JVC GRDVM80U - MiniDV Digital Camcorder Instructions Manual

LYT0590-001A

DIGITAL VIDEO CAMERA

INSTRUCTIONS

GR-DVM80

For Customer Use:

Enter below the Model No. and Serial No. which is located on the bottom of cabinet. Retain this information for future reference.

Model No.

Serial No.

ENGLISH

CONTENTS

AUTOMATIC DEMONSTRATION

GETTING STARTED

8 – 15

RECORDING

16– 35

Basic Recording .............................. 16

Advanced Features .......................... 22

PLAYBACK

36 – 43

Basic Playback ............................... 36

Advanced Features .......................... 37

Basic Connections ........................... 40

Advanced Connections ...................... 42

DUBBING

44 – 45

Dubbing To A VCR ........................... 44

Dubbing To Or From A Video Unit

Equipped With A DV Connector.......... 45

USING THE REMOTE CONTROL UNIT

46 – 56

Slow-Motion Playback, Frame-By-Frame

Playback and Playback Zoom............ 48

Playback Special Effects.................... 49

Random Assemble Editing ................. 50

For More Accurate Editing ................. 54

Audio Dubbing ............................... 56

USER MAINTENANCE

TROUBLESHOOTING

58 – 62

INDEX

63 – 68

Docking Station .............................. 63

Controls, Connectors And Indicators ..... 64

Indications .................................... 66

CAUTIONS

69 – 71

TERMS

72 – 73

SPECIFICATIONS

74 – 75

Please visit our Homepage on the World Wide Web and answer our Consumer Survey (in English only):

http://www.jvc-victor.co.jp/english/index-e.html

2 EN

This camcorder is designed to be used with NTSCtype color television signals. It cannot be used for playback with a television of a different standard. However, live recording and LCD monitor/ viewfinder playback are possible anywhere. Use the BN-V507U/V514U battery packs and, to recharge them, the provided multi-voltage AC Power Adapter/Charger. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)

Using This Instruction Manual

• All major sections and subsections are listed in the Table Of Contents on the cover page.

• Notes appear after most subsections. Be sure to read these as well.

• Basic and advanced features/operation are separated for easier reference.

It is recommended that you . . .

..... refer to the Index ( pgs. 63 – 68) and familiarize yourself with button locations, etc. before use.

..... read thoroughly the Safety Precautions and Safety Instructions that follow. They contain extremely important

information regarding the safe use of this product.

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

You are recommended to carefully read the cautions on pages 69 through 71 before use.

NOTES:

●

The rating plate (serial number plate) and safety caution are on the bottom and/or the back of the main unit.

●

The rating plate (serial number plate) of the AC Power Adapter/Charger is on its bottom.

●

The rating plate (serial number plate) of the Docking Station is on its bottom.

WARNING: TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

The AA-V51U AC Power Adapter/Charger should be used with: AC 120 V`, 60 Hz in the USA and Canada, AC 110 V – 240 V`, 50 Hz/60 Hz in other countries.

CAUTION (applies to the AA-V51U)

TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION (s’applique à l’AA-V51U)

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Dear Customer,

Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of this product.

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear).

Do not block the ventilation holes. (If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)

No naked flame sources, such as lighted candles, should be placed on the apparatus.

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing.

Do not use this equipment in a bathroom or places with water. Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups etc.) on top of this unit. (If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

EN3

5. Ventilation

Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered.

•Do not block the openings by placing the product on a bed, sofa, rug or other similar surface.

•Do not place the product in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

6. Wall or Ceiling Mounting

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

ANTENNA INSTALLATION INSTRUCTIONS

1. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

2. Lightning

For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

3. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

IMPORTANT PRODUCT SAFETY INSTRUCTIONS

Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.

ATTENTION:

Follow and obey all warnings and instructions marked on your product and its operating instructions. For your safety, please read all the safety and operating instructions before you operate this product and keep this manual for future reference.

INSTALLATION

1. Grounding or Polarization

(A) Your product may be equipped with a polarized

alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

(B) Your product may be equipped with a 3-wire

grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

2. Power Sources

Operate your product only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. If your product is intended to operate from battery power, or other sources, refer to the operating instructions.

3. Overloading

Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

4. Power Cord Protection

Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H)

NEC – NATIONAL ELECTRICAL CODE

ELECTRIC SERVICE EQUIPMENT

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

GROUND CLAMP

4 EN

USE

1. Accessories

To avoid personal injury:

•Do not place this product on an unstable cart, stand, tripod, bracket or table. It may fall, causing serious injury to a child or adult, and serious damage to the product.

•Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.

•Use a mounting accessory recommended by the manufacturer and follow the manufacturer’s instructions for any mounting of the product.

•Do not try to roll a cart with small casters across thresholds or deep-pile carpets.

2. Product and Cart

Combination

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

3. Water and Moisture

Do not use this product near water—for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.

4. Object and Liquid Entry

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

5. Attachments

Do not use attachments not recommended by the manufacturer of this product as they may cause hazards.

6. Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

7. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

SERVICING

1. Servicing

If your product is not operating correctly or exhibits a marked change in performance and you are unable to restore normal operation by following the detailed procedure in its operating instructions, do not attempt to service it yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

2. Damage Requiring Service

Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen

into the product.

c. If the product has been exposed to rain or water. d. If the product does not operate normally by

following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

e. If the product has been dropped or damaged in

any way.

f. When the product exhibits a distinct change in

performance—this indicates a need for service.

3. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

4. Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in safe operating condition.

PORTABLE CART WARNING (Symbol provided by RETAC)

EN5

SAFETY PRECAUTIONS

Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock.

CAUTION!

The following notes concern possible physical damage to the camcorder and to the user.

When carrying, be sure to always securely attach and use the provided shoulder strap. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the unit, or in a malfunction.

Take care not to get your finger caught in the cassette holder cover. Do not let children operate the camcorder, as they are particularly susceptible to this type of injury.

Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the camcorder.

CAUTION!

Attaching the camcorder to the Docking Station with cables (Audio/Video, S-Video, Editing, DC, etc.) connected, then leaving it on top of the TV is not recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage.

 This camcorder is designed exclusively for the digital video cassette. Only cassettes marked

“

” can be used with this unit.

Before recording an important scene . . .

.... make sure you only use cassettes with the Mini DV mark .

.... remember that this camcorder is not compatible with other digital video formats.

.... remember that this camcorder is intended for private consumer use only. Any commercial use

without proper permission is prohibited. (Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand.)

6 EN

•AC Power Adapter/Charger AA-V51U

•Remote Control Unit RM-V716U

•DC Cord

•CD-ROM

The CD ROM contains the following 5 software programs:

• JLIP Video Capture

• JLIP Video Producer

Mr. Photo Gold

• Mr. Photo

• PhotoAlbum

• ProImage Plus

•AAA (R03) Battery x 2 (for remote control unit)

•PC Connection Cable

•Audio Cable x 2

(for connection of an optional external microphone and headphones)

•Editing Cable (One plug has 3 rings around the pin, and the other has 1 ring around the pin.)

•Cleaning Cloth

PROVIDED ACCESSORIES

•Battery Pack BN-V507U

•JLIP Cable (Both plugs have

3 rings around the pin.)

•Docking Station CU-V503U

•Audio/Video Cable (ø3.5 mini-plug to RCA plug)

EN7

AUTOMATIC DEMONSTRATION

Automatic Demonstration takes place when “DEMO. MODE” is set to “ON” (factory-preset).

 Available when the POWER Switch is set to “ ” and no

cassette is in the camcorder.

 Performing any operation during the demonstration stops the

demonstration temporarily. If no operation is performed for more than 1 minute after that, the demonstration will resume.

 “DEMO. MODE” remains “ON” even if the camcorder power

is turned off.

 To cancel Automatic Demonstration, set the Operation Switch

to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then press the MENU wheel twice while the demo is in progress. This takes you directly to the demo mode’s Setting Menu (so you will not have to go through the Menu Screen). Rotate the MENU wheel to select “OFF” and press it. The normal screen appears.

How To Use Audio Cables

When using an optional external microphone or headphones, connect to the provided Audio cable (with a core filter attached), then connect the Audio cable to the camcorder. The core filter reduces interference.

To AV OUT

Microphone

Headphones

Audio cable

Core Filter

To MIC

Core Filter

S Z

S G B

R E O O N A E D

E C U O A

C T

N M P N P N

A U M D

/ U

M R O

M U

E N D M

O P A B

R E

O D

L E

D E L

EMEO

FUF

MENU Wheel

8 EN

GETTING STARTED

Power

This camcorder’s 2-way power supply system lets you choose the most appropriate source of power. Do not use provided power supply units with other equipment.

CHARGING THE BATTERY PACK

Make sure you unplug the camcorder’s DC cord from the AC Power Adapter/Charger. Plug the AC Adapter/ Charger’s power cord into an AC outlet. The POWER indicator lights.

Attach the battery pack with the mark aligned with the corresponding marks on the AC Power Adapter/Charger. The CHARGE Indicator begins blinking to indicate charging has started.

When the CHARGE indicator stops blinking but stays lit, charging is finished. Pull the battery out. Remember to unplug the AC Adapter/Charger’s power cord from the AC outlet.

To AC outlet

CHARGE indicator

POWER indicator

DC OUT connector

AC Power Adapter/Charger

NOTES:

●

Perform charging where the temperature is between 10°C and 35°C (50°F and 95°F). 20°C to 25°C (68°F to 77°F) is the ideal temperature range for charging. If the environment is too cold, charging may be incomplete.

●

Charging times noted above are for a fully discharged battery pack.

●

Charging time varies according to the ambient temperature and the status of the battery pack.

●

To avoid interference with reception, do not use the AC Power Adapter/Charger near a radio.

●

If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the camcorder and charging stops.

●

Since the AC Power Adapter/Charger processes electricity internally, it becomes warm during use. Be sure to use it only in well-ventilated areas.

●

When charging the battery pack for the first time or after a long storage period, the CHARGE indicator may not light. In this case, remove the battery pack from the AC Power Adapter/Charger, then try charging again.

●

If the battery operation time remains extremely short even after having been fully charged, the battery is worn out and needs to be replaced. Please purchase a new one.

Lithium-ion is vulnerable in colder temperatures.

About Batteries

DANGER! Do not attempt to take the batteries apart, or

expose them to flame or excessive heat, as it may cause a fire or explosion.

WARNING! Do not allow the battery or its terminals to come in contact with metals, as this can result in a short circuit and possibly start a fire.

The Benefits Of Lithium-Ion Batteries

Lithium-ion battery packs are small but have a large power capacity. However, when one is exposed to cold temperatures (below 10°C/50°F), its usage time becomes shorter and it may cease to function. If this happens, place the battery pack in your pocket or other warm, protected place for a short time, then re-attach it to the camcorder. As long as the battery pack itself is not cold, it should not affect performance.

(If you’re using a heating pad, make sure the battery pack does not come in direct contact with it.)

Battery pack

BN-V507U

BN-V514U (optional)

Charging time

approx. 1 hr. 30 min.

approx. 3 hrs.

Battery pack BN-V507U or BN-V514U

EN9

To battery pack mount

To DC OUT terminal

To AC outlet

AC Power Adapter/Charger

DC cord

ATTENTION:

Before detaching the power source, make sure that the camcorder’s power is turned off. Failure to do so can result in a camcorder malfunction.

USING THE BATTERY PACK

Insert the terminal end 1 of the battery pack into the battery pack mount, then firmly push the end 2 of the battery pack in the direction of the arrow until it locks into place as shown in the illustration.

•If the battery pack is attached in the wrong position, a malfunction may occur.

To Detach The Battery Pack. . .

.... while sliding down BATT. RELEASE, detach it.

Power cord

Approximate recording time

BATT. RELEASE Switch

NOTES:

●

Recording time is reduced significantly under the following conditions:

•

Zoom or Record-Standby mode is engaged repeatedly.

•

The LCD monitor is used repeatedly.

•

The playback mode is engaged repeatedly.

●

Before extended use, it is recommended that you prepare enough battery packs to cover 3 times the planned shooting time.

USING AC POWER

Use the AC Power Adapter/Charger (connect as shown in the illustration).

NOTES:

●

The provided AC Power Adapter/Charger features automatic voltage selection in the AC range from 110 V to 240 V.

●

For other notes,  pg. 8.

INFORMATION:

VU-V856KIT is a set composed of the BN-V856U battery pack and AA-V80U AC Power Adapter/Charger. Read the VU-V856KIT’s instruction manuals before using. It is impossible to charge the BN-V856U battery pack using the provided AC Power Adapter/ Charger. Use the optional AA-V80U AC Power Adapter/Charger.

Battery pack

BN-V507U

BN-V514U

(optional)

BN-V856U

(optional)

LCD monitor on/ Viewfinder off

55 min.

1 hr. 50 min.

7 hrs. 30 min.

LCD monitor off/ Viewfinder on

1 hr. 5 min.

2 hrs. 10 min.

9 hrs.

10 EN

PAUSE

Grip Adjustment

Separate the Velcro strip.

Pass your right hand through the loop and grasp the grip.

Adjust so that your thumb and fingers can easily operate the START/STOP Button and Power Zoom Lever. Refasten the Velcro strip.

Viewfinder Adjustment

Set the POWER Switch to “ ” while pressing down the Lock Button located on the switch and set the MODE Dial to any position.

Pull out the viewfinder fully.

Turn the Diopter Adjustment Control until the indications in the viewfinder are clearly focused.

START/STOP Button

Power Zoom Lever

Diopter Adjustment Control

POWER Switch

GETTING STARTED

(cont.)

MODE Dial

CAUTION:

When using a tripod, be sure to open and extend its legs fully to stabilize the camcorder. To prevent damage to the unit caused by falling over, do not use a smallsized tripod.

Tripod Mounting

Align the screw on the tripod with the camera’s mounting socket. Then tighten the screw.

Lock Button

EN11

FAD

W W

F F F

I A F A A A

P P

F D D D

E E D

E E E

– –

R R R

S S M

– – –

P C

W B B

E R

H L .

O T

I A W

L T

T C

E K

O D T

R N A

T M

O A

T S E E

C D

S U C

P R R T C

L N E

E M D

Y N

E E

MDE

255’

030

Date/Time Settings

The date/time is recorded onto the tape at all times, but its display can be turned on or off during playback ( pg. 37).

Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then open the LCD monitor fully or pull out the viewfinder fully. The POWER lamp lights and the camcorder is turned on.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”. Press it and “DISPLAY MENU” appears.

Rotate the MENU wheel to select “CLOCK ADJ.”. Press it and “month” is highlighted. Rotate the MENU wheel to input the month. Press it. Repeat to input the day, year, hour and minute. Rotate the MENU wheel to select “1RETURN”, and press it twice. The Menu Screen closes.

Built-in Clock’s Rechargeable Lithium Battery

To store the date/time in memory, the clock’s rechargeable lithium battery is integrated in the camcorder. While the camcorder is connected to an AC outlet using the AC Power Adapter/Charger, or while the battery pack attached to the camcorder continues to supply power, the clock’s rechargeable lithium battery is always charged. However, if the camcorder is not used for approx. 3 months, the clock’s lithium battery will become discharged and the date/time stored in memory will be lost. When this occurs, first connect the camcorder to an AC outlet using the AC Power Adapter/Charger for over 24 hours to charge the clock’s rechargeable lithium battery. Then perform the date/time setting before using the camcorder. Note that the camcorder can be used without setting the date/time.

NOTE:

Even if you select “CLOCK ADJ.”, if the parameter is not highlighted the camcorder’s internal clock continues to operate. Once you move the highlight bar to the first date/ time parameter (month), the clock stops. When you finish setting the minute and press the MENU wheel, the date and time begin operation from the date and time you just set.

Display

MENU Wheel

POWER Switch

DISPLAY MENU

POWER Lamp

Operation Switch

Lock Button

12 EN

Loading/Unloading A Cassette

The camcorder needs to be powered up to load or eject a cassette.

Slide down and hold OPEN/EJECT in the direction of the arrow then pull the cassette holder cover open until it locks. The cassette holder opens automatically.

•Do not touch internal components.

Insert or remove a tape and press “PUSH HERE” to close the cassette holder.

•Once the cassette holder is closed, it recedes automatically. Wait until it recedes completely before closing the cassette holder cover.

•When the battery’s charge is low, you may not be able to close the cassette holder cover. Do not apply force. Replace the battery with a fully charged one before continuing.

Close the cassette holder cover firmly until it locks into place.

OPEN/EJECT Switch

Cassette holder

PUSH HERE

Cassette holder cover

Make sure the window side is facing out.

Erase protection tab*

Tape

Recording mode

SP LP

30 min. 30 min. 45 min. 60 min. 60 min. 90 min. 80 min. 80 min. 120 min.

Approximate recording time

NOTES:

●

It takes a few seconds for the cassette holder to open. Do not apply force.

●

If you wait a few seconds and the cassette holder does not open, close the cassette holder cover and try again. If the cassette holder still does not open, turn the camcorder off then on again.

●

If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again.

●

When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover.

●

Closing the cassette holder cover before the cassette holder comes out may cause damage to the camcorder.

●

Even when the camcorder is switched off, a cassette can be loaded or unloaded. After the cassette holder is closed with the camcorder switched off, however, it may not recede. It is recommended to turn the power on before loading or unloading.

●

When resuming recording, once you open the cassette holder cover a blank portion will be recorded on the tape or a previously recorded scene will be erased (recorded over) regardless of whether the cassette holder came out or not. See page 20 for information about recording from the middle of a tape.

To Protect Valuable Recordings . . .

.... slide the erase protection tab on the back of

the tape in the direction of “SAVE”. This prevents the tape from being recorded over. To record on this tape, slide the tab back to “REC” before loading it.

GETTING STARTED

(cont.)

EN13

S Z S G B

O O N A E D E

U O A

E M

C T

N M P N P N O

A U

U T

E N

M O

P A B M

O D

L E

D E

L R D

Y E

N P

Recording Mode Setting

Set the tape recording mode depending on your preference.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ” and press it. “CAMERA MENU” appears.

Rotate the MENU wheel to select “REC MODE” and press it. The Sub Menu appears. Select “SP” or “LP” by rotating the MENU wheel and press it. Rotate the MENU wheel to select “1RETURN”, and press it twice. The Menu Screen closes.

•Audio Dubbing ( pg. 56) is impossible on a tape recorded in the LP mode.

•“LP” (Long Play) is more economical, providing

1.5 times the recording time.

NOTES:

●

If the recording mode is switched during recording, the playback picture will be blurred at the switching point.

●

It is recommended that tapes recorded in the LP mode on this camcorder be played back on this camcorder.

●

During playback of a tape recorded on another camcorder, blocks of noise may appear or there may be momentary pauses in the sound.

Display

Menu Screen

Sub Menu

MENU Wheel

POWER Switch

POWER Lamp

Operation Switch

Lock Button

14 EN

GETTING STARTED

(cont.)

F.AUTO

When the Operation Switch is set to “ ”, “F. AUTO” appears. When set to “ ”, there is

no indication.

To turn on the camcorder, set the POWER Switch to any operation mode except “OFF” while pressing down the Lock Button located on the switch.

POWER Switch

POWER Lamp

Operation Switch

Lock Button

Operation Switch Position

(Manual):

Allows you to set various recording functions using the Menus. If you want more creative capabilities than Full Auto recording, try this mode.

(Full Auto):

Allows you to record using NO special effects or manual adjustments. Suitable for standard recording.

POWER Switch Position

Allows you to record.

OFF:

Allows you to switch off the camcorder.

PLAY/PC

Allows you to play back a recording or to transfer a still image to a computer.

Operation Mode

Choose the appropriate operation mode according to your preference using the POWER Switch, Operation Switch and MODE Dial.

EN15

MODE

MODE Dial

Function

•Allows you to record video and still images. Approx. 6 seconds of a still image is inserted between video recordings ( pg. 18).

•Zoom magnification over 10X is available ( pg. 19, 25).

•Allows you to record moving images (successive jitter-free still images) with superior quality ( pg. 22). The still images can also be processed on a PC or printed out.

•Zoom magnification over 10X is available ( pg. 19, 25).

•Playback of images recorded in this mode is not smooth.

MODE Dial Position

VIDEO

(Progressive mode)

The following indications appear in the upper left corner, depending on the MODE Dial position.

No display :

When set to “VIDEO”

PS :

When set to “

”

16 EN

180°

90°

90 min

89 min

3 min

2 min

1 min0 min

min

BR I GHT

RECORDING

Basic Recording

POWER Lamp

Tally lamp (lights while recording is in progress)

MODE Dial

START/STOP Button

Tape remaining time indicator (Approximate)

(Now calculating)

(Blinking) (Blinking) (Blinking)

Display

To Adjust The Brightness Of The Display

.... rotate the MENU wheel until the bright level indicator

on the display moves and the appropriate brightness is reached.

•It is also possible to adjust the brightness of the viewfinder.

POWER Switch

NOTE:

You should already have performed the procedures listed below. If not, do so before continuing.

●

Power ( pg. 8)

●

Grip Adjustment ( pg. 10)

●

Viewfinder Adjustment ( pg. 10)

●

Load A Cassette ( pg. 12)

●

Recording Mode Setting ( pg. 13)

Set the MODE Dial to “VIDEO” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch.

Shooting while using the viewfinder:

Make sure the LCD monitor is closed and locked. Pull out the viewfinder fully.

•Be sure to pull out the viewfinder until you hear a

click, otherwise it may be pushed back in during use.

Shooting while using the LCD monitor:

Make sure the viewfinder is pushed back in. Open the LCD monitor fully.

•The POWER lamp lights and the camcorder enters

the Record-Standby mode. “PAUSE” is displayed.

Press START/STOP. “ ” appears while recording is in progress.

To Stop Recording . . .

.... press START/STOP. The camcorder re-enters the

Record-Standby mode.

MENU Wheel

Lock Button

EN17

Self-Recording

JOURNALISTIC SHOOTING

In some situations, different shooting angles may provide more dramatic results. Hold the camcorder in the desired position and tilt the LCD monitor in the most convenient direction. It can rotate 270° (90° downward, 180° upward).

NOTES:

●

When you use the LCD monitor outdoors in direct sunlight, the LCD monitor may be difficult to see. If this happens, use the viewfinder instead.

●

The image will not appear simultaneously in the LCD monitor and the viewfinder.

●

The cassette holder cannot be opened unless a power supply is attached.

●

There may be a delay after you open the cassette holder cover until the cassette holder opens. Do not use force.

●

Once the cassette holder is closed, it recedes automatically. Wait until it recedes completely before closing the cassette holder cover.

●

The time required to calculate and display the remaining tape length, and the accuracy of the calculation, may vary according to the type of tape used.

●

“TAPE END” appears when the tape reaches its end, and the power goes off automatically if left in this condition for 5 minutes. “TAPE END” also appears when a cassette at its end is loaded.

●

If the Record-Standby mode continues for 5 minutes, the camcorder’s power shuts off automatically. To turn the camcorder on again, push back and pull out the viewfinder again or close and re-open the LCD monitor.

●

When a blank portion is left between recorded scenes on the tape, the time code is interrupted and errors may occur when editing the tape. To avoid this, refer to “Recording from the middle of a tape” ( pg. 20).

●

During recording, sound is not heard from the speaker. To hear the sound, connect optional headphones to the headphone connector. The sound volume is at the level it was adjusted to during playback ( pg. 36).

●

To turn the tally lamp off during recording,  pg. 24, 25.

●

To remove the indications from the camcorder’s display during recording,  pg. 24, 27.

SELF-RECORDING

You can shoot yourself while viewing your own image in the LCD monitor. Open the LCD monitor and tilt it upward 180° so that it faces forward, then point the lens toward yourself and start recording.

18 EN

R S Z

G B

R E O O

A E D E

E C U O

E M

N M

N P N O

A U M D

R O

U T

E N D M

P A B M

L E

L R D

Y E

LNL

–UP

RECORDING

Basic Recording (cont.)

FULL Snapshot mode with no frame*

PIN-UP Pin-Up mode

Snapshot

This feature lets you record still images that look like photographs onto a tape.

SNAPSHOT MODE SELECTION

Set the POWER Switch to “ ” while pressing down the Lock Button located on the switch and the MODE Dial to “VIDEO” or “ ”, then set the Operation Switch to “ ”. Pull out the viewfinder fully or open the LCD monitor fully.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”. Press it and “CAMERA MENU” appears.

Rotate the MENU wheel to select “SNAP MODE”, then press it.

Rotate the MENU wheel to select the desired Snapshot mode, then press it. Rotate the MENU wheel to select “1RETURN” and press it twice. The Menu Screen closes.

SNAPSHOT RECORDING

Press SNAPSHOT.

If you press during Record-Standby . . .

.... “PHOTO” appears and a still image will be

recorded for approx. 6 seconds, then the camcorder re-enters the Record-Standby mode.

If you press during Recording . . .

.... “PHOTO” appears and a still image will be

recorded for approx. 6 seconds, then the normal recording resumes.

Motor Drive Mode

Keeping SNAPSHOT pressed provides an effect similar to serial photography. (Interval between still images: approx. 1 second)

NOTES:

●

To remove the shutter sound,  “BEEP/TALLY” on pg. 25.

●

If Snapshot recording is not possible, “PHOTO” blinks when SNAPSHOT is pressed.

●

If Program AE with special effects ( pg. 32) is engaged, certain modes of Program AE with special effects are disabled during Snapshot recording. In such a case, the icon blinks.

●

If SNAPSHOT is pressed when “DIS” is set to “ON” ( pg. 26), the Stabilizer will be disabled.

●

During playback as well, all snapshot modes are available.

●

When a headphone set is connected to the headphone connector, the shutter sound is not heard from the speaker, however it is recorded onto the tape.

Display

SNAPSHOT Button

MODE Dial

Operation Switch

POWER Switch

MENU Wheel

Menu Screen

* There is the sound effect of a shutter closing.

When the MODE Dial is set to “

”, snapshot

recording will be performed with higher quality (

 pg. 22).

Lock Button

EN19

10xW

1xW

10xW

20xW

40xW

Zoom in (T: Telephoto)

Zoom out (W: Wide angle)

Power Zoom Lever

Zoom display

FEATURE:

Zooming

PURPOSE:

To produce the zoom in/out effect, or an instantaneous change in image magnification.

OPERATION:

Zoom In

Slide the Power Zoom Lever towards “T”.

Zoom Out

Slide the Power Zoom Lever towards “W”.

 The further you slide the Power Zoom Lever, the

quicker the zoom action.

NOTES:

●

Focusing may become unstable during Zooming. In this case, set the zoom while in Record-Standby, lock the focus by using the manual focus ( pg. 21), then zoom in or out in Record mode.

●

Zooming is possible to a maximum of 200X, or it can be switched to 10X magnification using the optical zoom ( pg. 25).

●

Zoom magnification of over 10X is done through Digital image processing, and is therefore called Digital Zoom.

●

During Digital zoom, the quality of image may suffer.

●

Digital zoom cannot be used when digital image processing, such as Picture Wipe/Dissolve ( pg. 30, 31) or Video Echo ( pg. 33), is activated.

●

Macro shooting (as close as approx. 5 cm (2") to the subject) is possible when the Power Zoom Lever is set all the way to “W”. Also see “TELE MACRO” in the Menu Screen on page 26.

Approximate zoom ratio

Digital zoom zone

10X (optical) zoom zone

POWER Switch

20 EN

NOTE: Recording From The Middle Of A Tape

Time Code

During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame). If recording starts from the end of a previously recorded scene, the time code continues from the last time code number.

To perform Random Assemble Editing ( pg. 50 – 55), time code is necessary. If during recording a blank portion is left partway through the tape, the time code is interrupted. When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform “Recording From The Middle of A Tape” below in the following cases;

•When shooting again after playing back a recorded tape.

•When power shuts off during shooting.

•When a tape is removed and re-inserted during

shooting.

•When shooting using a partially recorded tape.

•When shooting on a blank portion located

partway through the tape.

•When shooting again after shooting a scene then opening/closing the cassette holder cover.

Recording From The Middle Of A Tape

1. Play back a tape or use Blank Search ( pg. 39) to find the spot at which you want to start recording,

then engage the Still Playback mode ( pg. 36).

2. Set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then

start recording.

NOTES:

●

The time code cannot be reset.

●

During fast-forwarding and rewinding, the time code indication does not move smoothly.

●

The time code is displayed only when “TIME CODE” is set to “ON” ( pg. 27, 37).

Shooting start point

Newly recorded sceneBlankAlready recorded scene

Time code 05:43:21

Time code 00:00:00

Tape

Time code 00:00:00

Shooting start pointShooting stop point

12:34:24

Display

When a blank portion is recorded on a tape

Shooting start point

Time code 05:43:21

Time code 05:44:00

Tape

Time code 00:00:00

Shooting start pointShooting start point

Proper recording

Latest sceneNew sceneAlready recorded scene

Frames (30 frames = 1 second)

Seconds

Minutes

Frames are not displayed during recording.

RECORDING

Basic Recording (cont.)

EN21

FOCUS FOCUS

While focusing on a nearer subject

While focusing on a further subject

FEATURE:

Auto Focus

PURPOSE:

The camcorder’s Full Range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm (2") to the subject) to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing):

•When two subjects overlap in the same scene.

•When illumination is low.*

•When the subject has no contrast (difference in brightness and darkness), such as a flat, one-color wall, or

a clear, blue sky.*

•When a dark object is barely visible in the viewfinder.*

•When the scene contains minute patterns or identical patterns that are regularly repeated.

•When the scene is affected by sunbeams or light reflecting off the surface of a body of water.

•When shooting a scene with a high-contrast background.

* The following low-contrast warnings appear blinking: , , and

NOTES:

●

If the lens is smeared or blurred, accurate focusing is not possible. Keep the lens clean, wiping with a piece of soft cloth if it gets dirty. When condensation occurs, wipe with a soft cloth or wait for it to dry naturally.

●

When shooting a subject close to the lens, zoom out first ( pg. 19). If zoomed-in in the auto focus mode, the camcorder may automatically zoom out depending on the distance between the camcorder and the subject. This will not occur when “TELE MACRO” ( pg. 26) is activated.

FEATURE:

Manual Focus

PURPOSE:

To obtain correct focus.

OPERATION:

1) If you are using the viewfinder, you should already have made the necessary viewfinder adjustments

( pg. 10).

2) Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then press FOCUS (

). The manual focus indicator appears.

3) To focus on a farther subject, rotate the MENU wheel towards “+”. “ ” appears and blinks. To focus on a nearer subject, rotate the MENU wheel towards “–”. “ ” appears and blinks.

4) Press the MENU wheel. Focus adjustment is complete.

To reset to Auto Focus, press FOCUS (

) twice or set the Operation Switch to “ ”.

If FOCUS (

) is pressed once, the camcorder will enter the focus adjustment mode again.

NOTES:

●

Be sure to focus the lens in the maximum telephoto position when you use the Manual Focus mode. If you focus in on a subject in the wide-angle position, sharply focused images cannot be obtained when zoomed up because the depth-of-field is reduced at longer focal lengths.

●

When the focus level cannot be adjusted any further or closer, “ ” or “ ” will blink.

Focus detection zone

22 EN

Progressive Mode Recording

This mode lets you record moving images (successive jitter-free still images) onto a tape. Images can then played back jitter-free, with superior quality. High-resolution still images can also be processed on a personal computer or can be printed out ( pg. 43).

Set the MODE Dial to “ ”, then set the POWER Switch to “ ” while pressing down the Lock Button located on the switch. Pull out the viewfinder fully or open the LCD monitor fully.

To start Progressive Mode Recording, press START/ STOP.

To End Progressive Mode Recording . . .

.... press START/STOP. The camcorder enters the Record-

Standby mode.

NOTES:

●

When an image recorded using the Progressive Mode is played back, the image may not look natural.

●

When the MODE Dial is set to “ ”, Picture Wipe/ Dissolve ( pg. 30) and some Program AE with special effects ( pg. 33) cannot be used.

●

If SNAPSHOT is pressed in the PS mode, a snapshot will be recorded with higher quality than in VIDEO mode. ( pg. 18).

SNAPSHOT Button

START/STOP Button

Lock Button

RECORDING

Advanced Features

MODE Dial

POWER Switch

EN23

Description of Progressive Scan CCD

Progressive Scan is a special image sensing method which, unlike conventional interlace scanning, is able to pick up all the lines of picture information in one Scan. Since the Progressive Scan CCD is capable of outputting 60 full Frames* per second — twice the amount of conventional systems — it is able to deliver a high quality picture even when its output signal is converted to a format that can be viewed on a TV screen.

*A NTSC TV screen image is composed of 30 Frames per second. 1 Frame is made up of 2 Fields.

Scan C

Scan A

1 Frame

Scan B

Skip

Scan D

Skip

Scan A

1. Regular shooting of moving images

Records 30 odd and 30 even image Fields, for a total of 60 per second. Since there is a time lag between an odd and even Field, when they are combined to make 1 Frame the part of the image that is moving appears as image jitter. However, during normal

playback, the moving picture looks smooth and natural.

2. Progressive mode shooting of moving images (Progressive Mode Recording  pg. 22)

Scan A is recorded, divided into an odd- and even-number Field, and then Scan B is skipped. Scans C and D are handled in the same way as Scans A and B, as illustrated below, thereby recording 30 Frames per second.

Since each recorded odd- and even-number Field originates from the same Scan there is no time lag between them, and so when they are combined into a Frame and a still image is displayed on a TV or PC monitor the

picture does not look jittery. However, when moving images are played back, the picture can look unnatural.

Even-number

Field

30 Frames per second

Odd-number

Field

Odd-number

Field

Even-number

Field

Scan B

24 EN

FAD

W W

F F F

I I

F A A A

R P

P N

F D D D

E E D

E E E

– –

R R R

S S M

– – –

P C

W B B

E R

H L .

O T

L T

T C

E K

O D

R N A

D E

T M

O A

T S E E

C D

S U C

P R R T C

L N E

A E

M D

Y N

E E

MDE

255’

030

END

S Z S G B

O O N A E D E

U O A

E M

C T

N M P N P N O

A U

U T

E N

M O

P A B M

O D

L E O

D E L

R D

Y E

N P

S 5

T W W

E S E

L L

D N

M T

F E

E D

A U

–

N R

M M

U N

A O U

C D T

E R

UFE

Display

Menu Screen

MENU Wheel

Lock Button

RECORDING

Advanced Features (cont.)

Using Menus For Detailed Adjustment

This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings ( pg. 25 – 27) .

Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then pull out the viewfinder fully or open the LCD monitor fully.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select the desired function icon, and press it. The selected function menu appears.

Function menu setting depends on the function.

If you have selected “ ”, “ ” or “ ” . . .

.... see pg. 25.

If you have selected “ ”, “ ” or “ ”. . .

.... go to step 5.

Rotate the MENU wheel to select the desired function and press it. The Sub Menu appears. Then, rotate the MENU wheel to select the parameter, and press it. Selection is complete.

Rotate the MENU wheel to select “1RETURN” and press it twice. The Menu Screen closes.

•The icon represents “END”.

Sub Menu

Normal Screen

POWER Switch

Operation Switch

EN25

Menu Screen Explanations

: Factory-preset

CONTINUED ON NEXT PAGE

CAMERA MENU

F ADER/WIPE P.AE/EFFECT W.BALANCE

REC MODE

SOUND MODE

ZOOM

GAIN UP

BEEP/ TALLY

SNAP MODE

ID NUMBER

12 BIT

16 BIT

10X

40X

200X

NOTE:

The “ CAMERA MENU” settings are effective when the Operation Switch is set to both “ ” and “ ”.

Refer to “Fade/Wipe Effects” ( pg. 30, 31). Refer to “Program AE With Special Effects” ( pg. 32, 33). Refer to “White Balance Adjustment” and “Manual White Balance Operation”

( pg. 35). Allows you to set the recording mode (SP or LP) depending on your

preference ( pg. 13). Enables recording of stereo sound on four separate channels, and is recom-

mended for use when performing audio dubbing. (Equivalent to the 32 kHz mode of previous models)

Enables recording of stereo sound on two separate channels. (Equivalent to the 48 kHz mode of previous models)

When set to “10X” while using digital zoom, the zoom magnification will reset to 10X since digital zoom will be disengaged.

Allows you to use the Digital Zoom. By digitally processing and magnifying images, zooming is possible from 10X (the optical zoom limit), to a maximum of 40X digital magnification.

Allows you to use the Digital Zoom. By digitally processing and magnifying images, zooming is possible from 10X (the optical zoom limit), to a maximum of 200X digital magnification.

Refer to “Snapshot” ( pg. 18).

Allows you to shoot dark scenes with no picture brightness adjustment. The overall appearance may be grainy, but the image is bright. The shutter speed is automatically adjusted (1/30 — 1/200 sec.). Shooting a

subject in low or poor lighting at 1/30 sec. shutter speed provides a brighter image than in the AGC mode, but the subject’s movements are not smooth or natural. The overall appearance may be grainy. When shooting a subject in low lighting in this mode, “ ” is displayed.

The tally lamp comes on to signal the start of recording. Instead of a beep, a melody sounds when any operation is performed. It also activates the shutter sound effect ( pg. 18).

The tally lamp comes on to signal the start of recording. The beep sounds when the power is turned on or off, and at the beginning and end of recording. Also to activate the shutter sound effect ( pg. 18).

The tally lamp remains off at all times. Even though not heard while shooting, shutter sound is recorded on the tape.

This number is necessary when connecting the camcorder to a device such as a computer using the J terminal (JLIP). The numbers range from 01 to 99. Factory setting is 06.

OFF AGC AUTO

ON: MEL.

ON:BEEP

OFF

FULL PIN-UP

26 EN

Menu Screen Explanations (cont.)

RECORDING

Advanced Features (cont.)

DIS

SELFTIMER

TELE MACRO

WIDE MODE

DEMO. MODE

CAMERA MENU

Demonstrates certain functions such as Program AE with special effects, etc., and can be used to confirm how these functions operate. When “DEMO. MODE” is set to “ON” and the Menu Screen is closed, demonstration starts. Performing any operation during the demonstration stops the demonstration temporarily. If no operation is performed for more than 1 minute after that, the demonstration will resume.

NOTES:

● If a tape is in the camcorder, the demonstration cannot be turned on.

● “DEMO. MODE” remains “ON” even if the camcorder power is turned off.

● If “DEMO. MODE” remains “ON”, some functions will not be available. After

viewing demo, set to “OFF”. Automatic demonstration will not take place. To compensate for unstable images caused by camera-shake, particularly at high

magnification.

NOTES:

● Accurate stabilization may not be possible if hand shake is excessive, or under

the following conditions:

•When shooting subjects with vertical or horizontal stripes.

•When shooting dark or dim subjects.

•When shooting subjects with excessive backlighting.

•When shooting scenes with movement in various directions.

•When shooting scenes with low-contrast backgrounds.

● Switch off this mode when recording with the camcorder on a tripod.

● The “ ” indicator blinks or goes out if the Stabilizer cannot be used.

Refer to “Self-Timer” ( pg. 28).

Refer to “5-Second Recording” ( pg. 29).

Allows you to record a few frames only. By using an inanimate object and changing its position between shots, you can record the subject as though it is moving ( pg. 29).

Usually the distance to a subject where the lens is in focus depends on the zoom magnification. Unless there is a distance more than 1m (3.3 ft.) to the subject, the lens is out of focus at the maximum telephoto setting. When set to “ON”, you can shoot a subject as large as possible at a distance of approx. 60 cm (2 ft.).

•Depending on the zoom position, the lens may go out of focus. Records with no change in the screen ratio. For playback on a TV with a normal

screen ratio. Inserts black bands at the top and bottom of the screen. During playback on wide-

screen TVs, the black bands at the top and bottom of the screen are cut and the screen ratio becomes 16:9. appears. When using this mode, refer to your widescreen TV’s instruction manual. During playback/recording on 4:3 TVs/LCD monitor/ viewfinder, black bands are inserted at the top and bottom of the screen and the image appears like a letterboxed 16:9 movie.

•“CINEMA” mode is effective only when the MODE Dial is set to “VIDEO” or “ ”. For playback on TVs with an aspect ratio of 16:9. Naturally expands the image to fit

the screen without distortion. appears. When using this mode, refer to your wide-screen TV’s instruction manual. During playback/recording on 4:3 TVs/LCD monitor/viewfinder, the image is elongated vertically.

•“SQUEEZE” mode is effective only when the MODE Dial is set to “VIDEO” or “ ”.

appears. The zoom range is extended beyond the maximum optical zoom wide angle range. This mode’s wide angle setting is equivalent to using a 0.7X wide conversion lens. Zooming is possible from 0.7X to 10X. This mode is suitable for shooting in a small room.

•PS-WIDE” mode is effective only when the MODE Dial is set to “ ”.

OFF

OFF 5S

ANIM.

OFF

CINEMA

SQUEEZE

PS-WIDE

MANUAL MENU

: Factory-preset

EN27

NOTES:

●

The “MANUAL MENU” settings are effective only when the Operation Switch is set to “ ”.

●

“DISPLAY MENU” functions which are set when the POWER Switch is set to “ ” are also applied when the POWER Switch is set to “

PLAY/PC

” ( pg. 37). “CLOCK ADJ.” only appears when the POWER

Switch is set to “ ”.

●

The “DISPLAY MENU” settings are effective even when the Operation Switch is set to “ ”.

●

The “ON SCREEN” setting can also be changed by pressing the DISPLAY Button on the remote control (provided) ( pg. 41, 44, 51).

: Factory-preset

DISPLAY MENU

ON SCREEN

DA TE/ TIME

TIME CODE

CLOCK ADJ.

WIND CUT

Disengages the function which cuts down on noise created by wind.

Helps cut down on noise created by wind. “ ” appears. The quality of the sound will change. This is normal.

Keeps the camcorder’s display (except the date, time and time code) from appearing on the connected TV screen.

Makes the camcorder’s display appear on screen when the camcorder is connected to a TV.

Keeps the indications (except the tape running indicator, warnings, date, time, time code, etc.) from appearing in the camcorder. Also keeps the camcorder’s display (except the date, time and time code) from appearing on the connected TV screen.

Displays the date/time for approx. 5 seconds in the following cases:

•When the POWER Switch is set from “OFF” to “ ” or “

PLAY/PC

”.

•When playback starts. The camcorder displays the date/time when scenes

are recorded.

•When the date is changed during playback. The date/time does not appear. The date/time is always displayed. Time code is not displayed. Time code is displayed on the camcorder and on the connected TV. Frame

numbers are not displayed during recording.

Allows you to set the current date and time ( pg. 11).

LCD

LCD/TV

SIMPLE

AUTO

OFF ON

OFF

MANUAL MENU

28 EN

T W W

S E

E S

L D N

M T

E E D

A U

–

N R

M M

U N

A O U

C D

R E

Self-Timer

Once the camcorder is set, the camcorder operator can become part of the scene in a more natural way, adding the final touch to a memorable picture.

Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then pull out the viewfinder or open the LCD monitor fully.

•You can tilt the LCD monitor upward to 180° so that it faces forward and view yourself while selfrecording with the viewfinder pushed back.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, and press it.

Rotate the MENU wheel to select “SELF-TIMER”, and press it. The Sub Menu appears. Rotate the MENU wheel to select “ON”, and press it. Selection is complete. Rotate the MENU wheel to select “1RETURN”, and press it twice to close the Menu Screen.

To engage the Self-Timer for video recording, press START/STOP. After 15 seconds, the beep sounds and video recording starts. To stop Self-Timer recording, press START/STOP again. The camcorder re-enters Record-Standby mode.

Press SNAPSHOT. After 15 seconds, the beep sounds and snapshot recording starts. After that, the camcorder re-enters Record-Standby mode.

To end Self-Timer recording, select “OFF” in step 4 or set the POWER Switch to “OFF” or set the Operation Switch to “ ”.

NOTE:

If “BEEP/TALLY” is set to “OFF” ( pg. 25), the beep does not sound and the tally lamp does not light.

Self-Timer indication

When START/STOP or SNAPSHOT is pressed, the tally lamp changes as shown:

POWER Switch

Display

MENU Wheel

Menu Screen

RECORDING

Advanced Features (cont.)

START/STOP Button

SNAPSHOT Button

Operation Switch

Lock Button

Blinks quickly (Self-Timer shooting starts soon)

Stops blinking and stays on (Self-Timer video recording starts)

Begins blinking (Self-Timer starts)

After approx. 15 sec.

Turns off (Self-Timer snapshot recording starts)

4 4

EN29

D S

T W W

I E

E S

L D N

M T

F E

E D

A U

–

N R

M M

U N

A O U

M C

E R

IM.

5-Second Recording

Record a vacation or an important event in 5-second clips to keep the action moving. This function is available only for video recording.

Set the POWER Switch to “ ” while pressing down the Lock Button located on the switch and set the MODE Dial to “VIDEO” or “ ”, then set the Operation Switch to “ ”. Pull out the viewfinder fully or open the LCD monitor fully.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, and press it. “MANUAL MENU” appears.

Rotate the MENU wheel to select “5S”, and press it. The Sub Menu appears.

Rotate the MENU wheel to select “5S”, and press it.

•“5S MODE” appears.

Press START/STOP. The tally lamp lights and beep sounds to indicate the start of recording, and after 5 seconds the camcorder enters Record-Standby mode.

•Even if you press START/STOP again within 5

seconds after recording starts, Record-Standby mode is not engaged.

To exit the 5S mode, select “OFF” in step 5 or set the Operation Switch to “ ” or the POWER Switch to “OFF”.

To Take A Snapshot In The 5-Second Recording Mode . . .

.... instead of pressing START/STOP in step 6, select the

desired Snapshot mode in the Menu Screen, then press SNAPSHOT. The camcorder records a 5-second still ( pg. 18). When “5S” is set to “ANIM.” ( pg. 26) this function is not available.

NOTE:

When “5S” is set to “ANIM.” in the Menu Screen the 5-second recording mode is not available. Animation recording of a few frames only is taken instead ( pg. 26).

Display

Menu Screen

SNAPSHOT Button

POWER Switch

MENU Wheel

START/STOP Button

MODE Dial

Lock Button

Operation Switch

30 EN

RECORDING

Advanced Features (cont.)

Fade/Wipe Effects

These effects let you make pro-style scene transitions. Use them to spice up the transition from one scene to the next. You can also vary transitions from scene to scene.

IMPORTANT:

Some Fade/Wipe Effects cannot be used with certain modes of Program AE with special effects ( pg. 32). If an unusable Fade/Wipe Effect is selected, its indicator blinks or goes out.

START/STOP Button

MENU Wheel

POWER Switch

FADE/WIPE SELECTION ( , , , ,

, , , , and )

Fade or Wipe works when recording is started or when you stop recording.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, then press it.

Rotate the MENU wheel to select the desired function, then press it. Selection is complete.

•The FADER/WIPE Menu disappears and the effect is reserved. The indicator representing the selected effect appears.

Press START/STOP to activate the Fade-in/out or Wipe-in/out.

PICTURE WIPE OR DISSOLVE SELECTION ( , , , , , and )

The Picture Wipe or Dissolve works when recording is started.

Follow steps 1 through 4 above.

Engage the Record-Standby mode.

If you select Picture Wipe/Dissolve during recording . . .

.... press START/STOP when one scene is finished.

The point at which the scene ended is stored in memory.

If you select Picture Wipe/Dissolve during RecordStandby mode . . .

.... press START/STOP to start recording and press it

again when one scene is finished. The point at which the scene ended is stored in memory.

If you select Picture Wipe/Dissolve during RecordStandby mode after performing a Picture Wipe/ Dissolve . . .

.... the point at which the scene ended is already

stored in memory.

If you start recording a new scene within 5 minutes of the end of the previous recording (without having turned the camcorder’s power off), the previous scene wipes out, revealing the new scene.

To Deactivate The Selected Effect . . .

.... select “OFF” in step 4.

NOTES:

●

You can extend the length of a Fade or Wipe by pressing and holding START/STOP.

●

If the power is turned off after a scene is finished recording, the stored point is erased, disabling the Picture Wipe/Dissolve combination. When this happens, the Picture Wipe/ Dissolve indicator blinks. Also note that power shuts off automatically if 5 minutes elapse in the Record-Standby mode.

●

Picture Wipe/Dissolve cannot be used when the MODE Dial is set to “ ”.

●

The sound at the end of the last recorded scene is not stored.

MODE Dial

Lock Button

Operation Switch

EN31

Fader And Wipe Menu

Menu Effect

Fade in or out with a white screen.

Fade in or out with a black screen.

Fade in to a color screen from a black and white screen, or fade out from color to black and white.

Wipe in on a black screen from the upper right to the lower left corner, or wipe out from lower left to upper right, leaving a black screen.

The scene starts in the center of a black screen and wipes in toward the corners, or comes in from the corners, gradually wiping out to the center.

Wipe in from right to left, or wipe out from left to right.

Wipe in as the two halves of a black screen open to the left and right, revealing the scene, or wipe out and the black screen reappears from left and right to cover the scene.

The scene wipes in from the bottom to the top of a black screen, or wipes out from top to bottom, leaving a black screen.

Wipe in from the center of a black screen toward the top and bottom, or wipe out from the top and bottom toward the center leaving a black screen.

The new scene gradually appears as the old one gradually disappears.

The new scene wipes in over the previous one from the upper right corner to the lower left corner.

The next scene gradually wipes in from the center of the screen toward the corners, covering the previous scene.

The next scene gradually wipes in over the previous one from right to left.

The previous scene wipes out from the center to the right and left, like a door being pushed open to reveal the next scene.

The new scene wipes in over the last one from the bottom of the screen to the top.

The new scene wipes in over the previous one from the center toward the top and bottom of the screen.

When this function is activated, the camcorder randomly selects the effect used in scene transition (from , , , , , ,

, , and ). The Picture Wipe/Dissolve function is not

available.

FADER — WHITE

FADER — BLACK

WIPE — CORNER

WIPE — WINDOW

WIPE — SLIDE

WIPE — DOOR

WIPE — SCROLL

WIPE — SHUTTER

FADER — B.W

DISSOLVE

WIPE — CORNER

WIPE — WINDOW

WIPE — SLIDE

RANDOM

WIPE — SHUTTER

WIPE — DOOR

WIPE — SCROLL

32 EN

1/60 1/100 1/250

P 1

S S V

S S S

A L

H H H

E O

O D

U U U

W W E

T T T

O T

T T

E E E

F 1

2 E

R R R

ECCHT

RECORDING

Advanced Features (cont.)

Program AE With Special Effects

Set the Operation Switch to “ ”, then set the POWER Switch to “ ” while pressing down the Lock Button located on the switch. Pull out the viewfinder fully or open the LCD monitor fully.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, then press it.

Rotate the MENU wheel to select the desired mode, then press it. Selection is complete.

•The P.AE/EFFECT Menu disappears and the selected mode is activated. The selected mode indicator appears.

To Deactivate The Selected Mode . . .

.... select “OFF” in step 4.

NOTE:

Program AE with special effects can be changed during recording or during Record-Standby.

MENU Wheel

POWER Switch

IMPORTANT:

Some modes of Program AE with special effects cannot be used with certain Fade/Wipe Effects ( pg. 31). If an unusable mode is selected, its indicator blinks or goes out.

MODE Dial

Display

Menu Screen

Lock Button

Operation Switch

EN33

TWILIGHT

Makes evening scenes look more natural. White Balance ( pg. 35) is initially set to , but can be changed to your desired setting. When Twilight is chosen, the camcorder automatically adjusts the focus from approx. 10 m (32 ft) to infinity. From less than 10 m (32 ft), adjust the focus manually.

SEPIA

Recorded scenes have a brownish tint like old photos. Combine this with the Cinema mode for a classic look.

MONOTONE

Like classic black and white films, your footage is shot in B/W. Used together with the Cinema mode, it enhances the “classic film” effect.

CLASSIC FILM

Gives recorded scenes a strobe effect.

STROBE

Your recording looks like a series of consecutive snapshots.

VIDEO ECHO

Adds a “ghost” to the subject, giving your recording a “fantasy” feeling. Zoom magnification of over 10X is not available.

SLOW (Slow Shutter)

Lights dark subjects or areas even brighter than they would be under good natural lighting. Use “SLOW” only in dark areas.

SLOW 1

Slow Shutter raises light sensitivity to allow shooting in dark environments.

SLOW 2

Slow Shutter raises light sensitivity further to allow shooting in even darker environments.

NOTES:

●

When using “SLOW”, the image takes on a strobe-like effect.

●

If the manual focus indicator blinks when “SLOW” is used, adjust focus manually and use a tripod.

SHUTTER (Variable Shutter Speed) 1/60–The shutter speed is fixed at 1/60th of a

second. Black bands that usually appear when shooting a TV screen become narrower. 1/100–The shutter speed is fixed at 1/100th of a second. The flickering that occurs when shooting under a fluorescent light or mercury-vapor lamp is reduced. 1/250 –This setting allows fast-moving images to be captured one frame at a time, for vivid, stable slow-motion playback. The faster the shutter speed, the darker the picture becomes. Use the shutter function under good lighting conditions.

Available only when the MODE Dial is set to “VIDEO”.

34 EN

RECORDING

Advanced Features (cont.)

Exposure Control

Manual exposure adjustment is recommended in the following situations:

•

When shooting using reverse lighting or when the background is too bright.

•

When shooting on a reflective natural background such as at the beach or when skiing.

•

When the background is overly dark or the subject light.

Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then pull out the viewfinder fully or open the LCD monitor fully.

Press EXPOSURE. “EXP.” and the exposure control indicator appear.

Rotate the MENU wheel towards “+” to brighten the image, or towards “–” to darken the image. (maximum ±6)

Press the MENU wheel. Exposure adjustment is complete. “EXP.” goes out.

To Return To Automatic Exposure Control . . .

.... press EXPOSURE or set the Operation Switch to

“ ”.

To Brighten The Subject Quickly . . .

.... press BACKLIGHT. is displayed and the

subject is brightened. If pressed again, disappears and the brightness returns to the previous level.

•+3 exposure has the same effect as the

BACKLIGHT Button.

•Using BACKLIGHT may cause the light around the

subject to become too bright and the subject to

become white.

•Backlight compensations is also available when the Operation Switch is set to “ ”.

EX0P.

Iris lock indicator

MENU Wheel

POWER Switch

Iris Lock

Use this function in the following situations:

•

When shooting a moving subject.

•

When the distance to the subject changes (so its size in the LCD monitor or the viewfinder changes), such as when the subject is backing away.

•

When shooting on a reflective natural background such as at the beach or when skiing.

•

When shooting objects under a spotlight.

•

When zooming.

When the subject is close, keep the iris locked. Even when the subject moves away from you, the image will not darken or brighten.

Before the following steps, perform steps 1 and 2 of “Exposure Control”.

Adjust zoom so that the subject fills the LCD monitor or the viewfinder, then press and hold the MENU wheel for over 2 seconds. The exposure control indicator and “ ” appear. Press the MENU wheel. “ ” changes to “ ” and the iris is locked. “EXP.” goes out.

To Return To Automatic Iris Control . . .

.... press EXPOSURE so that the exposure control

indicator and “ ” disappear. Or, set the Operation Switch to “ ”.

To Lock The Exposure Control And The Iris . . .

.... after step 2, adjust the exposure rotating the

MENU wheel. Then lock the iris in step 3. For

automatic locking, press EXPOSURE again in step 2. The iris becomes automatic after about 2 seconds.

Iris

Like the pupil of the human eye, it contracts in welllit environments to keep too much light from entering, and dilates in dim environments to allow in more light.

Operation Switch

BACKLIGHT Button (

)

EXPOSURE Button (

/6)

EN35

White Balance Adjustment

A term that refers to the correctness of color reproduction under various lighting. If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional color/tint reproduction.

Set the Operation Switch to “ ” and set the POWER Switch to “ ” while pressing down the Lock Button located on the switch, then pull out the viewfinder fully or open the LCD monitor fully.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, then press it. The “W.BALANCE” Menu appears.

Rotate the MENU wheel to select “MANUAL”, and press it. The Menu Screen disappears and “W.BAL” and the currently selected mode are displayed. Rotate it to select the desired mode.

“ MAN.” – White balance is set manually. “ ”–Outdoors on a sunny day. “ ”– Outdoors on a cloudy day. “ ”–A video light or similar type of lighting

is used.

Press the MENU wheel. Selection is complete.

To Return To Automatic White Balance . . .

.... select “AUTO” in step 4. Or, set the Operation

Switch to “ ”.

NOTE:

White balance cannot be used when Sepia or Monotone ( pg. 33) is activated.

Manual White Balance Operation

Perform Manual White Balance when shooting under various types of lighting.

Follow steps 1 through 4 of the white balance adjustment, and select “ MAN.”.

Hold a sheet of plain white paper in front of the subject. Adjust zoom or position yourself so that the white paper fills the screen.

Press the MENU wheel until begins blinking. When the setting is completed, stops blinking.

Press the MENU wheel. Only the Manual White Balance indicator is displayed.

White paper

POWER Switch

MENU Wheel

To Change The Tint For Recording . . .

.... in step 2, substitute colored paper for white. The

white balance is adjusted based on the color, changing the tint. Red paper = deeper green; blue paper = orange; yellow paper = deeper purple.

NOTES:

●

In step 2, it may be difficult to focus on the white paper. In such a case, adjust focus manually ( pg. 21).

●

A subject can be shot under various types of lighting conditions indoors (natural, flourescent, candlelight, etc.). Because the color temperature is different depending on the light source, the subject tint will differ depending on the white balance settings. Use this function for a more natural result.

●

Once you adjust white balance manually, the setting is retained even if the power is turned off or the battery removed.

Operation Switch

Lock Button

36 EN

PLAYBACK

Basic Playback

Rewind Button (2)

Fast-Forward Button (

)

Play/Pause Button (

/6)

Stop Button (5)

Load a tape ( pg. 12).

Set the POWER Switch to “

PLAY/PC

” while pressing down the Lock Button located on the switch. To start playback, press 4/6.

•To stop playback, press 5.

•Press

to rewind, or

to fast-forward the tape

during Stop mode.

To Control The Speaker Volume . . .

.... slide the Power Zoom Lever (VOL.) towards “+” to

turn up the volume, or towards “–” to turn down the volume.

NOTES:

●

If Stop mode continues for 5 minutes when power is supplied from a battery, the camcorder shuts off automatically. To turn on again, set the POWER Switch to “OFF”, then to “

PLAY/PC

”.

●

The playback picture can be viewed in the LCD monitor, viewfinder or on a connected TV ( pg. 40).

●

You can also view the playback picture on the LCD monitor with it flipped over and pushed against the camera body.

●

LCD monitor/viewfinder indications:

•

When power is supplied from a battery: the “ ” battery pack remaining power indicator is displayed. When power is supplied through the DC cord: “ ” does not appear.

•

During Stop mode, none of the indications are displayed.

●

When a cable is connected to the AV OUT connector, the sound is not heard from the speaker.

Power Zoom Lever (VOL.)

Speaker

MENU Wheel

Still Playback:

Pauses during playback.

1) Press 4/6 during playback.

2) To resume normal playback, press 4/6 again.

●

If still playback continues for more than about 3 minutes, the camcorder’s Stop mode is automatically engaged. After 5 minutes in the Stop mode, the camcorder’s power is automatically turned off.

●

When

is pressed, the image may not pause immediately while the camcorder stabilizes the still

image.

Shuttle Search:

Allows high-speed search in either direction.

1) Press

for forward or

for reverse search during playback.

2) To resume normal playback, press 4/6.

●

During playback, press and hold

. The search continues as long as you hold the button.

Once you release it, normal playback resumes.

●

A slight mosaic effect appears on screen during Shuttle Search. This is not a malfunction.

Frame-By-Frame Playback:

Allows frame-by-frame search.

1) Engage Still Playback.

2) Rotate the MENU wheel towards “+” for forward Frame-By-Frame Playback, or towards “–” for reverse

Frame-By-Frame Playback during Still Playback.

 To resume normal playback, press 4/6.

●

You can also use the provided remote control for Frame-By-Frame Playback ( pg. 48).

Slow-Motion Playback, Playback Zoom and Playback Special Effects

Available only with the remote control (provided) ( pg. 48, 49).

POWER Switch

Lock Button

EN37

1 S R B

2 Y E L

B N C A

V T

C N

I U

T H M K

D R

E N

M O D S

O E

S S

O O

U U

N N

D D

L R

R N A

E T

I T S E

S U C

P R R T

L N E

A E

Y N

Using Menus For Detailed Adjustment

The following procedure applies to all except Synchro Comp ( pg. 54, 55).

Set the POWER Switch to “

PLAY/PC

” while pressing

down the Lock Button located on the switch.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select the desired function icon, and press it. The selected function menu appears.

Rotate the MENU wheel to select the desired function, and press it to display the Sub Menu.

Rotate the MENU wheel to select the desired parameter and press it. Selection is complete.

Rotate the MENU wheel to select “1RETURN” and press it twice to close the Menu Screen.

Display

POWER Switch

MENU Wheel

 pg. 38.

 pg. 55.

Allows you to set the recording mode (SP or LP) depending on your preference ( pg. 13). It is recommended you use “REC MODE” in the “VIDEO MENU” when using this camcorder as a recorder during digital dubbing ( pg. 45).

Helps find a blank portion of tape when you want to record from the middle of a tape ( pg. 39).

Makes the camcorder’s indications appear/ disappear from the connected TV screen.

Makes the date/time appear/disappear on the camcorder.

Makes the time code appear/disappear on the camcorder.

SOUND MODE

12BIT MODE

SYNCHRO

REC MODE

BLANK SRCH

ON SCREEN*

DATE/TIME*

TIME CODE*

Menu Screen

START/STOP Button

* Each setting is linked with “DISPLAY MENU”,

which appears when the Operation Switch is set to “ ” ( pg. 27). The parameters are the same as in the description on pg. 27.

NOTES:

●

It is also possible to change the ON SCREEN settings by pressing DISPLAY on the remote control (provided).

●

“REC MODE” can be set when the Operation Switch is set to “ ” ( pg. 13, 25).

●

If “ON SCREEN” is set to “SIMPLE”, it keeps the camcorder’s display (except the date, time and time code) from appearing on the connected TV. It also makes the playback sound mode and tape speed disappear on the camcorder.

VIDEO MENU

DISPLAY MENU

Lock Button

PLAYBACK

Advanced Features

CONTINUED ON NEXT PAGE

38 EN

BIT/SOUND

DEPCM255’:030

12:34:24

Playback Sound

During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. According to the menu access explanation on pg. 37, select “SOUND MODE” or “12BIT MODE” from the Menu Screen and set it to the desired parameter.

Minutes

Seconds

Frames*

*30 frames = 1 second

NOTES:

●

The “SOUND MODE” setting is available for both 12-bit and 16-bit sound. (In previous models’ functions, “12-bit” is called “32 kHz” and “16-bit” is called “48 kHz”.)

●

The camcorder cannot detect the sound mode in which the recording was made during fast-forward or rewind. During playback the sound mode is displayed in the upper left corner.

SOUND MODE

12BIT MODE

: Factory-preset

STEREO

SOUND L

SOUND R

SOUND 1

SOUND 2

MIX

Sound is output on both “L” and “R” channels in stereo.

Sound from the “L” channel is output in stereo.

Sound from the “R” channel is output in stereo.

Original sound is output on both “L” and “R” channels in stereo.

Dubbed sound is output on both “L” and “R” channels in stereo.

Original and dubbed sounds are combined and output in stereo on both “L” and “R” channels in stereo.

ON SCREEN setting: For playback sound, tape speed and tape running.

DATE/TIME setting: For date/time.

TIME CODE setting: For time code.

Display

PLAYBACK

Advanced Features (cont.)

EN39

S 1 S R

2 Y E

E U B N C

V T N

I U D

T H M

D R

E N M M O D

O O

O E

D D

E E

AXNECCEUL

BLANK SEARCH

POWER Switch

MENU Wheel

Blank Search

Helps you find where you should start recording in the middle of a tape to avoid time code interruption ( pg. 20).

Load a tape ( pg. 12) and set the POWER Switch to

“

PLAY/PC

” while pressing down the Lock Button

located on the switch.

Press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ”, then press it. “VIDEO MENU” appears.

Rotate the MENU wheel to select “BLANK SRCH”, then press it. The Sub Menu appears.

Rotate the MENU wheel to select “EXECUTE”, then press it.

•“BLANK SEARCH” appears blinking and the camcorder automatically starts reverse or forward shuttle search, then stops at the spot which is about 3 seconds of tape before the beginning of the detected blank portion.

To cancel Blank Search midway . . .

.... press 5.

NOTES:

●

In step 5, if the current position is at a blank portion the camcorder searches in the reverse direction, and if the current position is at a recorded portion the camcorder searches in the forward direction.

●

Blank Search does not work if “HEAD CLEANING REQUIRED. USE CLEANING CASSETTE” has appeared with the tape.

●

If the beginning or end of the tape is reached during Blank Search, the camcorder stops automatically.

●

A blank portion which is shorter than 5 seconds of tape cannot be detected.

●

The detected blank portion may be located between recorded scenes. Before you start recording, make sure there is no recorded scene after the blank portion.

Lock Button

Display

Menu Screen

Stop Button (5)

40 EN

PLAYBACK

Basic Connections

These are some basic types of connections. When making the connections, refer also to your VCR and TV instruction manuals.

A. Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input connectors

To S-VIDEO IN

Connector cover*

To S-VIDEO OUT

To TV or VCR

S-Video cable (optional)

VCR

A. Connection to a TV or VCR equipped with an S-VIDEO

Audio/Video cable [mini-plug to RCA plug] (provided)

To AV OUT

Red to AUDIO R IN

VCR

To TV or VCR

White to AUDIO L IN

* When connecting the cables, open this cover.

Yellow to VIDEO IN

Docking Station Attachment

First align the camcorder direction stud and screw on the Docking Station with the camcorder’s stud hole and tripod mounting socket and tighten the screw. When removing the camcorder, loosen the screw and detach the camcorder.

A.Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input

connectors

When connecting to a TV or VCR, use the provided Docking Station, an optional Audio/Video cable and S-Video cable.

B. Connection to a TV or VCR equipped only with A/V input connectors

Use the provided Audio/Video cable.

Audio/Video cable [RCA plug to RCA plug] (optional)

Red to AUDIO R OUT

White to AUDIO L OUT

Yellow to VIDEO OUT*

Red to AUDIO R IN

White to AUDIO L IN

Yellow to VIDEO IN*

* Connect when an S-Video cable is not used.

Tripod mouting socket

Stud hole

Stud

Screw

EN41

Make sure all units are turned off.

Connect the camcorder to a TV or VCR as shown in the illustration ( pg. 40).

If using a VCR . . . go to step 3. If not . . . go to step 4.

Connect the VCR output to the TV input, referring to your VCR’s instruction manual.

Turn on the camcorder, the VCR and the TV.

Set the VCR to its AUX input mode, and set the TV to its VIDEO mode.

To choose whether or not the following displays appear on the connected TV . . .

•Date/Time

.... set “DATE/TIME” to “AUTO”, “ON” or “OFF”

in the Menu Screen ( pg. 37).

•Time Code

.... set “TIME CODE” to “ON” or “OFF” in the

Menu Screen ( pg. 37).

•Playback Sound Mode, Tape Speed And Tape

Running Displays for playback

.... set “ON SCREEN” to “LCD” or “SIMPLE” in the

Menu Screen ( pg. 37). Or, press DISPLAY on the remote control.

NOTES:

●

It is recommended to use the AC Power Adapter/ Charger as the power supply instead of the battery pack ( pg. 9).

●

The S-Video cable and Audio/Video cable (RCA plug to RCA plug) are optional. Be sure to use the following:

•

S-Video cable: YTU94146A

•

Audio/Video cable (RCA plug to RCA plug):

YTU94147A Consult the JVC Service Center described on the sheet included in the package for details on their availability. Make sure to connect the ends with a core filter to the camcorder. The core filter reduces interference.

●

To monitor the picture and sound from the camcorder without inserting a tape, set the camcorder’s POWER Switch to “ ”, then set your TV to the appropriate input mode.

●

Make sure you adjust the TV sound volume to its minimum level to avoid a sudden burst of sound when the camcorder is turned on.

●

If you have a TV or speakers that are not specially shielded, do not place the speakers adjacent to the TV as interference will occur in the camcorder playback picture.

●

When a cable is connected to the AV OUT connector, the sound is not heard from the speaker.

42 EN

PLAYBACK

Advanced Connections

Connection To A Personal Computer

This camcorder can transfer still images to a PC by using the provided software when connected as shown in the illustration. It is also possible to transfer still images to a PC with a DV connector-equipped capture board installed.

Make sure the camcorder and PC are turned off.

Connect the camcorder or Docking Station to your PC using the appropriate cable as shown in the illustration.

•To attach the camcorder to Docking Station, refer to “Docking Station Attachment” on pg. 40.

Turn the camcorder’s POWER Switch to “

PLAY/PC

”

while pressing down the Lock Button located on the switch and turn on the PC.

NOTES:

●

It is recommended to use the AC Power Adapter/ Charger as the power supply instead of the battery pack ( pg. 9).

●

Never connect the PC connection cable and the DV cable simultaneously to the camcorder. Connect only the cable you wish to use to the camcorder.

●

The date/time information cannot be captured into the PC.

●

Refer to the instruction manuals of the provided Software.

●

Also refer to the manufacturer’s instruction manual for the DV connector-equipped capture board.

●

When using a DV cable, be sure it has a core filter attached. The core filter reduces interference.

To D V IN/OUT

To RS-232C

DV cable (optional)

To DV connector

PC connection cable (provided)

To PC

POWER Switch

PC with DV connector-equipped capture board

Core filter

Open the connector cover.

Lock Button

EN43

Video unit equipped with a DV input connector

Connection To A Video Unit Equipped With A DV Connector

Connection to the GV-DT3 Digital Printer (optional) allows you to print out images or transfer them to a PC. It is also possible to copy recorded scenes from the camcorder onto another video unit equipped with a DV connector. This function is called Digital Dubbing ( pg. 45), which offers virtually no image or sound deterioration.

Make sure all units are turned off.

Make connections to the device you want to connect to using a DV cable, as shown in the illustration.

If necessary, connect the PC connection cable (provided) to the printer’s PC connector and the PC’s RS-232C connector.

Turn the camcorder’s POWER Switch to “

PLAY/PC

”

while pressing down the Lock Button located on the switch and turn on the other units.

NOTES:

●

It is recommended to use the AC Power Adapter/ Charger as the power supply instead of the battery pack ( pg. 9).

●

For Digital Dubbing, this camcorder can be connected only to one device at a time. This camcorder can also be used as a recorder ( pg. 45).

●

If Still Playback, Slow-Motion Playback, Fast-Forward or Rewind is attempted with the camcorder connected to a video unit via the DV connector, the image will take on an effect similar to a colored mosaic pattern or it will become black.

●

Also refer to the instruction manuals of the connected units.

●

When using a DV cable, be sure it has a core filter attached. The core filter reduces interference.

To DV IN/OUT

To D V connector

Digital Printer

To DV IN connector

DV cable (optional)

To P C connector

PC connection cable (provided)

To RS-232C

POWER Switch

Core filter

Lock Button

Open the connector cover.

44 EN

DUBBING

Dubbing To A VCR

Following the illustration, connect the camcorder and the VCR. Also refer to pg. 40 and 41.

Set the camcorder’s POWER Switch to “

PLAY/PC

”

while pressing down the Lock Button located on the switch, turn on the VCR’s power, and insert the appropriate cassettes in the camcorder and the VCR.

Engage the VCR’s AUX and Record-Pause modes.

Engage the camcorder’s Play mode to find a spot just before the edit-in point. Once it is reached, press

/6 on the camcorder.

Press 4/6 on the camcorder and engage the VCR’s Record mode.

Engage the VCR’s Record-Pause mode and press

/6 on the camcorder.

Repeat steps 4 through 6 for additional editing, then stop the VCR and camcorder when finished.

NOTES:

●

The S-Video cable and Audio/Video cable (RCA plug to RCA plug) are optional. Be sure to use the following:

•

S-Video cable: YTU94146A

•

Audio/Video cable (RCA plug to RCA plug):

●

You can use the AV OUT connector on the camcorder for connection.

●

You can use Playback Zoom ( pg. 48) or Playback Special Effects ( pg. 49) in step 5.

●

Before you start dubbing, make sure that the indications do not appear on the connected TV. If they do, they are being recorded onto the new tape.

To choose whether or not the following displays appear on the connected TV . . .

•Date/Time

.... set “DATE/TIME” to “AUTO”, “ON” or “OFF” in the

Menu Screen ( pg. 37).

•Time Code

.... set “TIME CODE” to “ON” or “OFF” in the Menu

Screen ( pg. 37).

•Playback Sound Mode, Tape Speed And Tape Running

Displays

.... set “ON SCREEN” to “LCD” or “SIMPLE” in the Menu

Screen ( pg. 37). Or, press DISPLAY on the remote control.

VCR

White to AUDIO L IN

Red to AUDIO R IN

To S-VIDEO IN

* Connect when an S-Video cable is not used.

Yellow to VIDEO IN*

POWER Switch

To S-VIDEO OUT

S-Video cable (optional)

Red to AUDIO R OUT

Yellow to VIDEO OUT*

White to AUDIO L OUT

Audio/Video cable [RCA plug to RCA plug] (optional)

Lock Button

Core filter

EN45

PLAY (4) STOP (5)

Dubbing To Or From A Video Unit Equipped With A DV Connector (Digital Dubbing)

It is also possible to copy recorded scenes from the camcorder onto another video unit equipped with a DV connector. Since a digital signal is sent, there is little if any image or sound deterioration.

[To use this camcorder as a player]

Make sure the camcorder’s power is off.

Connect the camcorder to your video unit equipped with a DV connector using a DV cable as shown in the illustration.

Press 4 to play back the source tape.

While watching the playback on the monitor, engage the DV connector-equipped video unit’s record mode from the spot on the source tape you want to begin recording.

NOTES:

●

It is recommended to use the AC Power Adapter/ Charger as the power supply instead of the battery pack ( pg. 9).

●

If the remote control is used when both the player and recorder are JVC video units, both units will perform the same operation. To prevent this from happening, press the buttons on both units.

●

For Digital Dubbing, this camcorder can be connected only to one device at a time. This camcorder can also be used as a recorder.

●

If a blank portion or disturbed image is played back on the player during dubbing, the dubbing may stop so that an unusual image is not dubbed.

●

Even though the DV cable is connected correctly, sometimes the image may not appear in step 3. If this occurs, turn off the power and make connections again.

●

If “Playback Zoom” ( pg. 48), “Playback Special Effects” ( pg. 49) or “Snapshot” is attempted during playback, only the original playback image recorded on the tape is output from the DV IN/OUT connector.

●

When using a DV cable, be sure it has a core filter attached. The core filter reduces interference.

DV cable (optional)

To Use This Camcorder As A Recorder . . .

1. Turn the POWER Switch to “

PLAY/PC

” while pressing down the Lock Button located on the switch.

2. Set “REC MODE” to “SP” or “LP” in the Menu Screen ( pg. 37)

3. Connect the DV cable as shown in the illustration and load a cassette to record on.

4. Press START/STOP to engage the Record-Pause mode. “DV IN” appears on the screen.

5. Press START/STOP to start recording. “DV IN” changes to “

DV IN

”.

6. Press START/STOP again to engage the Record-Pause mode. “

DV IN

” returns to “DV IN”.

NOTES:

●

Digital Dubbing is performed in the sound mode recorded on the original tape, regardless of the current “SOUND MODE” setting ( pg. 25).

●

During Digital Dubbing, no signals are output from the AV OUT connector.

Video unit equipped with DV connector

To DV IN/OUT

POWER Switch

Core filter

Lock Button

Open the connector cover.

46 EN

30°

5m(16 ft)

–

The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. It also makes additional playback functions possible.

Installing The Batteries

The remote control uses two “AAA (R03)” size batteries. See “General Battery Precautions” ( pg. 69).

Remove the battery compartment cover while pushing up the tab as illustrated.

Insert two “AAA (R03)” size batteries in the correct direction.

Re-attach the battery compartment cover.

USING THE REMOTE CONTROL UNIT

When using the remote control, be sure to point it at the remote sensor. The illustration shows the approximate transmitted beam effective area for indoor use. The transmitted beam may not be effective or may cause incorrect operation outdoors or when the remote sensor is directly exposed to sunlight or powerful lighting.

Transmitted beam effective area

Remote sensor

Tab

EN47

)

@ $

# %

(

6 8

7 9

Buttons

1 Infrared beam transmitting window

2 Zoom (T/W) Buttons 3 DISPLAY Button

4 SHIFT Button 5 SLOW Rewind/Forward Buttons

Left/Right Buttons

6 REW Button

7 FADE/WIPE Button 8 EFFECT ON/OFF Button

9 EFFECT Button 0 PAUSE IN Connector

! START/STOP Button @ MBR SET Button

# SNAPSHOT Button $ Up Button

INSERT Button*

% Down Button

A. DUB Button

^ PLAY Button & FF Button

* STOP Button

( PAUSE Button ) R.A.EDIT Buttons

Functions

With the camcorder’s POWER Switch set to the camera position (“ ”) .

Transmits the beam signal.

Zoom in/out ( pg. 19)

—

— —

—

Functions the same as START/STOP on the camcorder.

—

Functions the same as SNAPSHOT on the camcorder.

— —

—

With the camcorder’s POWER Switch set to “

PLAY/PC

”.

Zoom in/out (

 pg. 48)

 pg. 51

 pg. 48, 50

 pg. 48  pg. 48

Rewind, Reverse Shuttle Search ( pg. 36)

 pg. 52

 pg. 49

 pg. 51

 pg. 50

 pg. 48

—

 pg. 48  pg. 56

Starts Playback (

 pg. 36)

Forward, Forward Shuttle Search ( pg. 36)

Stop (

 pg. 36)

Pause (

 pg. 48)

 pg. 50 – 55

* This function is unavailable with this camcorder.

48 EN

USING THE REMOTE CONTROL UNIT

(cont.)

Press T

Normal

playback

Left or SLOW

Rewind Button

To move image, press

(Right) while keeping SHIFT held down.

PAUSE

PLAY

Zoom Buttons

SHIFT

Remote sensor

Right or SLOW

Forward Button

Up Button

Down Button

STOP

FEATURE:

Slow-Motion Playback

PURPOSE:

To allow slow-speed search in either direction during playback.

OPERATION:

1) To change from normal to Slow-Motion Playback, press SLOW (9 or 0) more than approx. 2 seconds. After

approx. 1 minute in Slow Rewind or approx. 2 minutes in Slow Forward, normal playback resumes.

 To stop Slow-Motion Playback, press PLAY (

NOTES:

●

You can also engage Slow-Motion Playback from Still Playback by pressing SLOW more than approx. 2 seconds.

●

During Slow-Motion Playback, due to digital image processing, the picture may take on a mosaic effect.

●

After SLOW

(9 or 0)

is pressed and held, the still image may be displayed for a few seconds, followed by a blue screen for a few seconds. This is not a malfunction.

●

There may be a small margin between the slow-motion playback start point you chose and the actual start point for Slow-Motion Playback.

●

During Slow-Motion Playback, there will be disturbances in video and the picture may seem unstable, especially with steady images. This is not a malfunction.

●

During Slow-Motion Playback, press PAUSE

(6)

pause playback.

FEATURE:

Frame-By-Frame Playback

PURPOSE:

To allow frame-by-frame search during playback.

OPERATION:

1) To change from normal to Frame-By-Frame Playback,

press SLOW (0) repeatedly for forward or SLOW (9) repeatedly for reverse. Each time it is pressed, the frame is played back.

NOTE:

You can also engage Frame-By-Frame Playback from Still Playback by pressing SLOW

(

)

repeatedly.

FEATURE:

Playback Zoom

PURPOSE:

To magnify the recorded image up to 10X at any time during playback.

OPERATION:

1) Press PLAY (4) to find the scene of interest.

2) Press the Zoom Buttons (T/W) on the remote control. Make sure the remote control is pointed at the camcorder's remote sensor. Pressing T zooms in.

3) You can move the image on screen around to find a particular portion of the picture. While holding down SHIFT, press (Left), (Right), (Up) and (Down).

 To end zoom, press and hold W until magnification returns to normal. Or, press STOP (5) and then press

PLAY (4).

NOTES:

●

Zoom can also be used during slow-motion and still playback.

●

Due to digital image processing, the quality of the image may suffer.

EN49

P4LOA

F 1 2 3 4 5

YFBACK

C M S S V

E T

A N P R D

S T A B

O E

C N

CFHIO

PLAY

EFFECT

EFFECT ON/OFF

PLAYBACK EFFECT Select Menu

Remote sensor

FEATURE:

Playback Special Effects

PURPOSE:

To allow you to add creative effects to the playback image.

OPERATION:

1) To start playback, press PLAY (4).

2) Point the remote control at the camcorder's remote

sensor and press EFFECT. The PLAYBACK EFFECT Select Menu appears.

3) Move the highlight bar to the desired effect by pressing EFFECT. The selected function is activated and after 2 seconds the menu disappears.

 To deactivate the selected effect, press EFFECT ON/

OFF on the remote control. Pressing it again re-

activates the selected effect.

 To change the selected effect, repeat from step 2

above.

NOTE:

The effects that can be used during playback are Classic Film, Monotone, Sepia, Strobe and Video Echo. The effects work the same in playback as they did in recording. Refer to page 33 for more information.

50 EN

VCR CODE LIST

VCR BRAND NAME

1

2

`

MAGNAVOX

5

1

MITSUBISHI

7

NEC

7

PHILIPS

9

5

1

4

1

6

JVC

1

6

HITACHI

6

A B C

BUTTONS

(A) (B)

VCR BRAND NAME

PHILIPS

3

SANYO

6

SHARP

5

SONY

5

`

9

1



TOSHIBA

9

ZENITH

RCA

2

4

6

3

PANASONIC

3

7

1

4

8



BUTTONS

(A) (B)

MBR SET

SHIFT

1 6

789`

2 5

Random Assemble Editing [R.A.Edit]

Create edited videos easily using your camcorder as the source player. You can select up to 8 “cuts” for automatic editing, in any order you like. R.A.Edit is more easily performed when the MBR (Multi-Brand Remote) is set to operate with your brand of VCR (see VCR CODE LIST), but can also be performed by operating the VCR manually. Before operation, make sure the batteries are installed in the remote control ( pg. 46).

SET REMOTE/VCR CODE

Turn off the power to the VCR and point the remote towards the VCR’s infrared sensor. Then, referring to the VCR CODE LIST, press and hold MBR SET, and press button (A) and then (B). The code is automatically set once you release

MBR SET, and the VCR’s power comes on.

Make sure the VCR’s power is on. Then, while holding SHIFT, press the button on the remote for the desired function. The functions the remote can control are PLAY, STOP, PAUSE, FF, REW and VCR REC STBY (you do not need to press SHIFT for this one).

You are now ready to try Random Assemble Editing.

IMPORTANT

Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions.

NOTES:

●

If the VCR’s power does not come on in step 1, try another code from the VCR CODE LIST.

●

Some brands of VCR do not come on automatically. In this case, turn the power on manually and try step 2.

●

If the remote control is not able to control the VCR, use the controls on the VCR.

●

When the remote control’s batteries run out, the VCR brand you have set will be erased. In that case, replace the old battery with a new one to reset the VCR brand.

USING THE REMOTE CONTROL UNIT

(cont.)

VCR (Recording deck)

EN51

DISPLAY

MAKE CONNECTIONS

Also refer to pg. 40 and 41.

A JVC VCR equipped with a remote pause connector . . .

... connect the editing cable to the Remote

PAUSE connector.

A JVC VCR not equipped with a remote pause connector but equipped with an R.A. EDIT connector . . .

... connect the editing cable to the R.A.EDIT

connector.

A VCR other than above . . .

... connect the editing cable to the remote

control’s PAUSE IN connector.

Insert a recorded tape into the camcorder and set the POWER Switch to “

PLAY/PC

” while pressing down

the Lock Button located on the switch.

Turn the VCR power on, insert a recordable tape and engage the AUX mode (refer to the VCR’s instructions).

NOTES:

●

Before Random Assemble Editing, make sure the indications do not appear on the TV monitor. If they do, they will be recorded onto the new tape.

To choose whether or not the following displays appear on the connected TV . . .

•Date/Time

.... set “DATE/TIME” to “AUTO”, “ON” or “OFF” in the

Menu Screen ( pg. 37).

•Time Code

.... set “TIME CODE” to “ON” or “OFF” in the Menu

Screen ( pg. 37).

•Playback Sound Mode, Tape Speed And Tape Running

Displays

.... set “ON SCREEN” to “LCD” or “SIMPLE” in the

Menu Screen ( pg. 37). Or, press DISPLAY on the remote control.

●

The S-Video cable and Audio/Video cable (RCA plug to RCA plug) are optional. Be sure to use the following:

•

S-Video cable: YTU94146A

•

Audio/Video cable (RCA plug to RCA plug):

●

When editing on a VCR equipped with a DV input connector, an optional DV cable can be connected instead of an S-Video cable and audio/video cable.

●

You can use the AV OUT connector on the camcorder for connection.

CONTINUED ON NEXT PAGE

To Remote PAUSE or R.A.EDIT

VCR

White to AUDIO L IN

Red to AUDIO R IN

To S-VIDEO IN

To PAUSE IN

Editing cable (provided)

S-Video cable (optional)

Audio/Video cable [RCA plug to RCA plug] (optional)

Yellow to VIDEO IN*

* Connect when an S-Video cable is not used.

To JLIP (EDIT)

To S-VIDEO

Core filter

ATTENTION FOR EDITING CABLE

• Be careful not to mistake it for the JLIP cable ( pg. 6).

• Make sure you connect the end with the core filter to the camcorder.

Red to AUDIO R OUT

Yellow to VIDEO OUT*

White to AUDIO L OUT

52 EN

2 3 4 5 6 7 8

––

TTIOM

–

E A

–

C–O–D

~ ~ ~ ~ ~ ~ ~ ~

EO–

–

: :

–0–

ODE

PLAY

CANCEL

R.A.EDIT ON/OFF

FADE/WIPE

EFFECT

EDIT IN/OUT

SELECT SCENES

Point the remote control at the camcorder’s remote sensor. Press PLAY (4) and then press R.A.EDIT ON/ OFF on the remote control. The Random Assemble Editing Menu appears.

If using a Fade/Wipe at the beginning of the scene, press FADE/WIPE on the remote control.

•Cycle through the effects by pressing repeatedly, and stop when the one you want is displayed.

•You cannot use a Picture Wipe/Dissolve at the beginning of Program 1.

At the beginning of the scene, press EDIT IN/OUT on the remote control. The Edit-In position appears in the Random Assemble Editing Menu.

At the end of the scene, press EDIT IN/OUT. The Edit-Out position appears in the Random Assemble Editing Menu.

If using a Fade/Wipe at the end of the scene, press FADE/WIPE.

•Cycle through the effects by pressing repeatedly, and stop when the one you want is displayed.

•If you select a Fade/Wipe effect for an Edit-Out point, the effect is automatically applied to the following Edit-In point.

•You cannot use a Picture Wipe/Dissolve at the end of the last scene.

•When you use Fade/Wipe effects, that time is included in the total time (this does not apply to Picture Wipe/Dissolve).

If using Playback Special Effects, press EFFECT ( pg. 49).

Repeat steps 6 through 9 to register additional scenes.

•To change previously registered points, press

CANCEL on the remote control. The registered points disappear, one at a time, from the most recently registered point.

•If you are not using Fade/Wipe or Program AE with special effects, repeat steps 6 and 7 only.

USING THE REMOTE CONTROL UNIT

(cont.)

NOTES:

●

When choosing a scene, set Edit-In and Edit-Out points so that there is a relatively large difference between them.

●

If the search time for an in-point exceeds 5 minutes, the recording deck’s Record-Standby mode will be canceled and editing will not take place.

●

If there are blank portions before or after the Edit-In and Edit-Out points, a blue screen may be included in the edited version.

●

Since time codes register time only as accurately as seconds, the time code total time may not match the total program time exactly.

●

Turning off the camcorder’s power erases all registered Edit-In and Edit-Out points.

●

If you select Sepia or Monotone mode from Program AE with special effects, you cannot use the Dissolve or Black & White Fader. In this case the Dissolve or Black & White indicator begins blinking. Once the next Edit-In point is registered, the effect is turned off. To combine these effects, use Sepia or Monotone during recording, then use the Dissolve or Black & White Fader during Random Assemble Editing.

●

It is not possible to use Fade/Wipe effects and Program AE with special effects during Random Assemble Editing using a DV cable.

Random Assemble Editing Menu

Program

Remote sensor

EN53

1 2 3 4 5

7 8

–––

–

TTIOM

0 0 0 0 1

–

I 0 7 3 9 5

–

: : : : : :

2 1 3 3 5

–

5 8 3 0 5

–

~ ~ ~ ~ ~ ~ ~ ~

O 0 0 0 1 1

U 2 8 5 3 6

6 9

: : : : :

: :

0 3 5 1 2

3 3

5 1 3 5 0

0 9

–

– –

–

– –

–

PAUSE

VCR REC STBY

REW

STOP

CANCEL

R.A.EDIT ON/OFF

FADE/WIPE

EFFECT

EDIT IN/OUT

AUTOMATIC EDITING TO VCR

Rewind the tape in the camcorder to the beginning of the scene you want to edit and press PAUSE (6).

Point the remote control towards the VCR’s remote sensor and press VCR REC STBY (q6), or manually engage the VCR’s Record-Pause mode.

Press START/STOP on the camcorder. Editing proceeds as programed, right through to the end of the last registered scene.

•Pressing START/STOP on the remote control does

not start editing.

•When dubbing is complete, the camcorder enters the Pause mode, and the VCR enters its RecordPause mode.

•If you do not register an Edit-Out point, the tape will be dubbed all the way to the end automatically.

•If you operate the camcorder during automatic editing, the VCR will enter its Record-Pause mode and automatic editing will stop.

Engage the Stop modes for the camcorder and the VCR. To make the R.A.Edit counter display disappear, press R.A.EDIT ON/OFF on the remote control.

NOTES:

●

Pressing R.A.EDIT ON/OFF on the remote control clears all settings registered during Random Assemble Editing.

●

When the editing cable is connected to the remote control’s Pause In connector during dubbing, make sure the remote control is pointed at the VCR’s sensor, and the path between the two is unobstructed.

●

Random Assemble Editing may not function properly when using a tape including several duplicated time codes ( pg. 20).

START/STOP Button

Random Assemble Editing Menu

Remote Sensor

54 EN

2 3 4 5 6 7 8

––

TTIOM

–

E A

–

C–O–D

~ ~ ~ ~ ~ ~ ~ ~

EO–

–

: :

–0–

ODE

R.A.EDIT ON/OFF

USING THE REMOTE CONTROL UNIT

(cont.)

For More Accurate Editing

Some VCRs make the transition from Record-Pause to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you have recorded scenes you did not want. For a cleanly edited tape, confirm and adjust the timing of the camcorder against your VCR.

DIAGNOSING VCR/CAMCORDER TIMING

Play back the tape in the camcorder, then point the remote control at the camcorder’s remote sensor and press R.A.EDIT ON/OFF. The Random Assemble Editing Menu appears.

Perform Random Assemble Editing on Program 1 only. In order to check VCR and camcorder timing, select the beginning of a scene transition as your EditIn point.

Play back the dubbed scene.

•If any images from the scene prior to the transition you chose for your Edit-In point were recorded, that means your VCR moves too quickly from Record-Pause to Record mode.

•If the scene you tried to dub starts in progress, the VCR is slow to start recording.

Random Assemble Editing Menu

Program 1

VCR

(Recording deck)

Remote sensor

EN55

R B

R O

E U B

C A

V T N

I U D T

D R

N M M

D S

O O

O E

D D

M E

1.0

ADJUSTMENT OF VCR/CAMCORDER TIMING

Point the remote control at the camcorder’s remote sensor and press R.A.EDIT ON/OFF to make the Random Assemble Editing menu disappear, then press the MENU wheel. The Menu Screen appears.

Rotate the MENU wheel to select “ ” and press it. “VIDEO MENU” appears. Then, rotate it to “SYNCHRO” and press it. The value for “SYNCHRO”

is highlighted.

Based on the diagnostics performed ( pg. 54), you can now advance the VCR’s record timing by rotating the MENU wheel towards “+”. You can also delay the VCR’s record timing by rotating the MENU wheel towards “–”. The adjustment range is from –1.3 to +1.3 seconds, in 0.1-second increments. Press the MENU wheel to finish the setting.

Rotate the MENU wheel to select “1RETURN” and press it twice. Now perform Random Assemble Editing beginning with step 4 on page 52.

NOTES:

●

Before performing actual Random Assemble Editing, do a few Random Assemble Editing trial runs to check whether the value you have input is appropriate or not, and make adjustments accordingly.

●

Depending on the recorder, there may be situations where the timing difference cannot be fully corrected.

Display

MENU Dial

VCR

(Recording deck)

56 EN

PAUSE

PLAY

DISPLAY

A.DUB

STOP

USING THE REMOTE CONTROL UNIT

(cont.)

Audio Dubbing

The audio track can be customized only when recorded in the 12-bit mode (墌 pg. 25).

NOTES:

●

Audio Dubbing is not possible on a tape recorded in 16bit audio, on a tape recorded in the LP mode or on a blank portion of a tape.

●

To perform Audio Dubbing while watching on the television, make connections (墌 pg. 40).

Play back the tape to locate the point where editing will start, then press PAUSE (6).

While holding A.DUB (e) on the remote control, press PAUSE (6). “6e” appears.

Press PLAY (4) , then begin “narrating”. Speak into the microphone.

•To pause dubbing, press PAUSE (6).

To end Audio Dubbing, press PAUSE (6), then STOP (5).

To hear the dubbed sound during playback . . .

.... set “12BIT MODE” to “SOUND 2” or “MIX” in the

Menu Screen (墌 pg. 37, 38).

NOTES:

●

Audio dubbing is also possible using an optional microphone connected to the MIC connector on the Docking Station. The provided Audio cable reduces interference.

●

Sound is not heard from the speaker during Audio Dubbing. To hear sound, connect optional headphones to the AV OUT connector.

●

When using an optional microphone or headphones, be sure to connect it to the provided Audio cable with a core filter attached to reduce interference (墌 pg. 7).

●

While an optional microphone is connected, the built-in microphone is disabled.

●

When editing onto a tape that was recorded at 12-bit, the old and new soundtracks are recorded separately.

●

If you dub onto a blank space on the tape, the sound may be disrupted. Make sure you only edit recorded areas.

●

If feedback or howling occurs during TV playback, move the camcorder’s microphone away from the TV, or turn down the TV’s volume.

●

If you change from 12-bit to 16-bit in mid-recording and then use the tape for Audio Dubbing, it is not effective from the point where 16-bit recording began.

●

During Audio Dubbing, when the tape moves to scenes recorded in the LP mode, scenes recorded in 16-bit audio or a blank portion, Audio Dubbing stops (墌 pg. 68).

Speaker

Audio Dub Standby mode

POWER Switch

Display

AV OUT (headphone) connector

Stereo microphone

Remote sensor

External microphone input connector

Located beneath the cover.

Lock Button

EN57

USER MAINTENANCE

OPEN/EJECT SwitchPUSH HERE

Cassette holder

Cleaning The Camcorder

To clean the exterior, wipe gently with a soft cloth. Put the cloth in diluted mild soap and wring it well to wipe off heavy dirt. Then wipe again with a dry cloth.

Open the LCD monitor. Wipe gently with a soft cloth. Be careful not to damage the monitor. Close the LCD monitor.

To clean the lens, blow it with a blower brush, then wipe gently with lens cleaning paper.

Pull out the viewfinder fully.

Open the viewfinder cleaning hatch in the direction of the arrow 1. Insert a lens blower or soft cloth into the gap at the side of the viewfinder and clean the interior of the viewfinder with it 2.

Close the hatch until it locks in place and push the viewfinder back in.

NOTES:

●

Avoid using strong cleaning agents such as benzine or alcohol.

●

Cleaning should be done only after the battery pack has been removed or other power units have been disconnected.

●

Mold may form if the lens is left dirty.

●

When using a cleaner or chemically treated cloth refer to the cautions of each product.

After Use

Turn off the camcorder.

Slide down and hold OPEN/EJECT in the direction of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically. Remove the cassette.

Press “PUSH HERE” to close the cassette holder.

•Once the cassette holder is closed, it recedes

automatically. Wait until it recedes completely before closing the cassette holder cover.

Slide down BATT. RELEASE 1 and remove the battery pack 2 3.

BATT. RELEASE Switch

Remove.

Hatch Lens blower

58 EN

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

TROUBLESHOOTING

No power is supplied.

“SET DATE/TIME!” appears.

Recording cannot be performed.

There is no picture.

Some functions are not available using the MENU wheel.

The focus does not adjust automatically.

The cassette will not load properly.

In the 5-Second mode, recording ends before 5 seconds have elapsed.

Snapshot mode cannot be used.

• The power is not connected properly.

• The battery is dead.

• The LCD monitor is not open

fully or the viewfinder is not pulled out when recording.

• The built-in clock’s rechargeable lithium battery is discharged.

• The previously set date/time is erased.

• The tape’s erase protection tab is set to “SAVE”.

• The POWER Switch is set to “

PLAY/PC

” or “OFF”.

•“TAPE END” appears.

• The cassette holder cover is

open.

• The camcorder is not getting power, or some other malfunction exists.

• The Operation Switch is set to “ ”.

• Focus is set to the Manual mode.

• The recording was done in a dark place, or the contrast was low.

• The lens is dirty or covered with condensation.

• The cassette is in the wrong position.

• The battery’s charge is low.

• The 5-Second mode is set to “ANIM.” in the Menu Screen.

• The Squeeze mode is selected.

• Connect the AC Power Adapter/Charger securely (墌 pg. 9).

• Replace the dead battery with a fully charged one (墌 pg. 8, 9).

• Open the LCD monitor fully or pull out the viewfinder.

• Connect the camcorder to an AC outlet using the AC Power Adapter/Charger for over 24 hours to charge the clock’s lithium battery (墌 pg. 11).

• Set the tape’s erase protection tab to “REC” (墌 pg. 12).

• Set the POWER Switch to “ ” (墌 pg. 14).

• Replace with new cassette

(墌 pg. 12).

• Close the cassette holder cover.

• Turn the camcorder’s power off and on again (墌 pg. 16).

• Set the Operation Switch to “ ” (墌 pg. 14).

• Set Focus to the Auto mode (墌 pg. 21).

• Clean the lens and check the focus again (墌 pg. 57).

• Set it in the right position (墌 pg. 12).

• Install a fully charged battery (墌 pg. 8, 9).

• Select “5S” in the Menu Screen (墌 pg. 29).

• Disengage the Squeeze mode (墌 pg. 26).

If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer.

The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Power Adapter/Battery Charger, etc.) and wait a few minutes; and then re-connect it and proceed as usual from the beginning.

EN59

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

10.

The color of Snapshot looks strange.

11.

The image taken using Snapshot is too dark.

12.

Digital Zoom does not work.

13.

Program AE with special effects and Fade/Wipe Effects do not work.

14.

The Black & White Fader does not work.

15.

The Dissolve function does not work.

16.

The Picture Wipe and Dissolve functions do not work.

10.

• The light source or the subject does not include white. Or there are various different light sources behind the subject.

• The Sepia or Monotone mode is activated.

11.

• Shooting was performed under backlit conditions.

12.

• 10X optical zoom is selected.

•“P.AE/EFFECT” is set to “VIDEO ECHO” in the Menu

Screen.

•“WIDE MODE” is set to “PS- WIDE” in the Menu Screen.

• Picture Wipe or Dissolve are being used in a scene transition.

13.

• The Operation Switch is set to “ ”.

14.

• The Sepia or Monotone mode is activated.

• The Sepia, Monotone or Slow Shutter mode of Program AE with special effects is activated.

•“WIDE MODE” is set to “SQUEEZE” or “PS-WIDE” in

the Menu Screen.

• The previously selected mode of Program AE with special effects was changed after the last selected scene for editing was registered.

16.

• The last selected editing scene is ending.

• At the end of the last selected scene for editing, the POWER Switch was set to “OFF”.

• The power is off.

10.

• Find a white subject and compose your shot so that it also appears in the frame (墌 pg. 18).

• Turn off Sepia and Monotone (墌 pg. 32).

11.

• Press the BACKLIGHT Button (墌 pg. 34).

12.

• Set “ZOOM” to “40X” or “200X” in the Menu Screen

(墌 pg. 25).

• Disengage the “VIDEO ECHO” mode (墌 pg. 19, 33).

• Disengage the “PS-WIDE” mode (墌 pg. 26).

• Wait until the Picture Wipe or Dissolve effects are completed (墌 pg. 19, 30).

13.

• Set the Operation Switch to “ ” (墌 pg. 30, 32).

14.

• Turn off Sepia and Monotone (墌 pg. 30, 32).

15.

• Turn off Sepia, Monotone or Slow Shutter before adding Dissolve to a scene transition (墌 pg. 30, 32).

• Set “WIDE MODE” to “CINEMA” or “OFF” mode

(墌 pg. 26).

• Make sure you have selected the mode of Program AE with special effects you want before starting editing (墌 pg. 30, 32).

• Select Picture Wipe or Dissolve before beginning recording. The effects are then automatically activated (墌 pg. 30).

• Do not turn off the camcorder’s power after setting Edit-In and Edit-Out points, as they will all be erased (墌 pg. 30).

• The camcorder automatically shuts off after 5 minutes have elapsed in the RecordStandby mode. Make sure you continue operations within 5 minutes after engaging Record-Standby mode (墌 pg. 30).

CONTINUED ON NEXT PAGE

60 EN

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

17.

The picture wipe function does not work.

18.

Scene transition does not go as expected.

19.

The Video Echo mode does not work.

20.

Even when Slow Shutter is not selected, the image looks like it is activated.

21.

There is no strobe when the Classic Film or Strobe mode is activated.

22.

White Balance cannot be activated.

23.

When shooting a subject illuminated by bright light, vertical lines appear.

24.

When the screen is under direct sunlight during shooting, the screen becomes red or black for an instant.

25.

During recording, the date/ time does not appear.

26.

The indicators and messages do not appear.

17.

• The Slow Shutter mode is activated.

•“WIDE MODE” is not set to “OFF”.

18.

• When using “Picture Wipe/ Dissolve” (墌 pg. 30), there is a delay of a fraction of a second between the previous record stop-point and the Dissolve start-point. This is normal, but this slight delay becomes especially noticeable when shooting fastmoving subject or during rapid panning.

19.

• The Picture Wipe or Dissolve functions are in use.

•“WIDE MODE” is set to “SQUEEZE” or “PS-WIDE” in

the Menu Screen.

• A Fade-In or Fade-Out is in progress.

20.

• When shooting in the dark, the unit becomes highly sensitive to light and the image takes on an effect similar to Slow Shutter.

21.

• The Picture Wipe or Dissolve function is in use.

22.

• The Sepia or Monotone mode is activated.

23.

• This is a result of exceedingly high contrast, and is not a malfunction.

24.

• This is not a malfunction.

25.

•“DATE/TIME” is set to “OFF” in the Menu Screen.

• Self-Recording is performed.

26.

•“ON SCREEN” is set to “SIMPLE” or “TIME CODE” is

set to “OFF” in the Menu Screen.

17.

• Disengage the Slow Shutter mode or set “WIDE MODE” to “OFF” before preparing to use the Picture Wipe (墌 pg. 26, 30, 32).

18.

————

19.

• Set “WIDE MODE” to “CINEMA” or “OFF” mode

(墌 pg. 26).

• Do not try to use the Video Echo mode during a Fade-In or Fade-Out (墌 pg. 30, 32).

20.

• If you want the lighting to look more natural, set GAIN UP to “AGC” or “OFF” in the Menu Screen (墌 pg. 25).

21.

• Do not try to use the Classic Film or Strobe mode during a scene transition (墌 pg. 30,

32).

22.

• Turn off Sepia or Monotone before setting White Balance (墌 pg. 32, 35).

23.

————

24.

————

25.

• Set “DATE/TIME” to “ON” in the Menu Screen (墌 pg. 27).

• During Self-Recording, the date/time does not appear (墌 pg. 17).

26.

• Set “ON SCREEN” to “LCD” or “LCD/TV” and set “TIME CODE” to “ON” in the Menu Screen (墌 pg. 27, 37).

TROUBLESHOOTING

(cont.)

EN61

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

27.

Images on the LCD monitor appear dark or whitish.

28.

The rear of the LCD monitor is hot.

29.

The indicators and the image color on the LCD monitor are not clear.

30.

The LCD monitor or viewfinder indications blink.

31.

Colored bright spots appear all over the LCD monitor or the viewfinder.

32.

During recording, sound cannot be heard.

33.

Play, Rewind and Fast-

Forward functions do not work.

34.

The tape is moving, but there is no picture.

27.

• In places subject to low temperature, images become dark due to the characteristics of the LCD monitor. When this happens, the displayed colors differ from those that are actually recorded. This is not a defect of the camcorder.

• When the LCD monitor's fluorescent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer.

28.

• The light used to illuminate the LCD monitor causes it to become hot.

29.

• This may occur when the surface or the edge of the LCD monitor is pressed.

30.

• Certain Fade/Wipe effects, certain modes of Program AE with special effects, “DIS” and other functions that cannot be used together are selected at the same time.

31.

• The LCD monitor and the viewfinder are made with high-precision technology. However, black spots or bright spots of light (red, green or blue) may appear constantly on the LCD monitor or the viewfinder. These spots are not recorded on the tape. This is not due to any defect of the unit. (Effective dots: more than

99.99 %)

32.

• The optional headphones are not connected to the headphones connector.

• The sound volume of the headphones connector was not adjusted appropriately. The sound volume at this point is the same as the level it was adjusted to during playback.

33.

• The POWER Switch is not set to “

PLAY/PC

”.

34.

• Your TV has AV input terminals, but is not set to its VIDEO mode.

• The cassette holder cover is open.

27.

• Adjust the brightness and angle of the LCD monitor (墌 pg. 16, 17).

28.

• Close the LCD monitor to turn it off or set the POWER Switch to “OFF”, and let the unit cool down.

29.

————

30.

• Re-read the sections covering Fade/Wipe effects, Program AE with special effects and “DIS” (墌 pg. 26, 30 – 33).

31.

————

32.

• Connect the optional headphones to the headphone connector (墌 pg. 64, 65).

• Adjust the sound volume during playback (墌 pg. 36).

33.

• Set the POWER Switch to “

PLAY/PC

” (墌 pg. 36).

34.

• Set the TV to the mode or channel appropriate for video playback (墌 pg. 40, 41).

• Close the cassette holder cover (墌 pg. 12).

CONTINUED ON NEXT PAGE

62 EN

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

35.

• During playback of the unrecorded portion, High-speed Search and still playback, LCD monitor indications appear distorted. This is not a defect.

36.

• The speaker volume is too great.

37.

————

38.

————

39.

————

40.

• A malfunction of some kind has occurred. In this case the camcorder’s functions become unusable.

41.

• The temperature of the battery is extremely high/low.

• Charging is difficult in places subject to extremely high/low temperatures.

42.

• The viewfinder is pulled out.

• The LCD monitor's brightness

setting is too dark.

43.

• This is not a malfunction.

44.

• The DV cable was plugged/ unplugged with power turned on.

45.

————

35.

————

36.

• Turn the speaker volume down (墌 pg. 36).

37.

•Clean the video heads with an optional cleaning cassette (墌 pg. 70).

38.

• Wipe them gently with soft cloth. Wiping strongly can cause damage (墌 pg. 57).

39.

• Check the section of the manual that explains LCD monitor/viewfinder indications (墌 pg. 66 – 68).

40.

• Remove the power supply (battery pack, etc.) and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer.

41.

• To protect the battery, it is recommended to charge it in places with a temperature of 10°C to 35°C (50°F to 95°F) (墌 pg. 69).

42.

• Push the viewfinder back in.

• Adjust the brightness of the

LCD monitor (墌 pg. 16).

• If the monitor is tilted upward 180 degrees, open the monitor fully (墌 pg. 16).

43.

• By recording with “DIS” activated (墌 pg. 26) this can be avoided.

44.

• Turn the camcorder’s power off and on again, then operate it.

45.

• Do not subject the camcorder to shock or excessive vibration during transport.

• Turn the camcorder on and off. The lens cover closes.

35.

The LCD monitor image is distorted.

36.

Images on the LCD monitor are jittery.

37.

Blocks of noise appear during playback, or there is no playback picture and the screen becomes blue.

38.

The LCD monitor, the viewfinder and the lens have become dirty (ex. fingerprints).

39.

An unusual mark appears.

40.

An error indication (E01 — E06) appears.

41.

The charger indicator on the AC Power Adapter/Charger does not light.

42.

Picture does not appear on the LCD monitor.

43.

When the image is printed from the printer, a black bar appears at the bottom of the screen.

44.

When the camcorder is connected via the DV connector, the camcorder does not operate.

45.

During transport, the lens cover opens.

TROUBLESHOOTING

(cont.)

EN63

INDEX

Docking Station

1 PC Connector [DIGITAL STILL] ............ 墌 pg. 42

2 J Terminal/Edit Connector [JLIP (Joint Level

Interface Protocol) (EDIT)] .................... 墌 pg. 51

•Connect to a JLIP-compatible camcorder or VCR to control it from the computer using the provided Software.

NOTE:

Make sure that the camcorder is turned on while connecting the camcorder to a PC using the Docking Station’s JLIP connector. If the camcorder is turned off (because the POWER Switch is set to “OFF” or due to Auto Shut Off* etc.) while the JLIP program software is used, it will be impossible to control the connected devices from the computer. In such a case, first try turning the camcorder on again, or unplug the JLIP connection cable from the Docking Station’s JLIP connector. Then, initialize or run the software again.

* Auto Shut Off:

If 5 minutes elapse in the Record-Standby mode or in the Pause mode, the camcorder’s power shuts off automatically to conserve energy.

•Connect the editing cable when performing

Random Assemble Editing ........ 墌 pg. 50 – 55.

3 External Stereo Microphone Input

Connector [MIC] ................................. 墌 pg. 56

4 Stud .................................................... 墌 pg. 40

5 Screw .................................................. 墌 pg. 40

6 Multi Connector

The Docking Station can be connected with this camcorder through this connector. Never touch it with your hand or hit it with a hard object; if the pins are damaged, the connectors will become unusable due to contact failure.

7 S-Video Output Connector

[S OUT] ........................................ 墌 pg. 40, 51

8 Video Output Connector

[VIDEO] ........................................ 墌 pg. 40, 51

9 Audio Output Connector

[AUDIO L/R] ................................. 墌 pg. 40, 51

0 Screw Knob ......................................... 墌 pg. 40

To attach the camcorder, tighten this clockwise.

64 EN

INDEX

Controls, Connectors And Indicators

(

& ^

tur

)

EN65

Controls

1 START/STOP Button ............................. 墌 pg. 16

2 • Power Zoom Lever [T/W] .................. 墌 pg. 19

•Speaker/Headphone Volume Control

[VOL.] .............................................. 墌 pg. 36

3 • MENU Wheel [+, –,

] ..................... 墌 pg. 24

•LCD Monitor Brightness

Control [+, –] .................................... 墌 pg. 16

4 Snapshot Button

[SNAPSHOT] ................................. 墌 pg. 18, 22

5 Battery Release Switch

[BATT. RELEASE] .................................... 墌 pg. 9

6 OPEN/EJECT Switch ............................. 墌 pg. 12

7 • Play/Pause Button [

/6] ................... 墌 pg. 36

•EXPOSURE Button ............................ 墌 pg. 34

8 • Rewind Button [

] ......................... 墌 pg. 36

•BACKLIGHT Button .......................... 墌 pg. 34

9 Stop Button [5] ................................... 墌 pg. 36

0 • Fast-Forward Button [

] ................. 墌 pg. 36

•FOCUS Button .................................. 墌 pg. 21

! Operation Switch [ , ] .................. 墌 pg. 14

@ POWER Switch

[ ,

PLAY/PC

, OFF] ...................... 墌 pg. 14

# Lock Button ......................................... 墌 pg. 14

$ MODE Dial

[ , VIDEO] ...................................... 墌 pg. 15

% Diopter Adjustment Control.................. 墌 pg. 10

Connectors

The connectors ^ to * are located beneath a cover.

^ Digital Video Connector [DV IN/OUT]

(i.link*) .................................... 墌 pg. 42, 43, 45

* i.Link refers to the IEEE1394-1995 industry

specification and extensions thereof. The logo is used for products compliant with the i.Link standard.

& • Audio/Video Output Connector

[AV OUT] ......................................... 墌 pg. 40

• Headphone Connector [ ] .............. 墌 pg. 56

* Multi Connector

When attached to the Docking Station, this part is connected.

Indicators

( Tally Lamp ........................................... 墌 pg. 16

) POWER Lamp ..................................... 墌 pg. 16

Other Parts

q LCD Monitor ................................. 墌 pg. 16, 17

w Battery Pack Mount ............................... 墌 pg. 9

e Speaker ............................................... 墌 pg. 36

r Camera Sensor

Be careful not to cover this area, a sensor necessary for shooting is built-in here.

t Stereo Microphone .............................. 墌 pg. 56

y Lens u Lens Protector

When using an optional lens filter (commercially available), you must first detach the lens cover.

i Remote Sensor ..................................... 墌 pg. 46

o Grip Strap ............................................ 墌 pg. 10

p Viewfinder ........................................... 墌 pg. 10

Q Viewfinder Cleaning Hatch .................. 墌 pg. 57

W Cassette Holder Cover ......................... 墌 pg. 12

E Tripod Mounting Socket ....................... 墌 pg. 10

R Stud Hole ............................................ 墌 pg. 40

66 EN

LCD Monitor/Viewfinder Indications During Recording

F P

A4U

T x

A B

N R

I I

M G

.HMTOTDE

235

5 R

’ :

0 0

(

)

0 ! @ # $*%

Appears when the Operation switch is set to “ ”.(墌 pg. 14)

2 Displays the shooting mode position. (墌 pg. 15) 3 Appears when backlight compensation is used.

(墌 pg. 34)

4 Appears when the white balance is adjusted.

(墌 pg. 35)

5 Appears when the exposure is adjusted.

(墌 pg. 34)

6 Displays the selected Program AE with special

effects. (墌 pg. 32)

7 Appears when Digital Image Stabilizer (“DIS”) is

engaged. (墌 pg. 26)

8 Appears when the focus is adjusted manually.

(墌 pg. 21)

9 Displays the Time Code. (墌 pg. 20, 27) 0 •Approximate zoom ratio: Appears during

zooming. (墌 pg. 19)

• : Appears when “GAIN UP” is set to “AUTO” and the shutter speed is automatically

adjusted. (墌 pg. 25)

! Appears during zooming.

Zoom level indicator (墌 pg. 19)

@ Displays the selected Fade/Wipe effect.

(墌 pg. 30, 31)

# Appears when in the Squeeze, Cinema or PS

Wide mode. (墌 pg. 26)

Displays the recording mode (SP or LP).

(墌 pg. 13)

Displays the tape remaining time. (墌 pg. 16)

^ Appears when taking a Snapshot. (墌 pg. 18) & •“REC” appears during recording.

•“PAUSE” appears during Record-Standby mode.

(墌 pg. 16)

* Appears while the tape is running. (墌 pg. 16) ( Appears when the iris is locked. (墌 pg. 34) ) Appears during Self-Timer recording. (墌 pg. 28) q Appears when the wind cut mode is engaged to

cut down on noise created by wind. (墌 pg. 27)

w 5S MODE/ANIM. MODE: Displays the 5 second

recording mode or Animation recording mode.

(墌 pg. 26, 29)

e BRIGHT: Displays the brightness of the LCD

monitor or the viewfinder. (墌 pg. 16)

SOUND: Displays the sound mode for

approx. 5 seconds after turning on the camcorder. (墌 pg. 25)

r Displays the date/time. (墌 pg. 11)

*Setting “ON SCREEN” to “SIMPLE” in the Menu Screen removes indications marked with * from the screen

(墌 pg. 27, 37).

INDEX

Indications

EN67

LCD Monitor/Viewfinder Indications During Playback

1 Displays the sound mode. (墌 pg. 37, 38) 2 Displays the Blank Search mode. (墌 pg. 39) 3 Displays the tape speed. (墌 pg. 13) 4 Appears while a tape is running.

: Playback

: Fast-Forward/Shuttle search

: Rewind/Shuttle search

6 : Pause 64: Forward slow-motion 1

6 : Reverse slow-motion e : Audio Dubbing 6e : Audio Dubbing Pause

5 Displays the date/time. (墌 pg. 37, 38) 6 BRIGHT :

Displays the brightness of the LCD monitor or the viewfinder.

(墌 pg. 16)

VOLUME : Displays the speaker or headphone

volume. (墌 pg. 36)

The level indicator moves.

7 Displays the time code. (墌 pg. 37, 38)

1 L

CBI1T0

L 6

E 0

SEADR

E P

LHP

255’

030

7 6

1 2 43

68 EN

Indications Function

Displays the battery remaining power. Remaining power level: high

Remaining power level: exhausted As the battery power comes close to nil, the battery indicator blinks.

When the battery power is exhausted, power turns off automatically.

Appears when no tape is loaded. (墌 pg. 12)

Appears when the erase protection tab is set to “SAVE” while the POWER Switch is set to “ ”. (墌 pg. 12)

Appears if dirt is detected on the heads during recording. Use an optional cleaning cassette. (墌 pg. 70)

Appears if condensation occurs. When this indication is displayed, wait more than 1 hour until condensation disappears.

Appears if a tape is not loaded when START/STOP is pressed while the POWER Switch is set to “ ” and the MODE Dial is set to “VIDEO” or “ ”.

Appears when the tape ends during recording or playback. (墌 pg. 17)

Appears if a tape in another format is loaded.

● Appears when the date/time is not set. (墌 pg. 11)

● Appears when the built-in clock (lithium) battery is discharged and the

previously set date/time is erased. (墌 pg. 11)

Appears if Audio Dubbing is attempted on a blank portion of a tape.

(墌 pg. 56)

● Appears if Audio Dubbing is attempted on a tape recorded in the LP mode. (墌 pg. 56)

● Appears if Audio Dubbing is attempted on a tape recorded in 16-bit audio. (墌 pg. 56)

● Appears if A. DUB (e) on the remote control is pressed when the erase protection tab is set to “SAVE”. (墌 pg. 56)

The error indications (E01 — E06) show what type of malfunction has occured. When an error indication appears, the camcorder turns off automatically. Remove the power supply (battery, etc.) and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer.

Warning Indications

TAPE!

TAPE END

SET DATE/TIME!

E01 — E06

UNIT IN SAFEGUARD

MODE REMOVE AND

REATTACH BATTERY

CHECK T APE’S ERASE

PROTECTION SWITCH

HEAD CLEANING

REQUIRED USE

CLEANING CASSETTE

CONDENSATION

OPERATION PAUSED

PLEASE WAIT

DIFFERENT

FORMATTED TAPE

A. DUB ERROR!

<CANNOT DUB

ON A LP RECORDED

TAPE>

<CANNOT DUB

ON A 16BIT

RECORDING>

<CHECK TAPE’S ERASE

PROTECTION SWITCH >

A. DUB ERROR!

INDEX

Indications (cont.)

EN69

General Battery Precautions

If the remote control is not functioning even if it is being operated correctly, the batteries are exhausted. Replace them with fresh ones.

Use only the following batteries: AAA (R03) size x 2 Please make note of the following rules for battery

use. When misused, the batteries can leak or explode.

1. When replacing batteries, refer to page 46.

2. Do not use any different size of batteries from those

specified.

3. Be sure to install batteries in the correct direction.

4. Do not use rechargeable batteries.

5. Do not expose the batteries to excessive heat as

they can leak or explode.

6. Do not dispose of the batteries in a fire.

7. Remove the batteries from the unit if it is to be

stored for an extended period to avoid battery leakage which can cause malfunctions.

Battery Packs

The supplied battery pack is a lithium-ion battery. Before using the supplied battery pack or an optional battery pack, be sure to read the following cautions:

1. To avoid hazards . . .

.... do not burn.

.... do not short-circuit the terminals.

.... do not modify or disassemble.

.... do not expose the battery to temperatures

exceeding 60°C (140°F), as this may cause the battery to overheat, explode or catch fire.

.... use only specified chargers.

CAUTIONS

When using the AC Power Adapter/Charger in areas other than the USA

䡲 The provided AC Power Adapter/Charger features

automatic voltage selection in the AC range from 110 V to 240 V.

USING HOUSEHOLD AC PLUG ADAPTER

In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer.

Plug adapter

2. To prevent damage and prolong service life . . .

.... do not subject to unnecessary shock.

.... charge in an environment where temperatures

are within the tolerances shown in the chart below. This is a chemical reaction type battery—cooler temperatures impede chemical reaction, while warmer temperatures can prevent complete charging.

.... store in a cool, dry place. Extended exposure

to high temperatures will increase natural discharge and shorten service life.

.... fully charge and then fully discharge the

battery every 6 months when storing the battery pack over a long period time.

.... remove from charger or powered unit when

not in use, as some machines use current even when switched off.

NOTES:

●

It is normal for the battery pack to be warm after charging, or after use.

Temperature Range Specifications

Charging ............. 10°C to 35°C (50°F to 95°F)

Operation ........... 0°C to 40°C (32°F to 104°F)

Storage ............... –10°C to 30°C (14°F to 86°F)

●

Recharging time is based on room temperature of 20°C (68°F).

●

The lower the temperature, the longer recharging take

Cassettes

To properly use and store your cassettes, be sure to read the following cautions:

1. During use . . .

.... make sure the cassette bears the Mini DV mark.

.... be aware that recording onto prerecorded

tapes automatically erases the previously recorded video and audio signals.

.... make sure the cassette is positioned properly

when inserting.

.... do not load and unload the cassette

repeatedly without allowing the tape to run at all. This slackens the tape and can result in damage.

.... do not open the front tape cover. This exposes

the tape to fingerprints and dust.

2. Store cassettes . . .

.... away from heaters or other heat sources.

.... out of direct sunlight.

.... where they won’t be subject to unnecessary

shock or vibration.

.... where they won’t be exposed to strong

magnetic fields (such as those generated by motors, transformers or magnets).

.... vertically, in their original cases.

Terminals

70 EN

CAUTIONS

(cont.)

LCD Monitor

1. To prevent damage to the LCD monitor, DO NOT . . .

.... push it strongly or apply any shocks.

.... place the camcorder with the LCD monitor on

the bottom.

2. To prolong service life . . .

.... avoid rubbing it with coarse cloth.

3. Be aware of the following phenomena for LCD monitor use. These are not malfunctions:

•While using the camcorder, the surface around

the LCD monitor and/or the back of the LCD monitor may heat up.

•If you leave power on for a long time, the

surface around the LCD monitor becomes hot.

Main Unit

1. For safety, DO NOT . . .

.... open the camcorder’s chassis.

.... disassemble or modify the unit.

.... short-circuit the terminals of the battery pack.

Keep it away from metallic objects when not in use.

.... allow inflammables, water or metallic objects

to enter the unit.

.... remove the battery pack or disconnect the

power supply while the power is on.

.... leave the battery pack attached when the

camcorder is not in use.

2. Avoid using the unit . . .

.... in places subject to excessive humidity or dust.

.... in places subject to soot or steam such as near

a cooking stove.

.... in places subject to excessive shock or vibration.

.... near a television set.

.... near appliances generating strong magnetic or

electric fields (speakers, broadcasting anten-

nas, etc.).

.... in places subject to extremely high (over 40°C

or 104°F) or extremely low (under 0°C or 32°F)

temperatures.

3. DO NOT leave the unit . . .

.... in places of over 50°C (122°F).

.... in places where humidity is extremely low

(below 35%) or extremely high (above 80%).

.... in direct sunlight.

.... in a closed car in summer.

.... near a heater.

4. To protect the unit, DO NOT . . .

.... allow it to become wet.

.... drop the unit or strike it against hard objects.

.... subject it to shock or excessive vibration

during transportation.

.... keep the lens directed at extremely bright

objects for long periods.

.... expose the lens to direct sunlight.

.... carry it by holding the LCD monitor or the

viewfinder.

.... swing it excessively when using the hand strap

or the grip.

.... swing the soft camera case excessively when

the camcorder is inside it.

5. Dirty heads can cause the following problems:

•No picture during playback.

•Blocks of noise appear during playback.

•During recording, the Head Clog Warning

indicator “ ” appears.

In such cases, use an optional cleaning cassette. Insert it and play back. If the cassette is used more than once consecutively, damage to the video heads may result. After the camcorder plays back for about 20 seconds, it stops automatically. Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time. In order to maintain a clear picture at all times, periodic check-ups are recommended after using the unit for about 1,000 hours. For periodic check-ups please consult your nearest JVC dealer.

EN71

Declaration of Conformity Model Number : CU-V503U

Trade Name : JVC Responsible party : JVC AMERICAS CORP. Address : 1700 Valley Road Wayne,

N. J. 07470

Telephone Number : 973-315–5000 This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Change or modifications not approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/ TV technician for help.

Serious malfunctioning

If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer.

The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Power Adapter/Battery Charger, etc.) and wait a few minutes and then re-connect it and proceed as usual from the beginning.

About moisture condensation . . .

● You have observed that pouring a cold liquid into a glass will cause drops of water to form on the glass‘ outer surface. This same phenomenon occurs on the head drum of a camcorder when it is moved from a cool place to a warm place, after heating a cold room, under extremely humid conditions or in a place directly subjected to the cool air from an air conditioner.

● Moisture on the head drum can cause severe damage to the video tape, and can lead to internal damage to the camcorder itself.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

How To Handle A CD-ROM

•Take care not to soil or scratch the mirror surface (opposite to the printed surface). Do not write anything or put a sticker on either the front or back surface. If the CD-ROM gets dirty, gently wipe it with a soft cloth outward from the center hole using a circular motion.

•Do not use conventional disc cleaners or cleaning spray.

•Do not bend the CD-ROM or touch its mirror surface.

•Do not store your CD-ROM in a dusty, hot or humid environment. Keep it away from direct sunlight.

72 EN

TERMS

Fade-In/Out ........................................ 墌 pg. 30, 31

Fast-Forward The Tape .............................. 墌 pg. 36

5-second recording mode ......................... 墌 pg. 29

Frame-By-Frame Playback .................. 墌 pg. 36, 48

Gain Up ................................................... 墌 pg. 25

Grip Adjustment ....................................... 墌 pg. 10

Icons ................................................ 墌 pg. 25 – 27

Iris ............................................................ 墌 pg. 34

Iris Lock ................................................... 墌 pg. 34

Journalistic Shooting ................................. 墌 pg. 17

LCD monitor/Viewfinder

Indications ..................................... 墌 pg. 66 – 68

Load A Tape ............................................. 墌 pg. 12

Manual Focus ........................................... 墌 pg. 21

Menu Screen, CAMERA MENU ................. 墌 pg. 25

Menu Screen, DISPLAY MENU ........... 墌 pg. 27, 37

Menu Screen, MANUAL MENU .......... 墌 pg. 26, 27

Menu Screen, VIDEO MENU .................... 墌 pg. 37

MODE Dial Position ................................. 墌 pg. 15

Monotone ................................................ 墌 pg. 33

Motor Drive Mode .................................... 墌 pg. 18

Operation Switch Position ........................ 墌 pg. 14

AC Power Adapter/Charger ..................... 墌 pg. 8, 9

Animation ................................................ 墌 pg. 29

Audio Dubbing ........................................ 墌 pg. 56

Auto Date ................................................. 墌 pg. 27

Auto Focus ............................................... 墌 pg. 21

Auto Shut off ...................................... 墌 pg. 17, 36

Backlight Compensation ........................... 墌 pg. 34

Battery Low .............................................. 墌 pg. 68

Battery Pack ..................................... 墌 pg. 8, 9, 69

Beep/Tally ................................................ 墌 pg. 25

Blank Search ............................................ 墌 pg. 39

Brighten The LCD Monitor ........................ 墌 pg. 16

Built-in Clock's Lithium Battery ................. 墌 pg. 11

Channels (Left/Right) ................................. 墌 pg. 38

Charge The Battery Pack ............................. 墌 pg. 8

Cinema .................................................... 墌 pg. 26

Classic Film .............................................. 墌 pg. 33

Clean The Camcorder ............................... 墌 pg. 57

Connections ...................... 墌 pg. 9, 40, 42 – 45, 51

Darken The LCD Monitor ......................... 墌 pg. 16

Date/Time Display ........................ 墌 pg. 27, 37, 38

Date/Time Settings .................................... 墌 pg. 11

Demonstration Mode ............................ 墌 pg. 7, 26

Digital Zoom ...................................... 墌 pg. 19, 25

DIS (Digital Image Stabilizer) .................... 墌 pg. 26

Diopter Adjustment .................................. 墌 pg. 10

Dubbing ............................................. 墌 pg. 44, 45

Erase Protection ........................................ 墌 pg. 12

Exposure Control ...................................... 墌 pg. 34

EN73

Picture Wipe/Dissolve......................... 墌 pg. 30, 31

Playback Special Effects ............................ 墌 pg. 49

Playback Zoom ........................................ 墌 pg. 48

POWER Switch Position ........................... 墌 pg. 14

Printer ...................................................... 墌 pg. 43

Program AE With Special Effects................ 墌 pg. 32

Progressive Mode ............................... 墌 pg. 22, 23

Progressive Wide ...................................... 墌 pg. 26

Provided Accessories .................................. 墌 pg. 6

Random Assemble Editing ................. 墌 pg. 50 – 55

Record-Standby ........................................ 墌 pg. 16

Recording Mode ....................................... 墌 pg. 13

Remote Control ........................................ 墌 pg. 46

Rewind The Tape ...................................... 墌 pg. 36

Self-Recording .......................................... 墌 pg. 17

Self-Timer ................................................. 墌 pg. 28

Sepia ........................................................ 墌 pg. 33

Set Remote Control/VCR Code .................. 墌 pg. 50

Shuttle Search ........................................... 墌 pg. 36

Shutter Speed ........................................... 墌 pg. 33

Slow-Motion Playback .............................. 墌 pg. 48

Slow Shutter ............................................. 墌 pg. 33

Snapshot .................................................. 墌 pg. 18

Snapshot Mode ........................................ 墌 pg. 18

Sound Mode ................................. 墌 pg. 25, 37, 38

Speaker Volume ....................................... 墌 pg. 36

Specifications ..................................... 墌 pg. 74, 75

Squeeze ................................................... 墌 pg. 26

Still Playback ............................................ 墌 pg. 36

Strobe ...................................................... 墌 pg. 33

Tele Macro ............................................... 墌 pg. 26

Time Code.............................. 墌 pg. 20, 27, 37, 38

Tripod Mounting ....................................... 墌 pg. 10

Twilight .................................................... 墌 pg. 33

Unload A Tape ......................................... 墌 pg. 12

Video Echo ............................................... 墌 pg. 33

White Balance .......................................... 墌 pg. 35

Wide Mode .............................................. 墌 pg. 26

Wind Cut ................................................. 墌 pg. 27

Wipe In/Out ....................................... 墌 pg. 30, 31

Zooming .................................................. 墌 pg. 19

74 EN

SPECIFICATIONS

Camcorder

For General

Power supply : DC 6.3 V (Using AC Power Adapter/Charger)

DC 7.2 V (Using battery pack)

Power consumption

LCD monitor off, viewfinder on : Approx. 4.4 W LCD monitor on, viewfinder off : Approx. 5.2 W

Dimensions (W x H x D) : 51 mm x 125 mm x 97 mm (2-1/16" x 4-15/16" x 3-7/8")

(with the LCD monitor closed and the viewfinder pushed back in)

Weight : Approx. 500 g (1.1 lbs)

(without cassette and battery) Approx. 575 g (1.3 lbs) (incl. cassette and battery)

Operating temperature :0°C to 40°C (32°F to 104°F) Operating humidity : 35% to 80% Storage temperature : –20°C to 50°C (–4°F to 122°F) Pickup : 1/4" CCD (Progressive Scan) Lens : F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens Filter diameter : ø27 mm LCD monitor : 2.5" diagonally measured, LCD panel/TFT active matrix system Viewfinder : Electronic viewfinder with 0.44" color LCD Speaker : Monaural

For Digital Video Camera

Format : DV format (SD mode) Signal format : NTSC standard Recording/Playback format : Video: Digital component recording

: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),

48 kHz 2-channel (16-bit)

Cassette : Mini DV cassette Tape speed : SP: 18.8 mm/s

LP: 12.5 mm/s

Maximum recording time : SP: 80 min. (using 80 min. cassette) LP: 120 min.

For Connectors

Video output :1 V (p-p

)

, 75 Ω, analog

Audio output : 300 mV (rms), 1 kΩ, analog, stereo

DV Input/output : 4-pin, IEEE 1394 compliant Headphone output : ø3.5 mm, stereo

EN75

AC Power Adapter/Charger AA-V51U

Power requirement

U.S.A. and Canada : AC 120 V`, 60 Hz

Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz Power consumption : 23 W Output

Charge : DC 7.2 V , 0.77 A

VTR : DC 6.3 V , 1.8 A Dimensions (W x H x D) : 68 mm x 45 mm x 110 mm (2-11/16" x 1-13/16" x 4-3/8") Weight : Approx. 254.5 g (0.57 lbs)

Docking Station CU-V503U

For General

Dimensions (W x H x D) : 55 mm x 36 mm x 107 mm (2-3/16" x 1-7/16" x 4-1/4") Weight : Approx. 89.9 g (0.2 lbs)

For Connectors

S-Video : Y: 1 V (p-p), 75 Ω, analog output

C: 0.29 V (p-p), 75 Ω, analog output

Video : 1 V (p-p), 75 Ω, analog output Audio : 300 mV (rms), 1 kΩ, analog output

JLIP/EDIT : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug) PC : ø2.5 mm, 3-pole External microphone input : 506 µV (rms), high impedance unbalanced with ø3.5 mm (stereo)

Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice.

Printed in Japan 0500FOV*UN*YP

VICTOR COMPANY OF JAPAN, LIMITE D

GR-DVM80

JVC GRDVM80U - MiniDV Digital Camcorder Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
