DVD VIDEO RECORDER

DR-M10

DVDTV

STANDBY/ON

TV/

DVD

MUTING

VIDEO

TV VOLUME

ABC

DEF

JKLGHI MNO

TUVPQRS WXYZ

DBS

AUXCANCEL

MEMO/MARK

TIMER

REC LINK

PROG/CHECK

G-CODE

SHOW VIEW

NAVIGATIONTOP MENU

ENTER

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

CLEAR

PAUSEREC

STOP/

REC MODE LIVE CHECK

OPEN/

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

STANDBY/ON

Region number of DVD VIDEO

DVD units and DVD VIDEO discs have their own region numbers. This unit can play back DVD VIDEO discs whose region numbers include the unit’s region number, which is indicated on the region number symbol on the rear panel.

S-VIDEO VIDEO

REC LINK

L(MONO)-AUDIO-R

REC MODE

PULL - OPEN

DV IN

INSTRUCTIONS

LPT0963-001A

2 EN

SAFETY FIRST

Safety Precautions

The rating plate and the safety caution are on the rear of the unit.

WARNING: DANGEROUS VOLTAGE INSIDE WARNING: TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION

A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.

WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CAUTION

8 When you are not using the unit for a long period

of time, it is recommended that you disconnect the power cord from the mains outlet.

8 Dangerous voltage inside. Refer internal servicing

to qualified service personnel. To prevent electric shock or fire hazard, remove the power cord from the mains outlet prior to connecting or disconnecting any signal lead or aerial.

IMPORTANT:

8 Please read the various precautions on pages 2 and

3 before installing or operating the unit.

8 It should be noted that it may be unlawful to

re-record pre-recorded tapes, DVDs, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable programme and in any literary, dramatic, musical, or artistic work embodied therein.

CLASS 1 LASER PRODUCT REPRODUCTION OF LABELS

WARNING LABEL INSIDE OF THE UNIT

● Manufactured under licence from Dolby Laboratories. “Dolby” and double-D symbol are trademarks of Dolby Laboratories.

● “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

● G-

CODE is a trademark of Gemstar Development Corporation and is registered in the following countries: Australia, China, Hong

Kong, Japan, South Korea, New Zealand, and Taiwan. S registered in the following countries: Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Hungary, Iceland, Italy, Luxembourg, Netherlands, Norway, Poland, Portugal, Russia, Slovakia, South Africa, Spain, Sweden and Switzerland. The G-

CODE/SHOWVIEW system is manufactured under license from Gemstar Development Corporation.

G-

CODE and SHOWVIEW are different trademarks used to represent the same easy recording feature. However, for simplicity, only the

term G-

● This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other

CODE will be used in the instructions. If you use SHOWVIEW system, follow the same steps listed for the G-CODE system.

intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

HOWVIEW is a trademark of Gemstar Development Corporation and is

EN 3

POWER SYSTEM: (DR-M10SAG/SAX only*)

This unit operates on voltage of AC110 – 240 Vd (Rating), AC90 – 260 Vd (Operating), 50/60 Hz with automatic switching.

* The model number depends on the country where you live.

Check the label on the rear of the unit.

The STANDBY/ON 1 button does not completely shut off mains power from the unit, but switches operating current on and off. “`” shows electrical power standby and “

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

Failure to heed the following precautions may result in damage to the unit, remote control or disc.

1. DO NOT

— in an environment prone to extreme temperatures or humidity. — in direct sunlight. — in a dusty environment. — in an environment where strong magnetic fields are generated. — on a surface that is unstable or subject to vibration.

2. DO NOT holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3. DO NOT control.

4. DO NOT the unit or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

5. DO NOT expose the apparatus to dripping or splashing.

6. DO NOT

with water. Also DO NOT place any containers filled

with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

7. DO NOT lighted candles, on the apparatus.

8. AVOID

place the unit —

block the unit’s ventilation openings or

place heavy objects on the unit or remote

place anything which might spill on top of

use this equipment in a bathroom or places

place any naked flame sources, such as

violent shocks to the unit during transport.

!” shows ON.

MOISTURE CONDENSATION

Moisture in the air will condense on the unit when you move it from a cold place to a warm place, or under extremely humid conditions—just as water droplets form on the surface of a glass filled with cold liquid. In conditions where condensation may occur, disconnect the unit’s power plug from the wall and keep it disconnected for a few hours to let the moisture dry, then turn on the unit.

TTENTION:

To mobile phone users:

Using a mobile phone in the vicinity of the unit may cause picture vibration on the TV screen or change the screen to a blue back display.

On placing the unit:

Some TVs or other appliances generate strong magnetic fields. Do not place such appliances on top of the unit as it may cause picture disturbance.

4 EN

CONTENTS

SAFETY FIRST 2

Safety Precautions ............................................... 2

DISC INFORMATION 5

About Discs ......................................................... 5

INDEX 10

INSTALLING YOUR NEW UNIT 16

Basic Connections ............................................. 16

S-VIDEO Connection ........................................ 17

Component Video Connection .......................... 18

INITIAL SETTINGS 19

Auto Set Up ....................................................... 19

Monitor Set ....................................................... 21

Language ........................................................... 22

PLAYBACK OPERATIONS 25

Basic Playback .................................................. 25

Playback Features .............................................. 26

Live Memory Playback ...................................... 31

Using Play Set Up Menu ................................... 36

Parental Lock .................................................... 43

RECORDING 47

Basic Recording ................................................ 47

Recording Features ............................................ 48

TIMER RECORDING 51

G-CODETM/SHOWVIEW G-

Manual Timer Programming .............................. 54

On-Disc Timer Programming ............................ 56

Automatic Satellite Programme Recording ......... 61

CODE

/SHOWVIEWTM Timer Programming ... 52

System Setup .............. 51

EDITING 76

DV Dubbing ......................................................76

Edit From A Camcorder ..................................... 78

Edit To Or From Another Recorder .................... 79

Output/Input Set ................................................ 80

Digital Audio Dubbing ...................................... 82

REMOTE CONTROL 83

Remote Control Functions ................................. 83

SYSTEM CONNECTIONS 85

Connecting To A Satellite Receiver ....................85

Connecting To A Dolby Digital Decoder Or An

Amplifier With Built-in DTS ............................ 86

SUBSIDIARY SETTINGS 87

Mode Set ........................................................... 87

Tuner Set ........................................................... 92

Clock Set ........................................................... 96

Format A Disc ...................................................97

Finalise A Disc ..................................................98

Scan Mode Set ................................................... 99

Tray Lock ..........................................................99

TROUBLESHOOTING 100

GLOSSARY 104

SPECIFICATIONS 105

LIST OF TERMS 106

NAVIGATION 62

Library Database DVD Navi .............................. 62

Modify Original Information .............................. 65

Modify Play List Information .............................. 68

Modify Library Information ................................ 72

Playback with MP3/JPEG Navigation ................. 74

DISC INFORMATION

About Discs

Recordable/playable discs

You can use discs with the following logos for recording and playback.

DVD-RA M 12 cm: 4.7 GB/9.4 GB

8 cm: 1.4 GB/2.8 GB (VR mode) Version 2.0 Version 2.1

DVD-R 12 cm: 4.7 GB

8 cm: 1.4 GB General Version 2.0

(Video mode)

DVD-RW 12 cm: 4.7 GB

Version 1.0 (VR mode) Version 1.1 (Video mode /VR mode)

● The above table is based on the information as of February

2004.

● Recording and playback may not be performed with some

DVD-RAM, DVD-R/-RW, and CD-R/-RW discs depending on the characteristics and condition of the disc used, leading to unsatisfactory results. Using discs manufactured by JVC is recommended since they have been tested to be compatible with this unit.

DVD-RAM Discs

It is only possible to use discs which conform with DVD-RAM standard Version 2.0 or 2.1.

● It is impossible to record on DVD-RAM discs which do not

conform to this standard. If you use a disc formatted under a different standard version, format it on this unit before use.

● It may not be possible to record, play back, edit or dub a

DVD-RAM disc even if it conforms to the standard if it was recorded or edited on the devices from other manufacturers or on a PC, or if it has far too many titles, or if there is very little available capacity remaining on the disc.

● Some DVD-RAM discs are contained in a cartridge. This unit

cannot handle this type of disc. Remove the disc from the cartridge (only discs with a removable cartridge); or the use of DVD-RAM discs not contained in a cartridge is recommended.

● DVD-RAM discs recorded on this unit cannot be played back

on an incompatible DVD player.

● It is possible to record copy-once programmes of digital

broadcasts only onto 4.7/9.4 GB DVD-RAM discs (2.8 GB DVD-RAM discs are not compatible).

EN 5

DVD-R/RW Discs

It is only possible to use DVD-R discs which conform with DVD-R standard Version 2.0. This unit is not in compliance with DVD-RW Version 1.2. When a DVD-R/RW disc (Video mode) is finalised ( can be played back on a standard DVD player as a DVD VIDEO disc. When a DVD-RW disc (VR mode) is finalised ( be played back on a standard DVD player compatible with the VR mode of DVD-RW discs.

Before finalising (

— it is possible to record on unrecorded areas of the disc, edit the disc title and programme titles, and delete programmes.

● Before finalising, it is possible to play or record DVD-R/RW (Video mode) discs only on this unit.

● It is impossible to overwrite recorded areas of DVD-R discs.

● Available recording capacity does not increase even if a

recorded programme is deleted from a DVD-R disc.

After finalising (

After a DVD-R/RW disc (Video mode) has been finalised, it is possible to play back the recorded programmes (video and/or audio) on a standard DVD video player as a DVD VIDEO disc.

● Edited titles are displayed as the “DVD menu” in video mode.

● It is impossible to record, edit or delete the data either in video

mode or in VR mode.

● Either in video mode or in VR mode, although the disc can be played back on DVD players from other manufacturers, sometimes it may not be possible to play depending on the disc and recording conditions.

● It is impossible to record on CD-R/RW or DVD-R discs used for authoring.

● It is impossible to record onto DVD-R/RW (Video mode) discs broadcasts that allow you to copy once. The copy once programmes can only be recorded onto DVD-RW discs formatted in VR mode.

墌 pg. 98) —

墌 pg. 98), it

墌 pg. 98), it can

NOTE:

The following may result if you play back a DVD-R disc recorded on another unit.

● The disc does not play.

● A mosaic pattern (block noise) appears on the screen.

● Video or audio may be dropped out.

● The unit stops during playback.

6 EN

DISC INFORMATION (cont.)

Discs for Playback Only

You can use discs with the following logos for playback only.

DVD VIDEO

(example of region code indications)

Audio CD

CD-DA files

CD-RW

CD-DA/ JPEG/MP3 files

● Playback may not be performed depending on the characteristics and condition of the disc used.

● DTS Audio CDs can also be played back (An optional DTS decoder is required).

● MP3 and JPEG discs can be played back on this unit only when they have been recorded in the ISO9660 or Joliet format and finalised.

● JPEG files that can be played back on this unit must conform to JFIF/Baseline process, and the maximum resolution of a JPEG file is 3,840 x 2,160 pixels.

● CD-R/RW discs recorded in music CD format need to be finalised to play on this unit.

● Operation and audio quality of this unit are not guaranteed for discs that do not conform to the Compact Disc specification (CD-DA). Before you play back a CD, check for the CD logo and read the notes on the package to confirm that it conforms to the Compact Disc specification.

● Depending on the intentions of the author of the software, recording conditions of DVD discs and Video CD/SVCD discs may be restricted. Since this unit plays back discs according to the intentions of the author of the software as indicated on the disc, some functions may not operate as commanded.

● When switching from the first layer to the second layer of double-layered DVD VIDEO discs, the image and sound may be momentarily distorted. This is not a malfunction.

● DVD-AUDIO discs compatible with DVD video players can be played.

● Super Audio CDs (SACD) compatible with conventional CD players can be played.

Video CD/Super Video CD

CD-R

CD-DA/ JPEG/MP3 files

CD-ROM

JPEG/MP3 files

Unplayable Discs

The following types of discs cannot be played using this unit. Do not attempt to play back any kind of disc that is damaged (cracked, warped, or repaired with adhesive tape) or discs in unusual shapes (heart-shaped, octagonal, or other forms). If such discs are accidentally played back, it may cause noise that can lead to speaker damage.

● CD-ROM discs (including PHOTO-CD and CD-G)

● Discs recorded in Packet Write (UDF) format.

● 1.3-GB double density CDs (DDCD)

● High density CDs (HDCD)

The following discs also cannot be played back.

● Discs whose region numbers do not include the unit’s region number, which is indicated on the region number symbol on the rear pannel.

● DVD-RAM (2.6 GB/5.2 GB)

Marks of discs in this instruction manual

Allows operation with a DVD-RAM disc.

Allows operation with a DVD-R disc.

Allows operation with a DVD-RW disc.

Allows operation with a DVD VIDEO disc.

Allows operation with a Video CD/ Super Video CD (SVCD) disc.

Allows operation with an Audio CD disc.

Allows operation with a disc including MP3 files.

Allows operation with a disc including JPEG files.

EN 7

Recording Medium and Format

DVD-RAM

● Recording and erasing can be performed as many times as possible on a disc.

● Editing can be performed after recording, such as deleting unwanted parts.

● While recording, it is possible not only to start playback of a programme currently being recorded, but also to watch another programme previously recorded.

DVD-RW (VR mode)

● Recording and erasing can be performed as many times as possible on a disc.

● Editing can be performed after recording, such as deleting unwanted parts.

DVD-RW (Video mode)

● Can be played back on other DVD players.

● New recording can be performed by erasing all the data on a

disc once played back.

DVD-R

● Can be played back on other DVD players.

● Suitable when keeping a recorded disc for a long time.

File Structure of Discs

DVD VIDEO

Typically, DVD VIDEO discs are made up of larger units called “titles”. Each title has a number (title number) that can be used to select desired titles. Titles are further divided into units called “chapters”. Each chapter has a number (chapter number) that can also be used to select desired chapters. Note that some discs are not divided into titles and chapters.

When you record a programme on a DVD-RAM/RW (VR mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes from monaural or bilingual to stereo due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during playback. (

When you record a programme on a DVD-R/RW (Video mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during either recording or playback. Once the disc has been finalised, these chapter marks are deleted and new chapter marks are assigned automatically approximately every 5 minutes.

墌 pg. 28)

DVD-RAM, DVD-RW, DVD-R or DVD VIDEO disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2 Chapter 3

● In Video mode, even before finalising, it is impossible to perform editing operations other than changing the disc name and/or title names and deleting programmes and/or titles.

● After finalising, it is impossible to perform editing operations.

Audio CD/Video CD/SVCD

Typically, Audio CD discs are divided into separate tracks each containing one song. Each track is assigned a number. For example, the third track is Track 3. The same is true for Video CD/SVCD discs. However, some discs are not divided into tracks.

Audio CD or Video CD/SVCD

Track 1 Track 2 Track 3 Track 4

8 EN

JPEG/MP3 Disc (CD-R/RW/ROM)

MP3/JPEG files put in directories nested in several levels on a disc will be organized as if they were put in single level directories (groups) by the MP3/JPEG Navigation of this unit. (

墌 pg. 74)

File structure of a disc before starting the MP3/JPEG Navigation

File structure of the disc after started ib(JT*0 Tc:2_293.[2(iale 82(i6 82i( n)-g the M0 0 9.96 igatInfo.fm])(gati24)]TJ-1221n)-i)2nce of203895c beforyeFe

DISC INFORMATION (cont.)

EN 9

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

OPEN/

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

Placing a Disc

Opening the disc tray

Press x on the unit or remote control to open the disc tray.

REC MODE

REC LINK

S-VIDEO VIDEO

L(MONO)-AUDIO-R

Unit Remote control

● Pressing the button on the unit or on the remote control again closes the disc tray.

● Use the buttons on the unit or on the remote control to open and close the disc tray.

● Do not block the disc tray with your hand while it is opening or closing as this may result in hardware failure.

● Do not place unplayable discs or any object other than a disc on the disc tray.

● Do not press down strongly on the disc tray or place any heavy objects on it.

Discs without cartridges

PULL - OPEN

DV IN

Care and Handling of Discs

How to handle discs

When handling a disc, do not touch the surface of the disc. Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the unit to malfunction.

Label side

Do not damage the label side, stick paper to or use any adhesives on its surface.

Recording side

Make sure that discs are not scratched and dirty on the recording side before use. Scratches and dirt on the recording side of a disc may hinder proper playback and recording. Also be careful that a DVD-RAM disc may get scratched or dirt when removed from cartridge then put back in after use.

Storage

Make sure that discs are kept in their cases. If discs are piled on top of one another without their protective cases, they can be damaged. Do not put discs in a location where they may be exposed to direct sunlight, or in a place where the humidity or temperature is high. Avoid leaving discs in your car!

E D O

C E R

PULL - OPEN

Y/ON DB N

TA S

Disc tray

Place the disc on the disc tray with the label side facing up. Since disc size changes depending on the disc to be played back, be sure to correctly align the disc with the grooves for its size. If the disc is not in its groove, it may be scratched or otherwise damaged. To insert an 8 cm disc, place it according to the inner groove.

DVD-RAM discs contained in cartridges

Double-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the side you wish to play back or record facing down. If you insert the disc with “Side A” facing down, programmes are recorded on the side A.

Single-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the label side facing up.

Maintenance of discs

If there are fingerprints or other dirt adhering to a disc, wipe with a soft dry cloth, moving from the centre outwards. If a disc is difficult to clean, wipe with a cloth moistened with water. Never use record cleaners, petrol, alcohol or any anti-static agents.

CAUTION

Sometimes during playback, noise may appear or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the unit.

10 EN

FRONT VIEW

INDEX

C D FE G H I JBA

STANDBY/ON

A Infrared Beam Receiving Window B Front Display Panel 墌 pg. 12 C Disc Tray D Open/Close Button (x) 墌 pg. 9 E Automatic Satellite Programme Recording Button

(REC LINK) 墌 pg. 61

F Stop Button (8) 墌 pg. 25, 47 G Play Button (4) 墌 pg. 25 H Pause Button (9) 墌 pg. 25

REC MODE

DV IN

S-VIDEO VIDEO

REC LINK

L(MONO)-AUDIO-R

L M

I Recording Mode Button (REC MODE) 墌 pg. 47 J Record Button (7) 墌 pg. 47 K Standby/On Button (1 (STANDBY/ON))

墌 pg. 19

L S-video/Video/Audio Input Connectors

(S-VIDEO/VIDEO/AUDIO (L/R)) 墌 pg. 78

M DV Input connector (DV IN (i*)) 墌 pg. 76

* i.Link refers to the IEEE1394-1995 industry specification and

extensions thereof. The i logo is used for products compliant with the i.Link standard.

PULL - OPEN

DV IN

O-R

To access covered connectors, pull and open the connector cover.

REAR VIEW

EN 11

A Antenna Input Connector (ANTENNA IN)

墌 pg. 16

B Component Video Output Connectors

(COMPONENT VIDEO OUT )墌 pg. 18

C S-video Output Connector (S-VIDEO OUT)

墌 pg. 17

D Audio Output Connectors

(AUDIO OUT (RIGHT/LEFT)) 墌 pg. 17

E Digital Audio Output Connectors

(DIGITAL OUT (COAXIAL/OPTICAL)) 墌 pg. 82, 86

F Cooling Fan

● This prevents the temperature from rising inside the unit. Do not remove it.

● Install the unit so as not to block the area around the fan.

● The cooling fan on the rear of the unit may be activated even if the

unit is turned off in the following cases; — In the Automatic Satellite Programme Recording standby mode

(墌 pg. 61)

G Mains Power Cord 墌 pg. 16 H Antenna Output Connector (ANTENNA OUT)

墌 pg. 16

I L-1 Input/Output Connector (L-1 IN/OUT)*

墌 pg. 16, 79, 80, 85

* This connector can not be used as input connector when using the

provided output cable adapter.

J L-2 Input Connector (L-2 IN) 墌 pg. 79, 85 K Region Number Label 墌 pg. 1

12 EN

FRONT DISPLAY PANEL

INDEX (cont.)

A Disc Type/Status Indicator

When a disc is loaded, the type of the disc is indicated.

When a disc is running, the disc marks rotate. During High-Speed Search: Rotate faster than normal

During Slow Motion: Rotate slower than normal

While recording: Inner red ring lights in the same

While paused: Disc marks blink when either

While stopped: Disc marks all light. While resume stopped: Disc marks all blink. While the disc tray opened: Disc marks all light out. No disc on the disc tray: Disc marks all light out.

playback.

way as normal playback. During Instant Timer Recording (ITR), inner red ring slowly blinks.

recording or playing back.

B VR Mode Indicator 墌 pg. 97

Lights when a DVD-RW disc is formatted in VR mode.

C Timer Recording Indicator 墌 pg. 52, 54, 56, 59

: Lights when a disc set up for On-Disc Timer

: Lights when timer recording other than On-Disc

Programming is loaded.

Timer Programming is on stand-by or being executed.

: Lights when On-Disc Timer Programming is on

stand-by or being executed.

: Blinks quickly if you press # (TIMER) in the

following cases;

● Disc is not loaded.

● Clock has not been set.

● There is no programme setting.

D Recording Mode Indicator (XP/SP/LP/EP/FR)

墌 pg. 48

Blinks when recording mode is being set. While “FR” is blinking, the left 3 digits of the Multi Display (L M) indicate setting values ranging from “60” to “480”. After the value has been set, only “FR” lights.

E Group/Title Indicator (GRP/TITLE) 墌 pg. 7, 39

“GRP” or “TITLE” lights depending on a disc loaded while the left 2 digits of the Multi Display (L) indicate the numbers explained below. “GRP”: Total number of groups or group number being

played back are displayed on the Multi Display.

“TITLE”: Total number of titles or title number being played

back are displayed on the Multi Display.

F Track/Chapter Indicator (TRK/CHAP) 墌 pg. 7, 39

“TRK” or “CHAP” lights depending on a disc loaded while the 3rd and 4th digits from the left of the Multi Display (M) indicate the numbers explained below. “TRK”: Total number of tracks or track number being

played back are displayed on the Multi Display.

“CHAP”: Chapter number being played back are displayed

on the Multi Display.

EN 13

G Simulated Surround Effect Indicator (3D)

墌 pg. 40

Lights when a simulated surround effect is set to “3D-ON” in Play Set Up menu.

H Linear PCM Indicator (LPCM)

Lights when “XP MODE REC AUDIO” is set to “LINEAR PCM” (墌 pg. 89) for recording with DVD-RAM, DVD-R and DVD-RW discs, and when Linear PCM audio is played.

I Random/Programme Playback Mode Indicator

(RND/PRGM) 墌 pg. 42

“RND”: Lights when Random Playback mode is set.

(墌 pg. 42)

“PRGM”: Lights when Programme Playback mode is set.

(墌 pg. 42)

J Repeat Mode Indicator ( /1/A–B) 墌 pg. 38, 39

Select Repeat Playback mode in Play Set Up menu. “ ”: Whole disc is played back repeatedly. “ 1”: A single title/chapter/track is played back

repeatedly.

“ A–B”: The selected part (A–B) is played back

repeatedly.

No display: Repeat Playback mode is off.

K Video Output Indicator ( ) 墌 pg. 99

No display: Indicates that interlace mode is engaged.

: Indicates that progressive mode is engaged. (Example) lights when video output mode is in progressive mode.

L Group/Title Number Display 墌 pg. 7, 39 M Track/Chapter Number Display 墌 pg. 7, 39 N Remaining Time/Elapsed Time Indicator

墌 pg. 28, 50

Lights when remaining time of DVD-RAM, DVD-R and DVD-RW discs is displayed, and lights out when elapsed time is displayed. The right 6 digits of the Multi Display (O) indicate elapsed or remaining time of each track. No display: Indicates elapsed time of the disc. Displayed: Indicates remaining time of the disc.

O Remaining Time/Elapsed Time Display

墌 pg. 28, 50

P Multi Display

Displays clock, received channel, elapsed time, and remaining time. Also displays status of the unit (NO DISC/OPEN/CLOSE/ READING).

14 EN

INDEX (cont.)

ON-SCREEN DISPLAY

When “SUPERIMPOSE” is set to “AUTO” and ON SCREEN on the remote control is pressed, various operational indicators appear on the TV screen. To clear the operational indicators, press ON SCREEN again.

A Disc Display

Displays the type of the disc loaded on the disc tray.

B Title Number*

Displays number of the title currently being played back.

C Playback Operation Status Indicator*

Indicates playback operation status by pictographs.

D Playback Time*

Displays playback time of the title currently being played back.

E Recording Mode

Displays recording mode as XP, SP, LP, EP, FR, FR60–FR360, FR420 and FR480. Current recording mode is displayed during recording, and recording mode in which the programme was recorded is displayed during playback. The recording mode is not displayed during play list playback.

F Title Number

Displays playback title number during playback, and recording title number during recording.

* During Live Memory playback, playback operation status is

displayed. During normal playback, the multichannel encoding method is displayed.

G Chapter Number

Displays playback chapter number during playback, and recording chapter number during recording.

H Clock Display I Bar Meter Display 墌 pg. 33

Displays playback point and other information in bar meter.

J Title Name Display

Displays title name newly registered to the title recorded on DVD-RAM/RW/R discs, or file name of JPEG and MP3 files.

K Operation Status Indicator

Indicates operation status by pictographs. (Also indicates its speed for forward high-speed search, reverse high-speed search and slow motion.)

L Time Display

Displays single title playback elapsed time, single track playback elapsed time, single track remaining time, total elapsed time, total remaining time, and other information in turn.

M Station Name Display

Displays currently selected station name.

N Audio Display

Displays audio that is being input.

O Input Display

Displays currently selected input.

EN 15

REMOTE CONTROL

TV/

MUTING

VIDEO

A B

D E

F G H I

K L M

N O P Q

R S

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

PROG/CHECK

G-CODE

SHOW VIEW

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

DEF

MEMO/MARK

REC LINK

ENTER

CLEAR

ON SCREEN

DVDTV

STANDBY/ON

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

U V

X Y Z

a b

c d

f g h i

j k l m

o p

L Reverse Search Button (3) 墌 pg. 27, 34

Reverse Slow Button (SLOW –) 墌 pg. 27

M Record Button (7) 墌 pg. 47 N Recording Mode Button (REC MODE) 墌 pg. 47 O Live Check Button (LIVE CHECK) 墌 pg. 34 P Set Up Button (SET UP) 墌 pg. 21 Q Display Button (DISPLAY)

墌 pg. 28, 49

R Audio Button (AUDIO) 墌 pg. 29 S Subtitle Button (SUBTITLE) 墌 pg. 29 T TV/DVD switch 墌 pg. 19 U DVD STANDBY/ON Button (DVD 1) 墌 pg. 19 V TV STANDBY/ON Button (TV 1) 墌 pg. 84 W TV Volume Button (TV VOLUME +/–) 墌 pg. 84 X Channel Button (CH +/–) 墌 pg. 47 Y Memo Button (MEMO) 墌 pg. 64, 71, 75

Mark Button (MARK) 墌 pg. 28

Z Automatic Satellite Programme Recording Button

(REC LINK) 墌 pg. 61

a Timer Button (# (TIMER)) 墌 pg. 53, 55 b Navigation Button (NAVIGATION) 墌 pg. 62 c we Button 墌 pg. 21, 34 d Enter Button (ENTER) 墌 pg. 19 e Return Button (RETURN) 墌 pg. 30, 52 f Forward Skip Button (6) 墌 pg. 26, 34

Next Button (NEXT) 墌 pg. 30

g Forward Search Button (5) 墌 pg. 27, 34

Forward Slow Button (SLOW +) 墌 pg. 27

h Play Button (4) 墌 pg. 25

Select Button (SELECT)

i Pause Button (9) 墌 pg. 25, 34 j Stop Button (8) 墌 pg. 25, 34, 47, 76

Clear Button (CLEAR) 墌 pg. 27, 35, 42, 52

k Skip Search Button ( ) 墌 pg. 27, 34 l Open/Close Button (x) 墌 pg. 9 m One Touch Replay Button ( ) 墌 pg. 34, 35 n On-screen Button (ON SCREEN)墌 pg. 14, 33,

o Progressive Scan Button (PROGRESSIVE SCAN)

墌 pg. 99

p Angle Button (ANGLE) 墌 pg. 29

Buttons with a small dot on the left side of the name can also be used to operate your TV. (墌 pg. 84)

A TV Muting Button (TV MUTING) 墌 pg. 84 B TV/VIDEO Button 墌 pg. 49 C Number Keys 墌 pg. 26, 43, 47, 52, 66, 83, 93

Character Keys 墌 pg. 66

D Auxiliary Button (AUX) E Cancel Button (&)

墌 pg. 39, 42, 52, 59, 75, 94

F Programme Check Button (PROG/CHECK)

墌 pg. 59

G G-CODE/SHOWVIEW Button 墌 pg. 52 H Top Menu Button (TOP MENU) 墌 pg. 26 I rt Button 墌 pg. 19 J Menu Button (MENU) 墌 pg. 26 K Reverse Skip Button (2) 墌 pg. 26, 34

Previous Button (PREVIOUS) 墌 pg. 30

How To Use

The remote control can operate most of your unit’s functions, as well as basic functions of TV sets of JVC and other brands. (墌 pg. 83, “Remote Control Functions”)

● Point the remote control toward the receiving window.

● The maximum operating distance of the remote control is

about 8 m.

NOTES:

● When inserting the batteries, be sure to insert in the correct directions as indicated under the battery cover.

● If the remote control doesn’t work properly, remove its batteries, wait for approximately 5 minutes, replace the batteries and then try operating the unit again.

16 EN

INSTALLING YOUR NEW UNIT

It’s essential that your unit be properly connected.

Basic Connections

TV aerial cable

ANTENNA IN

L-1 IN/OUT

Mains power cord

Back of unit

Mains outlet

Output Cable Adapter (provided)

THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO OPERATION CAN BE PERFORMED.

Check the contents.

Make sure the package contains all of the accessories listed in “SPECIFICATIONS” on page 105.

Install the unit.

Place the unit on a stable, horizontal surface.

Connect the unit to a TV.

A Disconnect the TV aerial cable from the TV. B Connect the TV aerial cable to the ANTENNA IN

connector on the rear panel of the unit.

C Connect the ANTENNA OUT connector on the rear

panel of the unit and the TV’s aerial connector with the provided RF cable.

D Connect the L-1 IN/OUT connector on the rear panel

of the unit and the TV’s audio/video input connectors with an audio video cable via a cable adapter.

● When you connect to the unit using the provided cable adapter, be sure to set “L-1 OUTPUT” to “SCART VIDEO”. (墌 pg. 80) If “L-1 OUTPUT” is set to “SCART S-VIDEO” or “SCART RGB”, the image may be distorted.

● For switching the TV’s mode, refer to the instruction manual of your TV.

Audio/Video cable

(provided)

ANTENNA OUT

Back of TV

RF cable (provided)

AUDIO/VIDEO input connectors

Aerial

connector

TTENTION:

An input cable adapter and output cable adapter are provided as accessories. Use these cable adapters when connecting the unit to the TV.

● When you connect L-1 IN/OUT connector to other devices, connect the provided output cable adapter to L-1 IN/OUT connector.

● When you connect L-2 IN connector to other devices, connect the provided input cable adapter to L-2 IN connector.

Connect the unit to mains.

Connect the AC plug of the mains power cord into a mains outlet.

● “LOADING” blinks on the front display panel when the AC plug of the mains power cord is connected into a mains outlet, and it takes the unit approximately 50 seconds to be turned on. This is not a malfunction.

Use the conversion plug (provided) depending on the type of your AC WALL outlet.

After connection is completed, perform “Auto Set Up” on page 19.

S-VIDEO Connection

EN 17

8 To connect to TV’s S-VIDEO input and AUDIO input

connectors

Connect the unit to a TV.

A Connect the aerial, unit and TV as per “Basic

Connections”. (墌 pg. 16)

B Connect the unit’s S-VIDEO OUT connector to the

TV’s S-VIDEO input connector.

C Connect the unit’s AUDIO OUT connectors to the

TV’s AUDIO input connectors.

TV aerial cable

ANTENNA IN

S-VIDEO OUT

AUDIO OUT

ANTENNA OUT

S-VIDEO input

connector

Mains power cord

Back of unit

Mains outlet

Audio cable (not provided)

S-Video cable (not provided)

Aerial

connector

Connect the unit to mains.

Connect the AC plug of the mains power cord into a mains outlet.

NOTES:

● You can obtain high-quality S-VHS pictures.

● If your TV is not stereo-capable, use the unit’s AUDIO OUT

connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

● For switching the TV’s video input mode, refer to the instruction manual of your television.

After the connection is completed, perform “Auto Set Up” on page 19.

Back of TV

RF cable (provided)

AUDIO input connectors

18 EN

Component Video Connection

INSTALLING YOUR NEW UNIT (cont.)

Component video connection enables you to obtain high-quality component video pictures.

8 To connect to TV’s component video input connectors

Connect the unit to TV.

A Perform A – C in step C in “Basic Connections”

(墌 pg. 16).

B Connect the unit’s COMPONENT VIDEO OUT

connectors to the TV’s component video input connectors.

C Connect the unit’s AUDIO OUT connectors to the

TV’s AUDIO input connectors.

Connect the unit to mains.

Connect the AC plug of the mains power cord into a mains outlet.

NOTES:

● If your TV is not stereo-capable, use the unit’s AUDIO OUT connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

● For switching the TV’s video input mode, refer to the instruction manual of your television.

INITIAL SETTINGS

Auto Set Up

The Auto Set Up simplifies installation by guiding you through the procedures of setting the language, clock and tuner channels — simply follow the on-screen menus that appear.

REC LINK

STANDBY/ON

rtwe

ENTER

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

L(MONO)-AUDIO-R

S-VIDEO VIDEO

DVDTV

DVD F

CH +/–

EN 19

Before starting, make sure of the following:

● The TV aerial cable should be connected to the unit.

● The unit’s mains power cord should be connected to a

mains outlet.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

Turn on the unit.

On the unit

Press 1 on the unit.

On the remote control Press DVD 1 on the remote control.

REC MODE

DV IN

DVDTV

● The Clock Set display appears on the TV screen.

PULL - OPEN

Set the date and time.

A Press rt to select

“YEAR”, then press

INITIAL SET UP / CLOCK SET

ENTER.

B Press rt to set the year,

then press ENTER.

● Repeat the same procedure to set the date and time.

● When you set the time, press and hold rt to change the time

by 30 minutes.

● When you set the date, press and hold rt to change the date by 15 days.

● If the confirmation screen appears, press we to select “OK”, then press ENTER.

Select the TV system.

Press rt to select the appropriate TV system (refer to the table below).

Major Countries/Areas TV System

Australia, New Zealand, Kuwait, U.A.E., Indonesia, Singapore, Thailand, Malaysia, Iran, Saudi Arabia, Egypt, Morocco, Lebanon, Iraq

THU

B/G

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

China, Mongolia, Russia D/K

Hong Kong I

20 EN

INITIAL SETTINGS (cont.)

Perform Auto Channel Set.

Press ENTER.

DO NOT press any button on the unit or remote control while Auto Set Up is in progress.

● Receivable channels in your area are automatically assigned to the CH +/– buttons, and non-receivable channels are skipped.

● When Auto Set Up is completed, the lowest position number will appear on the front display panel. If “SCAN COMPLETED –NO SIGNAL–” is displayed on the TV screen, make sure that the aerial cable is connected to the unit properly and press ENTER on the remote control. The unit will try Auto Set Up again.

TTENTION:

If you perform Auto Set Up successfully during installation, there’s no need to separately perform the Clock Set or Channel Set procedures, but if adjustments become necessary, they can be performed as follows:

● Language setting (墌 pg. 22)

● Tuner setting (墌 pg. 92)

● Clock setting (墌 pg. 96)

NOTES:

● If there is a power cut, or if you press 1 or SET UP while Auto

Set Up is in progress, Auto Set Up will be interrupted; be sure to turn off the unit power once and try again from step A.

● If no sound accompanies the picture or the audio sounds unnatural on some channels that have been stored by Auto Set Up, the TV system setting for those channels may be incorrect. Select the appropriate TV system for those channels. (墌 pg. 95, “TV System Selection — When you see the picture but the audio can’t be heard or sounds unnatural”)

After “Auto Set Up” is completed, perform “Monitor Set” on page 21.

Monitor Set

You can select the monitor type depending on the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

Access the Main Menu screen.

Press SET UP.

Access the “VIDEO IN/OUT” screen.

A Press we to move the

arrow to “FUNCTION SET UP”, then press ENTER.

B Press we to move the

arrow to “VIDEO IN/ OUT”, then press ENTER.

Select the desired option.

A Press rt to select “MONITOR TYPE”, then press

ENTER.

B Press rt to select the desired option, then press

ENTER.

Complete the setting.

Press SET UP.

EN 21

(The boldface settings in the table below indicate the settings at your purchase.)

8 MONITOR TYPE

4:3LB (Letter Box conversion):

Select this when the aspect ratio of your TV is 4:3 (conventional TV). While viewing a wide screen picture, the black bars appear on the top and the bottom of the screen.

4:3PS (Pan&Scan):

Select this when the aspect ratio of your TV is 4:3 (conventional TV). While viewing a wide screen picture, the black bars do not appear; however, the left and right edges of the pictures will not be shown on the screen.

16:9 AUTO (Wide television conversion):

Select this when the aspect ratio of your TV is 16:9 (wide TV).

16:9 FIX (Wide television conversion):

Select this when the aspect ratio of your TV is fixed to 16:9 (wide TV). The unit automatically adjusts the screen width of the output signal correctly when playing back a picture whose aspect ratio is 4:3.

Pan&Scan/Letter Box

In general, DVD VIDEO disc are produced for a wide-screen TV with 16:9 aspect ratio. Material with this ratio will not fit to a TV with 4:3 aspect ratio. There are two styles to display the image, “Pan&Scan” (PS) and “Letter Box” (LB).

Pan&Scan

The right and left side of the image are cut off. The image fills the screen.

● The picture will be shown in the “4:3LB” mode depending on the disc even if the “4:3PS” mode is selected.

Letter Box

Black bands appear at the top and bottom of the image. The image itself appears in 16:9 aspect ratio.

22 EN

Language

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

INITIAL SETTINGS (cont.)

On-screen Language Set

This unit offers you the choice to view on-screen messages in 10 different languages. You can change the language setting manually as required.

Access the Main Menu screen.

Press SET UP.

rtwe

ENTER

SET UP

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

DVDTV

Access the “DISPLAY SET” screen.

A Press we to move the

arrow to “FUNCTION SET UP”, then press ENTER.

B Press we to move the

arrow to “DISPLAY SET”, then press ENTER.

Select the desired language.

A Press rt to move the arrow to “ON SCREEN

LANGUAGE”, then press ENTER.

B Press rt to select your desired language, then press

ENTER.

Complete the setting.

Press SET UP.

rtwe

ENTER

SET UP

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

EN 23

Menu/Audio/Subtitle Language Set

DVDTV

Some DVD discs contain the DVD menu display, audio and subtitles in multiple languages. With these discs, you can set the default language as you like.

● The procedure shows how to set “MENU LANGUAGE” as an example.

Access the Main Menu screen.

Press SET UP.

Access the “LANGUAGE SET” screen.

A Press we to move the

arrow to “DVD SET UP”, then press ENTER.

B Press we to move the

arrow to “LANGUAGE SET”, then press ENTER.

Select the desired language.

A Press rt to move the arrow to “MENU

LANGUAGE”, then press ENTER.

● See “Language Code List” (墌 pg. 24).

B Press rt to select your desired language, then press

ENTER.

Complete the setting.

Press SET UP.

NOTE:

When the selected language is not available on the disc, the disc’s default menu language is played back.

24 EN

Language Code List

INITIAL SETTINGS (cont.)

AA AB AF AM AR AS AY AZ BA BE BG BH BI BN BO BR CA CO CS CY DZ EL EO ET EU FA FJ FO FY GA GD GL GN GU HA HI HR HU HY IA IE

Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byelorussian Bulgarian Bihari Bislama Bengali, Bangla Tib etan Breton Catalan Corsican Czech Welsh Bhutani Greek Esperanto Estonian Basque Persian Fiji Faroese Frisian Irish Scots Gaelic Galician Guarani Gujarati Hausa Hindi Croatian Hungarian Armenian Interlingua Interlingue

IK IN IS IW JI JW KA KK KL KM KN KO KS KU KY LA LN LO LT LV MG MI MK ML MN MO MR MS MT MY NA NE OC OM OR PA PL PS PT QU RM

Inupiak Indonesian Icelandic Hebrew Yiddish Javanese Georgian Kazakh Greenlandic Cambodian Kannada Korean (KOR) Kashmiri Kurdish Kirghiz Latin Lingala Laothian Lithuanian Latvian, Lettish Malagasy Maori Macedonian Malayalam Mongolian Moldavian Marathi Malay (MAY) Maltese Burmese Nauru Nepali Occitan (Afan) Oromo Oriya Panj ab i Polish Pashto, Pushto Portuguese Quechua Rhaeto-Romance

RN RO RU RW SA SD SG SH SI SK SL SM SN SO SQ SR SS ST SU SW TA TE TG TH TI TK TL TN TO TR TS TT TW UK UR UZ VI VO WO XH YO ZU

Kirundi Rumanian Russian Kinyarwanda Sanskrit Sindhi Sangho Serbo-Croatian Singhalese Slovak Slovenian Samoan Shona Somali Albanian Serbian Siswati Sesotho Sundanese Swahili Ta mi l Te lu gu Tajik Thai Tig rinya Tu rk me n Ta ga lo g Setswana Tonga Tu rk is h Tsonga Ta ta r Twi Ukrainian Urdu Uzbek Vietnamese Volapuk Wolof Xhosa Yoruba Zulu

PLAYBACK OPERATIONS

Basic Playback

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

STANDBY/ON

MUTING

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

STANDBY/ON

DEF

DVD

TV VOLUME

S-VIDEO VIDEO

DVDTV

REC LINK

L(MONO)-AUDIO-R

EN 25

To play back an MP3/JPEG disc, see “Playback with MP3/JPEG Navigation” (

A Press x to open the disc tray. B Place the disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

● Pressing 4 also closes the disc tray.

● Playback begins automatically if an auto-playback DVD disc is

loaded.

REC MODE

PULL - OPEN

DV IN

DVDTV

Press 4.

● If you load a DVD disc whose region code does not match the unit, “REGION CODE ERROR” appears on the TV screen. For details, refer to “Region number of DVD VIDEO” (

● With Video CD/SVCD discs with PBC control or some DVD discs, the menu display may appear on the TV screen after starting playback. In this case, select an item which you want to play back from the menu. Otherwise, the playback cannot go forward. Refer to “Locating a desired scene using the menu of a Video CD/SVCD with PBC” ( desired scene using the DVD menu” (

● The Library Database DVD Navi also enables you to search and select the desired programmes. (

Press 9.

● To resume normal playback, press 4.

墌 pg. 74).

Load a disc.

Start playback.

墌 pg. 1).

墌 pg. 30) or “Locating a

墌 pg. 26).

墌 pg. 62)

Pause playback.

AUXCANCEL

MEMO/MARK

ENTER

STOP/

REC LINK

CLEAR

ON SCREEN

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAU SEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

rtwe

ENTER

SELECT

PROG/CHECK

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

TTENTION:

● It takes approximately 30 seconds to read a disc depending on the type and condition of the disc since this unit is multi-disc compatible (DVD-RAM, DVD-RW, DVD-R). It may even take several minutes when a disc is dirty, scratched or warped.

● It may take a few seconds to start playback. This is not a malfunction.

● Forward/reverse high-speed search and other operations cannot be performed while playback is stopped.

Stop playback.

Press 8.

● When a recordable disc is played, playback stops and a programme received with the unit’s tuner resumes on the TV screen.

● When a playback-only disc is played, playback stops and the still image at the time you press 8 remains on the TV screen. Pressing 8 again resumes a programme received with the unit’s tuner.

● If x is pressed during playback, playback stops, then the disc tray opens.

NOTE:

When the Library Database DVD Navi screen appears, choose a thumbnail image of the desired programme on the TV screen, then press SELECT or ENTER. (

墌 pg. 64)

26 EN

Playback Features

PLAYBACK OPERATIONS (cont.)

2 Start playback.

Press rt w e to select a desired title, then press ENTER.

● It may be possible to select the desired item using the number keys depending on the menu display.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

TV/

VIDEO

STANDBY/ON

DVD

MUTING

DVDTV

DVD 1

TV VOLUME

ABC

DEF

0 – 9

TOP MENU

SLOW–

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

REC LINK

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

rtwe

ENTER

4 6 5

/SLOW+

Locating a desired scene using the DVD menu

NOTE:

When “X” appears on the TV screen in step 1, the disc does not have a top menu or disc menu.

Locating the start point of the item or skip the item

Press 2 or 6 during playback.

● Pressing 6 locates the start point of the item or skips the item for forward direction, then resumes playback.

● Pressing 2 locates the start point of the item or skips the item for reverse direction, then resumes playback.

When a DVD-RAM/RW/R disc is played

Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once. To locate the beginning of the previous item, press 2 three times.

When a DVD VIDEO, Audio CD or Video CD/SVCD disc is played

DVD VIDEO discs may have top menu and disc menu.

Top menu

DVD discs generally have their own menus which show the disc contents. These menus contain various items such as titles of a movie, names of songs, or artist information. You can locate a desired scene by using the top menu displayed on the TV screen. Press TOP MENU to access the top menu.

Disc menu

Disc menus include playback data (angle menu, subtitle menu, etc.) specific to each title. Press MENU to access the disc menu.

1 Access the DVD menu.

Press TOP MENU or MENU.

Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once.

EN 27

High-Speed Search

During playback, press 5 for forward high-speed search, or 3 for reverse high-speed search.

● Each press of the button increases the search speed for each direction.

● To resume normal playback, press 4.

During playback, press and hold 6 for 2 or more seconds for forward high-speed search, or press and hold 2 for 2 or more seconds for reverse high-speed search.

● Releasing the button resumes normal playback.

Still Picture/Frame-By-Frame Playback

1 Pause during playback.

Press 9.

2 Activate frame-by-frame playback.

Press 9.

● Each press of 9 advances the still picture frame by frame.

Press we.

● Each press of we advances/reverses the still picture frame by frame.

● Frame-by-frame playback for reverse direction cannot be performed with Video CD/SVCD discs.

● To resume normal playback, press 4.

Slow Motion

While paused, press SLOW – or SLOW +.

● Each press of SLOW – or SLOW + increases the slow motion speed for each direction (from 1/16 to 1/2 times the normal speed).

● Slow motion for reverse direction cannot be performed with Video CD/SVCD discs.

Press 2 or 6 for 2 or more seconds.

Skip Search

During playback, press .

● Each press initiates an approximately 30-second period of fastmotion playback. Normal playback resumes automatically.

Resume Function

It is possible to memorise the position where you stop playback and resume playback from that position.

● Be sure to set “RESUME” to “ON” or “DISC RESUME”. (

墌 pg. 91)

1 Memorize a resume point.

Press 8 during playback.

● The unit enters Resume Stop mode and memorises the position where you have stopped playback as a resume point. (The inside of the disc status indicator on the front display panel blinks in the Resume Stop mode.)

● The unit retains a memory of the resume points of the last 30 discs played back, even though they have been ejected if “RESUME” is set to “DISC RESUME”. (

● To clear the resume points: (The inside of the disc status indicator stops blinking and lights.)

When “RESUME” is set to “ON”:

• Press 1 on the unit or DVD1 on the remote control to

turn off the unit.

• Press x to take out the disc.

• Press 8 in stop mode.

• Press TOP MENU to display the top menu, then start

playback by selecting an item, etc.

• Press MENU to display the disc menu, then start playback by

selecting an item, etc.

When “RESUME” is set to “DISC RESUME”:

• Set “RESUME” to “OFF”. (

• Press 8 in stop mode.

• Press TOP MENU to display the top menu, then start

playback by selecting an item, etc.

• Press MENU to display the disc menu, then start playback by

selecting an item, etc.

墌 pg. 91)

2 Resume playback.

Press 4 in stop mode. The unit starts playback from the resume point.

NOTES:

● “DISC RESUME” setting works on DVD VIDEO, VCD, SVCD and already finalised DVD-R/DVD-RW (video mode) discs. For other types of discs, the function under “ON” setting will be applied even if “RESUME” is set to “DISC RESUME”.

● If you stop the playback of a disc for which an resume point has already been memorized, the memory will be updated with the new resume point.

● After the unit has memorized the resume point for 30 discs, remembering a new resume point will cause the unit to delete the oldest memorized point. Stopping playback of a disc for which a resume point is already stored may change the order in which the points are stored. This may potentially change the order in which points are deleted.

● When the unit memorizes a resume point for a disc, it also remembers audio language, subtitle and angle settings.

● This function may not work for some Video CD or SVCD.

● When “RESUME” is changed to “ON” or “OFF”, resume

points of the discs memorized with “RESUME” set to “DISC RESUME” will be cleared.

● Resume points are memorized for each side of a double-sided disc.

墌 pg. 91)

28 EN

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

STANDBY/ON

DEF

DVD

TV VOLUME

MUTING

DVDTV

MARK

AUXCANCEL

MEMO/MARK

ENTER

STOP/

REC LINK

NAVIGATIONTOP MENU

CLEAR

ON SCREEN

TIMER

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

ENTER

PROG/CHECK

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

DISPLAY

SET UP DISPLAY

SUBTITLE

AUDIO

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

ANGLE

DVDTV

PLAYBACK OPERATIONS (cont.)

NOTES:

● When a monaural programme or bilingual programme changes to a stereo programme while recording, a mark signal is automatically recorded.

● When a DVD-R/RW (Video mode) disc is finalised, marked points marked before finalising will be deleted, and programmes will be divided automatically into “chapters” approximately every 5 minutes. (

墌 pg. 98, “Finalise A Disc”)

Checking the time information

You can change the counter display on the front display panel and TV screen to check disc remaining time (only discs before finalising).

During playback

Each press of DISPLAY changes the display as follows: Clock time (front display panel only) ] Current title elapsed time ] Disc remaining time ] (back to the beginning)

● Clock time is displayed only when a recordable disc is played.

In stop mode or during playback

● In FR mode, it is possible to set recording time in detail using

we. (

墌 pg. 50, “Free Rate Function”)

● It is not possible to switch the recording mode during playback

or while recording.

Switching Time Indication

Marking positions to play again later

It is possible to mark positions (up to 999 points) where you want to play back once again later, and start playback from a marked position. Marking onto DVD-RAM/RW/R discs when recording is helpful to locate a start point when you play back the discs later.

1 Mark positions.

During playback, press MARK at positions you want to mark.

● “MARK” appears on the TV screen. You can easily locate the marked positions using 2 or 6 when you play back the disc.

2 Delete the marked positions.

While paused, press 2 or 6 to locate a marked

position you want to delete, then press MARK.

● Crossed “MARK” appears on the TV screen, and the marked position is deleted.

You can check time information of an audio CD and a Video CD/SVCD on the front display panel and the TV screen. Each press of DISPLAY changes the time indication as follows:

During playback

Current track elapsed time ] Current track remaining time ] Total elapsed time ] Total remaining time ] (back to the beginning)

In stop mode

0:00 ] Playback time of track 1 ] 0:00 ] Total length of a disc ] (back to the beginning)

NOTE:

When a PBC-compatible Video CD/SVCD disc is loaded, deactivate the PBC function. (

墌 pg. 30)

Angle Selection

You can enjoy a variety of scene angles if a DVD VIDEO disc contains “multi-angle” parts, where the same scene was shot from different angles. If the disc contains “multi-angle” parts, “ ” appears on the TV screen at the beginning of the “multi-angle” part.

1 Access Angle display.

2 Select the angle.

Press ANGLE or we to select your desired angle.

● Each time you press ANGLE or we, the angle changes.

● When “X” appears on the TV screen, the current scene is not

recorded from multiple angles. In addition, some discs prohibit angle selection.

● To clear the angle selection display, press ENTER. In addition, the angle selection display disappears automatically if no operation is done for 10 seconds.

EN 29

Subtitle Selection

Some DVD VIDEO discs contain more than one subtitle language, from am8the3e

30 EN

PLAYBACK OPERATIONS (cont.)

0 – 9

TOP MENU

AUDIO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

DEF

REC LINK

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY/SELECT

ON SCREEN

PROGRESSIVE

TV VOLUME

TIMER

NEXTPREVIOUS

PAUSEREC

OPEN/ CLOSE

SCAN

ENTER

RETURN NEXT

NOTE:

It is not possible for DVD-R/DVD-RW (Video mode) disc playback to switch the audio channel. The audio channel is played back as set in “AUDIO REC” (

墌 pg. 89).

When you can’t switch the audio channel of a bilingual programme

When the unit is connected with a digital audio device using an optional optical cable and “DIGITAL AUDIO OUT” is set to “DOLBY DIGITAL/PCM”, it is not possible to switch the audio channel of a bilingual programme recorded on a DVD-RAM or DVD-RW (VR mode) disc. ( case, perform the following steps using the remote control to switch “DIGITAL AUDIO OUT” from “DOLBY DIGITAL/ PCM” to “PCM ONLY”.

A Press SET UP to access the Main Menu screen. B Press we to select “DVD SET UP”, then press ENTER. C Press we to select “AUDIO OUTPUT”, then press

ENTER.

D Press rt to select “DIGITAL AUDIO OUT”, then press

ENTER.

E Press rt to select “PCM ONLY”, then press ENTER.

(

墌 pg. 88)

F Press SET UP to complete the setting. G Press AUDIO to select the desired audio channel.

墌 pg. 88) In this

Playback Control (PBC) Function — Locating a desired scene using the

Audio Channel Selection

When watching bilingual programmes or playing discs on which you recorded bilingual or stereo programmes, you can choose the desired audio channel.

● When “SUPERIMPOSE” is set to “AUTO”, you can confirm on the TV screen the audio channel you have chosen. (

● Each time you press AUDIO, the audio channel changes.

TRACK

On-Screen

USE

Display

For main and sub audio of bilingual programme

For main audio of bilingual programme

For sub audio of bilingual programme

For stereo discs

For audio of left channel

墌 pg. 90)

menu of a Video CD/SVCD with PBC

Some Video CD/SVCD discs support the PBC function. PBC is an abbreviation of “Play Back Control”. A Video CD/SVCD disc recorded with PBC has its own menus, such as a list of the songs on the disc. You can locate a specific scene by using the menu.

1 Access the PBC menu.

In stop mode

Press 4.

2 Start playback.

Press the number keys to enter the number of the desired scene.

● The unit starts playback of the selected item. “PBC” appears on the front display panel.

● When “NEXT” or “PREVIOUS” appears on the TV screen: Pressing NEXT advances to the next page. Pressing PREVIOUS returns to the previous page.

● You can return to the menu by pressing RETURN.

● The method of the operation is different depending on the

disc.

NOTES:

● If you want to playback a PBC-compatible Video CD/SVCD disc without activating the PBC function, start playback in stop mode by using the number keys, instead of the 4 button, to choose the track, then press ENTER.

● To activate the PBC function when a PBC-compatible Video CD/SVCD disc is being played back without the PBC function, press TOP MENU, or press 8 then press 4.

For audio of right channel

Live Memory Playback

This unit records pictures onto DVD-RAM discs, instead of video tapes, then plays back the pictures recorded on the discs. This makes it possible to achieve high-speed writing and read-out that has not been possible with conventional VCRs, enabling recording and playback simultaneously.

High-speed spin

(High-speed writing)

Recording

Image figure of DVD-RAM disc

It is called “Live Memory Playback” to start playback of the programme being recorded, with a time-lag between a recording point and a playback point, as shown in the figure below.

Current playback point

(Live Memory Playback)

Current recording position

Recording start point

Playback continues

0 30 min. 1 hour

Currently elapsed recording time

Not only can this unit play back a programme previously recorded while recording or timer recording another programme, but the unit also allows you to play back from the beginning of a programme while continuing to record the same programme.

Playback (High-speed read-out)

(Recording point)

Recording continues

EN 31

Recording/playback status display

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

DVD

ON SCREEN

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

DVDTV

Live Memory Playback status can be checked by pressing ON SCREEN to display the bar

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

meter on the superimpose display.

Press ON SCREEN. The current status is superimposed on the TV screen.

DVDTV

32 EN

PLAYBACK OPERATIONS (cont.)

Overview of Live Memory Playback

You can play back a programme you are recording from the beginning while continuing to record or timer record onto a DVD-RAM disc. This is called “Live Memory Playback”.

NOTES:

● Live Memory Playback cannot be performed for approximately 30 seconds after recording has started.

● Although high-speed search up to approximately 30 seconds before the current recording point is possible during Live Memory Playback, once the current recording point is reached, the unit resumes normal playback and maintains a delay of approximately 30 seconds so that recording and playback can continue.

● When using Live Memory Playback during timer recording, playback continues even after the end of the recording.

● When using Live Memory Playback during timer recording, playback is automatically stopped just before recording starts, and then recording starts when the time arrives for the next timer-programme.

● It is impossible to perform ITR even if you press 7 during Live Memory Playback. ( (ITR)”) Press 8 to display the programme being recorded, then perform ITR settings.

● Playback may be paused for a moment during Live Memory Playback, which does not interfere with recording.

● Live Memory Playback cannot be performed while recording the source from DV input.

● When LIVE CHECK is pressed to display the picture currently being recorded, the picture size may not be correct.

墌 pg. 48, “Instant Timer Recording

EN 33

Display during Live Memory Playback

During recording, you can watch at your will what was previously recorded or is currently being recorded. It is possible to perform freely normal playback operations (forward/reverse high-speed search and variable-speed search) within the range of the orange or blue bar on the TV screen. When Live Memory Playback reaches the point of 30 seconds before the current recording point by forward high-speed search or other operations, the unit returns to normal playback.

The superimpose display appears by pressing ON SCREEN. (

墌 pg. 14)

The Live Check picture is displayed on the bottom right corner by pressing LIVE CHECK.

Playback counter

Live Memory Playback mark

Playback title number

Disc used

Tit le name

Bar meter (see below)

This unit displays the current recording/playback status by the bar meter.

(Example of bar meter display)

Capacity of a disc

Recorded

While stopped

Total length of the programme being played back

Current playback position

During playback

Capacity of a disc

Remaining capacity when recording started

While recording

Recording mode

Recording title number

Recording counter display (remaining/elapsed time)

Present time

Recording channel Station name

Playback mark

Recording mark

Live Check picture

Recording mark

Not recorded

Current recording position

Live Memory Playback

Live Memory Playback of

another programme

Capacity of a disc

Recording start position

Capacity of a disc

Recording start position

Current playback position

Total length of the programme being played back

Blue (recorded part)

Orange (recording part)

Current playback position

Current recording position

Green (playing part)

Black (unrecorded or unplayed part)

34 EN

Buttons to be used during Live Memory Playback

PLAYBACK OPERATIONS (cont.)

LIVE CHECK

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

PROGRESSIVE

SCAN

6 5

DVDTV

buttons

● Pressing once skips forward to the beginning of the next chapter being played back.

● Pressing down for 2 or more seconds during playback advances playback at 5 times the normal speed while pressed. Releasing the button resumes normal playback.

Available only when paused

● Pressing down for 2 or more seconds advances playback at 1/16 times the normal speed.

● Pressing once skips back to the beginning of the chapter being played back.

● Pressing down for 2 or more seconds during

Available

Functions

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

EN 35

To play back from the beginning of the programme while recording

You can play back a programme you are recording from the beginning while continuing to record or timer record onto a DVD-RAM disc.

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

6 4

DVDTV

1 Start Live Memory Playback.

Press 4.

● Playback starts from the beginning of the programme being recorded.

● Pressing 2/6 allows you to locate the desired scenes.

To move back the playback position slightly while recording (One Touch Replay function)

You can move back the playback position while continuing to record or timer record onto a DVD-RAM disc.

1 Start One Touch Replay function.

Press .

● Each press skips back for approximately 7 seconds and resumes playback.

● Pressing while paused skips back for approximately 7 seconds and resumes pause.

To watch a programme previously recorded while recording

You can play back a programme you recorded previously while recording.

1 Start Live Memory Playback.

Press 4 while recording to establish Live Memory Playback mode.

2 Locate the beginning of the desired programme.

Press 2 or 6.

NOTE:

To stop playback, press 8. The programme being recorded is displayed.

36 EN

Using Play Set Up

PLAYBACK OPERATIONS (cont.)

How to Access Play Set Up Menu

Press ON SCREEN twice whenever a disc is loaded.

Play Set Up Menu allows you to control various playback functions. Some of the functions operated on Navigation Menu can be controlled on Set Up Menu.

Before using Play Set Up Menu

Be sure to clear Library Database DVD Navi screen by pressing NAVIGATION.

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

NAVIGATION

ON SCREEN

DVDTV

Contents of Play Set Up Menu during playback

DVD VIDEO

Video CD/SVCD

JPEG disc

A Disc type. B Select this for Repeat Playback. (

墌 pg. 38)

C Select this for A-B repeat Playback. (墌 pg. 39) D Select this for search function. ( E Select this for time search function. (

墌 pg. 39)

墌 pg. 40)

F Select this to switch Simulated Surround Effect

function. (

G Select this for Picture Control function. ( H Select this to switch picture source type. (

墌 pg. 40)

墌 pg. 41)

I Current status area for the selected item. J Select this for Programme Playback. (

墌 pg. 42)

K Select this for Random Playback. (墌 pg. 42) L Select this to control the switching interval of the slide

墌 pg. 42)

show. (

NOTE:

Although examples of Play Set Up Menu are provided here only for 3 types of discs, Play Set Up Menu will be displayed for whichever disc indicated in the left column.

EN 37

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

DVDTV

rtwe

ENTER

ON SCREEN

Basic operation on Play Set Up Menu

Example: When selecting Picture Control function of DVD

During playback or while stopped

1 Access Play Set Up Menu.

Press ON SCREEN twice.

● The item currently selected is highlighted and pointed by H.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● The pop-up window appears under the selected item.

3 Select the option.

Press rt to select the desired option, then press ENTER.

To clear Play Set Up Menu Press ON SCREEN.

NOTE:

See the corresponding pages for details on each menu item.

38 EN

PLAYBACK OPERATIONS (cont.)

0 – 9

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

PROGRESSIVE

SCAN

DVDTV

rtwe

ENTER

CLEAR

ON SCREEN

Repeat Playback

You can repeat playback as you like according to the type of disc.

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● The pop-up window appears under the selected item.

3 Select the repeat mode.

Press rt repeatedly to select the desired Repeat mode, then press ENTER.

DVD-RAM/RW/R

OFF: ALL REPEAT: The whole disc is played back

TITLE REPEAT:

DVD VIDEO

OFF: Repeat playback is not performed. TITLE REPEAT: The current title is played back

CHAPTER REPEAT:

Audio CD/Video CD/SVCD/JPEG/MP3

OFF:

ALL REPEAT:

TRACK REPEAT*:

* “TRACK REPEAT” cannot be selected for JPEG discs.

To clear Play Set Up Menu Press ON SCREEN.

To cancel Repeat Playback

Repeat the above procedure from step 1, select “OFF” in step 3, then press ENTER.

Repeat playback is not performed.

repeatedly.

The current title is played back repeatedly.

repeatedly.

The current chapter is played back repeatedly.

Repeat playback is not performed.

The whole disc is played back repeatedly.

The current track is played back repeatedly.

NOTES:

● Repeat Playback is not possible for a Video CD/SVCD with PBC function.

● Repeat Playback may not work properly depending on the type of the disc being used.

EN 39

A-B Repeat Playback

You can repeat the desired part.

During playback

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”.

3 Locate the start point.

Press ENTER at the beginning of the desired part you want to repeat (point A).

● The elapsed playing time of the point A appears

4 Locate the end point and start A-B Repeat

Playback.

Press

ENTER

repeat (point B).

● The elapsed playing time of the point B appears.

● The selected part of the disc (between point A and B) is played

repeatedly.

at the end of the desired part you want to

Locating the beginning of a desired selection

You can locate the beginning of a title, chapter, group or track.

During playback or while stopped

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

3 Select the desired item.

For DVD-RAM/RW/R, DVD VIDEO

“TITLE SEARCH” or “CHAPTER SEARCH” is selectable. (“TITLE SEARCH” only is selectable while stopped.)

For JPEG, MP3

“GROUP SEARCH” or “TRACK SEARCH” is selectable.

For Video CD/SVCD, Audio CD

“TRACK” is selectable.

Press rt to select the desired item, then press ENTER.

● Skip this step for Video CD/SVCD and Audio CD.

To clear Play Set Up Menu Press ON SCREEN.

To cancel A-B Repeat Playback Press we to select “ ”, then press ENTER.

NOTES:

● A-B Repeat Playback may not work properly depending on the type of disc being used.

● The subtitles recorded around the A-B point may not appear.

● When the end of the item is reached before the end point is

set, Play Set Up Menu disappears from the TV screen. In such a case, repeat the procedure from step 1.

● The point B must be set at least 3 seconds after the point A.

● When playing back a DVD, A-B Repeat Playback is possible

only within the same title.

● “ ” cannot be selected during Programme and Random Playback.

● “ ” cannot be selected while stopped.

4 Specify the number of the selected item.

Press number keys (1–9, 0) to enter the desired item number, then press ENTER.

● Playback starts from the selected section.

Examples:

To select track 5, press the number key “5”. To select track 15, press the number key “1” and “5”. To select track 25, press number key “2”, then “5”.

If you have specified a wrong selection

Press & or CLEAR to clear the wrong number, then enter the correct one before you press ENTER in this step.

To clear Play Set Up Menu Press ON SCREEN.

NOTES:

● When “X” is displayed on the TV screen in step 4, the chapter

you have selected is not contained in the disc, or chapter search does not work on the disc.

● Before you press ENTER, playback may start automatically when you enter the section’s number depending on the disc.

● This function is not possible for a Video CD/SVCD with PBC function.

40 EN

PLAYBACK OPERATIONS (cont.)

Time Search

You can play back a disc from the desired point by specifying the elapsed playing time from the beginning of a title (DVD-RAM, DVD-R, DVD-RW and DVD VIDEO) or a disc (Video CD/SVCD and Audio CD).

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● The pop-up window appears under the selected item.

3 Enter the time.

Use number keys (1–9, 0) to enter the time, then press ENTER.

● Playback starts from the specified time.

Example: To play back from a point 12 (minutes): 50 (seconds) elapsed.

Press 1 Press 2

Simulated Surround Effect

It is possible to get a simulated surround effect from your stereo system. You can enjoy the virtual surround sound with your 2-channel stereo system.

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● Above the selected item, “3D-ON” appears and Simulated Surround Effect is activated.

● Each time you press ENTER, “3D-ON” appears and disappears alternately.

To cancel the simulated surround effect Press ENTER to clear “3D-ON” from the screen.

NOTES:

● The simulated surround effect works correctly only when playing back a title recorded in multichannels.

● Simulated Surround Effect does not affect the DVD VIDEO bitstream signal from the “DIGITAL AUDIO OUT” connector.

● When Simulated Surround Effect is activated, the settings of “ANALOG AUDIO OUT” and “D. RANGE CONTROL” are disabled. (

墌 pg. 88)

Press 0Press 5

If you have specified a wrong selection,

Press & (for the last entered number) or 8 (for whole numbers) to clear the wrong number, then enter the correct one(s) before you press ENTER in this step.

To clear Play Set Up Menu Press ON SCREEN.

NOTES:

● When “X” is displayed on the TV screen in step 3, you have

selected a point that excesses the recording time of the disc.

● Some DVD VIDEO discs do not contain time information, and it is not possible to use the Time Search function. In such cases, “X” is displayed on the TV screen as well.

● This function is not possible for a Video CD/SVCD with PBC function.

EN 41

Adjusting the picture quality

You can obtain optimal picture quality by selecting an appropriate picture mode.

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● The pop-up window appears under the selected item.

3 Select the desired option.

Press rt to select the desired option, then press ENTER.

NORMAL: Normally select this option. CINEMA: Suitable for a movie disc, etc. SHARP: Clearer, sharper-edged picture when viewing

SOFT:

images with lots of flat, same-coloured surfaces such as cartoons.

Select this option when too much noise appears.

Setting the progressive mode

You can obtain optimal picture quality by selecting whether the content on the disc is processed by field (video source) or by frame (film source).

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “ ”, then press ENTER.

● The pop-up window appears under the selected item.

3 Select the desired option.

Press rt to select the desired option, then press ENTER.

AUTO 1: Used to play a disc containing both video

AUTO 2: Almost the same as the “AUTO 1”, but the

FILM: Suitable for playing back a progressive

VIDEO:

and film source materials. This system recognizes the source type (video or film) of the current disc according to the disc information. Normally select this option.

processing of the scenes with movement is different. Select “AUTO 1” or “AUTO 2” to your preference.

scanned film source disc.

Suitable for playing back a video source disc. The outlines on the played back pictures will be soft.

NOTE:

When the progressive mode is set, be sure to set “L-1 OUTPUT” to “COMPONENT”. ( Setting (L-1 OUTPUT and L-1 INPUT)”) Progressive scan is output only from COMPONENT VIDEO OUT connector.

墌 pg. 80, “L-1 Output and L-1 Input

42 EN

Programme Playback

You can play back up to 30 tracks in the desired order.

While stopped

1 Access Play Set Up Menu.

Press ON SCREEN twice.

2 Select the menu item.

Press we to select “PRGM”, then press ENTER.

● The programme table appears under Play Set Up Menu.

3 Select the tracks in the desired order.

Use number keys (1–9, 0) to enter the track numbers.

PLAYBACK OPERATIONS (cont.)

If you have specified a wrong selection

Press &. The last selection is erased. Or press 8. The whole selection is erased.

4 Start playback.

Press 4. Playback starts in the programmed order.

● When all of the programmed tracks have been played back, Programme Playback stops, but the programmed information remains.

● To add tracks to the end of the programme, perform steps 1 through 3.

● During Programme Playback, pressing 6 skips to the next selection of the programme. Pressing 2

Parental Lock

This function restricts playback of DVD VIDEO discs which contain violent (and other) scenes according to the level set by the user. For example, if a movie which includes violent scenes supports the parental lock feature, such scenes which you do not want to let children view can be cut or replaced by other scenes.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

0 – 9

SET UP

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY/SELECT

ON SCREEN

PROGRESSIVE

DVDTV

DVD

TV VOLUME

TIMER

NEXTPREVIOUS

PAUSEREC

OPEN/ CLOSE

SCAN

rtwe

ENTER

DVDTV

Access the “PARENTAL LOCK” screen.

A Press we to select

“UTILITY”, then press ENTER.

B Press rt to select

“PARENTAL LOCK”, then press ENTER.

Select the desired level.

A Press rt repeatedly to

select “PARENTAL LEVEL”, then press ENTER.

B Press rt repeatedly to

select the desired level, then press ENTER.

● The smaller the value of level is, the more restrictive the Parental Lock level becomes.

● Select “NONE” to cancel the restriction.

Enter your password.

Press the number keys to enter your desired four-digit number, then press ENTER.

● If you made a mistake, enter a correct number again.

Select your country code.

A Press rt repeatedly to

select “COUNTRY CODE”, then press ENTER.

B Press rt repeatedly to

select your country code, then press ENTER.

● If you do not need to change your country code, jump to G.

● See “Country/Area Code List for Parental Lock” (

墌 pg. 45).

EN 43

To set Parental Lock for the first time

While stopped

Access the “DVD SET UP” screen.

A Press SET UP. B Press we to select “DVD SET UP”, then press ENTER.

Enter your password.

Press the number keys to enter the same password as in step D above, then press ENTER.

Complete the setting.

Press SET UP twice.

● The normal screen resumes.

NOTE:

Remember your password, or make a note of it.

44 EN

PLAYBACK OPERATIONS (cont.)

To change the settings

You can change the Parental lock settings later.

Change the level.

A Press rt repeatedly to select “PARENTAL LEVEL”,

then press ENTER.

B Press rt repeatedly to select the desired level, then

press ENTER.

Change the country code.

A Press rt repeatedly to select “COUNTRY CODE”,

then press ENTER.

B Press rt repeatedly to select your country code, then

press ENTER.

● See “Country/Area Code List for Parental Lock” (墌 pg. 45).

Enter your password.

Press the number keys to enter the same password as in step D of “To set Parental Lock for the first time”, then press ENTER.

To temporarily release Parental Lock

When you set the parental lock level strictly, some discs may not be played back at all. When you insert such a disc and try to play it back, the confirmation screen appears on the TV screen, asking you whether you want Parental Lock to be temporarily released or not.

Access the password screen.

A Place the disc on the disc tray.

● If the disc is rated higher than the selected level, the confirmation screen appears.

B Press we to select “YES”, then press ENTER.

● If you select “NO”, you cannot play back that disc.

Complete the setting.

Press SET UP twice.

● The normal screen resumes.

NOTE:

If you forget your password, enter “8888” in step C.

Country/Area Code List for Parental Lock

EN 45

AD AE AF AG AI AL AM AN AO AQ AR AS AT AU AW AZ BA BB BD BE BF BG BH BI BJ BM BN BO BR BS BT BV BW BY BZ CA CC CF CG CH CI CK CL CM CN CO CR CU CV CX CY CZ DE DJ DK DM DO DZ EC EE EG EH ER

Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaijan Bosnia and Herzegovina Barbados Bangladesh Belgium Burkina Faso Bulgaria Bahrain Burundi Benin Bermuda Brunei Darussalam Bolivia Brazil Bahamas Bhutan Bouvet Island Botswana Belarus Belize Canada Cocos (Keeling) Islands Central African Republic Congo Switzerland Côte d’Ivoire Cook Islands Chile Cameroon China Colombia Costa Rica Cuba Cape Verde Christmas Island Cyprus Czech Republic Germany Djibouti Denmark Dominica Dominican Republic Algeria Ecuador Estonia Egypt Western Sahara Eritrea

ES ET FI FJ FK FM FO FR FX GA GB GD GE GF GH GI GL GM GN GP GQ GR GS GT GU GW GY HK HM HN HR HT HU ID IE IL IN IO IQ IR IS IT JM JO JP KE KG KH KI KM KN KP KR KW KY KZ LA LB

Spain Ethiopia Finland Fiji Falkland Islands (Malvinas) Micronesia (Federated States of) Faroe Islands France France, Metropolitan Gabon United Kingdom Grenada Georgia French Guiana Ghana Gibraltar Greenland Gambia Guinea Guadeloupe Equatorial Guinea Greece South Georgia and the South Sandwich Islands Guatemala Guam Guinea-Bissau Guyana Hong Kong Heard Island and McDonald Islands Honduras Croatia Haiti Hungary Indonesia Ireland Israel India British Indian Ocean Territory Iraq Iran (Islamic Republic of) Iceland Italy Jamaica Jordan Japan Kenya Kyrgyz stan Cambodia Kiribati Comoros Saint Kitts and Nevis Korea, Democratic People’s Republic of Korea, Republic of Kuwait Cayman Islands Kazakhstan Lao People’s Democratic Republic Lebanon

46 EN

PLAYBACK OPERATIONS (cont.)

LC LI LK LR LS LT LU LV LY MA MC MD MG MH ML MM MN MO MP MQ MR MS MT MU MV MW MX MY MZ NA NC NE NF NG NI NL NO NP NR NU NZ OM PA PE PF PG PH PK PL PM PN PR PT PW PY QA RE RO RU RW

Saint Lucia Liechtenstein Sri Lanka Liberia Lesotho Lithuania Luxembourg Latvia Libyan Arab Jamahiriya Morocco Monaco Moldova, Republic of Madagascar Marshall Islands Mali Myanmar Mongolia Macau Northern Mariana Islands Martinique Mauritania Montserrat Malta Mauritius Maldives Malawi Mexico Malaysia Mozambique Namibia New Caledonia Niger Norfolk Island Nigeria Nicaragua Netherlands Norway Nepal Nauru Niue New Zealand Oman Pana ma Peru French Polynesia Papua New Guinea Philippines Pakistan Poland Saint Pierre and Miquelon Pitcairn Puerto Rico Portugal Pala u Para gu ay Qatar Réunion Romania Russian Federation Rwanda

SA SB SC SD SE SG SH SI SJ SK SL SM SN SO SR ST SV SY SZ TC TD TF TG TH TJ TK TM TN TO TP TR TT TV TW TZ UA UG UM US UY UZ VA VC VE VG VI VN VU WF WS YE YT YU ZA ZM ZR ZW

Saudi Arabia Solomon Islands Seychelles Sudan Sweden Singapore Saint Helena Slovenia Svalbard and Jan Mayen Slovakia Sierra Leone San Marino Senegal Somalia Suriname Sao Tome and Principe El Salvador Syrian Arab Republic Swaziland Turks and Caicos Islands Chad French Southern Territories To go Thailand Taji ki st a n To ke la u Tu rk me ni st an Tunisia Tonga East Timor Turkey Trinidad and Tobago Tu valu Taiw an Tanzania, United Republic of Ukraine Uganda United States Minor Outlying Islands United States Uruguay Uzbekistan Vatican City State (Holy See) Saint Vincent and the Grenadines Venezuela Virgin Islands (British) Virgin Islands (U.S.) Viet Nam Vanuatu Wallis and Futuna Islands Samoa Ye me n Mayotte Yu g o sl a v i a South Africa Zambia Zaire Zimbabwe

RECORDING

Basic Recording

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

EN 47

Set the recording speed.

Press REC MODE repeatedly until the desired recording speed appears.

● Each time you press REC MODE, the recording speed changes as follows: XP ] SP ] LP ] EP ] FR60–FR360*, FR420, FR480 ] (Back to the beginning)

* The value is selectable from 1 to 6 hours in 5-min. increment by

● For details on the recording speed, see page 48.

pressing the value in 30-min. increments, press and hold

repeatedly after selecting “FR60–FR360”. To change

TTENTION:

It is not possible to record programmes on a DVD-R disc which has already been finalised.

REC MODE

REC

STANDBY/ON

S-VIDEO VIDEO

LINK

DV IN

L(MONO)-AUDIO-R

REC MODE4

Start recording.

Press and hold 7, then press 4 on the remote control, or press 7 on the unit.

798

PULL - OPEN

Pause recording.

Press 9.

● To resume recording, press 4.

Stop recording.

Press 8. It takes about 10 seconds to end the writing session when you stop recording.

NOTES:

● It is recommended to format a DVD-RAM disc before use if you use the disc on this unit for the first time.

● When using a brand-new DVD-RW disc, format the disc either in VR mode or in Video mode. ( DVD-RW disc”)

● You can record up to 99 programmes and 999 play lists on each disc.

● Some programmes can only be recorded one time.

● When recording is started, an index of the first part of

recording is automatically recorded ( Database DVD Navi”). To record a satellite programmes, refer to page 61. To delete the index, refer to page 67.

● Recording sometimes may stop or cannot be performed even if there is enough available capacity remaining on the disc.

墌 pg. 97, “Format a

墌 pg. 62, “Library

Load a disc.

A Press x to open the disc tray. B Place a recordable disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Choose a programme.

Press CH +/– or the number keys to select the channel you wish to record.

48 EN

Recording Features

REC MODE

REC

STANDBY/ON

S-VIDEO VIDEO

LINK

L(MONO)-AUDIO-R

PULL - OPEN

DV IN

RECORDING (cont.)

Recording Speed

MPEG2 format is used as recording format. As a guide for picture quality, the “bps” unit is used to represent how much data can be recorded per second. The larger this value is, the better the picture quality becomes but more capacity is required for the recording. Select XP or SP for programmes where quick movement occurs, such as sports programmes, and LP or EP for talk shows, etc. with relatively less movement. The recording speeds for a 4.7 GB disc are set as follows:

Instant Timer Recording (ITR)

This easy method lets you record for from 30 minutes to 6 hours (selectable in 30-min. increments), and shuts the unit off after recording is finished.

1 Start recording.

Press 7 on the unit.

2 Engage the ITR mode.

Press 7 again. On the front display panel, “0:30” appears.

3 Set the recording duration.

If you want to record for more than 30 minutes, press 7 to extend the time. Each press extends recording time by 30 minutes.

NOTE:

You can only perform ITR using the 7 button on the unit’s front panel.

EN 49

Record One Programme While Watching Another

Once recording is in progress, all you need to do is to set the channel controls on the TV for the station you wish to view.

● The programme selected with the TV’s channel controls appears on the TV screen while the one selected with the unit’s CH buttons is recorded on the disc.

Elapsed Recording Time and Disc Remaining Time Indication

During recording, press DISPLAY repeatedly until the desired indication appears on the front display panel.

● Each time you press DISPLAY, the time indication changes as follows:

Elapsed recording time ] Disc remaining time ] Clock ] (Back to the beginning)

Receiving Stereo and Bilingual Programmes

Your unit is equipped with a Sound-Multiplex decoder (A2) and a Digital stereo sound decoder (NICAM) making reception of stereo and bilingual broadcasts possible. When the channel is changed, the type of broadcast being received will be displayed on the TV screen for a few seconds.

Type of Broadcast Being Received

A2 Stereo A2 Bilingual Regular Monaural NICAM Stereo NICAM Bilingual NICAM Monaural

On-screen Display

NOTES:

● “SUPERIMPOSE” must be set to “AUTO”. Otherwise the on-screen displays will not appear. (

● If the quality of stereo sound being received is poor, the broadcast might be received in monaural with better quality.

墌 pg. 90)

Selection of the audio channel to be recorded on a disc

When a programme is recorded on a DVD-RAM or DVD-RW disc in VR mode, all audio channels of the receiving programme are recorded on the disc. When you record a programme on a DVD-R or DVD-RW disc in video mode, select the desired audio channel (from among “NICAM 1/MAIN”, “NICAM 2/SUB”, “MONO”) to be recorded on the disc. (

墌 pg. 89)

NOTE:

Before playing back a programme recorded in stereo, or a bilingual programme, refer to “Audio Channel Selection” on page 30.

50 EN

RECORDING (cont.)

Free Rate Function

To record the entire programme, the unit automatically set the appropriate recording speed depending on the combination of the total time of the programme to be recorded and either the remaining disc space or the specified recording time (from 60 minutes to 480 minutes).

To record the entire programme within the actual remaining disc space

Select “FR (JUST)” in a recording speed selection procedure. (

墌 pg. 53, 55)

● Note that this function is available only for timer programming

recording.

To record the entire programme by specifying the desired recording time

Select “FR60–FR360”, “FR420” or “FR480” in a recording speed selection procedure. (

To record a 25-min. long daily programme five times just on a same disc for example

Perform “G-CODETM/SHOWVIEWTM Timer Programming” (墌 pg. 52) procedure. Be sure to set the recording speed to “FR125” and set Weekly/Daily Rec Function to “MON–FRI” in step E to fit the total recording time to the whole disc space.

墌 pg. 47, 53, 55)

NOTES:

● You can programme this unit to timer-record, regar

When the same programme is recorded in SP mode instead of in “FR125”, the 5th programme cannot be recorded.

TIMER RECORDING

G-CODETM/SHOWVIEW

The G-CODE timer programming system eliminates the need to input channel, date, start and stop time data when setting the timer record function. Simply key in the Gtimer is automatically programmed. You have to set Guide Program numbers, which are assigned to each station for purposes of S stations stored in your unit’s memory to get proper results. Before G-

CODE setup you must have performed Auto Set Up (墌 pg. 19).

CODE number for the TV programme you wish to record (found in most TV listings) and the unit’s

System Setup

HOWVIEW timer programming, for all the

EN 51

IMPORTANT

After setting the Guide Program Numbers, channel positions may be incorrect if you stored or skipped channels. In this case, reperform Guide Program Number setting.

INFORMATION

G-CODE and SHOWVIEW are different trademarks used to represent the same easy recording feature, but only the term G-CODE system will be used in the instructions. If you use the S

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

HOWVIEW system, follow the same instructions listed for the G-CODE system.

Guide Program Number Set

Access the Main Menu screen.

Press SET UP.

Access the “GUIDE PR” screen.

A Press we to select

“INITIAL SET UP”, then press ENTER.

B Press we to select

“GUIDE PR”, then press ENTER.

Enter the Guide Program number.

A Press rt to select “GUIDE PROGRAMME”, then

press ENTER.

B Press rt to select the Guide Program number for the

desired station as shown in the TV listings. Then press ENTER.

● To change the Guide Program number in 10 increments, press

and hold rt.

Enter the receiving channel position number.

A Press rt to select “TV PROGRAMME”, then press

ENTER.

B Press rt to select the number of the unit’s channel

position on which the Guide Program number’s broadcast is received by the unit or the satellite receiver. Then press ENTER.

● If the satellite broadcast is received on your unit’s auxiliary channel “L-2”, select “L-2” for the channel position.

● Repeat steps C and D as necessary.

Complete the setting.

Press SET UP.

Guide Program Number

“Guide Program (GUIDE PROGRAMME) number” refers to the assigned TV station numbers, according to broadcast area, for the Gnumbers can be found in most TV listings.

CODE timer recording. The Guide Program

52 EN

G-CODETM/

HOWVIEW

Timer

Programming

You can programme this unit to timer-record as many as 8 programmes. With the Gsimplified because each TV programme has a corresponding code number which your unit is able to recognize. You can use the remote control to enter the G-

INFORMATION

G-CODE and SHOWVIEW are different trademarks used to represent the same easy recording feature, but only the term GS

HOWVIEW system, follow the same instructions listed for the

G-

SHOWVIEW

CODE system, timer programming is greatly

CODE number.

CODE system will be used in the instructions. If you use the

CODE system.

DVDTV

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

rtwe

ENTER RETURN

0 – 9

G-CODE/

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

TIMER RECORDING (cont.)

Before performing the G-CODE Timer Programming:

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

● Make sure that the unit’s built-in clock is set

properly.

● Be sure to read “G-

CODE

/SHOWVIEW

System Setup”

on page 51

Load a disc.

A Press x to open the disc tray. B Place a recordable disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access the G-CODE screen.

Press G-CODE/SHOWVIEW.

Enter the G-CODE number.

Press the number keys to enter the G-

CODE number of

a programme you wish to record, then press ENTER.

● If you have made a mistake,

DVDTV

press & and input the correct number before you press ENTER.

● To clear all entered numbers at a time, press 8.

● If the number you entered is invalid, “G-CODE/SHOWVIEW

NO. ERROR CONFIRM G-CODE/SHOWVIEW NO. THEN RETRY” appears on the TV screen. Input a valid Gnumber.

● If “GUIDE PROGRAMME IS NOT SET SELECT CHANNEL YOU WANT TO RECORD” appears on the TV screen, set Guide Program Numbers (

● When “PROGRAMME FULL DELETE UNWANTED TIMER PROGRAMME” appears on the TV screen, you need to cancel some of the reserved programmes. (

Check the programme data.

墌 pg. 51) manually.

墌 pg. 59)

CODE

The G-CODE number you entered and the matching timerrecording information are displayed on the TV screen. Check if they are correct.

● To cancel this setting, press G-CODE/SHOWVIEW or RETURN.

IMPORTANT:

Make sure the channel position number you wish to record is displayed; if not, see “Gpage 51 and set the Guide Program number correctly.

CODE

/SHOWVIEW

System Setup” on

EN 53

Set the following recording options as

required.

A Press we to select the desired option. B Press rt to select the desired setting, then press

ENTER.

“REC MODE” ( “Free Rate Function”), “DAILY/WEEKLY” (in the right column, “Daily/Weekly Rec Function” ), “NAME” (

墌 pg. 66, “Modify Programme Name”), and “STOP” (To

advance/go back the stop time by 30 minutes, press and hold rt).

● VPS/PDC recording is not available with this unit in your country.

Press ENTER.

● To programme another timer, repeat steps B – G.

● If “PROGRAM OVERLAPPED” appears on the TV screen, see

“When programmes overlap each other” (

Press # (TIMER). The unit turns off automatically and “#” appears on the front display panel.

● To disengage the timer mode, press # (TIMER) again.

墌 pg. 48, “Recording Speed”) (墌 pg. 50,

Access the confirmation screen.

Complete timer programming.

墌 pg. 60).

Engage the unit’s timer mode.

NOTES:

● There may be cases that G-CODE Timer Programming recording function prolongs the stop time of the programming.

● The beginning of a programme may not be recorded. Also, if the 1st programme’s recording stop time and the 2nd programme’s recording start time is the same, the ending of the 1st programme may not be recorded.

● If the copy limited programme is received during timer-recording, the unit enters Record Pause mode. Recording starts again if it is switched to a recordable broadcast during the time you programmed.

Satellite Receiver Users

To timer-record a satellite broadcast using the G-CODE system:

A Perform “G- B Set the satellite receiver to the appropriate channel before

the selected programme begins.

C Leave the satellite receiver’s power on.

Daily/Weekly Rec Function

You can record programmes with one of the following weekly/ daily timer settings.

WEEKLY Select to record a weekly programme.

MON–FRI Select to record a daily programme from

MON–SAT Select to record a daily programme from

SUN–SAT Select to record a daily programme from

CODE

/SHOWVIEWTM Timer Programming”.

Monday through Friday.

Monday through Saturday.

Sunday through Saturday.

54 EN

Manual Timer Programming

You can programme this unit to timer-record as many as 8 programmes. If you do not know the Gwish to record, use the following procedure to set your unit to timer-record the programme.

Before performing Manual Timer Programming:

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

● Make sure that the unit’s built-in clock is set

properly.

CODE number for the programme you

DVDTV

TV/

VIDEO

STANDBY/ON

DVD

MUTING

DVDTV

TIMER RECORDING (cont.)

Load a disc.

A Press x to open the disc tray. B Place a recordable disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access Programme Check screen.

Press PROG/CHECK.

● When “PROGRAMME FULL DELETE UNWANTED TIMER PROGRAMME” appears on the TV screen, you need to cancel some of the reserved programmes. (

Press rt repeatedly to select “NEW TIMER PROGRAMME”, then press ENTER.

墌 pg. 59)

Access the programme screen.

PROG/

CHECK

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

DEF

REC LINK

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAU SEREC

OPEN/

PROGRESSIVE

SCAN

rtwe

ENTER

Enter the recording date.

Press rt repeatedly to set the desired date.

● The current date appears on the TV screen. The date you enter appears in its place.

Enter the recording start time.

Press we to select “START”, then press rt repeatedly to set the desired start time.

● Each press of rt advances/goes back the start time in 1-min. increments.

● To advance/go back the start time in 30-min. increments, press and hold rt.

EN 55

Enter the recording stop time.

Press we to select “STOP”, then press rt repeatedly to set the desired stop time.

● Each press of rt advances/goes back the stop time in 1-min.

increments.

● To advance/go back the stop time in 30-min. increments, press

and hold rt.

Enter the channel position.

Press we to select “TV PROG”, then press rt repeatedly to select the desired channel.

Set the other recording options as required.

Refer to step E in “G-CODETM/SHOWVIEWTM Timer Programming” (

Access the confirmation screen.

Press ENTER.

Complete timer programming.

Press ENTER.

● To programme another timer, repeat steps B – J.

墌 pg. 52).

Satellite Receiver Users

To timer-record a satellite broadcast using Manual Timer Programming: A Perform “Manual Timer Programming”. Enter “L-2” for the

channel position.

B Set the satellite receiver to the appropriate channel before

the selected programme begins.

C Leave the satellite receiver’s power on.

Engage the unit’s timer mode.

Press # (TIMER). The unit turns off automatically and “#” appears on the front display panel.

● To disengage the timer mode, press # (TIMER) again.

NOTES:

● If the copy limited programme is received during timerrecording, the unit enters Record Pause mode. Recording starts again if it is switched to a recordable broadcast during the time you programmed.

56 EN

On-Disc Timer

TIMER RECORDING (cont.)

To make the disc for On-Disc Timer Programming

Programming

On-Disc Timer Programming is a function used with discs that are especially intended for a specific programme. The disc is then programmed for a programme you always watch every day or every week. Since older programs are automatically overwritten, a single DVD-RAM/RW (VR mode) disc can be used without worrying about how much recording capacity remains. (

墌 pg. 58, “How discs are overwritten”)

You can programme each disc to timer-record as many as 8 programmes.

Before performing On-Disc Timer Programming:

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

●

Make sure that the unit’s built-in clock is set properly.

TTENTION:

If data is recorded on a disc for On-Disc Timer Programming using a unit from another manufacturer, On-Disc Timer Programming may no longer function properly.

PROG/CHECK

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

STANDBY/ON

DEF

REC LINK

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

DVDTV

DVD

DVD1

rtwe

ENTER

DVDTV

Load a disc.

A Press x to open the disc tray. B Place a recordable disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access Programme Check screen.

Press PROG/CHECK.

Access the programme screen.

When On-Disc Timer Programming is made for the first time on the disc

Press rt repeatedly to select “DISC TIMER PRGM”, then press ENTER.

● When some programmes are recorded on the disc, a caution message appears. In such a case, backup the programmes as required, then format the disc before making On-Disc Timer Programming. (

墌 pg. 97, “Format A Disc”)

When On-Disc Timer Programming has already been made on the disc

Press rt repeatedly to select “NEW TIMER PROGRAMME”, then press ENTER.

Enter the recording date.

Press rt repeatedly to set the desired date.

● The current date appears on the TV screen. The date you enter appears in its place.

Enter the recording start time.

Press we to select “START”, then press rt repeatedly to set the desired start time.

● Each press of rt advances/goes back the start time in 1-min. increments.

● To advance/go back the start time in 30-min. increments, press and hold rt.

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

EN 57

Enter the recording stop time.

Press we to select “STOP”, then press rt repeatedly to set the desired stop time.

● Each press of rt advances/goes back the stop time in 1-min.

increments.

● To advance/go back the stop time in 30-min. increments, press

and hold rt.

Enter the channel position.

Press we to select “TV PROG”, then press rt repeatedly to select the desired channel.

Set “DAILY/WEEKLY” option.

Refer to step E in “G-CODETM/SHOWVIEWTM Timer Programming” (

● It is necessary to set “DAILY/WEEKLY” option for On-Disc Timer Programming. ( Function”)

Set the other recording options as required.

Refer to step E in “G-CODETM/SHOWVIEWTM Timer Programming” (

● You can select XP, SP, LP, EP or FR480 mode for “REC MODE”. You cannot select FR (JUST), FR60–FR360 and FR420.

Access the confirmation screen.

Press ENTER.

Complete timer programming.

Press ENTER.

● To programme another timer, repeat steps B – K.

墌 pg. 52).

墌 pg. 53, “Daily/Weekly Rec

墌 pg. 52).

To timer-record the programme with the programmed disc

Load the disc.

A Press x to open the disc tray. B Place the programmed disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Engage the unit’s timer mode.

Press DVD 1. The unit turns off and “ ” appears on the front display panel.

● To disengage the timer mode, press DVD 1 again.

NOTES:

● Even if On-Disc Timer Programming is overlapping with other timer programming, any caution message does not appear. In such a case, recording will be executed in the descending order of the recording start time of the programme.

● On-Disc Timer Programming is not possible on a DVD-RW disc formatted in video mode. ( disc”)

● The information of a programme recorded with On-Disc Timer Programming is not stored in the library. (

● The play list is not created for the programmes recorded with On-Disc Timer Programming. (

● Manual Timer Programming is not possible on the On-Disc Timer Programmed disc. (

● Basic Recording is not possible on the On-Disc Timer Programmed disc. (

● The On-Disc Timer Programming function does not work on the unit form other manufactures even if the On-Disc Timer Programmed disc is loaded.

● If there is a power cut while recording, the recordings before the power cut are not guaranteed.

墌 pg. 47)

墌 pg. 97, “Format a DVD-RW

墌 pg. 72)

墌 pg. 68)

墌 pg. 54)

Satellite Receiver Users

To timer-record a satellite broadcast using the On-Disc Timer Programming function: A Perform “On-Disc Timer Programming”. Enter “L-2” for

the channel position.

B Set the satellite receiver to the appropriate channel before

the selected programme begins.

C Leave the satellite receiver’s power on.

58 EN

How discs are overwritten

(Example 1) To record a 1-hour serial drama every Friday in SP mode

(Example 2) To record a 15-minute serial drama every morning in XP mode

TIMER RECORDING (cont.)

(Example 3) To record a 90-minute serial drama every Sunday in SP mode

NOTE:

On-Disc Timer Programming may not always work as these examples.

MUTING

TV/

VIDEO

STANDBY/ON

EN 59

Access the programme screen.

DVDTV

DVD

DVDTV

Press rt to select the programme, then press ENTER.

DVD 1

REC LINK

rtwe

ENTER

PROG/CHECK

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

DEF

REC LINK

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

Check, cancel and change programmes

Disengage the timer mode.

When “#” lights on the front display panel Press # (TIMER), then press DVD 1.

When “ ” lights on the front display panel Press DVD 1.

When “R-LK” lights on the front display panel Press REC LINK, then press DVD 1.

Change a programme.

Change the settings of the desired recording options as required.

● Refer to steps D – I in “Manual Timer Programming” (

墌 pg. 54).

Complete timer correction.

Press PROG/CHECK.

● The previous screen resumes.

Engage the unit’s timer mode.

For G-CODE or Manual Timer Programming Press # (TIMER).

For On-Disc Timer Programming Press DVD 1.

For Automatic Satellite Programme recording Press REC LINK for 2 seconds or more.

Programme’s information on the front display panel

You can check the details of the programmes even when the power is turned off. (It is necessary that the Power Save mode (

墌 pg. 90, “POWER SAVE”) is disengaged or the unit is not

in timer standby mode.) However, it is not possible to cancel or change the programme’s setting. A Press PROG/CHECK.

● “NEW PROG” or “P-1” (if 8 programmes have already been set) appears.

B Press rt repeatedly until the desired programme

number (“P-1” to “P-8”) appears, then press ENTER.

C Press e.

● Each time you press e, the indication changes as follows (the settings in parentheses are examples):

Date (“DATE 08.03SU”) ] Start time (“ON 11:00”) ] Stop time (“OFF 11:30”) ] Channel (“PR 1”) ] Weekly/Daily (“MO-FR DAILY”) ] Programme number (“P-1”) and Recording speed (SP) ] (Back to the beginning) D Press PROG/CHECK to complete checking.

● The normal display resumes.

Access Programme Check screen.

Press PROG/CHECK.

● To return to the previous screen after you check the programme, press PROG/

CHECK again.

To cancel the programme

Press rt repeatedly to select a programme to be cancelled, then press &.

60 EN

MUTING

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

STANDBY/ON

DEF

DVDTV

DVD

TV VOLUME

TIMER RECORDING (cont.)

When programmes overlap each other

DVDTV

If “PROGRAM OVERLAPPED” appears, you have another programme overlapping the programme you have just made. Confirm with the arrow on “OK”, then press PROG/CHECK. Programme Check screen appears and conflicting programmes will be highlighted in pink.

PROG/CHECK

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

REC LINK

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

ENTER

Example: Programme 3 (you have just made) and Programme 4 overlap each other.

Confirm the overlapping programmes.

Overlapping programmes appear on the TV screen.

NOTE:

If you do not mind this overlap, press PROG/CHECK to finish the timer programme setting. The programme with the lower programme number will be recorded and the other one will not be recorded correctly. If no changes are made for approximately 1 minute, the unit will return to the normal screen.

Select the desired programme to be cancelled

or changed.

Press rt.

To cancel the programme

Press &.

● “THE TIMER PROGRAMMING SETTING WAS CANCELLED” appears on the TV screen for about 5 seconds, then the normal screen resumes.

To change the programme setting Press ENTER.

Change the programme setting.

● Refer to steps D – J in “Manual Timer Programming” (

墌 pg. 54).

Check if the conflict has been settled.

Press PROG/CHECK.

● Programme check screen appears.

Engage the unit’s timer mode.

● Refer to step F in “Check, cancel and change programmes” (

墌 pg. 59).

NOTE:

When any overlaps remain after deletion and modification of programmes, Programme Check screen remains showing the conflicting programmes. In such a case, repeat the procedure above until the conflict is solved.

Automatic Satellite

AUXCANCEL

MEMO/MARK

Programme Recording

EN 61

TTENTION:

● Be sure not to turn on the satellite receiver before the programme is executed; otherwise, the unit will start recording when the satellite receiver’s power is turned on.

● If you have connected another appliance other than a satellite receiver to the L-2 IN connector, be sure not to engage the Automatic Satellite Programme Recording mode; otherwise, the unit will start recording when the connected appliance’s power is turned on.

● Automatic Satellite Programme Recording and timer-recording cannot be done at the same time.

This function allows you to automatically record a satellite programme which is timer-programmed on your external satellite receiver. Connect a satellite receiver to the unit’s L-2 IN connector and programme the timer on the satellite receiver. When the signals come into the unit from the satellite receiver, the unit automatically turns on and starts recording.

REC MODE

REC

TIMER

NEXTPREVIOUS

PAUSEREC

OPEN/

S-VIDEO VIDEO

LINK

L(MONO)-AUDIO-R

REC LINK

PULL - OPEN

DV IN

STANDBY/ON

REC MODE

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

REC LINK

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY/SELECT

Before performing the following steps:

● Make sure the satellite receiver is connected to the unit’s L-2 IN connector. (

● Programme the timer on the satellite receiver.

● Slide the TV/DVD switch to TV.

Select the L-2 SELECT mode.

墌 pg. 85)

Set “L-2 SELECT” to “VIDEO” (

墌 pg. 81, “L-2 Select Setting (L-2 SELECT)”).

Set the recording speed.

Press REC MODE.

Engage the Automatic Satellite Programme

Recording mode.

Press and hold REC LINK for about 2 seconds. “R-LK” appears on the front display panel and the unit turns off automatically.

NOTES:

● To disengage the Automatic Satellite Programme Recording mode, press REC LINK.

● If the unit’s power is off, it is not possible to engage the Automatic Satellite Programme Recording mode.

● In step C, if “R-LK” blinks quickly on the front display panel even though your satellite receiver’s power is off, Automatic Satellite

Programme Recording will not work properly with that satellite receiver*. If this is the case, perform “Manual Timer Programming” (

墌 pg. 54) to timer-record a satellite programme.

* Some satellite receivers output signals even if the power is off. Automatic Satellite Programme Recording is not possible with those satellite receivers.

● “R-LK” blinks on the front display panel while Automatic Satellite Programme Recording is in progress.

● For timer programming of the satellite receiver, refer to the instruction manual of the satellite receiver.

● Automatic Satellite Programme Recording is not possible if your satellite receiver does not have a timer.

● Pressing the unit’s 1 button while Automatic Satellite Programme Recording is in progress turns off the unit’s power and disengages

the Automatic Satellite Programme Recording mode.

● If there are more than one satellite programmes you wish to record with Automatic Satellite Programme Recording, it is not possible to set different recording speeds for each programme.

● Depending on the type of satellite receiver, the unit may not record a slight portion of the beginning of the programme or may record slightly longer than the actual length of the programme.

● If you engage the Automatic Satellite Programme Recording mode when the satellite receiver’s power is on, the unit will not start Automatic Satellite Programme Recording even though “R-LK” blinks on the front display panel. When the satellite receiver shuts off once and is turned back on again, the unit starts recording.

● You can also record a programme from your cable system in the same way if the system has a timer.

● When the Automatic Satellite Programme Recording mode is engaged, or the unit’s power is turned off after Automatic Satellite

Programme Recording is finished, the unit will not enter the Timer mode even though “AUTO TIMER” is set to “ON” (

墌 pg. 91).

62 EN

The Library Database DVD Navi enables you to search and select the desired programmes recorded on a DVD-RAM/R/RW

Library Database DVD Navi

The following screen appears as the Library Database DVD Navi screen when you press NAVIGATION. You can move the arrow to select the desired position on the screen by pressing rt w e on the remote control.

disc very easily. You can record up to 99 programmes on a disc. Each time a programme is recorded on the disc, the information of the programme is registered for the Library Database DVD Navi automatically. So, you can confirm the information of the programmes recorded on the disc with the Library Database DVD Navi screen. And, you can also select one of the programmes recorded on the disc using the Library Database DVD Navi.

A Index

(Small still picture of each programme)

B Names of functions

ORIGINAL ( PLAY LIST ( LIBRARY (

C Remaining time

(Based on the recording speed currently selected)

D Current/Total number of programme(s)

(For example, there are 6 recorded programmes and the programme indicated by the arrow is the 3rd one.)

E Icons

(Indicate the recording situation for each programme.)

F Recording information for the programme indicated by

the arrow

G Guidance for operations H Operational commands

墌 pg. 65)

墌 pg. 68)

墌 pg. 72)

NAVIGATION

The Icons and their meanings

This programme is write-protected.

This programme has stereo sounds.

This programme has bilingual sounds.

This programme was recorded with timer recording.

EN 63

Using Library Database DVD Navi system, you can easily modify registered information, edit the programme or play list, as well as search for the beginning of each programme.

About registration of information

The following information is automatically registered for each programme when ordinary recording or timer recording is performed, then stored in an area specified on the unit.

● index* (reduced still pictures to show programme titles)

● programme title*

● category*

● date and time

● channel

● recording speed

● length of recording time

The items marked with an asterisk (*) can be easily modified and registered again after recording by using Library Database DVD Navi system.

About editing of programmes

Library Database DVD Navi system has the following functions for editing of programmes.

● “Modify Original Information” (

● “Delete programme” (

The limitations of registration

You can register information up to 99 programmes. When the amount of information is at the limits of registration, you cannot record new programme any more. In this case, you need to delete old programmes to register new one. ( “Delete programme”)

墌 pg. 67)

墌 pg. 65)

墌 pg. 67,

NOTE:

Once a DVD-R/RW (Video mode) disc has been finalized, the displays for original and play list do not appear. Only display for library appears.

The display for original recording

The display for play list

The display for library

64 EN

NAVIGATION (cont.)

Scan for Beginning(s) of Programme(s)

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

MEMO

SELECT

CLEAR

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY/SELECT

ON SCREEN

PROGRESSIVE

DVDTV

DVD

TV VOLUME

TIMER

NEXTPREVIOUS

PAU SEREC

OPEN/

SCAN

DVD 1

NAVIGATION

rtwe

ENTER

DVDTV

You can scan the beginning of the programme easily with the Library Database DVD Navi.

Turn on the unit.

Press DVD 1.

Load a disc.

A Press x to open the disc tray. B Place a recorded disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access the Index screen.

A Press NAVIGATION. The

Library Database DVD Navi screen appears.

B Press rt w e to move

the arrow to “ORIGINAL”, then press ENTER.

Select the programme(s).

Press we to move the arrow on the index (small still pictures) of the desired programme.

● When you want the plural programmes to be played back continuously, press MEMO after selecting the desired programme. The numbers of the playback order appear on the index. You can select up to 30 programmes.

● When you want to correct the order, move the arrow on the desired index and press MEMO. The number disappears and the unit re-numbers the other programmes automatically.

● When you want to cancel the order, press CLEAR.

Start playback.

Press ENTER. Or simply press SELECT. The playback starts.

Pause playback.

Press 9.

● To resume normal playback, press 4.

Stop playback.

Press 8.

Modify Original Information

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

DVDTV

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

PROGRESSIVE

SCAN

DVD 1

NAVIGATION

rtwe

ENTER

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

AUDIO SUBTITLE ANGLE

EN 65

Modify Index

Turn on the unit.

Press DVD 1.

Access the Index screen.

A Press NAVIGATION. The Library Database DVD Navi

screen appears.

B Press rt w e to move the arrow to “ORIGINAL”,

then press ENTER.

Select a programme.

DVDTV

Press rt w e to move the arrow to select one programme you want to modify, then press t.

Access the modify screen.

A Press rt w e to move the arrow to “MODIFY”, then

press ENTER.

B Press we to move the arrow to “MODIFY INDEX”.

The “MODIFY INDEX” screen appears.

A Search for the picture

from the programme by pressing the appropriate buttons (3, 4, 5, or

9). The pictures of the programme appear on the left window.

B Confirm the arrow is on “REPLACE”, then press ENTER

to register new index. New index appears on the right window.

● When you press ENTER with the arrow on “RETURN” you can return to the previous screen.

Return to the normal screen.

Press NAVIGATION.

● Press 8 to cancel pause mode after pressing NAVIGATION.

66 EN

NAVIGATION (cont.)

Modify Programme Name

Perform steps A to C of “Modify Index” ( continuing.

Access the modify screen.

A Press rt w e to move the arrow to “MODIFY”, then

press ENTER.

B Press we to move the arrow to “MODIFY NAME”.

The “MODIFY NAME” screen appears.

Enter new name.

Press rt w e to move the arrow to the desired letter or command, then press ENTER. Repeat this process to complete the name.

● To correct a letter, press rt w e to move the arrow to

“DELETE” or “DELETE ALL”, then press ENTER.

● You can enter the letters up to 64.

● You can also enter the new name with number keys. For

example, when you press 2 repeatedly, “A”, “B”, “C”, “a”, “b”, “c”, “2”, and then “A” appear by turns. You can use the following buttons.

Number keys: for entering letters, numbers and blank space

we buttons: for moving the entering or inserting point 8 button: for correcting a letter 2/6 buttons: for changing character tables

墌 pg. 65) before

Modify Category

Perform steps A to C of “Modify Index” (墌 pg. 65) before continuing.

Access the modify screen.

A Press rt w e to move the arrow to “MODIFY”, then

press ENTER.

B Press we to move the arrow to “MODIFY

CATEGORY”. The “MODIFY CATEGORY” screen appears.

Select new category.

Press rt w e to move the arrow to the desired category, then press ENTER.

Press ENTER. The Library Database DVD Navi screen appears again.

Return to the normal screen.

Press NAVIGATION.

Press rt w e to move the arrow to “SAVE”, then press ENTER.

Return to the Library Database DVD Navi

screen.

Press rt w e to move the arrow to “RETURN”, then press ENTER. The Library Database DVD Navi screen appears again.

Return to the normal screen.

Press NAVIGATION.

Protect title

You can protect the programme to prevent accidental erasure of the important programme.

Perform steps A to B of “Modify Index” (墌 pg. 65) before continuing.

Select a programme.

Press rt w e to move the arrow to a programme you want to protect, then press t.

Protect the programme.

Press we to move the arrow to “PROTECT”, then press ENTER.

● “ ” appears.

● To cancel the protection, repeat A – B again.

Return to the normal screen.

Press NAVIGATION.

NOTE:

All the programmes on a disc will be deleted once the disc is formatted even if they are protected titles. (

墌 pg. 97)

EN 67

Delete programme

You cannot record any more with Library Database DVD Navi once the registered programmes on the disc reach 99 programmes. Deleting unnecessary programmes after dubbing (

墌 pg. 79, “Edit To Or From Another Recorder”) or other

operations can increase remaining time and available recording capacity. (For DVD-R discs, although it is possible to delete recorded programmes, available recording capacity does not increase.) The deleted programme is never resumed. Play lists and programme information in the unit’s library are also deleted.

Perform steps A to B of “Modify Index” ( continuing.

Select a programme.

Press we to move the arrow to select one programme you want to delete, then press t.

Access the delete screen.

Press rt w e to move the arrow to “DELETE”, then press ENTER. The message appears for your confirmation.

Confirm the deletion.

Press we to select “YES”, then press ENTER.

● When you cancel the deletion, select “NO”, then press ENTER.

Return to the normal screen.

Press NAVIGATION.

墌 pg. 65) before

Set edit-in and edit-out points.

A Find the point where you

want the deletion to begin, then press ENTER with the arrow on “IN”. The edit-in time is fixed and the elapsed playing time starts counting again.

B Find the point where you want the deletion to end,

then press ENTER with the arrow on “OUT”. The editout time is fixed.

● Press 3, 4, 5, 2, 6 or 9 to find the edit-in and

edit-out points.

Confirm the deletion.

A Press rt w e to move the arrow to “PREVIEW”, then

press ENTER to preview the edited programme.

B Press rt w e to select “EXECUTE”, then press

ENTER.

● If you do not want to delete the scene, select “CLEAR” and press ENTER.

C Press we to select “YES”, then press ENTER.

● The selected scene is deleted.

● To cancel the deletion, press we to select “NO”, then press

ENTER.

To modify the points

A Press we to move the arrow to “CLEAR”, then press

ENTER.

B Repeat step C – E.

Return to the normal screen.

Press NAVIGATION.

Delete unwanted part of the programme

You can delete unwanted part of the programme.

Perform steps A to B of “Modify Index” ( continuing.

Select a programme.

Press we to move the arrow to select one programme whose unwanted part you want to delete, then press t.

Access the delete screen.

Press we to move the arrow to “EDITING”, then press ENTER.

Start playback.

Press 4 to start playback. The playback pictures appear in the window on the screen. The elapsed playing time starts counting with the arrow on “IN”.

墌 pg. 65) before

NOTES:

● There may be a discrepancy of several seconds between the scene you intend to edit, and the scene which is actually edited.

● Available recording capacity may not match the deleted part after deletion.

68 EN

Modify Play List Information

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

NAVIGATION (cont.)

Create Play List

Turn on the unit.

Press DVD 1.

Load a disc.

A Press x to open the disc tray. B Place a DVD-RAM or DVD-RW (VR mode) disc that

was recorded with this unit on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

STANDBY/ON

DEF

REC LINK

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY/SELECT

ON SCREEN

DVD

TV VOLUME

TIMER

NEXTPREVIOUS

PAUSEREC

OPEN/

DVDTV

DVD 1

NAVIGATION

rtwe

ENTER

6 5

DVDTV

AUDIO SUBTITLE ANGLE

8Play List

It is a collection of the scenes. A play list can be freely edited and played back without ever changing any original recording data. Using the random access of a DVD disc (which allows video data to be instantly read no matter where it is on the disc), a play list includes information such as the timer counter for the playback start point and end point, indexes for checking the contents of recorded data, category information, and more. Playback according to a play list you have created allows you to enjoy various combinations of video images from a single programme.

PROGRESSIVE

SCAN

Access the Play List screen.

A Press NAVIGATION. The Library Database DVD Navi

screen appears.

B Press rt w e to move the arrow to “PLAY LIST”,

then press t or ENTER.

Create a play list.

Press rt w e to move the arrow to “CREATE”, then press ENTER.

Start playback.

Press 4 to start playback. The playback pictures appear in the window on the screen. The elapsed playing time starts counting with the arrow on “IN”.

● To locate the beginning of other titles, press 2/6.

Set edit-in and edit-out points.

A Find the point where you

want the created play list to begin, then press ENTER with the arrow on “IN”. The edit-in time is fixed and the elapsed playing time starts counting again.

B Find the point where you want the created play list to

end, then press ENTER with the arrow on “OUT”. The edit-out time is fixed.

● Press 3, 4, 5, 2, 6 or 9 to find the edit-in and edit-out points.

● The edit-out point must come after the edit-in point.

Confirm the play list.

A Press we to move the arrow to “PREVIEW”, then

press ENTER to preview the play list.

B Press we to select “EXECUTE”, then press ENTER.

● The play list is created.

To modify the points

A Press we to move the arrow to “CLEAR”, then press

ENTER.

B Repeat step E – G.

EN 69

Return to the normal screen.

Press NAVIGATION.

NOTES:

● There may be a discrepancy of several seconds between the scene you intend to edit, and the scene which is actually edited.

● The title, index and category of the play list can be modified in the same way as “ORIGINAL”. ( Information”)

● You can modify the play list that has just been created here by adding, moving, or deleting unwanted parts to create a digest edition, etc.

墌 pg. 65, “Modify Original

Add scenes to a play list

Perform steps A to C of “Create Play List” ( continuing.

Select a play list.

Press we to move the arrow to the play list to which you wish to add a scene, then press t.

Access the Editing screen.

A Press we to move the

arrow to “EDITING”, then press ENTER.

B Press we to move the

arrow to “ADD SCENE”.

Start playback.

Press 4 to start playback. The playback pictures appear in the window on the screen. The elapsed playing time starts counting with the arrow on “IN”.

● To locate the beginning of other titles, press 2/6.

墌 pg. 68) before

Confirm the addition.

A Press we to move the arrow to “PREVIEW”, then

press ENTER to preview approximately 5 seconds before and after the edited scene.

B Press we to select “EXECUTE”, then press ENTER.

● The selected scene is added.

To modify the points

A Press we to move the arrow to “CLEAR”, then press

ENTER.

B Repeat step C – E.

Return to the normal screen.

Press NAVIGATION.

NOTE:

There may be a discrepancy of several seconds between the scene you intend to edit, and the scene which is actually edited.

Move scenes

Perform steps A to C of “Create Play List” (墌 pg. 68) before continuing.

Select a play list.

Press we to move the arrow to a play list into which you wish to move a scene, then press t.

Access the Editing screen.

A Press we to move the

arrow to “EDITING”, then press ENTER.

B Press we to move the

arrow to “MOVE SCENE”.

Set edit-in and edit-out points.

A Find the point where you want the added scene to

begin, then press ENTER with the arrow on “IN”. The edit-in time is fixed and the elapsed playing time starts counting again.

B Find the point where you want the added scene to

end, then press ENTER with the arrow on “OUT”. The edit-out time is fixed.

● Press 3, 4, 5, 2, 6 or 9 to find the edit-in and edit-out points.

Start playback.

Press 4 to start playback. The playback pictures appear in the window on the screen. The elapsed playing time starts counting with the arrow on “IN”.

● To locate the beginning of other titles, press 2/6.

70 EN

NAVIGATION (cont.)

Set edit-in and edit-out points.

A Find the point where you want the moved scene to

begin, then press ENTER with the arrow on “IN”. The edit-in time is fixed and the elapsed playing time starts counting again.

B Find the point where you want the moved scene to

end, then press ENTER with the arrow on “OUT”. The edit-out time is fixed.

C Press 4 to start playback. D Find the point where you want the moved scene to be

moved, then press ENTER with the arrow on “MOVE TO”.

● Press 3, 4, 5, 2, 6 or 9 to find the edit-in, edit- out and move-to points.

Confirm the move.

A Press we to move the arrow to “PREVIEW”, then

press ENTER to preview the part approximately 5 seconds before and after the point to which the scene has been moved.

B Press we to select “EXECUTE”, then press ENTER.

● The selected scene is moved.

To modify the points

A Press we to move the arrow to “CLEAR”, then press

ENTER.

B Repeat step C – E.

Return to the normal screen.

Press NAVIGATION.

NOTE:

There may be a discrepancy of several seconds between the scene you intend to edit, and the scene which is actually edited.

Delete unwanted part from play list

Start playback.

Press 4 to start playback. The playback pictures appear in the window on the screen. The elapsed playing time starts counting with the arrow on “IN”.

● To locate the beginning of other titles, press 2/6.

Set edit-in and edit-out points.

A Find the point where you want the deletion to begin,

then press ENTER with the arrow on “IN”. The edit-in time is fixed and the elapsed playing time starts counting again.

B Find the point where you want the deletion to end,

then press ENTER with the arrow on “OUT”. The editout time is fixed.

● Press 3, 4, 5, 2, 6 or 9 to find the edit-in and

edit-out points.

Confirm the deletion.

A Press we to move the arrow to “PREVIEW”, then

press ENTER to preview the scene approximately 5 seconds before and after the deleted part.

B Press we to select “EXECUTE”, then press ENTER.

● The selected scene is deleted.

To modify the points

A Press we to move the arrow to “CLEAR”, then press

ENTER.

B Repeat steps C – E.

Return to the normal screen.

Press NAVIGATION.

NOTE:

There may be a discrepancy of several seconds between the scene you intend to edit, and the scene which is actually edited.

Perform steps A to C of “Create Play List” ( continuing.

Select a play list.

Press we to move the arrow to a play list from which you wish to delete unwanted parts, then press t.

Access the Editing screen.

A Press we to move the

arrow to “EDITING”, then press ENTER.

B Press we to move the

arrow to “DELETE SCENE”, then press ENTER.

墌 pg. 68) before

EN 71

Play back play list

Perform steps A to C of “Create Play List” (墌 pg. 68) before continuing.

Select the play list(s).

Press we to move the arrow on the index (small still pictures) of the desired play list.

● When you want the plural play lists to be played back continuously, press MEMO after selecting the desired play lists. The numbers of the playback order appear on the index. You can select up to 30 play lists.

● When you want to correct the order, move the arrow on the desired index and press MEMO. The number disappears and the unit re-numbers the other play lists automatically.

● When you want to cancel the order, press 8.

Start playback.

Press ENTER. Or simply press 4. The playback starts.

Pause playback.

Press 9.

● To resume normal playback, press 4.

Stop playback.

Press 8.

Delete play list

Perform steps A to C of “Create Play List” (墌 pg. 68) before continuing.

Select a play list.

A Press we to move the arrow to select one play list

you want to delete, then press t.

B Press we to move the arrow to “DELETE”, then press

ENTER.

Confirm the deletion.

Press we to select “YES”, then press ENTER.

● When you cancel the deletion, select “NO”, then press ENTER.

Return to the normal screen.

Press NAVIGATION.

NOTE:

Even if a play list is deleted, the programmes recorded on a DVD disc and the library information are not affected at all.

Modify Index

A Perform steps A to C of “Create Play List” (墌 pg. 68). B Perform steps C to F of “Modify Index” (

墌 pg. 65).

Modify Programme Title

A Perform steps A to C of “Create Play List” (墌 pg. 68). B Perform steps A to E of “Modify Programme Name”

(墌 pg. 66).

Modify Category

A Perform steps A to C of “Create Play List” (墌 pg. 68). B Perform steps A to D of “Modify Category”

(墌 pg. 66).

72 EN

Modify Library Information

Programme information can be registered in the unit’s memory for up to 1,300 programmes. It is helpful when finding out on which disc the desired programme is recorded.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

MUTING

TV/

VIDEO

STANDBY/ON

DVDTV

DVD

DVDTV

NAVIGATION (cont.)

Scan for Programme from library

Turn on the unit.

Press DVD 1.

Access the library screen.

A Press NAVIGATION. The Library Database DVD Navi

screen appears.

B Press rt w e to move the arrow to “LIBRARY”, then

press ENTER.

Sort the information.

Press we to move the arrow to the appropriate sort button to sort the information, then press ENTER.

rtwe

ENTER

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

DEF

REC LINK

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

DVD 1

NAVIGATION

“DISC No.” : Sort by disc number “CATEGORY” : Sort by category “DATE” : Sort by date “NAME” : Sort by name

● The sorting order can be switched between ascending order and descending order by pressing the sort buttons.

Select the programme(s).

Press we to move the arrow to select the desired programme, then press ENTER.

● Playback begins automatically after the selected programme is located.

When the disc that contains the selected programme is not loaded

A screen prompting you to load the designated disc appears. Place the disc whose number is displayed on the screen after pressing ENTER to close the prompt screen. Then perform steps B to D.

Return to the normal screen.

Press NAVIGATION.

NOTE:

If a disc registered in the library is recorded or modified on DVD units from other manufacturers, it may become impossible to operate properly.

EN 73

Register disc

Turn on the unit.

Press DVD 1.

Load a disc.

A Press x to open the disc tray. B Place a disc you want to register on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access the library screen.

A Press NAVIGATION. The Library Database DVD Navi

screen appears.

B Press rt w e to move the arrow to “LIBRARY”, then

press ENTER.

Press we to move the arrow to “REGISTER”, then press ENTER.

Confirm the registration.

Press we to select “REGISTER”, then press ENTER.

Delete information

Turn on the unit.

Press DVD 1.

Access the library screen.

A Press NAVIGATION. The Library Database DVD Navi

screen appears.

B Press rt w e to move the arrow to “LIBRARY”, then

press ENTER.

Select a programme.

A Press rt w e to move the arrow to the appropriate

sort button to sort the information, then press ENTER.

B Press we to move the arrow to a programme you

want to delete, then press t.

Delete the programme.

Press rt w e to move the arrow to “DELETE”, then press ENTER.

Confirm the deletion.

Press we to select “DELETE”, then press ENTER.

Return to the normal screen.

Press NAVIGATION.

NOTES:

● It is not possible to register discs used for On-Disc Timer Programming. (

● It is not possible to register discs formatted on devices other than JVC’s DVD recorders.

● It is not possible to register discs recorded on devices other than JVC’s DVD recorders.

● It is not possible to register discs when “SAVE AS LIBRARY” is set to “OFF” in FUNCTION SET UP menu. (

墌 pg. 56)

墌 pg. 89)

Return to the normal screen.

Press NAVIGATION.

74 EN

NAVIGATION (cont.)

Playback with MP3/JPEG Navigation

This unit can play back discs that MP3 sound files and JPEG image files taken with digital still cameras or other devices are recorded. The MP3/JPEG Navigation enables you to search and select the desired files recorded on CD-R/RW or CD-ROM discs very easily.

The following screen appears as the MP3/JPEG Navigation screen when you press NAVIGATION. You can move the arrow to select the desired position on the screen by pressing rt w e on the remote control.

A Name of the inserted disc. B Sort buttons (“MP3”⁄“JPEG”) C Selected group number/total number of groups on the

disc

D Group name E Return button (“RETURN”) F Group name/Created date G File type indicator

:MP3

:JPEG

H Selected file I Selected file number/total number of files in the group

that contains the selected file

J Programme number/file name

Locating the desired group and tracks

Load a disc.

A Press x to open the disc tray. B Place a disc on the disc tray.

● For details, refer to “Placing a Disc” (墌 pg. 9).

C Press x to close the disc tray.

Access the MP3/JPEG Navigation screen.

Press NAVIGATION. The MP3/JPEG Navigation screen appears.

Display the item.

For MP3 Playback

Press we to move the arrow to “MP3”.

● Only groups which contain MP3 files appear.

For JPEG Playback

Press we to move the arrow to “JPEG”.

● Only groups which contain JPEG files appear.

Select the group.

EN 75

Select the item.

NOTES:

● If you press 4 instead of ENTER in step D, the unit starts playback from the first file of the group.

● JPEG files are played back as a slide show at the set intervals. (

墌 pg. 42, “Select the switching interval of the slide show”)E

76 EN

EDITING

DV Dubbing

You can dub programmes from a camcorder or DV equipment connected to the unit with a DV cable. The unit’s remote control allows you the limited control of the connected camcorder or DV equipment functions during dubbing.

NOTE:

When you connect a PC to the DV IN connector, we do not assure the normal operation of this unit.

Your unit

REC MODE

SAT

STANDBY/ON

Camcorder

S-VIDEO VIDEO

L(MONO)-AUDIO-R

DV IN connector

DV cable

VC-VDV 204U

(not provided)

DV IN

REC MODE

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

REC LINK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

NAVIGATIONTOP MENU

DVDTV

DVD

TV VOLUME

TIMER

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAU SEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

DVDTV

CH +/–

rtwe

ENTER

4 5 8 9

ON SCREEN

DV equipment

DV connector

Make connections.

Connect a camcorder or DV equipment to the DV IN connector on the unit’s front panel.

Prepare the unit for dubbing.

A Load a DVD-RAM/RW/R

disc on the unit.

B Press CH +/– to set the

channel to “DV DUBBING”.

● The “DV DUBBING” controller appears on the TV screen.

● If “ ” does not appear on the “DV DUBBING” controller, make sure the DV equipment is connected correctly.

C Press we to move H to , then press

ENTER.

D Press rt repeatedly to select the desired sound track,

then press ENTER.

AUDIO 1: Select this to record the original stereo sound

AUDIO 2: Select this to record the dubbed stereo sound

MIX: Select this to record the sound of both

● Note that this selection is not available when the source programme is recorded in 16BIT (48 kHz) mode.

E Press REC MODE repeatedly until the desired

recording speed appears. ( Speed”)

played back on the connected DV equipment.

“AUDIO 1” and “AUDIO 2”.

墌 pg. 48, “Recording

EN 77

● To clear the “DV DUBBING” controller from the TV screen, press ON SCREEN.

Stop dubbing.

Press 8 on the remote control.

● Both the unit and the external DV equipment stop dubbing.

NOTES:

● Dubbing copyright guarded programmes is not possible.

● Original DV informations such as the recording date and time

are not recorded.

● The superimposed indication during the operation or dubbing is not recorded.

● Only DV format image can be dubbed; MPEG2 format image cannot be dubbed.

Performing dubbing without using the “DV DUBBING” controller

A Press CH +/– to set the channel to “DV DUBBING”. B Press REC MODE repeatedly until the desired recording

speed appears.

C Start playback on the external DV equipment slightly before

the actual point from where you wish to start dubbing.

D Press and hold 7, then press 4 on the remote control, or

press 7 on the unit.

● Dubbing starts.

E When the dubbing ends, press 8 on the unit, then stop

playback on the external DV equipment.

Prepare the DV equipment for dubbing.

Locate the point from where you want to start dubbing, then stop or pause playback by pressing the following buttons on the remote control: 4, 5, 3, 8, 9

● To play back in slow speed (1/10 of the normal speed), press 9 to pause playback, then press 3 or 5.

● To play back frame-by-frame, press 9 to pause playback, then press 9 repeatedly. Each press of 9 advances a frame.

● To change the playback direction, press 3 or 5.

Start dubbing.

Press we to move the arrow to , then press ENTER.

● Playback on the external DV equipment and recording on the unit should start simultaneously.

● When the playback from the beginning is not possible, the “DV DUBBING” controller cannot be used. Perform dubbing without using the “DV DUBBING” controller. ( column)

● To pause dubbing, press we to move H to , then press ENTER. Both the unit and the external DV equipment pause dubbing. Pressing 9 on the unit also works the same way.

墌 right

78 EN

Edit From A

EDITING (cont.)

You can use a camcorder as the source player and your unit as the recording deck.

Slide the TV/DVD switch to DVD.

Camcorder

A If the camcorder has no S-VIDEO output connector:

AUDIO input

Recorder

REC

STANDBY/ON

VIDEO input

Video cable (not provided)

VIDEO OUT

Camcorder

Player

Audio cable (not provided)

AUDIO OUT

B If the camcorder has an S-VIDEO output connector:

LINK

S-VIDEO VIDEO

L(MONO)-AUDIO-R

Make connections.

A If the camcorder has no S-VIDEO output connector:

— connect the camcorder’s AUDIO OUT and VIDEO OUT connectors to the unit’s AUDIO and VIDEO input connectors on the front panel.

B If the camcorder has an S-VIDEO output connector:

REC MODE

DV IN

— connect the camcorder’s AUDIO OUT and S-VIDEO OUT connectors to the unit’s AUDIO and S-VIDEO input connectors on the front panel.

● When using a monaural camcorder, connect its AUDIO OUT connector to the AUDIO L input connector on your unit.

Set the unit’s input mode.

Press CH +/– to set the channel to “F-1”.

● Set “F-1 INPUT” to “VIDEO” for the VIDEO input connector, or “S-VIDEO” for the S-VIDEO input connector, depending on the connector being used. ( (F-1 INPUT)”)

Set the recording speed.

Press REC MODE repeatedly until the desired recording speed appears.

Prepare the camcorder for dubbing.

Start playback on the camcorder slightly before the actual point from where you wish to start dubbing.

墌 pg. 81, “F-1 Input Setting

Recorder

STANDBY/ON

Camcorder

S-VIDEO input

S-Video cable (not provided)

S-VIDEO OUT

Audio cable (not provided)

AUDIO OUT

Player

AUDIO input

REC LINK

S-VIDEO VIDEO

L(MONO)-AUDIO-R

Start dubbing.

Press and hold 7, then press 4 on the remote control, or

REC MODE

DV IN

press 7 on the unit.

Stop dubbing.

Press 8 on the unit, then stop playback on the camcorder.

NOTES:

● All necessary cables can be obtained from your dealer.

● Refer to the camcorder’s instruction manual for operating

procedure.

● The quality of dubbed picture becomes poorer than that of the original.

Edit To Or From

EN 79

You can use your unit as the source player or as the recording deck.

Another Recorder

Make connections.

A When using your unit as the source player:

— connect its L-1 IN/OUT connector to the recording deck via output cable adapter.

B When using your unit as the recording deck:

— connect its L-2 IN connector to the source player via input cable adapter.

Set the input mode of recording deck.

With this unit, press CH +/– to select “L-2”.

● When using another recorder as the recording deck, refer to its instruction manual.

● When using the L-2 IN connector, set “L-2 SELECT” to “VIDEO”. (

Press REC MODE repeatedly until the desired recording speed appears.

Engage the Play mode of the source player.

Engage the Record mode of the recording deck.

墌 pg. 81, “L-2 Select Setting (L-2 SELECT)”)

Set the recording speed.

Start the source player.

Start the recording deck.

Stop dubbing.

Stop recording on the recording deck, then stop playback on the source player.

NOTES:

● All necessary cables can be obtained from your dealer.

● When you use this unit as the source player for editing, be sure

to set “SUPERIMPOSE” to “OFF” before starting. (

● If you are using another recorder with S-Video and Audio output connectors, connect its S-Video and Audio output connectors to this unit’s S-VIDEO and AUDIO input connectors on the front panel. Then, set the unit’s input mode to “F-1” in step B, and set “F-1 INPUT” to “S-VIDEO”. (

墌 pg. 81, “F-1 Input Setting (F-1 INPUT)”)

墌 pg. 90)

80 EN

Output/Input Set

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

Access the Output/Input Set screen.

A Press we to move the

arrow to“FUNCTION SET UP”, then press ENTER.

B Press we to move the

arrow to “VIDEO IN/ OUT”, then press ENTER.

EDITING (cont.)

rtwe

ENTER

SET UP

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

DVDTV

L-1 Output and L-1 Input Setting (L-1 OUTPUT and L-1 INPUT)

The L-1 IN/OUT connector accepts and delivers either a composite signal (regular video signal) or a Y/C signal (a signal in which the luminance and chrominance signals are separated). Set “L-1 OUTPUT” and “L-1 INPUT” to the appropriate mode depending on the type of appliance connected to the unit’s L-1 IN/OUT connector.

NOTES:

● When you connect the unit using the provided cable adapter, be sure to set “L-1 OUTPUT” to “SCART VIDEO”. If “L-1 OUTPUT” is set to “SCART S-VIDEO” or “SCART RGB”, the image may be distorted.

● When using the provided output cable adapter, L-1 IN/OUT connector can be used only as an output connector.

● Component video signals are not output from the L-1 IN/OUT connector.

● When Progressive scan mode is engaged, it is not possible to select the setting of “L-1 OUTPUT”. (

Access the Main Menu screen.

Press SET UP.

墌 pg. 99)

Select the output or input mode for the L-1

IN/OUT connector.

A Press rt to move the

arrow to “L-1 OUTPUT” or “L-1 INPUT”, then press ENTER.

B Press rt to select the

appropriate setting, then press ENTER.

(The boldface settings in the table below indicate the settings at your purchase.)

8 L-1 OUTPUT

SCART VIDEO: If a connected appliance’s input

SCART S-VIDEO*: If a connected appliance’s input

SCART RGB*: If a connected appliance’s input

COMPONENT: If a connected appliance’s input

8 L-1 INPUT

VIDEO: If a connected appliance’s output

S-VIDEO*: If a connected appliance’s

* These settings are not correctly operative when using the

provided cable adapter.

is compatible only with regular video signals, set to “SCART VIDEO”.

is compatible with Y/C signals, set to “SCART S-VIDEO”. (For connection, be sure to use a 21pin SCART cable that is compatible with the Y/C signal.)

is compatible with RGB signals, set to “SCART RGB”.

is compatible with Y/P

B/PR

signals, set to “COMPONENT”. You can obtain a high-quality Y/ P

picture. Switch the TV to

B/PR

the input that you can watch component video pictures.

is compatible only with regular video signals, set to “VIDEO”.

output is compatible with Y/C signals, set to “S-VIDEO”. (For connection, be sure to use a 21pin SCART cable that is compatible with the Y/C signal.)

EN 81

Return to the normal screen.

Press SET UP.

L-2 Select Setting (L-2 SELECT)

Set “L-2 SELECT” to the appropriate mode depending on the type of appliance connected to the unit’s L-2 IN connector.

NOTE:

When you connect the unit using the provided cable adapter, be sure to set “L-2 SELECT” to “VIDEO”. If “L-1 INPUT” is set to other than “VIDEO”, the image may be distorted.

Perform steps A and B of “L-1 Output and L-1 Input Setting (L-1 OUTPUT and L-1 INPUT)” on page 80.

Select the input mode for the L-2 IN

connector.

A Press rt to move the

arrow to “L-2 SELECT”, then press ENTER.

B Press rt to select the

appropriate setting, then press ENTER.

(The boldface settings in the table below indicate the settings at your purchase.)

8 L-2 SELECT

Select “VIDEO” to use this unit as the recording deck with the player connected to the L-2 IN connector, or to use the satellite receiver connected to the L-2 IN connector.

VIDEO: If a connected appliance’s output is

S-VIDEO*: If a connected appliance’s output is

SAT VIDEO**: If a connected satellite receiver’s

SAT S-VIDEO**: If a connected satellite receiver’s

* These settings are not correctly operative when using the

provided cable adapter.

** These settings are not available with this unit.

compatible only with regular video signals, set to “VIDEO”.

compatible with Y/C signals, set to “S-VIDEO”. (For connection, be sure to use a 21-pin SCART cable that is compatible with the Y/C signal.)

output is compatible only with regular video signals, set to “SAT VIDEO”.

output is compatible with Y/C signals, set to “SAT S-VIDEO”. (For connection, be sure to use a 21-pin SCART cable that is compatible with the Y/C signal.)

F-1 Input Setting (F-1 INPUT)

Set “F-1 INPUT” to the appropriate mode depending on the connector (VIDEO or S-VIDEO) being used on the front panel.

Perform steps A and B of “L-1 Output and L-1 Input Setting (L-1 OUTPUT and L-1 INPUT)” on page 80.

Select the input mode for the VIDEO/

S-VIDEO connector.

A Press rt to move the

arrow to “F-1 INPUT”, then press ENTER.

B Press rt to select the

appropriate setting, then press ENTER.

(The boldface settings in the table below indicate the settings at your purchase.)

8 F-1 INPUT

VIDEO: When connecting an appliance to

the VIDEO input connector, set to “VIDEO”.

S-VIDEO: When connecting an appliance to

the S-VIDEO input connector, set to “S-VIDEO”.

Return to the normal screen.

Press SET UP.

Return to the normal screen.

Press SET UP.

82 EN

Digital Audio

EDITING (cont.)

You can dub selected audio from a DVD or Audio CD disc to a digital audio device. However, it is not possible to dub copy-protected discs.

Example: Dubbing to an MD

Dubbing

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

Make connections.

Connect the unit and a digital audio device using either an optional optical cable or an optional coaxial cable.

Place a disc and load an MD.

For the unit

A Press x to open the disc tray. B Place a disc on the disc tray. C Press x to close the disc tray.

For the digital audio device

Load an MD.

Prepare the unit for dubbing.

A Select the audio to be dubbed. B Start playback slightly before the actual point from

where you wish to start dubbing.

C Press 9 to pause playback.

Prepare the digital audio device for dubbing.

Select the input mode.

Start dubbing.

A Press 4 to start playback on the unit. B Start recording on the digital audio device.

Stop dubbing.

Stop recording on the digital audio device. Then press 8 to stop playback on the unit.

NOTE:

There may be a discrepancy of several seconds between where you intend editing to start, and where it actually starts.

REMOTE CONTROL

Remote Control Functions

EN 83

On the remote control

Keep pressing SET UP down during steps A – B.

Change the remote control code.

Press the number key “1” for 1, “2” for 2, “3” for 3 or “4” for 4.

Remote 1/2/3/4 Code Switching

The remote control is capable of controlling four JVC video units independently. Each of the units can respond to one of four codes (1, 2, 3 or 4). The remote control is preset to send 3 code signals because your unit is initially set to respond to 3 code signals. You can easily modify your unit to respond to 2, 3 or 4 code signals.

Slide the TV/DVD switch to DVD.

REC MODE

REC LINK

STANDBY/ON

1 – 4

MUTING

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

STANDBY/ON

DEF

DVDTV

DVD

TV VOLUME

L(MONO)-AUDIO-R

S-VIDEO VIDEO

DVD F

PULL - OPEN

DV IN

DVDTV

Set the remote control code.

Press ENTER to set the code.

On the unit

Turn off the unit.

Press 1 on the unit.

Display the code.

Press 4 on the unit for over 5 seconds while the unit is turned off.

● The code currently set appears on the front display panel.

Change the unit’s code.

Press 8 on the remote control.

● The code currently set on the remote control blinks on the front display panel for approximately 5 seconds, and is applied to the unit.

NOTE:

When “POWER SAVE” is set to “ON” (墌 pg. 90), it is not possible to change the remote code.

ENTER

SET UP

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

REC LINK

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

PROGRESSIVE

SCAN

84 EN

REMOTE CONTROL (cont.)

TV Multi-Brand Remote Control

Your remote control can operate the basic functions of your TV set. In addition to JVC TVs, other manufacturer’s TVs can also be controlled.

Before performing the following steps:

● Turn off the TV using its remote control.

● Slide the TV/DVD switch to TV.

Set the TV brand code.

Keep pressing SET UP down during step A. Enter your TV’s brand code using the number keys, then press ENTER. Press TV 1 on the unit’s remote control to turn on the TV and try operations (

● Once you have set the remote control to operate the TV, you do not have to repeat this step until you replace your remote control’s batteries.

● Some brands of TVs have more than one code. If the TV does not function with one code, try entering another.

Operate the TV.

Press the corresponding button: TV 1, TV/VIDEO, CH +/–, TV VOLUME +/– (Volume), TV MUTING, number keys.

● For some brands of TVs, you must press ENTER after having pressed the number keys.

墌 step B).

IMPORTANT:

Although the provided remote control unit is compatible with JVC televisions, as well as many other models, it may not work with your TV, or in some instances, may have limited function capability.

SYSTEM CONNECTIONS

Connecting To A Satellite Receiver

EN 85

Connect the satellite receiver to the L-2 IN connector, then connect the L-1 IN/OUT connector to the TV’s connector via cable adapters. Make sure that the unit is turned on to view satellite broadcast with this connection.

Outdoor unit

Satellite cable

Satellite receiver

Aerial

TV aerial cable

NOTES:

● Set “L-2 SELECT” to “VIDEO”. (墌 pg. 81)

● You can use the Automatic Satellite Programme Recording

function (

● To record a programme via the satellite receiver, select L-2 mode by pressing CH +/– so that “L-2” appears on the front display panel.

● For details, refer to the instruction manual of the satellite receiver.

ANTENNA IN

ANTENNA OUT

墌 pg. 61) with this connection.

Aerial connector

Back of TV

Audio/video input connectors

Input Cable Adapter

Output Cable Adapter

Mains outlet

Back of unit

86 EN

SYSTEM CONNECTIONS (cont.)

Connecting To A Dolby Digital Decoder Or An Amplifier With Built-in DTS

These instructions enable you to connect your unit to a Dolby Digital decoder or an amplifier with built-in DTS.

Dolby Digital decoder or amplifier with built-in DTS

To DIGITAL AUDIO

input

Coaxial cable

(not provided)

Optical cable

(not provided)

Make connections.

Connect the unit and a Dolby Digital decoder or an amplifier with built-in DTS using either an optional optical cable or an optional coaxial cable.

NOTES:

● For Dolby Digital sound, set “DIGITAL AUDIO OUT” to “DOLBY DIGITAL/PCM”. (

● For DTS sound, set “DIGITAL AUDIO OUT” to “STREAM/ PCM”. (

墌 pg. 88)

CAUTIONS:

● This unit has a dynamic range of more than 110 dB with regards to its Hi-Fi audio capability. It is recommended that you check the maximum level if you are going to listen to the Hi-Fi audio signals through a stereo amplifier. A sudden surge in the input level to the speakers may damage them.

● Some speakers and televisions are specially shielded to prevent television interference. If both are of the non-shielded type, do not place the speakers adjacent to the TV set as this can adversely affect the playback picture.

墌 pg. 88)

Back of unit

When you can’t switch the audio channel of a bilingual programme

When the unit is connected with a digital audio device using an optional optical cable and “DIGITAL AUDIO OUT” is set to “DOLBY DIGITAL/PCM”, it is not possible to switch the audio channel of a bilingual programme recorded on a DVD-RAM or DVD-RW (VR mode) disc. In this case, perform the following steps using the remote control to switch “DIGITAL AUDIO OUT” from “DOLBY DIGITAL/PCM” to “PCM ONLY”.

A Press SET UP to access the Main Menu screen. B Press we to select “DVD SET UP”, then press ENTER. C Press we to select “AUDIO OUTPUT”, then press

D Press rt to select “DIGITAL AUDIO OUT”, then press

E Press rt to select “PCM ONLY”, then press ENTER.

F Press SET UP to complete the setting. G Press AUDIO to select the desired audio channel.

DIGITAL OUT

(COAXIAL)

ENTER.

(

墌 pg. 88)

(

墌 pg. 30, “Audio Channel Selection”)

DIGITAL OUT (OPTICAL)

Note for connection:

Remove the protection cap from the optical cable.

SUBSIDIARY SETTINGS

Mode Set

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

EN 87

Various modes of this unit are categorized into menus nested in 2 levels shown in the following table. To change the settings of these modes, find the desired mode in the menu (for details on each menu, see pages 88 through 91), then follow the procedure below.

DVD SET UP LANGUAGE SET (墌 pg. 23)

AUDIO OUTPUT (墌 pg. 88) UTILITY (墌 pg. 43, 97, 98)

SET UP

TV/

MUTING

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

G-CODE

SHOW VIEW

ENTER

CLEAR

STOP/

REC MODE LIVE CHECK

SET UP DISPLAY

ON SCREEN

AUDIO SUBTITLE ANGLE

STANDBY/ON

DEF

REC LINK

DVDTV

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

PROGRESSIVE

SCAN

rtwe

ENTER

FUNCTION SET UP VIDEO IN/OUT (墌 pg. 21, 80)

DVDTV

RECORDING SET (墌 pg. 89) DISPLAY SET (墌 pg. 90) OTHERS (墌 pg. 91)

INITIAL SET UP AUTO CH SET (墌 pg. 92)

MANUAL CH SET (墌 pg. 93) GUIDE PR (墌 pg. 51) CLOCK SET (墌 pg. 96)

● The procedure below shows how to set the desired option of the “AUDIO REC” mode as an example.

Access the Main Menu screen.

Press SET UP.

Access the “RECORDING SET” screen.

A Press we to select

“FUNCTION SET UP”, then press ENTER.

B Press we to select

“RECORDING SET”, then press ENTER.

Select the desired option.

A Press rt to select

“AUDIO REC”, then press ENTER.

B Press rt to select the

desired option, then press ENTER.

Complete the setting.

Press SET UP.

88 EN

AUDIO OUTPUT

(The boldface settings in the table below indicate the settings at your purchase.)

SUBSIDIARY SETTINGS (cont.)

8 DIGITAL AUDIO OUT

DOLBY DIGITAL/PCM

STREAM/PCM

PCM ONLY

8 ANALOG AUDIO OUT

STEREO

DOLBY SURROUND

8 D. RANGE CONTROL

NORMAL

WIDE RANGE TV MODE

Set to the appropriate mode according to the type of the device connected to DIGITAL OUT connector.

DOLBY DIGITAL/PCM:

Select this when you connect the digital input connector of a Dolby Digital decoder or an amplifier with a built-in Dolby Digital decoder.

STREAM/PCM:

Select this when you connect the digital input connector of an amplifier with a built-in DTS, Dolby Digital, or MPEG multichannel decoder.

PCM ONLY:

Select this when you connect the linear PCM digital input of other audio equipment (amplifier, MD or DAT deck, etc.).

Select the appropriate setting to accommodate the unit to the connected A/V equipment. This function takes effect when a DVD VIDEO disc is played back.

STEREO:

Select this when listening to conventional two-channel stereo audio with the unit’s AUDIO OUT connectors connected to a stereo amplifier/receiver or TV set, or in case you want to record the audio from a DVD VIDEO disc to a Mini Disc, etc.

DOLBY SURROUND:

Select this when listening to multichannel surround audio with the unit’s AUDIO OUT connectors connected to an amplifier/receiver with a built-in surround decoder or a surround decoder.

The dynamic range (the difference between the loudest sound and the quietest one) can be compressed during playback of a programme encoded in Dolby Digital format. This function takes effect when a DVD VIDEO disc recorded in Dolby Digital format is played back at low or middle volume.

NORMAL:

Normally select this setting to activate this function.

WIDE RANGE:

Select this to deactivate this function when you enjoy wide dynamic range programme.

TV MODE:

Select this when you hear the sound through the TV’s speaker(s).

8 OUTPUT LEVEL

STANDARD

LOW

NOTES:

● This function takes no effect on programmes other than that recorded in Dolby Digital format.

● This function dose not work when Simulated Surround Effect is activated. (

● The effect of “NORMAL” and “WIDE RANGE” may not be different depending on discs.

You can lower the output level of analog audio to accommodate the unit to the connected A/V equipment.

STANDARD:

Normally select this setting.

LOW:

The output level of analog audio is lowered.

墌 pg. 40)

RECORDING SET

(The boldface settings in the table below indicate the settings at your purchase.)

EN 89

8 SAVE AS LIBRARY

OFF

8 XP MODE REC AUDIO

DOLBY DIGITAL

LINEAR PCM

8 AUDIO REC

NICAM 1/MAIN

NICAM 2/SUB MONO

8 INPUT COLOUR SYSTEM

PAL

SECAM

When this function is set to “ON”, the recording information is automatically stored in the library. For details, refer to “Modify Library Information” (墌 pg. 72).

You can select the audio format when you record a programme in XP mode. When this function is set to “LINEAR PCM”, you can obtain a high-quality audio sound.

DOLBY DIGITAL:

To record in Dolby Digital format.

LINEAR PCM:

To record in Linear PCM format.

You can select the desired NICAM audio channel to be recorded on a DVD-R/ RW (Video mode) disc.

NICAM 1/MAIN:

To record the main language of NICAM audio.

NICAM 2/SUB:

To record the sub language of NICAM audio.

MONO:

To record the standard (monaural) sound of NICAM audio.

NOTE:

This function works only for the NICAM bilingual programme.

You can play back PAL discs, or record PAL and SECAM signals on this unit. Select the appropriate colour system.

PAL: To record PAL signals. SECAM: To record SECAM signals.

90 EN

DISPLAY SET

(The boldface settings in the table below indicate the settings at your purchase.)

SUBSIDIARY SETTINGS (cont.)

8 SUPERIMPOSE

OFF

AUTO

8 GREY BACK

OFF

8 DIMMER

BRIGHT

DIMMED1 DIMMED2 OFF

8 POWER SAVE

OFF

You can select the modes of indications superimposed on the TV screen.

OFF:

To turn off superimposed indications.

AUTO:

To superimpose operational indications for approximately five seconds just after the corresponding operation.

NOTES:

● When you use this unit as the source player for editing, be sure to set “SUPERIMPOSE” to “OFF” before starting. (

● When you select “AUTO”, during playback, the operation mode indicators may be disturbed depending on the type of disc being used.

When this function is set to “ON”, the TV screen becomes all grey when receiving a channel not in use.

墌 pg. 79, “Edit To Or From Another Recorder”)

NOTE:

When you want to receive an unstable channel with poor signals, set this function to “OFF”.

You can change the brightness of the front display panel and blue lamp of the disc tray.

BRIGHT:

Normally select this.

DIMMED1/DIMMED2:

To change the brightness level.

OFF:

To dim the front display panel.

When this function is set to “ON”, you can reduce the power consumption while the unit is turned off.

NOTES:

● During Power Save mode — — the front display panel will be turned off.

● Power Save does not work when — — the unit is in the Timer mode. — the unit’s power is turned off after timer-recording or Instant Timer Recording. — the Automatic Satellite Programme Recording mode is engaged. (

● It takes some time for the unit to complete initialisation after you turn on unit power, with “WAKE UP” blinking on the front display panel.

墌 pg. 61)

8 ON SCREEN LANGUAGE

This unit offers you the choice to view on-screen messages in 10 different languages. You can change the language setting manually as required. For details, refer to “On-screen Language Set” (

墌 pg. 22).

OTHERS

(The boldface settings in the table below indicate the settings at your purchase.)

EN 91

8 AUTO TIMER

OFF

8 RESUME

OFF DISC RESUME

When this function is set to “ON”, the timer is automatically engaged when the unit power is turned off, and automatically disengaged when the unit is powered back on.

NOTE:

For safety, when “AUTO TIMER” is set to “OFF”, all other functions are disabled while the Timer mode is engaged. To disengage the timer, press # (TIMER).

When this function is set to “ON” or “DISC RESUME”, you can use the resume function. (

墌 pg. 27)

ON: You can start playback from the resume point of the placed

disc.

OFF: You cannot use the resume function. DISC RESUME:

The unit retains a memory of the resume points of the last 30 discs played back, even though they have been ejected.

NOTE:

“DISC RESUME” setting works on DVD VIDEO, VCD, SVCD and already finalised DVD-R/DVD-RW (video mode) discs. For other types of discs, the function under “ON” setting will be applied even if “RESUME” is set to “DISC RESUME”.

92 EN

Tuner Set

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

DVDTV

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

PROGRESSIVE

SCAN

rtwe

ENTER

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

SET UP

AUDIO SUBTITLE ANGLE

IMPORTANT:

Perform the following steps only if — — Auto Channel Set has not been set correctly by Auto Set Up. (

墌 pg. 19)

— you have moved to a different area or if a new station starts broadcasting in your area.

SUBSIDIARY SETTINGS (cont.)

Your unit needs to memorise all necessary stations in channel positions in order to record TV programmes. Auto Channel Set automatically assigns all receivable stations in your area to call them up by using the CH +/– buttons without going through any vacant channels.

Auto Channel Set

Access the Main Menu screen.

DVDTV

Press SET UP.

Access the “AUTO CH SET” screen.

A Press we to select

“INITIAL SET UP”, then press ENTER.

B Press we to select

“AUTO CH SET”, then press ENTER.

Select the TV system.

Press rt to select the appropriate TV system (refer to the table below).

Major Countries/Areas TV System

Australia, New Zealand, Kuwait, U.A.E., Indonesia, Singapore, Thailand, Malaysia, Iran, Saudi Arabia, Egypt, Morocco, Lebanon, Iraq

China, Mongolia, Russia D/K

Hong Kong I

Perform Auto Channel Set.

B/G

Press ENTER.

● The Auto Set screen appears, and remains on screen while the unit searches for receivable stations. Wait until the TV screen as shown in step E appears.

EN 93

View the Confirmation screen.

“SCAN COMPLETED” is displayed on the TV screen. Press “OK”, then the Confirmation screen appears. The confirmation screen lists the channel position number (PR), station channel number (CH) of all stored broadcast stations. The programme currently received on the selected channel position appears behind the confirmation screen. To view the next page, press rt w e.

Complete the setting.

Press SET UP.

● Using the Confirmation screen, you can skip or add channel positions, enter station names and perform other operations. Refer to pages 93 – 95 for the procedures.

● Depending on reception conditions, the stations may not be stored in order.

Manual Channel Set

Store channels that were not stored during Auto Set Up (

墌 pg. 19) or Auto Channel Set (墌 pg. 92).

NOTES:

● Fine tuning is performed automatically during Auto Channel Set. If you want to perform tuning manually, refer to “FineTuning Channels Already Stored” (

● If you perform Auto Channel Set when the aerial cable is not connected properly, “SCAN COMPLETED –NO SIGNAL–” appears on the TV screen in step E. In such a case, make sure of the aerial connection and press ENTER; Auto Channel Set will start again.

墌 pg. 95, “TV System Selection — When you see the picture

but the audio can’t be heard or sounds unnatural”)

墌 pg. 95).

Access the Main Menu screen.

Press SET UP.

Access the Confirmation screen.

A Press we

94 EN

SUBSIDIARY SETTINGS (cont.)

Select the band.

A Press rt to select

“BAND”, then press ENTER.

B Press rt to change the

band between CH (regular) and CC (cable), then press ENTER.

Enter the channel.

A Press rt to select “CH”, then press ENTER. B Press rt to input the channel number you want to

store, then press ENTER.

● Repeat steps C – E as necessary.

● For fine tuning adjustment, press rt to select “FINE”, then

press ENTER. Press rt to perform fine-tuning.

Close the Confirmation screen.

Press SET UP three times.

● To change positions, see “Change Station Channel Position” (in the right column).

● If you wish to set station names other than the ones registered in your unit, see “Set Stations” (

墌 pg. 95).

TTENTION:

Guide Program numbers are not set when channels are stored manually. ( Setup”)

墌 pg. 51, “G-CODE

/SHOWVIEW

System

Delete A Channel

Perform steps A and B of “Manual Channel Set” on page 93 to access the Confirmation screen before continuing.

Select the item.

Press rt w e to select the item you want to delete.

Delete a channel.

Press &.

● The item next to the cancelled one moves up one line.

● Repeat steps A and B as necessary.

Close the Confirmation screen.

Press SET UP twice.

Change Station Channel Position

Perform steps A and B of “Manual Channel Set” on page 93 to access the Confirmation screen before continuing.

Select the item.

Press rt w e to select the item you want to move, then press ENTER.

Select the new position.

Press rt w e to select the new channel position, then press ENTER.

Example: If you moved the

● Repeat steps A and B as necessary.

Press SET UP twice.

station in position 4 to position 2, the stations originally in positions 2 and 3 each move down one space.

Close the Confirmation screen.

EN 95

Set Stations

You can set the desired station name.

Perform steps A and B of “Manual Channel Set” on page 93 to access the Confirmation screen before continuing.

Select the channel to set the station name.

Press rt w e to select the channel you want to set the station name, then press ENTER twice.

Select the character for station name.

Press rt to select “ID”, then press ENTER twice. ID setting screen appears.

Enter the character.

A Press we to locate the character insertion point. B Press rt to cycle through the characters (A–Z, 0–9,

–, f, +, I (space)) and stop when the desired character is indicated, then press e to enter.

C Enter the remaining characters the same way

(maximum of 4).

D After entering all characters, press we to select “OK”,

then press ENTER.

Close the Confirmation screen.

Press SET UP three times.

NOTE:

The characters available for the station name (ID) are A–Z, 0–9, –,

f, +, I (space) (maximum of 4).

TV System Selection — When you see the picture but the audio can’t be heard or sounds unnatural

Perform steps A and B of “Manual Channel Set” on page 93 to access the Confirmation screen before continuing.

Select the channel.

Press rt w e to select the channel you want to change its TV system, then press ENTER twice.

Select the TV system.

A Press rt to select “TV SYSTEM”, then press ENTER. B Press rt until the appropriate TV system appears,

then press ENTER.

Major Countries/Areas TV System

Australia, New Zealand, Kuwait, U.A.E., Indonesia, Singapore, Thailand, Malaysia, Iran, Saudi Arabia, Egypt, Morocco, Lebanon, Iraq

China, Mongolia, Russia D/K

Hong Kong I

Close the Confirmation screen.

Press SET UP three times.

B/G

Fine-Tuning Channels Already Stored

Perform steps A and B of “Manual Channel Set” on page 93 to access the Confirmation screen before continuing.

Select the channel to fine-tune.

Press rt w e to select the channel you want to finetune, then press ENTER twice.

Perform fine-tuning.

A Press rt to select “FINE”. B Press we until the picture appears in its best quality.

● Repeat steps A – B as necessary.

Close the Confirmation screen.

Press SET UP three times.

96 EN

Clock Set

SUBSIDIARY SETTINGS (cont.)

Access the Main Menu screen.

Press SET UP.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD .

DVDTV

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/

rtwe

ENTER

SET UP

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

Access the “CLOCK SET” screen.

A Press we to select

“INITIAL SET UP”, then press ENTER.

B Press we to select

DVDTV

“CLOCK SET”, then press

THU

ENTER.

Set the date and time.

A Press rt to select “YEAR”, then press ENTER. B Press rt to set the year, then press ENTER.

● Repeat the same procedure to set the date and time. When

you set the time, press and hold rt to change the time by 30 minutes.

● When you set the date, press and hold rt to change the date

by 15 days.

Start the clock operation.

Press SET UP.

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

Format A Disc

Some DVD-RAM/RW discs are unformatted. Format the disc when you use an unformatted disc or you want to delete all recordings and data on the disc.

TTENTION:

● When a disc is formatted, all recordings and data are erased. It is impossible to restore them.

● Never turn off the unit or disconnect the mains power cord while “NOW FORMATTING...” is displayed on the TV screen.

Format a DVD-RAM disc

Access the Main Menu screen.

Press SET UP.

Access the “UTILITY” screen.

A Press rt w e to select

“DVD SET UP”, then press ENTER.

B Press we to select

“UTILITY”, then press ENTER.

EN 97

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

● Load a DVD-RAM/RW disc to format.

TV/

VIDEO

ABC

JKLGHI MNO

TUVPQRS WXYZ

AUXCANCEL

MEMO/MARK

PROG/CHECK

ENTER

CLEAR

STOP/

ON SCREEN

STANDBY/ON

DEF

REC LINK

DVD

TV VOLUME

TIMER

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

OPEN/ CLOSE

MUTING

G-CODE

SHOW VIEW

REC MODE LIVE CHECK

SET UP DISPLAY

DVDTV

SET UP

AUDIO SUBTITLE ANGLE

PROGRESSIVE

SCAN

rtwe

ENTER

Format the disc.

A Press rt to select “FORMAT”, then press ENTER.

Press we to select “YES”, then press ENTER when “DISC WILL BE FORMATTED” appears on the TV screen.

B Press we to select “OK”, then press ENTER when

DVDTV

“DISC FORMATTING WAS SELECTED” appears on the TV screen.

Format a DVD-RW disc

Perform steps A to B of “Format a DVD-RAM disc” on the above before continuing.

Format the disc.

A Press rt to select “FORMAT”, then press ENTER.

Press we to choose “VR MODE” or “VIDEO MODE”, then press ENTER when “DISC WILL BE FORMATTED” appears on the TV screen. “VR MODE”: To be chosen when you want to

record, erase, or edit data on the disc repeatedly.

“VIDEO MODE”:To be chosen when you want to

erase all the data on the disc once played back to record new data, or play the disc on other DVD players.

B Press we to select “YES”, then press ENTER when

“DISC WILL BE FORMATTED IN VR MODE/VIDEO MODE” appears on the TV screen.

NOTES:

● It is impossible to format Version 1.0 DVD-RW discs in Video mode.

● It is impossible to format DVD-R discs.

● All the programmes on a disc will be deleted once the disc is

formatted even if they are protected titles. ( title”)

墌 pg. 66, “Protect

98 EN

Finalise A Disc

SUBSIDIARY SETTINGS (cont.)

Finalise a DVD-R/RW disc

Finalising DVD-R/RW discs recorded on this unit makes it possible for the discs to be played back on other DVD players. DVD-RW discs are finalised in the mode that the discs were formatted, enabling playback on compatible DVD players. Titles input in the Library Database DVD Navi are registered as titles in the DVD menu. (

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

● Load a DVD-R/RW disc to finalise.

Before finalising

● It is possible to record on a blank space.

● It is possible to enter a programme title. (

Programme Name”)

● It is possible to delete programmes. ( programme”)

● It is impossible to overwrite recorded areas of DVD-R discs.

● Available recording capacity does not increase even if a

recorded programme is deleted from a DVD-R disc.

● It is impossible to record or edit DVD-R/RW discs recorded on other devices even if they have not been finalised.

After finalising (For DVD-R/RW (Video mode) discs)

● Video and audio that have been recorded by then are recorded in conformity to the DVD Video standard, enabling you to play back the discs as DVD VIDEO discs. ( Playback Only”)

● Although DVD-R/RW discs finalised on this unit become playable on DVD players compatible with DVD-R/RW discs, some discs still may not play, for which JVC cannot take responsibility.

● Marked points marked before finalising will be deleted, and programmes will be divided automatically into “chapters” approximately every 5 minutes. ( positions to play again later”)

● Depending on the DVD players and DVD-R/RW discs used, and on the conditions of recording, it may not be possible to play back the discs. In this case, play back the discs on this unit.

● Additional recordings become impossible.

墌 pg. 26, 66)

墌 pg. 66, “Modify

墌 pg. 67, “Delete

墌 pg. 6, “Discs for

墌 pg. 28, “Marking

Finalise the disc.

A Press rt to select “FINALISE”, then press ENTER.

Press we to select “YES”, then press ENTER when “DISC WILL BE FINALISED” appears on the TV screen.

B Press we to select “OK”, then press ENTER when

“FINALISING WILL MAKE DISC READ-ONLY” appears on the TV screen.

Return to the normal screen.

Press SET UP.

● Menu screen is cleared.

● Once a DVD-R/RW (Video mode) disc has been finalized, the

displays for original and play list do not appear. Only display for library appears.

● Once a DVD-RW (VR mode) disc has been finalised, it can be played on DVD players compatible with VR mode.

Cancel the finalisation of a DVD-RW disc

Cancel the disc finalisation.

A Press rt to select “CANCEL DISC FINALISATION”,

then press ENTER.

B Press we to select “OK”, then press ENTER when

“CANCEL DISC FINALISATION” appears on the TV screen.

Return to the normal screen.

Press SET UP.

● When the disc finalisation is cancelled, the mode in which the disc was formatted is restored, making the disc recordable. (

墌 pg. 7, 97)

EN 99

Scan Mode Set

You can select the scan mode from two modes: Interlaced scan mode which is used in the conventional TV system, and Progressive scan mode which enables reproduction of higher-quality images. For details, refer to “GLOSSARY” (墌 pg. 104).

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

TTENTION:

Your TV needs to be compatible with PAL Progressive.

Set the scan mode.

Press PROGRESSIVE SCAN for 3 or more seconds.

● Video output indicator ( ) lights on the front display panel if Progressive scan mode has been established. (

● Each press of PROGRESSIVE SCAN for 3 or more seconds switches the scan mode.

NOTES:

● When the progressive mode is set, be sure to set “L-1 OUTPUT” to “COMPONENT”. ( L-1 Input Setting (L-1 OUTPUT and L-1 INPUT)”) Progressive scan is output only from COMPONENT VIDEO OUT connector.

● Interlaced scan mode is the setting at your purchase.

● When Progressive scan mode is engaged, no video signal is

output from S-VIDEO OUT connector and L-1 IN/OUT connector.

● Interlaced scan mode might be suitable depending on video material.

● Scan mode cannot be set while menu screen is displayed.

墌 pg. 80, “L-1 Output and

墌 pg. 13)

Tray Lock

You can lock the disc tray to prohibit the unwanted disc ejection by children.

● Turn off the unit.

Lock the disc tray.

While the unit is turned off, press and hold 8, then press x on the unit. “LOCK” appears on the front display

panel.

● If you try to eject the discs, “LOCK” appears and indicates that tray is locked.

To unlock tray

While the unit is turned off, press and hold 8, then press x on the unit. “UNLOCK” appears on the display panel.

100 EN

TROUBLESHOOTING

Before requesting service for a problem, use this chart and see if you can solve the trouble yourself. Small problems are often easily solved, and this can save you the trouble of sending your unit off for repair.

GENERAL

SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION

1. No power is supplied to the unit. ● The AC power plug is disconnected from

2. The channel cannot be changed. ● Recording or Live Memory recording is

3. The remote control does not operate the unit.

4. Dubbing from the external equipment is not possible.

5. The on-screen display superimposed on the programme played back/ received on this unit is recorded when you dub the programme to an external recording equipment.

6. The remote control does not work properly.

7. The unit does not operate. ● There are cases when the operation is

the mains.

in progress.

● The setting of the remote control code is inappropriate.

● The batteries are discharged. Replace the dead batteries with new ones.

● The setting of the input channel position

is inappropriate.

—

● The batteries are discharged. Replace the dead batteries with new ones.

prohibited on the disc.

● Lightning or static electricity may cause malfunction of the unit.

Connect the AC power plug to the mains securely. (

Press 9 to pause recording, change the channel, then press 4 to resume recording.

Set the same remote control code (1, 2, 3, or 4) on both the unit and the remote control. (

Select the input channel position (“F-1” or “L-2”) that corresponds to the input terminal connected to the external equipment. (

Set “SUPERIMPOSE” to “OFF”. (

墌 pg. 90)

Remove the batteries, wait for 5 minutes or more, then load the butteries again.

Press 1 to turn the power off, then press the button again to turn the power on.

墌 pg. 16)

墌 pg. 83)

墌 pg. 79)

—

PLAYBACK

SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION

1. Images do not appear on the TV screen.

2. Playback dose not start or stop immediately after playback is started by pressing 4. On the front display panel, “NO DISC” appears.

3. Images are blurred or distorted when you start High-Speed Search. —

4. Playback does not start.

5. Playback does not start when you select a title or a chapter.

● The TV is not set to the AV mode. Set the TV to the AV mode.

● When interlace scanned programme is

played back, progressive scan mode is selected.

● The disc is loaded upside down. Place the disc on the disc tray with the

● A disc not being compatible with the

unit is loaded.

● A dirty disc is loaded. Clean the disc. (

● Defective disc is loaded. Replace the warped or scratched disc with

● The Parental Lock is engaged and the

disc is rated higher than the set level.

Press and hold PROGRESSIVE SCAN until

disappears from the front display

panel.

playback surface facing downward. (

墌 pg. 9)

Load a playable disc on the unit. (墌 pg. 5, 6)

墌 pg. 9)

a normal one.

Images are blurred or distorted at the point where the playback speed changes and this is not a malfunction of the unit.

—

Playback does not start for approximately 30 seconds after recording is stopped and this is not a malfunction of the unit.

Release the Parental Lock temporarily or change the set level. (

墌 pg. 44)

JVC DR-M10 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

SAFETY FIRST

Safety Precautions

DISC INFORMATION

About Discs

Recordable/playable discs

Discs for Playback Only

Unplayable Discs

Recording Medium and Format

File Structure of Discs

Placing a Disc

Care and Handling of Discs

FRONT VIEW

INDEX

REAR VIEW

FRONT DISPLAY PANEL

ON-SCREEN DISPLAY

REMOTE CONTROL

INSTALLING YOUR NEW UNIT

Basic Connections

Component Video Connection

INITIAL SETTINGS

Auto Set Up

Monitor Set

Language

On-screen Language Set

Menu/Audio/Subtitle Language Set

Language Code List

PLAYBACK OPERATIONS

Basic Playback

Playback Features

Locating a desired scene using the DVD menu

Locating the start point of the item or skip the item

High-Speed Search

Still Picture/Frame-By-Frame Playback

Slow Motion

Skip Search

Resume Function

Checking the time information

Switching Time Indication

Marking positions to play again later

Angle Selection

Subtitle Selection

Audio Channel Selection

Live Memory Playback

Recording/playback status display

Overview of Live Memory Playback

Display during Live Memory Playback

Buttons to be used during Live Memory Playback

To play back from the beginning of the programme while recording

To move back the playback position slightly while recording (One Touch Replay function)

To watch a programme previously recorded while recording

How to Access Play Set Up Menu

Basic operation on Play Set Up Menu

Repeat Playback

A-B Repeat Playback

Locating the beginning of a desired selection

Time Search

Simulated Surround Effect

Adjusting the picture quality

Setting the progressive mode

Programme Playback

Parental Lock

To set Parental Lock for the first time

To change the settings

To temporarily release Parental Lock

Country/Area Code List for Parental Lock

RECORDING

Basic Recording

Recording Features

Instant Timer Recording (ITR)

Record One Programme While Watching Another

Elapsed Recording Time and Disc Remaining Time Indication

Receiving Stereo and Bilingual Programmes

Selection of the audio channel to be recorded on a disc

Free Rate Function

TIMER RECORDING
