mode

You can record without worrying about the setting details by using the
Intelligent Auto mode.

Open the lens cover.

1

.

Open the LCD monitor and select the still image mode.

2

.

0

The still image icon B appears.

3

Check if the recording mode is P Intelligent Auto.

Indications During Still Image Recording

.

Display Icon Description

Image Size Displays the icon of the image size.

1

The size of still images can be changed.

0

“IMAGE SIZE” (A p. 115)

Shutter Speed Displays the shutter speed.

2

Focus Lights up in green when focused.

3

.

0

If the mode is H Manual, press the H/T button to switch to P
Intelligent Auto.
The mode changes between Intelligent Auto and Manual with every
press.

Set the focus on the subject.

4

.

When focused, the focus icon lights up in green.

0

Take a still image.

5

.

PHOTO lights up when a still image is being captured.

0

Recording in

4

Appears when a still image is being captured.

Progress

Remaining Number

5

of Shots

Recording Mode Press the i.AUTO button to switch the

6

Displays the remaining number of shots for still
image recording.

recording mode between P (Intelligent Auto)
and H (Manual).

7

Display Button n

Some displays disappear after approximately
3 seconds.

Use the n button to change the displays as
shown below.

0

Tap n button
Displays appear for approximately 3
seconds with every tap.

0

Tap and hold n button
Displays are fixed such that they do not
disappear. After setting, the display button

changes from n to m.
Tap m to release the displays.

Battery Indicator Displays the approximate remaining battery

8

power.
Details of the battery power can be displayed
by pressing the INFO button.
“Remaining Recording Time/Battery Power”
(A p. 49)

Recording Media Displays the icon of the media where still

9

images are recorded to.
The recording media can be changed.
“REC MEDIA FOR IMAGE” (A p. 123)

32

3D/2D Mode Displays the current recording mode of 3D or

0

2D. “3D” is displayed during 3D recording,
while “2D” is displayed during 2D recording.

Recording

Operation Buttons for Still Image Recording

.

Operation Button Description

1

2 / 3

4

5

Parallax
Adjustment

T/W Zoom Allows the same functions as the zoom

Recording/
Playback Mode

Snapshot

Q

Adjusts the 3D effect when 3D images
are displayed on the LCD monitor.
“Adjusting Parallax During Recording”
(A p. 34)

lever to be performed.
Camera shake that often occurs when
using the zoom lever can be minimized.
“Zooming” (A p. 31)

Switches between recording and
playback modes.

Functions as the SNAPSHOT button.
However, focus cannot be set by
pressing halfway.

Useful Settings for Recording

When “QUICK RESTART” is set to “ON”, this unit turns on immediately if

0

you open the LCD monitor within 5 minutes after the power is turned off
by closing the monitor.

“QUICK RESTART” (A p. 124)

When “AUTO POWER OFF” is set to “ON”, this unit turns itself off

0

automatically to conserve power when it is not operated for 5 minutes.
(only when using the battery pack)

“AUTO POWER OFF” (A p. 124)

When “TOUCH PRIORITY AE/AF” is set to “FACE TRACKING”, this unit

0

detects faces and automatically adjusts its brightness and focus to record
the faces more clearly.

“Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 44)

The image resolution can be changed.

0

“IMAGE SIZE” (A p. 115)

Caution :

Do not expose the lens to direct sunlight.

0

Do not use this unit in the rain, snow, or places with high humidity like the

0

bathroom.
Do not use this unit in places subject to excessive humidity or dust, as well

0

as places exposed to steam or smoke directly.
Do not remove the battery pack, AC adapter, or SD card when the access

0

lamp is lighted. The recorded data may become unreadable.

Memo :

Before recording an important scene, it is recommended to conduct a trial

0

recording.
The digital image stabilizer does not work when recording still images.

0

LCD Monitor 3D/2D

6

Display

MENU Displays the various menus of still image

7

8

Display Button n

Switches the display on the LCD monitor
between 3D and 2D. The image will be
recorded in 3D even if the display on the
LCD monitor is set to 2D.

recording.
“Operating the Menu” (A p. 99)

Some displays disappear after
approximately 3 seconds.

Use the n button to change the displays
as shown below.

0

Tap n button
Displays appear for approximately 3
seconds with every tap.

0

Tap and hold n button
Displays are fixed such that they do not
disappear. After setting, the display

button changes from n to m.
Tap m to release the displays.

33

Recording

Zooming

The angle of view can be adjusted using zoom.

Use the W end (wide angle end) to shoot a wider field of view.

0

Use the T end (telephoto end) to magnify the subject for shooting.

0

.

The following zoom options are available:

0

- Optical Zoom (1 – 5x) *During 3D recording

- Optical Zoom (1 – 10x) *During 2D recording
You can also use the zoom (T/W) button on the touch screen to zoom.

0

.

Memo :

Only optical zoom is available in the still image recording mode.

0

Adjusting Parallax During Recording

When recording 3D images, parallax is automatically adjusted. If the left and
right images of an object close to the camera do not appear to be in
alignment, or the 3D effect of a distant object is weak, you can make
adjustments by bringing the left and right images closer to each other.

Parallax can only be adjusted when 3D images are displayed on the unit’s

0

LCD monitor.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

1

Tap k.

.

Tap “MANUAL”.

2

.

The parallax adjustment screen appears.

0

To set parallax adjustment to auto (default), tap “AUTO”.

0

Adjust the parallax.

3

.

To increase the amount of correction, tap “+”. Doing so increases the

0

value of the parallax display.
To reduce the amount of correction, tap “-”. Doing so decreases the

0

value of the parallax display.

Tap “SET” to confirm.

4

34

.

Caution :

Too much parallax may cause the 3D effect to be lost.

0

If you see double images even after parallax adjustment, set the display

0

on the LCD monitor to 2D immediately.

Memo :

While this unit is equipped with the function to adjust parallax

0

automatically, it may not work properly for the following subjects.

- Subjects beyond the recommended shooting distance (especially
subjects that are extremely close to the camera)

- Numerous subjects of the similar shape arrayed in a line, such as the
windows of a building

- Straight subjects such as electric wires
In these cases, adjust the parallax manually.

When the power of this unit is turned off or the mode is switched to

0

playback after parallax is manually adjusted, the “PARALLAX
ADJUSTMENT” setting returns to “AUTO”.

Recording

Manual Recording

You can adjust settings, such as brightness and shutter speed, by using the
manual mode.
Manual recording can be set for both video and still image modes.

Open the lens cover.

1

.

Open the LCD monitor and select the video or still image mode.

2

.

0

The video A or still image B icon appears.

Select the Manual recording mode.

3

.

0

If the mode is P Intelligent Auto, press the H/T button to switch to

H Manual.

The mode changes between Intelligent Auto and Manual with every

press.

Tap “MENU”.

4

.

Tap the item to set manually.

5

.

For details on the various manual settings, refer to “Manual Recording

0

Menu”.

Memo :

The manual settings are displayed only in the manual recording mode.

0

35

Recording

Manual Recording Menu

The following items can be set.

Name Description

SCENE SELECT

FOCUS

FOCUS ASSIST

FOCUS ASSIST
COLOR

BRIGHTNESS
ADJUST

0

“Scene Selection” (A p. 36)

0

“Adjusting Focus Manually” (A p. 37)

0

“Using Focus Assist” (A p. 38)

0

“FOCUS ASSIST COLOR” (A p. 112)

0

0

“Adjusting Brightness” (A p. 38)

SHUTTER SPEED

0
0

“Setting Shutter Speed” (A p. 39)

Recordings that suit the shooting conditions
can be performed easily.

Use manual focus if the subject is not
focused automatically.

Focused subject is outlined in color for more
precise focus.

Sets the color of the outline of a focused
object when Focus Assist is used.

Overall brightness on the screen can be
adjusted.

Use this when recording in a dark or bright
location.

Shutter speed can be adjusted.
Use this when shooting a fast-moving

subject or to emphasize the subject's
movement.

Scene Selection

Common scenes that are often encountered can be recorded with the most
suitable settings.

Tap “MENU”.

1

.

Tap “SCENE SELECT”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap the appropriate scene.

3

APERTURE PRIORITY

WHITE BALANCE

BACKLIGHT COMP.

TELE MACRO

You can adjust the aperture to capture an

0

image with only the subject in focus while
blurring the surroundings.

“Setting Aperture” (A p. 39)

Overall color on the screen can be adjusted.

0

Use this when the color on the screen

0

appears differently from the actual color.

“Setting White Balance” (A p. 40)

Corrects the image when the subject

0

appears dark due to backlight.
Use this when shooting against the light.

0

“Setting Backlight Compensation” (A p. 41)

Use this to take close-up (macro) shots of the

0

subject.

“Taking Close-up Shots” (A p. 41)
*Displayed only in the 2D recording mode.

.

After setting, the selected scene is immediately put on view.

0

Tap “OFF” to cancel the selection.

0

Tap ∧ or ∨ or flick on the list to move upward or downward for more

0

scene selection.
Tap L to exit the menu.

0

36

Recording

*The image is only an impression.

Setting Effect

b NIGHTALIVE

Increases gain and brightens the scene
automatically using a slow shutter when the
surrounding is dark.
To prevent camera shake, use a tripod.

.

c NIGHT

w PORTRAIT

Captures night scenes naturally.

.

Blurs the background to bring out the people in the
picture.

Adjusting Focus Manually

Set this when the focus is not clear in Intelligent Auto or when manual
focusing is desired.

Tap “MENU”.

1

.

Tap “FOCUS”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “MANUAL”.

3

e SPORTS

f SNOW

g SPOTLIGHT

.

Captures fast-moving subjects clearly in every
single frame.

.

Prevents the subject from appearing too dark when
recording snow scenes on a sunny day.

.

Prevents the human subject from appearing too
bright under light.

.

.

Adjust the focus.

4

.

Tap E to focus on a distant subject.

0
0

Tap p to focus on a near subject.

Tap “SET” to confirm.

5

.

When focus is confirmed, the focusing frame disappears and E and

0

p are displayed. (The icons may appear blinking.)

Memo :

A subject that is focused at the telephoto (T) end remains in focus when

0

it is zoomed out to the wide angle (W) end.
Focus cannot be achieved on a distant or near object beyond limit. ∧ or

0

∨ will appear blinking.
You can also use the control dial to adjust the focus.

0

“Using the Control Dial for Recording” (A p. 43)

37

Recording

Using Focus Assist

Focused subject is outlined in color for more precise focus.

Tap “MENU”.

1

.

Tap “FOCUS ASSIST”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Adjust the focus.

3

Adjusting Brightness

You can adjust the brightness to your preferred level.

Tap “MENU”.

1

.

Tap “BRIGHTNESS ADJUST”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “MANUAL”.

3

.

Tap E to focus on a distant subject.

0
0

Tap p to focus on a near subject.

Tap “SET” to confirm.

4

.

Memo :

The image becomes black and white while the outline of the focused object

0

is displayed in the selected color. Change outline color if it becomes
difficult to see.

“FOCUS ASSIST COLOR” (A p. 112)

.

Adjust the brightness value.

4

.

Compensation range during video recording: -6 to +6

0

Compensation range during still image recording: -2.0 to +2.0

0

Tap ∧ to increase the brightness.

0

Tap ∨ to decrease the brightness.

0

Tap “SET” to confirm.

5

.

Memo :

Settings can be adjusted separately for videos and still images.

0

38

Recording

Setting Shutter Speed

You can set the shutter speed to suit the type of subject.

Tap “MENU”.

1

.

Tap “SHUTTER SPEED”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “MANUAL”.

3

Setting Aperture

You can adjust the aperture to capture an image with only the subject in
focus.

Tap “MENU”.

1

.

Tap “APERTURE PRIORITY”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “MANUAL”.

3

.

Adjust the shutter speed.

4

.

Shutter speed can be set from 1/2 to 1/4000.

0

(Up to 1/500 for still image.)
Tap ∧ to increase the shutter speed.

0

Tap ∨ to decrease the shutter speed.

0

Tap “SET” to confirm.

5

.

After confirmation, the display for adjusting shutter speed disappears.

0

Memo :

Settings can be adjusted separately for videos and still images.

0

While fast-moving subjects can be captured clearly by increasing

0

“SHUTTER SPEED”, the screen appears darker. When recording in dark
places such as indoors, check the brightness of the LCD monitor and set
“SHUTTER SPEED” accordingly.

.

Adjust the aperture.

4

.

Aperture can be set from F1.2 to F5.6.

0

If you want the background to be in focus as well (larger aperture

0

value), tap ∧.

If you want the background to appear blurry (smaller aperture value),

0

tap ∨.

Tap “SET” to confirm.

5

.

After confirmation, the display for adjusting aperture disappears.

0

Memo :

Settings can be adjusted separately for videos and still images.

0

When zoomed to the telephoto end, setting the aperture to the minimum

0

value (F1.2) does not stop it down all the way. In this case, the aperture
value is set according to the zoom and indicated in yellow. Set the zoom

39

Recording

to the wide angle end to enable the aperture to be stopped down all the
way.

The larger the aperture value, the darker the subject appears.

0

Setting White Balance

You can set the color tone to suit the light source.

Tap “MENU”.

1

.

Tap “WHITE BALANCE”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap the appropriate shooting environment.

3

.

Tap ∧ or ∨ to move upward or downward to select.

0

Setting

AUTO Adjusts automatically to the natural colors.

MWB Use this when the problem of unnatural colors is not

resolved.

FINE Set this when shooting outdoors on a sunny day.

CLOUD Set this when shooting on a cloudy day or inside a

shade.

HALOGEN Set this when shooting under illumination such as a

video light.

MARINE:BLUE Set this when shooting the sea at deep water area

(water appears blue).

MARINE:GREEN Set this when shooting the sea at shallow water area

(water appears green).

Details

Using MWB

Hold a sheet of plain white paper in front of the lens so that the white

1

paper fills the screen.

Tap “MWB” and keep touching while the icon appears and blinks.

2

3

Release your touch after the menu disappears and o lights up.

Memo :

The setting will not change if “MWB” is being tapped too fast (less than 1

0

second).
Manual setting is temporarily canceled in the Intelligent Auto mode.

0

40

Recording

Setting Backlight Compensation

You can correct the image when the subject appears too dark due to
backlight.

Tap “MENU”.

1

.

Tap “BACKLIGHT COMP.”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “ON”.

3

Taking Close-up Shots

You can take close-up shots of an object using the tele macro function.

*The image is only an impression.

Tap “MENU”.

1

Tap “TELE MACRO”.

2

.

.

.

After setting, the backlight icon l appears.

0

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “ON”.

3

.

After setting, the tele macro icon o appears.

0

Setting

Details

OFF Enables close-up shots up to 1 m at the telephoto (T) end.

Enables close-up shots up to 5 cm at the wide angle (W) end.

ON Enables close-up shots up to 40 cm at the telephoto (T) end.

Enables close-up shots up to 5 cm at the wide angle (W) end.

Caution :

When you are not taking close-up shots, set “TELE MACRO” to “OFF”.

0

Otherwise, the image may be blur.

41

Recording

Setting the USER Button

By assigning one of manual adjustment functions that you frequently use to
the USER button, you can access the function quickly.

Assigning a Function to the USER Button

Tap “MENU”.

1

.

Tap “USER BUTTON SETTING”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Select the desired function.

3

Making Adjustments with the USER Button

Operate as follows.

In the case of functions that are turned on or off (NIGHTALIVE,

0

BRIGHTNESS ADJUST, SHUTTER SPEED, APERTURE PRIORITY,
BACKLIGHT COMP., DIS, FOCUS ASSIST, SELF-TIMER)

Press the USER button to turn on or off the function.

In the case of FOCUS

0

Press the USER button to switch FOCUS between automatic and manual.
To adjust focus manually, refer to ““Adjusting Focus Manually” (A p. 37) ”.
“Adjusting Focus Manually” (A p. 37)

In the case of functions that have settings to be selected (TOUCH

0

PRIORITY AE/AF, WHITE BALANCE)

1) Press the USER button.

2) Tap the desired function to set.

Memo :

The USER button is invalid when the menu is displayed.

0

.

You can select one of the following functions.

0

Video mode:

0

- NIGHTALIVE

- TOUCH PRIORITY AE/AF

- FOCUS

- BRIGHTNESS ADJUST

- SHUTTER SPEED

- APERTURE PRIORITY

- BACKLIGHT COMP.

- WHITE BALANCE

- FOCUS ASSIST

- DIS
Still image mode:

0

- NIGHTALIVE

- TOUCH PRIORITY AE/AF

- FOCUS

- BRIGHTNESS ADJUST

- SHUTTER SPEED

- APERTURE PRIORITY

- BACKLIGHT COMP.

- WHITE BALANCE

- FOCUS ASSIST

- SELF-TIMER

42

Using the Control Dial for Recording

You can use the control dial to change the settings for “FOCUS”,
“BRIGHTNESS ADJUST”, “SHUTTER SPEED”, “APERTURE PRIORITY”,
“WHITE BALANCE”, and “PARALLAX ADJUSTMENT”.

Press the ADJ button for about 3 seconds to display the control menu.

1

.

A menu screen containing the functions that can adjusted by the

0

control dial is displayed.

Select the function with the control dial.

2

.

For details on setting the items and values of each function, refer to

0

the following.

A BRIGHTNESS ADJUST

“Adjusting Brightness” (A p. 38)

B FOCUS

“Adjusting Focus Manually” (A p. 37)

C SHUTTER SPEED

“Setting Shutter Speed” (A p. 39)

D APERTURE PRIORITY

“Setting Aperture” (A p. 39)

E WHITE BALANCE

“Setting White Balance” (A p. 40)

F PARALLAX ADJUSTMENT

“Adjusting Parallax During Recording” (A p. 34)

G CLEAR

Select this to set all values adjusted by the ADJ button to “AUTO”.

Press the ADJ button.

3

Recording

When “CLEAR” is selected, all values adjusted by the ADJ button will be

0

set to “AUTO”.
(Exits the control menu.)

Caution :

Settings cannot be changed by tapping on the screen while the control

0

dial is being used. Change the setting with the control dial.(except
PARALLAX ADJUSTMENT)

When “3D VIDEO REC FORMAT” is set to “MP4(MVC)” and recording is

0

performed together with HDMI output, the control menu will not be
displayed.

.

The setting screen for the selected function appears.

0

Adjust the assigned function and record.

4

.

Change the setting using the control dial.

0

Press the ADJ button to set to “AUTO” or activate an assigned

0

function.
To change the setting of a different function, press the ADJ button for

0

about 3 seconds. The control menu appears. Go back to step 2 and
select a different function.

Memo :

By assigning “BRIGHTNESS ADJUST”, “FOCUS”, “SHUTTER SPEED”,

0

or “APERTURE PRIORITY” to the control dial, you can adjust the function
while recording.

Only one function can be operated by the control dial. The settings of all

0

other functions will remain unchanged. (Example: When focus is being
adjusted, the settings of brightness and shutter speed remain
unchanged.)

43

Recording

Reducing Camera Shake

When the image stabilizer is set, camera shake during recording can be
effectively reduced.

Tap “MENU”.

1

.

Tap “DIS”.

2

.

Tap “ON” or “ON (AIS)”.

3

Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)

“TOUCH PRIORITY AE/AF” is a function that adjusts focus and brightness
based on a tapped position.
This function is available for both videos and still images.

Select video or still image mode.

1

.

The video or still image mode icon appears.

0

Tap “MENU”.

2

.

Tap “TOUCH PRIORITY AE/AF”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Display

Z (OFF)

X (ON)

r (ON (AIS))

Deactivates image stabilizer.

Reduces camera shake under normal shooting
conditions.

Reduces camera shake more effectively when
shooting bright scenes on the wide angle end.
Only on the wide angle end (during 3D
recording: approx. 5x, during 2D recording:
approx. 10x).

Setting

Memo :

It is recommended to set the image stabilizer to “OFF” when shooting a

0

subject of little movement with the unit on a tripod.
Complete stabilization may not be possible if camera shake is excessive.

0

This setting is effective for video recording only.

0

Setting with the USER Button

When “DIS” is assigned to the USER button, the setting changes with every
press of the button.
“Setting the USER Button” (A p. 42)

0

“OFF”F“ON”F“ON (AIS)”F“OFF”F
The setting changes as above with every press of the USER button.

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap the desired setting.

4

.

Start recording and tap the desired position.

5

.

Focus and brightness will be adjusted automatically based on the

0

tapped position (face/color/area). A blue frame appears around the
selected subject (face/color), while a white frame appears around the
selected area.

To reset, tap the desired position (face/color/area) again.

0

To cancel “FACE TRACKING”, tap the blue frame.

0

To cancel “COLOR TRACKING”, tap the blue frame.

0

To cancel “AREA SELECT”, tap the white frame.

0

44

Setting

Details

OFF Deactivates the function.

Recording

FACE
TRACKING

COLOR
TRACKING

AREA
SELECT

e appears on the screen. Recording is performed
while tracking and automatically adjusting the tapped
face (subject) with appropriate focus and brightness. In
addition, a blue frame appears around the tapped face
(subject).

f appears on the screen. Recording is performed
while tracking and automatically adjusting the tapped
color (subject) with appropriate focus and brightness. In
addition, a blue frame appears around the tapped color
(subject).

g appears on the screen. Recording is performed
while automatically adjusting the tapped area (fixed
position) with appropriate focus and brightness. In
addition, a white frame appears around the tapped area.

Memo :

When “TOUCH PRIORITY AE/AF” is set, “FOCUS” will be set to “AUTO”

0

automatically.
If the camera loses track of a subject, tap the subject again.

0

Settings are canceled when zoom operation is performed. (“AREA

0

SELECT” only)
When “COLOR TRACKING” is set, the targeted subject (color) may

0

change if similar colors are detected. In this case, tap the subject again.
The targeted subject (color) may also be tracked back again if it appears
in the center of the screen within a specific time.

Caution :

Subjects near the sides of the LCD monitor may not respond or be

0

recognized when tapped. In this case, move the subject to the center and
tap again.

“COLOR TRACKING” may not function properly in the following cases:

0

- when recording subjects with no contrast

- when recording subjects that are moving at high speed

- when recording in a dark place

- when the surrounding brightness changes
When “FACE TRACKING” is set, the subject may be lost if the camera is

0

moved vertically or horizontally very fast. To track back the subject, tap on
it again.

Capturing Smiles Automatically (SMILE SHOT)

“SMILE SHOT” automatically captures a still image upon detection of a
smile.

Select still image mode.

1

.

The still image mode icon appears.

0

Tap “MENU”.

2

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “ON”.

4

.

Point the camera toward the human subject.

5

A still image is automatically captured when smiles are detected.

0

.

PHOTO lights up when a still image is being captured.

0

You can display the smile level (%) together with the frame by setting

0

“SMILE LEVEL” in the menu to ON before recording.

“Setting SMILE LEVEL Display (Still image only)” (A p. 46)

Memo :

The camera is able to detect up to 16 faces. Smile levels will be displayed

0

for up to 3 of the largest faces displayed on the screen.
This function may not work properly depending on the shooting conditions

0

(distance, angle, brightness, etc.) and the subject (direction of face, smile
level, etc.). It is also difficult to detect a smile in backlight.

After a smile is detected and captured, it takes time before the next

0

recording may be performed.

Caution :

When “TOUCH PRIORITY AE/AF” is set to “AREA SELECT” or “COLOR

0

TRACKING”, “SMILE SHOT” does not work.
If appropriate results cannot be obtained, record with “SMILE SHOT” set

0

to “OFF”.

Tap “SMILE SHOT”.

3

.

45

Recording

Setting SMILE LEVEL Display (Still image only)

“SMILE LEVEL” allows you to set the items to display when faces are
detected.
This item is only displayed when “TOUCH PRIORITY AE/AF” is set to “FACE
TRACKING”.

Open the LCD monitor and select the still image mode.

1

.

Tap “MENU”.

2

.

Tap “SMILE LEVEL”.

3

Recording at Intervals (TIME-LAPSE RECORDING)

Enables the changes of a scene that occur slowly over a long period to be
shown within a short time by taking frames of it at a certain interval.
This is useful for making observations such as the opening of a flower bud.

Open the LCD monitor and select the video mode.

1

.

0

The video mode icon A appears.

Tap “MENU”.

2

.

Tap “TIME-LAPSE RECORDING”.

3

.

Tap “ON”.

4

.

Setting

Details

OFF Displays only the frames when faces are detected.

ON Displays the frames and smile levels (%) when faces are

detected.

Frame: Appears around detected faces.

0

Smile level: Appears in value (0 % - 100 %) for detected smiles.

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap to select a recording interval (1 to 80 seconds).

4

.

The greater the number of seconds, the longer the recording interval.

0

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Start recording.

5

46

.

A frame is taken at intervals of the selected period.

0

When the recording interval is set to “80SEC INTERVAL”, this unit

0

switches to the power-saving mode between recordings.
At the next point to record, the power-saving mode will be turned off
and recording will start automatically.

Press the START/STOP button again to stop recording.

0

Recording

Indications During Time-Lapse Recording

.

Display Description

Speed Indicator Displays the recording interval that is set.

1

Video Quality Displays the icon of the video quality that is set.

2

Recorded Time Displays the actual recorded time of the video.

3

Actual Elapsed

4

Time

Remaining

5

Recording Time

Recorded time increases in units of frames.

Displays the actual elapsed time after
recording starts.

Remaining time left to record with the currently
selected video quality.

Time-Lapse Setting

The greater the number of seconds, the longer the recording interval.

Setting Details

OFF Deactivates the function.

1SEC INTERVAL Takes a frame at 1-second intervals.

10SEC INTERVAL Takes a frame at 10-second intervals.

80SEC INTERVAL Takes a frame at 80-second intervals.

Recorded videos will be played back at 30 times
speed.

Recorded videos will be played back at 300 times
speed.

Recorded videos will be played back at 2 400 times
speed.

Caution :

Audio cannot be recorded during time-lapse recording.

0

Zooming, simultaneous still image recording, and image stabilizer are not

0

available in time-lapse recording.
When recording is stopped with the recorded time less than “0:00:00:17”

0

, the video will not be saved.

Memo :

Settings of time-lapse recording are reset when the power is turned off.

0

To start time-lapse recording again, it is necessary to make the selection
once more.

Recording stops automatically 99 hours after it is started.

0

Make use of a tripod and AC adapter for time-lapse recordings with long

0

intervals.
It is also recommended to fix the focus and white balance manually.

“Tripod Mounting” (A p. 22)
“Adjusting Focus Manually” (A p. 37)
“Setting White Balance” (A p. 40)

47

Recording

Taking Group Shots (Self-timer)

The 10-second self-timer and Face Detection self-timer are convenient
functions for taking group photos.
The 2-second self-timer is useful for preventing camera shake caused by
pressing the shutter button.

Memo :

When shooting a photo using the self-timer function, use of a tripod is
recommended.
“Tripod Mounting” (A p. 22)

Using the 2-/10-second Self-timer

Select still image mode.

1

.

0

The still image icon B appears.

Tap “MENU”.

2

Take a still image.

6

.

A timer appears and countdown to shooting starts.

0

To stop the self-timer, press the SNAPSHOT button again.

0

Using the Face Detection Self-timer

Pressing the SNAPSHOT button starts face detection, and shooting is
performed three seconds after another person enters the frame.
This function is useful when you want to include the photographer in the
group photo.

Select still image mode.

1

.

0

The still image icon B appears.

Tap “MENU”.

2

.

Tap “SELF-TIMER”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “2SEC” or “10SEC”.

4

.

Set the focus on the subject.

5

.

Tap “SELF-TIMER”.

3

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.

Tap “FACE DETECTION”.

4

.

.

When focused, the focus icon lights up in green.

0

48

Recording

After making sure that everyone is facing the camera, press the

5

SNAPSHOT button.

.

.

Frames appear around the faces of the subjects.

0

Pressing the SNAPSHOT button again starts the 10-second self-

0

timer.

The photographer enters the frame.

6

Remaining Recording Time/Battery Power

You can check the remaining video recording time on the built-in memory
and SD card as well as the remaining battery power.

Open the LCD monitor and select the video or still image mode.

1

.

0

The video A or still image B icon appears.

Press the INFO button.

2

.

If in the still image mode, go directly to step 4.

0

Display the remaining recording time.

3

.

The frames around the faces disappear when the photographer is

0

detected, and a countdown timer appears.
The shutter is released three seconds after the photographer enters

0

the frame.
To stop the self-timer, press the SNAPSHOT button again.

0

Memo :

The “FACE DETECTION” function may fail to detect faces depending on

0

the shooting environment.

.

The remaining recording time is displayed only in the video recording

0

mode.

Press the INFO button to check the remaining recording time of each

0

recording media.

0

To display the remaining battery power, tap l.

0

Tap J to return to the recording mode.

To exit the display, tap L.

0

Display the remaining battery power.

4

.

0

For video recording, tap J to return to the remaining recording time

display. For still image recording, tap to return to the recording mode.

To exit the display, press the INFO button or tap L.

0

Remaining battery power will not be displayed when the AC adapter

0

is connected.

Memo :

You can change to the desired video quality by tapping on it from the

0

remaining recording time display.

49

Recording

Approximate Video Recording Time

3D Mode (MP4(MVC))

o

Quality Built-in Memory

THR 4 h 10 m 30 m 1 h 2 h 3 h 4 h 10 m

TSR 6 h 10 m 20 m 40 m 1 h 30 m 3 h 10 m 4 h 40 m 6 h 20 m

3D Mode (AVCHD)

o

Quality Built-in Memory

TXP 8 h 10 m 30 m 1 h 2 h 4 h 10 m 6 h 10 m 8 h 20 m

TSP 11 h 40 m 40 m 1 h 20 m 2 h 50 m 5 h 50 m 8 h 40 m 11 h 50 m

2D Mode

o

Quality Built-in Memory

UXP 5 h 50 m 20 m 40 m 1 h 20 m 2 h 50 m 4 h 20 m 5 h 50 m

XP 8 h 10 m 30 m 1 h 2 h 4 h 10 m 6 h 10 m 8 h 20 m

SP 11 h 40 m 40 m 1 h 20 m 2 h 50 m 5 h 50 m 8 h 40 m 11 h 50 m

EP 29 h 10 m 1 h 40 m 3 h 40 m 7 h 10 m 14 h 50 m 21 h 50 m 29 h 50 m

(64 GB)

4 GB 8 GB 16 GB 32 GB 48 GB 64 GB

(64 GB)

4 GB 8 GB 16 GB 32 GB 48 GB 64 GB

(64 GB)

4 GB 8 GB 16 GB 32 GB 48 GB 64 GB

SDHC/SDXC Card

SDHC/SDXC Card

SDHC/SDXC Card

The actual recording time may shorten depending on the shooting environment.

0

Approximate Number of Still Images (Unit: Number of Shots)

3D Mode

o

Image Size SDHC Card Built-in Memory

4 GB 8 GB 16 GB 32 GB

1920X1080(2M)(16:9) 1,000 2,200 4,400 4,999 4,999

2D Mode

o

Image Size SDHC Card Built-in Memory

4 GB 8 GB 16 GB 32 GB

2304X1296(2.9M)(16:9) 2,200 4,600 9,100 9,999 9,999

1920X1080(2M)(16:9) 3,200 6,700 9,999 9,999 9,999

1728X1296(2.2M)(4:3) 3,000 6,200 9,999 9,999 9,999

640X480(0.3M)(4:3) 9,999 9,999 9,999 9,999 9,999

Regardless of image size and quality, up to 9999 still images may be recorded on the built-in memory (during 2D mode) and SD cards with at least 16 GB

0

capacity (except for “2,304 x 1,296 (2.9M) (16:9)”).

(64 GB)

(64 GB)

50

Approximate Recording Time (Using Battery)

3D Display on LCD Monitor

o

Battery Pack Actual Recording Time Continuous Recording Time

3D Recording MP4(MVC) 3D Recording AVCHD 3D Recording MP4(MVC) 3D Recording AVCHD

Recording

BN-VF815U
(Supplied)

BN-VF823U 1 h 20 m 1 h 35 m 2 h 40 m 3 h 5 m

2D Display on LCD Monitor

o

Battery Pack Actual Recording Time

BN-VF815U
(Supplied)

BN-VF823U 1 h 25 m 1 h 40 m 1 h 55 m

Battery Pack Continuous Recording Time

BN-VF815U
(Supplied)

BN-VF823U 2 h 45 m 3 h 15 m 3 h 50 m

The above are values when “MONITOR BRIGHTNESS” is set to “STANDARD”.

0

The actual recording time may be shorter if zooming is used or if recording is stopped repeatedly.

0

(It is recommended to prepare battery packs ready for three times the expected recording time.)
When the battery life is reached, the recording time becomes shorter even if the battery pack is fully charged. (Replace the battery pack with a new one.)

0

55 m 1 h 1 h 45 m 2 h

3D Recording MP4(MVC) 3D Recording AVCHD 2D Recording

55 m 1 h 5 m 1 h 20 m

3D Recording MP4(MVC) 3D Recording AVCHD 2D Recording

1 h 50 m 2 h 10 m 2 h 35 m

51

Playback

Playing Back Videos

You can select and play back the recorded videos from an index screen
(thumbnail display).

Select video mode.

1

.

0

The video mode icon A appears.

2

Tap q to select the playback mode.

.

Press the 3D button to select 3D or 2D mode.

3

To play back 3D images, refer also to “Precautions on Recording and

0

Playing Back 3D Images”.

“Precautions on Recording and Playing Back 3D Images” (A p. 11)

.

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode
for playback.

During 3D mode, “3D” is displayed on the LCD monitor.

0

During 2D mode, “2D” is displayed on the LCD monitor.

0

Tap on the file to start playback.

4

.

Tap I/J to select the media for playback and change the index

0

screen (thumbnail display).

0

Tap e to pause.

0

Tap u to return to the index screen.

Memo :

Images recorded in 2D mode cannot be displayed as 3D images.

0

3D images may be played back when the 3D button lights up.

0

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode for
playback.

3D images recorded in “MP4(MVC)” format and “AVCHD” format are

0

displayed on the index screen separately.
Change the setting of 3D VIDEO REC FORMAT to the desired format for
playback.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

Scenes that are likely to cause motion sickness during 3D playback may

0

be played back in stop-motion, but this is not a malfunction. To play back
normally, set “3D MOTION RELIEF” to “OFF”.

“3D MOTION RELIEF (3D mode only)” (A p. 117)

Caution :

52

Playback

Operation Buttons for Video Playback

During Index Screen Display

.

Display Description

Date Moves to the previous/next date

1

3D/2D Mode Displays the current playback mode of 3D or

2

< Displays the previous index screen (thumbnail

3

> Displays the next index screen (thumbnail

4

Thumbnail (File) Tap on thumbnail - Starts playback

5

Recording/

6

Playback Mode

q

A

7

I/J

8

MENU Displays the menu screen

9

2D. “3D” is displayed during 3D playback, while
“2D” is displayed during 2D playback.

display)

display)

Drag to right - Scrolls to the right to show the
previous index screen (thumbnail display)
Drag to left - Scrolls to the left to show the next
index screen (thumbnail display)

Switches between recording and playback
modes.

Displays the index screen (thumbnail display)
to perform deletion

Switches between the index screen of the built­in memory and SD card

During Video Playback

.

Display Description

3D/2D Mode Displays the current playback mode of 3D or

1

Pointer Displays the current estimated playback

2

3

k

h

4

j

5

d / e

6

i

7

g

8

Recording/

9

Playback Mode

q

u

0

A

a

b

x

MENU Displays the menu screen

c

2D. “3D” is displayed during 3D playback, while
“2D” is displayed during 2D playback.

position within the scene

Enables manual parallax adjustment

Returns to the beginning of the scene

Reverse search

Playback/pause

Forward search

Advances to the next video

Switches between recording and playback
modes.

Stop (returns to index screen)

Displays the index screen (thumbnail display)
to perform deletion

Switches between 3D and 2D modes.

Memo :

Tap or drag on the operation area of the touch screen.

0

Operations buttons on the touch screen disappear if the unit is not

0

operated for about 5 seconds. Tap on the screen to display the operation
buttons again.

Operation buttons on the touch screen are displayed as long as there is

0

contact with the effective operation area.
You can search for a specific file by the recording date.

0

“Date Search” (A p. 58)

Caution :

Make a backup of important recorded data.

0

It is recommended to copy your important recorded data to a DVD or other
recording media for storage.
JVC will not be responsible for any lost data.

53

Playback

Adjusting the Volume of Videos

A Press the zoom lever during video playback.

.

Checking the Recording Date and Other Information

A Select a file and press the INFO button while playback is paused.

You can display the recording date and duration of the selected file.

.

Playing a Video with Defective Management Information

Plays videos with defective management information.

Select video mode.

1

.

2

Tap q to select the playback mode.

.

Tap “MENU”.

3

.

Tap “PLAYBACK OTHER FILE”.

4

.

Tap on the file to start playback.

5

.

“Playing Back Videos” (A p. 53)

Memo :

An MTS file is created in the EXTMOV folder when management

0

information is corrupted.
The thumbnails of the 3D files in the EXTMOV folder will be shown as

0

images separated into left and right on the index screen but this is not a
malfunction.

Depending on the condition of the damaged file, playback might fail or

0

may not run smoothly.

54

Playback

Playing Back Still Images

You can select and play back the recorded still images from an index screen
(thumbnail display).
The contents of the selected media are displayed on the index screen.
“REC MEDIA FOR IMAGE” (A p. 123)

Select still image mode.

1

.

2

Tap q to select the playback mode.

.

Press the 3D button to select 3D or 2D mode.

3

Operation Buttons for Still Image Playback

During Index Screen Display

.

Display Description

Date Moves to the previous/next date

1

3D/2D Mode Displays the current playback mode of 3D or

2

Thumbnail (File) Tap on thumbnail - Starts playback

3

2D. “3D” is displayed during 3D playback, while
“2D” is displayed during 2D playback.

Drag to right - Scrolls to the right to show the
previous index screen (thumbnail display)
Drag to left - Scrolls to the left to show the next
index screen (thumbnail display)

.

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode
for playback.

During 3D mode, “3D” is displayed on the LCD monitor.

0

During 2D mode, “2D” is displayed on the LCD monitor.

0

Tap on the file to start playback.

4

.

Tap I/J to select the media for playback and change the index

0

screen (thumbnail display).

0

Tap u to return to the index screen.

0

Tap W to show all the thumbnails that are displayed in a group.
Tap again to restore the group.

Memo :

Only 3D images are displayed during the 3D mode. Similarly, only 2D

0

images are displayed during the 2D mode.
3D images may be played back when the 3D button lights up.

0

You can search for a specific file by the recording date.

0

This is useful when searching from a large number of files.

“Date Search” (A p. 58)

Caution :

To play back 3D images, refer also to “Precautions on Recording and

0

Playing Back 3D Images”.

“Precautions on Recording and Playing Back 3D Images” (A p. 11)

Recording/

4

Playback Mode

q

5

W

A

6

I/J

7

MENU Displays the menu screen

8

Recording Date Recording date (only displayed on the first file

9

Switches between recording and playback
modes.

Switches between the group or full index
screen displays.

Displays the index screen (thumbnail display)
to perform deletion

Switches between the index screen of the built­in memory and SD card

of each date)

55

Playback

During Still Image Playback

.

Display Description

3D/2D Mode Displays the current playback mode of 3D or

1

2

T

3

k

h

4

Recording/

5

Playback Mode

q

u

6

A

7

8

x

MENU Displays the menu screen

9

2D. “3D” is displayed during 3D playback, while
“2D” is displayed during 2D playback.

Continuous playback of grouped files (such as
still images captured by continuous shooting).

Enables manual parallax adjustment

Returns to the previous still image

Switches between recording and playback
modes.

Returns to index screen

Displays the index screen (thumbnail display)
to perform deletion

Switches between 3D and 2D modes.

Adjusting Parallax During Playback

When playing back 3D images of scenes where there are multiple objects
arrayed in a line from near to far, or objects that are extremely close to the
camera, you can change the way they appear to the eye.

Parallax can only be adjusted when 3D images are displayed on the unit’s

0

LCD monitor.

1

Tap k.

.

Tap “MANUAL”.

2

.

The parallax adjustment screen appears.

0

To set parallax adjustment to auto (default), tap “AUTO”.

0

Adjust the parallax.

3

0

a

g

d

Advances to the next still image

Starts/pauses slideshow
“Slideshow Playback” (A p. 57)

Memo :

Tap or drag on the operation area of the touch screen.

0

Operations buttons on the touch screen disappear if the unit is not

0

operated for about 5 seconds. Tap on the screen to display the operation
buttons again.

Operation buttons on the touch screen are displayed as long as there is

0

contact with the effective operation area.

Checking the Recording Date and Other Information

A Press the INFO button.

You can display the recording date of the selected file.

.

.

To increase the amount of correction, tap “+”. Doing so increases the

0

value of the parallax display.
To reduce the amount of correction, tap “-”. Doing so decreases the

0

value of the parallax display.

Tap “SET” to confirm.

4

.

Caution :

Too much parallax may cause the 3D effect to be lost.

0

If you see double images even after parallax adjustment, set the display

0

on the TV to 2D immediately. In addition, set the LCD monitor to 2D display
accordingly.

Memo :

While this unit is equipped with the function to adjust parallax

0

automatically, it may not work properly for the following subjects.

- Subjects beyond the recommended shooting distance (especially
subjects that are extremely close to the camera)

- Numerous subjects of the similar shape arrayed in a line, such as the
windows of a building

- Straight subjects such as electric wires
In these cases, adjust the parallax manually.

56

When the power of this unit is turned off or the mode is switched to

0

recording after parallax is manually adjusted, the “PARALLAX
ADJUSTMENT” setting returns to “AUTO”.

Slideshow Playback

Still images can be played back in a slideshow.

Select still image mode.

1

.

2

Tap q to select the playback mode.

.

Press the 3D button to select 3D or 2D mode.

3

Playback

.

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode

for playback.

During 3D mode, “3D” is displayed on the LCD monitor.

0

During 2D mode, “2D” is displayed on the LCD monitor.

0

4

Tap on the thumbnail and tap d.

.

“Operation Buttons for Still Image Playback” (A p. 55)

57

Playback

Searching for a Specific Video/Still Image

When there is a large number of recorded videos and still images, it is difficult
to look for the desired file from the index screen.
Use the search function to find the file you want.

For both videos and still images, you can search by “SEARCH DATE”

0

(recording date).

“To search by recording dates” (A p. 58)

Date Search

You can search and play videos or still images according to recording dates.

The contents of the media selected in “REC MEDIA FOR VIDEO” or “REC

0

MEDIA FOR IMAGE” are searched.

Tap “MENU”.

1

.

Searching can be performed in both the video and still image modes.

0

*The image shows the video mode.

Tap “SEARCH DATE”.

2

Connecting to and Viewing on TV

You can connect this unit to a TV for playback. Select the most suitable way
of connecting to the TV based on the image to view (3D/2D image).

Refer also to the instruction manual of the TV in use.

0

“Playing Back 3D Images” (A p. 58)
“Playing Back 2D Images” (A p. 60)

Unnatural Displays on TV

Trouble Action

Images do not
appear on the TV
properly.

Images are
projected vertically
on the TV.

Images are
projected
horizontally on the
TV.

The color of images
looks strange.

Disconnect the cable and connect again.

0

Turn off and on this unit again.

0

Set “VIDEO OUTPUT” in the “COMMON” menu

0

to “4:3”.

“VIDEO OUTPUT (2D mode only)” (A p. 127)

Adjust the TV's screen accordingly.

0

If the video was recorded with “x.v.Color” set to

0

“ON”, set the x.v.Color setting of the TV to on.

“x.v.Color (2D mode only)” (A p. 106)

Adjust the TV's screen accordingly.

0

.

Select a recording date and tap “NEXT”.

3

.

Tap again to cancel the selected date.

0

Tap on the file to start playback.

4

HDMI-CEC
functions do not
work properly, and
the TV does not
work in conjunction
with this unit.

The language on
the display
changed.

3D images are not
displayed in 3D.

TVs may operate differently depending on the

0

specifications, even if they are HDMI-CEC
compliant. Therefore, the HDMI-CEC functions
of this unit cannot be guaranteed to operate in
combination with all the TVs. In such cases, set
“HDMI CONTROL” to “OFF”.

“HDMI CONTROL” (A p. 129)

It may occur when you connect this unit to a TV

0

with different language setting using an HDMI
mini cable.

Set “HDMI OUTPUT” in the “COMMON” menu

0

to “CERTAIN TV TYPES”.

“HDMI OUTPUT” (A p. 128)

Memo :

Fatigue or discomfort may be experienced if you view 3D images for a long

0

period of time. When viewing 3D images on this unit, a message will be
displayed every 30 minutes. To turn off the message display, set “3D
DISPLAY WARNING” to “OFF”.

“3D DISPLAY WARNING (3D mode only)” (A p. 127)

When recording 3D images, parallax is automatically adjusted. If the left

0

and right images of an object close to the camera do not appear to be in
alignment, or the 3D effect of a distant object is weak, you can change the
way they appear to the eye by adjusting the parallax.

“Adjusting Parallax During Playback” (A p. 56)

You can enjoy realistic audio sounds by viewing the video from the center

0

of the TV or center of the right and left speakers.

.

You can select videos in the video mode and still images in the still

0

image mode.
Only the files recorded on the selected date are displayed.

0

Deleting Files of a Selected Date

Tap A on the index screen (thumbnail display) to delete unwanted files.
“Deleting Unwanted Files” (A p. 65)

：

58

Playing Back 3D Images

If you are using a 3D compatible TV, you can play back 3D images by
connecting to the HDMI connector.

Use the provided HDMI mini cable or an optional High Speed HDMI mini

0

cable.
Refer also to the instruction manual of the TV in use.

0

Close the LCD monitor.

1

.

Close the LCD monitor to turn off the camcorder before connecting

0

to a TV.

Connect to a TV.

2

.

Connect the AC adapter to this unit.

3

Playback

When connected to the TV via the provided HDMI mini cable, images and

0

sounds may not be output properly depending on the TV connected.
In such cases, perform the following operations.

1) Disconnect the HDMI mini cable and connect it again.

2) Turn off and on this unit again.
If 3D images cannot be seen properly, change the setting in “HDMI

0

OUTPUT”. Refer also to the instruction manual of the TV in use.

“HDMI OUTPUT” (A p. 128)

The displayed 3D images may vary depending on the size of the TV

0

connected.
For questions about the TV or method of connection, contact your TV's

0

manufacturer.

.

This unit powers on automatically when the LCD monitor is opened.

0

Press the external input button on the TV to switch to the input from this

4

unit via the connected connector.

.

Play back a file.

5

.

“Playing Back Videos” (A p. 52)
“Playing Back Still Images” (A p. 55)

Caution :

To play back 3D images, refer also to “Precautions on Recording and

0

Playing Back 3D Images”.

“Precautions on Recording and Playing Back 3D Images” (A p. 11)

If you experience fatigue or discomfort while viewing 3D images, set

0

“HDMI OUTPUT” in the “COMMON” menu to “2D OUTPUT”. In addition,
set the TV to 2D display accordingly.

“HDMI OUTPUT” (A p. 128)

Memo :

59

Playback

Operating in Conjunction with TV via HDMI

Connecting this unit to an HDMI-CEC-enabled TV using the HDMI cable
allows linked operations with the TV to be performed.

HDMI-CEC (Consumer Electronics Control) is an industry standard that

0

enables interoperability between HDMI-CEC compliant devices that are
connected via HDMI cables.

Memo :

Not all HDMI-control devices comply with the HDMI-CEC standard. The

0

HDMI control function of this unit will not work when connected to these
devices.

This unit is not guaranteed to operate with all HDMI-CEC-enabled

0

devices.
Depending on the specifications of each HDMI-CEC-enabled device,

0

some functions may not work with this unit. (For details, refer to the
instruction manual of your TV.)

Unintended operations may occur with some connected devices. In these

0

cases, set “HDMI CONTROL” to “OFF”.

“HDMI CONTROL” (A p. 129)

Preparations

Close the LCD monitor to turn off the camcorder before connecting to a

0

TV.
Connect an HDMI cable between this unit and the TV.

0

“Connecting via the HDMI Mini Connector” (A p. 61)

Turn on the TV and set the HDMI-CEC related setting to “ON”. (For details,

0

refer to the instruction manual of the TV.)
Turn on this unit and set “HDMI CONTROL” in the “COMMON” menu to

0

“ON”.

“HDMI CONTROL” (A p. 129)

“Connecting via the AV Connector” (A p. 62)

Operation Method 1

Turn on this unit.

1

Select the playback mode.

2

Connect the HDMI cable.

3

TV turns on automatically and switches to HDMI input mode when

0

this unit is turned on.

Operation Method 2

Turn off the TV.

1

This unit turns off automatically.

0

Memo :

Depending on the TV connected, the display language of this unit will

0

automatically switch to the language that is selected for the TV when this
unit is turned on.
(This is applicable only if this unit supports the language selected for the
TV.) To use this unit with a language that differs from the display language
of the TV, set “HDMI CONTROL” to “OFF”.

The display language of the TV will not switch automatically, even if the

0

display language of this unit is changed.
These functions may not work correctly when devices such as amplifier

0

and selector are connected. Set “HDMI CONTROL” to “OFF”.
If HDMI-CEC does not work properly, turn off and on this unit again.

0

Caution :

Do not remove the recording medium or perform any other operation (such

0

as turning off the power) while accessing files. Also, be sure to use the
provided AC adapter, as the data on the recording medium may be
corrupted if the battery becomes exhausted during operation. If the data
on the recording medium becomes corrupted, format the recording
medium to use the medium again.

Playing Back 2D Images

The image quality on TV varies with the type of TV and the connecting cable.
Select the connector that best suits your TV.

Refer also to the instruction manual of the TV in use.

0

“Connecting via the HDMI Mini Connector” (A p. 61)

60

Connecting via the HDMI Mini Connector

If you are using an HDTV, you can play back in HD quality by connecting to
the HDMI connector.

Use a High Speed HDMI Cable.

0

Refer also to the instruction manual of the TV in use.

0

Close the LCD monitor.

1

.

Close the LCD monitor to turn off the camcorder before connecting

0

to a TV.

Connect to a TV.

2

Playback

When connected to the TV via the HDMI mini cable, images and sounds

0

may not be output properly depending on the TV connected.
In such cases, perform the following operations.

1) Disconnect the HDMI mini cable and connect it again.

2) Turn off and on this unit again.
For questions about the TV or method of connection, contact your TV's

0

manufacturer.

.

Connect the AC adapter to this unit.

3

.

This unit powers on automatically when the LCD monitor is opened.

0

Press the external input button on the TV to switch to the input from this

4

unit via the connected connector.

.

Play back a file.

5

“Playing Back Videos” (A p. 52)

.

“Playing Back Still Images” (A p. 55)

Memo :

Change the settings in “HDMI OUTPUT” according to the connection.

0

“HDMI OUTPUT” (A p. 128)

61

Playback

Connecting via the AV Connector

By connecting the supplied AV cable to the AV connector, videos can be
played back on a TV.

Refer also to the instruction manual of the TV in use.

0

Open the LCD monitor, then press and hold the power button for 2

1

seconds or more to turn off the power.

.

Connect to a TV.

2

.

A Connect using the provided AV cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

Press the external input button on the TV to switch to the input from this

3

unit via the connected connector.

.

Play back a file.

4

.

“Playing Back Videos” (A p. 52)
“Playing Back Still Images” (A p. 55)

Memo :

For questions about the TV or method of connection, contact your TV's

0

manufacturer.

62

Playback

Playing Back a DVD or Blu-ray Disc Created on this Unit

BD/DVDs created using the backup function on this unit can be played back on TV using an optional DVD writer (DVDs only) with playback function (CU­VD50U) or a normal BD/DVD player. DVDs can also be played back on this unit by connecting the optional DVD writer with playback function.
“Playing Back with a DVD Writer” (A p. 77)
“Playing Back with an External Blu-ray Drive” (A p. 82)
“Playing Back Files in the USB External Hard Disk Drive” (A p. 85)

For details on how to play back on a normal DVD or Blu-ray disc player, refer to the instruction manual of the player.

0

3D (AVCHD) Files

o

Playback Device DVD

DVD writer with playback function (CU-VD3U,
CU-VD50U)

External Blu-ray drive connected to this unit -

DVD player/
DVD recorder

Blu-ray player/
Blu-ray recorder

USB external hard disk drive - - -

Computer - *2 *2 *2

*1: Only on AVCHD compatible devices.
*2: Use Everio MediaBrowser 3D Player to play back an AVCHD file on the computer. Refer to the help file of the provided Everio MediaBrowser 3D software
to operate.

(DVD-Video format)

-

-

-

DVD

(AVCHD format)

P

P P

P*1

P*1 P*1 P

Blu-ray Disc Device’s Internal HDD

- -

-

-

P

P

Memo :

When AVCHD files recorded in 3D are played back on a normal recorder or player, the left and right images will be displayed separately.

0

When there are many files in the disc, it may take time for them to be displayed on the screen. Wait for a while as the access lamp appears blinking, which

0

indicates normal operation.

3D (MP4(MVC)) Files

o

Playback Device

DVD

(DVD-Video format)

DVD

(AVCHD format)

Blu-ray Disc Device’s Internal HDD

DVD writer with playback function (CU-VD3U,
CU-VD50U)

External Blu-ray drive connected to this unit - -

DVD player/
DVD recorder

Blu-ray player/
Blu-ray recorder

USB external hard disk drive - - -

Computer - - - *

* Use Everio MediaBrowser 3D Player to play back an MP4(MVC) file on the computer. Refer to the help file of the provided Everio MediaBrowser 3D software
to operate.

- - - -

P

- - - -

- - - -

-

P

Memo :

Videos recorded in MP4(MVC) format can be copied or played back only when dubbed to a Blu-ray disc or hard disk drive.

0

Copy or play back by connecting this unit to an external Blu-ray drive or USB external hard disk drive.
When there are many files in the disc, it may take time for them to be displayed on the screen. Wait for a while as the access lamp appears blinking, which

0

indicates normal operation.

63

Playback

2D Files

o

Playback Device DVD

DVD writer with playback function (CU-VD3U,
CU-VD50U)

External Blu-ray drive connected to this unit

DVD player/
DVD recorder

Blu-ray player/
Blu-ray recorder

USB external hard disk drive - - -

Computer

*1: Only on AVCHD compatible devices.
*2: Use Everio MediaBrowser 3D Player to play back an AVCHD file on the computer. Refer to the help file of the provided Everio MediaBrowser 3D software
to operate.

(DVD-Video format)

P P

P P P

P P*1

P P*1 P*1 P

P

DVD

(AVCHD format)

*2 *2

Blu-ray Disc Device’s Internal HDD

- -

-

-

P

P

P

Memo :

When there are many files in the disc, it may take time for them to be displayed on the screen. Wait for a while as the access lamp appears blinking, which

0

indicates normal operation.

Caution :

DVDs that are created in AVCHD format cannot be played back on DVD players with standard quality. You may not be able to remove the disc from the

0

player.

Digest Playback on a Blu-ray or DVD Player

You can play back a few seconds from each scene of the recorded videos in the created disc.

Load the created disc on a player.

1

Select “DIGEST PLAYBACK” on the TV.

2

The digest is played back continuously.

0

(The screen does not appear on this unit.)

.

Memo :

To normal playback/To index menu

0

1) Press the top menu button on the remote control of the player during digest playback.

2) Select the desired item.
“DIGEST PLAYBACK” menu is not available when the DVD is created using the provided Everio MediaBrowser 3D software.

0

Digest Playback is not available when playing back by connecting this unit to a DVD writer or external Blu-ray drive.

0

Digest Playback is not available for MP4(MVC) videos recorded to discs.

0

64

Deleting Unwanted Files

Delete unwanted videos and still images when the space in the recording
media is running out.
The remaining space in the recording media increases after deleting the files.
“Deleting the Currently Displayed File” (A p. 65)
“Deleting Selected Files” (A p. 65)

Memo :

Deleted files cannot be restored.

0

Files that are protected cannot be deleted.

0

Release protection before deleting the file.

“Protecting Files” (A p. 66)

Be sure to back up important files on a PC.

0

“Backing Up All Files” (A p. 93)

Caution :

Do not remove the recording medium or perform any other operation (such

0

as turning off the power) while accessing files.
Be sure to use the supplied JVC AC adapter.

0

If the data on the recording medium becomes corrupted, format the

0

recording medium to use the medium again.

“FORMAT SD CARD” (A p. 131)

Deleting the Currently Displayed File

Deletes the currently displayed file.

Caution :

Deleted files cannot be restored.

0

.

2

Tap q to select the playback mode.

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

3

Tap A.

Editing

1

Tap A.

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap “YES”.

2

.

0

Tap h / g to select the previous or next file.
When no file remains, the screen returns to the index screen.

0

Memo :

Files that are protected cannot be deleted.

0

Release protection before deleting the file.

“Protecting Files” (A p. 66)

.

Tap on the files to delete.

4

.

P appears on the selected files.

0

To remove P from a file, tap on the file again.

Tap “SEL ALL” to select all files.

0

Tap “REL ALL” to release all selections.

0

Still images that are recorded continuously within 2 seconds or with

0

the continuous shooting mode will be grouped together. Only the first

recorded file is shown and the group is displayed with a green frame.

When this is tapped, an index screen of the grouped files appears.

Tap on the files to delete, then tap “J”.

Tap “SET”.

5

Deleting Selected Files

Deletes the selected files.

Caution :

Deleted files cannot be restored.

0

Select video or still image mode.

1

.

Tap “EXECUTE” to confirm the deletion.

6

.

65

Editing

After deleting is complete, tap “OK”.

0

To cancel the deletion, tap “QUIT”.

0

Memo :

Files that are protected cannot be deleted.

0

Release protection before deleting the file.

“Protecting Files” (A p. 66)

Protecting Files

Prevent important videos/still images from being deleted accidently by
protecting them.
“Protecting/Releasing Protection of the Currently Displayed File”
(A p. 66)
“Protecting/Releasing Protection of Selected Files” (A p. 66)

Caution :

When the recording media is formatted, even the protected files will be

0

deleted.

Protecting/Releasing Protection of the Currently Displayed File

Protects or releases protection of the currently displayed file.

Tap “MENU”.

1

.

Tap “PROTECT/CANCEL”.

2

.

Tap “YES”.

3

.

0

Tap h / g to select the previous or next file.
After setting, tap “OK”.

0

Protecting/Releasing Protection of Selected Files

Protects or releases protection of the selected files.

Select video or still image mode.

1

.

2

Tap q to select the playback mode.

66

.

Tap “MENU”.

3

.

Tap “PROTECT/CANCEL”.

4

Editing

Capturing a Still Image in the Video during Playback

You can capture still images of the scenes you like in the recorded videos.

Select video mode.

1

.

2

Tap q to select the playback mode.

.

Tap on the desired video.

3

.

Tap on the files to protect or release protection of.

5

.

0

I and P are displayed on the files that are already protected.
To release protection of a file, tap on the file such that P is removed.

P appears on the selected files.

0

To remove P from a file, tap on the file again.
Tap “SEL ALL” to select all files.

0

Tap “REL ALL” to release all selections.

0

Still images that are recorded continuously within 2 seconds or with

0

the continuous shooting mode will be grouped together. Only the first
recorded file is shown and the group is displayed with a green frame.
When this is tapped, an index screen of the grouped files appears.

Tap on the files to protect or release protection of, then tap “J”.

Tap “SET”.

6

.

4

Tap pause e at the desired scene during playback.

.

After pausing the video, you can fine-tune the point to capture by

0

tapping forward slow-motion k and reverse slow-motion l.

Press the SNAPSHOT button.

5

.

Memo :

Still images are captured with a size of 1920×1080.

0

Captured still images are stored in the media where the video is being

0

played back from.
Still images cannot be captured from 3D videos.

0

.

0

Protect marks I appear on the selected files.
Protect marks I disappear from the deselected files.

67

Editing

Capturing a Required Part in the Video (TRIMMING)

Select the required part of a video and save it as a new video file.

The original video remains in its existing location.

0

Select video mode.

1

.

2

Tap q to select the playback mode.

.

Tap “MENU”.

3

7

Tap e to pause playback at the desired end point, then tap “B”.

.

To reset the start or end point, tap “A” or “B” at the desired scene

0

(position).

Tap “SET”.

8

.

Tap “SET”.

9

.

Tap “TRIMMING”.

4

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap on the video to edit.

5

.

6

Tap e to pause playback at the desired start point, then tap “A”.

.

When copying finishes, the copied file is added to the index screen.

0

After copying, tap “OK”.

0

Memo :

The division point may deviate slightly from the selected scene.

0

68

.

Editing

Capturing Videos for Uploading to YouTube

Capture and copy a part of a recorded video (maximum 15 minutes) for
uploading to YouTube, and save it as a YouTube video.
When capturing videos for YouTube, the duration cannot be longer than 15
minutes.

Select video mode.

1

.

2

Tap q to select the playback mode.

.

Tap “MENU”.

3

7

Tap e to pause playback at the desired start point, then tap “A”.

.

8

Tap e to pause playback at the desired end point, then tap “B”.

.

To reset the start or end point, tap “A” or “B” at the desired scene

0

(position).

When capturing videos for YouTube, the duration cannot be longer

0

than 15 minutes.

Tap “SET”.

9

.

Tap “UPLOAD SETTINGS”.

4

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap on the desired video.

5

.

Tap “TRIM”.

6

When trimming is not necessary, tap “DO NOT TRIM”.

0

.

Tap “YES”.

10

.

After copying, tap “OK”.

0

When copying finishes, the copied file is added to the index screen.

0

To exit upload settings, tap “STOP” on the upload settings screen.

0

After copying, tap “OK”.

0

Memo :

The division point may deviate slightly from the selected scene.

0

Uploading Videos to YouTube

You can upload your videos to YouTube using the provided software Everio
MediaBrowser 3D. Install the software on your PC and connect this unit to
the PC.

For details on how to use the software, refer to the help file.

0

“Installing the Provided Software” (A p. 92)
“Connecting this Unit to PC” (A p. 93)

Trouble with Uploading Videos

Check if you have created an account with YouTube. (You need a

0

YouTube account to upload files to YouTube.)
Refer to “Q&A”, “Latest Information”, “Download Information”, etc. in “Click

0

for Latest Product Info” in the help file of the provided software Everio
MediaBrowser 3D.

：

.

If the selected video is more than 15 minutes, trimming is necessary.

0

69

Copying

Copying Files

You can create discs or copy the files on this unit by connecting it to various devices.

Select the appropriate method of copying according to the device. If you are unsure about the method of copying, refer to “Copying Your Files”.

0

“Copying Your Files” (A p. 0 )

3D (AVCHD) Files

o

P: Can be copied, -: Cannot be copied

Recording Device DVD

DVD writer connected to this unit
“Creating Discs with a DVD Writer” (A p. 72)

External Blu-ray drive connected to this unit
“Creating Discs with an External Blu-ray Drive” (A p. 78)

Blu-ray recorder
“Creating a Disc Using a Connected Blu-ray Recorder”
(A p. 83)

DVD recorder
“Dubbing Files by Connecting to a DVD Recorder”
(A p. 83)

USB external hard disk drive
“Using a USB External Hard Disk Drive” (A p. 84)

Computer
“Copying to Windows PC” (A p. 91)

*1: Only on AVCHD compatible devices.
*2: When creating a disc with 3D images, there may be certain limitations due to the recording format. Refer to the help file of the provided Everio MediaBrowser
3D software to operate.

(AVCHD)

P

P P

-

- -

- -

*2 *2 *2

Blu-ray Disc Device’s Internal HDD

- -

-

P*1 P

P

P

Memo :

When AVCHD files recorded in 3D are played back on a normal recorder or player, the left and right images will be displayed separately.

0

3D images cannot be copied to a VHS tape. Copy them to a Blu-ray disc, DVD, or USB external hard disk drive.

0

To record to discs with a computer, a recordable DVD or Blu-ray drive is required for the computer in use.

0

3D (MP4(MVC)) Files

o

P: Can be copied, -: Cannot be copied

Recording Device

DVD writer connected to this unit
“Creating Discs with a DVD Writer” (A p. 72)

External Blu-ray drive connected to this unit
“Creating Discs with an External Blu-ray Drive” (A p. 78)

Blu-ray recorder
“Creating a Disc Using a Connected Blu-ray Recorder”
(A p. 83)

DVD recorder
“Dubbing Files by Connecting to a DVD Recorder”
(A p. 83)

USB external hard disk drive
“Using a USB External Hard Disk Drive” (A p. 84)

Computer
“Copying to Windows PC” (A p. 91)

*: When creating a disc with 3D images, there may be certain limitations due to the recording format. Refer to the help file of the provided Everio MediaBrowser
3D software to operate.

DVD

(AVCHD)

- - -

-

- - -

- - -

- -

- - *

Blu-ray Disc Device’s Internal HDD

P

-

P

Memo :

3D images cannot be copied to a VHS tape.

0

Videos recorded in MP4(MVC) format can be copied or played back only when dubbed to a Blu-ray disc or hard disk drive.

0

Copy or play back by connecting this unit to an external Blu-ray drive or USB external hard disk drive.

70

2D Files

o

P: Can be copied, -: Cannot be copied

Copying

Recording Device VHS Tape DVD

DVD writer connected to this unit
“Creating Discs with a DVD Writer” (A p. 72)

External Blu-ray drive connected to this unit
“Creating Discs with an External Blu-ray Drive”
(A p. 78)

Blu-ray recorder
“Creating a Disc Using a Connected Blu-ray
Recorder” (A p. 83)

DVD recorder
“Dubbing Files by Connecting to a DVD Recorder”
(A p. 83)

USB external hard disk drive
“Using a USB External Hard Disk Drive” (A p. 84)

VCR
“Dubbing Files to a VHS Tape Using a VCR”
(A p. 88)

Computer
“Copying to Windows PC” (A p. 91)

*1: Only on AVCHD compatible devices.
*2: Use Everio MediaBrowser 3D to record to discs on the computer. Refer to the help file of the provided Everio MediaBrowser 3D software to operate.

-

-

-

-

- - - -

P

- *2 *2 *2

(DVD-Video)

P P

P P P

P

P

- - - -

DVD

(AVCHD)

-

- -

Blu-ray Disc Device’s

Internal HDD

- -

-

P*1 P

P

P

P

Memo :

To record to discs with a computer, a recordable DVD or Blu-ray drive is required for the computer in use.

0

71

Copying

Creating Discs with a DVD Writer

You can copy the recorded files to discs or play back the created discs using
an optional DVD writer.

Compatible DVD Writers

Product Name Description

DVD Writer

CU-VD3U

0

DVD Writer

CU-VD50U

0

Creating Discs with a DVD Writer

Preparing a DVD Writer

o

“Preparing a DVD Writer (CU-VD50U)” (A p. 73)
“Preparing a DVD Writer (CU-VD3U)” (A p. 73)

Copying to Discs

o

“Copying All Files” (A p. 73)
“Copying Files by Date (2D mode only)” (A p. 75)
“Copying Selected Files” (A p. 76)

Other Operations

o

“Playing Back with a DVD Writer” (A p. 77)
“Finalizing Discs After Copying” (A p. 78)

Memo :

When there are many files to back up, it may take time for the backup to

0

be completed. Wait for a while as the access lamp appears blinking, which
indicates normal operation.

Recording date and time will not be displayed when playing back a disc

0

that contains videos recorded in 3D mode.

Caution :

3D images in MP4(MVC) format cannot be copied to a DVD writer.

0

Enables the images recorded on this unit to be

0

copied to a DVD without using a PC.

Creates DVDs and functions as an external DVD

0

drive when connected to a PC. In addition,
created DVDs can be played back by connecting
the CU-VD50U to a TV.

Changing the Media of the DVD Writer

Set the type of media according to the loaded DVD.

Prepare a DVD writer.

1

“Preparing a DVD Writer (CU-VD50U)” (A p. 73)
“Preparing a DVD Writer (CU-VD3U)” (A p. 73)

Tap “CHANGE REC. MEDIA” in the “BACK-UP” menu.

2

.

Tap “DVD(AVCHD)” or “DVD-Video”.

3

.

The media changes to the tapped item. Select the appropriate setting

0

according to the disc.
Selecting “DVD(AVCHD)” enables you to save videos in a DVD in the

0

high definition quality.
Selecting “DVD-Video” enables you to save videos in a DVD after

0

converting to the standard image quality.

Caution :

When copying 3D images in AVCHD format, the media of the DVD writer

0

cannot be changed.

72

Copying

Preparing a DVD Writer (CU-VD50U)

Connect the USB cable and the AC adapter.

1

0

Turn off the camcorder by pressing the M button for about 2 seconds.

.

A Connect the USB cable provided with the DVD writer.
B Connect the AC adapter of the DVD writer.
C Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

This unit turns on and the “BACK-UP” menu appears.

0

While the USB cable is connected, the “BACK-UP” menu is

0

displayed.
Refer also to the instruction manual of the DVD writer.

0

Turn on the DVD writer and insert a new disc.

2

Preparing a DVD Writer (CU-VD3U)

Connect the USB cable and the AC adapter.

1

0

Turn off the camcorder by pressing the M button for about 2 seconds.

.

A Connect the USB cable of the DVD writer to this unit.
B Connect the AC adapter of the DVD writer.
C Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

This unit turns on and the “BACK-UP” menu appears.

0

While the USB cable is connected, the “BACK-UP” menu is

0

displayed.

Refer also to the instruction manual of the DVD writer.

0

Insert a new disc.

2

.

A Press the power button to turn on the power.
B Press the eject button to open the disc tray.
C Pull out the tray completely and load a new disc properly.
D Push the disc tray in until it clicks into place.

Caution :

Be sure to turn off the power when connecting the devices.

0

Otherwise, electric shocks or malfunctions may occur.

Memo :

When connected to this unit, all buttons on the DVD writer CU-VD50, other

0

than the power and eject buttons, will not work.

.

A Press the eject button to open the disc tray.
B Pull out the tray completely and load a new disc properly.
C Push the disc tray in until it clicks into place.

Caution :

Be sure to turn off the power when connecting the devices.

0

Otherwise, electric shocks or malfunctions may occur.

Creating a Disc

Prepare a DVD writer.

1

Insert a new disc into the DVD writer.

0

“Preparing a DVD Writer (CU-VD50U)” (A p. 73)
“Preparing a DVD Writer (CU-VD3U)” (A p. 73)

Copy files to the disc with the following methods.

2

“Copying All Files” (A p. 73)
“Copying Files by Date (2D mode only)” (A p. 75)
“Copying Selected Files” (A p. 76)

Copying All Files

All videos or still images recorded on this unit will be copied.
You can also select and copy only the videos or still images that have never
been copied.

Select 3D or 2D mode.

1

73

Copying

.

Select video or still image mode.

2

.

Tap “CREATE FROM ALL” (video) or “SAVE ALL” (still image).

3

7

Tap “YES” or “NO”. (A mode only)

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.
When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

8

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the media to copy.

4

.

Tap the desired method.

5

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

“ALL SCENES” (video)/“ALL IMAGES” (still image):

0

All videos or still images in this unit are copied.

“UNSAVED SCENES” (video)/“UNSAVED IMAGES” (still

0

image):

Videos or still images that have never been copied are automatically
selected and copied.

Tap “EXECUTE”.

6

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

9

.

10

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with a DVD Writer”.

0

“Playing Back with a DVD Writer” (A p. 77)

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the basic settings menu is set to
OFF.
“AUTO FINALIZE” (A p. 129)

To play back on other devices, tap “YES”.

0

To add more files to the DVD later, tap “NO”.

0

Memo :

When two or more DVDs are created simultaneously, all the discs other

0

than the last one will be finalized automatically even when “AUTO
FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACK-

0

UP” menu.

“Finalizing Discs After Copying” (A p. 78)

To play back a BD-R disc on other devices, select “FINALIZE” after

0

creating the disc.
(The “AUTO FINALIZE” function on the basic settings menu can only be
used for creating DVDs.)

74

Copying

Copying Files by Date (2D mode only)

Videos or still images are sorted and copied according to the date on which
they were recorded.

Only 2D videos or still images can be sorted and copied according to the

0

date on which they were recorded.

Select 2D mode.

1

.

Select video or still image mode.

2

.

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still

3

image).

Tap “EXECUTE”.

7

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

8

Tap “YES” or “NO”. (A mode only)

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.

When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

9

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the media to copy.

4

.

Tap “CREATE BY DATE” (video) or “SAVE BY DATE” (still image).

5

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap to select a recording date.

6

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

10

.

11

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

3D videos cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with a DVD Writer”.

0

“Playing Back with a DVD Writer” (A p. 77)

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the basic settings menu is set to
OFF.
“AUTO FINALIZE” (A p. 129)

To play back on other devices, tap “YES”.

0

To add more files to the DVD later, tap “NO”.

.

0

Memo :

75

Copying

When two or more DVDs are created simultaneously, all the discs other

0

than the last one will be finalized automatically even when “AUTO
FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACK-

0

UP” menu.

“Finalizing Discs After Copying” (A p. 78)

To play back a BD-R disc on other devices, select “FINALIZE” after

0

creating the disc.
(The “AUTO FINALIZE” function on the basic settings menu can only be
used for creating DVDs.)

Copying Selected Files

Select and copy the desired videos or still images individually.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

A check mark appears on the selected file.

0

To remove the check mark, tap on the file again.
Tap “CHECK” to check the file.

0

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

After selecting all the files, tap “SAVE”.

7

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap “EXECUTE”.

8

.

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still

3

image).

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the media to copy.

4

.

Tap “SELECT FROM SCENES” (video) or “SELECT FROM IMAGES”

5

(still image).

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

9

Tap “YES” or “NO”. (A mode only)

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.
When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

10

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the videos or still images to copy.

6

76

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

11

.

12

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with a DVD Writer”.

0

“Playing Back with a DVD Writer” (A p. 77)

Copying

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the basic settings menu is set to
OFF.
“AUTO FINALIZE” (A p. 129)

To play back on other devices, tap “YES”.

0

To add more files to the DVD later, tap “NO”.

0

Memo :

When two or more DVDs are created simultaneously, all the discs other

0

than the last one will be finalized automatically even when “AUTO
FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACK-

0

UP” menu.

“Finalizing Discs After Copying” (A p. 78)

To play back a BD-R disc on other devices, select “FINALIZE” after

0

creating the disc.
(The “AUTO FINALIZE” function on the basic settings menu can only be
used for creating DVDs.)

Playing Back with a DVD Writer

You can play back the DVDs created on this unit.

Prepare a DVD writer.

1

Insert the DVD to play back into the DVD writer.

0

“Preparing a DVD Writer (CU-VD50U)” (A p. 73)
“Preparing a DVD Writer (CU-VD3U)” (A p. 73)

Tap “PLAYBACK” in the BACK-UP menu.

2

.

An index screen (thumbnail display) of the videos in the disc appears.

0
0

Tap “J” to return to the “BACK-UP” menu.

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode

for playback.

During 3D mode, “3D” is displayed on the LCD monitor.

0

During 2D mode, “2D” is displayed on the LCD monitor.

0

Tap on the file to start playback.

3

.

For details on video playback, refer to ““Operation Buttons for Video

0

Playback” (A p. 53) ”.

“Operation Buttons for Video Playback” (A p. 53)

0

To exit, stop playback and turn off the camcorder by pressing the M

button for about 2 seconds. Then, disconnect the USB cable.

Memo :

3D images may be played back when the 3D button lights up.

0

Scenes that are likely to cause motion sickness during 3D playback may

0

be played back in stop-motion, but this is not a malfunction. To play back
normally, set “3D MOTION RELIEF” to “OFF”.

“3D MOTION RELIEF (3D mode only)” (A p. 117)

When playing back a disc created in DVD-Video format, no information

0

such as date and time will be displayed.

77

Copying

Finalizing Discs After Copying

Finalize the disc after copying is finished. This enables the disc to be played
back using this unit, PC, DVD writer, DVD player, or external Blu-ray drive
that supports the BD-MV and AVCHD formats.

Select video or still image mode.

1

.

Tap “FINALIZE”.

2

.

Tap “YES”.

3

Creating Discs with an External Blu-ray Drive

You can copy the recorded files to discs or play back the created discs using
an optional external Blu-ray drive.

Compatible External Blu-ray Drives

You can use BE08LU20 from LG. (as of December, 2010)

Creating Discs with an External Blu-ray Drive

Preparing an External Blu-ray Drive

o

“Preparing an External Blu-ray Drive” (A p. 79)

Copying to Discs

o

“Copying All Files” (A p. 79)
“Copying Files by Date (2D mode only)” (A p. 80)
“Copying Selected Files” (A p. 81)

Other Operations

o

“Playing Back with an External Blu-ray Drive” (A p. 82)

Memo :

Discs that are recorded in MP4(MVC) format cannot be played back on

0

AVCHD compatible Blu-ray recorders. Play it back on an external Blu-ray
drive.

“Playing Back with an External Blu-ray Drive” (A p. 82)

The recordable time on the disc varies according to the way of recording.

0

When there are many files to back up, it may take time for the backup to

0

be completed. Wait for a while as the access lamp appears blinking, which
indicates normal operation.

Recording date and time will not be displayed when playing back a disc

0

that contains videos recorded in 3D mode.

.

After finalizing, tap “OK”.

0

Changing the Media of the External Blu-ray Drive

Set the type of media according to the loaded Blu-ray disc or DVD.

Prepare an external Blu-ray drive.

1

Insert a disc into the external Blu-ray drive.

0

“Preparing an External Blu-ray Drive” (A p. 79)

Tap “CHANGE REC. MEDIA” in the “BACK-UP” menu.

2

.

Tap “Blu-ray DISC”, “DVD(AVCHD)”, or “DVD-Video”.

3

The media changes to the tapped item. Select the appropriate setting

0

according to the disc.
Selecting “Blu-ray DISC” enables you to save videos in a Blu-ray disc

0

in the high definition quality.
Selecting “DVD(AVCHD)” enables you to save videos in a DVD in the

0

high definition quality.
Selecting “DVD-Video” enables you to save videos in a DVD after

0

converting to the standard image quality.

Caution :

“DVD-Video” cannot be selected when saving AVHCD(3D) videos.

0

Media cannot be changed when saving MP4(MVC) videos. (Only

0

recordable to BD)

78

Preparing an External Blu-ray Drive

Memo :

When connecting to the external Blu-ray drive, use a USB cable with Mini­A (Male) – B (Male) connectors.
The USB cable provided with this unit cannot be used.

To use the USB cable provided with the external Blu-ray drive, purchase

0

the USB extension cable.
Mini-A (Male) – A (Female)
(Part number: QAM0852-001)

Connect the USB cable and the AC adapter.

1

0

Turn off the camcorder by pressing the M button for about 2 seconds.

.

A Connect the USB cable of the external Blu-ray drive to this unit.
B Connect the AC adapter of the external Blu-ray drive.
C Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

This unit turns on and the “BACK-UP” menu appears.

0

While the USB cable is connected, the “BACK-UP” menu is

0

displayed.
Refer also to the instruction manual of the external Blu-ray drive.

0

Insert a new disc.

2

Press the power button on the external Blu-ray drive to turn on the

0

power.

.

Select video or still image mode.

2

.

Tap “CREATE FROM ALL” (video) or “SAVE ALL” (still image).

3

.

Tap on the media to copy.

4

.

Tap the desired method.

5

Copying

.

A Press the eject button to open the disc tray.
B Pull out the tray completely and load a new disc properly.
C Push the disc tray in until it clicks into place.

Caution :

Be sure to turn off the power when connecting the devices.

0

Otherwise, electric shocks or malfunctions may occur.

Creating a Disc

Creating a Disc

Prepare an external Blu-ray drive.

1

Insert a new disc into the external Blu-ray drive.

0

“Preparing an External Blu-ray Drive” (A p. 79)

Copy files to the disc with the following methods.

2

“Copying All Files” (A p. 79)
“Copying Files by Date (2D mode only)” (A p. 80)
“Copying Selected Files” (A p. 81)

Copying All Files

All videos or still images recorded on this unit will be copied.
You can also select and copy only the videos or still images that have never
been copied.

Select 3D or 2D mode.

1

.

“ALL SCENES” (video)/“ALL IMAGES” (still image):

0

All videos or still images in this unit are copied.

“UNSAVED SCENES” (video)/“UNSAVED IMAGES” (still

0

image):

Videos or still images that have never been copied are automatically
selected and copied.

Tap “EXECUTE”.

6

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

7

Tap “YES” or “NO”. (A mode only)

79

Copying

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.
When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

8

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

9

.

10

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the media to copy.

4

.

Tap “CREATE BY DATE” (video) or “SAVE BY DATE” (still image).

5

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap to select a recording date.

6

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with an External Blu-ray

0

Drive”.

“Playing Back with an External Blu-ray Drive” (A p. 82)

Copying Files by Date (2D mode only)

Videos or still images are sorted and copied according to the date on which
they were recorded.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

Tap “EXECUTE”.

7

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

.

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still

3

image).

80

Copying

8

Tap “YES” or “NO”. (A mode only)

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.
When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

9

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

10

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still

3

image).

.

Tap on the media to copy.

4

.

Tap “SELECT FROM SCENES” (video) or “SELECT FROM IMAGES”

5

(still image).

.

11

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

3D videos cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with an External Blu-ray

0

Drive”.

“Playing Back with an External Blu-ray Drive” (A p. 82)

Copying Selected Files

Select and copy the desired videos or still images individually.

Select 3D or 2D mode.

1

.

While the video mode is shown in the image, the same operations

0

apply for the still image mode.

Tap on the videos or still images to copy.

6

.

A check mark appears on the selected file.

0

To remove the check mark, tap on the file again.

Tap “CHECK” to check the file.

0

After selecting all the files, tap “SAVE”.

7

.

.

Select video or still image mode.

2

.

81

Copying

Tap “EXECUTE”.

8

.

The number of discs required to copy the files is displayed.

0

Prepare the discs accordingly.

9

Tap “YES” or “NO”. (A mode only)

.

When “YES” is selected, videos with similar recording dates are

0

displayed in groups.
When “NO” is selected, videos are displayed according to recording

0

dates.

Tap “EXECUTE”.

10

.

When “INSERT NEXT DISC” appears, change the disc.

0

After copying, tap “OK”.

11

.

12

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

.

An index screen (thumbnail display) of the videos in the disc appears.

0
0

Tap “J” to return to the “BACK-UP” menu.
Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode
for playback.

During 3D mode, “3D” is displayed on the LCD monitor.

0

During 2D mode, “2D” is displayed on the LCD monitor.

0

Tap on the file to start playback.

3

.

For details on video playback, refer to ““Operation Buttons for Video

0

Playback” (A p. 53) ”.

“Operation Buttons for Video Playback” (A p. 53)

0

To exit, stop playback and turn off the camcorder by pressing the M
button for about 2 seconds. Then, disconnect the USB cable.

Memo :

Images recorded in 2D mode cannot be displayed as 3D images.

0

3D images may be played back when the 3D button lights up.

0

3D images recorded in “MP4(MVC)” format and “AVCHD” format are

0

displayed on the index screen separately.
Change the setting of 3D VIDEO REC FORMAT to the desired format for
playback.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

Scenes that are likely to cause motion sickness during 3D playback may

0

be played back in stop-motion, but this is not a malfunction. To play back
normally, set “3D MOTION RELIEF” to “OFF”.

“3D MOTION RELIEF (3D mode only)” (A p. 117)

Videos recorded in MP4(MVC) format can only be played back when

0

dubbed to a Blu-ray disc.
Videos recorded in AVCHD format can be played back from either a Blu-

0

ray disc or DVD.
When playing back a disc created in DVD-Video format, no information

0

such as date and time will be displayed.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

Memo :

To check the created disc, refer to “Playing Back with an External Blu-ray

0

Drive”.

“Playing Back with an External Blu-ray Drive” (A p. 82)

Playing Back with an External Blu-ray Drive

You can play back the Blu-ray discs created on this unit.

Prepare an external Blu-ray drive.

1

Insert the Blu-ray disc to play back into the external Blu-ray drive.

0

“Preparing an External Blu-ray Drive” (A p. 79)

Tap “PLAYBACK” in the BACK-UP menu.

2

82

Copying

Creating a Disc Using a Connected Blu-ray Recorder

You can create discs using a Blu-ray recorder by connecting it to this unit
using a USB cable.

Connect the USB cable and the AC adapter.

1

0

Turn off the camcorder by pressing the M button for about 2 seconds.

.

A Connect using the provided USB cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

Be sure to use the supplied JVC AC adapter.

0

The “SELECT DEVICE” screen appears.

0

Tap “CONNECT TO OTHER”.

2

Dubbing Files by Connecting to a DVD Recorder

You can dub videos in standard quality by connecting to a DVD recorder.

Refer also to the instruction manuals of the TV and DVD recorder.

0

Open the LCD monitor, then press and hold the power button for 2

1

seconds or more to turn off the power.

.

Connect to a DVD recorder.

2

.

Tap the desired media.

3

.

Perform dubbing on the Blu-ray recorder.

4

Refer also to the instruction manual of the Blu-ray recorder.

0

Caution :

MP4(MVC) videos cannot be copied.

0

Memo :

The created discs are playable only on AVCHD compatible devices (such

0

as Blu-ray recorders).

.

A Connect using the provided AV cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

3

Tap q to select the playback mode.

Prepare the TV/DVD recorder for recording.

4

Switch to a compatible external input.

0

Insert a disc (DVD-R, etc.) into the DVD recorder.

0

Prepare this unit for playback.

5

Set “VIDEO OUTPUT” in the “COMMON” menu to the aspect ratio

0

(“4:3” or “16:9”) of the connecting TV.

“VIDEO OUTPUT (2D mode only)” (A p. 127)

Start recording.

6

Start playback on this unit and press the record button on the

0

recorder.

“Playing Back Videos” (A p. 52)

After playback is complete, stop the recording.

0

Caution :

3D videos cannot be dubbed.

0

83

Copying

Using a USB External Hard Disk Drive

You can copy video and still image files to a USB external hard disk drive
from this unit. You can also play the files in the USB external hard disk drive
on this unit.

Refer also to the instruction manual of the external hard disk drive.

0

Compatible External Hard Disk Drives

You can use the “LaCie Hard Disk Sleek black design USB2.0” series from
LaCie.

Memo :

Before purchasing, check the compatible devices on the LaCie website.

LaCie

0

http://www.lacie.com/home.htm?cc=1

USB external hard disk drives up to 2 TB can be used.

0

Copying and Playback with a USB External Hard Disk Drive

“Preparing a USB External Hard Disk Drive” (A p. 84)
“Copying All Files” (A p. 84)
“Playing Back Files in the USB External Hard Disk Drive” (A p. 85)
“Deleting Folders in the USB External Hard Disk Drive” (A p. 86)

Importing Files from the USB External Hard Disk Drive

“Importing Files from the USB External Hard Disk Drive” (A p. 87)

Memo :

Format the USB external hard disk drive when connecting it to this unit for

0

the first time. (All data will be deleted.)

“Formatting the USB External Hard Disk Drive” (A p. 87)

Refer to the help file of the provided Everio MediaBrowser 3D software

0

when you use the PC to operate the data in the USB external hard disk
drive directly copied from this unit.

USB external hard disk drives with the capacity over 2 TB cannot be used.

0

Copying may take time. (For example, saving 1 hour video in XP mode

0

takes about 20 minutes.)
When there are many files to back up, it may take time for the backup to

0

be completed. Wait for a while as the access lamp appears blinking, which
indicates normal operation.

Sound or video may be interrupted during playback.

0

Caution :

Do not connect a USB hub between this unit and the USB external hard

0

disk drive.
Disconnect the USB external hard disk drive when using other USB

0

devices such as DVD writer, external Blu-ray drive, or another USB
external hard disk drive.

Avoid the following operations during copying and playing back.

0

- Turning off the unit or the USB external hard disk drive.

- Disconnecting the USB cable.
Do not format the USB external hard disk drive using the PC. If you did,

0

format again using this unit. (All the data in the USB external hard disk
drive will be erased.)

Avoid the following operations using the PC.

0

- Deleting files or folders in the USB external hard disk drive.

- Moving files or folders in the USB external hard disk drive.

- Changing the name of files or folders in the USB external hard disk drive.
These operations make the data impossible to be played back on this unit.

When you use the PC to edit the data in the USB external hard disk drive,

0

copy the data to the PC before editing. Editing the data in the USB external
hard disk drive directly from the PC makes the data impossible to be
played back on this unit.

Preparing a USB External Hard Disk Drive

Memo :

When connecting to the external hard disk drive, use a USB cable with

0

Mini-A (Male) – B (Male) connectors.
The USB cable provided with this unit cannot be used.

To use the USB cable provided with the external hard disk drive, purchase

0

the following USB extension cable.
Mini-A (Male) – A (Female)
(Part number: QAM0852-001)

Connect the USB cable and the AC adapter.

1

0

Turn off the camcorder by pressing the M button for about 2 seconds.

*Consult your nearest JVC service center.

A Connect the USB cable with the USB external hard disk drive.
B Connect the AC adapter of the USB external hard disk drive.
C Connect the AC adapter to this unit.

0
0
0

0

Turn on the external hard disk drive.

2

.

This unit powers on automatically when the AC adapter is connected.
This unit turns on and the “BACK-UP” menu appears.
While the USB cable is connected, the “BACK-UP” menu is

displayed.
Refer also to the instruction manual of the external hard disk drive.

Caution :

Be sure to turn off the power when connecting the devices.

0

Otherwise, electric shocks or malfunctions may occur.
Do not connect a USB hub between this unit and the USB external hard

0

disk drive.

Copying All Files

All videos or still images recorded on this unit will be copied.
You can also select and copy only the videos or still images that have never
been copied.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

84

.

Copying

Tap “BACK UP”.

3

.

Tap on the media to copy.

4

.

Tap the desired method.

5

Playing Back Files in the USB External Hard Disk Drive

Videos or still images saved in an external hard disk drive can be played
back on this unit.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

Tap “PLAYBACK”.

3

.

“ALL SCENES” (video)/“ALL IMAGES” (still image):

0

All videos or still images in this unit are copied.

“UNSAVED SCENES” (video)/“UNSAVED IMAGES” (still

0

image):

Videos or still images that have never been copied are automatically
selected and copied.

Check that there is sufficient remaining space on the hard disk drive and

6

tap “YES”.

.

Backup starts when “YES” is tapped.

0

After copying, tap “OK”.

7

.

8

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is

0

complete.
Files that are not on the index screen during playback cannot be copied.

0

Copying may take time. (For example, saving 1 hour video in XP mode

0

takes about 20 minutes.)

.

Tap on the folder to play back.

4

.

0

Tap “J” to return to the “BACK-UP” menu.

Tap on the file to play back.

5

.

0

Tap “J” to return to the folder index screen.

For details on video playback, refer to ““Operation Buttons for Video

0

Playback” (A p. 53) ”.

“Operation Buttons for Video Playback” (A p. 53)

0

To exit, stop playback and turn off the camcorder by pressing the M

button for about 2 seconds. Then, disconnect the USB cable.

Memo :

Sound or video may be interrupted during playback.

0

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode for
playback.

3D images recorded in “MP4(MVC)” format and “AVCHD” format are

0

displayed on the index screen separately.
Change the setting of 3D VIDEO REC FORMAT to the desired format for
playback.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

85

Copying

Caution :

To play back 3D images, refer also to “Precautions on Recording and

0

Playing Back 3D Images”.

“Precautions on Recording and Playing Back 3D Images” (A p. 11)

Deleting Folders in the USB External Hard Disk Drive

Files that are copied to the external hard disk drive can be deleted.

Caution :

Deleted files cannot be restored.

0

Be sure to back up important files on a PC.

0

“Backing Up All Files” (A p. 93)

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

Tap “DELETE”.

3

.

Tap on the folder to delete.

4

.

Tap “YES”.

5

.

After deleting, tap “OK”.

0

Memo :

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode for
deletion.

3D images recorded in “MP4(MVC)” format and “AVCHD” format are

0

displayed on the index screen separately.
Change the setting of 3D VIDEO REC FORMAT to the desired format for
deletion.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

86

Copying

Formatting the USB External Hard Disk Drive

All files on the external hard disk drive can be deleted.

Caution :

All data on the external hard disk drive will be deleted when it is formatted.

0

Copy all files on the card to a PC before formatting.

Select video or still image mode.

1

.

Tap “FORMAT”.

2

.

Tap “YES”.

3

4

Tap “USB HDDFBUILT-IN MEM” or “USB HDDFSD”.

.

Files will be imported to the selected media.

0

Tap on the folder to import.

5

.

Tap on the files to import.

6

.

After formatting, tap “OK”.

0

Importing Files from the USB External Hard Disk Drive

You can copy video and still image files from a USB external hard disk drive
to the built-in memory of this unit or an SD card.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

Tap “IMPORT FROM DEVICE” in “BACK-UP”.

3

.

P appears on the selected files.

0

To remove P from a file, tap on the file again.

Tap “SEL ALL” to select all files.

0

Tap “REL ALL” to release all selections.

0

“SET” is deactivated when no file is selected.

0

Tap “SET”.

7

.

Tap “YES”.

8

.

Importing starts when “YES” is tapped.

0

To cancel importing of files, tap “STOP”, then tap “YES”.

0

After importing, tap “OK”.

9

.

87

Copying

.

10

Press and hold the M button for 2 seconds or more to turn off this unit
and disconnect the USB cable.

Memo :

Images recorded in 3D mode and 2D mode are displayed on the index

0

screen separately. Press the 3D button to switch to the desired mode for
importing.

3D images recorded in “MP4(MVC)” format and “AVCHD” format are

0

displayed on the index screen separately.
Change the setting of 3D VIDEO REC FORMAT to the desired format for
importing.

“3D VIDEO REC FORMAT (3D mode only)” (A p. 104)

Dubbing Files to a VHS Tape Using a VCR

You can dub videos in standard quality by connecting to a VCR.

Refer also to the instruction manuals of the TV and VCR.

0

Caution :

3D images cannot be copied to a VHS tape. Images recorded in 3D mode

0

cannot be copied as 2D images.

Open the LCD monitor, then press and hold the power button for 2

1

seconds or more to turn off the power.

.

Connect to a VCR/DVD recorder.

2

.

A Connect using the provided AV cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

3

Tap q to select the playback mode.

Prepare the TV/VCR for recording.

4

Switch to a compatible external input.

0

Insert a video tape.

0

Prepare this unit for playback.

5

Set “VIDEO OUTPUT” in the “COMMON” menu to the aspect ratio

0

(“4:3” or “16:9”) of the connecting TV.

“VIDEO OUTPUT (2D mode only)” (A p. 127)

Start recording.

6

Start playback on this unit and press the record button on the

0

recorder.

“Playing Back Videos” (A p. 52)

After playback is complete, stop the recording.

0

88

Copying

Copying Files to an SD Card

You can copy videos and still images from the built-in memory to SD card.
Copying still images to cards makes it convenient to bring them to the shop
for printing (developing).

Caution :

Make sure that there is enough space left in the destination medium.

0

Videos and still images in the SD card cannot be copied to the built-in

0

memory.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

.

3

Tap q to select the playback mode.

To remove

Tap “SEL ALL” to select all files.

0

Tap “REL ALL” to release all selections.

0

“SET” is deactivated when no file is selected.

0

Tap “SET”.

7

Tap “YES”.

8

Copying starts.

0

After copying, tap “OK”.

0

P from a file, tap on the file again.

.

.

.

Tap “MENU”.

4

.

Tap “COPY”.

5

.

Tap on the files to copy.

6

.

P appears on the selected files.

0

89

Copying

Moving Files to an SD Card

You can move videos and still images from the built-in memory to SD card.
Files that are moved will be deleted from the built-in memory.
Moving still images to SD cards makes it convenient to bring them to the
shop for printing (developing).

Caution :

Make sure that there is enough space left in the destination medium.

0

Videos and still images in the SD card cannot be moved to the built-in

0

memory.

Select 3D or 2D mode.

1

.

Select video or still image mode.

2

P appears on the selected files.

0

To remove P from a file, tap on the file again.
Tap “SEL ALL” to select all files.

0

Tap “REL ALL” to release all selections.

0

“SET” is deactivated when no file is selected.

0

Tap “SET”.

7

.

Tap “YES”.

8

.

3

Tap q to select the playback mode.

.

Tap “MENU”.

4

.

Tap “MOVE”.

5

.

Moving of files starts.

0

After moving, tap “OK”.

0

.

Tap on the files to move.

6

.

90

Copying to Windows PC

You can copy files to a computer using the provided software.
DVDs can also be created using the computer's DVD drive.
If the provided software is not installed, this unit will be recognized as an external storage when connected.

Memo :

To record to discs, a recordable DVD or Blu-ray drive is required for the computer in use.

0

Still images cannot be recorded to discs using the provided software.

0

Trouble with Using the Provided Software Everio MediaBrowser 3D

Consult the customer service center below.

Pixela User Support Center

0

Copying

Telephone USA and Canada (English): [phone] (toll-free)

Homepage http://www.pixela.co.jp/oem/jvc/mediabrowser/e/

For details on how to upload to YouTube, refer to Everio MediaBrowser 3DHelp in the “Help” menu of Everio MediaBrowser 3D.

0

Europe (UK, Germany, France, and Spain)
(English/German/French/Spanish): [phone] (toll-free)
Other Countries in Europe
(English/German/French/Spanish): [phone]
Asia (Philippines) (English): [phone]
China (Chinese): 10800-163-0014 (toll-free)

.

91

Copying

Verifying System Requirements (Guideline)

Right-click on “Computer” (or “My Computer”) in the “Start” menu and select “Properties” to check the following items.

Windows Vista/Windows 7

Refer to the operating instructions found in the animation on the Detailed User Guide.

0

Windows XP

Refer to the operating instructions found in the animation on the Detailed User Guide.

0

Windows Vista/Windows 7 Windows XP

OS Windows Vista 32/64-bit

CPU Intel Core Duo CPU 1.66 GHz or higher

RAM At least 2 GB At least 1 GB

Other requirements

o

Display: 1024×768 pixels or above (1280×1024 pixels or above recommended)

0

Graphic: Intel G965 or higher recommended

0

Home Basic or Home Premium
(Pre-installed versions only) Service Pack 2
Windows 7 32/64-bit
Home Premium
(Pre-installed versions only)

(Intel Core 2 Duo CPU 2.13 GHz or higher recommended)
(Video editing/AVCHD(3D) playback: Intel Core i7 CPU 2.53 GHz or
higher recommended)

Windows XP
Home Edition or Professional
(Pre-installed versions only) Service Pack 3

Intel Core Duo CPU 1.66 GHz or higher
(Intel Core 2 Duo CPU 2.13 GHz or higher recommended)
(Video editing/AVCHD(3D) playback: Intel Core i7 CPU 2.53 GHz or
higher recommended)

Memo :

If your PC does not meet the above system requirements, operations of the provided software cannot be guaranteed.

0

For more information, contact your PC's manufacturer.

0

Installing the Provided Software

You can display the recorded images in calendar format and perform simple editing using the provided software.

Refer to the operating instructions found in the animation on the Detailed User Guide.

0

92

Backing Up All Files

Before making backup, make sure that enough free space is left in the
computer's hard disk (HDD).

Connect the USB cable and the AC adapter.

1

.

A Connect using the provided USB cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

Be sure to use the supplied JVC AC adapter.

0

The “SELECT DEVICE” menu appears.

0

Tap “CONNECT TO PC”.

2

Copying

.

Backup starts.

0

After backup is complete, click “OK”.

6

Memo :

Before making backup, load the SD card in which the videos and still

0

images are stored on this unit.
If you encounter any problems with the provided software Everio

0

MediaBrowser 3D, please consult the “Pixela User Support Center”.

Telephone USA and Canada (English): [phone] (toll-free)

Europe (UK, Germany, France, and Spain)
(English/German/French/Spanish): [phone] (toll­free)
Other Countries in Europe
(English/German/French/Spanish): [phone]
Asia (Philippines) (English): [phone]
China (Chinese): 10800-163-0014 (toll-free)

.

Tap “BACK UP”.

3

.

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.
The provided software Everio MediaBrowser 3D starts up on the

0

computer.
The subsequent operations are to be performed on the computer.

Select the volume.

4

Homepage http://www.pixela.co.jp/oem/jvc/mediabrowser/e/

Delete unwanted videos before making backup.

0

It takes time to back up many videos.

“Deleting Unwanted Files” (A p. 65)

Disconnecting this Unit from Computer

Click “Safely Remove Hardware and Eject Media”.

1

.

Click “Safely Remove USB Mass Storage Device”.

2

(For Windows Vista) Click “OK”.

3

Disconnect the USB cable and close the LCD monitor.

4

Start backup.

5

.

93

Copying

Organizing Files

After backing up your files, organize them by adding labels such as “Family
Trip” or “Athletic Meet”.
This is useful not only for creating discs, but for viewing the files too.

Double-click on the Everio MediaBrowser 3D icon.

1

The provided software starts up.

0

.

Display the month of the files to organize.

2

.

Create a user list.

3

Identifying Video or Still Image

You can select files using the "SELECT" menu on the top right of the

0

：

screen.
Check the video/still image icon on the top right corner of the thumbnail.

0

.

Memo :

If you encounter any problems with the provided software Everio

0

MediaBrowser 3D, please consult the “Pixela User Support Center”.

Telephone USA and Canada (English): [phone] (toll-free)

Homepage http://www.pixela.co.jp/oem/jvc/mediabrowser/e/

Europe (UK, Germany, France, and Spain)
(English/German/French/Spanish): [phone] (toll­free)
Other Countries in Europe
(English/German/French/Spanish): [phone]
Asia (Philippines) (English): [phone]
China (Chinese): 10800-163-0014 (toll-free)

.

.

A new user list is added to the user list library.

0

Click on the recording day.

4

The thumbnails of the files recorded on the day are displayed.

0

Register files to the created user list.

5

94

.

Copying

Recording Videos to Discs

Copy the files that are arranged using the user list to discs.

Insert a new disc into the PC's recordable DVD or Blu-ray drive.

1

Select the desired user list.

2

.

Select the files to copy to disc in order.

3

BD-R
BD-RE

The following formats are supported by the provided software Everio

0

MediaBrowser 3D.
DVD-Video
AVCHD
BD

When copying videos recorded in UXP recording mode to create an

0

AVCHD disc, the videos need to be converted to XP recording mode
before copying. Therefore, it may take a longer time than copying videos
recorded in other modes.

Use Everio MediaBrowser 3D Player to play back an AVCHD disc. Refer

0

to the help file of the provided Everio MediaBrowser 3D software to
operate.

To view the help file of Everio MediaBrowser 3D, select “Help” from the

0

Everio MediaBrowser 3D’s menu bar or press F1 on the keyboard.
If you encounter any problems with the provided software Everio

0

MediaBrowser 3D, please consult the “Pixela User Support Center”.

Telephone USA and Canada (English): [phone] (toll-free)

Homepage http://www.pixela.co.jp/oem/jvc/mediabrowser/e/

Europe (UK, Germany, France, and Spain)
(English/German/French/Spanish): [phone] (toll­free)
Other Countries in Europe
(English/German/French/Spanish): [phone]
Asia (Philippines) (English): [phone]
China (Chinese): 10800-163-0014 (toll-free)

.

Click “Settings” to select the disc type.

0

Image quality is set to standard when DVD-Video is selected.
Click “Select all” to select all the displayed files.

0

After selecting, click “Next”.

0

Set the title of the top menu of the disc.

4

.

Click “Settings” to select the menu background.

0

After setting, click “Start”.

0

After copying is complete, click “OK”.

5

Caution :

When creating a disc with 3D images, there may be certain limitations due

0

to the recording format. For details, refer to the help file of the provided
Everio MediaBrowser 3D software.

To view the help file of Everio MediaBrowser 3D, select “Help” from the

0

Everio MediaBrowser 3D’s menu bar or press F1 on the keyboard.

Memo :

The following types of discs can be used on the provided software Everio

0

MediaBrowser 3D.
DVD-R
DVD-R DL
DVD-RW
DVD+R
DVD+R DL
DVD+RW

95

Copying

Backing Up Files Without Using Provided Software

Copy the files to a computer using the following method.

Connect the USB cable and the AC adapter.

1

.

A Connect using the provided USB cable.
B Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

0

Be sure to use the supplied JVC AC adapter.

0

The “SELECT DEVICE” menu appears.

0

Tap “CONNECT TO PC”.

2

Disconnecting this Unit from Computer

Click “Safely Remove Hardware and Eject Media”.

1

.

Click “Safely Remove USB Mass Storage Device”.

2

(For Windows Vista) Click “OK”.

3

Disconnect the USB cable and close the LCD monitor.

4

.

Tap “PLAYBACK ON PC”.

3

.

Tap L to exit the menu.

0
0

Tap J to return to the previous screen.
Close the Everio MediaBrowser 3D program, if it starts.

0

The subsequent operations are to be performed on the computer.

0

Select “Computer” (Windows Vista) / “My Computer” (Windows XP) /

4

“Computer” (Windows 7) from the “Start” menu, then click on the
“JVCCAM_MEM” or “JVCCAM_SD” icon.

Open the folder with the desired files.

0

“List of Files and Folders” (A p. 97)

Copy the files to any folder in the computer (desktop, etc).

5

Caution :

When the folders or files are deleted/moved/renamed in the computer,

0

they cannot be played back on this unit anymore.

Memo :

To edit/view the files, use a software that supports AVCHD (video)/MP4

0

(video)/MPF (3D still image)/JPEG (2D still image) files.
The above operations on computer may vary with the system used.

0

96

List of Files and Folders

Folders and files are created in the built-in memory and SD card as shown below.
They are created only when necessary.

.

Copying

Caution :

When the folders or files are deleted/moved/renamed in the computer, they cannot be played back on this unit anymore.

0

97

Copying

JVC Software Licence Agreement

IMPORTANT

TO CUSTOMERS: PLEASE MAKE SURE TO READ THIS CAREFULLY
BEFORE INSTALLING OR USING THE SOFTWARE PROGRAM NAMED
"DIGITAL PHOTO NAVIGATOR" ("Program") ON YOUR PC.
The right to use the Program is granted by Victor Company of Japan, Limited
("JVC") to You only on the condition that You agree to the following.
Should You not agree to the terms hereof, You may not install or use the
Program. HOWEVER, INSTALLING OR USING THE PROGRAM
INDICATES YOUR ACCEPTANCE OF THESE TERMS AND
CONDITIONS.

COPYRIGHT; OWNERSHIP

1

You acknowledge that all copyrights and other intellectual property
rights in the Program are owned by JVC and its licensor, and remain
vested in JVC and such licensor. The Program is protected under the
copyright law of Japan and other countries, and related Conventions.

GRANT OF LICENCE

2

A Subject to the conditions of this Agreement, JVC grants to You a non-

exclusive right to use the Program. You may install and use the
Program on a HDD or other storage devices incorporated in Your PC.

B You may make one (1) copy of the Program solely for your personal

backup or archival purposes.

RESTRICTION ON THE PROGRAM

3

A You may not reverse engineer, decompile, disassemble, revise or

modify the Program, except to the extent that expressly permitted by
applicable law.

B You may not copy or use the Program, in whole or in part, other than

as expressly specified in this Agreement.

C You have no right to grant a licence to use the Program, and may not

distribute, rent, lease or transfer the Program to any third party or
otherwise let them use the Program.

LIMITED WARRANTY

4

JVC warrants that any media in which the Program is embodied are free
from any defects in materials and workmanship for a period of thirty (30)
days from the date of Your purchasing any our products accompanying
the Program. JVC's entire liability and your exclusive remedy in
connection with the Program shall be replacement of such defective
media. EXCEPT FOR THE EXPRESS WARRANTIES STATED
HEREIN AND TO THE EXTENT PERMITTED BY APPLICABLE LAW,
JVC AND ITS LICENSORS DISCLAIM ANY OTHER WARRANTIES,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE IN REGARD TO THE PROGRAM AND
THE ACCOMPANYING PRINTED MATERIALS. SHOULD THERE BE
ANY PROBLEM ARISING FROM OR CAUSED BY THE PROGRAM,
YOU SHOULD SETTLE ALL SUCH PROBLEM AT YOUR OWN COST
AND EXPENSE.

LIMITED LIABILITY

5

TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT
SHALL JVC AND ITS LICENSORS BE LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
WHATSOEVER, REGARDLESS OF THE FORM OF ACTION
WHETHER IN CONTRACT, TORT OR OTHERWISE ARISING OUT
OF OR IN CONNECTION WITH THE USE OF OR INABILITY TO USE
THE PROGRAM, EVEN IF JVC HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. YOU WILL INDEMNIFY AND
HOLD HARMLESS JVC FROM ANY LOSS, LIABILITY OR COST
ARISING OUT OF OR IN ANY WAY CONNECTED TO CLAIMS FROM
ANY THIRD PARTY RELATING TO THE USE OF THE PROGRAM.

TERM

6

This Agreement will become effective on the date when You install and
use the Program on Your machine, and continue to be in effect until the
termination under the following provision.
Should You breach any provision of this Agreement, JVC may terminate
this Agreement without giving any notice to You. In this event, JVC may
claim against You for any damages caused by Your breach. Should this
Agreement be terminated, You must immediately destroy the Program
stored in Your machine (including the erasing from any memory in Your
PC), and no longer own such Program.

EXPORT CONTROL

7

You agree that You will not ship, transfer or export the Program or
underlying information and technology to any countries to which Japan
and other relevant countries have initiated an embargo on such goods.

U.S. GOVERNMENT USER

8

If You are an agency of the United States of America (the
"Government"), You acknowledge JVC's representation that the
Program is a "Commercial Item" as defined in Federal Acquisition
Regulation (FAR) part 2.101 (g) consisting unpublished "Commercial
Computer Software" as those items are used at FAR part 12.212 and is
only licenced to You with the same use rights JVC grants all commercial
end users pursuant to the terms of this Agreement.

GENERAL

9

A No modification, change, addition, deletion or other alternation of or to

this Agreement will be valid unless reduced to writing and signed by
an authorized representative of JVC.

B If any part of this Agreement is held invalid by or in conflict with any law

having jurisdiction over this Agreement, the remaining provisions will
remain in full force and effect.

C This Agreement shall be governed by and interpreted under the laws

of Japan. The Tokyo District Court has jurisdiction over all disputes
which may arise with respect to the execution, interpretation and
performance of this Agreement.

Victor Company of Japan, Limited

Memo :

If You acquired the Program in Germany, the provisions of Sections 4

0

(Limited Warranty) and 5 (Limited Liability) provided above will be
replaced with those of the German version of this Agreement.

Caution :

Operate this equipment according to the operating procedures described

0

in this manual.
Use only the provided CD-ROM. Never use any other CD-ROM to run this

0

software.
Do not attempt to modify this software.

0

Changes or modifications not approved by JVC could void user's authority

0

to operate the equipment.

How to handle a CD-ROM：

Take care not to soil or scratch the mirror surface (opposite to the printed

0

surface). Do not write anything or put a sticker on either the front or back
surface. If the CD-ROM gets dirty, gently wipe it with a soft cloth outward
from the center hole.

Do not use conventional disc cleaners or cleaning spray.

0

Do not bend the CD-ROM or touch its mirror surface.

0

Do not store your CD-ROM in a dusty, hot or humid environment. Keep it

0

away from direct sunlight.

98

Operating the Menu

There are two types of menus in this unit.

Main menu:

0

Menu that contains all the items specific to the video recording, still image
recording, video playback, and still image playback modes respectively.

0

Q menu in main (common) menu:
Menu that contains all common items in the video recording, still image
recording, video playback, and still image playback modes.

Operating the Main Menu

You can configure various settings using the menu.

Tap “MENU”.

1

The menu differs according to the mode in use.

0

.

Tap the desired menu.

2

.

2

Tap “Q”.

.

Tap the desired setting.

3

Menu Settings

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Tap the desired setting.

3

.

Memo :

To exit the screen

0

Tap “L” (quit).

To return to the previous screen

0

Tap “J” (return).

To display the help file

0

Tap “K” (help) and tap the item.

Help file may not be available for some items.

0

.

Tap ∧ or ∨ to move upward or downward for more selection.

0

Memo :

To exit the screen

0

Tap “L” (quit).

To return to the previous screen

0

Tap “J” (return).

To display the help file

0

Tap “K” (help) and tap the item.

Help file may not be available for some items.

0

Operating the Common Menu

You can configure common setting items regardless of the mode using the
common menu.

Tap “MENU”.

1

The menu differs according to the mode in use.

0

99

Menu Settings

Main Menu for Video Recording

You can adjust various settings, such as brightness and white balance, to suit the subject or purpose. You can also change settings such as picture quality
and gain.

Select video mode.

1

.

2

Tap q to select the recording mode.

.

Tap “MENU”.

3

.

Setting

Details

SCENE SELECT Settings to suit the shooting condition can be selected.

“Scene Selection” (A p. 36)
*Displayed only in the manual recording mode.

FOCUS Focus can be adjusted manually.

“Adjusting Focus Manually” (A p. 37)
*Displayed only in the manual recording mode.

FOCUS ASSIST Focused subject is outlined in color for more precise focus.

“Using Focus Assist” (A p. 38)
*Displayed only in the manual recording mode.

FOCUS ASSIST COLOR Sets the color of the outline of a focused object when Focus Assist is used.

“FOCUS ASSIST COLOR” (A p. 102)
*Displayed only in the manual recording mode.

BRIGHTNESS ADJUST Adjusts the overall brightness of the screen.

“Adjusting Brightness” (A p. 38)
*Displayed only in the manual recording mode.

SHUTTER SPEED Shutter speed can be adjusted.

“Setting Shutter Speed” (A p. 39)
*Displayed only in the manual recording mode.

APERTURE PRIORITY Adjusts the aperture value.

“Setting Aperture” (A p. 39)
*Displayed only in the manual recording mode.

WHITE BALANCE Adjusts the color according to the light source.

“Setting White Balance” (A p. 40)
*Displayed only in the manual recording mode.

100
