JVC LCT2518-001A-A, 1208TSH-II-IM User Manual

LCD Television Users Guide

1080p HDTV

LT-32P300
LT-42P300
LT-42PM30

32" class (31.5" Diagonal)

42" class (42" Diagonal)

42" class (42" Diagonal)

POWER

TIMER

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

+

RETURN

TUNE

TV

0

– CH + – VOL +

iPod MUTING

B

U

A

N

C

OK

E

K

M

F

A

T

V

C

O

E

R

P

I

T

S

E

A

DVR

PCON

STATUS

VIDEO

GUIDE

SOUND

SUB CH ML/MTS DISPLAY

SUB T.

TV/VCR

iTV

RM-C1485

TV

As an “ENERGY STAR®” partner, JVC has determined that
this product or product model meets the “ENERGY STAR®”
guidelines for energy efficiency.

Please read the important notice for energy efficiency on page 7.

Important Note:

In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user’s guide in a convenient place for future reference. Keep the carton
and original packaging for future use.

Serial Number:

Model Number:

LCT2518-001A-A

1208TSH-II-IM

Warnings

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do
not remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service
personnel.

The lightning flash with arrowhead
symbol, within an equilateral
triangle is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.

The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair
it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal of these materials
may be regulated in your community due to environmental considerations. For disposal
or recycling information, please contact your local authorities or for USA, the Electronic

Industries Alliance: http://www.eiae.org

Do not attempt to service the product yourself

Caution
To prevent electrical shock, do not open the cabinet.
There are no user serviceable parts inside.
Please refer to qualifi ed service personnel for repairs.

2

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

16) Place the television on a stable, flat surface. Failure to do so can result in the television

falling, causing injury.

17) Do not allow young children to play around or on the television. Do not hang from the TV.

Failure to do so can result in the television falling, causing injury.

18) Do not allow young children to play with the plastic bag that came with the television when

you unpacked it. Failure to do so can result in suffocation, causing injury.

19) Avoid improper installation and never position the unit where good ventilation is

impossible. When installing this TV, distance recommendations must be maintained
between the set and the wall, as well as inside a tightly enclosed area or piece of furniture.
Keep to the minimum distance guidelines shown for safe operation.

150 mm

5 7/8 in

200 mm

7 7/8 in

150 mm

5 7/8 in

200 mm

7 7/8 in

50 mm

2 in

3

Important Safety Instructions

20) Cautions for installation
— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way.
— The TV will generate a slight amount of heat during operation. Ensure that

sufficient space is available around the TV to allow satisfactory cooling.

— Have two people remove the TV from the box with the screen facing away

from you. It's possible your clothing, (such as a belt buckle or button) may
scratch the front of the TV. Do the same when moving the TV to another
location.

21) When attaching to a wall, use the optional JVC wall mounting unit.
For LT-32P300: JVC-XUF-2637 LCD FLAT WALL MOUNT
For LT-42P300 / LT-42PM30: JVC-XUF-2637 LCD FLAT WALL MOUNT
Caution
— Consult qualified installers.
— See the included manual on mounting procedures.
— JVC is not responsible for damages or injuries due to improper mounting.
— Use with other wall mounting unit is capable of resulting in instability or causing possible

injury.

22) Make enough room for inserting and removing the power plug. Place the TV as close
to the outlet as possible. The main power supply for this TV is controlled by inserting or
removing the power plug.

23) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

24) When this TV is connected to the wall outlet, it is always on standby even when all the LED

lamps are not lit. To shut down the TV, unplug the TV from the wall outlet.

FCC Notice:

Caution: Changes or modifi cations not expressly approved by party responsible for

compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

4

Table of Contents

Warnings . . . . . . . . . . . . . . . . . . 2

Important Safety Instructions . . . 3

Getting Started

Key Features . . . . . . . . . . . . . . . 6

Logos & Licenses . . . . . . . . . 7

Package Contents . . . . . . . . . 8

Basics

TV Basic Controls . . . . . . . . . . . 13

Remote Control . . . . . . . . . . . . . 18

Initial Setup . . . . . . . . . . . . . . . 22

Advanced

Customizing your TV . . . . . . . 24

Picture . . . . . . . . . . . . . . . . . 26

Video Status . . . . . . . . . . . . . . . . 26

Color Temp . . . . . . . . . . . . . . . . 27

Color Management . . . . . . . . . . . . . 27

Dynamic Gamma . . . . . . . . . . . . . . 27

Smart Picture . . . . . . . . . . . . . . . . 27

Digital VNR . . . . . . . . . . . . . . . . . 27

MPEG NR . . . . . . . . . . . . . . . . . 27

Natural Cinema . . . . . . . . . . . . . . . . . 27

Video Reset . . . . . . . . . . . . . . . . . 27

Display . . . . . . . . . . . . . . . . 28

Video Input Label . . . . . . . . . . . . . . 28

Photo Viewer . . . . . . . . . . . . . . . . 28

Aspect . . . . . . . . . . . . . . . . . . . . 30

TV . . . . . . . . . . . . . . . . . 31

Closed Caption . . . . . . . . . . . . . . . . 31

C.C. Type . . . . . . . . . . . . . . . . . . . 31

C.C. Setting . . . . . . . . . . . . . . . . . . . 31

Tuner Mode . . . . . . . . . . . . . . . . 32

Auto Scan . . . . . . . . . . . . . . . . 32

Add Channel . . . . . . . . . . . . . . . . 32

Edit Channel . . . . . . . . . . . . . . . . 33

V-Chip . . . . . . . . . . . . . . . . 33

Password . . . . . . . . . . . . . . . . 34

MPAA . . . . . . . . . . . . . . . . 35

Can. Eng. . . . . . . . . . . . . . . . . 36

Can. Fre. . . . . . . . . . . . . . . . . 36

TVPG . . . . . . . . . . . . . . . . . 37

Guide . . . . . . . . . . . . . . . . 37

PC . . . . . . . . . . . . . . . . . 38

Auto Adjustment . . . . . . . . . . . . . 38

Phase Adjustment . . . . . . . . . . . . 38

PC H-Position . . . . . . . . . . . . . . . . 38

PC V-Position . . . . . . . . . . . . . . . . 38

Reset . . . . . . . . . . . . . . . . . . 38

Sound . . . . . . . . . . . . . . . . . 39

MTS . . . . . . . . . . . . . . . . 39

Digital Audio (ML) . . . . . . . . . . . . 39

Surround . . . . . . . . . . . . . . . . 39

Sound Status . . . . . . . . . . . . . . . . 39

Audio Reset . . . . . . . . . . . . . . . . 39

Power . . . . . . . . . . . . . . . . . 40

Power Indicator . . . . . . . . . . . . 40

Illumination . . . . . . . . . . . . . . . . 40

Setting . . . . . . . . . . . . . . . . . 41

Plug-In Menu . . . . . . . . . . . . . . . . 41

Time Zone . . . . . . . . . . . . 41

D.S.T. . . . . . . . . . . . . . . . . 41

Language . . . . . . . . . . . . . . . . 41

Noise Mute . . . . . . . . . . . . 41

Front Panel Lock . . . . . . . . . . . . 41

Transparency . . . . . . . . . . . . 41

Auto Shut Off . . . . . . . . . . . . . . . . 41

Control with HDMI . . . . . . . . . . . . . 42

System Info . . . . . . . . . . . . . . . . 42

Auto Demo . . . . . . . . . . . . 42

Optical Out . . . . . . . . . . . . 43

PC Smart Input . . . . . . . . . . . 43

Sync Mode . . . . . . . . . . . . . . 43

Enjoy Movies/Music from your

iPod . . . . . . . . . . . . . . . . . . 44

Programming Your Remote . . . . 51

Etc.

Programming Codes . . . . . . . 53

Connecting Your Devices . . . . . 58

Troubleshooting . . . . . . . . . . . . 64

Specifi cations . . . . . . . . . . . . 66

Warranty . . . . . . . . . . . . 67

5

Key Features

Your JVC TV is equipped with many features. Here is some key features
highlighted in detail.

1 Simple playback of video and music on

TV. You can charge your iPod. You
can watch a program while listening
to the iPod (source of program must
be from TV’s Internal Tuner). You
can view photos from the iPod while
listening to the iPod.

2 Stunning picture quality via 1920x1080 Full HD panel.

Dynamic Gamma and Color Management give further
fi ne tuned picture reproduction. Smart Picture adjusts the
best possible picture quality automatically scene by scene
based on the incoming signal from any source!

3 JVC exclusive oblique cone speakers provide excellent

TV sound quality. OmniSurround sound provides you 4
different settings based on the program you are watching.
The equalizer will fi ne tune your listening preferences.

Dock Adapter

Dock

4 Full connectivity with 3 HDMI, 2 Component, 1 S-video and others. The variety of

connections are explained in pages. 58 to 63.

x 3 x 2

x 1

5 Aspect mode will show every pixel you are getting in High Defi nition. The Full Native mode

will show 100% of 1080p. Full – with slight overscan. Panorama, Cinema will fi ll the screen
with various aspect settings.

Full or Widescreen Mode

6

Logos & Licenses

Getting started

As an “ENERGY STAR®” partner, JVC has determined that
this product or product model meets the “ENERGY STAR
guidelines for energy efficiency.

This JVC Television is factory set to “Home” mode, which is optimized for normal home viewing.
This setting reduces power consumption to help the environment and to comply with ENERGY

®

qualifi cation.

STAR

Enabling certain features and functionality in this TV (e.g., Video Status) may increase its energy
consumption, possibly beyond the limits required for ENERGY STAR

iPod is a trademark of Apple Inc.,
registered in the U.S. and other countries.

Manufactured under license from Dolby Laboratories. "Dolby", and
the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI Logo and High-Defi nition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.

®

qualifi cation.

®

”

Notice:

• The open source software is embedded in this product. For more information, please go to:
http://software.jvc.com/opensource/lnx/DP/08_AtscQam_T/download.html

7

Package Contents

Television x 1

Remote Control x 1

POWER

TIMER

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

+

RETURN

TUNE

TV

0

– CH + – VOL +

iPod MUTING

B

U

A

N

C

OK

E

K

M

F

A

T

V

C

O

E

R

P

I

T

S

E

A

DVR

PCON

STATUS

VIDEO

GUIDE

SOUND

SUB CH ML/MTS DISPLAY

SUB T.

TV/VCR

iTV

RM-C1485

TV

Bottom Cover x 1

AA Batteries x 2

+

+

AA Alkaline

AA Alkaline

–

–

Screw x 1

Insert the batteries

Use two “AA” batteries (included).

Place the "–" end in the unit first, making sure the "+" and "–" markings are correct. Place the
"–" end in the unit first.

If this symbol is shown, it is only
valid in the European Union

8

Caring for the frame and stand

Your TV has a glossy frame and stand which have protection sheets attached to them. Peel
them off before use, but only after the TV has been properly placed. Take care with handling
the glossy frame and stand because these surfaces are delicate.

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.
If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly
moistened with water. You can add a few drops of mild liquid detergent to the water to help
remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Frame

Stand

Getting started

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a
soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner
and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

• DO NOT apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the

screen. These will remove the coating layer and cause discolorations.

• DO NOT push or hit the screen. This could cause scratches on the screen surface and image

distortions.

9

Package Contents

Avoiding Temporary Burn-in

Displaying fi xed images for extended periods of time can leave a subtle but temporary burn-in
image on your screen. To avoid this, mix your viewing pattern.

Examples include, but are not limited to the following:

• Stock-market report bars

• Shopping channel logos and pricing

displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style

images

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or

digital television tuners/converters

TV on

For example...

TV off

XYZ XYZ

10

Install your TV

To prevent the TV from falling, thread the belt through the hole on the back of the stand and
secure it to the TV rack.

Hole

Belt and screw (not included)

Tidying the cables

A cable holder which keeps your connection cables tidy is attached to the back of the stand.

Getting started

Connect the stand

The LT-32P300 TV stand is not attached to the TV when you purchased it. Please follow the

steps below on how to connect the stand to the TV.

1) Insert the TV stand onto the TV.

2) Tighten the 5 screws to the back of the

TV.

11

Package Contents

Disconnecting the stand

If you disconnect the stand, attach the bottom cover and the screw (supplied) into the hole.

1) Place the TV face down on a soft cloth on a table.

2) Remove the screws from the back of the TV.

3) Pull out the stand from the TV.

4) Cover the hole with the supplied bottom cover and tighten the screw.

Notes:

• To re-install the stand, reverse the procedure from 4) to 1).

• If you fi nd it diffi cult to remove the screws from inset screw wells, use a magnetized
screwdriver.

12

TV Basic Controls

Front Panel

1

3

Side Panel

4

2

Diffuser Illumination

1

Dock

2

Notes:

• Do not use unreasonable force to the
Dock.

• When not using the Dock, close the
cover.

• Do not touch the connector pins of the
Dock or the iPod terminal pins.

• Do not put different devices on the
Dock. It may cause a connection
failure.

Remote Control Sensor

3

Power Lamp

4

Basics

INPUT

MENU

1

2

CHANNEL

OK

VOLUME

BACK

5

POWER

PHOTO VIEWER

3

4

6

Input

1

Change the input

MENU

2

Used to access the TV’s onscreen
menus.

+CHANNEL–

3

Move sequentially through the
channels.

+VOLUME–

4

Raises or lowers the volume.

POWER

5

Turn the TV on or off.

Photo Viewer Connector

6

Note:

• Do not use Photo Viewer connector
to connect the iPod

13

TV Basic Controls

Rear Panel

9

8

2

3

5

7

4

10

1

6

75 Ω

(VHF/UHF)

INPUT 1 INPUT 2 INPUT 3

14

HDMI™ Connector

1

* This is used when you are using

HDMI analog audio

Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television. Some of the
connection terminals are color coded for easy connection with the proper cables.

To find the best possible connection that your device can use, see pages 16 - 17.

For more detailed information about connecting external devices, see pages 58 - 63.

Basics

1

2

3

5

6

7

8

HDMI
(INPUT 1, 2, or 3)

HDMI ANALOG AUDIO

Composite / Component

4

(INPUT 4 or 5)

S-Video

Antenna / Cable

DIGITAL AUDIO
OPTICAL OUT

AUDIO OUT

DVD Player

Video Camera

PC (with HDMI)

Audio System

STB (Digital Cable,
satellite) Tuner Box

Game Console

9

10

D-SUB

USB type B (for PC)
See page 50.

PC

15

TV Basic Controls

Video

Best

Video Connection Connection Cable TV Connection

HDMI HDMI Cable INPUT 1, 2 or 3

Good

Audio

Best

DVI + Audio

Component

Video + Audio

S-Video + Audio

Composite

Video + Audio

Audio Connection Connection Cable TV Connection

OPTICAL INPUT

DVI – HDMI Cable,

Audio Cable

Component

Video + Audio INPUT 4 or 5

S-Video Cable,

Audio Cable

Composite

Video + Audio INPUT 4 or 5

OPTICAL AUDIO

Cable

Input 1 +

HDMI ANALOG AUDIO

INPUT 4 +

AUDIO Input

DIGITAL AUDIO

OPTICAL OUT

16

Good

AUDIO INPUT

(L / R)

Audio Cable

AUDIO OUT

(L / R)

Compatible Signal Notes

Input

• HDMI (Digital)
SD: 480i, 480p
HD : 720p, 1080i, 1080p/24Hz,

1080p/30Hz, 1080p/60Hz

Audio L/R

HDMI™ (v.1.3, HDMI™ CEC Support)

Please usa a High Speed HDMI™ Cable.
High Speed HDMI™ Cable are tested to
carry an HD signal up to 1080p and higher.

See pages 62, 63.

Input

• DVI (Digital)
SD: 480i, 480p
HD : 720p, 1080i, 1080p/24Hz,

1080p/30Hz, 1080p/60Hz

• Audio L/R (Analog)

Input

• Component (Analog)
SD: 480i, 480p
HD: 720p, 1080i

• Audio L/R (Analog)

Input

• S-Video (Analog)

• Audio L/R (Analog)

Input

• Composite (Analog)

• Audio L/R (Analog)

Compatible Signal Notes

Basics

See page 61, 63.

See page 59.

See pages 59, 61.

See page 59.

Output

• Audio L/R (Digital)
(PCM or Dolby Digital)

Output

• Audio L/R (Analog)
(Fixed)

See page 60.

See page 60.

17

Remote Control

+

The following pages gives you a brief description of each button’s function.
This remote can also control up to four other devices. See pages 51 - 52.

Allows you to set the TV to turn on and set the TV to turn off
automatically after a set amount of time and channel of your choice.

On Timer / Input / Sleep Timer

Timer

TIMER

POWER

TV STB VCR DVD AUDIO

MODE

V1 V2 V3 V4 V5

123

456

789

TUNE

RETURN

TV

0

On Timer

Input

Sleep Timer

0 h 0 m

0 - 0

0 min

Notes:

¥ 

• If you set the interval of On Timer by pressing the

buttons,

select channel at Input and press OK.

• After you set On Timer and turn off the TV, power lamp lights.

• You can check the remaining time of On Timer by displaying
this menu again.

• You can set the interval of Sleep Timer by pressing the ¥



buttons.

• 60 seconds before the TV turns off, a message will appear and it
will count the remaining time.

• See page 50, “On Timer using iPod”.

Turns the TV on or off.

Switch between “TV / STB / VCR / DVD / AUDIO devices.
See page 51.

Switch between devices connected to Video-1, 2, 3, 4 and 5. For
V4 (Video-4) and V5 (Video-5) you must select the signal input type
fi rst (ie. composite, S-Video, or component). To do so, you need
to press the V4 or V5 button until the correct type is highlighted.
Select “Composite 1” for composite video signal input, “S-Video”
for S-video signal input, or “Component 1” for component video
signal input. Select “Composite 2” for composite video signal input
or “Component 2” for component video signal input. Select PC for
PC signal input.

Change channels. Input remote codes. See page 51.

18

Lets you decide the input channel and select it. After pressing the

TUNE

remote 0 - 9 buttons, press TUNE.

RETURN

TV

Has three functions.

Return – Returns to the channel viewed

just before the channel
currently onscreen.

Return+ – Lets you program a specific

channel to return to while
scanning through the
channels using the – CH +

+

button as you memorize the
channel.

TV – Returns to the TV mode as you are

watching a video, DVD, etc.

TIMER

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

TUNE

Note:

• Press TUNE and RETURN+ TV
buttons. This will memorize the
current channel to return to while you

– CH + – VOL +

iPod MUTING

scan through the other channels. To
cancel, press TUNE and RETURN+
TV buttons again.

U

N

E

M

OK

POWER

Basics

+

RETURN

TV

0

B

A

C

K

– CH +

– VOL +

iPod

MUTING

U

N

E

M

OK

B

A

C

K

Move sequentially through the channels.

Raise or lower the volume.

Control your iPod connected to the TV.
See page 46.

Turns the TV volume to 0. Press again
to restore the volume.

Used to access the TV’s onscreen
menus. See page 24.

Used to navigate through the TV’s
onscreen menus.

Go back to a previous onscreen menu or
to correct a mistake.

RM-C1485

TV

19

Remote Control

Allows you to save channels you like so you can view them easily. First you
must register the channels you like.

F

A

V

O

R

I

T

E

Notes:

• Go to the channel you want to register and press the FAVORITE. A list will
appear. Press the FAVORITE button again to register your channel.

• To view your favorite channels, press FAVORITE. Move to select your
channel and press OK.

• To erase your favorite channels, press FAVORITE. Move to select your
channel and press

• Both analog and digital channels can be registered.

• The channels you registered will appear in numerical order at the top of the
list.

Allows you to adjust the way the image appears on your TV based on the format
that is being received.

T

C

E

P

S

A

Full / Regular / Slim / Panorama / Cinema / Full Native

See page 30.

Favorite

1

2

4

5

6

7

9

11

13

FAVORITE

¥ 

:Remove:Add

.

20

SOUND

VIDEO

GUIDE

You can choose several types of sound modes.

Speech / Jazz / Classic / Rock / User

See page 39.

Allows you to choose different picture settings according to personal
preferences. You can access this feature for each input (TV, V1, V2, V3, V4,
V5).

Standard / Dynamic / Theater / Game

See page 26.

You can view program information for Digital Channels.

Note:

• The GUIDE will not show the correct time and date depending on the Time
Zone and D.S.T. settings. See page 41.

SUB CH

TV/VCR

ML/MTS

SUB T.

DISPLAY

Digital broadcast sometimes offers sub channels.
By using the SUB CH button, you can select a
sub channel easily.

For example, to move to sub channel 123-45:

1) Press 1, 2 and 3 in order

2) Press the SUB CH button

3) Press 4 and 5 in order

4) Press the TUNE button

Allows you to listen to a program in Stereo,
Mono sound or another language (Sap) if
available. First you must set the MODE to TV on
your remote.

Notes:

• When you are receiving a digital broadcast, if
there are other languages, you can change the
language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best
sound quality. The sound will work in stereo
mode even if a certain broadcast is in mono
sound only.

• Choose the mono setting to reduce excessive
noise on a certain channel or broadcast.

• MTS is unavailable if your television’s Input
source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using
HDMI.

View current channel information.

F

A

V

O

R

I

T

E

DVR

STATUS

VIDEO

SOUND

SUB CH ML/MTS DISPLAY

SUB T.

TV/VCR

T

C

E

P

S

A

PCON

GUIDE

Basics

* See page 52 for buttons that control your external devices.

RM-C1485

TV

21

Initial Setup

When you turn on your TV for the first time, the Initial Setup menu appears automatically.
These menus will help you setup your TV with basic information for Language, Time and

Tuner Setup. You can also set this setting in the Plug In Menu.

1) Turn on the TV

POWER

2) Set the language

Set Language/Langue/Idioma

English

Next

3) Set the mode

Select Home for use at home.
Retail is used in the TV store.

Set Mode

Home

Next

1 Select a language

OK

1 Select a mode

OK

2 Select “Next”

OK

3 Move to next menu

2 Select “Next”

OK

3 Move to next menu

4) Set time attribute

Set Time Attribute

Time Zone

D.S.T.

Atlantic

On

Next

2 Select an item

Time Zone Choose the time zone you live in.

D.S.T. Changes the clock automatically for daylight

saving time. On / Off

22

1 Change settings

OK

3 Select “Next”

OK

4 Move to next menu

5) Set TV attribute

Set TV Attribute

Tuner Mode Air

Start Scan Exit

Tuner Mode Choose Air (antenna) or Cable

Notes:

• If you use a set top box (satellite or cable box), press Exit to skip this step.

• If you want to turn off the Auto Demo, press the MENU button.

1 Change settings

OK

2 Select an item

OK

“Thank you! Setup is now complete”

3 Select “Start Scan”

4 Start scanning

channels

Basics

Cable Users: After your auto tuner setup is complete, you may, (depending on the type of

hookup), have only 1 channel, usually 2, 3 or 4 in the auto tuner memory. This
is normal.

We have an important note for customers who subscribe to basic cable services (do not have
a separate cable box) and plan to use their JVC TV remote control to select channels.

Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is
receiving through the RF input), every channel number available from your cable company
will appear in your television’s Channel Summary and they will all be marked as available for
scanning. Even though every channel is detected and appears as available, you will only be
able to view those that you specifi cally subscribe to from your cable company. This will likely
mean there are blank channels between those channels you wish to scan or “surf”.

We apologize for any inconvenience this may cause but it is important to note that this is
not a malfunction of your television. If you want to sequentially scan those channels you
subscribe to without blank ones in between, you can contact your cable company for their
cable box and remote, or manually deselect them using the edit / skip feature on page 33.

23

Customizing Your TV

You can customize your TV by operating the menus on the TV screen. The TV screen displays
the Menu Bar, Menu Item and available items are highlighted.

Picture Display TV Sound Power Setting

Video Status

Tint

Menu Bar

Menu Item

Color

Contrast

Bright

Detail

Backlight

Color Temp

Color Management

Dynamic Gamma

Smart Picture

Digital VNR

MPEG NR

Natural Cinema

Video Reset

Explanation of function displays

Using the menus

1) Display the menu bar

Standard

0 –

– 100

50

0 –

– 100

25

0 –

– 100

50

0 –

– 100

43

0 –

– 100

94

0 –

– 100

50

Cool

Off

On

On

High

On

On

BACK

:OperateOK:Back

:Select

Choose from several preset Video modes.

MENU

:Exit

Guide

U

N

E

M

2) Display the desired menu

Picture Display TV Sound Power Setting


(P. 26)

1 Press ¥ to select a menu

24

Display

(P. 28)

TV

(P. 31)

Sound
(P. 39)

Power
(P. 40)

OK

2 Press  to select a menu item

Setting

(P. 41)

3) Change or adjust the setting

Video Status

Tint

Color

Contrast

Bright

Detail

Backlight

Color Temp

Color Management

Dynamic Gamma

Smart Picture

Digital VNR

MPEG NR

Natural Cinema

Video Reset

Standard

0 –

50

0 –

25

0 –

50

0 –

43

0 –

94

0 –

50

Cool

Off

On

On

High

On

On

– 100

– 100

– 100

– 100

– 100

– 100

1 Press  to select

a menu item

OK

2 Press ¥ to change the setting

■ To enter an item’s sub menu

Video Input Label

Photo Viewer

Aspect

Select

AIR TV

Full

Enter

OKOK

Thumbnail View

Interval 10

(Example: Photo Viewer)

■ To the previous screen

B

A

C

K

Advanced

4) Close the menu

U

N

E

M

Note:

• Depending on the situation (analog channels, digital channels, video signal format, external
inputs, etc.), some items will be displayed in gray and can not be selected.

25

Customizing your TV


Video Status

Choose different display settings according to personal preferences. You can use this feature
with TV, V1, V2, V3, V4 and V5.

Standard

Resets the picture display to the factory settings.

Dynamic

Gives a vivid picture with better contrast when viewing in a brightly lit room.

Theater

Gives a rich, film-like look to video when viewing in a dimly lit room.

Game

Used for when you are playing video games connected to your TV.

Notes:

• Each mode is memorized for each analog TV / composite / S-Video, Digital TV, HDMI,

component signal input.

• Each video status can be chosen along with your favorite picture settings (Tint, Color,

Contrast, Bright, Detail and Backlight).

■ Allows you to change and adjust the way the picture appears on your television.

Tint

Allows you to adjust the levels of red and green on your TV.

Color

Allows you to make all the colors on your TV appear more vivid or subtle.

Contrast

Allows you to adjust the level of black and white on your TV giving you a darker or brighter
picture overall.

Bright

Allows you to adjust the overall brightness of the TV.

Detail

Allows you to adjust the level of fine detail on your TV.

Backlight

Allows you to adjust the brightness of the internal lamp which effects the overall brightness of
the TV.

26

Color Temp

Allows you to adjust colors to look as accurate as possible. Cool / Natural / Warm

Color Management

Allows you to compensate for dull colors to ensure dull colors are reproduced with natural hues.

On / Off

Dynamic Gamma

Allows you see more detail in very dark or bright areas so these areas don’t appear “muddied”.
Normally, this feature should be left On for optimum picture quality. On / Off

Smart Picture

Allows the TV to adjust the brightness level automatically to a level suitable for what you are
watching. On / Off

Digital VNR

This function can be selected to change the effect of Digital VNR (Video Noise Reduction).

High – Adjusts the effect maximally
Low – Adjusts the effect minimally
Off – Function is turned off.

MPEG NR

This function effects the block noise removal and mosquito NR (Noise Reduction)
simultaneously.

Note:

• When you are receiving digital channels, block noise removal will have no effect.

Natural Cinema

Allows you to compensate for image blurring when the original video you are watching was shot
at 24 frames/sec, and is broadcast at 30 frames/sec. This conversion process is known as
“TELECINE”. On / Off

Notes:

• When you are receiving a 480p, 720p or 1080p signal, Natural Cinema cannot be selected.

• Natural Cinema is only applied for NTSC, SD 480i and HD 1080i signals.

Advanced

Video Reset

Resets all picture adjustments at once to the default settings, except for Natural Cinema.

27

Customizing your TV

Display

Video Input Label

Allows you to label all the devices you have connected to the TV that use the VIDEO-1, 2, 3, 4
and 5 inputs.

VCR

DVD

PVR

D-VHS

STB

SAT

AMP

GAME

CAM

DISC

Blu-ray DVD

Default

Photo Viewer

Photo Viewer allows you to enjoy your digital pictures stored on your USB Mass Storage Class
devices. You can view them on the TV in high quality if USB Mass Storage device is connected
to the Photo Viewer terminal on the TV.

1 Select

OK

2 Set

Thumbnail View

Photo Viewer

j1010001 j1010002 j1010003 j1010004

j1010005 j1010006 j1010007 j1010008

BACK

MENU

TUNE

:OperateOK:Back

:Exit

:Select

:Slide show

Page 1

j1010009

1 Select

OK

2 Display

When you select Thumbnail view and press OK, a folder or file list will be displayed. Select
your folder by using the ¥ or  buttons. Choose a picture and press the OK button. It
will now be shown on the screen. To move to the next picture, press the  button. To move to
the previous picture, press the ¥ button.

* If there is more than 10 images, those images will be shown in the next page. To go to the

next page, select the last image on the page and press the  or  buttons. To go back to
the previous page, press the ¥ or  buttons.

Slide Show
– In Thumbnail View screen, you can view slide show by pressing the TUNE button.

Photo Viewer with iPod

– In Thumbnail View screen, you can listen to music content stored on your iPod. Start your

iPod to play music, and put it on the TV’s Dock. You cannot operate iPod with TV remote.

28

DISPLAY

M

Display help screen

– VOL +

1

2

3

4

5

90º Rotation

Move to the upper left

Move up

Move to the upper right

Move to the left

Reset

Enlarge

(in Slide Show)

OK

Play/Pause

Move to the right

6

Move to the lower left

7

Move down

8

Move to the lower right

9

Reduce

Interval

Choose Slide Show Interval of 5, 10 or 20 seconds by pressing the ¥ buttons.

Notes:

• Gently pull out your USB device from the Photo Viewer terminal after fi nishing the Photo
Viewer menu.

• Use the supplied USB cable that came with your device. Do not use HUB or USB extension
cable.

• Photo Viewer cannot be guaranteed to work with all USB Mass Storage Devices. It may take
some time to display or it may not display correctly.

• Please refer to the Customer Support website at www.jvc.com/support for information and
notes regarding your devices you wish to connect.

• Supported fi le formats are “.jpg” or “.JPG”.

• All your stored data should be backed up fi rst as a precaution before connecting to the TV.

• Depending on your stored fi le size, it can take extra time to display “Photo Viewer” page.

• Depending on your stored fi le type, some data may not be able to be displayed in the
thumbnail screen.

• You can not display photos using the SD card from the JVC Everio Camera.

Advanced

Display Continued...

29

Customizing your TV

Aspect

Allows you to adjust the way the image appears on your TV based on the format that is being
received.

Full - When watching a 4:3 aspect picture,

it is stretched to fit the dimensions of
the TV. When watching a 16:9 aspect
picture, it displays 95% of the ratio.

Panorama - When watching a 4:3 aspect

picture it is stretched to fit the
dimensions of the 16:9 aspect
screen.

Full Native - This ratio displays 100%

of the ratio. Normally, all
aspects except for Full Native
display about 95%.

Regular - When watching a 4:3 aspect

picture without modifying
the original picture to fit the
dimensions of your 16:9 screen.
Black bars will appear along the
picture’s sides. The picture will be
centered within the boundaries of
the 16:9 screen.

Cinema - This ratio “zooms in” on

the center part of a 4:3
aspect picture, blowing it up
proportionally to fill the 16:9
screen.

Slim - This aspect mode shrinks the

screen of a 16:9 broadcast to 4:3.
There are some programming that
is already stretched by mistake at
broadcasting companies, so this
mode corrects it. Black side bars will
appear.

Notes:

• Depending on the signal format, some aspect modes are unavailable.

• If you change the aspect mode after the television changed it to Full automatically, the

television will change to the aspect mode you choose. It also turns to Full automatically
when the TV receives an HD (1080p, 1080i or 720p) signal.

• In iPod mode, selections of Aspect menu changes to Full / Regular / 16:9 Mini / 4:3 Mini.

30

TV

Closed Caption

Allows you to select the mode of the closed caption. First you must set the MODE to either TV,
STB or VCR on your remote. On / Smart / Off

Note:

• Smart caption will appear when you press the MUTING button only on channels where the

broadcast contains closed captioning.

C.C. Type

Allows you to select the type of the closed caption. Basic is for analog channel’s cation, and
Advanced is for digital channel’s caption. Auto / Basic / Advanced

C.C. Setting

You can choose between caption or text in mode to decide how closed captioning will appear.

Analog CC

Digital CC

Font

Font Size

Font Style

Text Color

Text Opacity

BG Color

BG Opacity

Edge Color

Analog CC

Choose the CC feature that you like for analog closed captioning.

Digital CC

Choose the CC feature that you like for digital closed captioning.

Font

Choose the font that you like for closed captioning.

Font Size

Choose how big the text appears in closed captioning.

Font Style

Choose the style of the font in closed captioning.

Text Color

Choose the color of the text in closed captioning.

Text Opacity

Choose how translucent the text appears in closed captioning.

Service1

Default

Standard

Default

Default

Default

Default

Default

Off

CC1

1 Select

OK

2 Adjust

Advanced

31

Customizing your TV

BG Color

Choose the background box color for the Closed Captioning text.

BG Opacity
Choose how translucent the background box color for the Closed Captioning text.

Edge Color

Choose the color of the border of the background box color for the Closed Captioning text.

Note:

• The Font, Font Size, Font Style, Text Color, Text Opacity, BG Color, BG Opacity and BG
Color settings will not apply to closed caption of analog channels. In addition, some of these

settings for closed caption for digital channels may or may not be available, depending on the
closed captioning data being broadcast.

Tuner Mode

If you skipped this step in the initial setup or your setup has changed, you can redo your setup
in this menu. Air / Cable

Autoscan

Allows you to scan through all available channels your TV can receive, and memorizes them.

Note:

• The Autoscan is finished when the message “Scanning has completed” appears on the
screen.

Add Channel

Allows you to add analog channels. Regarding digital channels, the only channels that will
appear are the ones that are being broadcast.

Please insert scan

number or range

32

to

Start

123

456

789

TUNE

+

RETURN

TV

0

Enter the new channel number

1 Select

OK

2 Start

Edit Channel

Allows you to skip channels when using the + CH – button. “✔” means don’t skip, “ ” means
to skip. You can still access those skipped channels manually using the number buttons on the
remote.

Main Channel List

3-2

CH-2



3-3

CH-3



5-0



6-0



6-0



11- 0



14-0



22-1

CH-1



36-0



63-0



OK

Select

OK

Select to skip or not to skip.

Also, select the channel.

V-Chip

Allows you to block channels or content that you deem inappropriate for children.

Notes:

• V-CHIP will not work with video signals from VCRs, DVD players, Blu-ray or camcorders

connected to the TV.

• (For Canadian viewers only) V-CHIP is designed specifically for the US and may not work

properly in Canada.

Advanced

– When entering the password –

When you try and access the V-Chip menu, “Please input password” will appear. Press the
“0” button four times on your remote to access the V-Chip menu for the first time.

Please input password:

123

456

789

TUNE

+

RETURN

TV

0

TV Continued...

33

Customizing your TV

– When you lock or unlock channels –

You can lock or unlock ratings as shown below.

Password

MPAA

Can. Eng.

Can Fre.

TVPG

NR

G

PG

PG13

R

NC-17

X

1 Select

OK

2 Lock / Unlock

Note:

• If you lock a rating, any rating that is higher is automatically blocked.

Password

New Password

Confirm Password

OK Clear

You can change the four digit password using
the number buttons on your remote.

* If you forget your password, unplug the TV

from the wall and then plug it back in. Your
password will reset to “0000”

1) Set a new password

123

456

789

TUNE

+

RETURN

TV

0

Enter the four digit number

OK

Next

2) Confi rm and set

123

456

789

TUNE

Enter the four digit number

34

RETURN

TV

0

OK

+

Next

OK

Set

MPAA

NR

G

PG

PG13

R

NC-17

X

NR – Not Rated.
Any type of programming that does not contain a rating.

G – General Audience.
Suitable for all ages.

PG – Parental Guidance Suggested.
Suitable for all ages with parental guidance.

PG 13 – Parents Strongly Cautioned.
Intended for viewers 13 years or older.

R – Restricted.
Not recommended for viewers 17 years without parental guidance.

NC-17 – No One Under 17.
Not intended for viewers 17 years or younger.

X – No One Under 18.
Not intended for viewers 18 years or younger.

Viewing Guidelines:

At the beginning of a program, the program will display its rating and the content it contains
(Except for unrated programming).

This setting is based on the US Motion Picture
Association of America (MPAA) ratings system.

Advanced

A program can contain any or all of the following:

V/FV – VIOLENCE/FANTASY VIOLENCE
S – SEXUAL Content
L – Strong LANGUAGE
D – Suggestive DIALOG

TV Continued...

35

Customizing your TV

Can. Eng.

E

C

C8+

G

PG

14+

18+

This setting is based on the Canada ratings
system.

E – Exempt.
Any type of programming that does not contain a rating.

C – Intended for children.
Suitable for all ages.

C8+ – Intended for children over 8 years old.
Suitable for all ages over 8 years.

G – General Audience.
May contain material not suited for younger viewers.

PG – Parental Guidance.
May contain material not suited for younger viewers. Parents may consider some content not
appropriate for children 8 - 13 years old.

14+ – 14 Years or Older.
Parents strongly urged to use their discretion in allowing viewing by persons under 14.

18+ – Adult.
Intended for viewers 18 years or older.

Can. Fre.

E

G

8 Ans+

13 Ans+

16 Ans+

18 Ans+

For instructions on Can. Fre., please see page
36 in the French user’s guide.

36

TVPG

This setting is based on the US ratings system.

D

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

ALL

FV V

SL

TV Y – Appropriate for all children.
Intended for all children 2 - 6 years old.

TV Y7 – Appropriate for older children.
Intended for children 7 years or older.

TV G – General Audience.
Suitable for all ages.

TV PG – Parental Guidance Suggested.
Suitable for all ages with parental guidance.

TV 14 – Parents Strongly Cautioned.
Intended for viewers 14 years or older.

TV MA – Mature Audiences Only.
Intended for viewers 18 years or older.

Viewing Guidelines:
In addition to the above ratings, you can also block or allow more specifi c content (Except for
unrated programming).

A program can contain any or all of the following:

V/FV – VIOLENCE/FANTASY VIOLENCE
S – SEXUAL Content
L – Strong LANGUAGE
D – Suggestive DIALOG

Advanced

Guide

You can view program information. (Digital channels only)

Note:

• If the programming information is not being broadcast, the guide function has no effect or

may display incorrect information.

37

Customizing your TV

PC

Notes:

• This menu will replace the TV menu when you connect a PC to your TV terminal. See page

63.

• There are some menus that PC mode can not use. (In Picture and Sound menu)

• As for Aspect in the Display menu, only Regular and Full are available.

• When headphones are used, the Sound menu is not available.

Auto Adjustment

Adjust the screen position automatically.

Note:

• Sometimes Auto Adjustment will not operate properly. Either adjust with the following
functions or change the signal.

Phase Adjustment

Adjust it when noise shows up across the screen. Also, use it when letters become blurry.

PC H-Position

Allows you to adjust the screen position horizontally.

PC V-Position

Allows you to adjust the screen position vertically.

Reset

Resets all PC mode adjustments at once to the default setting.

38

Sound

MTS

Allows you to listen to a program in stereo, mono sound or another language (SAP).

(Depending if available in the program) First you must set the MODE to TV on your remote.

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the

language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo

mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• MTS unavailable if your television’s input source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using the HDMI.

Digital Audio (ML)

You can change the language if there are other languages available. (Digital channels only)

Surround

You can select the surround mode you like. Off / Movie / Music / News / Mono

Advanced

Sound Status

You can choose several types of sound modes. User / Speech / Jazz / Classic / Rock

Note:

• If you select User, you can customize the various sound frequencies.

100Hz / 330Hz / 1KHz / 3.3KHz / 10KHz

Audio Reset

Resets all sound adjustments at once to the default settings.

39

Customizing your TV

Power

Power Indicator

Allows you adjust the brightness of the blue power indicator light.

High – Light is brightly lit
Low – Light is dimly lit
Off – Light is off

Illumination

Allows you adjust the brightness of the Diffuser Illumination. See page 13.

High – Light is brightly lit
Low – Light is dimly lit
Off – Light is off

40

Settings

Plug In Menu

When you turn on your TV for the first time, the Initial Setup menu appears. If you skip it, or
your setup has changed, you can set it up in this menu anytime.

Time Zone

Choose the time zone you live in and the clock sets automatically.

Atlantic / Eastern / Central / Mountain / Pacific / Alaska / Hawaii

D.S.T.

Adjust your TV’s clock for Daylight Savings. On / Off

Language

Allows you to change the TV’s onscreen menu languages to English, French or Spanish.

Noise Mute

Displays a blank gray screen over channels that are too weak to be received clearly.

On / Off

Front Panel Lock

This allows you to lock the buttons on the side of the TV. On / Off

Transparency

Change the transparency of the menu screens. 1 / 2 / 3 / 4

Auto Shut Off

This function automatically shuts off your TV when there is no signal from the channel while the
TV is on for 10 minutes. On / Off

Advanced

Settings Continued...

41

Customizing your TV

Control with HDMI

If you use a HDMI CEC compatible device, set this setting to “On”.

HDMI CEC (Consumer Electronics Control) allows the TV to connect and control multiple HDMI
CEC enabled devices with a single remote. CEC (Consumer Electronics Control) is an optional
protocol used in HDMI.

• HDMI CEC on this TV is compliant with “High-Definition Multimedia Interface Specification”.

• The TV does not support HDMI CEC functions that are not listed below.

• The TV does not guarantee to support use of all HDMI CEC enabled devices.

• Devices that are not enabled to HDMI CEC cannot be controlled with this TV.

– Control the TV using the HDMI CEC enabled device –

• Turn the TV on and switch to the video source of the operating device.

• Switch to the video source of the operating device.

• Turn the TV off with the HDMI CEC enabled device you are viewing.

• For operating instructions of the device, refer to the device’s manual.

– Control the HDMI CEC enabled device using the TV –

• Turn off the operating device by turning off the TV.

• Some device may not support this function. For more details refer to the device’s manual.

– Send status of the TV to the HDMI CEC enabled device –

• When switching the TV’s external input or channel.

• When switching the TV’s menu language.

• Information regarding behavior of the device when status is received, refer to the external
device’s manual.

If HDMI CEC does not work correctly:

• When HDMI CEC enabled device is connected to INPUT 1, INPUT 2 or INPUT 3 with an
HDMI cable, you may not be able to control TV’s external input. To solve the problem set this
setting to “Off”.

System Info

You can confirm the TV’s software version.

Auto Demo

Auto Demo explains this TV’s features to you.

Notes:

• The Auto Demo mode will start automatically when you set Retail in Initial Setup.

• If you press any button on the television or remote, with the exception of

POWER or MENU, the Auto Demo mode will stop for 30 seconds. After 30 seconds
have passed with no operation, the Auto Demo mode will start again.

• If you want to turn off the Auto Demo, press the MENU button.

42

Optical Out

You can select the optical digital sound output as PCM or DOLBY DIGITAL when your TV is
connected to an amplifier that has a DOLBY DIGITAL decoder. If you select DOLBY DIGITAL,
you can enjoy listening to 5.1ch sound when watching digital broadcasts. This only applies to
digital channels.

Notes:

• Optical Out can be used for both digital and analog channels.

• If your amplifier does not have DOLBY DIGITAL decoder, select PCM. If you don’t

select PCM, it cannot output the sound from the speakers.

• For connecting an amplifier using the optical output, see page 60.

PC Smart Input

When PC is turned on it will power on TV and put it in PC mode. Any other function is not logical.
Also it is called PC Smart Input in TV menu so it suggest fl ow from PC to TV.

D-Sub / HDMI / Off

Notes:

• When you use PC Smart Input function with HDMI cable, connect your PC with HDMI

terminal (INPUT 1).

• You cannot use PC Smart Input when Control with HDMI is “On”.

Sync Mode

Lets iTunes synchronize your iPod when USB is connected with computer. When you start
Sync Mode, the menu displays “Start” and after fi nished, “Exit” is displayed.

Sync Mode Syncronizing

your iPod

Start

OK

Press OK to start or exit Sync Mode.

Advanced

Notes:

• You need USB type A - type B cable connector, see page 50.

• Do not detach your iPod when you start Sync Mode.

• When you exit the Sync Mode, make sure your iPod and PC communication has fi nished.

43

Enjoy Movies/Music From Your iPod

Compatible iPod Types

* If your iPod is not listed in this chart, it is incompatible with this television.

iPod

4G photo/color 5G classic touch (1G) touch (1G)

(FW:2.0+)

touch 2G

20GB
40GB

20GB
30GB
40GB
60GB

30GB
60GB
80GB

80GB
120GB
160GB

8GB
16GB
32GB

8GB
16GB
32GB

TV Control Mode

Music Play

Video Play

Setting

✔✔✔✔✔✔

✔✔ ✔

✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3)

Pod Control Mode

Music Play

Video Play

Photo Slide
Show

Setting

✔ (1) ✔ (1) ✔ (1) ✔ (1) ✔ (1, 2) ✔ (1, 2)

✔✔✔ (2) ✔ (2)

✔✔✔✔✔

✔✔✔✔✔ (2) ✔ (2)

Sync Mode

✔✔✔✔✔✔

• Some setups will require the selection by using the iPod. (Especially those that require wheel
control).

• Not available except for Music/Video play, Photo Slide Show (Pod Control Mode).

(1) – The registration of “On-The-Go” can be done by using the iPod
(2) – Due to the nature if iPod touch, lock/unlock, Main Menu and the selection of music/video

has to be done using the iPod touch.

(3) – “Shuffl e”, “Repeat” and “Audiobook” can be available in TV Control Mode.

44

iPod nano iPod mini

1G 2G 3G 4G

1GB
2GB
4GB

✔✔✔✔✔

✔ (3) ✔ (3) ✔ (3) ✔ (3) ✔ (3)

✔ (1) ✔ (1) ✔ (1) ✔ (1) ✔ (1)

✔✔✔✔✔

✔✔✔✔✔

2GB
4GB
8GB

4GB
8GB

✔✔

✔✔

✔✔

8GB

16GB

4GB
6GB

Advanced

45

Enjoy Movies/Music From Your iPod

By inserting your iPod into the Dock, you can display movies or music on your TV from your
iPod. Also, while inserted you can recharge your iPod.

Ready to play

1) Insert your iPod into the Dock on the front of the TV.

* When you put your iPod on the Dock, please

use the Dock adapter.

Dock Adapter

Dock

Notes:

• It is recommended that music, pictures and movies on the iPod be saved on your PC or other

hard drive for backup.

• Please be sure to connect/disconnect the iPod properly from the Dock and use the iPod

without any accessory/case.

• Please do not jiggle the iPod in the Dock to avoid connection failure or damage to the

connector.

* If you have difficulty detaching the Dock

adapter, gently use a flat head screwdriver to
remove.

2) Press the iPod button on your remote, then the JVC logo will appear

iPod

on the screen of the iPod.

Notes:

• You cannot operate the iPod while the Apple logo appears on the screen of the iPod.

• If your iPod doesn’t work correctly, gently pull out and try again.

3) TV screen will change to the iPod start screen.

1 Select

JVC iPod classic(2)

Music Play

Video Play

Music Shuffle Play

Settings

Now Playing

1

OK

2 Set

4) To exit the menu, press the iPod button. The TV will return to the program you were

watching.

5) When you detach your iPod, while gently holding the base, pull the iPod gently straight

upwards.

Notes:

• If the iPod does not play correctly, please update your iPod software to the latest version.

For details about updating your iPod, check on the Apple web site, http://www.apple.com.

• Sound distortion may occur when playing back audio sources with high recording levels.

When distortion occurs, it is recommended to turn off the equalizer of the iPod. For
information on operating the iPod, see the iPod instruction manual.

• JVC is not responsible for any loss of or damage to iPod that might result from the use of this

product.

46

TV Control Mode

You can operate the iPod by using the TV’s remote control and onscreen menus.

Music Play

JVC iPod classic(2)

Music Play

Video Play

Music Shuffle Play

Settings

Now Playing

1

Video Play
Music Shuffle Play
Settings
Now Playing (when playing music)

OK

OK

OK

Set

Skip to the next/last pageSelect

B

A

C

Back to previous menu

K

Note:

• When Music Play is selected, you can then search by the catagories supported on your

iPod, such as Playlist, Albums, Songs, Podcast etc.

Icons of Music Play screen

Your iPod name Blinks when communicating with the iPod

Shuffle

Repeat

1

Songs

Albums

One

All

Rewind

Pause/
Stop

Music Play

1

00:00:43 / 00:06:21

Forward

Play

NOWHERE

WHY ARE WE HERE

SOME RANDOM BAND

ROCK

JVC iPod classic(2)

1 / 334

* Language Support:
English, French and Spanish

Advanced

Music

Artist

Album

Genre

47

iTV

A

S

P

E

C

T

Enjoy Movies/Music From Your iPod

A

S

P

E

C

T

Music Play / Video Play

OK

B

A

C

K

U

N

E

M

– VOL +

VIDEO

Music Play

1

00:00:43 / 00:06:21

NOWHERE

WHY ARE WE HERE

SOME RANDOM BAND

ROCK

JVC iPod classic(2)

1 / 334

Skip to the next/last song

Back to previous menu

TV’s onscreen menu
(“Picture” and “Sound”)

Volume

Adjust Video status
(Video Play)

Change the aspect ratio
(Video Play)

SOUND

TIMER

iPod

DISPLAY

MUTING

Rewind

file title

Adjust sound status

Choose Timer

Back to TV

Display title (Video Play)

You can view the last program
you were watching while

iTV

listening to your iPod (iTV
Mode). Press iTV button when
playing music.

Mute

Play

Forward

Back to Previous Menu

iTV (in Music Play mode)

iTV allows you to watch TV and at the same time, listen to the music content on your iPod.
When you are listening to music in Music Play mode, press the iTV button.

VIDEO

Adjust Video status

– CH +

Adjust Aspect Ratio

–

V1

–

0

9

TUNE

SUB CH

TV/VCR

Adjust sound status

SOUND

Select a channel.
(See page 18, 21)

RETURN

TV

iTV

DISPLAY

Note:

• Basic operations are the same as the operations when playing in Music Play mode.

48

Change channel

V5

Select input

+

Change between iPod’s sound
and TV’s sound

Back to Music Play screen

Display information

Pause

Music Shuffle Play

A

S

P

E

C

T

iTV

This function selects songs randomly.

Note:

• Basic operations are the same as the operations when playing in Music Play mode.

Settings

You can adjust the settings below by pressing the  and OK buttons.

Shuffle / Repeat / Audiobook

Pod Control Mode

You can operate the iPod using the TV’s remote control and the onscreen of the iPod. Press
the PCON button to switch between Pod Control Mode and TV Control Mode.

PCON

1) Press the PCON button on the remote control. JVC logo will disappear

and the normal screen of your iPod will appear.

2) Operate with TV remote control.

OK

B

A

C

K

U

N

E

M

– VOL +

MUTING

DISPLAY

* Operation varies from

iPod type and/or mode.

Back to previous menu

TV’s onscreen menu
(“Picture” and “Sound”)

Volume

Mute

Exit message

SOUND

Adjust sound status

VIDEO

Adjust Video status

Adjust Aspect Ratio

TIMER

Choose Timer

iPod

Back to TV

* Operation varies

from iPod type
and/or mode

GUIDE

Advanced

Note:

• TV will display a blank black screen when operating the iPod in Pod Control Mode.

49

Enjoy Movies/Music From Your iPod

Recharge iPod

While your iPod is connected to the Dock, you have the ability to recharge your iPod. The time
it takes depends on how low your batteries are.

On Timer using iPod

You can set the timer to listen to your iPod music content. After you set On Timer and select
iPod at Input in Timer menu. See page 18. Insert your iPod into the Dock.

Notes:

• If you want to set the timer to listen to your favorite music content, play the music content

operating your iPod and press pause. And put it on the TV Dock. On Timer will start to play
the selected music.

• You cannot play Video content using On Timer function.

PC sync.

You can synchronize your iPod and PC using this TV. Please use USB type A - type B cable
(not supplied) when you connect with SYNC (PC) connector.

SYNC (PC)

Back of the TV

PC

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

Notes:

• Make sure you inserted your iPod into the Dock and both PC and TV’s power is on.

• Depending on your PC and USB cable, Sync Mode (page 43) may not operate correctly.

Also, it is not recommended to use a hub between the PC and TV connection.

• For details about syncing with iTunes, refer to your iPod’s manual.

• You can display iTunes screen on TV. See page 63.

Error messages

“iPod not found” This appears when you press the iPod button

“ Communication failed.

Check Connection”

“File not found” This appears when your iPod has no files to

50

without inserting an iPod.

Insert your iPod again. This is a connection
error.

play.

Programming Your Remote

You can program your remote control to operate your external devices, using the instructions
and codes on pages 51 - 57.

How to set the codes

1) Manually turn on the device.

2) Change the remote control mode according to the device by pressing the MODE button.

Refer to the following list for which mode to use.

Device Applied for these devices

JVC brand only

TV

Cable Set Top Boxes, Cable/PVR Combinations, Satellite Set Top Box

STB

DBS/PVR Combination

VCR, DBS/PVR Combination, PVR, DVD/PVR Combination

VCR

DVD Player, DVD Recorder, Home Theater in a Box, Receiver

DVD

AUDIO

3) Find the remote control code for your device. See pages 53 - 57.

4) Set the remote code.

TUNE

Amplifier, Home Theater in a Box, Receiver

123

456

789

TUNE

+

RETURN

TV

0

The mode indicator goes
out for a second, then it
lights.

Advanced

Enter the four digit numberPress and hold

5) Point the remote at the device and press power. If your device did not turn off or respond, try

another code.

Notes:

• If your device doesn’t respond to any of the codes listed or is not listed, see page 52.

• Some codes may have only limited functions. Try other codes that may have more functions.

51

iPod MUTING

F

Programming Your Remote

Search Code Function

This function searches for codes one by one if none of the codes listed for your device has
worked.

1) Manually turn on the device.

2) Change the remote control mode according to the device. Press MODE to select the correct

mode.

3) Activate the search code function. Press and hold POWER and RETURN+/TV until the mode

indicator blinks.

4) Point the remote at the device and press POWER. If no response, try the next code by

pressing  and POWER until the device turns off.

5) Press RETURN+/TV to register and set the code. Then the MODE indicator light goes out.

Notes:

• If your remote still doesn’t work with the “Search Code Function”, use the remote that came
with your device. Your TV remote can not be guaranteed to work with all devices, modes or
operations.

Remote Control Functions

POWER

Turns the selected device off

– CH +

– VOL +

TV STB VCR DVD AUDIO

MODE

V1 V2 V3 V4 V5

Operates menus

Select

Display
menu

52

Channel Up / Down

Volume Up / Down

U

N

OK

E

M

B

A

C

K

OK

SUB T.

Displays Subtitles

Open / Close

Changes the remote control mode

Audio Input
Selection

Playback / Record, etc.

Rewind

Back to

iTV

previous
menu

Record Stop Pause

Play

Forward

Programming Codes

STB mode

Cable Set Top Box

ABC
Americast
Bell South
Digeo
Director
General Instrument

GoldStar
Hamlin
Jerrold

Memorex
Motorola

Pace
Panasonic
Paragon
Philips
Pioneer

Pulsar
Quasar
Regal
Runco
Samsung
Scientific Atlanta

Sony
Starcom
Supercable
Torx
Toshiba
Zenith

Cable/PVR Combination

Americast
Digeo
General Instrument
Jerrold
Motorola
Pace
Pioneer
Scientific Atlanta
Sony
Supercable
Zenith

0003, 0008
0899
0899
118 7
0476
0476, 0810, 0276,
0003
0144
0009, 0273
0476, 0810, 0276,
0003
0000
1376, 0476, 0810,
0276, 1187
1877, 0237, 0008
0000, 0008, 0107
0000
1305, 0317, 0025
1877, 0877, 0144,
0533
0000
0000
0279, 0273
0000
0000, 0144
1877, 0877, 0477,
0008
1006
0003
0276
0003
0000
0000, 0525, 0899

0899
118 7
0810
0810
1376, 0810, 1187
1877, 0237
1877, 0877
1877, 0877
1006
0276
0899

Satellite Set Top Box

AlphaStar
Chaparral
Coolsat
Crossdigital
DirecTV

Dish Network System

Dishpro

Echostar

Expressvu
GE
General Instrument
GOI
Hisense
Hitachi
HTS
Hughes Network Systems

Humax
iLo
JVC
LG
Magnavox
Memorex
Mitsubishi
Motorola
Next Level
Panasonic
Pansat
Paysat
Philips

Proscan
Proton
RadioShack
RCA

0772
0216
1806
110 9
1377, 0392, 0566,
0639, 1639, 1142,
0247, 0749, 1749,
0724, 0819, 1856,
1076, 1108, 0099,
1109, 1414, 1442,
1609, 1392, 1640
1505, 1005, 0775,
1170, 1775
1505, 1005, 0775,
1775
1505, 1005, 0775,
1170, 1775
0775, 1775
0566
0869
0775, 1775
1535
0819
0775, 1775
1142, 0749, 1749,
1442
1790
1535
0775, 1170, 1775
1414
0724, 0722
0724
0749
0869
0869
0247, 0701
1807
0724
1142, 0749, 1749,
0724, 1076, 0722,
0099, 1442
0392, 0566
1535
0869
0566, 0855, 0143,
1392

Satellite Set Top Box

Samsung

SKY
Sony
Star Choice
Tivo
Toshiba

UltimateTV
Ultrasat
Uniden
US Digital
USDTV
Voom
Zenith

DBS/PVR Combination

DirecTV

Dish Network System
Dishpro
Echostar
Expressvu
Hughes Network Systems
JVC
Motorola
Philips
Proscan
RCA
Samsung
Sony
Star Choice

1377, 1276, 1108,
1109, 1442, 1609
0856
0639, 1639, 1640
0869
1142, 1442
0749, 1749, 0790,
1285
1392, 1640
1806
0724, 0722
1535
1535
0869
0856, 1856

1377, 0392, 0639,
1142, 1076, 0099,
1392, 1442, 1640
1505, 0775
1505, 0775
1505, 0775, 1170
0775
1142, 1442
117 0
0869
1142, 0099, 1442
0392
1392
1442
0639, 1640
0869

Etc.

53

Programming Codes

Programming Codes

VCR mode

ABS
Admiral
Adventura
Aiko
Aiwa

Akai
Alienware
America Action
American High
Asha
Audiovox
Beaumark
Bell & Howell
Broksonic

Calix
Canon
Capehart
Carver
CCE
Citizen
Colt
Craig

Curtis Mathes

Cybernex
CyberPower
Daewoo

Daytron
Dell
Denon
DirecTV
Durabrand
Dynatech
Electrohome
Electrophonic
Emerex
Emerson

VCR

1972
0048, 0209
0000
0278
0037, 0000, 0307,
0479
0041, 0061, 0106
1972
0278
0035
0240
0037, 0278
0240
0104
0184, 0121, 0209,
0002, 0479, 1479
0037
0035
0020
0081
0072, 0278
0037, 0278, 1278
0072
0037, 0047, 0240,
0072, 0271
0060, 0035, 0162,
0041, 0760, 1035
0240
1972
0045, 0104, 0278,
0020, 0046, 0561,
1278
0020
1972
0042
0739
0039, 0038
0000
0037
0037
0032
0035, 0037, 0184,
0240, 0045, 0000,
0121, 0043, 0209,
0002, 0278, 1593,
1479, 1278, 0593,
0561, 0479, 0208,
0061

Fisher
Fuji
Funai
Garrard
Gateway
GE

Go Video
GoldStar

Gradiente
Harley Davidson
Harman/Kardon
Harwood
Headquarter
Hewlett Packard
HI-Q
Hitachi

Howard Computers
HP
Hughes Network Systems
Humax
Hush
iBUYPOWER
Jensen
JVC

KEC
Kenwood
KLH
Kodak
LG

Linksys
Lloyd's
Logik
LXI
Magnasonic
Magnavox

Magnin
Marantz

VCR

0047, 0104, 0046
0035, 0033
0000, 0593, 1593
0000
1972
0060, 0035, 0240,
0202, 0760, 0761,
0807, 1035, 1060
0432, 0526
0037, 0209, 0038,
0225, 1237
0000
0000
0081, 0038
0072
0046
1972
0047
0037, 0240, 0000,
0042, 0041, 0105,
1037
1972
1972
0042, 0739
0739
1972
1972
0041
0045, 0067, 0041,
0008, 0366, 1707,
1945, 1774, 1775,
1776, 1777
0037, 0278
0067, 0041, 0038
0072
0035, 0037
0037, 0045, 0042,
0209, 0038, 1037
1972
0000, 0208
0240, 0072
0037
0593, 1278
0035, 0039, 0081,
0000, 0149, 0563,
0593, 1593, 1781
0240
0035, 0081

Marta
Matsushita

Media Center PC
MEI
Memorex

MGA
MGN Technology
Microsoft
Mind
Minolta
Mitsubishi

Motorola
MTC
Multitech
NEC

Nikko
Niveus Media
Noblex
Northgate
Olympus
Optimus

Orion

Panasonic

Penney

Pentax
Philco

VCR

0037
0035, 0162, 0227,
116 2
1972
0035
0035, 0162, 0037,
0048, 0039, 0047,
0240, 0000, 0104,
0209, 0046, 0307,
0479, 1037, 1048,
1162, 1237, 1262
0240, 0043, 0061
0240
1972
1972
0042, 0105
0081, 0067, 0043,
0041, 0061, 0173,
0807
0035, 0048
0240, 0000
0000, 0072
0035, 0037, 0048,
0104, 0067, 0041,
0038, 0008
0037
1972
0240
1972
0035
1062, 0162, 0037,
0048, 0104, 0432,
0593, 1048, 1162,
1262
0184, 0121, 0209,
0002, 0208, 0479,
1479
1062, 0035, 0162,
0225, 0227, 0616,
1035, 1162, 1262
0035, 0037, 0240,
0042, 0038, 1035,
1237
0042, 0105
0035, 0000, 0038

54

VCR VCR

VCR mode

Philips

Pilot
Pioneer
Polk Audio
Portland
Presidian
Profitronic
Proscan

Protec
Pulsar
Quarter
Quartz
Quasar

RadioShack
Radix
Randex
RCA

Realistic

ReplayTV
Ricavision
Runco
Samsung

Sanky
Sansui

Sanyo

Scott

Sears

Sharp

Shintom
Shogun
Singer
Sonic Blue
Sony

Stack 9
STS
Sylvania

0035, 0081, 0000,
0563, 0593, 0618,
0739, 1081, 1181,
1266
0037
0081, 0042, 0067
0081
0020
1593
0240
0060, 0202, 0760,
0761, 1060
0072
0039
0046
0046
0035, 0162, 1035,
116 2
0000, 1037
0037
0037
0060, 0035, 0240,
0000, 0042, 0149,
0105, 0106, 0202,
0760, 0761, 0807,
0880, 1035, 1060
0035, 0037, 0048,
0047, 0000, 0104,
0046
0614, 0616
1972
0039
0240, 0045, 0432,
0739, 0760, 1014
0048, 0039
0000, 0067, 0209,
0041, 0271, 0479,
1479
0047, 0240, 0104,
0046
0184, 0045, 0121,
0043
0035, 0037, 0047,
0000, 0042, 0104,
0046, 0057, 0105,
1237
0048, 0209, 0807,
0848, 1048
0104, 0072
0240
0045, 0072
0614, 0616
0035, 0032, 0033,
0000, 0034, 0636,
0639, 0640, 1032,
1232, 1972
1972
0042
0035, 0081, 0000,
0043, 0593, 1593,
1781

Symphonic
Systemax
Tagar Systems
Tatung

Tea c
Technics
Teknika
Thomas
Tivo

TMK
Toshiba

Totevision
Tou c h
Unitech
Vector
Vector Research
Video Concepts
Videomagic
Videosonic
Viewsonic
Villain
Voodoo
Wards

White Westinghouse
XR-1000
Yamaha
Zenith

ZT Group

Echostar
Hughes Network Systems
JVC
Philips
Samsung

ABS
Alienware
CyberPower
Dell
DirecTV
Dish Network System
Echostar
Gateway
Hewlett Packard

0000, 0593, 1593
1972
1972
0081, 0045, 0000,
0067, 0041, 0008,
0366
0000, 0041
0035, 0162
0035, 0037, 0000
0000
0618, 0636, 0739,
1996
0240, 0208
0081, 0045, 0042,
0067, 0043, 0041,
0008, 0057, 0366,
0845, 1008, 1145,
1972, 1996
0037, 0240
1972
0240
0045
0038
0045, 0061
0037
0240
1972
0000
1972
0060, 0035, 0048,
0047, 0081, 0240,
0000, 0042, 0072,
0149, 0760
0209, 0072
0035, 0000, 0072
0041, 0038
0039, 0033, 0000,
0209, 0034, 0479,
1139, 1479
1972

1945
0739
1945
0739
0739

1972
1972
1972
1972
0739
1945
1945
1972
1972

DBS/PVR Combination

PVR

Howard Computers
HP
Hughes Network Systems
Humax
Hush
iBUYPOWER
JVC
Linksys
Media Center PC
Microsoft
Mind
Niveus Media
Northgate
Panasonic
Philips
RCA
ReplayTV
Samsung
Sonic Blue
Sony
Stack 9
Systemax
Tagar Systems
Tivo
Toshiba
Tou c h
Viewsonic
Voodoo
ZT Group

Emerson

1972
1972
0739
0739
1972
1972
1945
1972
1972
1972
1972
1972
1972
0616, 1777
0618, 0739
0880
0614, 0616
0739
0614, 0616
0636, 1972
1972
1972
1972
0618, 0636, 0739
1008, 1972, 1996
1972
1972
1972
1972

0000

DVD/PVR Combination

PVR

Etc.

55

Programming Codes

DVD mode

Accurian
Advent
Aiwa
Akai
Alco
Allegro
Apex Digital

Arrgo
Aspire Digital
Audiovox
Blaupunkt
Blue Parade
Broksonic
Cinea
Cine Vision
Citizen
Coby
Craig
Curtis Mathes
CyberHome

Daewoo

Denon
Disney
Durabrand
DVD2000
Emerson

Enterprise
ESA
Fisher
Funai
Gateway
GE
Go Video

GoldStar
Greenhill
Harman/Kardon
Hitachi
Hiteker
Humax
iLo
Initial
Insignia
Integra
JBL
Jensen
JVC

Kawasaki
Kenwood
KLH
Koss
Lasonic
Lenoxx
LG
LiteOn

DVD DVD

1416
1016
0641
0695, 0770, 0899
0790
0869
0672, 0717, 0755,
0830, 1056, 1061
1023
116 8
0790
0717
0571
0695
0831
0876, 0833, 0869
1277
0778, 1107
0831
1087
0816, 0874, 1023,
1024, 1117, 1129
0784, 0705, 0770,
0833, 0869, 1169,
117 2
0490, 0634
0675, 1270
112 7
0521
0591, 0675, 0821,
1268
0591
0821, 1268
0670
0675, 1268, 1334
115 8
0522, 0815, 0717
0744, 0715, 0741,
0783, 0833, 0869,
1044, 1075, 1099,
1158, 1304, 1730
0741
0717
0582, 0702
0573, 0664, 1247
0672
1500, 1588
1348
0717
1268
0627
0702
1016
0558, 0623, 0867,
1164, 1602, 1770,
1771, 1772, 1773
0790
0490, 0534
0717, 0790, 1149
0651
0798
112 7
0591, 0741, 0869
1058, 1158, 1416,
1440

Magnavox

Marantz
Memorex
Microsoft
Mintek
Mitsubishi
NAD
NEC
Nesa
NexxTech
Norcent
Onkyo
Oritron
Panasonic

Philips

Pioneer
Polaroid
Polk Audio
Portland
Presidian
Prima
Proscan
Pro Vision
Qwestar
RCA

Rio
Rotel
Sampo
Samsung

Sansui
Sanyo
Sensory Science
Sharp

Sharper Image
Sherwood
Shinsonic
Sonic Blue
Sony

Superscan
Sylvania
Symphonic
Tea c
Technics
Theta Digital
Tivo
Toshiba

Urban Concepts
US Logic
Venturer
Xbox
Yamaha
Zenith

0503, 0539, 0646,
0675, 0821, 1268
0539
0695, 0831, 1270
0522, 1708
0839, 0717
1521, 0521
0741
0785
0717
1402
1003, 1107
0503, 0627
0651
0490, 0703, 1362,
1462, 1490, 1762
0503, 0539, 0646,
0675, 0854, 1158,
1260, 1267, 1354
0525, 0571, 0631
1061
0539
0770
0675
1016
0522
0778
0651
0522, 0571, 0717,
0790, 0822, 1022,
113 2
0869
0623
0752
0490, 0573, 0744,
0820, 0899, 1044,
1075, 1470
0695
0670, 0695, 0873
115 8
0630, 0675, 0752,
1256
1117
0770
0533, 0839
0869, 1099
0533, 1533, 0864,
1033, 1431, 1536
0821
0675, 0821, 1268
0675, 0821
0717, 0790
0490, 0703
0571
1503
0503, 0695, 1045,
1154, 1503, 1515,
1588
0503
0839
0790
0522, 1708
0490, 0539, 0545
0503, 0591, 0741,
0869

Accurian
Apex Digital
Aspire Digital
CyberHome
Denon
Funai
Gateway
Go Video

iLo
JVC
LG
LiteOn
Magnavox
Panasonic
Philips
Pioneer
RCA
Samsung
Sensory Science
Sharp
Sony
Sylvania
Zenith

Home Theater in Box

Aiwa
Audiovox
JVC

KLH
Koss
Oritron
Polk Audio
RCA
Rio
Sonic Blue
Tea c
Venturer

DVD Recorder

1416
1056
116 8
112 9
0490
0675, 1334
115 8
0741, 1158, 1304,
1730
1348
116 4
0741
1158, 1416, 1440
0646, 0675
0490
0646, 1158
0631
0522
0490, 1470
115 8
0630, 0675
1033, 1431
0675
0741

0641
0790
1770, 1771, 1772,
1773
0790
0651
0651
0539
0790
0869
0869
0790
0790

56

Audio mode

Amstrad
Bose
Curtis Mathes
Durabrand
GE
Harman/Kardon
JVC
Left Coast
Lenoxx
Linn
Marantz
NEC
Optimus
Philips
Pioneer
Polk Audio
RCA
Shure
Sony
Soundesign
Victor
Wards
Yamaha

ADC
Aiwa

Akai
Alco
Amphion Media Works
AMW
Anam
Apex Digital
Audiotronic
Audiovox
Bose

Brix
Cambridge Soundworks
Capetronic
Carver
Classic
Coby
Criterion
Daewoo
Delphi
Denon

Garrard
Gateway
Go Video
Harman/Kardon

Initial
Insignia
Integra
JBL
JVC

Kenwood
KLH

Amplifier

Receiver

0078
0674
0300
1561
0078
0892
0331
0892
1561
0269, 0282, 0829
0892, 0269
0264
0300, 0823
0892, 0269
0013, 0300, 0823
0892, 0269
0300, 0823
0264
0689, 0815, 1126
0078
0331
0078, 0013
0354, 0133

0531
1405, 0121, 1243,
1388, 1641
1512
1390
1563, 1615
1563, 1615
1609, 1074
1257, 1430
118 9
1390
1229, 0639, 1841,
1933
1602
1370
0531
118 9
1352
1389
1420
1250
1414
1360, 0771, 1142,
1660, 2832
0463
1517
1532
0110, 0891, 1304,
1306
1426
1751
0135, 1298, 1320
0110, 1306
0531, 1374, 1495,
1560, 1676, 1871,
1894
1313, 1570, 1569
1390, 1412

Koss
Lasonic
Lenoxx
LG
Liquid Video
Magnavox

Marantz

Mitsubishi
NexxTech
Norcent
Nova
Onkyo

Optimus
Oritron
Panasonic

Philips

Pioneer

Polaroid
Polk Audio
Proscan
RCA

Regent
Rio
Saba
Samsung
Sansui
Sanyo
Sharp
Sharper Image
Sherwood
Shinsonic
Sirius
Sonic Blue
Sony

Stereophonics
Sunfire
Teac

Technics
Thorens
Toshiba
Venturer
Wards
XM
Yamaha

Zenith

Receiver

1366, 1497
1798
1437
1293, 1869
1497
1189, 1269, 0531,
1514
1189, 1269, 0891,
1289
1393
1751
1389, 1751
1389
0135, 0842, 1298,
1320, 1531
1023, 0531, 1074
1366, 1497
1308, 1518, 0367,
1288, 1316, 1548,
1633, 1763, 1764
1189, 1269, 0891,
1266, 1289, 1673
1023, 0014, 0150,
0531, 0630, 1123,
1384, 1823
1508
1289, 1414
1254
1023, 1609, 1254,
0531, 1074, 1123,
1390, 1511
1437
1869
0531, 1519
1295, 1500
1764
1251, 1469
0771, 1286
1556
1517, 1653
1426
1602
1532, 1869
1058, 1441, 1258,
1759, 1622, 0474,
1406, 1558, 1658,
1758, 1858, 1958
1023
1313
0463, 1074, 1390,
1528
1308, 1518, 1384
1189
1788
1390
0014
1406, 1414
0176, 1176, 1276,
1331, 1375, 1476
0857, 1293

Home Theater in Box

Aiwa
Amphion Media Works
AMW
Anam
Apex Digital
Audiovox
Bose
Cambridge Soundworks
Classic
Coby
Criterion
Daewoo
Denon
Durabrand
Gateway
Go Video
Initial
Insignia
Integra
JBL
JVC

KLH
Koss
Lasonic
Lenoxx
LG
Liquid Video
Magnavox
NexxTech
Norcent
Nova
Onkyo
Oritron
Panasonic

Philips
Pioneer
Polaroid
Polk Audio
RCA
Regent
Rio
Saba
Samsung
Sanyo
Sharper Image
Sherwood
Shinsonic
Sonic Blue
Sony

Teac
Toshiba
Venturer
Yamaha
Zenith

1388, 1641
1563, 1615
1563, 1615
1609
1257, 1430
1390
1229, 1933
1370
1352
1389
1420
1250
2832
1561
1517
1532
1426
1751
1298
1306
1374, 1495, 1676,
1871
1390, 1412
1366, 1497
1798
1561
1293, 1869
1497
1514
1751
1389, 1751
1389
1298, 1531
1366, 1497
1288, 1316, 1548,
1633, 1763, 1764
1266, 1673
1384
1508
1289
1609, 1390, 1511
1437
1869
1519
1295, 1500
1469
1556
1517
1426
1532, 1869
0689, 1622, 1558,
1658, 1758, 1858,
1958
1390, 1528
1788
1390
1331, 1375
1293

Etc.

57

INPUT 1

INPUT 2

INPUT 3

INPUT 1

INPUT 2

INPUT 3

Connecting Your Devices

Notes:

• The following connection diagrams are examples on connecting some of the most common
devices to your TV. Please refer to your device’s instruction manual on other connection
methods or for devices not shown here in this instruction book.

• When you are finished connecting your devices, turn on your TV and devices.

Connect an Antenna or Basic Cable

Cable or Antenna

Output

75 Ω

(VHF/UHF)

Notes:

• If you are able to receive ATSC (Digital terrestrial) signal, High Definition (HD) broadcasting

can be watched.

• All digital broadcasting is not necessary High Definition. Check by pressing the DISPLAY
button.

• Digital broadcasting is not available in all areas.

INPUT 1 INPUT 2 INPUT 3

TV Rear Panel

Connect a Cable Box

Cable or Antenna

Output

Note:

• To view channels on your cable box, make sure your TV’s channel is set to 2, 3 or 4

(depending on the area you live in).

58

CABLE BOX

IN

OUT

75 Ω

(VHF/UHF)

TV Rear Panel

INPUT 1 INPUT 2 INPUT 3

Connect a VCR / DVD Player using Component Video

Green cable is for “Y”

TV Rear Panel

(INPUT 4)

VCR / DVD Player

Blue cable is for “P

Red cable is for “P

Audio Out

L

R

Video Out

YPB

B”

R”

P

R

Notes:

• Green, blue and red are the most common colors for Component Cables. Some models may

vary in color.

• To watch your VCR / DVD player, make sure your TV is displaying INPUT 4 or INPUT 5 by
pressing the V4 or V5 button on your remote control.

Connect a VCR / DVD Player using Composite Video

TV Rear Panel

(INPUT 5)

Etc.

Yellow cable is for “Video”

White cable is for “L”

Red cable is for “R”

Audio Out

VCR / DVD Player

Video Out

L

Y

R

Notes:

• Yellow, white and red are the most common colors for Composite Cables. Some models may
vary in color.

• To watch your VCR / DVD player, make sure your TV is displaying INPUT 4 or INPUT 5 by
pressing the V4 or V5 button on your remote control.

• If your device has S-Video Output, you can use that instead of using Composite Cables.

Connect INPUT 4 (S-VIDEO) and S-video Output with an S-Video Cable.

59

Connecting Your Devices

Connect an Amplifier or Home Theater System

TV Rear Panel
(AUDIO OUT)

Amplifier

or

Home Theater System

SpeakerSpeaker

Notes:

• Refer to your amplifier’s or Home Theater System’s manual for more information.

• If you have a device connected to INPUT 1, INPUT 2 or INPUT 3, you will not be able to hear

any audio from the AUDIO OUT on the back of the TV otherwise.

Connect an Amplifier using the DIGITAL AUDIO OPTICAL OUT

TV Rear Panel

(DIGITAL AUDIO OPTICAL OUT)

(with DIGITAL AUDIO OPTICAL INPUT)

Notes:

• Refer to your amplifier’s manual for more information.

• This terminal can only output digital audio (PCM or DOLBY DIGITAL).

• In order to use the optical output connection, select PCM or DOLBY DIGITAL. See page 43.

• You can not output sound from your DIGITAL AUDIO OPTICAL OUT connection if the audio
source is from your HDMI device.

60

Amplifier

SpeakerSpeaker

Connect a Digital Source Device

INPUT 2

INPUT 3

75 Ω

(VHF/UHF)

TV Rear Panel

INPUT 1

HDMI ANALOG

AUDIO

TV Rear Panel (INPUT 1)

INPUT 1 INPUT 2 INPUT 3

Digital Source Device

LR

AUDIO OUT

After the connections have been made,

tighten the screw to secure the cables.

DIGITAL OUT

75 Ω

(VHF/UHF)

Notes:

• To watch your digital source device, make sure your TV is displaying INPUT 1 by pressing the
V1 button on your remote control.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• The INPUT 1 HDMI ANALOG AUDIO input can only be used with INPUT 1.

Connect a Camcorder

TV Rear Panel

Camcorder

(INPUT 4)

Etc.

Notes:

• To watch video from your camcorder, make sure your TV is displaying INPUT 4 or INPUT 5
by pressing the V4 or V5 button on your remote control.

• If your device has S-Video Output, you can use that instead of using Composite Cables.

Connect INPUT 4 (S-VIDEO) and S-video Output with an S-Video Cable.

61

INPUT 3

INPUT 1

75 Ω

(VHF/UHF)

Connecting Your Devices

Connect a Blu-ray or HDMI Device

TV Rear Panel (INPUT 2)

75 Ω

(VHF/UHF)

INPUT 1 INPUT 2 INPUT 3

Blu-ray / HDMI Compatible Device

Notes:

• To watch your Blu-ray or HDMI device, make sure your TV is displaying INPUT 1, INPUT 2 or
INPUT 3 by pressing the V1, V2 or V3 button on your remote control.

• Some decoders may not respond depending on the equipment that is connected to the HDMI.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• This JVC television can accept a variety of HD signals, including 720p, 1080i, 1080p/24Hz,

1080p/30Hz and 1080p/60Hz. Please note that in some cases, a Blu-ray may only offer the
choice of 1080/60i or 1080/24p. In this case, it is necessary to choose the 1080/60i output.
Please refer to your Blu-ray manual for complete details on choosing the correct output.

• Some HDMI Output Devices may fail to detect this TV as a 1080p device. If this occurs,

manually select 1080p on the HDMI Output Device.

62

Connect a Computer

INPUT 2

INPUT 3

75 Ω

(VHF/UHF)

PC

TV Rear Panel

Or...

PC

TV Rear Panel (INPUT 1)

75 Ω

(VHF/UHF)

Notes:

• Make sure your TV is displaying INPUT 1, INPUT 2, INPUT 3 or INPUT 5 by pressing the V1,
V2, V3 or V5 button on your remote control.

• To use PC Smart Input function, see page 43.

• When you connect a PC using HDMI-DVI cable, connect an audio cable to INPUT 1 HDMI
ANALOG AUDIO on the TV.

• Use a D-SUB cable with ferrite cores and no longer than 3 meters to avoid electromagnetic
disturbances.

• Refer to your computer’s manual for more information.

INPUT 1 INPUT 2 INPUT 3

Etc.

Resolution

Format

VGA

SVGA

XGA

D-SUB

640 x 480

800 x 600

1024 x 768

V. Frequency

(Hz)

60

60

60

H. Frequency

(kHz)

31.5

37.9

48.4

Format

VGA

SVGA

XGA

FHD

HDMI

Resolution

640 x 480

800 x 600

1024 x 768

1920 x 1080

V. Frequency

(Hz)

60

60

60

60

Notes:

• Depending on signal quality, some pictures may not be displayed correctly.

• Computers that cannot set the refresh rate to 60 Hz, cannot be used with this TV.

• If you are inputting a PC signal that is invalid, “No signal or Signal can not be displayed” will

appear on the TV screen. It appears when the input is PC and it is a single screen.

• When you connect a PC using an HDMI cable, the TV image may not be displayed correctly.

H. Frequency

(kHz)

31.5

37.9

48.4

67.4

63

Troubleshooting

Refer to the table below to check the condition. If you think that there is a problem, contact the
JVC Service Center where you purchased the television.

There is no power

• See if the power cord became unplugged.

• Check for a blown fuse or circuit breaker or a power outage.

There is no picture or sound

• The antenna could be disconnected.

• The tuner could be set improperly. See page 58.

• The TV station may be having diffi culties. Check to see if other stations are working.

• Use the HDMI cable with HDMI logo.

• If you have a device connected to INPUT-1, INPUT-2 or INPUT-3, you will not be able to

hear any audio from the AUDIO OUT on the back of the TV.

• You cannot output audio using the DIGITAL AUDIO OPTICAL OUT when you have digital

sound from an HDMI device connected to the INPUT-1, INPUT-2 or INPUT-3 connection on
the back of the TV.

• This TV can accept 480i (Composite / S / HDMI / Component), 480p, 720p, 1080i and

1080p signals. Please check your settings.

Remote control is not operating properly or at all

• Check to see that the batteries are still working and properly installed.

• Make sure the remote has a clear sight path to the TV.

• You may be too far from the TV. You must be within 23 feet (7 meters).

The power turns off by itself

• Make sure the set did not become unplugged.

• Perhaps the Auto Shut Off is set. See page 41.

• Check to see if the Sleep Timer was set. See page 18.

It does not operate correctly

• This television is operated by a microprocessor. It is possible that external noise or

interference is causing the problem. If the television does not function correctly, remove
the electrical plug from the wall outlet and wait a while before inserting it into the wall outlet
again and operating the television.

The color quality is poor

• Tint and Color may be improperly adjusted. See page 26.

• The Video Status mode may be turned to the wrong setting. See page 26.

There are lines across the picture

• There could be interference from another electrical appliance, such as a computer, another

TV or VCR. Move any such appliances further away from the TV.

The picture is spotted

• There could be interference from a high-wattage appliance, like a hairdryer or vacuum,

operating nearby. Move the antenna away from the appliance or change to a coaxial cable
connection which is less prone to interference.

There are double pictures (ghosts)

• A building or passing airplane can refl ect the original signal and produce a second, slightly

delayed one. Adjust your antenna position.

64

Picture is snowy (image noise)

• Your antenna may be damaged, disconnected or turned. Check the antenna connection. If
the antenna is damaged, replace it.

Screen is 80% black

• The Closed Caption Text mode is on. Turn it off in the Closed Caption menu, page 31.

Stereo or bilingual programs can’t be heard

• Make sure the MTS settings are correct. See page 39.

Static electricity

• It is normal to feel static electricity if you brush or touch the screen.

You hear occasional crackling sounds

• It is normal for the TV to make crackling sounds when fi rst turned on or off. Unless the
sound or picture become abnormal, this is fi ne.

The picture is slightly cut off when you use 1080p format only

• Change the picture format setting on your external device to 1080i or other resolution.

The screen disappears except for the menu screen

• This occurs when you select a digital menu when your input source is from the HDMI
connection. Press the MENU button.

My HDMI device doesn’t work or doesn’t work properly

• Please usa a High Speed HDMI™ Cable. High Speed HDMI™ Cable are tested to carry
an HD signal up to 1080p and higher.

No signal or signal can not be displayed

• This OSD appears when the digital channel that you have selected is too weak to receive

or no signal is being detected for that channel.

• It appears when that channel is not receiving a signal and you have the Noise Mute

function Off and you have a single screen. It moves automatically every two seconds to
prevent the screen from burn-in.

• Even if “No signal or signal can not be displayed” appears on the screen, your timer

functions and auto shut off functions that you set, are still active.

Etc.

The following are not malfunctions.

• The television may make a creaking sound if the temperature of the room or the temperature

of the inside of the television changes. If there is no problem with the screen or sound, then
there is no need to worry.

• The picture may be temporarily disturbed and noise may be seen on the screen if the power

is turned on immediately after it has been turned off. This is not a malfunction.

65

Specifi cations

Model

Reception Format

Reception Range

Power Source

Power Consumption

Screen Size

Audio Output 10W + 10W

Speakers

iPod Output

Power

Antenna Terminal

(VHF/UHF,

ATSC/DIGITAL

CABLE IN)

Input 4, 5
Terminal

Input 4, 5 Terminal

(Component Terminal)

Input 1, 2, 3 Terminal

(HDMI Input Terminal)

LT-32P300

LCD Flat TelevisionType

NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable

CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable

VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands

• Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers)

155W

32 inch / 80.03 cm

measured diagonally,

16:9 ratio

480i
S (Input 4)
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance

1080i / 720p / 480p / 480i
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
P

B/PR: 0.7 Vp-p 75 ohms

Video: 1080p / 1080i / 720p / 480p / 480i
Audio: 2ch PCM, 32 / 44.1 / 48 KHz 16 / 20 / 24 bit

VHF 2 to 13, UHF 14 to 69 at ATSC,

(191 channel frequency synthesizer system) at Analog

is not recommended for your TV set.

AC 120V, 60 Hz

4 x 16cm Oblique x 2

75 ohms (VHF/UHF)(F-type connector)

5 V, 500 mA

LT-42P300

LT-42PM30

215W

42 inch / 106.73 cm

measured diagonally,

16:9 ratio

PC Input Jacks

Audio Output Jacks

(FIX)

Optical Output

Digital Audio

Dimensions (inch/mm)

W X H X D

Weight (lbs / kg)

31 1/4 x 23 1/2 x 9 1/8

(with stand)

792 x 595.7 x 230

(with stand)

31 1/4 x 21 1/2 x 4 3/8

(without stand)

792 x 544.6 x 109.6

(without stand)

29.0 / 13.2 (with stand)

27.1 / 12.3 (without stand)

Analog RGB D-SUB (15 pin) x 1

FIX : 500mVrms (-4dBs), Low Impedance

Specifications subject to change without notice.

66

Digital Out (optical) x 1

39 7/8 x 28 7/8 x 11 5/8

(with stand)

1013.6 x 733.5 x 296
(with stand)

39 7/8 x 26 5/8 x 4 1/2

(without stand)

1013.6 x 677.3 x 114.8
(without stand)

49.5 / 22.5 (with stand)

46.0 / 20.9 (without stand)

67

U.S.A.

TOLL FREE: 1 [phone]
http://www.jvc.com

Canada

TOLL FREE: 1 [phone]
http://www.jvc.ca

Remember to retain your Bill of Sales for Warranty Service.

Digital Television Transition Notice:

This device contains a digital television tuner, so it should receive digital over the air TV
programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the
United States on February 17, 2009.

Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive
over the air digital programming, but should continue to work as before for other purposes (e.g.,
for watching low-power TV stations still broadcasting in analog, watching pre-recorded movies,
or playing video games).

For more information, see http://www.DTV.gov or call 1-888-CALL-FCC. For converter box
information, see http://www.dtv2009.gov or call the NTIA at 1–888–DTV–2009.

JVC COMPANY OF AMERICA

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square

Scarborough, Ontario

Canada, M1X 1A7
