PowerPlus Amplifiers

420, 840, 900, 1150, 1302, 1304

Installation & Operation Manual

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Features and Specifications . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Speaker Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Indicators and Controls . . . . . . . . . . . . . . . . . . 11

Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Remote Input Level Control . . . . . . . . . . . . . . . 12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 13

CEA Power Output . . . . . . . . . . . . . . . . . . . . . . 14

PowerPlus Amplifiers

Introduction

The Jensen PowerPlus series of amplifiers were designed to meet or exceed the CEA-2006 test standards. These new standards give all participating manufacturers (and many don't participate) a baseline when comparing amplifiers of similar power output. The CEA Power rating protects you, the customer. “Power is power – it doesn't matter who makes it,” is not always true. What does matter is whether the power can be produced in the first place. The RMS rating is the true power you are getting. At Jensen, to be fair to you and to the competition, we rate our amps in the two most popular ratings, including the CEA RMS rating. So feel confident that your Jensen purchase decision was a sound one, and remember "If it's Too Loud, You're Too Old."

Before You Begin

We need to get the legal stuff out of the way, so please keep reading. Afterwards, you’ll be armed with the knowledge to install your new hard-hitting, speaker-pumping Jensen amplifier.

Exposure to loud sounds or music can permanently damage your hearing. Unfortunately, in many cases, the damage is not noticeable until years later. In addition, loud music may hinder your ability to hear traffic, police, and fire or emergency vehicles. Please be responsible and have respect for other people by listening at moderate volumes!

Warranty Service

If your Jensen amplifier should ever require service, you will need the original dated receipt. If you must return the unit for any reason, always include the receipt with the product.

2

Features and Specifications

Your new PowerPlus Jensen mobile stereo power amplifier is the amplifier of choice for the high demands of auto sound reproduction. With its deep-bass reproduction and plenty of reserve power, low harmonic distortion and neutral reproduction, the PowerPlus series of amplifiers takes Mobile Hi-Fi to new heights. Like all Jensen products, when it comes to accurate sound reproduction the PowerPlus series takes a back seat to no one. Jensen will bring your Hi-Fi experience to new heights with the following features:

Low profile Aluminum extruded heat sink

Pass-Thru RCA's

Variable Bass EQ 0 - 12dB @ 45Hz

12dB / octave Low Pass and High Pass filters

Variable Input Level 400mV - 5V

Encapsulated power and speaker connectors

Short circuit, DC-offset and Thermal Overload protection circuitry

Blue illuminated VU level meter(s)

Diagnostic LED's - Green: Power, Red: Standby / Fault

PowerPlus 420 / 840 / 1304

Low Pass filter 40 - 240Hz

High Pass filter 40 - 400Hz

High Pass/Low Pass/Full Range selector switch

Stereo/Mono Mode switch (PowerPlus 420)

2/3/4 Channel Mode switch (PowerPlus 840 and 1304)

PowerPlus 1302

Low Pass filter 50 - 250Hz

High Pass filter 40 - 500Hz

High Pass / Low Pass / Full Range selector switch

Stereo/Mono Mode switch

Remote Input Level Control w/ 5 meter interface cable

PowerPlus 900 / 1150

Mono subwoofer amp

Low Pass filter 40 - 250Hz

Subsonic filter 10 - 40Hz, 12dB / octave

Remote Input Level Control w/ 5 meter interface cable

Specifications

PowerPlus 420 / 840 / 1302 / 1304

• Load Impedance: 2-4ohm

PowerPlus Amplifiers

Signal to Noise @ 1 kHz: >100dB (rated power)

Channel Separation @ 1 kHz: >60dB

Frequency Response: 5-60 kHz, -3dB

Input Impedance: 20 kHz, nominal

THD+N @ 5 watts: 0.02%, 1 kHz, 14.4VDC

PowerPlus 900 / 1150

Signal to Noise @ 125Hz: >100dB (rated power)

Channel Separation not applicable

THD+N @ 5 watts: 0.02%, 125Hz, 14.4VDC

Power Output

RMS Power Output @ 2% THD+N, 1kHz, 14.4VDC

PowerPlus 420

75 x 2 Watts, 4-ohm

110 x 2 Watts, 2-ohm

210 x 1 Watts, 4-ohm Bridged

PowerPlus 840

75 x 4 Watts, 4-ohm

110 x 4 Watts, 2-ohm

210 x 2 Watts, 4-ohm Bridged Stereo

PowerPlus 900

275 x 1 Watts, 4-ohm

450 x 1 Watts, 2-ohm

PowerPlus 1302

195 x 2 Watts, 4-ohm

320 x 2 Watts, 2-ohm

650 x 1 Watts, 4-ohm Bridged

PowerPlus 1304

125 x 4 Watts, 4-ohm

160 x 4 Watts, 2-ohm

325 x 2 Watts, 4-ohm Bridged Stereo

PowerPlus 1150

350 x 1 Watts, 4-ohm

575 x 1 Watts, 2-ohm

Specifications subject to change without notice.

3

PowerPlus Amplifiers

Installation

Before you begin the installation of your PowerPlus series amp remember, there are two ways to do things – right and twice! Use the proper installation techniques, tools and accessories to ensure that your Jensen PowerPlus series amp will put out all the power it was designed to. If necessary, seek a professional installer to have the amplifier installed correctly. Most mobile amp installations do not have the proper gauge wire for power and ground – do not let your amp be a victim of this common installation oversight!

NOTE: This device is a high-power audio amplifier intended for installation in vehicles with a 12-Volt negative ground electrical system. Attempting to connect or operate the amplifier with another type of electrical system may cause damage to the amplifier or the electrical system.

Installation Assistance

For installation assistance, call 1-800-323-4815 during normal business hours, or visit www.jensen.com at any time.

Supplies and Tools Needed

To install the amplifier, you will need tools, supplies and adapters. It is best to make sure you have everything you need before you start.

going to the vehicle chassis) and make sure the battery is grounded to the chassis with at least a #8 gauge wire. Also check the alternator connections, making sure they are tight and free from corrosion, rust or dirt.

Location and Mounting

The amplifier’s compact design allows great flexibility in mounting. Common mounting locations include under the front passenger seat or in the trunk area.

When selecting a location, remember that amplifiers generate heat. Select a location on a flat surface away from heat and moisture where air can circulate around the amplifier.

Place the amplifier in the mounting location and mark the positions of the holes with a marker, pen or pencil. Carefully drill the mounting holes in the marked positions, then use the supplied mounting screws to securely fasten the amplifier to the mounting surface.

WARNING: Do not cover the amplifier with carpets or enclose it behind interior trim panels, and do not mount the amplifier in an inverted or upside down configuration. Be sure the mounting location and the drilling of pilot holes will not damage any wires, control cables, fuel lines, fuel tanks, hydraulic lines or other vehicle systems or components.

Supplies

Black electrical tape

Amplifier Installation Kit

Tools

Cordless drill with assortment of bits

Flat-head and Philips screwdrivers

Wire cutters/strippers

Crimping tool

12-volt test light or digital multimeter

Wire brush, sandpaper or scraping tool (ground connection to vehicle should be a clean, unpainted metal surface)

Routing Wires

Proper wiring connections are illustrated on the following pages. If wiring connections are made incorrectly, the unit will not operate properly and could become permanently damaged. Follow the installation instructions carefully, or have the amplifier installed by an experienced technician.

Disconnect Battery

Disconnect the negative (-) battery cable before starting the installation. Check the battery ground (there should be two (2) ground wires coming from the battery – one going to the starter mounting bolt or engine block and another

4

Power Wiring

Charging System

In some cases, the installation of just one (1) amplifier could be enough to overload your factory electrical system (i.e., alternator). Depending on the state of your electrical system and overall condition of your vehicle, you may need to upgrade your alternator and battery. After the vehicle is started, the alternator provides the power to your electrical system, not the battery. When the engine is running, the alternator is your main source of power. Upgrading the alternator should be your first consideration if you should experience a voltage drop in the system when operating your audio system. Adding capacitors and/or batteries without upgrading the alternator will only make the problem worse because these devices put an extra load on the alternator. After upgrading the alternator, capacitors and/or batteries can be installed if desired.

Use the following recommended wire gauge as a guide when installing your amplifier(s):

MODEL NUMBER

MAX CURRENT DRAW

MIN WIRE GAUGE













420

30A

#8







840

50A

#8







900

90A

#4







1150

120A

#4







1302

60A

#6







1304

80A

#8







PowerPlus Amplifiers

Power Terminal (+12V/B+)

Connect the main power wire to the battery, within 18 inches from the positive

(+) battery post, using an adequate size fuse or circuit breaker capable of handling the current of the selected power wire. A fuse or circuit breaker must be installed to prevent a possible electrical fire should the main power wire short to ground.

Battery Terminal

Fuse or Circuit Breaker

Adaptor

Install as close to the battery as possible.

Remote Terminal (REM)

Connect the power antenna or amplifier turn-on lead from the receiver to the amplifier remote terminal.

Remote Turn-On (Power Antenna)





CD

2620











TRBE











BA

S



















i

CD

RECEIVER

40













WATTSx4























1















2















3















4

















5

















6



5

PowerPlus Amplifiers

Ground Terminal (GND)

Make the ground lead as short as possible, leaving enough length to complete the installation and to allow for any service that may be needed at a later date. To ensure a good ground, scrape away any paint or undercoating to expose bare metal. Use a "ring" terminal of the proper gauge and an "outside star washer" (between the chassis and ring terminal) when making your ground connection. Although you’ve scraped away the paint to expose bare metal, the outside star washer will help to "bite into" the chassis for a tight, secure ground.

Drill hole in chassis sheet metal.

Replacement Fuse Requirements (FUSE)

Model

Quantity

Amps

Type

















420

2

15

ATO









480

2

25

ATO









900

3

30

ATO









1150

4

30

ATO









1302

1

60A

MAXI









1304

1

80A

MAXI









6

Speaker Wiring

The Speaker Wiring diagrams illustrate options for connecting one or two speakers. Observe the proper speaker polarity.

NOTE: PowerPlus amplifiers can drive speakers with a nominal impedance range of 2~ 4-ohms. For maximum power, configure your speakers for a nominal 2-ohm load.

NOTE: Do not overlook the use of the proper gauge speaker wire. The PowerPlus series of amplifiers require a minimum of 12-gauge wire.

PowerPlus 900/1150

Two Subwoofers

One Subwoofer





– – + +

– – + +

SPEAKER OUTPUT

SPEAKER OUTPUT

2 ohm nominal

4 ohm nominal





PowerPlus Amplifiers

PowerPlus 420/1302



Two Speakers

One Subwoofer

2 ohm nominal

4 ohm nominal



Tri-Mode

L

Inductor

C

HPF LPF FULL

C L

Capacitor

4 ohm minimum

7

PowerPlus Amplifiers

PowerPlus 840/1304



Two Speakers and Bridged Subwoofer



Four Speakers











HPF LPF OFF

HPF LPF OFF

HPF LPF OFF

HPF LPF

OFF







SPEAKER OUTPUT

SPEAKER OUTPUT

+ CH1 – + CH2 – + CH3 – + CH4

+ CH1 – + CH2 – + CH3 – + CH4







+ BRIDGED – +

BRIDGED –

+ BRIDGED – + BRIDGED –

4 ohm nominal

2 ohm minimum

4 ohm nominal

4 ohm nominal

4 ohm nominal

2 ohm minimum

2 ohm minimum

Two Subwoofers

HPF LPF OFF HPF LPF OFF

SPEAKER OUTPUT

+ CH1 – + CH2 – + CH3 – + CH4

+ BRIDGED – + BRIDGED –

4 ohm nominal

4 ohm nominal

8

Input Wiring

Most trunk/hatchback installations will require a 15-20 foot RCA cable, while pickup trucks and under-seat mounting will require a 6-12 foot RCA cable. Connect an RCA cable from your receiver to the RCA input on your amplifier.

PowerPlus Amplifiers

PowerPlus 840/1304

The PowerPlus 1304 and 840 can be configured for three different input modes: 2 channel, 3 channel or 4 channel.

PowerPlus 420/900/1150/1302

























Input Wiring - Stereo Mode









2 Channel



























RCA Cable











MODE













CAR STEREO /











4 3 2













SOURCE UNIT

























Input Wiring - Mono Mode



MODE























4 3 2





CH4

CH2























CH3

CH1













HPF LPF OFF 40Hz

240Hz

40Hz 400Hz

0dB 12dB

5V

0.4V

5V

0.4V

0dB 12dB

40Hz

400Hz

40Hz 240Hz

HPF LPF OFF

X-OVER LPF

HPF

BASS EQ

GAIN

3/4 INPUT OUTPUT 1/2 INPUT GAIN

BASS EQ HPF

LPF

X-OVER

RCA Cable

























CAR STEREO /

























SOURCE UNIT

























3 Channel

MODE











4

3

2













MODE



























CH3



CH1













4

3 2



























CH4



CH2









HPF LPF OFF

40Hz 240Hz

40Hz

400Hz

0dB 12dB

5V 0.4V



5V 0.4V

0dB 12dB

40Hz 400Hz

40Hz 240Hz

HPF LPF OFF

X-OVER

LPF

HPF

BASS EQ

GAIN 3/4 INPUT OUTPUT

1/2 INPUT GAIN

BASS EQ

HPF

LPF

X-OVER

9

PowerPlus Amplifiers

4 Channel



MODE



4 3 2

MODE



CH3

CH1

4 3 2

CH4

CH2

HPF LPF OFF

40Hz 240Hz

40Hz 400Hz

0dB 12dB

5V 0.4V

5V 0.4V

0dB 12dB

40Hz 400Hz

40Hz 240Hz

HPF LPF OFF

X-OVER

LPF

HPF

BASS EQ

GAIN

3/4 INPUT OUTPUT 1/2 INPUT GAIN

BASS EQ

HPF

LPF

X-OVER

NOTE: The use of good quality RCA cables is just as important as power and speaker wire. Choose a high quality low capacitance cable for the best results.

Connecting Additional Amplifiers

Pass-Thru RCA connectors are provided to connect additional amplifiers without the need to purchase "Y" adapters.

10

Indicators and Controls

Power Indicator (POWER)

The power indicator provides a visual indication that the amplifier is turned on.

Input Level Control (LEVEL/GAIN)

The INPUT LEVEL control (or GAIN) matches the output of your radio to the input of the amplifier. After the installation is complete, make sure the input level control on the amplifier is turned down all the way (counter-clockwise or all the way to the left). Play a tape or CD (make sure bass and treble settings or Bass EQ are flat) and turn the volume up slowly until you just start to hear distortion. Back the volume down just a bit. On the amplifier, slowly turn up the input level control (clockwise or to the right) until you just start to hear distortion, then back it down a bit. Now your radio and amplifier levels are matched.

BASS EQ

The Bass EQ is continuously adjustable from 0 to +12dB @ 45Hz. Adjusting the Bass Boost level allows different subwoofer/enclosure combinations to be equalized. Use this control to increase the level of low bass available from your subwoofer/enclosure combination. Ported and Band Pass enclosures should be limited to about +6dB to +9dB of boost. Sealed enclosures should be able to accept the full +12dB of boost, if necessary. The full +12dB of boost should be reserved for special applications since improper use of the Bass Boost could damage your subwoofers at high volumes.

PowerPlus Amplifiers

speakers (6 1/2", 6 X 9", etc.) by adjusting the crossover to a higher setting (80–100Hz).

Crossover (X-OVER)

The Jensen PowerPlus series of amplifiers have built-in low-pass and highpass crossover filters for bi-amplifying the system. Adjust the crossover to accommodate your chosen installation method. Select LPF (low pass filter) when the amplifier will be driving woofers or subwoofers. Choose FULL or OFF when crossover mode is not active and the amplifier is in “full range” mode. Select HPF (high pass filter) when the amplifier will be driving full-range or separate speakers, and you want to limit the “bass” being transferred to these speakers.

Mode Switch

PowerPlus 420 and 1302

The 420 and 1302 come equiped with a ST/MO (stereo/mono) MODE switch. Use STEREO mode when you have a 2-channel input from the source unit. Use MONO mode when you have a single input from the source unit. See “Input Wiring” on page 9.

PowerPlus 840 and 1304

The 840 and 1304 come equiped with a 4/3/2 MODE switch and can be configured for three different input modes: 2 channel, 3 channel or 4 channel.

Low Pass Filter (LPF)

The Low Pass Filter controls adjust the crossover point. Typical crossover is between 60Hz and 80Hz for ported and sealed enclosures. Bandpass boxes will typically use a higher crossover setting between 125Hz and 150Hz. Since musical tastes vary, you should play music that you would normally listen to in your vehicle, with the above settings as a starting point. If necessary, set the crossover by ear.

High Pass Filter (HPF)

The high pass filter will limit the low frequencies being transmitted to your speakers. This can be useful in number of situations. For example, if you selected the high pass filter and set the crossover to 40Hz, then you would have an infra-sonic (sub-sonic) filter at 40Hz, which would be useful with certain enclosure/subwoofer combinations that were tuned between 45Hz and 50Hz. Other uses might include limiting the low frequencies to smaller

11

PowerPlus Amplifiers

Testing

Before finishing the installation, perform the following tests to make sure the wiring is correct and everything is operating properly.

Reconnect Battery

When wiring is complete, reconnect the battery negative terminal.

Test Power Wiring

Turn on the receiver, but do not turn up the volume. The amplifier power light should come on. If not, check the REM and +12V (B+) wires. Turn up the receiver volume slightly. All speakers should operate. If not, check wiring connections at amplifier and speakers.

Test Speaker Connections

These tests make sure the speakers are connected properly. If speakers don’t play at all, one (or both) speaker wires may be disconnected.

Remote Input Level Control

The PowerPlus 900, 1150 and 1302 come equipped with a Remote Input Level Control. The Remote Input Level Control allows the input level to be adjusted from an alternate location. It can be mounted under-dash or in-dash. When the amplifier is used to drive subwoofers and the low pass crossover is activated, the Remote Input Level Control can be used as a “remote bass level control”. This enables you to control the bass level independent from the rest of the system. This is convenient for system tuning and/or when playing many different types of music.

The Remote Input Level Control uses a 6-pin modular cable for connectivity. Simply plug the 6-pin modular cable into the amplifier and then into the Remote Input Level Control to activate the circuit.

Power

Min Max

50

250

500

12

Troubleshooting

Problem

Possible Cause

Corrective Action

Amplifier does not

No power to +12V

Check fuse(s)

turn on

terminal





No power to REM

Check head unit fuse(s) and



terminal

wiring



Blown main fuse at

Replace fuse and identify



battery

cause of failure



Blown fuse at amplifier

Replace fuse and identify





cause of failure



Faulty ground

Re-ground main power





ground to bare metal





chassis

Volume control too

Input level control

Re-adjust the input level

sensitive

adjusted too high

(refer to page 8)

Distorted sound

Input level control

Re-adjust the input level



adjusted too high

(refer to page 8)

Blows fuse(s) at amp

Power wires connected

Reconnect power wires



backwards

properly



Internal problem with

Take unit for service



amp



Engine noise /

Ground loop(s)

Use good quality shielded

Alternator whine



RCA cables



Faulty ground at amp

Re-ground amp to clean





bare metal chassis



Faulty ground at head

Re-ground head unit to



unit

clean bare metal chassis



Inductive coupling

Re-route RCA and/or





speaker wires away from





factory harnesses



Input level on amp set

Re-adjust input level (refer



too high

to page 8)

Thermal protection

Amplifier driving 2 ohm

If the amplifier “thermals”

activated

load for long durations

frequently while driving





subwoofers, install fan to





keep amp cool.

13

PowerPlus Amplifiers

Short circuit

Blown speakers

Check all speakers

protection activated





Speaker wire(s) shorting

Check for faulty wiring



to ground





Defective crossover

Faulty passive crossover

Low impedance

Amp connected to

Check speaker connections

protection activated

improper load





Amp will not drive a 1

Verify that speakers are



ohm mono load, 2 ohm

connected properly



minimum in mono





configuration





Speakers defective/

Check speakers



blown





Faulty passive

Check crossovers



crossovers



Poor bass response

Speakers out of phase

Check speaker polarity;





reverse the connection to





one speaker only if two





subwoofers are connected





to the amplifier.

NOTE: If the protection light is activated with no speakers connected to the amplifier, and all the power connections are correct, this would indicate an internal problem with the amplifier.

PowerPlus Amplifiers

CEA Power Output

RMS Power Output @ 1% THD+N, 14.4VDC

PowerPlus 420

Power Output: 65 watts RMS X 2 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

90 watts RMS X 2 channels into 2-ohms @ < 1% THD+N

170 watts RMS X 1 channels (Bridged Mono) into 4-ohms @ < 1% THD+N Frequency Response: 10Hz to 60 kHz, -3dB (Reference: 1 watt) Dimensions: L10.5" x H2.5" x W11.75"

PowerPlus 840

Power Output: 70 watts RMS X 4 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

100 watts RMS X 4 channels into 2-ohms @ < 1% THD+N

175 watts RMS X 2 channels (Bridged Stereo) into 4-ohms @ < 1% THD+N Frequency Response: 10Hz to 60 kHz, -3dB (Reference: 1 watt) Dimensions: L14" x H2.5" x W11.75"

PowerPlus 900

Power Output: 260 watts RMS X 1 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

430 watts RMS X 1 channels into 2-ohms @ < 1% THD+N Frequency Response: 10Hz to 240Hz, -3dB (Reference: 1 watt) Dimensions: L17.25" x H2.5" x W11.75"

PowerPlus 1150

Power Output: 330 watts RMS X 1 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

550 watts RMS X 1 channels into 2-ohms @ < 1% THD+N Frequency Response: 10Hz to 240Hz, -3dB (Reference: 1 watt) Dimensions: L19" x H2.5" x W11.75"

PowerPlus 1302

Power Output: 175 watts RMS X 2 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

280 watts RMS X 2 channels into 2-ohms @ < 1% THD+N

570 watts RMS X 1 channels (Bridged Mono) into 4-ohms @ < 1% THD+N Frequency Response: 10Hz to 60 kHz, -3dB (Reference: 1 watt) Dimensions: L15.5" x 2.5" x 11.75"

PowerPlus 1304

Power Output: 117 watts RMS X 4 channels into 4-ohms @ < 1% THD+N Signal to Noise Ratio: 100dBA below reference (Reference: 1 watt, 4-ohms)

Additional Power Output:

145 watts RMS X 4 channels into 2-ohms @ < 1% THD+N

290 watts RMS X 2 channels (Bridged Stereo) into 4-ohms @ < 1% THD+N Frequency Response: 10Hz to 60 kHz, -3dB (Reference: 1 watt) Dimensions: L15.5" x 2.5" x 11.75"

Audiovox Electronics Corporation

Hauppauge, NY 11788

1-800-323-4815 www.jensen.com

© 2006 Audiovox

v. 111806

14
