JVC CA-FSH30 User Manual
COMPACT COMPONENT SYSEM
FS-H35— Consists of CA-FSH35 and SP-UXH35
FS-H30— Consists of CA-FSH30 and SP-UXH30
COMPACT COMPONENT SYSTEM
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GVT0101-001B
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION— (standby/on) button!
Disconnect the mains plug to shut the power off completely
(all lamps and indications go off). The (standby/on)
button in any position does not disconnect the mains line.
• When the unit is on standby, the STANDBY lamp lights
red.
• When the unit is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
For U.S.A.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
ATTENTION—Touche (attente/sous tension)
Déconnectez la fiche secteur pour mettre l’appareil
complètement hors tension (tous les témoins et toutes les
indications s’éteignent). La touche (attente/sous
tension) dans n’importe quelle position ne déconnecte pas
l’appareil du secteur.
• Quand l’appareil est en mode d’attente, le témoin
STANDBY est allumé en rouge.
• Quand l’appareil est sous tension, le témoin STANDBY
s’éteint.
L’alimentation ne peut pas être commandée à distance.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir
le coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
G-1
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to Section 820-40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as
close to the point of cable entry as practical.
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS
ELECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED
THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT
IN THE INTERFERENCE-CAUSING EQUIPMENT
STANDARD ENTITLED “DIGITAL APPARATUS,”
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES
LIMITES DE BRUITS RADIOELECTRIQUES
APPLICABLES AUX APPAREILS NUMERIQUES DE
CLASSE B PRESCRITES DANS LA NORME SUR
LE MATERIEL BROUILLEUR: “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
G-2
Introduction
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly to obtain
the best possible performance from your unit, and retain this manual for future
reference.
About This Manual
This manual is organized as follows:
• The manual mainly explains operations using the
buttons on the remote control.
You can use the buttons both on the remote
control and on the main unit for the same
operations if they have the same or similar names
(or marks), unless mentioned otherwise.
• Basic and common information that is the same for
many functions is grouped in one place, and is not
repeated for each procedure. For instance, we do not
repeat the information about turning on/off the unit,
setting the volume, changing the sound effects, and
others, which are explained in the section “Common
Operations” on pages 10 and 11.
• The following symbols are used in this manual:
Gives you warning and caution to
prevent damage or risk of fire/electric
shock.
Furthermore, it gives you information
about what is not good for obtaining
the best possible performance from the
unit.
Gives you information and hints you
should know.
Power sources
• When unplugging the unit from the wall outlet,
always pull on the plug, not the AC power cord.
DO NOT handle the AC power cord with
wet hands.
Moisture condensation
Moisture may condense on the lens inside the unit in
the following cases:
• After starting heating in the room
• In a damp room
• If the unit is brought directly from a cold to a warm
place
Should condensation occur, the unit may malfunction.
In this case, leave the unit turned on for a few hours
until the moisture evaporates, unplug the AC power
cord, then plug it in again.
Others
• Should any metallic object or liquid fall into the unit,
unplug the power cord and consult your dealer
before operating any further.
• If you are not going to operate the unit for an
extended period of time, unplug the power cord.
DO NOT disassemble the unit since there
are no user serviceable parts inside.
Precautions
Installation
• Install in a place which is level, dry and neither too
hot nor too cold—between 5˚C (41˚F) and 35˚C
(95˚F).
• Install the unit in a location with adequate
ventilation to prevent internal heat buildup in the
unit.
• Leave sufficient distance between the unit and the
TV.
• Keep the speakers away from the TV to avoid
interference with TV.
DO NOT install the unit in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
1
If anything goes wrong, unplug the power cord and
consult your dealer.
Contents
Location of the Buttons ............................................... 3
Main Unit .......................................................................... 3
Remote Control ................................................................. 5
Getting Started............................................................. 6
Supplied Accessories ......................................................... 6
Connecting Antennas ........................................................ 6
Connecting Speakers ......................................................... 7
Connecting Other Equipment ............................................ 8
Putting the Batteries into the Remote Control .................. 9
Common Operations ................................................. 10
Setting the Clock ............................................................. 10
Turning On the Power ..................................................... 11
Adjusting the Volume ...................................................... 11
Adjusting the Tone (Bass/Treble).................................... 11
Reinforcing the Bass Sound ............................................ 11
Listening to FM and AM Broadcasts ....................... 12
Tuning in to a Station ...................................................... 12
Presetting Stations ........................................................... 12
Tuning in to a Preset Station ........................................... 13
Playing Back Discs ..................................................... 14
Playing Back the Entire Disc—Normal Play .................. 14
Basic Disc Operations ..................................................... 15
Programming the Playing Order of the Tracks
—Program Play......................................................... 15
Playing at Random—Random Play ................................ 16
Repeating Tracks—Repeat Play...................................... 16
Playing Back Tapes .................................................... 17
Playing Back a Tape ........................................................ 17
Recording ................................................................... 18
Recording on a Tape ........................................................ 18
Disc Direct Recording .....................................................19
One Track Recording ...................................................... 19
Using the Timers ........................................................ 20
Using Daily Timer and Recording Timer ........................ 20
Using Snooze Timer ........................................................ 22
Using Sleep Timer........................................................... 22
Maintenance ...............................................................23
Troubleshooting ......................................................... 25
Specifications.............................................................. 26
2
Location of the Buttons
Become familiar with the buttons on your unit.
Main Unit
Top view
Front view
1
2
3
4
5
6
PHONES
ONE TOUCH
COMPACT
DIGITAL AUDIO
7
8
TIMER/SNOOZE
REC
AUX
MULTI CONTROL
4
7
BAND
TAPE CD
TUNER
¢
VOLUME
AHB PRO
OPEN
9
p
q
w
STANDBY
COMPACT COMPONENT SYSTEM
r
e
t
3
SNOOZE
r
twe
Display window
Continued
1234
5
REC ON
REC
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
PROGRAM RANDOM ALL OVER
See the pages in parentheses for details.
Main unit
1 PHONES jack (11)
2 Disc cover
3 TIMER/SNOOZE button (10, 20 – 22)
4 ONE TOUCH REC (recording) button (18, 19)
(standby/on) button (11, 21)
5
6 Source buttons
• AUX, @ # TAPE, BAND TUNER, and
#/8 CD
Pressing one of these buttons also turns on the
unit.
7 MULTI CONTROL buttons
• 4 (reverse skip), 7 (stop), and ¢ (forward
skip)
8 AHB (Active Hyper Bass) PRO button (11)
9 0 OPEN (disc cover open) button (14)
p VOLUME + / – buttons (11)
q Display window
w STANDBY lamp (11)
e Cassette holder
r Remote sensor
t ) (cassette holder open) button (17 – 19)
67
BASS
SLEEP SNOOZE
MONOCLOCKOFF
Display window
1 Tape operation indicators
• 2 3 (tape direction),
(reverse mode)
2
(timer) indicator
3 REC (recording timer) indicator
4 ON/OFF (timer on-time/off-time) indicators
5 CLOCK indicator
BASS
6
SLEEP
7
8
9 MONO and STEREO indicators
p Main display
• Shows the source name, frequency, etc.
q Track calender indicators
w PROGRAM indicator
e RANDOM indicator
r Repeat indicators
•
t OVER indicator
STEREO
indicator
indicator
indicator
and ALL
8
9
p
q
REC
(recording), and
4
Remote Control
1
4
1
2
3
4
5
6
7
7
10
BASS
CD TAPE
3
2
5
6
9
8
10
UP
DOWN
TUNER AUX
REV.MODE FM MODE
RANDOM
PRGM
STANDBY/ON
DISPLAY
CLOCK
/TIMER
SLEEP
TREBLE
CANCELSET
AUTO
PRESET
REPEAT
AHB PRO
8
9
p
q
w
e
r
t
y
u
i
See the pages in parentheses for details.
1 Number buttons
2 BASS button (11)
3 Multi control buttons
UP, 4 (reverse skip), 7 (stop), ¢
•
(forward skip), and
DOWN
4 SET button (13)
5 Source buttons
• 3/8 CD, 2 3 TAPE, TUNER, and AUX
Pressing one of these buttons also turns on the
unit.
6 REV.MODE (reverse mode) button (17 – 19)
7 PRGM (program) button (15)
8 STANDBY/ON
button (11, 21)
9 DISPLAY button (10)
p CLOCK/TIMER button (10, 20, 21)
q SLEEP button (22)
w TREBLE button (11)
e CANCEL button (16)
r AUTO PRESET button (12)
t FM MODE button (12)
y REPEAT button (16)
u RANDOM button (16)
i AHB (Active Hyper Bass) PRO button (11)
o VOLUME + / – button (11)
o
VOLUME
STANDBY
COMPACT COMPONENT SYSTEM
When using the remote control, point it at the
remote sensor on the front panel.
5
Getting Started
Continued
Supplied Accessories
Make sure that you have all the following items.
The number in parentheses indicates the quantity of
each piece supplied.
• AM loop antenna (1)
• FM antenna (1)
• AC power cord (1)
• Remote control (1)
• Batteries (2)
If anything is missing, consult your dealer
immediately.
Connecting Antennas
FM antenna
FM antenna (supplied)
To connect an outdoor FM antenna
Before connecting the antenna, disconnect the supplied
FM antenna.
Outdoor FM antenna
(not supplied)
Coaxial cable (not supplied)
A 75 Ω antenna with coaxial type connector
should be used.
1 Attach the FM antenna to the FM
COAXIAL 75 Ω terminal.
2 Extend the FM antenna.
3 Fasten it up in the position which gives
you the best reception, then fix it on the
wall, etc.
About the supplied FM antenna
The FM antenna supplied with this unit can be used as
temporary measure. If reception is poor, you can connect an
outdoor FM antenna.
6
AM antenna
Connecting Speakers
1
Vinyl-covered wire
(not supplied)
2
AM loop antenna
(supplied)
1 Connect the AM loop antenna to the
AM LOOP terminals as illustrated.
2 Turn the AM loop antenna until you
have the best reception.
To connect an outdoor AM antenna
When reception is poor, connect a single vinyl-covered
wire to the AM EXT terminal and extend it
horizontally. The AM loop antenna must remain
connected.
12
Speaker cord
Speaker cord
Right speaker Left speaker
1 Press and hold the clamp of the
speaker terminal on the rear of the
unit.
2 Insert the end of the speaker cord into
the terminal.
Match the polarity between the unit and the
speaker terminals: ª to ª and · to ·.
3 Release your finger from the clamp.
For better reception of both FM and AM
• Make sure the antenna conductors do not touch any other
terminals and connecting cords.
• Keep the antennas away from metallic parts of the unit,
connecting cords, and the power cord.
7
• DO NOT connect speakers while the
power is on.
• DO NOT connect more than one speaker
to each speaker teminal.
IMPORTANT: Use only speakers with the same
speaker impedance as shown on the speaker
terminals on the rear of the unit.
Loading...
