JVC GR-D340E-EK User Manual

DIGITAL VIDEO CAMERA

GR-D340E/EK

Please visit our Homepage on the World Wide Web for Digital Video Camera:

http://www.jvc.co.jp/english/cyber/

For Accessories:

http://www.jvc.co.jp/english/accessory/

INSTRUCTIONS

Dear Customer,

Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions contained in the pages 2 – 5 and 11 to ensure safe use of this product.

	ENGLISH
GETTING STARTED	8
VIDEO RECORDING &	18
PLAYBACK
ADVANCED FEATURES	23
REFERENCES	36
TERMS	43

To deactivate the demonstration, set “DEMO MODE” to “OFF”. ( pg. 23, 25)

LYT1507-001A EN

2 EN

READ THIS FIRST !

●Before recording important video, be sure to make a trial recording.

Play back your trial recording to make sure the video and audio have been recorded properly.

●We recommend cleaning your video heads before use.

If you haven’t used your camcorder for a while, the heads may be dirty. We recommend periodically cleaning the video heads with a cleaning cassette (optional).

●Be sure to store your cassette tapes and camcorder in the proper environment.

Video heads can become dirty more easily if your cassette tapes and camcorder are stored in a dusty area. Cassette tapes should be removed from the camcorder and stored in cassette cases. Store the camcorder in a bag or other container.

●Use SP (Standard) mode for important video recordings.

LP (Long Play) mode lets you record 50% more video than SP (Standard) mode, but you may experience mosaic-like noise during playback depending on the tape characteristics and the usage environment.

So, for important recordings, we recommend using SP mode.

●For safety and reliability.

It is recommended only genuine JVC batteries and accessories are used in this camcorder.

●This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BNVF707U/VF714U/VF733U battery packs. Using generic non-JVC batteries can cause damage to the internal charging circuitry.

●Make sure you only use cassettes with the Mini DV mark .

●Remember that this camcorder is intended for private consumer use only.

Any commercial use without proper permission is prohibited. (Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand).

●DO NOT leave the unit

-in place of over 50°C (122°F)

-in place where humidity is extremely low (below 35%) or extremely high (80%).

-in direct sunlight.

-in a closed car in summer.

-near a heater.

●The LCD monitor is made with high-precision technology. However, black spots or bright spots of light (red, green or blue) may appear constantly on the LCD monitor. These spots are not recorded on the tape. This is not due to any defect of the unit. (Effective dots: more than 99.99%)

●Do not leave the battery pack attached when the camcorder is not in use and check the unit regularly whether it is working or not.

SAFETY PRECAUTIONS

IMPORTANT (for owners in the U.K.)

Connection to the mains supply in the United Kingdom.

DO NOT cut off the mains plug from this equipment.

If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.

BE SURE to replace the fuse only with an identical approved type, as originally fitted, and to replace the fuse cover.

If nonetheless the mains plug is cut off be sure to remove the fuse and dispose of the plug immediately, to avoid possible shock hazard by inadvertent connection to the mains supply.

If this product is not supplied fitted with a mains plug then follow the instructions given below: DO NOT make any connection to the Larger Terminal coded E or Green.

The wires in the mains lead are coloured in accordance with the following code:

Blue to N (Neutral) or Black

Brown to L (Live) or Red

If these colours do not correspond with the terminal identifications of your plug, connect as follows:

Blue wire to terminal coded N (Neutral) or coloured black.

Brown wire to terminal coded L (Live) or coloured Red.

If in doubt — consult a competent electrician.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTIONS:

●To prevent shock, do not open the cabinet. No user serviceable parts inside. Refer servicing to qualified personnel.

●When you are not using the AC Adapter for a long period of time, it is recommended that you disconnect the power cord from AC outlet.

EN 3

CAUTION:

To avoid electric shock or damage to the unit, first firmly insert the small end of the power cord into the AC Adapter until it is no longer wobbly, and then plug the larger end of the power cord into an AC outlet.

CAUTIONS:

●This camcorder is designed to be used with PAL-type colour television signals. It cannot be used for playback with a television of a different standard. However, live recording and LCD monitor/viewfinder playback are possible anywhere.

●This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BN-VF707U/VF714U/VF733U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)

NOTES:

●The rating plate (serial number plate) and safety caution are on the bottom and/or the back of the main unit.

●The rating information and safety caution of the AC Adapter are on its upper and lower sides.

4 EN

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

Do not block the ventilation holes.

(If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out).

No naked flame sources, such as lighted candles, should be placed on the apparatus.

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing.

Do not use this equipment in a bathroom or places with water.

Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups etc.) on top of this unit. (If water or liquid is allowed to enter this equipment, fire or electric shock may be caused).

Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock.

CAUTION!

The following notes concern possible physical damage to the camcorder and to the user.

When carrying, be sure to always securely attach and use the provided strap. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the unit, or in a malfunction.

Take care not to get your finger caught in the cassette holder cover. Do not let children operate the camcorder, as they are particularly susceptible to this type of injury.

Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the camcorder.

CAUTION!

Connecting cables (Audio/Video, S-Video, etc.) to the camcorder and leaving it on top of the TV is not recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage.

Information for Users on Disposal of Old Equipment

[European Union]

This symbol indicates that the electrical and electronic equipment should not be disposed as general household waste at its end-of-life. Instead, the product should be handed over to the applicable collection point for the recycling of electrical and electronic equipment for proper treatment, recovery and recycling in accordance with your national legislation.

By disposing of this product correctly, you will help to conserve natural resources and will help prevent potential negative effects on the environment and human health which could otherwise be caused by inappropriate waste handling of this product. For more information about collection point and recycling of this product, please contact your local municipal office, your household waste disposal service or the shop where you purchased the product.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.

(Business users)

If you wish to dispose of this product, please visit our web page www.jvc-europe.com to obtain information about the take-back of the product.

[Other Countries outside the European Union]

If you wish to dispose of this product, please do so in accordance with applicable national legislation or other rules in your country for the treatment of old electrical and electronic equipment.

SOME DO’S AND DON’TS ON THE SAFE USE OF EQUIPMENT

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

DO read the operating instructions before you attempt to use the equipment.

DO ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing connections.

DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

DO be careful with glass panels or doors on equipment.

DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way — switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages.

DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has a standby mode. Switch off using the switch on the equipment and make sure that your family knows how to do this. Special arrangements may need to be made for infirm or handicapped people.

EN 5

DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of road safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume, as such use can permanently damage your hearing. DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten the life of the equipment.

DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s approved stand or legs with the fixings provided according to the instructions.

DON’T allow electrical equipment to be exposed to rain or moisture.

ABOVE ALL

●NEVER let anyone especially children push anything into holes, slots or any other opening in the case — this could result in a fatal electrical shock;

●NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!

6 EN

Major Features of this Camcorder

Wipe/Fader Effects

You can use the Wipe/Fader Effects to make pro-style scene transitions. ( pg. 31)

Fade in

Fade out

Program AE, Effects and Special Effects

For example, “SPORTS” mode allows fastmoving images to be captured one frame at a time, for vivid, stable slow-motion. ( pg. 31)

Backlight Compensation

Simply pressing the BACKLIGHT button brightens the image darkened by backlight. ( pg. 29)

●You can also select a spot metering area so that more precise exposure compensation is available. ( pg. 29, Spot Exposure Control)

Data Battery

You can check the battery status by simply pressing the DATA button. ( pg. 13)

BATTERY CONDITION

LEVEL MAX TIME

100%		LCD
50		80min
		FINDER
0		90min

Auto Button

You can change the recording mode between manual setting to the standard mode setting of the camcorder by pressing the AUTO button. ( pg. 14)

M

			CONTENTS	EN 7
GETTING STARTED	8 ADVANCED FEATURES			23

Index.................................................................	8
Provided Accessories .....................................	11
Power..............................................................	12
Operation Mode..............................................	14
Auto/Manual Mode .....................................	14
Power-Linked Operation.............................	15
Language Settings..........................................	15
Date/Time Settings .........................................	15
Grip Adjustment..............................................	15
Viewfinder Adjustment....................................	16
Brightness Adjustment Of The Display...........	16
Tripod Mounting..............................................	16
Loading/Unloading A Cassette .......................	17
VIDEO RECORDING & PLAYBACK	18
VIDEO RECORDING ...........................................	18
Basic Recording..............................................	18
Tape Remaining Time ................................	18
LCD Monitor And Viewfinder ......................	18
Zooming......................................................	19
Journalistic Shooting ..................................	19
Time Code ..................................................	19
Quick Review..............................................	20
Recording From The Middle Of A Tape......	20
VIDEO PLAYBACK .............................................	21
Normal Playback.............................................	21
Still Playback ..............................................	21
Shuttle Search ............................................	21
Blank Search ..............................................	21
Playback Snapshot.....................................	21
Connections To A TV Or VCR........................	22

MENUS FOR DETAILED ADJUSTMENT..................	23
Changing The Menu Settings .........................	23
Recording Menus............................................	24
Playback Menus .............................................	26
FEATURES FOR RECORDING...............................	27
Wide Mode......................................................	27
Night-Scope....................................................	27
Snapshot (Record Still Image On Tape).........	27
Manual Focus .................................................	28
Exposure Control ............................................	28
Iris Lock ..........................................................	29
Backlight Compensation .................................	29
Spot Exposure Control....................................	29
White Balance Adjustment..............................	30
Manual White Balance Adjustment.................	30
Wipe Or Fader Effects ....................................	31
Program AE, Effects and Shutter Effects........	31
EDITING............................................................	33
Dubbing To A VCR .........................................	33
Dubbing To A Video Unit Equipped With A DV
Connector (Digital Dubbing) .......................	34
Connection To A Personal Computer .............	35
REFERENCES	36
TROUBLESHOOTING ..........................................	36
USER MAINTENANCE.........................................	39
CAUTIONS ........................................................	40
SPECIFICATIONS................................................	42
TERMS	43

8 EN GETTING STARTED

Index

GETTING STARTED EN 9

Controls

A Rewind Button [3] ( pg. 21) Left Button [ ] ( pg. 15)

Quick Review Button [QUICK REVIEW] ( pg. 20)

B Set Button [SET] ( pg. 15)

Data Battery Button [DATA] ( pg. 13) C Stop Button [8] ( pg. 21)

Backlight Compensation Button [BACKLIGHT] ( pg. 29) Down Button [] ( pg. 15)

D Play/Pause Button [4/9] ( pg. 21) Manual Focus Button [FOCUS] ( pg. 28) Up Button [] ( pg. 15)

E Wide 16:9 Button [16:9] ( pg. 27) Blank Search Button [BLANK] ( pg. 21)

F Menu Button [MENU] ( pg. 23)

G Fast-Forward Button [5] ( pg. 21) Right Button [ ] ( pg. 15)

Night Button [NIGHT] ( pg. 27)

H Dioptre Adjustment Control ( pg. 16) I Auto Button [AUTO] ( pg. 14)

J Snapshot Button [SNAPSHOT] ( pg. 27) K Power Zoom Lever [T/W] ( pg. 19)

Speaker Volume Control [VOL. +, –] ( pg. 21)

L Battery Release Button [PUSH BATT.] ( pg. 12)

M Recording Start/Stop Button ( pg. 18)

N Power Switch [REC, OFF, PLAY] ( pg. 14) O Lock Button ( pg. 14)

P Cassette Open/Eject Switch [OPEN/EJECT] ( pg. 17)

Other Parts

V LCD Monitor ( pg. 18) W Viewfinder ( pg. 16)

X Battery Pack Mount ( pg. 13) Y Shoulder Strap Eyelet ( pg. 12) Z Speaker ( pg. 21)

a Grip Strap ( pg. 15)

bLens

cCamera Sensor

(Be careful not to cover this area, a sensor necessary for shooting is built-in here.)

dStereo Microphone

eStud Hole ( pg. 16)

fTripod Mounting Socket ( pg. 16)

gCassette Holder Cover ( pg. 17)

GETTING STARTED

Connectors

The connectors are located beneath the covers. Q Audio/Video Output Connector

[AV] ( pg. 22, 33)

R S-Video Output Connector [S] ( pg. 22, 33) S DC Input Connector [DC] ( pg. 12)

T Digital Video Connector [DV OUT] (i.LINK*) ( pg. 34, 35)

*i.LINK refers to the IEEE1394-1995 industry

specification and extensions thereof. The logo is used for products compliant with the i.LINK standard.

Indicators

U POWER/CHARGE Lamp ( pg. 12, 18)

	10 EN GETTING STARTED
	LCD Monitor/Viewfinder Indications			R Wipe/Fader Mode Indicator ( pg. 31)
	During Video Recording			S Wind Cut Indicator ( pg. 25)
				T Time Code ( pg. 25)
		8 9 0qw e	r	U Manual Focus Adjustment Indicator
				( pg. 28)
			t	Brightness Control Indicator (LCD monitor/
		10 x		Viewfinder) ( pg. 16)
	1		y
	2	1/50	u
	3
			i
	4			BRIGHT
		B/W	o
	5
	6			V Date/Time ( pg. 15)
	7

1.1.2006

p a s a Auto/Manual Mode Indicator

A : Auto Mode M : Manual Mode

B : Night-Scope Indicator ( pg. 27)

: Gain Up Mode ( pg. 24) C Shutter Speed ( pg. 32)

D White Balance Indicator ( pg. 30) E Effect Mode Indicator ( pg. 31)

F Program AE Mode Indicator ( pg. 32)

G SOUND 12BIT/16BIT: Sound Mode Indicator ( pg. 24) (Appears for approx. 5 seconds after turning on the camcorder).

H Battery Remaining Power Indicator ( pg. 38)

I Approximate Zoom Ratio ( pg. 19) J Zoom Indicator ( pg. 19)

K Digital Image Stabiliser ( pg. 24) L Wide16:9 Mode Indicator ( pg. 27)

M Recording Speed Mode (SP/LP) ( pg. 24) (Only LP Indicator is displayed)

N Tape Running Indicator ( pg. 18) (Rotates while tape is running).

O Tape Remaining Time ( pg. 18)

P REC: (Appears during recording). ( pg. 18) PAUSE: (Appears during Record-Standby mode). ( pg. 18)

PHOTO: (Appears when taking snapshot). ( pg. 27)

Q : Spot Exposure Control Indicator ( pg. 29)

: Backlight Compensation Indicator ( pg. 29)

: Iris Lock Indicator ( pg. 29)

±: Exposure Adjustment Indicator ( pg. 28)

During Video Playback

1

2

3

4 5

25min

12BIT

9

BLANK SEARCH

PUSH "STOP" BUTTON

TO CANCEL

VOLUME

1:15 PM

15:29:03

1.1.2006

8 7 6

a Battery Remaining Power Indicator ( pg. 38)

B Blank Search Indicator ( pg. 21) C Tape Speed (SP/LP) ( pg. 26)

(Only LP Indicator is displayed) d Cassette Indicator

E4: Playback

5: Fast-Forward/Shuttle Search

3: Rewind/Shuttle Search

9: Pause

FDate/Time ( pg. 15)

GVOLUME: Volume Level Indicator ( pg. 21) BRIGHT: Brightness Control Indicator (LCD monitor/Viewfinder) ( pg. 16)

HTime Code ( pg. 26)

ISound Mode Indicator ( pg. 26)

EXPOSURE

GETTING STARTED EN 11

Before Using This Camcorder			Provided Accessories
Make sure you only use cassettes with the Mini
DV mark		.
This camcorder is designed exclusively for the
digital video cassette. Only cassettes marked
“	” can be used with this unit.		OR

Remember that this camcorder is not compatible with other digital video formats.

Remember that this camcorder is intended for private consumer use only.

Any commercial use without proper permission is prohibited. (Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand).

Before recording important video, be sure to make a trial recording.

Play back your trial recording to make sure the video and audio have been recorded properly.

	We recommend cleaning your video heads
	before use.	a AC Adapter AP-V17E or AP-V14E
	If you haven’t used your camcorder for a while, the	b Power Cord (only for AP-V14E)
	heads may be dirty. We recommend periodically	c Battery Pack BN-VF707U
	cleaning the video heads with a cleaning cassette
		d Audio/Video Cable(Ø3.5 mini-plug to RCA
	(optional).
		plug)
	Be sure to store your cassette tapes and
		e Shoulder Strap ( pg. 12 for attachment)
	camcorder in the proper environment.
		f Lens Cap ( pg. 12 for attachment)
	Video heads can become dirty more easily if your
	cassette tapes and camcorder are stored in a dusty	NOTES:
	area. Cassette tapes should be removed from the	● In order to maintain optimum performance of the
	camcorder and stored in cassette cases. Store the
		camcorder, provided cables may be equipped with
	camcorder in a bag or other container.
		one or more core filter. If a cable has only one core
	Use SP (Standard) mode for important video
		filter, the end that is closest to the filter should be
	recordings.	connected to the camcorder.
	LP (Long Play) mode lets you record 50% more
		● Make sure to use the provided cables for
	video than SP (Standard) mode, but you may
		connections. Do not use any other cables.
	experience mosaic-like noise during playback
	depending on the tape characteristics and the
	usage environment.
	So, for important recordings, we recommend using
	SP mode.
	It is recommended that you use JVC brand
	cassette tapes.
	Your camcorder is compatible with all brands of
	commercially available cassette tapes complying
	with the MiniDV standard, but JVC brand cassette
	tapes are designed and optimized to maximize the
	performance of your camcorder.
	Also read “CAUTIONS” on pages 40 – 41.

GETTING STARTED

	12 EN GETTING STARTED
	How To Attach The Lens Cap	Power
	To protect the lens, attach	This camcorder’s 2-way power supply system
	the provided lens cap to the
		lets you choose the most appropriate source of
	camcorder as shown in the
		power. Do not use provided power supply units
	illustration.
		with other equipment.
	NOTE:
		Charging The Battery Pack
	To confirm the lens cap is on
	correctly make sure the cap is
	flush to the camcorder.	Battery pack mount
			PUSH
		Battery pack	BATT.
	Place here during
	shooting.		POWER/
	How To Attach The Shoulder Strap	Arrow	CHARGE
			lamp

Follow the illustration.

1 Thread the strap through the eyelet.

2 Fold it back and thread it through the strap guide and the buckle.

●To adjust the length of the strap, loosen and then tighten the strap in the buckle.

3 Slide the strap guide fully towards the eyelet.

To DC	To AC outlet
connector

Power switch

	Buckle		AC Adapter (ex. AP-V17E)
Strap guide	2		1 Set the Power Switch to “OFF”.
			2 With the arrow on the battery pack pointing
	2		downward, push the battery pack slightly against
			the battery pack mount a.
			3 Slide down the battery pack until it locks in
			place b.
			4 Connect the AC Adapter to the camcorder.
			5 Connect the Power Cord to the AC Adapter.
			(AP-V14E only)
1		3	6 Plug the AC Adapter into an AC outlet. The
			POWER/CHARGE lamp on the camcorder
Eyelet			blinks to indicate charging has started.
			7 When the POWER/CHARGE lamp goes out,
			charging is finished. Unplug the AC Adapter
			from the AC outlet. Disconnect the AC Adapter
			from the camcorder.

					GETTING STARTED		EN 13
	To detach the battery pack			Using The Battery Pack
	Slide the battery pack upward while pressing
				Perform steps 2 – 3 in “Charging The Battery
	PUSH BATT. to detach it.
				Pack”.
	Battery pack	Charging time		Maximum continuous recording time
	BN-VF707U*	Approx. 1 hr. 30 min.
	BN-VF714U	Approx. 2 hr. 40 min.		Battery pack	LCD monitor	Viewfinder on
					on
	BN-VF733U	Approx. 5 hr. 40 min.
				BN-VF707U*	1 hr. 30 min.	1 hr. 40 min.
	* Provided
				BN-VF714U	3 hr.	3 hr. 25 min.
	NOTES:
				BN-VF733U	7 hr.	8 hr.
	● It is recommended that only genuine JVC
				* Provided
	batteries are used in this camcorder. Using
				NOTES:
	generic non-JVC batteries can cause damage
	to the internal charging circuitry.			● Recording time is reduced significantly under the
	● If the protective cap is attached to the battery			following conditions:
	pack, remove it first.			• Zoom or Record-Standby mode is engaged
	● During charging, the camcorder cannot be			repeatedly.
	operated.			• The LCD monitor is used repeatedly.
	● Charging is not possible if the wrong type of			• The playback mode is engaged repeatedly.
	battery is used.			● Before extended use, it is recommended that you
	● When charging the battery pack for the first time			prepare enough battery packs to cover 3 times the
	or after a long storage period, the POWER/			planned shooting time.
	CHARGE lamp may not light. In this case, remove			ATTENTION:
	the battery pack from the camcorder, then try
				Before detaching the power source, make sure that
	charging again.
				the camcorder’s power is turned off. Failure to do so
	● If the battery operation time remains extremely
				can result in a camcorder malfunction.
	short even after having been fully charged, the
				Data Battery System
	battery is worn out and needs to be replaced.
	Please purchase a new one.
	● Since the AC Adapter processes electricity			You can check the remaining battery power and
	internally, it becomes warm during use. Be sure to			the recordable time.
	use it only in well-ventilated areas.			1) Make sure the battery is attached and the
	● Using the optional AA-VF7 Battery Charger, you			Power Switch is set to “OFF”.
	can charge the BN-VF707U/VF714U/VF733U			2) Open the LCD monitor fully.
	battery pack without the camcorder.			3) Press DATA, and the battery status screen
	● After 5 minutes has elapsed in Record-Standby
				appears.
	mode with the cassette inserted, and no operation
				● It is displayed for 5 seconds if the button is
	is performed (“T PAUSE” indicator may not			pressed and released quickly, and for 15
	appear), the camcorder will automatically turn off
				seconds if the button is pressed and hold for
	its power supplied from the AC adapter. In this
				several seconds.
	case, the battery charge starts if the battery is
	attached to the camcorder.			● If “COMMUNICATION ERROR” appears

instead of the battery status even though you tried to press DATA several times, there may be a problem on the battery. In such a case, consult your nearest JVC dealer.

GETTING STARTED

14 EN	GETTING STARTED
Using AC Power					Operation Mode
Perform steps 4 – 6 in “Charging The Battery
			To turn on the camcorder, set the Power Switch
Pack”.
			to any operation mode except “OFF” while
NOTE:
			pressing down the Lock Button located on the
The provided AC Adapter features automatic			switch.
voltage selection in the AC range from 110 V to					POWER/
240 V.					Lock Button CHARGE
About Batteries					lamp

DANGER! Do not attempt to take the batteries	MENU
	AUTO
apart, or expose them to flame or excessive
heat, as it may cause a fire or explosion.
WARNING! Do not allow the battery or its
terminals to come in contact with metals, as this
can result in a short circuit and possibly start a
fire.
To resume the original function of the
accurate battery power indication	Choose the appropriate operation mode
If the battery power indication differs from the
actual operating time, fully charge the battery,	according to your preference using the Power
and then run it down. However this function may	Switch.
not turn back if the battery was used for a long	Power Switch Position
period of time under extremely high/low
temperature condition or charged too many	REC:
times.	● Allows you to perform recording on the tape.
	● Allows you to set various recording functions
	using the Menus. ( pg. 23)
	OFF:
	Allows you to switch off the camcorder.
	PLAY:
	● Allows you to play back a recording on the
	tape.
	● Allows you to set various playback functions
	using the Menus. ( pg. 23)
	Auto/Manual Mode
	Press AUTO button repeatedly to switch to auto/
	manual recording mode. When manual mode is
	selected, the indicator “M” appears on the LCD
	monitor.
	Auto Mode: A
	You can record using no special effects or
	manual adjustments.
	Manual Mode: M
	Manual recording is possible by setting various
	functions.
