GN Netcom
Now high-volume outbound call centers have a new profitability-enhancing tool—the
HT-Two headset telephone from GN Netcom. The HT-Two is an integrated headset
telephone solution: a professional-quality analog telephone made expressly for use with
any GN Netcom brand headset. The ideal choice for call centers and service bureaus with
predictive, preview and/or progressive dialing capabilities, the HT-Two’s no-dialpad design
eliminates unauthorized calls—and the associated expense—while ensuring agents stay
focused on their work. And since it takes the place of both the telephone and the headset
amplifier on an agent’s desk, the compact HT-Two saves space and reduces clutter—as
well as equipment costs.
• All-in-one headset telephone
• For outbound call center and CTI applications
• Reduces equipment costs and desktop clutter
• Compatible with any GN Netcom brand headset
• Two-year “No Fine Print” warranty
THE MORE-CALLS, LESS-COST HEADSET TELEPHONE.
HT-TWO
Page 2
The HT-Two (shown here with headset
stand and ADDvantage Plus headset) is the
perfect choice for high-volume outbound
call centers with predictive, preview and/or
progressive dialing capabilities.
General Specifications
Compatibility: Connects in parallel with an analog desk
Line Connection: 6-pin modular plug
Line Impedance: 600 ohms
Operating Current: 10-70 ma
Dialer: None (uses dialer in desk phone or computer)
Ringer: A three-tone ringer is heard in the headset
The HT-Two is designed to work with any GN Netcom brand headset. For high-volume
call center use, we recommend using the following models:
Indicators: Hookswitch Indicator LED lights when line is
Controls: Pick Up/Hang Up switch, Microphone Mute
Operating Temperature: +10 ° to +50 ° C
Storage Temperature: -10 ° to +50 ° C
Size: 121 mm (l) x 73 mm (w) x 32 mm (h)
Color: Black
Compliance: Complies with FCC Part 68, CS-03, UL & cUL
The ADDvantage Plus has become the
call center standard, with its combination of
great sound, lasting comfort and exceptional
durability. (Binaural model also available.)
The Orator-G’s unique features, like its
swing-away microphone boom, add up to a
dramatic new level of comfort, stability and
performance. (Monaural model also available.)
Recommended Headsets: All GN Netcom brand headsets
Receive Specifications
Receive Sensitivity: 100 dB SPL typical @ 1 kHz with Max Volume
Volume Control Range: 12 dB
Frequency Response: 200 Hz - 4 kHz
Distortion: < 5%
phone or PC modem to phone systems with
an analog line and RJ-11 jack.
receiver.
picked up. Mute Indicator LED flashes when
headset microphone is muted.
switch and Receive Audio Level Control
and –12 dBV from 600 ohm source
Transmit Specifications
The Optima-G delivers great sound and a
sleek, ergodynamic design plus surprising
affordability. (Binaural model also available.)
The Profile SureFit gives you three models (405, 405-FLEX and 405-UNC) to choose from, each
with three interchangeable wearing styles—flexible earhook, earloop and headband.
Printed in USA.
8/99
GNI-159A
Stratus Ultra-G offers versatility and value,
plus an array of features—like our Adjustable
Lobe Hinge™—that maximize comfort,
convenience and call clarity.
Sensitivity: -12 dBV/Pa typical @ 1 kHz into 600 ohms
Frequency Response: 200 Hz - 4 kHz
with 94 dB SPL into microphone
For more information:
GN Netcom, Inc.
77 Northeastern Blvd. Nashua NH 03062
1-800-826-4656 www.gnnetcom.com
