JVC AV-28BS88EN, AV-28BT80EN, AV-28BT80EP, AV-28BT8EEB, AV-28BT8EES Parts List

A

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

A

P

A

V-28BT8EPS / AV-28BT8EPB / AV-28BT80E

V-28BT8EES / AV-28BT8EEB/ AV-28BS88EN

PARTS LIST

USI NG PW BOARD & REMOT E CONTRO L U NIT

!

EXPLODED VIEW PARTS LIST

!

EXPLODED VIEW

!

PRI NT ED W IRING BOARD PARTS LIST

････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

"

MAIN PW BOARD ASS'Y

"

CRT SOCKET PW BOARD ASS’Y

"

FRONT CONTROL PW BOARD ASS’Y

"

FRONT AV & HEADPHONE PW BOARD ASS’Y

･･････････････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････

[ AV-28BT8EPS / AV-28BT8EPB / AV-28BT80EP ]

"

MAIN PW BOARD ASS'Y ･･････････････････････････････････････････････････････････････････････････ 31

"

CRT SOCKET PW BOARD ASS’Y

"

FRONT CONTROL PW BOARD ASS’Y･･････････････････････････････････････････････････････････････ 34

"

FRONT AV & H EADPHONE PW BOARD ASS’Y

･･････････････････････････････････････････････････････････････････

[ AV-28BT8EES / AV-28BT8EEB ]

"

MAIN PW BOARD ASS'Y

"

CRT SOCKET PW BOARD ASS’Y ･･････････････････････････････････････････････････････････････････ 38

"

FRONT CONTROL PW BOARD ASS’Y

"

FRONT AV & H EADPHONE PW BOARD ASS’Y ･･････････････････････････････････････････････････････ 38

･･････････････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････

[ AV-28BS8EN ]

"

MAIN PW BOARD ASS'Y

"

CRT SOCKET PW BOARD ASS’Y

"

FRONT CONTROL PW BOARD ASS’Y

"

FRONT AV & H EADPHONE PW BOARD ASS’Y

･･････････････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････

･･････････････････････････････････････････････････････

23 24 25

26

30

34

35

38

39

42

!

PACKING / PACKING PARTS LIST

･･････････････････････････････････････････････････････････････････

USING PW BOARD & REMOTE CONTROL UNIT

Model

PW B AS S' Y

MAI N PWB VE -2 01015 77 VE -2 01015 76 VE -2 01016 22 VE -2 01015 78

CRT SOCKET PWB

FRONT CO NTROL PWB

FRONT AV & HEADPHONE PWB

REMOTE CONTROL UNI T

AV - 28 BT8 EN S

AV - 28 BT8 EN B

AV - 28 BT8 0EN

VE -2 00946 70 ←← ←

VE -2 00824 81 ←← ←

VE -2 00836 46 ←← ←

VE -3 00177 63

(RM-C1100)

AV- 28 BT8 EPS

AV- 28 BT8 EPB

AV - 28 BT8 0EP

No. 52057

AV- 28 BT8 EES

AV- 28 BT8 EEB

←← ←

AV-28 BS 88EN

43

23

A

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

A

V-28BT8EPS / AV-28BT8EPB / AV-28BT 80EP V-28BT8EES / AV-28BT8EEB/ AV-28BS88EN

EXPLODED VIEW PARTS LIST

!

Ref.No. Part No. Part Name Description

!

V01 VE-30002751 PICTURE TUBE (ITC) L01 VE-30002138 DEG COIL

!

TR601 VE-30017522 FBT Within MAIN PWB

! !

1 VE-20083491 BUTTON ON/OFF (SILVER MODEL)

!

1 VE-20069016 BUTTON ON/OFF (BLACK MODEL) 2 VE-35004544 SPRING 3 VE-20069218 LENS (except AV-28BT80EN,AV-28BT80EP,AV-28BS88EN)

!

3 VE-20096162 LENS SILVER (AV-28BT80EN,AV-28BT80EP,AV-28BS88EN)

! !

4 VE-20078776 LENS LED

!

5 VE-20004339 LENS PRE-AMP

!

6 VE-20101840 FRONT AV DOOR (SILVER MODEL) 6 VE-20101841 FRONT AV DOOR (BLACK MODEL)

!

7 VE-20003605 PIN (FRONT AV DOOR) (X2) 8 VE-40000026 EJECTOR

!

9 VE-20082289 FRONT CABINET (SILVER MODEL)

!

9 VE-20081489 FRONT CABINET (BLACK MODEL) 10 VE-30001946 SPEAKER 8R 15W (X2) 11 VE-20083502 BUTTON FUNCTION (SILVER MODEL)

!

11 VE-20069014 BUTTON FUNCTION (BLACK MODEL)

! !

12 VE-20081578 BASE 13 VE-20094516 SHASSIS FRAME 14 VE-30015614 PFC TRF 15 VE-35000217 SCREW (3.5X9.5) (X2) 16 VE-20084616 BACK COVER (SILVER MODEL)

! !

16 VE-20069018 BACK COVER (BLACK MODEL) 17 VE-35004572 SCREW (4X20) (X8)

!

18 VE-20067720 AV TERMINAL BOARD 19 VE-35000211 SCREW (2.9X9.5) (X4) 20 VE-20102137 RATING LABEL (AV-28BT8ENS)

! !

20 VE-20102147 RATING LABEL (AV-28BT8ENB)

!

20 VE-20101937 RATING LABEL (AV-28BT8EPS)

!

20 VE-20101939 RATING LABEL (AV-28BT8EPB) 20 VE-20101919 RATING LABEL (AV-28BT8EES)

!

20 VE-20101920 RATING LABEL (AV-28BT8EES POLAND)

! !

20 VE-20101915 RATING LABEL (AV-28BT8EEB)

!

20 VE-20101913 RATING LABEL (AV-28BT8EEB POLAND)

!

20 VE-20102144 RATING LABEL (AV-28BT80EN) 20 VE-20101934 RATING LABEL (AV-28BT80EP)

!

20 VE-20102141 RATING LABEL (AV-28BS88EN)

!

21 VE-40009154 LOGO JVC (SILVER MODEL) 21 VE-40009152 LOGO JVC (BLACK MODEL)

24

No. 52057

A

P

A

EXPLODED VIEW

!

20

17

19

!

18

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

V-28BT8EPS / AV-28BT8EPB / AV-28BT 80E

V-28BT8EES / AV-28BT8EEB/ AV-28BS88EN

!

16

!

TR 601

MAIN PWB

!

13

!

12

15

!

V01

14

!

L01

FRON T CON TRO L PWB

FRON T AV &

!

11

10

HEADPHONE PWB

8

7

!

6

10

21

!

9

!

5

4

!

3

!

2

1

No. 52057

25

A

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

PRINTED WIRING BOARD PARTS LIST

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

MAIN P.W. BOARD ASS’Y (VE-20101577)

Symbol No. Part No. Part Name Description

!

RESISTOR

R102 VE-30012657 SMD RES. 1/16W 1K J R103 VE-30012657 SMD RES. 1/16W 1K J

R106 VE-30012713 SMD RES. 1/16W 75R J R107 VE-30012649 SMD RES. 1/16W 150R J R109 VE-30012713 SMD RES. 1/16W 75R J R110 VE-30012713 SMD RES. 1/16W 75R J R111 VE-30012649 SMD RES. 1/16W 150R J

R113 VE-30012713 SMD RES. 1/16W 75R J R114 VE-30012713 SMD RES. 1/16W 75R J R115 VE-30012713 SMD RES. 1/16W 75R J R117 VE-30000792 CF RES. 1/4W 75R J R118 VE-30012713 SMD RES. 1/16W 75R J R121 VE-30012649 SMD RES. 1/16W 150R J

R122 VE-30000792 CF RES. 1/4W 75R J R123 VE-30000792 CF RES. 1/4W 75R J R124 VE-30012649 SMD RES. 1/16W 150R J R126 VE-30012657 SMD RES. 1/16W 1K J R129 VE-30012713 SMD RES. 1/16W 75R J

R135 VE-30012657 SMD RES. 1/16W 1K J R137 VE-30000466 CF RES. 1/4W 1K J R138 VE-30012657 SMD RES. 1/16W 1K J R139 VE-30012713 SMD RES. 1/16W 75R J R141 VE-30012657 SMD RES. 1/16W 1K J

R145 VE-30012713 SMD RES. 1/16W 75R J R149 VE-30012703 SMD RES. 1/16W 56K J R151 VE-30012696 SMD RES. 1/16W 47K J R152 VE-30000752 CF RES. 1/4W 56K J R153 VE-30012657 SMD RES. 1/16W 1K J

R154 VE-30000723 CF RES. 1/4W 47K J R155 VE-30012649 SMD RES. 1/16W 150R J R169 VE-30012703 SMD RES. 1/16W 56K J R171 VE-30012713 SMD RES. 1/16W 75R J R172 VE-30012692 SMD RES. 1/16W 4.7K J

R174 VE-30012713 SMD RES. 1/16W 75R J R175 VE-30012713 SMD RES. 1/16W 75R J R176 VE-30012703 SMD RES. 1/16W 56K J R201 VE-30012674 SMD RES. 1/16W 27K J R202 VE-30012692 SMD RES. 1/16W 4.7K J R204 VE-30000459 CF RES. 1/4W 100R J

R206 VE-30000459 CF RES. 1/4W 100R J R319 VE-30014076 SMD RES. 1/16W 4.7R J R320 VE-30014076 SMD RES. 1/16W 4.7R J R324 VE-30012667 SMD RES. 1/16W 220K J R328 VE-30012649 SMD RES. 1/16W 150R J

R329 VE-30012692 SMD RES. 1/16W 4.7K J R332 VE-30012641 SMD RES. 1/16W 10K J R333 VE-30012702 SMD RES. 1/16W 560R J R338 VE-30012641 SMD RES. 1/16W 10K J R340 VE-30012644 SMD RES. 1/16W 12K J

R341 VE-30012702 SMD RES. 1/16W 560R J R343 VE-30012659 SMD RES. 1/16W 2.2K J R370 VE-30012669 SMD RES. 1/16W 22K J R371 VE-30012669 SMD RES. 1/16W 22K J R391 VE-30012696 SMD RES. 1/16W 47K J

R417 VE-30012510 SMD RES. 1/16W 100R J R418 VE-30012510 SMD RES. 1/16W 100R J R419 VE-30012649 SMD RES. 1/16W 150R J R420 VE-30000466 CF RES. 1/4W 1K J R421 VE-30012650 SMD RES. 1/16W 15K J R422 VE-30012659 SMD RES. 1/16W 2.2K J

R423 VE-30012712 SMD RES. 1/16W 8.2K J R425 VE-30012510 SMD RES. 1/16W 100R J R426 VE-30012659 SMD RES. 1/16W 2.2K J R427 VE-30012674 SMD RES. 1/16W 27K J R428 VE-30012510 SMD RES. 1/16W 100R J

R430 VE-30012702 SMD RES. 1/16W 560R J R431 VE-30012674 SMD RES. 1/16W 27K J R432 VE-30012707 SMD RES. 1/16W 680R J R433 VE-30012683 SMD RES. 1/16W 330K J R437 VE-30000466 CF RES. 1/4W 1K J

R438 VE-30000466 CF RES. 1/4W 1K J R439 VE-30012657 SMD RES. 1/16W 1K J R440 VE-30012714 SMD RES. 1/16W 820R J R441 VE-30012674 SMD RES. 1/16W 27K J R442 VE-30000466 CF RES. 1/4W 1K J

R446 VE-30012714 SMD RES. 1/16W 820R J R447 VE-30012714 SMD RES. 1/16W 820R J R448 VE-30012683 SMD RES. 1/16W 330K J R449 VE-30012659 SMD RES. 1/16W 2.2K J

Symbol No. Part No. Part Name Description

!

RESISTOR

R450 VE-30012702 SMD RES. 1/16W 560R J R458 VE-30012510 SMD RES. 1/16W 100R J

R459 VE-30012668 SMD RES. 1/16W 220R J R460 VE-30012668 SMD RES. 1/16W 220R J R461 VE-30012668 SMD RES. 1/16W 220R J R462 VE-30012510 SMD RES. 1/16W 100R J R467 VE-30000670 CF RES. 1/4W 330K J

R468 VE-30000670 CF RES. 1/4W 330K J R469 VE-30000628 CF RES. 1/4W 2.7K J R471 VE-30014022 SMD RES. 1/16W 47R J R472 VE-30012662 SMD RES. 1/16W 2.7K J R474 VE-30012662 SMD RES. 1/16W 2.7K J R481 VE-30000466 CF RES. 1/4W 1K J

R482 VE-30012657 SMD RES. 1/16W 1K J R483 VE-30012657 SMD RES. 1/16W 1K J R485 VE-30012657 SMD RES. 1/16W 1K J R486 VE-30012657 SMD RES. 1/16W 1K J R487 VE-30012657 SMD RES. 1/16W 1K J

R507 VE-30000466 CF RES. 1/4W 1K J R508 VE-30012510 SMD RES. 1/16W 100R J R509 VE-30012641 SMD RES. 1/16W 10K J R510 VE-30012702 SMD RES. 1/16W 560R J R511 VE-30012657 SMD RES. 1/16W 1K J

R512 VE-30000495 CF RES. 1/4W 1.2K J R513 VE-30000459 CF RES. 1/4W 100R J R514 VE-30000459 CF RES. 1/4W 100R J R515 VE-30012659 SMD RES. 1/16W 2.2K J R516 VE-30012659 SMD RES. 1/16W 2.2K J

R517 VE-30012692 SMD RES. 1/16W 4.7K J R518 VE-30000471 CF RES. 1/4W 10K J R519 VE-30012698 SMD RES. 1/16W 5.6K J R525 VE-30012649 SMD RES. 1/16W 150R J R526 VE-30012641 SMD RES. 1/16W 10K J

R527 VE-30012692 SMD RES. 1/16W 4.7K J R528 VE-30012698 SMD RES. 1/16W 5.6K J R529 VE-30012698 SMD RES. 1/16W 5.6K J R530 VE-30012698 SMD RES. 1/16W 5.6K J R532 VE-30012659 SMD RES. 1/16W 2.2K J R533 VE-30012644 SMD RES. 1/16W 12K J

R534 VE-30000628 CF RES. 1/4W 2.7K J R537 VE-30012641 SMD RES. 1/16W 10K J R538 VE-30012698 SMD RES. 1/16W 5.6K J R539 VE-30012659 SMD RES. 1/16W 2.2K J R540 VE-30012644 SMD RES. 1/16W 12K J

R545 VE-30012644 SMD RES. 1/16W 12K J R548 VE-30012641 SMD RES. 1/16W 10K J R554 VE-30012641 SMD RES. 1/16W 10K J R555 VE-30012659 SMD RES. 1/16W 2.2K J R556 VE-30012657 SMD RES. 1/16W 1K J

R560 VE-30012674 SMD RES. 1/16W 27K J R561 VE-30012692 SMD RES. 1/16W 4.7K J R568 VE-30000594 CF RES. 1/4W 22K J R572 VE-30012659 SMD RES. 1/16W 2.2K J R573 VE-30012641 SMD RES. 1/16W 10K J

R574 VE-30012657 SMD RES. 1/16W 1K J R603 VE-30000459 CF RES. 1/4W 100R J R604 VE-30012510 SMD RES. 1/16W 100R J R606 VE-30000471 CF RES. 1/4W 10K J R607 VE-30000554 CF RES. 1/4W 180R J R608 VE-30000859 MF RES. 1/2W 1R F

R609 VE-30000711 CF RES. 1/2W 470R J R610 VE-30000599 CF RES. 1/4W 220K J R611 VE-30012708 SMD RES. 1/16W 68K J R614 VE-30012509 SMD RES. 1/16W 100K J R616 VE-30012669 SMD RES. 1/16W 22K J

R617 VE-30000572 CF RES. 1/4W 2K J R630 VE-30012702 SMD RES. 1/16W 560R J R634 VE-30000633 CF RES. 1/4W 27K J R639 VE-30000471 CF RES. 1/4W 10K J R640 VE-30000628 CF RES. 1/4W 2.7K J

R646 VE-30000531 CF RES. 1/4W 15K J R647 VE-30000466 CF RES. 1/4W 1K J

!

R648 VE-30001246 FUSE RES. 1W 0.4 7R J R650 VE-30012702 SMD RES. 1/16W 560R J R651 VE-30012668 SMD RES. 1/16W 220R J

!

R656 VE-30001230 FUSE RES. 1/2W 27R J

!

R657 VE-30001228 FUSE RES. 1/2W 2.2R J R662 VE-30012674 SMD RES. 1/16W 27K J R666 VE-30000815 CF RES. 1/4W 8.2K J

26

No. 52057

A

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

Symbol No. Part No. Part Name Description

!

RESISTOR

R668 VE-30000790 CF RES. 1/4W 6.8R J R669 VE-30012510 SMD RES. 1/16W 100R J R670 VE-30012510 SMD RES. 1/16W 100R J R674 VE-30012662 SMD RES. 1/16W 2.7K J

!

R675 VE-30001244 FUSE RES. 1/2W 0.47R J R677 VE-30001124 MO RES. 3W 220R J R678 VE-30014022 SMD RES. 1/16W 47R J R680 VE-30000477 CF RES. 1/4W 100K J R681 VE-30012509 SMD RES. 1/16W 100K J

R682 VE-30008856 MO RES. 2W 270R J R683 VE-30017083 WW RES. 5W 2.2K J RAD. R689 VE-30000718 CF RES. 1/4W 4.7K J R690 VE-30000466 CF RES. 1/4W 1K J R691 VE-30012696 SMD RES. 1/16W 47K J R692 VE-30012509 SMD RES. 1/16W 100K J

R693 VE-30012708 SMD RES. 1/16W 68K J R694 VE-30000689 CF RES. 1/4W 3.9K J R695 VE-30000471 CF RES. 1/4W 10K J R696-Y VE-30001350 ZENER DIODE 12V R697 VE-30000712 CF RES. 1/4W 470R J

R698 VE-30012657 SMD RES. 1/16W 1K J R699 VE-30012685 SMD RES. 1/16W 33K J R700 VE-30012649 SMD RES. 1/16W 150R J R701 VE-30000459 CF RES. 1/4W 100R J R703 VE-30000459 CF RES. 1/4W 100R J

R705 VE-30000459 CF RES. 1/4W 100R J R715 VE-30012702 SMD RES. 1/16W 560R J R717 VE-30012702 SMD RES. 1/16W 560R J R719 VE-30012657 SMD RES. 1/16W 1K J R721 VE-30012510 SMD RES. 1/16W 100R J

R722 VE-30012510 SMD RES. 1/16W 100R J R723 VE-30012510 SMD RES. 1/16W 100R J R724 VE-30012510 SMD RES. 1/16W 100R J R801 VE-30000718 CF RES. 1/4W 4.7K J R803 VE-30012659 SMD RES. 1/16W 2.2K J

R805 VE-30000650 CF RES. 1/4W 33R J R806 VE-30000982 MF RES. 1/4W 4.7K J R807 VE-30001173 MO RES. 1W 0.47R J R809 VE-30007784 MO RES. 5W 33K J(RADIAL) R810 VE-30001257 MG RES. 1/2W 4.7M J

!

R811 VE-30000718 CF RES. 1/4W 4.7K J R812 VE-30012641 SMD RES. 1/16W 10K J

R813 VE-30000466 CF RES. 1/4W 1K J R814 VE-30000466 CF RES. 1/4W 1K J R817 VE-30000880 MF RES. 1/4W 130K F R818 VE-30012675 SMD RES. 1/16W 2K J

R819 VE-30000526 CF RES. 1/4W 1.5K J R828 VE-30000530 CF RES. 1/2W 15K J R829 VE-30000530 CF RES. 1/2W 15K J R834 VE-30001159 MO RES. 1W 0.33R J R836 VE-30012662 SMD RES. 1/16W 2.7K J

R839 VE-30000526 CF RES. 1/4W 1.5K J R842 VE-30014128 SMD RES. 1/16W 33R J R844 VE-30012641 SMD RES. 1/16W 10K J R845 VE-30012509 SMD RES. 1/16W 100K J R846 VE-30012692 SMD RES. 1/16W 4.7K J

R847 VE-30014128 SMD RES. 1/16W 33R J R848 VE-30012641 SMD RES. 1/16W 10K J R849 VE-30012510 SMD RES. 1/16W 100R J R851 VE-30000718 CF RES. 1/4W 4.7K J R852 VE-30000650 CF RES. 1/4W 33R J

R853 VE-30012642 SMD RES. 1/16W 120K J R855 VE-30000459 CF RES. 1/4W 100R J R856 VE-30012694 SMD RES. 1/16W 470K J

CAPACITOR

C141 VE-30007081 EL CAP. 4.7UF 50V M (NPL) C142 VE-30007081 EL CAP. 4.7UF 50V M (NPL) C143 VE-30012589 SMD CAP. 4.7NF 50V K C144 VE-30012589 SMD CAP. 4.7NF 50V K

C145 VE-30012589 SMD CAP. 4.7NF 50V K C146 VE-30012589 SMD CAP. 4.7NF 50V K C147 VE-30012589 SMD CAP. 4.7NF 50V K C148 VE-30012589 SMD CAP. 4.7NF 50V K C149 VE-30012589 SMD CAP. 4.7NF 50V K

C150 VE-30012589 SMD CAP. 4.7NF 50V K C155 VE-30012560 SMD CAP. 100PF 50V J C157 VE-30012560 SMD CAP. 100PF 50V J C159 VE-30000352 EL CAP. 100UF 16V M C160 VE-30000345 EL CAP. 10UF 50V M

C161 VE-30000345 EL CAP. 10UF 50V M

Symbol No. Part No. Part Name Description

!

CAPACITOR

C162 VE-30012573 SMD CAP. 47PF 50V J C164 VE-30012692 SMD RES. 1/16W 4.7K J C165 VE-30000413 EL CAP. 4.7UF 50V M C201 VE-30000400 EL CAP. 47UF 50V M

C205 VE-30000345 EL CAP. 10UF 50V M C206 VE-30012610 SMD CAP. 10NF 50V J C207 VE-30012610 SMD CAP. 10NF 50V J C230 VE-30016654 SMD CAP. 100NF 16V K R C246 VE-30000295 CER CAP. 100NF 50V Z F

C303 VE-30000100 MKT CAP. 330NF 63V J C305 VE-30012590 SMD CAP. 47NF 50V K C310 VE-30000345 EL CAP. 10UF 50V M C333 VE-30000083 MKT CAP. 150NF 63V J C363 VE-30000083 MKT CAP. 150NF 63V J C364 VE-30012590 SMD CAP. 47NF 50V K

C366 VE-30000407 EL CAP. 470UF 16V M C368 VE-30012590 SMD CAP. 47NF 50V K C404 VE-30000190 CER CAP. 100PF 50V J CH C408 VE-30012586 SMD CAP. 22NF 50V K C409 VE-30000345 EL CAP. 10UF 50V M

C410 VE-30000384 EL CAP. 2.2UF 50V M C411 VE-30000345 EL CAP. 10UF 50V M C412 VE-30016654 SMD CAP. 100NF 16V K R C413 VE-30000362 EL CAP. 1UF 50V M C414 VE-30012585 SMD CAP. 2.2NF 50V K R

C415 VE-30012581 SMD CAP. 1NF 50V K R C416 VE-30000362 EL CAP. 1UF 50V M C417 VE-30000362 EL CAP. 1UF 50V M C418 VE-30016654 SMD CAP. 100NF 16V K R C419 VE-30000384 EL CAP. 2.2UF 50V M

C420 VE-30000100 MKT CAP. 330NF 63V J C422 VE-30000352 EL CAP. 100UF 16V M C423 VE-30000352 EL CAP. 100UF 16V M C424 VE-30000352 EL CAP. 100UF 16V M C425 VE-30016654 SMD CAP. 100NF 16V K R

C427 VE-30016654 SMD CAP. 100NF 16V K R C429 VE-30012589 SMD CAP. 4.7NF 50V K C430 VE-30016654 SMD CAP. 100NF 16V K R C431 VE-30000362 EL CAP. 1UF 50V M C432 VE-30016654 SMD CAP. 100NF 16V K R C433 VE-30000345 EL CAP. 10UF 50V M

C434 VE-30016654 SMD CAP. 100NF 16V K R C435 VE-30016654 SMD CAP. 100NF 16V K R C436 VE-30000384 EL CAP. 2.2UF 50V M C437 VE-30016654 SMD CAP. 100NF 16V K R C438 VE-30016654 SMD CAP. 100NF 16V K R

C439 VE-30016654 SMD CAP. 100NF 16V K R C440 VE-30000295 CER CAP. 100NF 50V Z F C441 VE-30012582 SMD CAP. 10NF 50V K R C442 VE-30000362 EL CAP. 1UF 50V M C443 VE-30000362 EL CAP. 1UF 50V M

C444 VE-30000384 EL CAP. 2.2UF 50V M C448 VE-30012586 SMD CAP. 22NF 50V K C449 VE-30012560 SMD CAP. 100PF 50V J C453 VE-30000352 EL CAP. 100UF 16V M C455 VE-30000345 EL CAP. 10UF 50V M

C459 VE-30012560 SMD CAP. 100PF 50V J C501 VE-30016654 SMD CAP. 100NF 16V K R C502 VE-30000400 EL CAP. 47UF 50V M C504 VE-30016654 SMD CAP. 100NF 16V K R C505 VE-30012589 SMD CAP. 4.7NF 50V K

C507 VE-30000345 EL CAP. 10UF 50V M C510 VE-30016654 SMD CAP. 100NF 16V K R C511 VE-30012566 SMD CAP. 22PF 50V J C513 VE-30000345 EL CAP. 10UF 50V M C514 VE-30016654 SMD CAP. 100NF 16V K R C515 VE-30012560 SMD CAP. 100PF 50V J

C517 VE-30016654 SMD CAP. 100NF 16V K R C518 VE-30016654 SMD CAP. 100NF 16V K R C519 VE-30012560 SMD CAP. 100PF 50V J C520 VE-30012560 SMD CAP. 100PF 50V J C521 VE-30012562 SMD CAP. 15PF 50V J

C522 VE-30012562 SMD CAP. 15PF 50V J C523 VE-30012585 SMD CAP. 2.2NF 50V K R C524 VE-30012566 SMD CAP. 22PF 50V J C525 VE-30012566 SMD CAP. 22PF 50V J C526 VE-30016654 SMD CAP. 100NF 16V K R

C527 VE-30000345 EL CAP. 10UF 50V M C529 VE-30012589 SMD CAP. 4.7NF 50V K C530 VE-30012589 SMD CAP. 4.7NF 50V K C532 VE-30016654 SMD CAP. 100NF 16V K R C536 VE-30000295 CER CAP. 100NF 50V Z F

C541 VE-30000362 EL CAP. 1UF 50V M

No. 52057

27

A

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

Symbol No. Part No. Part Name Description

!

CAPACITOR

C542 VE-30000107 MKT CAP. 47NF 250V J C543 VE-30000431 CER CAP. 100PF 1KV M C544 VE-30000345 EL CAP. 10UF 50V M C547 VE-30000345 EL CAP. 10UF 50V M

C565 VE-30016654 SMD CAP. 100NF 16V K R C566 VE-30016654 SMD CAP. 100NF 16V K R C567 VE-30000431 CER CAP. 100PF 1KV M C602 VE-30017319 MKT CAP. 120NF 63V J C604 VE-30000356 EL CAP. 100UF 63V M

C605 VE-30000360 EL CAP. 1000UF 25V M C607 VE-30012581 SMD CAP. 1NF 50V K R

!

C618 VE-30000159 MKP CAP. 4.7NF 1.6KV J C621 VE-30000179 MKP CAP. 9.1NF 1600V %3.5

!

C622 VE-30000121 KP CAP. 27NF 630V J C625 VE-30000156 MKP CAP. 430NF 250V J

!

C627 VE-30000167 MKP CAP. 560NF 250V J C629 VE-30000177 MKP CAP. 820NF 250V J C632 VE-30000100 MKT CAP. 330NF 63V J C635 VE-30000385 EL CAP. 2.2UF 250V M C636 VE-30000387 EL CAP. 33UF 50V M

C640 VE-30000100 MKT CAP. 330NF 63V J C641 VE-30000090 MKT CAP. 22NF 100V J C642 VE-30000407 EL CAP. 470UF 16V M C644 VE-30000409 EL CAP. 470UF 25V M C645 VE-30000090 MKT CAP. 22NF 100V J

C646 VE-30000100 MKT CAP. 330NF 63V J C647 VE-30007748 EL CAP. 1000UF 35V M C648 VE-30000394 EL CAP. 3.3UF 160V M C649 VE-30000295 CER CAP. 100NF 50V Z F C652 VE-30000330 CER CAP. 4.7NF 50V K B

C653 VE-30000107 MKT CAP. 47NF 250V J C655 VE-30000415 EL CAP. 4.7UF 250V M C700 VE-30012565 SMD CAP. 1.8PF 50V J CH C701 VE-30012565 SMD CAP. 1.8PF 50V J CH C702 VE-30012576 SMD CAP. 56PF 50V J CH

C703 VE-30012576 SMD CAP. 56PF 50V J CH C704 VE-30012576 SMD CAP. 56PF 50V J CH C705 VE-30000345 EL CAP. 10UF 50V M C706 VE-30000345 EL CAP. 10UF 50V M C708 VE-30016654 SMD CAP. 100NF 16V K R C712 VE-30000345 EL CAP. 10UF 50V M

C713 VE-30016654 SMD CAP. 100NF 16V K R C714 VE-30000100 MKT CAP. 330NF 63V J C716 VE-30000100 MKT CAP. 330NF 63V J C717 VE-30000100 MKT CAP. 330NF 63V J C718 VE-30000100 MKT CAP. 330NF 63V J

C719 VE-30016654 SMD CAP. 100NF 16V K R C720 VE-30000345 EL CAP. 10UF 50V M C721 VE-30000100 MKT CAP. 330NF 63V J C723 VE-30000100 MKT CAP. 330NF 63V J C724 VE-30000345 EL CAP. 10UF 50V M

C729 VE-30016654 SMD CAP. 100NF 16V K R C730 VE-30000393 EL CAP. 3.3UF 50V M C733 VE-30000345 EL CAP. 10UF 50V M C734 VE-30000345 EL CAP. 10UF 50V M C735 VE-30016654 SMD CAP. 100NF 16V K R

C736 VE-30000345 EL CAP. 10UF 50V M C737 VE-30000384 EL CAP. 2.2UF 50V M C738 VE-30000384 EL CAP. 2.2UF 50V M C739 VE-30000384 EL CAP. 2.2UF 50V M C740 VE-30000384 EL CAP. 2.2UF 50V M

C741 VE-30012589 SMD CAP. 4.7NF 50V K C742 VE-30012589 SMD CAP. 4.7NF 50V K C745 VE-30016654 SMD CAP. 100NF 16V K R C801 VE-30000094 MKT CAP. 220NF 275V M AC

!

C802 VE-30000094 MKT CAP. 220NF 275V M AC

!

C803 VE-30000433 CER CAP. 1NF 1KV M B

! !

C804 VE-30000433 CER CAP. 1NF 1KV M B C808 VE-30012590 SMD CAP. 47NF 50V K C809 VE-30000420 EL CAP. 150UF 400V M C810 VE-30000387 EL CAP. 33UF 50V M C811 VE-30000161 MKP CAP. 47NF 630V J

C812 VE-30007708 CER CAP. 1NF 1KV K (PULSE)

!

C816 VE-30000440 CER CAP. 2.2NF 4KV M C817 VE-30000198 CER CAP. 120PF 500V J SL C818 VE-30012590 SMD CAP. 47NF 50V K C819 VE-30012590 SMD CAP. 47NF 50V K

C822 VE-30007308 CER CAP. 220PF 1KV K (PULSE) C826 VE-30000406 EL CAP. 47UF 250V M (HR) C827 VE-30000411 EL CAP. 4700UF 16V M C828 VE-30012590 SMD CAP. 47NF 50V K C829 VE-30000407 EL CAP. 470UF 16V M

C830 VE-30000383 EL CAP. 2200UF 25V M

Symbol No. Part No. Part Name Description

!

CAPACITOR

C832 VE-30012590 SMD CAP. 47NF 50V K C833 VE-30000407 EL CAP. 470UF 16V M C834 VE-30012590 SMD CAP. 47NF 50V K C835 VE-30012590 SMD CAP. 47NF 50V K

C838 VE-30000407 EL CAP. 470UF 16 V M C839 VE-30000407 EL CAP. 470UF 16V M C840 VE-30000407 EL CAP. 470UF 16V M C848 VE-30000407 EL CAP. 470UF 16V M C850 VE-30000383 EL CAP. 2200UF 25V M

C851 VE-30012590 SMD CAP. 47NF 50V K

!

C852 VE-30000440 CER CAP. 2.2NF 4KV M C857 VE-30000106 MKT CAP. 47NF 100V J C858 VE-30007708 CER CAP. 1NF 1KV K (PULSE) C859 VE-30009208 CER CAP. 470PF 1KV K (PULSE) C860 VE-30000296 CER CAP. 100NF 100V Z F

C872 VE-30007708 CER CAP. 1NF 1KV K (PULSE)

TRANSF

TR600 VE-30002090 LINE DRIVER

!

TR601 VE-30017522 FBT TRF TR802 VE-30018785 SMPS TRF

!

COIL

L101 VE-30001971 FERRITE BEAT L102 VE-30001971 FERRITE BEAT L106 VE-30001971 FERRITE BEAT

L108 VE-30001971 FERRITE BEAT L109 VE-30001971 FERRITE BEAT L110 VE-30001971 FERRITE BEAT L111 VE-30001971 FERRITE BEAT L112 VE-30001971 FERRITE BEAT

L113 VE-30001971 FERRITE BEAT L114 VE-30001971 FERRITE BEAT L115 VE-30001971 FERRITE BEAT L116 VE-30001971 FERRITE BEAT L117 VE-30001971 FERRITE BEAT L201 VE-30001979 FIXED COIL 1UH

L210 VE-30001971 FERRITE BEAT L215 VE-30001971 FERRITE BEAT L401 VE-30001971 FERRITE BEAT L402 VE-30001992 FIXED COIL 10UH L403 VE-30001971 FERRITE BEAT

L405 VE-30014048 ADJ. COIL 44MHZ L406 VE-30001971 FERRITE BEAT L408 VE-30001992 FIXED COIL 10UH L501 VE-30001971 FERRITE BEAT L502 VE-30001971 FERRITE BEAT

L503 VE-30001971 FERRITE BEAT L504 VE-30001971 FERRITE BEAT L600 VE-30002031 FIXED COIL 15MH L602 VE-30002156 LINEARITY COIL 30UH L603 VE-30002026 FIXED COIL 1MH

L700 VE-30001971 FERRITE BEAT L701 VE-30001971 FERRITE BEAT L702 VE-30001992 FIXED COIL 10UH L703 VE-30001971 FERRITE BEAT L704 VE-30001971 FERRITE BEAT

L801 VE-30002011 CHOKE COIL 150UH L803 VE-30001992 FIXED COIL 10UH

DIODE

D105 VE-30007760 ZENER DIODE D106 VE-30007760 ZENER DIODE D107 VE-30007760 ZENER DIODE D303 VE-30001329 DIODE D405 VE-30007763 ZENER DIODE

D407 VE-30001284 DIODE D408 VE-30001285 DIODE D409 VE-30001284 DIODE D413 VE-30018526 ZENER DIODE D501 VE-30001285 DIODE

D505 VE-30001285 DIODE D506 VE-30001284 DIODE D512 VE-30001285 DIODE D513 VE-30001369 ZENER DIODE D533 VE-30001377 ZENER DIODE

28

No. 52057

A

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

Symbol No. Part No. Part Name Description

!

DIODE

D601 VE-30001329 DIODE D603 VE-30001285 DIODE D605 VE-30001320 DIODE D606 VE-30001323 DIODE

D609 VE-30001318 DIODE D610 VE-30001318 DIODE D613 VE-30001318 DIODE D614 VE-30001285 DIODE D616 VE-30003696 DIODE

D617 VE-30001318 DIODE D651 VE-30001285 DIODE D653 VE-30001285 DIODE D656 VE-30007763 ZENER DIODE D657 VE-30007763 ZENER DIODE D658 VE-30007763 ZENER DIODE

D659 VE-30001350 ZENER DIODE D660 VE-30001347 ZENER DIODE D661 VE-30001350 ZENER DIODE D700 VE-30001285 DIODE D701 VE-30001369 ZENER DIODE

D800 VE-30001318 DIODE D801 VE-30001372 ZENER DIODE D802 VE-30001318 DIODE D803 VE-30001315 DIODE D804 VE-30001318 DIODE

D805 VE-30001315 DIODE D806 VE-30001315 DIODE D808 VE-20092405 CN.ASY D809 VE-30001329 DIODE D810 VE-30009366 DIODE

D811 VE-30009366 DIODE D812 VE-30001285 DIODE D889 VE-30001384 TR D891 VE-30007758 BRIDGE DIODE

!

D892 VE-30001318 DIODE D893 VE-30001318 DIODE

D894 VE-30001285 DIODE D897 VE-30001329 DIODE

TRANSISTOR

Q104 VE-30001457 TR Q106 VE-30001457 TR Q141 VE-30001457 TR Q142 VE-30001457 TR

Q307 VE-30001457 TR Q316 VE-30001458 TR Q403 VE-30001457 TR Q404 VE-30001457 TR Q503 VE-30001457 TR

Q504 VE-30001458 TR Q600 VE-30001435 TR

!

Q601 VE-30001441 TR H.OUT Q602 VE-30001429 TR Q603 VE-30001458 TR

Q604 VE-30001457 TR Q605 VE-30001458 TR Q700 VE-30001458 TR Q801 VE-30001386 TR Q802 VE-30001457 TR

Q804 VE-30001454 TR

IC

IC301 VE-30016113 IC IC403 VE-30014521 IC

IC500 VE-20099532 IC (SERVICE) IC501 VE-20093395 IC (MICOM) IC601 VE-30013985 IC IC700 VE-30013658 IC

IC800 VE-30011968 IC

!

IC801 VE-30015087 IC IC802 VE-30001622 IC IC803 VE-30001500 IC IC804 VE-30001622 IC

IC818 VE-30001506 IC

Symbol No. Part No. Part Name Description

!

OTHERS

!

TR801 VE-30002104 LINE FILTER

!

F801 VE-30001731 FUSE 2.5A TH800 VE-30001270 PTC 9 OHM

!

TU201 VE-30009637 TUNER VR800 VE-30001064 RES ADJ

X401 VE-30001749 XTAL X402 VE-30015592 XTAL X501 VE-30002851 XTAL X700 VE-30001756 XTAL

Z401 VE-30001705 SAW FILTER Z402 VE-30015591 SAW FILTER

No. 52057

29

A

V-28BT8ENS / AV-28BT8ENB / AV-28BT80EN

[ AV- 28BT8 ENS / AV- 28BT8 ENB / AV-28BT 80EN ]

CRT SOCKET P.W. BOARD ASS’Y (VE-20094670)

Symbol No. Part No. Part Name Description

!

RESISTOR

R900 30000788 CF RES. 1/4W 6.8M J R902 30000459 CF RES. 1/4W 100R J R903 30000459 CF RES. 1/4W 100R J

R904 30000459 CF RES. 1/4W 100R J R906 30000535 CF RES. 1/2W 150K J R907 30000477 CF RES. 1/4W 100K J R908 30000477 CF RES. 1/4W 100K J R909 30000525 CF RES. 1/2W 1.5K J

R910 30000525 CF RES. 1/2W 1.5K J R911 30000525 CF RES. 1/2W 1.5K J R912 30000477 CF RES. 1/4W 100K J R913 30000525 CF RES. 1/2W 1.5K J R914 30001084 MO RES. 1W 1K J

R916 30001170 MO RES. 1W 4.7K J

!

R917 30001208 FUSE RES. 1W 10R J R918 30000471 CF RES. 1/4W 10K J R921 30000599 CF RES. 1/4W 220K J R922 30000590 CF RES. 1/4W 2.2K J

CAPACITOR

C900 30000075 MKT CAP. 100NF 250V K (DC) C902 30000415 EL CAP. 4.7UF 250V M

C903 30000438 CER CAP. 2.2NF 2KV C904 30000295 CER CAP. 100NF 50V Z F C905 30000234 CER CAP. 270PF 50V J SL C906 30000350 EL CAP. 10UF 250V M C907 30000075 MKT CAP. 100NF 250V K (DC)

C909 30000385 EL CAP. 2.2UF 250V M C910 30000438 CER CAP. 2.2NF 2KV C911 30000433 CER CAP. 1NF 1KV M B

COIL

L900 30002170 COIL

DIODE

D901 30001329 DIODE D902 30001318 DIODE D903 30001329 DIODE

D904 30001329 DIODE D905 30001284 DIODE D906 30001284 DIODE D907 30001284 DIODE D908 30001284 DIODE

D909 30001344 ZENER DIODE NOT1 30001329 DIODE

TRANSISTOR

Q900 30001427 TR Q901 30001454 TR

IC

IC900 30008721 IC

OTHERS

!

PL902 30001855 CRT SOCKET SG901 30000428 SPARK GAP 300V SG902 30000428 SPARK GAP 300V SG903 30000428 SPARK GAP 300V

SG904 30000428 SPARK GAP 300V

FRONT C ONT ROL P.W. BOARD ASS’Y (VE-20082481)

Symbol No. Part No. Part Name Description

!

RESISTOR

R2 VE-30000526 CF RES. 1/4W 1.5K J R3 VE-30000770 CF RES . 1/4W 680R J R4 VE-30000712 CF RES. 1/4W 470R J R5 VE-30000622 CF RES. 1/4W 270R J

DIODE

D1 VE-30001279 LED RED/GREEN

IC

IC1 VE-30001670 PREAMPLIFIER

OTHERS

SW1 VE-30002181 SWITCH TACT SW2 VE-30002181 SWITCH TACT

SW3 VE-30002181 SWITCH TACT SW4 VE-30002181 SWITCH TACT SW5 VE-30002181 SWITCH TACT

FRONT AV & HEADPHONE P.W. BOARD ASS’Y (VE-20083646)

!

Symbol No. Part No. Part Name Description

RESISTOR

R109 VE-30000594 CF RES. 1/4W 22K J R110 VE-30000712 CF RES. 1/4W 470R J R113 VE-30000744 CF RES. 1/4W 560R J R114 VE-30000744 CF RES. 1/4W 560R J R115 VE-30000712 CF RES. 1/4W 470R J

R116 VE-30000712 CF RES. 1/4W 470R J

CAPACITOR

C103 VE-30000213 CER CAP. 180PF 50V J C104 VE-30000213 CER CAP. 180PF 50V J C106 VE-30000190 CER CAP. 100PF 50V J

COIL

L103 VE-30001996 FIXED COIL 22UH Q40 K L104 VE-30001996 FIXED COIL 22UH Q40 K

30

No. 52057

A

P

PRINTED WIRING BOARD PARTS LIST

[ AV-28BT8EPS / AV-28BT8EPB / AV-28BT80EP ]

MAIN P.W. BOARD ASS’Y (VE-20101576)
