JVC 1004MKH-CR-VP, LCT1774-001A User Manual

PD-Z42DX4
ENGLISH
PDP COLOUR TELEVISION
INSTRUCTIONS
LCT1774-001A
Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
WARNING
Always use the power cords which are supplied with the TV. Some power cords are supplied with this TV. Use the power cord which best suits the area in which you live, and insert it into a correctly earthed outlet. Failure to use the supplied power cord or to insert it into a correctly earthed outlet may result in electric shocks.
WARNING FOR TABLE TOP STAND:
To ensure safety in an emergency such as an earthquake, and to prevent accidents, ensure that measures are taken to prevent the TV dropping or falling over.
• Use the supplied screws to firmly attach the supplied hooks to the back of the TV, and use commercially available cord to fix the TV to rigid components such as walls and columns.
ENGLISH
Supplied hooks
CAUTION:
• Operate only from the power source specified (AC 110 – 240 V, 50/60 Hz) on the unit.
• Avoid damaging the AC plug and power cord.
• When you are not using this unit for a long period of time, it is recommended that you disconnect the power cord from the main outlet.
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
Distance recommendations
Avoid improper installation and never position the unit where good ventilation is impossible. When installing this TV, distance recommendations must be maintained between the set and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the minimum distance guidelines shown for safe operation.
150 mm
200 mm
50 mm
150 mm
200 mm
50 mm
Burn-in
A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay on the screen (this is called phosphor burn-in).
Avoid burn-in as follows.
Use the PICTURE SHIFT function. To prevent burn-in, the picture displayed on the screen is shifted up, down and to the left and right at regular intervals. See page 40 for details.
• Even if the PICTURE SHIFT function is turned off, the picture may shift to the left or right when the channel or input is changed.
ENGLISH
The PICTURE MODE function is initially set to BRIGHT. Unless the TV is being
watched in an extremely bright room, we recommend you change the PICTURE MODE setting to either STANDARD or SOFT. Doing so will reduce the chance of burn-in and extend the life of the PDP. See “PICTURE MODE” on page 26.
Do not display static images or characters for long periods of time.
While an image is displayed With power OFF
19:03
Burn-in example
19:03
• Reduce CONTRAST and BRIGHT on the PICTURE menu (page 26) when viewing.
Do not view for long periods of time in the REGULAR mode (page 15).
Screen size is normally chosen to ensure that the picture is displayed on the entire screen. After viewing in the REGULAR mode in which black bands may occur at the left and right of the screen, it is recommended to change to the PANORAMIC mode to display the picture on the entire screen.
While an image is displayed With power OFF
Burn-in example
Do not view for long periods of time using the MULTI-PICTURE function (page 17).
If Burn-in has occurred
If burn-in occurs, try the REFRESH function (page 34). If burn-in is minimal it may gradually become less noticeable.
Note: Once burn-in occurs it will never disappear completely.
Pixel defects
PDPs use collections of fine dots (“pixels”) to display images. While there is no problem with more than 99.99% of these pixels, please understand that a very small number of pixels may not light, or may light all the time.
Do not install the TV near electronic equipment that is susceptible to electromagnetic waves
It may cause interference in images, sound, etc. In particular, keep video equipment away from this product.
Effect on infrared devices
There may be interference while using infrared devices such as infrared cordless headphones.
Failure to take the following precautions may result in damage to the TV or remote control.
DO NOT block the TV’s ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)
DO NOT place anything on top of the TV.
(such as cosmetics or medicines, flower vases, potted plants, cups, etc.)
DO NOT allow objects or liquid into the cabinet openings.
(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)
DO NOT place any naked flame sources, such as lighted candles, on the TV.
The surface of the TV screen is easily damaged. Be very careful with it when handling the TV. Should the TV screen become soiled, wipe it with a soft dry cloth. Never rub it hard. Never use any cleaner or detergent on it.
ENGLISH
In the event of a fault, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover.
PICTURE MANAGEMENT demonstration
To start the PICTURE MANAGEMENT demonstration: Press the H button to display the menu bar. Then press the yellow button. A picture split in two (PICTURE MANAGEMENT turned on and PICTURE MANAGEMENT turned off) will appear on the screen.
To quit the PICTURE MANAGEMENT demonstration: Press the yellow button, b button, 6 p buttons or any of the number buttons.
CONTENTS
Checking the contents of packages .......5
Setting up your TV ...................................6
Installation.................................................. 6
Connecting the aerial and video cassette
recorder (VCR) ....................................... 7
Connecting the power cord to the AC
ENGLISH
outlet....................................................... 8
Putting the batteries into the remote
control..................................................... 9
Initial settings (Setup tour) ......................... 9
TV buttons and functions......................11
Turn the TV on from standby mode ......... 11
Choose a TV channel .............................. 11
Adjust the volume .................................... 11
Using the Menu........................................ 11
Remote control buttons and
functions..............................................12
Turn the TV on or off from standby mode Choose a TV channel and watch images
from external devices ........................... 13
Adjust the volume .................................... 14
Display function........................................ 14
ZOOM function......................................... 15
CINEMA SURROUND function................ 16
Using the FREEZE function ..................... 16
Using the MULTI-PICTURE function ....... 17
RETURN PLUS function and Return
function................................................. 18
Favourite channel function....................... 19
Operating a JVC brand DVD player......... 20
Teletext function ....................................21
Basic operation ........................................ 21
Using the List Mode ................................. 21
Hold.......................................................... 22
Sub-page ................................................. 22
Reveal...................................................... 22
Size .......................................................... 22
Index ........................................................ 23
Cancel...................................................... 23
Using the TV’s menu..............................24
Basic operation ........................................ 24
... 12
PICTURE menu ......................................26
PICTURE MODE...................................... 26
CONTRAST ............................................. 26
BRIGHT.................................................... 26
SHARP..................................................... 26
COLOUR.................................................. 26
TINT ......................................................... 26
WHITE BALANCE.................................... 26
FEATURES .............................................. 27
SOUND menu ......................................... 30
STEREO / I • II ......................................... 30
BASS........................................................ 30
TREBLE ................................................... 30
BALANCE ................................................ 30
CINEMA SURROUND ............................. 30
A.H.B. (Active Hyper Bass) ...................... 30
BBE .......................................................... 31
SPEAKER ................................................ 31
FEATURES menu................................... 32
SLEEP TIMER ......................................... 32
CHANNEL GUARD .................................. 32
APPEARANCE......................................... 33
BLUE BACK ............................................. 34
CHILD LOCK............................................ 34
AUTO SHUTOFF ..................................... 34
REFRESH ................................................ 34
FAVOURITE SETTING ............................ 34
SET UP menu ......................................... 35
AUTO PROGRAM.................................... 35
EDIT/MANUAL ......................................... 35
LANGUAGE ............................................. 39
VIDEO-1 SETTING/VIDEO-3 SETTING ..39
AI VOLUME.............................................. 39
TELETEXT LANGUAGE .......................... 40
PICTURE SHIFT ...................................... 40
HDMI SETTING ....................................... 40
Displaying a computer screen.............. 41
Connecting to the computer ..................... 41
Looking at images from a computer......... 41
Table of signals for each type of
computer............................................... 41
Additional preparation ..........................42
Connecting external equipment ...............42
Using the HDMI terminal .......................... 46
CH/CC numbers ..................................... 48
Troubleshooting ....................................49
Specifications ........................................51

Checking the contents of packages

Check that all components are present. Contact your retailer immediately if any components are missing.
Remote control unit 1 (RM-C1830)
AA/R6 batteries 2 (used to check operation)
Hooks 2 (to prevent the TV from falling)
Mounting screws 2 (to fix the hooks)
Power cord Use the power cord which best suits your area.
ENGLISH

Setting up your TV

Be sure to have someone help you when you lift up the TV. The TV is too
heavy to lift up by yourself. If the TV falls, it will cause injuries and damage.

Installation

Fit the separately sold tabletop stand or wall mounting brackets to the TV.
ENGLISH
Only use JVC approved accessories with your model.
Warning for wall mounting unit:
• Use only authorized service personnel to install your TV in order to prevent accidents. Do not try to install your TV by yourself.
• We sell this product on the understanding that it will be assembled and installed by qualified service personnel.
• Please read the instruction manual for the wall mounting unit before starting installation in order to prevent accidents.
• We are not liable for any damage caused by faulty assembly, faulty wall mounting, insecure wall mounting, misuse, alterations, or natural disasters.
Cautions for installation
• Do not tilt the TV towards the left or right, or towards the back.
• Install the TV in a corner on a wall or on the floor so as to keep cords out of the way.
• The TV will generate a slight amount of heat during operation. Ensure that sufficient space is available around the TV to allow satisfactory cooling. See “Distance recommendations” on page 1.
Setting up your TV

Connecting the aerial and video cassette recorder (VCR)

Caution
• Turn off all the equipment including the TV before connecting anything.
• Aerial cable is not supplied. Use a good quality 75-ohm coaxial cable.
• Read the manual that came with the VCR before connecting.
If not connecting a VCR (see Fig. A):
Connect an aerial cable to the aerial socket on this TV.
If connecting a VCR (see Fig. B):
1 Connect the aerial cable to the
aerial input socket on the VCR, and connect the VCR and TV with another aerial cable
2 Connect the VCR’s VIDEO OUT
(video output) terminal and the TV’s VIDEO terminal with a video cable
To connect a VCR to the TV with an S-VIDEO cable:
Connect the VCR’s S-VIDEO OUT (S­VIDEO output) terminal and TV’s S terminal with an S-VIDEO cable A, instead of connecting with a video cable.
3 Connect the VCR’s AUDIO OUT
(audio L/R output) terminals and the TV’s AUDIO terminals (L and R) with an audio cable
• If the VCR’s audio output is in mono, connect the VCR’s AUDIO OUT (audio output) jack and the TV’s VIDEO-1 AUDIO L/MONO jack with an audio cable.
• To connect more equipment, please see “Connecting external equipment” on page 42.
• To connect additional audio equipment, see “Connecting speakers/amplifier” on page 43.
Fig. A
AUDIO IN (ANALOG)
LR
AUDIO VIDEO
LR
Cr/Pr
COMPONENT
Fig. B
AUDIO
AUDIO IN (ANALOG)
LRLRAUDIO VIDEO
Cr/Pr
COMPONENT
CENTER CHANNEL INPUT
IN
VIDEO-1
VIDEO-3
YCb/Pb
VIDEO-2
S
Back of the TV
CENTER CHANNEL INPUT
AUDIO
IN
IN
VIDEO-1
VIDEO-3
R AUDIO L/MONO
IN
YCb/Pb
VIDEO-2
OUT
AUDIO
VIDEOLR
IN
R AUDIO L/MONO
VIDEO
IN
VIDEO
AUDIO IN (ANALOG)
AUDIO VIDEO
Cr/Pr
COMPONENT
S-VIDEO
VIDEOLRAUDIO
CENTER CHANNEL INPUT
LR
IN
IN
LR
VIDEO-1
VIDEO-3
R AUDIO L/MONO
IN
YCb/Pb
VIDEO-2
ENGLISH
OUT
R
AUDIO
SUB WOOFER
L
OUT
VIDEOLR
VIDEO
VIDEOLRAUDIO
R
AUDIO
OUT
COMPONENT
Cr/Pr
S-VIDEO
AUDIO
VIDEOLR
VIDEO
VIDEOLRAUDIO
OUT
COMPONENT
YCb/Pb
Cr/Pr
S-VIDEO
S-VIDEO
SUB WOOFER
L
OUT
YCb/Pb
A
OUT
R
AUDIO
SUB WOOFER
L
OUT
OUT
COMPONENT
YCb/Pb
Cr/Pr
S-VIDEO
S-VIDEO
Setting up your TV
Rear Panel
ENGLISH
AUDIO
CENTER
IN
CHANNEL
(ANALOG)
INPUT
IN
VIDEO
LRLRAUDIO
VIDEO-1
VIDEO-3
YCb/Pb
Cr/Pr
VIDEO-2
COMPONENT
1 Aerial socket (page 7) 2 VIDEO-1 terminal (pages 7, 42) 3 VIDEO-2 terminal (pages 7, 42) 4 VIDEO-3 terminal (page 42) 5 CENTER CHANNEL INPUT terminal
(page 43)
6 AUDIO IN terminal (page 46) 7 OUT terminal (page 42) 8 AUDIO OUT terminal (page 43) 9 SUBWOOFER OUT terminal (page 43) 0 AC INLET (page 8)
- AV COMPU LINK terminal (page 44) = HDMI terminal (page 46)
OUT
R
AUDIO
OUT
VIDEOLR
AUDIO
IN
IN
Cr/Pr
S-VIDEO
VIDEOL/MNOR AUDIO
S-VIDEO
VIDEOLRAUDIO
COMPONENT

Connecting the power cord to the AC outlet

Insert the AC plug on the power cord from the TV into AC outlet.
Caution
• Operate only from the power source specified (AC 110 – 240 V, 50/60 Hz) on the unit.
• Failure to use the supplied power cord
SUB WOOFER
L
OUT
YCb/Pb
or to insert it into a correctly earthed outlet may result in electric shocks.
Use the supplied power cord which best suits the area in which you live.
Insert the AC plug into a correctly earthed outlet.
Back of the TV
AC INLET
Power cord
Setting up your TV
CHANNEL
VOLU
M
E
MENU/
O
K
T
V/
V
ID
E
O

Putting the batteries into the remote control

Use two AA/R6 dry cell batteries. Insert the batteries from the - end, making sure the + and - polarities are correct.
• Follow the warnings printed on the batteries.
• Battery life is about six months to one year, depending on how much you use the remote control.
• The batteries we supply are only for setting up and testing your TV, please replace them as soon as you need to.
• If the remote control does not work properly, replace the batteries.

Initial settings (Setup tour)

When the TV is first turned on, it goes into the initial settings mode, and you will see the JVC logo. Follow the instructions on the screen display to make the initial settings.
1 Press the A button on the TV
The power lamp lights blue and the JVC logo appears.
A button Power lamp
CHANNEL
VOLUME
PC IN(D-SUB)
MENU/OK TV/VIDEO
L/MONO-AUDIO-RVIDEOS-VIDEO
VIDEO-4
• If the JVC logo does not appear this is because your TV has already been turned on for the first time: use the “LANGUAGE”, “TELETEXT LANGUAGE” and “AUTO PROGRAM” functions to make the initial settings. For details, see “SET UP menu” on page 35.
ENGLISH
6 buttons
Setting up your TV
2 Press the a button
The LANGUAGE menu appears.
ENGLISH
3 Press the 6 buttons to choose
ENGLISH. Then press the a button
The TELETEXT LANGUAGE menu appears. Set the teletext language group that corresponds to the language of the teletext program that you want to watch. For details, see “TELETEXT LANGUAGE” on page 40.
> TELETEXT LANGUAGE
GROUP-1 GROUP-2 GROUP-3 GROUP-4
OK
D1003
-EN
4 Press the 6 buttons to choose a
group. Then press the a button
The AUTO PROGRAM function starts. The TV channels you receive are automatically stored in the programme numbers (PR) list.
>>
AUTO PROGRAM
CH
28
14%
5 After the TV channels have been
registered in the programme numbers (PR), the EDIT menu appears
EDIT
>
D0038
-EN
PR ID AV 01 02 03 04 05 06 07 08 09
OK
MOVE
CH/CC
CH CH CH CH CH CH CC CC CC
ID
INSERT
21 22 23 24 25 26 01 02 03
MANUAL
DELETE
• You can proceed to edit the programme numbers (PR) list using the EDIT/MANUAL function. For details, see “EDIT/MANUAL” on page 35.
• If a TV channel you want to view is not stored in the programme numbers (PR) list, you can register it using the MANUAL function. For details, see “EDIT/MANUAL” on page 35.
• The AUTO PROGRAM function does not store a TV channel to the programme number PR 0 (AV).
• If you do not need to use the EDIT/ MANUAL function, press the a button to close the EDIT menu.
Now, setting up is complete. Please enjoy your new JVC TV!
10
OK
D0004
-EN
• To stop the AUTO PROGRAM
function, press the a button.

TV buttons and functions

CHA
NNEL
V
O
L
U
M
E
M
EN
U
/O
K
T
V
/
V
ID
EO

Turn the TV on from standby mode

Press the A button or the CHANNEL p buttons to turn the TV on from standby mode.
When the TV is turned on, the power lamp lights blue.
To turn the TV off:
Press the A button again. The power lamp goes off.
Caution
•The A button on the TV does not fully
isolate the TV from the AC supply. If you are not going to use the TV for a
CHANNEL
VOLUME
PC IN(D-SUB)
MENU/OK TV/VIDEO
L/MONO-AUDIO-RVIDEOS-VIDEO
VIDEO-4
See the pages in brackets for details.
1 A (power) button 2 VOLUME q buttons
5 buttons (page 24)
3 CHANNEL p buttons
6 buttons (page 24)
4 MENU/OK button (page 24) 5 Power lamp (page 9) 6 TV/VIDEO button (page 24) 7 VIDEO-4 terminal (page 42) 8 PC IN (D-SUB) terminal (page 41) 9 Headphone jack (mini jack) (page 42) 0 Remote control sensor
long period, be sure to disconnect the AC plug from the AC socket.

Choose a TV channel

Press the CHANNEL p buttons to choose a programme number (PR) or a VIDEO terminal
Press the TV/VIDEO button to choose a VIDEO terminal.

Adjust the volume

Press the VOLUME q buttons
The volume level indicator appears.

Using the Menu

Use the MENU/OK button
Refer to “Using the TV’s menu” (see page 24) for details of using the menu.
ENGLISH
11

Remote control buttons and functions

1 Muting button 2 Number buttons 3 1 button 4 c button 5 2 button 6 4 button 7 7 buttons 8 5 button 9 6 p buttons 0 VCR/DVD/Teletext control buttons
- p buttons = d (Favourite) button ~ # (Standby) button ! PIP/TV/DVD switch @ g (Text) button # Colour buttons $ H button % a button ^ b button & 7 q buttons * f (Freeze) button ( X (Multi) button ) c (Select) button
ENGLISH
1
2
3
4 5
6
7 8
~
!
@ #
$ %
^
12
9
0
­=
&
* (
)

Turn the TV on or off from standby mode

Press the # (standby) button to turn the TV on or off
When the TV is turned on, the power lamp lights blue.
• The power can be turned on by pressing
the 4 button, 6 p buttons or Number buttons.
To turn the TV on or off, set the PIP/TV/ DVD switch on the remote control to the TV position and press the # button. If the PIP/TV/DVD switch on the remote control is set to the DVD position, the TV will not be turned on or off even if the # button is pressed.
Remote control buttons and functions

Choose a TV channel and watch images from external devices

Use the number buttons:
Enter the programme number (PR) of the channel using the number buttons.
Example:
•PR 6 → press 6
• PR 12 → press 1 and 2
Use the 6 p buttons:
Press the 6 p buttons to choose the programme number (PR) you want or a VIDEO terminal.
Use the 4 button:
Press the 4 button to choose a VIDEO terminal.
Programme
numbers
PR 1 – PR 99
or
• Since this TV is designed to make full use of the resolution of the original video source, the motion may appear unnatural when the video source is input with 576p progressive-scanning component signals. If this happens, change the output setting of the connected device to 576i interlace-scanning component signal output. See the instructions that came with the device for more information.
• The PC sound is the same as the VIDEO-4 sound.
To return to a TV channel:
Press the 4 button, the 6 p buttons or the number
buttons.
To use the programme number PR 0 (AV):
When the TV and VCR are connected only by the aerial cable, choosing the programme number PR 0 (AV) allows you to view images from the VCR. Set the VCR RF channel to the programme number PR 0 (AV) manually. For details, see “EDIT/ MANUAL” on page 35.
ENGLISH
or
• If you do not have a clear picture or no colour appears, follow the operation procedure “COLOUR SYSTEM” on page 28.
• If you cannot hear the normal sound even if the picture of the TV channel appears normally. Follow the description “EDIT/MANUAL” on page 35 to use the MANUAL function to change the SYSTEM setting.
13
Remote control buttons and functions

Adjust the volume

Press the 7 q buttons to adjust the volume.
The volume indicator appears and the volume changes as you press the 7 q buttons.
ENGLISH
Muting the sound
Press the l (muting) button to turn off the sound.
Pressing the l (muting) button again restores the previous volume level.

Display function

You can see the channel number of the programme you are watching or the PR LIST. From the PR LIST, you can choose a channel or VIDEO terminal.
Press the
5
the information you want to see.
Pressing the
5
display as follows:
PR LIST
PR ID
AV 01 02 03 04 05 06 07 08 09
OK
+10-10
D0011
-EN
Channel number display:
The channel number and channel name (when the channel name is registered) of the programme you are watching or the VIDEO terminal number is displayed.
button to display
button changes the
Channel number display
No indication
PR LIST:
The programme number (PR) and VIDEO terminal list is displayed. Pressing the a button after choosing the programme number (PR) or VIDEO terminal with the 7 buttons will display the chosen programme or VIDEO terminal.
• For programme numbers (PR) for which the CHANNEL GUARD function is set, the n (CHANNEL GUARD) mark is displayed. For details see “CHANNEL GUARD” on page 32.
• The VIDEO terminals are registered after the programme number PR 99.
• For programme numbers (PR) which is registered as a favourite channel, the d (favourite) mark is displayed. For details see “Favourite channel function” on page 19.
14
Remote control buttons and functions

ZOOM function

You can change the screen size according to the picture aspect ratio. Choose the optimum one from the following ZOOM modes.
• The ZOOM mode is fixed at FULL when you are using the TV as a PC screen.
AUTO:
When a WSS (Wide Screen Signalling) signal, which shows the aspect ratio of the picture, is included in the broadcast signal or the signal from an external device, the TV automatically changes the ZOOM mode to 16:9 ZOOM mode or FULL mode according to the WSS signal. If a WSS signal is not included, the picture is displayed according to the ZOOM mode set with the 4:3 AUTO ASPECT function.
• For details of the 4:3 AUTO ASPECT function, see “4:3 AUTO ASPECT” on page 29.
• When the AUTO (WSS) mode does not function correctly due to poor WSS signal quality or when you want to change the ZOOM mode, press the c button and change to another ZOOM mode.
REGULAR:
Use to view a normal picture (4:3 aspect ratio) as this is its original shape.
16:9 ZOOM:
This zooms up the wide picture (16:9 aspect ratio) to the full screen.
16:9 ZOOM SUBTITLE:
This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.
FULL:
This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the wide TV screen.
• For 16:9 aspect ratio pictures that have been squeezed into a normal picture (4:3 aspect ratio), use the FULL mode to restore the picture to its original shape.
Choose the ZOOM mode
1 Press the c button to display
the ZOOM menu
ZOOM
AUTO REGULAR PANORAMIC 14:9 ZOOM 16:9 ZOOM 16:9 ZOOM SUBTITLE FULL
ENGLISH
PANORAMIC:
This stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the screen, without making the picture appear unnatural.
• The top and bottom of the picture are slightly cut off.
14:9 ZOOM:
This zooms up the wide picture (14:9 aspect ratio) to the upper and lower limits of the screen.
OK
D0009
-EN
2 Press the 6 buttons to choose a
ZOOM mode. Then press the a button
The picture expands and the chosen ZOOM mode is displayed in about 5 seconds.
• The ZOOM mode may be automatically changed by the control signal from an external device. When you want to return to the previous ZOOM mode, choose the ZOOM mode again.
• The ZOOM mode is fixed at FULL when watching a 1080i picture signal from the HDMI terminal.
15
Remote control buttons and functions
Adjusting the visible area of the
If subtitles or the top (or bottom) of the picture are cut off, you can adjust the visible area of the picture manually.
1 Press the c button
ENGLISH
The ZOOM menu appears.
2 Press the a button to display the
ZOOM mode indicator
The indicator appears.
16 : 9 ZOOM
D0010-EN
3 While it is displayed, press the 6
buttons to change the position of the picture
• You cannot adjust the visible area in REGULAR or FULL mode.
The visible area adjustment is saved even after the TV channel is changed. However, it is cancelled if the following operations are performed.
• The power is turned off/on
• The ZOOM mode is changed
• The X (Multi) button, f (Freeze) button, or g (Text) button is pressed
• The TV is switched between TV mode and VIDEO mode

CINEMA SURROUND function

You can enjoy sounds with a wider ambience.
• This function does not work for the sound from headphones.
• When you set the CINEMA SURROUND function to HIGH mode, there may be slight volume distortion. If that occurs, please switch to LOW mode. The effect of CINEMA SURROUND functions will be less noticeable, but the volume distortion will be corrected.
MONO:
Select the MONO mode, when you listen to the mono sound. You can enjoy the sound for a wider audience similar to stereo sound.
OFF:
The CINEMA SURROUND function switches off.
• You can choose the CINEMA SURROUND mode with the “SOUND menu” (see page 30).

Using the FREEZE function

You can view the current programme as a still picture.
1 Set the PIP/TV/DVD switch to the
PIP position
When using the FREEZE function, set the PIP/TV/DVD switch to the PIP position.
2 Press the f button
The still picture of the current picture will appear.
current
programme
D0056
still picture
Press the 2 button to select one of CINEMA SURROUND modes
HIGH/LOW:
When you listen to stereo sound, please select HIGH or LOW mode. You can enjoy sound similar to the experience at the theatre. When you combine the functions of A.H.B. and BBE, you can enjoy more powerful sound.
16
Loading...
+ 37 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
