RC-2
Remote Controller
User manual
1
Features
The remote controller is an accessory of series smart alarm system. It
helps you quickly arm/disarm/home arm/trigger SOS the system.
It’s small and exquisite, convenient for carrying out on keychain or in pocket/bag.
Parameters
Reference RC-2
Code 261022
Wortking voltage DC 6V
Battery 2xCR2016 (3V)
Working current < 7.4mA
Standby current 0mA
Transmission distance Without obstacle 200m
Transmission frequency 433.92MHz
Working Temperature -20°C ~ 50°C
Humidity < 90% (non-condensing)
Dimension 58,0x33,1x11,0mm
Weight 16.4g (battery included)
2
Appearance
LED Indicator
Arm
Home arm
PCB Layout
Disarm
SOS
Keychain
Cover for
Battery
1× CR2032
Button Battery
3
Pairing with Main Panel
• Scanning the QR Code for Pairing.
• Scan the QR code printed on this accessory by App.
• The pairing result would be confirmed in App.
Learn Mode
• Launch the App/PC client for turn on Learn Mode.
• Follow the guideline in App/PC client to trigger the accessory for the system to learn.
• The pairing result would be confirmed in App/PC client.
Hint: How to trigger
• Press any button of the remote controller.
Operating Clarification
Arm
Press
Home Arm
Press
Disarm
Press
SOS
Press
ming status to call/text emergency contacts.
the LED indicator lights on, the system enters armed status.
the LED indicator lights on, the system enters home armed status.
the LED indicator lights on, the system enters disarmed status.
the LED indicator lights on, the system immediately enters emergent alar-
4
EKSELANS by ITS
ITS Partner O.B.S. S.L
Av. Corts Catalanes 9-11
08173 Sant Cugat del Vallès
Barcelona (Spain)
Tel: +34 935839543
