MP5OOO Quick Reference Guide
CD Player Controls
MUTE: Press to
MUTE audio.
TUNE/TRACK:
Press UP or DOWN
to tune to next track.
Press & hold UP
or DOWN to FAST
FORWARD or REWIND
current track playing.
PLAY/PAUSE:
Press to PLAY or
PAUSE current audio.
INTRO SCAN: Press when
CD is playing to play each
track for 10 seconds in sequential order. Press again
to SELECT current song.
RPT: Press to
REPEAT current
playing track. Press
to release function.
RDM: Press when CD is
playing to play each track
in RANDOM order. Press
again for NORMAL play.
EJECT: Pres s to
EJECT CD.
STOP: Press to
SUSPEND disc play.
Press PLAY/PAUSE
to RESUME disc play.
AM/FM Tuner Controls
AS/PS: Press to
SCAN through
currently stored
presets. Press &
hold to STORE
strongest broadcast stations in
your area.
MUTE: Press to
MUTE audio.
AM/FM: Press to directly
access TUNER MODE.
Press to select between
two AM BANDS (AM1 &
AM2) & three FM BANDS
(FM1, FM2, & FM3).
TUNE/TRACK: Press UP
or DOWN to tune to next
station. Press & hold Up
or DOWN to SEEK to
next strong station.
STATION STORE BUTTONS:
Press & hold to store current channel playing. Momentarily press to recall stored channel.
NOTE: you can store up to 30 channels (5 channels per band FM1, FM2, FM3, AM1, AM2).
Basic Operation
Power On/Of f:
Push to turn
ON or OFF.
AUDIO: With each
press of the button
choose from the
following AUDIO
ADJUSTMENT
options: VOLUME,
BASS, TREBLE,
BALANCE (left to
right), & FADER
(front to back).
MUTE: Press to
MUTE audio.
SPEAKER OUTPUT:
Press any speaker
button (SPEAKER A,
SPEAKER B, or
SPEAKER C) to control
corresponding speaker
output from the stereo.
Red light above each
button will illuminate
when selected speaker
is turned on.
Page 2
DVD Player Controls
MUTE: Press to MUTE audio.
ENTER: Press to
SELECT menu option.
PLAY/PAUSE:
Press to PLAY or
PAUSE current audio.
LANG: Press to select
AUDIO LANGUAGE.
MENU: Press to
return to root menu.
EJECT: Pres s to EJECT DVD.
STOP: Press to
SUSPEND disc play.
Press PLAY/PAUSE
to RESUME disc play.
Clock Settings
TUNE/TRACK:
Press UP or DOWN
to INCREASE or
DECREASE the
hour & minutes
onc e in clock mode.
T/F: Press & hold
to enter CLOCK
SETTING MODE.
Press & release to
switch the display
from frequency/
track to TIME.
©
Copyright 2007 ASA, LLC
JEN5000 - 307
EJECT: Pres s to EJECT DVD.
MUTE: Press to MUTE audio.
PLAY/PAUSE: Press to PLAY or PAUSE current audio.
TITLE: Press to enter TITLE MENU. Use the DIRECTIONA L
ARROWS to choose menu item. Press ENTER to select.
ZOOM: Press to ZOOM in on cur rent picture.
Press repeatedly to change MAGNIFICATION LEVEL of current pic ture.
ANGLE: Pre ss to select dif ferent visual angle if stored on DVD.
LANG: Press to select AUDIO LANGUAGE.
ENTER: Press to select menu option.
DIRECTIONAL ARROWS: Press to move
cursor to desired MENU ITEM. Press ENTER
to select desired MENU ITEM.
STOP: Press once SUSPEND disc play.
Press PLAY/PAUSE to RESUME disc play.
Press twice to completely stop disc play.
CHAPTER SKIP: Pres s to skip to NEXT or PREVIOUS chapter.
FAST FORWARD/REWIND: Press to FAST FORWARD or REWIND
current play. Continue to press to enhanc e the speed.
Press PLAY/PAUSE to resume current play.
GOTO: Press to view CHAPTER, TR ACK, & TIME. Press again to c lear.
DISPLAY: Press to DISPLAY cur rent playback information on the scr een.
SETUP: Press to enter SETUP MENU.
SUBTITLES: Press to select CLOSED CAPTIONING.
Continue to press to select AUDIO LANGUAGE.
DVD Remote Controls
