John Deere CT315 SPECIFICATIONS

CT315

45 NET HORSEPOWER

Even less of a good thing.

Need a smaller track loader to deliver big-time performance? Choose a CT315. Lightweight and agile,
yet surprisingly powerful, this highly capable compact is the perfect size for work in confi ned areas. Easy to
transport between jobsites, too. Like its larger compact track loader siblings, it delivers best-in-class stability,
breakout force, visibility, and wide-open service access. So you can get more done, more reliably, for less.
Features such as direct-mounted planetary drives, easy-to-fi ll large-capacity fuel tank, and a self-cleaning,
never-grease Quik-Tatch™ ensure it’s as easy to maintain as it is to run. Plus, this little dynamo is highly versatile.

2

3

Equip it with any of many Worksite Pro™ attachments, and watch productivity take off.

John Deere 2.4L diesel engine runs smooth and effi ciently. Meets
interim Tier 4 interim emission standards, too.

Best-in-class visibility allows clear sightlines to the bucket or
attachment, edge of the tracks, and out back. For increased confi -
dence and close-quarters agility.

Boom design delivers excellent reach through the “work zone.”
Perfect for loading pickup trucks, placing pallets, or whatever.

CT315 is as inexpensive to own as it is to acquire. Daily and periodic
maintenance is quick, convenient, and minimal.

Long-life undercarriage incorporates many of the same components
as our larger CTLs. It’s simple, yet durable. Standard 12½-inch
track provides plenty of productivity-enhancing balance, traction,
and fl otation.

Available JDLInk Express™ delivers 24/7 anywhere access to your
CT315’s engine hours and location, as well as geofencing, curfew,
and maintenance-tracking capabilities.

CT315 specs:

45 net hp; 49 gross hp

4,412-lb. tipping load

1,500-lb. SAE rated operating capacity

( 35% of tipping load )

2,178-lb. bucket breakout force

2,700-lb. boom breakout force

8,000-lbf tractive effort

Lightweight agility,
heavyweight ability.

Whether you’re tiptoeing around zero lot lines or laboring in close quarters, this nimble
loader won’t have any trouble fi tting in. Its small stature enables the CT315 to slip comfortably
through narrow openings and into tight spaces. Makes it easy to trailer and easy on turf,
too. But this “lightweight” won’t get pushed around. Optimal 60/40-weight distribution
gives it the stability needed for handling heavy loads. Best-in-class pushing power and rated
operating capacities deliver plenty of productive punch. And its high-torque turbocharged

2.4L diesel won’t toss in the towel when the going gets tough, either.

4

5

Smooth-running turbocharged 2.4L John Deere diesel delivers power without
compromise. Packs plenty of torque reserve, too, for daylong stamina and
strength.

Unlike other comparable-size CTLs, the CT315’s heavy-duty planetary reduction
fi nal drive provides plenty of pushing power.

1

2

1. Forty-degree dump angle enables buckets to
empty completely, shedding even sticky material.
Exclusive cushioned bucket and lift cylinders
reduce spillage.

2. Boom design keeps the load close to the
machine, close to the ground. Thirty degrees
of bucket rollback helps ensure that the load
arrives at its intended destination.

3. Just over 60 inches wide, the small-but-mighty
CT315 excels at close-quarters work.

4. Optimal weight distribution and low center of
gravity provide superior stability on slopes.
