Jeep Grand Cherokee SRT 2009 Quick Reference Guide
2009
QUICK
REFERENCE
GUIDE
GRAND
CHEROKEE
vehicle features
FUEL CAP:
LOOSE GAS CAP MESSAGE
• If a “CHECK GASCAP” message appears in the Electronic Vehicle
Information Center (EVIC), tighten the gas cap until a “clicking”
sound is heard.
• If the message continues to appear for more than three days after
tightening the gas cap, see your dealer.
TIRE PRESSURE MONITORING
SYSTEM (TPMS):
• A Tire Pressure Monitoring Light and a “low tire” message will display
in your instrument cluster along with an audible chime if one or more of
your vehicle’s four road tires are signicantly under-inated.
• Check the ination pressure of each tire and inate to the recommended
pressure for your vehicle. The tire pressures recommended for your
vehicle are found on the “Tire and Loading Information” label located on
the driver’s side door opening. The TPMS light should not be used as a
tire pressure gauge when adjusting your tire pressure.
• It is recommended that you check the tire pressure in the morning
when tires are cool; inate each tire to the recommended pressure for
your vehicle. The light will turn off after your vehicle’s tire pressures are
properly inated and the pressure has been recognized. The vehicle may
need to be driven for up to 20 minutes above 15 mph (25 km/h) before the
light will turn off.
• T
emperature changes can affect tire pressure, causing the TPMS light
to turn on. Tire pressures will also increase as the vehicle is driven - this
is normal and you should not adjust for this increased pressure.
• Driving on under-inated tires reduces your vehicle’s fuel efciency and
tire tread life. If a spare tire is in use on the vehicle, the TPMS light may
turn on. Refer to your Owner’s Manual.
OIL CHANGE INDICATOR:
MESSAGE
• A “CHAngE OIL” or “Oil Change Required” message will illuminate and a
single chime will sound when it is time for your next required oil change.
RESETTING LIGHT AFTER SERVICING
• Turn the ignition switch to the ON/RUN position (do not start engine).
• Fully depress the accelerator pedal three times within 10 seconds.
• Turn the ignition switch to the OFF/LOCK position.
Rotate Temp. Control
Press A/C
Button
Press Rear W in dow
Defroster Button
Rotate Blower Control Rotate Mode Control
MANUAL CLIMATE CONTROLS:
AIR RECIRCULATION
• Use recirculation for MAX A/C operation.
• For window defogging, turn recirculation off.
• Recirculation is not allowed in defrost, oor, defrost/oor (mix) modes.
DRIVER MEMORY SEAT:
• T he memory seat feature allows you to save two different driver
seating positions. The memory seat switches are located on the
driver’s door panel. With the key in the ON/RUN position,
push , then push 1 or 2 within ve seconds.
• P ush 1 or 2 to recall the saved positions.
• K ey Fobs may be programmed to automatically recall position
1 or 2 when UNLOCK is pushed.
• R efer to your Owner’s Manual for further details.
Recirc.
AUTOMATIC TEMPERATURE
CONTROLS (ATC):
AUTOMATIC OPERATION
• Turn the Mode Control to the AUTO position and the Blower Control to
either LO AUTO or HIGH AUTO position.
• Select the desired temperature by rotating the Temperature Control.
• The system will maintain the set temperature automatically.
AIR CONDITIONING
• If the air conditioning button is pressed while in the AUTO mode, the
indicator light may ash three times to indicate the air conditioning is
being controlled automatically.
AIR RECIRCULATION
• Use recirculation for MAX A/C operation.
• For window defogging, turn air recirculation off.
• If the recirculation button is pressed while in the AUTO mode, the
indicator light may ash three times to indicate the cabin air is being
controlled automatically.
WIND BUFFETING:
• Wind buffeting can be described as a helicopter-type percussion sound.
If buffeting occurs with the rear windows open, adjust the front and rear
windows together.
• If buffeting occurs with the sunroof open, adjust the sunroof opening,
or adjust any window. This will minimize the buffeting.
Rot ate Blo we r
Control
Press A/C
Button
Press Air Recirc.
Button
Rotate Driver
Temp. Control
Rotate Passenger
Temp. Control
Press Rear Window
Defroster Button
Rotate Mode
Control
