JVC LCT1676-001B-A, 1204TNH-II-IM User Manual

Projection Television Users Guide

For Models:

AV-56P785 AV-56P775 AV-48P775

Illustration of AV-56P775 and RM-C14G

Important Note:

In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.

Model Number:

Serial Number:

LCT1676-001B-A

1204TNH-II-IM

Important Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV

SET TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to

* To prevent electric shock do not use this polarized plug with an

ventilation is unattainable.

not attempt to repair it yourself or remove the rear cover.

disconnect both the power plug from the AC outlet and antenna for your safety.

extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.

IMPORTANT RECYCLING INFORMATION

This product utilizes both a Cathode Ray Tube (CRT) and other components that contain lead. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities, or the Electronic Industries Alliance: http://www.eiae.org

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Important Safeguards

CAUTION:

Please read and retain for your safety.

Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. But improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards incorporated in this TV set, observe the following basic rules for its installation, use and servicing. Also follow all

warnings and instructions marked on your TV set.

INSTALLATION

1 Your TV set is equipped with a polarized AC line plug (one

blade of the plug is wider than the other). This safety feature allows the plug to fit into the power outlet only one way. Should you be unable to insert the plug fully into the outlet, try reversing the plug. Should it still fail to fit, contact your electrician.

2 Operate the TV set only from a power source as indicated on the TV set or refer to the

operating instructions for this information. If you are not sure of the type of power supply to your home, consult your TV set dealer or local power company. For battery operation, refer to the operating instructions.

3 Overloaded AC outlets and extension cords are dangerous, and so are frayed power cords

and broken plugs. They may result in a shock or fire hazard. Call your service technician for replacement.

4 Do not allow anything to rest on or roll over the power cord, and do not place the TV set

where power cord is subject to traffic or abuse. This may result in a shock or fire hazard.

5 Do not use this TV set near water — for example, near a bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or near swimming pool, etc.

6 If an outside antenna is connected to the TV set, be sure the antenna system is grounded

so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection requirements for the grounding electrode.

(POLARIZED-TYPE)

7 An outside antenna system should not be located in the vicinity of overhead power lines

or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

ELECTRICAL SERVICE EQUIPMENT

NEC - NATIONAL ELECTRIC CODE

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ARTICLE 250, PART H)

8 TV sets are provided with ventilation openings in the cabinet to allow heat generated during

operation to be released.

Therefore:

— Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa,

rug, etc.

— Never place a TV set in a “built-in” enclosure unless proper ventilation is provided. — Never cover the openings with a cloth or other material. — Never place the TV set near or over a radiator or heat register.

9 To avoid personal injury:

— Do not place a TV set on a sloping shelf unless properly secured.

— Use only a cart or stand recommended by the TV set manufacturer. — Do not try to roll a cart with small casters across thresholds or deep pile carpets. — Wall or shelf mounting should follow the manufacturer’s instructions, and should use a

mounting kit approved by the manufacturer.

Use

10 Caution children about dropping or pushing objects into the TV set through cabinet

openings. Some internal parts carry hazardous voltages and contact can result in a fire or electrical shock.

11 Unplug the TV set from the wall outlet before cleaning. Do not use liquid or an aerosol

cleaner.

12 Never add accessories to a TV set that has not been designed for this purpose. Such

additions may result in a hazard.

PORTABLE CART WARNING

(Symbol provided by RETAC)

13 For added protection of the TV set during a lightning storm or when the TV set is to be left

unattended for an extended period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to product due to lightning storms or power line surges.

14 A TV set and cart combination should be moved with care. Quick stops, excessive force,

and uneven surfaces may cause the TV set and cart combination to overturn.

Service

15 Unplug this TV set from the wall outlet and refer servicing to qualified service personnel

under the following conditions: A. When the power cord or plug is damaged or frayed. B. If liquid has been spilled into the TV set. C. If the TV set has been exposed to rain or water. D. If the TV set does not operate normally by following the operating instructions. Adjust

only those controls that are covered in the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV set to normal operation.

E. If the TV set has been dropped or damaged in any way. F. When the TV set exhibits a distinct change in performance — this indicates a need for

service.

16 Do not attempt to service this TV set yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17 When replacement parts are required, have the service technician verify in writing that the

replacement parts he uses have the same safety characteristics as the original parts. Use of manufacturer’s specified replacement parts can prevent fire, shock, or other hazards.

18 Upon completion of any service or repairs to this TV set, please ask the service technician

to perform the safety check described in the manufacturer’s service literature.

19 When a TV set reaches the end of its useful life, improper disposal could result in a picture

tube implosion. Ask a qualified service technician to dispose of the TV set.

20 Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Warnings

Screen Burn-in

Displaying ﬁ xed images on your screen for extended periods of time can leave a subtle but permanent ghost image in your screen. This is referred to as "burn-in". To avoid this, mix your viewing patterns and aspect modes from time to time..

Examples include, but are not limited to the following:

• Stock-market report bars

• Shopping channel logos and pricing displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style images.

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or digital television tuners/converters.

• Aspect modes that leave solid black bars on the top and bottom, or both sides of the screen.

Note: Warranty DOES NOT cover screen burn-in or uneven picture tube aging.

TV on

For example...

TV off

XYZ XYZ

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen. These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image distortions.

Table of Contents

Important Safety Precautions . 2

Warnings . . . . . . . . . . . . 6

Quick Setup . . . . . . . . . . . 9

Unpacking your TV . . . . . . . . . . . . 9

TV Models . . . . . . . . . . . . . . . . 11

TV Remote Control . . . . . . . . . . . 12

Getting Started . . . . . . . . . . . . . 13

The Remote Control . . . . . . . . . . 13

Connecting Your Devices . . . . . . . 14

Interactive Plug In Menu . . . . . . . . 25

Remote Programming . . . . . 28

Setting CATV, VCR and DVD Codes . . . 28

CATV or Satellite Codes . . . . . . . . 28

VCR Codes . . . . . . . . . . . . . . 29

DVD Codes . . . . . . . . . . . . . . 30

Search Codes . . . . . . . . . . . . . 31

Onscreen Menus . . . . . . . . 32

Using the Guide . . . . . . . . . . . . . 32

Onscreen Menu System . . . . . . . . . 33

Initial Setup . . . . . . . . . . 35

Auto Tuner Setup . . . . . . . . . . . . 35

Channel Summary . . . . . . . . . . . . 36

Channel Label . . . . . . . . . . . . 37

V-Chip . . . . . . . . . . . . . . . . . . 38

Set Lock Code . . . . . . . . . . . . . 43

Adjusting CRT Color Conversion . . . . . 44

Auto Demo . . . . . . . . . . . . . . . 46

Language . . . . . . . . . . . . . . . . 46

Closed Caption . . . . . . . . . . . . . 47

Auto Shut Off . . . . . . . . . . . . . . 49

XDS ID . . . . . . . . . . . . . . . . . 49

Noise Muting . . . . . . . . . . . . . . 49

Front Panel Lock . . . . . . . . . . . . 50

V1 Smart Input . . . . . . . . . . . 50

Video Input Label . . . . . . . . . . 51

Position Adjustment . . . . . . . . . . . 52

Power Indicator . . . . . . . . . . . . . 52

Digital-In . . . . . . . . . . . . . . . . . 53

Digital-In Audio . . . . . . . . . . . . . 53

Center CH Input . . . . . . . . . . . . . 54

Video-1 Monitor Out . . . . . . . . . . 54

Sound Adjust . . . . . . . . . 57

Sound Settings . . . . . . . . . . . . . 57

Adjust Sound Settings . . . . . . . . . 57

Reset . . . . . . . . . . . . . . . . . . 57

Clock Timers . . . . . . . . . . 58

Set Clock . . . . . . . . . . . . . . . . 58

On/Off Timer . . . . . . . . . . . . . . . 59

Button Functions . . . . . . . 60

Multi Screen Function . . . . . . . . . . 60

Twin . . . . . . . . . . . . . . . . . . 60

Index . . . . . . . . . . . . . . . . . 61

Freeze . . . . . . . . . . . . . . . . . . 61

Swap . . . . . . . . . . . . . . . . . 61

Select . . . . . . . . . . . . . . . . . . 61

Power . . . . . . . . . . . . . . . . . . 62

Number Buttons . . . . . . . . . . . . . 62

Tune . . . . . . . . . . . . . . . 62

Input . . . . . . . . . . . . . . . . . . . 62

Channel +/- . . . . . . . . . . . . . 62

Volume +/- . . . . . . . . . . . . . 62

Return +/TV . . . . . . . . . . . . . . . 63

Sound . . . . . . . . . . . . . . . . . . 63

Video Status . . . . . . . . . . . . . . . 64

Natural Cinema . . . . . . . . . . . . . 64

TheaterPro D6500K . . . . . . . . . . . 64

Sleep Timer . . . . . . . . . . . . . . . 65

ML/MTS . . . . . . . . . . . . . . . . . 65

Muting . . . . . . . . . . . . . . . . . . . 65

Display . . . . . . . . . . . . . . . . 66

C.C. . . . . . . . . . . . . . . . . . . . 66

Favorite . . . . . . . . . . . . . . . . 67

Aspect . . . . . . . . . . . . . . . . . 68

Aspect Ratios . . . . . . . . . . . . . 68

Menu . . . . . . . . . . . . . . . . . . 69

OK . . . . . . . . . . . . . . . . . . . 69

Back . . . . . . . . . . . . . . . . . . . 69

TV/CATV Slide Switch . . . . . . . . . . 70

VCR/DVD Slide Switch . . . . . . . . . 70

VCR Buttons . . . . . . . . . . . . . . . 70

DVD Buttons . . . . . . . . . . . . . . . 70

Light . . . . . . . . . . . . . . . . . . . 70

Super Focus . . . . . . . . . . . . . . . 70

Picture Adjust . . . . . . . . . 55

Picture Settings . . . . . . . . . . . . . 55

Adjust Picture Settings . . . . . . . . . 55

Color Temperature . . . . . . . . . . . . 55

Digital Noise Clear . . . . . . . . . . . . 56

VSM . . . . . . . . . . . . . . . . . . . 56

Reset . . . . . . . . . . . . . . . . . . 56

Table of Contents (Continued...)

Digital Setup . . . . . . . . . . . 71

Digital Setup . . . . . . . . . . . . . . . 71

Antenna Level . . . . . . . . . . . . . 71

Digital Sound . . . . . . . . . . . . . . 72

Aspect Ratios . . . . . . . . . . . . . . 72

Cable Card Application . . . . . . . . . 73

i.LINK Auto Play . . . . . . . . . . . . 73

Software Update . . . . . . . . . . . . 73

Digital Button Functions . . . 74

Digital CH D/A (Digital/Analog) . . . . . 74

Sub Channel . . . . . . . . . . . . . 74

i.LINK Menu . . . . . . . . . . . . . 75

Timer . . . . . . . . . . . . . . . . 77

Guide . . . . . . . . . . . . . . . 79

OSD Information . . . . . . . . 80

Weak Signal . . . . . . . . . . . . . 80

Cable Card Information . . . . 81

Cable Card Connection . . . . . . . . 81

Appendices . . . . . . . . . . 82

No Program . . . . . . . . . . . . . . 82

Troubleshooting . . . . . . . . . . . . . 83

Warranty . . . . . . . . . . . . . . . . . 84

Authorized Service Centers . . . . . . . 85

Specifications . . . . . . . . . . . . . . . 86

Quick Setup Unpacking your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items. In addition to this guide, your television box should include:

Television x 1

DIGITAL IMAGE SCALING TECHNOLOGY

POWER

PROGRAM

PULL/OPEN

Splitter x 2

2-WAY SPLITTER

Remote Control x 1

POWER

CATV VCR DVD

ASPECT

MULTI SCREEN

INDEX

SELECT

TWIN

SLEEP

FREEZE

SWAP

ML/MTS

DISPLAY

INPUT

123

D/A

456

i.LINK MENU

789

RETURN+

TIMER

TUNE

THEATER

VIDEO

SUB

FAVORITE

CHANNEL

PRO

STATUS

SUB

NATURAL CINEMA

SOUND

LIGHT

C.C.

MUTING

GUIDE

VOL VOL

BACK

VCR CHANNEL

VCR DVD

PREV NEXT

POWER

TV VCR

REW

FFPLAY

REC PAUSE

STOP

OPEN CLOSE

STILL PAUSE

RM-C14G

Batteries x 2

AA Alkaline

Note: Your television and/or remote control may differ from the examples illustrated here.

RF Cables x 2

Quick Setup Unpacking your TV

Once you have unpacked your television, the next step is to connect it to your antenna/ cable or satellite system and to connect the audio/video devices you want to use with your television. To make these connections you will use plugs like the ones illustrated below.

Coaxial Cables

Used to connect an external antenna or cable TV system to your TV.

S-Video Cable

Used to make video connections with S-Video VCRs, Camcorders and DVD players.

Component Cables

Composite Cables

Audio Cables

Used to connect audio/ video devices like VCRs, DVD players, stereo amplifiers, game consoles, etc.

AV CompuLink Cable

Used to connect JVC AV CompuLink capable components for an automated home theater.

We recommend that before you start using your new television, you read your entire User’s Guide so you can learn about your new television’s many great features. If you’re anxious to start using your television right away, a quick setup guide follows on the next few pages.

Quick Setup TV Models

NOTE: Before you connect your television to another device, please refer to the proper

diagrams for your specific TV and remote. These will help assist you in understanding how to connect your television to another device, as well as use the remote to set up your television.

Rear Panel Diagram

UNPLUG THE POWER CORD FROM AC OUTLET BEFORE REMOVING THE REAR COVER

When the rear cover is removed, follow "CAUTION AT DISASSEMBLY" procedure in the

MODELS: AV-56P785 AV-56P775 AV-48P775

Note: The terminal

labeled "SERVICE ONLY", is exclusively used to update the software version.

75Ω (VHF/UHF)

AV COMPULINK III

ATSC

/DIGITAL CABLE IN

CABLE CARD

i.LINK IN/OUT S400(TS)

OPTICAL OUT

Digital Audio

CENTER

CHANNEL

INPUT

AUDIO OUT

SERVICE ONLY

INPUT-3

INPUT-2

INPUT-1

AUDIO VIDEO

service manual before plugging the TV's power cord into an AC outlet. Failure to follow the procedure will result in PERMANENT damage to some of the television features. DÉBRANCHEZ LE CORDON DE LA PRISE DE COURANT C.A. AVANT DE RETIRER LE COUVERCLE ARRIÈRE. Une fois le couvercle arrière déposé suivez la procédure ««ATTENTION LORS DU DÉMONTAGE»» décrite dans la manuel de service avant de brancher le cordon du téléviseur dans une prise c.a. L'omission de suivre la procédure causera des dommages PERMANENTS à certaines fonctions du téléviseur.

Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc. Sous licence de BBE Sound, Inc. BBE et le symbole BBE sont des marques déposées de BBE Sound, Inc. Licenciado de BBE Sound, Inc. BBE y el simbolo de BBE son marcas registradas de BBE Sound, Inc.

Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

MACROVISION PATENT NUMBERS U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098; 4,907, 093; and 6,516,132. LICENSED FOR LIMITED PAY-PER-VIEW USES ONLY.

AUDIO (ANALOG)

VIDEO (DIGITAL)

AUDIO (DIGITAL)

DIGITAL IN

OVER

S-VIDEO

VIDEO

AUDIO

MONITOR /REC OUT

INPUT–1INPUT–2

COMPONENT VIDEO

LC32925-001A-A

Front Panel Diagram

P U

- 4

S-VI

DE O

VIDEO

O V E R

A U

L / M

DIO

DIGITAL IM

AGE SCALING

TECHNOLOG

CHANNEL

– + – +

P O W

VOLUME

E R

PER

ATE

R O

SUPER

G R A

FOCUS

P U L

L / O P

E N

PULL/OPEN

MENU CHANNEL VOLUME SUPER

– + – +

OPERATE

FOCUS

DIGITAL IMAGE SCALING TECHNOLOGY

DIGITAL IM

AGE SCALING

TECHNOLOG

P O W

E R

P R O

G R A M

P U L

L /O P E N

Pull to open the door

POWER

PROGRAM

PULL/OPEN

INPUT- 4

S-VIDEO VIDEO AUDIO

OVER

RL / MONO

MODELS: AV-56P785, AV-56P775, AV-48P775

Note: When you have set a REC timer or VIEW timer, a PROGRAM indicator will light on the

front panel. While a timer is set, the indicator light will not turn off even if you turn the power off. See page 77.

Quick Setup TV Remote Control

CATV VCR DVD

MULTI SCREEN

INDEX

TWIN

FREEZE

SWAP

INPUT

123

D/A

456

i.LINK MENU

789

TIMER

TUNE

THEATER

FAVORITE

PRO

SOUND

C.C.

MUTING

OPEN CLOSE

VOL VOL

VCR CHANNEL

PREV NEXT

REW

STOP

REC PAUSE

RM-C14G

ASPECT

SELECT

ML/MTS

VIDEO

STATUS

NATURAL

CINEMA

VCR DVD

POWER

STILL PAUSE

POWER

SLEEP

DISPLAY

RETURN+

SUB

CHANNEL

SUB

LIGHT

GUIDE

BACK

TV VCR

FFPLAY

RM-C14G

MODELS: AV-56P785 AV-56P775 AV-48P775

• For information on remote control buttons, see pages 60-70 and 74-80.

• i.LINK MENU, TIMER, SUB CHANNEL, FAVORITE and GUIDE buttons are for digital channels. If your TV is connected to an ATSC antenna or Digital Cable, you can use these buttons.

Quick Setup Getting Started

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you need to begin using your new television right away.

If you have questions, or for more detailed information on any of these steps, please consult other sections of this manual.

Step 1 – The Remote Control

Before you can operate your remote control, you first need to install the batteries (included).

Slide the cover on the back of the remote down towards the bottom of the remote control. Insert two batteries (included) carefully noting the “+” and “–” markings, placing the “–” end in the unit first. Slide the cover back into place.

When you change the batteries, try to complete the task within three minutes. If you take longer than three minutes, the remote control codes for your VCR, DVD, and/or cable box/satellite receiver may have to be reset. See pages 28 - 31.

Key Feature Buttons

The four key feature buttons at the center of the remote can be used for basic operation of the television. The top and bottom buttons will scan forward and back through the available channels. To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH –. The channels will zip by at a rate of five channels per second. The right and left buttons will turn the volume up or down. These buttons are also marked with four arrows and are used with JVC’s onscreen menu system. To use the onscreen menus, press the M

ENU button.

MUTING

VOL VOL

GUIDE

BACK

Basic Operation

Turn the television on and off by pressing the POWER button at the top right corner of the remote. If this is the first time you are turning on the TV, the interactive plug-in menu appears.

• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if you need to operate a cable box.

• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to DVD to control a DVD player. Please see pages 28 to 31 for instructions on programming your remote control to operate a cable box, VCR or DVD player.

POWER

CATV

VCR DVD

Quick Setup Connections

Step 2 – Connecting Your Devices

Notes:

• These connections are examples.

• After you are finished connecting your devices, plug the power cord into the nearest power outlet and turn on the TV.

• To connect a DVD player, see VCR Connection. A DVD player is optional

• If you have a satellite television system, refer to the satellite TV manual.

No VCR Connection

Cable or Antenna

Output

Two-way Splitter

OUT OUT

(Attachment)

75Ω (VHF/UHF)

ATSC

/DIGITAL CABLE IN

TV Rear Panel

Coaxial Cable

(Attachment)

Quick Setup Connections

VCR Connection

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables.

• You may also connect the DVD player to Input 1.

Diagram #1

ATSC

/DIGITAL CABLE IN

Cable or Antenna

Output

Coaxial Cable

(Attachment)

TV Rear Panel

OUT OUT

Coaxial Cable

(Attachment)

Two-Way

Splitter

(Attachment)

CENTER

CHANNEL

INPUT

75Ω (VHF/UHF)

AV COMPULINK III

DVD Player (OPTIONAL)

AUDIO OUT

AUDIO VIDEO

AUDIO OUT

R L

OUT

VCR

R L V

OUT

INPUT-1INPUT-2

INPUT-3

INPUT-2

INPUT-1

VIDEO

OVER

AUDIO

OVER

MONITOR

S-VIDEO

/REC OUT

COMPONENT VIDEO

Y P

OUT

Green

Blue

Red

Note:

• If this connection setup does not work for you, try the connection setup on page 16.

Quick Setup Connections

Diagram #2

Coaxial Cable

(Attachment)

Two-Way

Splitter

(Attachment)

/DIGITAL CABLE IN

OUT OUT

ATSC

Two-Way

Splitter

Coaxial Cable

(Attachment)

Cable or Antenna

Output

OUT OUT

OUT

75Ω (VHF/UHF)

AV COMPULINK III

TV Rear Panel

DVD Player (OPTIONAL)

Coaxial Cable

OUT

CENTER

CHANNEL

INPUT

AUDIO OUT

R L V

AUDIO VIDEO

R L

INPUT-3

INPUT-2

INPUT-1

VCR

INPUT-1INPUT-2

VIDEO

OVER

AUDIO

OVER

MONITOR

S-VIDEO

/REC OUT

Y P

OUT

COMPONENT VIDEO

Green

Blue

Red

Quick Setup Connections

Connecting to Monitor/Recording Output Terminal

INPUT-1INPUT-2

TV Rear Panel

75Ω (VHF/UHF)

AV COMPULINK III

CENTER CHANNEL

INPUT

AUDIO OUT

AUDIO VIDEO

INPUT-3

INPUT-2

INPUT-1

R L V

OUT

Notes:

• When you this connection, Set the Video-1 Monitor Out menu to ON. See page 54.

• If you are receiving ATSC/Digital Cable signal, it can be outputted to the S-Video output terminal or Video (composite video) terminal.

• If you are receiving Analog TV signal, it can not be outputted to the S-Video output terminal.

• No signal will be outputted through the S-Video output terminal when you are not viewing images coming from the composite video input terminal.

• No signal will be outputted through the Monitor/Recording output terminal when you are viewing images from the component video input.

VIDEO

OVER

AUDIO

OVER

S-VIDEO

COMPONENT VIDEO

VCR

Quick Setup Connections

Connecting to JVC AV Compu Link

JVC’s AV CompuLink feature makes playing video tapes or DVDs totally automatic. Simply insert a pre-recorded tape into your JVC brand VCR or DVD into your JVC DVD player and the device will automatically turn on and begin playback. At the same time, using the AV CompuLink, the VCR or DVD player sends a signal to the television telling it to turn on and switch to the proper video input.

• The AV CompuLink cable may be included with the JVC AV CompuLink unit you wish to connect. If it is not, contact JVC Parts Department at (800)-882-2345, or www.jvcservice.com for part # EWP 805-012.

• AV CompuLink can only be used with JVC brand products.

AV CompuLink Cable

To Connect: Plug one end of the AV CompuLink cable

into the AV COMPULINK INPUT on your VCR, DVD, or other CompuLink device. Plug the other end of the AV CompuLink cable into the AV COMPULINK at the rear of the television.

Note:

• The AV CompuLink cable has a male 3.5 mm (mono) plug on each end.

TV Rear Panel

AV COMPULINK III

OUT

V L R

AV CompuLink

VCR

OUT

Notes:

• In order for the VCR playback to begin automatically, the recording tabs must be removed from the VHS tape. If the tab is in place, automatic switching will occur when you push the VCR’s PLAY button.

• If your JVC brand VCR has “A code/B code remote control switching” (see your VCR’s instruction book), using VCR A code will switch the TV to input 1.

• Refer to your DVD instruction book for detailed connection information.

• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see the receiver connection instructions for detailed connection information.

• AV CompuLink is compatible with select AV CompuLink receivers.

Quick Setup Connections

Connecting to a Camcorder

You may connect a camcorder, game console or other equipment to your television by using the front input jacks (Input 4) located under the front panel door. To access, pull on the door to open it. You can also connect these using the television’s rear input jacks, using the same instructions.

INPUT- 4

S-VIDEO VIDEO AUDIO

OVER

1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on

the front of the TV, OR connect an S-Video cable from the front of the TV to the camcorder.

2) Connect a white cable from the camcorder LEFT AUDIO OUT, into the LEFT AUDIO IN on

the front of the TV.

3) Connect a red cable from the camcorder RIGHT AUDIO OUT, into the RIGHT AUDIO IN on

the front of the TV.

Note:

• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to the

LEFT AUDIO IN on the front of the TV.

- OR -

RL / MONO

MENU CHANNEL VOLUME SUPER

– + – +

OPERATE

FOCUS

CAMCORDER

Connecting to an External Amplifier

SpeakerSpeaker

Amplifier

75Ω (VHF/UHF)

1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to

the LEFT AUDIO INPUT on the amplifier.

2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to

the RIGHT AUDIO INPUT on the amplifier.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

CHANNEL

AV COMPULINK III

TV Rear Panel

CENTER

INPUT

AUDIO OUT

Quick Setup Connections

Connecting to the Surround Amplifier

In multi-channel sound such as 5.1 channel, the speech characters are played back from the center speaker.

A center speaker in a movie theater is set in back of the screen so it can recreate a conversation scene in the movie more natually. By using your TV's speaker as the center speaker, you can obtain the same sound effect as in a movie theater in you home theater sound system.

Front Surround

Front

TV Rear Panel

CENTER

CHANNEL

INPUT

75Ω (VHF/UHF)

AV COMPULINK III

1) Connect the Pin cable from the TV's CENTER CHANNEL INPUT terminal to the surround

amplifier's CENTER CHANNEL OUTPUT terminal.

Note:

• Please read the benefit of this feature on page 54.

AUDIO OUT

CENTER CHANNEL OUTPUT

Connecting to an amplifier using your optical output

You can connect an amplifier that has an optical digital input terminal by using an optical digital cable from the optical output. The signal that is output can be PCM or Dolby Digital.

Television Rear Panel

OPTICAL OUT

Digital Audio

Amplifier

1) Connect the optical cable from the back of the television to the back of the amplifier.

Notes:

• This terminal can only output digital audio.

• In order to use the optical output connection, select PCM or Dolby Digital on Digital Sound in

the Digital Setup Menu. See page 72.

• Refer to your owners manual on using your amplifier.

Quick Setup Connections

Connecting to a Digital TV Receiver

By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in their digital form.

DTV Decoder

AUDIO OUTDIGITAL OUT

HDMI to DVI Cable

After the connections have been made,

tighten the screw to secure the cables.

1) Connect the HDMI to DVI Cable from the DIGITAL OUT on the back of your DTV decoder, to the DIGITAL-IN on the back of your television.

2) Connect a red cable from the DTV decoder RIGHT AUDIO OUT, to the RIGHT AUDIO DIGITAL-IN on the back of your television.

3) Connect a white cable from the DTV decoder LEFT AUDIO OUT, to the LEFT AUDIO DIGITAL-IN on the back of your television.

• The digital-in terminal is not compatible with the picture signal of a personal computer.

• Use a HDMI to DVI cable (commercially available) in order to digitally connect the television

with a DTV decoder.

AUDIO (ANALOG)

VIDEO (DIGITAL)

AUDIO (DIGITAL)

DIGITAL IN

TV Rear Panel

Notes:

• If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance

may be slightly shifted. Access the “DIGITAL-IN” in the initial setup menu to adjust it. (Refer to page 53.)

• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to

ANALOG. See "DIGITAL-IN AUDIO", page 53.

Quick Setup Connections

Connecting to an HDMI Compatible Device

By connecting an HDMI compatible device, high definition pictures can be displayed on your TV in their digital form. Some HDMI devices can include DVD players, D-VHS or any HDMI compatible device.

HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all digital audio/video interface. HDMI provides and interface between any audio/video source, such as a set-top box, DVD player, A/V receiver or an audio and/or video monitor, such as a digital television (DTV).

HDMI Compatible Device

DIGITAL OUT

AUDIO OUT

HDMI Cable

AUDIO (ANALOG)

VIDEO (DIGITAL)

AUDIO (DIGITAL)

DIGITAL IN

TV Rear Panel

1) Connect the HDMI Cable from the DIGITAL OUT on the back of your DTV or HDMI device, to

the DIGITAL-IN on the back of your television.

Notes:

• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to

DIGITAL. See "DIGITAL-IN AUDIO", page 53.

• Some decoders may not respond depending on the equipment that you have connected

when it is connected to the HDMI.

Quick Setup Connections

Connecting to an AV Receiver using your television's V1 Smart Input

By connecting your AV Receiver to your television's V1 Smart Input, you can watch picture sources from many different devices, without having to change or use the other input connections on your TV. This allows you to free up the other input connections so you can connect more devices to your television.

AV Receiver

MONITOR

OUT

MONITOR OUT

AUDIO VIDEO

INPUT-3

INPUT-2

INPUT-1

INPUT–1INPUT–2

S-VIDEO

MONITOR /REC OUT

VIDEO

AUDIO

COMPONENT VIDEO

OVER

TV Rear Panel

1) Connect an S-Video Cable from the AV Receiver's MONITOR OUT, to the S-Video INPUT-1 on the back of your television.

2) Connect a Yellow Composite Cable from the AV Receiver's MONITOR OUT, into the VIDEO INPUT-1 on the back of your television.

3) Connect a Green Component Cable from the AV Receiver's Y MONITOR OUT, into the Y VIDEO INPUT-1 on the back of your television.

4) Connect a Blue Component Cable from the AV Receiver's Pb MONITOR OUT, into the Pb VIDEO INPUT-1 on the back of your television.

5) Connect a Red Component Cable from the AV Receiver's Pr MONITOR OUT, into the Pr VIDEO INPUT-1 on the back of your television.

Note:

• Please refer to your AV Receiver instruction manual for more information on connecting your

speakers and other devices like a DVD player.

• Use your AV Receiver's remote to switch to the different devices you have connected.

• Some AV Receivers may not respond when the V1 Smart Input function is turned on.

• If you have video connections for each input device connected to your AV Receiver, you

should not connect them using both S-Video and Composite connection at the same time when you are using V1 Input as the V1 Smart Input. In this case we recommend using the S-Video connection.

Quick Setup Connections

Connecting an i.LINK compatible device to the back of your television

i.LINK is a digital serial interface that allows devices equipped with an i.LINK connector to exchange digital video signals, digital audio signals and device control signals bi-directionally over a single cable. (For example, a JVC D-VHS VCR).

i.LINK refers to the IEEE1394-1995 industry specification and extensions thereof. The logo is used for products compliant with the i.LINK standard.

This projection television uses a four-pin i.LINK connector to input and output MPEG2 video signals, audio signals and control signals.

TV Rear Panel

i.LINK IN/OUT S400(TS)

i.LINK Compatible Device

1) Connect the i.LINK cable from the back of the television to the back of the i.LINK compatible device.

Notes:

• Use only the S400 i.LINK cable when connection your devices.

• See page 75 on how to select the i.LINK device.

• Refer to your owners manual on using your i.LINK device.

• When recording or playing back video with an i.LINK device, if you perform the Auto Tuner

Setup, the video signal you are recording or playing back may stop or you may not be able to perform the Digital Auto Tuner Setup.

• Your television can connect with i.LINK D-VHS decks and HD-Camcorders (JVC brand only).

If you connect other brand devices, with i.LINK cable, they will not work.

• It can play only the recorded contents in Digital Mode.

• Use only tapes bearing the DVHS (SVHS) mark for recording.

Quick Setup Plug-In Menu

Step 3 – The Interactive Plug In Menu

When you turn your television on for the first time the interactive plug-in menu will appear. The plug-in menu helps you to get your TV ready to use by letting you set your preferences for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You can

choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug-in items before you start using your television.

Notes:

• The interactive plug-in menu setting does not appear if your TV has been turned on before.

In this case use the onscreen menus to perform these settings. See pages 46, 58 and 35.

• If you press the Menu button while setting up the interactive plug-in menu, it will skip over it.

Language

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically switches to the LANGUAGE settings. You can choose to view your onscreen menus in three languages: English, French (Français) or Spanish (Español).

LANGUAGE/LANGUE/IDIOMA

ENGLISH

SELECT OPERATE EXIT

√®

To choose a language:

(English, Français or Español)

†

To NEXT (To set clock)

(To be continued...)

Quick Setup Plug-In Menu

Auto Clock Set

Before you use any of your TV’s timer functions, you must first set the clock. You may precisely set your clock using the XDS time signal broadcast by most public analog broadcasting stations. If you do not have this in your area, you will have to set the clock manually. See manual clock set below. To set the clock using the XDS signal:

√®

SET CLOCK

MODE

TIME

TIME ZONE

DATE/YEAR

D.S.T.

SELECT OPERATE EXIT

AUTO

: --

ATLANTIC

JAN/01/04

Notes:

• D.S.T. can be used when it is set to ON in the SET CLOCK menu.

• Only when the MODE is set to AUTO, the Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

Manual Clock Set

To choose AUTO

†

To TIME ZONE

√®

To select your time zone: (Atlantic, Eastern, Central, Mountain, Pacific, Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

√®

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose AUTO, see auto clock set above.

√®

SET CLOCK

MODE TIME TIME ZONE DATE/YEAR D.S.T.

START CLOCK

SELECT OPERATE EXIT

MANUAL

: --

ATLANTIC

JAN/01/04

To choose MANUAL

†

√®

†

To minute

√®

†

To TIME ZONE

√®

Central, Mountain, Pacific, Alaska or Hawaii)

†

To DATE/YEAR

√®

†

To day

√®

†

To year

√®

†

To move to D.S.T. (Daylight Savings Time)

√®

†

To START CLOCK

To TIME

To set the hour

To set the minute

To select your time zone: (Atlantic, Eastern,

To set the month

To set the day

To set the year

To turn D.S.T. ON or OFF

Note:

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

(To be continued...)

Quick Setup Plug-In Menu

Auto Tuner Setup

In auto tuner setup, the TV automatically scans through all available channels, memorizing the active ones and skipping over blank ones or channels with weak signals. This means when you scan (using the C two tuner modes to choose from, ANALOG or DIGITAL.

HANNEL +/– buttons) you will receive only clear, active channels. There are

AUTO TUNER SETUP

IN ANALOG

IN DIGITAL TUNER MODE

START

SELECT OPERATE EXIT

AIRTUNER MODE

ATSC

√®

you skip Analog Auto Tuner Setup)

π†

√®

when you skip Digital Auto Tuner Setup)

†

After Analog Auto Tuner Setup is finished, Digital Auto Tuner Setup starts.

To choose CABLE or AIR (or SKIP when

To TUNER MODE (IN DIGITAL)

To choose ATSC or Digital Cable (or SKIP

To START

NOW

Now Programming...

PROGRAMMING !

When the setup is finished, "THANK YOU ! SETUP IS NOW COMPLETE" is displayed. Your quick setup is now complete. You can now begin watching your television, or you can continue on in this guide for more information on programming your remote control, or using the JVC onscreen menu system to customize your television viewing experience.

Notes:

• If you want to cancel the Auto Tuner Setup, press the MENU button.

• Noise muting will not work during Auto Tuner Setup.

• If you choose SKIP, it finished without doing the Auto Tuner Setup.

Cable Box and Satellite Users: After your auto tuner setup is complete, you may, (depending on the type of hookup), have only 1 channel, usually 3 or 4 in the auto tuner memory. This is normal.

STOP

The Quick Setup is complete

Remote Programming

Setting the CATV, VCR and DVD Codes

You can program your remote to operate your cable box, satellite receiver, VCR or DVD player by using the instructions and codes listed below. If the equipment does not respond to any of the codes listed below or to the code search function, use the remote control supplied by the manufacturer.

Cable Box or Satellite Codes

The remote control is programmed with cable box and satellite codes for power on/off, channel up/down, and 10 key operation.

1) Find the cable box or satellite brand from the list of codes shown below.

2) Slide the 2-way selector switch to “CATV”.

3) Press and hold down the D key pad.

4) Release the DISPLAY button, and confirm the operation of the cable box/satellite receiver.

• If your cable or satellite box does not respond to the first code, try the others listed. If it does

not respond to any code, try the search codes function, on page 31.

ISPLAY button, then enter the first code number listed with the 10

Cable Box Codes

ABC Archer Cableview Citizen Curtis Diamond Eagle Eastern GC Brand Gemini General

Instrument/Jerrold

Hamlin

Hitachi

Macom

Magnavox Memorex

Movietime Oak Panasonic

Paragon

Philips

Pioneer

Pulsar

024 032, 025 051, 032 022, 051 058, 059 024, 032, 025 029 034 032, 051 022, 043 065, 024, 025,

026, 027, 020, 021, 022, 057, 023, 072, 074 040, 041, 042, 045, 058, 064 049, 024

049, 050, 051, 054

033 030 032, 051 039, 037, 048 055, 056, 060,

071, 073 063

028, 029, 030, 052, 053, 031, 069

047, 062 051, 032

Cable Box Codes

Puser RCA Realistic Regal

Regency Rembrandt

Samsung Scientific Atlanta

SLMark Sprucer Stargate

Telecaption Teleview Texscan

Tocom

Toshiba Unika

Universal Videoway Viewstar

Zenith

Zenith/Drake

Satellite

032 061, 070 032 058, 064, 040,

041, 042, 045, 068 034

037, 032, 051, 038

051 057, 058, 059 051, 047 051, 056 032, 051

067 047, 051 044 035, 036, 066,

074

050, 048 032, 025

022, 032 052 029, 030

063, 046 046

Digital Satellite Systems

Echostar (Dish Network)

Express VU

G.E. G.I.

Gradiente Hitachi

HNS (Hughes)

Magnavox 102, 103

Panasonic Philips

Primestar

Proscan RCA Sony Star Choice Toshiba

Uniden

Codes

100, 113, 114, 115

100, 113

106 108, 120, 121,

122

112 104, 111

104

105 102, 103, 116

108

106, 109, 110 106, 109, 110

107 104, 108 101, 104, 117,

118 , 119

102, 103

Remote Programming

VCR Codes

The remote control is programmed with VCR codes for power on/off, play, stop, fast-forward, rewind, pause, record, channel up/down operation.

1) Find the VCR brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”.

3) Press and hold down the D key pad.

4) Release the D

ISPLAY button, and confirm the operation of the VCR.

• If your VCR does not respond to the first code, try the others listed. If it does not respond to

any of the codes, try the search codes function on page 31.

• After you program your remote, some VCR buttons may not work properly. If so, use the

VCR’s remote.

• To record, hold down the R

ISPLAY button, then enter the first code number listed with the 10

EC button on the remote and press PLAY.

VCR

Admiral Aiwa Akai

Audio Dynamic Bell & Howell Broksonic Canon CCE Citizen Craig Curtis Mathes

Daewoo

DBX Dimensia Emerson

Fisher

Funai

G.E. Go Video

Goldstar Gradiente

Hitachi

Instant Replay Jensen JVC

Kenwood

LG 064

LXI 027, 064, 058,

Magnavox

Codes

035 027, 032, 095 029, 072, 073,

074 003, 005 063, 071 020, 026, 094 023, 025 043 064 063, 029, 064 045, 024, 027,

093 043, 059, 024,

092 003, 004, 005 045, 093

043, 026, 077, 061, 025, 042, 020, 076

063, 066, 067, 065, 071, 091

027, 026, 020, 000

033, 045, 024 037, 051, 049,

050, 089 064 083, 084, 081,

000, 001 023, 045, 058,

093, 027, 081

024, 023 003 003, 004, 005,

000, 001, 002, 006, 007

003, 004, 064, 005

065, 066, 063, 067

031, 023, 024, 086

VCR VCR

Marantz Marta Memorex MGA

Minolta Mitsubishi

Multitech NEC

Olympic Optimus

Orion Panasonic

Penney

Pentax

Philco

Philips

Pioneer

Proscan

Quasar

Radio Shack

RCA

Realistic 024, 063, 036,

Codes

003, 004, 005 064 024, 067 038, 040, 047,

048, 041, 042 058, 045, 093 038, 040, 047,

048, 041, 042, 078, 090

047, 027, 062 003, 004, 005,

000 024, 023

028, 021, 035, 064 026, 020

023, 024, 021, 022

024, 058, 045, 063, 003, 004, 005, 093

058, 005, 045, 093

031, 024, 027, 023, 026, 020, 043

031, 023, 024, 086

023 045, 058, 023,

024, 031, 046, 059, 060, 093, 033, 087

021, 022, 023, 024

033, 024, 063, 036, 067, 040, 027

033, 045, 058, 023, 024, 031, 046, 059, 060, 083, 084, 085, 087, 093, 096

067, 040, 027

Samsung

Samtron Sansui

Sanyo

Scott

Sears

Sharp

Shintom 075 Signature 2000

Singer Sony

SV 2000 Sylvania

Symphonic Tashiro Tatung Tea c

Technics

Teknika

Thomson 033, 096 Toshiba Vector Research Wards

Yamaha

Zenith 044, 082, 064,

Codes

037, 060, 062, 033, 089

089 003, 026, 020,

052 063, 067, 091,

071 059, 060, 062,

067, 038, 040, 047, 048, 026, 020

063, 064, 065, 066, 058

035, 036, 080, 088

027, 035

075 028, 029, 030,

053, 054, 055 027 031, 023, 024,

027 027, 081

064 003, 004, 005 003, 004, 027,

005 021, 022, 023,

024 024, 027, 070

059, 046, 079 005 035, 036, 067,

044, 064

063, 003, 004, 005

094

Remote Programming

DVD Codes

The remote control is programmed with DVD codes for power on/off, play, stop, fast-forward, rewind, previous/next chapter, tray open/close, and still/pause operation.

1) Find the DVD player brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “DVD”.

3) Press and hold down the D key pad.

4) Release the DISPLAY button, and confirm the operation of the DVD player.

• If your DVD player does not respond to the first code, try the others listed. If it does not

respond to any of the codes, try the search codes function on page 31.

• After you program your remote, some DVD buttons may not work properly. If so, use the

DVD player’s remote.

ISPLAY button, then enter the first code number listed with the 10

Aiwa 043 Apex 040, 054,

Bose 058 Denon 020, 037

Funai 038 Go–Video 032 Harman

Kardon Hitachi 031 JVC 000 Kenwood 035, 020 KLH 051 Konka 039 Koss 050

055

053

DVD Player DVD Player

Mintek 057 Mitsubishi 025

Next Base 056 Onkyo 041, 052

Oritron 044 Panasonic 020 Philips 023, 036

Pioneer 022 Polk Audio 036 Raite 033 RCA 021, 026

Sampo 034 Samsung 030

Sharp 028 Silvania 038

SMC 048 Sony 024, 045,

Technics 020 Thomson 021 Toshiba 023

Venturer 051

Vialta 050 Wave 042 Yamaha 020, 049 Zenith 027, 032

CodesDVD Player Codes Codes

046, 047

Remote Programming

Search Codes

Cable/Satellite Search Codes Function

1) Slide the first 2-Way Mode Selector switch to CATV.

2) Press the POWER and RETURN+/TV buttons. Hold for at least three seconds and release.

3) Press the P

4) If there was a response, press RETURN+/TV. The codes are now set. If there was no response, repeat Step 3. If you repeat Step 3 a total of 80 times without a response, use the remote control that came with your equipment.

5) Press RETURN+/TV to exit.

VCR/DVD Search Codes Function

1) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR” or “DVD”.

2) Press the VCR or DVD P and release.

3) Press the VCR or DVD POWER button, and see if the VCR or DVD responds.

4) If there was a response, press RETURN+/TV. The codes are now set. If there was no response, repeat Step 3. If you repeat Step 3 a total of 80 times for the VCR (40 times for the DVD player), and there is no response, use the remote control that came with your equipment.

5) Press RETURN+/TV to exit.

OWER button on the remote, and see if the cable or satellite box responds.

OWER and RETURN+/TV buttons. Hold for at least three seconds

Onscreen Menus

Using the Guide

Certain symbols are used throughout this guide to help you learn about the features of your new television. The ones you will see most frequently are:

π†

Up and Down arrows mean press the CH+ or CH– buttons. Pressing the CH+ or CH–

buttons let you:

• Move vertically in a main menu screen

• Move through a submenu screen

• Move to the next letter, number, or other choice in a submenu

• Back up to correct an error

• Scan through TV channels (when not in a menu screen)

√®

Left and right arrows mean press the VOLUME+ or VOLUME– buttons to move left or right

to:

• Select a highlighted menu item

• Select an item in a submenu

• Select numbers in certain menu options

• Turn the volume up or down (when not in a menu screen)

The “press button” icon means you should press the button named on your remote

control. (Button names appear in S

The “helping arrow” icon points to the highlighted or selected item in a menu.

To bring up the onscreen menu, press the MENU button on the remote control. The item that appears in green is the one currently selected. If you use the Menu button on the TV’s front panel instead of the remote, an additional menu screen showing INPUT, VIDEO STATUS and ASPECT will appear between INITIAL SETUP and PICTURE ADJUST. The “interactive plug-in menu” will appear the first time the TV is plugged in.

MALL CAPITAL LETTERS.)

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE CONVERGENCE AUTO DEMO

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

(4/5)

Note:

• Menus shown in this book are illustrations, not exact replications of the television’s onscreen displays.

Onscreen Menus

The Onscreen Menu System

Your television comes with JVC’s onscreen menu system. The onscreen menus let you make adjustments to your television’s operation simply and quickly. Examples of the onscreen menus are shown on the next page. Detailed explanations on using each menu follow later in this guide. For information about the interactive plug-in Menu, see pages 25 - 27.

The Onscreen Menu System

To open the onscreen menu system, press the MENU button on the remote control. You navigate within the onscreen menus by using the four directional arrow buttons on the remote control. (These buttons are also the CH +/– and VOL +/– buttons. Channel and volume functions will not operate when the onscreen menu is active).

The selected feature and option on a menu screen are highlighted in a different color.

Selected Option (Green)

To move to a different feature use the π† arrows to move up or down the list. When you press the up arrow at the top of the list or the down arrow at the bottom, the next menu screen will appear. Use the arrows √ ® to select an option from the highlighted feature. Pressing

ENU on the remote control will close the onscreen menu system and return you to normal

M television viewing.

Each menu and its features will be discussed in the following pages of this guide.

Notes:

• If you do not press any buttons for about a minute, the onscreen menu will automatically shut off.

• Button names in this guide are shown in S

• Menus may appear in different sizes onscreen depending on the aspect ratio selected.

• Some menu items may not appear in menu screens when certain aspect ratios or inputs are selected.

LANGUAGE CLOSED CAPTION

ENG. FRAN. ESP.

MALL CAPITAL LETTERS.

Selected Option (Blue)

Onscreen Menus

Press the MENU button

TO INITIAL SETUP 03

INITIAL SETUP

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE CONVERGENCE AUTO DEMO

NEXT PAGE SELECT OPERATE EXIT

OFF

INITIAL SETUP 04

INITIAL SETUP

PREVIOUS DIGITAL SETUP

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP 05

PICTURE ADJUST

TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

NEXT PAGE SELECT OPERATE

STANDARD 00 00 00 00 00

HIGH

PICTURE ADJUST 01

CLOCK / TIMERS

PREVIOUS SET CLOCK ON / OFF TIMER

(4/5)

NEXT PAGE SELECT OPERATE EXIT

CLOCK/TIMERS INITIAL SETUP 01

SOUND ADJUST

BASS

TREBLE

BALANCE

RESET

(5/5)

NEXT PAGE SELECT OPERATE EXIT

SOUND ADJUST

PICTURE ADJUST

PREVIOUS STANDARD DIG. NOISE CLEAR VSM

RESET

(1/2)

EXIT

SELECT OPERATE EXIT

PICTURE ADJUST 02

PREVIOUS DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT VIDEO-1 MONITOR OUT

SELECT OPERATE EXIT

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

SELECT OPERATE EXIT

INITIAL SETUP

SIZE1

DIGITAL

OFF

LOW

(1/5)

(2/5)

INITIAL SETUP 02

(2/2)

LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

OFF

INITIAL SETUP

ENG. FRAN. ESP.

OFF

NEXT PAGE SELECT OPERATE EXIT

(3/5)

INITIAL SETUP 03

TO INITIAL SETUP 04

Notes:

• The DIGITAL-IN menu can only be displayed when a 480p picture signal is input to the digital-in terminal and the picture is being displayed on the screen.

• When the Menu button on the TV side panel is pressed, the FRONT PANEL CONTROL menu between INITIAL SETUP 05 and PICTURE ADJUST 01 will appear.

• Regarding the digital setup menu, see page 71.

Initial Setup

Auto Tuner Setup

The auto tuner setup function is described on page 27 as the interactive plug-in menu. If you need to run the auto tuner setup again, follow the steps below.

Press the M

π†

√®

π†

√®

π†

√®

Programming will take approximately 2 to 4 minutes. The auto tuner is finished when the message PROGRAMMING OVER! appears onscreen.

To AUTO TUNER SETUP To operate To TUNER MODE (IN ANALOG) To choose CABLE, AIR or SKIP To TUNER MODE (IN DIGITAL) To choose ATSC, DIGITAL CABLE or SKIP

Press the OK button to start

ENU button

AUTO TUNER SETUP

IN ANALOG

IN DIGITAL TUNER MODE

PRESS OK TO START

SELECT OPERATE EXIT

AIRTUNER MODE

ATSC

Press the Menu button when finished

Initial Setup

Channel Summary

Channel summary allows you to customize the line-up of channels received by your TV. Regarding analog channels, you can add or delete channels from the line-up or prevent any unauthorized viewers from watching any or all 191 channels. Regarding digital channels, the only channels that will appear are the ones that are broadcasting.

Press the M

π†

√®

To CHANNEL SUMMARY

To operate

ENU button

The Channel summary screen will now be displayed with the channels set to scan marked with an “√”. Regarding analog channels, you can delete channels from the scan by removing the “√”. If any channels were missed during auto tuner setup and you wish to add them, you may by placing an “√” next to the channel number.

• Digital channels can not be added to the channel summary if the auto tuner setup did not find them.

π† √® To the SCAN column

Press the OK button to include or delete from

scan

Press the MENU button when finished

Note:

• The number of a digital channel may change, depending on the time of some broadcastings. If this channel existed and now had disappeared, the lock channel or scanned channel by the channel summary for that channel will be cancelled.

Analog Channels

CHANNEL SUMMARY

CHNO.

SCAN CHNO. SCANID ID 01 02

MTV 03 04

A&E 05

SELECT OPERATE EXIT

06 07 08 09 10

Digital Channels

Channel Summary Digital

CH No.

Scan

Station Name

D01

D02

D10-1

D10-2

D12345

Operate

FOX

ABC

CNN

NBC

BOX

NHK

BACK

Back

Note:

• When the Cable Card is not inserted into the Cabe Card Slot:

If you are watching analog

channels, the above screen appears.

If you are watching digital

channels, the below screen appears.

• When the Cable Card is inserted into the Cabe Card Slot:

Below screen appears Both analog and digital

channels are listed, but the background video is not displayed.

HBO

Exit

Initial Setup

How to set the channel label. (This is only for analog broadcasting.)

Press the M

π†

√®

π†

Press the OK button to enter

√®

π†

...continue to follow these directions for all four

Press the OK button to finish

Your characters are now set

Press the M

If you want to reset the characters you set:

Press the MENU button

π†

√®

π†

Press the OK button to enter

π†

Press the O

Your characters are now reset

To CHANNEL SUMMARY To operate To the ID column

To select the character you want To move to the next space

spaces

To CHANNEL SUMMARY To operate To the ID column

To select RESET

ENU button

ENU button when finished

K button to finish

CHANNEL 09

RESET

SELECT OPERATE EXIT

PRESS TO FINISH

Notes:

• You can use characters for: Alphabet, numbers, marks and spaces.

• It is possible to set the maximum of 40 channel labels.

• If you try to set more than the 40 maximum, the message "MEMORY OVERFLOW" will appear.

You can block access to a channel by activating the channel lock.

Press the MENU button

π†

To CHANNEL SUMMARY

√®

To operate

π† √® To the Lock Column ( )

Press the ZERO button to lock or unlock that channel

Press the MENU button when finished

Initial Setup

Channel Guard Message

When a viewer attempts to watch a guarded channel, the following message appears:

To watch a channel that you have locked, enter the Lock Code using the 10 key pad. If the wrong code is entered, the message “INVALID LOCK CODE!” will flash on the screen.

The channel cannot be accessed until the correct code is entered.

Notes:

• Once a channel has been unlocked, it will remain unlocked until the television is turned off.

• See also “Set Lock Code”, page 43.

V-Chip

Your TV is equipped with V-Chip technology which enables you to block channels or content that you feel to be inappropriate for children, based on US rating guidelines. V-Chip has no effect on video signals from DVD discs or Camcorder connection.

Note: Some programs, and movies are broadcast without a ratings signal. Even if you set up V-CHIP ratings limits, these programs will not be blocked. See page 39 for information on how to block unrated programs

THIS CHANNEL IS LOCKED BY CHANNEL GUARD. PLEASE ENTER LOCK CODE BY 10 KEY PAD TO UNLOCK IT.

NO. - - - -

You can customize the V-Chip settings of your television to match your personal tastes. The V-Chip menu below is the starting point for your V-Chip settings

You can use US V-Chip settings and movie ratings. You may use any or all of the settings (US V-Chip and Movie ratings). Descriptions for setting each of the three V-Chip formats appear in the next five pages along with descriptions of the rating categories.

To access the rating categories:

Press the M

π†

√®

To V-CHIP To operate (Lock icon will appear)

ENU button

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS

OFF

Press ZERO to access the V-Chip menu

√®

To turn V-Chip ON or OFF (V-Chip must be

UNRATED

VIEW

turned ON for rating settings to operate)

π†

To move to SET US TV RATINGS and

SELECT OPERATE EXIT

SET MOVIE RATINGS. (see following pages for descriptions of each item)

Initial Setup

Unrated Programs

Unrated programming refers to any programming which does not contain a rating signal. Programming on television stations which do not broadcast rating signals will be placed in the “Unrated Programming” category.

Examples of Unrated programs:

• Emergency Bulletins • Locally Originated Programming

• News • Political Programs

• Public Service Announcements • Religious Programs

• Sports • Weather

• Some Commercials

Note:

• TV programs or movies that do not have rating signals will be blocked if the unrated category is set to BLOCK.

Directions to Block Unrated Programs

You can block programs that are not rated.

Press the MENU button

π†

√®

To V-CHIP To operate (The lock icon appears)

Press ZERO to access V-Chip setup options

π†

√®

To UNRATED To VIEW or BLOCK

Press MENU when done

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS

UNRATED

SELECT OPERATE EXIT

OFF

VIEW

Initial Setup

US V-Chip Ratings

U.S. PARENTAL RATING SYSTEMS Programs with the following ratings are appropriate for children.

❒ TV Y is Appropriate for All Children

Programs are created for very young viewers and should be suitable for all ages, including children ages 2 - 6.

❒ TV Y7 is for Older Children

Most parents would find such programs suitable for children 7 and above. These programs may contain some mild fantasy violence or comedic violence, which children should be able to discern from reality.

Programs with the following ratings are designed for the entire audience. ❒ TV G stands for General Audience

Most parents would find these programs suitable for all age groups. They contain little or no violence, no strong language, and little or no sexual dialog or situations.

❒ TV PG Parental Guidance Suggested

May contain some, but not much, strong language, limited violence, and some suggestive sexual dialog or situations. It is recommended that parents watch these programs first, or with their children.

❒ TV 14 Parents Strongly Cautioned

Programs contain some material that may be unsuitable for children under the age of 14 including possible intense violence, sexual situations, strong coarse language, or intensely suggestive dialog. Parents are cautioned against unattended viewing by children under 14.

❒ TV MA Mature Audiences Only

These programs are specifically for adults and may be unsuitable for anyone under 17 years of age. TV MA programs may have extensive V, S, L, or D.

Viewing Guidelines

In addition to the ratings categories explained above, information on specific kinds of content are also supplied with the V-Chip rating. These types of content may also be blocked. The content types are:

• V/FV is for VIOLENCE/FANTASY VIOLENCE

• S stands for SEXUAL CONTENT

• L stands for strong LANGUAGE

• D stands for suggestive DIALOG

Setting US V-Chip Ratings

Initial Setup

Press the MENU button

π†

√®

To V-CHIP To operate (lock icon appears)

V-CHIP V-CHIP SET US TV RATINGS SET MOVIE RATINGS

OFF

Press ZERO to access the V-Chip menu

√®

π†

√®

To operate

To turn V-Chip ON or OFF To move to SET US TV RATINGS

UNRATED

SELECT OPERATE EXIT

VIEW

Directions to set US V-Chip Ratings

Line up the cursor in the column (TV PG, TV G, etc.) with the content row (V/FV, S, etc.) and press the feature on or off. An item is locked if the icon appears instead of a “—”.

For example. To block viewing of all TV 14 shows, move the cursor to the top row of that column and add a lock icon. Once you’ve put a lock on the top row, everything in that column is automatically locked.

π† √®

Press the MENU button when finished

Note:

• If you want to change the setup, move the cursor to

π† or √®

to move the cursor to the correct location. Press OK to turn the locking

To the TV 14 Column

Press the OK button to lock

the top column and change the lock icon to “—” by pressing OK again. You may then select individual categories to block.

SET US TV RATINGS

TVMATV14TVPGTVGTVY7TV

V/FV S L D

SELECT OPERATE

EXIT

Initial Setup

Movies Ratings

❒ NR – Not Rated

This is a film which has no rating. In many cases these films were imported from countries which do not use the MPAA ratings system. Other NR films may be from amateur producers who didn’t intend to have their film widely released.

NR (Not Rated) Programming may contain all types of programming including children’s programming, foreign programs, or adult material.

❒ G – General Audience

In the opinion of the review board, these films contain nothing in the way of sexual content, violence, or language that would be unsuitable for audiences of any age.

❒ PG – Parental Guidance

Parental Guidance means the movie may contain some contents such as mild violence, some brief nudity, and strong language. The contents are not deemed intense.

❒ PG-13 – Parents Strongly Cautioned

Parents with children under 13 are cautioned that the content of movies with this rating may include more explicit sexual, language, and violence content than movies rated PG.

❒ R – Restricted

These films contain material that is explicit in nature and is not recommended for unsupervised children under the age of 17.

❒ NC-17 – No One Under 17

These movies contain content which most parents would feel is too adult for their children to view. Content can consist of strong language, nudity, violence, and suggestive or explicit subject matter.

❒ X – No One under 18

Inappropriate material for anyone under 18.

Directions to set Movie (MPAA) Ratings

Press the MENU button

π†

√®

To V-CHIP To operate (Lock icon appears)

Press ZERO to access V-Chip setup options

π†

√®

To SET MOVIE RATINGS To enter movies menu

For example:

To block viewing of X and NC-17 rated from shows:

π† √®

Press the M

To the X Column

Press the OK button to lock

To the NC-17 Column

Press the OK button to lock

ENU button to finish

SET MOVIE RATINGS

SELECT OPERATE

EXIT

Initial Setup

Set Lock Code

Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes preset with a lock code of “0000”. You may change the code to any four-digit number you wish. To change the lock code, follow the steps below.

Press the M

π†

√®

To SET LOCK CODE

To operate (lock icon appears)

Press Z

ENU button

ERO to access the lock code

SET LOCK CODE

LOCK CODE

0000

The first digit will be highlighted

√®

To select the number

π†

To move to the next digit

SELECT OPERATE EXIT

PRESS TO FINISH

Continue to follow these directions for all four numbers

Press the OK button to finish (your lock code is now set)

Press the Menu button when finished

When a viewer attempts to watch a blocked channel, this message appears:

THIS PROGRAMMING EXCEEDS YOUR RATING LIMITS. PLEASE ENTER LOCK CODE BY 10 KEY PAD TO UNLOCK IT. NO. - - - -

The channel will remain blocked until the correct lock code is entered (see above for information on setting your lock code).

Notes:

• After a power interruption you must reset the lock code.

• Write your lock code number down and keep it hidden from potential viewers.

• If you forget the lock code, a new code may be set using the steps listed above.

Initial Setup

Adjusting CRT Color Convergence

This TV has three color projection tubes: one for red, green, and blue. When mixed together in the proper portions, the output of these three color tubes can produce any color. To produce these colors, however, the beams must be precisely aligned over each other so that the colors can be mixed. The produce of aligning these picture beams is called “convergence”.

Attention:

• Please have your TV on for at least 20 minutes before using this feature.

• This adjustment will be needed only when the colors of the characters/lines are separated and lack in distinction. If not, please don’t perform the adjustment.

Colors may become separated after the TV has been moved, or over a long period of time if regularly subjected to low levels of vibrations. If the colors become separated, please perform the adjustments below again. In the beginning, please be sure to perform

CONVERGENCE

AUTO MANUAL

RESET

AUTO convergence adjustment.

Auto

Press the M

π†

To CONVERGENCE

√®

To Enter

π†

To select “AUTO” (The convergence adjustment

will start. It will take about 50 seconds).

When the adjustment is finished, it will return to

ENU button

SELECT OPERATE EXIT

SUPER FOCUS

what you were watching.

Note:

• You can reset the adjustment if you do not like the results. See the next page.

• If you want to adjust it more, you can perform the manual color convergence adjustment.

See the next page.

• You can also access this feature by pressing the S

UPER FOCUS button on the front panel of

your TV.

INPUT- 4

S-VIDEO VIDEO AUDIO

OVER

OPEN

RL / MONO

MENU CHANNEL VOLUME SUPER

– + – +

OPERATE

FOCUS

SUPER FOCUS

Initial Setup

Adjusting CRT Color Convergence (continued...)

Manual

Press the MENU button

π†

To CONVERGENCE

√®

To Enter

π†

To choose MANUAL

√®

To Enter

If all the lines are white, no convergence adjustment is necessary. If not, you need to perform the manual color

convergence below.

Select the location you want to adjust by using the

number buttons on the remote control.

You can select any of the 81 points.

Press the S

box to the color of the cross you wish to adjust (red or blue).

π† √®

Notes:

• When you adjust the convergence, make sure you start with the center position (position 5),

• When you make the adjustment in the center (position 5), you are making the adjustment for

• You can reset the adjustment if you do not like the results. See below.

• If you perform AUTO convergence after performing MANUAL convergence, your manual

Adjust the position of the cross.

Press the OK button

and work your way around radially for best results.

the whole screen. In other positions, you are making the adjustment only in that area.

convergence you performed will be cancelled.

ELECT button to change the color of the

Adjust the three color crosses until they overlap and appear as a single white cross.

Reset

RESET resets all convergence adjustments to the factory default settings.

Press the M

π†

To CONVERGENCE

√®

To Enter

π†

To RESET

√®

To enter

When the adjustment is reset, it will return to what you were watching.

ENU button

Initial Setup

Auto Demo

This function lets you preview the many different viewing modes of your TV. It will cycle through “Multi Screen Demo”, “Picture in Picture Demo”, all of the different “Aspect” ratios and all of the different “Video Status” modes.

Press the M

π†

To AUTO DEMO

√®

To turn AUTO DEMO ON or OFF

Note:

• To stop auto demo, press the MENU button, and select auto demo by pressing the by pressing the

ENU button

π†

√®

buttons. Press the MENU button to

buttons, and turn it off

PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE CONVERGENCE AUTO DEMO

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

(4/5)

finish.

Language

The language function is described on page 25 as the interactive plug-in menu. If you need to choose the language again, follow the steps below.

Press the Menu button

π†

√®

To LANGUAGE

To choose a language: ENG. (English), FRAN.

(French) or ESP. (Spanish)

Press the MENU button when finished

PREVIOUS LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

SELECT OPERATE EXIT

INITIAL SETUP

ENG. FRAN. ESP.

OFF

(3/5)

Initial Setup

Closed Caption

Many broadcasts now include an onscreen display of dialog called closed captions. Some broadcasts may also include displays of additional information in text form. Your television can access and display this information using the closed caption feature. To activate the closed caption feature, follow the steps below. There are three methods. When you are watching analog channels, you can perform Analog Setting of closed caption. When you are watching digital channels, you can perform Digital Auto Setting or Digital Manual Setting.

Analog Setting

Press the MENU button

π†

√®

π†

√®

π†

√®

To CLOSED CAPTION

To enter

To MODE

To select CAPTION or TEXT in MODE

To CAPTION or TEXT

To select a caption (CC1 to CC4) or text

channel (T1 to T4)

Press the OK button to save

Press the MENU button when finished

Digital Auto Setting

Press the MENU button

π†

√®

π†

√®

Auto: Shows closed caption a priority for

Advanced: Shows only the digital cloased

Basic: Shows only the analog closed

π†

√®

π†

√® √®

π†

Press the OK button to save

The font/type and color are set automatically.

Press the MENU button when finished

To CLOSED CAPTION

To enter

To Type

To select Auto, Advanced or Basic

digital channels over analog channels. It is set automatically.

caption.

To Service

To select 1, 2, 3, 4, 5 or 6

To Appearance

To enter To select Auto

To Set

CLOSED CAPTION

Back

TEXTMODE

AUTO

Exit

Auto

Exit

CAPTION TEXT

PRESS TO FINISH

SELECT OPERATE EXIT

Digital Closed Caption

Preview

Closed Caption Sample

Type

Service

Appearance

Cancel Set

Select

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

Operate

BACK

Back

CC1

Note:

• If you want to cancel the settings, select cancel.

Initial Setup

Digital Manual Setting

Press the M

π†

√®

π†

√®

π†

√®

π†

√® √®

π†

√®

π†

√®

To CLOSED CAPTION

To enter

To Type

To select Auto, Advanced or Basic

To Service

To select 1, 2, 3, 4, 5 or 6

To Appearance

To enter To select Manual

To Font

To enter

To select Font Size or Font Style

To select the setting you like Font Size: Auto, Standard, Large or Small Font Style: Auto, Serif Mono, Serif, Sanserif mono,

Sanserif, Casual, Cursive or Small Capital

π†

To Set

Press the OK button to save

π†

√®

π†

√®

To Colors

To enter

To select Text, Edge or Background

To select the setting you like Auto, White, Black, Red, Green, Blue,

Yellow, Magenta or Cyan

π†

To Set

Press the OK button to save

π†

To Opacities

√®

To enter

π†

To select Text/Edge or Background

√®

To select Auto, Transparent, Translucent, Solid or Flashing

π†

To Set

Press the OK button to save

ENU button

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

Digital Closed Caption > Appearance

Preview

Closed Caption Sample

Appearance Mode

Font

Colors

Opacities

Cancel Set

Select

BACK

Operate

Font Size

Font Style

Cancel Set

BACK

Operate

Tex t

Edge

Background

Cancel Set

BACK

Operate

Back

Manual

Standard

Auto

White

Black

Exit

Press the MENU button when finished

Notes:

• Closed caption subtitles are usually found on closed caption channel CC1. Some programs may include additional text information which is usually found on text channel T1. The other channels are available for future use.

• Closed captioning may not work correctly if the signal being received is weak or if you are playing a video tape.

• Most broadcasts containing closed captioning will display a notice at the start of the program.

• To select the mode, press the C.C. button. See page 66.

Initial Setup

Auto Shut Off

This function automatically shuts off your TV when there is no signal from the channel the TV is on.

Press the M

π†

To AUTO SHUT OFF

√®

To turn ON or OFF

Press the M

ENU button

ENU button when finished

PREVIOUS LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

• If the channel that you have on does not receive a signal for more than one minute, the blinking text “NOT RECEIVING A SIGNAL AUTO SHUT OFF

NEXT PAGE SELECT OPERATE EXIT

in 9 MIN.” appears on the screen, and starts the countdown. If no signal is being received within 10 minutes, the TV shuts itself off.

• When i.LINK is displayed, Auto Shut Off will not work.

XDS ID

XDS ID Display provides a channel’s call letters, the network’s name, and even a program name. The XDS ID information is provided by the broadcaster.

Press the M

π†

To XDS ID

√®

To turn ON or OFF

Press the MENU button when finished

ENU button

PREVIOUS LANGUAGE CLOSED CAPTION AUTO SHUT OFF XDS ID

INITIAL SETUP

ENG. FRAN. ESP.

OFF

ENG. FRAN. ESP.

OFF

(3/5)

SELECT OPERATE EXIT

(3/5)

Noise Muting

This feature inserts a blank gray screen over channels which are not broadcasting or are too weak to be received clearly.

Press the M

π†

√®

To NOISE MUTING

To turn noise muting ON or OFF

Press the MENU button when finished

Notes:

• Noise muting will not work during auto tuner setup or

ENU button

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

LOW

when you operate channel summary.

• Noise muting will not work when the digital TV or i.LINK is displayed.

(2/5)

Initial Setup

Front Panel Lock

This allows you to lock the keys on the front of the TV, so that a child may not accidentally change your viewing preferences.

Press the M

π†

To FRONT PANEL LOCK

√®

To turn ON or OFF

Press the MENU button when finished

You can turn off this feature in the following ways:

• Unplug the power cord, and plug it back in. Do this if your batteries die, or you lose your remote control.

• Use the remote control.

• Press the M for FRONT PANEL LOCK will appear.

Note:

• To turn ON/OFF the TV, press the power button for more than 3 seconds. This feature will

remain ON.

V1 Smart Input

This feature is used if you have connected an AV Receiver to your television. By turning this feature on, your television can automatically detect the signal source from your components that are connected to your AV Receiver.

Press the M

π†

√®

Notes:

• If you do not have an AV Receiver connected to your

• Some AV Receivers may not work with this function.

To V1 SMART INPUT To turn ON or OFF

Press the MENU button when finished

television, turn this feature OFF. By doing so, you can take advantage of using AV CompuLink components with your television.

ENU button

ENU button on the front of the TV for more than 3 seconds. In this case, the OSD

ENU button

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

LOW

OFF

LOW

(2/5)

Initial Setup

Video Input Label

This function is used to label video input connections for the onscreen displays.

Press the M

π†

√®

π†

√®

To VIDEO INPUT LABEL

To enter

To select the desired video input

To select the desired preset input label (see

chart below)

Press the OK button to save

Press the MENU button when finished

ENU button

Preset Labels

VCR

DVD

DVHS

STB

SAT

AMP

GAME

CAM

DISC

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

VIDEO INPUT LABEL

VIDEO-1 VIDEO-2 VIDEO-3 VIDEO-4 DIGITAL-IN

SELECT OPERATE EXIT

Select when...

You have a VCR connected to the video input

You have a DVD connected to the video input

You have a Digital VCR connected to the video input

You have a Set-top Box connected to the video input

You have a Satellite Receiver connected to the video input

You have an Amplifier connected to the video input

You have a Video Game connected to the video input

You have a Video Camera connected to the video input

You have a Video Disc player connected to the video input

INITIAL SETUP

PRESS TO FINISH

LOW

GAME

OFF

VCR DVD

(2/5)

SAT

STB

Initial Setup

Position Adjustment

Position adjustment allows you to adjust the position of the picture on the screen vertically when the aspect is set to panorama, cinema or full.

Press the M

π†

To POSITION ADJUSTMENT

√®

π†

To enter

√®

To adjust the position

Press the M

Notes:

• To reset the adjustment to the center, press the O

ENU button

ENU button to finish

K button.

OPERATE

RESET EXIT

• When the arrow disappears, while you are adjusting the position, the position is at its maximum limit.

• If you select regular size with aspect or Multi Screen, position adjustment option is not seen.

• When you change the screen size, perform the position adjustment again.

• Position adjustment allows you to adjust the screen position vertically and horizontally when the aspect is set HD panorama or cinema zoom for 1080i and 720p signals.

Power Indicator

Power indicator allows you to adjust the brightness of the power indicator

Press the MENU button

π†

To POWER INDICATOR

√®

To adjust POWER INDICATOR LOW, HIGH

or OFF

Note:

• If you set a timer on the TV, the power indicator will light even if the TV is on stand by.

PREVIOUS NOISE MUTING FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL POSITION ADJUSTMENT POWER INDICATOR

NEXT PAGE SELECT OPERATE EXIT

INITIAL SETUP

OFF

LOW

(2/5)

Initial Setup

Digital-In

The DIGITAL-IN option can only be displayed in the INITIAL SETUP menu when an HDMI480p picture signal is being input to the DIGITAL-IN terminal. This option adjusts the position when an HDMI or DVI 480p picture signal is being displayed on the screen. There are two types of HDMI 480p picture signals: 640x480 and 720x480. If the displayed picture is slightly shifted, the position can be adjusted by selecting either SIZE1 or SIZE2.

Press the M

π†

To DIGITAL-IN

√®

To select SIZE1 or SIZE2

Press the MENU button to finish

ENU button

PREVIOUS DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT VIDEO-1 MONITOR OUT

SELECT OPERATE EXIT

INITIAL SETUP

SIZE1

DIGITAL

OFF

(1/5)

Digital-In Audio

This feature is used if you have a DTV or HDMI compatible component connected to your TV.

Press the MENU button

π†

To DIGITAL-IN AUDIO

√®

To select ANALOG or DIGITAL

Press the Menu button when ﬁ nished

Notes:

• If your DTV or HDMI component is capable of digital

PREVIOUS DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT VIDEO-1 MONITOR OUT

SELECT OPERATE EXIT

audio and video, choose DIGITAL. If your DTV or HDMI component is capable of analog audio and digital video, choose ANALOG.

• Refer to your DTV or HDMI component’s instruction manual for more information.

• When you select DIGITAL, select PCM on Digital Sound in the Digital Setup menu. See page

72.

INITIAL SETUP

SIZE1

DIGITAL

OFF

(1/5)

Initial Setup

Center CH Input

When you are using a surround system, you can substitute the speaker of this television for the center speaker of your surround system. Set CENTER CH INPUT to ON when you use the speaker as the center speaker of your surround system. The volume differs when the TV is being utilized as the Center Channel Input versus when it is not.

Press the MENU button

π†

To CENTER CH INPUT

√®

To adjust CENTER CH INPUT to ON or OFF

PREVIOUS DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

VIDEO-1 MONITOR OUT

INITIAL SETUP

SIZE1

DIGITAL

OFF

Press the MENU button when finished

Note:

SELECT OPERATE EXIT

(1/5)

• In order to use the CENTER CHANNEL SPEAKER feature, you need a video signal present as well as sound. Because of that we recommend using this feature for Home Theater setup only. If there is no video signal present, the TV will be muted.

• There are two different volume adjustment levels, one for regular TV and one for TV used as a CENTER CHANNEL. Please remember that when switching CENTER CHANNEL mode ON and OFF in TV menu.

Video-1 Monitor Out

This function allows you to set whether the signal, which comes from VIDEO-1 input terminal, should be output from MONITOR OUT terminal. If you select it from MONITOR OUT, set it to "ON".

Press the M

π†

To VIDEO-1 MONITOR OUT

√®

To select ON or OFF

Press the MENU button to finish

ENU button

PREVIOUS DIGITAL-IN DIGITAL-IN AUDIO CENTER CH INPUT

VIDEO-1 MONITOR OUT

SELECT OPERATE EXIT

INITIAL SETUP

SIZE1

DIGITAL

OFF

(1/5)

Picture Adjust

Picture Settings

These settings allow you to change and adjust the way the picture appears on your television.

TINT

Tint allows you to adjust the levels of red and green in your TV picture.

COLOR

The color function lets you make all the colors in the TV picture appear either more vivid or subtle.


Picture allows you to adjust the levels of black and white on the TV screen, giving you a darker or brighter picture overall.

BRIGHT

You can adjust the overall brightness of the TV picture with the Bright control.

DETAIL

The Detail feature adjusts the level of fine detail displayed in the picture.

Adjust the Picture Settings

Press the MENU button

π† To TINT, COLOR, PICTURE, BRIGHT or

DETAIL

√ ®

To enter

TINT

√ ®

To adjust the setting

π†

To move to the next setting

+02

PICTURE ADJUST

PREVIOUS TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

NEXT PAGE SELECT OPERATE

Press the MENU button when finished

Color Temperature

You can decide how strong or dull the colors appear on the TV screen.

Press the M

π†

To COLOR TEMPERATURE

√®

To enter

COLOR TEMPERATURE LOW HIGH

√®

To set LOW or HIGH

Press the MENU button when finished

ENU button

PICTURE ADJUST

PREVIOUS TINT COLOR PICTURE BRIGHT DETAIL COLOR TEMPERATURE

NEXT PAGE SELECT OPERATE

00 00 00 00 00

STANDARD

HIGH

(1/2)

EXIT

(1/2)

EXIT

Picture Adjust

Digital Noise Clear

With digital noise clear, this helps take our static or noise from a channel that may not be coming in clearly.

Press the M

π†

To DIG. NOISE CLEAR

√®

To enter

π†

To select the mode LOW, HIGH or OFF

Press the MENU button when finished

(VSM) Velocity Scan Modulation

Velocity scan modulation circuitry varies the electron beam’s horizontal scanning speed to help accentuate the differences in picture brightness to sharpen the edges of images.

Press the M

π†

√®

To VSM

To enter

VSM ON OFF

To turn VSM ON or OFF

ENU button

DIG. NOISE CLEAR

OFF

LOW

HIGH

PICTURE ADJUST

PREVIOUS STANDARD DIG. NOISE CLEAR VSM

RESET

NEXT PAGE SELECT OPERATE EXIT

OFF

(2/2)

Reset

Reset resets all picture adjustments (tint, color, picture, bright, detail, color temperature, dig. noise clear and VSM) at once to the default settings.

Press the MENU button

π†

To RESET

√®

To enter

The onscreen menu disappears for a

PICTURE ADJUST

PREVIOUS STANDARD DIG. NOISE CLEAR VSM

OFF

moment, and then the settings are reset to the default setting for all the picture adjustments.

Press the MENU button when finished

RESET

NEXT PAGE SELECT OPERATE EXIT

(2/2)

Sound Adjust

Sound Settings

These settings allow you to change and adjust the sound on your television.

You can increase or decrease the level of low-frequency sound in the TV’s audio with

BASS –

TREBLE –

BALANCE –

Adjust the Sound Settings

Press the MENU button

π† To BASS, TREBLE or BALANCE

√ ®

π†

Press the MENU button when finished

Note:

• You can reset the sound adjustments

• You can adjust BALANCE only when A.H.S. is off. See page 63.

the bass adjustment.

Use treble to adjust the level of high-frequency sound in your TV’s audio.

Adjust the level of sound between the TV’s left and right speakers with the

balance setting.

SOUND ADJUST

To adjust the setting

To move to the next setting

BASS TREBLE BALANCE

RESET

NEXT PAGE SELECT OPERATE EXIT

(BASS, TREBLE and BALANCE) you set at once as the default setting when you select reset. See page 56.

00 00 00

Reset

Reset resets all Sound Adjustments (Bass, Treble and Balance) at once to the default settings. See page 56 on how to use reset.

Clock/Timers

Set Clock

The set clock function is described on page 26 as the interactive plug-in menu. You can choose to set the clock automatically or manually. If you need to set the clock again, follow the steps below.

Press the M

π†

To SET CLOCK

√®

To enter

When you set the clock automatically, choose AUTO by pressing the √ or ® arrows.

π†

√®

π†

√®

To TIME ZONE

To select your time zone

ATLANTIC

To D.S.T. (daylight savings time)

To turn D.S.T. ON or OFF

Press OK to finish

Press the MENU button when finished

When you set the clock manually, choose MANUAL by pressing the √ or ® arrows.

π†

√®

π†

√®

π†

√®

To move to the hours

To set the hours

To move to minutes

To set the minutes

To TIME ZONE

To select your time zone:

(Atlantic, Eastern, Central, Mountain, Pacific,

Alaska or Hawaii)

π†

To DATE/YEAR

√®

To set the month

π†

To day

√®

To set the day

π†

To year

√®

To set the year

π†

To D.S.T. (daylight savings time)

√®

To turn D.S.T. ON or OFF

Press OK to start clock

ENU button

EASTERN

HAWAII

ALASKA

CENTRAL

PACIFIC

MOUNTAIN

SET CLOCK

MODE

TIME

TIME ZONE

DATE/YEAR

D.S.T.

SELECT OPERATE EXIT

SET CLOCK

MODE TIME TIME ZONE DATE/YEAR D.S.T.

SELECT OPERATE EXIT

PRESS TO FINISH

PRESS TO START CLOCK

AUTO

: --

ATLANTIC

JAN/01/04

MANUAL

: --

ATLANTIC

JAN/01/04

THANK YOU !!

Press the MENU button when finished

Notes:

• D.S.T. can be used when it is set to ON in the SET CLOCK menu.

• Only when the MODE set to AUTO, the Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

Clock/Timers

On/Off Timer

The on/off timer lets you program your television to turn itself on or off. You can use it as an alarm to wake up, to help you remember important programs, or as a decoy when you’re not home.

Press the MENU button

π†

√® √®

To ON/OFF TIMER

To enter (begins with ON TIME)

To set the hour (AM/PM) you want the TV to

turn on

†

To move to minutes

√®

To set the minutes

†

To accept ON TIME and move to OFF TIME (the time the TV will turn off). Set the

OFF TIME the same way as ON TIME

†

To accept OFF TIME and move to CHANNEL

√®

To select channel

†

To ON VOLUME

√®

To set the volume level

†

To move to MODE

√®

Choose ONCE or EVERYDAY

†

To ON/OFF TIMER

√®

Choose YES to accept the timer setting, choose NO if you don’t wish to accept

Press the OK button to finish

Press the MENU button to exit the menu

ON/OFF TIMER ON TIME OFF TIME CHANNEL ON VOLUME MODE ON/OFF TIMER

SELECT OPERATE EXIT

PRESS TO FINISH

7:00 PM

10:00 PM

CURRENT

EVERYDAY

Notes:

• The on/off time cannot be set to locked or guarded channels.

• In order for the on/off timer to work, the clock must be set.

• After a power interruption, the timer settings must be reset.

Button Functions

Multi Screen Function

Your television has two kinds of screen: TWIN (2 channels) and INDEX (12 channels).

Note: After you press any multiscreen buttons, if you press the menu button, only the picture

adjust screen will appear.

Twin

Activate the split-screen option by pressing TWIN on the remote control. The channel (or input) you were watching before pressing TWIN will appear on the left, the new channel will appear on the right. The sound will continue to come from the main screen channel (or input). To turn split-screen off and return to normal television viewing, press T the BACK button.

Notes:

• If the signal that you are watching is coming from the HDMI input, you cannot enter the TWIN mode.

• Main Screen and Split Screen will not display the same channel or input at the same time.

• You can enter the TWIN mode when the screen is in NORMAL or INDEX mode.

• Split-screen functions will not work with locked channels or channels blocked by V-Chip ratings limits. A gray screen will display instead.

• The aspect of MAIN CHANNEL PICTURE becomes 16:9 when you input the picture of 480p, 720p and 1080i from the component terminal.

• After you press the S

OK button, select normal screen. If you don’t operate, the MAIN CHANNEL SCREEN will be automatically selected about 8 seconds later.

• Aspect does not work in Twin mode.

• When the cable card is inserted into the TV, the combination of analog broadcasting and digital broadcasting will not appear in the TWIN mode.

ELECT button, and select SPLIT SCREEN when you press the

WIN again or press

MAIN SCREEN


SPLIT SCREEN


V-1

Button Functions

Index

This allows you to quickly look at up to 12 channels at a time so that you can decide which one to watch.

Notes:

• Only RF input signal will be displayed.

• You can watch the channel added in channel summary. See page 36.

Freeze

Pressing the FREEZE button causes the screen to change to the split-screen display with the still picture displayed on the right. In order to return to the normal display, press the FREEZE button once again.

Note: When the screen is in freeze mode, if you do not operate it within 15 minutes, this function will cancel out.

Swap

You can exchange the channel (or input) displayed in the split screen window for the main screen image by pressing the SWAP button.

Note: It will only work in TWIN mode.

Select

With SELECT, you can select the picture (channel) while viewing TWIN screen. When you press SELECT button, the channel number on the top will be highlighted. Each press of SELECT will shift the channel.

Button Functions

Power

Turns the TV on or off.

Press the P

Number Buttons - 10Key Pad

Use the number buttons on the remote control to move directly to a specific channel. For example, to move to channel 12:

0 (Zero)

1 (One)

2 (Two)

Tune

OWER button

Lets you decide the input channel and select it. After you press the number buttons on the remote, press the T

1 (One)

2 (Two)

Press the TUNE button

UNE button. For example, to move to channel 12:

Input

Selects the signal input source for the television: Input-1, 2, 3, 4 DIGIATL-IN or i.LINK for video devices like VCRs, DVD players or camcorders.

Press the I

By every press of the INPUT button, you can change the input mode.

Notes:

• When you return to TV mode, press the RETURN+ button or direct 10 key pad.

• You can also access the FRONT CONTROL PANEL screen by using the MENU button on the front of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose INPUT by pressing MENU† on the front panel and choose a mode by using the CHANNEL+/- buttons ( √ OPERATE ® ).

• i.LINK can be selected only when you have an i.LINK device connected.

NPUT button

Channel +/–

Use these buttons to move up or down all the available channels your TV is able to receive.

Volume +/–

Use these buttons to raise or lower the TV’s volume level.

Button Functions

Return +/TV

The RETURN+/TV button has three functions:

Return - Returns to the channel viewed just before the channel currently onscreen.

Return+ - Lets you program a specific channel to return to while scanning through the

TV - Returns to the TV mode.

Press the R

channels using the CH+ and CH– buttons.

ETURN+/TV and hold for three seconds

RETURN CHANNEL

PROGRAMMED!

The channel currently active has been programmed as your return+ channel. Now scan

through the channels using the CHANNEL+/– buttons.

Press the RETURN+/TV

You will return to your programmed channel.

• To cancel your return+ channel, press and hold the RETURN+ button for three seconds. The message “RETURN CHANNEL CANCELLED!” will appear.

• Return+ works only with the Channel+/– buttons. Pressing any number key will cancel return+.

Sound

Note : SMART SOUND (AV-56P785 ONLY)

By pressing the SOUND button, you can change the A.H.S. (Advanced Hyper Surround) mode, BBE, and SMART SOUND on or off.

A.H.S. - Adds a more spacious surround sound. Music gives basic effect and movie for more

BBE - BBE High Definition Sound restores clarity and presence for better speech intelligibility

SMART SOUND - Decreases high sound levels, giving a regulated sound level.

Press the S

π†

√®

Press the MENU when finished

effect.

and musical realism.

OUND button

To select A.H.S., BBE or SMART SOUND

To choose the setting

SOUND EFFECT

A.H.S. BBE SMART SOUND

OPERATE EXIT

SELECT

MOVIE MUSIC OFF

ON OFF

Manufactured under license from BBE Sound, Inc. Licensed by BBE Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

Note: Smart Sound may become an unnatural effect, depending on the signal source.

Button Functions

Video Status

The VIDEO STATUS button gives you a choice of four TV picture display settings, including a display of your own preferences.

Standard - Resets the picture display to the factory settings.

Dynamic - Gives a vivid picture with better contrast when viewing in

Theater - Gives a rich, film-like look to video when viewing in a

Game - Used for when you are playing video games connected to

Press the V By every press of the VIDEO STATU S button, you change the mode.

Note:

• You can also change the mode by pressing the

• You can also access the FRONT CONTROL PANEL screen by using the MENU button on the back of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose VIDEO STATUS by pressing MENU† on the back panel and choose a mode by using the CHANNEL +/- buttons ( √ OPERATE ® ).

a brightly lit room.

dimly lit room.

your TV.

IDEO STATUS button

π†

buttons.

Natural Cinema

Natural cinema corrects the problem of blurred edges which may occur when viewing a program originally shot on film (such as motion pictures) or animation. If you notice blurring at the edges of these programs, press N conversion errors that occur when film, which is shot at 24 frames-per-second, is broadcast at the television rate of 30 frames-per-second.

ATURAL CINEMA and set it to AUTO. Natural Cinema helps correct

VIDEO STATUS

STANDARD

DYNAMIC THEATER

GAME

Press the NATURAL CINEMA button

Notes: The natural cinema mode is automatically set to “AUTO” in the

following cases:

• Turning on or off

• Changing the channel or input mode

• Using multi-screen functions

NATURAL CINEMA

AUTO

OFF

TheaterPro D6500K

The TheaterPro D6500K color temperature technology function makes sure that the video you watch is set to the standard color temperature, so that what you see is as true to what the film to video editors intended it to be.

Press the THEATERPRO button

Button Functions

Sleep Timer

The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work in intervals of 15 minutes, for a total time of up to 180 minutes.

Press the S

LEEP button

0 15 30 45 60 75 90 105 120 135 150 165 180

Sleep Timer Message

20 seconds before the automatic shutoff, this message will appear:

GOOD NIGHT!!

PUSH SLEEP TIMER BUTTON

You then have 20 seconds to press the S

delay the shut off for another 15 minutes.

TO EXTEND

LEEP button to

ML/MTS

MTS technology allows several audio signals to be broadcast in analog at once, giving you a choice in what you wish to hear with a TV program. In addition to mono or stereo sound, an MTS broadcast may also include a second audio program (SAP).

Press the ML/MTS button

By every press of the ML/MTS button, you change

the mode

ON AIR

MTS

STEREO

SAP

MONO

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the language by pressing the M

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• Selecting SAP will allow you to hear an alternative soundtrack, if one is available.

• MTS unavailable if your television’s Input source is in input 1, 2, 3 or 4 mode, as described on page 62.

• ML/MTS will not work when you are using the Digital-In.

• You can also change the mode by pressing the

L/MTS button.

π†

buttons.

Muting

The MUTING button instantly turns the volume down completely when you press it. Press

UTING and the volume level will instantly go to zero. To restore the volume to its previous

M level, press MUTING again.

Button Functions

Display

The display screen shows the current status of timers, inputs and XDS ID.

Press the D

ISPLAY button

The screen to the right shows the following information:

•

The current channel or AV input (Channel 05)

• The current time (12:20 pm)

• Sleep timer status/minutes remaining (The Sleep Timer is off)

• On/off timer status (Set to turn on everyday at 7:00 PM, off at 10:00 PM)

• Each Press of the D mode:

ISPLAY button changes the display

05 KLVX PBS JAZZ FESTIVAL NOW SLEEP TIMER ON/OFF TIMER ON TIME OFF TIME

Display Time Channel Off

Display - Full screen shown above

Time - Shows the current time only

Channel - Shows the current channel

Off - Turns display off

Notes:

• You may also turn off the display at any step by pressing MENU.

• If the clock, sleep timer or on/off timer are not set, the display screen will show: “CLOCK NOT SET”, “SLEEP TIMER OFF”, and “ON/OFF TIMER OFF” respectively.

C.C. (Closed Caption)

Use the C.C. (Closed Caption) button to select the mode of closed caption.

Press the C.C. button

AV-56P785 ONLY

OFF SMART CAPTION ON

12:20 PM

OFF

EVERYDAY

7:00 PM

10:00 PM

AV-56P775 and AV-48P775 ONLY

ONOFF

• Smart Caption will appear when you press the M broadcast contains closed captioning. (AV-56P585 ONLY)

• When you select ON, it will be the mode selected in the Closed Caption Menu.

• See page 47 when you set the caption/text mode.

• You can also change the mode by pressing the π† buttons.

UTING button, only on channels where the

Button Functions

Favorite

The Favorite button allows you to select your favorite channels easily. First, you must register the channels that you like. See how to register below.

Press the F

π†

To select the channel you want to watch

Press the O

Press the channel number you want to register

Press the F

Notes:

• Both analog and digital channels can be registered. The digital channels have a "D" in front of the channel number.

• The maximum number of channels you can register is 24.

• If you have registered the maximum number of channels, and try to register more channels, the oldest channel you registered will be deleted.

• Sub channels can not be registered.

• The newest channel you registered will appear at the top of the list.

• Regarding digital channels, see pages 74 to 80.

AVORITE button

The favorite channel list will appear.

K button

It will change to the channel you have selected.

The channel program will change.

AVORITE button for three seconds

The channel will be registered in the favorite channel list.

D103

D107

101 102

FAVORITE

CBS FOX

PBS2

HBO

ABC

Delete the favorite channel

Press the FAVORITE button

π†

√®

To enter

Press the OK button

Press the FAVORITE button when finished

Note:

• Before pressing the FAVORITE button when you are finished, press the √® button again, and

you can return to the deleted channel.

The favorite channel list will appear.

To select the channel you want to delete

The channel was deleted.

Button Functions

Aspect

This feature will help you adjust the picture you are watching to give you the best possible picture quality.

Aspect Ratios

PANORAMA - With this ratio a normal

4:3 aspect picture is stretched to fit the dimensions of the 16:9 aspect screen.

CINEMA - This ratio “zooms in” on the center part of a 4:3 aspect picture, blowing it up to fill the 16:9 screen.

FULL - This is the ratio to use when watching 16:9 High-Definition broadcasts.

HD PANORAMA - This ratio stretches the High-Definition 16:9 aspect image to eliminate the black side bars.

REGULAR - The regular ratio is used when you want to watch a 4:3 broadcast or recorded program without modifying the original picture to fit the dimensions of your 16:9 screen. The 4:3 picture will fill the screen from top to bottom, while black bars will appear to fill up the remaining space along the picture’s sides. The 4:3 picture will be centered within the boundaries of the 16:9 screen.

CINEMA ZOOM - This ratio stretches the High-Definition 16:9 aspect image to eliminate the black surrounding bars.

Button Functions

Aspect Ratios (Continued)

Press the ASPECT button

• By pressing the A

When you change the aspect ratios, it is different from their broadcast or recorded program.

SPECT button, you can change the size.

HD (1080i, 720p)NTSC, 480i, 480p

ASPECT

PANORAMA

CINEMA

FULL

REGULAR

Notes:

• You can also choose the size by pressing the

• When you change the aspect ratio or signal, reset the picture position to center.

• You can also access the FRONT CONTROL PANEL screen by using the MENU button on the front of the TV instead of the remote control. It appears between INITIAL SETUP and PICTURE ADJUST screen, and it has INPUT, VIDEO STATUS and ASPECT menus. Choose ASPECT by pressing MENU† on the front panel and choose a mode by using the CHANNEL +/- buttons ( √ OPERATE ® ).

π† buttons.

ASPECT

HD PANORAMA

CINEMA ZOOM

FULL

The MENU button allows you to access JVC’s onscreen menu system. Press MENU to activate the onscreen menu system.

• See individual topics like “Sound Adjust” for specific information on using menus.

This button confirms your selection when you are in one of the onscreen menus.

Back

This button allows you to go back in the menu to change a selection or correct a mistake.

Button Functions

TV/CATV Slide Switch

Use either the television’s own tuner or a cable box to select channels. Set this switch to TV to operate the television’s built-in tuner. Move the switch to CATV to operate a cable box.

Note:

• See page 28 for information on programming your remote for cable box operation.

VCR/DVD Slide Switch

You can control a VCR or DVD player with the buttons on the lower part of the remote control. Move the slide switch to VCR or DVD to operate.

Notes:

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other manufacturer’s brand VCR, please see the code chart and instructions on page 29.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other manufacturer’s brand DVD player, please see the code chart and instructions on page 30.

VCR Buttons

You can use this remote control to operate the basic functions of your VCR. These functions include: play, record, rewind, fast-forward, stop, pause, channel scan, TV/VCR, power on and power off.

Move the selector switch to VCR to operate.

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other manufacturer’s brand VCR, please see the code chart and instructions on page 29.

DVD Buttons

You can also use this remote control to operate the basic functions of your DVD player. These functions include: play, rewind, fast-forward, stop, still/pause, previous/next, tray open/close, power on and power off.

Move the selector switch to DVD to operate.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other manufacturer’s brand DVD player, please see the code chart and instructions on page 30.

Light

All remote control buttons are illuminated, except for the TV/CATV slide switch, VCR/DVD slide switch and Light button. Press the LIGHT button to turn the illumination on for 4 seconds.

Super Focus

This button is only located on the front panel of your TV. When you press the SUPER FOCUS button on the front of the TV, you can access the auto convergence mode in the convergence menu screen automatically. See page 44.

Digital Setup

Use this function when you are receiving a digital broadcast.

Press the M

π†

√®

To DIGITAL SETUP

To enter

The onscreen will appear

Notes:

• Software Update will only appear when the SD Card is inserted.

• If you are watching an analog channel, you can still access the digital setup menu at anytime, while you are doing this, the background screen will turn blank. In this case, the tuner will switch to digital, since you are accessing the digital setup menu.

Antenna Level

Confirms the present antenna level.

Press the MENU button

π†

√®

π†

√®

Note:

• If you are watching an analog channel or a signal from your i.Link device, antenna level will

To DIGITAL SETUP

To enter

To Antenna Level

To enter

not appear.

ENU button

Digital Setup

Antenna Level

Digital Sound

Aspect Ratio

Cable Card Application

i.LINK Auto Play

Software Update

Select

BACK

Back

BACK

Back

Operate

Antenna Level

Exit

PCM

4:3

OFF

Exit

Digital Setup

Digital Sound

You can select the optical digital sound output, either PCM or Dolby Digital when your TV is connected to an amplifier that has Dolby Digital decoder. If you select Dolby Digital, you can enjoy listening in 5.1ch sound when watching digital broadcasts.

Press the M

π†

√®

π†

√®

Notes:

• If your amplifier does not have Dolby Digital decoder, select PCM. If you don't select PCM, it

• For connecting an amplifier using the optical output, see page 20.

To DIGITAL SETUP

To enter

To Digital Sound

To select PCM or DOLBY DIGITAL

Press the MENU button when finished

cannot output the sound from the speakers.

ENU button

Manufactured under license from Dolby Laboratories. "Dolby", and the double-D symbol are trademarks of Dolby Laboratories.

Aspect Ratio

You can select the aspect mode for ATSC from 4:3 or 16:9.

Press the MENU button

π†

√®

π†

√®

Press the MENU button when finished

To DIGITAL SETUP

To enter

To Aspect Ratio

To select 4:3 or 16:9

Notes:

• Set the mode to 4:3 or 16:9 before you record a program using the ATSC MONITOR OUT.

• Make sure the mode you choose is the same as the TV’s aspect ratio when the recorded program is played back, so that you can obtain a good picture quality, free from any unatural distortions.

Digital Setup

Cable Card Application

Press the MENU button

π†

√®

π†

√®

Press the OK button

The application will perform

i.LINK Auto Play

When playing a D-VHS tape, you can set it to the i.LINK input automatically, or manually.

Press the MENU button

π†

√®

π†

√®

ON: Set to i.LINK input automatically OFF: Select the input manually

Press the MENU button when finished

To DIGITAL SETUP

To enter

To Cable Card Application

To enter

To DIGITAL SETUP

To enter

To i.LINK Auto Play

To select ON or OFF

Software Update

At first, insert the SD(Multi-media) card into the memory card slot. This function will appear only when you insert an SD Card.

Press the MENU button

π†

To DIGITAL SETUP

√®

To enter

π†

To Software Update

√®

To enter

π†

Checks the card if it needs an update or not

Press the MENU button when finished

Digital Button Functions

Digital CH D/A (Digital/Analog)

The D/A button changes the analog and digital channel. Each time you press the D/A button, you can switch back and forth the analog and digital channels. Digital channels have a "D" in front of the channel number.

Note:

• If the cable card is inserted into the TV, you cannot use the D/A button. You can select a digital channel only.

Press the D/A button

To watch digital channels

For example, to move to channel D23:

Press 2 (Two)

Press 3 (Three)

Press the T

Sub Channel

The main channel sometimes has minor channels (Sub Channels). By using the SUB button, you can select a sub channel easily.

For example, to move to sub channel 123-45:

Press 1 (One)

Press 2 (Two)

Press 3 (Three)

Press the SUB button

Press 4 (Four)

Press 5 (Five)

Press the TUNE button

UNE button

Note:

• If there are more than 2 major channels, select the digital channel by using the π† buttons and then press the O

K button.

Digital Button Functions

i.LINK Menu

i.LINK has two menus - Controller and Device.

By connecting a D-VHS VCR with an i.LINK cable, you can set the timer easily.

Notes:

• The i.LINK/Timer function will only work when you are receiving digital programming only.

• As for the connection of a D-VHS VCR with the i.LINK cable, see page 24.

• When operating the i.LINK, don't insert or disconnect the i.LINK cable.

Controller

You can operate a D-VHS VCR connected with an i.LINK cable by using this controller.

Notes:

• If the i.LINK is not connected, the Controller OSD will not appear. The OSD of device on page 76 will appear.

• Some controller operations may differ from your D-VHS VCR operations.

Press the i.

LINK MENU button

i.LINK

D-VHS1

Device

√®

π†

To select the key you want to operate

Press the OK button

Controller

STOP 00:00:00

POWER

Digital Button Functions

Device

To operate, select a device.

i.LINK

Controller Renumber

Device

D-VHS1

HM-DH30000U

D-VHS2

HM-DH40000U

HD-MOVIE 1

GR-HD1

π†

To select your device connecting with i.LINK

Press the OK button

Notes:

• If you do not select the device, you cannot use the i.LINK timer functions.

• When one device is selected and you select controller, you will move to the Controller onscreen.

• The devices listed on the device onscreen are only D-VHS and HD-MOVIE that have i.LINK,

which can be recognized on this television. However, you can not record programs to HDMOVIE.

• If you disconnect one device, it will be removed from the list. Then, select Renumber to rearrange the list in the new order.

Page 2/3

JVC

Digital Button Functions

Timer

You can set the two timers: Record and view. The timer starts the recording or turns to the channel you set for it automatically.

Reservation

Press the T

π†

To New Reservation

Press the OK button

†

To Timer Mode

√®

To select Rec or View

†

To Channel

√®

To select the channel you want to set the timer for

†

To Date

√®

To select the date

†

To Start Time

√®

To set the start time

†

To End Time

√®

To set end time

†

To Weekly/Daily

√®

To select Once, Weekly, Daily(Sun.-Sat.), Daily(Mon.-Sat.) or Daily(Mon.-Fri.)

†

To Rec to i.LINK

√®

To select ON or OFF

†

To Set Timer

Press the OK button

If you set the Rec on timer mode, set recording is added in front of the program

title.

If you set the View on timer mode, set viewing is added in front of the program

title.

Notes:

• In order for the i.LINK timer setting to work, you must set the clock on your television. See page 60.

• When you want to edit the timer settings, see Timer Edit on page 78.

• When you have set a REC timer or VIEW timer, a PROGRAM indicator will light on the front panel. While a timer is set, the indicator light will not turn off even if you turn the power off.

IMER button

New Reservation

Timer Mode

0. New Reservation

New Reservation

80-3 PBS1DTV

Sep. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

i.LINK

Sep. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

335-1 KDVRet Regular Schedule

Sep. 18 (Wed) 5:00PM - 6:00PM Daily

35-1 PBPBPB

i.LINK

Sep. 18 (Wed) 8:00PM - 8:30PM Weekly

Channel

Date

Start Time

End Time

Weekly/Daily

Rec to i.LINK

Cancel

Sept. 10 (Wed) 4:55PMTimer

Set Timer

Page 1/3

Sep. 10 (wed)

5:00PM

6:00PM

Weekly

Rec

35-1

Digital Button Functions

Timer Edit

When you want to confirm the timer you set or edited, or delete the timer setting, use this function.

Timer Edition

Press the TIMER button

π†

To select the timer list you want to edit

Press the OK button

Timer Edit

Sept. 10 (Wed) 4:55PMTimer

Timer Mode

0. New Reservation

i.LINK

√®

π†

To change the setting you want to edit

†

To Set Timer

Channel

Date

New Reservation

Start Time

80-3 PBS1DTV

End Time

Sep. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

Weekly/Daily

Sep. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

Rec to i.LINK

335-1 KDVRet Regular Schedule

Sep. 18 (Wed) 5:00PM - 6:00PM Daily

35-1 PBPBPB

Sep. 18 (Wed) 8:00PM - 8:30PM Weekly

Press the OK button

Cancel

Set Timer

Rec

35-1

Page 1/3

Sep. 10 (wed)

5:00PM

6:00PM

Weekly

Delete

Timer Deletion

Press the TIMER button

π†

To select the timer list you want to delete

Press the O

π†

To Delete

Press the OK button

K button

Digital Button Functions

Cancel the timer recording

When you record a digital program now, you can cancel the recording.

Press the T

π†

To select the timer list you want to cancel

the recording

Press the OK button

The message "Do you want to

IMER button

0. New Reservation

New Reservation

80-3 PBS1DTV

Do you want to terminate current program?

Sept. 11 (Wed) 6:00PM - 6:30PM Once

335-1 KDVRet Retailer News Channel

i.LINK

Sept. 11 (Wed) 6:00PM - 7:00PM Mon - Fri

No Yes

Sep. 10 (Wed) 4:55PMTimer

Page 1/1

terminate current program ?" will appear.

√®

To select

YES: Cancel the recording NO: Continue the recording

Press the OK button

Guide

You can view the program from the GUIDE.

Notes:

• The GUIDE function will only work when you are receiving digital programming only.

• The GUIDE will not show the correct time and date if you have not performed the set clock function on your television. See page 58.

OSD Information

Weak Signal

This OSD warning appears when the digital channel that you have selected is too weak to receive or no signal is being detected for that channel.

Weak Signal

Cable Card Information

Cable card offers information when a cable card is inserted into the CABLE CARD slot on the back of the TV.

Note:

• Please contact your local cable company regarding detailed information.

Cable Card Connection

CABLE CARD

ATSC

/DIGITAL CABLE IN

CABLE CARD

TV Rear Panel

Note for inserting Cable Card:

• When you are watching a digital program, and if a weather or government emergency occurs, the following may occur automatically regardless of what channel you were watching: the channel may change, the screen will disappear or important text will appear on the screen. The information is transmitted from EAS (Emergency Alert System), Firmware Upgrade of Cable Card or compulsory HTML.

No Program

If the TV channel you selected, or were watching is not receiving a signal, "NO PROGRAM" appears on the television screen. It appears when that channel is not receiving a signal and you have the Noise Muting function OFF and you have a single screen. It moves automatically every two seconds to prevent the screen from burn-in. See page 6.

Note:

• Even if "NO PROGRAM" appears on the screen, your timer functions and auto shut off functions that you set, are still active.

Troubleshooting

PROBLEMS CHECK

There is no power

There is no picture or sound

Remote control is not operating properly or at all

You cannot select a certain channel

The power turns off by itself

The clock is wrong

The color quality is poor

There are lines across the picture

The picture is spotted

There are double pictures (ghosts)

Picture is snowy (image noise)

Screen is 40% black

Stereo or bilingual programs can't be heard

There is no sound from the TV's speaker

Static electricity

You hear occasional crackling sounds

The AUTO DEMO finished automatically

The square appears and blinking

It does not operate correctly

• See if the power cord became unplugged.

• Check for a blown fuse or circuit breaker or a power outage.

• The antenna could be disconnected.

• The input mode could be set improperly. See page 62.

• The tuner (Auto Tuner Setup) could be set improperly. See page 35.

• The TV station may be having difficulties. Check to see if other stations are working.

• Check to see that the batteries are still working and properly installed.

• Make sure the remote has a clear sight path to the TV.

• Check that the TV/CATV switch is in the proper position.

• You may be too far from the TV. You must be within 23 feet (7 meters).

• Make sure the channels have been programmed. See "Channel Summary", page 36.

• Check to see if the channel is locked. See "Channel Summary - Lock" page 37.

• Make sure the set did not become unplugged.

• Perhaps the On/Off Timer is set. See page 59.

• Check to see if the Sleep Timer was set. See page 65.

• The power was interrupted and the clock was not reset. See page 58.

• Tint and Color may be improperly adjusted. See page 55.

• The Video Status mode may be turned to the wrong setting. See page 64.

• There could be interference from another electrical appliance, such as a computer, another TV or VCR. Move any such appliances further away from the TV.

• There could be interference from a high-wattage appliance, like a hairdryer or vacuum, operating nearby. Move the antenna away from the appliance or change to a coaxial cable connection which is less prone to interference.

• A building or passing airplane can reflect the original signal and produce a second, slightly delayed one. Adjust your antenna position.

• Your antenna may be damaged, disconnected or turned. Check the antenna connection. If the antenna is damaged, replace it.

• The Closed Caption Text mode is on. Turn it off in the Closed Caption Menu, page 47.

• Make sure the MTS settings are correct. See page 65.

• The Center CH Input may be turned on. See page 54.

• It is normal to feel static electricity if you brush or touch the screen.

• It is normal for the TV to make crackling sounds when first turned on or off. Unless the sound or picture become abnormal, this is fine.

• The TV recieved a signal from the AV CompuLink

• The On Timer that you programmed has started.

• The channel that the AUTO DEMO is using is a channel that is blocked by V-Chip.

• The Auto Shut Off that you programed has occured.

• It appears when you are operating the Auto Convergence. If not, then this may be a problem with the Auto Convergence. Contact a service agent.

• Press the CHANNEL- and VOLUME- buttons on the front panel of the TV simultaneously for a few seconds. The Digital Tuner will be reset. If this does not reset it correctly, unplug the power cord and plug it back in.

848586

Specifications

Model

Reception Format

Reception Range

Power Source

Power Consumption

Screen Size 48 inch / 122 cm

Speakers 13 cm round X 2

Audio Output Full Range - 10W + 10W

Antenna Terminal

(VHF/UHF,

ATSC/DIGITAL

CABLE IN)

External Input Jacks

Component Input

Jack

S-Video Input Jacks

Monitor/Recording

Output

Audio Output Jacks

(FIX)

Optical Output

Digital Audio

i.LINK In/Out Jack

AV CompuLink III

Jack

Digital–In

Dimensions (in) W X H X D (cm)

Weight (lbs / kg)

Accessories

VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands (191 channel frequency synthesizer system)

• Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers) is not recommended for your TV set.

AV-48P775

Rear Projection TelevisionType

NTSC, BTSC System (Multi-Channel Sound)

ATSC Terrestrial, Digital Cable

AC 120V, 60 Hz

259W

measured diagonally, 16:9 ratio

75 ohms (VHF/UHF)(F-type connector)

Video: 1 Vp-p, 75 ohms

Audio: 500 mVrms (-4dBs) high impedance

Y: 1Vp-p positive, 75 ohms (negative sync provided)

500mVrms (-4dBs) Low impedance (1000 Hz when modulated 100%)

IEEE1394 compliant DTCP digital copy protection compatible

HDMI jack x 1 Note: The Digital–In terminal is not compatible with picture signals of a personal computer

47 1/4 x 46 7/8 x 24 1/2

120 x 118.9 x 62.2

Illuminated remote control unit x 1 / AA batteries X 2

Pb/Pr: 0.7 Vp-p 75 ohms

C: 0.286 Vp-p (burst signal), 75 ohms

Video: 1Vp-p, 75ohms

C: 0.286 Vp-p (burst signal), 75 ohms

Audio: 250mVrms (-10dBs)

Fs-18dB Low Impedance

Digital Out (optical) x 1

TS IN/OUT (4-pin, S400) x 2

3.5 mm mini jack X 1

168 / 76 183 / 83

Two-way Splitter x 1 / RF Cable x 2

AV-56P785 AV-56P775

56 inch / 142 cm

measured diagonally, 16:9 ratio

53 7/8 x 51 1/8 x 26 3/8

136.8 x 129.6 x 66.7

Specifications subject to change without notice.

Notes

JVC COMPANY OF AMERICA

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square Scarborough, Ontario

Canada, M1X 1A7

JVC LCT1676-001B-A, 1204TNH-II-IM User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
