LEANER SETUP MANUAL
Detail # |
Description |
Quantity |
1 |
3/8”-16 x 1” serrated flange hex bolt |
118 |
2 |
3/8”-16 x 1” serrated flange hex nut |
108 |
3 |
3/8”-16 x 1” centerlock hex nut |
10 |
NOTE: This is a general list of parts for a leaner. Some of these will be already installed on arrival or installed in sideboard set up. The purpose of this list here is to provide a visual aid along with the previous page.
STEP - 1.0
NOTE
FOR CARTS WITH THE TARP OPTION:
The boxed in area shown above is to show which bolt holes should have rounded head bolts placed in them during assembly. Use rounded head bolts at any location where it is possible that the tarp may hit the bolt head to avoid damage to the tarp during use.
-1-
LEANER SETUP MANUAL
STEP - 1.0
Remove the bolt that holds the two off auger sideboards together for transport.
STEP - 1.0
STEP - 2.0
Install the front corner using 3/8” X 1” bolts and nuts.
-2-
LEANER SETUP MANUAL
STEP - 3.0
Install the back piece to the rear corner using 3/8” X 1” bolts and nuts.
STEP - 1.0
STEP - 3.1
Install the side piece to the rear corner using 3/8” X 1” bolts and nuts.
-3-
LEANER SETUP MANUAL
STEP - 4.0
Fold out the front sideboard.
STEP - 1.0
STEP - 5.0
Insert 3/8” X 1” bolt and nut in adjustment brace and shell bracing. Adjust brace until the carts sidewall is straight.
-4-
LEANER SETUP MANUAL
STEP - 56.10
Install the Front Off Auger Side Brace and bolt with 3/8” X 1”.
STEP - 6.0
Fold out the rear sideboard. Insert bolts and nuts in adjustment braces. Then adjust the braces until the carts sidewall is straight and in line. Complete inserting all bolts to the sideboards and corners and tighten.
-5-
