HP6B, HP8B,
HP82B,
HP88F
simple
set-up guide
thank you for choosing JBL. For over 50 years, JBL has
been involved in every aspect of musical and film recording and
reproduction, from live performances to monitoring the recordings
you play in your home, car, or office.
We’re confident that the
chosen will provide every note of enjoyment that you expected –
and that when you think about purchasing additional audio
equipment for your home, car, or office, you will once again
choose JBL.
Please take a moment to complete the enclosed profile card. It
enables us to keep you posted on our latest advancements, and
helps us to better understand our customers and build products
that meet your needs and expectations.
JBL Consumer Products
JBL loudspeakers you have
one. Speaker Placement
Magnet
Magnet
HP6B, HP8B, HP82B
HP88F
Tweeter Grille Installation (optional)
two. Speaker Connections
– +– +
– + – +
Speaker Outputs
RIGHT LEFT
RIGHT LEFT
Connection Tips
Speakers and electronics terminals have corresponding (+) and
(–) terminals. It is important to connect both speakers identically: (+) on the speaker to (+) on the amplifier and (–) on the
speaker to (–) on the amplifier. Wiring “out of phase” results in
thin sound, weak bass and a poor stereo image.
Troubleshooting
If there is no sound from
any of the speakers, check
the following:
• Receiver/amplifier is on and
a source is playing.
• Review proper operation of
your receiver/amplifier.
If there is no sound coming
from one speaker, check the
following:
• Check the “Balance” control
on your receiver/amplifier.
• Check all wires and connections between receiver/
amplifier and speakers.
• Make sure all wires are
connected. Make sure none of
the speaker wires are frayed,
cut, or punctured.
If the system plays at low
volumes but shuts off as
volume is increased, check
the following:
• Check all wires and connections between receiver/
amplifier and speakers.
• Make sure all wires are connected. Make sure none of the
speaker wires are frayed, cut,
or punctured.
• If more than one pair of
main speakers is being used,
check the minimum impedance requirements of your
receiver/amplifier.
If there is low bass output,
check the following:
• Make sure the polarity
(+ and –) of the left and
right “Speaker Inputs” are
connected properly.
Declaration of Conformity
We, JBL Europe A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the products described
in this owner’s manual are in compliance with technical
standards:
EN 50 081-1/1992
EN 50 082-1/3.1995
Steen Michaelsen
JBL Europe A/S
Birkerød. DENMARK. 7/96
C
E
L
E
B
R
A
T
I
N
G
5
0
Y
E
A
R
S
Specifications
A Harman International Company
SYSTEM
Frequency Response (–6dB): 57Hz – 22kHz 48Hz – 22kHz
Recommended Maximum
Power Handling*: 100 watts 150 watts
Sensitivity @ 1 watt/1 meter:
Normal Impedance: 8 ohms 8 ohms
Crossover Frequency: 2800Hz 3000Hz
Woofer: 6-1/2" cast frame 8" cast frame
Midrange: N/A N/A
Tweeter: 1" pure titanium 1" pure titanium
Finish: black ash woodgrain vinyl black ash woodgrain vinyl
Dimensions (HxWxD): 16-1/2 x 9-1/4 x 8-1/8 inches 19-7/8 x 11-1/2 x 9-1/8 inches
Weight (each): 15 lbs/6.8 kg 21-1/4 lbs/9.6 kg
HP6B HP82B
89dB 90dB
419 x 235 x 206mm 501 x 292 x 232mm
SYSTEM
HP8B HP88F
Frequency Response (–6dB): 46Hz – 22kHz 40Hz – 22kHz
Recommended Maximum
Power Handling*: 200 watts 250 watts
Sensitivity @ 1 watt/1 meter:
91dB 93dB
Normal Impedance: 8 ohms 8 ohms
Crossover Frequency: 850Hz, 3000Hz 850Hz, 3000Hz
Woofer: 8" cast frame 2 x 8" cast frame
Midrange: 5" cast frame 5" cast frame
Tweeter: 1" pure titanium 1" pure titanium
Finish: black ash woodgrain vinyl black ash woodgrain vinyl
Dimensions (HxWxD): 23-1/8 x 11-1/2 x 10 inches 35-1/4 x 11-1/2 x 12-1/2 inches
584 x 292 x 254mm 870 x 292 x 318mm
Weight (each): 27 lbs/12.25 kg 47 lbs/21.3 kg
Occasional refinements may
be made to existing products
without notice, but will
always meet or exceed original speci-fications unless
otherwise stated.
*The maximum recommended
amplifier power rating will
ensure proper system headroom to allow for occasional
peaks. We do not recommend
sustained operation at these
maximum power levels.
JBL Consumer Products
80 Crossways Park West, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
1-800-336-4JBL (4525) (USA only)
1996 JBL, Incorporated. JBL is a registered trademark
©
of JBL, Incorporated.
Printed in USA 7/96 Part No. 330990-001
