Page 1
COLOR TELEVISION
AV-14FN15
AV-20NN15
Contents
Knowing your TV’s features
Remote control buttons and basic functions.3
TV buttons and functions
Setting up your TV
Basic setting for picture
Advanced setting for picture
Original features for picture
Advanced setting for sound
Favorite channel and video setting
Customized setting
TV channel presetting
Additional preparation
Troubleshooting
Specifications
........................................
.....................................
..........................................
..............................................
..........................
..............................
.................................
.........................
...........................
..........................
.............
.................................
.................................
10
11
12
13
13
14
2
5
6
8
9
9
9
INSTRUCTIONS
GGT0079-001A-H
Page 2
Thank you for buying this JVC color television.
To make sure you understand how to use your new TV, please read this manual
throughly before you begin.
Safety Instructions
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING
RULES REGARDING THE USE OF THIS TV.
1 Operate only from the power source indicated on the rear of the TV.
2 Avoid damaging the power cord and AC plug. When unplugging the TV, grasp the AC plug.
Do not pull on the power cord.
3 Never block or cover the cabinet ventilation
openings. Never install the TV where good
ventilation is unattainable. When installing
this TV, leave space for ventilation around the
TV more than the minimum distances as
shown in the diagram.
4 Do not allow objects or liquid into the cabinet
10 cm
openings.
5 In the event of a fault, unplug the unit and call a JVC service technician.
Do not attempt to repair it yourself or remove the rear cover.
6 The surface of the TV screen is easily damaged. Be very careful with it when handling
the TV. Should the TV screen become soiled, wipe it with a soft dry cloth. Never rub it
forcefully. Never use any cleaner or detergent on it.
7 If you are not going to use this TV for a long period of time, be sure to disconnect the
AC plug from the AC socket.
8 The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
15 cm
15 cm10 cm
Knowing your TV’s functions
Main features
Function Description
Closed caption You can display dialog on the screen from TV broadcasts with Closed caption
Favorite CH (Channel) You can register up to four favorite channels for quick recall with one press.
AI Volume TV adjusts automatically the volume to the same level for all TV channels to
VNR You can reduce the picture noise when viewing noisy TV programs or video
White balance You can choose one of three tones of white to match to the video source such
Child lock To prevent accidental operation by your children, you can disable the control
2
system. You also may be able to display some information in text form if available.
avoid sudden change of the volume when selecting different TV channel.
sources.
as movie, sports, etc. Changing White balance affects the appearance of all other
colors on the screen.
buttons on the TV.
Page 3
Remote control buttons and basic functions
1
6
9
0
8
2
3
7
4
RM-C1265
No.Press To
1 POWER Turn on or off the TV from standby mode.
2 MENU/OK Display menu and confirm selected function.
3 5/∞/2/3 Select and adjust menu function.
4 CHANNEL M Select the desired channel number.
5 VOLUME M Adjust the volume level.
6 TV/VIDEO Select TV or VIDEO terminal input.
7 MUTING Turn off the volume. Press this button again to resume the volume.
8 DISPLAY/BACK Display the program number or video terminal number on the screen.
On the other hand, you can use this button to return to the previous menu.
9 CLOSED CAPTION Display information in text which are broadcasted by some TV channels.
0 0-9, 100+ Select the program number. For three-digit program numbers, press 100+,
then press the number button.
- RETURN, a) Return to the frequently viewed channels with one touch.
1 Choose the channel you want to register.
2 Press and hold RETURN, button until “RETURN PLUS PROGRAMMED!”
appears.
To cancel, press and hold RETURN, button until “RETURN PLUS CANCELED!”
appears.
b) Return to the previously viewed channel, if you have not set or have
canceled the Return channel as above.
5
3
Page 4
Remote control buttons and basic functions
How to operate menus and menu locations
TO Operation Note
Display the MENU. Press the MENU/OK button 2.To exit the MENU, press the
DISPLAY/BACK button* 8 or
choose EXIT menu.
Display the top menu. Press 5/∞ buttons 3 to choose a menu title. Press ∞ button 3 to display the
Then press MENU/OK button 2. next page for more functions.
Display the 2nd menu. Press 5/∞ buttons 3 to choose a menu title.
Then press MENU/OK button 2.
Display the 3rd menu. Press 5/∞ buttons 3 to choose a menu title.
Then press MENU/OK button 2.
Return to the previous Press the DISPLAY/BACK button* 8.–
menu.
Choose the setting of Press 5/∞ buttons 3 to choose a function. Press the MENU/OK button 2 to
a function. Then press the 2/3 buttons 3 to change the exit from the menu.
setting.
Adjust the effect level Press 5/∞ buttons 3 to choose a function.
of a function. Then press the 2/3 buttons 3 to adjust the
effect level.
Display the sub menu Press 5/∞ buttons 3 to choose a function.
of a function. Then press MENU/OK button 2 to display –
the sub menu.
The following chart shows locations of functions in menus.
In this manual, location of a function is described as follows:
MENU Top menu 2nd menu
MENU Top menu 2nd menu
3rd menu
Note: Some functions have the 4th menus as the sub-menus.
*To exit the menu, the on screen display will show BACK indicated in blue. But it doesn’t refer to the
blue button on the remote control. Instead, it refers to the DISPLAY/BACK button on the remote
control.
Top menu 2nd menu Location 3rd menu Location
MENU INPUT EXT. INPUT P.11 - -
DISPLAY P.11 - -
CLOSED CAPTION P.9 - -
PICTURE PICTURE MODE P.8 - -
* If you want to
adjust
SETTING
menu, you must
set PICTURE
MODE menu to
USER.
SOUND AI VOLUME P.9 - -
FEATURES OFF TIMER P.11 - -
INSTALL AUTO PROGRAM P.12 - -
EXIT - - - -
PICTURE SETTING P.8 - -
WHITE BALANCE P.8 - -
PICTURE FEATURES - VNR P.11
FAVORITE CH SETTING P.10
VIDEO SETTING P.10
COLOR SYSTEM P.8
CHILD LOCK P.11 - -
CHANNEL SUMMARY P.12 - -
BLUE BACK P.9 - -
AUTO SHUTOFF P.11 - -
4
Page 5
TV buttons and functions
The following illustrations are for AV-14FN15 and AV-20NN15 only, which are used for
explanation purposes. Your TV may not look exactly like the illustration.
Front of the TV
9 7 4 3 2 18 6 5
AV-14FN15
VIDEO AUDIO
IN (VIDEO-2)
MENU
OK
9 7 4 3 2 18 6 5
AV-20NN15
VIDEO AUDIO
IN (VIDEO-2)
Rear of the TV
VIDEO-1
AV-14FN15 AV-20NN15
INPUT
OUTPUT
VIDEO
AUDIO
=
No. Button/terminal Description
1I(main power) Press to turn on or turn off the TV’s main power.
2 Power lamp Indicate the TV is being turned on or off.
No color : TV’s main power is being turned off.
Red : TV’s main power is being turned on.
3 TIMER lamp Lights when the TV is in the OFF TIMER mode.
4 Remote control sensor
5 VOLUME M Press to adjust the volume level.
6 CHANNELM Press to select the desired channel.
7 MENU Press to display the menu.
8 IN (VIDEO-2) Video and audio input jacks for VIDEO-2 mode.
9 Headphone jack.
0 Antenna socket.
- OUTPUT Video and audio output jacks.
= VIDEO-1 INPUT Video and audio input jacks for VIDEO-1 mode.
MENU
OK
VIDEO-1
0-
INPUT
OUTPUT
VIDEO
AUDIO
0-=
How to operate the menus with the TV button
TV button
Work as same as the button on the
remote control unit
MENU MENU/OK button To display main menu and exit
CHANNEL M ∞/5 button To select menu function.
VOLUME M 2/3 button To adjust the desired function.
Note
menu after finish setting.
5
Page 6
Setting up your TV
CAUTION
• Turn off the equipment including the TV before connecting.
1 Connecting the antenna
To install rod antenna
Install into the top-rear holder. Once installed, it cannot be removed.
Indoor antenna
Rod antenna
(1)
VHF/UHF outdoor antenna
Antenna holder
(2)
Matching
VIDEO-1
INPUT
OUTPUT
VIDEO
AUDIO
antenna
adapter
(supplied)
(3)
VIDEO-1
OUTPUT
INPUT
VIDEO
AUDIO
Illustration of AV-14FN15 only
If you connect a VCR, connect the antenna output jack of your VCR and the antenna jack on the TV
with the antenna cable. Then connect the output jacks of your VCR and the VIDEO-1 input jacks of
the TV with the video cable and audio cables. For details, see the manual of your VCR.
VHF/UHF outdoor antenna
3 Inserting batteries into the remote
control.
Rear of the TV
VIDEO-1
OUTPUT
INPUT
Insert two batteries by following the ª and
· polarities and inserting the · end first.
CAUTION:
VIDEO
AUDIO
Follow the cautions printed on the batteries.
Notes:
• Use AA/R6/UM-3 dry cell batteries.
• If the remote control does not work
To audio/video
output
To RF
output
properly, install new batteries. The supplied
batteries are for testing, not regular use.
VCR
To antenna input
The illustration shown is just a sample. It may
not be same as your TV.
2 Connecting the compatible AC plug
to the AC outlet.
6
4Turn on the TV by pressing the main
power button.
JVC logo appears on the screen.
Page 7
Setting up your TV (continued)
5 Making the initial settings
Set up your TV by pressing MENU/OK button or waiting for 15 seconds, then the TV will operate
by following steps as below:
7
•Press 5/∞ button to select AIR or CABLE,
press the MENU/OK button. TV will start
searching for the channels.
• Press the red button to cancel the SETUP
TOUR RESTART function.
If you want to make initial settings again
when the next time you turn on the TV,
press the MENU/OK button to activate the
≠
To stop AUTO PROGRAM, press MENU/OK
SETUP TOUR RESTART function.
≠
■
■
■
■
button.
•To complete the initial setting, press the
MENU/OK button. To set undesired
channels to be skipped, see page 12.
• If the JVC logo does not appear, use AUTO PROGRAM function to make the initial
settings. This function is located in the INSTALL menu.
• If the JVC logo appears, although you had made the initial settings, press the TV/VIDEO
button to exit from initial settings.
7
Page 8
Basic setting for picture
COLOR SYSTEM
You can select the appropriate color system when
the picture is not clear or no color appears.
Press the COLOR SYSTEM button to select a
setting.
In TV mode: NTSC 3.58 MHz (Fixed)
In VIDEO mode:
AUTO PAL SECAM
NTSC3.58NTSC4.43
To operate this function with a menu:
❇
MENU PICTURE PICTURE FEATURES
COLOR SYSTEM
For the color system in each country or region,
see the table below:
Area Country or Region System
Bahrain, Kuwait, Oman, Qatar,
United Arab Emirates, Yemen, etc.
Indonesia, Malaysia, Singapore,
Asia, Middle Thailand, India, etc.
East China, Vietnam, etc. PAL
Hong Kong, etc. PAL
Islamic Republic of Iran, Lebanon,
Saudi Arabia, etc.
Philippines, Taiwan, Myanmar, etc. NTSC
Russia, etc. SECAM
Europe
Oceania Australia, New Zealand, etc. PAL
Africa Nigeria, etc. PAL
Czech Republic, Poland, etc. PAL
Germany, Holland, Belgium, etc. PAL
UK, etc. PAL
Republic of South Africa, etc. PAL
Egypt, Morocco, etc. SECAM
PAL
SECAM
PICTURE MODE
You can choose the desired picture setting with
one touch.
Press the PICTURE MODE button to select a
setting.
To operate this function with a menu:
MENU PICTURE PICTURE MODE
❇
To return the USER setting to the default, press
the blue button when the PICTURE SETTING
menu appears.
Adjusting the picture - USER
You can adjust the desired picture setting when
selecting USER in PICTURE MODE.
1 Select the USER in PICTURE MODE under
PICTURE menu.
MENU PICTURE PICTURE MODE
❇
USER
2 Select the PICTURE SETTING in PICTURE
menu, then adjust the setting.
MENU PICTURE PICTURE SETTING
❇
PICTURE 2 : Lower 3 : Higher
BRIGHT 2 : Darker 3 : Brighter
DETAIL 2 : Softer 3 : Higher
COLOR 2 : Lighter 3 : Deeper
TINT* 2 : Reddish 3 : Greenish
*TINT can only be adjusted in NTSC system.
WHITE BALANCE
You can change the white balance of the picture
to better match the type of video being viewed.
Select the WHITE BALANCE in the PICTURE
menu, then choose the desired setting.
MENU PICTURE WHITE BALANCE
❇
NORMAL Normal white balance.
COOL Bluish white.
WARM Reddish white.
SOFT Softens contrast and sharpness.
BRIGHT Heightens contrast and sharpness.
STANDARD Standard picture setting.
USER You can change this picture setting
as you like.
Select USER and adjust following
items in the PICTURE SETTING menu.
(PICTURE, BRIGHT, DETAIL, COLOR,
TINT*)
*TINT can only be adjusted in NTSC system.
8
❇ About the basic operations of the menu,
please see the “How to operate menus
and menus locations” on page 4.
Page 9
Advance setting for picture
BLUE BACK
You can set the TV to automatically change to a
blue screen and mute the sound if the signal is
weak or absent, or when there is no input from
an antenna.
Select the BLUE BACK in the INSTALL menu,
then choose ON or OFF.
MENU INSTALL BLUE BACK
❇
If you wish to continue viewing the poor picture,
cancel the BLUE BACK function.
Original features for picture
CLOSED CAPTION
If they are included in a program, you can view
closed captions or text information.
Press the CLOSED CAPTION button to select a
setting.
OFF TEXTCLOSED CAPTION
To operate this function with a menu:
1 Select the CLOSED CAPTION in INPUT
menu, then choose “CAPTION” or
“TEXT”.
MENU INPUT CLOSED CAPTION
❇
2 Press the 2/3 button to select the desired
caption or text channel.
Advanced setting for sound
AI VOLUME
You can adjust the volume of all the channels
and video inputs to the same level automatically.
Select the AI VOLUME in SOUND menu, then
choose ON or OFF.
MENU SOUND AI VOLUME
❇
❇ About the basic operations of the menu,
please see the “How to operate menus
and menus locations” on page 4.
9
Page 10
Favorite channel and video setting
VIDEO SETTING
MENU
PICTURE FEATURES
VIDEO SETTING
VIDEO STATUS
To register the favorite channel
You can register and recall 4 favorite channels by
using the color buttons (red, green, yellow, blue).
1 In TV mode, select a TV channel (CH02-
CH69, CC01-CC125) you desired to register.
2 Press and hold a color button for 3
seconds or more.
“FAVORITE CHANNEL 7 PROGRAMMED!”
appears on the screen and current channel
is registered.
3 To register other favorite channels, repeat
Step 1 to 2.
To recall the favorite channel, press the color
button.
When the TV is in menu mode, favorite channel
function is not available.
To adjust favorite channel setting
(FAVORITE CH SETTING)
You can adjust the picture settings for the favorite
channels.
1 Display the PICTURE menu and select
FAVORITE CH SETTING in PICTURE
FEATURES menu.
MENU PICTURE PICTURE FEATURES
❇
FAVORITE CH SETTING
2 Select FAVORITE CHANNEL in FAVORITE
CH SETTING menu, then choose the
desired favorite channel.
FAVORITE CH SETTING
❇
FAVORITE CHANNEL
To adjust the video setting
(VIDEO SETTING)
You can adjust the picture settings for video
inputs.
1 Display the PICTURE menu and select
VIDEO SETTING in PICTURE FEATURES
menu.
❇
2 Select VIDEO STATUS in VIDEO SETTING
menu, then choose the desired video
input.
❇
3 Select EFFECT, then press 2/3 button to
choose ON. To cancel the settings, choose
OFF.
4 Select the desired item that you wish to
adjust.
PICTURE BRIGHT DETAIL
TINT COLOR
5 Press the MENU/OK button to exit the
menu.
3 Select EFFECT, then press 2/3 button to
choose ON.
To cancel the settings, choose OFF.
4 Select the desired item that you wish to
adjust.
PICTURE BRIGHT DETAIL
TINT COLOR
5 Press the MENU/OK button to exit the
menu.
10
❇ About the basic operations of the menu,
please see the “How to operate menus
and menus locations” on page 4.
Page 11
Customized setting
MENU INPUT EXT.INPUT
VNR
You can reduce the picture noise.
Select the VNR in the PICTURE FEATURES menu
under PICTURE menu, then choose a setting of
VNR function.
❇
MENU PICTURE PICTURE FEATURES
VNR
OFF VNR is turned off.
AUTO Effect of VNR is automatically controlled.
MIN Effect of VNR becomes minimum level.
MAX Effect of VNR becomes maximum level.
If you select MAX, the picture becomes softer
even if the original picture is sharp.
CHILD LOCK
You can disable the front control buttons of the
TV.
Select the CHILD LOCK in the FEATURES menu,
then choose ON or OFF.
❇
MENU FEATURES CHILD LOCK
OFF TIMER
You can set the TV to turn off automatically to
standby mode after a set time.
Press the OFF TIMER button to select a desired
period of time.
OFF TIMER
AUTO SHUTOFF
You can set the TV to turn off automatically
when no signal is received for about 15 minutes
or longer after the end of a broadcast.
Select AUTO SHUTOFF in INSTALL menu, then
choose ON or OFF.
MENU INSTALL AUTO SHUTOFF
❇
The AUTO SHUTOFF function does not turn off
the TV’s main power.
The AUTO SHUTOFF function is not available in
video mode.
EXT. INPUT (TV/ VIDEO)
You can select TV or video terminal input with
one touch.
Press the TV/VIDEO button to select an input.
To operate this function with a menu:
❇
DISPLAY
You can display the program number, video
terminal number on the screen.
Press the DISPLAY button to display the indication on screen.
To operate this function with a menu:
MENU INPUT DISPLAY
❇
0 120
10
You can set the period of time to a maximum of
120 minutes in 10-minute steps.
To operate this function with a menu:
❇
MENU FEATURES OFF TIMER
When the elapsed of time left one minute,
“GOOD NIGHT!” appears on the screen.
You can display the OFF TIMER menu again to
confirm or change the remaining time.
❇ About the basic operations of the menu,
please see the “How to operate menus
and menus locations” on page 4.
11
Page 12
TV channel presetting
To register the TV channels automatically
You can register the TV channels into the TV’s
channel list automatically.
1 Display the INSTALL menu.
MENU INSTALL
❇
2 Choose AUTO PROGRAM, then press the
MENU/OK button.
3 Press the 5/∞ button to select AIR or
CABLE, then press the MENU/OK button.
AUTO PROGRAM function starts, and the
channels received are registered automatically.
4 “SETUP TOUR RESTART?” appears.
To start the Press the MENU/OK button.
SETUP TOUR Then proceed to step 5 of
“Setting up your TV” on page
7.
To skip the Press the Red button.
SETUP TOUR
5 The CHANNEL SUMMARY menu appears.
For details of “SETUP TOUR”, see page 7.
CHANNEL SUMMARY
You can set undesired channels to be skipped.
Channels set to be skipped cannot be selected by
the CHANNEL M button.
1 Display the INSTALL menu.
MENU INSTALL
❇
2 Choose CHANNEL SUMMARY, then press
the MENU/OK button. CHANNEL SUMMARY menu appears.
■
■
■
■
3 Choose the channel which you want to
skip. The skip can be set to all channels of
AIR (CH02-CH69) and CABLE (CC01CC125).
4 Press the yellow button to skip the
channel. To cancel the skip, press the blue
button.
5 Press the MENU/OK button to exit the
menu.
❇ About the basic operations of the menu,
please see the “How to operate menus
and menus locations” on page 4.
12
Page 13
Additional preparation
The illustrations shown in this section are for AV-20NN15 only, which are used for explanation purposes.
Your TV may not look exactly the same as the illustration.
Before connecting
• Read the manuals provided with the devices
for the proper connection.
• Turn off all the devices including the TV.
• Note that connecting cables are not supplied.
Headphones
Rear of the TV
VIDEO-1
INPUT
Front of the TV
OUTPUT
VIDEO
AUDIO
VIDEO AUDIO
IN (VIDEO-2)
Camcorder or TV game
MENU
OK
VCR (for playing)
DVD player
(Composite signals)
VCR (for recording)
Troubleshooting
If a problem occurs when you are using the TV, check the following troubleshooting guide before
calling for repair.
No picture,
no sound
Snowy picture
Stripes appear
on the picture
Double-pictures
(ghosting) occur
Poor picture
White and bright
still image look as
if it were colored
Top of the image
from software
products or video
tape is distorted
• Deactivate the BLUE BACK function
if it is turned on.
• Check the antenna cable and its
connection with the TV.
• Interference occurs caused by other
devices such as an amplifier,
personal computer, or a hair drier.
Move such devices away from your
TV.
• Interference occurs caused by
signal reflecting from mountains or
building. Try to adjust the antenna
direction or use a better directionality antenna.
• Choose the appropriate color
system. Refer to “COLOR SYSTEM”
on page 8.
• Adjust the COLOR or BRIGHT
setting. Refer to “Adjusting the
picture - USER” on page 8.
• Inevitable phenomenon due to the
nature of the picture tube. This is
not a malfunction.
• This is due to the condition of the
video signal whereby the image
was not recorded properly.
This is not a malfunction.
Cannot operate the
remote control
Cannot operate the
menus
Cannot operate the
front control
buttons
TV turns off
suddenly
Color patches
appear at the
corner of the
screen
Image takes a
short period to be
displayed
TV emits a
crackling sound
Feel a slight
electric shock
when touching the
TV screen
• The batteries may be exhausted.
Replace with new batteries (see
page 6).
• Ensure that you are operating the
remote less than seven meters from
the front of your TV.
• Press TV/VIDEO button to return to
TV mode and try operating the
menus.
• Deactivate the CHILD LOCK
function if it is turned on (see page
11).
• This may due to the AUTO SHUT
OFF function is activated. Press the
POWER button to turn on the TV.
• This may due to a magnetized
device such as a speaker near to
your TV. Keep the device apart
from your TV. Alternately, you can
also use the magnetically shielded
speaker.
• A short periode of time is required
to stabilize the image.
This is not a malfunction.
• This is due to a sudden change in
temperature and it is not a
malfunction. If the crackling sound
is too frequent, request your service
technician for inspection.
• This is due to the static electricity
of the picture tube and it will not
harm the human body. This is not a
malfunction.
13
Page 14
Specifications
TV RF systems
M
Color systems
TV mode: NTSC 3.58 MHz
VIDEO mode: PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz
Receiving channels
VHF low channel (VL), VHF high channel (VH), UHF channel (U)
Receives cable channels in mid band, super band and hyper band.
Power requirements
AC 110 to 240 V, 50/60 Hz
External input / output
VIDEO-1: VIDEO input, AUDIO input
VIDEO-2: VIDEO input, AUDIO input,
OUTPUT: VIDEO output, AUDIO output
Headphone jack: stereo mini jack (3.5 mm diameter,
sound is monaural)
Viewing Screen size (Visible area)
AV-14FN15: 335.4 mm
AV-20NN15: 480.0 mm
Design and specifications are subject to change without notice.
14
Page 15
MEMO
15
Page 16
0105-NIC-JMT© 2005 Victor Company of Japan, Limited
Page 17
INSTRUCTIONS
GGT0071-001A-H
Contents
Knowing your TV’s features ....................................................... 3
Remote control buttons and basic functions .............................. 4
TV buttons and functions ........................................................... 6
Setting up your TV ..................................................................... 7
Basic setting for picture .............................................................. 9
Advanced setting for picture ..................................................... 11
Basic setting for sound ............................................................. 12
Advanced setting for sound ..................................................... 13
Favorite channel and video setting .......................................... 14
Customized setting .................................................................. 15
TV channel presetting .............................................................. 17
Additional preparation .............................................................. 18
Troubleshooting ....................................................................... 19
Specifications ........................................................................... 20
Page 18
7 If you are not going to use this TV for a long period of time, be sure to
disconnect the AC plug from the AC socket.
8 The apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.
WARNING: <AV-21YA15 only>
A REMOVABLE PLASTIC COVER IS FIXED TO THE
TELEVISION’S FRONT AUDIO/VIDEO CONNECTOR. TO
PREVENT THIS COVER FROM BEING ACCIDENTALLY
SWALLOWED BY BABIES OR CHILDREN, REMOVE IT
FROM THE TELEVISION AND STORE IT IN A SAFE
PLACE. IF THE COVER IS SWALLOWED SEEK THE
ADVICE OF A DOCTOR IMMEDIATELY.
Page 19
3
Page 20
Page 21
5
–
–
Top menu 2nd menu Location 3rd menu Location
MENU INPUT EXT. INPUT P.16 – –
DISPLAY P.16 – –
CLOSED CAPTION P.15 – –
PICTURE PICTURE MODE P.9 – –
PICTURE SETTING P.10 – –
WHITE BALANCE P.10 – –
PICTURE – VNR P.15
FEATURES
FAVORITE CH SETTING
P.14
VIDEO SETTING P.14
COLOR SYSTEM P.9
SOUND AI VOLUME P.13 – –
MTS P.13 – –
SOUND MODE P.12 – –
EQUALIZER P.13 – –
BALANCE P.12 – –
SOUND TURBO P.12 – –
CINEMA SURROUND
P.13 – –
FEATURES OFF TIMER P.15 – –
CHILD LOCK P.15 – –
INSTALL AUTO PROGRAM P.17 – –
CHANNEL SUMMARY
P.17 – –
BLUE BACK P.11 – –
AUTO SHUTOFF P.16 – –
EXIT – – – –
*If you want to
adjust PICTURE
SETTING menu,
you must set
PICTURE MODE
menu to USER.
*If you want to
adjust
EQUALIZER
menu, you must
set SOUND
MODE menu to
USER.
Page 22
No. Button/terminal Description Page
1 L (main power) Press to turn on or turn off the TV’s main power. –
2 POWER lamp Indicate the TV is being turned on or off. –
No color: TV’s main power is being turned off.
Red: TV’s main power is being turned on.
Note: When you turn off the power switch while TV is in standby
mode, the light of power lamp will be off in 10 -15 seconds.
3 Remote control sensor –
4 VOLUME -/+ Press to adjust the volume level. –
5 CHANNEL -/+ Press to select the desired channel. –
6 MENU Press to display the menu. –
7 IN (VIDEO-2) Video and audio input jacks for VIDEO-2 mode. 18
8 Headphone jack. 18
9 Aerial socket. 7
! OUTPUT Video and audio output jacks. (The component video
signal cannot be output.) 18
" VIDEO-1 INPUT
Video or S-VIDEO, and audio input jacks for VIDEO-1 mode
7
# TIMER lamp Indicate the OFF TIMER function is being turned on or off. –
No color : The OFF TIMER function is being turned off.
Orange : The OFF TIMER function is being turned on.
How to operate the menus with the TV button
TV button
Work as same as the button on the
Note
remote control unit
MENU MENU/OK button To display main menu and exit
menu after finish setting.
CHANNEL -/+ ∞/5 button To select menu function.
VOLUME -/+ 2/3 button To adjust the desired function.
Page 23
7
2 Connecting the compatible main plug to the AC
outlet.
3 Inserting batteries into the remote control.
Insert two batteries by following the + and polarities and inserting the - end first.
CAUTION:
Follow the cautions printed on the batteries.
Notes:
• Use AA/R6/UM-3 dry cell batteries.
• It the remote control does not work properly, fit new
batteries. The supplied batteries are for testing, not regular use.
4 Turn on the TV by pressing the main
power button.
JVC logo appears on the screen.
The illustration shown is just a sample. It may not be same as your TV.
To RF
output
To video
output
To aerial input
To audio
output
V
L
R
V
L
R
/
MONO
OUTPUT
VIDEO-1
INPUT
Rear of TV
VHF/UHF outdoor aerial
VCR
Page 24
.
SETUP TOUR RESTART?
AUTO PROGRAM
OK
RESTART
■
NO
CHANNEL SUMMARY
BACK ■
■
SKIP
OK
■
CANCEL
CH/CC SKIP
CH02
■
CH03
■
CH04 ■
CH05
■
CH06
CH07
CH08
• To complete the initial
setting, press the
MENU/OK button. To
set undesired
channels to be
skipped, see page 17.
• Press the red button to
cancel the SETUP TOUR
RESTART function.
If you want to make initial
settings again when the
next time you turn on the
TV, press the MENU/OK
button to activate the
SETUP TOUR RESTART
function.
Page 25
9
PICTURE MODE
You can choose the desired picture setting with one-touch.
Press the PICTURE MODE button to select a setting.
SOFT Softens contrast and sharpness.
BRIGHT Heightens contrast and sharpness.
STANDARD Standard picture setting.
USER You can change this picture setting as you like.
Select USER and adjust following items in the
PICTURE SETTING menu. (PICTURE, BRIGHT,
DETAIL, COLOR, TINT*)
*TINT can only be adjusted in NTSC system.
To operate this function with a menu:
To return the USER setting to the default, press the blue button
when the PICTURE SETTING menu appears.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
PICTURE menu
PICTURE MODE
Page 26
WHITE BALANCE
You can change the white balance of the picture to better match
the type of video being viewed.
Select the WHITE BALANCE in the PICTURE menu, then choose
the desired setting.
NORMAL Normal white balance.
COOL Bluish white.
WARM Reddish white.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
PICTURE menu
WHITE BALANCE
❇
Page 27
11
Page 28
BALANCE
You can adjust the volume balance between the left and right
speakers.
Select the BALANCE in SOUND menu, then adjust the setting.
SOUND TURBO
You can enjoy the emphatic low and high frequency levels.
Press the SOUND TURBO to select ON or OFF.
To operate this function with a menu:
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
SOUND menu
BALANCE
❇
MENU SOUND menu
SOUND TURBO
❇
Page 29
13
EQUALIZER
You can adjust the sound level of each frequencies when selecting
USER mode in SOUND MODE.
1 Select the USER in SOUND MODE under SOUND menu.
2 Select the EQUALIZER in SOUND menu.
The following display appears.
3 Select and adjust the desired frequencies.
4 Press the MENU/OK button to exit the menu.
Adjust high frequency will affect higher pitch sound and vice versa.
AI VOLUME
You can adjust the volume of all the channels and video inputs to
the same level automatically.
Select the AI VOLUME in SOUND menu, then choose ON or OFF.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
SOUND menu
SOUND MODE USER
MENU SOUND menu
EQUALIZER
EQUALIZER
IIIIIIIIIIII
IIIIIIIIIIIIIIIII
IIIIIIIIIIIIIIIIIIIIIII
IIIIIIIIIIIIIIIIIIIIIIIII
IIIIIIIIIIII
100 300 1K 3K 8K Hz
BACK ■
OK
.
MENU
SOUND menu
AI VOLUME
❇
❇
❇
Page 30
4 Select the desired item that you wish to adjust.
5 Press the MENU/OK button to exit the menu.
To adjust the video setting (VIDEO SETTING)
You can adjust the picture and sound settings for video inputs.
1 Display the PICTURE menu and select VIDEO SETTING in
PICTURE FEATURES menu.
2 Select VIDEO STATUS in VIDEO SETTING menu, then
choose the desired video input.
3 Select EFFECT, then press 2/3 button
to choose ON.
To cancel the settings, choose OFF.
4 Select the desired item that you wish to adjust.
5 Press the MENU/OK button to exit the menu.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
PICTURE menu
PICTURE FEATURES menu
VIDEO SETTING
VIDEO SETTING
VIDEO STATUS
PICTURE BRIGHT DETAIL COLOR
SOUND MODE (USER, DYNAMIC, MUSIC, NEWS)
TINT
❇
❇
PICTURE BRIGHT DETAIL COLOR
SOUND MODE (USER, DYNAMIC, MUSIC, NEWS)
TINT
■
CH02
VIDEO SETTING
BACK ■
■
RESET
OK
VIDEO STATUS VIDEO-1
BRIGHT
DETAIL
COLOR
TINT
SOUND MODE USER
EFFECT ON
Page 31
15
CHILD LOCK
You can disable the front control buttons of the TV.
Select the CHILD LOCK in the FEATURES menu, then choose
ON or OFF.
OFF TIMER
You can set the TV to turn off automatically to standby mode after
a set time.
Press the OFF TIMER button to select a desired period of time.
You can set the period of time
to a maximum of 120 minutes
in 10 minutes step.
To operate this function with a menu:
When the elapsed of time left one minute, “GOOD NIGHT!”
appears on the screen.
You can display the OFF TIMER menu again to confirm or
change the remaining time.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
MENU
FEATURES menu
CHILD LOCK
OFF TIMER
0 120
10
BACK ■
OK
.
MENU
FEATURES menu
OFF TIMER
❇
❇
Page 32
MENU
INPUT menu
EXT. INPUT
MENU
INPUT menu
DISPLAY
❇
❇
EXT. INPUT (TV/VIDEO)
You can select TV or video terminal input with one touch.
Press the TV/VIDEO button to select an input.
To operate this function with a menu:
DISPLAY
You can display the program number and video terminal number
on the screen.
Press the DISPLAY button to display the indication on the screen.
To operate this function with a menu:
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
Page 33
17
2 Choose CHANNEL SUMMARY, then press the MENU/OK
button.
CHANNEL SUMMARY menu appears.
3 Choose the channel which you want to skip.
The skip can be set to all channels of AIR (CH02-CH69) and
CABLE (CC01-CC125).
4 Press the yellow button to skip the channel.
To cancel the skip, press the blue button.
5 Press the MENU/OK button to exit the menu.
❇ About the basic operations of the menu, please see the “How
to operate menus and menus locations” on page 5.
CHANNEL SUMMARY
BACK ■ ■
SKIP
OK
■
CANCEL
CH/CC SKIP
CH02
■
CH03
■
CH04
■
CH05
■
CH06
CH07
CH08
.
.
Page 34
Connecting to rear component/video input
terminal and output terminal
Rear of TV
VCR (for playing)
DVD player (composite signals)
VCR (for recording)
AV-14FT15
V
L
R
V
L
R
/
MONO
OUTPUT
VIDEO-1
INPUT
.
V
L
R
V
L
R
/
MONO
OUTPUT
VIDEO-1
INPUT
/
Rear of TV
AV-21YA15
VCR (for playing)
DVD player (composite signals)
VCR (for recording)
Page 35
19
• The batteries may be exhausted. Replace with
new batteries (see page 7).
• Ensure that you are operating the remote less
than seven meters from the front of your TV.
• Press TV/VIDEO button to return to TV mode and
try operating the menus.
• Deactivate the CHILD LOCK function if it is turned
on (see page 15).
• This may due to the AUTO SHUTOFF function is
activated. Press the POWER button to turn on the
TV.
• This may due to the magnetized device such as a
speaker near to your TV. Keep the device apart
from your TV. Alternately, you can also use the
magnetic-shielded speaker.
• Image required time to stabilize before display.
This is not a malfunction.
• This is due to a sudden change in temperature
and it is not a malfunction. If the crackling sound
is too frequent, request your service technician for
inspection.
• This is due to the static electricity of the picture
tube and it will not harm the human body. This is
not a malfunction.
• Cannot operate the
remote control
• Cannot operate the
menus
• Cannot operate the
front control buttons
• TV is turned off
suddenly
• Color patches
appear at the corner
of the screen
• Image takes a short
period to be
displayed
• TV may emitted
crackling sound
• Feel a slight electric
shock when
touching the TV
screen
Page 36
0105-FLE-JMT
Loading...
