2O1O

Commander

USER

GUIDE

GO ANYWHERE

IMPORTANT: This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual, Navigation Radio or Multimedia Radio

Manual, Warranty Booklets, Tire Warranty and 24-Hour Towing Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you nd it useful. If you are the rst registered owner of your vehicle, you may obtain a printed copy of the Owner’s Manual, Navigation Radio or Multimedia Radio Manual or

Warranty Booklet by calling 1-800-992-1997 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer. Replacement manuals may be purchased by visiting www.techauthority.com.

Jeep

TABLE OF CONTENTS

INTRODUCTION/WELCOME

WELCOME FROM

CHRYSLER GROUP LLC .......... 2

CONTROLS AT A GLANCE

DRIVER COCKPIT .............. 4

INSTRUMENT CLUSTER .......... 6

GETTING STARTED

KEYFOB .................. 8

THEFT ALARM ............... 9

SEAT BELT ................. 9

FRONT SEATS ...............10

REAR SEATS ................13

TILT/TELESCOPING STEERING

COLUMN ..................15

ADJUSTABLE PEDALS ...........16

PROGRAMMABLE FEATURES .......16

OPERATING YOUR VEHICLE

TURN SIGNAL/LIGHTS LEVER .......17

WIPER/WASHER LEVER ..........18

SPEED CONTROL LEVER .........19

ELECTRONIC RANGE SELECT (ERS) . . . 20

MANUAL CLIMATE CONTROLS ......20

AUTOMATIC TEMPERATURE CONTROLS

(ATC) ....................21

PARKSENSE PARKVIEW®REAR BACK-UP CAMERA . . 22

POWER LIFTGATE .............23

LIFTGATE FLIPPER GLASS ........23

POWER SUNROOF .............23

WIND BUFFETING .............24

REAR PARK ASSIST ....22

ELECTRONICS

NON-TOUCH-SCREEN RADIOS ......25

TOUCH-SCREEN RADIOS .........27

REMOTE AUDIO CONTROLS ........31

VIDEO ENTERTAINMENT SYSTEM

(VES)™ ...................31

ELECTRONIC VEHICLE INFORMATION

CENTER (EVIC) ...............33

UNIVERSAL GARAGE DOOR OPENER . . . 33

POWER INVERTER .............34

POWER OUTLET ..............35

uconnect™ phone .............35

VOICE RECOGNITION ............37

OFF-ROAD CAPABILITIES

FOUR-WHEEL DRIVE OPERATION .....38

UTILITY

INTERIOR STORAGE COMPARTMENTS . . 40

TRAILER TOWING WEIGHTS (MAXIMUM

TRAILER WEIGHT RATINGS) ........41

RECREATIONAL TOWING (BEHIND

MOTORHOME, ETC.) ............42

BRAKE/TRANSMISSION INTERLOCK

MANUAL OVERRIDE ............43

WHAT TO DO IN EMERGENCIES

24 HOUR TOWING ASSISTANCE ......44

INSTRUMENT CLUSTER WARNING

LIGHTS ...................44

IF YOUR ENGINE OVERHEATS .......47

JACKING AND TIRE CHANGING ......48

JUMP-STARTING ..............51

EMERGENCY TOW HOOKS .........53

TOWING A DISABLED VEHICLE ......54

EVENT DATA RECORDER (EDR) ......55

MAINTAINING YOUR VEHICLE

OPENING THE HOOD ............56

ENGINE COMPARTMENT .........57

FLUIDS AND CAPACITIES .........59

MAINTENANCE CHART ..........60

FUSES ...................62

TIRE PRESSURES .............67

WHEEL AND WHEEL TRIM CARE .....68

EXTERIOR BULBS .............68

CONSUMER ASSISTANCE

CHRYSLER GROUP LLC CUSTOMER

CENTER ...................69

CHRYSLER CANADA INC. CUSTOMER

CENTER ...................69

ASSISTANCE FOR THE HEARING

IMPAIRED ..................69

PUBLICATIONS ORDERING ........69

REPORTING SAFETY DEFECTS IN THE 50 UNITED STATES AND

WASHINGTON, D.C. ............70

TIRE WARRANTY ..............70

MOPAR ACCESSORIES

MOPAR®ACCESSORIES ..........73

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER GROUP LLC

Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles.

IMPORTANT: This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual, Warranty Booklets, Tire Warranty, and 24 Hour Towing Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you find it useful. Retail customers may obtain a printed copy of any of these booklets, call 1-800-890-4038 (U.S.) or 1-800-387-1143 (Canada) or ask your dealer.

For complete owner information, refer to the DVD in the owner’s kit provided at the time of new vehicle purchase. For your convenience, the information contained on the DVD may also be printed and saved for future reference.

Not all features shown in this guide may apply to your vehicle.

Chrysler Group LLC is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on our environment.

Vehicles Sold In Canada

With respect to any Vehicles Sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefore.

Driving And Alcohol

Drunken driving is one of the most frequent causes of accidents.

Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you are drinking, don’t drive. Ride with a designated non-drinking driver, call a cab, a friend, or use public transportation.

WARNING!

Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower, and your judgment is impaired when you have been drinking. Never drink and then drive.

This guide illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This guide may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this guide that are not available on this vehicle. Chrysler Group LLC reserves the right to make changes in design and specifications and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

INTRODUCTION/WELCOME

Rollover Warning

WARNING!

Never use the ‘PARK’ position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

CAUTION!

Never park your vehicle over dry grass or other combustible materials. The heat from your vehicle exhaust system could cause a fire.

CHRYSLER, DODGE, JEEP, ATF+4, MOPAR and uconnect are registered trademarks of Chrysler Group LLC.

CONTROLS AT A GLANCE

DRIVER COCKPIT

CONTROLS AT A GLANCE

INSTRUMENT CLUSTER

Warning Lights

- Low Fuel Warning Light

- Charging System Light**

- Oil Pressure Warning Light**

- Anti-Lock Brake (ABS) Light**

- Airbag Warning Light**

- Electronic Throttle Control (ETC) Light

- Tire Pressure Monitoring System (TPMS) Light

- Seat Belt Reminder Light

- Brake Warning Light**

- Malfunction Indicator Light (MIL)**

- Electronic Stability Program (ESP) Indicator Light/Brake Assist System (BAS) Warning Light**

CONTROLS AT A GLANCE

Indicators

- Turn Signal Indicators

- High Beam Indicator

- Front Fog Light Indicator

- Vehicle Security Indicator*

- TOW/HAUL Indicator

- 4WD LOW Indicator

- Electronic Stability Program (ESP) Indicator Light/Traction Control System (TCS) Indicator

- Cruise Indicator

* If equipped

** Bulb Check with Key On

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors/Liftgate

• Press the LOCK button once to lock all the doors and the liftgate. Press the UNLOCK button once to unlock the driver’s door only and twice within five seconds to unlock all the doors and liftgate.

• All doors can be programmed to unlock on the first press of the UNLOCK button.

WARNING!

Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be injured. Children should be warned not to touch the parking brake, brake pedal, or the shift lever. Do not leave the key in the ignition. A child could operate power windows, other controls, or move the vehicle.

Unlock Flipper Glass

• Press the FLIPPER GLASS button two times within five seconds to open the liftgate flipper glass.

WARNING!

Driving with the flipper glass open can allow poisonous exhaust gases into your vehicle. You and your passengers could be injured by these fumes. Keep the flipper glass closed when you are operating the vehicle.

Remote Start

• Press the REMOTE START button START button a third time shuts the engine off.

• To drive the vehicle, press the UNLOCK button, insert the Key Fob in the ignition and turn to the ON/RUN position.

• With remote start, the engine will only run for 15 minutes (timeout) unless the ignition Key Fob is placed in the ON/RUN position.

• The vehicle must be started with the Key Fob after two consecutive timeouts.

twice within five seconds. Pressing the REMOTE

GETTING STARTED

WARNING!

• Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause serious injury or death when inhaled.

• Keep Key Fob transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause serious injury or death.

Panic Alarm

• Press the PANIC button once to turn the panic alarm on.

• Wait approximately three seconds and press the button a second time to turn the panic alarm off.

Express Window Feature

• To remotely lower both front door windows at the same time, press and release the UNLOCK button and then immediately press and hold the UNLOCK button until the windows lower to the level desired or until they lower completely.

Emergency Key

• Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob. To remove the emergency key, slide the button at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand.

• The emergency key is also for locking the glove compartment.

THEFT ALARM

To Arm

• Press the Key Fob LOCK button or the power door lock switch while the door is open.

To Disarm

• Press the Key Fob UNLOCK button or turn the ignition to the ON position.

SEAT BELT

• Be sure everyone in your vehicle is in a seat using a seat belt properly.

WARNING!

In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.

GETTING STARTED

FRONT SEATS

WARNING!

Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Only adjust a seat while the vehicle is parked.

Manual Seat Adjustment

Forward/Rearward

• Lift up on the adjusting bar located at the front of the seat near the floor and release at the desired position.

Recliner

• Lift the rear lever located on the outboard side of the seat, lean back and release at the desired position.

WARNING!

Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision, you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.

Manual Lumbar Adjust Lever

• Rotate the lumbar lever downward to increase the support or upward to decrease the support.

GETTING STARTED

Eight-Way Driver Power Seat

Four-Way Passenger Power Seat

• The recline switch, located on the outboard side of the seat, controls seatback adjustment.

• The power seat switch controls forward/back, up/down, and tilt adjustment.

• The recline switch, located on the outboard side of the seat, controls seatback adjustment.

• The power seat switch controls forward/back adjustment.

CAUTION!

DO NOT place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.

Heated Seats

• The controls for front heated seats are located near the bottom center of the instrument panel (below the heater/air conditioning controls).

• Press the switch once to select High-level heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

GETTING STARTED

WARNING!

• Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

• Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

CAUTION!

Repeated overheating of the seat could damage the heating element and/or degrade the material of the seat.

Memory Seats

• The memory seat feature allows you to save two different driver seating positions, driver's outside mirror, adjustable brake and accelerator pedals, and radio station preset settings. The memory seat switch is located on the driver's door panel.

• Adjust all memory profile settings, press the SET button then press 1 or 2 within five seconds.

• To program a Key Fob to the memory position, press and release the LOCK button within 10 seconds on the Key Fob to be programmed.

• Place the ignition switch in the ON position, select Remote Linked to Memory in the Electronic Vehicle Information Center (EVIC) and enter Yes.

• Press 1 or 2 to recall the saved positions, or press UNLOCK on the programmed Key Fob.

• Refer to the Owner's Manual on the DVD for further details.

GETTING STARTED

REAR SEATS

40/20/40 Second Row Folding Seat

Fold and Tumble - Second Row Seat

• The left, center, or right side of the second row seat can be lowered. The left and right side of the second row seat can also be tumbled forward to allow access to the third row seat.

• Pull up on the seatback lever located on the outboard side of the seat.

NOTE: Also, pulling upward on this handle allows the outboard seating positions to be reclined.

• Fold the seatback down, and tumble the seat forward.

NOTE: If sitting in the third row seat, pull rearward on the release strap located at the rear of the seat and tumble the seat forward.

WARNING!

Do not drive the vehicle with the outer second row seats in the tumbled position. The outer second row seats are only intended to be tumbled for entry and exit to the third row seat. Failure to follow these instructions could result in personal injury.

Folding Second Row Middle Seatback

• Pull the release strap.

• Lower the center seatback.

GETTING STARTED

50/50 Third Row Folding Seat

• Either side of the third row seat can be lowered.

• Open the liftgate.

• Pull the seatback release handle (toward the rear of the vehicle), and lower the seatback using the pull strap.

• To raise the rear seat, detach the pull strap from the back of the seat, and pull the seatback upward until it locks into place.

2nd Row Heated Seats

• Second row heated seat switches are located on the rear of the center console.

• Press the switch once to select High-level heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

WARNING!

(Continued)

GETTING STARTED

WARNING! (Continued)

CAUTION!

Repeated overheating of the seat could damage the heating element and/or degrade the material of the seat.

TILT/TELESCOPING STEERING COLUMN

• The tilt/telescoping control lever is located below the steering wheel at the end of the steering column.

• Push down on the lever to unlock the steering column.

• To tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired.

• Pull upward on the lever to lock the column firmly in place.

WARNING!

Do not adjust the steering wheel while driving. The tilt/telescoping adjustment must be locked while driving. Adjusting the steering wheel while driving or driving without the tilt/telescoping adjustment locked could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.

GETTING STARTED

ADJUSTABLE PEDALS

• The adjustable pedal switch is located on the left side of the instrument panel.

• Press the bottom of the switch to move the brake and accelerator pedals away from the driver. Press the top of the switch to move the pedals closer to the driver.

NOTE: The pedals cannot be adjusted when the vehicle is in REVERSE or when the Electronic Speed Control is set.

WARNING!

Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always adjust the pedals while the vehicle is parked.

CAUTION!

Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls. Pedal travel may become limited if movement is stopped by an obstruction in the adjustable pedal’s path.

PROGRAMMABLE FEATURES

Electronic Vehicle Information Center (EVIC) – If Equipped

• The EVIC can be used to program the following Personal Settings. Press and release the MENU button

scroll through the settings. Press the FUNCTION SELECT button

• Language • Easy Entry/Exit Seat

• Auto Door Locks • Key-Off Power Delay

• Auto UNLK On Exit • Illuminated Approach

• RKE Unlock • Display Units of Measure In

• Sound Horn With RKE Lock • Automatic High Beams

• Flash Lamp Lock • Hill Start Assist

• Headlamp Off Delay • Display ECO

• Turn Headlamps On with Wipers • Rain Sensing Intermittent Wipers

until Personal Settings displays, then press the SCROLL button to

to change the setting.

OPERATING YOUR VEHICLE

TURN SIGNAL/LIGHTS LEVER

Headlights/Parking Lights

• Rotate the end of the lever to the first detent for parking lights , the second detent for headlights

• When set to AUTO, the system automatically turns the headlights on or off based on ambient light levels.

SmartBeams™

• Automatically controls the use of the headlight high beams.

Instrument Panel Dimmer

• Rotate the center portion of the lever to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened.

• Rotate the center portion of the lever up to increase the brightness of the instrument panel lights when the parking lights or headlights are on.

• Rotate the center portion of the lever upward to the next detent position to brighten the odometer and radio controls when the parking lights or headlights are on.

• Rotate the center portion of the lever upward to the last detent to turn on the interior lighting.

Flash To Pass

• Pull the lever toward you to activate the high beams. The high beams will remain on until the lever is released.

High Beam Operation

• Push the lever forward to activate the high beams.

NOTE: For safe driving, turn off high beams when oncoming traffic is present to prevent headlight glare and as a courtesy to other motorists.

and the third detent for AUTO.

OPERATING YOUR VEHICLE

Fog Lights

• Turn on the parking lights or low beam headlights and pull out the end of the lever.

Turn Signals/Lane Change Assist

• Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.

WIPER/WASHER LEVER

Front Wipers

Intermittent, Low And High Operation

• Rotate the end of the lever to the first detent position for one of five intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

Washer Operation

• Pull the lever toward you and hold for as long as spray is desired.

Mist

• Pull down on the lever and release when a single wipe is desired.

Rain Sensing Wipers

• This feature senses moisture on the vehicle's windshield and automatically activates the wipers for the driver when the switch is in the intermittent position.

Rear Wiper

Wiper Operation

• Rotate the center portion of the lever forward to the first detent for rear wiper operation.

Washer Operation

• Rotate the center portion of the lever past the first detent to activate the rear washer.

OPERATING YOUR VEHICLE

SPEED CONTROL LEVER

Cruise ON/OFF

• Push the ON/OFF button to activate the Speed Control.

• CRUISE will appear on the instrument cluster to indicate the Speed Control is on.

• Push the ON/OFF button a second time to turn the system off.

WARNING!

Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the Electronic Speed Control system off when you are not using it.

Set

• With Speed Control on, push down and release the lever to set a desired speed.

WARNING!

Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control. An accident could be the result. Do not use Electronic Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.

Accel/Decel

• Push and hold the lever up to accelerate or down to decelerate the vehicle; release the lever to save the new set speed.

• Once a speed is set, tapping the lever up or down will increase or decrease the set speed approximately 1 mph (2 km/h).

Cancel

• Pull the lever toward you or apply the brakes to cancel the set speed and maintain the set speed in memory.

• Push the ON/OFF button to turn the system off and erase the set speed memory.

Resume

• To resume a previously selected speed in memory, push the lever up and release.

OPERATING YOUR VEHICLE

ELECTRONIC RANGE SELECT (ERS)

• The Electronic Range Select (ERS) feature allows you to select the desired top gear. For example, if you shift the transaxle into third gear, the transaxle will never shift above third gear, but can shift down to second or first gear automatically when needed.

• To shift from DRIVE mode to ERS mode, move the shift lever to the left (-) once. The current gear will be maintained as the top gear. To disable ERS, simply press and hold the shift lever to the right (+) until “D” is displayed in the instrument cluster odometer.

• Switching from ERS to DRIVE can be done at any vehicle speed.

MANUAL CLIMATE CONTROLS

Air Recirculation

• Use recirculation for maximum A/C operation.

• For window defogging, turn the recirculation button off.

• Recirculation is not allowed in defrost, floor, defrost/floor (mix) modes.

OPERATING YOUR VEHICLE

AUTOMATIC TEMPERATURE CONTROLS (ATC)

Automatic Operation

• Turn the Mode Control to the AUTO position and the Blower Control to either LO AUTO or HIGH AUTO position.

• Select the desired temperature by rotating the temperature controls for the driver or passenger.

• The system will maintain the set temperature automatically.

Air Conditioning (A/C)

• If the air conditioning button is pressed while in AUTO mode, the indicator light may flash three times to indicate the air conditioning is being controlled automatically.

Air Recirculation

• Use recirculation for maximum A/C operation.

• For window defogging, turn the recirculation button off.

• If the recirculation button is pressed while in the AUTO mode, the indicator light may flash three times to indicate the cabin air is being controlled automatically.

OPERATING YOUR VEHICLE

Rear Climate Control

• The Manual Rear Climate Control system has one floor air outlet (passenger side), and two panel outlets in the rear quarter trim (on each side). The unit provides warm or cool air through the floor and upper outlets.

• The rear temperature, blower speed, and mode control can be adjusted as desired by the third row seat occupants.

NOTE: The rear climate control system cannot be controlled from the front seat; it can only be turned on and off. All control of the rear system must be performed by the rear occupants.

PARKSENSE® REAR PARK ASSIST

• If an object is detected behind the rear bumper while the vehicle is in REVERSE, a warning will display in the headliner near the flipper glass and a chime will sound. The chime rate will change depending on the distance of the object, getting faster as the object gets closer to the bumper.

PARKVIEW® REAR BACK-UP CAMERA

• You can see an on-screen image of the rear of your vehicle whenever the shift lever is put into REVERSE. The ParkView displayed on the radio display screen, located on the center stack of the instrument panel.

Drivers must be careful when backing up even when using the ParkView®Rear Back-Up Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstructions, or blind spots before backing up. You are responsible for the safety of your surroundings and must continue to pay attention while backing up. Failure to do so can result in serious injury or death.

Rear Back-Up Camera camera image will be

WARNING!

OPERATING YOUR VEHICLE

POWER LIFTGATE

• The power liftgate may be opened manually or by pressing the LIFTGATE button on the Key Fob. Press the LIFTGATE button on the Key Fob twice within five seconds to open the power liftgate. Once the liftgate is open, pressing the button twice within five seconds a second time will close the liftgate.

• Also, the power liftgate may be closed by pressing the Liftgate switch located on the left rear trim, near the liftgate opening. Pressing once will close the liftgate only. This button cannot be used to open the liftgate.

LIFTGATE FLIPPER GLASS

• The liftgate flipper glass is also unlocked when the liftgate is unlocked. To open the flipper glass, push up on the window switch located on the liftgate.

WARNING!

To avoid injury, stand back when opening. Glass may automatically rise.

NOTE: If a malfunction to the liftgate latch should occur, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the liftgate trim panel.

WARNING!

POWER SUNROOF

• The power sunroof switch is located on the overhead console.

WARNING!

• Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.

• In an accident, there is a greater risk of being thrown from a vehicle with an open sunroof. You could also be seriously injured or killed. Always fasten your seat belt properly and make sure all passengers are properly secured too.

• Do not allow small children to operate the sunroof. Never allow your fingers, other body parts, or any object to project through the sunroof opening. Injury may result.

OPERATING YOUR VEHICLE

Opening Sunroof

Express

• Press the switch rearward and release. The sunroof will fully open and stop automatically.

Closing Sunroof

Express

• Press the switch forward and release. The sunroof will close automatically from any position.

Manual Open/Close

• Press and hold the switch rearward to open or forward to close the sunroof. Any release of the switch will stop the movement, and the sunroof will remain in a partially open or closed position until the switch is pressed again.

Venting Sunroof

• Press and release the "V" button, and the sunroof will open to the vent position. This is called “Express Vent” and will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof.

Pinch Protection Feature

• This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically return to the open position.

NOTE: Pinch protection is disabled while the switch is pressed and held during manual opening and closing of the sunroof.

WIND BUFFETING

• Wind buffeting can be described as a helicopter-type percussion sound. If buffeting occurs with the rear windows open, adjust the front and rear windows together.

• If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any window. This will minimize buffeting.

NON-TOUCH-SCREEN RADIOS

RES Radio

ELECTRONICS

RES/RSC Radio

ELECTRONICS

NOTE: uconnect™ phone and Voice Recognition are vehicle options which must be ordered separately. The buttons on the radio will only be active if the vehicle has been equipped with the option.

• The radio sales code is located on the lower right side of the radio faceplate.

• Unless otherwise noted, the information provided on the operation and functionality of the radios in this section is common to all non-touch-screen radios.

Seek Up/Down Buttons

• Press and release to search for and stop at the next listenable station in AM/FM mode.

• Holding either button will bypass stations without stopping.

Audio Settings

• Press the TUNE/SCROLL control knob and BASS, MID, TREBLE, BALANCE and FADE will display. Rotate the TUNE/SCROLL control knob to select the desired setting.

Auxiliary Mode

• The auxiliary (AUX) jack allows a portable device, such as an MP3 player or a cassette player, to be plugged into the radio and utilize the vehicle’s audio system and play through the vehicle speakers.

Clock Setting

• Press and hold the TIME button until the hours blink; turn the TUNE/SCROLL control knob to set the hours.

• Press the TUNE/SCROLL control knob until the minutes begin to blink; turn the TUNE/SCROLL control knob to set the minutes.

• Press the TUNE/SCROLL control knob to save the time change.

• To exit, press any button/knob or wait five seconds.

Station Presets

• Press the SET/RND button once and SET 1 will show in the display. Then select the button (1–6).

• A second station may be added to each push button. Press the SET/RND button twice and SET 2 will show in the display, then select button (1–6).

TOUCH-SCREEN RADIOS

Navigation Radio – RER

ELECTRONICS

Multimedia Radio – REN

ELECTRONICS

NOTE: uconnect™ phone and Voice Recognition are vehicle options which must be ordered separately. The buttons on the radio will only be active if the vehicle has been equipped with the option.

• The radio sales code is located on the lower right side of the radio faceplate.

• Unless otherwise noted, the information provided on the operation and functionality of the radios in this section is common to all touch-screen radios.

Seek Up/Down

• Press to seek through radio stations in AM, FM, or SAT bands. Seek through tracks in CD

Radio Mode

• Press the RADIO/MEDIA hard-key to display the different radio modes, then press the

Auxiliary Mode

• The auxiliary (AUX) jack allows a portable device, such as an MP3 player or a cassette

Clock Setting

• Turn the radio on, then touch the screen where the time is displayed.

• Touch the USER CLOCK soft-key (Navigation radio only).

• To adjust the hours, touch either the HOUR FORWARD or HOUR BACKWARD soft-key.

• To adjust the minutes, touch either the MINUTE FORWARD or MINUTE BACKWARD

• To save the new time setting, touch the screen where the word “Save” is displayed.

Store Radio Presets

• Press the RADIO/MEDIA hard-key repeatedly until AM FM SAT is displayed in the upper

• Select the radio band by touching either the AM, FM, or SAT soft-key.

• Find the station to store by either pressing the SEEK UP/DOWN hard-key, or touching the

• Once the station is found, touch and hold one of the PRESET soft-keys in the list to the

or iPod

desired soft-key to select AM, FM, SAT, TV, HDD, Disk, Aux or Video Entertainment System (VES)™ modes.

player, to be plugged into the radio and utilize the vehicle’s audio system and play through the vehicle speakers.

soft-key.

left corner of the screen.

SCAN soft-key, DIRECT TUNE soft-key or the left and right arrows.

right, until you hear a confirmation beep.

modes or through songs in the HDD playlist.

ELECTRONICS

Hard Disc Drive Operation

Copy Complete Audio Disc To Hard-Drive

• Press the OPEN/CLOSE hard-key and insert a disc, then press the MENU hard-key.

• Touch the MY FILES soft-key, then select MY MUSIC.

• Touch the IMPORT MUSIC soft-key, then touch the FROM DISC soft-key in the next screen to start the process.

Copying From USB

• Insert a USB device, then select MY MUSIC.

• Touch the IMPORT MUSIC FILES soft-key, then touch the FROM USB soft-key in the next screen.

• Select the folders or titles you would like to copy, then touch the DONE soft-key to start the copy process.

Copy Pictures To The Hard-Drive

• Insert either a CD or a USB device containing your pictures.

• Touch the MY FILES soft-key, then go to the MANAGE MY FILES screen.

• Touch the MY PICTURES soft-key to get an overview of the currently stored images.

• Touch one of the ADD PICTURES soft-keys, then select the type of media inserted.

• Use the PAGE soft-keys to page through a list of pictures and press the picture you would like to import.

• Confirm your selection by touching the YES soft-key. The imported picture is now available in the MANAGE MY PICTURES screen.

• In order to display the imported picture in the radio screen, touch the desired pictures soft-key.

• Select this picture by pressing the PICTURE VIEW soft-key. A check mark indicates the currently used picture.

Cleaning Your Touch-Screen Radio

• Do not spray any liquid or caustic chemicals directly on the screen. Use a clean and dry micro fiber lens cleaning cloth in order to clean the touch-screen.

• If necessary, use a lint-free cloth dampened with a cleaning solution such as isopropyl alcohol or an isopropyl alcohol and water solution ratio of 50:50. Be sure to follow the solvent manufacture's precautions and directions.

Navigation

Navigation Radio – RER Only

• Navigation radios require digital data from a navigation database. The data in the navigation database is licensed from Navigation Technologies digitized.

. Not all roads are

ELECTRONICS

• For software updates, visit http://www.chrysler.com/en/owners/mygig/ website, visit http://www.navteq.com website, or contact your authorized dealer for the latest available software.

NOTE: Many features of this radio are speed dependent. For your own safety, it is not possible to use the touch-screen keyboard to enter a name (e.g., street name) while the vehicle is in motion. Pull over at a safe location to complete your task.

• The Navigation system receives GPS signals from satellites to display the position of your vehicle.

New Destination

• Press the NAV hard-key to access the Navigation Main Menu.

• Touch the NEW DESTINATION soft-key to program a destination, then select the destination soft-key of your choice.

Program/Storing Home Address

• Press the NAV hard-key to access the Navigation Main Menu.

• Touch the GUIDE ME HOME soft-key, then touch the STREET ADDRESS soft-key.

• Touch the STATE soft-key, then enter your state name into the speller; select your state from the list and press the CHANGE soft-key.

• Touch the INPUT STREET NAME soft-key and enter your street name into the speller.

• Touch the CONTINUE soft-key and enter your address into the speller; then touch the CONTINUE soft-key again.

• Touch the city name and touch the SAVE soft-key to complete programming.

Change Stored Home Address

• Press the MENU hard-key, then touch the MY FILES soft-key.

• Touch the MY ADDRESS BOOK soft-key, then touch the HOME soft-key.

• In the Home Address Information screen, touch the EDIT CONTACT soft-key, then touch the CHANGE ADDRESS soft-key in the next screen.

• Touch the INPUT STREET NAME soft-key and enter your street name into the speller.

• Touch the CONTINUE soft-key and enter your address into the speller; touch the CONTINUE soft-key again.

• Touch the city name and touch the SAVE soft-key to complete programming.

Guide Me Home

• Press the NAV hard-key to access the Navigation Main Menu.

• Touch the GUIDE ME HOME soft-key to route you back to your home destination from your current location. Touch the GO soft-key to start your trip.

Map

• Press the NAV hard-key to access the Navigation Main Menu.

• Touch the MAP soft-key to display a map of your current position.

ELECTRONICS

REMOTE AUDIO CONTROLS

• The switches are located on the rear surface of the steering wheel.

Right Switch

• Press the switch up or down to increase and decrease the volume.

• Press the button in the center to change modes AM/FM/CD/SAT.

Left Switch

• Press the switch up or down to search for the next listenable station or select the next or previous CD track.

• Press the button in the center to select the next preset station (Radio) or to change CDs if equipped with a CD Changer.

VIDEO ENTERTAINMENT SYSTEM (VES)™

System Operation

• The screen is located on the headliner behind the front seat. To lower the screen, press the release button located in the center of the console rear of the screen.

• The system may be controlled by the front seat occupants using the touch-screen radio, or by the rear seat occupants using the remote control.

• The video screen displays information in a split screen format. The left side of the screen is referred to as Channel 1 and the right side of the screen is referred to as Channel 2. All modes except video modes are displayed in a split screen format.

• To use the headphones, press the power button located on the right ear cup. Select the channel on the headphones (1or2) that corresponds to the channel selected on the VES™ screen.

ELECTRONICS

Operation Of The Touch-Screen Radio

• To view a DVD video press the OPEN/CLOSE hard-key and insert the disc. Playback will begin automatically after the DVD is recognized by the disc drive. If playback does not begin automatically follow these steps:

• Press the MENU hard-key, then touch the REAR VES™ soft-key. If a chapter list appears on the right side of the screen touch the HIDE LIST soft-key to display the Rear VES™ Control screen.

• Touch the 1 soft-key to select an audio channel, then touch the DISC soft-key in the MEDIA column.

SIRIUS Backseat TV™

• Press the MENU hard-key, then touch the Rear VES™ soft-key. If a chapter list appears on the right side of the screen, touch the HIDE LIST soft key to display the Rear VES™ Control screen.

• Touch the 1 soft-key to select an audio channel, then touch the TV soft-key in the RADIO column to select SIRIUS Backseat TV™.

Operation Of The Remote

• The remote control operates similarly to any DVD remote you have used before and allows the rear seat passengers to change stations, tracks, discs and audio/video modes.

• The remote control is designed to control either channel by using the selector switch located on the right side of the remote.

• Pressing the power button will turn the VES™ system ON/OFF.

• Pressing the MODE button causes the Mode Selection menu to appear on the VES™ screen. Use the remote control arrow buttons to scroll through the available modes, then press ENTER to select the desired mode.

SIRIUS Backseat TV™

• To view SIRIUS Backseat TV™ set the remote control channel selector switch to channel 1. Press the MODE button, then using the arrow buttons select TV and press ENTER.

Auxiliary Audio/Video Input Jacks

• The Aux jacks are located on the rear of the center console.

• Connect the video game or other external media devices to the AUX jacks following the color coding for VES™ jacks.

• Using either the touch-screen radio or remote control, select AUX from the Rear VES™ Control or Mode Selection screen.

• Refer to “uconnect™ studios” in the uconnect™ user's manual on the DVD for further details.

ELECTRONICS

ELECTRONIC VEHICLE INFORMATION CENTER (EVIC)

• The EVIC features a driver interactive display that is located in the instrument cluster. Pressing the controls on the steering wheel allows the driver to select vehicle information and Personal Settings. For additional information refer to Programmable Features in this guide.

• Press and release the MENU the mode displayed will change between Compass/Temperature, Trip, System Status, and Personal settings.

• Press the STEP Economy, DTE, Elapsed Time, and Units).

• Press and release the Compass/Temperature Compass/Temperature screens.

• Press the RESET

button to scroll through sub menus (i.e., Trip Functions, Avg. Fuel

button for instant access to the

button to RESET Trip Functions and change Personal Settings.

UNIVERSAL GARAGE DOOR OPENER

Programming HomeLink

Begin Programming

• The HomeLink®buttons are located in the overhead console.

• Erase all channels before you begin training by holding the two outside buttons for up to 20 seconds until “CHANNELS CLEARED” appears in the EVIC display.

button and

.®

• Park your vehicle outside of the garage and turn the ignition switch to the ON/RUN position.

• Place the hand-held transmitter 1 to 3 in (3 to 8 cm) from the HomeLink keeping the EVIC display in view. Simultaneously, press and hold both the chosen HomeLink from “CHANNEL # TRAINING” to “CHANNEL # TRAINED.” This may take up to 30 seconds, or longer, in rare cases.

• Press and hold the just-trained HomeLink EVIC display will show “CHANNEL # TRANSMIT” and the device should operate.

NOTE: If you are having difficulty training your HomeLink manufactured after 1995, you may have a rolling code system. Follow the steps for programming a rolling code system.

button and the hand-held transmitter button until the EVIC display changes

button; if the channel has been trained, the

and your garage door was

buttons while

ELECTRONICS

Programming A Rolling Code System

• At the garage door opener motor (in the garage), locate the “learn” or “training” button. This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door).

• Firmly press and release the “learn” or “training” button. The name and color of the button may vary by manufacturer. Within 30 seconds, return to the vehicle and press the programmed HomeLink the device is plugged in and activates, programming is complete.

• If the device does not activate, press the button a third time (for two seconds) to complete the training.

Using HomeLink

• To operate, simply press and release the programmed HomeLink®button and the trained device will operate.

• Refer to your Owner’s Manual on the DVD for further details. If you have any problems programming HomeLink or on the Internet, at www.HomeLink.com.

POWER INVERTER

button twice (holding the button for two seconds each time). If

, or require assistance, please call toll-free 1–800–355–3515,

• There is a 115–volt, 150–watt power inverter outlet located on the back of the center console. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 watts.

• Press the switch located in the switch bank on the lower instrument panel to turn the power to the outlet on.

• Press the switch again to turn the power off. The status indicator of the AC power inverter indicates whether the inverter is producing AC power.

NOTE: The power inverter is designed with built-in overload protection. If the power rating of 150 watts is exceeded, the power inverter will automatically shut down. Once the electrical device has been removed from the outlet, the inverter should automatically reset. If the power rating exceeds approximately 170 watts, the power inverter may have to be reset manually. To reset the inverter manually, press the power inverter button OFF and ON. To avoid overloading the circuit, check the power ratings on electrical devices prior to using the inverter.

ELECTRONICS

WARNING!

To Avoid Serious Injury or Death: Do not use a three-prong adaptor. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock and failure.

POWER OUTLET

• The two front power outlets are located on the instrument panel below the Climate Controls. The right side outlet is powered only when the key is in the ON position. The left side outlet is powered directly from the battery and will receive power whether the ignition is in the ON or LOCK position. All accessories connected to the left outlet should be removed or turned off when the vehicle is not in use to protect the battery against discharge.

• The rear power outlet is located in the left rear cargo area and will receive power whether the ignition is in the ON or LOCK position. All accessories connected to the rear outlet should be removed or turned off when the vehicle is not in use to protect the battery against discharge.

NOTE: Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.

uconnect™ phone

• The uconnect™ phone is a voice-activated, hands-free, in-vehicle communications system.

• The uconnect™ phone allows you to dial a phone number with your cellular phone using simple voice commands.

• Please refer to uconnect™ phone in the uconnect™ User's Manual on the DVD for further details.

WARNING!

• Any voice commanded system should be used only in safe driving conditions following local laws and phone use. All attention should be kept on the roadway ahead. Failure to do so may result in an accident causing serious injury or death.

• Your phone must be turned on and paired to the uconnect™ phone to allow use of this vehicle feature in emergency situations, when the cellular phone has network coverage and stays paired to the uconnect™ phone.

NOTE: The uconnect™ phone requires a cellular phone equipped with the Bluetooth Hands-Free Profile, Version 0.96 or higher. For uconnect™ customer support, call 1–877–855–8400.

ELECTRONICS

Phone Pairing

NOTE: Pairing is a one-time initial setup before using the phone. You will also need to follow the Bluetooth instructions in your cell phone user guide to complete the phone pairing setup.

• Press the Phone button

• Wait for the “ready” prompt and beep.

• (After the BEEP), say “uconnect setup”.

• (After the BEEP), say “phone pairing”.

• (After the BEEP) say, “pair a phone”.

• Follow the audible prompts.

• You will be asked to create a four-digit PIN which you will later need to enter into your phone (typically..settings, bluetooth, device, list, new).

• You will then be prompted to give the phone pairing a name (each phone paired should have a unique name).

• Next you will be asked to give this new pairing a priority of 1 thru 7 (up to seven phones may be paired).

Making A Phone Call

• Press the Phone button .

• (After the BEEP), say “dial” (or “call” to a name).

• (After the BEEP), say number (or name).

Phonebook (uconnect™ local) Edit

• Press the Phone button .

• (After the BEEP), say “phonebook”.

• (After the BEEP), say “new entry” or “list names” or “delete”.

• Follow the prompts.

Receiving A Call – Accept (And End)

• When an incoming call rings / is announced on uconnect™, press the Phone button .

• To end a call, press the Phone button

to begin.

Mute (Or Unmute) Microphone During Call

• During a call, press the Voice button .

• (After the BEEP), say “mute on” (or “mute off ”).

Transfer Ongoing Call Between Handset And Vehicle

• During a call, press the Voice button .

• (After the BEEP), say “transfer call”.

ELECTRONICS

Changing The Volume

• Start a dialogue by pressing the Phone button , then adjust the volume during a normal call.

• Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the uconnect™ system is speaking. Please note the volume setting for uconnect™ is different than the audio system.

NOTE: To access the tutorial, press the uconnect™ hard-key. After the BEEP, say “tutorial”. Press any hard-key or touch the display to cancel the tutorial.

VOICE RECOGNITION

• The Voice Recognition (VR) system allows you to control your AM, FM radio, satellite radio, disc player, and a memo recorder. When you press the VR button hear a beep. The beep is your signal to give a command. If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the VR button and say your command.

• Please refer to uconnect™ tunes in the uconnect™ User's Manual on the DVD for further details.

Changing The Volume

• Start a dialogue by pressing the VR button , then say a command (e.g., “tutorial”).

• Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Voice Recognition system is speaking. Please note the volume setting for Voice Recognition is different than the audio system.

, you will

, listen for the BEEP,

WARNING!

Any voice commanded system should be used only in safe driving conditions and all attention should be kept on the roadway ahead. Failure to do so may result in an accident causing serious injury or death.

NOTE: To access the tutorial, press the VR button Press any hard-key or touch the display to cancel the tutorial.

. After the BEEP, say “tutorial”.

OFF-ROAD CAPABILITIES

FOUR-WHEEL DRIVE OPERATION

Quadra-Trac I®Operating Instructions/Precautions

• The Quadra-Trac I®is a single-speed (HI range only) transfer case, which provides convenient full-time four–wheel drive. No driver interaction is required. The Brake Traction Control (BTC) System, which combines standard ABS and Traction Control, provides resistance to any wheel that is slipping to allow additional torque transfer to wheels with traction.

Quadra-Trac II®/Quadra-Drive

Operating Instructions/

Precautions

• When additional traction is required, the 4WD LOW position can be used to lock the front and rear driveshafts together and force the front and rear wheels to rotate at the same speed. The 4WD LOW position is intended for loose, slippery road surfaces only. Driving in the 4WD LOW position on dry, hard-surfaced roads may cause increased tire wear and damage to driveline components.

• When operating your vehicle in 4WD LOW, the engine speed is approximately three times that of the 4WD HI position at a given road speed. Take care not to overspeed the engine and do not exceed 25 mph (40 km/h).

NOTE:

• If shift conditions/interlocks are not met, or a transfer case motor temperature protection condition exists, a “CHECK SHIFT PROCEDURES” message will flash from the Electronic Vehicle Information Center (EVIC).

WARNING!

• The Quadra-Trac II®/Quadra-Drive II transfer case is fully automatic in the normal driving 4WD HI mode. The Quadra-Trac II transfer case provides three mode positions:

• 4WD HI

• NEUTRAL

• 4WD LOW

• This transfer case is fully automatic in the 4WD HI mode.

/Quadra-Drive II

You or others could be injured if you leave the vehicle unattended with the transfer case in the N (Neutral) position without first fully engaging the parking brake. The transfer case

N (Neutral) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move regardless of the transmission position. The parking brake should always be applied when the driver is not in the vehicle.

OFF-ROAD CAPABILITIES

Shifting Procedures

4WD HI To 4WD LOW

• With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), key ON or engine running, shift the transmission into NEUTRAL, and raise the transfer case T-handle. The “4WD LOW” indicator light in the instrument cluster will begin to flash and remain on solid when the shift is complete. Release the T-handle.

• Shifting into or out of 4WD LOW is possible with the vehicle completely stopped; however, difficulty may occur due to the mating clutch teeth not being properly aligned. Several attempts may be required for clutch teeth alignment and shift completion to occur. The preferred method is with the vehicle rolling 0 to 3 mph (0 to 5 km/h). If the vehicle is moving faster than 3 mph (5 km/h), the transfer case will not allow the shift.

4WD LOW To 4WD HI

• With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), key ON or engine running, shift the transmission into NEUTRAL, and raise the transfer case T-handle. The “4WD LOW” indicator light in the instrument cluster will flash and go out when the shift is complete. Release the T-handle.

NEUTRAL Shift Procedure

• Key ON, engine off.

• Vehicle stopped, with foot on brake.

• Place the transmission into NEUTRAL.

• Hold down the NEUTRAL “pin” switch (with a pen, etc.) for four seconds until the LED light by the switch starts to blink indicating shift in progress. The light will stop blinking (stay on solid) when the NEUTRAL shift is complete. A “4WD SYSTEM IN NEUTRAL” message will display on the Electronic Vehicle Information Center (EVIC).

• Repeat these Steps to shift out of NEUTRAL.

UTILITY

INTERIOR STORAGE COMPARTMENTS

Rear Storage Compartment

• The cargo tie-downs, located on the cargo area floor, should be used to safely secure loads when the vehicle is moving.

WARNING!

• To help protect against personal injury, passengers should not be seated in the rear cargo area. The rear cargo space is intended for load carrying purposes only, not for passengers, who should sit in seats and use seat belts.

(Continued)

WARNING! (Continued)

• Cargo tie-down hooks are not safe anchors for a child seat tether strap. In a sudden stop or collision, a hook could pull loose and allow the child seat to come loose. A child could be badly injured. Use only the anchors provided for child seat tethers.

Wt. (See Note)

Max. Trailer Tongue

Trailer Wt.)

Max. GTW (Gross

Frontal Area

UTILITY

Wt. Rating)

GCWR (Gross Combined

Engine Model

TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS)

Refer to local laws for maximum trailer towing speeds.

3.7L 4x2 8,700 lbs (3 946 kg) 40 sq ft (3.72 sq m) 3,500 lbs (1 587 kg) 350 lbs (159 kg)

3.7L 4x4 8,800 lbs (3 991 kg) 40 sq ft (3.72 sq m) 3,500 lbs (1 587 kg) 350 lbs (159 kg)

5.7L 4x2 12,700 lbs (5 760 kg) 60 sq ft (5.57 sq m) 7,400 lbs (3 356 kg) 740 lbs (336 kg)

5.7L 4x4 12,700 lbs (5 760 kg) 60 sq ft (5.57 sq m) 7,200 lbs (3 266 kg) 720 lbs (327 kg)

UTILITY

RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.)

Towing - Two-Wheel Drive Models

• Recreational towing is allowed ONLY if the driveshaft is removed. Towing with the rear wheels on the ground while the driveshaft is connected can result in severe transmission damage.

WARNING!

If the driveshaft is removed, the vehicle can roll even if the transmission is in PARK, which could cause serious injury or death.

• The parking brake must be firmly engaged and the wheels chocked during driveshaft removal and installation. The parking brake must remain engaged unless the vehicle is securely and properly connected to the tow vehicle, or the driveshaft is completely reinstalled. See your authorized dealer for proper driveshaft removal and reinstallation procedures, including flange orientation/alignment, use of thread-locking compound, proper bolt torque specifications, etc.

Towing - Quadra-Trac I

(Single-Speed Transfer Case) Four-Wheel Drive Models

• Recreational towing is not allowed. This model does not have a NEUTRAL position in the transfer case.

Towing - Quadra-Trac II

/Quadra-Drive II®Four-Wheel Drive Models

• Depress the brake pedal and turn the ignition switch ON with the engine shut off.

• Shift the transmission into NEUTRAL.

• Shift the transfer case into NEUTRAL by holding down the NEUTRAL Pin switch for four seconds until the LED starts to blink. The LED will stop blinking and remain on when the shift is complete.

• Start the engine and shift into DRIVE to ensure there is no vehicle movement.

• Shut the engine off and shift the transmission into PARK.

• Place the ignition switch in the OFF position and remove the key.

• Apply the parking brake, attach the vehicle to the tow vehicle with a tow bar and release the parking brake.

• Refer to your Owner's Manual on the DVD for further details.

UTILITY

BRAKE/TRANSMISSION INTERLOCK MANUAL OVERRIDE

• The manual override may be used in the event that the shift lever should fail to move from PARK with the Key Fob in the ON position and the brake pedal pressed.

• To operate the shift lock manual override, perform the following steps:

• Turn the Key Fob to the ON position but do not start the engine.

• Firmly set the parking brake.

• Using a flat-bladed screwdriver, carefully remove the shift lock manual override cover which is located on the PRNDL bezel.

• Press and maintain firm pressure on the brake pedal.

• Using the screwdriver, reach into the manual override opening. Press and hold the shift lock lever down.

• Press the Shifter Release button and shift into NEUTRAL.

• The vehicle may then be started in NEUTRAL.

• Have your vehicle inspected by your local authorized dealer if the shift lock manual override has been used.

WHAT TO DO IN EMERGENCIES

24 HOUR TOWING ASSISTANCE

• Dial toll-free 1-800-521-2779.

• Provide your name, vehicle identification number and license plate number.

• Provide your location, including telephone number, from which you are calling.

• Briefly describe the nature of the problem and answer a few simple questions.

• You will be given the name of the service provider and an estimated time of arrival. If you feel you are in an “unsafe situation”, please let us know. With your consent, we will contact local police or safety authorities.

INSTRUMENT CLUSTER WARNING LIGHTS

- Electronic Stability Program (ESP) Indicator Light

• If this indicator light flashes during acceleration, apply as little throttle as possible. While driving, ease up on the accelerator. Adapt your speed and driving to the prevailing road conditions. To improve the vehicles traction when starting off in deep snow, sand or gravel, it may be desirable to switch the ESP system off.

- Tire Pressure Monitoring System (TPMS) Light

• A Tire Pressure Monitoring Light and a “low tire” message will display in your instrument cluster along with an audible chime if one or more of your vehicle’s four road tires are significantly under-inflated.

• Check the inflation pressure of each tire and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information” label located on the driver’s side door opening. The TPMS light should not be used as a tire pressure gauge when adjusting your tire pressure.

• It is recommended that you check the tire pressure in the morning when tires are cool; inflate each tire to the recommended pressure for your vehicle. The light will turn off after your vehicle’s tire pressures are properly inflated and the pressure has been recognized. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) before the light will turn off.

• Temperature changes can affect tire pressure, causing the TPMS light to turn on. Tire pressures will also increase as the vehicle is driven – this is normal and you should not adjust for this increased pressure.

• Driving on under-inflated tires reduces your vehicle’s fuel efficiency and tire tread life. If a spare tire is in use on the vehicle, the TPMS light may turn on.

- Brake Warning Light

• The Brake Warning light illuminates when there is either a system malfunction or the parking brake is applied. If the light is on and the parking brake is not applied, it indicates a possible brake hydraulic malfunction, brake booster problem or an Anti-Lock Brake System problem.

• We recommend you drive to the nearest Service Center and have the vehicle serviced immediately.

WHAT TO DO IN EMERGENCIES

WARNING!

Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident. Have the vehicle checked immediately.

- Malfunction Indicator Light (MIL)

• Certain conditions, such as a loose or missing gas cap, poor fuel quality, etc., may illuminate the MIL after engine start. The vehicle should be serviced if the light stays on through several typical driving cycles. In most situations, the vehicle will drive normally and not require towing.

• If the MIL flashes when the engine is running, serious conditions may exist that could lead to immediate loss of power or severe catalytic converter damage. We recommend you do not operate the vehicle. Have the vehicle serviced as soon as possible if this occurs.

- Electronic Stability Program (ESP) Indicator Light/Brake Assist

System (BAS) Warning Light

• If the ESP/BAS warning light comes on continuously with the engine running, a malfunction has been detected.

• If this light remains on after several ignition cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), we recommend you drive to the nearest Service Center as soon as possible to have the problem diagnosed and corrected.

- Charging System Light

• This light shows the status of the electrical charging system. If the charging system light remains on, it means that the vehicle is experiencing a problem with the charging system.

• We recommend you do not continue driving if the charging system light is on. Have the vehicle serviced immediately.

- Oil Pressure Warning Light

• This light indicates low engine oil pressure. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound for four minutes when this light turns on.

• We recommend you do not operate the vehicle or engine damage will occur. Have the vehicle serviced immediately.

- Anti-Lock Brake (ABS) Light

• This light monitors the Anti-Lock Brake System (ABS).

• If the light is not on during starting, stays on, or turns on while driving, we recommend you drive to the nearest Service Center and have the system serviced as soon as possible.

WHAT TO DO IN EMERGENCIES

- Electronic Throttle Control (ETC) Light

• This light informs you of a problem with the Electronic Throttle Control (ETC) system.

• If a problem is detected, the light will come on while the engine is running. Cycle the ignition key when the vehicle has completely stopped and the shift lever is placed in the PARK position; the light should turn off.

• If the light remains lit with the engine running, your vehicle will usually be drivable; however, see an authorized dealer for service as soon as possible. If the light is flashing when the engine is running, immediate service is required and you may experience reduced performance, an elevated/rough idle or engine stall and your vehicle may require towing.

- Airbag Warning Light

• If the light is not on during starting, stays on, or turns on while driving, we recommend you drive to the nearest Service Center and have the system serviced as soon as possible.

Fuel Cap/Loose Gas Cap Message

• If a “gas cap” message (shown as Check Gascap) appears, tighten the gas cap until a “clicking” sound is heard.

• If the message continues to appear for more than three days after tightening the gas cap, see your dealer.

Oil Change Indicator

Message

• If an “oil change” message (shown as Oil Change Required) appears and a single chime sounds, it is time for your next required oil change.

Resetting The Light After Servicing

• Turn the ignition switch to the ON/RUN position (do not start engine).

• Fully depress the accelerator pedal three times within 10 seconds.

• Turn the ignition switch to the OFF/LOCK position.

WHAT TO DO IN EMERGENCIES

IF YOUR ENGINE OVERHEATS

• In any of the following situations, you can reduce the potential for overheating by taking the appropriate action.

• On the highways — slow down.

• In city traffic — while stopped, shift transmission into NEUTRAL, but do not increase engine idle speed.

NOTE: There are steps that you can take to slow down an impending overheat condition:

• If your air conditioner (A/C) is on, turn it off. The A/C system adds heat to the engine cooling system and turning the A/C off can help remove this heat.

• You can also turn the Temperature Control to maximum heat, the Mode Control to floor and the Fan Control to high. This allows the heater core to act as a supplement to the radiator and aids in removing heat from the engine cooling system.

• If the temperature reading does not return to normal, turn the engine off immediately.

• We recommend that you do not operate the vehicle or engine damage will occur. Have the vehicle serviced immediately.

CAUTION!

Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads HOT (H), pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range. If the pointer remains on HOT (H), and you hear continuous chimes, turn the engine off immediately and call for service.

WARNING!

You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator or coolant bottle is hot.

WHAT TO DO IN EMERGENCIES

JACKING AND TIRE CHANGING

WARNING!

• Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

• Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.

• The jack is designed to use as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.

• If it is necessary to retrieve the spare tire from under the vehicle on the side of the vehicle close to moving traffic, pull far enough off the road to avoid the danger of being hit.

Jack Location

• The scissor-type jack and tire changing tools are located in a compartment behind the third row seat.

WHAT TO DO IN EMERGENCIES

Spare Tire Stowage

• To remove or stow the spare, use the jack handle to rotate the “spare tire drive” nut which is located under a plastic cover under the cargo load floor, just inside the liftgate opening.

• Lower the spare tire by turning the drive nut counterclockwise with the jack-handle assembly until the spare tire is on the ground with enough cable slack to allow you to pull the spare tire out from underneath the vehicle.

• When the spare is clear, tilt the retainer at the end of the cable and pull it through the center of the wheel.

Preparations For Jacking

• Park on a firm, level surface. Avoid ice or slippery areas.

• Set the parking brake and shift the automatic transmission into PARK.

• Turn the ignition to LOCK and turn on the Hazard Warning flasher.

• Block both the front and rear of the wheel diagonally opposite of the jacking position. For example, if changing the right front tire, block the left rear wheel.

NOTE: Passengers should not remain in the vehicle when the vehicle is being jacked.

Jacking And Tire Changing Instructions

WARNING!

Carefully follow these tire changing procedures to help prevent personal injury or damage to your vehicle: Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.

• Remove the spare tire, jack and tools from their stored location.

• Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground.

• Assemble the jack and jacking tools. Connect the jack handle driver to the extension, then to the lug wrench.

WHAT TO DO IN EMERGENCIES

• Place the jack:

• For front wheels, place it under the front lower control arm.

• For rear wheels, place it under the axle near the wheel to be changed.

• Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange.

• Raise the vehicle by turning the jack screw clockwise. Raise the vehicle only until the tire just clears the surface and enough clearance is obtained to install the spare tire.

WARNING!

Raising the vehicle higher than necessary can make the vehicle less stable and cause an accident. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire.

• Remove the lug nuts, wheel cover (if equipped) and wheel.

• Position the spare wheel/tire on the vehicle and install the lug nuts with the cone-shaped end toward the wheel. Do NOT attempt to install a center cap or wheel cover on the compact spare. Lightly tighten the lug nuts clockwise. To avoid the risk of forcing the vehicle off the jack, do not tighten the nuts fully until the vehicle has been lowered.

• Lower the vehicle by turning the jack screw to the left, and remove the jack and wheel blocks.

• Finish tightening the lug nuts. Push down on the wrench while tightening for increased leverage. Alternate nuts until each one has been tightened twice. The correct wheel nut tightness is 95 ft lbs (130 N•m). If in doubt about the correct tightness, have them checked with a torque wrench by your authorized dealer or at a service station.

WARNING!

A loose tire or jack, thrown forward in a collision or hard stop, could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided.

• Secure the tire, jack, and tools in their proper locations.

NOTE: Tire should be stowed with the “beauty” side up. Storing the tire upside down may result in scratching or damage to the wheel face. Continue winching up the tire until you hear the winch “ratchet” three times.

WHAT TO DO IN EMERGENCIES

JUMP-STARTING

WARNING!

Any procedure other than the following could result in:

• Personal injury caused by electrolyte squirting out the battery vent,

• Personal injury or property damage due to battery explosion,

• Damage to the charging system of the booster vehicle or of the immobilized vehicle.

WARNING!

• Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be hurt by the fan.

• Remove any metal jewelry, such as watch bands or bracelets, that might make an inadvertent electrical contact. You could be seriously injured.

• Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or clothing. Do not lean over a battery when attaching clamps or allow the clamps to touch each other. If acid splashes in your eyes or on skin, flush the contaminated area immediately with large quantities of water.

(Continued)

WHAT TO DO IN EMERGENCIES

WARNING! (Continued)

• A battery generates hydrogen gas which is flammable and explosive. Keep flames or sparks away from the battery vent holes. Don’t lean over the battery when attaching clamps or allow the clamps to touch each other.

• Do not use a booster battery or any other booster source with an output that exceeds 12-volts (i.e., do not use a 24-volt power source).

• Check the battery test indicator (if equipped). If a light or bright colored dot is visible in the indicator, DO NOT jump-start the battery. If the indicator is dark or shows a green dot, proceed as follows:

• Remove all metal jewelry, such as watch bands or bracelets, which might make an unintended electrical contact.

WARNING!

• Do not permit vehicles to touch each other as this could establish a ground connection and personal injury could result.

• Do not connect the cable to the negative post of the discharged battery. The resulting electrical spark could cause the battery to explode and could result in personal injury.

• Park the booster vehicle within cable reach but without letting the vehicles touch. Set the parking brake on both vehicles, shift the automatic transmission into PARK, and turn the ignition to LOCK.

• Turn off the heater, radio, and all unnecessary electrical loads.

• Connect one end of a jumper cable to the positive terminal of the booster battery. Connect the other end of the same cable to the positive terminal of the discharged battery.

• Connect the other cable, first to the negative terminal of the booster battery and then to the engine ground (-) of the vehicle with the discharged battery. Make sure you have a good contact on the engine ground.

• Start the engine in the vehicle which has the booster battery; let the engine idle a few minutes.

• Start the engine in the vehicle with the discharged battery.

• When removing the jumper cables, reverse the above sequence exactly. Be careful of the moving belts and fan.

WARNING!

During cold weather when temperatures are below the freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump-starting because the battery could rupture or explode. The battery temperature must be brought up above the freezing point before attempting a jump-start.

WHAT TO DO IN EMERGENCIES

EMERGENCY TOW HOOKS

• If your vehicle is equipped with tow hooks, they are mounted in the front and the rear.

NOTE: For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the vehicle.

WARNING!

• Chains are not recommended for freeing a stuck vehicle. Chains may break, causing serious injury or death.

• Stand clear of vehicles when pulling with tow hooks. Tow straps and chains may break, causing serious injury.

CAUTION!

Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow truck hookup or highway towing. You could damage your vehicle. Tow straps are recommended when towing the vehicle; chains may cause vehicle damage.

WHAT TO DO IN EMERGENCIES

Rear Wheels Raised,

Front Wheels on the

Ground

NOT permitted without

towing dolly

Shift lever must be In

NEUTRAL, the speed

less than 30 mph

(48 km/h) and the

distance traveled less

than 15 mi (24 km).

NOT permitted without

towing dolly

Front Wheels Raised,

Rear Wheels on the

Ground

towing dolly

NEUTRAL, the speed

less than 30 mph

(48 km/h) and the

distance traveled less

than 15 mi (24 km).

towing dolly

Flatbed Towing (all

four wheels suspended

OFF the ground)

Flat Towing (all four

wheels on the ground)

Model

TOWING A DISABLED VEHICLE

Remove the driveshaft Recommended method NOT permitted without

Two-wheel drive -

Transmission not

operable

Recommended method Shift lever must be In

Shift lever must be In

Two-wheel drive -

NEUTRAL, the speed

less than 30 mph

Transmission operable

(48 km/h) and the

distance traveled less

than 15 mi (24 km).

Not permitted Recommended method NOT permitted without

Four-wheel drive

WHAT TO DO IN EMERGENCIES

EVENT DATA RECORDER (EDR)

• This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle's systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were buckled/fastened;

• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

• How fast the vehicle was traveling.

• This data can help provide a better understanding of the circumstances in which a crash and injuries occur. NOTE: EDR data is recorded by your vehicle only if a non-trivial crash situation occurs; no data is recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) is recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

• To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

MAINTAINING YOUR VEHICLE

OPENING THE HOOD

• Pull the hood release lever located below the steering wheel at the base of the instrument panel.

• Reach into the opening beneath the center of the hood and move the safety latch lever while lifting the hood at the same time.

WARNING!

Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.

MAINTAINING YOUR VEHICLE

ENGINE COMPARTMENT

3.7L Engine

MAINTAINING YOUR VEHICLE

5.7L Engine

MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES

Component Fluid, Lubricant, or Genuine Part Capacities

Engine Coolant -

3.7L without rear heat.

Engine Coolant -

3.7L with rear heat.

Engine Coolant -

5.7L without rear heat.

Engine Coolant -

5.7L with rear heat.

Engine Oil with Filter 3.7L

Engine Oil with Filter 5.7L

Fuel Selection 5.7L 87 Octane acceptable. 89 recommended for 5.7L. 21 Gallons (79 Liters) Engine Oil Filter

3.7L, 5.7L Spark Plug 3.7L ZFR6F–11G (Gap 0.043 in [1.09 mm]) — Spark Plug 5.7L LZFR5C–11G (Gap 0.043 in [1.09 mm]) — Automatic

Transmission Transfer Case

(NV140 Single Speed Only.

Transfer Case (NV245 Two Speed Only)

Axle Differential (Front / Rear)

Brake Master Cylinder

Power Steering Reservoir

MOPAR /100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent.

Antifreeze/Coolant Five Year

12.7 Quarts (11.8 Liters) Includes heater and coolant recovery bottle filled to MAX level.

14 Quarts (13.2 Liters) Includes heater and coolant recovery bottle filled to MAX level.

15.2 Quarts (14.4 Liters) Includes heater and coolant recovery bottle filled to MAX level.

MOPAR®Antifreeze/Coolant Five Year /100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent.

16.7 Quarts (15.8 Liters) Includes heater and coolant recovery bottle filled to MAX level.

API certified 5W-20 engine oil, Meeting the

5 Quarts (4.7 Liters) requirements of Chrysler Material Standard MS-6395. Refer to your oil filler cap for correct SAE grade.

API certified 5W-20 engine oil, meeting the

7 Quarts (6.6 Liters) requirements of Chrysler Material Standard MS-6395. Refer to your oil filler cap for correct SAE grade.

MOPAR

MOPAR or equivalent licensed ATF+4

MOPAR

Engine Oil Filter or equivalent.

ATF+4®Automatic Transmission Fluid

NV 247 / 245 Transfer Case Lubricant

product.

product.. —

or equivalent. —

MOPAR

Synthetic Gear & Axle Lubricant SAE 75W–140 (API–GL5) or equivalent with Friction Modifier Additive.

MOPAR

DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 is not available, then DOT 4 is acceptable. Use only recommended brake fluids.

This system requires the use of MOPAR

Hydraulic System Power Steering Fluid or equivalent, Which meets Chrysler Matreial Standard MS–10838.

—

MAINTAINING YOUR VEHICLE

XXXX

6,000 12,000 18,000 24,000 30,000 36,000 42,000 48,000 54,000 60,000 66,000 72,000 78,000

Miles:

Or Months: 6 12 18 24 30 36 42 48 54 60 66 72 78

MAINTENANCE CHART

10,000 20,000 30,000 40,000 50,000 60,000 70,000 80,000 90,000 100,000 110,000 120,000 130,000

Or Kilometers:

Change the engine oil and engine oil filter. XXXXXXXXXXXXX

XXXX X

Rotatethetires. XXXXXXXXXXXXX

If using your vehicle for any of the following: Dusty or

off-road conditions. Inspect the engine air cleaner

XXXX

Replace the engine air cleaner filter. X X

Inspect the front and rear axle fluid, change if using

your vehicle for police, taxi, fleet, off-road or frequent

trailer towing.

Inspect the transfer case fluid X

Change the transfer case fluid if using your vehicle

for the following: police, taxi, fleet or frequent trailer

towing.XAdjust the parking brake on vehicles equipped with

four wheel disc brakes.

Inspect the brake linings, replace if necessary. XXXXXX

Inspect the CV joints. Perform the first inspection at

12,000 miles (20,000 km) or 12 months.

Inspect the exhaust system. Perform the first

filter, replace if necessary.

inspection at 12,000 miles (20,000 km) or 12 months.

Change the automatic transmission fluid and filter if

XXXXXX

using your vehicle for any of the following: police,

taxi, fleet of frequent trailer towing.XInspect front suspension, tie rod ends, and boot seals

for cracks or leaks and all parts for damage, ware,

improper looseness or end play; replace if necessary.

Replace the spark plugs (3.7L & 5.7L engines). X X

• Refer to the Owner's Manual on the DVD for the complete maintenance schedule.

MAINTAINING YOUR VEHICLE

Maintenance Record

Odometer Date Signature, Authorized Service Center

6,000 Miles (10,000 km) or 6 Months

12,000 Miles (20,000 km) or 12 Months

18,000 Miles (30,000 km) or 18 Months

24,000 Miles (40,000 km) or 24 Months

30,000 Miles (50,000 km) or 30 Months

36,000 Miles (60,000 km) or 36 Months

42,000 Miles (70,000 km) or 42 Months

48,000 Miles (80,000 km) or 48 Months

54,000 Miles (90,000 km) or 54 Months

60,000 Miles (100,000 km) or 60 Months

66,000 Miles (110,000 km) or 66 Months

72,000 Miles (120,000 km) or 72 Months

78,000 Miles (130,000 km) or 78 Months

MAINTAINING YOUR VEHICLE

FUSES

Underhood Fuses (Integrated Power Module)

MAINTAINING YOUR VEHICLE

• The Integrated Power Module (IPM) is located in the engine compartment near the battery. This center contains cartridge fuses, mini-fuses and relays.

Cavity Cartridge Fuse Mini-Fuse Description

8 10 Amp Red Lt Park Lamps

9 10 Amp Red Trailer-Tow Park Lamps 10 10 Amp Red Rt Park Lamps 12 20 Amp Yellow Front Control Module (FCM) Batt #4 13 20 Amp Yellow Front Control Module (FCM) Batt #2 14 20 Amp Yellow Adjustable Pedal 15 20 Amp Yellow Ft Fog Lamps 16 20 Amp Yellow Horn 17 20 Amp Yellow Rear Fog Lamps (Export Only) 18 20 Amp Yellow Front Control Module (FCM) Batt #1 19 20 Amp Yellow Lt Trailer-Tow Stop/Turn 20 20 Amp Yellow Front Control Module (FCM) Batt #3 21 20 Amp Yellow Rt Trailer-Tow Stop/Turn 22 30 Amp Pink Final Drive Control Module (FDCM)

23 50 Amp Red Radiator Fan 27 15 Amp Blue Ignition Off Draw (IOD) #1 —

28 20 Amp Yellow Ignition Off Draw (IOD) #2 — Radio 29 10 Amp Red Occupant Restraint Controller (ORC)

30 10 Amp Red Occupant Restraint Controller (ORC)

MOD

Intrusion Module, Satellite Video, Steering Control Module

R/S

R/O

MAINTAINING YOUR VEHICLE

Underhood Fuses (Power Distribution Center)

• The Power Distribution Center (PDC) is located in the left side of the engine compartment near the Brake Fluid Reservoir. This center contains cartridge fuses, mini-fuses and relays.

Cavity Cartridge Fuse Mini-Fuse Description

1 50 Amp Red PTC Heater 1 (Diesel Only) 2 40 Amp Green HID Headlamps 3 50 Amp Red PTC Heater 2 (Diesel Only) 4 30 Amp Pink Power Outlets 5 50 Amp Red PTC Heater 3 (Diesel Only) 6 30 Amp Pink Cig Lighter, Trail Tow Batt 7 40 Amp Green Power Liftgate (Commander Only) 8 40 Amp Green Starter, JB Power

9 20 Amp Blue Front Power Windows 10 — Spare 11 40 Amp Green HVAC Blower 12 30 Amp Pink Rear Wiper, Ign R/O 13 40 Amp Green Rear Window Defroster (EBL)/Heated

14 30 Amp Pink Rear HVAC (If Equipped) 15 — Spare 16 50 Amp Red ASD

Mirror

MAINTAINING YOUR VEHICLE

Cavity Cartridge Fuse Mini-Fuse Description

17 30 Amp Pink ABS Pump 18 40 Amp Green Accessory Delay, Seats 19 40 Amp Green JB Power 20 30 Amp Pink Wiper Motor 21 20 Amp Yellow Fuel Pump 22 20 Amp Yellow TCM, A/C Clutch 23 25 Amp Natural Power Inverter 24 20 Amp Yellow Rear Heated Seats 25 20 Amp Yellow Final Drive Control Module (FDCM) 26 15 Amp Blue Brake Lamps 27 20 Amp Yellow HD Washer (If Equipped) (Export

28 30 Amp Green ABS Valves 29 20 Amp Yellow PCM Batt (Gasoline Only) 30 — Spare 31 — Spare 32 15 Amp Blue Powertrain Control Module (Diesel

33 20 Amp Yellow Final Drive Control Module (FDCM)

34 — Spare 35 20 Amp Yellow Trail-Tow Mod (Export Only) 36 — Spare 37 20 Amp Yellow Ignition Switch 38 20 Amp Yellow HID Left 39 20 Amp Yellow HID Right 40 25 Amp Natural Next Generation Controller (NGC),

41 20 Amp Yellow Subwoofer (SRT Only) 42 — Spare 43 25 Amp Natural Coils, Actuators 44 — Spare

Only)

E-Diff

Injectors

MAINTAINING YOUR VEHICLE

Interior Fuses

• The fuse panel is on the lower instrument panel just to the left of the steering column.

Cavity Mini-Fuse Description

F1 30 Amp Green Audio Amp F2 15 Amp Blue Sunroof F3 10 Amp Red Htd Mirror (EBL) F4 20 Amp Yellow Rr Pwr Out F5 10 Amp Red Rr HVAC (R/O) (Commander Only) F6 Spare F7 20 Amp Yellow Door Locks F8 Spare F9 20 Amp Yellow Pwr Outlet

F10 10 Amp Red Final Drive Control Module (FDCM), HVAC,

F11 Spare F12 10 Amp Red Door Mods, O/H Lamps, IP Courtesy Lamps,

F13 10 Amp Red Autowipe (R/A) F14 20 Amp Yellow Cigar Ltr (R/A) F15 10 Amp Red Tire Pressure Transponders F16 10 Amp Red Upper & Lower Switch Bank, Diag. Connector,

Rear Heated Seat Switch, O/H, HVAC Relay, Rear Park Assist

Glove Box Lamp

Cluster

MAINTAINING YOUR VEHICLE

Cavity Mini-Fuse Description

F17 15 Amp Blue Flipper Glass F19 Spare (R/S) F20 10 Amp Red Steering Column Control Module, Cluster (R/S) F21 Spare (Acc Delay) F22 15 Amp Blue Rear Wiper (B+) F24 10 Amp Red Power Distribution Center (PDC) Relays,

F25 10 Amp Red Shifter Assy (BTSI), Trans. Case Switch,

TIRE PRESSURES

• Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle.

• The tire pressures recommended for your vehicle are found on the “Tire and Loading Information” label located on the driver’s side door opening.

NOTE: Refer to the Owner's Manual on the DVD for more information on the life of tires.

Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.

Powertrain Control Module, A580 (R/S)

ESP/ABS, Trailer Sway Damp Relay

WARNING!

Improperly inflated tires are dangerous and can cause accidents. Under-inflation is the leading cause of tire failure and may result in severe cracking, component separation, or “blow out”. Over-inflation reduces a tire’s ability to cushion shock. Objects on the road and chuck holes can cause damage that results in tire failure. Unequal tire pressures can cause steering problems. You could lose control of your vehicle. Over-inflated or under-inflated tires can affect vehicle handling and can fail suddenly, resulting in loss of vehicle control.

MAINTAINING YOUR VEHICLE

WHEEL AND WHEEL TRIM CARE

• All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.

• To remove heavy soil and/or excessive brake dust, use MOPAR equivalent or select a nonabrasive, non-acidic cleaner.

CAUTION!

Do not use scouring pads, steel wool, a bristle brush, or metal polishes. Do not use oven cleaner. These products may damage the wheels protective finish. Avoid automatic car washes that use acidic solutions or harsh brushes that may damage the wheels protective finish. Only MOPAR recommended.

Wheel Cleaner or equivalent is

EXTERIOR BULBS

LIGHT BULBS – Exterior Bulb Number

Backup, Tail, Stop, Turn Lamp 3057K Center High-Mounted Stop Lamp

(CHMSL) Fog Lamp - If Equipped 9145 Front Park/Turn Signal 3157A Front Side Marker W5W Headlamp – High Intensity Discharge

(HID) Headlamp - Low Beam 9006 Headlamp – High Beam 9005 License Lamp 168

* CHMSL is not serviceable. It is a LED lamp. To replace the LED, the entire CHMSL assembly must be replaced.

** The headlamps are a type of high-voltage discharge tube. High voltage can remain in the circuit even with the headlamp switch off and the key removed. Because of this, you should not attempt to service a headlamp bulb yourself. If a headlamp bulb fails, take your vehicle to an authorized dealer for service.

LED(*)

Service at Authorized Dealer (**)

Wheel Cleaner or

CONSUMER ASSISTANCE

CHRYSLER GROUP LLC CUSTOMER CENTER

P.O. Box 21–8004

Auburn Hills, MI 48321–8004

Phone: 1–800–992–1997

CHRYSLER CANADA INC. CUSTOMER CENTER

P.O. Box 1621

Windsor, Ontario N9A 4H6

Phone: 1–800–465–2001

ASSISTANCE FOR THE HEARING IMPAIRED

• To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf ) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY. Canadian residents with hearing difficulties that require assistance can use the special needs relay service offered by Bell Canada. For TTY teletypewriter users, dial 711 and for Voice callers, dial 1–800–855–0511 to connect with a Bell Relay Service operator.

WARNING!

Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm.

PUBLICATIONS ORDERING

• If you are the first registered retail owner of your vehicle, you may obtain a free printed copy of the Owner's Manual, Warranty Booklet or Radio Manuals on your DVD by calling 1–800–992–1997 (U.S.) or 1–800–387–1143 (Canada) or by contacting your dealer.

• Replacement User Guides or DVDs or, if you prefer, a printed copy of the Owner's Manual, Warranty Booklet or Radio Manuals may be purchased by visiting www.techauthority.com or by calling 1–800–890–4038 (U.S.) or 1–800–387–1143 (Canada). Visa, Master Card, American Express and Discover orders are accepted. If you prefer mailing your order, please call the above numbers for an order form.

NOTE: A street address is required when ordering manuals (no P.O. Boxes).

CONSUMER ASSISTANCE

REPORTING SAFETY DEFECTS IN THE 50 UNITED STATES AND WASHINGTON, D.C.

• If you believe that your vehicle has a defect that could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer.

• If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.

• To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424–

9153), or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE., West Building, Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.

In Canada

• If you believe that your vehicle has a safety defect, you should contact the Customer Service Department immediately. Canadian customers who wish to report a safety defect to the Canadian government should write to: Transport Canada, Motor Vehicle Defect Investigations and Recalls, 2780 Sheffield Road, Ottawa, Ontario K1B 3V9.

TIRE WARRANTY

Tire Limited Warranty And Adjustment Policy

• When a tire is removed from service due to a covered warranty condition under a tire manufacturer’s “Limited Warranty Program”, you may be eligible for a free tire replacement or a comparable new tire on a “prorated basis”.

• Certain conditions, such as irregular wear or tire damage due to road hazards, collision, improper inflation, intentional alteration, and misuse, are excluded from the Limited Warranty Program. The Limited Warranty Program expires when your tires either wear to a specified tread depth, and/or after a period of time from the date of purchase, as stated in the Tire Warranty on the DVD.

NOTE: Refer to the Tire Warranty on the DVD for specific information relating to the manufacturer's limited warranty for the tires installed on your vehicle. The DVD can play on any computer or DVD player. If you have any questions regarding the limited tire warranty coverage, contact your local Chrysler dealer or your local authorized tire dealer. If you cannot access the DVD and would like a paper copy of the limited warranty for the tires installed on your vehicle, call 1-800-922-1997 (U.S.) or 1-800-387-1143 (Canada) or ask your Chrysler dealer.

CONSUMER ASSISTANCE

Disclaimer:

• THE TIRE MANUFACTURER’S LIMITED WARRANTY PROGRAM, THE DETAILS OF WHICH CAN BE FOUND, ON THE OWNERS MANUAL DVD, THE TIRE MANUFACTURER’S WEBSITE OR AT ANY AUTHORIZED SERVICE CENTER ARE IN LIEU OF ALL OTHER REMEDIES OR WARRANTIES, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY. THE TIRE MANUFACTURER EXPRESSLY DISCLAIMS LIABILITY FOR INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOST PROFIT, LOSS OF BUSINESS, LOSS OF GOODWILL, LOSS OF REPUTATION, PUNITIVE OR ANY OTHER DAMAGE, COST OR LOSS OF ANY KIND. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

WARNING!

NOTE: Refer to the Owner’s Manual on the DVD for complete warning information that could prevent accidents, injuries and even deaths.

WARNING!

Death, serious injury and/or property damage may result from:

• Tire failure due to impact damage and/or improper maintenance.

(Continued)

WARNING! (Continued)

• Tires should be inspected regularly by a qualified technician for signs of damage, such as punctures, impacts, underinflation or overloading.

• Progressive air loss may result from punctures, cuts, curbing, impacts or partial bead unseating.

Some fitment causes for air loss are:

• Incomplete bead seating.

• Bead tearing caused by a machine tool due to insufficient lubrication or improper adjustment.

• Leaking valve core or rubber valve components (these should be replaced when problems are detected and whenever tires are replaced).

• Tire failure due to improper repairs.

• See Rubber Manufacturer’s Association (RMA) established repair procedures at www.rma.org for information on proper repair procedures. Never perform a temporary repair or use an inner tube as a substitute for a proper repair. Only qualified persons should repair tires.

• Explosion of tire/rim assembly due to improper mounting.

• Only specially trained persons should mount tires.

• Failure to mount tires on approved rims.

• Failure to deflate single or dual assemblies completely before demounting.

CONSUMER ASSISTANCE

Using Lift Kits

• Use of lift kits with some vehicle/tire combinations can cause instability or loss of control. When changing tire sizes, always consult an installer for optimum rim width and carefully check vehicle/tire clearances.

Check Your Tires For Damage

• Frequent (at least monthly) inspection of your tires for signs of damage, uneven tread wear and their general condition is important for safety. Impacts, penetrations, cracks, knots, bulges or air loss always require tire removal and expert inspection.

Tire Service Life

• The service life of a tire is dependent upon varying factors including, but not limited to, your driving style, tire pressure and distance driven.

WARNING!

Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death.

• Keep dismounted tires in a cool, dry place with as little exposure to the light as possible.

• Protect tires from contact with oil, grease, and gasoline.

NOTE: All tire warranties are made by the tire manufacturer. Tires are not covered under your Chrysler New Vehicle Limited Warranty.

MOPAR ACCESSORIES

MOPAR® ACCESSORIES

• The following highlights just some of the authentic Jeep Accessories by MOPAR®that have been engineered to customize your Jeep Commander.

• To see the full line of accessories stop by your Jeep dealer or visit MOPAR.com

CHROME:

• Grille • Tubular Side Steps • Body Side Moldings

• Front Air Deflectors • Fuel Door

OFF ROAD:

• Tubular Grille Guards • Rock Rails • Skid Plates

• Tow Hooks

EXTERIOR:

• Splash Guards • Side Window Air

• Wheels • Tail lamp Guards

INTERIOR:

• Premium Carpet Floor Mats

• Molded Cargo Tray • Folding Cargo Mat • Carpet Cargo Mat

Deflector

• Slush Floor Mats • Door Sill Guards

• Molded Running Boards

ELECTRONICS:

• Portable Navigation Systems

• uconnect™ gps (RER) • Sirius Satellite Radio • Rear Seat Video

•iPod

CARRIERS:

• Hitch-mount Bike Carrier • Hitch Receivers • Roof Top Bike Carrier

• Roof Top Cargo Basket • Roof Top Ski and

iPod

Adapter • Rear View Camera • Heated Seats

is a registered trademark of Apple Inc.

• uconnect™ web (WiFi) • uconnect™ tunes (REN)

• Roof Top Cargo Box

Snowboard Carrier

NOTES

DO ANYTHING

This guide has been prepared to help you get quickly acquainted with your new Jeep and to provide a convenient reference source for common questions.

However, it is not a substitute for your Owner’s Manual.

For complete operational instructions, maintenance

procedures and important safety messages, please

consult your Owner’s Manual, Navigation Radio User

Manual, Multimedia User Manual and other Warning

Labels in your vehicle.

Not all features shown in this guide may apply to your

vehicle. For additional information on accessories to help personalize your vehicle, visit www.mopar.com or your local Jeep dealer.

10XK74-926-AA

Commander

First Printing

User Guide

JEEP.com

Jeep COMMANDER 2010 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER GROUP LLC

Vehicles Sold In Canada

Driving And Alcohol

Rollover Warning

CONTROLS AT A GLANCE

DRIVER COCKPIT

INSTRUMENT CLUSTER

Warning Lights

Indicators

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors/Liftgate

Unlock Flipper Glass

Remote Start

Panic Alarm

Express Window Feature

Emergency Key

THEFT ALARM

To Arm

To Disarm

SEAT BELT

FRONT SEATS

Manual Seat Adjustment

Eight-Way Driver Power Seat

Four-Way Passenger Power Seat

Heated Seats

Memory Seats

REAR SEATS

40/20/40 Second Row Folding Seat

50/50 Third Row Folding Seat

2nd Row Heated Seats

TILT/TELESCOPING STEERING COLUMN

ADJUSTABLE PEDALS

PROGRAMMABLE FEATURES

Electronic Vehicle Information Center (EVIC) – If Equipped

OPERATING YOUR VEHICLE

TURN SIGNAL/LIGHTS LEVER

Headlights/Parking Lights

SmartBeams™

Instrument Panel Dimmer

Flash To Pass

High Beam Operation

Fog Lights

Turn Signals/Lane Change Assist

WIPER/WASHER LEVER

Front Wipers

Rear Wiper

SPEED CONTROL LEVER

Cruise ON/OFF

Accel/Decel

Cancel

Resume

ELECTRONIC RANGE SELECT (ERS)

MANUAL CLIMATE CONTROLS

Air Recirculation

AUTOMATIC TEMPERATURE CONTROLS (ATC)

Automatic Operation

Air Conditioning (A/C)

Air Recirculation

Rear Climate Control

PARKSENSE® REAR PARK ASSIST

PARKVIEW® REAR BACK-UP CAMERA

POWER LIFTGATE

LIFTGATE FLIPPER GLASS

POWER SUNROOF

Opening Sunroof

Closing Sunroof

Manual Open/Close

Venting Sunroof

Pinch Protection Feature

WIND BUFFETING

NON-TOUCH-SCREEN RADIOS

RES Radio

ELECTRONICS

RES/RSC Radio
