OPERATOR’S MANUAL
and Set-Up Instructions for
HEADER TRANSPORTS
HS-30B
HS-36B
JMMAN0101 (Rev . 08/01/05)
J. & M. Mfg. Co., Inc.
P .O. Box 547 Ft. Recovery , OH 45846
Ph: (419) 375-2376 Fax: (419) 375-2708
www .jm-inc.com
TO THE DEALER:
Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists
in the Operator’s Manual are completed before releasing equipment to the owner.
The dealer must complete the Warranty Registration Card attached to the front inside cover of this manual and return
to J. & M. Mfg. Co., Inc. at the address indicated on the card. Warranty claims will be denied if the Warranty
Registration Card has not been completed and returned. THE DEALER MUST ALSO COMPLETE AND RETURN THE
TIRE REGISTRATION FORM A TTACHED T O THE INSIDE COVER OF THIS MANUAL. In case of a recall, we can reach
you only if the card is complete and returned to the address printed on the form. The Dealer MUST return this card
to be on our recall list.
EXPRESS WARRANTY :
J. & M. Mfg. Co. Inc. warrants against defects in construction or materials for a period of ONE year . We reserve the right
to inspect and decide whether material or construction was faulty or whether abuse or accident voids our guarantee.
Warranty service must be performed by a dealer or service center authorized by J. & M. Mfg. Co. Inc. to sell and/or
service the type of product involved, which will use only new or remanufactured parts or components furnished by J.
& M. Mfg. Co. Inc. Warranty service will be performed without charge to the purchaser for parts or labor based on the
Warranty Labor Times schedule. Under no circumstance will allowable labor times extend beyond the maximum
hours indicated in the Warranty Labor Times schedule for each warranty procedure. The purchaser will be responsible,
however, for any service call and/or transportation of the product to and from the dealer or service center ’s place of
business, for any premium charged for overtime labor requested by the purchaser, and for any service and/or
maintenance not directly related to any defect covered under the warranty. Costs associated with equipment rental,
product down time, or product disposal are not warrantable and will not be accepted under any circumstance.
Each warranty term begins on the date of product delivery to the purchaser. Under no circumstance will warranty be
approved unless (i) the product warranty registration card (attached to the inside of the Operator’s Manual) has been
properly completed and submitted to the equipment manufacturer, and (ii) a warranty authorization number has been
issued by the equipment manufacturer. This Warranty is effective only if the warranty registration card is returned
within 30 days of purchase.
This warranty does not cover a component which fails, malfunctions or is damaged as a result of (i) improper
modification or repair, (ii) accident, abuse or improper use, (iii) improper or insufficient maintenance, or (iv) normal
wear or tear. This warranty does not cover products that are previously owned and extends solely to the original
purchaser of the product. Should the original purchaser sell or otherwise transfer this product to a third party, this
Warranty does not transfer to the third party purchaser in any way. J. & M. Mfg. Co. Inc. makes no warranty , express or
implied, with respect to tires or other parts or accessories not manufactured by J. & M. Mfg. Co. Inc. Warranties for
these items, if any, are provided separately by their respective manufacturers.
THIS WARRANTY IS EXPRESSL Y IN LIEU OF ALL OTHER W ARRANTIES OR CONDITIONS, EXPRESS, IMPLIED OR
STATUTORY, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSE.
In no event shall J. & M. Mfg. Co. Inc. be liable for special, direct, incidental or consequential damages of any kind. The
exclusive remedy under this Warranty shall be repair or replacement of the defective component at J. & M. Mfg. Co.
Inc’s. option. This is the entire agreement between J. & M. Mfg. Co. Inc. and the Owner about warranty and no J. & M.
Mfg. Co. Inc. employee or dealer is authorized to make any additional warranty on behalf of J. & M. Mfg. Co. Inc.
The manufacturer reserves the right to make product design and material changes at any time without notice. They
shall not incur any obligation or liability to incorporate such changes and improvements in products previously sold to
any customer, nor shall they be obligated or liable for the replacement of previously sold products with products or
parts incorporating such changes.
SERVICE:
The equipment you have purchased has been carefully manufactured to provide dependable and satisfactory use.
Like all mechanical products, it will require cleaning and upkeep. Lubricate the unit as specified. Observe all safety
information in this manual and safety signs on the equipment.
For service, your authorized J. & M. dealer has trained mechanics, genuine J. & M. service parts, and the necessary
tools and equipment to handle all your needs.
Use only genuine J. & M. service parts. Substitute parts may void the warranty and may not meet standards required
for safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces
provided:
Serial No.: Date of Purchase:
Purchased From:
Provide this information to your dealer to obtain correct repair parts.
2
HS-30B and HS-36B HEADER TRANSPORTS
SPECIFICATIONS
DIMENSIONS
HS-30B HS-36B
A 41’-0” 47’-0”
B 6’-0” 6’-0”
C 26’-0” 26’-0”
D 2’-10 1/2” 2’-10 1/2”
E 6’-0” 6’-0”
SPECIFICA TIONS
Weight 3,050 lbs (HS-30B)
3,190 lbs (HS-36B)
Wheels 15 x 6
Hu b 6 bolt
Spindles 2-1/4” dia. (front) and 2-1/2” dia. (rear)
Front Construction 4” x 6” x 3/8” steel tubing
Steel Upper Bar 4” x 6” x 3/16” steel tubing
Rear Electric Brakes Standard on both rear axles
Adjustable Header Mounts S tandard
Tie Down S traps S tandard
GENERAL INFORMATION
TO THE OWNER:
The purpose of this manual is to assist you in operating and maintaining your header transport in a safe
manner. Read it carefully . It furnishes information and instructions that will help you achieve years of dependable
performance and help maintain safe operating conditions. If this machine is used by an employee or is loaned
or rented, make certain that the operator(s), prior to operating:
1. Is instructed in safe and proper use.
2. Reviews and understands the manual(s) pertaining to this machine.
Throughout this manual, the term IMPORT ANT is used to indicate that failure to observe can cause damage to
equipment. The terms CAUTION, WARNING and DANGER are used in conjunction with the Safety-Alert
Symbol, (a triangle with an exclamation mark), to indicate the degree of hazard for items of personal safety .
When you see this symbol, carefully read the message that follows and be alert to the possibility of personal
injury or death.
This Safety-Alert symbol indicates a hazard and means
A TTENTION! BECOME ALER T! YOUR SAFETY IS INVOL VED!
Indicates an imminently hazardous situation that, if not avoided, will
result in death or serious injury .
Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury , and includes hazards that are
exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury .
Indicates that failure to observe can cause damage to equipment.
Indicates helpful information.
3
GENERAL INFORMATION
BOLT TORQUE CHART
Always tighten hardware to these values unless a different torque or tightening procedure is listed for a specific
application.
Fasteners must always be replaced with the same grade as specified in the manual parts list.
Always use the proper tool for tightening hardware: SAE for SAE hardware and Metric for metric hardware.
Make sure fastener threads are clean and you start thread engagement properly .
All torque values are given to specifications used on hardware defined by SAE J1701 & J1701M JUL 96.
4
TABLE OF CONTENTS
INTRODUCTION 2
EXPRESS WARRANTY 2
SPECIFICATIONS 3
GENERAL INFORMA TION 3
BOLT TORQUE CHART 4
SAFETY RULES 6
SAFETY SIGNS 7
SET-UP INSTRUCTIONS 7-10
P ARTS DIAGRAMS 1 1
P ARTS LIST 12
ADJ. BRACKETS, TIE-DOWN BRACKETS, HEADER MOUNTS 13
INITIAL OPERA TION, OPERA TING INSTRUCTIONS/MAINTENANCE 14
REPORTING SAFETY DEFECTS 15
SERVICE RECORDS 16
5
SAFETY RULES
A TTENTION! BECOME ALERT! YOUR SAFETY IS INVOL VED!
Safety is a primary concern in the design and manufacture of our products. Unfortunately , our efforts to provide
safe equipment can be erased by an operator’s single careless act. In addition, hazard control and accident
prevention are dependent upon the awareness, concern, judgement, and proper training of personnel involved in
the operation, transport, maintenance and storage of equipment.
Make certain that the operator(s), prior to operating is instructed in safe and proper use and reviews and
understands the manual(s) pertaining to this machine.
Read this manual before you operate this machine. If you do not understand any part of this manual, or need
more information, contact the manufacturer or your authorized dealer .
SAFETY
Understand that your safety and the safety of other persons is measured by how you service, and operate this
machine. Know the positions and functions of all controls before you try to operate them. Make sure to check
all controls in a safe area before starting you work.
The safety information given in this manual does not replace safety codes, federal, state or local laws. Make
certain your machine has the proper equipment as designated by local laws and regulations.
A frequent cause of personal injury or death is from persons falling of f equipment and being run over. Do not
permit persons to ride on this machine.
Travel speeds should be such that complete control and machine stability is maintained at all times. Where
possible, avoid operating near ditches, embankments and holes. Reduce speed when turning, crossing slopes
and rough, slick or muddy surfaces.
Make sure that the header is fastened securely to the transport before moving.
Make sure that everyone is clear of equipment before moving the machine. NEVER position yourself under or
near header when mounting on header transport.
Never adjust, service, clean, or lubricate the header transport until all power is shut off.
Make sure that the header transport is fastened securely to the tractor by using a high strength hitch pin, clip
and safety chains.
Before unhooking the header transport from the towing unit, be sure to properly block the wheels to prevent the
transport from moving.
IMPORT ANT : Use caution when transporting. Be alert of the transport unit’ s overall width when approaching
obstacles, such as post signs and poles, along the road. Check the transport width of the unit to ensure
clearance before entering bridges.
COMPLY WITH ALL SAFETY WARNINGS AND CAUTIONS IN THIS MANUAL AND IN THE COMBINE
OPERA TOR’S MANUAL.
WARNING
Be certain all lights are working properly BEFORE highway travel.
Use only 2-5/16” Ball Hitch to transport unit.
6
SAFETY SIGNS
A TTENTION! BECOME ALERT! YOUR SAFETY IS INVOL VED!
Replace Immediately If Damaged or Missing!
IMPORTANT: Install new safety signs if the old signs are destroyed,
lost, painted over or cannot be read. When parts are replaced that
have safety signs, make sure you install a new sign with each new
part. New signs are available from the manufacturer or your
authorized dealer.
SET-UP INSTRUCTIONS
1. Mounting the Rear Axles
Secure the Dura-Flex Rear Axles (61) to the axle mounts
located on the underside of the Header Transport Main Frame
83
48
1
3
5
84
61
6
4
2
(1) using four 5/8” x 1-3/4” Grade 5 bolts (48) with eight 5/8”
flat washers (83) and four 5/8” locknuts (84). NOTE: The
axle should be positioned so the spindle is located toward
the rear of the axle centerline.
Position both axles so
the spindle is located
toward the rear of the axle
centerline.
2. Mounting the Rear Tires
Secure one tire and wheel assembly (18)(16) to each of the
rear hub assemblies using the wheel nuts (17) provided. Use
a star pattern to tighten the spindle nuts according to SAE
standards.
7
SET-UP INSTRUCTIONS (Continued)
3. Mounting the Rear Fenders
A
78 80
79
B
81
82
21
45
47
44
29
73
49
Place one of the Base Fender Support Rail (Left or Right) (45L
and 45R) on top of the two rear axles between the main frame
and spindle as shown. Align the holes in the support rail with
the rear axles and loosely secure to each axle using one 3/8”
x 3 1/2” x 3 1/2” U-Bolt (80), two 3/8” flat washers (78) and two
3/8” lock nuts (79). IMPORTANT: Be sure the vertical face of
the support rail faces the outside of the transport (toward the
tires) and the support rail extends farther behind the second
rear axle (A) than it does the first rear axle (B). If the support
rail does not project farther behind the second rear axle, the
rail is located on the wrong side of the transport and the other
rail should be used.
Repeat on opposite side of transport.
Slide the Fender Support Arm (44) across the header transport
main frame and loosely secure to the Angle Iron Support (49)
using two 1/2” x 1 1/2” Grade 5 bolts (29), two 1/2” washers
(73) and two 1/2” lock nuts (5). Mount the Fender to the top of
the Fender Support Arm using two 3/8” x 1” flange bolt s (21),
two 3/8” rubber/metal washers (81) and two 3/8” whiz nuts
(82). Be sure the side tear drop of the fender is located toward
5
the outside of the transport. Slide the Fender Support Arm
along the main frame until the Fender is centered above the
tires to ensure proper clearance.
Repeat on opposite side of transport.
77
Mount one Fender L-Brackets (77) to each inside end of the
fender using two 3/8” x 1” flange bolt (21), two 3/8” washers
(81) and two 3/8” whiz nuts (82) as shown. Secure the other
side of the L-Bracket to the Base Fender Support Rail using
two 3/8” x 1” flange bolts (21) and two 3/8” whiz nuts (82).
21
7882
45
8221
Repeat on opposite end of fender.
Repeat on opposite side of transport.
8
SET-UP INSTRUCTIONS (Continued)
1
2120811982
Mount two wheel and tires (16)(18) to the hubs on
the Ball Hitch T ongue and Axle Assembly (3). Use a
star pattern to secure the wheel rim to the hub and
tighten to SAE specifications. Once both wheels
are secured to the front axle, raise the spring loaded
pin on the Header Transport Main Frame (1) and
4. Mounting the Front Axle Assembly
3
engage the ball hitch on the Front Axle Assembly.
Once the ball hitch has engaged the locking tube,
161718
lower the spring loaded pin into the hole located on
the Front Axle Assembly to ensure the assembly
from unlatching during transport.
Secure the Front Fenders (19)(20) using four 3/8” x
1” Flange Bolts (21), four 3/8” rubber/metal washers
(81) and four 3/8” Flange Nuts (82).
31
2
28
5. Attaching the Adjustable Brackets and Upper Bar,
Tie-Down Brackets and Adjustable Header Mounts
Straddle each cross frame member of the Header Transport
Main Frame (1) with one Upper Bar Adjustable Bracket (31)
36 35
as shown. Be sure to position and align all Adjustable
1
Brackets at the far right end of the cross frame as necessary .
Secure each Upper Bar Adjust able Bracket (31) to the cross
frame member using the 7/8” x 5-1/2” grade 5 bolts (36) and
7/8” Handle Nuts (35) provided. IMPORTANT: Before
operating the transport, be sure the clamping handle is
extended upward for maximum ground clearance during
transport.
Place the Adjust able Header Mounts (42)
and Tie-Down Bracket Assemblies (39) on
the outside left tube of the Header Transport
28
2
31
Main Frame as shown. Position one
Adjustable Header Mount (42) and Tie-Down
Bracket Assembly (39) on each side of the
31
39
42
42
center cross member. Secure the
Adjustable Header Mount to the outside
tube using one 7/8” x 5-1/2” Grade 5 Bolt
(36) and 7/8” Handle Nut (35). IMPORT ANT :
Before operating the transport, be sure the
clamping handle is extended upward for
maximum ground clearance during
transport.
Secure the Tie-Down Bracket Complete (39) to the outside tube using two 1/2” x 5” Bolts (50) and two 1/2”
Lock Nuts (5). DO NOT OVER TIGHTEN THE 1/2” BOL TS ON THE T OP OF THE ASSEMBL Y, BUT ALLOW
THE TIE-DOWN BRACKETS TO MOVE FREEL Y ALONG THE OUTER TUBE.
Position the Upper Bar (2) on the three Upper Bar Adjustable Bracket s (31) so the front end of the bar is located
adjacent to the front axle as necessary . Secure the Upper Bar at each Upper Bar Mount using the Upper Bar
Clamp (28), two 1/2” Washers (73) and two 1/2” Lock Nuts (5). The angle of the Upper Bar can be adjusted by
removing and repositioning the 5/8” x 6” Hitch Pins (32) in the Upper Bar Adjust able Brackets.
9
SET-UP INSTRUCTIONS (Continued)
55
51
56
49
50
57
53
5
73
67
67
2
68
68
22
66
54
86
87
6. Header Transport Light Kit
Place Extension Bracket Arm (51) at rear end of Upper Bar (2). Att ach using the two Angle Iron Supports (49)
and secure with four 1/2” x 5” bolts (50), four 1/2” washers (73) and four 1/2” lock nuts (5).
Place Light Mounting Bar (53) at the end of the Extension Bracket Arm (51) so the Light Mounting Bar is level
or horizontal and extends towards the center of the header transport. Secure using two 1/2 x 1 1/4” Grade 5
Flange Bolts (86) and two 1/2” Whiz Nuts (87).
Mount each Rear Light Assembly (54)(55) at the end of the Light Mounting Bar (53) so the reflective side lense
is positioned toward the outside of the transport. Secure each light assembly using four small Self-tapping
Screws (27). Secure the Rear Light Panel (56) to the center of the Light Mounting Bar (53) using four 1/4” x 1”
Bolts (58) and four 1/4” Lock Nuts (85).
7. Installing the Light and Electric Brake Wiring Harnesses
A) Insert the Main Wiring Harness, end opposite the 7-Prong Connector End, through the grommet located at
the front of the gooseneck of the Header Transport Main Frame and exit the A-Frame behind the gooseneck.
B) Extend the Main Wiring Harness along the inside right side of the Header Transport Main Frame. Reinsert
the Main Wiring Harness through the opening located along the front of the A-Frame and extend the harness
through the main frame tubing toward the rear of the transport.
C) Exit the Main Wiring Harness at the opening located adjacent to the two rear axles. Extend the Main
Wiring Harness along the top of the front Dura-Flex Rear Axle.
D) Connect the wire to each of the side marker lights located on the outside of the rear fenders and the center
of the Header Transport Main Frame. Extend the wires along the top of the Header Transport Main Frame to
the end of the Main Wiring Harness.
E) Connect the brake wires to each of the brake clusters located on the rear axles and extend the wires along
the top of the Header Transport Main Frame to the end of the Main Wiring Harness.
F) Extend the Light Wiring Harness through the Light Mounting Bar and connect to both the Rear Red Lights
and Light Mounting Bar. Insert the Light Wiring Harness through the Upper Bar and exit at the opening near the
Dura-Flex Rear Axles. Proceed the wire harness along the top of the Header Transport Main Frame to the Main
Wiring Harness.
10
SET-UP INSTRUCTIONS (Continued)
A
B
7. Installing the Light and Electric Brake Wiring
Harnesses (continued)
G) Connect the Rear Brake-Away Kit Wire to the end of
the Main Wiring Harness located at the top of the front
Dura-Flex Rear Axle. Extend the harness through the
Header Transport Main Frame and Connect to the Brake
Away Kit mounted on the inside, right side of the A-Frame.
Connect the Brake-Away Cable to the Break-Away Switch
mounted on the top of the gooseneck and attach to the
rear of the towing vehicle.
H) Secure all wires to the outside of the transport to the
Header Transport Main Frame using the small wire clips
and self tapping screws, and plastic bands provided.
D
E
E
C
E
E
D
25
69
72
66
F
2
67
76
WARNING
* Be certain all lights and brakes are working properly
BEFORE highway travel.
* Use only a 2-5/16” Ball Hitch to transport unit.
45
67
68
66
67
22
26
11
REP AIR PARTS DIAGRAMS
12
REPAIR PARTS LIST
# Part # Description Qty
1 HCM F 1 Header Transport M ai n F ram e
(HS-30B or HS -36B)
2UB-36
UB-874XL
3 BHT-1 Ba ll Hi tch Tongue Compl et e 1
4 124BG5 1/2" x 4" Bol t (G rade 5) 1
5 12LN 1/2" Lock Nut 1
6 F S -HC1 Front Spindle 1
7 02700 1500 Grease Seal 6
8 25580 Large Beari ng (0170012C) 6
9 31603 33 Hub, 6 B ol t, with cups and
10 HCWS -1 W heel S tud 36
11 104082 Sm al l Bearing 6
12 HC-SW Spindle Washer 6
13 SN-HC1 Slotted Spindle Nut 6
14 HC-CP Cotter Pin 6
15 502019 Dust Cap 6
16 WR-156-6HC Wheel Ri m , 15x6 6 hol e, HC 6
17 WN-HC1 Wheel Nut 36
18 15NT 15" New Tire 6
19 FFL-1 F ront F ender (Left ) 1
20 FFR-1 Front Fender (Ri ght) 1
21 381FB 3/8" x 1" F l ange Bolt 8
22 BA K-1C Break A way Ki t Com pl ete 1
23 HS-B 1 Bat tery for B rea k Away Kit 1
24 HS-B B1 Bat tery B ox 1
25 HS-B A S-1 Break Away Swit ch 1
26 BA W-CW 1 Break Away Ki t Connecting
27 STS-1 Self Tapping Screws 4
28 UBC-2 Upper Bar Clamp 3
29 12112BG5 1/2" x 1-1/2" Bol t (Grade 5) 9
30 WF LSA-1 Fender Lower S upport Assy. 2
31 AB -HC1 Ad justable Brac ket s for Upper
32 HP-586 5/8" x 6" Hi t ch Pi n 6
33 316HP 3/16" Hai r P i n 3
34 MB 585 5/8" x 5" Bol t 3
35 78HDN 7/ 8" Handle Nut 8
36 78512BG5 7/8" x 5-1/2" Bol t (Grade 5) 8
37 TDS-1 Tie Down Strap and Hook
38 RA-1 Rat chet A ssembly 2
39 TDB-2 Tie Down Bracket Complete 2
40 CHP-1 Cl aw Hook & Pin Ass em bl y 2
41 3412P 3/ 4" x 12" Pi n 4
42 HM874NS Adj ustabl e Header M ount with
43 126BLN 1/2" x 6" Bolt (Grade 5) 8
Upper Bar (4" x 6" x 36'-0")
(HS-36B)
Upper Bar (4" x 6" x 30'-0")
(HS-30B)
studs
Wires
Bar (2 pcs)
Assembly
Decals
# Pa r t # Descripti o n Qty
1
1
1
2
2
3
2
2
44 FSA-2 Fender Suppo rt Arm 2
45L
BFSR-L
45R
BFSR-R
46 381BG5 3/ 8" x 1" Bol t (G rade 5) 8
47 W F-1 Wheel F ender 2
48 58134B 5/8" x 1-3/4" B ol t 8
49 AIS-2 Angle Iron Support 2
50 125HBN 1/2" x 5" B ol t 4
51 EB -1 Extension B rac ket 1
52 381HBNF 3/8" x 1" F l ange Bolt 2
53 LMB -2 Light M ounting B ar 1
54 RLA-1R Rear Li ght Assembl y (Right ) 1
55 RLA-1L Rear Li ght Assem bl y (Left) 1
56 RLP-1 Rear Light Panel 1
57 LPM B -1 Licens e P l ate Mount i ng
58 141-BLN 1/ 4" x 1" Bol t 8
59 SM L-1 Side M arker Light (F ender) 2
60 SM L-2 Side M arker Light (M ai n
61 7350881 Dura-Flex A xle Weldm ent
62 38-N 3/8" Regular Nut 16
63 3160629G
3160630G
64 3160121G Hub with Brake Drum with
65 RD-SR1 Si l ver/Red Reflective Decal 12
66 MW H-HS Main Wiring Harness 1
67 LW H-HS Light Wiri ng Harness 1
68 BWH-HS Brak e Wi ring Harness 4
69 CBA K -1 Cable for B reak Away Ki t 1
70 SM L-W1 Side Marker Light Wi re
71 SM L-W2 Side Marker Light Wi re (M ai n
72 GR-134 Grommet 1
73 W -12 Regular Was her 4
74 EB SLK-1 E l ectri c Brake Shoe and
75 SC-HS-1 Safety Chain (each) 2
76 UBHC-1 Upper Bar Harness Cover 1
77 FLB -4 F ende r L-Bracke t 4
78 38-FW 3/8" F l at Was her 8
79 38-LN 3/8" Lock Nut 8
80 38312312UB 3/8" x 3 1/2" x 3 1/2" U-B ol t 4
81 38-RMW 3/ 8" Rubber/Met al Was her 12
82 38-W N 3/8" Wh i z Nut 28
83 58-FW 5/8" F l at Was her 8
84 58-LN 5/8" Lock Nut 8
85 14-LN 1/4" Lock Nut 8
86 12114FB G5 1/2" x 1 1/4" Gr 5 Flang e B ol t 2
87 12-W N 1/2" Wh i z Nut 2
Base Fender S upport Rai l (L)
Base Fender S upport Rai l ®
Bracket
Frame)
Complete with Brakes
12" E l ectri c Brake (L/H)
12" Elec t ri c Brake (R/H)
Cups and S tuds
(Fender)
Frame)
Lining Kit (repai r)
1
1
1
2
2
2
2
2
2
4
13
ADJUSTABLE TIE-DOWN BRACKET,
HOOK & STRAP ASSEMBLY (TDB-2)
POSSIBLE HEADER MOUNT POSITIONS FOR
RECTANGULAR, ROUND AND STAND LEG FRAME HEADERS
Possible Header Mount positions for Rectangular Frame
Headers. The Header Mount can be adjusted up, down,
forward or backwards, depending upon the type of header
being transported.
Possible Header Mount positions for Round Frame Headers.
The Header Mount can be adjusted up, down, forward or
backwards, depending upon the type of header being
transported.
Possible Header Mount positions for Stand Leg Headers.
The Header Mount can be adjusted up, down, forward or
backwards, depending upon the type of header being
transported.
14
WARNING
INITIAL OPERATION/MAINTENANCE
BE CERT AIN THA T ALL POWER IS SHUT OFF BEFORE SERVICING THE HEADER TRANSPOR T
Before the header transport is put into service:
Have all danger, warning, caution and import ant signs on the equipment been read and understood? If employees
or others use or are near this equipment, make sure that they also have read and understood all danger,
warning, caution and important signs on the equipment and have also read the operator’s manual.
Are all braces, bolts, nuts, lug bolts and lug nuts properly fastened?
Has the header transport been properly fastened to the towing unit? Use a good quality hitch pin with clip and
safety chains.
SAFETY CHAIN USER INSTRUCTIONS
a) Secure the safety chain by looping it around the tongue support
located on the underside of the Ball Hitch Tongue and connect to
the towing machine’s attaching bar .
b) Do Not allow more slack than necessary for articulation.
c) Do Not use any intermediate support as the attaching point.
d) Store the safety chain by securing it around the tongue.
e) Replace the safety chain if one or more links or end fittings are
broken, stretched or otherwise damaged or deformed.
OPERATING INSTRUCTIONS/MAINTENANCE
Adjust the brackets on the header transport to best fit your make and model header. When mounting the
header, NEVER position yourself under or near the header . Securely fasten the header to the header transport.
Do not exceed the load and size limits of the unit.
Keep the tires properly inflated. Both under inflation and over inflation can greatly reduce tire life.
Inspect bracing and welds periodically and repair immediately if needed. Failure to repair could cause extensive
damage and greatly reduce the life of the unit.
Repack the bearings in the hub assembly once a year or as needed. Use a good quality bearing lubricant such
as Bearing Gard MK1 or equivalent.
Be sure to check the hub nuts often and keep them properly tightened.
BRAKING SYSTEM REQUIREMENTS:
Tow Loads Safely
Stopping dist ance increases with speed and weight of towed loads, and on slopes. T owed loads with or without
brakes that are too heavy for the tractor or are towed too fast can cause loss of control. Consider the total
weight of the equipment and its load.
Observe these recommended maximum road speeds, or local speed limits which may be lower:
If towed equipment does not have brakes, do not travel more than 32 km/h (20 mph) and do not tow
loads more than 1.5 times the tractor weight.
If towed equipment does have brakes, do not travel more than 40 km/h (25 mph) and do not tow
loads more than 4.5 times the tractor weight.
Ensure the load does not exceed the recommended weight ratio. Use additional caution when towing loads
under adverse surface conditions, when turning, and on inclines.
15
REPORTING SAFETY DEFECTS
J. & M. Manufacturing Co., Inc.
P.O. Box 547
Fort Recovery , OH 45846
Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death,
you should immediately inform the National Highway T raffic Safety Administration (NHTSA) in addition
to notifying J. & M. Manufacturing Co., Inc.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect
exists in a group of vehicles, it may order a recall and remedy campaign. However , NHTSA cannot
become involved in any individual problems between you, your dealer, or J. & M. Manufacturing Co.,
Inc.
T o contact NHTSA you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (366-0123 in
Washington, DC area) or write to:
NHTSA
U.S. Department of Transportation
400 7th Street SW , (NSA-1 1)
Washington, DC 20590
Y ou can also obtain information about motor vehicle safety from the Hotline.
16
SERVICE / MAINTENANCE RECORD
DATE DESCRIPTION NOTES
17
Loading...
