BLU-RAY DISC & HDD RECORDER

STOP REV PLAY PAUSEFWD

OPEN/ CLOSE

STANDBY/ON

HDV/DVIN

REC

SDREC CERDDH BD

ONETOUCH

DUBBING

REC

MODE

RESET

INPUT

SELECT

HDD

MIDIA SELECT

BD/SD

For Customer Use:

Enter below the Model No. and Serial No. which are located on the rear of cabinet. Retain this information for future reference.

Model No.

Serial No.

INSTRUCTIONS

SR-HD1500US SR-HD1250US

(A)

LST1083-001C

OF ELECTRIC SHOCK

NOT OPEN

DE CHOC ELECTRIQUE

NE PAS OUVRIR.

Cautions

CLASS 1 LASER PRODUCT REPRODUCTION OF LABELS

WARNING LABEL INSIDE OF THE UNIT

This unit apply to the standard AIEC60825-1:2001B for laser products.

Dear Customer,

Thank you for purchasing the JVC BLU-RAY DISC & HDD recorder. Before use, please read the safety information and precautions to ensure safe use of your new unit.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION:

A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.

WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CAUTION

AVIS

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classeBest conformeàla norme NMB-003 du Canada.

RISQUE DE CHOC ELECTRIQUE

- NE PAS OUVRIR.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION:

This unit should be used with AC 120VH, 60Hz only. To prevent electric shocks and fire hazards, DO NOT use any other power source.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

“WARNING” and the following or equivalent. “To reduce the risk of fore or electric shock, do not expose this apparatus to rain or moisture.”

A warning that an apparatus with CLASS I construction shall be connected to a MAINS socket outlet with protective earthing connection.

WARNING

Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

Main Plug The Main Plug is used as the disconnect device, the disconnect device shall remain readily operable

Safety Precaution

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10)Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11)Only use attachments/accessories specified by the manufacturer.

12)Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tipover.

13)Unplug this apparatus during lightning storms or when unused for long periods of time.

14)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Failure to heed the following precautions may result in damage to the unit, remote control or disc/cassette.

1. DO NOT

place the unit ^

^ in an environment prone to extreme temperatures or

humidity.

^ in direct sunlight. ^ in a dusty environment. ^ in an environment where strong magnetic fields are

generated.

^ on a surface that is unstable or subject to vibration.

2. DO NOT

block the unit’s ventilation openings or holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3. DO NOT

place heavy objects on the unit or remote control.

4. DO NOT

place anything which might spill on top of the unit

or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

5. DO NOT

expose the apparatus to dripping or splashing.

6. DO NOT

use this equipment in a bathroom or places with

water. Also DO NOT place any containers filled with water or

liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

7. DO NOT

place any naked flame sources, such as lighted

candles, on the apparatus.

8. AVOID

violent shocks to the unit during transport.

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly. Use the supplied power cord. (If not, fire or electric shock may be caused.) DON'T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way -- switch off, withdraw the mains plug and consult your dealer. DO be careful with glass panels or doors on equipment. DO consult you dealer if you are ever in doubt about the installation, operation or safety of your equipment. NEVER let anyone especially children push anything into holes, slots or any other opening in the case -- this could result in a fatal electrical shock.

MOISTURE CONDENSATION

Moisture in the air will condense on the unit when you move it from a cold place to a warm place, or under extremely humid conditions^just as water droplets form on the surface of a glass filled with cold liquid. In conditions where condensation may occur, disconnect the unit’s power plug from the wall and keep it disconnected for a few hours to let the moisture dry, then turn on the unit.

CAUTION:

Changes or modifications not approved by JVC could void user’s authority to operate the equipment.

Declaration of Conformity

Model Number: SR-HD1500US Trade Name: JVC

Responsible Party: JVC Americas Corp. Address: 1700 Valley Road Wayne, N.J. 07470 Telephone Number: 973-317-5000 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Safety Precaution

● Manufactured under license from Dolby Laboratories. Dolby and

the double-D symbol are trademarks of Dolby Laboratories.

● Manufactured under license under U.S. Patent #'s: 5,451,942;

5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio | Essential are trademarks of DTS, Inc. © 19962008 DTS, Inc. All Rights Reserved.

● This product incorporates copyright protection technology that is

protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

● DVD logo is a registered trademark of DVD Format/Logo

Licensing Corporation.

● HDMI, the HDMI logo and High-Definition

Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

● “Blu-ray Disc” and the “Blu-ray” logo are trademarks.

● “x.v.Color” and the “x.v.Color” logo are trademarks of Sony

Corporation Co., Ltd.

● Java and all Java-based trademarks and logos are trademarks or

registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

● SDHC logo is trademark.

● “AVCHD” and the “AVCHD” logo are trademarks of Panasonic

Corporation and Sony Corporation.

● Other product and company names included in this instruction

manual are trademarks and/or registered trademarks of their respective holders.

● This product is licensed under the AVC patent portfolio license

and VC-1 patent portfolio license for the personal and noncommercial use of a consumer to (i) encode video in compliance with the AVC Standard and VC-1 Standard (“AVC/VC-1 Video”) and/or (ii) decode AVC/VC-1 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to provide AVC/VC-1 Video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC. See http://www.mpegla.com.

DISCLAIMER OF LIABILITY

JVC shall not be liable for any loss relating to the unit’s failure to properly record, store or playback any content (video, audio or otherwise) for any reason whatsoever. Any applicable warranties shall only cover replacement or repair of the effected unit, and shall not apply to recovery or replacement of lost content.

● This unit can play back and record only NTSC signals.

The hard disk is a consumable item. Replacement is recommended after 10000 hours of use (if use in a 25°C environment). For information on maintenance planning and costs, consult your nearest JVC dealer. The fan motor is a consumable item. Replacement is recommended after 30000 hours of use (if use in a 25°C environment). For information on maintenance planning and costs, consult your nearest JVC dealer.

HOW TO USE THIS INSTRUCTION MANUAL

● All major sections and subsections are listed in the Table Of

Contents on page 5. Use this when searching for information on a specific procedure or feature.

● The A mark signals a reference to another page for instructions

or related information.

● Operation buttons necessary for the various procedures are

clearly indicated through the use of illustrations at the beginning of each major section.

BEFORE YOU INSTALL YOUR NEW UNIT . . . . . . please read the sections/literature listed below.

● “Cautions” on page 2

“ IMPORTANT SAFETY INSTRUCTIONS” on page 3 to 4

Batteries -- Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below:

● Use the specified batteries only.

● Install the batteries with due attention to the plus (+) and

minus (-) sides of the batteries according to the instructions in the compartment.

● Do not mix old and new batteries.

● Do not mix batteries of different types. Voltage specifications

of batteries of the same shape may vary.

● Replace an exhausted battery with a new one promptly.

● If you will not use the remote control for a long time, remove

the batteries.

● If leaked battery fluid gets on your skin or clothing, rinse

immediately and thoroughly. If it gets into you eye, bathe your eye well rather than rubbing and seek medical treatment immediately. Leaked battery fluid that gets into your eye or your clothing may cause a skin

●

Do not put the batteries in a place where young children can reach.

irritation or damage your eye.

ATTENTION:

Using a mobile phone in the vicinity of the unit may cause picture vibration on the TV screen or change the screen to a black back display. Some TVs or other appliances generate strong magnetic fields. Do not place such appliances on top of the unit as it may cause picture disturbance. When moving the product, press A to turn off the power, and wait at least 30 seconds before unplugging the power cord. Then, wait at least 2 minutes before moving the product. If there is a power outage when using the unit, the recorded data may be erased. It is recommended to back up discs which contain important recordings periodically (every few years). As digital signals do not deteriorate, failure to play back or record might arise due to the effects of the disc aging through the years depending on the storage environment. Recorded programs and data cannot be restored once the disc or tape is damaged.

If this symbol is shown, it is only valid in the European Union.

Safety Precaution

Contents

Safety Precaution

Contents

Getting Started

Key Features ..................................................................... 6

How to Read this Manual .................................................. 6

Other Precautionary Notes ................................................ 7

Hard Disk Drive (HDD) ...................................................... 8

SD Cards ........................................................................... 8

Discs .................................................................................. 9

Precautions on the Use of Discs ..................................... 11

On-screen Displays ......................................................... 12

Name and Function of Parts ............................................ 13

Front panel ................................................................... 13

Display window ............................................................ 14

Rear panel ................................................................... 14

Remote control ............................................................ 15

Preparation

Connecting a Monitor ...................................................... 17

Connecting a Video Deck or Other Equipment ............... 18

Connecting an Amplifier .................................................. 18

Connecting External Devices .......................................... 19

Connecting the Power Supply ......................................... 19

Setting and Displaying Date/Time ................................... 20

Dubbing/Importing

Dubbing/Importing ........................................................... 23

Dubbing chart .............................................................. 24

Formatting ....................................................................... 25

Recording Modes ............................................................ 28

Importing Data to the HDD Using the ONE TOUCH

DUBBING Button ......................................................... 29

Importing Data from a BD/DVD to the HDD .................... 30

Importing Data from a USB-compatible Device to the HDD

...................................................................................... 33

Importing Data from an SD Card to the HDD .................. 35

Importing Data from an i.LINK-compatible Device to the

HDD ............................................................................. 37

Dubbing a Title from the HDD to a BD/DVD .................... 39

Dubbing Still Images from the HDD ................................ 42

Enabling Playback on Other Devices (Finalizing) ............ 44

Copying the Entire Disc ................................................... 46

Recording Using External Inputs ..................................... 47

Playing Back

About Playing Back ......................................................... 48

Using Playback Navigation .............................................. 48

Option menu list ........................................................... 50

Video Playback Operation ............................................... 51

Playing Videos on a BD/DVD .......................................... 53

Playing Videos on the HDD ............................................. 54

Playing Videos on a SD Card .......................................... 54

Playing Still Images (JPEG) ............................................ 55

Changing Playback Settings ........................................... 56

Playback Settings Menu .................................................. 56

Audio/subtitle settings .................................................. 56

Playback settings ......................................................... 56

Video settings .............................................................. 57

Editing

Editing ............................................................................. 58

Entering Characters ........................................................ 59

Character List .............................................................. 59

Grouping .......................................................................... 60

Changing the Title/Group Name ...................................... 62

Deleting a Title/Group ..................................................... 62

Turning On Title/Group Protection .................................. 63

Turning Off Title/Group Protection .................................. 64

Creating a Playlist ........................................................... 65

Editing a Thumbnail ......................................................... 66

Editing a Chapter ............................................................. 67

Dividing ............................................................................ 69

Delete Scenes ................................................................. 70

Changing the Disc Name ................................................ 72

Changing the Shooting Date/Time .................................. 72

Mode conversion ............................................................. 73

Settings Menu

Changing Settings of this Unit ......................................... 74

Setting Menu List ............................................................. 74

Setup ........................................................................... 75

Playback Setting .......................................................... 76

Record ......................................................................... 77

Audio ............................................................................ 78

Display ......................................................................... 79

Connection ................................................................... 80

Others

Locking the Disc Tray ...................................................... 82

Turning on the Mode Lock ............................................... 82

Last Function Memory ..................................................... 82

RS-232C Interface (only for SR-HD1500) ....................... 83

Command Table .......................................................... 83

Specifications ............................................................... 83

Command .................................................................... 84

Language Code List ........................................................ 94

Country Code List ............................................................ 96

Using the HDMI Consumer Electronics Control (HDMI

CEC) ............................................................................ 98

Creating a Seamless BD ................................................. 98

Troubleshooting ............................................................... 99

Specifications ................................................................ 101

Index .............................................................................. 102

Getting Started

Key Features

Professional Blu-ray Disc recorder of the high-definition era

Copy videos to a Blu-ray Disc in high-definition from a highdefinition camcorder, or down convert the videos and record them onto DVDs, all without the need for a PC. The internal hard disk drive enables for easy editing and dubbing multiple discs.

Compatible with ProHD Camcorder GYHM700/100 (only for SR-HD1500)

MOV files that are taken in SP mode (*1) using the JVC ProHD Camcorder GY-HM700/100 are compatible with the SR-HD1500, and can be imported into the HDD or dubbed onto discs.

(*1) SP mode : 1280x720/60p, 30p, 24p, 1440x1080/60i

Compatibility with other consumer camcorders

In addition to AVCHD, HDV and DV, JVC Everio file formats are also compatible, and digital dubbing can be done.

Digital interface that allows for camcorder compatibility

This unit is equipped with USB, SD slots and i.Link input terminals for connecting the camcorder.

Create menu-supported Blu-ray discs

Blu-ray discs can be created using the BDMV (with menu) format. BDAV discs can also be created and dubbed according to the intended use. The SR-HD1500 also enable users to use an original image as the background.

How to Read this Manual

About this manual

This manual mainly describes operation procedures using the remote control unit buttons.

The buttons on the remote control unit are indicated as [Button Name].

The menu items are indicated as “Menu Item”.

Supplementary remarks in the main text

Memo : States restrictions on the functions or use of this unit.

Note : States precautions to be taken during operation.

: Indicates the page numbers or items to refer to.

Memo:

The displays of operable media are highlighted.

HDD : Hard disk

DVD : DVD

BD : Blu-ray disc

SD : SD card

SDHC : SDHC Card

CD : Music compact disc

JPEG : JPEG (still picture) file disc

The unit illustrations used in this manual are from the SRHD1500.

Refer to the supplied CD-ROM for the Spain and French GUIDEBOOK. In order to view the GUIDEBOOK, AdobeT AcrobatT ReaderE or AdobeT ReaderT must be installed. AdobeT ReaderT can be loaded from Adobe’s web site:http://www.adobe.com/

Compatible with dual layer 50 GB Blu-ray discs, and records up to 24 hours of full high-definition images in a single disc

This unit is also compatible with high capacity dual layer 50 GB Blu-ray discs, and up to 24 hours (AE mode) of full highdefinition images can be recorded in a single disc. Writing to inexpensive LTH discs is also supported.

Authoring menu enables discs to be created and used industrially such as for demonstrations

Disc authoring can be used to create discs for industrial use, such as discs that repeat playback automatically.

Equipped with external control RS-232C terminal (only for SR-HD1500)

This unit is equipped with a RS-232C terminal that allows for external control using a PC.

Menu operation

Pressing the remote control buttons below calls up the respective menu screens.

[SET UP], [NAVIGATION], [EDIT], [INFORMATION CORRECT], [DUBBING], [MEDIA MANAGE]

Press any of the [ J / K / H / I ] buttons to move to a specific menu item (yellow item indicated by a small arrow).

Press the [OK] button to confirm the selection.

Press the [RETURN] button to return to the previous screen.

Simple instructions on the operation procedure may be displayed at the bottom of the screen.

Getting Started

Other Precautionary Notes

This unit supports copyright protection technologies.

Copyrights

According to the copyright law, video or music data that you store must not be used for purposes other than personal enjoyment without the authorization of the copyright holder.

This product employs the CPRM technology, and is protected by the proprietary technologies as well as intellectual property rights of the United States and Japan. Use of the CPRM technology is subject to the approval of Macrovision Solutions Corporation. Unless special authorization is obtained from Macrovision Solutions Corporation, the CPRM is restricted to household and some pay-per-view uses. Do not dismantle or remodel this product. The copyright protection function prevents copyrighted video images from being saved to equipment such as a video recorder. This function may also cause deterioration in the playback picture quality when the data is output to a monitor through a video recorder. This is not a hardware malfunction. To play back copyrighted videos, connect this product directly to the monitor.

Read and understand fully the terms and conditions of all copyright works before using this unit in the correct manner. Under no circumstances shall JVC take any responsibility for any infringements of copyright caused by the customer when using this unit. The customer shall be responsible for resolving all legal issues regarding to any copyright infringements.

Stored video content and compensation

For discs containing important video content, backup on a periodic basis (once every few years) is recommended. Although digital signals do not deteriorate, playback or dubbing may fail due to aging of the disc resulting from the storage conditions.

Recorded data may be lost if power outage occurs while this unit is being used. It is therefore recommended that videos stored on the HDD be dubbed to a BD or DVD as soon as possible in case the HDD breaks down.

Videos or data stored on a BD/DVD, HDD, or SD card cannot be recovered if the media is damaged.

Disclaimer of compensation for loss or damage of stored video content

Please note that our company will not be liable for compensation of the content or any incidental damages in the event that dubbing or playback cannot be performed properly for some reasons. The same applies during repair of this unit.

Handling precautions

Do not use the plug or power point with dust or metallic objects attached to it

Failure to do so may cause short circuit or heating, and result in fire or electric shock.

Remove the plug once every half a year, and clean it with a dry cloth.

Make use of a power point that allows the power plug to be inserted or removed easily

Make sure that the plug can be removed immediately in case an abnormality is found in the unit.

Insert the plug firmly into the power point

Failure to do so may cause short circuit or heating, and result in fire or electric shock.

Do not make use of a power voltage other than that specified

Doing so may result in fire or electric shock.

Do not insert or remove the plug with wet hands

Doing so may result in electric shock.

Do not touch the plug when there is thunder or lightning

Doing so may cause electric shock.

Do not insert any foreign object into this unit

Doing so may result in fire or electric shock.

Do not dismantle or remodel this unit

This unit consists of high-voltage components. Dismantling or remodeling the unit may cause fire or electric shock.

Request the authorized dealer to inspect the interior part of the unit once a year

Using this unit with dust accumulated inside may result in fire.

It is particularly effective to perform servicing before the humid rainy season.

Do not connect any video cameras that are not made by JVC to the USB terminal

Doing so may result in malfunction.

Getting Started

Hard Disk Drive (HDD)

Hard disk drive (HDD)

The HDD rotates at a high speed whenever the power is turned “On”. Pay particular attention to the following precautions when using this unit.

Warning

Do not subject it to vibration or strong impact

Subjecting this unit to excessive impact may result in loss of recorded data and even damage of the HDD.

Do not remove the power plug when this unit is running

Shutting down the power when the HDD is running may result in data loss and even damage of the HDD. Make sure that the power plug is removed only after turning off the power. (Wait for the “GOODBYE” message on the display window to disappear first)

SD Cards

Precautions for handling SD and SDHC cards

Note:

The disc operation display icon appears blinking and “READING” is displayed on the display window when the SD card is being accessed (such as during dubbing, playback, or formatting). When access to the SD card is in progress, do not remove the card or the power plug. Doing so may cause the SD card to become unusable. If the SD card is not usable, reformat the card. If the problem persists even after reformatting, use a new SD card.

Do not use or store the card at a place that is subject to static or electrical noise.

Inserting the SD card incorrectly may cause this unit or the card to malfunction.

Our company will not be liable for any damage or loss of the stored data due to accidents. (Be sure to back up the data.)

Use the card according to the prescribed conditions. Do not use it at the following locations.

Places that are exposed to direct sunlight

Places near heat-generating equipment

Inside a car that is under the sun with the windows tightly shut

Places that are subject to high humidity and corrosion

Do not bend or drop the card, or subject it to strong impact or vibration.

Do not expose the card to water.

Do not place near devices that emit strong magnetic or radio waves.

Do not touch the metal part of the card.

Memo:

To dispose a card after erasing all data inside, it is recommended that this be done using a commercially available data deletion software, or by destroying the card physically, such as with a hammer. Formatting or deletion of data using this unit only changes the file administration information, and does not erase the data completely.

BD video data

You can erase BD Video data from the SD card as follows.

Insert the SD card which has BD video data stored on it, into the [SD SLOT]

Memo:

The BD video data cannot be erased if the SD card is writeprotected. In this case, turn off the write-protect lock before inserting the SD card.

Press the [MEDIA MANAGE] button on the remote control unit

Select “BD-VIDEO DATA ERASE” from “SD CARD”

The confirmation screen for erasing the BD video data is displayed.

Select “ERASE”, and press the [OK] button

The BD video data will be erased.

Discs

BD recording formats

BDAV mode

Videos can be edited (chapter edit etc) and new videos can be added to the disk. This format is suitable for recording videos.

MPEG2 with HD quality will be recorded as it is onto the disc. This format has low playback compatibility, but performs well when used for backups.

BDMV mode

Compatible and playable on other BD players. Menu functions similar to those of DVD video mode are also included. This format performs well for distribution purposes.

DVD recording formats

VR MODE

Format the disc using “VR MODE” if you want to add new videos to the disc.

Deleting currently saved videos increases the remaining space on the disc. (except for the case of DVD-R discs.)

VIDEO MODE

Format the disc in this mode if you want to play the disc on a different DVD player.

Getting Started

When using DVD-RW discs

Formatting is required. Format the disc using this unit.

Format using “VR MODE” or “VIDEO MODE”.

Formatting of discs

Formatting is required for some disc types. Perform formatting if this is necessary.

When using BD-RE or BD-R discs

Formatting is required. Format the disc using this unit.

When using DVD-R discs

Formatting is required depending on the disc mode to be used.

Formatting is required when the disc is used in “VR MODE” . Format the disc using this unit.

Formatting is not required when using the disc in “VIDEO MODE”.

Note:

BD-R and DVD-R discs cannot be reformatted. Check the disc mode before formatting the disc.

Getting Started

Discs (Continued)

Discs that enable both dubbing and playback

Disc Type Recording Format Format Finalize Repeated Use

(Reformat)

BD-RE BDAV mode V - V

BDMV mode V - V

BD-R BDAV mode V V -

BDMV mode V - -

DVD-RW Video mode V V V

VR mode V V V

DVD-R Video mode - V -

VR mode V V -

Discs that enable playback only

Disc Type Description

DVD-RAM (4.7 GB) Supports specific forms of playback, but no recording can be done.

BD-ROM Commercially available Blu-ray discs (movies, music, etc.)

The region code that can be played back on this unit is “A”.

DVD video Commercially available DVD-Video discs (movies, music, etc.)

The region code that can be played back on this unit is “1”. The video format used is NTSC.

Music CD CD-DA

DTS music CDs are also playable.

Memo:

If 8 cm discs are used, only playback can be performed. The disc cannot be used for recording or editing.

8 cm discs can be used without adapters.

DVD-RAM cartridges and BD-RE are not supported. Take the DVD-RAM out of the cartridge before using it.

Discs that are not supported

DVD-RAM (2.6 GB/5.2 GB)

DVD-R (for authoring)

CD-ROM/R/RW (PhotoCD, CD-G, VCD etc.)

DDCD (1.3 GB, Double Density CD)

HDCD (High Density CD)

Memo:

To playback a BD or DVD that was created using this unit on another player, finalize the disc.

There is no need for finalizing if the BD-RE disc is recorded using BDAV mode.

If a DVD that was recorded using VR mode has been finalized, the disc can only be played back on VR mode compatible devices.

To perform high-speed dubbing, make use of a disc that supports high-speed recording.

This unit can play back and record only NTSC signals.

Note:

Do not use disc if the sticker or label is peeled off from the disc surface, if the disc is not round in shape, or if it is significantly warped or cracked.

Getting Started

Precautions on the Use of Discs

Maintenance of discs

Dirt attached to the disc, such as fingerprints and dust, may cause distortion in the video image or sound. Keep the disc clean at all times such as by using a soft cloth.

Wipe the disc lightly from the center outward using the cloth.

If dirt is stubborn, wipe it off using a slightly wet cloth, followed by a dry cloth.

Do not use thinner, benzine, alcohol, conventional record cleaners, or antistatic sprays. Doing so may damage the disc surface.

Handling discs

Removing a disc

Disc storage

Avoid storing the disc at the following locations.

Places that are subject to high humidity, dust, or mold

growth

Places that are exposed to direct sunlight or near a

heater

Inside a car during summer

Do not drop the disc or subject it to strong impact.

Place the disc in a case and store it vertically.

Stacking the discs without using a case, placing the discs against one another or dropping them may result in deformation or cracking.

When the recording/playback lens is dirty

Dust or dirt may be attached to the recording/playback lens after using this unit for a prolonged period of time, and recording or playback may not be properly performed as a result. Although the performance of this unit varies according to the frequency of use and installation environment, it is recommended that cleaning of the lens be performed once every half a year using commercially available DVD lens cleaners. For cleaning procedures, refer to the instruction manual of the lens cleaner.

Keeping a disc

Correct way to hold a disc

Make sure that your hands do not touch the recording/ playback side of the disc.

Precautions when playing a dual disc

The side of the dual disc that is not used for DVD recording does not comply with the standard specifications of music CDs. It is recommended that playback on this unit be limited to the DVD recording side of the dual disc.

Use genuine JVC discs

The best performance may not be obtained for some discs. It is recommended that genuine JVC discs be used to ensure the best results.

Power Cable

Do not unplug the cable during recording or playback. Doing so may cause the disc to become unusable. If the disc becomes unusable, refer to the following.

BD-R or DVD-R

BD-RE or DVD-RW

Do not turn off the [A] button or unplug the power cable immediately after closing the disc tray.

: Use a new disc.

: Reformat the disc after erasing the data. If the

disc is still not usable, use a new disc.

Getting Started

On-screen Displays

Status display

Displays the current settings and operating status (such as playback, pause) of this unit. Pressing the [ON SCREEN] button on the remote control displays the status. To cancel the display, press the [ON SCREEN] button again. You can select whether to display the statuses by changing the settings in the settings menu. For more details, refer to “Display” (A page 79) .

Memo:

To display the statuses, set the ON SCREEN GUIDE item on the DISPLAY menu screen to “AUTO”.

Setting the DISPLAY item to “OFF” hides display of all status information.

Event display

An on-screen event display appears on the display window as well as the monitor when there is a misoperation.

The event display appears for an interval of about three seconds.

Memo:

The same event display may appear several times.

Alarm display

When an operation is not accepted by this unit, an on-screen alarm display appears on the display of the main unit as well as the monitor.

Name and Function of

A B C D E H

RQPON

J LGF MI K

Parts

Front panel

Getting Started

A [ A ] button

Turn On/Off the power.

B Disc tray C [ M ] button

Opens/closes the disc tray.

D Display window E Remote control sensor F [RESET] switch

Reset the unit.

G [REC MODE] button

Switches the recording mode.

H [HDD] lamp

Lights up when in HDD mode. The [REC] lamp lights up while recording/importing.

I [INPUT SELECT] button

Switches the external input signals (HDV/DV, L1).

J [BD] lamp

Lights up when in BD/DVD mode. The [REC] lamp lights up while recording/dubbing.

K [MEDIA SELECT] button

Switches between HDD and BD/SD.

L [SD] lamp

Lights up when in SD mode.

M [ONE TOUCH DUBBING] button

Starts dubbing at a single touch.

N Playback control buttons

[ I ] button Plays back the data.

[ o ] button Stops playback/recording.

[ O ] button Fast reverses playback.

[ N ] button Fast forwards playback.

[ W ] button Pauses playback.

O [ R ] button

Starts recording of a title.

P [SD SLOT]

Used for inserting SD cards.

Q [i.LINK(HDV/DV IN)] terminal

Connect a video camera using i.LINK (HDV/DV. IN).

R [USB] terminal

Connect a video camera using USB.

A B C D

A B C D E F

JIHG

Getting Started

Name and Function of Parts (Continued)

Display window

A HDD/DISC remaining level display B Dubbing display C Disc status display D HDMI output display

Memo:

The brightness of the display window can be adjusted.

For more details, refer to “PANEL DISPLAY BRIGHTNESS” (A page 75) .

Rear panel

A AC inlet

For connecting the power supply.

B Cooling fan C [DIGITAL AUDIO OUT (OPTICAL)] terminal

For connecting to the amplifier using an optical audio cable.

D [AUDIO OUT/IN] terminals

For connecting using an audio cable.

E [VIDEO OUT/IN] terminals

For connecting using a video cable.

English messages appear for a number of operations. (Examples)

HELLO : When the power plug is inserted

READING : When reading the disc

ONSCREEN : Upon moving to the playback navigation

screen

F [SERIAL COM.(RS-232C)] terminal

(only for SR-HD1500)

For connecting to a computer using a serial cable.

G [HDMI] terminal

For connecting using an HDMI cable.

H [S-VIDEO OUT/IN] terminals

For connecting using an S-video cable.

I [COMPONENT VIDEO OUT] terminals

For connecting using a component video cable.

J [REMOTE IN] terminal

For connecting a wired remote control.

Getting Started

Remote control

A [DELETE]

Deletes a title or characters.

B [ M ]

Opens/closes the disc tray.

C [HDD]

For operating the HDD.

D [1]-[9]

For entering characters.

E [Z]

For entering characters.

F [RED]

Enabled when the color button (red) is displayed.

G [GREEN]

Enabled when the color button (green) is displayed.

H [DUBBING]

Displays the dubbing menu screen.

I [ J / K / H / I ]

The cursor can be moved to select an item.

J [OPTION]

Displays the option screen.

K [ S ]

Move to the chapter just before the current chapter.

L [ O ]

Fast reverses the video and starts slow playback.

M [ R ]

Press the [ R ] and [ I ] buttons together to start recording.

N [REC MODE]

For checking the recording mode settings and amount of time remaining.

O [ON SCREEN]

Displays information on the screen.

P [PROGRESSIVE SCAN]

Switches the resolution of the image output.

Q [AUDIO]

Switches the playback audio.

R [EDIT]

Displays the editing menu screen.

S [MEDIA MANAGE]

Displays the media management menu screen.

T [ A ]

For turning On/Off the power.

U [INPUT SELECT]

Switches the external input signals (HDV/DV, L1).

V [BD/SD]

For operating BD/DVD or SD.

W [PAGE PRV][PAGE NEXT]

Returns to the previous page. Or advances to the next page.

X [ w ]

Move the playback position slightly backwards.

Y [ v ]

Advance the playback position slightly.

Z [#]

For entering characters.

a [YELLOW]

Enabled when the color button (yellow) is displayed.

b [BLUE]

Enabled when the color button (blue) is displayed.

c [NAVIGATION]

Displays the playback navigation screen.

d [OK]

Confirms a selection or entry.

e [RETURN]

Returns to the previous screen without applying the selection or entry.

f [ T ]

Move to the next chapter.

Getting Started

Name and Function of Parts (Continued)

g [ N ]

Fast forwards the video and starts slow playback.

h [ I ]

Plays the video.

i [ W ]

Pauses the video that is currently playing.

j [ o ]

Stops playback/recording.

k [MARK]

Adds a chapter mark during playback or recording. Select multiple titles from the playback navigation screen or other screens.

l [PB MODE]

Display the playback settings screen.

m [ANGLE]

Switches the camera angle for playback.

n [SET UP]

Displays the settings menu screen.

o [SUB TITLE]

Switches the playback subtitle.

p [INFORMATION CORRECT]

Displays the information editing screen.

Change batteries for the remote control

If the operable distance of the remote control unit becomes shorter, this means that the batteries are running out. When this occurs, replace the batteries with new ones.

Remote control codes

By setting a remote control code for the unit and remote control, you can prevent two recorders from operating simultaneously using the remote control for this unit. (the setting for the unit and remote control at time of purchase is “REMOTE CONTROL 3”.)

Memo:

Changing the remote control code for the remote control before the unit’s remote control code is changed will cause the unit to be inoperable. Change the unit’s remote control code first when changing remote control codes.

Changing the remote control code for the unit

Press the [SET UP] button on the remote control to display the “SETUP” menu

Change the “REMOTE CONTROL CODE” option in the “SETUP” menu

Memo:

For more details, refer to “REMOTE CONTROL CODE” (A page 75) .

Changing the remote control code for the remote control

Press and hold the [OPTION] button on the remote control

Press either of the [1], [2], [3] or [4] buttons

Press the number button that is equivalent to the remote control code you desire.

Press the [OK] button

Press the [OK] button to change the remote control code.

Release the [OPTION] button on the remote control

Memo:

If the remote control code is different from the unit, the remote control code for the unit will be displayed on the display window.

Examples: REMOTE CONTROL 3

Batteries

Insert the batteries correctly according to the + and - signs. Insert the - side of the battery first.

If an error occurs while using the remote control unit, remove the batteries, wait for about five minutes, and operate the remote control unit again after re-inserting the batteries.

Battery life : Approximately 6 months

(depending on the frequency of use)

Preparation

Connecting a Monitor

To display video images from this unit, connect it to a monitor.

This unit supports connections using “HDMI cable”, “component video cable”, “S-video cable”, or “video cable”.

Memo:

Switch to the appropriate monitor input according to the type of connection cable used. For details, refer to the instruction manual of the monitor.

Connecting using a HDMI cable

Connecting using a HDMI cable (sold separately) enables signals to be maintained in the digital format, and thus playback of clear video images.

Memo:

After connecting a component video cable, change the unit setting to “COMPONENT OUTPUT”.

For more details, refer to “COMPONENT OUTPUT” (A page

81) .

Connecting using an S-video cable

Connecting using an S-video cable (sold separately) delivers video images that are clearer than those by a video cable.

Connecting using a video cable

Connect the output terminal of this unit to the input terminal of a TV using the supplied video/audio cable. (Use the supplied BNC adapter)

Memo:

Videos cannot be displayed on a monitor that does not support the copyright protection system (HDCP).

Use a High Speed HDMI Cable.

After connecting using a HDMI cable, change the unit setting to “HDMI CONNECTION”.

For more details, refer to “ VIDEO PRIORITY MODE ” (A page 80) .

Connecting using a component video cable

Connecting using a component video cable (sold separately) delivers playback images that are clearer than those by an Svideo cable.

Note:

Connect the S-video/video output of this unit directly to the TV (or monitor). Connecting this unit to the TV or monitor via a video deck triggers the copy protection function, and may cause distortion in the video images during playback.

OPEN/ CLOSE

STANDBY/ON

HDV/DV IN

STOP REW PLAY PAUSE RECFF

SDRECHDD RECBV

ONE TOUCH DUBBING

REC MODE

RESET

INPUT SELECT

HDD

MIDIA SELECT

BD/SD

HDV/DV IN

SDRECHDD RECBV

ONE TOUCH

DUBBING

REC

MODE

INPUT

SELECT

HDD

MIDIA SELECT

BD/SD

OPEN/ CLOSE

STANDBY/ON

HDV/DV IN

STOP REW PLAY PAUSE RECFF

SDRECHDD RECBV

ONE TOUCH DUBBING

REC MODE

RESET

INPUT SELECT

HDD

MIDIA SELECT

BD/SD

HDV/DV IN

SDRECHDD RECBV

ONE TOUCH

DUBBING

REC

MODE

INPUT

SELECT

HDD

MIDIA SELECT

BD/SD

Preparation

Connecting a Video Deck or Other Equipment

Connecting a video camera

Connecting via the i.LINK terminal

Connecting via the USB terminal

Connecting an Amplifier

Connecting an audio amplifier

Connecting using an optical digital cable

Memo:

Remove the protection cap of the cable before connecting. Store the protection cap properly to prevent it from being misplaced.

Connecting using an audio cable

Memo:

Some video camera models may require an AC adapter instead of batteries to run. For details, refer to the video camera’s instruction manual.

Connecting a video deck or other equipment (recording using this unit)

Memo:

When connecting using an S-video cable, change the setting of “VIDEO INPUT SETTING” to “S-VIDEO”.

For more details, refer to “VIDEO INPUT SETTING” (A page 81) .

To record video images played back on this unit to an external device (video deck, etc.), connect the output terminal of this unit to the input terminal of the external device.

Preparation

Connecting External Devices

Connecting a wired remote control

Using a wired connection enables stable control of this unit from an external device. Operation is possible using any code (1 to 4) regardless of the remote control code settings of this unit.

Memo:

There is currently no compatible remote control unit available.

To create a wired remote controller, refer to “RS-232C Interface” (A page 83) .

Connecting the Power Supply

Connect the supplied power cable to this unit as follows.

Connect the supplied power cable to the AC IN terminal of this unit

Connect the other end of the power cable to a power point

Press the [A] button on the remote control or this unit to switch on the unit.

The power of this unit turns on, and a “HELLO” message appears on the display window.

Note:

Do not use power cables other than that supplied with this unit. Doing so may cause this unit to malfunction.

Connecting using a RS-232C cable (only for SR-HD1500)

External operation is enabled by connecting a RS-232C cable to a PC or similar device. For details on external operation, refer to “RS-232C Interface” (A page 83) .

4'6740

':+6

5'.'%6

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

5'672

5QHVYCTG8GTUKQP

ZZZZZZZZZZZZZZZ

4'6740

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

':+6

5'.'%6

5'672

4'6740

':+6

5'.'%6

5'672

%.1%-5'6&+52.#;

%.1%-5'6

'&+52.#;

6+/'&+52.#;%*1+%'*

/106*&#;;'#4

5'672

4'6740

%.1%-5'6&+52.#;

':+6

5'.'%6

5'672

%.1%-5'6

5'672





#/

%.1%-5'6

;'#4

/106*&#;,#0

6+/'

'06'4

4'6740

':+6

5'.'%6

%.1%-5'6&+52.#;

5'672

%.1%-5'6

5'672

#/





%.1%-5'6

;'#4

/106*&#;,#0

6+/'

'06'4

Preparation

Setting and Displaying Date/Time

Set the date/time of the built-in clock as follows. The recording date/time is stored on the disc.

Setting the date/time

Set the date/time of the built-in clock as follows.

Press the [SET UP] button on the remote control unit

The Settings menu screen appears.

Select “CLOCK SET”, and press the [OK] button

The Clock Set menu screen appears.

Set the time and date

Repeat the steps below to specify the time and date.

① Press the [ J ] or [ K ] button, select the Clock Set

item, and press the [OK] button.

Select “SETUP”, and press the [OK] button

Select “CLOCK SET/DISPLAY”, and press the [OK] button

“CLOCK SET/DISPLAY” menu screen appears.

② Press the [ J ] or [ K ] button, change the setting

value, and press the [OK] button.

4'6740

%.1%-5'6&+52.#;

':+6

5'.'%6

5'672

%.1%-5'6

5'672





#/

%.1%-5'6

;'#4

/106*&#;,#0

6+/'

'06'4

4'6740

':+6

5'.'%6

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

5'672

5QHVYCTG8GTUKQP

ZZZZZZZZZZZZZZZ

4'6740

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

':+6

5'.'%6

5'672

4'6740

%.1%-5'6&+52.#;

5'672

':+6

5'.'%6

%.1%-5'6

'&+52.#;

6+/'&+52.#;%*1+%'*

/106*&#;;'#4

5'672

4'6740

%.1%-5'6&+52.#;

%.1%-5'6

'&+52.#;

6+/'&+52.#;%*1+%'*

5'672

':+6

5'.'%6

/106*&#;;'#4

5'672

;'#4/106*&#;

/106*&#;;'#4

&#;/106*;'#4

Preparation

After setting is complete, select “ENTER”, and press the [OK] button

Doing so exits date/time setting, and returns to the initial screen.

Memo:

The value for seconds cannot be set. After setting the minute, press the [SET UP] button according to the time signal.

To cancel date/time setting, press the [RETURN] button. Doing so cancels date/time setting and returns to the initial screen.

The year can be set from 2009 to 2037. If "2037.12.31 PM11:59" is set, the time will change to "2009.1.1 AM00:00" after one minute.

Select “CLOCK SET/DISPLAY”, and press the [OK] button

The Clock Set/Display menu screen appears.

Select “DATE DISPLAY”, and press the [OK] button

The Date Display menu screen appears.

Changing the date display style

You can specify the display style of the date as follows.

Press the [SET UP] button on the remote control unit

Select “SETUP”, and press the [OK] button

The Settings menu screen appears.

Select the date display style.

Select a date display style from the following items.

YEAR.MONTH.DAY : Displays the date in the year/month/

day order.

MONTH.DAY.YEAR : Displays the date in the month/day/

year order.

DAY.MONTH.YEAR : Displays the date in the day/month/

year order.

After selecting, press the [OK] button

The date display style will be saved.

4'6740

':+6

5'.'%6

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

5'672

5QHVYCTG8GTUKQP

ZZZZZZZZZZZZZZZ

4'6740

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

':+6

5'.'%6

5'672

4'6740

%.1%-5'6&+52.#;

%.1%-5'6

'&+52.#;

6+/'&+52.#;%*1+%'*

5'672

':+6

5'.'%6

/106*&#;;'#4

5'672

4'6740

6+/'&+52.#;%*1+%'

5'672

%.1%-5'6&+52.#;

%.1%-5'6

'&+52.#;

*

':+6

5'.'%6

/106*&#;;'#4

5'672

*

*

Preparation

Setting and Displaying Date/Time (Continued)

Memo:

The date display style will be applied in the following information displays.

Recording date of the title that is shown in the playback navigation screen (The recording date will be shown in place of the title if the title has not been input).

Shooting date and time that is shown when AVCHD is played back

Date that is displayed in the title information display screen

Changing the time display style

You can specify the display style of the time as follows.

Press the [SET UP] button on the remote control unit

Select “SETUP”, and press the [OK] button

The Settings menu screen appears.

Select “TIME DISPLAY CHOICE”, and press the [OK] button

The Time Display menu screen appears

Select the time display style

Select “CLOCK SET/DISPLAY”, and press the [OK] button

The Clock Set/Display menu screen appears.

Select from “12H” or “24H”.

12H : Displays the time in AM/PM format.

24H : Displays the time in 24-hour format.

After selecting, press the [OK] button

The time display style will be saved.

Memo:

The time display style applies to the following.

Current time

Date/time registered on the disc

Recording time of the title that is shown in the playback navigation screen (The recording time will be shown in place of the title if the title has not been input.)

Shooting date and time that is displayed when AVCHD is played back

Time of recording that is displayed in the title information display screen

Dubbing/Importing

BDMV

BDAV

AVC HD

DVD -Video *

DVD -VR

EverioBackup *

AVC

AF/AN/AL/AE

XP/SP/LP/EP

EverioBackup

(JPEG)

JPEG

BDAV

(BD-RE, JPEG)

Encode dubbing

Deterioration-free dubbing

DVD

HDD

BD/DVD

MOV*

HDV

SD-VIDEO(HD)*

SD-VIDEO(SD)*

AVC HD

VIDEO/

S-VIDEO

(MOV*)

AVC

XP/SP/LP/EP

AF/AN/AL/AE

terminal

HDV/DV

USB/SDHC/SD

JPEG

HDD

Video Camera

Encode dubbing

Deterioration-free dubbing

Bi-directional dubbing between the HDD and a BD/DVD is possible using this unit alone. Also, data can be imported to the HDD from a video camera by connecting it via i.LINK or USB.

Dubbing from the HDD to a BD/DVD

High-speed dubbing

Select this option if you want to significantly shorten the time required for dubbing. Make use of a BD/DVD disc that supports high-speed recording.

Dubbing in a specific recording mode

Select this option when you want to specify the recording mode for dubbing. Dubbing can be performed in the recording mode of your preference, such as whether to “maintain a high picture quality” or “save as many titles as possible”. For more details, refer to “Recording Modes” (A page 28) .

Memo:

The image quality will not improve even when a recording mode with image quality higher than that of the original recording mode is chosen.

Dubbing using a specific recording mode will cause the disc to be re-encoded.

Dubbing/Importing

Importing data from a SDHC/SD to the HDD

Videos captured using a video camera can be imported to the HDD by inserting the SDHC/SD card that the videos are saved on.

Importing data from a video camera to the HDD

Videos captured using a video camera can be imported to the HDD. This unit supports video camera connections via i.LINK and USB.

Memo:

For MOV format videos, only videos in MOV format (SP mode) taken using JVC ProHD camcorder GY-HM700/100 are compatible. There is no guarantee for importing videos taken on devices by other company. In addition, MOV videos cannot be imported using the SRHD1250.

Other options for importing data into the HDD

Importing data from a BD/DVD to the HDD

You can import titles from a BD/DVD.

DVD-video* : Discs that are not finalized cannot be

EverioBackup* : Data disc containing high-definition videos

imported.

that are recorded in the MPEG2 format using a DVD writer for Everio.

MOV* : MOV files that are taken in SP mode using

the JVC ProHD Camcorder GYHM700/100

SD-VIDEO(HD)* : SD-VIDEO(JVC Everio MPEG2 TS)

SD-VIDEO(SD)* : SD-VIDEO(JVC Everio MPEG2 PS)

Importing data from a video deck

You can import data to the HDD from an external video deck by connecting it to a composite video or S input terminal. For more details, refer to “Recording Using External Inputs” (A page 47) .

Memo:

Videos that are copy-controlled cannot be imported.

Motion JPEG is not supported

BDMV(HD Quality)

Dubbing Quality

Content Quality

BDAV(HD Quality) BDAV(SD Quality) DVD-VR

Format (BD) Format (DVD)

DVD-VIDEO

DR (MOV*)

High-speed dubbing High-speed dubbing /

Re-encoding

Re-encoding Re-encoding Re-encoding

DR (Other) -

High-speed dubbing / Re-encoding

Re-encoding Re-encoding Re-encoding

AF/AN/AL/AE

High-speed dubbing High-speed dubbing /

Re-encoding

Re-encoding Re-encoding Re-encoding

AVC

High-speed dubbing High-speed dubbing /

Re-encoding

Re-encoding Re-encoding Re-encoding

FR - - Re-encoding

High-speed dubbing / Re-encoding

Re-encoding

XP/SP/LP/EP* - - Re-encoding

High-speed dubbing / Re-encoding

Dubbing/Importing

Dubbing chart

Dubbing the video data from the HDD

Memo:

EP* : High-speed dubbing to DVD-VIDEO format discs in EP mode title

To perform high-speed dubbing of a EP mode title to a DVD-VIDEO format disc, set “ HIGH-SPEED DUBBING ” (A page 77) in the settings menu to “4:3” before recording or importing. Only re-encoding will be performed when dubbing a title that is recorded or imported with a setting other than “4:3”.

MOV* : MOV files that are taken in SP mode using the JVC ProHD Camcorder GY-HM700/100

Dubbing the picture data from the HDD

Importing file (HDD)

BDAV(BD-RE) SDHC/SD

Media

JPEG V V

Memo:

Video images may be distorted in the following situations during reencoding/dubbing when the monitor (TV) is connected to this unit using a HDMI cable, or when the screen resolution is set to 1080p.

Proceeding with dubbing from the menu screen

Returning to the normal screen after dubbing has finished

This is not a malfunction. Change the screen resolution to a setting other than 1080p if you feel that this is annoying.

/'&+#/#0#)'/'06

$&&8&

(14/#6

(+0#.+<'

4'0#/'&+5%

5&%#4&

$&8+&'1#'4#5'

*&&

(14/#6

%10(+4/

6*'&+5%9+..$'(14/#66'&

5'.'%6#(14/#6/1&'

84/1&'8+&'1/1&'

Dubbing/Importing

Formatting

Unused discs or SD cards may require formatting in some cases. When the need arises, format the disc or SD card accordingly.

Memo:

Formatting a disc or SD card erases all existing data from the media. Double-check carefully before formatting so as not to erase important titles.

When using a DVD-R disc in the Video mode, formatting is not required.

Format chart

Refer to the following chart for the disc types and format when formatting a disc.

Note:

If a disc is formatted using an equipment not manufactured by JVC, the disc may not be read correctly even though it corresponds to the chart below. In this case, reformat the disc using this unit, or make use of another blank disc.

Memo:

BD-R and DVD-R discs can only be formatted once.

When a disc is re-formatted into another format, remove the disc and load it again.

Formatting a disc

Set the DVD or BD to be formatted on the disc tray

Press the [MEDIA MANAGE] button on the remote control unit

The Media Management menu screen appears.

Select “FORMAT” from “BD/DVD”

DVD : A format selection screen appears.

BD : A confirmation screen to execute formatting

appears.

Select a format mode from the format selection screen

DVD format chart

Format VR

Format

DVD-RW Single-sided, single

V V

layer (4.7 GB)

DVD-R Single-sided, single

V V(*)

layer (4.7 GB)

Single-sided, dual layer

V V (*)

(8.5 GB)

V : Format supported.

* : Formatting not required.

BD format chart

Format

BD-RE Single-sided, single layer (25 GB) V

Single-sided, dual layer (50 GB) V

BD-R Single-sided, single layer (25 GB) V

Single-sided, dual layer (50 GB) V

V : Format supported.

Video

Format

DVD-RW : Select a “Format mode” from “VR MODE” or

“VIDEO MODE”.

Memo:

This screen does not appear when a BD or DVD-R disc is used.

%10(+4/

6*'&+5%9+..$'(14/#66'&+0:::

#..4'%14&'&6+6.'59+..$''4#5'&

+66#-'5#$176;;;/+076'5

&1;179#0661(14/#6!

;'501

%10(+4/

6*'&+5%*#5$''0(14/#66'&



126+105

$#%-

5612

(14/#6

;17%#0':+6(41/6*'126+105%4''0



%10(+4/

(14/#66+0)9+..$'56122'&

5612!

;'501

(14/#6

;17%#0':+6(41/6*'126+105%4''0

Dubbing/Importing

Formatting (Continued)

Select “YES”, and press the [OK] button in the format confirmation screen

Cancel formatting

Press the [OPTION] button while formatting

Formatting starts.

After formatting is complete, a “THE DISC HAS BEEN FORMATTED” message appears on the monitor, and the normal screen is displayed.

Memo:

To return to the initial screen without formatting the disc, select “DO NOT FORMAT” and press the [OK] button. Alternatively, you can press the [RETURN] button to return to the initial screen without formatting.

Note:

Do not turn off the power or unplug the power cable when the “FORMATTING DISC…” message is displayed.

Note that formatting a disc with copyright-protected titles erases all the titles from the disc.

Select “STOP” and press the [OK] button

A confirmation screen to stop formatting appears.

Select “YES” on the confirmation screen and press the [OK] button

Formatting is stopped.

Note:

Formatting can be stopped if it seems to take a long time (more than two minutes).

If for any reason formatting cannot be stopped, the confirmation screen for stopping formatting will not appear even if the [OPTION] button is pressed.

Formatting an SD Card

/'&+#/#0#)'/'06

$&&8&

(14/#6

(+0#.+<'

4'0#/'&+5%

5&%#4&

$&8+&'1#'4#5'

*&&

(14/#6

%10(+4/

6*'%#4&5%106'069+..$''4#5'&

&1;179#066156#46(14/#66'&!

;'501

Insert the SD card to be formatted into the [SD SLOT]

With the terminal side facing down, insert the SD card until a “click” sound is heard.

Dubbing/Importing

Select “YES”, and press the [OK] button

Note:

Formatting cannot be performed if the SD card is writeprotected. In this case, turn off the write-protect lock before inserting the SD card.

Press the [MEDIA MANAGE] button on the remote control unit

The Media Management menu screen appears.

Select “FORMAT” from “SD CARD”

A confirmation screen to execute formatting appears.

Formatting starts.

After formatting is complete, a “THE SD CARD HAS BEEN FORMATTED” message appears on the monitor, and the normal screen is displayed.

Memo:

To return to the initial screen without formatting the disc, select “NO” and press the [OK] button. Alternatively, you can press the [RETURN] button to return to the initial screen without formatting.

Note:

Do not turn off the power or unplug the power cable when the “FORMATTING SD CARD…” message is displayed. Do not remove the SD card as well. Doing so may damage the SD card.

Note that formatting a disc with copyright-protected titles erases all the titles from the disc.

Once the formatting of the SD card begins, it cannot be stopped.

Dubbing/Importing

Recording Modes

Maximum recording time for each recording mode

You can specify a recording mode according to the intended use. Setting the video to a high picture quality shortens the maximum recording time, while setting to a lower picture quality lengthens the recording time. Refer to the following table for the maximum recording time in the respective modes. All figures shown in the table are approximate values.

Recording

Mode

DR HD - - - - 40 hours (*2)

AF 4 hours 8 hours - - 80 hours

AN 6 hours 12 hours - - 126 hours

AL 9 hours 18 hours - - 189 hours

AE 12 hours 24 hours - - 252 hours

XP SD 5.25 hours 10.5 hours 1 hours 1.7 hours 110 hours

SP 10.5 hours 21 hours 2 hours 3.5 hours 222 hours

Quality BD (Single-

sided, Single

Layer)

BD (Single-

sided, Dual

Layer)

DVD (Single-

sided, Single

Layer)

DVD (Single-

sided, Dual

Layer)

HDD (500 GB)

(*1)

LP 21 hours 42 hours 4 hours 7.1 hours 442 hours

EP 42 hours 84 hours 8 hours 14.3 hours 887 hours

*1 : If the HDD capacity is 250 GB (SR-HD1250US model) the time will be approximately half of what is stated here.

*2 : An estimated figure when HDV is imported.

Memo:

DR mode Abbreviation for Direct Recording. Videos are recorded in the original picture quality.

AF/AN/XP/SP mode Recommended for recording images with fast motion, such as sports videos.

The AF/AN mode record images at the high-quality HD level.

The XP/SP modes record images at the high-quality SD level.

AL/AE/LP mode Recommended for recording images with slow motion and little contrast, such as dramas.

AL/AE mode records images at the low-quality HD level.

LP mode records images at the low-quality SD level.

EP mode Recommended for recording images with sharp outlines, such as animation videos, and when the recordable time (remaining

time) is limited.

HD picture quality

Using BD enables dubbing to be done with HD picture quality. To dub HD picture quality titles that are imported in the HDD, use BD.

Note:

Dubbing to a DVD cannot be done in HD picture quality.

DR mode

HDV, MOV* and SD-VIDEO(JVC Everio MPEG2 TS) titles are imported using DR mode.

MOV* : MOV files that are taken in SP mode using the JVC

ProHD Camcorder GY-HM700/100

FR mode

FR mode is displayed as the recording mode in the following cases.

FR mode during import into HDD During import of SD-VIDEO (JVC Everio MPEG2 PS) titles via high-speed dubbing. During import of data via highspeed dubbing from DVD-VR discs recorded using other units.

FR mode during dubbing from HDD When selecting the most appropriate mode automatically between XP and EP according to the remaining memory on the disc.

%10(+4/

&7$$+0)+5%1/2.'6'&

Dubbing/Importing

Importing Data to the HDD Using the ONE TOUCH DUBBING Button

Titles can be imported to the HDD from an SD card or device connected to the USB or i.LINK terminal simply by pressing the [ONE TOUCH DUBBING] button.

File formats that can be imported

① USB connection device, SD card

AVCHD, SD-VIDEO(JVC Everio MPEG2 TS, PS), MOV*, and JPEG

MOV* : MOV files that are taken in SP mode using the

JVC ProHD Camcorder GY-HM700/100

② i.LINK-connected device

DV and HDV content

Memo:

Data is searched according to the order of priority listed below when multiple devices are connected to this unit. USB h SD card h i.LINK Data is retrieved only from the first device and imported to the HDD. Connect only the device that contains data you want to import to the HDD. The i.LINK connected device can only be used to import from tape media.

All video files (scenes) imported using “ONE TOUCH DUBBING” are combined into one title. This unit does not support combining of titles during the editing operation after import is complete. To combine and import data, select “ONE TOUCH DUBBING”.

Titles of two or more scenes cannot be combined if the recording criteria, such as video size, are different.

Import of MOV files recorded using JVC GY-HM700/100 SP mode 1080i (25 Mbps) requires a duration that is about

1.3 times longer than the usual time.

When importing DV contents with shooting date/time information, the date/time information at the beginning of the contents will be taken as the shooting date/time information. For HDV contents or DV contents without shooting date/time information, the importing date/time will be taken as the shooting date/time information.

Note:

Do not unplug the cable while importing to the HDD is in progress. Doing so may result in loss or damage of the titles.

Only titles that are not copyright-protected can be imported.

Recognizing the device and importing the files may take a long time depending on the amount of files in the device or media.

Procedure for one-touch importing

Connect the device to be used. Alternatively, insert an SD card.

Once preparations for importing have been done, the message below will be shown on this unit’s display window.

i.LINK device : “HDV/DV RDY”

USB device : “USB RDY”

SD card : “SD RDY”

Press the [ONE TOUCH DUBBING] button on the unit

One-touch importing starts.

Memo:

Refer to the following for the flow of operations by the system of this unit.

System checks the device connection

The system of this unit detects the connected device. Search for devices is performed in the sequence of USB, SD card, followed by i.LINK.

System detects the titles to import

All titles that can be imported will be detected and imported.

Importing of titles by this unit starts

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor

Memo:

The following buttons are enabled when importing is in progress.

[ A ] : Continues importing while switching this

unit to the Standby mode.

[ONE TOUCH DUBBING]

[OPTION] : Displays a pop-up menu for canceling

[ON SCREEN] : Pressing this button each time displays or

Note:

Importing stops and a message appears on the monitor if an error occurs during the importing process.

: Press this button for three seconds or

longer to cancel importing.

importing.

hides the importing information.

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

&+5%

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

0':6

&+5%

&7$$+0)

56'2

5'66*'4'%14&+0)/1&'

*&&

%#0%'.$#%-

':+6

5'.'%6

126+10

4'6740

56#46

4'%14&+0)/1&'

&7$$+0)

Dubbing/Importing

Importing Data from a BD/ DVD to the HDD

Data can be imported from a BD/DVD to the HDD as follows.

File formats that can be imported BD-MV, BD-AV, AVCHD, DVD-VR, DVD-VIDEO,

EverioBackup, and JPEG

Memo:

Titles that are imported using “FULL IMPORT” combined into one title. This unit does not support combining of titles during the editing operation after import is complete. To combine and import data, select “FULL IMPORT”.

For data that is selected for import via “SEL. TITLE(VIDEO)”, titles with the same date are combined.

Titles of two or more scenes cannot be combined if the recording criteria, such as video size, are different.

Note:

Only titles that are not copyright-protected can be imported.

Recognizing the device and importing the files may take a long time depending on the amount of files in the device.

Preparations

Set a BD or DVD on the disc tray

Press the [DUBBING] button on the remote control unit

The importing screen appears.

Full import

Select “FULL IMPORT” in the import selection screen, and press the [OK] button

A check mark is added to the “FULL IMPORT” item.

Select “NEXT”, and press the [OK] button

“START” will appear instead of “NEXT” in the menu if the disc is of a format other than “BD-AV”. In this case, go to Step 5.

Select “RECORDING MODE”, and press the [OK] button

A pop-up menu appears.

Select the “RECORDING MODE” option

Select “DISChHDD” in the importing screen, and press the [OK] button

A check mark is added to the “DISChHDD” item.

Select “NEXT”, and press the [OK] button

The import selection screen appears.

Memo:

A recording mode selection appears instead of the import selection screen when DVD-VIDEO is detected. For more details, refer to “Importing DVD-VIDEO” (A page

32) .

For more details, refer to “Recording Modes” (A page 28) .

%10(+4/

&7$$+0)+5%1/2.'6'&

&+5%

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

0':6

&+5%

126+10

4'6740

&7$$+0)

56'2

5'66*'4'%14&+0)/1&'

*&&

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

0':6

4'%14&+0)/1&'

Select “START”, and press the [OK] button

Importing of the titles starts.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Specify a title

Select “SEL. TITLE(VIDEO)” in the import selection screen, and press the [OK] button

A check mark is added to the “SEL. TITLE(VIDEO)” item.

Select “NEXT”, and press the [OK] button

If a “BD-AV” disc is set, a recording mode selection screen will appear.

If the disc is of a format other than “BD-AV”, a screen for creating an import title list will appear. Go to step 5.

Dubbing/Importing

Select “RECORDING MODE”, and press the [OK] button

A pop-up menu appears.

Select the “RECORDING MODE” option.

For more details, refer to “Recording Modes” (A page 28) .

Select “NEXT”, and press the [OK] button

A screen for creating the import title list appears.

Create an import title list

Follow the steps below to create an import title list.

① Select “ADD TITLE LIST FOR DUBBING”, and press

the [OK] button

The Title List screen is displayed.

② Select the titles to import, and press the [OK] button

Titles selected are added to the list.

Memo:

Press the [MARK] button. A check mark will appear beside the title. All titles with a check mark can be added to the list at the same time.

Select a title from the dubbing title list, and press the [OK] button to perform the following changes.

Delete the selected title from the list

Thumbnails may not be displayed during title selection depending on the discs used.

#$%

5RQTVU

%QQMKPI

-+&5914.&

0GYU###

4GRQTV

(.19'4.'5510

&+5%

126+10

4'6740

&7$$+0)

56'2

2.'#5'%4'#6'#6+6.'.+56(14+/2146

*&&

#&&6+6.'.+56(14&7$$+0)

%#0%'.

':+6

5'.'%6

&7$$+0)

$#%-56#46

%10(+4/

&7$$+0)+5%1/2.'6'&

&+5%

&7$$+0)

56'2

5'66*'4'%14&+0)/1&'

*&&

%#0%'.$#%-

':+6

5'.'%6

126+10

4'6740

56#46

4'%14&+0)/1&'

&7$$+0)

%10(+4/

&7$$+0)+5%1/2.'6'&

Dubbing/Importing

Importing Data from a BD/ DVD to the HDD (Continued)

Select “START”, and press the [OK] button

Importing of titles starts according to the sequence in the created title list.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Select “RECORDING MODE”, press the [OK] button, and select “RECORDING MODE” from the recording mode selection screen

Select the “RECORDING MODE” option.

For more details, refer to “Recording Modes” (A page 28) .

Select “START”, and press the [OK] button

Importing of the titles starts.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Note:

“START” cannot be selected for the following cases.

A title that cannot be dubbed has been selected

HDD memory is insufficient

The amount of titles in the HDD has reached the maximum amount

A dubbing title list has not been created

Importing DVD-VIDEO

When DVD-VIDEO is detected, a recording mode selection screen appears. Follow the steps below to import DVD-VIDEO to the HDD.

Memo:

If the first play setting of the DVD-video has been set to top menu or other settings, the title will not playback. If playback does not start, press the play button or playback the DVD-Video.

Canceling importing

To cancel importing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel importing of a title.

Alternatively, you can press the [RETURN] button to cancel importing and return to the initial screen.

To cancel importing while it is in progress

Press the [OPTION] button to display the pop-up menu. Select “CANCEL” from the pop-up menu and press the [OK] button. Data will be written onto the disc up to the point where import is cancelled.

Importing will also be stopped when the [o] button is pressed to stop playback.

Importing Data from a USB-

OPEN/ CLOSE

STANDBY/ON

HDV/DV IN

STOP REW PLAY PAUSE RECFF

SDRECHDD RECBV

ONE TOUCH DUBBING

REC

MODE

RESET

INPUT SELECT

HDD

MIDIA SELECT

BD/SD

HDV/DV IN

SDRECHDD RECBV

ONE TOUCH

DUBBING

REC

MODE

INPUT

SELECT

HDD

MIDIA SELECT

BD/SD

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

75$

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

56#46

compatible Device to the HDD

Data on devices connected to the USB terminal can be imported to the HDD as follows.

File formats that can be imported AVCHD, SD-VIDEO(JVC Everio MPEG2 TS, PS), MOV*,

and JPEG

MOV* : MOV files that are taken in SP mode using the

JVC ProHD Camcorder GY-HM700/100

Memo:

For data that is selected for import via “SEL. TITLE(VIDEO)”, titles with the same date are combined.

Titles of two or more scenes cannot be combined if the recording criteria, such as video size, are different.

Import of MOV files recorded using JVC GY-HM700/100 SP mode 1080i (25 Mbps) requires a duration that is about

1.3 times longer than the usual time.

Note:

Turn off the power for this unit and the connecting device if an USB compatible device is to be connected to this unit.

Do not unplug the USB cable while importing a title. Doing so may result in loss or damage of the titles.

Only titles that are not copyright-protected can be imported.

Recognizing the device and importing the files may take a long time depending on the amount of files in the USB device.

If a USB connection is used, this unit will only recognize one device out of all the recording devices. Depending on the video camera, the memory card slot will be recognized but the internal device will not be recognized. Use the following methods to solve this.

If the internal device is not recognized: Copy the data from the camera’s internal memory or HDD onto the SD card.

If using a JVC camcorder that has two memory card slots: Put the memory card that has the required data in slot A.

If the target device is not recognized using the USB connection, use the camcorder's burner or a similar device to dub the disc before proceeding with dubbing on this unit. For more details, refer to “Importing Data from a BD/DVD to the HDD” (A page 30) .

When importing videos from a USB-connected camcorder, data reading from the internal memory of the camcorder may fail. If both the camcorder’s internal memory and SD card are available, the SD card may be detected first. To prevent this from occurring, remove the SD card before reading data from the internal memory.

Dubbing/Importing

Preparations

Connect the USB device (Everio, etc.) to this unit using a USB cable

Memo:

After connecting the USB cable, turn on the camera and switch the mode of the camera. (Choose "Connect to a computer" or a similar option. For details refer to the camera’s instruction manual.)

“USB RDY” appears on the display window of the unit when an USB device is recognized.

Press the [DUBBING] button on the remote control unit

The importing screen appears.

Select “USBhHDD” in the importing screen, and press the [OK] button

A check mark is added to the “USBhHDD” item.

Select “NEXT”, and press the [OK] button

The import selection screen appears.

Full import

Select “FULL IMPORT” in the import selection screen, and press the [OK] button

A check mark is added to the “FULL IMPORT” item.

Select “START”, and press the [OK] button

%10(+4/

&7$$+0)+5%1/2.'6'&

75$

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

0':6

75$

126+10

4'6740

2/

2/

2/

#/

#/

#/

#/

&7$$+0)

56'2

2.'#5'%4'#6'#6+6.'.+56(14+/2146

*&&

#&&6+6.'.+56(14&7$$+0)

%#0%'.

':+6

5'.'%6

&7$$+0)

$#%-56#46

%10(+4/

&7$$+0)+5%1/2.'6'&

Dubbing/Importing

Importing Data from a USBcompatible Device to the HDD (Continued)

Importing of the titles starts.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Select “START”, and press the [OK] button

Importing of titles starts according to the sequence in the created title list.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Specify a title

Select “SEL. TITLE(VIDEO)” in the import selection screen, and press the [OK] button

A check mark is added to the “SEL. TITLE(VIDEO)” item.

Select “NEXT”, and press the [OK] button

A screen for creating the import title list appears.

Create an import title list

Follow the steps below to create an import title list.

① Select “ADD TITLE LIST FOR DUBBING”, and press

the [OK] button

The Title List screen is displayed.

② Select the titles to import, and press the [OK] button

Titles selected are added to the list.

Memo:

Press the [MARK] button. A check mark will appear beside the title. All titles with a check mark can be added to the list at the same time.

You can perform the following editing operations by selecting a title from the dubbing title list and pressing the [OK] button.

Delete the selected title from the list

Thumbnails will not be displayed when a title is selected.

Note:

“START” cannot be selected for the following cases.

A title that cannot be dubbed has been selected

HDD memory is insufficient

The amount of titles in the HDD has reached the maximum amount

A dubbing title list has not been created

Canceling importing

To cancel importing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel importing of a title.

Alternatively, you can press the [RETURN] button to cancel importing and return to the initial screen.

To cancel importing while it is in progress

Press the [OPTION] button. Select “CANCEL” from the Cancel Importing menu, and press the [OK] button. Doing so imports data to the HDD up to the position where you have chosen to stop.

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

56#46

%10(+4/

&7$$+0)+5%1/2.'6'&

Importing Data from an SD Card to the HDD

Data can be imported from a SD (SDHC) card to the HDD as follows.

File formats that can be imported AVCHD, SD-VIDEO(JVC Everio MPEG2 TS, PS), MOV*,

and JPEG MOV* : MOV files that are taken in SP mode using the

Memo:

For data that is selected for import via “SEL. TITLE(VIDEO)”, titles with the same date are combined.

Titles of two or more scenes cannot be combined if the recording criteria, such as video size, are different.

Import of MOV files recorded using JVC GY-HM700/100 SP mode 1080i (25 Mbps) requires a duration that is about

1.3 times longer than the usual time.

Note:

Do not remove the SD card when importing of the titles is in progress or when the importing screen is displayed. Doing so may result in loss or damage of the titles.

Only titles that are not copyright-protected can be imported.

JVC ProHD Camcorder GY-HM700/100

Full import

Dubbing/Importing

Select “SDhHDD” in the importing screen, and press the [OK] button

A check mark is added to the “SDhHDD” item.

Select “NEXT”, and press the [OK] button

The import selection screen appears.

Select “FULL IMPORT” in the import selection screen, and press the [OK] button

A check mark is added to the “FULL IMPORT” item.

Select “START”, and press the [OK] button

Importing of the titles starts. After titles are successfully imported, a “DUBBING IS

COMPLETED” message appears on the monitor.

Preparations

Insert the SD (SDHC) card into the [SD SLOT]

Memo:

“SD RDY” appears on the display window of the unit when an SD card is recognized.

Press the [DUBBING] button on the remote control unit

The importing screen appears.

Memo:

Choose “BACK” from the menu and press the [OK] button to return to the previous screen.

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

*&&

(7..+/21465'.6+6.'8+&'1

5'.6+6.'2+%674'

%#0%'.$#%-

':+6

5'.'%6

&7$$+0)

0':6

126+10

4'6740

2/

2/

2/

#/

#/

#/

#/

&7$$+0)

56'2

2.'#5'%4'#6'#6+6.'.+56(14+/2146

*&&

#&&6+6.'.+56(14&7$$+0)

%#0%'.

':+6

5'.'%6

&7$$+0)

$#%-56#46

%10(+4/

&7$$+0)+5%1/2.'6'&

Dubbing/Importing

Importing Data from an SD Card to the HDD (Continued)

Specify a title

Select “SEL. TITLE(VIDEO)” in the import selection screen, and press the [OK] button

A check mark is added to the “SEL. TITLE(VIDEO)” item.

Select “NEXT”, and press the [OK] button

Importing of titles starts according to the sequence in the created title list.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

A screen for creating the import title list appears.

Create an import title list

Follow the steps below to create an import title list.

① Select “ADD TITLE LIST FOR DUBBING”, and press

the [OK] button

The Title List screen is displayed.

② Select the titles to import, and press the [OK] button

Titles selected are added to the list.

Memo:

Press the [MARK] button. A check mark will appear beside the title. All titles with a check mark can be added to the list at the same time.

You can perform the following editing operations by selecting a title from the dubbing title list and pressing the [OK] button.

Delete the selected title from the list

When there are files of different formats (AVCHD, SDVIDEO, MOV*) in the SD card, press the [RED] button to select the format you want to display. MOV*: MOV files that are taken in SP mode using the JVC ProHD Camcorder GY-HM700/100

Select “START”, and press the [OK] button

Memo:

Choose “BACK” from the menu and press the [OK] button to return to the previous screen.

Note:

“START” cannot be selected for the following cases.

A title that cannot be dubbed has been selected

HDD memory is insufficient

The amount of titles in the HDD has reached the maximum amount

A dubbing title list has not been created

Thumbnails will not be displayed when a title is selected.

Canceling importing

To cancel importing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel importing of a title.

Alternatively, you can press the [RETURN] button to cancel importing and return to the initial screen.

To cancel importing while it is in progress

Press the [OPTION] button. Select “CANCEL” from the Cancel Importing menu, and press the [OK] button. Doing so imports data to the HDD up to the position where you have chosen to stop.

OPEN/ CLOSE

STANDBY/ON

HDV/DV IN

STOP REW PLAY PAUSE RECFF

SDRECHDD RECBV

ONE TOUCH DUBBING

REC MODE

RESET

INPUT SELECT

HDD

MIDIA SELECT

BD/SD

HDV/DV IN

SDRECHDD RECBV

ONE TOUCH

DUBBING

REC

MODE

INPUT

SELECT

HDD

MIDIA SELECT

BD/SD

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

*&8&8

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

+/2146(41/$')+00+0)

+/2146(41/%744'06215+6+10

%#0%'.$#%-

*&&

&7$$+0)

0':6

Dubbing/Importing

Importing Data from an i.LINK-compatible Device to the HDD

Data on devices connected to the i.LINK terminal can be imported to the HDD as follows.

Video formats that can be imported: DV and HDV content

Memo:

Only titles that are not copyright-protected can be imported.

Devices that have in-built copyright protection such as D-VHS and digital tuners cannot be connected. This unit only allows import from tape media.

Importing will not be performed if no tape has been inserted into the HDV/DV camera.

Importing will be cancelled when the mode is changed from HDV to DV or vice versa.

For camcorders that support both HDV and DV recording, use only one of the modes for recording and playback.

There is no support for editing using a connected PC.

Only one i.LINK device can be connected to this unit at a time.

Note:

Turn off the power for this unit and the connecting device when connecting using an i.LINK compatible device.

Do not unplug the i.LINK cable while importing to the HDD is in progress. Doing so may result in loss or damage of the titles.

For example, during full import of HDV content from JVC GYHD100 via i.LINK connection, the beginning of the image may not be captured if GY-HD100 is not set as follows. (1) Set the [IEEE1394] switch at the rear of the GY-HD100 unit to [HDV] or [DV] according to the recorded content. (2) Set [MENU]/[VIDEO FORMAT]/[PB TAPE] on the GYHD100 unit to [HDV] or [DV]. (As with (1), set according to the recorded content. Setting to [AUTO] is not allowed.) (3) Check to ensure that the [HDV] or [DV] lamp on the side of the GY-HD100 unit is lit. (Check to ensure that the lamp that is lit corresponds to the setting in (1) and (2).) When importing from a tape that contains data captured in the HDV recording and DV recording modes, change the video camera setting according to each recording mode, check to ensure that the corresponding lamp in (3) is lit, and choose to start import from the current position.

After the device (camera, etc.) has been connected using an i.Link cable, turn on the power of the device and switch it to playback mode. (refer to the device's (camera, etc.) instruction manual for more details.)

“HDV/DV RDY” appears on the display window of the unit when an iLINK device is recognized.

The importing screen appears.

A check mark is added to the “HDV/DVhHDD” item.

The import selection screen appears.

Imports data from the beginning

You can import videos from the beginning till the end as follows. If the current position is halfway through the tape, import after rewinding the tape to the beginning.

A check mark is added to the “IMPORT FROM BEGINNING” item.

Memo:

Press the [DUBBING] button on the remote control unit

Select “HDV/DVhHDD” in the importing screen, and press the [OK] button

Select “NEXT”, and press the [OK] button

Select “IMPORT FROM BEGINNING”, and press the [OK] button

Select “NEXT”, and press the [OK] button

Preparations

Connect the device (camera, etc.) to this unit using an i.LINK cable

A recording mode selection screen appears.

Select “RECORDING MODE”, press the [OK] button, and select from the pop-up menu

*&8&8

126+10

4'6740

&7$$+0)

56'2

5'66*'4'%14&+0)/1&'

*&&

&7$$+0)(14*&86#2'%106'065 &4/1&'&8%106'065 52'%+(+'&4'%/1&'

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

4'%14&+0)/1&'

%10(+4/

&7$$+0)+5%1/2.'6'&

*&8&8

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%66*'/'6*1&1(+/2146

+/2146(41/$')+00+0)

+/2146(41/%744'06215+6+10

%#0%'.$#%-

*&&

&7$$+0)

0':6

*&8&8

126+10

4'6740

&7$$+0)

56'2

5'66*'4'%14&+0)/1&'

*&&

&7$$+0)(14*&86#2'%106'065 &4/1&'&8%106'065 52'%+(+'&4'%/1&'

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

4'%14&+0)/1&'

%10(+4/

&7$$+0)+5%1/2.'6'&

Dubbing/Importing

Importing Data from an i.LINK-compatible Device to the HDD (Continued)

Select “XP”, “SP”, “LP”, or “EP” from the “RECORDING MODE” option.

Memo:

HDV contents will be imported in DR mode.

For more details, refer to “Recording Modes” (A page 28) .

Select “START”, and press the [OK] button

Importing of the titles starts.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Select “RECORDING MODE” and press the [OK] button to display the pop-up menu

Select “XP”, “SP”, “LP”, or “EP” from the “RECORDING MODE” option.

Memo:

HDV contents will be imported in DR mode.

For more details, refer to “Recording Modes” (A page 28) .

Select “START”, and press the [OK] button

Importing of the titles starts.

After titles are successfully imported, a “DUBBING IS COMPLETED” message appears on the monitor.

Imports data from current position

You can import videos from the current tape position till the end as follows.

Select “IMPORT FROM CURRENT POSITION”, and press the [OK] button

A check mark is added to the “IMPORT FROM CURRENT POSITION” item.

Select “NEXT”, and press the [OK] button

A recording mode selection screen appears.

Cancel dubbing

To cancel importing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel importing of a title.

Alternatively, you can press the [RETURN] button to cancel importing and return to the initial screen.

To cancel importing while it is in progress

Press the [OPTION] button. Select “CANCEL” from the Cancel Importing menu, and press the [OK] button. Doing so imports data to the HDD up to the position where you have chosen to stop.

Dubbing a Title from the

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

&+5%

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

*&&

4'%14&+0)(14/#6

4'%14&+0)/1&'

*+)*52''&&7$$+0)

%#0%'.$#%-0':6

':+6

5'.'%6

&7$$+0)

&8&8+&'1

&+5%

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

*&&

4'%14&+0)(14/#6

4'%14&+0)/1&'

*+)*52''&&7$$+0)

%#0%'.$#%-0':6

':+6

5'.'%6

&7$$+0)

&8&8+&'1

HDD to a BD/DVD

Titles stored in the internal HDD can be dubbed to a BD/DVD as follows.

Memo:

Disc types that can be used for dubbing with this unit are: BD-RE, BD-R, DVD-RW, and DVD-R.

For more details, refer to “Discs that enable both dubbing and playback” (A page 10) .

HD content for which the delete scene operation has been applied cannot be dubbed to BDMV. Perform seamless conversion before starting a dubbing operation.

For details, refer to “Mode conversion” (A page 73) .

Note:

The following high bit-rate files may not meet the Blu-ray Disc standards when they are dubbed to a BD.

When a BDAV/BDMV disc is created (high-speed dubbing) by importing content captured in the JVC GYHM700/100 SP mode.

When a BDAV disc is created (high-speed dubbing) by importing content captured in the JVC GZ-HD7/6 etc FHD mode.

When a BDAV/BDMV disc is created by importing content that is captured using another video camera at a peak bit-rate that exceeds 28.8 Mbps.

If the Blu-ray Disc standards are not met, playback on another player may fail. To ensure that the standards are satisfied, perform high-speed dubbing after converting the recording mode, or perform dubbing by specifying a recording mode.

Dubbing/Importing

On this screen, select “DISCiVIDEO”

A check mark is added to the “DISCiVIDEO” item.

Select “NEXT”, and press the [OK] button

Memo:

Dubbing can also be performed from the Playback Navigation screen.

① Select the titles to dub, and press the [OPTION]

button

② Select “DUB”, and press the [OK] button ③ Follow Steps 3 to 4 of "Preparation"

Dubbing titles

Select “RECORDING FORMAT”, and press the [OK] button

Dubbing from the HDD to a BD/DVD

Preparation

Set a BD or DVD on the disc tray

Memo:

A message appears on the monitor in the following cases where a disc cannot be written to. Take the necessary actions according to the message.

When an incompatible disc type is set

When there is insufficient space on the set disc

When a finalized disc is set

Press the [DUBBING] button on the remote control unit

The Dubbing menu screen appears.

Choose a format.

For more details, refer to “Format chart” (A page 25) .

Select “RECORDING MODE”, and press the [OK] button

Select “HIGH-SPEED DUBBING” or a recording mode of your preference.

&+5%

126+10

4'6740

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

*&&

4'%14&+0)(14/#6

4'%14&+0)/1&'

*+)*52''&&7$$+0)

%#0%'.$#%-0':6

':+6

5'.'%6

&7$$+0)

&8&8+&'1

#$%

5RQTVU

%QQMKPI

-+&5914.&

0GYU###

4GRQTV

(.19'4.'5510

&+5%

126+10

4'6740

&7$$+0)

56'2

%4'#6'6+6.'.+56(14&7$$+0)

*&&

#&&6+6.'.+56(14&7$$+0)

%#0%'.

$#%-

0':6

':+6

5'.'%6

&7$$+0)

#$%

5RQTVU

%QQMKPI

-+&5914.&

0GYU###

4GRQTV

(.19'4.'5510

&+5%

126+10

4'6740

&7$$+0)

56'2

%4'#6'6+6.'.+56(14&7$$+0)

*&&

#&&6+6.'.+56(14&7$$+0)

%#0%'.

$#%-

0':6

':+6

5'.'%6

&7$$+0)

&+5%

126+10

4'6740

*&&

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

%*#0)'&+5%/'07$#%-)4170&

5'.'%6(41/&'(#7.6$#%-)4170&

5'.'%6(41/56+..2+%674'5

(+0#.+<'

4'0#/'&+5%

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

(+4562.#;

4'2'#6

010'

1((

Dubbing/Importing

Dubbing a Title from the HDD to a BD/DVD (Continued)

Memo:

High-speed dubbing Select this option if you want to significantly shorten the

time required for dubbing. Make use of a disc that supports high-speed recording.

AF/AN/AL/AE Can be selected for BD-R and BD-RE. Dubbing is done

with HD picture quality.

XP/SP/LP/EP Dubbing is done with SD picture quality.

FR An appropriate mode will be chosen automatically between

XP to EP according to the remaining memory on the disc.

For more details, refer to “Dubbing the video data from the HDD” (A page 24) and “Recording Modes” (A page 28) .

Select “NEXT”, and press the [OK] button

Memo:

Press the [MARK] button. A check mark will appear beside the title. All titles with a check mark can be added to the list at the same time.

You can perform the following editing operations by selecting a title from the dubbing title list and pressing the [OK] button.

Delete the selected title from the list

Change the list arrangement

Change the name of the selected title

Select “RENAME TITLE”, and press the [OK] button to change the title of the dubbing source. Dubbing of the new title is performed.

Select “NEXT”, and press the [OK] button

A screen for creating a dubbing title list appears.

Create a dubbing title list

Follow the steps below to create a dubbing title list.

① Select “ADD TITLE LIST FOR DUBBING”, and press

the [OK] button

② Select the titles to dub, and press the [OK] button

Note:

“NEXT” cannot be selected for the following cases.

A title that cannot be dubbed has been selected

Disc memory is insufficient

A dubbing title list has not been created

Memo:

Steps 6 and 7 are not applicable for “BDAV” and “DVD-VR” disc formats. Go to step 8.

Select a background image for the disc menu

Select a background image for the disc menu from “Background” or “Still Picture”.

“SELECT FROM DEFAULT BACKGROUND” A default background set is used for the disc menu.

“SELECT FROM STILL PICTURES”(only for SRHD1500)

Use a still image on the HDD for the disc menu. The largest size allowed for a still image that is used as the background is 5120 x 3840.

&+5%

126+10

4'6740

*&&

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

%*#0)'&+5%/'07$#%-)4170&

5'.'%6(41/&'(#7.6$#%-)4170&

5'.'%6(41/56+..2+%674'5

(+0#.+<'

4'0#/'&+5%

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

(+4562.#;

4'2'#6

010'

1((

&+5%

126+10

4'6740

*&&

&7$$+0)

56'2

5'.'%66*'&7$$+0)&'6#+.5

%*#0)'&+5%/'07$#%-)4170&

5'.'%6(41/&'(#7.6$#%-)4170&

5'.'%6(41/56+..2+%674'5

(+0#.+<'

4'0#/'&+5%

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

(+4562.#;

4'2'#6

010'

1((

Dubbing/Importing

Memo:

The background image of the disc menu can be selected (only for DVD-Video and BD-MV).

The following sizes are recommended for still images. BD : 1920 x 1080 DVD : 720 x 480

When a still image is used, the two vertical or horizontal edges are trimmed based on the side that is smaller than the aspect ratio of the video to be dubbed.

Example of Side-cut Still Image

Set the operations for finalize

② Select “REPEAT”, and choose either “OFF” or “ON”

“OFF”

The disc will stop and the menu will be displayed after all

the titles are played back.

“ON”

Repeat playback from the first title will start automatically

after all the titles are played back.

③ Select “RENAME DISC”, and press the [OK] button

Change the disc name when finalizing is performed.

Select “START”, and press the [OK] button

Dubbing starts. A progress bar is displayed during the dubbing process.

After dubbing is complete, a “DUBBING IS COMPLETED” message appears on the monitor.

Memo:

Choose “BACK” from the menu and press the [OK] button to return to the previous screen.

Finalize will be performed after dubbing if “ON” has been set for “FINALIZE”. If a BD-MV disc is being dubbed, “OFF” cannot be set for “FINALIZE”. And once the BD-MV disc is dubbed the disc cannot be rewritten.

If a DVD-Video or BD-MV disc is being dubbed, the settings for “FIRST PLAY”, “REPEAT” and “RENAME DISC” can be changed.

① Select “FIRST PLAY”, and select either “NONE”,

“TOP MENU” or “TITLE 1”

“NONE”

A finalized disc will not be automatically played back when it is inserted into another device.

“TOP MENU”

The disc menu will be displayed automatically when a finalized disc is inserted into another device.

“TITLE 1”

The first title on a finalized disc will be played back automatically when it is inserted into another device.

Memo:

“NONE” cannot be selected for “FIRST PLAY” for BD-MV.

Cancel dubbing

To cancel dubbing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel dubbing.

Alternatively, you can press the [RETURN] button to cancel dubbing and return to the initial screen.

To discontinue dubbing while it is in progress

Press the [OPTION] button. Select “CANCEL” from the Cancel Dubbing menu, and press the [OK] button.

Memo:

When dubbing to a BD-R or DVD-R, the disc memory will be reduced as data will still be written onto the disc up to the point where dubbing is discontinued.

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

$&4'

126+10

4'6740

&7$$+0)

56'2

+05'46#0&5'.'%6#/'&+#

*&&*&&5&%#4&

%#0%'.0':6

':+6

5'.'%6

&7$$+0)

$#%-

2CIG

126+10

4'6740

2CIG

&7$$+0)

56'2

%4'#6'6+6.'.+56(14&7$$+0)

)4172

#..

':+6

5'.'%6

24'82)0':62)

&7$$+0)

Dubbing/Importing

Dubbing Still Images from the HDD

Still images stored in the internal HDD can be dubbed to a BD-RE or an SD card as follows.

Memo:

Only “JPEG” still image format is supported.

For more details, refer to “Dubbing the picture data from the HDD” (A page 24) .

Before dubbing

Dubbing to a disc Set the BD-RE for dubbing on the disc tray

Dubbing to an SD card Insert the SD card to be dubbed into the [SD SLOT]

Dubbing still images

Press the [DUBBING] button on the remote control unit

The Dubbing menu screen appears.

On this screen, select “DISC/SDiPICTURE”

Select “NEXT”, and press the [OK] button

Memo:

A message appears on the monitor when dubbing cannot be performed in the following cases. When this occurs, replace the disc or SD card with one that is usable.

When an incompatible disc or SD card is set

When there is insufficient space on the set disc or SD card

When an unformatted disc or SD card is set

For details, refer to “Formatting a disc” (A page 25) or “Formatting an SD Card” (A page 27) .

Select the still images to dub, and press the [MARK] button

Select the media to dub to from the media selection screen

A checkmark will be added to the selected media.

Pressing the [MARK] button adds a check mark to the selected image. All still images with a check mark are dubbed.

Memo:

To clear the check mark, select the corresponding still image, and press the [MARK] button.

Pressing the [OPTION] button displays a pop-up menu. The pop-up menu enables you to perform the following operations.

BACK : Exits the pop-menu and returns to the

initial screen.

SELECT ALL : Selects all still images within the same

group.

DESELECT ALL : Clears the selection of all still images

within the same group.

Note:

A message appears if the selected still images do not fit into the disc. Check mark cannot be added to a still image if there is insufficient space on the disc.

126+10

4'6740

&7$$+0)

56'2

5'.'%656#4661$')+0&7$$+0)

&7$$+0)56+..2+%674'5

07/$'41(56+..2+%674'561$'&7$$'&

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

root DCIM 100JVCS PIC_0001.JPG






101JVCS

126+10

4'6740

0#8+)#6+10

8+&'12+%674'

)4172#..

24'82)

0':62)

':+6

5'.'%6

)4172

8+&'1

2+%674'

6+6.'6*7/$0#+.

0#8+)#6+10

126+105

$#%-

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

Select “START”, and press the [OK] button

Dubbing starts. A progress bar is displayed during the dubbing process.

After dubbing is complete, a “DUBBING IS COMPLETED” message appears on the monitor.

Memo:

A directory of the following configuration is created in the media, and still images are written with file names ranging from “PIC_0001.jpg” to “PIC_9999.jpg”.

Dubbing/Importing

Dubbing from the Playback Navigation screen

Dubbing can also be performed from the Playback Navigation screen.

Select the still images to dub, and press the [OPTION] button

Select “DUB”, and press the [OK] button

Follow steps 3 to 5 of “Dubbing still images”

Memo:

Check marks of still images that appear on the Playback navigation screen will remain added to the image on the still image selection screen.

Cancel dubbing

To cancel dubbing before it starts

Select “CANCEL” from the menu, and press the [OK] button to cancel dubbing.

Alternatively, you can press the [RETURN] button to cancel dubbing and return to the initial screen.

To discontinue dubbing while it is in progress

Press the [OPTION] button. Select “CANCEL” from the Cancel Dubbing menu, and press the [OK] button.

/'&+#/#0#)'/'06

$&&8&

(14/#6

(+0#.+<'

4'0#/'&+5%

5&%#4&

$&8+&'1#'4#5'

*&&

(14/#6

%10(+4/

&+5%9+..$'(+0#.+<'&(142.#;$#%-1016*'4&8&&'8+%'5

+69+..6#-'#$176::/+076'5

;17%#001656126*'(+0#.+<#6+1010%'+656#465

&1;179#0661(+0#.+<'!

;'5

&8&498KFGQ

(+0#.+<'

%*#0)'&+5%/'07$#%-)4170&

5'.'%6(41/&'(#7.6$#%-)4170&

5'.'%6(41/56+..2+%674'5

(+4562.#;

4'2'#6

1((

':+6

/'&+#/#0#)'

5'.'%6

126+10

4'6740

6*'&+5%9+..$'(+0#.+<'&61'0#$.'2.#;$#%-1016*'4&8&&'8+%'5

612/'07

&1016(+0#.+<'

(+0#.+<'

Dubbing/Importing

Enabling Playback on Other Devices (Finalizing)

DVD-R and DVD-RW discs may need to be finalized before they can be played on other DVD players.

Memo:

Discs in the Video mode becomes a DVD-Video format with a title menu after finalizing.

Discs containing DVD-Video data can be finalized by setting the disc operation settings according when the disc is inserted into this unit.

Recording or editing of the disc will not be possible after it is finalized.

If a DVD that was recorded using VR mode has been finalized, the disc can only be played back on VR mode compatible devices.

Finalizing

Set the BD or DVD to be finalized on the disc tray

Press the [MEDIA MANAGE] button on the remote control unit

The Media Management menu screen appears.

Select “FINALIZE” from “BD/DVD”

Select “YES” and press the [OK] button

The top menu setting screen appears.

Memo:

To cancel the finalizing operation, select “NO” and press the [OK] button.

Setting the top menu items

Before finalizing, set “FIRST PLAY”, “REPEAT”, and “CHANGE DISC MENU BACKGROUND” accordingly. Set according to the steps below.

① Select “FIRST PLAY”, and select an appropriate first

play setting item

This item is used for setting the disc operation when a finalized disc is inserted into another device.

NONE : A finalized disc will not be automatically

played back when it is inserted into another device.

TOP MENU : The disc menu will be displayed

automatically when a finalized disc is inserted into another device.

TITLE 1 : The first title on a finalized disc will be

played back automatically when it is inserted into another device.

② Select “REPEAT”, and select an appropriate repeat

setting item

Set the disc action to be taken after all titles have been played back.

OFF : The disc will stop and the menu will be displayed

after all the titles are played back.

ON : Repeat playback from the first title will start

automatically after all the titles are played back.

2CIG

126+10

4'6740

2CIG

(+0#.+<'

5'.'%6#6+6.'#5$#%-)4170&&'5+)0(146*'/'075%4''0

)4172#..

':+6

/'&+#/#0#)'/'06

5'.'%6

&8&498KFGQ

(+0#.+<'

%*#0)'&+5%/'07$#%-)4170&

5'.'%6(41/&'(#7.6$#%-)4170&

5'.'%6(41/56+..2+%674'5

(+4562.#;

4'2'#6

1((

':+6

5'.'%6

126+10

4'6740

6*'&+5%9+..$'(+0#.+<'&61'0#$.'2.#;$#%-1016*'4&8&&'8+%'5

612/'07

&1016(+0#.+<'

FINALIZE

/'&+#/#0#)'

%10(+4/

6*'&+5%*#5$''0(+0#.+<'&

/'&+#/#0#)'/'06

$&&8&

(14/#6

(+0#.+<'

4'0#/'&+5%

5&%#4&

$&8+&'1#'4#5'

*&&

(14/#6

%10(+4/

6*'&+5%9+..$'70(+0#.+<'

+66#-'5#$176:::/+076'5

;17%#001656126*'241%'5510%'+656#46'&

&1;179#066170(+0#.+<'!

;'501

Dubbing/Importing

③ Select “CHANGE DISC MENU BACKGROUND” to

select a background image for the top menu

You can register and use a background image of your preference.

Memo:

The items in “FIRST PLAY”, “REPEAT” and “CHANGE DISC MENU BACKGROUND” can also be set in “Dubbing a Title from the HDD to a BD/DVD” (A page 39) .

Select “FINALIZE”, and press the [OK] button

Unfinalizing a disc

Only DVD-RW discs that are finalized on this unit can be unfinalized. After a disc is unfinalized, addition of new titles and editing are possible.

Note:

All discs except DVD-RW (VR mode) cannot be unfinalized.

To unfinalize a disc

Set a DVD-RW disc that is finalized by this unit on the disc tray

Press the [MEDIA MANAGE] button on the remote control unit

The media management menu screen appears.

Finalizing starts.

After finalization is complete, a “THE DISC HAS BEEN FINALIZED” message appears on the monitor.

Select “FINALIZE” from “BD/DVD”

Select “YES” and press the [OK] button

Unfinalizing starts.

After unfinalizing is complete, a “THE DISC HAS BEEN UNFINALIZED” message appears on the monitor.

75$

&+5%

*&8&8

&+5%

&+5%5&

126+10

4'6740

':+6

5'.'%6

&7$$+0)

56'2

5'.'%6+/2146&7$$+0)

*&&

61*&&61&8&

&+5%%12;

%#0%'.0':6

&7$$+0)

8+&'1

2+%674'

126+10

4'6740

':+6

5'.'%6

&7$$+0)

52'%+(;6*'07/$'41(%12+'5#0&5'.'%6':'%76'

07/$'41(%12+'5

%#0%'.$#%-0':6

&7$$+0)

24'82)0':62)

126+10

4'6740

&7$$+0)

56'2

%#0%'.

':+6

5'.'%6

&7$$+0)

5'.'%656#4661$')+0&7$$+0)

&+5%%12;

+05'466*'&+5%61$'%12+'&

$#%-

56#46

126+10

4'6740

&7$$+0)

56'2

%#0%'.

':+6

5'.'%6

&7$$+0)

5'.'%656#4661$')+0&7$$+0)

4'#&;61%12;019+05'466*'&+5%(14%12;+0)

&+5%%12;

$#%-56#46

Dubbing/Importing

Copying the Entire Disc

Copying the entire disc allows all content on a BD (BDMV) or DVD (AVCHD, DVD-Video) to be copied onto another disc.

Note:

Content cannot be copied to a formatted BD-R or DVD-R disc. Make use of an unformatted disc.

Use a DVD-R/-RW instead of a BD-R/-RE or DVD when the source disc is a BD disc.

The disc to be copied onto will be formatted when copy is performed. Check that the disc has not been used before or if it is ok to delete data on the disc when using a BD-RE or a DVD-RW.

In the case of BD, volume labels are not copied.

If an unsupported disc is set, “UNABLE TO IMPORT FROM DISC” or “UNABLE TO DUB ONTO DISC INSERT ANOTHER DISC” will be displayed on the monitor. Use a disc that is supported by this unit.

For details on discs that are supported by this unit, refer to “Discs that enable both dubbing and playback” (A page 10) and “Discs that enable playback only” (A page 10) .

Press the [DUBBING] button on the remote control unit

The Dubbing screen appears.

Select “NEXT”, and press the [OK] button

The disc tray will open automatically.

Set the source BD or DVD on the disc tray

Select “START”, and press the [OK] button

The disc tray will close automatically. The source BD or DVD will be recognized, and copying to the internal HDD will proceed.

The disc tray will open automatically after copying has finished and “READY TO COPY NOW. INSERT THE DISC FOR COPYING” will be displayed on the monitor.

Memo:

Confirm the insufficient space on the internal HDD when the copy interrupts.

Select “DISChDISC”, and press the [OK] button

A menu screen for copying the entire disc appears.

Memo:

During copy of the entire disc, data is temporarily copied to the internal HDD.

Only discs that are not copyright-protected can be copied.

Set the number of discs to copy using the [ J / K ] buttons

You can specify up to a maximum of 10 discs.

Set a BD or DVD to copy on the disc tray

Select “START”, and press the [OK] button

The disc tray will close automatically. BD or DVD will be recognized, and the contents that were copied to the HDD will be copied to the disc.

Memo:

The copy operation will not be performed when the remaining disc memory is not sufficient.

%10(+4/

%12;+0)10616*':::&+5%+5%1/2.'6'&

126+10

4'6740

&7$$+0)

56'2

5'.'%656#4661$')+0&7$$+0)

&+5%%12;

%12;+0)10616*'56&+5%+5%1/2.'6'&

+05'46#0'9&+5%

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

126+10

4'6740

&7$$+0)

56'2

5'.'%656#4661$')+0&7$$+0)

&+5%%12;

%#0%'.$#%-56#46

':+6

5'.'%6

&7$$+0)

%10(+4/

;'501

&1;179#0661%#0%'.&7$$+0)!

Complete the entire disc copying

After copy is complete the tray will open automatically, and copy of the entire disc ends.

Memo:

The screen prompting you to insert a new disc appears repeatedly until this unit has finished copying the number of discs specified in Step 3. When the message appears, set a new BD or DVD on the disc tray, select “START”, and press the [OK] button.

After copy is complete, the data copied onto the HDD will be deleted.

Select “CANCEL” from the menu, and press the [OK] button to cancel disc copying.

Dubbing/Importing

Recording Using External Inputs

Videos on an external device that is connected to i.LINK (HDV/ DV) or video / S-video input can be recorded to the HDD. BD, DVD can be recorded from the [VIDEO]/[S-VIDEO] input.

Memo:

Only titles that are not copyright-protected can be imported.

Press the [HDD] or [BD/SD] button to select the location to record the file

Press the [INPUT SELECT] button on the remote control, and choose external input (HDV/DV or L-1)

Press the [REC MODE] button and select a recording mode

Press the [ R ] and [ I ] remote control buttons together to start the recording process

Recording can also be start by pressing the [ R ] button on this unit.

Operate the external device using i.LINK(HDV/ DV) or the video/S-video input to output the videos to be recorded

Press the [ o ] button on either this unit or the remote control to display the pop-up screen, choose “STOP” and press the [OK] button

End the recording.

Memo:

When recording images via a video camera using i.LINK connection, recording may stopped if the video camera is loaded with a DV tape while in the shooting mode. In this case, remove the DV tape before recording.

Recording will be stopped if the maximum recording time has been reached, or if there is insufficient memory in the media.

For HDV contents, “DR” will be used to record instead of the selected recording mode.

RECORDABLE MEDIA

RECORDING

MODE

DR HDV - -

AF (HD) - - -

AN (HD) - - -

AL (HD) - - -

AE (HD) - - -

XP (SD) DV/L1 L1 L1

SP (SD) DV/L1 L1 L1

LP (SD) DV/L1 L1 L1

EP (SD) DV/L1 L1 L1

MAXIMUM CONTINUOUS RECORDING TIME HDD : 24 hours (*1) DVD-RW : 8 hours BD-RE : 8 hours *1: Title will automatically be split into time separated by 8

hours. The dividing point will not be recorded.

For the recording modes and maximum recording time for each disc, refer to “Recording Modes” (A page 28) .

RECORDABLE MEDIA

HDD DVD-RW

(VR format)

BD-RE

(BD-AV format)

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

5'.'%6



VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

':+6

)41722+%674'

)4172

0#8+)#6+10

.+5624'82)0':62)

Playing Back

About Playing Back

Videos or edited videos stored on the internal HDD, as well as videos stored on a disc or SD card can be played back on this unit.

Using Playback Navigation

Videos can be easily played back for viewing using the “Playback Navigation” function available on this unit.

The types of media that are playable on this unit are as follows.

Videos and still images stored on the internal HDD

Videos stored on different disc types

Videos and still images stored on backup discs created using the “Everio Writer”

Videos and still images stored on SD cards

These videos can be easily played back for viewing using the

Displaying the Playback Navigation screen

“Playback Navigation” software that comes with this unit. For details on the “Playback Navigation” software, refer to “Using Playback Navigation” (A page 48) .

Memo:

This unit does not support DivX videos.

If AVCHD files are displayed in thumbnails, black bars may appear on the left and right borders depending on the video resolution.

To display MOV* files stored on an SD card using Playback Navigation, make use of list display. Thumbnail display is not supported. Files on the SD card cannot be played back

Memo:

directly. To do so, import them into a HDD.

For details on importing MOV* files from an SD card, refer to “Importing Data from an SD Card to the HDD” (A page 35) .

MOV* : MOV files that are taken in SP mode using the JVC

ProHD Camcorder GY-HM700/100

Operating Playback Navigation

Plays the selected video/still image.

Display Marks on the Playback Navigation Screen

Select the location of the playback file

Press the [HDD] button on the remote control unit Play back videos or still images stored on the HDD. Press the [BD/SD] button on the remote control unit. Play back videos or still images stored on a BD/DVD or a

SD.

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Pressing the [BD/SD] button each time switches the media to play back between BD/DVD and SD.

You can also switch the media to play back by pressing the [HDD] or [BD/SD] button when the Playback Navigation screen is displayed.

Playing a video/still image

Icon Mark name Explanation

Protect Mark Indicates protected titles.

Conversion

Mode

Indicates titles for which mode conversion has been preset.

Preset Mark

Not Viewed

Mark

Indicates titles that have not been viewed or groups containing titles that have not been viewed.

Scene

Delete Mark

Indicates titles for which scene delete or chapter delete has been applied.

Group Mark Indicates a group.

Playlist Mark Indicates a playlist.

Not Playable

Mark

Indicates titles that cannot be played.

Select a title to play back, followed by pressing the [OK] or [I] button to play the selected video/still image.

Memo:

Select a group and press the [OK] button to display all titles in the group.

Question

Mark

Indicates titles of which the thumbnails cannot be displayed. Playback may not be possible.

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

5'.'%6



VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

':+6

)41722+%674'

)4172

0#8+)#6+10

.+5624'82)0':62)

#$%

5RQTVU

%QQMKPI

-+&5914.&

0GYU###

4GRQTV

(.19'4.'5510

#PKOCN

2CIG

126+10

4'6740

0#8+)#6+10

6+6.'.+56

8+&'12+%674'

#..

24'82)0':62)

':+6

5'.'%6

6*7/$0#+.

0#8+)#6+10

2+%674'

)4172

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

4'/#+0 

0#8+)#6+10

6+6.'.+56

8+&'1

24'82)0':62)

':+6

5'.'%6

2+%674'

0#8+)#6+10

.+56

)4172

#..

9GFFKPI

&TKXKPI

$KTVJFC[%QOOKVVGG

6TCXGN

2KEPKE

5RQTVUFC[

2KCPQEQPEGTV

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

5'.'%6



VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

':+6

)41722+%674'

)4172

0#8+)#6+10

.+5624'82)0':62)

2CIG

126+10

4'6740

5'.'%6

2CIG



0#8+)#6+10

6+6.'

6*7/$0#+.

8+&'12+%674'

4'/#+0

':+6

%106'06

0#8+)#6+10

24'82)0':62)

(1.&'4

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

24'82)0':62)

.+56

126+105

2.#;

&'.'6'

&7$

&1016)4172

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

Playing Back

Switching between thumbnail and list displays

You can switch between the thumbnail display and list display of a video.

When the video thumbnail list screen is displayed

Press the [RED] button to display the title list screen.

When the title list screen is displayed

Switching between video and still image displays

You can switch the display between the video thumbnail list screen and still image thumbnail screen.

When the video thumbnail list screen is displayed

Press the [GREEN] button to display the still image thumbnail list screen.

When the still image thumbnail list screen is displayed

Press the [RED] button to display the video thumbnail list screen.

Displaying a group/folder

A group/folder screen can be displayed.

Press the [YELLOW] button to display the group/folder screen.

Press the [RED] button to display the video thumbnail list screen.

Displaying the Option menu

Displaying the Option menu enables you to perform different operations on a selected title/group, including “BACK”, “PLAY”, “DELETE”, “DUB”, “GROUP”, “UNGROUP”, “DO NOT GROUP”, “MODE CHANGE”, “EDIT”, “EDIT INFO” and “OTHERS”.

Select a title/group, and press the [OPTION] button

An Option menu appears.

Playing Back

Using Playback Navigation (Continued)

Select an operation option, and press the [OK] button

Options that cannot be operated are displayed in gray and cannot be selected.

For details on the Option menu items, refer to “Option menu list” (A page 50) .

Option menu list

BACK

Returns to the previous screen.

PLAY

Plays back the selected title/group. For details on the button operations during playback, refer to “Video Playback Operation” (A page 51) .

DELETE

Deletes a selected title/group. For details, refer to “Deleting a Title/Group” (A page 62) .

DUB

Performs dubbing of a selected title/group. For details, refer to “Dubbing/Importing” (A page 23) .

GROUP

Groups the selected titles/groups. For details, refer to “Grouping” (A page 60) .

UNGROUP

Ungroups a selected group. For details, refer to “Ungrouping” (A page 60) .

DO NOT GROUP

Removes the selected titles from a group. For details, refer to “Excluding from a group” (A page

61) .

MODE CHANGE

Changes the mode of the selected title/group. For details, refer to “Mode conversion” (A page 73) .

CHAPTER LIST

Displays the chapters of a selected title.

EDIT

Switches to the menu screen of the sub-items.

CHAPTER EDIT

Switches to the chapter edit screen of the selected title. For details, refer to “Editing a Chapter” (A page 67) .

PLAYLIST EDIT

Switches to the playlist edit screen of the selected title. For details, refer to “Creating a Playlist” (A page 65) .

DELETE SCENE

Switches to the delete scene screen of the selected title. For details, refer to “Delete Scenes” (A page 70) .

DIVIDE

Switches to the dividing screen of the selected title. For details, refer to “Dividing” (A page 69) .

EDIT INFO

Switches to the menu screen of the sub-items.

MODIFY TITLE NAME/MODIFY GROUP NAME

Switches to the rename screen for the selected title/ group name. For details, refer to “Changing the Title/Group Name” (A page 62) .

MODIFY THUMBNAIL

Switches to the thumbnail modification screen of the selected title. For details, refer to “Editing a Thumbnail” (A page 66) .

MODIFY DATE

Switches to the recording date modification screen of the selected title. For details, refer to “Changing the Shooting Date/Time” (A page 72) .

PROTECT

Switches to the protection screen of the selected title/ group. For details, refer to “Turning On Title/Group Protection” (A page 63) .

UNPROTECT

Switches to the screen for turning off protection of the selected title/group. For details, refer to “Turning Off Title/Group Protection” (A page 64) .

OTHERS

Switches to the menu screen of the other-items.

CHAPTER LIST

DETAILS

THUMBNAIL

LIST

VIDEO


GROUP

FOLDER SELECT

CONTENT

Playing Back

Video Playback Operation

Frequently used button operations

[ I ] button

If the stop position (resume point) is memorized in the selected video, pressing the button plays back the video from this position. The video may not resume playback depending on the media and settings used. Refer to “RESUME” (A page

77) .

If playback is paused (Still mode), pressing the button resumes playback.

[ o ] button

Pressing the button stops playback after memorizing the stop position (resume point).

Pressing the button again after playback stops clears the memory of the stop position (resume point).

[ W ] button

Pressing the button stops playback temporarily.

[ N ] button

Pressing the button once during playback switches to a playback speed of 1.3 times (with audio sound).

Pressing the button in the 1.3x playback or fast forward mode fast forwards the video. Pressing the button each time switches the search speed. (5xh10xh30xh60x)

Memo:

The listed speed for searching and slow motion is an approximate amount.

Pressing the button in the Still mode forwards the video frame by frame.

Pressing and holding down the button in the Still mode starts playback in slow motion. Pressing the button during playback in slow motion switches the playback speed. The speed changes each time the button is pressed. (1/24xh1/16xh1/8xh1/2x)

[ O ] button

During normal playback, 1.3x playback, fast forward, or fast reverse, pressing the button fast reverses playback. Pressing the button each time switches the search speed. (1xh5xh10xh30x)

Pressing the button in the Still mode reverses the video frame by frame.

Pressing and holding down the button in the Still mode starts reverse playback of the video in slow motion. Pressing the button during playback in slow motion switches the playback speed. The speed changes each time the button is pressed. (1/24xh1/16xh1/8xh1/2x)

Memo:

The listed speed for searching and slow motion is an approximate amount.

[ T ] / [ S ] button

Pressing any of the buttons moves the chapter position.

[MARK] button

Pressing the button enables you to add a chapter mark to a title.

Playing Back

Video Playback Operation (Continued)

[ v ] button

During normal playback, 1.3x playback, slow motion playback, fast forward, or fast reverse, pressing the button moves the playback position forward by about 30 seconds. Pressing the button multiple times moves playback to the position equivalent to the number of times pressed multiplied by 30 seconds.

Normal playback will resume after the position has been moved. If pressed during 1.3x playback, 1.3x playback will continue after the position has been moved. Contents may be played back in the normal mode depending on the type of disc or content.

Pressing the button in the Still mode moves the current paused position forward by about 30 seconds while maintaining the Still mode.

[ w ] button

During normal playback, 1.3x playback, slow motion playback, fast forward, or fast reverse, pressing the button moves the playback position back by about seven seconds. Pressing the button multiple times moves playback to the position equivalent to the number of times pressed multiplied by seven seconds.

Pressing the button in the Still mode moves the current paused position back by about seven seconds while maintaining the Still mode.

[HDD] button

During playback of videos on a “BD/DVD” or “SD”, pressing the button stops the current playback and switches to the “HDD” mode. Pressing the button during display of the Playback Navigation screen switches to the Playback Navigation screen for the “HDD” mode.

[BD/SD] button

During playback of videos on a “BD/DVD” or “SD”, pressing the button stops the current playback and switches from “BD/DVD” to “SD” or vice versa. Pressing the button during display of the Playback Navigation screen switches to the Playback Navigation screen for the other media. During playback of videos on the “HDD”, pressing the button stops the current playback and switches to “BD/DVD” mode.

Memo:

The display switches automatically to the SD mode only if the inserted SD card contains playable videos or still images.

Useful button operations

[PB MODE] button

Displays the Playback Settings screen, which enables you to modify the settings. For details, refer to “Changing Playback Settings”.

[AUDIO] button

Switches the audio channel.

[SUB TITLE] button

Switches the subtitle display.

[ANGLE] button

Switches the angle.

Memo:

Pressing the [AUDIO], [SUB TITLE], or [ANGLE] button has no effect if their selection is not available in the playback video.

001

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

24'82)0':62)

':+6

5'.'%6

126+10

'06'4

$#%-

)4172

8+&'12+%674'

Playing Back

Playing Videos on a BD/ DVD

Playback starts automatically after a BD/DVD is set. If the Auto Play feature is disabled, play the title using Playback Navigation.

Memo:

For details on the button operations during playback, refer to “Video Playback Operation” (A page 51) .

Playing a disc when Auto Play is enabled

Set a BD or DVD on the disc tray

Auto Play starts.

Playing a disc when Auto Play is disabled

Set a BD or DVD on the disc tray

Press the [NAVIGATION] button

The Playback Navigation screen appears.

Select a title, and press the [OK] button

Playback of the selected title starts.

Memo:

If the current playback location is HDD or SD, press the [BD/SD] button on the remote control unit to switch it to BD/ DVD.

Videos can also be played back without starting up Playback Navigation. Pressing the [I] button starts playback from the stop position (resume point) of the disc. If the stop position (resume point) is not memorized or if the setting for resume has been set to “OFF”, playback starts from the beginning of the disc.

Playing an EverioBackup Disc*

EverioBackup* : Data disc containing high-definition videos

that are recorded in the MPEG2 format using a DVD writer for Everio.

Set the disc on the disc tray

Press the [NAVIGATION] button

The Playback Navigation screen appears.

Select a title, and press the [OK] button

Playback of the selected title starts.

Memo:

If the current playback location is HDD or SD, press the [BD/SD] button on the remote control unit to switch it to BD/ DVD.

Videos can also be played back without starting up Playback Navigation. Pressing the [I] button plays back titles starting from that with the oldest recording date.

Playing Video Discs Created Using a PC

Videos that are created using a PC can be played back using Playback Navigation.

Set the disc on the disc tray

Press the [NAVIGATION] button

The Playback Navigation screen appears.

Select a title, and press the [OK] button

Playback of the selected title starts.

Memo:

The formats that can be played back are BDAV, BDMV, DVD-Video and DVD-VR (CPRM-compatible).

If the current playback location is HDD or SD CARD, press the [BD/SD] button on the remote control unit to switch it to BD/DVD.

Playback may not be possible due to compatibility problems.

001

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

24'82)0':62)

':+6

5'.'%6

126+10

'06'4

$#%-

)4172

8+&'12+%674'

Playing Back

Playing Videos on the HDD

Titles stored on the HDD can be played back using Playback Navigation. You can select a video to play from “Title”, “Group”, or “Playlist”.

Memo:

For details on the button operations during playback, refer to “Video Playback Operation” (A page 51) .

Playing titles stored on the HDD

Press the [NAVIGATION] button

The Playback Navigation screen appears.

Select the titles to playback, and press the [I] button

Playback of the selected title starts.

Memo:

If the current playback location is “BD/DVD” or “SD CARD”, press the [HDD] button on the remote control unit to switch it to “HDD”.

To play back specific titles within a group, select the group, press the [OK] button, and select the titles accordingly.

Videos can also be played back without starting up Playback Navigation. Pressing the [I] button starts playback of the most recently played title. If there are no recently played titles, playback starts from the title with the most recent recording date.

Playing Videos on a SD Card

Titles stored on an SD card can be played back using Playback Navigation. You can select a video to play from “Title”.

Insert the SD card into the [SD SLOT]

Switch the playback location to “SD CARD” after the SD card is detected by the unit.

Press the [NAVIGATION] button

The Playback Navigation screen appears.

Select a title, and press the [OK] button

Playback of the selected title starts.

Memo:

Playback navigation displays AVCHD files stored on the SD card in titles, not in scenes (chapters). Titles are grouped such as according to the date, recording mode, or number of scenes. Make use of thumbnail display to display titles. List display is not supported.

The formats that can be played back are AVCHD and SDVIDEO. If AVCHD files are displayed in thumbnails, black bars may appear on the left and right borders depending on the video resolution.

Videos can also be played back without starting up Playback Navigation. Pressing the [I] button starts playback from the stop position (resume point). If the stop position (resume point) is not memorized, playback starts from the beginning of the playable content. If the setting for “QUICK STARTUP” is set to “OFF”, the resume point will not be memorized when the power is turned OFF.

For details on the button operations during playback, refer to “Video Playback Operation” (A page 51) .

2CIG

126+10

4'6740

5'.'%6

2CIG



0#8+)#6+10

6+6.'

6*7/$0#+.

8+&'12+%674'

4'/#+0

':+6

%106'06

0#8+)#6+10

24'82)0':62)

(1.&'4

Playing Back

Playing Still Images (JPEG)

Still images stored on the HDD/BD/DVD/SD card can be played back using Playback Navigation.

Playing still images

Select the playback location

HDD : If the current playback location is “BD/DVD” or

“SD CARD”, press the [HDD] button on the remote control unit to switch it to “HDD”.

BD/DVD : If the current playback location is “HDD” or “SD

CARD”, press the [BD/SD] button on the remote control unit to switch it to “BD/DVD”.

SD card : If the current playback location is “HDD” or “BD/

DVD”, press the [BD/SD] button on the remote control unit to switch it to “SD CARD”.

Set the media

To play a media other than “HDD”, set the media on which the still images are stored.

BD/DVD : Set a BD or DVD on the disc tray

SD card : Insert the SD card into the [SD SLOT]

Select the still images to play, and press the [ I ] button

Images selected are played back in a slideshow.

Memo:

The slide show plays back images according to the date of the files.

If folders exist, files inside the selected folder will be played.

You can specify the “REPEAT”, “SLIDESHOW INTERVAL” and “SLIDESHOW EFFECTS” settings in the Playback Settings menu. For details, refer to the “REPEAT” (A page 56) , “SLIDESHOW INTERVAL” (A page 56) , and “SLIDESHOW EFFECTS” (A page 56) items under “Playback Settings”.

Enabled button operations during still image playback

[ I ] button

Pressing the button when a title/group is selected starts playback of the still images in the title/group in a slideshow.

[ o ] button

Pressing the button stops the slideshow and displays the Playback Navigation screen.

[ W ] button

Pressing the button stops the slideshow temporarily.

[ S ] / [ T ] button

Pressing the button displays the previous or next still image.

[ A ] button

Pressing the button ends playback of the still images and turns the power of the unit to "Off".

Memo:

The display of still images can be zoomed in/out or rotated using the following buttons when the slideshow is paused.

[ v ] / [BLUE] button

Rotates the still image by 90° in the anti-clockwise

direction.

[ w ] / [YELLOW] button

Rotates the still image by 90° in the clockwise direction.

[OK] / [RED] button

Enlarges the still image.

[RETURN] / [GREEN] button

Reduces the still image.

[ J / K / H / I ] button

Moves the display position toward the direction indicated

by the button.

This unit does not have a still image edit feature. Still images cannot be saved when they are zoomed in or rotated.

Priority of display is given to the media (“BD/DVD” or “SD CARD”) that contains playable still images. If both “BD/DVD” and “SD CARD” contain playable videos, priority of display will be given to the most recently used media.



#7&+157$6+6.'

#7&+1.#0)7#)'



%*#0)'#7&+1176276.4

57$6+6.'.#0)7#)'

2.#;$#%-5'66+0)

4'2'#61((

%*#0)'6+6.'

%*#0)'%*#26'4

6+/',7/2

Playing Back

Changing Playback Settings

Displaying the playback settings menu

Press the [PB MODE] button on the remote control unit during the playback of a title

The Settings Menu screen appears.

The playback settings menu can only be displayed during the playback of a title.

Only settings that are supported by the current title being played back can be changed in the playback settings menu. Items displayed in gray cannot be set.

Playback Settings Menu

Audio/subtitle settings

Memo:

“AUDIO/SUBTITLE” will be displayed only if they are available in the video content. The setting value differs depending on the content. Items that are not available in the content cannot be set.

AUDIO LANGUAGE

CHANGE AUDIO OUTPUT

SIGNAL TYPE (BD-ROM)

PRIMARY VIDEO

PRIMARY AUDIO

SECONDARY VIDEO

CHANGE SECONDARY VIDEO

SECONDARY AUDIO

SECONDARY AUDIO LANGUAGE

SUBTITLE LANGUAGE

SUBTITLE STYLE

CHANGE ANGLE

Playback settings

REPEAT

The following items can be set. Items are not displayed if they cannot be set.

Setting Values Description

OFF Turns off repeat.

TITLE

CHAPTER

TRACK

FOLDER

ALL

A-B

CHANGE TITLE

You can change to a different title by entering the corresponding numeric value. Any value that is larger than the number of titles cannot be entered.

CHANGE CHAPTER

You can change to a different chapter by entering the corresponding numeric value. Any value that is larger than the number of chapters cannot be entered.

TIME JUMP

You can move to a specific playback position by entering a time. This is not possible if the specified time is not valid.

SLIDESHOW INTERVAL

The following items can be set. 3SEC/5SEC/10SEC/20SEC/30SEC modes

SLIDESHOW EFFECTS

The following items can be set.

Setting Values Description

OFF Turns off slideshow effect.

Repeats playback of the currently played title.

Repeats playback of the currently played chapter.

Repeats playback of the currently played track.

Repeats playback within the currently played folder.

Repeats playback of the entire disc.

Repeats playback of the section between the specified starting and ending points. Pressing the [OK] button specifies the displayed scene as the starting point (Point A). Pressing the [OK] button after forwarding playback specifies the displayed scene as the ending point (Point B).

Turns on slideshow effect. “Fade out” and “Fade in” effects can be applied when switching from one slide to another.

8+&'15'66+0)

2+%674'37#.+6;014/#.

&+)+6#.01+5'4'&7%6+10

1((

241)4'55+8'176276#761

Playing Back

Video settings

PICTURE QUALITY

The following items can be set.

Setting Values Description

NORMAL Standard picture quality.

CINEMA Effective when playing movies.

FINE Produces sharp images with enhanced

outlines.

SOFT Reduces noise that is prominent in the

video image.

PROGRESSIVE OUTPUT

The following items can be set.

Setting

Description

Values

AUTO1 Displays video images after they are

converted according to the film material.

AUTO2 In addition to the “AUTO1” option, support is

also provided for progressive videos recorded at 30 frames per second.

VIDEO Most suitable for video images (TV broadcast,

etc.). Select this option when playing videos with significant movements or animated videos.

USER SETTING

DETAIL SETTING

Enables the Details setting. For more details, refer to “DETAIL SETTING”.

The following items can be set. Choose an option and press [OK] to set the respective values.

Setting Values

CONTRAST

BRIGHTNESS

SHARPNESS

COLOR

GAMMA

DIGITAL NOISE REDUCTION

A value between “-7” and “+7” can be set.

A value between “0” and “15” can be set.

A value between “-6” and “+6” can be set.

A value between “-7” and “+7” can be set.

A value between “0” and “5” can be set.

Description

The following items can be set.

Setting

Description

Values

OFF Turns off DNR (Digital Noise Reduction).

ON Reduces noise that is prominent in images

of lengthy videos.

Editing

Before editing

This unit mainly edits video images stored on the HDD. To edit video images stored in a disc or SD card, do so after importing them to the HDD. Data on a finalized disc cannot be edited. To edit a finalized disc, you have to either unfinalize the disc, or do so after importing the data to the HDD.

Memo:

Only discs that are finalized using this unit can be unfinalized.

Editable items for different media

Items that are editable vary according to the type of media on which the video data is stored. For details, refer to the media chart below.

Media chart

Editing option HDD BD-R

(BDAV)

Grouping V - - - - -

BD-RE (BDAV)

DVD-RW/

DVD-R

SD HDD/BD-

RE/SD

(picture)

Changing the Title/Group Name V V V V - -

Deleting a Title/Group V V V V - V

Turning On Title/Group Protection V V V *1 - V

Turning Off Title/Group Protection V V V *1 - -

Creating a Playlist V - - - - -

Editing a Thumbnail V V V V - -

Editing a Chapter V *2 *2 *1,*2 - -

Delete Scene V - - - - -

Dividing V - - - - -

Changing the Disc Name - V V V - -

Changing the Shooting Date/Time V - - - - -

Memo:

*1 : Supports only the “VR MODE”.

*2 : Supports only dividing and combining of chapters.

!CDE

IJKLMNOPQ

RSTUVWX



YZ[\

FGH

2#)'248

2#)'0':6

126+10

4'6740

4'0#/'6+6.'

4'0#/'6*'5'.'%6'&6+6.'

24'8%*#4#%6'4

0':6%*#4#%6'4

%*#4#%6'46;2'

%.'#4

':+6

5'.'%6

%10(+4/

+0(1%144'%6

)

ì 5 ø S ú Z

å ê

ò ÿ û ý ?

/ à ë î

ó ß ü þ ~

: á ð

ô $ Ù Ý

(

_ â È

õ 7 Ú Þ

)

ã É

Û 9

Ä Ë

Ð 4

;

>Ç$

>% &

[

] ' ` { | }

[1] [2] [3] [4] [5] [6] [7] [8] [9] [0]

[*]

. a d g

t w 0

, b e h k n q u x

? c

f i l

r v y

T J

s T z

1 B E G K N P U

C F H

L O Q

V X

( ä è I £ ö

Editing

Entering Characters

Names can be changed or given to stored videos or groups. You can enter characters while referring to the input on the monitor.

Character input screen

A Function name field B Screen description C Input window

Characters entered appear on the input window.

D Operation guide 1

The [0]-[9], [Z], [#], [PAGE PRV ], [w] and [v] buttons are displayed.

E Operation guide 2

[ J / K / H / I], [OK], [RETURN], [OPTION], [BLUE], [RED], [GREEN] and [YELLOW] buttons are displayed.

F Character input keyboard

A character input keyboard appears during input of symbol. You can enter characters by selecting them accordingly from the keyboard.

Entering characters

Enter characters using the [0]-[9], [Z] or [#] buttons

After character input is complete, press the [YELLOW] button

Memo:

Switch between alphanumeric and symbol input by pressing the [ w ] button.

For details on the correspondence between each button and the input characters, refer to the “Character List”.

Press the [ v ] button to delete an input character. Press and hold down the [ v ] button to delete all input characters.

Pressing the [RETURN] button calls up the confirmation screen to cancel character input. To cancel character input and return to the initial screen, select “YES” and press the [OK] button. To return to the character input screen, select “NO” and press the [OK] button.

Up to about 20 alphanumeric characters can be displayed on the disc menu of BDMV and DVD-VIDEO. (The number of characters that can be displayed varies with the character.)

Note:

If you switch the screen display before confirming the input characters, a message will appear on the screen. To cancel character input and proceed to switch the screen display, select “YES” and press the [OK] button. To return to the character input screen, select “NO” and press the [OK] button.

If the converted characters exceed the maximum number of input characters, a message will appear on the screen. Select “OK” and press the [OK] button to delete the excess characters and to input the remaining ones. Select “RETURN” and press the [OK] button to restore the unconfirmed characters.

No more characters can be input if the maximum character limit has been reached.

Character List

*1: Single-byte space

*2: Press the [#] button to return to the previous input character.

126+10

4'6740

24'82)0':62)':+6

5'.'%6

)4172

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

2+%674'

0#8+)#6+10

.+56

126+10

4'6740

24'82)0':62)':+6

5'.'%6

)4172

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

2+%674'

0#8+)#6+10

.+56

126+105

2.#;

&'.'6'

&7$

)4172

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

2CIG

126+10

4'6740



24'82)0':62)':+6

5'.'%6

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

)41722+%674'

0#8+)#6+10

.+56

)4172

6*'5'.'%6'&6+6.'59+..$')4172'&61)'6*'4

;17%#0/1&+(;6*')41720#/'(41/

'&+6+0(170&'46*'126+10/'07

)4172$#%-

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

70)4172

Editing

Grouping

Multiple titles stored on the HDD can be combined into a group.

Memo:

Only video data stored on the HDD can be grouped.

Grouping

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the titles or groups to be grouped, and press the [MARK] button

Pressing the [MARK] button adds a check mark to the selected titles/groups. All titles and groups with the check mark will be grouped together.

Press the [OPTION] button on the remote control unit

A pop-up option list appears.

Select “GROUP”, and press the [OK] button

A grouping confirmation screen appears.

Select “GROUP”, and press the [OK] button

The selected titles and groups are now grouped together.

Memo:

To cancel grouping, select “BACK” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel grouping and return to the initial screen.

Ungrouping

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the group to ungroup, and press the [OPTION] button

A pop-up option list appears.

Select “UNGROUP”, and press the [OK] button

An ungroup confirmation screen appears.

Memo:

You cannot ungroup multiple groups at the same time. When multiple groups are selected, the “UNGROUP” item does not appear in the option list.

2CIG

126+10

4'6740



0#8+)#6+10

6+6.'

6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

24'82)0':62)':+6

5'.'%6

.+56)4172

0#8+)#6+10

2+%674'

70)4172

6*'5'.'%6'&)41729+..$'70)4172'&

70)4172!

;'501

126+10

4'6740

24'82)0':62)':+6

5'.'%6

)4172

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

2+%674'

0#8+)#6+10

.+56

2CIG

126+10

4'6740



24'82)0':62)':+6

5'.'%6

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

)4172

2+%674'

0#8+)#6+10

.+56

&1016)4172

6*'5'.'%6'&6+6.'59+..$'4'/18'&(41/6*+5)4172

4'/18'(41/)4172!

;'501

Editing

Select “YES”, and press the [OK] button

All titles within the selected group are ungrouped.

Memo:

To cancel ungrouping, select “NO” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel ungrouping and return to the initial screen.

Excluding from a group

You can select titles and exclude them from a group.

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the titles to exclude from the group, and press the [MARK] button

Pressing the [MARK] button adds a check mark to the selected titles/groups. All titles with the check mark will be excluded from the group.

Press the [OPTION] button on the remote control unit

A pop-up option list appears.

Select “DO NOT GROUP”, and press the [OK] button

A confirmation screen for group exclusion appears.

Select “YES”, and press the [OK] button

The selected titles are now excluded from the group.

Memo:

To cancel, select “NO” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel group exclusion and return to the initial screen.

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

0#8+)#6+10

24'82)0':62)

5'.'%6

VKVNG

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..



0#8+)#6+10

2+%674'.+56

&'.'6'

&1;179#0661&'.'6'!

$#%-

':+6)4172

&'.'6'

Editing

Changing the Title/Group Name

The saved title/group name can be changed as follows.

Memo:

A title/group name can be added to video data stored on the HDD, BD-RE, BD-R, DVD-RW, or DVD-R, and the name can be changed.

Video data stored on a DVD-RW or DVD-R in the Video mode cannot be changed.

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the title/group for which the name is to be changed, and press the [OPTION] button

A pop-up option list appears.

Select “EDIT INFO”, and press the [OK] button

An information editing screen appears.

Deleting a Title/Group

Titles/groups can be deleted. When you delete a group, all titles contained within the group are deleted.

Memo:

When a title/group is deleted from the HDD, BD-RE, or DVD-RW, the remaining space on the media increases according to the size of the deleted title/group. Deleting a title/group from a BD-R or DVD-R does not increase the amount of available space on the disc.

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the titles/groups to delete, and press the [OPTION] button

A pop-up option list appears.

Select “DELETE”, and press the [OK] button

A confirmation screen for title/group deletion appears.

Select “MODIFY TITLE NAME” or “MODIFY GROUP NAME”, and press the [OK] button

A title/group name modifying screen appears.

Modify the title/group name

The modified title/group name is now saved.

Memo:

For details on the method of character input, refer to “Entering Characters” (A page 59) .

Select “DELETE”, and press the [OK] button

The selected titles/groups are deleted.

Memo:

To cancel the title/group deletion operation, select “BACK” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel the deletion operation and return to the initial screen.

Turning On Title/Group

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

2CIG

126+10

4'6740



0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

24'82)0':62)':+6

5'.'%6

.+56)4172

0#8+)#6+10

2+%674'

2416'%6

6*'5'.'%6'&6+6.'9+..$'2416'%6'&

&1;179#06615'62416'%6+10!

;'501

Protection

Titles/groups can be protected. Editing and deletion cannot be performed on protected titles/ groups.

Title/group protection can be turned on for video data stored on the HDD, BD-RE (BDAV), BD-R (BDAV), and DVD-RW (VR).

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the titles/groups to be protected, and press the [OPTION] button

A pop-up option list appears.

Editing

Select “PROTECT”, and press the [OK] button

If only a single title was selected in step 2, a confirmation screen for title protection will appear.

If multiple titles or groups were selected in step 2, “PROTECT” and “UNPROTECT” items will be displayed.

Select “YES” or “PROTECT”, and press the [OK] button

The selected titles/groups are now protected.

Memo:

All selected titles and groups will be protected when multiple titles or groups are selected.

To turn off the title/group protection, select “NO” and press the [OK] button.

Alternatively, you can press the [RETURN] button to turn off the protection and return to the initial screen.

Select “EDIT INFO”, and press the [OK] button

An information editing screen appears.

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

702416'%6

%*#0)'5*116+0)'6+/'

2CIG



24'82)0':62)':+6

5'.'%6

4'6740

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

(4''52#%'

)4172#..

0#8+)#6+10

126+10

)4172.+562+%674'

702416'%6

::6+6.'5*#8'$''05'.'%6'&614'/18'6*'2416'%6+10

;'501

Editing

Turning Off Title/Group Protection

Protection of a title/group can be turned off. Titles/groups can be edited and deleted after their protection is turned off.

Title/group protection can be turned off for video data stored on the HDD, BD-RE (BDAV), BD-R (BDAV), and DVD-RW (VR).

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the titles/groups to turn off protection for, and press the [OPTION] button

A pop-up option list appears.

Select “UNPROTECT”, and press the [OK] button

If only a single title was selected in step 2, a confirmation screen for turning off protection will appear.

If multiple titles or groups were selected in step 2, “UNPROTECT” and “PROTECT” items will be displayed.

Select “YES”, and press the [OK] button

Protection of the selected titles/groups is now turned off.

Memo:

Protection will be turned off from all selected titles and groups when multiple titles or groups are selected.

If you do not want to turn off the title/group protection, select “NO” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel protection removal and return to the initial screen.

Select “EDIT INFO”, and press the [OK] button

An information editing screen appears.

Creating a Playlist

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

&1016)4172

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6



2CIG

126+10

4'6740

2.#;.+56'&+6

5#8'2.#;.+56

'&+62.#;.+56

5174%'6+6.'

6#4)'62.#;.+56

24'82)0':62)':+6

'&+6

5'.'%6

5#8'

A playlist can be created from the video titles on the HDD.

Playlists can only be created for titles that are stored on the HDD.

Playlist : Enables you to create a program by selecting

chapters from a specific title and editing their playback sequence.

Memo:

The playlist created comes in handy during playback and dubbing to a disc.

Creating a Playlist

Press the [NAVIGATION] button on the remote control unit

The Playback Navigation screen appears.

Select the title for which a playlist is to be created, and press the [OPTION] button

Select “EDIT”, and press the [OK] button

The Edit menu screen appears.

Select “PLAYLIST EDIT”, and press the [OK] button

The playlist edit screen appears.

Editing

Edit the playlist accordingly by selecting chapters from the source title according to your preference

Edit the playlist. For details, refer to “Editing the playlist”.

Press the [YELLOW] button on the remote control unit

A playlist is created.

Editing the playlist

Chapter insertion

① Select the chapter to insert from the thumbnails of

the “SOURCE TITLE”, and press the [OK] button

② Select the position to insert the chapter from the

“TARGET PLAYLIST”, and press the [OK] button

Chapter deletion

① Select the chapter to delete from the thumbnails of

the “TARGET PLAYLIST”, and press the [OK] button

② Select “DELETE”, and press the [OK] button

Entering the playlist name

① Select “TARGET PLAYLIST”, and press the [OK]

button.

② Enter a playlist name, and press the [OK] button

Memo:

For details on the method of character input, refer to “Entering Characters”.

Note:

Deleting the original title list will cause the playlist to be deleted as well. Editing the original title list, or changing the recording mode may cause the playlist to be deleted.

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

- : -- : --



+0(1%144'%6

126+10

4'6740

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

/1&+(;6*7/$0#+.

;17%#0%*#0)'6*'6+6.'6*7/$0#+.5

%*#0)'

6*7/$0#+.

':+6

5'.'%6

%10(+4/

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

Editing

Editing a Thumbnail

Thumbnails (index images) can be changed to a still image according to your preference.

Memo:

Thumbnails of titles stored on the HDD, BD-RE, BD-R, DVD-RW, and DVD-R can be edited.

However, thumbnails of titles that are stored on an SD card or finalized disc cannot be edited.

Press the [INFORMATION CORRECT] button on the remote control unit

An information editing screen appears.

Select “CHANGE”, and press the [OK] button

The displayed still image now becomes the thumbnail image.

Select “CONFIRM”, and press the [OK] button

Doing so ends the editing of thumbnails.

Memo:

You can also display the thumbnail modification screen from the Playback Navigation screen.

① Select the title for which the thumbnail is to be

changed, and press the [OPTION] button

② Select “EDIT INFO”, and press the [OK] button

An information editing screen appears.

Select “MODIFY THUMBNAIL”, and press the [OK] button

A thumbnail modification screen appears.

Play the video, and press the [W] button to stop at the scene you want to use as thumbnail display

Memo:

For details on how to play videos, refer to “Video Playback Operation” (A page 51) .

③ Select “MODIFY THUMBNAIL”, and press the [OK]

button

A thumbnail modification screen appears.

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

&1016)4172

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6

Editing

Editing a Chapter

Creating a chapter mark for a saved title enables you to find a specific scene within the title.

Memo:

All chapter editing functions can be performed on titles stored on the HDD. Titles stored on a BD-RE (BDAV), BD-R (BDAV), DVD-R (VR), or DVD-RW (VR) only allow chapters to be divided or combined.

The chapters of titles that are stored on an SD card or finalized disc cannot be edited.

Also, protected titles cannot be edited. To perform chapter edit of a title, turn off the protection.

For details on turning off protection of a title, refer to “Turning Off Title/Group Protection” (A page 64) .

Chapter edit functions

Chapter mark insertion (divide chapter) Divides a chapter by inserting a chapter mark.

Chapter mark deletion (combine chapters) Combine chapters by deleting the chapter mark.

Chapter deletion Deletes a specified chapter.

Editing a chapter

Press the [EDIT] button on the remote control unit

The Edit menu screen appears.

Select “CHAPTER EDIT”, and press the [OK] button

The title screen appears.

Select a title, and press the [OK] button

Memo:

The chapter edit screen can also be called up from the Playback Navigation screen.

① Select the title to perform chapter edit, and press the

[OPTION] button

② Select “EDIT”, and press the [OK] button

③ Select “CHAPTER EDIT”, and press the [OK] button

For details on how to play videos, refer to “Video Playback Operation” (A page 51) .

Frame movement on the Chapter Edit screen can only be performed one frame at a time regardless of the “STILL MODE” (A page 77) setting.

001 0 : 00 : 00

126+10

4'6740

%*#26'4'&+6

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

24'82)0':62)

':+6

%*#26'4'&+6

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

24'82)

0':62)

5'.'%6

2CIG

'&+6

%10(+4/

001 0 : 00 : 00

126+10

4'6740

'&+6

':+6

2CIG

%*#26'4'&+6

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

24'82)0':62)':+6

5'.'%6

%*#26'4/#4-#.4'#&;':+565

&1;179#0661&'.'6'6*'

':+56+0)%*#26'4/#4-!

;'501

%*#26'4'&+6

001 0 : 00 : 00

126+10

4'6740

%*#26'4'&+6

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

':+6

2CIG

'&+6

%*#26'4'&+6

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

24'82)0':62)':+6

5'.'%6

6*'52'%+(+'&%*#26'49+..$'&'.'6'&

&'.'6'&#%#0016$'4'5614'&

&'.'6'%#0%'.

%*#26'4'&+6

Editing

Editing a Chapter (Continued)

Chapter mark insertion (divide chapter)

Play the video, and press the [W] button to stop at the scene you want to add a chapter mark

Press the [MARK] button on the remote control unit

A chapter mark is inserted into the paused scene.

Memo:

The chapter is now divided into two parts at the position of the chapter mark.

Deleting a video chapter

Select the chapter for which you want to delete the video from the chapter edit screen

Press the [DELETE] button on the remote control unit

A confirmation screen for deleting the chapter appears.

Select “DELETE”, and press the [OK] button

The selected video chapter is deleted.

Note:

Videos cannot be restored once they are deleted.

Deletion of the video may fail if the length of the chapter is too short.

Chapter mark deletion (combine chapters)

Play the video, and press the [W] and [ H / I ] buttons to display the scene for which you want to delete the chapter mark

Press the [MARK] button on the remote control unit

A confirmation screen for deleting the chapter mark appears.

Select “YES”, and press the [OK] button

The chapter mark is deleted from the selected scene.

Memo:

The chapters before and after the position of the chapter mark are now combined.

Pressing the [T / S] button displays the next/previous page.

Chapter options

Pressing the [OPTION] button on the remote control when the Chapter Edit screen is displayed enables you to perform the following editing operations.

Combining with previous chapter

Combines the selected chapter with the previous chapter.

① Select a chapter, followed by “COMB. W/PREV CH”,

and press the [OK] button

Combines chapters.

Combining with next chapter

Combines the selected chapter with the next chapter.

① Select a chapter, followed by “COMB. W/NEXT CH”,

and press the [OK] button

Combines chapters.

Combining all chapters

Combines all chapters.

① Select “COMB. ALL CHAP.”, and press the [OK]

button

A confirmation screen for combining all the chapters is displayed.

② Select “YES”, and press the [OK] button

Combines all the chapters.

Dividing

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6

001 0 : 00 : 00 - : -- : --

126+10

4'6740

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

&+8+&'

;17%#0&+8+&'6*'6+6.'

&+8+&+0)21+06

':'%76'

14+)+0#.

':+6

'&+6

5'.'%6

001 0 : 00 : 00 - : -- : --

126+10

4'6740

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

&+8+&'

;17%#0&+8+&'6*'6+6.'

&+8+&+0)21+06

':'%76'

14+)+0#.

':+6

'&+6

5'.'%6

001 0 : 00 : 00 - : -- : --

126+10

4'6740

;17%#0'&+66*'6+6.'618+'9$;%*#26'45

&+8+&'

;17%#0&+8+&'6*'6+6.'

&+8+&+0)21+06

':'%76'

14+)+0#.

':+6

5'.'%6

'&+6

&+8+&'

70#$.'614'5614'6*'14+)+0#.#10%'+6+5&+8+&'&

&1;179#0661&+8+&'!

%#0%'.

&+8+&'

You can select a saved title and divide it into two titles.

Memo:

Dividing can only be applied to titles stored on the HDD.

Titles that are protected cannot be divided. To divide a title, turn off the protection.

For details on turning off the title protection, refer to “Turning Off Title/Group Protection” (A page 64) .

Dividing

Press the [EDIT] button on the remote control unit

The Edit menu screen appears.

Select “DIVIDE”, and press the [OK] button

The title screen appears.

Select “EXECUTE”, and press the [OK] button

A confirmation screen for performing dividing appears.

Select “DIVIDE”, and press the [OK] button

Dividing starts.

Editing

Select a title, and press the [OK] button

Play the video, and press the [W] button at the scene where you want to perform dividing

Select “DIVIDING POINT”, and press the [OK] button

Memo:

For details on how to play videos, refer to “Video Playback Operation” (A page 51) .

Frame movement on the Chapter Edit screen can only be performed one frame at a time regardless of the “STILL MODE” (A page 77) setting.

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

&1016)4172

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6

'&+6

2.#;.+56'&+6

&'.'6'5%'0'

&+8+&'

%*#26'4'&+6

Editing

Dividing (Continued)

Memo:

To cancel the dividing operation, select “CANCEL” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel the divide operation and return to the initial screen.

The dividing edit screen can also be called up from the Playback Navigation screen.

① Select the titles to divide, and press the [OPTION]

button

② Select “EDIT”, and press the [OK] button

③ Select “DIVIDE”, and press the [OK] button

Delete Scenes

Unwanted scenes of a saved title can be deleted. Doing so helps to increase the free space on the disc.

Memo:

Deleting scenes can only be applied to titles stored on the HDD.

Titles that are protected cannot be deleted. To enable scene delete of a title, turn off the protection.

For details on turning off the title protection, refer to “Turning Off Title/Group Protection” (A page 64) .

HD content for which the delete scene operation has been applied cannot be dubbed to BDMV. Perform seamless conversion before starting a dubbing operation.

For details, refer to “Mode conversion” (A page 73) .

Delete Scenes

Press the [EDIT] button on the remote control unit

The Edit menu screen appears.

Select “DELETE SCENE”, and press the [OK] button

Displays the Title Display screen.

Select a title, and press the [OK] button

Edit the delete scene section

Follow the steps below to edit the section for which delete scene is to be applied.

① Play the video, and press the [W] button at the point

- : -- : -- - : -- : --



126+10

4'6740

&'.'6'5%'0'

;17%#0&'.'6'5%'0'5

56#46

'0&

0':6

':'%76'

':+6

5'.'%6

56#46

'0&

'&+6

0 : 00 : 03001 - : -- : --



126+10

4'6740

&'.'6'5%'0'

;17%#0&'.'6'5%'0'5

56#46

'0&

0':6

':'%76'

':+6

5'.'%6

56#46

'0&

'&+6

0 : 00 : 03001 0 : 00 : 17001



126+10

4'6740

&'.'6'5%'0'

;17%#0&'.'6'5%'0'5

56#46

'0&

0':6

':'%76'

':+6

5'.'%6

56#46

'0&

'&+6

0 : 00 : 00001 0 : 00 : 09001



126+10

4'6740

&'.'6'5%'0'

;17%#0&'.'6'5%'0'5

56#46

'0&

':'%76'

':+6

5'.'%6

56#46

'0&

6*'52'%+(+'&5'%6+10::5')/'0659+..$'&'.'6'&

':'%76'%#0%'.

'&+6

&'.'6'5%'0'

where you want to start the delete operation

② Select “START”, and press the [OK] button

Editing

Select “EXECUTE”, and press the [OK] button

A confirmation screen for performing scene delete appears.

Select “EXECUTE”, and press the [OK] button

Scene deletion starts.

③ Play the video, and press the [W] button at the point

where you want to end the delete operation

④ Select “END”, and press the [OK] button

⑤ To continue specifying other sections to delete,

select “NEXT”, and press the [OK] button

Memo:

To cancel the delete scene operation, select “CANCEL” and press the [OK] button.

Alternatively, you can press the [RETURN] button to cancel delete scene and return to the initial screen.

⑥ Repeat Steps 1 to 4 to specify the sections to delete

Memo:

For details on how to play videos, refer to “Video Playback Operation” (A page 51) .

Frame movement on the Chapter Edit screen can only be performed one frame at a time regardless of the “STILL MODE” (A page 77) setting.

/'&+#/#0#)'/'06

$&&8&

(14/#6

(+0#.+<'

4'0#/'&+5%

5&%#4&

$&8+&'1#'4#5'

*&&

(14/#6

!CDE

IJKLMNOPQ

RSTUVWX



YZ[\

FGH

2#)'248

2#)'0':6

126+10

4'6740

24'8%*#4#%6'4

0':6%*#4#%6'4

%*#4#%6'46;2'

%.'#4

':+6

/'&+#/#0#)'

5'.'%6

%10(+4/

4'0#/'&+5%

2.'#5'4'0#/'6*'&+5%

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

2CIG

+0(1%144'%6

126+10

4'6740



24'82)0':62)

':+6

5'.'%6

)4172

6+6.'

6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

2+%674'.+56

+0(1%144'%6





%*#0)'5*116+0)'6+/'

;'#4

/106*&#;

6+/'

'06'4

,#0

Editing

Changing the Disc Name

The name of a BD or DVD disc can be changed as follows.

Set the BD or DVD for which the disc name is to be changed on the disc tray

Press the [MEDIA MANAGE] button on the remote control unit

The Media Management menu screen appears.

Select “RENAME DISC” under “BD/DVD”, and press the [OK] button

A disc name modification screen appears.

Changing the Shooting Date/Time

The date/time of the stored video can be changed as follows.

The shooting date/time of videos stored on the HDD can be changed.

Press the [INFORMATION CORRECT] button on the remote control unit

An information correct screen appears.

Select “CHANGE SHOOTING DATE/TIME”, and press the [OK] button

A thumbnail screen appears.

Select the title for which the shooting date/time is to be changed, and press the [OK] button

The screen for changing the shooting date/time appears.

Change the shooting date/time

Perform the following steps to change the shooting date/ time.

Memo:

Modifying the Disc Name

The new disc name is now saved.

For details on the method of character input, refer to “Entering Characters” (A page 59) .

① Use the [ J ] and [ K ] buttons to move the cursor to

the item you want to change

② Press the [OK] button to display the pop-up screen ③ Use the [ J ] and [ K ] buttons to select a desired

value

④ Press the [OK] button to choose the value ⑤ Repeat Steps 1 to 4 to change settings for any

desired items

001 002 003 004

006005 007 008

126+10

4'6740

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

126+105

2.#;

&'.'6'

&7$

/1&'%*#0)'

'&+6

'&+6+0(1

16*'45

$#%-

001 002 003 004

006005 007 008

2CIG

126+10

4'6740

24'82)0':62)

5'.'%6

VKVNG

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

4'/#+0

)4172#..

':+6)4172



0#8+)#6+10

2+%674'.+56

+0(14/#6+10%144'%6

/1&+(;6+6.'0#/'

/1&+(;6*7/$0#+.

2416'%6

%*#0)'5*116+0)'6+/'

2CIG



126+10

4'6740

5'.'%6

0#8+)#6+10

6+6.'6*7/$0#+.

8+&'12+%674'

)4172#..

':+6)4172

2+%674'

0#8+)#6+10

.+56

24'82)0':62)

4'/#+0

&1016)4172

/1&'%*#0)'

/1&'

5'#/.'55

56#46/'6*1&

+//'&+#6'

%10(+4/

Select “ENTER”, and press the [OK] button

The modified shooting date/time is saved.

Memo:

Alternatively, you can press the [RETURN] button to cancel the shooting date/time modification and return to the initial screen.

The shooting date/time modification will not be reflected on a title that was dubbed.

Pressing the [OPTION] button in the playback navigation screen instead of the [INFORMATION CORRECT] button will also display the shooting date/time edit screen.

① Select the title for which the shooting date/time is to

be changed, and press the [OPTION] button

② Select “EDIT INFO”, and press the [OK] button

③ Select “CHANGE SHOOTING DATE/TIME”, and press

the [OK] button

Editing

Mode conversion

You can convert HD quality video titles saved on the HDD if they are recorded in the DR, AVC, AF, AN, AL, or AE mode.

Seamless conversion

Recording mode conversion

Memo:

As seamless conversion does not re-encode video and audio, there is no deterioration in the image quality.

Re-encoding is performed during recording mode conversion.

Only titles that are recorded in the DR mode enable conversion to the XP/SP/LP/EP mode.

To apply “MODE CHANGE” after turning off the power, select “AFTER POWER OFF” for “START METHOD” under the “MODE CHANGE”.

Note:

When seamless conversion is performed, the chapters (excluding joints of scenes) will be combined. To divide the chapters, insert chapter marks after seamless conversion. For details on dividing the chapters, refer to “Chapter mark insertion (divide chapter)” (A page 68) .

Press the [NAVIGATION] button on the remote control

Select a title/group, and press the [OPTION] button

Select “MODE CHANGE” from the Option menu, and press the [OK] button

The “MODE CHANGE” screen appears.

: Seamless conversion can be performed to

enable smooth playback of joined scenes after dubbing to a BD. (Titles recorded in the DR recording mode h seamless)

: Enables conversion of recording mode.

(Titles recorded in the DR, AVC, AF, AN, AL, or AE mode hAF/AN/AL/AE/XP/SP/LP/ EP)

Select a recording mode from “MODE CHANGE”, and press the [OK] button

Select “CONFIRM”, and press the [OK] button

Settings Menu

Changing Settings of this Unit

Settings changed in the Settings Menu screen are stored on this unit even when its power is turned off.

Displaying the Settings Menu

Press the [SET UP] button on the remote control unit

The Settings Menu screen appears.

Memo:

When playback is in progress, pressing the button stops it and displays the Settings Menu screen.

The cursor position appears at the position when the screen was last closed.

Setting Menu List

The following items can be set. Items that cannot be set cannot be selected.

SETUP ................................................................. (A page 75)

AUTO POWER (OFF) ....................................... (A page 75)

REMOTE CONTROL CODE ............................ (A page 75)

CLOCK SET/DISPLAY ..................................... (A page 75)

CLOCK SET .................................................. (A page 75)

DATE DISPLAY ............................................ (A page 75)

TIME DISPLAY CHOICE .............................. (A page 75)

PANEL DISPLAY BRIGHTNESS ..................... (A page 75)

DIMMER (POWER ON) ................................ (A page 75)

DIMMER (POWER OFF) .............................. (A page 76)

QUICK STARTUP ............................................ (A page 76)

BUZZER OUTPUT ........................................... (A page 76)

REMOTE CONTROL SENSOR TONE ......... (A page 76)

ALERT/WARNING TONE ............................. (A page 76)

DEFAULT SETTING ......................................... (A page 76)

PLAYBACK SETTING .......................................... (A page 76)

BD-/DVD-VIDEO PB SETTING ........................ (A page 76)

BD-VIDEO RATINGS .................................... (A page 76)

COUNTRY CODE ......................................... (A page 76)

AUDIO LANGUAGE ...................................... (A page 76)

SUBTITLE LANGUAGE ................................ (A page 76)

MENU LANGUAGE ...................................... (A page 76)

RESUME .......................................................... (A page 77)

STILL MODE .................................................... (A page 77)

SEAMLESS PLAYBACK .................................. (A page 77)

RECORD .............................................................. (A page 77)

XP MODE RECORDING AUDIO ...................... (A page 77)

HIGH-SPEED DUBBING .................................. (A page 77)

VIDEO MODE RECORDING ASPECT ......... (A page 77)

DISC RECORDING AUDIO .......................... (A page 78)

AUDIO .................................................................. (A page 78)

DYNAMIC RANGE CONTROL ......................... (A page 78)

DOWN MIX ....................................................... (A page 78)

DIGITAL OUT ................................................... (A page 78)

PCM DOWN SAMPLING .............................. (A page 78)

Dolby Digital .................................................. (A page 78)

Dolby Digital Plus/TrueHD ............................ (A page 78)

DTS ............................................................... (A page 78)

DTS-HD ........................................................ (A page 79)

AAC ............................................................... (A page 79)

DV IN AUDIO SETTING ................................... (A page 79)

BD MIX SOUND ............................................... (A page 79)

DISPLAY .............................................................. (A page 79)

ON SCREEN GUIDE ........................................ (A page 79)

BLUE BACK ..................................................... (A page 79)

SCREEN SAVER ............................................. (A page 79)

OSD LANGUAGE ............................................. (A page 79)

CONNECTION ..................................................... (A page 80)

MONITOR TYPE .............................................. (A page 80)

HDMI CONNECTION ....................................... (A page 80)

VIDEO PRIORITY MODE ............................. (A page 80)

HDMI OUTPUT RESOLUTION ..................... (A page 80)

BD-VIDEO 24p OUT ..................................... (A page 80)

x.v.Color ........................................................ (A page 81)

Deep Color .................................................... (A page 81)

HDMI RGB OUTPUT RANGE ....................... (A page 81)

HDMI --> DVI COLOR ................................... (A page 81)

HDMI AUDIO OUTPUT ................................. (A page 81)

HDMI-CEC ........................................................ (A page 81)

COMPONENT OUTPUT ................................... (A page 81)

VIDEO INPUT SETTING .................................. (A page 81)

Memo:

The highlighted value is the default setting.

Setup

4'6740

':+6

5'.'%6

5'672

#761219'41((1((

1((

4'/16'%10641.%1&'

4'/16'%10641.

%.1%-5'6&+52.#;

2#0'.&+52.#;$4+)*60'55

37+%-56#4672

$7<<'4176276

&'(#7.65'66+0)

5'672

5QHVYCTG8GTUKQP

ZZZZZZZZZZZZZZZ

AUTO POWER (OFF)

You can specify a time for the power of the unit to turn off automatically when it is not being operated.

Setting Values Description

OFF Power does not turn off automatically.

2 HOURS Turns off power after two hours.

6 HOURS Turns off power after six hours.

REMOTE CONTROL CODE

For remote control units compliant with JVC’s products, different remote control codes can be specified for those that are used with this unit.

Setting Values Description

REMOTE CONTROL 1 Sets remote control code to 1.

REMOTE CONTROL 2 Sets remote control code to 2.

REMOTE CONTROL 3 Sets remote control code to 3.

REMOTE CONTROL 4 Sets remote control code to 4.

CLOCK SET/DISPLAY

The current date/time and the display format on the screen can be specified using the “CLOCK SET”, “DATE DISPLAY”, and “TIME DISPLAY CHOICE” items.

Settings Menu

CLOCK SET

Sets the current date and time.

Memo:

For details on the setting procedures, refer to “Setting the date/time” (A page 20) .

DATE DISPLAY

For setting the date (year, month, and day) display format.

Setting Values Description

YEAR.MONTH.DAY Displays the date in the year/month/

day order.

MONTH.DAY.YEAR Displays the date in the month/day/

year order.

DAY.MONTH.YEAR Displays the date in the day/month/

year order.

TIME DISPLAY CHOICE

For setting the time display format.

Setting Values Description

12H Displays the time in AM/PM format.

24H Displays the time in 24-hour format.

PANEL DISPLAY BRIGHTNESS

The brightness of the display window can be specified using the “DIMMER (POWER ON)”, and “DIMMER (POWER OFF)” control items.

DIMMER (POWER ON)

For setting the brightness of the display window when the power is turned "On".

Setting Values Description

BRIGHT Bright

DIMMED1 Slightly dim

DIMMED2 Dim

DIMMED3 Dimmer

OFF Off

4'6740

2.#;$#%-5'66+0)

$&&8&8+&'12$5'66+0)

4'57/'

56+../1&'#761

5'#/.'552.#;$#%-

':+6

5'.'%6

5'672

Settings Menu

DIMMER (POWER OFF)

For turning on/off the light of the display window when the power is turned "Off".

Setting Values Description

OFF Turns off the light.

ON Turns on the light.

QUICK STARTUP

The quick startup setting can be specified as follows.

Setting

Values

Description

Playback Setting

OFF Starts up in the normal way.

ON Operation is speedily enabled after turning

on the power. (Quick start)

Memo:

Setting to “ON” increases power consumption while the unit is in the standby mode.

BUZZER OUTPUT

The buzzer setting can be specified as follows.

REMOTE CONTROL SENSOR TONE

For setting whether to sound the buzzer when the remote control sensor receives signals.

Setting

Description

Values

OFF Buzzer does not sound when the remote

control sensor receives signals.

ON Sounds the buzzer when the remote control

sensor receives signals.

ALERT/WARNING TONE

For setting whether to sound the buzzer when an operation is completed or when a warning message appears.

Setting Values Description

OFF Buzzer does not sound.

ON Sounds the buzzer.

DEFAULT SETTING

Restores the setting values on the setting screen to their factory default values.

Setting

Description

Values

YES Restores the factory default values.

NO Returns to the initial screen without

resetting the values.

Memo:

“BD-VIDEO RATINGS” and “COUNTRY CODE” settings cannot be reset once they have been specified.

BD-/DVD-VIDEO PB SETTING

BD-Video and DVD-Video playback settings can be specified using the “BD-VIDEO RATINGS”, “COUNTRY CODE”, “AUDIO LANGUAGE”, “SUBTITLE LANGUAGE”, and “MENU LANGUAGE” items.

BD-VIDEO RATINGS For setting the lower age limit for BD-Video ratings.

Setting Values Description

NO LIMIT All BD-Videos can be viewed.

254YEAR(S)0YEAR(S)

BD-Videos that are subject to the age limit cannot be viewed.

Memo:

In order to set the restrictions, password (four-digit

number) registration is required.

The password status becomes unregistered if the

restriction setting is disabled. A new password can be

registered after setting the age limit again.

It is recommended that you note down the password in

case it is lost or forgotten.

COUNTRY CODE For setting the country code.

For details on the country codes, refer to the “Country Code List” (A page 96) .

Memo:

If the “BD-VIDEO RATINGS” setting is specified, you will

be required to enter the password registered for the “BD-

VIDEO RATINGS” in order to change the “COUNTRY

CODE”.

AUDIO LANGUAGE For setting the audio sound when playing back BD-Videos

or DVD-Videos. For details on the language codes, refer to the “Language Code List” (A page 94) .

SUBTITLE LANGUAGE For setting the subtitle language when playing back BD-

Videos or DVD-Videos. For details on the language codes, refer to the “Language Code List” (A page 94) .

MENU LANGUAGE For setting the menu language when playing back BD-

Videos or DVD-Videos. For details on the language codes, refer to the “Language Code List” (A page 94) .

4'6740

4'%14&

:2/1&'4'%14&+0)#7&+1

&QND[&KIKVCN

*+)*52''&&7$$+0)

':+6

5'.'%6

5'672

Settings Menu

RESUME

The stop position can be stored when playback of a BDVideo, DVD-Video, BDMV, AVCHD, finalized discs, or SD card is stopped halfway.

Setting Values Description

OFF Resume information is not stored.

ON Stores resume information.

Memo:

Resume information is stored at all times for other discs as well as the HDD regardless of this setting.

When a HDD title is selected using Playback Navigation, it is played back from the beginning.

Some discs do not allow playback from the resume point.

STILL MODE

For setting the method for displaying paused images during playback of the HDD or a disc.

Setting

Description

Values

AUTO Automatic control.

FIELD Use this setting for moving images or when

there is blurring in the “AUTO” mode.

FRAME Use this setting when detailed patterns or

designs are not clear in the “AUTO” mode.

Memo:

This setting is disabled for programs in the DR mode and during playback of AVCHD videos.

SEAMLESS PLAYBACK

For setting the method for playing back partially erased scenes.

Setting Values Description

OFF Plays back with high accuracy.

ON Plays back smoothly.

Memo:

SD picture quality is retained during re-encode dubbing.

For joints of scenes that are 15 seconds or shorter, seamless playback may fail even when it is set to “ON”. The same applies during re-encode dubbing in the SD picture quality.

Record

XP MODE RECORDING AUDIO

For changing the settings of audio mode during recording in the XP mode.

Setting Values Description

Dolby Digital Records in “Dolby Digital”.

LPCM Records in “LPCM”.

HIGH-SPEED DUBBING

Items under “VIDEO MODE RECORDING ASPECT” and “DISC RECORDING AUDIO” can be set to support highspeed dubbing.

VIDEO MODE RECORDING ASPECT

For setting the aspect ratio during recording.

Setting

Values

AUTO Performs recording in the aspect ratio

setting when recording starts.

4:3 Records at the fixed aspect ratio of 4:3.

16:9 Records at the fixed aspect ratio of 16:9.

Memo:

High-speed dubbing to a DVD-Video disc cannot be performed when there are different aspect ratios in a title. In this case, fix the aspect ratio to 4:3 or 16:9. This setting remains valid during re-encode dubbing.

For details on high-speed dubbing and re-encode dubbing, refer to the “Dubbing chart” (A page 24) .

Description

4'6740

#7&+1

&;0#/+%4#0)'%10641.

&190/+:

56'4'1

&+)+6#.176

&8+0#7&+15'66+0)

56'4'1

$&/+:5170&

':+6

5'672

5'.'%6

Settings Menu

DISC RECORDING AUDIO

For changing the settings of audio to be recorded to the disc when in the AF, AN, AE or AL mode.

Setting

Description

Values

AUTO Records “Stereo”, “Surround” or “Dual

broadcast” audio sounds as they are.

FIXED Records “Stereo” and “Surround” sounds in

“Stereo”. “Dual broadcast” audio sounds are recorded as they are.

Memo:

Surround sounds of a title become stereo sounds when reencode dubbing is performed.

Audio

DIGITAL OUT

Set this item according to the device connected to the digital audio output terminal (optical digital).

PCM DOWN SAMPLING

For specifying settings on sampling frequency conversion.

Setting

Description

Values

OFF Sampling frequency is not converted.

ON Audio recorded at a sampling frequency of

96 kHz or 88.2 kHz is converted to 48 kHz and 44.1 kHz respectively.

Memo:

Setting to “OFF” may produce the same effects as the “ON” mode for some discs.

Dolby Digital

For setting audio output to “BITSTREAM” or “PCM”.

Setting Values Description

BITSTREAM Use this setting when connecting a

device that is able to decode “Dolby Digital”.

DYNAMIC RANGE CONTROL

For setting the dynamic range compression ratio (ratio between the maximum and minimum volume) during Dolby Digital playback.

Setting Values Description

AUTO Perform compression only for Dolby

TrueHD.

OFF Not compressed.

ON Perform maximum compression.

Memo:

Setting to “OFF” may produce the same effects as the “ON” mode for some discs.

Performing compression allows even the slightest sound to be heard clearly.

There may be differences in the effect depending on the disc used.

DOWN MIX

For setting whether to output analog audio.

Setting Values Description

PCM Audio input will be changed and output as

“PCM”. Use this setting when connecting a device that is unable to decode “Dolby Digital”.

Dolby Digital Plus/TrueHD

For setting audio output to “BITSTREAM” or “PCM”.

Setting

Description

Values

BITSTREAM Use this setting when connecting a

device that is able to decode “Dolby Digital Plus/TrueHD”.

PCM Audio input will be changed and output as

“PCM”. Use this setting when connecting a device that is unable to decode “Dolby Digital Plus/TrueHD”.

DTS

For setting audio output to “BITSTREAM” or “PCM”.

Setting Values Description

BITSTREAM Use this setting when connecting a

device that is able to decode “DTS”.

PCM Audio input will be changed and output as

“PCM”. Use this setting when connecting a device that is unable to decode “DTS”.

STEREO Use this setting when connecting an

audio amplifier or TV.

DOLBY SURROUND

Use this setting when connecting an amplifier that supports Dolby Surround.

4'6740

&+52.#;

105%4''0)7+&'#761

$.7'$#%-10

105%4''05#8'4

15&.#0)7#)''0).+5*

':+6

5'.'%6

5'672

DTS-HD

For setting audio output to “BITSTREAM” or “PCM”.

Setting Values Description

BITSTREAM Use this setting when connecting a

device that is able to decode “DTS-HD”.

PCM Audio input will be changed and output as

“PCM”. Use this setting when connecting a device that is unable to decode “DTS-HD”.

AAC

For setting audio output to “BITSTREAM” or “PCM”.

Setting Values Description

BITSTREAM Use this setting when connecting a

device that is able to decode “AAC”.

PCM Audio input will be changed and output as

“PCM”. Use this setting when connecting a device that is unable to decode “AAC”.

Memo:

Audio sound may not be properly played back if the audio equipment in use does not support “BITSTREAM” output. In this case, set to “PCM”.

DV IN AUDIO SETTING

For changing the audio recording settings during DV input.

Setting Values Description

STEREO 1 Records the audio sound during video

recording (L1, R1).

STEREO 2 Records audio sound that is added later

(L2, R2), such as during editing.

MIX Records “STEREO 1” and “STEREO 2”

sounds.

BD MIX SOUND

For setting a mixture of BD video secondary audio and operation sounds output.

Setting

Values

Description

Settings Menu

Display

ON SCREEN GUIDE

For displaying operation details.

Setting Values Description

AUTO Appears for five seconds when an

operation is performed.

OFF Not displayed.

BLUE BACK

For setting the screen display when there is no signal input.

Setting Values Description

OFF Displays screen as it is.

ON Switches display to a blue screen.

SCREEN SAVER

For setting whether to use a screensaver.

Setting Values

OFF Screen saver is not used.

ON Screen saver is used. Switches to the burn-

in prevention screen when the unit is not operated for more than five minutes.

OSD LANGUAGE

For setting the language for messages displayed on-screen.

Description

OFF Outputs main audio only.

ON Outputs a mixture of BD video secondary

audio and operation sounds during playback of BD-Videos that contain BD video secondary audio and menu operation sounds.

Memo:

Output is converted to Dolby Digital or DTS according to the main audio when the “DIGITAL OUT” item is set to “BITSTREAM”.

4'6740

%100'%6+10

*&/+%100'%6+10

1((

%1/210'06176276

':+6

5'.'%6

K

8+&'1+02765'66+0)8+&'1

5'672

/10+6146;2'

*&/+%'%

Settings Menu

Connection

HDMI OUTPUT RESOLUTION

Setting

Description

Values

AUTO Automatically selects an appropriate

resolution according to the connected device.

480p Fixes the resolution at 480p.

1080i Fixes the resolution at 1080i.

720p Fixes the resolution at 720p.

1080p Fixes the resolution at 1080p.

MONITOR TYPE

For setting the aspect ratio according to the connected monitor.

Setting Values Description

16:9 Set to this value when connected to

monitors with 16:9 aspect ratio.

16:9FULL Choose this setting when a 16:9 monitor

is connected to display images without the black borders.

4:3 PAN&SCAN Set to this value when connecting to

monitors with an aspect ratio of 4:3. Plays back videos with the left and right edges trimmed off.

4:3 LETTERBOX

Set to this value when connecting to monitors with an aspect ratio of 4:3. Plays back videos with a black band at the upper and lower ends.

HDMI CONNECTION

VIDEO PRIORITY MODE

Setting Values Description

COMPONENT Set to this value for output at a resolution

of “480p” or higher from the [COMPONENT VIDEO OUT] terminal.

HDMI Set to this value when priority is to be

given to the “HDMI OUTPUT RESOLUTION” setting.

Memo:

During data output from the [HDMI] terminal, setting to “COMPONENT” automatically outputs data in the “COMPONENT OUTPUT” setting. Setting to “HDMI” outputs data in the “HDMI OUTPUT RESOLUTION” setting.

During data output from the [HDMI] and [COMPONENT VIDEO OUT] terminals, setting to “COMPONENT” automatically outputs data in the “COMPONENT OUTPUT” setting. Setting to “HDMI” outputs data at the “480i” resolution from the [COMPONENT VIDEO OUT] terminal.

When there is no output from the [HDMI] terminal, data is automatically output in the “COMPONENT OUTPUT” setting from the [COMPONENT VIDEO OUT] terminal.

Memo:

When the resolution is set to “720p”, videos are output at “1080i” other than those recorded at “720p” even though “720p” is shown on the display.

Depending on the conditions (monitor type 16:9,resolution “720p” and above, aspect 4:3), some of the OSD display of the component output may be cut off. In this case, set “VIDEO PRIORITY MODE” to “COMPONENT”. OSD of the [VIDEO OUT]/[S-VIDEO OUT] terminals may be cut off with the above conditions even when “COMPONENT” is selected. In this case, set the component resolution to “480p” or below, or set the monitor type to other settings except 16:9.

BD-VIDEO 24p OUT

Setting

Description

Values

OFF Outputs in the resolution set by “HDMI

OUTPUT RESOLUTION”.

ON Outputs 24p elements at 24p.

Memo:

24p playback is possible for commercially available BDVideos or BDMVs that are recorded in 24p. Content other than BDMVs that is dubbed or recorded on this unit at 24p, as well as 24p content on SD cards are played back at 60p or 60i.

This is applicable for BD-ROM and DVD-Video titles. This is available when connected to a 24p compatible monitor.

Elements other than 24p ones are output at 60p.

No video images will be output from the video, S-video and component outputs when the HDMI output resolution is at 1080/24p.

x.v.Color

Setting

Description

Values

AUTO Outputs x.v.Color information with HDMI

when video images that include x.v.Color information are played back.

OFF This is applicable when an x.v.Color

compatible monitor is connected.

Memo:

This is applicable when an x.v.Color compatible monitor is connected.

Deep Color

Setting

Values

Description

Settings Menu

HDMI-CEC

For setting the HDMI-CEC operation from the connected device.

Setting Values Description

OFF Disables HDMI-CEC.

ON Enables HDMI-CEC.

COMPONENT OUTPUT

For setting the resolution of video output from the [COMPONENT VIDEO OUT] terminals.

Setting Values Description

480i Sets output to “480i”.

480p Sets output to “480p”.

AUTO Set to this value when a “Deep Color” device

is connected.

OFF Set to this value when the video image is

distorted, or colors are unnatural.

HDMI RGB OUTPUT RANGE

Setting Values Description

STANDARD Set to this value for standard uses.

ENHANCED Set to this value when the black and

white parts of the video image are not distinct.

Memo:

This is available when connected to a DVI device that only supports RGB input.

HDMI --> DVI COLOR

Setting

Description

Values

AUTO Value is set automatically according to the

monitor.

RGB FIX Use this setting when video images are not

correctly displayed on the monitor.

Memo:

This is available when the “x.v.Color” setting is set to “OFF”. When the “x.v.Color” setting is set to “AUTO”, this setting will be set to “AUTO” automatically.

Change this setting when no video image appears while connected to a DVI device.

HDMI AUDIO OUTPUT

Setting Values

Description

720p Sets output to “720p”.

1080i Sets output to “1080i”.

Memo:

When the resolution is set to “720p”, videos are output at “1080i” other than those recorded at “720p” even though “720p” is shown on the display.

This unit does not support component output at “1080p”. To output at “1080p”, do so via HDMI connection.

If “VIDEO PRIORITY MODE” is set to “HDMI”, the unit will output at “480i” regardless of the current setting.

If “VIDEO PRIORITY MODE” is set to “COMPONENT”, or when a HDMI connection is used, DVD videos will be output at “480p” even if “720p” or “1080i” has been set.

The aspect ratio of video/S-video output changes according to the component output setting. As such, there may be cases where the aspect ratio of the video/S-video output is different from the predefined setting of the content.

VIDEO INPUT SETTING

Choose a setting according to the video terminal to be connected when an external analog input terminal is used.

Setting

Values

VIDEO Use this setting when connecting via the

video (BNC) terminal.

S-VIDEO Use this setting when connecting via the

S-video (black) terminal.

Description

OFF Use this setting if you do not want to send

audio output from the HDMI cable.

ON Use this setting to send audio output from

the HDMI cable.

Press the " " button for five seconds or longer

Others

Locking the Disc Tray

By turning on the lock for the disc tray, the tray cannot be opened or closed using the [M] button.

Memo:

When the [M] button is pressed while the disc tray lock is turned on, a “LOCKED” message will appear on the display window of the unit for about three seconds.

Locking the disc tray

Press the [A] button on the unit to turn “Off” the power

Press and hold the [o] button on this unit, then press the [M] button

A “LOCKED” message appears on the display window of the unit, indicating that the disc tray is locked.

Turning on the Mode Lock

Turning on the mode lock disables all operations using the buttons on the unit and remote control, except for “Play” and “Record”.

Memo:

When a button that is disabled is pressed, a “LOCKED” message will appear on the display window of the unit for three seconds.

Turning on the mode lock

Press the [Z] button on the remote control for five seconds or longer when in the “Normal Recording”, “Stop”, or “Normal Playback” mode

A “LOCKED” message appears on the display window of the unit, indicating that the mode lock is turned on.

Unlocking the disc tray

Press the [A] button on the unit to turn “Off” the power

Press and hold the [o] button on this unit, then press the [M] button

An “UNLOCK” message appears on the display window of the unit, indicating that the disc tray is unlocked.

Turning off the mode lock

Press the [Z] button on the remote control for five seconds or longer when the mode lock is turned on

An “UNLOCK” message appears on the display window of the unit, indicating that the mode lock is turned off.

Last Function Memory

When the power plug is disconnected from unit or when power failure occurs, your settings for the following functions are kept in the memory. These settings will resume when the unit is turned on again.

Various setting menus (A Page 74 - 81)

Deck selection: HDD/BD/SD

Recording mode: XP, etc. (A page 28)

Input selection: L-1/DV (A page 47)

Repeat playback of the disc playback settings menu (A page 56) Kept for DVD-Video/AVCHD/BDMV and title/chapter only.

RS-232C Interface (only for

Lower Order Higher Order

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 Complete Error Cassette

Out

Not Target

ACK NAK

3 Play Stop

4 Still

5 Clear

6 Sense

Chapter

Title Sense

8 Chapter

Title Search

Date Preset

Clock Preset

9 Finalize

CancelDisc Finalization

Disc Erase

TOP MENU

MENU NEXT

CHAPTER

PREV CHAPTER

Setup SET UP DOWN RIGHT LEFT Next

Title

Prev Title

Remote Data

A StandbyOnStandby

Off

Eject FF REW Fwd

Field Step

Rev Field Step

B Fwd Shtl Rev Shtl Select

Preset

Select Sense

Date Data Sense

Clock Data Sense

C Rec

D Status

Sense

Tc Data Sense

CTL Data Sense

JVC Status Sense

F Command

Target

Rec/Dub Request

D6 D7D4 D5D2 D3D0 D1

Starting bit

Stopping bit

Parity check

SR-HD1500)

Command Table

only for SR-HD1500

Others

Specifications

Pin layout

Mode : Non-synchronous

Character length : 8 bits

Parity check : Odd

Start bit : 1

PIN No. Signal Operation Direction of signal

2 TxD Transmit data This unit h PC

3 RxD Receive data This unit i PC

5 GND Signal grounding

Memo:

When using the Serial Command Connector, the cable to be used should be a RS-232C interface cable (straight type, 3 m or shorter).

When using RS-232C, set “QUICK STARTUP” in the settings menu to “ON”.

During command transmission, a minimum interval of About 50 milliseconds is required between each command.

During command transmission, do not send the next command until the ACK (refer to “System Commands” (A page 90) ) or response (refer to “Response Commands” (A page 90) ) for each command is received.

The recommended maximum waiting time for the ACK or response for each command is as follows.

ACK : About 50 milliseconds

Response : About 5 seconds

Stop bit : 1

Data rate : 9600 bps

Bit configuration

Others

Command

Operation Commands

Commands for operating functions such as PLAY and REC on the BLU-RAY DISC & HDD RECORDER

Command Description

A1 Power Off

3A Plays the selected deck.

3F Stops the selected deck. Resume will be

cleared when this is pressed while in the Stop mode. Rec Request will be cleared.

4F Switches the selected deck to the Still mode.

56 Clear: Clears the Error status.

80 Searches the specified chapter and starts

playback from the beginning.

81 Searches the specified title under “ORIGINAL”

or in the “PLAY LIST” by its number and starts playback from the beginning.

8E For setting the date.

8F For setting the time.

90 Finalizes the disc. (BD Deck)

91 Cancels disc finalization. (BD Deck)

92 For erasing rewritable discs.

93 Displays/Closes the top menu of a disc. (BD

Deck)

94 Displays/Closes the disc menu. (BD Deck)

95 Advances to the next chapter. Functions like

the T button on the remote control.

96 Returns to the previous chapter. Functions

like the S button on the remote control.

97 Displays/Closes the Main Menu, Editing,

Library Database Navigation or Dubbing screen. 97 h 30: Closes the screen. 97 h 31: Displays the Main Menu screen. 97 h 32: Displays the Library Database Navigation screen. 97 h 35: Displays the Editing screen. 97 h 37: Displays the Dubbing screen.

98 Functions as a confirmation key.

99 Functions as an up key.

A3 Eject: Opens/Closes tray. (BD Deck only)

AB FF: Functions only during playback. Activates

forward search.

AC REW: Functions only during playback.

Activates reverse search.

AD Functions as a key for advancing (FWD) a

frame. When this command is received during still mode, the unit advances the still picture by one frame (or field) in the FWD direction.

AE Functions as a key for reversing (REV) a

frame. When this command is received during still mode, the unit reverses the still picture by one frame (or field) in the REV direction.

B5 Fwd Shtl: Functions only during playback.

Activates forward search. B5 h 30: STILL B5 h 31: FWD SLOW at a slow speed. B5 h 33: FWD SLOW at a fast speed. B5 h 35: 1x B5 h 36: FWD SEARCH at a fast speed. B5 h 37: FWD SEARCH at a faster speed. B5 h 38: FWD SEARCH at the fastest speed.

B6 Rev Shtl: Functions only during playback.

Activates reverse search. B6 h 30: STILL B6 h 31: REV SLOW at a slow speed. B6 h 33: REV SLOW at a fast speed. B6 h 36: REV SEARCH at a fast speed. B6 h 37: REV SEARCH at a faster speed. B6 h 38: REV SEARCH at the fastest speed.

B8 For setting the input/output, recording mode,

audio language selection and subtitle selection.

CA Rec: Starts recording at the selected deck

when a Rec Request is received.

F0 Command Target:

F0 h 34: For selecting HDD deck. F0 h 38: For selecting BD deck. F0 h 3C: For selecting SD deck.

9A Functions as a down key.

9B Functions as a right key.

9C Functions as a left key.

9D Advances to the next title. Functions like the

T button on the remote control.

9E Returns to the previous title. Functions like the

S button on the remote control.

9F Issues the same codes as the wired remote

control via RS-232C.

A0 Power On

FA Rec Request: For issuing approval for

recording. This can be cleared using STOP.

Others

80-8F

80 : Chapter Search

1st Byte 2nd Byte 3rd Byte

Chapter Search Hundreds Tens Ones

ASCII codes (30 - 39) 3* 3* 3*

E.g. (012) 30 31 32

E.g. : When searching the 12th chapter.

81 : Title Search under “ORIGINAL”

1st Byte 2nd Byte 3rd Byte 4th Byte

Title Search (ORIGINAL) 30 Hundreds Tens Ones

ASCII codes (30 - 39) 30 3* 3* 3*

E.g. (345) 30 33 34 35

E.g. : When searching the 345th title, as indicated by the title number on the top right corner of the index, under “ORIGINAL”.

81 : Title Search in “PLAY LIST”

1st Byte 2nd Byte 3rd Byte 4th Byte

Title Search (PLAY LIST) 38 Hundreds Tens Ones

ASCII codes (30 - 39) 38 3* 3* 3*

E.g. (028) 38 30 32 38

E.g. : When searching the 28th play list, as indicated by the play list number on the top right corner of the index, in the “PLAY

LIST”.

8E : Date Preset

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte

Date Preset Mth (Tens) Mth (Ones) Day (Tens) Day (Ones) Yr (Tens) Yr (Ones)

ASCII code (30 - 39) 3* 3* 3* 3* 3* 3*

E.g. (09.14.2009) 30 39 31 34 30 39

E.g. : When setting the date to September 14 2009.

8F : Clock Preset

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte

Clock Preset Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones)

ASCII code (30 - 39) 3* 3* 3* 3* 3* 3*

E.g. (12:34:56) 31 32 33 34 35 36

E.g. : When setting the time to 12 hrs 34 min and 56 sec.

Others

9F : Remote Data

The remote control codes for controlling the wired remote controller via RS-232C is as shown in the following table. The codes apply to all three HDD, BD and SD deck unless otherwise stated.

Code Items Remarks

81 MENU BD/DVD Deck only

01 INPUT SELECT

03 STOP

06 F.F/SPEED+

07 REW/SPEED-

0B POWER ON/OFF

0C PLAY

0D PAUSE/STILL

14 FWD SKIP

15 REV SKIP

17 AUDIO

1A Power Off

1D Power On Use with “QUICK

STARTUP” set to “ON”. Refer to “QUICK STARTUP” (A page 76) .

21 TEN KEY 1

22 TEN KEY 2

23 TEN KEY 3

82 CUSOR 90° Moves the arrow in the

index list to the up. (J)

84 CUSOR 180° Moves the arrow in the

index list to the left. (H)

86 CUSOR 270° Moves the arrow in the

index list to the down. (K)

87 OPEN/CLOSE BD/DVD Deck only

8E PROGRESSIVE HDD/BD Deck only

8F TOP MENU DVD Deck only

90 MARK HDD/DVD Deck only

96 CM SKIP

AF REV FRAME

B0 -SLOW D

B1 SHUTTLE-C

B2 SHUTTLE-B

B3 SHUTTLE-A

B4 SHUTTLE-2

B5 SHUTTLE-1

24 TEN KEY 4

25 TEN KEY 5

26 TEN KEY 6

27 TEN KEY 7

28 TEN KEY 8

29 TEN KEY 9

2A KEY Z

2B TEN KEY 0

2C KEY #

31 REC MODE (XP/SP/LP/

EP…)

32 BD/DVD DECK

34 DUBBING

37 SET UP

3C OK/ENTER

3E ON SCREEN

44 HDD DECK

48 MEDIA MANAGEMENT

80 CUSOR 0° Moves the arrow in the

index list to the right. (I)

B6 -SLOW B

B7 -SLOW C

B8 +SLOW C

B9 +SLOW B

BA SHUTTLE +1

BB SHUTTLE +2

BC SHUTTLE +A

BD SHUTTLE +B

BE SHUTTLE +C

BF +SLOW D

C0 ANGLE/LIVE CHECK ANGLE (BD/DVD Deck

only) LIVE CHECK (HDD/BD Deck only)

C4 SUBTITLE DVD Deck

only

CC REC

D4 RETURN

D5 COLOR KEY BLUE

D7 COLOR KEY RED

D9 JOG-1/6

Others

DA JOG +1/6

DB JOG +1

DC INSTANT REPLAY

DD EDIT

DE COLOR KEY GREEN

DF COLOR KEY YELLOW

E0 NAVIGATION

E1 L1 Y/C INPUT SELECT HDD Deck only

B8 : Input/Output Selection

1st Byte 2nd Byte

External input selection L-1 VIDEO 30 31

External input selection L-1 S-VIDEO 30 39

External input selection DV 30 34

B8 : Recording Mode Selection

1st Byte 2nd Byte

XP 34 30

E2 L1 COMPOSITE INPUT

SELECT

E3 PLAYBACK SETTING

E4 DELETE

E5 INFORMATION

CORRECT

ED FWD FRAME

F2 MODE LOCK

HDD Deck only

SP 34 31

LP 34 32

EP 34 33

DR 34 3A

AF 34 3B

AN 34 3C

AL 34 3D

AE 34 3E

Others

Subtitle Selection

B8 : Subtitle Selection

1st

Byte

OFF 3C 10 EL 3C 31 LO 3C 56 SL 3C 78

JAPANESE 3C 11 EO 3C 32 LT 3C 57 SM 3C 79

ENGLISH 3C 12 ET 3C 33 LV 3C 58 SN 3C 7A

GERMAN 3C 13 EU 3C 34 MG 3C 59 SO 3C 7B

FRENCH 3C 14 FA 3C 35 MI 3C 5A SQ 3C 7C

ITALIAN 3C 15 FJ 3C 36 MK 3C 5B SR 3C 7D

SPANISH 3C 16 FO 3C 37 ML 3C 5C SS 3C 7E

DUTCH 3C 17 FY 3C 38 MN 3C 5D ST 3C 7F

SWEDISH 3C 18 GA 3C 39 MO 3C 5E SU 3C 80

NORWEGIAN 3C 19 GD 3C 3A MR 3C 5F SW 3C 81

FINNISH 3C 1A GL 3C 3B MS 3C 60 TA 3C 82

DANISH 3C 1B GN 3C 3C MT 3C 61 TE 3C 83

2nd

Byte

1st

Byte

2nd

Byte

1st

Byte

2nd

Byte

1st

Byte

2nd

Byte

AA 3C 1C GU 3C 3D MY 3C 62 TG 3C 84

AB 3C 1D HA 3C 3E NA 3C 63 TH 3C 85

AF 3C 1E HI 3C 3F NE 3C 64 TI 3C 86

AM 3C 1F HR 3C 40 OC 3C 65 TK 3C 87

AR 3C 20 HU 3C 41 OM 3C 66 TL 3C 88

AS 3C 21 HY 3C 42 OR 3C 67 TN 3C 89

AY 3C 22 IA 3C 43 PA 3C 68 TO 3C 8A

AZ 3C 23 IE 3C 44 PL 3C 69 TR 3C 8B

BA 3C 24 IK 3C 45 PS 3C 6A TS 3C 8C

BE 3C 25 IS 3C 47 PT 3C 6B TT 3C 8D

BG 3C 26 KA 3C 4B QU 3C 6C TW 3C 8E

BH 3C 27 KK 3C 4C RM 3C 6D UK 3C 8F

BI 3C 28 KL 3C 4D RN 3C 6E UR 3C 90

BN 3C 29 KM 3C 4E RO 3C 6F UZ 3C 91

BO 3C 2A KN 3C 4F RU 3C 70 VI 3C 92

BR 3C 2B KO 3C 50 RW 3C 71 VO 3C 93

CA 3C 2C KS 3C 51 SA 3C 72 WO 3C 94

CO 3C 2D KU 3C 52 SD 3C 73 XH 3C 95

CS 3C 2E KY 3C 53 SG 3C 74 YO 3C 96

CY 3C 2F LA 3C 54 SI 3C 76 ZH 3C 97

DZ 3C 30 LN 3C 55 SK 3C 77 ZU 3C 98

“Language Code List” (A page 94)

Others

Audio Language Selection

B8 : Audio Language Selection

1st

Byte

JAPANESE 39 11 EO 39 32 LT 39 57 SM 39 79

ENGLISH 39 12 ET 39 33 LV 39 58 SN 39 7A

GERMAN 39 13 EU 39 34 MG 39 59 SO 39 7B

FRENCH 39 14 FA 39 35 MI 39 5A SQ 39 7C

ITALIAN 39 15 FJ 39 36 MK 39 5B SR 39 7D

SPANISH 39 16 FO 39 37 ML 39 5C SS 39 7E

DUTCH 39 17 FY 39 38 MN 39 5D ST 39 7F

SWEDISH 39 18 GA 39 39 MO 39 5E SU 39 80

NORWEGIAN 39 19 GD 39 3A MR 39 5F SW 39 81

FINNISH 39 1A GL 39 3B MS 39 60 TA 39 82

DANISH 39 1B GN 39 3C MT 39 61 TE 39 83

AA 39 1C GU 39 3D MY 39 62 TG 39 84

2nd

Byte

1st

Byte

2nd

Byte

1st

Byte

2nd

Byte

1st

Byte

2nd

Byte

AB 39 1D HA 39 3E NA 39 63 TH 39 85

AF 39 1E HI 39 3F NE 39 64 TI 39 86

AM 39 1F HR 39 40 OC 39 65 TK 39 87

AR 39 20 HU 39 41 OM 39 66 TL 39 88

AS 39 21 HY 39 42 OR 39 67 TN 39 89

AY 39 22 IA 39 43 PA 39 68 TO 39 8A

AZ 39 23 IE 39 44 PL 39 69 TR 39 8B

BA 39 24 IK 39 45 PS 39 6A TS 39 8C

BE 39 25 IS 39 47 PT 39 6B TT 39 8D

BG 39 26 KA 39 4B QU 39 6C TW 39 8E

BH 39 27 KK 39 4C RM 39 6D UK 39 8F

BI 39 28 KL 39 4D RN 39 6E UR 39 90

BN 39 29 KM 39 4E RO 39 6F UZ 39 91

BO 39 2A KN 39 4F RU 39 70 VI 39 92

BR 39 2B KO 39 50 RW 39 71 VO 39 93

CA 39 2C KS 39 51 SA 39 72 WO 39 94

CO 39 2D KU 39 52 SD 39 73 XH 39 95

CS 39 2E KY 39 53 SG 39 74 YO 39 96

CY 39 2F LA 39 54 SI 39 76 ZH 39 97

DZ 39 30 LN 39 55 SK 39 77 ZU 39 98

EL 39 31 LO 39 56 SL 39 78

“Language Code List” (A page 94)

Others

Response Commands

Commands relating to RS-232C control system.

Command Description

01 Complete: Issued by the external recorder upon completing all specified operations by commands.

02 Error: Issued by the external recorder when receiving invalid commands in the context. In such cases,

commands that are sent will not be accepted. However, a return command will be issued but only to the Status Sense. To clear the Error status, perform command 56 (Clear).

05 Not Target: Issued by the external recorder when specified operations by commands cannot be completed

properly.

0A ACK: A return command issued when a defined command is received.

0B NAK: A return command issued when an undefined or possibly nonexistent command is received.

03 Cassette Out: Issued upon completing the operation of opening and closing the tray when the HDD/DVD deck

is selected.

System Commands

Commands for acquiring information such as deck status.

Command Description

60 Chapter Sense: For acquiring the current chapter number. (*)

61 Title/Track Sense: For acquiring the current title number under “ORIGINAL” or in the “PLAY LIST”. (*)

B9 Select Sense: For acquiring the status of the inputs, outputs, recording mode, audio language selection and

subtitle selection. (*)

BE Date Sense: For acquiring the currently configured year, month and day. (*)

BF Time Sense: For acquiring the currently configured hour, minute and second. (*)

D7 Status Sense: For acquiring the deck information. (*)

D8 TC Data Sense: For acquiring the total remaining time in the current recording mode when there is a media in

the selected deck. (*)

D9 CTL Data Sense: For acquiring the lapse counter when there is a media in the selected deck. (*)

DD JVC Status Sense: Returns data from the unit. (*)

FB VTR Ind: A command for checking whether the connected device is the external recorder.

(*) : See A pages 90-93 for data format.

Sense

Chapter Sense

1st Byte 2nd Byte 3rd Byte

Chapter Sense Hundreds Tens Ones

60 3* 3* 3*

E.g. (012) 30 31 32

E.g. : When the current chapter is the 12th chapter.

Title/Track Sense under “ORIGINAL”

1st Byte 2nd Byte 3rd Byte 4th Byte

Title/Track Sense (ORIGINAL) 30 Hundreds Tens Ones

61 30 3* 3* 3*

E.g. (345) 30 33 34 35

E.g. : When the current title under “ORIGINAL” is the 345th title.

Title/Track Sense in “PLAY LIST”

1st Byte 2nd Byte 3rd Byte 4th Byte

Title/Track Sense (PLAY LIST) 38 Hundreds Tens Ones

61 38 3* 3* 3*

E.g. (028) 38 30 32 38

E.g. : When the current title under “PLAY LIST” is the 28th title.

Select Sense

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte

Others

Select Sense External input

selection

Output selection Recording mode

selection

Audio language selection

B9 3* 3* ** ** **

E.g. (3930311213) 39 30 31 12 13

E.g. : When the selection status of the video deck is as follows: External input selection h L-1 S-VIDEO

Output selection h Common output (Frame is fixed at 0.) Recording mode selection h SP Audio language selection h ENGLISH Subtitle selection h GERMAN For response data for B9, see data format for “B8 (Select Preset)” (A page 87-89). When the current status cannot be acquired, the value is fixed as “-” (0x2D).

Date Data Sense

For acquiring the currently configured year, month and day in ASCII codes.

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte

Date Sense Mth (Tens) Mth (Ones) Day (Tens) Day (Ones) Yr (Tens) Yr (Ones)

BE 3* 3* 3* 3* 3* 3*

E.g. (09.14.2009) 30 39 31 34 30 39

When the current date is not set, the value is fixed as “-” (0x2D).

Time Data Sense

For acquiring the currently configured hour, minute and second in ASCII codes.

Subtitle selection

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte

Time Sense Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones)

BF 3* 3* 3* 3* 3* 3*

E.g. (12:34:56) 31 32 33 34 35 36

When the current time is not set, the value is fixed as “-” (0x2D).

Others

Status Data Sense

For acquiring the remaining time in the current recording mode in hours, minutes and seconds for HDD/DVD.

STATUS

SENSE

bit7 1 (Fixed) 1 (Fixed) 1 (Fixed) Video EE 0 (Fixed) During PLAY During PAUSE (Set

bit6 0 (Fixed) 1 (Fixed) 1 (Fixed) Audio EE 0 (Fixed) 0 (Fixed) 0 (Fixed)

bit5 0 (Fixed) 0 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) During Reverse

bit4 Record

bit3 Disc Not

bit2 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) During

1byte 1byte 1byte 2byte 3byte 4byte 5byte

HDD BD SD HDD/BD/SD HDD/BD/SD HDD/BD/SD HDD/BD/SD

to 1 simultaneously with “During PLAY” in STILL mode.)

Shuttle Search (Excluding STILL)

Forbidden

Inserted

Record Forbidden

Disc Not Inserted

1 (Fixed) 0 (Fixed) 0 (Fixed) During

STOP

Disc Not Inserted

Occurrence of abnormality in VTR

0 (Fixed) During

STANDBY (Unit Power Off)

0 (Fixed) Refer to the Repeat Playback (Including PAUSE)

During Forward Shuttle Search (Excluding STILL)

Refer to the SEARCH SPEED table.

SEARCH SPEED table.

bit1 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) During REC Refer to the

SEARCH SPEED table.

bit0 RS-232C

command error status. Clear using 56 (Clear).

TC Data Sense

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte 7th Byte 8th Byte

TC Data Sense Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones) Frame (Tens) Frame (Ones)

D8 3* 3* 3* 3* 3* 3* 3* 3*

E.g. (01:23:45) 30 31 32 33 34 35 30 30

E.g. : When remaining time is 1 hr 23 min 45 sec.

Frame is fixed as 0.

RS-232C command error status. Clear using 56 (Clear).

0 (Fixed) 0 (Fixed) 0 (Fixed) Refer to the

SEARCH SPEED table.

Others

SEARCH SPEED

bit3 bit2 bit1 bit0

STILL 0 0 0 0

x1 0 0 0 1

SEARCH1 0 1 0 0

SEARCH2 0 1 0 1

SEARCH3 0 1 1 0

SEARCH4 0 1 1 1

SEARCH5 1 0 0 0

CTL Data Sense

For acquiring lapse counter of selected deck in hours, minutes and seconds.

1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte 7th Byte 8th Byte

CTL Data Sense Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones) Frame (Tens) Frame (Ones)

D9 3* 3* 3* 3* 3* 3* 3* 3*

E.g. (01:23:45) 30 31 32 33 34 35 30 30

E.g. : When time lapse counter is 1 hr 23 min 45 sec.

Frame is fixed as 0.

JVC Status Sense

1byte 2byte 3byte 4byte

HDD/BD/SD HDD/BD/SD HDD/BD/SD HDD/BD/SD

bit7 1 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed)

bit6 0 (Fixed) 0 (Fixed) 0 (Fixed) 1 (Fixed)

bit5 0 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed)

bit4 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)

bit3 0 (Fixed) Refer to the DISC TYPE table below. 0 (Fixed) During dubbing (Including

PAUSE)

bit2 0 (Fixed) Refer to the DISC TYPE table below. 0 (Fixed) 0 (Fixed)

bit1 0 (Fixed) Refer to the DISC TYPE table below. 0 (Fixed) 0 (Fixed)

bit0 1 (Fixed) Refer to the DISC TYPE table below. During dubbing (Including

0 (Fixed)

PAUSE)

DISC TYPE

bit3 bit2 bit1 bit0 bit3 bit2 bit1 bit0

DVD 0 0 0 0 CD 0 1 1 1

DVD-RAM 0 0 0 1 BD-ROM 1 0 0 0

DVD-R 0 0 1 0 BD-R 1 0 0 1

DVD-RW 0 0 1 1 BD-RE 1 0 1 0

DVD+R 0 0 0 0 No disc 1 1 1 1

DVD+RW 0 0 0 0 Unknown 1 1 1 0

When SD deck is selected, the values are fixed as bit3:0, bit2:0, bit1:1 and bit0:0.

Others

Language Code List

Code Language Code Language Code Language

AA Afar HI Hindi OS Ossetian

AB Abkhazian HO Hiri Motu PA Panjabi

AF Afrikaans HU Hungarian FA Persian

AK Akan IG Igbo PI Pali

SQ Albanian IS Icelandic PL Polish

AM Amharic IO Ido PT Portuguese

AR Arabic II Sichuan Yi PS Pashto

AN Aragonese IU Inuktitut QU Quechua

HY Armenian IE Interlingue RM Rhaeto-Romance

AS Assamese IA Interlingua (International

Auxiliary language Association)

AV Avar ID Indonesian RN Kirundi

AE Avestan IK Inupiak RU Russian

AY Aymara IT Italian SG Sango

AZ Azerbaijani JV Javanese SA Sanskrit

BA Bashkir JA Japanese SR Serbia

BM Bambara KL Kalaallisut HR Croatian

EU Basque KN Kannada SI Sinhala

BE Belarusian KS Kashmiri SK Slovak

BN Bengali KR Kanuri SL Slovenian

BH Bihari KK Kazakh SE Northern Sami

BI Bislama KM Khmer SM Samoan

BS Bosnian KI Kikuyu SN Shona

BR Breton RW Kinyarwanda SD Sindhi

BG Bulgarian KY Kirghiz SO Somali

MY Burmese KV Komi ST Southern Sotho

RO Romanian

CA Catalan, Valencian KG Kongo ES Spanish

CH Chamorro KO Korean SC Sardinian

CE Chechen KJ Kwanyama SS Swati

ZH Chinese KU Kurukh SU Sundanese

CU Church Slavic LO Lao SW Swahili

CV Chuvash LA Latin SV Swedish

KW Cornish LV Latvian TY Tahitian

CO Corsican LI Limburgish TA Tamil

CR Cree LN Lingala TT Tatar

CS Czech LT Lithuanian TE Telugu

DA Danish LB Luxembourgish TG Tajik

DV Divehi LU Luba-Katanga TL Tagalog

NL Dutch LG Ganda TH Thai

DZ Dzongkha MK Macedonian BO Tibetan

EN English MH Marshallese TI Tigrinya

EO Esperanto ML Malayalam TO Tongan

ET Estonian MI Māori TN Tswana

EE Ewe MR Marathi TS Tsonga

FO Faroese MS Malay TK Turkmen

FJ Fijian MG Malagasy TR Turkish

FI Finnish MT Maltese TW Twi

FR French MO Moldavian UG Uighur

FY Western Frisian MN Mongolian UK Ukrainian

FF Fulah NA Nauruan UR Urdu

KA Georgian NV Navajo UZ Uzbek

DE German NR South Ndebele VE Venda

Others

GD Scottish Gaelic ND North Ndebele VI Vietnamese

GA Irish NG Ndonga VO Volapük

GL Galician NE Nepali CY Welsh

GV Manx NN Norwegian Nynorsk WA Walloon

EL Greek NB Norwegian Bokmål WO Wolof

GN Guaraní NO Norwegian XH Xhosa

GU Gujarati NY Chichewa YI Yiddish

HT Haitian OC Occitan YO Yoruba

HA Hausa OJ Ojibwa ZA Zhuang

HE Hebrew OR Oriya ZU Zulu

HZ Herero OM Oromo

Others

Country Code List

Code Country Name Code Country Name Code Country Name

AD Andorra GM Gambia NU Niue

AE United Arab Emirates GN Guinea NZ New Zealand

AF Afghanistan GP Guadeloupe OM Oman

AG Antigua and Barbuda GQ Equatorial Guinea PA Panama

AI Anguilla GR Greece PE Peru

AL Albania GS South Georgia and South Sandwich

Islands

AM Armenia GT Guatemala PG Papua New Guinea

AN Netherlands Antilles GU Guam PH Philippines

AO Angola GW Guinea-Bissau PK Pakistan

AQ Antarctica GY Guyana PL Poland

AR Argentina HK Hong Kong PM Saint Pierre and Miquelon

AS American Samoa HM Heard and McDonald Islands PN Pitcairn Islands

AT Austria HN Honduras PR Puerto Rico

AU Australia HR Croatia PT Portugal

AW Aruba HT Haiti PW Palau

AZ Azerbaijan HU Hungary PY Paraguay

BA Bosnia and Herzegovina ID Indonesia QA Qatar

BB Barbados IE Ireland RE Reunon Island

BD Bangladesh IL Israel RO Romania

BE Belgium IN India RU Russian Federation

BF Burkina Faso IO British Indian Ocean Territory RW Rwanda

BG Bulgaria IQ Iraq SA Saudi Arabia

BH Bahrain IR Iran SB Solomon Islands

BI Burundi IS Iceland SC Seychelles

BJ Benin IT Italy SD Sudan

BM Bermuda JM Jamaica SE Sweden

BN Brunei JO Jordan SG Singapore

BO Bolivia JP Japan SH Saint Helena

BR Brazil KE Kenya SI Slovenia

BS Bahamas KG Kyrgyzstan SJ Svalbard and Jan Mayen Islands

BT Bhutan KH Cambodia SK Slovakia

BV Bouvet Island KI Kiribati SL Sierra Leone

BW Botswana KM Comoros SM San Marino

BY Belarus KN Saint Kitts and Nevis SN Senegal

BZ Belize KP Korea, Democratic People's RepublicofSO Somalia

PF Polynesia

CA Canada KR Korea, Republic of SR Suriname

CC Cocos Islands KW Kuwait ST Sao Tome and Principe

CF Central African Republic KY Cayman Islands SV El Salvador

CG Congo, Republic of KZ Kazakhstan SY Syria

CH Switzerland LA Laos SZ Swaziland

CI Cote d'Ivoire LB Lebanon TC Turks and Caicos Islands

Others

CK Cook Islands LC Saint Lucia TD Chad

CL Chile LI Liechtenstein TF French Southern Territories

CM Cameroon LK Sri Lanka TG Togo

CN China LR Liberia TH Thailand

CO Colombia LS Lesotho TJ Tajikistan

CR Costa Rica LT Lithuania TK Tokelau

CU Cuba LU Luxembourg TM Turkmenistan

CV Cape Verde LV Latvia TN Tunisia

CX Christmas Island LY Libya TO Tonga

CY Cyprus MA Morocco TP East Timor

CZ Czech Republic MC Monaco TR Turkey

DE Germany MD Moldova TT Trinidad and Tobago

DJ Djibouti MG Madagascar TV Tuvalu

DK Denmark MH Marshall Islands TW Taiwan

DM Dominica, Commonwealth of ML Mali TZ Tanzania

DO Dominican Republic MM Myanmar UA Ukraine

DZ Algeria MN Mongolia UG Uganda

EC Ecuador MO Macau UM Minor Outlying Islands

EE Estonia MP Northern Mariana Islands US United States

EG Egypt MQ Martinique UY Uruguay

EH Western Sahara MR Mauritania UZ Uzbekistan

ER Eritrea MS Montserrat VA Vatican

ES Spain MT Malta VC Saint Vincent and the Grenadine

ET Ethiopia MU Mauritius VE Venezuela

FI Finland MV Maldives VG British Virgin Islands

FJ Fiji MW Malawi VI Virgin Islands of the United States

FK Falkland Islands (Malvinas) MX Mexico VN Vietnam

FM Micronesia (Federated States of) MY Malaysia VU Vanuatu

FO Faroe Islands MZ Mozambique WF Wallis and Futuna

FR France NA Namibia WS Samoa

FX France, Metropolitan NC New Caledonia YE Yemen

GA Gabon NE Niger YT Mayotte

GB United Kingdom of Great Britain and

Northern Ireland

GD Grenada NG Nigeria ZA South Africa

GE Georgia NI Nicaragua ZM Zambia

GF French Guiana NL Netherlands ZR Zaire

GH Ghana NO Norway ZW Zimbabwe

GI Gibraltar NP Nepal

GL Greenland NR Nauru

NF Norfolk Island YU Yugoslavia

Others

Using the HDMI Consumer Electronics Control (HDMI CEC)

HDMI Consumer Electronics Control

By using a HDMI cable to connect this unit with a TV that supports the HDMI CEC standard, this unit and the TV can be linked and operated together.

HDMI CEC (Consumer Electronics Control) is an industrial standard that allows HDMI devices to be linked and operated among each other by connecting them with a HDMI cable.

HDMI Consumer Electronics Control operations

Perform the following operations when this unit is turned on, and the TV will switch automatically to the HDMI input that this unit is connected to.

Playback from HDD, BD/DVD or SD CARD

Press the [NAVIGATION] or [SETUP] button

Turning off the power for the TV will also turn the power off for this unit automatically. If HDD, BD/DVD or SD CARD is being used for dubbing, the power will be turned off after dubbing finishes.

Using HDMI Consumer Electronics Control (activating the function)

Connect this unit to a TV that is HDMI CEC compatible using a HDMI cable

Change the setting of “HDMI-CEC” to “ON”.

Check the monitor (TV) setting if the HDMI CEC function does not work.

Memo:

If you are not using the HDMI CEC function (deactivating), change the setting of “HDMI-CEC” to “OFF”.

Note:

The HDMI CEC function cannot be used if a TV that is not compatible with HDMI CEC has been connected.

If a HDMI cable is not used for connecting, the HDMI CEC function will not be usable.

Creating a Seamless BD

When titles are imported into the HDD in the HD quality from a video camera, or when edited titles (e.g., after applying scene delete) are dubbed to a disc, seamless playback may not be possible at the joints of scenes. In this case, perform dubbing after executing “SEAMLESS” under the “MODE CHANGE” setting menu. For details, refer to “Mode conversion” (A page 73) .

Creating a seamless BD that uses “MODE CONVERSION” (seamless conversion, recording mode conversion)

Procedures to create a seamless BDMV

File to import If you do not want to

perform scene delete/

chapter delete

AVCHD Recording mode

conversion

MOV* Conversion not required Seamless conversion

SD-VIDEO(HD)* HDV

SD-VIDEO(HD)*

MOV* :

Recording mode conversion after seamless conversion

: SD-VIDEO(JVC Everio MPEG2 TS)

MOV files that are taken in SP mode using the JVC ProHD Camcorder GY-HM700/100

Procedures to create a seamless BDAV

File to import If you do not want to

perform scene delete/

chapter delete

AVCHD Conversion not required Seamless

MOV* Conversion not required Seamless

SD-VIDEO(HD)* HDV

SD-VIDEO(HD)*

MOV* :

Seamless conversion Seamless

: SD-VIDEO(JVC Everio MPEG2 TS)

MOV files that are taken in SP mode using the JVC ProHD Camcorder GY-HM700/100

Memo:

During dubbing to BDMV, the recording mode cannot be specified.

Do not perform recording mode conversion before seamless conversion. Otherwise, seamless conversion cannot be performed.

If scene delete or chapter delete is applied to a title, it cannot be dubbed to a BDMV disc without performing seamless conversion.

For titles that use the H.264/AVC video compression format such as AVCHD, titles using B-frames as reference for Bframes (pyramidal reference format) are not supported.

For titles that are imported into the HDD in the SD picture quality, you can create a seamless DVD by setting “SEAMLESS PLAYBACK” under the “Setting Menu List” to “ON”, followed by performing re-encode dubbing.

Refer to “SEAMLESS PLAYBACK” (A page 77) .

If you want to perform scene delete/chapter

delete

Seamless conversion

Recording mode conversion after seamless conversion

If you want to perform scene delete/chapter

delete

conversion

Troubleshooting

Problem Symptom Action Reference

Others

Page

Power does not turn on The “HELLO” message remains

displayed, and the unit does not start up.

“FAN LOCKED” is displayed on the display window of this unit

Power turns off automatically

The power turns on automatically

Input cannot be switched

There are no video images on the monitor

The cooling fan motor is not working. The cooling fan motor is spoiled. Remove

The “AUTO POWER (OFF)” setting is set to “2 HOURS” or “6 HOURS”.

The temperature of this unit has rose, and operation has ceased for safety purposes.

The “HDMI-CEC” setting is set to “ON”.

i.LINK connection is currently being established.

Monitor only supports RGB input. Set “HDMI --> DVI COLOR” in the setting

“HDCP ERROR” is displayed. Use a monitor that supports HDCP. -

Press the [RESET] button on the front panel. If it does not start up, stop using this unit, unplug the plug from the power point, and bring it to the dealer or “Service Center”.

the power plug from the power point, and consult the dealer from which this product is purchased, or any nearby JVC Servicing Center.

Change the “AUTO POWER (OFF)” setting of “SETUP” to “OFF”.

Place this unit in an area with ventilation if possible, and wait approximately 30 minutes for it to cool down.

Change the “HDMI-CEC” setting of “CONNECTION” to “OFF”.

Cancel importing, or wait until the connection ends.

menu to “RGB FIX”.

(A page 13)

(A page 75)

(A page 81)

(A page 37)

(A page 81)

Video images may be distorted during reencoding/dubbing when the monitor (TV) is connected to this unit using a HDMI cable, or when the screen resolution is set to “1080p”.

Screen is distorted Video images may be distorted during

reencoding/dubbing when the monitor (TV) is connected to this unit using a HDMI cable, or when the screen resolution is set to “1080p”.

There is no audio sound The “HDMI AUDIO OUTPUT” setting

is set to “OFF”.

The amplifier does not support “BITSTREAM” output.

Dubbing cannot be performed

High-speed dubbing cannot be performed for EP mode titles

The title to be dubbed is copyright protected.

A finalized disc has been inserted. Insert a disc that has not been finalized. -

The disc is not formatted. Format the disc. (A page 25)

The SD card is write-protected. Remove the SD card and remove the write

Dubbing cannot be performed and “SOME TITLES CANNOT BE DUBBED” is displayed when trying to perform high-speed dubbing of a EP mode title to a DVD-VIDEO mode disc.

This is not a malfunction. Change the “HDMI OUTPUT RESOLUTION” to a value other than “1080p” (e.g., 1080i) if you find it annoying.

Change the “HDMI AUDIO OUTPUT” setting of “CONNECTION” to “ON”.

Use an amplifier that supports bitstream output.

Titles that are copyright-protected cannot be dubbed. Select a title that is not copyright-protected.

protect lock.

Set “HIGH-SPEED DUBBING” in the settings menu to “4:3” before recording or importing in the EP mode.

(A page 80)

(A page 24)

(A page 81)

(A page 78)

(A page 23)

(A page 27)

(A page 24) (A page 77)

Others

Troubleshooting (Continued)

Problem Symptom Action Reference

Page

Data cannot be imported

The title/group name cannot be changed

The remote control unit does not work

The disc cannot be ejected

The title to be dubbed is copyright protected.

The number of titles stored in the HDD has reached the maximum amount.

The remaining space on the HDD is running out.

Protection of the title/group name is turned on.

The battery of the remote control unit has run out.

The remote control code of this unit and the remote control unit are different from each other.

A “LOCKED” message appears on the display window of the unit.

The “READING” message does not disappear from the unit's display window, and the disc tray does not open when the [ M ] button is pressed.

Titles that are copyright-protected cannot be dubbed. Select a title that is not copyright-protected.

Delete or combine the titles in the HDD to reduce the amount of titles to less than

500.

Delete the titles in the HDD to increase the remaining space.

Turn protection off for the title/group name. (A page 64)

Change new batteries for the remote control.

Change the “REMOTE CONTROL CODE” for the remote control to the same number used by this unit.

Disable the “mode lock” setting. (A page 82)

Disable the “tray lock” setting. (A page 82)

Pressing the [ M ] button at the front of the unit for five seconds or longer opens the disc tray. To close the disc tray after removing the disc, press the [ A ] button, and wait until the tray is closed and power is turned off. (If the disc tray does not open after pressing the [ M ] button for five seconds or longer, consult our authorized dealer.)

(A page 23)

(A page 62)

(A page 16)

The disc cannot be played

Output is at 480i regardless of the component output resolution setting

The aspect ratios of the HDMI output and component output are different

100

A disc that cannot be played on this unit is inserted.

The region code of the BD or DVD is different from that of this unit.

An unfinalized DVD disc that is recorded using another device is inserted.

The component output setting may be changed to 480i after viewing at a setting of 1080/24p using a HDMI connection.

When two monitors are connected respectively to the HDMI output and component output terminals of this unit, the screen aspect ratio of the component output may not be appropriate if “VIDEO PRIORITY MODE” is set to “HDMI”.

Confirm that the disc is playable on this unit.

Confirm that the region number is playable on this unit.

Use that device to finalize the disc. -

Turn the power off, and turn it on again. -

When two monitors are connected simultaneously, users are recommended to set “VIDEO PRIORITY MODE” to “COMPONENT”.

(A page 10)

(A page 80)

JVC LST1083-001C, 1010MTH-SW-MT, SR-HD1250US, SR-HD1500US User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Precaution

Contents

Getting Started

Key Features

How to Read this Manual

Other Precautionary Notes

Hard Disk Drive (HDD)

SD Cards

Discs

Precautions on the Use of Discs

On-screen Displays

Front panel

Display window

Rear panel

Remote control

Preparation

Connecting a Monitor

Connecting a Video Deck or Other Equipment

Connecting an Amplifier

Connecting External Devices

Connecting the Power Supply

Setting and Displaying Date/Time

Dubbing/Importing

Dubbing/Importing

Dubbing chart

Formatting

Recording Modes

Importing Data to the HDD Using the ONE TOUCH DUBBING Button

Importing Data from a BD/ DVD to the HDD

Importing Data from an SD Card to the HDD

Importing Data from an i.LINK-compatible Device to the HDD

Dubbing Still Images from the HDD

Enabling Playback on Other Devices (Finalizing)

Copying the Entire Disc

Recording Using External Inputs

Playing Back

About Playing Back

Using Playback Navigation

Option menu list

Video Playback Operation

Playing Videos on a BD/ DVD

Playing Videos on the HDD

Playing Videos on a SD Card

Playing Still Images (JPEG)

Changing Playback Settings

Playback Settings Menu

Audio/subtitle settings

Playback settings

Video settings

Editing

Editing

Entering Characters

Character List

Grouping

Changing the Title/Group Name

Deleting a Title/Group

Turning Off Title/Group Protection

Creating a Playlist

Editing a Thumbnail

Editing a Chapter

Dividing

Delete Scenes

Changing the Disc Name

Changing the Shooting Date/Time

Mode conversion

Settings Menu

Changing Settings of this Unit

Setting Menu List

Setup

Playback Setting

Record

Audio

Display

Connection

Others

Locking the Disc Tray
