Invacare
®
Excel
™
Power Wheelchair Front-Wheel Drive
Specifications
Dimensions Captain Seat Sling Seat
Overall
Height 35"-39" 35"-39"
Width open 24.75" with MKIV joystick 25.5" with MKIV joystick
23.75" without MKIV joystick 24.5" without MKIV joystick
Width closed 14.25" with MKIV joystick 14" with MKIV joystick
14" without MKIV joystick 14" without MKIV joystick
Depth
*
43.5" 43.5"
Seat-to-floor height 22" 18.5"
Arm Height 9" fixed 9" fixed
9.4"-13.4" adjustable 9.4"-13.4" adjustable
Rear wheel size 12.5"x2.25" 12.5"x2.25"
Casters
8"x1.75" Semi-pneumatic standard standard
8"x2" Pneumatic optional optional
Weight
with 22NF batteries and front riggings 203 lb.-207 lb. 170 lb.-180 lb.
without batteries and front riggings 122 lb.-127 lb. 90 lb.-100 lb.
Maximum speed 3.6 mph 3.6 mph
Battery (not included)
16",18", 20" models 22NF deep-cycle gel cell 22NF deep-cycle gel cell
14" models U1 deep-cycle - sling seat only U1 deep-cycle - sling seat only
dual-mode automatic battery charger, standard on all models
Incline capability 9º grade 9º grade
Shipping weight 153 lb.-157 lb. 115 lb.
Ground clearance 4" 4"
Full turning radius >25" >26"
All specifications are approximate.
Meets requirements of Medicare K0010 code.
*Base at 16" seat depth and P93 front riggings.
Invacare
®
Excel
™
Power Wheelchair Front-Wheel Drive
Invacare
Excel™Power
Wheelchair
FWD
n
A
Liquid Black - LBK
n
B
Candy Apple Red - CRD
n
C
Ocean Blue - OBL
n
D
Emerald Green - ERG
Style
Beautiful high gloss shrouds with color
molded into the shrouds complete the
look of this innovative and incomparable
power wheelchair – the Invacare Excel.
Invacare
®
Excel
™
Power Wheelchair Front-Wheel Drive
Electronics Features
• MKIV-RII-LP control system
• Invacare
®
Virtual Service
SM
software
• Separate MKIV-styled and -sized
joystick and module are
permanently attached and will
stay with chair when folded
• Safety features of soft-stop
technology bring chair to a
controlled stop in the event of
an accidental switch-off while
driving
• FWD software program
maintains the MKIV feel and
performance in this new
configuration
• Three-color LED provides gas
gauge information and self
diagnostic information:Green =
full tank, Amber = medium tank,
Red = low tank, Red flashing =
empty tank
• Self-diagnostics that monitor 31
critical sites for ease when
troubleshooting
• Four-item performance
adjustment menu:Forward
speed, Reverse speed,Turning
speed, Joystick throw
Standard Features
• Separate, removable battery boxes
• Closed-loop system to help maintain
speed and direction, even downhill
• Automatic motor locks
• Dynamic (on-demand) braking with
regeneration
• Easily accessible clutch for free-
wheeling
• Angle-, height-, and depth-adjustable
flip-up footboard standard (Captain
seat)
Optional Features
• Oxygen tank holder available with
low back (LOB) model
• Full range of swing-away front riggings
available
I
ntroducing the perfect match for your active lifestyle – the Invacare®Excel™front-wheel drive. It
combines the stability and obstacle handling characteristics of a traditional rear-wheel drive, with the
maneuverability of a mid-wheel drive – which means that the Excel FWD performs, both indoors
and outdoors. And because it’s a chair for people on the go, the Excel FWD is transportable, complete
with an exciting new flip-up battery tray that remains on the chair. Plus, a wide range of captain seats
are available, which are not only beautiful, but comfortable and functional as well. Beautifully styled
shrouds complete the package, creating a functional, attractive system.
Highlights
• Exciting shroud colors
• To increase convenience and
independence for the user, the
charger port is located in a position
easily reached by both left- and righthanded people
• Extremely maneuverable with a front
turning radius as low as 13.5" and a
full turning radius as low as 25"*
• No front stabilizers to interfere with
surfaces or mark floor coverings
• Handles obstacles better than a mid-
wheel drive chair
• Easily transportable with flip-up
battery tray remaining on chair for
utmost convenience
• 250 lb. weight capacity
* Measured with a flip-up footboard.
Up to 3" of depth adjustability.
Up to 5" of height adjustability.
Disassembled for transport.
A
B
D
C
Invacare
®
Excel
™
Power Wheelchair Front-Wheel Drive
High Back Captain Seat
• Provides greater support with a back height of 20"
• Adjustable lumbar support and swing-back arms on
HIB only
• Standard with drive lockout that prevents driving while
at more than 115º of recline
• Full assisted recline of 85º to 170º
• Optional headrest available (shown)
Low Back Captain Seat in
Gray or Tan Vinyl Upholstery
• Easy-to-clean
• Durable vinyl fabric
• Optional headrest extension available
(shown)
• Assisted recline of 80º to 115º
• Swing-back arms
Low Back Captain Seat
with Solid Seat Base
• Provides the option of using a pressure relief cushion
(i.e. the Personal Seat or the Ulti-Mate
®
cushion)
with a Captain seat
• Optional headrest extension available (shown)
T
hese high quality seats offer beautiful styling and another level of functionality. The contact surfaces
are covered with gray automobile-quality fabric, while the sides are trimmed with vinyl for added
durability. A contoured design provides excellent comfort and support. The new seats are available
in two models: the high-back seat (HIB) and the low-back seat (LOB). (Optional headrest extension shown.)
Captain Seat Highlights
• Captain seats are available in low back (LOB), standard, and
optional high back (HIB) models
• Low back captain seats can be ordered with a solid seat to
accommodate pressure-relief wheelchair cushions like the
Invacare
®
Personal Seat, Infinity™, or Ulti-Mate®cushion
• Low back captain seats are available in gray fabric or gray vinyl
Captain Seat Specifications
LOB Seat HIB Seat
Width 19" 19"
Depth 18" 17"
Back height 15" 20.75"
Extension height 6" 8"
Weight
Without extension 31 lb. 38 lb.
With extension 37 lb. 44 lb.
Base without seat*175 lb. 175 lb.
*With 22NF batteries and front riggings
