The most secure desktop
3 .1
TM
hard drive ever made
Ultra-secure, super speed USB 3.1,
PIN authenticated, hardware encrypted
desktop hard drive incorporating
TM
unique iStorage EDGE
Protecting You Always with Advanced Data Security
The diskAshur DT2 is an easy to use, ultra-secure, hardware encrypted desktop
hard drive with capacities of up to 8TB. Simply switch the power on and connect
the USB 3.1 cable to any computer and enter a 7-15 digit PIN, if the correct
PIN is entered, all data stored on the drive will be decrypted and accessible.
To lock the drive and encrypt all data, simply eject the diskAshur DT
host computer and the entire contents of the drive will be encrypted (full disk
encryption) using military grade AES 256-bit hardware encryption (XTS mode).
If the drive is lost or stolen and an incorrect PIN is entered 15 consecutive times,
the drive will reset, the encryption key will be deleted and all data previously
stored on the drive will be lost forever.
One of the unique and underlying security features of the GDPR compliant diskAshur DT
microprocessor (Common Criteria EAL4+ ready), which employs built-in physical protection mechanisms designed to defend against
external tamper, bypass attacks and fault injections. Unlike other solutions, the diskAshur DT
the deadlock frozen state, which renders all such attacks as useless. In plain and simple terms, without the PIN there’s no way in!
technology
2
from the
2
is the dedicated hardware based secure
2
reacts to an automated attack by entering
READY
OS and Platform Independent
With software free setup and operation, the diskAshur DT2 is platform/device agnostic and works across all operating systems including
all versions of MS Windows, macOS, Linux, Android, Chrome, Thin Clients, Zero Clients and embedded systems. In fact it will work
on any device with a USB port! The diskAshur DT
Common Criteria and NLNCSA government accreditations. You will be the envy of your peers, friends and family and be safe in the
knowledge that your data remains your data and is protected at all times.
2
is designed to be certied to FIPS 140-2 Level 2, NCSC CPA Foundation Level,
Main Features
Common Criteria EAL4+ ready on-board secure
microprocessor
Real-time military grade AES 256-bit XTS Full-Disk
Hardware Encryption
FIPS PUB 197 Validated Encryption Algorithm Read-Only (Write Protect) & Read/Write modes
PINs and encryption keys are always encrypted
while at rest
Brute Force Hack Defence Mechanism Self Destruct Feature
Tamper Proof Drive Reset Feature for easy redeployment
Immune to BadUSB Super Speed USB 3.1
Epoxy coated wear resistant keypad Unattended Auto-Lock feature
FIPS 140-2 Level 2, NCSC CPA (foundation level),
Common Criteria & NLNCSA - Certications all
pending
No software or drivers required - 100% Hardware
Encryption
PIN authenticated - Supports Admin and User
Independent PINs 7-15 digits in length
No speed degradation - as fast as any
non-encrypted USB 3.1 HDD
Desk Lock Slot
All components covered with a layer of super tough
epoxy resin
www.istorage-uk.com
info@istorage-uk.com | Tel: + 44 (0) 20 8991 6260 | Fax: + 44 (0) 20 8991 6277
iStorage Limited, iStorage House, 13 Alperton Lane, Perivale, Middlesex, UB6 8DH, UK
No admin rights needed
OS & Platform Independent - Works on any device
with a USB port
Technical Specications
Capacity 1TB, 2TB, 3TB, 4TB, 6TB, 8TB
Data Transfer Speed Read 225 MBps / Write 223 MBps
Power Supply 12V AC Adapter
Dimensions (W, D, H) 185.5 mm x 112 mm x 43.5 mm
Weight
Approvals FIPS PUB 197 Validated, FCC, CE, RoHS, WEEE, TAA Compliant
Accreditations FIPS 140-2 Level 2, NCSC CPA (foundation level), Common Criteria & NLNCSA
Interface Super Speed USB 3.1 - up to 5Gbps. Backward compatible with USB 3.0/2.0/1.1
Operating System Compatibility
Hardware Data Encryption Real-Time Military Grade AES 256-bit XTS Full-Disk Hardware Encryption
Warranty 2 Years
iStorage Part Number IS-DT2-256-XXXX-C-G (xxxx = Capacity)
Box Contents Drive, Universal Mains Adapter, USB cable & Quick Start Guide
1238 grams approx. (based on a 8TB drive, other capacities may vary)
Certifications pending
MS Windows, macOS, Linux, Android, Chrome, Thin Clients, Zero Clients and embedded
systems
EDGETM Security Features
Offering advanced portable data security via built-in FIPS PUB 197 validated AES 256-bit XTS hardware encryption engine. The data
encryption key is randomly generated by a Common Criteria EAL4+ ready Random Number Generator and protected by NCSC, FIPS and
Common Criteria validated wrapping algorithms.
Uniquely featuring a dedicated on-board Common Criteria EAL4+ ready secure microprocessor to enhance security through true random
number generation and built-in cryptography. The security component employs physical protection mechanisms to protect itself from any
external tamper, bypass laser attacks and fault injections and incorporates active-shield violation technology. More specically, the secure
microprocessor reacts to all forms of automated hacking attempts by entering the deadlock frozen state where the device can only restart
through a Power On Reset procedure (i.e. power off/power on).
All authentication parameters are encrypted and physically protected by the microprocessors’ memory encryption (scrambler) and access
control schemes.
The security lock feature protects the device against any unauthorised rmware modications from the host side (fully protected against
BadUSB)
LED LIGHTS
- Standby State/Locked
- User Mode/Unlocked
- Admin Mode
LOCK
SHIFT
UNLOCK
USB 3.1 PORT Mains Power
diskAshur DT2 rear view
ON/OFF SWITCHDESK LOCK SLOT AIR VENT
Alphanumeric
Keypad
Main Security Features Explained
Brute Force Hack Defence Mechanism: The iStorage diskAshur DT
attacks. After ve consecutive incorrect PIN entries the drive will freeze, requiring the drive to be powered off and powered back on again in order to
get a further ve PIN entry attempts. If a further ve (10 in total) consecutive incorrect PIN attempts are entered again, the diskAshur DT2 will freeze
again. To get a further and nal ve PIN attempts (15 in total), the “shift” button must be pressed whilst powering the diskAshur DT2 off and then
powering back on before entering the iStorage preset PIN. On the fteenth consecutive incorrect PIN entry, the diskAshur DT2 assumes it is being
attacked and will delete the encryption key and lock itself, rendering all data previously stored on the drive as lost forever. At this point the drive can be
reset to factory default settings and redeployed.
Self Destruct Feature: You can pre-program the diskAshur DT
2
with your own unique Self Destruct PIN which, once implemented, instantly
deletes the encryption key, all PINs, data and then creates a new encryption key.
Unattended Auto-Lock Feature: Set the unattended diskAshur DT
has not been used.
Tamper Proof Design: In addition to incorporating a secure microprocessor, encrypting the data and the encryption key, the diskAshur DT
another barrier between your data and a hacker. All of the components of the diskAshur DT2 are completely covered by a layer of super tough epoxy
resin, which is virtually impossible to remove without causing permanent damage to the components. This barrier prevents a potential hacker from
accessing the critical components and launching a variety of futile attacks.
Wear Resistant Epoxy Coated Keypad: Designed with protection in mind, the diskAshur DT
usage to avoid tipping off a potential hacker to commonly used keys.
Designed, Developed and Assembled in the UK.
2
is intelligently programmed to protect against all forms of Brute Force
2
to automatically lock after a pre-determined amount of time where the drive
2
adds
2
wear resistant epoxy coated keypad hides key
iStorage Product Range - Innovative data security solutions
Trade Agreements Act (TAA) Compliant
All trademarks and brand names are the property of their respective owners.
info@istorage-uk.com | Tel: + 44 (0) 20 8991 6260 | Fax: + 44 (0) 20 8991 6277
iStorage Limited, iStorage House, 13 Alperton Lane, Perivale, Middlesex, UB6 8DH, UK
www.istorage-uk.com
