Page 1
52031C200301
AV-21LS2
AV-21LX2
AV-2168TEE
SERVICE MANUAL
COLOUR TELEVISION
BASIC CHASSIS
AV-21LS2/E
CH
AV-21LX2/E
AV-21LX2/E-A
AV-2168TEE/E
Supplementary
The following items for the AV-21LS2/E, AV-21LX2/E, AV-21LX2/E-A, AV-2168TEE/E model were changed
partly from AV-21LS2, AV-21LX2, AV-21LX2/-A, AV-2168TEE model.
Therefore, this service manual describes only the items which differ from those of the AV-21LS2, AV21LX2, AV-21LX2/-A, AV-2168TEE model service manual.
For details other than those described in this manual, please refer to the AV-21LS2, AV-21LX2, AV-21LX2/
-A, AV-2168TEE model service manual (No.52031, Oct.2002).
OUTLINE
Since the picture tube was changed, we have issued the SERVICE MANUAL for AV-21LS2/E, AV-21LX2/E, AV21LX2/E-A, AV-2168TEE/E.
HOW TO IDENTIFY MODELS
“AV-21LS2/E”, “AV-21LX2/E”, “AV-21LX2/EA”, “AV-2168TEE/E” is added to the serial No. under at the
Rating label.
MODEL
AV-21LS2
AV-21LX2
AV-21LX2/A
AV-2168TEE
AV-21LS2/E
AV-21LX2/E
SERIAL No.
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
Indicated
AV-21LX2/EA
AV-2168TEE/E
No.52031C
2003/01
Page 2
AV-21LS2
AV-21LX2
AV-2168TEE
DIFFERENCE LIST
USING P.W.BOARD (Page 41)
Model
P.W.B ASS’Y Name
MAIN PWB SCH-1084A-H2 SCH-1134A-H2 Non compatible
AV-21LS2 AV-21LS2/E DESCRIPTION
USING P.W.BOARD (Page 55)
Model
P.W.B ASS’Y Name
MAIN PWB SCH-1079A-H2 SCH-1133A-H2 Non compatible
Model
P.W.B ASS’Y Name
MAIN PWB SCH-1085A-H2 SCH-1136A-H2 Non compatible
AV-21LX2/A
AV-21LX2
AV-2168TEE AV-2168TEE/E DESCRIPTION
AV-21LX2/E-A
AV-21LX2/E
DESCRIPTION
EXPLODED VIEW PARTS LIST
EXPLODED VIEW (Page 42)
PARTS No.
Ref. No.
V01 A51LVV896X A51QDX992X PICTURE TUBE
DY01 QQD0082-001 QQD0095-001 DEFLECTION YOKE
AV-21LS2
AV-21LX2
AV-21LX2/A
AV-2168TEE
AV-21LS2/E
AV-21LX2/E
AV-21LX2/E-A
AV-2168TEE/E
PARTS NAME DESCRIPTION
1-2 (No.52031C)
Page 3
PRINTING WIRING BOARD PARTS LIST
MAIN PW BOARD ASS’Y [ AV-21LS2/E ] (Page 44-47)
Symbol No.
R1358 QRE121J-272Y QRE121J-182Y C R 1.8kΩ 1/2W J
R1414 QRE121J-120Y QRE121J-270Y C R 27Ω 1/2W J
C1374 QCZ0364-222 QCZ0364-681 C CAP. 680pF
C1524 QFZ0200-632 QFZ0200-612 MPP CAP. 6100pF 1.5kV H ±3%
C1525 QFZ0196-382 QFZ0200-342 MPP CAP. 3400pF 1.5kV H ±3%
C1972 QEHR1VM-476Z QEHR1VM-108Z E CAP. 1000µF 35V M
L1524 QQLZ034-430 QQLZ034-220 COIL 22µH
MAIN PW BOARD ASS’Y [ AV-21LX2/E ] [ AV-21LX2/E-A ] [ AV-2168TEE/E ] (Page 49-52)
Symbol No.
R1358 QRE121J-272Y QRE121J-182Y C R 1.8kΩ 1/2W J
R1414 QRE121J-120Y QRE121J-270Y C R 27Ω 1/2W J
C1374 QCZ0364-222 QCZ0364-681 C CAP. 680pF
C1524 QFZ0200-632 QFZ0200-612 MPP CAP. 6100pF 1.5kV H ±3%
C1525 QFZ0196-382 QFZ0200-342 MPP CAP. 3400pF 1.5kV H ±3%
C1972 QEHR1VM-476Z QEHR1VM-108Z E CAP. 1000µF 35V M
L1524 QQLZ034-430 QQLZ034-220 COIL 22µH
SCH-1084A-H2 SCH-1134A-H2
SCH-1079A-H2
SCH-1085A-H2
PARTS No.
PARTS No.
SCH-1133A-H2
SCH-1136A-H2
PARTS NAME DESCRIPTION
PARTS NAME DESCRIPTION
AV-21LS2
AV-21LX2
AV-2168TEE
(No.52031C)1-3
Page 4
AV-21LS2
AV-21LX2
AV-2168TEE
VICTOR COMPANY OF JAPAN, LIMITED
AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
(No.52031C)
Printed in Japan
200301WPC
