JVC DLA-VS2100, DLA-VS2100NL Instruction Manual

Operation

Others

Preparation

Getting Started

Maintenance

0211TTH-AO-AO

© 2011 Victor Company of Japan, Limited

DLA-F110

D-ILA PROJECTOR

PROYECTOR D-ILA

PROJECTEUR D-ILA

DLA-VS2100/VS2100NL

For Customer use :

Enter below the serial No. which is
located on the side of the cabinet.
Retain this information for future
reference.

Model No. DLA-VS2100

DLA-VS2100NL

Serial No.

Instrucción para el cliente :

Introduzca a continuación el nº de
serie que aparece en la parte
inferior lateral de la caja. Conserve
esta información como referencia
para uso ulterior.

Modelo Nº DLA-VS2100

Nº de serie

DLA-VS2100NL

Pour utilisation par le client :

Entrer ci-dessous le N° de série qui
est situé sous le boîtier. Garder

cette information comme référence
pour le futur.

N° de modèle DLA-VS2100

N° de série

DLA-VS2100NL

ENGLISH FRANÇAIS ESPAÑOL/CASTELLANO

INSTRUCTIONS

MANUEL D’INSTRUCTIONS

MANUAL DE INSTRUCCIONES

D-ILA PROJECTOR
PROJECTEUR D-ILA
PROYECTOR D-ILA

DLA-VS2100
DLA-VS2100NL

ON

STAND BY

COMPONENT

COMP

.

HDMI 2

HDMI 1

ASPECT

PC

ANAMO

LENS.

AUTO

C.M.D

ALIGNMENT

CONTROL

HIDE

LIGHT

OK

BACK

MENU

PICTURE MODE

3D

DYNAMIC

NATURAL

USER1

USER3

USER2

USER5 USER6

USER4

PIC.

COLOR

LENS.

GAMMA

TEMP

ADJ.

AP

PC010685798-0

1

Getting started

Safety Precautions

IMPORTANT INFORMATION

This product has a High Intensity Dis­charge (HID) lamp that contains
mercury.
Disposal of these materials may be
regulated in your community due to
environmental considerations. For
disposal or recycling information,
please contact your local authorities or
for USA, the Electronic Industries
Alliance: http://www.eiae.org.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO

NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.

WARNING:

THIS APPARATUS MUST BE EARTHED.

CAUTION:

To reduce the risk of electric shock, do not remove

cover. Refer servicing to qualied service personnel.

This projector is equipped with a 3-blade grounding
type plug to satisfy FCC rule. If you are unable to
insert the plug into the outlet, contact your
electrician.

MACHINE NOISE INFORMATION
(Germany only)

Changes Machine Noise Information Ordinance 3.

GSGV, January 18, 1991: The sound pressure level

at the operator position is equal or less than 20 dB
(A) according to ISO 7779.

FCC INFORMATION (U.S.A. only)

CAUTION:

Changes or modication not approved by JVC

could void the user’s authority to operate the
equipment.

NOTE:

This equipment has been tested and found to
comply with the limits for Class B digital devices,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protec
tion against harmful interference in a residential
installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the instruc
tions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encourage to try to correct the
interference by one or more of the following
measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the

equipment and receiver.

● Connect the equipment into an outlet on a

circuit different from that to which the receiver

is connected.

● Consult the dealer or an experienced radio/

TV technician for help.

About the installation place

Do not install the projector in a place that cannot
support its weight securely.
If the installation place is not sturdy enough, the
projector could fall or overturn, possibly causing
personal injury.

IMPORTANT SAFEGUARDS

Electrical energy can perform many useful
functions. This unit has been engineered and
manufactured to assure your personal safety. But
IMPROPER USE CAN RESULT IN POTENTIAL

ELECTRICAL SHOCK OR FIRE HAZ ARD.

In order not to defeat the safeguards incorporated
into this product, observe the following basic rules
for its installation, use and service. Please read
these Important Safeguards carefully before use.

- All the safety and operating instructions should
be read before the product is operated.

- The safety and operating instructions should be
retained for future reference.

2

Getting Started

ENGLISH

150 mm and above

300 mm
and above

200 mm
and above

300 mm
and above

150 mm
and above

PORTABLE CART WARNING
(symbol provided by RETAC)

S3126A

- All warnings on the product and in the operating
instructions should be adhered to.

- All operating instructions should be followed.

- Place the projector near a wall outlet where the
plug can be easily unplugged.

- Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

- Do not use attachments not recommended by the
product manufacturer as they may be hazardous.

- Do not use this product near water. Do not use
immediately after moving from a low temperature
to high temperature, as this causes condensation,

which may result in re, electric shock, or other

hazards.

- Do not place this product on an unstable cart,
stand, or table. The product may fall, causing
serious injury to a child or adult, and serious
damage to the product. The product should be
mounted according to the manufacturer’s
instructions, and should use a mount recommend
ed by the manufacturer.

- When the product is used on a
cart, care should be taken to avoid
quick stops, excessive force,
and uneven surfaces which may
cause the product and cart to
overturn, damaging equipment or
causing possible injury to the
operator.

- Slots and openings in the cabinet are provided for
ventilation. These ensure reliable operation of the
product and protect it from overheating. These
openings must not be blocked or covered. (The
openings should never be blocked by placing the
product on bed, sofa, rug, or similar surface. It
should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is
provided and the manufacturer’s instructions have
been adhered to.)

- To allow better heat dissipation, keep a clearance
between this unit and its surrounding as shown
below. When this unit is enclosed in a space of
dimensions as shown below, use an air-conditioner
so that the internal and external temperatures are
the same. Overheating can cause damage.

Front

- power source indicated on the label. If you are
not sure of the type of power supply to your
home, consult your product dealer or local
power company.

- This product is equipped with a three-wire plug.

This plug will t only into a grounded power

outlet. If you are unable to insert the plug into
the outlet, contact your electrician to install the
proper outlet. Do not defeat the safety purpose
of the grounded plug.

- Power-supply cords should be routed so that
they are not likely to be walked on or pinched
by items placed upon or against them. Pay
particular attention to cords at doors, plugs,
receptacles, and the point where they exit from
the product.

- For added protection of this product during a
lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from
the wall outlet and disconnect the cable system.
This will prevent damage to the product due to
lightning and power line surges.

- Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as

this can result in a risk of re or electric shock.

- Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short out parts that could result
in a re or electric shock. Never spill liquid of
any kind on the product.

- Do not attempt to service this product yourself
as opening or removing covers may expose you
to dangerous voltages and other hazards. Refer

all service to qualied service personnel.

- Unplug this product from the wall outlet and

refer service to qualied service personnel

under the following conditions:

a)When the power supply cord or plug is damaged.
b)If liquid has been spilled, or objects have fallen on
the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the Operation
Manual, as an improper adjustment of controls may
result in damage and will often require extensive

work by a qualied technician to restore the product

to normal operation.
e)If the product has been dropped or damaged in any
way.
f) When the product exhibits a distinct change in
performance, this indicates a need for service.

- When replacement parts are required, be sure

the service technician has used replacement

parts specied by the manufacturer or with

same characteristics as the original part.

Unauthorized substitutions may result in re,

electric shock, or other hazards.

- Upon completion of any service or repairs to
this product, ask the service technician to
perform safety checks to determine that the
product is in proper operating condition.

3

1

Getting started

- The product should be placed more than one foot
away from heat sources such as radiators, heat
registers, stoves, and other products (including

ampliers) that produce heat.

- When connecting other products such as VCR’s,
and DVD players, you should turn off the power of

this product for protection against electric shock.

- Do not place combustibles behind the cooling fan.

For example, cloth, paper, matches, aerosol cans
or gas lighters that present special hazards when
over heated.

- Do not look into the projection lens while the
illumination lamp is turned on. Exposure of your
eyes to the strong light can result in impaired
eyesight.

- Do not look into the inside of this unit through
vents (ventilation holes), etc. Do not look at the
illumination lamp directly by opening the cabinet
while the illumination lamp is turned on. The
illumination lamp also contains ultraviolet rays and
the light is so powerful that your eyesight can be
impaired.

- Do not drop, hit, or damage the light-source lamp
(lamp unit) in any way. It may cause the light­ source lamp to break and lead to injuries. Do not
use a damaged light source lamp. If the light­ source lamp is broken, ask your dealer to repair it.
Fragments from a broken light-source lamp may
cause injuries.

- The light-source lamp used in this projector is a
high pressure mercury lamp. Be careful when
disposing of the light-source lamp. If anything is
unclear, please consult your dealer.

- Do not ceiling-mount the projector to a place which

tends to vibrate; otherwise, the attaching xture of

the projector could be broken by the vibration,
possibly causing it to fall or overturn, which could
lead to personal injury.

- Use only the accessory cord designed for this

product to prevent shock.

- Once every three years, please perform an
internal test. This unit is provided with
replacement parts needed to maintain its
function (such as cooling fans). Estimated
replacement time of parts can vary greatly
depending on frequency of use and the
respective environment. For replacement,
please consult your dealer, or the nearest

authorized JVC service center.

- When xing the unit to the ceiling, Please note

that we do not take any responsibility, even
during the warranty period, if the product is

damaged due to use of metal xtures used for
xation to the ceiling other than our own or if the
installation environment of said metal xtures is

not appropriate. If the unit is suspended from the
ceiling during use, please be careful in regard to
the ambient temperature of the unit. If you use
a central heating, the temperature close to the
ceiling will be higher than normally expected.

- Video images can burn into the electronic com

ponent parts. Please do not display screens with
still images of high brightness or high contrast,
such as found in video games and computer
programs. Over a long period of time it might
stick to the picture element. There is no problem
with the playback of moving images, e.g. normal
video footage.

- Not using the unit for a long time can lead to
malfunction. Please power it on and let it run
occasionally. Please avoid using the unit in a
room where cigarettes are smoked. It is impos
sible to clean optical component parts if they are
contaminated by nicotine or tar. This might lead
to performance degradation.

DO NOT allow any unqualied person

*

to install the unit.

Be sure to ask your dealer to install the unit
(e.g.attaching it to the ceiling) since special
technical knowledge and skills are required
for installation. If installation is performed by

an unqualied person, it may cause personal

injury or electrical shock.

4

Getting Started

Safety Precautions (Continued)

POWER CONNECTION

ENGLISH

For USA and Canada only
Use only the following power cord.

The power supply voltage rating of this product is

AC110V – AC240V. Use only the power cord

designated by our dealer to ensure Safety and EMC.
Ensure that the power cable used for the projector is
the correct type for the AC outlet in your country.
Consult your product dealer.

For United Kingdom For European continent

countries

Power cord

Power cord

WARNING:

Do not cut off the main plug from this
equipment.

If the plug tted is not suitable for the power points

in your home or the cable is too short to reach a
power point, then obtain an appropriate safety
approved extension lead or adapter or consult your
dealer. If nonetheless the mains plug is cut off,
dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the main

supply. If a new main plug has to be tted, then

follow the instruction given below.

WARNING:

THIS APPARATUS MUST BE EARTHED.

IMPORTANT (Europe only):

The wires in the mains lead on this product are

colored Vert et jaune in accordance with the

following cord:
Green-and-yellow
Blue
Brown
As these colors may not correspond with the
colored making identifying the terminals in your
plug, proceed as follows:
The wire which is colored green-and-yellow must
be connected to the terminal which is marked M
with the letter E or the safety earth or colored
green or green-and-yellow. The wire which is
colored blue must be connected to the terminal
which is marked with the letter N or colored black.
The wire which is colored brown must be
connected to the terminal which is marked with the
letter L or colored red.

:Earth
:Neutral
:Live

POWER CONNECTION
(United Kingdom only)

HOW TO REPLACE THE FUSE:

When replacing the fuse, be sure to use only a

correctly rated approved type, re-t the fuse cover.

IF IN DOUBT —— CONSULT A COMPETENT
ELECTRICIAN.

Open the fuse compartment with the blade
screwdriver, and replace the fuse.
(* An example is shown in the illustration below.)

Fuse

Dear Customer,

This apparatus is in conformance with the valid European directives and standards regarding
electromagnetic compatibility and electrical safety.

European representative of Victor Company of Japan, Limited is:
JVC Technical Services Europe GmbH

Postfach 10 05 04
61145 Friedberg
Germany

5

1

Getting started

ENGLISH

Information for Users on Disposal of Old Equipment and Batteries

[European Union only]

These symbols indicate that equipment with these symbols

should not be disposed of as general household waste. If you
want to dispose of the product o r battery, please consider the
collection systems or fa cilities for appr opriate recycling.

Notice: The sign Pb below the symbol for batteries indicates that
this battery contains lead.

Products

Battery

DEUTSCH

Benutzerinformationen zur Entsorgung alter Geräte und Batterien

[Nur Europäische Union]
Diese Symbole zeigen an, dass derartig gekennzeichnete Geräte

nicht als normaler Haushaltsabfall entsorgt werden dürfen. We
nden Sie sich zur Entsorgung des Produkts oder der Batterie an
die hierfür vorgesehenen Sammelstellen oder Einrichtungen,
damit eine fachgerechte Wiederverwertung möglich ist.

Produkte
dass diese Batterie Blei enthält.

Batterie

Hinweis: Das Zeichen Pb unterhalb des Batteriesymbols gibt an,

FRANÇAIS

Informations relatives à l’élimination des appareils et des piles usagés, à
l’intention des utilisateurs

[Union européenne seulement]
Si ces symboles gurent sur les produits, cela signie qu’ils ne

doivent pas être jetés comme déchets ménagers. Si vous voulez
jeter ce produit ou cette pile, veuillez considérer le système de
collection de déc hets ou les centres de recyclage appropriés.

Notication: La marque Pb en dessous du symbole des piles

Produits

Pile
indique que cette pile contient du plomb.

NEDERLANDS

Informatie voor gebruikers over het verwijderen van oude apparatuur en
batterijen

[Alleen Europese Unie]

Deze symbolen geven aan dat appara tuur met dit symbool niet
mag worden weggegooid als algemeen huishoudelijk afval. Als u
het product of de batterij wilt weggooien, kun t u inzamelsystemen
of faciliteiten voor een geschikte recycling gebruiken.

Opmerking: Het teken Pb onder het batterijsymboo l geeft aan
dat deze batterij lood bevat.

Batterij

Producten

6

Getting Started

ENGLISH

ESPAÑOL / CASTELLANO

Información para los usuarios sobre la eliminación de baterías/pilas usadas

Estos símbolos indican que el equipo con estos símbolos no debe
desecharse con la basura doméstica. Si desea desechar el pro
ducto o batería/pila, acuda a los sistemas o centros de recogida
para que los reciclen debidamente.

Atención: La indicación Pb debajo del símbolo de batería/pila
indica que ésta contiene plomo.

Productos

Baterías/pilas

[Sólo Unión Europea]

ITALIANO

Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie
obsolete

[Solo per l’Unione Europea]

Questi simboli indicano che le apparecchiature a cui sono relativi

non devono essere smaltite tra i riuti domestici generici. Se si

desidera smaltire questo prodotto o questa batteria, prendere in
considerazione i sistem i o le strutture di raccolta appropriati per
il riciclaggio corretto.

Nota: Il simbolo Pb sotto il simbolo delle batter ie indica che

Prodotti

questa batteria contiene piombo.

Batteria

PORTUGUÊS

Informação para os utilizadores acerca da eliminação de equipamento usado e
pilhas

[Apenas União Europeia]

Estes símbolos indicam que o equipamento com estes símbolos
não deve ser eliminado juntamente com o restante lixo doméstico.
Se p retende eliminar o produto ou a pilha, utilize os sistemas de
recolha ou instalações para uma reciclagem apropriada.

Aviso: O sinal Pb abaixo do símbolo para pilhas indica que esta
pilha contém chumbo.

Produtos

Πληροφορίες για την απόρριψη παλαιού εξοπλισμού και μπαταριών

[ Ευρωπαϊκή Ένωση μόνο ]

Αυτά τα σύμβολα υποδηλώνουν ότι ο εξοπλισμός που τα φέρει
δεν θα πρέπει να απορριφθεί ως κοινό οικιακό απόρριμμα . Εάν
επιθυμείτε την απόρριψη αυτού του προϊόντος ή αυτής της
μπαταρίας , χρησιμοποιήστε το σύστημα περισυλλογής ή
εγκαταστάσεις για ανάλογη ανακύκλωση .

Σημείωση : Το σύμβολο Pb κάτω από το σύμβολο μπαταρίας

Προϊόντα

υποδηλώνει ότι η μπαταρία περιέχει μόλυβδο .

Pilha

ΕΛΛΗΝΙΚΑ

Μπαταρία

7

1

Getting started

Brugerinformation om bortskaffelse af gammelt udstyr og batterier

DANSK

Disse symboler angiver, at udstyr med disse symboler ikke må

bortskaffes som almindeligt husholdningsaffald. Hvis du ønsker at
smide dette produkt eller batteri ud, bedes du overveje at bruge
indsamlingssystem et eller steder, hvor der kan ske korrekt gen
brug.

Bemærk: Tegnet Pb under symbolet for batterierne angiver, at

Produkter

dette batteri indeholder bly.

Batteri

[Kun EU]

SUOMI

Tietoja vanhojen laitteiden ja akkujen hävittämisestä

[Vain Euroopan unioni]

Nämä symbolit ilmaisevat, että symboleilla merk ittyä laitetta ei

tulisi hävittää tavallisen kotitalousjätteen mukana. Jos haluat hävit

tää tuotteen tai sen akun, tee se hyödyntämällä akkujen
keräyspisteitä tai muita kier rätyspaikkoja .

Huomautus: Akkusymbolin alapuolella oleva Pb-merk intä tarkoit
taa, että akku sisältää lyijyä.

Tuotteet

Akku

SVENSKA

Information för användare gällande bortskaffning av gammal utrustning och
batterier

[Endast den Europeiska unionen]

Dessa symboler indikerar att utrustning med dessa symboler inte
ska hanteras som vanligt hushållsavfall. Om du vill bortsk affa
produkten eller batteriet ska du använda uppsamlingssystem eller
inrättningar för lämplig återvinning.

Observera! Märkningen Pb under symbolen för batterier indikerar
att detta batteri innehåller bly.

Batteri

Produkter

NORSK

Opplysninger til brukere om kassering av gammelt utstyr og batterier

[Bare EU]

Disse symbolene viser at utstyr med dette symbolet, ikke skal

kastes sammen med vanlig husholdningsavfall. Hvis du vil kass
ere dette produkte t eller batteriet, skal du vurdere å bruke innsam
lingssystemene eller andre muligheter for riktig gjenbruk.

Merk: Tegnet Pb under symbolet for batterie r, viser at batteriet

Produkter

inneholder bly.

Batteri

8

Getting Started

ENGLISH

Сведения для пользователей по утилизации старого оборудования и
батарей

[только для Европейского союза]

Данные символы указывают на то, что оборудование, на
которое они нанесены, не должны утилизироваться, как
обычные бытовые отходы. При необходимости утилизировать
такое изделие или батарею обратитесь в специальный пункт
сбора для их надлежащей переработки.

Уведомление: Надпись Pb под символом батар ей указывает

Изделия

на то, что данная батарея содержит свинец.

Батарея

Informace pro uživatele k likvid aci starého zařízení a baterií

[Pouze Evropská unie]

Tyto symboly označují, že produkty s těmito symboly se nesmí
likvidovat jako běžný odpad. Pokud chcete produkt nebo baterii
zlikvidovat, využijte sběrný systém nebo jiné zařízení, které zaji stí
řádnou recyklaci.

Upozornění: Značka Pb pod symbolem pro ba te rie znamená, že

Produkty

tato baterie obsahuje olovo.

Baterie

Informacje dla użytkowników dotyczące poz bywania się zużytego sprzętu i

baterii

[Tylko kraje Unii Europejskiej]

Te symbole oznaczają, że sprzę tu nie należy wyr zucać razem z
odpadami gospodarczymi. Jeśli trzeba po zbyć się tego produktu
lub ba terii, proszę skorzystać z systemu odbioru lub urządzeń do

zbió rki odpadów elektronicznych, w celu odpowiedniego ponowne
go ich przetworzenia.

Uwaga: Oznaczenie Pb, znajdujące się pod symbole m baterii

Produkty

wskazuje, że ta bateria zawiera ołów.

Felhasználói információ az elhasznált be rendezések és akkumulátorok

elhelyezéséről

[Csak az Európai Unióban]

Ez a szimbólum azt jelzi, hogy a berendezés nem helyezhető az
általános háztartási hulladék közé. Ha meg szeretne szabadulni a
terméktől vagy az akkumulátortól, akkor legyen tekintettel az
gyűjtő rendszerre vagy intézményekre a megfelelő hasznosítás

érdekében.

Megjegyzés: Az alábbi Pb szimbólum - ha az akkum ulátoron

Termékek

megtalálható - azt jelzi, hogy az akkumulátor ólmot

tartalmaz.

POLSKI

Bateria

MAGYAR

Akkumulátor

9

1

Getting started

Contents

Getting started

Safety Precautions ...........................2

Contents .........................................10

Accessories/Optional

Accessories ....................................11

Check the Accessories .............................. 11

Optional Accessories ................................. 11

Controls and features ....................12

Main body - Front ......................................12

Main body - Bottom ...................................12

Main body - Rear ....................................... 13

Main body - About the indicator display .....14

Main body - Warning display and

conrmation/response ...............................15

Main body - Input terminal ......................... 16

How to insert batteries into the remote

control ........................................................ 17

Preparation

About installation ...........................18

IImportant points concerning the

installation .................................................18

Installing the Projector and Screen ...........19

Set Angle ................................................19

VS21

RS50RS50

Shift

Fixation of the projector ............................. 20

Screen Size and Projection Distance

Effective Range of Remote Control Unit....21

.................................................19

VS21

RS50RS50

.21

About the connection .....................22

Types of possible input signals

(PC compatible) ......................................... 22

Connection to the unit ...............................23

Connection of the power cord (provided) ..29

Operation

Basic Operation ..............................30

Basic operation procedures ....................... 30

Frequently used useful functions ............... 32

Setting the Screen Size ............................. 32

Masking the Surrounding Area of

an Image ...................................................33

Temporary turning-off of the video ............. 34

Adjustments and settings

in the menu .....................................35

Structure of the menu hierarchy

(summary) .................................................35

Menu operation button ..............................41

Menu operation procedure ........................42

Menu item description ...............................43

Operation guide (glossary) ............52

Maintenance

Explanation of the installation/
removal of the lamp attachment ..54

Lamp attachment replacement

procedures ................................................ 54

Lamp attachment removal procedure ....... 56

Attachment of the installation

verication seal .......................................... 57

Replacing the Lamp .......................58

Lamp replacement procedure ...................58

Resetting lamp Time ..................................60

Method for cleaning and

replacing lters ...............................62

Others

Troubleshooting .............................64

In case this message is

displayed .........................................66

RS-232C Interface ...........................67

RS-232C Specications ............................67

TCP/IP-connection ....................................67

Command Format .....................................68

RS-232C Communication Examples ......... 70

Copyright and Caution ...................71

About Trademarks and Copyright ..............71

Caution ......................................................71

Specications .................................72

Dimensions ................................................ 74

Index ................................................75

CAUTION

About the marks used in this
book

VS21

RS50RS50

Compatible only with

DLA-VS2100

RS50RS50

VSNL

Compatible only with

DLA-VS2100NL

10

Getting Started

ENGLISH

Accessories/Optional Accessories

Check the Accessories

Remote Control ..........................................................................1 piece

AAA size Batteries (for operation conrm)..................................2 pieces

Power Cord For the US market (2 m) .........................................1 piece

Power Cord For the EU market (2 m) .........................................1 piece

Power Cord For the UK market (2 m) .........................................1 piece

Lamp Attachment .......................................................................1 piece

Installation Verication Seal........................................................1 piece

●

warranty card and other printed material are also included.

Optional Accessories

Please check with your authorized dealer for details.

●

Replacement Lamp: PK-L2210U

●

Replacement Filter: PC010661199

●

Replacement lamp attachment: PC010685599

11

1

Getting started

Controls and features

Main body - Front

③ Indicator

STANDBY/ON LAMP WARNING

④ Exhaust Vent

② Remote receiver (front)

VS21

① Lens

This is a projection lens. Please do not look

inside during projection.

RS50RS50

③ Indicator

Please see “About the indicator display” for
details. (Reference page: 14)

① Lens

VS21

RS50RS50

④ Exhaust

Vent

② Remote receiver (front)

Please aim the remote control at this area when

using it.

* There is also a remote receiver at the rear.

Main body - Bottom

⑤ Inlets

⑥ Feet

④ Exhaust Vent

Warm air ows out in order to cool the interior of
the set. Please do not block the vents.

⑤ Inlets (at 3 points on the rear/

bottom)

In order to cool the inside of the unit, air is let
inside. Do not block or prevent the outow of
hot air. Doing so could lead to failure of the unit.
* There are inlets at two points on the right and
left sides of the rear side. (Reference page: 13)

⑥ Feet

The height (0 to 5 mm) can be adjusted by
turning the foot.

12

Getting Started

ENGLISH

Controls and features (continued)

Main body - Rear

⑤ Inlets
⑧ Lamp Cover

⑤ Inlets

⑦ Input

terminal

⑪ Power input

terminal

⑦ Input terminal

There is also a terminal other than the input
terminal for video images, such as those used
for controlling or optional equipment. Please see
“

About input terminals” for detailed information

about terminals. (Reference page: 16)

⑧ Lamp Cover

When replacing the light source lamp, remove
this cover. (Reference page: 58)

⑨ Operation panel

See the following illustration “Control panel” for
more details.

Operation panel

■

⑨ Operation panel

⑩ Light receiving section

of the remote control (rear)

⑩ Light receiving section of the

remote control (rear)

Please aim the remote control at this section
when using.
* There is also a light receiving section at the

rear.

⑪ Power input terminal

This is the power input terminal. It is
connected via the supplied power cord.
(Reference page: 29)

STANDBY/ON

To turn on/off the power

INPUT

To switch input

OK

To select or conrm

Left button

Down button

To display the menu

MENU

BACK

Up button

Right button

eturn to the previous menu

To r

13

1

Getting started

Controls and features (continued)

Main body - About the indicator display

Warnings and indications used during normal operation mode of this unit are displayed with the indicators
for [STAND BY / ON], [LAMP], [WARNING] at the front of this unit.

Meaning of the lighting gures:

The display the indicator lights.

They display ashing of the indicator.

Operation mode display

Displays the color and lighting/ashing of the [STAND BY / ON] indicator.

STAND BY

Duringstandby

STANDBY/ON

STAND BY

When"Hide"issettoON

STANDBY/ON

Light on(Red)

LAMP WARNING

Blinking(Green)

LAMP WARNING

STAND BY

Whileactivatingthelamp
(about1minute)

STANDBY/ON



All Off 

Duringimageprojection

STANDBY/ON

Light on(Green)

LAMP WARNING

LAMP WARNING

STAND BY

Duringcooldown

STANDBY/ON

Blinking(Red)

LAMP WARNING

Criterion indication of the lamp replacement

Displays lighting/ashing of the [LAMP] indicator. Moreover, the [STAND BY / ON] indicator, which shows
the operation mode of this unit, is displayed as described above. (Reference page: 72)

LAMP Light on(orange)

Lamp replacement is

near(When accumulated lamp
time has exceeded 2900 hours)

STANDBY/ON

LAMP WARNING

14

Getting Started

ENGLISH

Controls and features (continued)

Main body - Warning display and conrmation/response

Warning display

You are informed of the contents of warning notices by the (repeated) displays of the [WARNING] and
[LAMP] indicators. Moreover, the [STAND BY / ON] indicator, which shows the operating mode of the unit,
is displayed simultaneously as described above.
Upon activation of the warning mode, the projection is interrupted at the same time for about 60 seconds
and the cooling fan is turne
cooling fan has stopped. Subsequently, please perform the following checks and take appropriate
countermeasures.

d on. Please disconnect the power plug from the electric socket after the

Lighting/flashing lights

status diagram

STANDBY/ON

LAMP WARNING

red

(

)　　(

red

red

)

)

Mode

display

STANDBY/ON

Mode

display

STANDBY/ON

Mode

display

(*)

LAMP WARNING

orange

(

ultaneous

Sim

ashing

LAMP WARNING

orange

(

) (

Blinking

Frequency

1 time

2 times Cooling fan stops

3 times

4 times

1 time

2 times

)

3 times

1 time

2 times

3 times

Abnormalities in the power
supply

Internal temperature is too
high

External temperature is
too high

Abnormal electrical circuit

Lamp does not light up
and unit is unable to
project

Lamp is turned off during
projection

Lamp cover is removed

Content

Conrmation and
countermeasures

●

Check that nothing is

blocking the air inlets.

●

Check that the external
temperature is normal.

Action

Leave the unit until it cools
down.
After that, turn on the power
again.

●

Check that an impact shock

has not occurred during
operation.

●

Check that the lamp

unit and lamp cover are
correctly installed.

Action

Turn on the power again.

If the warning indication is displayed again, please wait for the cooling fan stopped, then pull out the power
plug from the power outlet. Then call your authorized dealer for repair.
(*)If the scheduled time for the replacement of the lamp is exceeded, the light might light up.

15

1

Getting started

Controls and features (continued)

Main body - Input terminal

① HDMI 1 ② HDMI 2 ③ LAN

⑤ COMPONENT

④ RS-232C

⑧ REMOTE

⑥ PC

① HDMI 1 Terminal

You can connect a device equipped with HDMI
output, etc. It is tted to the M3 lock hole.
Screw hole depth 3mm. (Reference page: 24)

② HDMI 2 Terminal

You can connect a device equipped with HDMI
output, etc. It is tted to the M3 lock hole.
Screw hole depth 3mm. (Reference page: 24)

③ LAN terminal “RJ-45”

This is a LAN-terminal. If one connects an
external PC, it is possible to control this unit by
sending control commands.

(Reference page: 28)

④ RS-232C terminal (male D-Sub 9

pin)

This is a RS-232C interface standard terminal.
If one connects an external PC, it is possible to
control this unit. (Reference page: 27)

⑤ COMPONENT terminal “RCAx3”

It is also used as input terminal for analog
RGB (G on Sync) signals, component (Y, Cb,
Cr) signals, DTV format (Y, Pb, Pr) signals. It
can also be connected with devices, which are
equipped with signal output, etc. (Reference
page: 25)

⑦ TRIGGER

⑥ PC terminal “D-Sub 15 pin”

This is an input term used for Personal Computer
(PC) signals only (RGB video signals and sync
signals). Use to connect a computer display
output terminal, etc. (Reference page: 26)

⑦ TRIGGER terminal( )

DC power supply output terminal with DC12V,
100mA. It is used for output signals which
control the vacillating screen responding to the
SCREEN TRIGGER. Please note it can cause
damage to your equipment if the connection is
done incorrectly. (Tip = DC +12 V, Sleeve = GND)
(Reference Page: 27, 50)

⑧ REMOTE terminal to “Stereo mini

jack”

In case it is impossible to use the remote control
due to the installation of this unit’s dedicated
BOX or rear projection, one can set up an
external light receiving section. It is used to
connect this external receiver and this unit. There
is no such product as an external light receptor.
Therefore, please consult your authorized JVC
service center. (Reference page: 28)

16

Getting Started

ENGLISH

BACK

HIDE

LIGHT

C.M.D

PC

HDMI 1

STAND BY

ASPECT

HDMI 2

ANAMO

COMP

.

LENS.

CONTROL

MENU

GAMMA

AP

LENS.

ADJ.

PIC.

ON

NATURAL

3D

USER4

USER5 USER6

PICTURE MODE

COMPONENT

TEMP

COLOR

AUTO
ALIGNMENT

DYNAMIC

USER1

USER2

USER3

Controls and features (continued)

■

Remote Control

To turn off the power

To set the screen size

(Reference page: 32)

VS21

RS50RS50

To control lens

(Reference page: 30)

To hide the image

temporarily(Reference

page: 34)

To display/close the menu

(Reference page: 41)

To adjust color temperature

To set gamma

To turn on the power

To select input mode
(Reference page: 30)

Clear Motion Drive
Auto Alignment

(Reference page: 48)
To illuminate buttons on the remote

control for 7 second

To select or conrm

To return to the previous menu
(Reference page: 41)

To switch picture mode

Lens Aperture

Sequentially switched picture
adjust items, such as contrast and
brightness.The switching items are
not the same for different models, or
different picture modes.

How to insert batteries into the remote control

①

●

●

●

If the remote control has to be brought closer to the projector to operate, it means that the batteries are

wearing out.

When this happens, replace the batteries. Insert the batteries according to the
Be sure to insert the end rst.
If an error occurs when using the remote control, remove the batteries and wait for 5 minutes. Load the

batteries again and operate the remote control.

②

③

marks.

17

2

CAUTION

CAUTION

CAUTION

Preparation

About installation

Important points concerning the installation

Please read the following carefully before the installation of this unit.

Installation environment

This unit is a precision device. Therefore, please refrain
from installation or use in the following locations.
Otherwise, it may cause re or malfunction.

• Dust, wet and humid locations.

• Sooty or cigarette smoke lled locations.

• On top of a carpet or bedding, or other soft surfaces.

• Locations with high temperatures - as located in direct

sunlight.

• Locations with high or low temperatures.

Permissible operating temperature range: +5 º to +35º .
Relative humidity range permissible for operating: 20%
~ 80% (non-condensing) .
Storage temperature tolerance: -10º to +60º.

• If the installation of the unit is done in a room with soot

and/or smoke over a longer period, even small amounts
of these substances will affect the device.This unit
cools its optical components, which produce a great
amount of heat, by sucking in air. If the optical circuits
get dirty, this might lead to malfunctions, like the video
images becoming darker or a deterioration of the color
development. Dirt sticking to the optical components
cannot be removed.

Please be careful to perform
the installation at a certain
distance from walls and
other devices

For better heat dissipation, please keep a minimum
distance between this unit and its surroundings as shown

the following illustration.

in
Moreover, please open the front of the unit. If there are
any objects in front of the exhaust port, the hot air will
ow back to the unit and heat it. The hot air owing out of
the unit might cause shadows on the screen (heat haze
phenomenon).
Moreover, when it is enclosed in a space as shown in the
following illustration, please make sure that the enclosed
interior has the same temperature as the outside. High
temperatures might lead to failure of the unit.

Please be careful when using

This unit uses a projection lamp, which will get hot when
in use. Please refrain from projecting in the following
circumstances.
Otherwise, it might cause re or malfunction.

• Projection while lying on its side.
Please avoid projection if the installation of the unit is
done at an excessive angle of more tha
cause harm to the life of the lamp and color shading.

• Please avoid projection at a location where the air vents
or exhaust ports might get blocked.

Please choose a non-uniform cloth material for the screen.
If you choose something uniform, like something with a
checkered pattern, there might be interference with the
pixel array of the D-ILA components. One way to reduce
the interference pattern is to change the size of the screen,
so that it will not be so noticeable.

n ± 90 °. It may

Inclination adjustment
for this unit

How to adjust the vertical angle

Height and inclination of the unit (0 ~ 5mm) can be
adjusted by rotating its feet. Lift the unit and adjust
the four feet.

18

300 mm
and above

150 mm
and above

Front

150 mm and above

300 mm
and above

200 mm
and above

Stand

Extend Contract

ENGLISH

Horizontal lens shift

About installation (Continued)

Installing the Projector and Screen

While installing, please place this unit and the screen perpendicular to each other. Failing
to do so may increase trapezoidal distortion.

Set Angle

As shown in the illustration, this unit can be installed
with a tilted angle, but for some areas there might be
other conditions. Moreover, depending on the angle of
installation, it may be necessary to have a hanging metal
mount and secure installation base depending on the angle
of the installation.

Area A: The range where installation is possible.
Area B: The necessary range for the installation of the
lamp attachment. Please make sure to use the
supplied lamp attachment. (Reference page: 54)
Failure to attach it might cause equipment failure.

VS21

Shift

■

　 *

RS50RS50

Left/Right position

0% up/down position (center)

■

Up/Down position

　 *

Downward slope
of 45 °

0% left/right position (center)

Area A

Area B

Downward slope
of 45 °

Preparation

Approximately 34%
(maximum) of the
projected image

Approximately 34%
(maximum) of the
projected image

Lens shift correlation chart:

Left-Right Shift(%)

Up-Down Shift(%)

●

Maximum Up-Down shift varies with the amount of Left-Right shift.
Likewise, maximum Left-Right shift varies with the amount of Up­Down shift.

●

The values on the chart are intended to act as a guide. Use them

for reference during installation.

0% 10% 20% 30% 34%

80% 66% 47% 18% 0%

Approximately 80%
(maximum) of the
projected image

Approximately 80%
(maximum) of the
projected image

■

Lens shift movement

range

90

80

70

60

Vertical lens shift（％）

50

40

30

20

Lens movability

10

range

0   10  20

  30  40

（％）

19

2

Preparation

About installation (Continued)

Fixation of the projector

Measures to prevent the unit from toppling or dropping should be taken for safety reasons and
accident prevention during emergencies including earthquakes.
When mounting this unit on a pedestal or ceiling, remove the 4 feet on the bottom surface and
use all the 4 screw holes (M5 screws) to mount.

Ceiling

Precautions for Mounting

●

Special expertise and techniques are required for
mounting this unit. Be sure to ask your dealer or a
specialist to perform mounting.

●

Depth of the screw holes (screw length) is 23
mm. Use screws shorter than 23 mm but longer

than 13 mm.

Using other screws will result in
malfunctioning or cause the unit to drop.

●

When mounting to a pedestal, ensure
sufcient space (foot height of 10 mm or

higher) around the unit so that the air inlets
are not blocked.

●

Do not tilt this unit more than ±5 degrees
from side to side when using.

■

Bottom Surface

4 locations

Air inlets

●

Regardless whether the unit is still under
guarantee, JVC is not liable for any product
damage caused by mounting the unit with non-

JVC ceiling ttings or when the environment is

not suitable for ceiling-mount.

●

When using the unit hanging from a ceiling,
pay attention to the surrounding temperature.

When a heater is in use, temperature around
the ceiling is higher than expected.

20

ENGLISH

30°

30°

20°

20°

About installation (Continued)

VS21

Screen Size and Projection Distance

Determine the distance from the lens to the screen to achieve your desired screen size.
This unit uses a 2.0x power zoom lens for projection.

■

Relationship Between Projection Screen Size and Projection Distance

RS50RS50

Pr o je c ti o n Sc re e n

Size

(Height, Width)

Aspect Ratio 16:9

"

60

Approx.

(

(Approx.0.9, 1.5m)

(Approx.1.0, 1.8m)

(Approx.1.1, 2.0m)

(Approx.1.2, 2.2m)

(Approx.1.4, 2.4m)

(Appro

(Approx.1.6, 2.9m)

0.7, 1.3m)

70"

80"

90"

100"

110"

120"

x.1.5, 2.7m)

130"

A p pr o x im a t e P r oj e c ti o n

Distance

W(Wide) to T(Tele)

Approx.1.78m to

Approx.3.66m

Approx.2.09m to Approx.4.28m

Approx.2.40m to Approx.4.89m

Approx.2.70m to Approx.5.51m

Approx.3.01m to Approx.6.13m

Approx.3.31m to Approx.6.75m

Approx.3.62m to Approx.7.36m

Approx.3.92m to Approx.7.98m

Projection Screen Size

(Height, Width)

Aspect Ratio 16:9

140"

(Approx.1.7, 3.1m)

150"

(Approx.1.9, 3.3m)

160"

(Approx.2.0, 3.5m)

170"

(Approx.2.1, 3.8m)

180"

(Approx.2.2, 4.0m)

190"

(Approx.2.4, 4.2m)

200"

(Approx.2.5, 4.4m)

Effective Range of Remote Control Unit

A p pr ox im at e P r oj e c ti o n

Distance

W(Wide) to T(Tele)

Approx.4.23 m to

Approx.8.60m

Approx.4.53m to

Approx.9.22m

Approx.4.84m to

Approx.9.84m

Approx.5.14m to

Approx.10.45m

Approx.5.45m to

Approx.11.07m

Approx.5.75m to

prox.11.68m

Ap

Approx.6.06m to

Approx.12.30m

Preparation

When directing the remote control toward this

■

unit.

●

When aiming the remote control towards the
remote sensor on this unit, ensure that the
distance to the sensor in front or at the rear of
this unit is within 7 m.

●

If the remote control fails to work properly, move

closer to this unit.

When reecting off a screen

■

●

Ensure that the total of distance A between this

unit and screen and distance B between remote
control and screen is within 7 m.

●

As the efciency of signals reected from the

remote control unit differ with the type of screen
used, operable distance may decrease.

Screen

This unit

20°

A

20°

B

Remote control

30°

Remote control

30°

This unit

21

2

Preparation

About the connection

Types of possible input signals (PC compatible)

●

HDMI

No.

Designation

1

2
3
4
5
6
7
8

WSXGA

9

●

PC (D-sub 3-lines 15 pins)

No.

1

2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19 1920x1080 60 1920 X 1080 67.500 60.00 148.500 2200 1125 1920 1080
20
21
22

60 640 X 480 31.500 60.000 25.200 800 525 640 480

VGA

59.94 640 X 480 31.469 59.940 25.175 800 525 640 480

VGA

SVGA

60 1024 X 768 48.363 60.004 65.000 1,344 806 1,024 768

XGA

WXGA

+60 1440 X 900 55.919 59.999 106.470 1,904 932 1,440 900

WXGA

SXGA

WUXGA

Designation

VGA

VGA
VGA
VGA

SVGA
SVGA

SVGA
SVGA
SVGA

XGA
XGA
XGA
XGA

WXGA

WXGA+

SXGA

SXGA+

WSXGA+

13" 640 X 480 35.000 66.667 30.240 864 525 640 480

MAC

16" 832 X 624 49.107 75.087 55.000 1120 654 832 624

MAC

19" 1024 X 768 60.241 74.927 80.000 1328 804 1024 768

MAC

Resolution

60 800 X 600 37.879 60.317 40.000 1,056 628 800 600

60 1280 X 768 47.760 60.000 79.998 1,675 796 1,280 768

60 1280 X 1024 63.981 60.020 108.000 1,688 1,066 1,280 1,024

+60 1680 X 1050 65.222 60.002 147.140 2,256 1,087 1,680 1,050

60 1920 X 1200 74.038 59.95 154.000 2,080 1,235 1,920 1,200

Resolution

60 640 X 480 31.500 60.000 25.175 800 525 640 480

72 640 X 480 37.900 72.000 31.500 832 520 640 480
75 640 X 480 37.500 75.000 31.500 840 500 640 480
85 640 X 480 43.300 85.000 36.000 832 509 640 480

56 800 X 600 35.200 56.000 36.000 1024 625 800 600
60 800 X 600 37.900 60.000 40.000 1056 628 800 600
72 800 X 600 48.100 72.000 50.000 1040 666 800 600
75 800 X 600 46.900 75.000 49.500 1056 625 800 600

85 800 X 600 53.700 85.000 56.250 1048 631 800 600
60 1024 X 768 48.400 60.000 65.000 1344 806 1024 768
70 1024 X 768 56.500 70.000 75.000 1328 806 1024 768
75 1024 X 768 60.000 75.000 75.750 1312 800 1024 768
85 1024 X 768 68.700 85.000 94.500 1376 808 1024 768

60 1280 X 768 47.760 60.000 79.998 1675 796 1280 768

60 1440 X 900 55.919 59.999 106.470 1904 932 1440 900

60 1280 X 1024 64.000 60.000 108.000 1688 1066 1280 1024

60 1400 X 1050 63.981 60.020 108.000 1688 1066 1400 1050

60 1680 X 1050 65.222

fh

[kHz]fv[Hz]

fh

[kHz]

60.002 147.140 2256 1087 1680 1050

dot CLK

[MHz]

fv

[Hz]

Total No.

of dots

[dot]

dot CLK

[MHz]

Total No.

Total No.

of dots

[dot]

of lines

[line]

Total

No. of

lines
[line]

No. of

effective

dots

[dot]

No. of

effective

dots
[dot]

effective

lines [line]

lines [line]

No. of

No. of

effective

22

ENGLISH

About the connection (Continued)

Connection to the unit

●

Do not turn on the power until connection is complete.

●

The connection procedures differ according to the device used. For details, refer to the instruction

manual of the device to be connected.

●

This device is used for image projection. Connect to an audio output device such as amplier and

speaker for audio output from the connected device.

●

The images may not be displayed depending on the devices and cables to be connected.

For HDMI cable (sold separately), only use one that is HDMI-approved.

●

It may not be possible to connect to this unit depending on the dimension of the connector cover of the

cables to be connected.

BD/DVD Recorder BD/DVD Player

Preparation

To connect via HDMI
terminal

(Reference page: 24)

To connect RS­232C terminal

(Reference
page: 27)

Connection by LAN terminal (Reference page: 28)

To connect via video terminal

STANDBY/ON

1 HDMI 2

RS-232-C

C

R/PR CB/PB Y

PC

TRIGGER

REMOTE
CONTROL

INPUT

OK

MENU

BACK

Connection by REMOTE terminal (Reference page: 28)

To connect via Trigger terminal

To connect via PC terminal

(Reference page: 26)

(Reference page: 27)

(Reference page: 25)

PC

VCR and

camcorder

23

2

1 HDMI 2

RS-232-C

C

R/PRCB/PB

Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

1 HDMI 2

RS-232-C

C

R/PRCB/PB

Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

Preparation

About the connection (Continued)

■

Connecting via HDMI Cable

This unit

Notebook PC

BD/DVD recorder

HDMI 1 input terminal
HDMI 2 input terminal

HDMI output terminal

HDMI cable (sold separately)

●

If noise is produced, take PCs (Notebook PC) away from this unit.

●

For a transmission bandwidth in compliance with the HDMI standard, a 340MHz cable is recommended

In case a cable is used for transmission bandwidth of 75MHz, it is recommended to choose 1080i or less
for the transmitting equipment.

●

If the video is not displayed, try to reduce the length of the cable or lowering the resolution of the video

transmitting equipment.

■

Connecting via HDMI-DVI Conversion Cable

This unit

Desktop computer

HDMI 1 input terminal
HDMI 2 input terminal

●

If noise is produced, take PCs (desktop computer) away from this unit.

●

If the video is not displayed, try to reduce the length of the cable or lowering the resolution of the video

HDMI-DVI conversion cable

(sold separately)

DVI output terminal

transmitting equipment.

24

About the connection (Continued)

C

Connecting via Component Video Cable

■

This unit

STANDBY/ON

INPUT

OK

1 HDMI 2

RS-232-C

C

R/PR CB/PB Y

PC

TRIGGER

REMOTE
CONTROL

MENU BACK

To component video input terminals

Component video cable

(sold separately)

●

Set “COMP.” in the setting menu to “Y Pb/Cb Pr/Cr”.

(Reference page: 48)

BD/DVD player

Component video output terminals

C

R/PR

C

B/PB

Y (green)

ENGLISH

Preparation

(red)

(blue)

■

Connecting via RGB Video Cable

This unit

STANDBY/ON

1 HDMI 2

RS-232-C

C

R/PR CB/PB Y

PC

REMOTE

TRIGGER

CONTROL

To RGB video input terminals

INPUT

OK

MENU

BACK

RGB video cable
(sold separately)

●

Set “COMP.” in the setting menu to “RGB”. (Reference page: 48)

●

For information on compatible input signals, see “Specications”.(Reference page: 72)

Device equipped with

RGB video output terminals

R(Red)
B(Blue)

G(Green)
signals)

RGB output

(Includes sync

25

2

1 HDMI 2

RS-232-C

C

R/PRCB/PB

Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

Preparation

About the connection (Continued)

■

Connecting via PC Cable

This unit

Notebook PC

To PC input terminal

PC cable(sold separately

●

For information on supported input signals, please refer to “Specications

)

VGA output terminal

(Reference page: 72)

”.

26

ENGLISH

1 HDMI 2

RS-232-C

C

R/PRCB/PB

Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

1 HDMI 2

3D

C

R/PRCB/PB

Y

SYNCHRO

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

About the connection (Continued)

■

Connecting via Trigger Cable

This unit

Screen

To Trigger output terminal

Trigger cable

(sold separately)

CAUTION

Trigger input terminal
(Φ3.5)

Preparation

●

Do not supply the power to the other devices.

●

Do not connect audio terminals of the other devices such as headphones etc. Otherwise, this may

cause a malfunction of the other devices or injury.

●

Using beyond the rated value will cause malfunction.

● Exercise adequate caution to prevent short circuit as the trigger terminal outputs a voltage of 12V.

●

The default is set to "No output". Please set it under the item "Trigger" of menu [5] "Function" (Reference
page: 50).

■

Connected by RS-232C connection cable

This unit

RS-232C connection cable (sold separately)

RS-232C

terminal

27

2

1 HDMI 2

RS-232-C

C

R/PR CB/PB Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

Preparation

About the connection (Continued)

■

Connected by LAN terminal

This unit

HUB

connection cable

(sold separately)

STANDBY/ON

1 HDMI 2

C

R/PR CB/PB Y

RS-232-C

REMOTE

TRIGGER

PC

●

The network is used to control the unit. It is not used for transmission of the video signal.

●

Please contact your network administrator for questions concerning the network connection.

CONTROL

INPUT

OK

MENU

BACK

Network

Server

■

Connected by a REMOTE terminal

This unit

External infrared sensor

connection cable(sold separately)

●

For an external infrared sensor and connecting cable, please contact your dealer or a JVC service

center.

(sold separately)

28

ENGLISH

1 HDMI 2

RS-232-C

C

R/PRCB/PB

Y

PC

TRIGGER

REMOTE
CONTROL

STANDBY/ON

MENU

BACK

INPUT

OK

Power Cord
(Supplied)

About the connection (Continued)

Connection of the power cord (provided)

Once you have connected the equipment, connect the projector power cord.

1 Connect the power cord supplied with the

unit power input terminal

2 Connect to the power outlet

1

2

Be carful to avoid re and electric shocks

● As the amount of electrical energy for this unit is large, please connect it directly into

the wall outlet.

CAUTION

● When you are not using the equipment, please unplug the power cord.

● Connect it only with the provided power cord.

● Do not use voltage other than the indicated power voltage.

● Do not damage, break or modify the power cord. Moreover, the power cord will be

damaged if you place it under heavy objects, heat or pull it.

● Do not unplug with wet hands.

Preparation

29

3

BACK

HIDE

LIGHT

C.M.D

PC

HDMI 1

STAND BY

ASPECT

HDMI 2

ANAMO

COMP

.

LENS.

CONTROL

MENU

GAMMA

AP

LENS.

ADJ.

PIC.

ON

NATURAL

3D

USER4

USER5 USER6

PICTURE MODE

COMPONENT

TEMP

COLOR

AUTO
ALIGNMENT

DYNAMIC

USER1

USER2

USER3

INPUT

LENS

LENS

Operation

Basic Operation

Basic operation procedures

6

1

2

3
4
5

Once you have nished the basic setup, the unit can normally be
used just with the following operations.

Turn on power source

1

ON

STANDBY/ON

Light on (Green)

●

You can also press the

on the power

Choose the projected image

2

1

Select input mode

●

You can also select the input mode by pressing the

. (Reference page: 13)

button on the unit to turn

button on the unit. (Reference page: 13)

HDMI 1

Play back the selected device

2

Adjust the zoom (screen size)

3

HDMI 2 COMP. PC

VS21

RS50RS50

30

Lens Control

Zoom

Exit

MENU

Select
Operate

Back

Adjust accordingly

BACK

by pressing the up/

down buttons

STANDBY/ON

LAMP

WARNING

VS21

Adjust the focus (focal point)

4

Lens Control

Focus

Select

Exit

MENU

Operate

Adjust accordingly

Back

BACK

by pressing the up/

RS50RS50

down buttons

Adjust the shift (image position)

OK



)RFXV =RRP

6KLIW

LENS

LENS

5

Lens Control

VS21

RS50RS50

ENGLISH

Shift

●

After adjusting the image position, it may be necessary to
select “Pixel Adjust” from the Settings menu “Installation”.

(Reference page:49)

●

Every time the

LENS

button is pressed, the adjustment

item will be switched among “Focus”, “Zoom” and “Shift”.

Turn off power source

6

It can also be switched with the button.

STAND BY

While a confirmation screen is displayed

STAND BY

Select
Operate

Back

Adjust accordingly

BACK

by pressing the

up/down/left/right

buttons

MEMO

About Cool Down
mode

●

The Cool Down mode is a

function to cool down the lamp
for approximately 60 seconds
after projection is complete.
This function prevents the
internal parts of the unit from
deformation or damage due to
overheating of the lamp. It also
prevents lamp blowout and
premature shortening of lamp
life.

●

During Cool Down mode, the

[STANDBY/ON] indicator blinks
in red.

●

After the Cool Down mode is

complete, the unit automatically
returns to standby mode.

●

Do not pull out the power plug

during Cool Down mode. This
may shorten the lamp life and
cause a malfunction.

Operation

STAND BY/ON

Blinking (Red Lamp)

Cool Down mode

STAND BY/ON

Light on (Red Lamp)

●

The power cannot be turned off within approximately 90
seconds after it has been turned on. Start operation only
after 90 seconds time.

●

You can also press the

the power. (

●

Pull out the power plug when the unit will not be used for a

Reference page: 13

button on the unit to turn off

)

prolonged time.

31

3

4:3 16:9 Zoom





Operation

Basic Operation (continued)

Frequently used useful functions

You can change the screen size of the projected image or
hide the surrounding area of an image for which quality at the
outer area has deteriorated.

A

Setting the Screen Size

B

Masking the Surrounding Area of an Image

C

Temporary turning-off of the video

A

Setting the Screen Size

The projected image can be set to a most appropriate screen
size (aspect ratio).

ASPECT



COMPONENT

HDMI 2

ANAMO

C.M.D

ON

COMP.

PC

AUTO
ALIGNMENT

LIGHT

STAND BY

HDMI 1

A

ASPECT

LENS.

CONTROL

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

LENS.

TEMP

AP

BACK

3D

USER3

PIC.
ADJ.

● The screen size can also be set from

“

Aspect(Video)” of the

setting menu. (Reference page: 46)

● When PC signals are input, the

“

Aspect(Computer)” setting will be

available instead. (Reference page: 46)

■

Input Image and Projected Image by Different Screen

Size

Input Image

SDTV(4:3)

SDTV(4:3)
Image recorded in
landscape (black
bands on top and
bottom) of DVD
software

● Depending on the input image, selecting

4:3

Aspect Ratio:Same
Most appropriate
screen size

Aspect Ratio:Same
Small image is
projected

vertically stretched image, while selecting “16:9” provides you
with the most appropriate screen size.

Screen Size

16:9

Aspect Ratio:
Landscape
Image is stretched
horizontally

Aspect Ratio:
Landscape
Image is stretched
horizontally

“

4:3” may result in a

Zoom

Aspect Ratio:Same
Top and bottom of
the image are
missing

Aspect Ratio:Same
Most appropriate
screen size

32

MEMO

Exit

MENU

BACK

Back

Select

Operate

Aspect (Video)

Progressive

HDMI

COMP.

Auto

PC　
Picture Position

16:9

Off

Mask

2.5%
5%

Off

Custom

Input Signal

Exit

MENU

BACK

Back

Select

Operate

Aspect (Video)

Progressive

HDMI

COMP.

Auto

PC　
Picture Position

16:9

5%

5%

Mask

2.5%
5%

Off

Custom

Input Signal

MENU

●

Mask in g is av ailab le onl y
when high definition images
are input.

COMPONENT

HDMI 2

ANAMO

C.M.D

ON

COMP.

PC

AUTO
ALIGNMENT

LIGHT

STAND BY

HDMI 1

ASPECT

LENS.

CONTROL

HIDE

B

ENGLISH

B

Masking the Surrounding Area of an Image

Images for which quality at the outer area has deteriorated
can be projected by masking (hiding) the surrounding area of
the projected image.

Project the image

1

Image for which quality at the outer
area has deteriorated.

Mask the image

2

1

Display the setting menu

Picture Adjust

MENU

Picture Mode

Color Temp.
Gamma
Contrast
Brightness
Color
Tint
Advanced

Exit

MENU

Select

0
0

0

0

Operate

Natural

6500K

Normal

Reset

Back

BACK

Operation

MENU

PICTURE MODE

DYNAMIC

NATURAL

USER1

USER2

USER5 USER6

USER4

COLOR

TEMP

LENS.

AP

GAMMA

Example:
When the “Mask” value is

changed from “Off”

BACK

3D

USER3

PIC.
ADJ.

“5%”

2

Select “Input Signal” “Mask

① Select

② Confirm

3

Set a mask value

① Select

② Confirm

”

3

To end

33

3

Operation

Basic Operation (continued)

C

Temporary turning-off of the video

You can hide the image temporarily.

COMPONENT

HDMI 2

ANAMO

C.M.D

ON

COMP.

PC

AUTO
ALIGNMENT

HIDE

Green light blinks

when the image is

hidden.

●

Press the

●

The power cannot be turned off when the image is temporarily

HIDE

button again to display image.

hidden.

STAND BY

HDMI 1

ASPECT

LENS.

CONTROL

C

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

TEMP

LENS.

LIGHT

BACK

3D

USER3

PIC.
ADJ.

AP

34

ENGLISH

Picture Adjust

Reset

Exit

MENU

BACK

Back

Select

Operate

Picture Mode

Natural

Color Temp.
Gamma
Contrast
Brightness
Color

Tint
Advanced

0
0

0

0

6500K

Normal

Exit

MENU

BACK

Back

Select

Operate

Aspect(Video)

HDMI

Mask
Progressive

Auto

Short Delay

Off

COMP.
PC

Picture Position

16:9

Off

Input Signal

Adjustments and settings in the menu

Structure of the menu hierarchy (summary)

The Menu of this unit is organized as follows. As this is only a brief guideline, items, which might not be
displayed due to certain settings, are still displayed in the illustration. Moreover, in regard to
countermeasures for all kinds of devices, but there the values for setting and adjustment might be different.
See “Description of menu items” (Reference: Since 43 and following) for details. It can be moved to
subscreens used for adjustment, even for items that do not feature submenus.

, it shows

COM

[1] Picture Adjust

[2] Input Signal

COM COM

(*)

Operation

(*) When there is a PC

signal input, “Aspect
(PC)” is displayed.

Continue to

the next

To “[1] Layers and

organization of the picture

quality submenu

To “[2] Layers and

organization of the input

”

signal submenu”

35

3

Exit

MENU

BACK

Back

Select

Operate

Pixel Adjust　

Installation

Lens Control

Black Level

Installation Style

Front

Exit

MENU

BACK

Back

Select

Operate

Pixel Adjust　

Installation

Black Level

Installation Style

Front

Exit

MENU

BACK

Back

Select

Operate

Display Setup

Back Color

Menu Display

On

Line Display

５sec

Source Display

On

Logo

On

Language

English

Black

Menu Position

Operation

Adjustments and settings in the menu (continued)

[4] Display Setup[3] Installation

Continued from

the previous page

VS21

RS50RS50

RS50RS50

VSNL

COM

Continue

to the next

36

To “[3] Layers and
organization of the
installation submenu”

ENGLISH

Exit

MENU

BACK

Back

Select

Operate

Trigger

Off Timer

Communication Terminal

Network
Lamp Reset

High Altitude Mode

LAN

Off

Off

Off

Function

Exit

MENU

BACK

Back

Select

Operate

160H

HDMI-2

1080p60

10bit

Input
Source
Deep Color
Lamp Time

Information

：

：

：

：

Exit

MENU

BACK

Back

Select

Operate

Lamp Time

Deep Color

160H

PC

1920X1080

Information

Resolution　　

67.50kHz

H Frequency

60.0Hz

V Frequency　 　　　　　

Input

：
：

：

：
：
：

8bit

Adjustments and settings in the menu (continued)

[6] Information[5] Function

Continued

from the

previous

page

COM

COM

COM

Operation

To “[5] Layers and
organization of the function
submenu”

For PC signal input

37

3

Color Management

Color Selection
Axis Position
Hue
Saturation
Brightness

Off

Custom1
Custom2
Custom3

Picture Adjust

Exit

MENU

BACK

Back

Select

Operate

0
0

0
0

Pause

Off

Reset

Red

>

>

Exit

MENU

BACK

Back

Select

Operate

0

>

>

25

Detail Enhance

Sharpness

Picture Adjust

Sharpness

Picture Adjust

Reset

Exit

MENU

BACK

Back

Select

Operate

Picture Mode

Natural

Color Temp.

Gamma
Contrast
Brightness
Color
Tint

Advanced

0
0

0

0

6500K

Normal

>

Color Temp.

Gain Red
Gain Green
Gain Blue

Offset Red
Offset Green
Offset Blue

5500K

6500K
9500K
High Bright
Custom1
Custom2
Custom3

Picture Adjust

Exit

MENU

BACK

Back

Select

Operate

Reset

0
0

0
0
0

0

Picture Adjust

Exit

MENU

BACK

Back

Select

Operate

>

Advanced

NR

Sharpness

0

Lens Aperture

Clear Motion Drive

Color Management

Lamp Power

Off

Off

Normal

Operation

Adjustments and settings in the menu (continued)

[1] Layers and organization of the picture adjust submenu

[1] Picture Adjust

[1-1]

[1-2]

[1-2-1]

COM

[1-1] Color temp.

COM

[1-2-1] Sharpness

COM

[1-2] Advanced

COM

38

[1-2-2]

[1-2-2] Color Management

COM

ENGLISH

Exit

MENU

BACK

Back

Select

Operate

Input Signal

COMP.

Y Pb/Cb Pr/Cr

Color Space

Exit

MENU

BACK

Back

Select

Operate

Level Check

Input Signal

HDMI

Auto

Color Space　

Enhanced

Input

Exit

MENU

BACK

Back

Select

Operate

Input Signal

PC

16

Phase　

2200

Tracking　

Picture Position　

Auto Alignment

Exit

MENU

BACK

Back

Select

Operate

Aspect(Video)

HDMI

Mask
Progressive

Auto

Short Delay

Off

COMP.
PC

Picture Position

16:9

Off

Input Signal

Adjustments and settings in the menu (continued)

[2] Layers and organization of the input signal submenu

[2-1] HDMI

COM

[2] Input Signal

[2-1]
[2-2]
[2-3]

COM

[2-2] COMP.

COM

Operation

[2-3] PC

COM

39

3

Exit

MENU

BACK

Back

Select

Operate

Trigger
Off Timer

Communication Terminal

Network

Lamp Reset

High Altitude Mode

LAN

Off

Off

Off

Function

Exit

MENU

BACK

Back

Select

Operate

IP Address　
Subnet Mask
Default Gateway

Network

DHCP Client

Off

Function

Set

MAC Address :

AA-BB-CC-DD-EE-FF

192. 168. 0.254

255. 255. 255. 0

192. 168. 0. 2

Exit

MENU

BACK

Back

Select

Operate

Lock

Off

Zoom　

Shift

On

Image Pattern

Installation

Lens Control

Focus

Exit

MENU

BACK

Back

Select

Operate

Horiz. Green　
Horiz. Blue

Installation

Pixel Adjust

Vert. Red
Vert. Green
Vert. Blue

3

3

3

3

3

Horiz. Red

3

Exit

MENU

BACK

Back

Select

Operate

Pixel Adjust　

Installation

Lens Control

Black Level

Installation Style

Front

Exit

MENU

BACK

Back

Select

Operate

Pixel Adjust　

Installation

Black Level

Installation Style

Front

Operation

Adjustments and settings in the menu (continued)

Layers and organization of the submenus [3] installation and [5] function

[3-1] Lens Control

VS21

RS50RS50

[3] Installation

VS21

RS50RS50

[3-1]
[3-2]

[3-2]

[5] Function

[5-1]

RS50RS50

VSNL

COM

[3-2] Pixel Adjust

COM

[5-1] Network

COM

(*)

40

(*) MAC address is different

depending on the
respective equipment

ENGLISH

STANDBY/ON

MENU

BACK

INPUT

OK

Adjustments and settings in the menu (continued)

Menu operation button

Operate the menu by use of the buttons on the main body or the
remote control.

Button

This unit Remote Control

MENU

OK OK

BACK

This unit

Remote Control

MENU

BACK

Function

Menu is displayed.

While t he menu is displa yed,
the men u screen is turne d off.

While showing "Main menu" (Layer 1)
selected items are confirmed, and
"Submenu" (Layer 2) will be displayed.
When the submenu is displayed, press
OK, and the displayed items in the
selection are moved to the
"Setting screen" (Layer 3).

Return to the previous menu screen.

The menu screen is turned off when
the main menu screen is shown.

Displaying the main menu and the
submenu

Select an adjustment item in the

：/

menu. Set the setting value of the
selected adjustment item. The
adjusted setting value is immediately
reflected in the image.

：

/

Selection of a displayed sub-menu
item. Selection of an item in the
menu.

STAND BY

HDMI 1

ASPECT

LENS.

CONTROL

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

COMPONENT

HDMI 2

ANAMO

C.M.D

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

LENS.

TEMP

AP

ON

COMP.

PC

AUTO
ALIGNMENT

USER3

LIGHT

BACK

3D

PIC.
ADJ.

Menu
operation
buttons

Menu
operation
buttons

Operation

41

3

STANDBY/ON

MENU

BACK

INPUT

OK

Exit

MENU

BACK

Back

Select

Operate

160H

HDMI-2

1080p60

10bit

Input
Source
Deep Color
Lamp Time

Information

：

：

：

：

Exit

MENU

BACK

Back

Select

Operate

Lamp Time

Deep Color

160H

PC

1920X1080

Information

Resolution　　

67.50kHz

H Frequency

60.0Hz

V Frequency　 　　　　　

Input

：
：

：

：
：
：

8bit

Operation

Adjustments and settings in the menu (continued)

Menu operation procedure

1 Press MENU.

The main menu is displayed on the screen.

The submenu items, which are currently
selected, are shown. Currently selected menu

Natural

items are highlighted and the icon is colored

6500K

Normal

in orange.
The submenu items, which are currently
selected, are displayed.

Reset

Back

BACK

COM

COM COM

1

STAND BY

ON

3
3,4

2,5

6

Picture Adjust

Picture Mode

Color Temp.
Gamma
Contrast
Brightness
Color
Tint
Advanced

Exit

MENU

Select

0
0

0

0

Operate

Example: Picture Adjust

2 Press cursor ( / ) to select a submenu.

● A submenu (picture adjust, input signal, installation, display

setup, function, information) is selected:

● If one selects "Information", information about the currently

selected video input and PC input are displayed at the bottom
of the menu.

3 Press OK or cursor ( / ).

● Sub-menu item is displayed.

● Sub-menu items vary depending on the input signal and the

picture mode. See "Content menu" on the next page for more
details.

1

HDMI 1

ASPECT

LENS.

CONTROL

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

COMPONENT

HDMI 2

ANAMO

C.M.D

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

LENS.

TEMP

AP

COMP.

PC

AUTO
ALIGNMENT

LIGHT

BACK

3D

USER3

PIC.

ADJ.

3,4
2,5

3

6

Example: Input of signals
other than PC signals

Example: When inputting
PC signals

4 Press the cursor ( / ) to select the items to

adjust.

If the name of a submenu item is displayed in a dimmed manner,
it cannot be selected.

5 Press cursor ( / ) to change settings.
6 After adjusting, press BACK.

Every time it is pressed, you will return to the respective previous
menu screen.

7 Repeat steps 6-2 to adjust other items.

After all adjustments are done, press MENU, and the menu
disappears from the screen.

42

ENGLISH

Adjustments and settings in the menu (continued)

Menu item description

All numbers for the items within [ ]are default settings.

● It is possible to operate all items displayed in the menu display by pressing OK/BACK or the cursor (up,

down, left, right arrows).

● Displayed items vary depending on the selected item in the menu and type of input signal or absence of

any signal.

[1] Picture Adjust

Picture Mode

Natural It is an image quality setting with natural color/tone. Suitable for viewing video material,

Dynamic This is the picture setting best suited for viewing the picture in a room that cannot be

User 1
User 2
User 3
User 4
User 5
User 6

Please refer to the description of each mode, and then use the mode to best suited for
you. Moreover, it is possible to adjust the image quality by using a user 1, 2, 3, 4, 5and 6.
Settings: Natural, Dynamic, User 1, User 2, User 3, User 4, User 5, User 6.
[Natural]

such as dramas/serials.

made completely dark.
The users 1, 2, 3, 4, 5, and 6 should adjust the image quality as desired in each case.

Data of the last adjustment is saved.

Color Temp.

Gamma

Normal Typically we recommend this setting.
Custom 1
Custom 2
Custom 3

Contrast

Brightness

Color

Tint

Advanced

Reset

It is possible to set the color temp.
To "[1-1] Color Temp." of the submenu

It is possible to set the gamma curve. Please set to your preference.
Settings: Normal, Custom 1, Custom 2, Custom 3
[Normal]

In regard to normal gamma, this is a gamma curve focused on tone.

This is a gamma curve for the lm's unique S curve.
This is a gamma curve that – in regard to the gamma of B – emphasized even more the

feeling of contrast.
Adjusts the contrast of the video images.

Settings: (blackish) -50 to 50 (whitish)
You can adjust the brightness of the video image.

Settings: (dark) -50 to 50 (bright)
Adjust the color intensity of the video images.

Settings: (dim), -50 to 50 (saturated)
Adjusts the image tint of the video images.

Settings: (reddish) -50 to 50 (greenish)
Functions such as contour correctionand color management can be set to sub-menu

"[1-2] Advanced".
Sets settings to default factory settings.

Operation

43

3

Operation

Adjustments and settings in the menu (continued)

[1-1] Color Temp.

Set the color temp. of the video images.
Please adjust to your preference.
(*) For this setting, the setting items can differ in accordance with the "Picture Mode".
Settings: (Preset value), High Bright, Custom 1, Custom 2, Custom 3
[Preset value]

(Preset value) You can set the Color Temp. to 5500K, 6500K or 9500K.

High Bright Select this to get the brightest image.

Custom 1
Custom 2
Custom 3

Gain It is possible to adjust the bright part of the video images for each color.

Red Settings: (Weak red) -255 to 0 (strong red) [0]
Green Setting: (Weak green) -255 to 0 (strong green) [0]
Blue Setting: (Weak blue) -255 to 0 (strong blue) [0]

Offset

Red
Green
Blue

It is said that a value of 6500K produces a well balanced video image.

Settings: (reddish) 5500, 6500, 9500 (bluish) [6500]

(*) It is not possible to set it when the "Picture Mode" is set to "Natural".
You can adjust the color temp. and save each Custom 1, 2, and 3.Please save your

preferred adjustment values and enjoy it.

For each color, the dark areas of the video images can be adjusted.
Settings: (Weak red) -50 to 50 (strong red) [0]

Setting: (Weak green) -50 to 50 (strong green) [0]
Setting: (Weak blue) -50 to 50 (strong blue) [0]

[1-2] Advanced

Sharpness
NR

RNR Adjusts the intensity of random noise elimination of the image.

MNR Adjusts the intensity of mosquito noise elimination of the video images.

BNR Reduces the block noise of the video images.

You can set the sharpness and detail enhance to "[1-2-1] Sharpness" of the submenu
Reduces the noise of the video images. Please adjust to your preference.

Values: (Low) 0 to16 (strong) [0]

Moreover, it is not possible to set it when there is an input of HD input signals.

Values: (Low) 0 to16 (strong) [0]

Moreover, it is not possible to set it when there is an input of HD input signals.
Settings: On, Off [Off]

44

ENGLISH

Adjustments and settings in the menu (continued)

Color Management

Clear Motion Drive

Off Off
Mode 1 Black insertion weak
Mode 2 Black interpolation strong
Mode 3 Interpolation weak
Mode 4 Interpolation strong

Lens Aperture

Lamp Power

Normal Normally this setting is chosen.(160W drive)
High In a bright room, when the video is hard to see, this setting is chosen.(220W drive)

It is possible to set the color of the screen to the preferred color and save it.
To "[1-2-2] Color Management" of the submenu.

It improves video images with fast movements to produce clear video images with little
residual image retention.

For PC signals, the "Clear motion Drive” cannot be set.

(*) If "Short Delay" is set to "On", "Mode 3" and "Mode 4" are not available.
Moreover, it may happen that the image is distorted in some scenes, or light and dark

ashes occur. In this case, please choose "Off", etc., and then a setting of your choice.

Settings: Off, Mode 1, Mode 2, Mode 3, Mode 4 [Off]

Adjusts the amount with which the optical iris is squeezed. A setting of 0 means fully
opened.
Settings: (Dark) -15 to 0 (bright) [0]

Settings: (Dark) -3 to 0 (bright) [0]
It is possible to change the brightness of the lamp.

(*) If continually used with "High", the lamp will become dark earlier.
(*) The more one lets the interior temperature of the device rise due to generation of heat,
the less the level of tolerance against high temperatures.
(*) For about 60 seconds after the lamp is lit, the lamp cannot be switched off.
Settings: Normal, High [Normal]

VS21

RS50RS50

RS50RS50

VSNL

[1-2-1] Sharpness

Sharpness

Detail Enhance

Emphasizes the outlines of video images. Please adjust to your preference.

Values: 0 to 50 (clear)

It makes minute details of the video images stand out. Please adjust to your preference.

Values: 0 to 50 (strong)

Operation

45

3

Operation

Adjustments and settings in the menu (continued)

[1-2-2] Color Management

Custom 1~3

Pause It is possible to display the input video image of the background being adjusted as a still

On
Off

Color Selection It is possible with the 7 colors of red, orange, yellow, green, cyan, blue and magenta to

Axis Position Fine-tune the position of the central axis of the selected color further.

Hue Adjust the hue.

Saturation Adjust the color saturation.

Brightness Adjust the brightness.

Set the 7 color axis (red / orange / yellow / green / cyan / blue / magenta) color as you
like and save it then. For example you may want to change only the red color of roses.
Please adjust to your preference. According to your adjustments, the input image in the

background changes. It is possible to conrm the video image before adjustment by

pressing the "HIDE" button of the remote control.

picture.
Settings: On, Off [Off]

Freezes the input video image.
Unfreezes the input video image.

precisely adjust the hue, color saturation and brightness, and then save it. Please adjust
to your preference.

Settings: -30 to 30 [0]

Settings: -30 to 30 [0]

Settings: (dim color), -30 to 30 (vivid colors) [0]

Settings: (dark) -30 to 30 (bright colors) [0]

[2] Input Signal

HDMI It is possible to set this if one selects the HDMI terminal to the submenu "[2-1] HDMI".
COMP. This can be set if one selects the COMP. terminal to the submenu "[2-2] COMP."
PC This can be set if one selects the PC terminal to the submenu "[2-3] PC".
Picture Position

Horiz.

Vert.

Aspect (Video)

4:3 Sets the screen size of the image to 4:3. For HD signals, left and right sides are reduced.
16:9 Sets the screen size of the video image screen to 16:9. For SD signals left and right sides

Zoom Zooms the video images. (*) For HD signals, this cannot be selected.

Aspect (PC)

Auto Positions the video image screen in the center of the display range, to ll the screen.

Just The video image screen size is displayed with the size of the input image.

Full It does not keep the aspect ratio of the video image screen and lls the entire screen.

Please adjust if the edges of the picture are partially missing due to the timing of
horizontal and vertical synchronization signals. The value of the picture position depends
on the input signal.
(*) Depending on the input signal, it may be the case that not everything of the video
image is displayed.

This aligns the horizontal direction of the image position.
This aligns the vertical positions of the image.
(*) It is displayed when there is a video signal input.

Settings: 4:3, 16:9, Zoom [16:9]

are expanded.

Sets the video image screen size when there is a PC video signal input.
(*) Is displayed when there is a PC signal input.
Settings: Auto, Just, Full [Auto]

Depending on the size of the video screen, left and right black borders will be drawn.

Depending on the input video image, the screen will become smaller or part of the input
image off the screen is cut off.

46

ENGLISH

Adjustments and settings in the menu (continued)

Mask

Off Not masked.

2.5% Compared to the original video images, around 2.5% around the video images are

5% Compared to the original video images, around 5% around the video images are masked.
Custom

Left Compared to the original video images, around 5% of the video images are masked on

Right Compared to the original video images, around 5% of the video images is masked on the

Top Compared to the original video images, around 5% of the video images are masked at the

Bottom Compared to the original video images, around 5% of the video images are masked at the

Progressive

Auto It is automatically detected if the 24p video images, which can be seen in the lm screens,

Off The interpolation of video images as interlaced video signals, e.g. video material is done.

Short Delay

It hides the upper, lower, left and right borders of the screen with a black mask. Can be
individually adjusted vertically and horizontally. Please adjust to your preference.
Setting: Off, 2.5%, 5%, Custom [Off]

masked.

the left side.
Settings: 0 ~ 48 [0]

right side.
Settings: 0 ~ 48 [0]

upper side.
Settings: 0 ~ 28 [0]

bottom side.
Settings: 0 ~ 28 [0]

Interlaced signals (480i/576i/1080i) are converted to progressive signals. Interpolates
interlaced signal video images with video images from the surrounding. Please set to your
preference.
Settings: Auto, Off [Auto]

interlaced signals from the original video material or if they are the product of signal
conversion and are interpolated accordingly.

Supports only 1080p50/60 signals.
(*) If set to "On ", "Mode 3" and "Mode 4" of the "Clear Motion Drive" (page reference: 45)
are not available.
Settings: On, Off [Off]

Operation

[2-1] HDMI

Input

Standard It gets set if the dynamic image range of the gradation level of the input image is set to

Enhanced It is set if the dynamic range of the input video scale level is 0-255.If these are PC signals,

Super White It is set if the dynamic range of the input video scale level is 16-255.Please set the output

Level Check

0 235

255 16

Color Space

Auto YCbCr(4:4:4), YCbCr(4:2:2), RGB signals are automatically detected and congured.
YCbCr (4:4:4) Sets it if the input of the YCbCr(4:4:4) input video image signal is performed.
YCbCr (4:2:2) Sets it if the input of the YCbCr(4:2:2) input video image signal is performed.
RGB It is set when the RGB video signals input is performed.

(*) It can be set when the HDMI terminal is selected.
Sets the dynamic range of the input video images (scale). Dark and bright areas, which

are not matched to the range, might get brighter or darker. If you are unsure of the input
signal dynamic range, please check under "Level Check".
Settings: Standard, Enhanced, Super White [Enhanced]

16-235. In case of a video signal, please set it up here.

please set them here.

to video equipment compatible with Super White for Super White-enabled DVD / BD etc.
You can conrm the dynamic range of the input signal.A pattern as shown in the

illustration is displayed in the four corners and center of the screen. Please compare the

dynamic range of input signal with this pattern illustration and conrm.

(*) The number in the illustration is the scale level. This number is not displayed. The

illustration of the gradation in the gure is accentuated for explanatory purposes It is

different from the actual scale level.
It sets the color space of the input signal.

Settings: Auto, YCbCr(4:4:4), YCbCr(4:2:2), RGB [Auto]

47

3

Operation

Adjustments and settings in the menu (continued)

[2-2] COMP.

(*) It can be set when the COMP. terminal is selected.

Color Space

Y Pb/Cb Pr/Cr It is set for the component video image input signal.
RGB It is set for the RGB video image input signal.

[2-3] PC

Auto Alignment
Tracking

Phase

Picture Position

Horiz. Adjusts the horiz. of the video image.
Vert. Adjusts the vertical position of the image.

[3] Installation

Lens Control To Sub-menu "[3-1] Lens Control"
Pixel Adjust To submenu "[3-2] Pixel Adjust"
Installation Style

Front Front upright projection mode.
Ceiling Mount (F) Ceiling/front projection mode.
Rear Rear upright projection mode.

Ceiling Mount (R) Ceiling/ rear projection mode.

VS21

RS50RS50

It congures the input signal method of the component input terminal.

Settings: Y Pb/Cb Pr/Cr, RGB [Y Pb/Cb Pr/Cr]

(*) Setting can be done when selecting a PC terminal.
The picture position of Tracking and Phase are automatically adjusted.
Adjusts the size and display of the horizontal direction and display area of the video

images.
(Depending on the signal, there is normally no need to be adjusted.)

Adjusts the ickering and blur of the video images.

(Depending on the signal, there is normally no need to adjustment.)
Adjust the display of the picture position.

Matching the state of the projector’s projection, one can switch horizontal and vertical ip

/ forward switch.
Settings: Front, Ceiling Mount (Front), Rear, Ceiling Mount (RE) [Front]

48

ENGLISH

Adjustments and settings in the menu (continued)

Black Level

[3-1] Lens Control

Focus
Zoom
Shift
Image Pattern

On During the adjustment, the image pattern is displayed.

Off The external input signal is displayed without displaying the image pattern.

Lock

On It is not possible to adjust the above setting items. If the remote control button "LENS"

Off This functions as lens control function.

Sets the black level when used indoors.
Settings: 0 to 10 [0]

VS21

RS50RS50

It controls each motorized functions of the lens during the projector-installation.

This function is used to adjust the focus.
This function is used to adjust the zoom.
This function is used to adjust the shift.
It is possible to adjust the projection screen during adjustment of the focus zoom shift.

Settings: On, Off [On]

The image pattern is displayed in conjunction with the above setting items.

This sets the lens control to on/off.
Settings: On, Off [Off]

button is pressed, a warning message is issued.

[3-2] Pixel Adjust

This ne tunes each slight color errors in the horizontal/vertical directions of the video

images in units of 1 pixel.
(*) It is impossible to match all image pixels on the screen. Due to the equipment, there
will always be some gaps.
(*) In case the image is reversed, or upside-down, the horizontal and vertical directions
are reversed.
(*) Please perform adjustments on a clear still picture.

(*) For ne tuning, the effects of adjustments may be difcult to understand for some

video images.

Horiz. Red
Horiz. Green
Horiz. Blue

Vert. Red
Vert. Green
Vert. Blue

(Move red to the left) 1 to 5 (Move red to the right) [3]
(Move green to the left), 1 to 5 (Move red to the right) [3]
(Move blue to the left) 1 to 5 (Move red to the right) [3]
(Move red down) 1 to 5 (Move red up) [3]
(Move green down) 1 to 5 (Move green up) [3]
(Move blue down) 1 to 5 (Move blue up) [3]

Operation

49

3

Operation

Adjustments and settings in the menu (continued)

[4] Display Setup

Back Color

Blue Sets the background color to blue.
Black Sets the background color to black.

Menu Position

Menu Display

15 sec If there is no menu operation for 15 seconds, the menu display vanishes.
On Display always.

Line Display

5 sec Displays for 5 seconds.
Off Not displayed.

Source Display

On Display.
Off Not displayed.

Logo

On Displayed for 5 seconds.
Off Not displayed.

Sets the color of the background, which is displayed without an input signal.
Settings: Blue, Black [Black]

Sets the picture position of the menu. Please set to your preferred position Navigate the
menu by pressing the left or right keys when you have selected an item. Moreover, if

one presses the button [OK], an image illustration appears at the position of the menu.

The highlighted position in the illustration moves by use of the left and right keys. If one

presses [OK], the menu moves to the highlighted position.

If you press the key to the right, the menu will move starting from the higher left -> the
higher right -> the center -> the lower left -> the lower right and then back to the higher
left. By pressing of the left key, the menu moves in the opposite direction.
[the higher left]

Sets the time for the menu to be displayed.
Settings: 15 sec, On [On]

Congures if input is displayed or not when input is switched.

value: 5 sec, Off [5 sec]

Congures whether or not to display the signal, when the input is switched.

Settings: On, Off [On]

Congures whether or not to display the "D-ILA" logo upon activation.

Settings: On, Off [On]

[5] Function

Trigger

Off No output.
On (Power) When turned on, control signals (12V) from the trigger terminal are emitted.

Off Timer

Congures 12V output to an external screen equipped with a trigger function.

Settings: Off, On(Power) [Off]

If you turn off the power, the output of the control signal stops.
During standby mode, an output will occur if the OPERATE button is pressed.
After cooling, the output stops when you go back to standby.

Sets Off Timer function and its time.
* If there are no operations, the unit powers off automatically.
* It powers off automatically even while projecting an image.
Settings: Off, 1 hour, 2 hours, 3 hours, 4 hours [Off]

50

ENGLISH

Adjustments and settings in the menu (continued)

Off Power is not turned off.
1 Hour Power is turned off automatically after 1 hour.
2 Hours Power is turned off automatically after 2 hours.
3 Hours Power is turned off automatically after 3 hours.
4 Hours Power is turned off automatically after 4 hours.

High Altitude Mode

On Set.
Off Do not set.

Communication
Terminal

RS-232C Sets the RS-232C terminal.
LAN Sets the LAN terminal.

Network It is displayed, if the setting of the "Communication terminal” to the submenu "[5-1]

Lamp Reset

[5-1] Network

DHCP Client

On Obtains automatically an IP address from within the connected network's DHCP server.

Off The network settings are being done manually.

IP Address
Subnet Mask
Default Gateway
MAC Address
Set

Set to use at low pressure locations (900m above sea level).
Settings: On, Off [Off]

Sets the used control terminal. It is not possible to use it at the same time.
Settings: RS-232C, LAN [RS-232C]

Network" is set to "LAN".
Reset of the lamp use time to "0".

Sets the DHCP client.
Settings: On, Off [Off]

* The automatic retrieval starts with the "Set" within the menu.

Sets the IP address. [192.168.0.2]
Sets the subnet mask. [255.255.255.0]
Sets the default gateway. [192.168.0.254]
Displays the MAC address of the unit.

[5-1] Reects the network setting.

Operation

[6] Information

Displays upon HDMI/COMP. input

Input Displays video image input terminal.
Source Displays the name of the input source.
Deep Color Displays the color bit depth concerning an input video image signal.

Lamp Time Displays the lamp use time.

Displays upon PC input

Input Displays video image input terminal.
Resolution Displays image resolution.
H Frequency Displays the H Frequency.

V Frequency Displays V Frequency.

Deep Color Displays the color bit depth concerning an input video image signal.

Lamp Time Displays the lamp use time.

* When you input YCbCr (4:2:2), it is not displayed.
* When there is information about DeepColor from the source device, it is displayed.

* When you input YCbCr (4:2:2), it is not displayed.
* When there is information about DeepColor from the source device, it is displayed.

51

3

Operation

Operation guide (glossary)

Gamma Curve

The description of the gamma curve that assumes a gamma curve unit. Please read the relevant detailed description
and professional books.
The gamma curve of the projector to the input video signal determines for each color the relative value of its light output.
The value of the input video image signal is displayed as a percentage - with
both being displayed in % as units - of the maximum light input signal for bright­ness and the brightness output value as a percentage of the maximum output
value of each color or the projector. In relation to the signal value of 50% of the
input, it projects with brightness output value of 50%. However, a light output
value of 0% is not completely black and neither no projection. As the possibil­ity of the projector to reproduce blackness is limited, it will be actually slightly
brighter.
The input video image signal value becomes a continuous curve of 0% to 100%
for the gamma curve, which can be set with the projector. Moreover, it is impos­sible to get only one light output value for the input video image signal value.
The gamma curve can be set for each color, i.e. red, green and blue. By select­ing the white color, the 3 colors can be adjusted at the same time.
A larger angle of inclination of the gamma curve leads to a greater gap of the
light output value of that area and makes it easier to distinguish the video images. A low angle of inclination leads, on the
contrary, to the difference in that area becoming smaller, so that the video images are harder to distinguish. If it is im­possible to get an inclination angle, so that it is chosen to become horizontal, the gap in that area vanished and it might
be impossible to distinguish the video images.

100%

A

A

100%

50%

The light output

0%

0%

Input signal value

B C

50%

100%

B

The light output

C

0%

Input signal

0%

value

Suppose you knew the inclination of the input video image signal values of the watched video images, and would
increase the slope of the portion of this area and attenuate the slope of other areas. It would then be easier to determine
the video images. Also, if you did not know the inclination of the input video image signal value of the watched video
images, adjustment would be difcult.However, there are some trends of the distribution of the input video image signal
value depending on the type of video content. As some typical examples are prepared in the [Gamma] (Reference Page:

43), it is recommended to perform similar settings before watching.
Some methods about how to adjust the gamma curve are presented here, but in reality one can think of various adjust-

ment methods, for examp
enjoy the process of trial and error.

le where red, green and blue are individually adjusted. In your own image creation, please

100%

The light output

0%

Input signal

0%

value

100%

100%

100%

0%

The light output

Input signal

0%

value

100%

52

The distribution of the input signal

The distribution of the input signal

MEMO

ENGLISH

Operation

53

4

Maintenance

Explanation of the installation/
removal of the lamp attachment

● For cases where you want to use it and the installation situation of the projector main unit shows a
downward slope above 45 °, it is necessary to use the lamp attachment included in the set, or a
separately sold lamp attachment (PC010685599). For cases with less than 45 °, please do not attach

the lamp attachment.

Lamp attachment replacement procedures

Insert the "a" section of the lamp attachment into the "A"

1

section of the lamp unit. Hang the lamp attachment into
the clasp-shaped part of the of the lamp unit

lamp attachment

"

b

"

lamp unit

"

a

"

"

a

Figure 1-1

"

Figure 1-2

"A"

Figure 2

CAUTION

In case the lamp attachment is bent in any other
direction than stated in the written instructions, or if it

is modied, or remodeled, the lamp attachment will be

damaged or break off. This may lead to failure of the
main unit of the projector.
Moreover, in case it is repeatedly installed and re-

"

a

"

Figure 3

Fit the "b" section of the lamp attachment (see Figure 1-2)

2

into the clasp-shaped part of the lamp unit by pressing the
former into the latter

moved, it may be possible that the "a” section of the
clasp section breaks off. In this case, please purchase
and use a new replacement lamp attachment.
As the folding section of the "b" section is fragile when
bending it in the direction of the arrow, please be
careful.

54

pushing into

Figure 4

Maintenance

ENGLISH

As shown in Figure 5, make sure that the lamp attachment

3

is coupled with the clasp of the lamp unit

"c"

Figure 5

Bend the "c" section of the lamp attachment (see Figure 5)

4

by pressing it in the direction of the lamp unit

bending by pressing

Figure 6

As shown in Figure 7, make sure that the lamp attachment

5

is coupled with the clasp of the lamp unit

Figure 7

55

4

Maintenance

Explanation of the installation/removal of
the lamp attachment

● When replacing the lamp, please do not forget to remove the lamp attachment.

Lamp attachment removal procedure

Bend the clasp coupling of the lamp attachment vertically

1

(see Figure 2)

● If you remove it without bending it vertically, it will be difcult to install the next time.

bending

Figure 1

Remove the clasp coupling of the lamp unit and the lamp

2

attachment in the direction of the arrow

(continued)

Figure 2

56

Figure3

Make sure that the clasp is removed from the

3

lamp attachment

Figure 4

Maintenance

ENGLISH

Remove the clasp coupling of lamp attachment on the

4

reverse side and the lamp unit

Figure 5

Attachment of the installation verication seal

After replacing the lamp, attach the "installation

1

verication seal" on the lamp cover

● Attach the installation verication seal at the bottom right of the lamp cover.

installation verication seal

● The installation verication seal states "DOWN45 ° ~ 90 °".

● When the lamp attachment is removed, peel off the attached verication seal and keep it for

further use.

57

4

Maintenance

Replacing the Lamp

The lamp is a consumable item. If the image is dark or the lamp is turned off, replace the lamp
unit.

● When the lamp replacement time approaches, a message is displayed on the screen and the condition

is indicated by the indicator. (Reference page: 14 to 15, 66)

CAUTION

●

Do not insert your hands into
the opening of the lamp!
This could cause obvious
deterioration of the
equipment’s function, wounds
and electric shocks.

●

Do not replace the lamp

immediately after the unit has
been used, and allow a cooling
period of 1 hour or more before
replacement. The temperature
of the lamp is still high and this
may cause a burn.

●

Do not apply shock to the

lamp unit. I
blowout.

●

Do not use ammable air duster

to clean the internal parts of the
unit. This may cause re.

Usable Lamp Life

●

When using the “Lamp Power”

set at “Normal", the lifetime of
the lamp will be approximately
3000 hours.
This is an average lifetime and
cannot be guaranteed.

●

The lamp life may not reach

3000 hours depending on the
operating conditions.

●

When the lamp has reached

the end of its usable life,
deterioration progresses
rapidly.

●

If the picture becomes dark,

the tint becomes strange, or
the image ickers, promptly the
lamp unit for a new one.

t may cause lamp

MEMO

Lamp replacement procedure

Remove the power plug from the

1

outlet

Remove the lamp cover

2

●

Remove the screws with a

Loosen the screws on the lamp unit

3

●

Loosen the screws with a screwdriver.

Pull out the lamp unit

4

●

Grasp the handle and pull out the lamp unit.

screwdriver.

Purchasing the Lamp Unit

Please consult your authorized
dealer.

Lamp Unit

■

Part No.: PK-L2210U

58

Handle

Maintenance

ENGLISH

Install the new lamp unit

5

Handle

Tighten the screws of the new lamp

6

unit

●

Tighten the screws with a screwdriver.

CAUTION

●

Use only genuine replacement

parts for the lamp unit. Also,
never attempt to reuse an old
lamp unit. This may cause a
malfunction.

●

Do not touch the surface of a

new lamp. This may shorten
the lamp life and cause lamp
blowout.

MEMO

After Replacing the Lamp

●

Do not place the removed
lamp unit at locations that is
reachable by children or near
combustible items

●

Dispose used lamp units in

the same way as uorescent

lamps. Follow your local
community rules for disposal.

.

Attach the lamp cover

7

●

Insert the top part (with 2 claws) of the lamp cover into

the unit.

●

Fasten the screws with a screwdriver.

59

4

Exit

MENU

BACK

Back

Select

Operate

Trigger
Off Timer

Communication Terminal

Network

High Altitude Mode

LAN

Off

Off

Off

Function

Lamp Reset

Reset Lamp Time?

YES

NO

Maintenance

Replacing the Lamp (Continued)

Resetting lamp Time

STAND BY

HDMI 1

ASPECT

LENS.

CONTROL

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

COMPONENT

HDMI 2

ANAMO

C.M.D

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

LENS.

TEMP

AP

ON

COMP.

PC

AUTO
ALIGNMENT

USER3

LIGHT

BACK

3D

PIC.

ADJ.

After replacing a new lamp unit, please reset the lamp time.
Description of two methods.

Reset the lamp time from the menu screen.

Display the setting menu

1

Picture Adjust

Picture Mode

Color Temp.

MENU

Select“Function” “Lamp Reset”

2

Gamma
Contrast
Brightness
Color
Tint
Advanced

Exit

MENU

Select

① Select

0
0

0

0

Operate

Natural

6500K

Normal

Reset

Back

BACK

60

② Confirm

Re-conrm

3

● Select

“

Yes” and the lamp time is set to zero. Moreover,

one returns to the previous menu.

Maintenance

ENGLISH

Reset the lamp time by remote control.

Insert the power plug to the power

1

outlet

Red Lights

Must operate with the remote

2

control in the standby mode (the
projector is powered, but is not
turned on).

●

Press in the order as shown.

●

Press each button within 2-second intervals and press

the last button for 2 seconds or more.

BACK

OK

HIDE

Press for 2 seconds or more

STAND BY

HDMI 1

ASPECT

LENS.

CONTROL

HIDE

MENU

NATURAL

USER1

USER4

GAMMA

COMPONENT

HDMI 2

ANAMO

C.M.D

PICTURE MODE

DYNAMIC

USER2

USER5 USER6

COLOR

LENS.

TEMP

AP

ON

COMP.

PC

AUTO
ALIGNMENT

LIGHT

BACK

USER3

3D

PIC.
ADJ.

●

[STANDBY/ON] indicator and [LAMP] indicator blink
alternately for 3 seconds. After that, the unit switches to
standby mode.

STANDBY/ON

LAMP

WARNING

CAUTION

●

Reset the lamp time only when
you have replaced the lamp.

●

Never reset the service time when

the lamp is still in use. Otherwise,
the approximate standard for
gauging replacement time may be
inaccurate and lamp blowout may
occur.

61

4

Maintenance

Method for cleaning and
replacing lters

Clean the filter regularly or air intake efficiency may deteriorate and malfunction may
occur.

Remove the inner lter.

1

Clean the lter.

2

Lift up while pushing the claw

●

Pull the power plug from the

power outlet.

●

Please turn this unit and if

you put in on a bed or a table,
rst place something soft
like a piece of cloth below.
Then you can put it on top of
it. Otherwise, it may cause
scratches on this unit.

CAUTION

●

Wash the lter with water and dry it in a shaded area.

●

In extremely soiled cases, using a neutral detergent

is recommended. Put on rubber gloves when using a
neutral detergent.

●

After washing the lter with water, make sure that it is

completely dry before reinstalling. Otherwise electric
shock or malfunctions may occur.

●

Do not clean the lter with a vacuum cleaner or air

duster. The lter is soft and may be damaged.

Reinstall the inner lter.

3

Check that the left and
right claws are locked onto
the unit

MEMO

If the lter is damaged or
too dirty to be cleaned.

●

Replace with a new lter. A

dirty lter will dirty the internal
parts of the unit and cause
shadows on the video image.

●

To purchase a new lter or

when it is dirty in the internal
parts, consult your authorized
dealer.

Inner Filter

■

Part No.:

●

Replacement Filter:

PC010661199

62

Maintenance

MEMO

ENGLISH

63

5

Others

Troubleshooting

Before sending the unit to your authorized dealer for repair, please check
the following points.

The following situations are not malfunctions.

■

You do not need to worry about the following situations if there is no abnormality on the

screen.

●

Part of the top surface or front of the unit is hot.

●

A creaking sound is heard from the unit.

●

An operating sound is heard from the inside of the unit.

●

Color smear occurs on some screens.

■

Perform the following operations when the unit is unable to operate normally due to external

static or noise.

① When the unit is in standby mode, please pull out the power plug, then insert again.
② Press the power button on the unit to turn on the power again.

■

A sound may be heard when the lamp is off but there is no danger.

■

D-ILA device is manufactured using high-precision technology but there may be some missing

pixels or pixels that remain permanently lit up.

Power is not supplied

Is the power cord disconnected? Insert the power cord (plug) rmly.

Is the lamp cover properly shut?

Is the lamp in Cool Down
mode?

Remove the power plug when the unit is
in standby mode and close the lamp cover
properly. After that, insert the plug again.

After the Cool Down mode is complete, turn
on the power again.

Reference page:
29

Reference page:
59

Reference page:
31

Video image does not appear

Is the correct external input
selected?

Is the AV device properly
connected?

Is the power of the AV device
turned on?

Are the correct signals being
output from the AV device?

Is the setting of the input
terminal correct?

Is the video image temporarily
hidden?

Select the correct external input.

Connect the AV device properly.

Turn on the power of the AV device and play
the video.

Set the AV device prope

Set “COMP.” and “HDMI” in the setting menu
according to the input signal.

Press the [HIDE] button to display the video
image again.

rly.

Remote control does not work

Are batteries installed
correctly?

Are batteries exhausted? Replace with new batteries.

Is there an obstructive object
between the remote control
and remote sensor?

Is the remote control held too
far away from the unit?

Match the polarities (
inserting the batteries.

Remove any obstructive objects.

Hold the remote control closer to the sensor
when using.

or ) correctly when

Reference page:
30

Reference page:
23 to 28

Reference page:
30

Reference page:
23 to 28

Reference page:
47 to 48

Reference page:
34

Reference page:
17

Reference page:
17

Reference page:
21

Reference page:
21

64

The picture cannot be projected

Will the picture icker and

become invisible with HDMI
input?

Please use a short HDMI cable.

Color does not appear or looks strange

Is the image correctly adjusted?

VS21

Video image is fuzzy

Is the focus correctly adjusted? Adjust the focus.

Is the unit placed too near or too
far away from the screen?

RS50RS50

Adjust “Color” and “Tint” in the setting menu.

Set the unit at a correct distance from the
screen.

Video images are missing

Has setting been performed for
screen mask?

Is the display out of position?

Set “Mask” in the setting menu to “Off”.

Alter the “Picture Position” value in the setting
menu to ensure that images are not missing.

Projected image is dark

Check the lamp time on the information menu.

Is the lamp near exhaustion?

Prepare a new lamp unit or replace as soon
as possible when the lamp is near exhaustion.

ENGLISH

Reference page:
24

Reference page:
43

Reference page:
30

Reference page:
19, 21

Reference page:
33, 47

Reference page:
46

Reference page:
58 to 61

The unit works when power is turned on but stops abruptly after a few minutes

Are the air inlets and exhaust
vent blocked?

Is the lter dirty? Clean the lter.

Remove the power plug when the unit is in
standby mode and remove any blocking object.
After that, insert the plug again.

Reference page:
3, 12

Reference page:
62

Power is cut off suddenly

Has setting been performed for
off timer?

Set “Off Timer” in the setting menu to “Off”.

Reference page:
50 to 51

Others

65

5

COMP.

Others

In case this message is
displayed

Message Cause (Details)

COMP㧚

䇭NO Input

Lamp replacement

Back

BACK

No device is connected to the input terminal.
The input terminal is connected but there is no signal.

Input the video signals.

A video signal that cannot be used in this unit has been input.

Input video signals that can be used.

* The names of input terminals such as COMP. will be displayed in yellow

This message is displayed when the accumulated lamp time has
exceeded 2900 hours.
To clear the message, press the [Back] button.

Get ready a new lamp unit and replace as soon as possible. Reset

the lamp time after replacing the lamp. (Reference page: 58 to 61)

66

ENGLISH

RS-232C Interface

It is possible to control this machine, if it is connected by an RS-232C cross cable (D-Sub9 pin) to a
PC. Otherwise, this machine can be controlled via a computer network by connecting it with a LAN
cable and sending of control commands. Please use it after you have understood this by reading
professional books, or by discussing it with a system administrator.

RS-232C Specications



This unit



Pin No. Signal Function Signal Direction

2 RxD

Receive data PC→This unit



Mode

Character Length

Parity

Start Bit

Stop Bit

Data rate

Data format



●

3 TxD

5 GND

1,4,6 - 9 N/C - -

PC refers to the controller such as a personal computer.

Non-synchronous

8 bit

None

1

1

19200 bps

Binary

Transmit data This unit→PC

Signal ground

Start Bit

-

D6 D7D4 D5D2 D3D0 D1

Stop Bit

TCP/IP-connection

Before you can co
necessary for a connection authentication to send from the projector "PJ_OK" and - within 5 seconds after
sending a "PJREQ" – to receive "PJACK". Please perform this operation – after conrming the operating
status of the projector - again after establishment of a TCP connection, if you cannot send within 5 seconds
"PJ_NG" or could not receive "PJNAK".

ntrol it via LAN, you have to establish a TCP-connection via a "3-way-handshake". It is

Within 5 seconds

Projector

ＰＪ_ＯＫ

ＰＪＡＣＫ

TCP-layer connection establishment
TCP port number 20554
Three-way handshake

Control PC

Connection authentication procedure

Others

Projector Control

ＰＪＲＥＱ

67

5

Others

RS-232C Interface (Continued)

Command Format

The command between this unit and the computer consists of “Header”, “Unit ID”, “Command”, “Data”
and “End”.

●

Header (1 byte), Unit ID (2 bytes), Command (2 bytes), Data (n bytes), End (1 byte)

Header

■

This binary code indicates the start of communication.

Binary code

21 Operating command PC → This unit

3F Response command PC → This unit

40 Reference command This unit → PC

06 ACK

Unit ID

■

This code species the unit. The binary code is xed at “8901”.

Command and data

■

Operating command and data (Binary code)

Command Type Description

0000

5057

Connection check

Power supply

Type Description

This unit → PC
(When the command is accepted without error, it
returns to PC)

Check whether communication is available between this
unit and the PC during standby.

During standby
31: Turn on the power.
During power on
30: Turn off the power. (Standby mode)

68

4950

5243

Input

Remote Control

During power on
32: COMP.
33: PC
36: HDMI 1
37: HDMI 2

Sends the same code as the supplied remote control.

●

“Remote control code” (Reference page:69)

Reference command and data (Binary code)

Command Type Data description

During standby or power on
30: Standby mode

5057 Power supply

4950 Input

■

End

31: Power-on mode
32: During Cool Down mode
34: Warning mode

During power on
32: COMP.
32: PC
36: HDMI 1
37: HDMI 2

ENGLISH

This code indicates the end of communication. The binary code is xed at

■

Remote control code

●

Binary code is sent during communication.

Remote control button

name

BACK 37 33 30 33 USER 1 37 33 36 43

ON 37 33 30 35 USER 2 37 33 36 44

STAND BY 37 33 30 36 USER 3 37 33 36 45

AUTO ALIGNMENT 37 33 31 33 HDMI 1 37 33 37 30

HIDE 37 33 31 44 HDMI 2 37 33 37 31

LENS.AP. 37 33 32 30 PIC.ADJ. 37 33 37 32

MENU 37 33 32 45 GAMMA 37 33 37 35

OK 37 33 32 46 C.TEMP 37 33 37 36

LENS CONTROL

VS21

RS50RS50

Binary code

37 33 30 31 　 NATURAL 37 33 36 41

37 33 30 32 DYNAMIC 37 33 36 42

37 33 33 30 ASPECT 37 33 37 37

37 33 33 34 C.M.D 37 33 38 41

37 33 33 36 USER 4 37 33 43 41

Remote control button

name

“0A”.

Binary code

PC 37 33 34 36 USER 5 37 33 43 42

COMP. 37 33 34 44 USER 6 37 33 43 43

Others

69

5

Others

RS-232C Interface (Continued)

RS-232C Communication Examples

This section shows the communication examples of RS-232C.

Operating command

■

Type Command Description

Connection

check

Power (On)

Power (Off)

Input

(COMP.)

Remote

Control

(MENU)

■

Reference command

PC→This unit: 21 89 01 00 00 0A
This unit→PC:

PC→This unit: 21 89 01 50 57 31 0A
This unit→PC:

PC→This unit: 21 89 01 50 57 30 0A
This unit→PC: 06 89 01 50 57 0A

PC→This unit: 21 89 01 49 50 32 0A
This unit→PC: 06 89 01 49 50 0A

PC→This unit: 21 89 01 52 43 37 33 32 45 0A
This unit→PC:

06 89 01 00 00 0A

06 89 01 50 57 0A

06 89 01 52 43 0A

Connection check.

When power is turned on from
standby mode.

When power is turned off
(standby mode) from power-on
mode.

When video input is set to
component.

When the same operation as
pressing the [MENU] button
on the remote control is made

Type Command Description

Power (On)

Input

(HDMI 1)

PC→This unit: 3F 89 01 50 57 0A
This unit→PC: 06 89 01 50 57 0A
This unit→PC: 40 89 01 50 57 31 0A

PC→This unit: 3F 89 01 49 50 0A
This unit→PC: 06 89 01 49 50 0A
This unit→PC: 40 89 01 49 50 36 0A

When information of power­on mode is acquired.

When information of HDMI 1
input is acquired.

70

Copyright and Caution

About Trademarks and Copyright

●

HDMI, HDMI logo and high denition multimedia interface

are trademarks or registered trademarks of HDMI Licensing
LCC.

Caution

ENGLISH

D-ILA Device Characteristics

Do not project still pictures or pictures that have still
segments for a long period of time. The still parts of
the picture may remain on the screen.
Take special notice of images on the screens of
video games and computer programs. There is no
problem when playing normal video images such as
movies.

When Unit is Unused for a Long Time

Prolonged disuse of the unit may effect an error on the
functions. Turn on the power occasionally and operate
the unit.

Usage Environment

●

Avoid direct exposure of screen to direct sunlight
and illumination. Block light using a curtain.
Images can be well projected by darkening the
brightness of the room.

●

Do not use this unit in rooms with cigarette

smoke or oily smoke. This may cause the unit
to malfunction.

Parts Replacement

Maintenance Procedures

Dirt on the cabinet

●

Gently clean dirt on the cabinet with a soft cloth.
In the case of heavy soiling, soak a cloth in water,
wring dry and wipe, followed by wiping again with
a dry cloth. Pay attention to the following as the
cabinet may deteriorate in condition or paint may
come off.

● Do not wipe with thinner or benzene.

● Do not spray with volatile chemicals like
insecticide.

● Do not allow prolonged contact with rubber or
plastic products.

Dirt in the air inlets

●

Use a vacuum cleaner to suck up the dirt.
Otherwise, use a cloth to wipe off the dirt. If dirt
is allowed to accumulate in the air inlets, the
internal temperature cannot be adjusted and this
may cause a malfunction.

VS21

Dirt on the lens

●

Clean the dirt using commercial blowers or

lens cleaning papers for cleaning glasses and

cameras. Do not use uid-type cleaning agents.

This may lead to peeling of the surface coating

lm.

( Reference page: 12)

RS50RS50

This unit contains parts (optical part, cooling
fan, etc.) that require replacement to maintain
its functioning. The estimated time for parts
replacement varies greatly depending on the
usage and environment. Please consult your
authorized dealer for replacement.

Others

71

5

Others

Specications

Product Name

Model Name

Display Panel/Size

VS21

Input

RS50RS50

VS21

RS50RS50

Projection Lens

Light-source Lamp

Screen Size
Projection Distance Approx.

Analog Video Input

Format

Digital Video Input

Format

Resolution 1920 dots x 1080 dots
Input terminal

Video Input

HDMI

Projector

D-ILA

DLA-VS2100-B, DLA-VS2100NL-B *1

device

D-ILA

" (1920pixels x 1080pixels) x 3 (Total no. of pixels: Approx. 6.22million)

0.7

2.0 x power zoom lens (1.4:1 to 2.8:1)
(Zoom/Focus: Power)

220 W Ultra-high pressure mercury lamp [Part No. :
Average lifespan:

Approx. 60" to 200" (Aspect ratio: 16:9)

480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50
1080i/60

480i, 480p, 576i, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50
1080i/60 Hz, 1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz
PC compatible signals

1 system, RCA
Y:1.0Vp-p, 75Ω
Pb/C

b, Pr/Cr:0.7Vp-p, 75Ω

Also supports R / G / B Sync on G

*
2 system, HDMI 19

Compatible with the HDMIv1.4a standard

* 2 *3

3000

1.8m to 12m

Hz

pin jack

pin

hours (normal mode)

(Reference page: P22)

3

×

2(HDCP

×

compliant

* 5

PK-L2210U]

Hz

Hz

) * 4

Input

PC

Output terminal

Trigger terminal

Control terminal

RS-232C terminal 1 system , D-sub 9-pin (male) x1 (External control)

Remote terminal 1 system, stereo mini jack x1 (Remote Control)

LAN terminal 1 system, RJ-45 plug x1

Power Requirements

Power Consumption

Operation Environment

Installation Height
Dimensions

(Width x Height x Depth)

Mass

Accessories

1 system, D-Sub 15 pin VGA

1 system, Φ3.5mmDC Power Jack (
DC OUT 12V, 0.1A

AC 110V-240V 50/60Hz

350W(3.4A) (
Temperature:

Humidity: 20% to 80%(No condensation)
(Storage Temperature:

Below

About 455mmx179mmx472mm

(Excluding foot, lens, and other protruding parts)

15.1kg

(Please see page 11)

Standby mode:

5ºC to 35ºC

5000ft (1524 m)

0.9W)

-10℃ to 60℃ )

)

72

ENGLISH

Regarding -W the color of the main body is some kind of white color. Regarding –B, the color of the

* 1

main body is some kind of black.

D-ILA is the abbreviation for Direct drive Image Light Amplier.

* 2
* 3 D-ILA devices are manufactured using extremely high-precision technology. Pixel effectiveness is

99.99%. Only 0.01% or less of the pixels are either missing or would remain permanently lit up.
* 4 HDCP is the abbreviation for High-bandwidth Digital Cont
The image of HDMI input terminal may not be displayed due to HDCP specication change.
* 5 Ethermet is not supported.

●

Design and specications are subject to change without prior notice.

●

Please note that some of the pictures and illustrations may have been abridged, enlarged or

contextualized in order to aid comprehension. Images may differ from the actual product.

ent Protection system.

Others

73

5

Dimensions

Others

(Unit: mm)

■

Top Surface

Front

Lens center

■

Bottom Surface

472

5

455

Lens

VS21

RS50RS50

227.5

178.5

103.5

Φ60

24

290

91

59

■■



Back Surface

110

32

Lamp cover

337

Lens

110

VS21

RS50RS50

92

74

Index

ENGLISH

HDMI

Shorthand for "High-Denition Multimedia
Interface"

Specications ......................................Page 72

Connection method ............................ Page 24

[2-1] HDMI .......................................... Page 47

(Note on length) ................................. Page 24

Color

Color temp. of [1] Picture Adjust......... Page 43

Color of [1] Picture Adjust .................. Page 43

Tint o

f [1] Picture Adjust .................... Page 43

[1-1] Color temp. ............................... Page 44

[1-2-2] Color Management ................ Page 46

Screen Size

VS21

Distance Chart

RS50RS50

............................ Page 21

Aspect (Video) and aspect

PC of [2] Input Signal ......................... Page 46

VS21

RS50RS50

Zoom of [3-1] Lens Control

......... Page 49

Mask

Mask of [2] Input Signal ..................... Page 47

Screen Menu

Table Menu Structure ......................... Page 35

[1] Picture Adjust .......................... Page 35, 38

[2] Input Signal ............................. Page 35, 39

[3] Installation ............................... Page 36, 40

[4] Display Setup ............................... Page 36

[5] Function ...................

.............. Page 37, 40

[6] Information .................................... Page 37

Operating procedure ......................... Page 42

Batteries

Types .................................................Page 11

How to insert batteries ...................... Page 17

Gamma
