Diamond Series
QUICK START GUIDE
Rev. 8/14 Diamond Series QUICK START GUIDE
IMPORTANT SAFETY INFORMATION
• Read and follow all these instructions.
• Heed all warnings.
• Do not use this device near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with manufacturer’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other heat-generation devices.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the device.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods of
time.
• Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
• Apparatus should not be exposed to dripping or splashing, and objects filled with
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated dangerous voltage with the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
liquids, such as vases, should not be placed on the apparatus.
• An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits, as contact
with them might be fatal.
• Do not overload wall outlets and extension cords, as this can result in a risk or fire
or electric shock.
• Do not push objects through any openings in this unit as they may touch
dangerous voltage points or short out parts that could result in fire or electric
shock. Never spill or spray any type of liquid into the unit.
• If an outside antenna or cable system is connected to the unit, be sure he
antenna or cable system is grounded to provide some protection against voltage
surges and built-up static charges, Section 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with respect to proper grounding practices
• When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
• Upon completion of any service or repairs to this unit, ask the service technician
to perform safety checks to determine that the unit is in proper operating
condition.
• When you connect the product to other equipment, turn off the power and
unplug all of the equipment from the wall outlet.
• Sudden high volume sound may cause hearing or speaker damage. When you
use headphones (if the unit is equipped with a headphone jack), keep the volume
at a moderate level.
Rev. 8/14 Diamond Series QUICK START GUIDE
CHECK MATERIALS IN PACKAGE
Ultra High Definition TV
Roku® Streaming Stick™
(Roku Ready® Version)
DOWNLOAD FULL VERSION USER MANUAL
http://jvc-tv.com
*Images shown here are for illustration purpose only.
Rev. 8/14 Diamond Series QUICK START GUIDE
REMOTE CONTROL
TV POWER button
Playback Controls**
Control USB multimedia and HDMI-
CEC, HDMI/MHL devices
Directional buttons
MUTE button
IR Transmitter
LED indicator
INPUT button
Select Input source
←RETURN button**
ROKU Home button**
INFO* button**
OK button
MENU button
Global Return button
**Compatible with ROKU® Streaming Stick™.
Qwerty Keyboard
VOLUME Controls
CHANNEL Controls
JVC Home button
Number Pad
To directly key in channels. Use “-”
for sub-channel. Example: 2-1 or 18-7
Instant Replay Button
/Last button**
Note: If you are encountering problem with remote control, please first make sure your remote control is paired with the TV. The remote control can be paired
with the TV at any time when TV is On, simply press and hold and buttons for 3 seconds. Upon release of the and buttons, LED indicator will flash
once to indicate successful pairing.
*Images shown here are for illustration purpose only.
Touchpad
Rev. 8/14 Diamond Series QUICK START GUIDE
FRONT VIEW
DM65USR
Power Indicator & Remote Sensor
DM85UXR
*Images shown here are for illustration purpose only.
Rev. 8/14 Diamond Series QUICK START GUIDE
REAR VIEW
*Images shown here are for illustration purpose only.
DM65USR
AC Power
HDMI-1
HDMI-2
HDMI 2.0
HDMI-3
HDMI-4
HDMI / MHL
Power and Function Buttons
Ethernet
Audio Out
Component/
Video Input
USB 2.0
USB 3.0
Digital Optical Out
Audio Input Antenna
Input
Rev. 8/14 Diamond Series QUICK START GUIDE
REAR VIEW
*Images shown here are for illustration purpose only.
DM85UXR
HDMI-1
HDMI-2
HDMI 2.0
HDMI-3
HDMI-4
HDMI / MHL
AC Power
Ethernet
Audio Out
Component/
Video Input
Power and
Function
Buttons
Audio Input Antenna
Input
USB 2.0
USB 3.0
Digital Optical Out
