JVC AV-1415EE/SK, AV-1416EE/SK Service Manual

52029C200303

AV-1415EE
AV-1416EE

SERVICE MANUAL

COLOUR TELEVISION

BASIC CHASSIS

AV-1415EE/SK,

CG

AV-1416EE

/SK

Supplementary

The following items for the AV-1415EE/SK, AV-1416EE/SK models were changed partly from AV-1415EE
models.
Therefore, this service manual describes only the items which differ from those of the AV-1415EE model
service manual.
For details other than those described in this manual, please refer to the AV-1415EE model service manual
(No.52029, Jun.2002).

OUTLINE

Since the production place of the model has been changed, changes are presented here.

HOW TO IDENTIFY MODELS

“AV-1415EE/SK”, “AV-1416EE/SK” is added to the serial No. under at the Rating label.

MODEL

SERIAL No.

COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.

Indicated

AV-1415EE

AV-1415EE/SK
AV-1416EE/SK

No.52029C

2003/03

AV-1415EE
AV-1416EE

DIFFERENCE LIST

USING P.W.BOARD (Page 34)

P.W.B ASS’Y AV-1415EE AV-1415EE/SK AV-1416EE/SK DESCRIPTION

MAIN PWB SCG-1426A-H2 SCG-1458A-H2 SCG-1463A-H2 Non compatible

CRT SOCKET PWB - - SCG-3002A-CK

EXPLODED VIEW PARTS LIST

EXPLODED VIEW (Page 36)

 Ref. No.

AV-1415EE AV-1415EE/SK

 V01 A34AGT13X - PICTURE TUBE
 V01 - A34KQW42X01 ITC
 L01 QQW0093-001 QQW0096-001 DEG COIL
 DY01 QQD0046-001 - DEF YOKE
 T1522 QQH0132-001 QQH0108-001 F.B.TRANSF.
 1 LC10164-028A-H LC10164-028A-HK FRONT CABINET

4 CE40305-00B - PC MAGNET

7 CE42153-00AJ1 - WEDGE ASSY (x3)

 14 LC10165-001D-H LC10165-001D-HK REAR COVER
 18 GG20024-001A-H GG20024-001B-H RATING LABEL

PARTS No.

PARTS NAME DESCRIPTION

 Ref. No.

AV-1415EE AV-1416EE/SK

PARTS No.

PARTS NAME DESCRIPTION

 V01 A34AGT13X - PICTURE TUBE
 V01 - A34KQW42X01 ITC
 L01 QQW0093-001 QQW0096-001 DEG COIL
 DY01 QQD0046-001 - DEF YOKE
 T1522 QQH0132-001 QQH0108-001 F.B.TRANSF.
 1 LC10164-028A-H LC10164-031A-HK FRONT CABINET

4 CE40305-00B - PC MAGNET

7 CE42153-00AJ1 - WEDGE ASSY (x3)

 14 LC10165-001D-H LC10165-001D-HK REAR COVER
 18 GG20024-001A-H GG20024-001B-H RATING LABEL

PRINTED WIRING BOARD PARTS LIST
[AV-1415EE/SK]

Since there are many differences in MAIN PW BOARD, lists of all the parts are described here.

MAIN PW BOARD(SCG-1458A-H2)

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

IC1301 NN5198K IC
IC1301 NN5198K IC
IC1421 AN5522 IC
IC1651 AN5265 IC
IC1701 MN1873287JK1 IC(MCU)
IC1702 AT24C08-21DMG3 IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 GP1UM281QK IR DETECT UNIT 38kHz
IC1921 STR-W5753A/F5 IC
IC1971 BA17809T IC
IC1972 BA17805T IC

Q1102 2SC5083/L-P/-T TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SD601A/QR/-X TRANSISTOR

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

Q1351 STC344-T TRANSISTOR
Q1352 STC344-T TRANSISTOR
Q1353 STC344-T TRANSISTOR
Q1401 DTC124ESA-T DIGI TRANSISTOR
Q1402 2SD601A/QR/-X TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR
Q1522 2SD2658LS-YB11 POW TRANSISTOR
Q1571 2SA1208/ST/Z1-T TRANSISTOR
Q1572 2SD601A/QR/-X TRANSISTOR
Q1651 2SD601A/QR/-X TRANSISTOR
Q1652 2SD601A/QR/-X TRANSISTOR
Q1653 2SB709A/QR/-X TRANSISTOR
Q1702 2SD601A/QR/-X TRANSISTOR
Q1703 2SD601A/QR/-X TRANSISTOR
Q1708 UN2212-X DIGI TRANSISTOR

1-2 (No.52029C)

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

Q1710 UN2212-X DIGI TRANSISTOR
Q1803 2SC1815/YG/-T TRANSISTOR
Q1804 2SD601A/QR/-X TRANSISTOR
Q1974 2SA966/OY/-T TRANSISTOR
Q1975 UN2212-X DIGI TRANSISTOR

D1001 MTZJ33A-T2 Z DIODE
D1102 IM-BW BUS WIRE
D1301 MTZJ9.1B-T2 Z DIODE
D1302 MTZJ9.1B-T2 Z DIODE
D1303 MA3091/M/-X Z DIODE
D1305 AK04-T2 SB DIODE
D1306 QRE121J-121Y C RESISTOR 120Ω 1/2W J
D1341 MA111-X SI DIODE
D1421 MTZJ75-T2 Z DIODE
D1423 1SR124-400A-T2 SI DIODE
D1425 MA111-X SI DIODE
D1427 MTZJ27B-T2 Z DIODE
D1501 MTZJ6.8C-T2 Z DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1552 RGP10J-5025-T3 SI DIODE
D1553 MTZJ9.1B-T2 Z DIODE
D1554 MA111-X SI DIODE
D1571 MTZJ7.5S-T2 Z DIODE
D1581 MTZJ20B-T2 Z DIODE
D1582 RGP10J-5025-T3 SI DIODE
D1651 MA111-X SI DIODE
D1652 MTZJ12C-T2 Z DIODE
D1653 MA111-X SI DIODE
D1654 MTZJ12C-T2 Z DIODE
D1655 MA111-X SI DIODE
D1656 MA111-X SI DIODE
D1657 MA111-X SI DIODE
D1703 SPR-39MVWF LED RED-GREEN
D1707 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1920 1SS133-T2 SI DIODE
D1921 RGP10J-5025-T3 SI DIODE
D1925 RGP10J-5025-T3 SI DIODE
D1927 MTZJ36A-T2 Z DIODE
D1928 MTZJ3.3A-T2 Z DIODE
D1930 RGP10M-5010-T3 SI DIODE
D1931 MA111-X SI DIODE
D1933 MTZJ16C-T2 Z DIODE
D1941 RU3AM-LFC4 SI DIODE
D1942 RGP30B-F1 SI DIODE
D1943 RGP10J-5025-T3 SI DIODE
D1982 MA111-X SI DIODE
D1983 MA111-X SI DIODE

C1001 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1008 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1103 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C1112 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1115 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1116 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1117 QFV71HJ-224Z MF CAPACITOR 0.22uF 50V J
C1119 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1120 NDC31HJ-121X C CAPACITOR 120pF 50V J
C1121 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1122 NCB31HK-103X C CAPACITOR 0.01uF 50V K

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

C1162 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1301 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C1302 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1303 NDC31HJ-100X C CAPACITOR 10pF 50V J
C1304 QFV71HJ-474Z MF CAPACITOR 0.47uF 50V J
C1305 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1306 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1307 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1308 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1309 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1310 NDC31HJ-221X C CAPACITOR 220pF 50V J
C1311 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1312 QENC1HM-474Z BP E CAPACITOR 0.47uF 50V M
C1313 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C1314 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1315 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1316 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1317 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1321 NDC31HJ-120X C CAPACITOR 12pF 50V J
C1322 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C1323 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1324 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1325 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1326 NCS21HJ-221X C CAPACITOR 220pF 50V J
C1341 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1352 QFZ0097-103 MM CAPACITOR 0.01uF
C1354 NDC31HJ-271X C CAPACITOR 270pF 50V J
C1355 NDC31HJ-221X C CAPACITOR 220pF 50V J
C1356 NDC31HJ-331X C CAPACITOR 330pF 50V J
C1357 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1365 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1366 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1367 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1401 QFV71HJ-474Z MF CAPACITOR 0.47uF 50V J
C1423 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C1424 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C1426 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C1427 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1428 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1429 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1430 QFN32AJ-472Z M CAPACITOR 4700pF 100V J
C1433 QEHR1HM-475Z E CAPACITOR 4.7uF 50V M
C1435 QETM1EM-228 E CAPACITOR 2200uF 25V M
C1436 QFV71HJ-334Z MF CAPACITOR 0.33uF 50V J
C1437 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1501 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1523 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1525 QFZ0200-782 MPP CAPACITOR 7800pF 1.5kV H
C1526 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1527 QFZ0199-514 MPP CAPACITOR 0.51uF
C1529 QFN32AJ-102Z M CAPACITOR 1000pF 100V J
C1531 QEZ0203-107 E CAPACITOR 100uF 160V M
C1552 QETM1VM-108 E CAPACITOR 1000uF 35V M
C1554 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C1555 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1571 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1572 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1581 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1652 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1653 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1654 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1655 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1656 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1657 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1658 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1659 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1663 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1664 QETN1CM-107Z E CAPACITOR 100uF 16V M

(No.52029C)1-3

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

C1665 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1705 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1706 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1707 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1708 QETN1AM-108Z E CAPACITOR 1000uF 10V M
C1709 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1710 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1711 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1713 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1716 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1717 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1718 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1719 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1720 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1721 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C1722 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1723 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1724 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1728 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1729 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1730 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1741 IM-BW BUS WIRE
C1742 IM-BW BUS WIRE
C1743 IM-BW BUS WIRE
C1744 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1805 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1806 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1811 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1841 NCB31HK-152X C CAPACITOR 1500pF 50V K

 C1901 QFZ9078-224 MPP CAPACITOR 0.22uF
 C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1907 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z

C1909 QEZ0552-127 E CAPACITOR 120uF

 C1910 QFZ9078-473 MPP CAPACITOR 0.047uF

C1922 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1924 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1925 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1926 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1929 QFKA2JK-103 MM CAPACITOR 0.01uF 630V K
C1931 QCZ0364-681 C CAPACITOR 680pF
C1932 NDC31HJ-221X C CAPACITOR 220pF 50V J
C1941 QCZ0364-561 C CAPACITOR 560pF
C1942 QEZ0203-107 E CAPACITOR 100uF 160V M
C1944 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1945 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1946 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C1947 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1948 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C1949 NDC31HJ-471X C CAPACITOR 470pF 50V J
C1976 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1977 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1978 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1979 QETN1AM-227Z E CAPACITOR 220uF 10V M

 C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1993 QCZ9079-152 C CAPACITOR 1500pF AC250V M

R1002 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1003 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1004 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1102 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1103 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R1109 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1110 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1111 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1112 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R1113 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1120 NRSA63J-391X MG RESISTOR 390Ω 1/16W J

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R1121 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1159 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R1301 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1302 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1304 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1305 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1306 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1307 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1308 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1312 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1313 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1314 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1321 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1322 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1323 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1324 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1326 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1327 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J
R1341 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1345 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R1346 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R1353 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R1354 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1355 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1356 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1357 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1358 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1359 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1360 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1361 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1362 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R1363 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1364 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1365 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R1366 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1367 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1368 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1372 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1374 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1421 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1423 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1424 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1425 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1426 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1429 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1430 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1431 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1432 QRE121J-3R9Y C RESISTOR 3.9Ω 1/2W J
R1433 QRE121J-3R9Y C RESISTOR 3.9Ω 1/2W J
R1436 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1440 QRE121J-471Y C RESISTOR 470Ω 1/2W J
R1441 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1442 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1443 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1453 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1501 IM-BW BUS WIRE
R1502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1503 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1525 QRL029J-680 OMF RESISTOR 68Ω 2W J
R1526 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1529 QRL039J-221 OMF RESISTOR 220Ω 3W J
R1531 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1532 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

 R1551 QRZ9011-1R0 FUSI RESISTOR 1Ω 1/2W J

R1552 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1554 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R1571 QRE121J-272Y C RESISTOR 2.7kΩ 1/2W J
R1573 QRT029J-2R2 MF RESISTOR 2.2Ω 2W J

1-4 (No.52029C)

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R1574 QRT029J-2R2 MF RESISTOR 2.2Ω 2W J
R1576 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R1577 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1578 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1581 QRE121J-182Y C RESISTOR 1.8kΩ 1/2W J
R1582 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1583 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R1584 IM-BW BUS WIRE
R1651 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1652 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1653 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1654 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1655 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1656 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1657 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1658 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1659 QRE121J-4R7Y C RESISTOR 4.7Ω 1/2W J
R1660 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1661 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1662 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1664 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1665 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1666 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1667 QRE121J-101Y C RESISTOR 100Ω 1/2W J
R1668 QRT029J-5R6 MF RESISTOR 5.6Ω 2W J
R1704 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1705 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1706 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1707 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1708 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1710 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1711 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1712 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1713 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1714 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1715 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1716 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1718 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1719 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1720 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1721 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1723 QRL039J-270 OMF RESISTOR 27Ω 3W J
R1725 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1726 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1727 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1728 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1729 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1730 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1731 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1736 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1737 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1738 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1739 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1740 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R1741 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1742 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1746 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1747 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1748 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1749 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1772 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1773 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1791 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1792 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1793 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1794 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1795 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1796 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1797 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R1802 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1806 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1807 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R1810 QRG01GJ-560 OMF RESISTOR 56Ω 1W J
R1811 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1815 QRE121J-181Y C RESISTOR 180Ω 1/2W J
R1816 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R1817 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1901 QRF074K-4R7 UNF WW RESISTOR 4.7Ω 7W K
R1903 QRL029J-104 OMF RESISTOR 100kΩ 2W J
R1906 QRL029J-104 OMF RESISTOR 100kΩ 2W J
R1921 QRE121J-1R8Y C RESISTOR 1.8Ω 1/2W J
R1922 QRE121J-221Y C RESISTOR 220Ω 1/2W J
R1923 QRM034J-R18 MP RESISTOR 0.18Ω 3W J
R1924 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R1925 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R1928 QRL039J-683 OMF RESISTOR 68kΩ 3W J
R1933 QRE121J-4R7Y C RESISTOR 4.7Ω 1/2W J
R1934 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R1935 QRE121J-392Y C RESISTOR 3.9kΩ 1/2W J
R1974 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1976 QRL029J-120 OMF RESISTOR 12Ω 2W J
R1977 QRE121J-122Y C RESISTOR 1.2kΩ 1/2W J
R1978 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1979 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1980 QRL029J-183 OMF RESISTOR 18kΩ 2W J

 R1991 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K

L1001 QQL244K-8R2Z COIL 8.2uH K
L1101 QQL244J-2R2Z COIL 2.2uH J
L1103 QQL244K-8R2Z COIL 8.2uH K
L1351 IM-BW BUS WIRE
L1352 IM-BW BUS WIRE
L1353 IM-BW BUS WIRE
L1354 IM-BW BUS WIRE
L1551 QQLZ034-300 COIL 30uH
L1552 IM-BW BUS WIRE
L1701 QQL244J-5R6Z COIL 5.6uH J
L1941 QQL26AK-820Z COIL 82uH K
L1942 QQL244J-4R7Z COIL 4.7uH J
L1943 QQL244J-4R7Z COIL 4.7uH J
T1501 CE40203-00CJ1 DRIVE TRANSF

 T1921 QQS0161-001 SW TRANSF

CN100S QGA2501C5-03Z CONNECTOR W-B (1-3)
CN100T QJL001-052210 SIN CR B-B WIRE
CN100U CHGC04-260 CONNECTOR ASSY
CN10E1 CHGT0015-0A CONNECTOR ASSY
CN10HV QGZ5004C1-04 CONNECTOR (1-4)
CN10PW QGA7901C1-02 CONNECTOR W-B (1-2)
CN10S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)
CP1701 IM-BW BUS WIRE

 CP1981 ICP-N50-Y IC PROTECTOR 2.0A
 CP1982 ICP-N75-Y IC PROTECTOR 2.7A
 F1901 QMF51E2-3R15J4 FUSE 3.15A AC250V

FC1901 CEMG002-001Z FUSE CLIP (x2)
H1001 LC31334-002A HEAT SINK/AL-F/
H1002 LC31722-001A HEAT SINK/FE-P/
H1003 LC32126-001A HEAT SINK/FE-P/
H1006 CEHE007-001KH HEAT SINK
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK
J1004 QNN0281-002 PIN JACK
J1005 QNS0197-001 3.5 JACK
K1001 IM-BW BUS WIRE
K1351 QQR0621-002Z FERRITE BEADS
K1421 QQR1113-001Z FERRITE BEADS
K1701 IM-BW BUS WIRE
K1703 IM-BW BUS WIRE

(No.52029C)1-5

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

K1704 IM-BW BUS WIRE
K1901 QQR1113-001Z FERRITE BEADS
K1902 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS

 LF1901 QQR0673-002 LINE FILTER

S1701 QSW0619-003Z TACT SWITCH
S1702 QSW0619-003Z TACT SWITCH
S1703 QSW0619-003Z TACT SWITCH
S1704 QSW0619-003Z TACT SWITCH
S1705 QSW0619-003Z TACT SWITCH

 S1901 QSW0750-001 PUSH SWITCH

SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER

 SK1351 CE42554-001 C R T SOCKET

TH1901 QAD0121-9R0 P THERMISTOR 9Ω
TU1001 QAU0246-002 TUNER

 VA1901 ERZV10V621CS ZNR

W1155 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1231 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1422 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1590 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1591 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1653 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 C RESONATOR
Y1302 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1372 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1373 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1374 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1704 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1973 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

PRINTED WIRING BOARD PARTS LIST
[AV-1416EE/SK]

Since there are many differences in MAIN PW BOARD and CRT SOCKET PW BOARD, lists of all the parts are described here.

MAIN PW BOARD(SCG-1463A-H2)

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

IC1301 NN5198K IC
IC1301 NN5198K IC
IC1421 AN5522 IC
IC1651 AN5265 IC
IC1701 MN1873287JK1 IC(MCU)
IC1702 AT24C08-21DMG3 IC (SERVICE)
IC1703 L78LR05E-MA IC
IC1704 GP1UM281QK IR DETECT UNIT 38kHz
IC1921 STR-W5753A/F5 IC
IC1971 BA17809T IC
IC1972 BA17805T IC

Q1102 2SC5083/L-P/-T TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SD601A/QR/-X TRANSISTOR
Q1401 DTC124ESA-T DIGI TRANSISTOR
Q1402 2SD601A/QR/-X TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR
Q1522 2SD2658LS-YB11 POW TRANSISTOR
Q1571 2SA1208/ST/Z1-T TRANSISTOR
Q1572 2SD601A/QR/-X TRANSISTOR
Q1651 2SD601A/QR/-X TRANSISTOR
Q1652 2SD601A/QR/-X TRANSISTOR
Q1653 2SB709A/QR/-X TRANSISTOR
Q1702 2SD601A/QR/-X TRANSISTOR
Q1703 2SD601A/QR/-X TRANSISTOR
Q1708 UN2212-X DIGI TRANSISTOR
Q1710 UN2212-X DIGI TRANSISTOR

1-6 (No.52029C)

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

Q1803 2SC1815/YG/-T TRANSISTOR
Q1804 2SD601A/QR/-X TRANSISTOR
Q1974 2SA966/OY/-T TRANSISTOR
Q1975 UN2212-X DIGI TRANSISTOR

D1001 MTZJ33A-T2 Z DIODE
D1102 IM-BW BUS WIRE
D1301 MTZJ9.1B-T2 Z DIODE
D1302 MTZJ9.1B-T2 Z DIODE
D1303 MA3091/M/-X Z DIODE
D1305 AK04-T2 SB DIODE
D1306 QRE121J-121Y C RESISTOR 120Ω 1/2W J
D1341 MA111-X SI DIODE
D1421 MTZJ75-T2 Z DIODE
D1423 1SR124-400A-T2 SI DIODE
D1425 MA111-X SI DIODE
D1427 MTZJ27B-T2 Z DIODE
D1501 MTZJ6.8C-T2 Z DIODE
D1551 RGP10J-5025-T3 SI DIODE
D1552 RGP10J-5025-T3 SI DIODE
D1553 MTZJ9.1B-T2 Z DIODE
D1554 MA111-X SI DIODE
D1571 MTZJ7.5S-T2 Z DIODE
D1581 MTZJ20B-T2 Z DIODE
D1582 RGP10J-5025-T3 SI DIODE
D1651 MA111-X SI DIODE
D1652 MTZJ12C-T2 Z DIODE
D1653 MA111-X SI DIODE

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

D1654 MTZJ12C-T2 Z DIODE
D1655 MA111-X SI DIODE
D1656 MA111-X SI DIODE
D1657 MA111-X SI DIODE
D1703 SPR-39MVWF LED RED-GREEN
D1707 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1920 1SS133-T2 SI DIODE
D1921 RGP10J-5025-T3 SI DIODE
D1925 RGP10J-5025-T3 SI DIODE
D1927 MTZJ36A-T2 Z DIODE
D1928 MTZJ3.3A-T2 Z DIODE
D1930 RGP10M-5010-T3 SI DIODE
D1931 MA111-X SI DIODE
D1933 MTZJ16C-T2 Z DIODE
D1941 RU3AM-LFC4 SI DIODE
D1942 RGP30B-F1 SI DIODE
D1943 RGP10J-5025-T3 SI DIODE
D1982 MA111-X SI DIODE
D1983 MA111-X SI DIODE

C1001 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1008 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1103 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C1112 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1115 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1116 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1117 QFV71HJ-224Z MF CAPACITOR 0.22uF 50V J
C1119 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1120 NDC31HJ-121X C CAPACITOR 120pF 50V J
C1121 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1122 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1162 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1301 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C1302 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1303 NDC31HJ-100X C CAPACITOR 10pF 50V J
C1304 QFV71HJ-474Z MF CAPACITOR 0.47uF 50V J
C1305 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1306 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1307 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1308 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1309 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1310 NDC31HJ-221X C CAPACITOR 220pF 50V J
C1311 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1312 QENC1HM-474Z BP E CAPACITOR 0.47uF 50V M
C1313 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C1314 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1315 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1316 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1317 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C1321 NDC31HJ-120X C CAPACITOR 12pF 50V J
C1322 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C1323 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C1324 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1325 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1326 NCS21HJ-221X C CAPACITOR 220pF 50V J
C1341 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1365 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1366 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1367 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1401 QFV71HJ-474Z MF CAPACITOR 0.47uF 50V J

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

C1423 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C1424 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C1426 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C1427 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1428 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1429 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1430 QFN32AJ-472Z M CAPACITOR 4700pF 100V J
C1433 QEHR1HM-475Z E CAPACITOR 4.7uF 50V M
C1435 QETM1EM-228 E CAPACITOR 2200uF 25V M
C1436 QFV71HJ-334Z MF CAPACITOR 0.33uF 50V J
C1437 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1501 QETN1AM-477Z E CAPACITOR 470uF 10V M
C1502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1523 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1525 QFZ0200-782 MPP CAPACITOR 7800pF 1.5kV H
C1526 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1527 QFZ0199-514 MPP CAPACITOR 0.51uF
C1529 QFN32AJ-102Z M CAPACITOR 1000pF 100V J
C1531 QEZ0203-107 E CAPACITOR 100uF 160V M
C1552 QETM1VM-108 E CAPACITOR 1000uF 35V M
C1554 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C1555 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C1571 QETN1AM-107Z E CAPACITOR 100uF 10V M
C1572 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1581 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1652 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1653 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1654 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1655 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1656 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C1657 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1658 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1659 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1663 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1664 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1665 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1705 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1706 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1707 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1708 QETN1AM-108Z E CAPACITOR 1000uF 10V M
C1709 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1710 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1711 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1713 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1716 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1717 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1718 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1719 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1720 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1721 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C1722 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1723 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1724 NDC31HJ-560X C CAPACITOR 56pF 50V J
C1728 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1729 NDC31HJ-181X C CAPACITOR 180pF 50V J
C1730 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1741 IM-BW BUS WIRE
C1742 IM-BW BUS WIRE
C1743 IM-BW BUS WIRE
C1744 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1805 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1806 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1811 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1841 NCB31HK-152X C CAPACITOR 1500pF 50V K

 C1901 QFZ9078-224 MPP CAPACITOR 0.22uF
 C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1907 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z

(No.52029C)1-7

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

C1909 QEZ0552-127 E CAPACITOR 120uF

 C1910 QFZ9078-473 MPP CAPACITOR 0.047uF

C1922 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1924 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1925 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1926 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1929 QFKA2JK-103 MM CAPACITOR 0.01uF 630V K
C1931 QCZ0364-681 C CAPACITOR 680pF
C1932 NDC31HJ-221X C CAPACITOR 220pF 50V J
C1941 QCZ0364-561 C CAPACITOR 560pF
C1942 QEZ0203-107 E CAPACITOR 100uF 160V M
C1944 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1945 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1946 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C1947 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1948 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C1949 NDC31HJ-471X C CAPACITOR 470pF 50V J
C1976 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1977 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1978 QETN1EM-227Z E CAPACITOR 220uF 25V M
C1979 QETN1AM-227Z E CAPACITOR 220uF 10V M

 C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1993 QCZ9079-152 C CAPACITOR 1500pF AC250V M

R1002 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1003 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1004 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1102 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1103 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R1109 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1110 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1111 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R1112 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R1113 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1120 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1121 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1159 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R1301 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1302 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1304 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1305 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1306 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1307 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R1308 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R1312 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1313 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1314 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1321 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R1322 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1323 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1324 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1326 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1327 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J
R1341 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1345 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R1372 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1374 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1421 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1423 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1424 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1425 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R1426 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1429 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1430 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1431 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1432 QRE121J-3R9Y C RESISTOR 3.9Ω 1/2W J
R1433 QRE121J-3R9Y C RESISTOR 3.9Ω 1/2W J

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R1436 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R1440 QRE121J-471Y C RESISTOR 470Ω 1/2W J
R1441 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1442 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1443 QRE121J-1R0Y C RESISTOR 1Ω 1/2W J
R1453 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R1501 IM-BW BUS WIRE
R1502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1503 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1525 QRL029J-680 OMF RESISTOR 68Ω 2W J
R1526 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1529 QRL039J-221 OMF RESISTOR 220Ω 3W J
R1531 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1532 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

 R1551 QRZ9011-1R0 FUSI RESISTOR 1Ω 1/2W J

R1552 QRJ146J-2R2X UNF C RESISTOR 2.2Ω 1/4W J
R1554 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R1571 QRE121J-272Y C RESISTOR 2.7kΩ 1/2W J
R1573 QRT029J-2R2 MF RESISTOR 2.2Ω 2W J
R1574 QRT029J-2R2 MF RESISTOR 2.2Ω 2W J
R1576 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R1577 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R1578 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1581 QRE121J-182Y C RESISTOR 1.8kΩ 1/2W J
R1582 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R1583 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R1584 IM-BW BUS WIRE
R1651 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1652 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1653 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R1654 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R1655 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1656 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R1657 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1658 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1659 QRE121J-4R7Y C RESISTOR 4.7Ω 1/2W J
R1660 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1661 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1662 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1664 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R1665 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1666 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1667 QRE121J-101Y C RESISTOR 100Ω 1/2W J
R1668 QRT029J-5R6 MF RESISTOR 5.6Ω 2W J
R1704 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1705 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1706 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1707 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1708 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1710 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1711 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1712 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1713 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1714 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1715 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1716 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1718 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1719 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1720 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1721 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1723 QRL039J-270 OMF RESISTOR 27Ω 3W J
R1725 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1726 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1727 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1728 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1729 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R1730 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1731 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1736 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J

1-8 (No.52029C)

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R1737 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R1738 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1739 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1740 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R1741 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1742 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R1746 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1747 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R1748 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R1749 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1772 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R1773 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R1791 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1792 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1793 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1794 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1795 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1796 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R1797 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R1802 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R1806 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R1807 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R1810 QRG01GJ-560 OMF RESISTOR 56Ω 1W J
R1811 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R1815 QRE121J-181Y C RESISTOR 180Ω 1/2W J
R1816 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R1817 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R1901 QRF074K-4R7 UNF WW RESISTOR 4.7Ω 7W K
R1903 QRL029J-104 OMF RESISTOR 100kΩ 2W J
R1906 QRL029J-104 OMF RESISTOR 100kΩ 2W J
R1921 QRE121J-1R8Y C RESISTOR 1.8Ω 1/2W J
R1922 QRE121J-221Y C RESISTOR 220Ω 1/2W J
R1923 QRM034J-R18 MP RESISTOR 0.18Ω 3W J
R1924 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R1925 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R1928 QRL039J-683 OMF RESISTOR 68kΩ 3W J
R1933 QRE121J-4R7Y C RESISTOR 4.7Ω 1/2W J
R1934 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R1935 QRE121J-392Y C RESISTOR 3.9kΩ 1/2W J
R1974 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R1976 QRL029J-120 OMF RESISTOR 12Ω 2W J
R1977 QRE121J-122Y C RESISTOR 1.2kΩ 1/2W J
R1978 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R1979 QRL039J-470 OMF RESISTOR 47Ω 3W J
R1980 QRL029J-183 OMF RESISTOR 18kΩ 2W J

 R1991 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

FC1901 CEMG002-001Z FUSE CLIP (x2)
H1001 LC31334-002A HEAT SINK/AL-F/
H1002 LC31722-001A HEAT SINK/FE-P/
H1003 LC32126-001A HEAT SINK/FE-P/
H1006 CEHE007-001KH HEAT SINK
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK
J1004 QNN0281-002 PIN JACK
J1005 QNS0197-001 3.5 JACK
K1001 IM-BW BUS WIRE
K1421 QQR1113-001Z FERRITE BEADS
K1701 IM-BW BUS WIRE
K1703 IM-BW BUS WIRE
K1704 IM-BW BUS WIRE
K1901 QQR1113-001Z FERRITE BEADS
K1902 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS

 LF1901 QQR0673-002 LINE FILTER

S1701 QSW0619-003Z TACT SWITCH
S1702 QSW0619-003Z TACT SWITCH
S1703 QSW0619-003Z TACT SWITCH
S1704 QSW0619-003Z TACT SWITCH
S1705 QSW0619-003Z TACT SWITCH

 S1901 QSW0750-001 PUSH SWITCH

SF1102 QAX0666-002 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
TH1901 QAD0121-9R0 P THERMISTOR 9Ω
TU1001 QAU0246-002 TUNER

 VA1901 ERZV10V621CS ZNR

W1155 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1231 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1422 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1590 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1591 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
W1653 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z X-TAL
X1701 QAX0307-001 C RESONATOR
Y1302 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1372 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1373 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1374 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1704 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
Y1973 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

L1001 QQL244K-8R2Z COIL 8.2uH K
L1101 QQL244J-2R2Z COIL 2.2uH J
L1103 QQL244K-8R2Z COIL 8.2uH K
L1551 QQLZ034-300 COIL 30uH
L1552 IM-BW BUS WIRE
L1701 QQL244J-5R6Z COIL 5.6uH J
L1941 QQL26AK-820Z COIL 82uH K
L1942 QQL244J-4R7Z COIL 4.7uH J
L1943 QQL244J-4R7Z COIL 4.7uH J
T1501 CE40203-00CJ1 DRIVE TRANSF

 T1921 QQS0161-001 SW TRANSF

CN100S QGA2501C5-03Z CONNECTOR W-B (1-3)
CN100T QJB003-052220 SIN ID C-B WIRE
CN100U QJB003-042624 SIN ID C-B WIRE
CN10HV QGZ5004C1-04 CONNECTOR (1-4)
CN10PW QGA7901C1-02 CONNECTOR W-B (1-2)
CN10S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)
CP1701 IM-BW BUS WIRE

 CP1981 ICP-N50-Y IC PROTECTOR 2.0A
 CP1982 ICP-N75-Y IC PROTECTOR 2.7A
 F1901 QMF51E2-3R15J4 FUSE 3.15A AC250V

CRT SOCKET PW BOARD(SCG-3002A-CK)

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

Q3351 STC344 TRANSISTOR
Q3351 STC344 TRANSISTOR
Q3352 STC344 TRANSISTOR
Q3353 STC344 TRANSISTOR

C3352 QFZ0097-103 MM CAPACITOR 0.01uF
C3354 QDC31HJ-271 C CAPACITOR 270pF 50V J
C3355 QDC31HJ-221 C CAPACITOR 220pF 50V J
C3356 QDC31HJ-331 C CAPACITOR 330pF 50V J
C3357 QETM1AM-477 E CAPACITOR 470uF 10V M

R3345 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3346 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3353 QRE142J-151 C RESISTOR 150Ω 1/4W J
R3354 QRE142J-331 C RESISTOR 330Ω 1/4W J
R3355 QRE142J-331 C RESISTOR 330Ω 1/4W J
R3356 QRE142J-331 C RESISTOR 330Ω 1/4W J
R3357 QRE142J-101 C RESISTOR 100Ω 1/4W J
R3358 QRE142J-101 C RESISTOR 100Ω 1/4W J
R3359 QRE142J-101 C RESISTOR 100Ω 1/4W J
R3360 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K

(No.52029C)1-9

AV-1415EE
AV-1416EE

 Ref. No. PARTS No. PARTS NAME DESCRIPTION

R3361 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R3362 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R3363 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3364 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3365 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R3366 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J
R3367 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J
R3368 QRE142J-182 C RESISTOR 1.8kΩ 1/4W J

L3354 CH41005-H-5C BUS WIRE

CN300T QGA2501C5-05 CONNECTOR W-B (1-5)
CN300U QGA2501C5-04 CONNECTOR W-B (1-4)
CN30E1 CHGT0015-0A CONNECTOR ASSY
K3351 QQR0621-002 FERRITE BEAD

 SK3351 CE42554-001 C R T SOCKET

PACKING PARTS LIST

PACKING (Page 54)

 Ref No.

AV-1415EE AV-1415EE/SK

2 GG20025-001A-H GG20025-003A-H CORNER LABEL 2pcs in 1set

11 BT-54012-2 BT-54012-3H WARRANTY CARD

PARTS No.

PARTS NAME DESCRIPTION

 Ref No.

AV-1415EE AV-1416EE/SK

PARTS No.

PARTS NAME DESCRIPTION

2 GG20025-001A-H LC21271-001A-H CORNER LABEL

 8 LCT1195-001A-H LCT1341-001A-H INST BOOK

11 BT-54012-2 BT-54012-3H WARRANTY CARD

1-10 (No.52029C)

AV-1415EE
AV-1416EE

(No.52029C)1-11

AV-1415EE
AV-1416EE

VICTOR COMPANY OF JAPAN, LIMITED

AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan

(No.52029C)

Printed in Japan

200303WPC
